Oppo A5S Schematics

5

该文档是极速PDF编辑器生成，
如果想去掉该提示,请访问并下载：

http://www.jisupdfeditor.com/

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

Project : MT6765 LPDDR3

D D

C C

B B

REF_SCH TOP LEVEL

Connectivity ANT

TCXO

26M_WBG

26M_NFC

4

LPDDR3 EMI

eMMC MSDC0 / eMMC

micro SD
+ hot-plug

MT6631

LCD
module

Camera
Modules

CTP
controller

MEMs & ALS/PS

ST21NFCD

SIM1

SIM2

Keypad

Debug
port

MSDC 4-bit

CONN IQ

CONN ctrl

LCD IF

Camera IF

I2C

I2C

I2C

I2C

GPIOs

SIM1

SIM2

GPIOs / EINTs

PERI. Device

JTAG

UART

USB 2.0

MSDC1

I/Q

CONN IF

LCD
(MIPI DSI)

Camera
(MIPI CSI)

I2C_2 / I2C_4

I2C_0

I2C_1

I2C_6

I2C_3

SPI

SIM1

SIM2

EINT

PERIPHERAL_EN

Keypad

MSDC1/SPI Pin-MUX
JTAG

USB2.0

3

ABB

MT6765
(SBS)

Audio I/F

PWRAP I/F

BC 1.1

I2C_5

BPI, APC

RF IQ

BSI ctrl

26M_BB

26M_RF

LDOs

Bucks

AUD I/F

SPI

BC1.1

I2C

26M_RF
26M_BB
26M_WBG
26M_NFC

32K_BB

LCM's
BL

VSYS

MT6177

MT6357

DCXO / TMS

LDOs

Bucks

MT6371

LCM Gate
Driver

WLED
BST

VSYS

USB 2.0

RTC

Vibrator

Audio
Speech

VSYS

Flash

Charger/
SW

RXD

RX

TX

26M

VIB

Headset
(HPL,HPR,AU_VIN1)

Receiver

AU_VIN0

AU_LO

SPK Driver

LCM_AVDD/AVEE

FLASH

2

RxD FEM

FEM

Battery

USB Type-C

1

RXD ANT

Main 1 ANT

OPPO

OPPO

OPPO

Title

Title

A A

5

4

3

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

01_Block_Diagram

01_Block_Diagram

01_Block_Diagram

A5S_MB_V1

A5S_MB_V1

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

1

1 35

1 35

1 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

4

3

2

1

Sub SYS

I2C-0

I2C-1

(I3C)

C C

B B

I2C-2

(I3C)

I2C-3

I2C-4

(I3C)

I2C-6

Note :

I2C Spec. : Standard mode (100 kbps) and Fast mode (400 kbps), Fast mode Plus (1 Mbps) and High-speed mode (3.4 Mbps)

AP

AP

Sensor Hub

AP

AP

AP

API2C-5

AP

Function i2C Slave Address / Write / Read (7-bit mode)I2C I2C Spec.

Cap Touch controller

Magnetic Sensor

Ambient Light Sensor
Proximity Sensor

Pressure Sensor

Rear Camera

Audio Smart PA

NFC

Front Camera

Sub-PMIC

Part Number

GT1151 0x5D Write:0xBA / Read:0xBB

AK09918C 400 Kbps 0x0C Write:0x18 / Read:0x19

CM36558 400 Kbps 0x51 Write:0xA2 / Read:0xA3

BMP280 400 Kbps 0x77 Write:0xEE / Read:0xEF

IMX230 400 Kbps 0x1A Write:0x34 / Read:0x35

EEPROM 400 Kbps 0x50 Write:0xA0 / Read:0xA1
AF driver 400 Kbps 0x0C Write:0x18 / Read:0x19

RT5510 400 Kbps 0x34 Write:0x68 / Read:0x69

ST21NFCD 400 Kbps 0x08 Write:0x10 / Read:0x11

S5K2T7 400 Kbps

EEPROM 400 Kbps

AF driver=NA

MT6371 PD 3.4 Mbps

400 Kbps

3.4 MbpsMT6371 PMU

0x2D Write:0x5A / Read:0x5B

0x34
0x4E

Write:0xA4 / Read:0xA50x52

Write:0x68 / Read:0x69
Write:0x9C / Read:0x9D

OPPO

OPPO

OPPO

Title

Title

Title

A A

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet

Date: Sheet

Date: Sheet

5

4

3

02_I2C_ID_Overview

02_I2C_ID_Overview

02_I2C_ID_Overview

A5S_MB_V1

A5S_MB_V1

C

C

C

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

V1

V1

V1

of

2 35

of

2 35

of

2 35

2

1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

C C

4

3

2

1

B B

OPPO

OPPO

OPPO

Title

Title

Title

A A

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet

Date: Sheet

Date: Sheet

5

4

3

03_Change_Notice

03_Change_Notice

03_Change_Notice

A5S_MB_V1

A5S_MB_V1

C

C

C

A5S_MB_V1

V1

V1

V1

of

3 35Friday, December 28, 2018

of

3 35Friday, December 28, 2018

of

3 35Friday, December 28, 2018

2

1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

4

3

2

1

1, BQ25601

D D

2, ADD USB

3， WS3218

4

，增加

5

，更正

C C

08.24:

1. J7506

更换库为

2.

B B

HQ11910421000

电路优化

电压侦测电路

兼容设计优化

CONFIG0/1

测试点 换

U5101 WIFI/GPS

去掉4颗

D2200

合路器

TVS

物料

OPPO

OPPO

OPPO

Title

Title

A A

5

4

3

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

04_CHANGELIST

04_CHANGELIST

04_CHANGELIST

A5S_MB_V1

A5S_MB_V1

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

1

04 35

04 35

04 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

Note: 5-2

C C

B B

GND

R500

电阻_240R_0201_1/20W_F
电阻_240R_0201_1/20W_F

R501

4

U501

EMI0_CA0[14]
EMI0_CA1[14]
EMI0_CA2[14]
EMI0_CA3[14]
EMI0_CA4[14]
EMI0_CA5[14]
EMI0_CA6[14]
EMI0_CA7[14]
EMI0_CA8[14]
EMI0_CA9[14]

EMI0_DQ0[14]
EMI0_DQ1[14]
EMI0_DQ2[14]
EMI0_DQ3[14]
EMI0_DQ4[14]
EMI0_DQ5[14]
EMI0_DQ6[14]
EMI0_DQ7[14]
EMI0_DQ8[14]
EMI0_DQ9[14]
EMI0_DQ10[14]
EMI0_DQ11[14]
EMI0_DQ12[14]
EMI0_DQ13[14]
EMI0_DQ14[14]
EMI0_DQ15[14]
EMI0_DQ16[14]
EMI0_DQ17[14]
EMI0_DQ18[14]
EMI0_DQ19[14]
EMI0_DQ20[14]
EMI0_DQ21[14]
EMI0_DQ22[14]
EMI0_DQ23[14]
EMI0_DQ24[14]
EMI0_DQ25[14]
EMI0_DQ26[14]
EMI0_DQ27[14]
EMI0_DQ28[14]
EMI0_DQ29[14]
EMI0_DQ30[14]
EMI0_DQ31[14]

GND

Y2

CA0

Y3

CA1

W2

CA2

W3

CA3

V3

CA4

L3

CA5

K3

CA6

J3

CA7

J2

CA8

H2

CA9

W12

DQ0

V11

DQ1

V13

DQ2

U11

DQ3

U13

DQ4

T11

DQ5

T13

DQ6

R12

DQ7

N12

DQ8

M13

DQ9

M11

DQ10

L13

DQ11

L11

DQ12

K11

DQ13

K13

DQ14

J12

DQ15

AB12

DQ16

AB11

DQ17

AB10

DQ18

AA13

DQ19

AA12

DQ20

AA10

DQ21

Y13

DQ22

Y11

DQ23

H11

DQ24

H13

DQ25

G10

DQ26

G12

DQ27

G13

DQ28

F10

DQ29

F11

DQ30

F12

DQ31

G2

ZQ0

ZQ0

G3

ZQ1

ZQ1

F13

VSSQ1

G11

VSSQ2

H10

VSSQ3

J8

VSSQ4

J13

VSSQ5

K8

VSSQ6

K9

VSSQ7

L10

VSSQ8

L12

VSSQ9

M8

VSSQ10

N13

VSSQ11

P9

VSSQ12

R13

VSSQ13

T8

VSSQ14

U10

VSSQ15

U12

VSSQ16

V8

VSSQ17

V9

VSSQ18

W8

VSSQ19

W13

VSSQ20

Y10

VSSQ21

AA11

VSSQ22

F2

VSS1

G4

VSS2

G8

VSS3

H3

VSS4

H5

VSS5

L4

VSS6

M3

VSS7

M4

VSS8

N4

VSS9

N8

VSS10

P4

VSS11

P12

VSS12

R3

VSS13

R4

VSS14

R8

VSS15

T4

VSS16

Y4

VSS17

Y5

VSS18

AA2

LP-DDR3

VSS19

AA4

VSS20

AA8

VSS21

H4

VSSCA1

J4

VSSCA2

K4

VSSCA3

P2

VSSCA4

U4

VSSCA5

V4

VSSCA6

W4

VSSCA7

A3

VSSM1

A8

VSSM2

A12

VSSM3

B2

VSSM4

B7

VSSM5

B11

VSSM6

C3

VSSM7

C5

VSSM8

C8

VSSM9

C10

VSSM10

C12

VSSM11

C13

VSSM12

D7

VSSM13

A2

VSF1

A13

VSF2

B1

VSF3

B14

VSF4

D2

VSF5(RX)

D3

VSF6(TX)

D4

VSF7

D5

VSF8

D6

VSF9

<DEVICE>

MCP_MCP_32 GB-EMMC_4 GB-LPDDR3-eMMC_MCP_32 GB-EMMC_4 GB-LPDDR3-LPDDR3

Power

eMMC

VDD1-1
VDD1-2
VDD1-3
VDD1-4
VDD1-5
VDD1-6
VDD1-7
VDD1-8
VDD1-9

VDD2-1
VDD2-2
VDD2-3
VDD2-4
VDD2-5
VDD2-6
VDD2-7
VDD2-8

VDD2-9
VDD2-10
VDD2-11
VDD2-12
VDD2-13
VDD2-14
VDD2-15
VDD2-16
VDD2-17
VDD2-18

VDDQ1

VDDQ2

VDDQ3

VDDQ4

VDDQ5

VDDQ6

VDDQ7

VDDQ8

VDDQ9
VDDQ10
VDDQ11
VDDQ12
VDDQ13
VDDQ14
VDDQ15
VDDQ16
VDDQ17
VDDQ18
VDDQ19
VDDQ20
VDDQ21
VDDQ22

VDDCA-1
VDDCA-2
VDDCA-3
VDDCA-4

VCCQ-1

VCCQ-2

VCCQ-3

VCCQ-4

VCCQ-5

DQS0#

DQS1#

DQS2#

DQS3#

VREFCA
VREFDQ

F3

F4
F9
G5
AA3
AA5
AB3
AB4
AB9

F5
F8
J5
K5
L2
L5
M5
N5
P5
P8
P11
R5
T5
U5
V5
W5
AB5
AB8

G9
H8
H12
J11
K10
K12
L8
L9
M10
M12
N11
R11
T10
T12
U8
U9
V10
V12
W11
Y8
Y12
AA9

K2
N2
U2
V2

B3

VCC-1

B12

VCC-2

B13

VCC-3

C4

VCC-4

D8

VCC-5

A4
B6
B9
C7
C11

eMMC_VDDI

A11

VDDI

A7

DS

B8

CLKM

C2

RST

A6

CMD

B4
A5
A10
C9
B5
C6
B10
A9

U3
T3

T2
R2

P3
N3

T9
R9
M9
N9
Y9
W9
H9
J9

R10
N10
W10
J10

M2
P13

AB14
AB13
AB2
AB1
AA14
AA1
A14
A1

P10

R505

1 2

R0201_NC

MSDC0_DAT7 [14]
MSDC0_DAT6 [14]
MSDC0_DAT5 [14]
MSDC0_DAT4 [14]
MSDC0_DAT3 [14]
MSDC0_DAT2 [14]
MSDC0_DAT1 [14]
MSDC0_DAT0 [14]

1

TP505 TP0.3

EMI0_CS0 [14]
EMI0_CS1 [14]

EMI0_CKE0 [14]
EMI0_CKE1 [14]

EMI0_CK_T [14]
EMI0_CK_C [14]

EMI0_DQS0_T [14]
EMI0_DQS0_C [14]
EMI0_DQS1_T [14]
EMI0_DQS1_C [14]
EMI0_DQS2_T [14]
EMI0_DQS2_C [14]
EMI0_DQS3_T [14]
EMI0_DQS3_C [14]

EMI0_DMI0 [14]
EMI0_DMI1 [14]
EMI0_DMI2 [14]
EMI0_DMI3 [14]

GND

DAT7
DAT6
DAT5
DAT4
DAT3
DAT2
DAT1
DAT0

CS0#
CS1#

CKE0
CKE1

CLK

CLK#

DQS0

DQS1

DQS2

DQS3

DM0
DM1
DM2
DM3

DNU1
DNU2
DNU3
DNU4
DNU5
DNU6
DNU7
DNU8

ODT

1

TP501

TP0.3

电容_100nF_0201_X5R_6.3V_K

1

TP502

TP503

TP0.3

TP0.3

电容_100nF_0201_X5R_6.3 V_M(±20%)

3

GND

电容_100nF_0201_X5R_6.3V_K

C502

C503

电容_100nF_0201_X5R_6.3V_K

GND

MSDC0_DSL [14]
MSDC0_CLK [14]
MSDC0_RSTB [14]
MSDC0_CMD [14]

1

1

TP504

Close to Memory

TP0.3

C516

电容_100nF_0201_X5R_6.3 V_M(±20%)

C517

GND

C500

C504

电容_100nF_0201_X5R_6.3V_K

VDRAM_PMU [5,10,21]

EVREF [5,14]
EVREF [5,14]

2

C501

电容_2.2uf_0201_6.3 V_M(±20%)

C505

C506

电容_4.7uF_0402_X5R_6.3V_M

电容_100nF_0201_X5R_6.3V_K

EMI_VDD1 [11,21]

Note: 5-4

C507

C518

电容_10uF_0402_X5R_6.3V_M

电容_10uF_0402_X5R_6.3V_M

C517+C518+C519=22uf--20181007-caifeng

Note: 5-1

VDRAM_PMU [5,10,21]

1

Note: 5-3

C508

GND GND

电容_100nF_0201_X5R_6.3V_K

Note: 5-3

C515

电容_100nF_0201_X5R_6.3V_K

电容_1uF_0201_X5R_6.3V_M

C514

GND

电容_100nF_0201_X5R_6.3V_K

C509

GND

C511

电容_100nF_0201_X5R_6.3V_K

电容_100nF_0201_X5R_6.3V_K

C510

C512

电容_4.7uF_0402_X5R_6.3V_M

GNDGND GND

C513

电容_2.2uF_0402_X5R_6.3V_M

VEMC_PMU [21]

VIO18_PMU [06,09,11,12,13,15,18,19,21,23,26,31,32,33]

Schematic design notice of "44_Memory_eMMC_LPDDR3"

Please refer to power supply related page select VDRAM1 output

Note 44-1:

voltage properly for LPDDR3

Note 44-2: DRAM ZQx resistor = 240ohm (1%) that must be connected to GND

Note 44-3: Please refer to eMCP vendor's datasheet or MTK common design notice to

get the recommendation bypass cap. value for VCC/VCCQ/VDDI power
domains of eMMC.

Note 44-4:

VDD2 VDDQ VDDCA decoupling cap: closed to DRAM ball.
For other cap for PMIC [>10uF, at PMIC page]:
please also refer to MMD and layout guide for placement.

OPPO

OPPO

OPPO

Title

Title

A A

5

4

3

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

5_Memory_eMMC_LPDDR3

5_Memory_eMMC_LPDDR3

5_Memory_eMMC_LPDDR3

A5S_MB_V1

A5S_MB_V1

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

1

5 35

5 35

5 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

4

3

2

1

SIM1/SIM2 Card

D D

SD CARD

12

D3504

LESD11LH5.0CT5G

MSDC1_DAT2[13]

MSDC1_DAT3[13]

MSDC1_CMD[13]

C C

R600 电阻_22R_0201_1/20 W_F(±1%)

R602 电阻_22R_0201_1/20 W_F(±1%)

R603 电阻_22R_0201_1/20 W_F(±1%)

VMCH_PMU[21]

width:1mm

C615

电容_4.7uF_0402_X5R_6.3V_M

LESD11LH5.0CT5G

12

D3505

J602

1

DAT2_1

9

DAT2_2

2

CD/DAT3_1

10

CD/DAT3_2

3

CMD_1

11

CMD_2

4

VDD_1

12

VDD_2

2

3.2.04.0220

+

D603

-

PESDTC5VB(BASIN)

1

DAT0_1
DAT0_2

DAT1_1
DAT1_2

12

D3507

LESD11LH5.0CT5G

5

CLK_1

13

CLK_2

6

VSS_1

14

VSS_2

7
15

8
16

LESD11LH5.0CT5G

12

D3506

R601

电阻_22R_0201_1/20 W_F(±1%)

R604

电阻_22R_0201_1/20 W_F(±1%)

R605

电阻_22R_0201_1/20 W_F(±1%)

LESD11LH5.0CT5G

D3508

12

12

D3509

LESD11LH5.0CT5G

MSDC1_CLK [13]

MSDC1_DAT0 [13]

MSDC1_DAT1 [13]

VSIM2_PMU[11,21]

SIM2_SRST[12]

SIM2_SCLK[12]

挡块

SH601

1

TP0.5

R617 电阻_2.2Ω_0201_1/20W_J

R619 电阻_100R_0201_1/20W_J

R620 电阻_47R_0201_1/20W_J(±5%)

SIM1/SIM2

J603

1

18

VCC_1

I/O_1

2

17

VCC_2

I/O_2

3

16

VCC_3

I/O_3

4

15

RST_1

VPP_1

5

14

RST_2

VPP_2

6

13

RST_3

VPP_3

7

12

CLK_1

GND_1

8

11

CLK_2

GND_2

10

CLK_39GND_3

C602

电容_1uF_0201_X5R_6.3V_M

3.2.03.0582

R616

电阻_100R_0201_1/20W_J

SIM2_SIO [12]

SIM1/SIM2

J601

1

GND_1

2

GND_2

3

GND_3

4

GND_4

5

R611,R612 added--20181007-caifeng

EINT_SIM1[13]

EINT_SIM2[13]

EINT_SD[13]

B B

VIO18_PMU[5,09,11,12,13,15,18,19,21,23,26,31,32,33]

R3539

电阻_1K_0201_1/20W_J

R611

电阻_1K_0201_1/20W_J

R607

电阻_1K_0201_1/20W_J

R608

电阻_100KΩ_0201_1/20W_F

2

D604

-

1

PESDTC5VB(BASIN)

GND_5

6

GND_6

7

GND_7

8

GND_8

9

GND_9

10

GND_10

11

GND_11

12

GND_12

13

GND_13

14

DETECT SWITH VCC

3.2.16.0069

+

VSIM1_PMU[11,21]

SIM1_SRST[12]

SIM1_SCLK[12]

电阻_2.2Ω_0201_1/20W_J

R621

R624

电阻_100R_0201_1/20W_J

R625

电阻_47R_0201_1/20W_J(±5%)

C603

电容_1uF_0201_X5R_6.3V_M

J604

1

VCC_1

2

VCC_2

3

VCC_3

4

RST_1

5

RST_2

6

RST_3

7

CLK_1

8

CLK_2
CLK_39GND_3

3.2.03.0582

18

I/O_1

17

I/O_2

16

I/O_3

15

VPP_1

14

VPP_2

13

VPP_3

12

GND_1

11

GND_2

10

R622 电阻_100R_0201_1/20W_J

SIM1_SIO [12]

Schematic design notice of "46_MEMORY_SD Card" page.

OPPO

OPPO

OPPO

Note 46-1: For better ESD performance, please select suitable components for system protection.

Title

Title

A A

5

4

3

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

06_Memory_SD_SIM_Card

06_Memory_SD_SIM_Card

06_Memory_SD_SIM_Card

A5S_MB_V1

A5S_MB_V1

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

1

06 35

06 35

06 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

4

3

2

1

Receiver

close to connector

close to IC

AU_HSN[23]

AU_HSP[23]

C C

C701

电容_100pF_0201_C0G_50V_J

C704

C705

电容_33pF_0201_C0G_50V_J

电容_33pF_0201_C0G_50V_J

LB703

1 2

磁珠_1000R@100MHz_0402

LB704

1 2

磁珠_1000R@100MHz_0402

12

12

D702

D701

LESD11LH5.0CT5G

LESD11LH5.0CT5G

单点下地

J702

112

1890-rec-stell-1109

J701

112

1890-rec-stell-1109

2

3

3

2

3

3

B B

AU_VIN0_P[23]

AU_VIN0_N[23]

A A

5

电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

R701,R703->1uF for ACC mode

4

Main MIC

C702

电容_100pF_0201_C0G_50V_J

C700

电容_33pF_0201_C0G_50V_J

C703

电容_33pF_0201_C0G_50V_J

MIC0_P [17]

MIC0_N [17]

OPPO

OPPO

OPPO

Title

Title

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

3

Date: Sheet of

2

07_AUDIO_REC_MAIN_MIC

07_AUDIO_REC_MAIN_MIC

07_AUDIO_REC_MAIN_MIC

A5S_MB_V1

A5S_MB_V1

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

1

07 35

07 35

07 35

V1

V1

V1

C711

C712

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

C C

4

C805

电容_100nF_0201_16 V_M(±20%)

LO_P[23]

C810

电容_100nF_0201_16 V_M(±20%)

LO_M[23]

AUD_PA_CTRL[13]

R804

电阻_3.3K_0201_1/20W_J

R807

电阻_3.3K_0201_1/20W_J

！！走线

≥0.75mm

主电源拉线到音频

VSYS[09,16,17,19,20,21,22,26,27,28]

TP9010

TP0.3

1

C811

电容_220pF_0201_X7R_50V_K

，要求单独从

PAU712

C815

电容_100nF_0201_16 V_M(±20%)

C819

电容_2.2uF_0402_X5R_6.3V_M

C820

B3

电容_2.2uf_0201_6.3 V_M(±20%)

VDD1A3VDD2

A4

SHDN

A1

INP

A2

INN

R801,R802->inductor

3

C814

C813

C712\C714走线≥0.4mm

，靠近

87318

放置

C1

D1

B1

U801

C1PD2C2P

C1N

C2N

D3

PVDD

电容_2.2uF_0402_X5R_10 V_M(±20%)

电容_2.2uF_0402_X5R_10 V_M(±20%)

B4

VOP

D4

VON

GND1C2GND2

磁珠_220R@100MHz_0603

C4

B801 磁珠_220R@100MHz_0603

1 2
1 2

B802

C717靠近87318

放置，需要回

到芯片

C2\C4的GND

，并且要求在

C717

电容端直接下主地

C817 电容_4. 7uF_0402_X5R_10V_M

SPK_OUT_P & SPK_OUT_N

上下左右包地走差分，走线
短而粗，宽度

C802电容_100pF_0201_C0G_25V_J

C801电容_100pF_0201_C0G_25V_J

GND

SPK_OUT_P [17]
SPK_OUT_N [17]

≥0.5mm

2

1

B B

OPPO

OPPO

OPPO

Title

Title

A A

5

4

3

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

08_AUDIO_SPEAKER_AMP

08_AUDIO_SPEAKER_AMP

08_AUDIO_SPEAKER_AMP

A5S_MB_V1

A5S_MB_V1

D

D

D

A5S_MB_V1

08 35Friday, December 28, 2018

08 35Friday, December 28, 2018

08 35Friday, December 28, 2018

1

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

4

3

2

1

LCD MIPI Common Mode Filter

R0201_NC

R906

12

R913

R904

R903

R908

R907

R910

R909

R912

T905

EXC14CE900U

R901

T902

EXC14CE900U

T901

EXC14CE900U

T903

EXC14CE900U

T904

EXC14CE900U

1234

1234

R0201_NC

12

R0201_NC

12

1234

R0201_NC

12

R0201_NC

12

1234

R0201_NC

12

R0201_NC

12

1234

R0201_NC

12

R0201_NC

12

R0201_NC

12

D D

C C

MIPI_DSI0_CLK_P_CON [09]

MIPI_DSI0_CLK_N_CON [09]

MIPI_DSI0_LANE0_P_CON [09]

MIPI_DSI0_LANE0_N_CON [09]

MIPI_DSI0_LANE1_P_CON [09]

MIPI_DSI0_LANE1_N_CON [09]

MIPI_DSI0_LANE2_P_CON [09]

MIPI_DSI0_LANE2_N_CON [09]

MIPI_DSI0_LANE3_P_CON [09]

MIPI_DSI0_LANE3_N_CON [09]

DSI0_CKP[13]

DSI0_CKN[13]

DSI0_D0P[13]

DSI0_D0N[13]

DSI0_D1P[13]

DSI0_D1N[13]

DSI0_D2P[13]

DSI0_D2N[13]

DSI0_D3P[13]

DSI0_D3N[13]

Main LCM+CTP INCELL

J901

40

40

GND

MIPI_DSI0_LANE3_N_CON[09]

MIPI_DSI0_LANE3_P_CON[09]

MIPI_DSI0_LANE0_N_CON[09]

MIPI_DSI0_LANE0_P_CON[09]

MIPI_DSI0_CLK_N_CON[09]

MIPI_DSI0_CLK_P_CON[09]

MIPI_DSI0_LANE1_N_CON[09]

MIPI_DSI0_LANE1_P_CON[09]

MIPI_DSI0_LANE2_N_CON[09]

MIPI_DSI0_LANE2_P_CON[09]

LCD_ID2[13]

R934

电阻_1K_0201_1/20W_J

LCD_ID1[13]

R932

LCD_ID0[13]

电阻_1K_0201_1/20W_J

R931

电阻_1K_0201_1/20W_J

39

39

TDN3

38

38

TDP3

37

37

GND

36

36

TDN0

35

35

TDP0

34

34

GND

33

33

TCN

32

32

TCP

31

31

GND

30

30

TDN1

29

29

TDP1

28

28

GND

27

27

TDN2

26

26

TDP2

25

25

GND

24

24

ID2

23

23

ID1

22

22

ID0
GND

21

21

WP7B-S040VA1

42

414142

VSN_6V

VSP_6V

LCD_RST

LED_K1

LED_K2

LED_A

TP_VDD

CTP_RST

TP_SCL

TP_SDA

TP_EINT

434344

44

CTP

1

VDDI

1

2

NC

2

3

3

4

NC

4

5

5

6

6

GND

7

7

CABC

FTE

GND

NC

NC

8

9

10

11

12

13

14

15

16

17

18

19

20

8

9

10

11

12

13

14

15

16

17

18

19

20

R924 电阻_0R_0201_1/20W_J

电容_100pF_0201_C0G_25V_J

C902

C903

电容_100pF_0201_C0G_25V_J

C919

C920

电容_33pF_0201_C0G_50V_J

电容_33pF_0201_C0G_50V_J

LCD_BACKLIGHT_CABC

DSI_TE [13]

LCD_BL_LED_K [09]

C910

电容_33pF_0201_C0G_50V_J

1

1

R922

TP901

电阻_1K_0201_1/20W_J

TP0.3

TP902

TP0.3

[09]

C918

电容_100pF_0201_C0G_25V_J

LCD_BL_LED_A [09]

SCL0 [13]

SDA0 [13]

LCM_RST [13]

C6716

电容_100pF_0201_C0G_25V_J

电容_1uF_0201_X5R_6.3V_M

GPIO_CTP_RSTB [13]

1 2

VIO18_PMU [5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

C904

C917

电容_100pF_0201_C0G_25V_J

R919

VIO18_PMU [5,06,09,11,12,13,15,18,19,21,23,26,31,32]

[13]

R0201_NC

EINT_CTP

LCM_AVEE [27]

C914

LCM_AVDD [27]

电容_100pF_0201_C0G_25V_J

VIO28_PMU [19,21]

C905

电容_1uF_0201_X5R_6.3V_M

First using 0R ,Second using EMI Filter.

B B

LCD-BACKLIGHT

L901

VSYS[08,16,17,19,20,21,22,26,27,28]

C924

LCD_BACKLIGHT_CABC

电容_10uF_0402_X5R_10 V_M(±20%)

电容_10uF_0402_X5R_10 V_M(±20%)

A A

5

贴片功率电感器_10uH_2520_0.9 A(lrat)_0.8 A(lrms)_M(±20%)_500 毫欧

C923

LCM_BL_PWM

[13]

1.2mm H

U908

4

SW

6

VIN

3

GND-1

7

GND-2

1

FB

5

CTRL

2

NC

4

D904

PMEG4010ESB

电阻0R(0402-0.0625W-J)

R916

电阻_5.1R_0201_1/20W_F

12

电容_1uF_0603_X5R_50V_K

R933

电阻0R(0402-0.0625W-J)

C926

C925

R944

电容_68pF_0201_C0G_50 V_G(±2%)

LCD_BL_LED_K [09]

LCD_BL_LED_A [09]

OPPO

OPPO

OPPO

Title

Title

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

3

2

09_LCD_CTP_BL

09_LCD_CTP_BL

09_LCD_CTP_BL

A5S_MB_V1

A5S_MB_V1

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

1

09 35

09 35

09 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

4

3

2

1

U1200E

MT6761-SBS

D D

12

电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

1uF

1uF

电容_0.47uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

1uF

电容_0.47uF_0201_X5R_6.3V_M

电容_0.47uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

1uF

电容_100nF_0201_X5R_6.3V_K

电容_100nF_0201_X5R_6.3V_K

电容_100nF_0201_X5R_6.3V_K

电容_2.2uF_0402_X5R_6.3V_M

电容_10uF_0402_X5R_6.3V_M

DVDD_MODEM[20]

SG1001

LS_PAD_DIFFERENT

22UF

22UF

VSRAM_OTHERS_PMU[10,21]

VSRAM_OTHERS_PMU[10,21]

DVDD_SRAM_DVFS[21]

VDRAM_PMU[5,21]

12

R9

DVDD_VDD_MODEM0

T10

DVDD_VDD_MODEM1

U9

DVDD_VDD_MODEM2

U13

DVDD_VDD_MODEM3

V10

DVDD_VDD_MODEM4

V13

DVDD_VDD_MODEM5

W9

DVDD_VDD_MODEM6

W10

DVDD_VDD_MODEM7

W8

DVDD_VDD_MODEM8

Y8

DVDD_VDD_MODEM9

MODEM

SRAM

R19

DVDD_MFG_SRAM

L13

DVDD_TOP_SRAM1

V12

DVDD_TOP_SRAM2

V15

DVDD_MCUSYS_SRAM

VDDQ

H11

AVDDQ_EMI01

H12

AVDDQ_EMI02

H18

AVDDQ_EMI11

H19

AVDDQ_EMI12

H10

AVDD2_EMI1

H13

AVDD2_EMI2

H17

AVDD2_EMI3

H20

AVDD2_EMI4

MT6761V/WA

DVDD_MODEM_6357_FB[20]

DVDD_MODEM_6357_GND[20]

SG1000

LS_PAD_DIFFERENT

C1014

电容_22uF_0603_X5R_6.3V_M

C1015

电容_22uF_0603_X5R_6.3V_M

C1017

C1019

C1021

C1023 电容_1uF_0201_X5R_6.3V_M

C1024

C C

B B

GND

GND

GND

GND

GND

C1026 电容_1uF_0201_X5R_6.3V_M

C1032

C1033

C1038

C1039

C1040 电容_1uF_0201_X5R_6.3V_M

C1041

C1042

C1043

C1045 电容_100nF_0201_X5R_6.3V_K

C1046

C1049

C1052 电容_4.7uF_0402_X5R_6.3V_M

C1055

GPU

CPU

CORE

DVDD_MFGSYS1
DVDD_MFGSYS2
DVDD_MFGSYS3
DVDD_MFGSYS4
DVDD_MFGSYS5
DVDD_MFGSYS6
DVDD_MFGSYS7
DVDD_MFGSYS8
DVDD_MFGSYS9

DVDD_DVFS0
DVDD_DVFS1
DVDD_DVFS2
DVDD_DVFS3
DVDD_DVFS4
DVDD_DVFS5
DVDD_DVFS6
DVDD_DVFS7
DVDD_DVFS8

DVDD_DVFS9
DVDD_DVFS10
DVDD_DVFS11
DVDD_DVFS12
DVDD_DVFS13
DVDD_DVFS14
DVDD_DVFS15

DVDD_TOP1
DVDD_TOP2
DVDD_TOP3
DVDD_TOP4
DVDD_TOP5
DVDD_TOP6
DVDD_TOP7
DVDD_TOP8

DVDD_TOP9
DVDD_TOP10
DVDD_TOP11
DVDD_TOP12
DVDD_TOP13

DVDD_TOP14
DVDD_TOP15
DVDD_TOP16
DVDD_TOP17
DVDD_TOP18
DVDD_TOP19

K20
L19
L20
M20
N19
N20
P20
T20
T21

U16
U18
U20
U22
Y16
Y18
Y20
Y21
Y22
AA16
AA18
AA20
AA21
AA22
AB16
AB18

J21
K10
K13
K14
K17
L17
M10
M18
N17
P18
P23
R17
T18

R13
P14
P13
P10
N13
M14

DVDD_CORE [10,11,20]

C1001

电容_22uF_0603_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

C1006

C1008

电容_1uF_0201_X5R_6.3V_M

C1010 电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

C1012

C1013 电容_1uF_0201_X5R_6.3V_M

DVDD_DVFS [20]

SG1002

12

LS_PAD_DIFFERENT

C1018

电容_22uF_0603_X5R_6.3V_M

C1020

电容_22uF_0603_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

C1025

C1027

电容_1uF_0201_X5R_6.3V_M

C1028 电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

C1029

电容_1uF_0201_X5R_6.3V_M

C1030

C1031 电容_1uF_0201_X5R_6.3V_M

C1034

电容_1uF_0201_X5R_6.3V_M

C1035

电容_1uF_0201_X5R_6.3V_M

C1036

电容_1uF_0201_X5R_6.3V_M

C1037

电容_1uF_0201_X5R_6.3V_M

DVDD_CORE [10,11,20]

SG1005

12

LS_PAD_DIFFERENT

C1044

电容_22uF_0603_X5R_6.3V_M

C1047 电容_1uF_0201_X5R_6.3V_M

C1048

电容_1uF_0201_X5R_6.3V_M

C1050

电容_1uF_0201_X5R_6.3V_M

C1051 电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

C1053

C1054

电容_1uF_0201_X5R_6.3V_M

C1056

电容_1uF_0201_X5R_6.3V_M

C1057

电容_1uF_0201_X5R_6.3V_M

22UF

DVDD_DVFS_6357_FB [20]
DVDD_DVFS_6357_GND [20]

SG1003

12

LS_PAD_DIFFERENT

22UF

22UF

DVDD_CORE_6357_FB [20]
DVDD_CORE_6357_GND [20]

SG1006

12

LS_PAD_DIFFERENT

C1000

C1003

C1004

C1005

C1007

电容_22uF_0603_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

GND

GND

GND

OPPO

OPPO

OPPO

Title

Title

A A

5

4

3

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

10_MT6762_BB_POWER_PDN

10_MT6762_BB_POWER_PDN

10_MT6762_BB_POWER_PDN

A5S_MB_V1

A5S_MB_V1

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

1

10 35

10 35

10 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

4

3

2

1

D D

C C

B B

A A

U1200F

MT6761-SBS

A11

DVSS1

A13

DVSS2

A15

DVSS3

B3

DVSS4

B21

DVSS5

C2

DVSS6

C6

DVSS7

C12

DVSS8

C16

DVSS9

C20

DVSS10

C23

DVSS11

D3

DVSS12

D9

DVSS13

D13

DVSS14

D23

DVSS15

D27

DVSS16

E4

DVSS17

E24

DVSS18

E25

DVSS19

F2

DVSS20

F4

DVSS21

F5

DVSS22

F6

DVSS23

F7

DVSS24

F8

DVSS25

F10

DVSS26

F11

DVSS27

F12

DVSS28

F14

DVSS29

F17

DVSS30

F19

DVSS31

F20

DVSS32

F21

DVSS33

F22

DVSS34

F23

DVSS35

G4

DVSS36

G6

DVSS37

G11

DVSS38

G12

DVSS39

G13

DVSS40

G14

DVSS41

G15

DVSS42

G21

DVSS43

G22

DVSS44

G26

DVSS45

H14

DVSS46

H15

DVSS47

H22

DVSS48

H25

DVSS49

J22

DVSS50

J23

DVSS51

J24

DVSS52

K9

DVSS53

K11

DVSS54

K12

DVSS55

K15

DVSS56

K16

DVSS57

K18

DVSS58

L8

DVSS59

L11

DVSS60

L15

DVSS61

L16

DVSS62

L21

DVSS63

L22

DVSS64

L26

DVSS65

M6

DVSS66

M7

DVSS67

M12

DVSS68

M16

DVSS69

M22

DVSS70

M24

DVSS71

M28

DVSS72

N6

DVSS73

N7

DVSS74

N11

DVSS75

N15

DVSS76

N21

DVSS77

N22

DVSS78

P7

DVSS79

P12

DVSS80

P16

DVSS81

P21

DVSS82

P22

DVSS83

R11

DVSS84

R15

DVSS85

R21

DVSS86

R22

DVSS87

T8

DVSS88

T12

DVSS89

T22

DVSS90

U11

DVSS91

V8

DVSS92

V16

DVSS93

V17

DVSS94

V19

DVSS95

V21

DVSS96

W17

DVSS97

W19

DVSS98

W21

DVSS99

AA9

DVSS100

AA11

DVSS101

AA13

DVSS102

AB10

DVSS103

AB12

DVSS104

AD7

DVSS105

AD11

DVSS106

AD14

DVSS107

AE8

DVSS108

AE11

DVSS109

AE14

DVSS110

AF8

DVSS111

AF11

DVSS112

AF14

DVSS113

AF17

DVSS114

AF28

DVSS115

AG26

DVSS116

GND

MT6761V/WA

AVDD & MD_AGND

PLL

PERI_D

PERI_A

AVDD12_MD

AVDD18_MD

AVDD18_AP

AVDD18_CPU

AVDD18_DDR

AVDD12_PLLGP

AVDD18_PLLGP

DVDD18_IOLT

DVDD18_IOLM

DVDD18_IOBL

DVDD18_IORB1
DVDD18_IORB2

DVDD18_IORT

DVDD_VQPS

DVDD18_MSDC0

DVDD28_MSDC1

DVDD28_SIM1

DVDD28_SIM2

DVDD18_MSDC1

DVDD18_SIM

AVDD12_CSI

AVDD12_DSI

AVDD04_DSI

AVDD18_USB

AVDD12_USB

AVDD33_USB

AVDD18_WBG

AVDD12_WBG

AG21

AG19

AG18
AC18

H21

T14

T16

G28
W28

AG27

U1
AG6

J1

AD18

A27

AD28

AE28

AC28

AA28

AB28

U2

R28

T28

D28

E28

B28

H2

C3

电容_1uF_0201_X5R_6.3V_M

C1106

电容_100nF_0201_X5R_6.3V_K

C1108

100nF

电容_100nF_0201_X5R_6.3V_K

C1113

GND

电容_100nF_0201_X5R_6.3V_K

Note: 11-3

C1119

GND

电容_1uF_0201_X5R_6.3V_M

GND

电容_1uF_0201_X5R_6.3V_M

C1122

GND

电容_1uF_0201_X5R_6.3V_M

C1126

GND

电容_100nF_0201_X5R_6.3V_K

GND

电容_100nF_0201_X5R_6.3V_K

C1101

电容_100nF_0201_X5R_6.3V_K

Note: 11-1

C1121

C1100

100nF

C1109

电容_1uF_0201_X5R_6.3V_M

GND

电容_100nF_0201_X5R_6.3V_K

C1120

GND

电容_1uF_0201_X5R_6.3V_M

C1123

GND

电容_100nF_0201_X5R_6.3V_K

VA12_PMU [11,28]

VA12_PMU [11,28]

C1102

GND GNDGND

电容_1uF_0201_X5R_6.3V_M

VA12_PMU [11,28]

C1107

GNDGND

电容_100nF_0201_X5R_6.3V_K

C1110

电容_100nF_0201_X5R_6.3V_K

电容_100nF_0201_X5R_6.3V_K

C1114

C1117

电容_100nF_0201_X5R_6.3V_K

AVDD18_SOC [11,21]

AVDD18_SOC [11,21]
AVDD18_SOC [11,21]

EMI_VDD1 [5,21]

C1105

GNDGND

AVDD18_SOC [11,21]

VIO18_PMU [5,06,09,12,13,15,18,19,21,23,26,31,32,33]

VEFUSE_PMU [21]

VMC_PMU [21]

VSIM1_PMU [06,21]

VSIM2_PMU [06,21]

GND

电容_100nF_0201_X5R_6.3V_K

C1111

GNDGND

Note: 11-2

电容_100nF_0201_X5R_6.3V_K

C1118

C1103

C1104

电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

电容_100nF_0201_X5R_6.3V_K

C1112

GNDGND GND GNDGND

电容_100nF_0201_X5R_6.3V_K

C1115

C1116

GND

电容_100nF_0201_X5R_6.3V_K

VA12_PMU [11,28]

VA12_PMU [11,28]

DVDD_CORE [10,20]

Schematic design notice of "11_BB_POWER_IO" page.

Note 11-1: C4101 closed DVDD18_MSDC0 150mil

AVDD18_SOC [11,21]

VA12_PMU [11,28]

VUSB_PMU [21]

C1124

GND

电容_1uF_0201_X5R_6.3V_M

C1125

GND

AVDD18_SOC [11,21]

Note 11-2: C4302 closed DVDD28_MSDC1 150mil

Note 11-3: C4301 closed DVDD18_MSDC1 150mil

OPPO

OPPO

OPPO

Title

Title

Title

11_MT6762_BB_POWER_IO

11_MT6762_BB_POWER_IO

11_MT6762_BB_POWER_IO

Size Project Rev

Size Project Rev

Size Project Rev

D

D

D

Date: Sheet of

Date: Sheet of

5

4

3

Date: Sheet of

2

A5S_MB_V1

A5S_MB_V1

A5S_MB_V1

V1

V1

V1

11 34Friday, December 28, 2018

11 34Friday, December 28, 2018

11 34Friday, December 28, 2018

1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

U1200A

MT6761-SBS

PMU_IF

SYSRSTB[22,30]

D D

RTC32K_CK[22]

WATCHDOG[22]

SRCLKENA0[22]

SRCLKENA1[22,31]

PWRAP_SPI0_CSN[12,22]

PWRAP_SPI0_CK[22]
PWRAP_SPI0_MO[22]
PWRAP_SPI0_MI[12,22]

AUD_CLK_MOSI[23]
AUD_CLK_MISO[23]

AUD_DAT_MISO0[23]
AUD_DAT_MISO1[23]

AUD_DAT_MOSI0[12,23]
AUD_DAT_MOSI1[23]

AUD_SYNC_MISO[23]
AUD_SYNC_MOSI[23]

E27

K24

L25

M25

H26

K27
L27
M27
K28

J25
G27

J27
J28

K26
K25

H27
J26

SYSRSTB

WATCHDOG

SRCLKENA0

SRCLKENA1

RTC32K_CK

PWRAP_SPI0_CSN
PWRAP_SPI0_CK
PWRAP_SPI0_MO
PWRAP_SPI0_MI

AUD_CLK_MOSI
AUD_CLK_MISO

AUD_DAT_MISO0
AUD_DAT_MISO1

AUD_DAT_MOSI0
AUD_DAT_MOSI1

AUD_SYNC_MISO
AUD_SYNC_MOSI

Test Pin

F27

TESTMODE

W13

TP_PLLGP

W12

GND

C C

B B

TN_PLLGP

AC5

CDM3P5A

AB6

CDM5P5A

A1

NC1

A28

NC2

AG1

NC3

AG28

NC4

MT6761V/WA

4

U1200B

MT6761-SBS

SIM

SIM1_SCLK[06]
SIM1_SIO[06]
SIM1_SRST[06]

SIM2_SCLK[06]
SIM2_SIO[06]
SIM2_SRST[06]

RFIC0_BSI_EN[31]
RFIC0_BSI_CK[31]

RFIC0_BSI_D0[31]
RFIC0_BSI_D1[31]

MIPI0_SCLK[32]
MIPI0_SDATA[32]

MIPI1_SCLK[33]
MIPI1_SDATA[33]

AA25

AA26

AC25

AB25

AC26

AE21
AF22
AE20
AF21

AG22

Y25

AG7
AF7

AF5
AF6

AE6
AD6

AE5
AD5

SIM1_SCLK
SIM1_SIO
SIM1_SRST

SIM2_SCLK
SIM2_SIO
SIM2_SRST

RFIC_Ctrl

RFIC0_BSI_EN
RFIC0_BSI_CK
RFIC0_BSI_D0
RFIC0_BSI_D1
RFIC0_BSI_D2

RF MIPI

MISC_BSI_CK_0
MISC_BSI_DO_0

MISC_BSI_CK_1
MISC_BSI_DO_1

MISC_BSI_CK_2
MISC_BSI_DO_2

MISC_BSI_CK_3
MISC_BSI_DO_3

BPI

Modem_ID1[12]
Modem_ID2[12]

BPI_BUS14[34]
Modem_ID4[12]

BPI_BUS12[34]
BPI_BUS11[17]

BPI_BUS9[32]
BPI_BUS8[17]
BPI_BUS7[34]
BPI_BUS6[34]
BPI_BUS5[33]
BPI_BUS4[33]
BPI_BUS3[33]
BPI_BUS2[34]
BPI_BUS1[34]
BPI_BUS0[34]

AE2
AD3

AF24

AE3

AE25

AE24

AD4

AF25
AF26

AD25

AC6
AG4
AG3
AG2
AF4
AF3
AF2
AE4

BPI_PA_VM1
BPI_PA_VM0

BPI_BUS15_ANT2
BPI_BUS14_ANT1
BPI_BUS13_ANT0

BPI_BUS12_OLAT1
BPI_BUS11_OLAT0

BPI_BUS10
BPI_BUS9
BPI_BUS8
BPI_BUS7
BPI_BUS6
BPI_BUS5
BPI_BUS4
BPI_BUS3
BPI_BUS2
BPI_BUS1
BPI_BUS0

MT6761V/WA

3

ABB_IF

MAIN_X26M_IN

AUX IN

REF POWER

TX_BB_IP0

TX_BB_IN0
TX_BB_QP0
TX_BB_QN0

PRX_BB_I0P

PRX_BB_I0N

PRX_BB_I1

PRX_BB_Q0P
PRX_BB_Q0N

PRX_BB_Q1

DRX_BB_I0P
DRX_BB_I0N

DRX_BB_I1

DRX_BB_Q0P
DRX_BB_Q0N

DRX_BB_Q1

DET_IP0
DET_IN0

DET_QP0

DET_QN0

RFIC_ET0_P
RFIC_ET0_N

AUXIN4

AUXIN3

AUXIN2

AUXIN1

AUXIN0

2

Modem_ID1[12]
Modem_ID2[12]
Modem_ID3[12]

AB13

AE9
AD9
AE10
AD10

AF13

6177_i0

AG13
AF15

6177_i1

AF12

6177_q0

AG12
AG15

6177_q1

6177_i0

AD13
AE13
AG16

6177_i1

AD12

6177_q0

AE12

6177_q1

AF16

AG9
AF9
AF10
AG10

AD8
AC9

AC10

APC

AE17

AE18

AE19

AF19

AF20

AF18

REFP

REFP

6177m_iP
6177m_iN

6177m_qP
6177m_qN

6177m_iP
6177m_iN

6177m_qP
6177m_qN

GND

APC1 [33]

C1202

PMIC_CLK_BB [22]

LTE_TX_BB_IP0 [31]
LTE_TX_BB_IN0 [31]
LTE_TX_BB_QP0 [31]
LTE_TX_BB_QN0 [31]

LTE_PRX_BB_IP0 [31]
LTE_PRX_BB_IN0 [31]

LTE_PRX_BB_QP0 [31]
LTE_PRX_BB_QN0 [31]

LTE_DRX_BB0_IP [31]
LTE_DRX_BB0_IN [31]

LTE_DRX_BB0_QP [31]
LTE_DRX_BB0_QN [31]

LTE_DET_BB_IP0 [31]
LTE_DET_BB_IN0 [31]
LTE_DET_BB_QP0 [31]
LTE_DET_BB_QN0 [31]

电容_1uF_0201_X5R_6.3V_M

Note: 12-5

VBUS_ADC [26]

AUX_IN3_NTC [12]

AUX_IN2_BATID [26]

AUX_IN1_NTC [15]

AUX_IN0_NTC [15]

C1200

C1201

C1277

GNDGND

GND

Note: 12-2

电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

C1203

GND GND

电容_1uF_0201_X5R_6.3V_M

C1205

电容_100nF_0201_X5R_6.3V_K

Modem_ID4[12]

Thermistor to sense Charger IC (U2601)
temperature

Note: 12-1

电容_100nF_0201_X5R_6.3V_K

1

VIO18_PMU[5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

R1220

R1222

R1224

电阻_10K_0201_1/20W_F

电阻_10K_0201_1/20W_F

R1221

电阻_10K_0201_1/20W_F

电阻_10K_0201_1/20W_F

GND GND GND

[5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

VIO18_PMU

R1226

电阻_10K_0201_1/20W_F

电阻_10K_0201_1/20W_F

R1223

R1225

R1227

电阻_10K_0201_1/20W_F

电阻_10K_0201_1/20W_F

GND

R1206

电阻_100K_0201_1/20W_J

R1208

热敏电阻NTC_100k_0.1 mA_F(±1%)

GND

AUX_IN3_NTC [12]

VIO18_PMU [5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

Note: 12-3

DDR3 selection

PWRAP_SPI0_MI[12,22]

1

R1205

电阻_12KΩ_0201_1/20W_F

GND

Note: 12-4

V1

V1

V1

12 35Friday, December 28, 2018

12 35Friday, December 28, 2018

12 35Friday, December 28, 2018

R1230

R0201_NC

Schematic design notice of "12_BB_1" page.

AUD_DAT_MOSI0[12,23]

1 2

PWRAP_SPI0_CSN[12,22]

R1203

电阻_12KΩ_0201_1/20W_F

GND

R1201

电阻_12KΩ_0201_1/20W_F

R1232

R0201_NC

1 2

GND

Note 12-1: The de-coupling cap. for REFP (AF18 ball) have to be placed as close to BB as possible.

Note 12-2: To shunt a 1uF capacitor in the AUXIN ADC input to prevent noise coupling. It should
be placed as close to BB as possible. Connect the unused AUX ADC input to GND.

Note 12-3: "PWRAP_SPI0_CSN" and "AUD_DAT_MOSI0" are bootstrap pin to select which interface will be the JTAG pin out.

A A

PWRAP_SPI0_CSN AUD_DAT_MOSI0

HI LO
HI HI
LO LO

Note 12-4: PWRAP_SPI0_MO and PWRAP_SPI0_MI are DDR type feature in bootstrap

LO HI

PWRAP_SPI0_MI

default=PU

LO
HI

(by ext. PD)

(by ext. PD)

(by ext. PD)

default=PDdefault=PU

(by ext. PU)

(by ext. PU)

Booting interface

DDR

LPDDR3
LPDDR4X

5

MSDC0 pin mux

follow LP3 Ref SCH.

follow LP4X Ref SCH.

AP_JTAG

N/A
SPI0+EINT8
SPI0+EINT8
MSDC1

JTAG Function

MD_JTAG

N/A
SPI1+SPI3
N/A
N/A

Note 12-5: Please set unused IQ pins in NC

4

3

OPPO

OPPO

OPPO

Title

Title

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

12_MT6762_BB_1

12_MT6762_BB_1

12_MT6762_BB_1

D

D

D

A5S_MB_V1

A5S_MB_V1

A5S_MB_V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

4

3

2

1

D D

U1200C

MT6761-SBS

CSI-0

GND

CSI2A_L0P[16]
CSI2A_L0N[16]

CSI2A_CP[16]
CSI2A_CN[16]

RDP2_B[16]
RDN2_B[16]

RDP0_B[16]
RDN0_B[16]

RCP_B[16]

C C

RCN_B[16]

RDP1_B[16]
RDN1_B[16]

RDP3_B[16]
RDN3_B[16]

RDP1[16]
RDN1[16]

RDP3[16]
RDN3[16]

N3

CSI0A_L0P

N4

CSI0A_L0N

N1

CSI0A_L1P

N2

CSI0A_L1N

P1

CSI0A_L2P

P2

CSI0A_L2N

P3

GND

CSI0B_L0P

P4

CSI0B_L0N

R3

GND

CSI0B_L1P

R4

CSI0B_L1N

N5

GND

CSI0B_L2P

P5

CSI0B_L2N

CSI-1

L3

CSI1A_L0P

L4

CSI1A_L0N

L1

CSI1A_L1P

L2

CSI1A_L1N

M1

CSI1A_L2P

M2

CSI1A_L2N

L5

CSI1B_L0P

M5

CSI1B_L0N

M3

CSI1B_L1P

M4

CSI1B_L1N

CSI-2

R1

RDP2[16]
RDN2[16]

RDP0[16]
RDN0[16]

RCP[16]
RCN[16]

CSI2A_L0P

R2

CSI2A_L0N

T1

CSI2A_L1P

T2

CSI2A_L1N

T3

CSI2A_L2P

T4

CSI2A_L2N

U3

CSI2B_L0P

U4

CSI2B_L0N

R5

CSI2B_L1P

T5

CSI2B_L1N

CSI Ctrl

CAM_RST0[16]

CAM_PDN0[16]

CAM_RST1[16]

CAM_RST2[16]

B B

CAM_CLK0[16]

CAM_CLK1[16]

CAM_CLK2[16]

CAM_PDN2[16]

R1302电阻_0R_0201_1/20W_J

R1304电阻_0R_0201_1/20W_J

R1305电阻_0R_0201_1/20W_J

GNDGND

V2

CAM_RST0

W6

CAM_PDN0

V1

CAM_RST1

Y2

CAM_PDN1

K3

CAM_RST2

K2

CAM_PDN2

AF23

CAM_RST3

L24

CAM_PDN3

47nH

W5

CAM_CLK0

47nH

W2

CAM_CLK1

47nH

J2

CAM_CLK2

AG24

CAM_CLK3

MT6761V/WA

12

12

12

C1303C0201_NC

C1302

C1301C0201_NC

C0201_NC

GND

DSI-0

GPIO

GPO

DSI0_CKP
DSI0_CKN

DSI0_D0P
DSI0_D0N

DSI0_D1P
DSI0_D1N

DSI0_D2P
DSI0_D2N

DSI0_D3P
DSI0_D3N

LCM_RST

DISP_PWM

SPI0_MI

SPI0_CSB

SPI0_MO

SPI0_CLK

SPI1_MI

SPI1_CSB

SPI1_MO

SPI1_CLK

SPI2_MI

SPI2_CSB

SPI2_MO

SPI2_CLK

SPI3_MI

SPI3_CSB

SPI3_MO

SPI3_CLK

SPI4_MI

SPI4_CSB

SPI4_MO

SPI4_CLK

PERIPHERAL_EN0

PERIPHERAL_EN1

PERIPHERAL_EN2

PERIPHERAL_EN3

PERIPHERAL_EN4

PERIPHERAL_EN5

DSI_TE

P25
P26

N25
N26

N28
N27

R25
R26

P27
R27

AD26

AE27

AD27

AD1

AC1

AC2

AD2

W24

U23

Y24

V24

U24

T26

T25

T24

U25

U26

V26

V25

U27

V28

T27

V27

AD22

AD24

AD23

AC24

AE23

AE22

GPIO21

GPIO22

GPIO23

Note: 13-1

DSI0_CKP [09]
DSI0_CKN [09]

DSI0_D0P [09]
DSI0_D0N [09]

DSI0_D1P [09]
DSI0_D1N [09]

DSI0_D2P [09]
DSI0_D2N [09]

DSI0_D3P [09]
DSI0_D3N [09]

LCM_RST [09]

DSI_TE [09]

Modem_ID5

[12]

FRONT_CAMERA_AVDD_EN [16]

RERA_CAMERA_AVDD_EN [16]

GPIO157_FLASH_EN [27]

LCD_ID1 [09]

LCD_ID0 [09]

LCD_ID2 [09]

SPI4_MI [19]

SPI4_CSB [19]

SPI4_MO [19]

SPI4_CLK [19]

AUD_PA_CTRL [08]

GPIO_CHG_EN_0 [26]

USB_PHY_ID[17]

SCL1[19]

SDA1[19]

VIO18_PMU[5,06,09,11,12,15,18,19,21,23,26,31,32,33]

R1306

USB_DP[17]
USB_DM[17]

电阻_2.2K_0201_1/20 W_J(±5%)

R1306->NC

CHD_DP[22]
CHD_DM[22]

GPIO_GPS_LNA_EN[35]

KPCOL0[18]
KPCOL1[18]

SCL0[09]

SDA0[09]

1

1

TP1302

TP1303

SCL2[16]
SDA2[16]

TP0.3

TP0.3

SCL3[27]
SDA3[27]

SCL4[16]
SDA4[16]

SCL5[26]
SDA5[26]

URXD0[17,30]

UTXD0[17,30]

MSDC1_CLK[06]

MSDC1_CMD[06]

MSDC1_DAT3[06]
MSDC1_DAT2[06]
MSDC1_DAT1[06]
MSDC1_DAT0[06]

C27
B27

AB27
AB26

D26
E26

AA1
AB1

AB3

AB2

AB5
AC4

AE1
AF1

V4
V3

AC21
AC22

U6
V6

AB23
AC23

J3
J4

AA3

AA2

W26

W27

W25

AA27

Y26
Y27

U1200D

USB

USB_DP
USB_DM

IDDIG
DRVBUS

BC

CHD_DP
CHD_DM

KEYPAD

KPROW0
KPROW1

KPCOL0
KPCOL1

I2C

SCL0
SDA0

SCL1
SDA1

SCL2
SDA2

SCL3
SDA3

SCL4
SDA4

SCL5
SDA5

SCL6
SDA6

UART

URXD0

UTXD0

SD (MSDC1)

MSDC1_CLK

MSDC1_CMD

MSDC1_DAT3
MSDC1_DAT2
MSDC1_DAT1
MSDC1_DAT0

MT6761V/WA

MT6761-SBS

PD
PD

Power Domain
DVDD18_IORB

PU
PD

Touch

Sensor Hub

Rear Cam

LCM BIAS

Front Cam

Sub PMIC&Charger

SMART PA

CONN_Dig.

CONN_TOP_CLK

CONN_TOP_DATA

CONN_BT_DATA

CONN_WF_CTRL0
CONN_WF_CTRL1
CONN_WF_CTRL2

CONN_WB_PTA

CONN_IQ

GPIO

CONN_BT_CLK

CONN_HRST_B

XIN_WBG

ANT_SEL0
ANT_SEL1
ANT_SEL2

GPIO_EXT0

GPIO_EXT1

GPIO_EXT2

GPIO_EXT3

GPIO_EXT4

GPIO_EXT5

GPIO_EXT6

GPIO_EXT7

GPIO_EXT8

GPIO_EXT9

GPIO_EXT10

GPIO_EXT11

GPIO_EXT12

GPIO_EXT13

GPIO_EXT14

GPIO_EXT15

SRCLKENAI

INT_SIM1

INT_SIM2

GPS_Q

WF_IN
WF_QP
WF_QN

BT_QP
BT_QN

EINT10

EINT11

EINT12

J6

CONN_TOP_CLK [35]

K7

CONN_TOP_DATA [35]

J5

BT_CLK [35]

K8

BT_DATA [35]

H5

WF_CTRL0 [35]

H4

WF_CTRL1 [35]

H3

WF_CTRL2 [35]

G2

CONN_WB_PTA [35]

G3

CONN_HRST_B [35]

G7

CONN_XO_IN_BB [35]

K5
K6
K4

F1
G1

A3
A2
B1
B2

D2
D1
E3
F3

G23

F25

F24

G24

F26

G25

H23

H24

AA24

Y23

AA23

AD21

AD20

AD19

AC20

AC19

Y1

AC3

AE26

AF27

AB4

AA7

AA5

AA4

Y6

Y7

Y4

Y3

AA6

W4

W3

W7

M26

GPS_I [35]
GPS_Q [35]

WF_IP [35]
WF_IN [35]
WF_QP [35]
WF_QN [35]

BT_IP [35]
BT_IN [35]
BT_QP [35]
BT_QN [35]

GPIO165_LCD_BIAS_ENN [27]

GPIO166_LCD_BIAS_ENP [27]

R1332 电阻_1K_0201_1/20W_J

R1333 电阻_1K_0201_1/20W_J

Modem_ID3

[12]

GPIO_CTP_RSTB [09]

EINT_SIM1 [06]

EINT_SIM2 [06]

EINT_CTP [09]

EINT_SD [06]

1

TP1301 TP0.3

EINT_ALS [19]

GPIO6_TORCH_EN [27]

EINT_PS [19]

EINT_CHG_0 [26]

EINT_ACC [19]

CONFIG033

CONFIG133

增加

ramdump

测试点

GPS_I

WF_IP

BT_IP
BT_IN

PWM0

EINT0

EINT1

EINT2

EINT3

EINT4

EINT5

EINT6

EINT7

EINT8

EINT9

OPPO

OPPO

A A

Note 13-1: The enable pin of acoustic or optoelectronic devices (e.g. SPK AMP/Backlight/Charger
OCP/OVP) suggest to use Peripheral_EN[0:5]
If use other GPIOs as enable pin, suggest to reserve 0201 NC to GND

5

4

3

Schematic design notice of "13_BB_2" page.

OPPO

Title

Title

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

13_MT6762_BB_2

13_MT6762_BB_2

13_MT6762_BB_2

A5S_MB_V1

A5S_MB_V1

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

1

13 35

13 35

13 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

C C

Note: 14-1

R1400

电阻_36R_0201_1/20W_J

GND

B B

EMI0_DQ0[5]

EMI0_DQ1[5]

EMI0_DQ2[5]

EMI0_DQ3[5]

EMI0_DQ4[5]

EMI0_DQ5[5]

EMI0_DQ6[5]

EMI0_DQ7[5]

EMI0_DQ8[5]

EMI0_DQ9[5]

EMI0_DQ10[5]

EMI0_DQ11[5]

EMI0_DQ12[5]

EMI0_DQ13[5]

EMI0_DQ14[5]

EMI0_DQ15[5]

EMI0_DQ16[5]

EMI0_DQ17[5]

EMI0_DQ18[5]

EMI0_DQ19[5]

EMI0_DQ20[5]

EMI0_DQ21[5]

EMI0_DQ22[5]

EMI0_DQ23[5]

EMI0_DQ24[5]

EMI0_DQ25[5]

EMI0_DQ26[5]

EMI0_DQ27[5]

EMI0_DQ28[5]

EMI0_DQ29[5]

EMI0_DQ30[5]

EMI0_DQ31[5]

4

EVREF[5]

Note: 14-2

MSDC0_DAT7[5]
MSDC0_DAT6[5]
MSDC0_DAT5[5]
MSDC0_DAT4[5]
MSDC0_DAT3[5]
MSDC0_DAT2[5]
MSDC0_DAT1[5]
MSDC0_DAT0[5]

EMI_EXTR

U1200G

MT6761-SBS

C13

EMI0_DQ0

C15

EMI0_DQ1

C14

EMI0_DQ2

E15

EMI0_DQ3

B15

EMI0_DQ4

D15

EMI0_DQ5

E16

EMI0_DQ6

B17

EMI0_DQ7

A17

EMI0_DQ8

E18

EMI0_DQ9

F18

EMI0_DQ10

C18

EMI0_DQ11

D19

EMI0_DQ12

E19

EMI0_DQ13

C19

EMI0_DQ14

A19

EMI0_DQ15

D10

EMI0_DQ16

C11

EMI0_DQ17

C10

EMI0_DQ18

D12

EMI0_DQ19

B13

EMI0_DQ20

B11

EMI0_DQ21

B12

EMI0_DQ22

E11

EMI0_DQ23

D20

EMI0_DQ24

E20

EMI0_DQ25

E21

EMI0_DQ26

D21

EMI0_DQ27

B20

EMI0_DQ28

C22

EMI0_DQ29

C21

EMI0_DQ30

A21

EMI0_DQ31

F16

VREF_EMI

G16

N1

E23

N2

B4

EMI_EXTR

A26

MSDC0_DAT7

B24

MSDC0_DAT6

B23

MSDC0_DAT5

A23

MSDC0_DAT4

C24

MSDC0_DAT3

A25

MSDC0_DAT2

D24

MSDC0_DAT1

C26

MSDC0_DAT0

MT6761V/WA

EMI_DDR

eMMC (MSDC0)

EMI0_CS0_n

EMI0_CS1_n

EMI0_CKE0

EMI0_CKE1

EMI0_DM0

EMI0_DM1

EMI0_DM2

EMI0_DM3

EMI0_CK_T

EMI0_CK_C

EMI0_DQS0_C

EMI0_DQS0_T

EMI0_DQS1_C

EMI0_DQS1_T

EMI0_DQS2_C

EMI0_DQS2_T

EMI0_DQS3_C

EMI0_DQS3_T

EMI0_CA0

EMI0_CA1

EMI0_CA2

EMI0_CA3

EMI0_CA4

EMI0_CA5

EMI0_CA6

EMI0_CA7

EMI0_CA8

EMI0_CA9

MSDC0_RSTB

MSDC0_CMD

MSDC0_CLK

MSDC0_DSL

3

A9

E8

D8

E7

B16

C17

E10

B19

F9

E9

E14

D14

D17

E17

E13

F13

E22

D22

B8

B7

C7

D6

B5

D5

C5

E6

E5

A5

A7

N3

B9

N4

C4

N5

C9

N6

D4

N7

D7

N8

D11

N9

D18

N10

C25

B25

D25

B26

EMI0_CS0 [5]

EMI0_CS1 [5]

EMI0_CKE0 [5]

EMI0_CKE1 [5]

EMI0_DMI0 [5]

EMI0_DMI1 [5]

EMI0_DMI2 [5]

EMI0_DMI3 [5]

EMI0_CK_T [5]

EMI0_CK_C [5]

EMI0_DQS0_C [5]

EMI0_DQS0_T [5]

EMI0_DQS1_C [5]

EMI0_DQS1_T [5]

EMI0_DQS2_C [5]

EMI0_DQS2_T [5]

EMI0_DQS3_C [5]

EMI0_DQS3_T [5]

EMI0_CA0 [5]

EMI0_CA1 [5]

EMI0_CA2 [5]

EMI0_CA3 [5]

EMI0_CA4 [5]

EMI0_CA5 [5]

EMI0_CA6 [5]

EMI0_CA7 [5]

EMI0_CA8 [5]

EMI0_CA9 [5]

MSDC0_RSTB [5]

MSDC0_CMD [5]

MSDC0_CLK [5]

MSDC0_DSL [5]

2

1

Schematic design notice of "14_BB_3" page.

Note 14-1: R4001 please select 34.8 ohm (1%) resistor

Note 14-2: Please check eMCP LP3 and eMCP LP4X pin mux

OPPO

OPPO

OPPO

Title

Title

A A

5

4

3

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

14_MT6762_BB_3

14_MT6762_BB_3

14_MT6762_BB_3

A5S_MB_V1

A5S_MB_V1

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

1

14 35

14 35

14 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

C C

4

PA_THERMAL

change to NCP03WF104F05RL Murata

VIO18_PMU [5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

R1500

390K

电阻_390K_0201_1/20 W_F(±1%)

R1502

热敏电阻NTC_100k_0.1 mA_F(±1%)

Thermistor to sense RF PA
temperature

1. NTC1502 must close to LTE Band 7 PA or the hottest PA <2mm.

2. The distance is the shortest distance from package edge to edge.

AUX_IN1_NTC [12]

3

2

1

Thermistor / To sense board level temperature

VIO18_PMU [5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

USE 390K

R1501

电阻_390K_0201_1/20 W_F(±1%)

B B

A A

5

4

AUX_IN0_NTC[12]

Distance to AP is 5~7mm and away form other heat resource 10mm~12mm

R1503

热敏电阻NTC_100k_0.1 mA_F(±1%)

OPPO

OPPO

OPPO

Title

Title

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

3

2

15_BB_AUXADC_Thermal

15_BB_AUXADC_Thermal

15_BB_AUXADC_Thermal

A5S_MB_V1

A5S_MB_V1

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

1

15 35

15 35

15 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

Dual cam

Rear Camera

D D

RDN3_B[13]

RDP3_B[13]

RDN1_B[13]

RDP1_B[13]

RCN_B[13]

RCP_B[13]

RDN0_B[13]

RDP0_B[13]

RDN2_B[13]

RDP2_B[13]

C C

NOTE：C2142-》DNI

注意：

AGND AFGND

J1601

31

1

GND

MCLK

2

D3N

PWDN

3

D3P

RESET

4

GND

5

D1N

6

D1P

7

GND

SYNC

8

CKN

GND

9

CKP

AF_GND

10

GND

AF_VDD

11

D0N

12

D0P

13

GND

14

D2N

15 16

D2P

32

33 34

30

29

28

27

SDA

26

SCL

25

NC

24

23

22

21

20

AVDD

19

AGND

18

DVDD

17

DOVDD

GND

OK-23GF030-04(001A)

都要单独下主地

C1624

电容_15pF_0201_C0G_25V_J

VCAMIO_PMU [16,21]

C1617

12

C0201_NC

C0201_NC

1 2

C1607

12

C1609

C1627C0201_NC

1 2

C0201_NC

C1626

电容_1uF_0201_X5R_6.3V_M

C1619

电容_4.7uF_0402_X5R_6.3V_M

1 2

4

C1608

C0201_NC

CAM_CLK0 [13]

CAM_PDN0 [13]

电阻_0R_0201_1/20W_J

R1608

1

TP1601 TP0.3

VLDO28_PMU [09,21]

VCAMD_PMU[16,21]

C1610电容_100pF_0201_C0G_25V_J

ASYNC [16]

CAM_RST0 [13]

TP1605

TP0.3

C1611

电容_100pF_0201_C0G_25V_J

NOTE：C2141-》DNI

3

2

1

Rear Camera 2

VIO18_PMU

[5,06,09,11,12,15,18,19,21,23,26,31,32,33]

R1602

R1601

R0201_NC

R0201_NC

1 2

1 2

SDA2 [13]

SCL2 [13]

1

1

1606

TP0.3

VCAMA_REAR_EXT [16]

C1602

SG1600

2 1

电容_10uF_0402_X5R_6.3V_M

VCAMA_FRONT_EXT[16]

VCAMIO_PMU[16,21] CAM_CLK2 [13]

SG1601

2 1

C1623

CAM_RST2[13]

C1614

电容_2.2uF_0402_X5R_6.3V_M

电容_100pF_0201_C0G_25V_J

ASYNC[16]

SCL4[13,16]

SDA4[13,16]

R1609

CAM_PDN2

C1644

1 2

C0201_NC

电容_1uF_0201_X5R_6.3V_M

[13]

C1636

C1637

电容_100pF_0201_C0G_25V_J

电阻_0R_0201_1/20W_J

J1602

S3

S4

OK-23GF024-04(001A)

27

28

13

GND

GND

121213

14

DOVDD

MCLK

11

14

15

GND

DVDD

10

15

16

GND

CKP

9

16

17

CKN

AGND

8

17

18

GND

AVDD

7

18

19

D0P

GND

6

19

20

D0N

SYNC

5

20

21

GND

SCL

4

21

22

D1P

SDA

3

22

23

D1N

RESET

2

23

24

PWDN

GND

1

24

26S225

S1

电容_15pF_0201_C0G_25V_J

CSI2A_CP [13]

CSI2A_CN [13]

CSI2A_L0P [13]

CSI2A_L0N [13]

C1625

11

10

9

8

7

6

5

4

3

2

1

Front Camera - 8M

B B

A A

5

VIO18_PMU

[5,06,09,11,12,15,18,19,21,23,26,31,32,33]

SCL4[13,16]

SDA4[13,16] VCAMD_PMU [16,21]

R0201_NC

1

1

TP1603

TP1604

TP0.3

TP0.3

C0201_NC

C0201_NC

R1604

R1603

R0201_NC

1 2

1 2

J1603

1 2

1 2

C1605

C1606

SCL

SDA

11

DGND

10

MDP0

9

RDP0[13]

MDN0

RDN0[13]

8

7

MCP

RCP[13]

6

MCN

RCN[13]

MDP1

5

RDP1[13]

MDN1

4

RDN1[13]

DGND

3

2

VXS

AGND

1

S4

28

121213

11

10

9

8

7

6

5

4

3

2

1

26S225

C1638

S3

27

14

15

16

17

18

OK-23GF024-04(001A)

19

20

21

22

23

24

S1

4

C1615

电容_4.7uF_0402_X5R_6.3V_M

DOVDD

13

DVDD

14

电容_100pF_0201_C0G_25V_J

电阻_0R_0201_1/20W_J

R1610

15

RESET

DGND

16

MDP2

17

RDP2 [13]

MDN2

18

RDN2 [13]

MDP3

19

RDP3 [13]

MDN3

20

RDN3 [13]

DGND

21

MCLK

22

DGND

23

AVDD

24

21

SG1602

C1604C0201_NC

1 2

VCAMIO_PMU [16,21]

CAM_CLK1 [13]

C1618

电容_15pF_0201_C0G_25V_J

U1601 WL2820X28-4/TR

1

VSYS[08,09,16,17,19,20,21,22,26,27,28] VCAMA_REAR_EXT [16]

CAM_RST1 [13]

VCAMA_FRONT_EXT [16]

C1603电容_100pF_0201_C0G_25V_J

C1613

电容_10uF_0402_X5R_6.3V_M

3

VSYS[08,09,16,17,19,20,21,22,26,27,28]

RERA_CAMERA_AVDD_EN[13]

C1620

电容_1uF_0201_X5R_6.3V_M

FRONT_CAMERA_AVDD_EN[13]

C1634

电容_1uF_0201_X5R_6.3V_M

OPPO

OPPO

OPPO

Title

Title

Title

Size Project Rev

Size Project Rev

Size Project Rev

D

D

D

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

4

VOUT

VIN

3

5

EN

GND-2

GND-1

2

R1622

R0201_NC

1 2

U1602 WL2820X28-4/TR

4

VOUT

VIN

3

EN

GND-2

GND-1

2

R1623

R0201_NC

1 2

16_CAMERA_INTERFACE

16_CAMERA_INTERFACE

16_CAMERA_INTERFACE

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

C1621

电容_1uF_0201_X5R_6.3V_M

1

2.8V

5

A5S_MB_V1

A5S_MB_V1

A5S_MB_V1

C1622

电容_1uF_0201_X5R_6.3V_M

VCAMA_FRONT_EXT [16]

1

16 35

16 35

16 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

4

3

2

1

Schematic design notice of "71_PERI_USB 2.0" page.

Note 71-1:

For better ESD or surge performance we need choose suitable device for system
protection. Please refer to [Surge device selection guide V2.0] provide by MTK.

D D

C C

BTB Connector

Grond protected separately each lane
90Ohm Differential impedance

USB_DP_CON

[17]

[17]

USB_DM_CON

R1741 电阻_5.1R_0201_1/20W_F

R1742 电阻_5.1R_0201_1/20W_F

AVSS28_AUD

[23]

EAR_DET

[17]

EAR_L[17]

EAR_GND

[17]

EAR_R[17]

[12]

1

Grond protected

1

USB_PHY_ID

[13]

D1707

12

ESD9X5VL-2/TR

D709

12

ESD9X5VL-2/TR

Modem_ID5

TP1

TP1701

TP1

TP1702

1

-

2

R1722

D1705

+

电阻_820R_0201_1/20_F(±1%)

TP1700

TP0.3

[12]

[21,32]

[21]

PESDTC5VB(BASIN)

[12]

1

BPI_BUS11

VFE28_PMU

BPI_BUS8

VIBOUT_P

VBUS_USB_IN[17,22,26,30]

TP2615

TP1

1

J1701

10

11

12

13

14

TP1705

1

TP1

32

GND GND

AVSS28_AUD

1

1

EAR_DET

2

2

EAR_L

3

3

EAR_GND

4

4

EAR_JACK_GNDEAR_R

5

5

Modem_ID5

6

6

GND

7

7

USB_DP

8

8

USB_DM

9

9

GND

10

USB_ID

11

BPI_BUS11

12

BPI_BUS8

13

2P8

14

VIB

151516

C1703

电容_1.2nF_0201_X7R_25V_K

FM_LANT_P

FM_LANT_N

EAR_MIC

MICBIAS

VCHG

333334

TP2608

TP1

1

313132

30

30

29

29

GND

28

28

27

27

26

26

GND

25

25

24

24

MICP

23

23

MICN

22

22

GND

21

21

SPKP

20

20

SPKP

19

19

SPKN

18

18

SPKN

17

17

GND

16

34

FM_LANT_P

FM_LANT_N

EAR_JACK_GND

MIC0_P

MIC0_N

SPK_OUT_N

SPK_OUT_P

[17]

12

[35]

C1718

C0201_NC

EAR_MIC

[17]

[07]

[07]

[08]

[08]

[17]

AU_MICBIAS0 [23]

EAR_R[17]

EAR_L[17]

EAR_GND[17]

1 2

LB1701 磁珠_1000R@100MHz_0402

NC

EAR_DET[17]

每个耳机信号上共5颗

AU_REFN [23]

LQP03TN82NJ02D，0603

VAUD28_PMU
[23]

R1707

电阻_51K_0201_1/20W_J

R1733

电阻_30.9K_0201_1/20W_F(±1%)

HP_EINT [23]

电阻_20R_0201_1/20W_J

R1703

20R

20R

电阻_20R_0201_1/20W_J

R1704

C1710

C1709

GND

电容_33pF_0201_C0G_50V_J

电容_33pF_0201_C0G_50V_J

AU_HPR [23]

AU_HPL [23]

R1710

R1709

电阻_470R_0201_1/20_F(±1%)

电阻_470R_0201_1/20_F(±1%)

GND

GND

R1731

12

R0201_NC

R1730

12

R0201_NC

B B

A A

USB_DP_CON[17]

USB_DM_CON[17]

5

U1704

A3

COM1

A2

COM2

GND

KTU1002A

B3

B1

VCC

NC1

NC2

NO1

NO2

EN

CB1

CB2

FLAG

C1716

C4

C3

C2

C1

B4

A1

B2

A4

VSYS [08,09,16,19,20,21,22,26,27,28]

电容_100nF_0201_X5R_6.3V_K

TP1703

TP1

VBUS_USB_IN
[17,22,26,30]

电阻_10K_0201_1/20W_J

1

1

TP1704

TP1

R1724

1

2

URXD0 [13,30]

UTXD0 [13,30]

U1701

G

S

USB_DP [13]

USB_DM [13]

3

D

4

VBUS_IN

IN

OUT

电阻_10K_0201_1/20W_J

R1725

SELECT(default PD)

CB

0

COM=NC

1

COM=NO

VSYS [08,09,16,19,20,21,22,26,27,28]

Earphone MICPHONE
ACC MODE

C1732

AU_VIN1_N[23]

电容_1uF_0201_X5R_6.3V_M

C1712

C1733

AU_VIN1_P[23]

ACCDET[23]

Platform

Mode

EINT

Key-Detection

R7112

R7113

R7114

R7115

R7116

R7118

R7119

R7107 47K ohm 47K ohm

3

MT6357

ACC mode

DCC mode

HP_EINT

HP_EINT

ACCDET AU_VIN1_P

1uF

0 ohm

1uF

0 ohm

1K

NC

1.5K

NC

NC

2.49K

4.7uF

0 ohm

0 ohm

NC

电容_1uF_0201_X5R_6.3V_M

R1719 电阻_0R_0201_1/20W_J

OPPO

OPPO

OPPO

Title

Title

Title

Size Project Rev

Size Project Rev

Size Project Rev

D

D

D

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

Adjust to use ACC MODE

C1713

GND

C1715

电容_100pF_0201_C0G_50V_J

电容_33pF_0201_C0G_50V_J

电容_33pF_0201_C0G_50V_J

17_B2B_OVP_AUDIO_JACK

17_B2B_OVP_AUDIO_JACK

17_B2B_OVP_AUDIO_JACK

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

AU_MICBIAS1[23]

Close to BB

R1714

电阻_1K_0201_1/20W_J

C1734

电容_4.7uF_0402_X5R_6.3V_M

R1715

R1716

电阻_1.5K_0201_1/20W_J

R0201_NC

1 2

A5S_MB_V1

A5S_MB_V1

A5S_MB_V1

L1702

USE 68NH

C1714

GND

电容_2.2nF_0201_X7R_16V_K(±10%)

EAR_JACK_GND [17]

叠层电感_56nH_0402_150mA_J

EAR_MIC [17]

1

17 35

17 35

17 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

4

Power Key / Key Pad

DO NOT put pull-up resistor on PWRKEY

3

2

1

1

TP1800

J1801

2

C C

B B

81800411

J1803

81800411

J1804

81800411

J1802

81800411

J1805

81800411

1

2

1

2

1

2

1

2

1

TP1

1

TP1801

TP1

LESD11LH5.0CT5G

1

TP1802

TP1

UP

DOWN

D1801

12

LESD11LH5.0CT5G

POWER

D1800

1 2

LESD11LH5.0CT5G

R1800

R1801

D1803

12

R1802

电阻_1K_0201_1/20W_J

电阻_1K_0201_1/20W_J

电阻_1K_0201_1/20W_J

PWRKEY [22,26]

NLU1G32CMUTCG

1

IN B

2

IN A

3

OUT Y

GND

U1801

HOMEKEY

[22]

PWRKEY[18,22]

HOMEKEY [22]

6

VCC

5

NC

4

NLU1G32CMUTCG

1

IN B

2

IN A

3

GND

VIO18_PMU

R1806

KPCOL1 defailt L

电阻_47K_0201_1/20W_J

[5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

VIO18_PMU [5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

12

TP1806

D1802

TP0.3

LESD11LH5.0CT5G

6

VCC

5

NC

4

OUT Y

U1802

KPCOL1 [13]

KPCOL0 [13]

1

C1810

电容_100nF_0201_X5R_6.3V_K

BQ25601-QON [18,26]

VBAT [18.22,26,32.33]

Schematic design notice of "65_PERI_Dual_SIM_ICUSB_KEYPAD" page.

Note 75-1: DO NOT put pull-up resistor on PWRKEY

Volume Up : HOME Key / GND

Note 75-2:

Volume Down : KPROW0/KPCOL0

For better ESD performance, please select suitable components for system protection.Note 75-3:

OPPO

OPPO

OPPO

Title

Title

A A

Title

18_KEYPAD_INTERFACE

18_KEYPAD_INTERFACE

18_KEYPAD_INTERFACE

Size Project Rev

Size Project Rev

Size Project Rev

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Date: Sheet of

Date: Sheet of

5

4

3

Date: Sheet of

2

Friday, December 28, 2018

A5S_MB_V1

A5S_MB_V1

A5S_MB_V1

1

18 35

18 35

18 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

4

3

2

1

M-Sensor

D D

ALS SENSOR

AK09918 / M-Sensor I2C Address : 0x0C (Write:0x18, Read:0x19)

U1904

1

U1901

B1

VIO18_PMU[5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

SDA1[13,19]

C C

C1905

电容_2.2uf_0201_6.3 V_M(±20%)

VDD

B2

SDA

AK09918C

AF9133需要VDD加2.2uf

A1

VSS

A2

SCL

SCL1 [13,19]

电容

G Sensor

Gyro sensor

必须使用

SPI

接口，不能用

I2C

80%,

EINT_ACC [13]

。

12ms-->37.1ms,

內部沒有量產過，目前

其餘應用不知

Code尚未Porting I2C

如用

I2C

接口，会有以下风险：

1.

功耗增加

2.

反應速度較慢, 以计步器来说，耗时

3. I2C G-sensor on sensor hub

U1902

VIO18_PMU[5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

B B

VIO18_PMU[5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

C1910

电容_100nF_0201_X5R_6.3V_K

3

7

C1911

4

9

8

电容_100nF_0201_X5R_6.3V_K

BMA253

5

VDDIO

INT1

6

INT2

VDD

10

SPI4_CSB [13]

CSB

1

SPI4_MI [13]

SDO

NC

2

SPI4_MO [13]

SDX

GND

12

SPI4_CLK [13]

SCX

GNDIO

11

PS

EINT_ALS[13]

PS Or ALS&PS SENSOR

ALS_PS_SDA[19]

EINT_PS[13]

R1942

电阻_1K_0201_1/20W_J

6

SCL

SDA

2

5

INT

VDD

4

GND3NC

TSL25913HFN

C1912

C1913

电容_100pF_0201_C0G_25V_J

电容_2.2uf_0201_6.3 V_M(±20%)

VDD 1.7~3.0V VLEDA 2.8~4.6V STK3332 4X1.5X1mm

ALS_PS_SCL [19]

U1903

1

2

VDD

SCL

8

SDA

7

/INT

GND

3

STK3331-A

LEDA

LDR

NC

电容_100pF_0201_C0G_25V_J

4

5

6

R1938

R1937

电阻_22R_0201_1/20 W_F(±1%)

C1921

C1901

电容_2.2uf_0201_6.3 V_M(±20%)

C1902电容_100pF_0201_C 0G_25V_J

C1922

电阻_0R_0201_1/20W_J

电阻_0R_0201_1/20W_J

R1901

电容_4.7uF_0402_X5R_6.3V_M

VIO28_PMU [19,21]

VIO28_PMU [19,21]

C1903

电容_33pF_0201_C0G_50V_J

VSYS [08,09,16,17,20,21,22,26,27,28]

ALS_PS_SCL [19]

C1906

电容_33pF_0201_C0G_50V_J

ALS_PS_SDA [19]

R1940

R0201_NC

1 2

SDA1 [13,19]

SCL1 [13,19]

R1941

R0201_NC

1 2

[5,06,09,11,12,15,18,19,21,23,26,31,32,33]

VIO18_PMU

OPPO

OPPO

OPPO

Title

Title

A A

5

4

3

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

19_SENSORS_ALS_PS_M_A

19_SENSORS_ALS_PS_M_A

19_SENSORS_ALS_PS_M_A

A5S_MB_V1

A5S_MB_V1

D

D

D

A5S_MB_V1

19 35Friday, December 28, 2018

19 35Friday, December 28, 2018

19 35Friday, December 28, 2018

1

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

4

3

2

1

D D

VSYS[08,09,16,17,19,21,22,26,27,28]

C C

B B

1

D2001

1

LTVS16H5.0ET5G

2

2

GND

For EOS Optional

R2000

电阻_1R_0201_1/20 W_J(±5%)

SH2000

LS_PAD_DIFFERENT

GND

SH2001

LS_PAD_DIFFERENT

GND

SH2002

LS_PAD_DIFFERENT

GND

SH2003

LS_PAD_DIFFERENT

GND

SH2004

LS_PAD_DIFFERENT

GND

SH2005

LS_PAD_DIFFERENT

GND

C2000

电容_1uF_0201_X5R_10 V_M(±20%)

12

C2001

电容_10uF_0402_X5R_10 V_M(±20%)

GND_VPROC

12

C2002

电容_10uF_0402_X5R_10 V_M(±20%)

GND_VCORE

12

C2003

电容_4.7uF_0402_X5R_10V_M

12

C2004

电容_10uF_0402_X5R_10 V_M(±20%)

GND_VPA

12

C2006

电容_4.7uF_0402_X5R_10V_M

GND_VS1

12

VSYS_SMPS

GND_SMPS

U2000A

MT6357

VBUCK CTRL

B2

VSYS_SMPS

B1

GND_SMPS

VPROC IN VPROC

A4

VSYS_VPROC_0

B4

VSYS_VPROC_1

C4

VSYS_VPROC_2

A5

GND_VPROC_0

B5

GND_VPROC_1

C5

GND_VPROC_2

A8

VSYS_VCORE_0

B8

VSYS_VCORE_1

C8

VSYS_VCORE_2

C9

GND_VCORE_0

B9

GND_VCORE_1

A13

VSYS_VMODEM_0

B13

VSYS_VMODEM_1

A12

GND_VMODEM_0

B12

GND_VMODEM_1

C12

GND_VMODEM_2

VPA IN VPA

A2

VSYS_VPA_0

A3

VSYS_VPA_1

B3

GND_VPA

B14

VSYS_VS1_0

A14

VSYS_VS1_1

A15

GND_VS1_0

B15

GND_VS1_1

MT6357CRV

VCOREVCORE IN

VMODEMVMODEM IN

VS1VS1 IN

VPROC_0
VPROC_1
VPROC_2
VPROC_3
VPROC_4
VPROC_5

VPROC_FB

GND_VPROC_FB

VCORE_0
VCORE_1
VCORE_2
VCORE_3

VCORE_FB

GND_VCORE_FB

VMODEM_0
VMODEM_1

VMODEM_FB

GND_VMODEM_FB

VPA_FB

5000mA

A6
A7

贴片功率电感器_0.47uH_2016_4.9 A(lrat)_3.6 A(lrms)_M(±20%)_33 毫欧

B6
B7
C6
C7

Differential and shielded with GND

C2

4mil

D2

4mil

HQ11880131000

5000mA

绕线电感_0.47uH_2016_饱和电流5A_温升电流4.05A_20%

Differential and shielded with GND

4mil

4mil

1800mA

VMODEM

贴片功率电感器_1uH_2016_4.7 A(lrat)_3.9 A(lrms)_M(±20%)_45 毫欧

Differential and shielded with GND

4mil

4mil

1000mA

VPA

绕线电感_1UH_2016_饱和电流2.7A_温升电流2.6A_20%

VS1

2500mA

贴片功率电感器_1uH_2016_4.7 A(lrat)_3.9 A(lrms)_M(±20%)_45 毫欧

VS1_FB

A9
A10
B10
C10

D3

E3

B11
C11

E13

D14

A1

VPA

E4

A16

VS1_0

B16

VS1_1

E14

L2000

L2001

L2002

L2004

5.2A

L2003

VPA_PMU [20,32]

Set power inductor
close to PMIC

Set power inductor
close to PMIC

Set power inductor
close to PMIC

Set power inductor
close to PMIC

Set power inductor
close to PMIC

VS1_PMU [20,21,28]

DVDD_DVFS_6357_FB [10]

DVDD_DVFS_6357_GND [10]

DVDD_CORE_6357_FB [10]

DVDD_CORE_6357_GND [10]

DVDD_MODEM_6357_FB [10]

DVDD_MODEM_6357_GND [10]

C2005

GND

电容_2.2uF_0402_X5R_6.3V_M

Set cap. C2040 close to
VPA power inductor

VS1_PMU [20,21,28]

DVDD_DVFS [10]

DVDD_CORE [10,11]

DVDD_MODEM [10]

Note: 20-1

VPA_PMU [20,32]

Schematic design notice of "20_POWER_MT6357_Buck"

C2040, please choose 0603 size

Note 20-1:

OPPO

OPPO

OPPO

Title

Title

A A

5

4

3

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

20_POWER_MT6357_Buck

20_POWER_MT6357_Buck

20_POWER_MT6357_Buck

A5S_MB_V1

A5S_MB_V1

D

D

D

A5S_MB_V1

20 35Friday, December 28, 2018

20 35Friday, December 28, 2018

20 35Friday, December 28, 2018

1

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

GND

U2000B

LDO IN LDO

C17

VS1_LDO1

Note: 21-5

F15

VS2_LDO1

F17

VS2_LDO2

G14

VSYS_LDO1

N17

VSYS_LDO2

K7

VSYS_LDO3

F13

D_GND_0

G8

D_GND_1

G7

D_GND_2

G9

D_GND_3

G12

D_GND_4

H6

D_GND_5

G10

D_GND_6

G11

D_GND_7

H7

D_GND_8

H8

D_GND_9

H9

D_GND_10

H10

D_GND_11

H11

D_GND_12

F12

D_GND_13

F11

D_GND_14

F10

D_GND_15

F9

D_GND_16

H12

D_GND_17

J6

D_GND_18

D7

D_GND_19

D8

D_GND_20

D6

D_GND_21

D9

D_GND_22

F5

D_GND_23

J7

D_GND_24

D10

D_GND_25

D11

D_GND_26

D12

D_GND_27

D13

D_GND_28

F6

D_GND_29

J8

D_GND_30

K12

D_GND_31

E6

D_GND_32

E7

D_GND_33

E8

D_GND_34

F7

D_GND_35

J9

D_GND_36

E11

D_GND_37

E9

D_GND_38

E10

D_GND_39

E12

D_GND_40

F8

D_GND_41

J11

D_GND_42

VREF

T14

VREF

T13

GND_VREF

DIG Power

K10

DVDD18_IO

L10

DVDD18_DIG

J10

DVSS18_IO

MT6357CRV

D D

VS1_PMU[20,28]

Note: 21-3

Suggest trace width > 40 mil

VS2_EXT2[28]

SH2100

1.46V

EXT_VS2_FB[28]

LS_PAD_DIFFERENT

For EOS

VSYS[08,09,16,17,19,20,22,26,27,28]

C C

B B

Set cap. close to PMIC

VIO18_PMU[5,06,09,11,12,13,15,18,19,21,23,26,31,32]

Note: 21-3

C2100

GND

电容_10uF_0402_X5R_6.3V_M

12

换成

4.7uf 0.65mm

C2107

GND

GND

电容_10uF_0402_X5R_6.3V_M

电容_22uF_0603_X5R_6.3V_M

Set cap. and shortpad close to PMIC

GND

SH2102

12

LS_PAD_DIFFERENT

C2125

电容_1uF_0201_X5R_6.3V_M

SH2103

GND

LS_PAD_DIFFERENT

GND

GND

电容_22uF_0603_X5R_6.3V_M

高度器件

C2108

SH2101

LS_PAD_DIFFERENT

12

电容_1uF_0201_X5R_6.3V_M

22UF

C2101

C2120

电容_100nF_0201_X5R_6.3V_K

12

C2126

C2102

GND

电容_4.7uF_0402_X5R_6.3V_M

NC

C2109

GND

电容_4.7uF_0402_X5R_6.3V_M

C2127

电容_100nF_0201_X5R_6.3V_K

VREF

GND_VREF

10mA

DVDD18_DIG

DVSS18_IO

MT6357

4

ALDO

DLDO

SLDO1

VSRAM_PROC

VSRAM_OTHERS

SLDO2

Power Switch

3

1. "Typical Cap" defined in design notice is the minimum cap. to LDO Cout.

2. NC cap can move to application, if (PCB L<20nH, PCB R<0.2 ohm)
=> value and placement of Cap, please refer design notice

Set cap. close to PMIC

6mil

50mA

L14

VXO22

VCN28

VCAMA

VAUX18

VAUD28

VCN33

VLDO28

VEFUSE

VRF18

VCN18

VCAMD

VCAMIO

VRF12

VDRAM

VFE28

T4

K13

H16

T5

L7

P17

L16

K15

VIO28

L15

VMC

N16

VMCH

L17

VEMC

J17

VSIM1

K16

VSIM2

M16

VIBR

J14

VUSB

H15

D16

E15

E17

A17

B17

VIO18

E16

G15

G16

H17

R9

TREF

GND

电容_1uF_0201_X5R_6.3V_M

电容_4.7uF_0402_X5R_6.3V_M

25mA

50mA

200mA

50mA

50mA

400mA

400mA

200mA

200mA

800mA

400mA

200mA

200mA

200mA

200mA

200mA

C2110

450mA

300mA

350mA@<1.5V

300mA

600mA

400mA

200mA

500mA

1200mA

C2121

6mil

6mil

8mil

6mil

6mil

C2116

GND

电容_1uF_0201_X5R_6.3V_M

GND

VCN33_PMU [35]

GND

电容_1uF_0201_X5R_6.3V_M

C2131

电容_1uF_0201_X5R_6.3V_M

C2117

C2103

C2104

C2105

GND

GND

12mil

12mil

8mil

8mil

20mil

12mil

6mil

6mil

6mil

6mil

8mil

C2111

GND

14mil

8mil

[email protected]

电容_1uF_0201_X5R_6.3V_M

8mil

25mil

C2118

GND

8mil

电容_4.7uF_0402_X5R_6.3V_M

8mil

8mil

30mil

C2122

GNDGND

电容_2.2uf_0201_6.3 V_M(±20%)

6mil1mA

GND

电容_2.2uf_0201_6.3 V_M(±20%)

电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

C2112

C2114

C2113

GND

电容_1uF_0201_X5R_6.3V_M

14mil

电容_1uF_0201_X5R_6.3V_M

C2119

GND GND

GND

电容_1uF_0201_X5R_6.3V_M

电容_4.7uF_0402_X5R_6.3V_M

C2123

GND

GND

电容_2.2uf_0201_6.3 V_M(±20%)

电容_4.7uF_0402_X5R_6.3V_M

C2115

GNDGND

GND

电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

C2128

C2129

电容_1uF_0201_X5R_6.3V_M

C2124

Note: 21-2

Note: 21-1

SH2104

SH2105

LS_PAD_DIFFERENT

12

12

VFE28_PMU [17,32]

VCN28_PMU [35]

VAUX18_PMU [22]

VAUD28_PMU [23]

VLDO28_PMU [09,16]

VIO28_PMU [19]

VMC_PMU [11]

VMCH_PMU [06]

VEMC_PMU [5]

VSIM1_PMU [06,11]

VSIM2_PMU [06,11]

VIBOUT_P [17]

VUSB_PMU [11]

VEFUSE_PMU [11]

VRF18_PMU [31]

VCN18_PMU [35]

VCAMD_PMU [16]

VCAMIO_PMU [16]

VIO18_PMU [5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

AVDD18_SOC [11]

EMI_VDD1 [5,11]

Note: 21-4

VRF12_PMU [31]

DVDD_SRAM_DVFS [10]

VSRAM_OTHERS_PMU [10]

VDRAM_PMU [5,10]

TREF_PMU [26]

2

1

MT6356 LDO output

Input Power Power Name Output Voltage (V) Output Current Default Voltage

LDO from

LDO from

LDO from

VFE28

VXO22

VCN28

VCAMA

VAUX18

VAUD28

VBIF28

VCN33

VBAT

VLDO28

VIO28

VMC

VMCH

VEMC

VSIM1

VSIM2

VIBR

VUSB

VRF18

VMIPI

VCN18

VS1

VCAMD

VCAMIO 1.8 1.8V300mA

VIO18

VRF12

VA12

VSRAM_PROC

VS2

VSRAM_OTHERS

VSRAM_GPU

VDRAM

1.8/2.5/2.8

3.3/3.4/3.5/3.6

1.86/2.9/3.0/3.3

2.9/3.0/3.3

2.9/3.0/3.3

1.7/1.8/1.86/2.76/3.0/3.1

1.7/1.8/1.86/2.76/3.0/3.1

1.2/1.3/1.5/1.8/2.0/2.8/3.0/3.3

1.71/1.8/1.84

1/1.05/1.1/1.2/1.3/1.5/1.8

2.8 40mA

2.24

2.8

1.8

2.8

2.8

2.8/3.0

2.8

3.07

1.81

1.8

1.8

1.2

1.2

0.6-1.31

0.6-1.31

0.6-1.31

1.12/1.24

25mA

40mA

200mA

20mA

50mA

1mA

800mA

360mA

200mA

200mA

800mA

800mA

200mA

200mA

200mA

50mA

450mA

300mA

200mA

600mA

1200mA

200mA

300mA

400mA

200mA

400mA

1000mA

2.8V

2.24V

2.8V

2.8V

1.8V

2.8V

2.8V

3.3V

2.8V

2.8V

3.0V

3.0V

3.3V

1.86V

1.86V

2.8V

3.07V

1.81V

1.84V

1.8V

1.2V

1.8V

1.2V

1.2V

1.1V

0.9V

1.0V

1.24v

OPPO

OPPO

Schematic design notice of "21_POWER_MT6357_LDO"

If these power trace can meet LDO layout constraint, these CAP can be NC or removed.

Note 21-1:

A A

Please refer to MT6357 design notice.

Output cap range please follow MT6357CRV LDO design notice

Note 21-2:

Ext Buck BOM option

Note 21-3:

C2104 10uF 22uF
R2851 0-ohm , 0603
R2852

5

Ext. buck option

w/ EXT VS2 Buck w/o EXT VS2 Buck

NC

NC

0-ohm , 0603

Note 21-4: Please set SH2101 and SH2102 close to C2141, making star connection among VIO18_PMU, AVDD18_SOC, and

EMI_VDD1 near to LDO cap. C2141

Please also refer to MT6357 design notice for further detail design information

Note 21-5: Please connect VS2_LDO1(F15) to VS1_PMU if voltage applied to VCAMD(E17) >= 1.3 V

4

3

OPPO

Title

Title

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

21_POWER_MT6357_LDO

21_POWER_MT6357_LDO

21_POWER_MT6357_LDO

A5S_MB_V1

A5S_MB_V1

D

D

D

A5S_MB_V1

21 35Friday, December 28, 2018

21 35Friday, December 28, 2018

21 35Friday, December 28, 2018

1

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

VSYS[08,09,16,17,19,20,21,22,26,27,28]

Disable USB DL WITHOUT BATEERY

Schottky diode (VF <0.3V @ 1mA) MUST be for
PWRKEY ESD protection and to

R2212

avoid inverse current from MT6371.

电阻_100K_0201_1/20W_J

D D

HOMEKEY[18]

Note: 22-3

PWRKEY[18,26]

SYSRSTB[12,30]

WATCHDOG[12]

GND

SRCLKENA0[12]

SRCLKENA1[12,31]

EXT_PMIC_EN2[28]

PWRAP_SPI0_CSN[12]

PWRAP_SPI0_CK[12]

PWRAP_SPI0_MO[12]

PWRAP_SPI0_MI[12]

Set cap. close to PMIC

SH2200

VSYS[08,09,16,17,19,20,21,22,26,27,28]

C C

B B

VBUS_USB_IN[17,26,30]

R2206

电阻_330K_0201_1/20W_F

R2207

电阻_39K_0201_1/20W_F

GND

VCDT rating: 1.268V

12

LS_PAD_DIFFERENT

C2202

电容_1uF_0201_X5R_10 V_M(±20%)

GND

BATON[26]

VBUS_USB_IN[17,26,30]

SH2201

12

VSYS[08,09,16,17,19,20,21,22,26,27,28]

LS_PAD_DIFFERENT

VBAT[26,32,33]

C2203

电容_100nF_0201_X5R_10V_K

GND

R2208

电阻_7.5K_0201_1/20W_J

C2209

GND

Set resistor and cap. close to PMIC

电容_1uF_0201_X5R_6.3V_M

LS_PAD_DIFFERENT

1 2

D2200 PSBD2FD40V02

R2201

电阻_200K_0201_1/20 W_F(±1%)

SH2202

12

C2204

GND

电容_100nF_0201_X5R_10V_K

4

U2000C

CHD_DM[13]

CHD_DP[13]

UVLO_VTH

CS_P[26]

CS_N[26]

PWRKEY_PMIC

GND

CHRLDO

Differential

Differential

R4

PWRKEY

N4

FCHR_ENB

R5

RESETB

T8

WDTRSTB_IN

N3

UVLO_VTH

N7

SRCLKEN_IN0

N8

SRCLKEN_IN1

M5

EXT_PMIC_EN1

N5

EXT_PMIC_EN2

M6

EXT_PMIC_PG

R8

SPI_CSN

M8

SPI_CLK

M7

SPI_MOSI

M9

SPI_MISO

P5

PMU_TESTMODE

P9

FSOURCE

N9

VSYSSNS

M13

BATSNS

N13

ISENSE

R13

BATON

BATON

T11

VCDT

R11

CHRLDO

P13

VDRV

M10

CHG_DM

M11

CHG_DP

N12

PCHR_LED

T10

CS_P

R10

CS_N

L12

ISINK1

MT6357CRV

MT6357

Control I/F RTC

Charger I/F

Note: 22-5

Gauge

ISINK

DCXO

AUXADC

AVSS22_XOBUF_0
AVSS22_XOBUF_1

AVSS22_XO_ISO_0
AVSS22_XO_ISO_1

AVDD18_AUXADC

AVSS18_AUXADC

VRTC28

RTC32K_1V8_0

RTC32K_1V8_1

RTC32K_2V8

AVSS22_XO

XO_SOC

XO_CEL

XO_WCN

XO_NFC

XO_EXT

AUXADC_VIN

XTAL1

XTAL2

Set cap. close to chip

R12

GND

P14

电容_100nF_0201_X5R_6.3V_K

R15

P11

AVSS22_XO

M2

AVSS22_XOBUF

P1
R1

AVSS22_XO_ISO

N2
P2

XO_SOC

R3

XO_CEL

T1

XO_WCN

P3

R2

T2

M1

XTAL1

3mil trace width

N1

XTAL2

3mil trace width

R7

P7

12

T7

LS_PAD_DIFFERENT

GND

C2200

RTC32K_CK [12]

GND

GND

GND

电阻_0R_0201_1/20W_J

电阻_0R_0201_1/20W_J

电阻_0R_0201_1/20W_J

XTAL1 [22]

XTAL2 [22]

SH2203

电容_1uF_0201_X5R_6.3V_M

Set cap. close to PMIC

AVSS18_AUXADC

AUXADC_VIN

AVDD18_AUXADC

3

R2200

电阻_1.5K_0201_1/20W_J

22UF

C2201

GND

电容_10uF_0402_X5R_6.3V_M

Note: 22-2

R2202

R2203

R2204

C2205,C2206,C2207直接下主GND,不能有表层GND相连接。

C2206

C2210

C2211

GND GNDGND

电容_100nF_0201_X5R_6.3V_K

3mil trace width

3mil trace width

3mil trace width

电阻_100KΩ_0201_1/20W_F

AVSS18_AUXADC

C2205

1 2

R2210

C0201_NC

电阻0R(0402-0.0625W-J)

1 2

C0201_NC

R2209

Note: 22-1

C2207

1 2

C0201_NC

Note: 22-4

VAUX18_PMU [21]

3mil trace width

3mil trace width

XTAL2

X2200

SMT 26M NTC

3

XT2

2

RT2

OZ26030001

PMIC_CLK_BB [12]

PMIC_CLK_RF [31]

PMIC_CLK_WCN [35]

3mil trace width

1

XT1

4

RT1

XTAL1 [22]

2

XTAL2 [22]

1

Route AVDD18_AUXADC, AUXADC_VIN, and AVSS18_AUXADC with 3mils width traces and well GND shielding

OPPO

OPPO

OPPO

A A

5

Schematic design notice of "22_POWER_MT6357-IF"

Please implement 2520 & 2016 Size TMS PCB co-layout.

Note 22-1:

Please refer to MT6765_MT6357 Co-Clock Design Notice for co-layout guide

1. Please Connect P1 and R1 ball first and then to GND

Note 22-2:

2. Please Connect P2 and N2 ball first and then to GND

3. Please connect DCXO GND to main GND by independent L1-2 GND via.;
DO NOT connect it through L1 GND

Let floating if disable HOMEKEY function

Note 22-3:

Please follow MT6765_MT6357 Co-Clock Design Notice for Layout guide of VAUX18,

Note 22-4:

then R8101 can use 0 ohm to replace BEAD.

4

Note 22-5:

3

Please connect to battery connector

Title

Title

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

22_POWER_MT6357_IF

22_POWER_MT6357_IF

22_POWER_MT6357_IF

A5S_MB_V1

A5S_MB_V1

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

1

22 35

22 35

22 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

C C

- AU_HPL and AU_HPR should be routed as single end signal,
and be guarded by GND, up and down, left and right respectively

- The suggested layout pattern of AU_HPL/ AU_HPR/ AU_REFN
is " GND AU_HPL AU_REFN AU_HPR GND"

B B

4

R2301 Deleted--20181007-caifeng

AU_HPL[17]

AU_REFN[17]

AU_HPR[17]

GND

电容_1nF_0201_X7R_25V_K

Set cap. close to PMIC

AUD_CLK_MISO[12]

AUD_DAT_MISO0[12]

AUD_DAT_MISO1[12]

AUD_SYNC_MISO[12]

AUD_CLK_MOSI[12]

AUD_DAT_MOSI0[12]

AUD_DAT_MOSI1[12]

AUD_SYNC_MOSI[12]

P-N pair should be
differential pair & shielded with GND

AU_VIN0_P[07]

AU_VIN0_N[07]

AU_VIN1_P[17]

AU_VIN1_N[17]

P-N pair should be differential pair & shielded with GND

P-N pair should be
differential pair & shielded with GND

ACCDET[17]

HP_EINT[17]

C2306

P-N pair should be differential pair & shielded with GND

AU_HSP[07]

AU_HSN[07]

R2301 电阻_0R_0201_1/20W_J

C2390

GND

电容_2.2uf_0201_6.3 V_M(±20%)

LO_P[08]

LO_M[08]

P-N pair should be
differential pair & shielded with GND

U2000D

MT6357

AUDIO IF UL POWER

R16

AUD_CLK_MISO

T17

AUD_DAT_MISO0

R17

AUD_DAT_MISO1

T16

AUD_SYNC_MISO

P16

AUD_CLK_MOSI

P15

AUD_DAT_MOSI0

N14

AUD_DAT_MOSI1

M14

AUD_SYNC_MOSI

AUDIO INPUT

K3

AU_VIN0_P

K4

AU_VIN0_N

K5

AU_VIN1_P

L5

AU_VIN1_N

J4

AU_VIN2_P

J5

AU_VIN2_N

ACCDET

M4

ACCDET

J1

HP_EINT

AUDIO OUTPUT

J2

AU_HPL

H3

AU_REFN

G3

AU_HPR

F4

AU_LOLP

F3

AU_LOLN

G6

AU_HSP

G5

AU_HSN

MT6357CRV

3

CHARGE PUMP

AVDD28_AUD

AVSS28_AUD

AU_MICBIAS0

AU_MICBIAS1

AVDD18_AUD

AVSS18_AUD

AU_V18N

2

K1

H5

AVSS28_AUD[17]

L3

M3

G2

AVSS_AUD

F2

AU_V18N

D1

F1

FLYP

FLYP

E2

FLYN

FLYN

C2300

C2302

C2301

电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

电容_1uF_0201_X5R_6.3V_M

Set cap. and shortpad close to PMIC

C2303

C2304

电容_4.7uF_0402_X5R_6.3V_M

电容_2.2uf_0201_6.3 V_M(±20%)

C2305

电容_4.7uF_0402_X5R_10V_M

Set cap. close to PMIC

SH2301

LS_PAD_DIFFERENT

1. AVSS18_AUD is connected to GND in very short trace

2. AVSS18_AUD is connected to de-couple cap of
AVDD18_AUD and AU_V18N with 6mil trace respectively

SH2300

LS_PAD_DIFFERENT

12

VAUD28_PMU [21]

12

GND

AU_MICBIAS0 [17]

AU_MICBIAS1 [17]

VIO18_PMU [5,06,09,11,12,13,15,18,19,21,26,31,32,33]

GND

1

OPPO

OPPO

OPPO

Title

Title

A A

5

4

3

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

23_POWER_MT6357_Audio

23_POWER_MT6357_Audio

23_POWER_MT6357_Audio

A5S_MB_V1

A5S_MB_V1

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

1

23 35

23 35

23 35

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

C C

4

3

2

1

B B

A A

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

5

4

3

Date: Sheet

24_ Reserved

24_ Reserved

24_ Reserved

<Doc> <RevCode>

A

<Doc> <RevCode>

A

<Doc> <RevCode>

A

of

24 35Friday, December 28, 2018

24 35Friday, December 28, 2018

2

24 35Friday, December 28, 2018

1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

C C

4

3

2

1

B B

A A

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

5

4

3

Date: Sheet

25_ Reserved

25_ Reserved

25_ Reserved

<Doc> <RevCode>

A

<Doc> <RevCode>

A

<Doc> <RevCode>

A

of

25 35Friday, December 28, 2018

25 35Friday, December 28, 2018

2

25 35Friday, December 28, 2018

1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

4

3

2

1

BQ25601 Charger

D D

C2602-BOM

变更为

电容

C2602

VBUS_USB_IN[17,22,30]

VIO18_PMU[5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

EINT_CHG_0[13]

REGN[26]

GPIO_CHG_EN_0[13]

C C

SCL5[13]

SDA5[13]

[18,26]

Note1:PSEL pin,Power source selection input. Set 500 mA input current limit by pulling this pin high and set 2.4A input current limit by pulling this pin low.
Once the device gets into host mode, the host can program different input current limits to IINDPM register

电容_100pF_0201_C0G_25V_J

REGN[26]

R2615

电容_4.7uF_0402_X5R_10V_M

R2618

IIC default up 5K 1K

BQ25601-QON

C2601

12

R2601 R0201_NC

R2602

电阻_10K_0201_1/20W_J

R0201_NC

12

C2607

电阻_10K_0201_1/20W_J

1 2

D2602 PSBD2FD40V02

电容_2.2uf_0402_25 V_M(±20%)

BTST[26]

12

C2615

HQ11712276000

_2.2uF_0402_X5R_16 V_M(±20%)

U2601

走线宽度

C0402_NC

C2616

电容_10uF_0402_X5R_10 V_M(±20%)

L3001 use HQ11880073000,same to AL2017

2mm

1

VAC

24

VBUS

PSEL

2

PSEL

3

PG

4

STAT

7

INT

21

BTST

22

REGN

23

PMID

9

/CE

CE

5

SCL

6

SDA

12

QON

BQ25601

BQ25601 I2C address:0x6BH

SW_CHG

19

SW1

20

贴片功率电感器_1 uH_2520_4.6 A(lrat)_4 A(lrms)_M(±20%)_53 毫欧

PGND1

PGND2

SW2

SYS1

SYS2

BAT1

BAT2

GND3

NC1
NC2

15

16

13

14

11

TS

17

18

25

8
10

C2606电容_47nF_0402_X7R_25 V_K(±10%)

C906使用HQ11712369000

电容

_47nF_0402_X5R_50 V_K

NC

C2603

L2601

电容_4.7uF_0402_X5R_10V_M

BTST [26]

change 25V

，

C2614

电容_10uF_0402_X5R_10 V_M(±20%)

C2618 电容_10uF_0402_X5R_10 V_M(±20%)

R2608

TS_CHG

R2609

电阻_10K_0201_1/20W_J

C2604

电容_10uF_0402_X5R_10 V_M(±20%)

走线宽度：

电阻_10K_0201_1/20W_J

REGN [26]

2mm

VBAT [22,26,32,33]

VSYS [08,09,16,17,19,20,21,22,27,28]

VBUS_USB_IN[17,22,30]

RT301 is for Charge surface temperature detect

R2620

电阻_330K_0201_1/20W_F

390K

VBUS_ADC [12]

R2623

1%

电阻_100K_0201_1/20W_J

TP2610

TP2600

TP1

TP1

1

1

B B

A A

BATTERY
CONNECTOR

CS_N[22]

CS_P[22]

12

SH2600

R2603

LS_PAD_DIFFERENT

电阻_0.01R_0805_1/2W_F(±1%)

TP2601

12

TP2609

TP1

TP1

1

SH2601

LS_PAD_DIFFERENT

ADC

1

检测上拉与

2

2

1

D2601

J2601

3

11

6

14

P-

P+

P-

ID

G/P_3

G/P_6

SIG_13

G/P_11

G/P_14

NTC

SIG_12

SIG_5

SCL/NC

SIG_4

SDA/NC

P+

G/P_10

G/P_77G/P_88G/P_9

9

BM25-4S/2-V51

10

电阻_10K_0201_1/20W_F

电阻_1K_0201_1/20W_F

,BAT

下拉电阻

R2605

?

300K F

13
12
5
4

R2607

R2625

1%

电阻_56K_0201_1/20W_F

精度电阻

16

G/P_16

1

G/P_1

2

G/P_2

15

G/P_15

VIO18_PMU[5,06,09,11,12,13,15,18,19,21,23,26,31,32,33]

AUX_IN2_BATID[12]

bat

内部下拉电阻分压

1

NSPM1041BMUTBG

12

12

D2603

LESD11LH5.0CT5G

LESD11LH5.0CT5G

Schematic design notice of "26_POWER_SubPMIC-Charger + PP" page.

For better ESD or surge performance we need choose suitable device for system

Note 26-1:

protection. Please refer to [Surge device selection guide V2.0] provide by MTK.

5

4

D2604

耐压

10V

C2608

电容_33pF_0201_C0G_50V_J

电容_10uF_0402_X5R_10 V_M(±20%)

R2604

电阻_16.9K_0201_1/20 W_F(±1%)

电阻_1K_0201_1/20W_F

1

TP1

TP2602

VBAT [22,26,32,33]

C2610

NTC 10K R2604 TREF PULL UP R=16.9K

1%

R2606

3

TREF_PMU [21]

BATON [22]

OPPO

OPPO

OPPO

Title

Title

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

26_Charger_IC_BQ25601+BATTERY

26_Charger_IC_BQ25601+BATTERY

26_Charger_IC_BQ25601+BATTERY

A5S_MB_V1

A5S_MB_V1

D

D

D

A5S_MB_V1

26 35Friday, December 28, 2018

26 35Friday, December 28, 2018

26 35Friday, December 28, 2018

1

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

4

3

2

1

Rear Camera Flash

主供

12

LED_OUT

0.7mm

0.7mm

电阻_150K_0201_1/20 W_F(±1%)

C2718

C0201_NC

ELCH06-BJ4J6Z10-N0(YY)

D2702

R2704

电阻_16.9K_0201_1/20 W_F(±1%)

C2701

电容_10uF_0402_X5R_10 V_M(±20%)

2

+

-

ELCH07-KB4247J5J8283910-F3H 220lm 4150~4850K

1

R2724

电阻0R(0402-0.0625W-J)

电阻0R(0402-0.0625W-J)

R2725

ELCH06-BJ4J6Z10-N0(YY)

D2703

C2723

C1

A1

电容_100pF_0201_C0G_25V_J

B1

B2

C2

C3

A3

C2708

A2

电容_2.2uf_0402_25 V_M(±20%)

C2725

C2711

电容_4.7uF_0402_X5R_10V_M

电容_100pF_0201_C0G_25V_J

C2708-BOM

电容

_2.2uF_0402_X5R_16 V_M(±20%)

L2702

叠层电感_4.7uH_0806_1.1A_20%

U2702

VIN

LX

ENN

BSTO1

ENP

BSTO2

SCL

AVDD

SDA

CFLY1

AGND

CFLY2

PGND2

AVEE

PGND1

NT50358ACG/J

变更为

HQ11712276000

VSYS[08,09,16,17,19,20,21,22,26,27,28]

R2706

1 2

R0201_NC

LCM_AVEE[09]

C2704

电容_4.7uF_0402_X5R_10V_M

R2734

电阻0R(0402-0.0625W-J)

2

+

-

1

GPIO165_LCD_BIAS_ENN[13]

GPIO166_LCD_BIAS_ENP[13]

SDA3[13]

TP2702

TP0.3

2

1

R2705R0201_NC

1

TP2701

TP0.3

1

C C

C2702

电容_10uF_0402_X5R_10 V_M(±20%)

VSYS[08,09,16,17,19,20,21,22,26,27,28]

绕线电感_2.2UH_2016_饱和电流1.60A_温升电流1.60A_20%

GPIO157_FLASH_EN[13]

GPIO6_TORCH_EN[13]

L1002 换HQ11880253000,高度1mm

C2703

L2701

电容_33pF_0201_C0G_50V_J

SW_Flash

U2701

5

SW-2

6

SW-1

4

VIN

10

ENF

11

ENM

PGND

3

7

1.3mm

8

VOUT-1

9

VOUT-2

12

D1

14

D2

2

RSETF

1

RSETM

AGND-2

AGND-3

AGND-1

13

15

R2703

SGM3785

Iflash=8556/16.9*2=1012mA;R2704->16.9K

Imovie=7063/150*2=94mA;R2703->150k HQ11600244000

B B

NT50358

二供

SM5109 HQ11150971000

LX_LCM

D1

D3

C2706

E2

电容_10uF_0402_X5R_10 V_M(±20%)

E3

D2

E1

B3

C2707

10V

耐压

10V

C2724

电容_100pF_0201_C0G_25V_J

电容_4.7uF_0402_X5R_10V_M

R2733

电阻0R(0402-0.0625W-J)

；

LCM_AVDD [09]SCL3[13]

OPPO

OPPO

Schematic design notice of "27_POWER_SubPMIC-HV powers" page:

A A

Note 27-1: To minimize RF de-sense, it is recommended to reserve 0-ohm and 0402 cap for BOM fine tuning.

OPPO

Title

Title

Title

27_LCD+-5V_TORCH_DRIVER_IC

27_LCD+-5V_TORCH_DRIVER_IC

27_LCD+-5V_TORCH_DRIVER_IC

Note 27-2: To minimize RF de-sense, it is recommended to reserve 0-ohm and 0201 cap. for BOM fine tuning.

Size Project Rev

Size Project Rev

Note 27-3: C2705 could be replaced with C / 1 / uF / 50V + C / 1 / uF / 50V

5

4

3

Size Project Rev

A5S_MB_V1

A5S_MB_V1

D

D

D

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

A5S_MB_V1

27 35Friday, December 28, 2018

27 35Friday, December 28, 2018

27 35Friday, December 28, 2018

1

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

4

3

2

1

Suggest trace width > 12 mil

VS2_EXT2[21,28]

EXT_PMIC_EN2[22]

R2810

VSYS[08,09,16,17,19,20,21,22,26,27,28]

C C

B B

电阻_1K_0201_1/20W_F

Suggest trace width > 25 mil

VSYS[08,09,16,17,19,20,21,22,26,27,28]

C2805

GND GND

电容_100nF_0201_X5R_10V_K

VS1_PMU[20,21]

电容_10uF_0402_X5R_10 V_M(±20%)

C2806

LDO for VA12

C2802

电容_4.7uF_0402_X5R_6.3V_M

C2800

电容_1uF_0201_X5R_10 V_M(±20%)

A2

B2

C2

GND

GND

Ext. Bulk for VS2

U2801

7

TP2800

8

1

PGOOD

1

TP0.3

EN

PGND

3

5

GND

VOUT

AGND

MT6690N

U2803

VOUTA1VIN

ADJB1EN

BIAS

GND

MT6680P

C1

GND

LX6VIN

2

FB

4

Note: 28-1

Suggest trace width > 12 mil

C2801

C2808

GND

GND

电容_4.7uF_0402_X5R_6.3V_M

R2800

电阻_29.4K_0201_1/20W_F(±1%)

电容_4.7uF_0402_X5R_6.3V_M

R2801

电阻_20K_0201_1/20W_J

GND

1.2V

R2800 VALUE?

28k

0.5V x (1+R2820/R2821)

Note: 28-2

L2800

贴片功率电感器_1 uH_2016_2.7 A(lrat)_2.6 A(lrms)_M(±20%)_70 毫欧

EXT_VS2_FB [21]

R2802

GND

电阻_105K_0201_1/20W_F(±1%)

电阻_150K_0201_1/20 W_F(±1%)

R2803

0.6V x (1+R1/R2)

C2803

GND

电容_10uF_0402_X5R_6.3V_M

VA12_PMU [11]

电容_10uF_0402_X5R_6.3V_M

Suggest trace width > 40 mil

C2804

GND

1.46V

VS2_EXT2 [21,28]

OPPO

OPPO

OPPO

Title

Title

A A

Schematic design notice of "28_POWER_ThirdParty-Power"

Note 28-1:

Note 28-2:

Note 28-3:

5

4

VA12 Layout placement please close to AP

VS2 Buck Layout placement please close to PMIC MT6357

VCN33 LDO Layout placement please close to MT6631

3

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

28_POWER_ThirdParty_Powers

28_POWER_ThirdParty_Powers

28_POWER_ThirdParty_Powers

A5S_MB_V1

A5S_MB_V1

D

D

D

A5S_MB_V1

28 35Friday, December 28, 2018

28 35Friday, December 28, 2018

28 35Friday, December 28, 2018

1

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

C C

4

3

2

1

B B

A A

Title

Title

Title

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet of

Date: Sheet of

5

4

3

Date: Sheet

29_ Reserved

29_ Reserved

29_ Reserved

<Doc> <RevCode>

A

<Doc> <RevCode>

A

<Doc> <RevCode>

A

of

29 35Friday, December 28, 2018

29 35Friday, December 28, 2018

2

29 35Friday, December 28, 2018

1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

D D

4

CONFIG0 7

CONFIG1 7

3

TP9008

1

TP1

1

TP9009

TP1

TP3008

VBUS_USB_IN[17,22,26]

1

TP1

2

1

Note: 30-1

1

C C

SYSRSTB[12,22]

TP3002 TP0.3

RF_PCB TO A-COVER Rear Camera TO GND

ANT3006
818010089

112

ANT3000

1

81800411

2

SHIEDING FRAME

TP3010

TP3012

TP3011

TP3009

TP1

TP1

SH3006

SH3010

SH3008

1

B B

1

TP0.5

TP0.5

SH3009

TP0.5

SH3002

SH3003

SH3001

1

1

TP0.5

SH3004

1

1

1

TP0.5

TP0.5

TP0.5

SH3005

TP0.5

SH3007

1

1

1

TP0.5

TP0.5

TP1

1

1

TP3014

TP1

TP1

1

1

1

TP3017

TP1

TP3018

TP1

1

1

ANT3001
81800411

1

ANT3002

ANT3005

81800411

81800411

2

1

2

2

1

2

12

R3001

R3002

R0201_NC

电阻0R(0402-0.0625W-J)

1

MARK1_S

F3001

光学定位孔

F3002

1

MARK1_S

F3003

1

MARK1_S

1

MARK1_S

F3004

F3005

1

MARK1_S

OPPO

OPPO

OPPO

Title

Title

A A

5

4

3

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

30_DEBUG_IO

30_DEBUG_IO

30_DEBUG_IO

D

D

D

A5S_MB_V1

A5S_MB_V1

A5S_MB_V1

30 35Friday, December 28, 2018

30 35Friday, December 28, 2018

30 35Friday, December 28, 2018

1

V1

V1

V1

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

4

3

2

1

TXM_GSM

DPDT SWITCH

4

J3302

D D

GND-3

电容_33pF_0201_C0G_50V_J

1

IN2GND-1

GND-2

3

LTE_VMIPI[32]

叠层电感_68nH_0201_50mA_J

50ohm

C3368

R3315

电阻_10K_0201_1/20W_J

R3314

L3355

电阻_100K_0201_1/20W_J

C3362

电容_33pF_0201_C0G_25V_J

电容_100pF_0201_C0G_25V_J

C3361

J3303

BPI_BUS12 [12]

4

GND-1

1

IN2OUT

GND-2

D3301

3

NC

LESD11LH5.0CT5G

RF_Ant_TRX_carkit

12

R3300

电阻_0R_0201_1/20W_J

50ohm

MAIN_ANT_DPDT_OUT [33]

L3301

L0201_NC

1 2

优先保证射频走线，兼容通路，不要有断头线

BPI_BUS5[12]

C3309

电容_100pF_0201_C0G_25V_J

MAIN_ANT_DPDT_OUT[33]

MAIN_ANT_DPDT_IN[33] DIV_ANT_DPDT_IN[34]

C3308

电容_2.2nF_0201_X5R_25V_K

U3306

10

QM11022

1

9

GND

CTL

VDD

2

8

RF3

RF4

3

7

GND1

GND2

4

6

RF1

RF2

GND4

5

LTE_VFE28 [32,34]

DIV_ANT_DPDT_OUT [34]

ASM SWITCH

MAIN_ANT_DPDT_IN[33]

RF_B40_TRX_TXM[32]

RF_B20_TRX_TXM[33]

RF_DCS/PCS_PRX_TXM[33]

RF_B38B41_TRX_TXM[32]

RF_B8_TRX_TXM[33]

RF_B7_TRX_TXM[33]

RF_B3_TRX_TXM[33]

RF_B5_TRX_TXM[33]

RF_B1_TRX_TXM[33]

RF_B28B_TRX_TXM[33]

RF_B28A_TRX_TXM[33]

R3330

电阻_0R_0201_1/20W_J

L3304

L0201_NC

1 2

50 ohm

RF_TXDET[31]

20

RF_Ant_TRX_TXM

L3305

L0201_NC

1 2

21

22

50 ohm

23

24

25

26

27

28

29

30

电池连接器到PA VBAT 脚，不小于2mm线宽，峰值电流2A

12

16

17

18

19

CPL

NC-2

GND-513GND-914GND-815GND-7

GND-2

GND-11

U3314

SKY77916-21

TRX731TRX632TRX533TRX434TRX335TRX236TRX137GND-10

HB_SWOUT

LB_SWOUT

GND-3

VBATT

VRAMP

SDATA

GND-6

38

NC-1

GND-1

ANT

GND-4

TRX14

TRX13

TRX12

TRX11

TRx3-5 only, 2300 to 2690 MHz,IL=1.3dB

TRX10

TRx8 only, 2300 to 2690 MHz,IL=1dB

TRX9

TRX8

C3302

C3365

C3367

C3390

电容_33pF_0201_C0G_50V_J

电容_10uF_0402_X5R_10 V_M(±20%)

电容_100nF_0201_X5R_10V_K

11

10

9

VCC

8

7

VIO

6

5

SCLK

4

3

电容_1nF_0201_X7R_25V_K

HB_IN

2

LB_IN

1

39

50 ohm

50 ohm

电容_10uF_0402_X5R_10 V_M(±20%)

不小于0.2mm 线宽

C3364

C3385

电容_18pF_0201_C0G_50V_J

C3369

RF_2G_HB_TX_PA

50 ohm 50 ohm

电容_33pF_0201_C0G_50V_J

12

C3366

C0201_NC

C3363

RF_2G_LB_TX_PA

电容_56pF_0201_C0G_25V_J

12

C3360

C0201_NC

1

D3300
PTVS5V0Z1USKNYL

2

C3386

电容_18pF_0201_C0G_50V_J

12

C3389

C0201_NC

12

C3305

C0201_NC

VBAT [22,26,32]

R3331

电阻_7.5K_0201_1/20W_J

C3382

电容_220pF_0201_X7R_50V_K

LTE_VMIPI [32]

MIPI1_SDATA [12]

MIPI1_SCLK [12]

C3388

电容_33pF_0201_C0G_50V_J

C3387

电容_33pF_0201_C0G_50V_J

APC1 [12]

RF_2G_HB_TX_RFIC [31]

50 ohm

RF_2G_LB_TX_RFIC [31]

B20 DPX

B1 DPX

U3301

RF_B1_TRX_DPX

L3320

叠层电感_4.3nH_0201_220mA_S

SAYRH1G95BA0F0A

6

ANT

C C

RF_B1_TRX_TXM[33]

C3344

电容_8.2pF_0201_C0G_50V_B

L3319

叠层电感_4.3nH_0201_220mA_S

RF_B1_TRX_DPX

3

TX

1

RX

GND-1

GND-24GND-3

GND-47GND-5

2

5

8

RF_B1_PRX_DPX_RFIP1

12

C3353

C0201_NC

R3340

电阻_0R_0201_1/20W_J

B5 DPX

C3384

RF_B5_TRX_TXM[33]

C0201_NC

RF_B5_PA_DPX[32]

电容_56pF_0201_C0G_25V_J

12

C3379

RF_B5_TRX_DPX

L3306

叠层电感_6.8nH_0201_200mA_J

U3305

6

SFX836CYA02

RF_B5_PRX_DPX_RFIP1

3

ANT

RX1TX

GND18GND27GND35GND44GND5

2

12

C3381

C0201_NC

R3344

电阻_0R_0201_1/20W_J

12

C3347

C0201_NC

12

C3383

C0201_NC

C3348

电容_33pF_0201_C0G_50V_J

C3380

电容_33pF_0201_C0G_50V_J

RF_B1_PA_DPX [32]

RF_B1_PRX_RFIC [31]

B8 DPX

RF_B5_PRX_RFIC [31]

RF_B20_TRX_TXM[33]

RF_B20_PA_DPX[32]

RF_B8_TRX_TXM[33]

RF_B8_PA_DPX[32]

12

C3329

C0201_NC

L3311

叠层电感_1.5nH_0201_500mA_J

C3332

电容_8.2pF_0201_C0G_50V_B

12

C3333

C0201_NC

L3312

叠层电感_2.2nH_0201_290mA_S

L3313

叠层电感_4.3nH_0201_220mA_S

RF_B8_TRX_DPX

6

3

TX

GND-4

GND-24GND-3

2

5

RF_B20_TRX_DPX

U3308
SAYEY897MBG0F0A

RX

ANT

GND-57GND-1

8

U3320

6

SAYEY707MBA0F0A

RF_B20_PRX_DPX_RFIP1

1

3

ANT

RX

TX

GND-4

GND-24GND-3

GND-57GND-1

2

5

1

8

RF_B8_PRX_DPX_RFIP1

C3351

12

C3311

C0201_NC

12

电阻_0R_0201_1/20W_J

C0201_NC

电阻_0R_0201_1/20W_J

C3350

R3335

电容_33pF_0201_C0G_50V_J

12

C3349

C0201_NC

R3302

C3312

电容_33pF_0201_C0G_50V_J

12

C3310

C0201_NC

RF_B20_PRX_RFIC [31]

RF_B8_PRX_RFIC [31]

B3 DPX

B B

RF_B3_PA_DPX[32]

RF_B3_TRX_TXM[33]

叠层电感_1.5nH_0201_500mA_J

12

C3343

C0201_NC

L3317

叠层电感_2.2nH_0201_290mA_S

RF_B3_TRX_DPX

L3318

U3303
D6DA1G842K2C4

3

6

2

4

C3357

C0201_NC

R3310

电容_22pF_0201_C0G_50V_J

电阻_0R_0201_1/20W_J

12

12

C3358

C3359

C0201_NC

RF_B3_PRX_RFIC

[31]

RF_B3_PRX_DPX_RFIP1

1

TX

RX

ANT

5

GND3

7

GND1

GND4

8

GND2

GND5

GSM DCS/PCS RX

U3312

RF_DCS/PCS_PRX_TXM[33]

B7 DPX

A A

RF_B7_TRX_TXM[33]

RF_B7_PA_DPX[32]

5

电阻_0R_0201_1/20W_J

12

C3371

C0201_NC

电容_8.2pF_0201_C0G_50V_B

12

C3322

C0201_NC

R3341

C3306

叠层电感_4.3nH_0201_220mA_S

RFLPF1608060E0T

RF_PCS_PRX_SAW_IN RF_PCS_PRX_SAW_OUT

1

3

IN

RF_B7_TRX_DPX

3

TX

2

GND-4

2

OUT

GND

U3307

6

SAYEY2G53BA0F0A

ANT

GND-24GND-3

GND-57GND-1

5

8

RX

12

C3373

C0201_NC

L3310

RF_B7_PRX_DPX_RFIP1

1

电阻_0R_0201_1/20W_J

12

C3398

C0201_NC

12

C3326

C0201_NC

R3345

R3311

电阻_0R_0201_1/20W_J

12

C3399

C0201_NC

12

C3301

电容_33pF_0201_C0G_50V_J

C3324

电容_33pF_0201_C0G_50V_J

C3327

C0201_NC

4

RF_DCS/PCS_PRX_RFIC [31]

RF_B7_PRX_RFIC [31]

B28A DPX

B28B DPX

3

RF_B28A_TRX_TXM[33]

RF_B28A_PA_DPX[32]

RF_B28B_TRX_TXM[33]

RF_B28B_PA_DPX[32]

C3345

电容_8.2pF_0201_C0G_50V_B

L3346

叠层电感_4.3nH_0201_220mA_S

R3308

电阻_0R_0201_1/20W_J

12

C3346

C0201_NC

L3322

叠层电感_4.3nH_0201_220mA_S

L3325

叠层电感_4.3nH_0201_220mA_S

RF_B28A_TRX_DPX

U3328
SAYEY718MBC0F0A

3

RF_B28B_TRX_DPX

2

6

1

ANT

RX

TX

GND-4

GND-24GND-3

GND-57GND-1

2

5

8

U3329

6

SAYEY733MBC0F0A

3

ANT

RX

TX

GND-4

GND-24GND-3

GND-57GND-1

2

5

8

R3303

RF_B28A_PRX_DPX_RFIP1

电容_33pF_0201_C0G_50V_J

12

C3341

C3314

C0201_NC

C0201_NC

C3315

RF_B28B_PRX_DPX_RFIP1

1

电容_33pF_0201_C0G_50V_J

12

C3313

C0201_NC

OPPO

OPPO

OPPO

Title

Title

Title

33_RF_MT6177_RF_PRX

33_RF_MT6177_RF_PRX

33_RF_MT6177_RF_PRX

Size Project Rev

Size Project Rev

Size Project Rev

E

E

E

Date: Sheet of

Date: Sheet of

Date: Sheet of

C0201_NC

12

电容_33pF_0201_C0G_50V_J

12

C3342

R3313

电阻_0R_0201_1/20W_J

C3340

A5S_MB_V1

A5S_MB_V1

A5S_MB_V1

RF_B28A_PRX_RFIC [31]

RF_B28B_PRX_RFIC [31]

33 35Friday, December 28, 2018

33 35Friday, December 28, 2018

33 35Friday, December 28, 2018

1

V1

V1

V1

5

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

ANT3400
818010089

112

ANT3403
818010089

112

2

12

D3402

LESD11LH5.0CT5G

2

12

D3403

LESD11LH5.0CT5G

C3403

电容_100pF_0201_C0G_50V_J

L3400

叠层电感_39nH_0201_80mA_J

L3433

L0201_NC

1 2

1 2

L3430

L0201_NC

电容_100pF_0201_C0G_50V_J

A1

B1

C1

电容_100pF_0201_C0G_50V_J

C3426

电容_100pF_0201_C0G_50V_J

BPI_BUS6

[12]

A1

B1

C1

C3423

C3424

BPI_BUS7

[12]

U3400

A2

RF1117

A3

NC

RF1

RF2

B3

GND-1

GND-2

C3

CTL

VBAT

EN

C2

12

C3410

C3472

C0201_NC

LTE_VFE28

DIV_ANT

D D

C C

B28 DRX

U3428

RF_B28_DRX_ASM[34]

L3424

叠层电感_2.2nH_0201_290mA_S

C3461

电容_1pF_0201_C0G_50V_C

RF_B28_DRX_SAW

SAFFB780MAA0F0A

1

INPUT

4

OUTPUT

GND-12GND-2

GND-3

3

5

电阻_0R_0201_1/20W_J

R3403

RF1

GND-1

CTL

电容_100pF_0201_C0G_50V_J

R3405

BPI_BUS14

R3402

电阻_0R_0201_1/20W_J

C3404

电容_100pF_0201_C0G_50V_J

[32,33,34]

RF_B28_DRX_SAW_RFIP2

4

4

J3400

GND-1

1

IN2OUT

GND-2

L3432

3

L0201_NC

电容_100pF_0201_C0G_50V_J

C0201_NC

[32,33,34]

LTE_VFE28 [32,33,34]

电阻_0R_0201_1/20W_J

12

C3462

C0201_NC

1 2

LTE_VFE28 [32,33,34]

C3425

R3411

C3460

电容_33pF_0201_C0G_50V_J

12

C3464

C0201_NC

U3410

A2

RF1117

A3

NC

RF2

B3

GND-2

C3

VBAT

EN

C2

电阻_0R_0201_1/20W_J

12

C3471

[12]

LTE_VFE28

RF_Ant_DRX_carkit

12

NC

LESD11LH5.0CT5G

RF_B28_DRX_RFIC [31]

R3401

1 2

L3408

L0201_NC

DIV_ANT_DPDT_OUT [33]

电阻_0R_0201_1/20W_J

D3401

3

DRX Switch

DIV_ANT_DPDT_IN[33]

B1/B3 DRX

B5 DRX

RF_B5_DRX_ASM[34]

C3454

电容_18pF_0201_C0G_50V_J

RF_B7_DRX_ASM[34]

RF_B40_DRX_ASM[34]

RF_B38B41_DRX_ASM[34]

RF_B1B3_DRX_ASM[34]

C3414

电容_100pF_0201_C0G_50V_J

12

C3415

C0201_NC

RF_B1B3_DRX_ASM[34]

叠层电感_4.7nH_0201_220mA_B

L3423

L3412

叠层电感_2.2nH_0201_290mA_S

U3405
SAFFB881MAN0F0A

RF_B5_DRX_SAW RF_B5_DRX_LNA_OUTRF_B5_DRX_LNA_IN

1

IN

GND-12GND-2

GND-3

3

5

50ohm

RF_B20_DRX_ASM[34]

RF_B8_DRX_ASM[34]

RF_B5_DRX_ASM[34]

RF_B28_DRX_ASM[34]

OUT

C0201_NC

DIV_L/MB_1

4

C3473

C3405

电容_1pF_0201_C0G_50V_C

电阻_0R_0201_1/20W_J

12

50ohm

50ohm

50ohm

RF_B1B3_DRX_SAW

R3430

R3431

电阻_0R_0201_1/20W_J

2

50ohm

50ohm

U3409

8

11

VC1618

RF29RF410RF6

N/C-4

12

RF8

7

13

ANT

14

RF7

15

GND

U3413
SAWFD1G84AA0F0A

1

UNBALANCEDPORTL/HCH

5

RF51RF32RF13VDD

GND12GND23GND34GND4

RF_IN

5

4

GND57GND6

GND7

8

10

GND

V1

6

V2

5

V3

电容_100nF_0201_X5R_10V_K

9

LCH

6

HCH

2

6

U3425

VCC

47090086+NXP

ENABLE

GND_RF

1

4

C3402

电容_100nF_0201_X5R_10V_K

C3416

电容_100nF_0201_X5R_10V_K

RF_B3_DRX_SAW_RFIP2

C3450

C0201_NC

RF_B1_DRX_SAW_RFIP2

C3419

C0201_NC

C3474

C0201_NC

3

RF_OUT

C3413

LTE_VFE28 [32,33,34]

12

12

12

电阻_0R_0201_1/20W_J

电阻_0R_0201_1/20W_J

C3412

电容_100nF_0201_X5R_10V_K

R3408

电阻_0R_0201_1/20W_J

R3415

电阻_0R_0201_1/20W_J

R3432

R3433

C3451

C0201_NC

C3420

C0201_NC

BPI_BUS4 [12]

LTE_VFE28 [32,33,34]

电容_33pF_0201_C0G_50V_J

12

电容_33pF_0201_C0G_50V_J

12

C3444

C3418

12

C3458

C0201_NC

BPI_BUS0 [12]

BPI_BUS1 [12]

BPI_BUS2 [12]

R3410

电阻_0R_0201_1/20W_J

RF_B3_DRX_RFIC [31]

RF_B1_DRX_RFIC [31]

12

C3455

电容_33pF_0201_C0G_50V_J

C3459

C0201_NC

1

RF_B5_DRX_RFIC [31]

BPI_BUS3 [12]

B8 DRX

U3408

L3429

L0201_NC

1 2

SAFFB942MAN0F0A

1

INPUT

OUTPUT

GND32GND2

GND1

3

5

C3406

电容_18pF_0201_C0G_50V_J

C0201_NC

4

C3476

电阻_0R_0201_1/20W_J

12

L3414

叠层电感_4.7nH_0201_220mA_B

R3434

R3435

电阻_0R_0201_1/20W_J

RF_B40_DRX_SAW

B B

B20 DRX

RF_B20_DRX_ASM[34]

C3452

电容_18pF_0201_C0G_50V_J

叠层电感_4.7nH_0201_220mA_B

U3420
SAFFB806MAA0F0A

RF_B20_DRX_SAW

1

UNBALANCE_PORT-2

L3420

UNBALANCE_PORT-1

GND-3

5

RF_B20_DRX_SAW_RFIP2

4

GND-12GND-2

3

12

C3456

C0201_NC

电阻_0R_0201_1/20W_J

C3453

R3409

12

C3457

C0201_NC

电容_33pF_0201_C0G_50V_J

RF_B20_DRX_RFIC [31]

RF_B8_DRX_ASM[34] RF_B8_DRX_RFIC [31]

B40 DRX

C3470

电容_1pF_0201_C0G_50V_C

RF_B40_DRX_ASM[34]

B7 DRX

RF_B7_DRX_ASM[34]

3

5

U3438
SAFFB2G60AA0F0A

GND-12GND-2

A A

B38/B41 DRX

L3426

叠层电感_1.5nH_0201_500mA_J

5

RF_B38B41_DRX_SAW

L3427

叠层电感_15nH_0201_160mA_J

GND-3

UNBALANCE_PORT-2

UNBALANCE_PORT-1

1

4

RF_B38B41_DRX_SAW_RFIP2

电阻_0R_0201_1/20W_J

12

C3465

C0201_NC

C3463

R3414

电容_33pF_0201_C0G_50V_J

12

C3466

C0201_NC

4

RF_B38B41_DRX_RFIC [31]RF_B38B41_DRX_ASM[34]

3

C3429

电容_18pF_0201_C0G_50V_J

RF_B7_DRX_SAW

L3411

叠层电感_4.7nH_0201_220mA_B

2

U3440

1

UNBALANCE_PORT-2

2

GND-1

5

GND-3

SAFFB2G35AA0F0A

5

RF_IN

UNBALANCE_PORT-1

3

5

GND-3

UNBALANCE_PORT-2

1

GND-12GND-2

UNBALANCE_PORT-1

4

2

6

VCC

ENABLE

GND

GND_RF

1

4

GND-2

U3407
SAFFB2G65AA0F0A

RF_B7_DRX_SAW_RFIP2

U3430

47090086+NXP

3

4

C0201_NC

RF_B8_DRX_LNA_OUTRF_B8_DRX_LNA_INRF_B8_DRX_SAW

3

RF_OUT

RF_B40_DRX_SAW_RFIP2

LTE_VFE28 [32,33,34]

12

12

C3477

C3478

C0201_NC

R3436

电阻_0R_0201_1/20W_J

电阻_0R_0201_1/20W_J

R3416

电阻_0R_0201_1/20W_J

12

R3417

C0201_NC

R3418

电阻_0R_0201_1/20W_J

12

R3419

C0201_NC

OPPO

OPPO

OPPO

Title

Title

Title

34_RF_MT6177_RF_DRX

34_RF_MT6177_RF_DRX

34_RF_MT6177_RF_DRX

Size Project Rev

Size Project Rev

Size Project Rev

E

E

E

Date: Sheet of

Date: Sheet of

Date: Sheet of

电阻_0R_0201_1/20W_J

12

R3424

C0201_NC

R3437

电容_33pF_0201_C0G_50V_J

12

C3421

C0201_NC

C3468

电容_33pF_0201_C0G_50V_J

12

C3490

C0201_NC

A5S_MB_V1

A5S_MB_V1

A5S_MB_V1

R3423

C3422

50 ohm

电容_33pF_0201_C0G_50V_J

12

C3489

C0201_NC

RF_B40_DRX_RFIC [31]

RF_B7_DRX_RFIC [31]

C3417

50 ohm

34 35Friday, December 28, 2018

34 35Friday, December 28, 2018

1

34 35Friday, December 28, 2018

V1

V1

V1

ANT3501

Edited by Foxit Reader ActiveX For Evaluation Only.

Copyright(C) 2006-2009 Foxit Corporation

81800411

1

ANT3503
818010089

ANT3502
818010089

112

2

112

2

5

WIFI_ANT

2

4

3

2

1

D D

R3514

电阻_0R_0201_1/20W_J

C3529

C0201_NC

12

C0201_NC

C3528

12

C C

B B

3

J3500

GND-2

IN2OUT

GND-1

4

C3512

电容_18pF_0201_C0G_50V_J

1

12

D3503

LESD11LH5.0CT5G

12

R3538

C0201_NC

12

C3506

C0201_NC

GPS IN

Close to ANT

50 Ohm

1

电阻_0R_0201_1/20W_J

R3502

U3503
SAFFB1G56KB0F0A

INPUT

OUTPUT

GND32GND2

GND1

3

5

1

3

50 Ohm

2

GND-3

GND-2

ANT_IN

12

C3507

C0201_NC

matching value depends on
LNA selected

C3519

4

电容_18pF_0201_C0G_50V_J

叠层电感_5.6nH_0201_200mA_S

12

C3520
C0201_NC

GPIO_GPS_LNA_EN[13]

U3510

5

MDPX18M1524P69-D03

6

H_P

GND-1

4

L_P

L3501

电阻_0R_0201_1/20W_J

FM_LANT_P[17]

GPS xLNA

2

GND11GND2

3

RFIN

RFOUT

VCC4EN

U3504

5

C3530

12

C0201_NC

R3508

R3533

电阻_0R_0201_1/20W_J

12

C3576

C0201_NC

FM_LANT_N[17]

AW5005

6

L3502

叠层电感_56nH_0201_80mA_J

C3524

电容_10nF_0201_X7R_16V_K

50 Ohm

12

C3577

C0201_NC

叠层电感_82nH_0201_50mA_J

12

C3514

C0201_NC

GPS_ANT

VCN28_PMU [21,35]

L3500

R3504

电阻_0R_0201_1/20W_J

12

C3516

C0201_NC

4

U3500
B8852

12

12

OUTPUT

C3515

C0201_NC

BYPASS

C3517

C0201_NC

AVDD18_WBT[35]

INPUT

GND12GND2

GND3

3

5

电阻_0R_0201_1/20W_J

C3504

电容_1pF_0201_C0G_50V_C

电容_4.7uF_0402_X5R_6.3V_M

Close to MT6631

FM_AVDD28[35]

50 Ohm

AVDD33_WBT[35]

C3510

C3509

电容_100pF_0201_C0G_50V_J

C3513

电容_10nF_0201_X7R_16V_K

GPS_RFIN

AVDD18_GPS[35]

12

C3505

C0201_NC

31

WB_RF_2G

32

N/C2

33

AVDD33_WBT

34

WF_RF_5G

35

WF_AUX_5G

36

AVDD28_FM

37

FM_LANT_N

38

FM_LANT_P

39

GPS_RFIN

40

AVDD18_GPS

41

C3518

GND

电容_4.7nF_0201_X7R_10v_K

CONN_HRST_B[13]

CONN_TOP_DATA[13]

CONN_TOP_CLK[13]

CONN_WB_PTA[13]

WB_ANT

50 Ohm

R3501

1

C3500

C3501

电容_100pF_0201_C0G_50V_J

电容_100nF_0201_X5R_6.3V_K

24

25

27

29

30

WF_AUX_2G

WF_VDET_5G28WF_VDET_2G

BT_DATA

AVDD18_WBT126AVDD18_WBT2

Note: 51-3

MT6631N

Note: 51-4

AVDD28_FSOURCE1HRST_B2TOP_DATA3TOP_CLK4WB_PTA5CEXT6N/C17XO_IN8GPS_QN9GPS_QP

CONN_TOP_CLK

PMIC_CLK_WCN[22]

R3509

电阻_0R_0201_1/20W_J

C3521

C3522

电容_1uF_0201_X5R_6.3V_M

BT_CLK

电容_100pF_0201_C0G_50V_J

23

R3507

电阻_0R_0201_1/20W_J

CONN_XO_IN_BB [13]

BT_DATA

BT_CLK

WF_CTRL0

WF_CTRL1

U3502

MT6631N/A

WF_HB221WF_HB122WF_HB0

20

WF_IP

19

WF_IN

18

WF_QP

17

WF_QN

16

BT_IP

15

BT_IN

14

BT_QP

13

BT_QN

12

GPS_IP

11

GPS_IN

10

BT_DATA [13]

BT_CLK [13]

WF_CTRL0 [13]

WF_CTRL1 [13]

WF_CTRL2 [13]

WF_IP

WF_IP [13]

WF_IN

WF_IN [13]

WF_QP

WF_QP [13]

WF_QN

WF_QN [13]

BT_IP

BT_IP [13]

BT_IN

BT_IN [13]

BT_QP

BT_QP [13]

BT_QN

BT_QN [13]

GPS_I

GPS_I [13]

GPS_Q

GPS_Q [13]

WCN Power Supply

Schematic design notice of "51_CONNECTIVITY_CONSYS_MT6631"

For R5015 size, please select 0402 size or larger one

Note 51-1:

Please refer to MT6765 Baseband design notice for VCN33 LDO selection guide

Note 51-2:

If WiFi 5G not support, connect pin 34(WF_RF_5G) to GND

Note 51-3:

Pin 36 (AVDD28_FM) must be connected to VCN28 even if FM not support

Note 51-4:

A A

5

4

AVDD33_WBT[35]

FM_AVDD28[35] VCN28_PMU [21,35]

AVDD18_GPS[35] VCN18_PMU [21]

AVDD18_WBT[35]

R3510

0R

B3500

1 2

磁珠_1000R/100MHz_0402

R3511

电阻_0R_0201_1/20W_J

R3512

电阻_0R_0201_1/20W_J

12mil

电阻0R(0402-0.0625W-J)

C3526

电容_10nF_0201_X7R_16V_K

12mil

12mil

3

VCN33_PMU [21]

C3536

电容_1uF_0201_X5R_6.3V_M

OPPO

OPPO

OPPO

Title

Title

Title

Size Project Rev

Size Project Rev

Size Project Rev

Date: Sheet of

Date: Sheet of

Date: Sheet of

2

35_CONNECTIVITY_CONSYS_MT6631

35_CONNECTIVITY_CONSYS_MT6631

35_CONNECTIVITY_CONSYS_MT6631

A5S_MB_V1

A5S_MB_V1

D

D

D

Friday, December 28, 2018

Friday, December 28, 2018

Friday, December 28, 2018

A5S_MB_V1

35 35

35 35

35 35

1

V1

V1

V1
