The Portable Wireless Bluetooth Speaker
Quick Start Guide
TheOontZ.com
Designed and Engineered By
Table of Contents
In the Package
Buttons
Lights
Connectors
Play Horizontally or Vertically
Battery Features
Charging the Battery
Turning On and Off
Pair & Connect - Step 1
Pair & Connect - Step 2 --
-- From Your iPhone, iPad, iPod, Smartphone, Tablet and Mobile Devices
-- From Your Apple Mac or Windows Laptop/Computer
-- From Your Amazon Echo Dot or Amazon Echo
Playing From Non-Bluetooth Audio Source Devices Using the 3.5mm Audio Cable
OontZ Wireless Dual Stereo
IPX6 Water Resistant
Wireless Hands Free Personal Speakerphone
Troubleshooting & Customer Support
Safety and Precautions
Pages
1
2
3
4
5
6
7-8
9
10
11
11
12 - 13
14
15 - 19
20
21
22
23 - 24
In the Package
The
The Portable Wireless Bluetooth Speaker
Quick Start Guide
TheOontZ.com
Designed and Engineered By
Quick Start Guide
Extra Long 6 foot Micro USB Charging Cable
3 foot 3.5mm Audio Cable
Note: The Micro USB Charging Cable and the 3.5mm Audio
Cable are packed below the cardboard insert in the box.
Slide out the cardboard insert to locate the cables.
Page 1
Buttons
Bluetooth (Dual Function)
Track Back Track Forward
Press and Release to play
previous track
Volume Down
Press to decrease volume
Power
Note: The track back feature is application-dependent. Some apps may not support track back, track forward, or play/pause
Play/Pause
Press and Release to Pause/Play
Press and Release to play next track
Volume Up
Press to increase volume
Page 2
Lights
Blue Light lit when speaker is on:
- Flashing Blue
speaker is in pairing mode
- Solid Blue
speaker is connected
- Blue Light will turn to Solid Green
when the 3.5mm audio cable is
plugged into the AUX IN Jack
Red Light lit when charging:
- Slowly flashing Red
battery is charging
- Solid Red
battery is fully charged
OontZ Wireless Dual Stereo Light:
- With a second OontZ Angle 3 ULTRA
speaker (sold separately) you can
wirelessly connect both speakers
together to play with incredible stereo
separation or playing full stereo in
separate areas.
- For more details please see page 15.
Page 3
Connectors
Built-in Mic for
Speakerphone
AUX IN Jack
Micro USB
Charging Connector
Rubber Flap
- covers connectors
- pull gently from the top to access
connectors, it is a snug fit to provide
water resistance
Note: The rubber flap needs to be closed
to keep the speaker water resistant
Page 4
Play Horizontally or Vertically
Play Horizontally
Controls on side
Play Vertically
Controls on top
Dual Precision Stereo Drivers
Passive Bass Radiator
– Has its own grille
– Faces away from Dual Precision
Stereo Drivers
– Rich bass does not interfere
with Mids and Highs
Page 5
Battery Features
- The rechargeable battery comes
with a partial charge and the
speaker is ready to play.
- For maximum playtime, fully
charge the battery.
- You can play while charging.
Low Charge Remaining
- When the battery charge has less
than 15% remaining the Red Light will
begin flashing rapidly.
- The volume will decrease to preserve
the remaining battery charge.
Power Saving Feature
- When playing from battery power the
OontZ Angle 3 ULTRA will turn off after
30 minutes of not playing audio to
conserve the battery charge. *
- When plugged into a charging source
the OontZ Angle 3 ULTRA will remain on
until you turn the power off.
- You can continue to keep the speaker
plugged into a charging source even
when it is fully charged.
*Exception: when connected to an Amazon Echo Dot or Amazon Echo, the power saving feature is disabled and the speaker will remain on.
Page 6
Charging the Battery
Red Light lit
when charging:
- Slowly flashing Red
battery is charging
- Solid Red
battery is fully charged
- Insert the small end of the Micro USB
Charging Cable into the Micro USB
Charging Connector as shown.
- Insert the large end of the Micro USB
Charging cable into either a USB wall charger
for a Smartphone or iPhone, or a USB port
on your laptop/computer to charge the
battery (see illustrations on page 8).
Charging Time:
- Up to 7 hours to fully charge a low battery.
Page 7
Charging the Battery (continued)
Insert the large end of the Micro USB charging cable into either a USB wall charger for a Smartphone or iPhone
(a USB wall charger that is 5V 1.0A up to 5V 2.4A maximum) or a USB port on your laptop/computer to charge the
OontZ Angle 3 ULTRA rechargeable battery.
Page 8
Turning On and Off
Turn ON
Press and Release
the Power Button
Red Light will turn
on for 3 seconds
Blue Light will turn on
after Red Light turns off
- Flashing Blue
The speaker is in pairing mode
- Solid Blue
The speaker is connected to a source
device and ready to play
Turn OFF
Press and Hold Down the Power Button
for 2 Seconds
Blue Light will turn off
Page 9
Pair & Connect -- Step 1
- Make sure your OontZ Angle 3 ULTRA battery has a sufficient charge, it is not able to connect when the charge is too low.
- Your device needs to be within 66 unobstructed feet of the OontZ Angle 3 ULTRA to pair and connect.
Turn ON your OontZ Angle 3 ULTRA
Flashing Blue Light
- The OontZ Angle 3 ULTRA is ready to pair and connect.
Solid Blue Light
- The OontZ Angle 3 ULTRA has automatically reconnected to the last device it was
connected to and is ready to play.
- The OontZ Angle 3 ULTRA will automatically try to connect to the last device it was connected
to each time it is turned on and that device is within range.*
The OontZ Angle 3 ULTRA can be connected to one device at a time.
- To pair and connect to a different device, you need to first disconnect the currently paired device.
- To disconnect the current device, press and hold down the Bluetooth button for 3 seconds.
- The Blue Light will begin flashing and the OontZ Angle 3 ULTRA is ready to pair and connect to your device.
*Exception: Amazon Echo Dot or Amazon Echo will not automatically reconnect, you will need to say "Alexa, connect my speaker"
Page 10
Pair & Connect -- Step 2 --
-- From Your iPhone, iPad, or iPod -- From Your Smartphone, Tablet & Mobile Devices
- Go to Settings > Bluetooth, check Bluetooth is on
- Select 'OontZ Angle 3 Uxxx' when it appears under DEVICES
(xxx: 3 characters which are unique to your speaker)
- The speaker will connect in a few seconds
- The Blue Light will turn solid blue and there will be
a quiet chime
- You can now play your audio wirelessly to your
OontZ Angle 3 ULTRA
Important: Make sure the volume level is set high on your audio source device. The volume on the OontZ Angle 3 ULTRA and
your audio source device both need to be set to the highest level for the loudest volume. The volume controls on your audio
source device and the speaker work independently of each other.
-- From Your Apple Mac or Windows Laptop/Computer
For the pairing and connecting guide for your Apple Mac or Windows laptop/computer, please visit: TheOontZ.com/pairing
- Go to Settings > Bluetooth, check Bluetooth is on
- Scan or Search and select 'OontZ Angle 3 Uxxx' when it appears
under AVAILABLE DEVICES (xxx: 3 characters which are unique to
your speaker)
- The speaker will connect in a few seconds
- The Blue Light will turn solid blue and there will be a quiet chime
- You can now play your audio wirelessly to your OontZ Angle 3 ULTRA
Note: Your Smartphone or Tablet instructions may vary
Page 11
Pair & Connect -- Step 2 --
-- From Your Amazon Echo Dot or Amazon Echo
To pair and connect the first time from the Amazon Echo Dot/Echo use the Alexa app on your device.
- Open the Alexa app
- Go to the 'Home' menu by pressing the 3 horizontal lines in the upper left corner next to 'Home'
- Press 'Settings'
- Select your Amazon Echo Dot/Echo under 'Devices' by pressing it
- Press 'Bluetooth'
- Select the 'OontZ Angle 3 Uxxx' (xxx: 3 characters unique to your speaker) when it appears in the list of 'Available Speakers'
- Alexa will announce: "Connected to OontZ Angle 3 Uxxx"
To connect the next time, turn on the OontZ Angle 3 ULTRA and say "Alexa, connect my speaker" or "Alexa, pair"
Page 12
Pair & Connect -- Step 2 --
-- From Your Amazon Echo Dot or Amazon Echo (continued)
Important Note: When the OontZ Angle 3 ULTRA is playing from battery power and connected to the Amazon Echo
Dot/Echo, the speaker will remain on and it will not automatically turn off after 30 minutes of not playing audio.
This will use up the battery charge.
We recommend to:
1) Keep the OontZ Angle 3 ULTRA plugged into a USB wall charger. It can remain on and available to play from the Amazon
Echo Dot/Echo, without using up the battery charge.
- Or -
2) Turn off the OontZ Angle 3 ULTRA when you are done listening.
- Either turn off the speaker by pressing and holding down the power button for 2 seconds,
- or say "Alexa, disconnect my speaker" and the OontZ Angle 3 ULTRA will automatically turn off after 30 minutes.
- When you want to connect and play to the speaker again turn on the OontZ Angle 3 ULTRA and say "Alexa, connect my
speaker" or "Alexa, pair".
For assistance with the Alexa app, contact Amazon's Customer Service.
Open the Alexa app and select Help & Feedback > Email Customer Service
Page 13
Playing From Non-Bluetooth Audio Source Devices
Using the 3.5mm Audio Cable
- Make sure your OontZ Angle 3 ULTRA
battery has a sufficient charge
Turn ON your OontZ Angle 3 ULTRA
- Plug one end of the included 3.5mm audio
cable into the AUX IN Jack on the back of
your speaker.
- The Blue Light will turn solid Green
- Plug the other end of the cable into the
headphone jack on your audio device.
- You are now ready to play.
Note: The Bluetooth on the OontZ Angle 3 ULTRA is disabled when the 3.5mm audio cable is connected to the speaker.
Remove the cable from the speaker to enable Bluetooth.
Page 14
OontZ Wireless Dual Stereo -
Connect two OontZ Angle 3 ULTRA speakers together
Play your music wirelessly through both speakers up to 100 feet apart
Bluetooth
for playing music
or
Audio Cable
for playing the
audio from a video
Bluetooth
for playing music
or
Audio Cable
for playing the
audio from a video
speakers will significantly reduce the distance apart the two speakers can play together
Left Channel Right Channel
Full Stereo Full Stereo
*Placing the speakers on the ground or having walls or obstructions between the
Left Channel - Right Channel
for stereo separation
Dual Stereo
for full stereo in separate areas
*
Page 15
Connecting two OontZ Angle 3 ULTRA Speakers together for Left Channel - Right Channel
– Turn on both OontZ Angle 3 ULTRA speakers.
– Pair and Connect one of the speakers with your device. When connected the Blue Light will be lit solid.
This speaker will serve as the Play Control Speaker.
– The second speaker must not be connected to any device, its Blue Light needs to be flashing. If the second speaker
has a solid Blue Light it is connected to a device and you need to disconnect it, by pressing and holding down the
Bluetooth button for 3 seconds until the Blue Light begins flashing.
- On the Play Control Speaker (speaker with solid Blue Light) press and hold down the Play/Pause button
for 5 seconds until the flashing White Light appears and the speaker says “Dual Pairing”.
- After a few seconds the Play Control Speaker will say “Left Channel” and the second speaker will say “Right Channel”
and the speakers will be connected together for Left Channel - Right Channel and you are ready to play.
Page 16
Two OontZ Angle 3 ULTRA Speakers connected for Left Channel - Right Channel
Blue Light lit solid
White Light lit solid
Blue Light OFF
White Light lit solid
Play Control Speaker
– Use the buttons on the Play Control Speaker for play/pause, track back, track forward, answer and end
phone calls. These controls are disabled on the second speaker when paired together.
– Use the Play Control Speaker for connecting to different audio devices via Bluetooth or AUX IN. The
Bluetooth and AUX IN are disabled on the second speaker when paired together.
– Speakerphone call audio will only play through the Play Control Speaker
Second Speaker
Page 17
Changing to Dual Stereo from Left Channel - Right Channel
Use Dual Stereo when placing the two speakers in different areas, and both speakers will play in full stereo.
– To set both speakers for Dual Stereo they must first be connected together for Left Channel - Right Channel (see page 15).
– With the speakers connected together for Left Channel - Right Channel, you can change the speakers to Dual Stereo.
–
To change to Dual Stereo, press and hold down the Track Forward button on the Play Control Speaker for 5 seconds until the
White Lights turn solid Orange on both speakers.
–
Both speakers will say “Dual Stereo” and you are ready to play.
Changing back to Left Channel - Right Channel from Dual Stereo
- To change back to Left Channel - Right Channel, press and hold down the Track Forward button on the Play Control Speaker
for 5 seconds until the Orange Lights turn solid White on both speakers.
Play Control Speaker will say “Left Channel” and the second speaker will say “Right Channel” and you are ready to play.
- The
Page 18
OontZ Wireless Dual Stereo - Important Notes
Turning the speakers off
– Turning the Play Control Speaker off will turn both speakers off.
– Turning the second speaker off first will only turn that speaker off and the Play Control Speaker will play as a single speaker.
Turning the speakers back on
– Turn both speakers on and they will automatically try to connect to each other again.
– Turn one of the speakers on and a device can connect with it, and play as a single speaker.
Disconnecting the two speakers from each other
– Both speakers need to be turned on.
– On the Play Control Speaker press and hold down the Play/Pause button for 5 seconds.
The White Lights will turn off and the speakers will be disconnected from each other.
Playing the audio from a video in OontZ Wireless Dual Stereo
–To play the audio from a video or TV in OontZ Wireless Dual Stereo you will need to connect the Play Control Speaker to your
device or TV using the 3.5mm audio cable, allowing the audio and video to play in sync with each other. If the Play Control
Speaker is connected over Bluetooth to your device or TV there will be a delay in the audio playback from a video.
Page 19
IPX6 Water Resistant
No more worries about the
rain or getting splashed
Listen to music in the shower
Perfect for taking to the beach
or by the pool
The rubber flap needs to be
closed to keep the speaker
water resistant and dustproof
Gentle Water Spray
or Splash is okay
Safety Precaution: When the OontZ Angle 3 ULTRA speaker is plugged in to a charging source with the Micro USB
charging cable, never use the speaker in the shower, bath, or near water, to prevent risk of electric shock.
IPX6 rating - The OontZ Angle 3 ULTRA can resist water spray & splash but cannot be partially or fully submerged or left in a wet environment for an
extended period of time, any of which could cause unrepairable damage to the speaker.
When charging or using the 3.5mm audio cable, please keep the speaker away from water as it can be damaged by water entering the connectors.
DO NOT allow speaker
to sit in water
DO NOT allow speaker
to submerge fully or
partially in water
Page 20
Wireless Hands Free Personal Speakerphone
The Wireless Hands Free Personal Speakerphone feature works over Bluetooth
with Smartphones and iPhones only; this feature is not supported when connected
to other types of devices.
To answer an Incoming Call / To End a Call
- Press and Release the Bluetooth Button
To Reject an Incoming Call
- Press and Hold Down the Bluetooth Button for 2 Seconds
- Please keep the speaker close in front of you so you may be heard clearly by the listener.
- You can use your Smartphone or iPhone to switch between using Hands Free Speakerphone
and your phone.
- When two speakers are paired together in OontZ Wireless Dual Stereo, calls will come through the Play Control
Speaker only. Use the Bluetooth button on the Play Control Speaker for the speakerphone functions.
For more information on OontZ Wireless Dual Stereo please see page 15.
Page 21
Troubleshooting
For issues with your OontZ Angle 3 ULTRA, please view our troubleshooting tips at:
TheOontZ.com/troubleshooting
and select the OontZ Angle 3 ULTRA
Customer Support
If you have any issues with your OontZ Angle 3 ULTRA, our Customer Support Team wants to assist you.
Please contact us at:
TheOontZ.com/support
and fill in our customer support form.
Page 22
Safety and Precautions
When the OontZ Angle 3 ULTRA speaker is plugged in to a charging source with the Micro USB charging cable, never
1.
use the speaker in the shower, bath, or near water, to prevent risk of electric shock.
Read and follow all instructions – All operating and use instructions should be followed.
2.
Protect the Micro USB charging cable from being pinched, particularly at the connectors.
3.
Unplug the Micro USB charging cable during lightning storms or when unused for long periods of time.
4.
Do not place speaker near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
5.
amplifiers) that produce heat.
Refer all servicing to qualified personnel. Servicing is required when the speaker has been damaged in any way.
6.
Do NOT make unauthorized alterations to this speaker.
7.
Use this speaker only with an agency approved power supply which meets local regulatory requirements (e.g., UL, CSA, VDE,
8.
CCC) in accordance with the manufacturer’s specifications.
Do NOT place naked flame sources, such as lighted candles, on or near the speaker.
9.
Do not expose products containing batteries to excessive heat (e.g. from storage in direct sunlight, fire or the like)
10.
If the battery leaks, do not allow the liquid to come in contact with the skin or eyes. If contact is made, seek medical advice.
11.
Apple, iPhone, iPad, iPod, and Mac are registered trademarks of Apple Inc.
Amazon, Alexa, Amazon Echo and Amazon Echo Dot are registered trademarks of Amazon.com, Inc.
Windows is a registered trademark of Microsoft Corporation
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Page 23
Safety and Precautions (continued)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes to this device not expressly approved by SoundWorks, INC may void the user’s authority to operate this device.
Page 24
OontZ Angle 3 ULTRA Carry Case
Sold separately
• Lightweight neoprene rubber with reinforced zipper
• Includes a durable aluminum carabiner for easily
attaching to backpacks, luggage, laptop bags,
coolers, camera bags, purses, belts, and other
clippable items
Available at TheOontZ.com:
TheOontZ.com/angle3ultra-carry-case
OontZ Wireless Dual Stereo
With a second OontZ Angle 3 ULTRA speaker
you can wirelessly connect both speakers together.
Incredible Stereo Separation
Left Channel Right Channel
Full Stereo Full Stereo
or purchase a second OontZ Angle 3 ULTRA, sold separately at TheOontZ.com
Up to 100 feet apart
Full Stereo in Separate Areas
Connect with a friend's OontZ Angle 3 ULTRA
Loading...
