Onkyo HT-R420, TX-SR8240, RC-518M, RC-479S Service Manual

TX-SR402/8240/HT-R420

SERVICE MANUAL

AV RECEIVER

MODEL

TX-SR402 TX-SR8240 HT-R420

Ref. No. 3796

032004

TX-SR402

Silver and Golden models

220-230V AC, 50/60HzSMGR,GMGR

HT-R420 Black and Silver models

120V AC, 60HzBMDC,BMDD,SMDC,SMDD 230-240V AC, 50HzBMPA,SMPA,SMPT 120V/220-230V AC, 50HzSMWT

TX-SR8240 Golden models

220-230V AC, 50/60HzGMGR

RC-518M

(Noth American model)

RC-479S

(Other models)

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL. MAKE LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE APPLIANCE TO THE CUSTOMER.

TX-SR402/8240/HT-R420

SPECIFICATIONS-1

TX-SR402/TX-SR8240

Audio Outputs

Analog Outputs: TAPE, VIDEO1 Subwoofer Pre Outputs: 1 Speaker Outputs: 5+2 Phones: 1

Specifications and features are subject to change without notice.

Power Supply: AC 220-230 V, 50/60 Hz Power Consumption: 300W Dimensions: 435 W x 150 H x 374 D mm 17 1/8 W x 5 7/8 H x 14 3/4 D inches Weight: 8.8 kg

18.4 lbs

Video Inputs

S-Video Compatible Jack Input: DVD, VIDEO1, VIDEO2 A/V Input: DVD, VIDEO1, VIDEO2, VIDEO3

Video Outputs

S-Video Compatible Jack Output: MONITOR, VIDEO1 A/V Output: MONITOR, VIDEO1

Audio Inputs

Digital Inputs: 1 (Optical ) , 1 (Coaxial ) Analog Inputs: DVD (MULTI CHANNEL), CD, TAPE, VIDEO1, VIDEO2, VIDEO3 Multichannel Inputs: 6

General

Power Output:

All channels: 100 W (6 , 1kHz, JEITA) Dynamic Power: 160 W + 160 W (3 , Front) 125 W + 125 W (4 , Front) 85 W + 85 W (8 , Front) THD (Total Harmonic Distortion): 0.08 % (Power Rated) Damping Factor: 60 (Front, 1kHz, 8 ) Input Sensitivity and Impedance: 200 mV/ 47 k (LINE) Output Level and Impedance: 200 mV/ 470 (REC OUT) Frequency Response: 10 Hz~100 kHz / +1 dB -3 dB (Direct mode) Tone Control: +12 dB, -12 dB, 50 Hz (BASS) +12 dB, -12 dB, 20k Hz (TREBLE) SN Ratio: 100 dB (CD, IHF-A) Speaker Impedance: 6-16

Amplifier Section

Input Sensitivity/Output Level and Impedance: 1 Vp-p /75 (Component and S-Video Y)

0.28 Vp-p /75 (Component Pb/Cb,Pr/Cr)

0.28 Vp-p /75 (S-Video C) 1 Vp-p /75 (Composite)

Video Section

FM

Tuning Frequency Range: 87.5 MHz~108.0 MHz Usable Sensitivity: Stereo 17.2 dBf 2 V (75 IHF) Mono 11.2 dBf 1 V (75 IHF) S/N Ratio: Stereo 70 dB (IHF-A) Mono 76 dB (IHF-A) THD: Stereo 0.3 % (1kHz) Mono 0.2 % (1kHz) Frequency Response: 30 Hz~15 kHz / +1 dB, -1 dB Stereo Separation: 45 dB ( 1kHz )

AM

Tuning Frequency Range: 522-1611 kHz Usable Sensitivity: 30 V S/N Ratio: 40 dB THD: 0.70%

Tuner Section

TX-SR402/8240/HT-R420

SPECIFICATIONS-2

HT-R420

Audio Outputs

Analog Outputs: TAPE, VIDEO1 Subwoofer Pre Outputs: 1 Speaker Outputs: 5+2 Phones: 1

Specifications and features are subject to change without notice.

Power Supply: American model: AC 120 V, 60 Hz Australian model: AC 230 V, 50 Hz Others model: AC 120-220/230 V, 50/60 Hz Power Consumption: American model: 4.7A Australian and Worldwide model: 300 W Dimensions: 435 W x 150 H x 374 D mm 17 1/8 W x 5 7/8 H x 14 3/4 D inches Weight: 8.8 kg

19.4 lbs

Video Outputs

S-Video Compatible Jack Output: MONITOR, VIDEO1 A/V Output: MONITOR, VIDEO1

Video Inputs

S-Video Compatible Jack Input: DVD, VIDEO1, VIDEO2 A/V Input: DVD, VIDEO1, VIDEO2, VIDEO3

Audio Inputs

Digital Inputs: 1 (Optical ) , 1 (Coaxial ) Analog Inputs: DVD (MULTI CHANNEL), CD, TAPE, VIDEO1, VIDEO2, VIDEO3 Multichannel Inputs: 6

General

Power Output:

All channels: 100 W (8 , 20Hz~20kHz, FTC) American model 100 W (8 , 1kHz, DIN) Australian model 100 W (6 , 1kHz, JEITA) Asian model Dynamic Power: 230 W + 230 W (3 , Front) 170 W + 170 W (4 , Front) 115 W + 115 W (8 , Front) THD (Total Harmonic Distortion): 0.08 % (Power Rated) Damping Factor: 60 (Front, 1kHz, 8 ) Input Sensitivity and Impedance: 200 mV/ 47 k (LINE) Output Level and Impedance: 200 mV/ 470 (REC OUT) Frequency Response: 10 Hz~100 kHz / +1 dB -3 dB (Direct mode) Tone Control: +12 dB, -12 dB, 50 Hz (BASS) +12 dB, -12 dB, 20k Hz (TREBLE) SN Ratio: 100 dB (CD, IHF-A) Speaker Impedance: 8~16

Amplifier Section

Input Sensitivity/Output Level and Impedance: 1 Vp-p /75 (Component and S-Video Y)

0.28 Vp-p /75 (Component Pb/Cb,Pr/Cr)

0.28 Vp-p /75 (S-Video C) 1 Vp-p /75 (Composite)

Video Section

FM

Tuning Frequency Range: 87.5 MHz~108.0 MHz Usable Sensitivity: Stereo 17.2 dBf 2 V (75 IHF) Mono 11.2 dBf 1 V (75 IHF) S/N Ratio: Stereo 70 dB (IHF-A) Mono 76 dB (IHF-A) THD: Stereo 0.3 % (1kHz) Mono 0.2 % (1kHz) Frequency Response: 30 Hz~15 kHz / +1 dB, -1 dB Stereo Separation: 45 dB ( 1kHz )

AM

Tuning Frequency Range: American model: 530 kHz~1710 kHz Australian model: 522 kHz~1611 kHz Others model: 530/522 kHz~1710/1611 kHz Usable Sensitivity: 30 V S/N Ratio: 40 dB THD: 0.70%

Tuner Section

TX-SR402/8240/HT-R420

SERVICE PROCEDURES-1

120V

VOLTAGE SELECTOR

220-230V

120 V

VOLTAGE

SELECTOR

220-230 V

SWITCHED 100W MAX.

AC OUTLET

1. Replacing the fuses

2. Safety-check out

(Only U.S.A. model) After correcting the original service problem perform the following safety check before releasing the set to the customer Connect the insulating-resistance tester between the plug of power supply cord and terminal GND on the back panel. Specifications: More than 10Mohm at 500V

This symbol located near the fuse indicates that the fuse used is show operating type, For continued protection against fire hazard, replace with same type fuse, For fuse rating, refer to the marking adjacent to the symbol.

Ce symbole indique que le fusible utilise est e lent. Pour une protection permanente, n'utiliser que des fusibles de meme type. Ce demier est indique la qu le present symbol est apposre.

3. To initialize the unit

This unit does not require memory preservation batteries. A built-in memory power backup system preserves the contents of memory during power failures and even when the power cord is unplugged. The power cord must be plugged in order to charge the backup system. The memory preservation period after the unit has been turned off varies depending on climate and placement of the unit. On average, memory contents are protected over a period of a few weeks after the time the unit has been turned off. This period is shorter when the unit is exposed to a very humid climate.

[NOTE]

<DD> : 120V model only <DC> : 120V model only <WT> : World wide model only <GR> : Chinese model only for 220V <PA> : Australia model only for230V <PT>

: Asian model only for 230V

This device employs a microprocessor to perform various functions and operations. If interference generated by an external power supply, radio wave, or other electrical sauce results in accident which causes the specified operations and functions to operate abnormally. To perform a result, please follow the procedure below.

1. Press and the hold down the VIDEO 1 button , then press the STANDBY/ON button when the unit is Power ON.

2. After "Clear" is displayed, the preset memory and each mode stored in the memory, are initialized and will return to the factory settings.

5. Memory Preservation

6.Setting the voltage selector (Worldwide models only)

The Worldwide model has a voltage selector for compatibility with power systems around the world. Before you plug in this model, make sure that the voltage selector is set to the correct voltage for your area. If it isn't, use a small screwdriver to set it as appropriate. For example, if the voltage in your area is 120 volts (V), set the selector to "120V. " And if it's between 220 and 230 volts (V), set it to "220-230V."

REF NO. PART NO. DESCRIPTION NOTES

F6901,F6902 F6901,F6902 F6901or,F6902or F901 F901 or F902 F902 or F902 or F903 F903 or F903 or F903 F903 or

252099 252198 252261 252198 252261 252076 252242 252276 252075 252241 252275 252164 252258

8A-EAK FUSE 8A-UL 8A-T/UL-ST2 8A-UL 8A-T/UL-ST2

3.15A-SE-EAK FUSE

3.15A-SE-TL250V

2.5A-SE-EAK FUSE

2.5A-SE-TL250V

2.5A-SE-TL250V 5A-UL/T-237 5A-T/UL-ST2

GR,WT,PA,PT DC,DD DC,DD DC,WT,DD DC,WT,DD GR,WT,PA,PT GR,WT,PA,PT GR,WT,PA,PT GR,WT,PA,PT GR,WT,PA,PT GR,WT,PA,PT DC,DD DC,DD

Main microprocessor Q7008.

1. Press and the hold down the DISPLAY button , then press the STANDBY/ON button when the unit is Power ON. Version is displayed on FL display only for 3 seconds.

2. Press the STANDBY/ON button to Power Off.

Sub microprocessor Q7502.

Check is impossible. (Unnecessary)

4. How to check version of microprocessor?

Version 30212a

ex.

TX-SR402/8240/HT-R420

SERVICE PROCEDURES-2

NCDG-7401 25137401C

002

C7003

D7001

D7002

R7001

R7002

R7003

R7004

R7011

R7012

R7015

R7016

R7017

R7018

R7019

R7020

R7120

Q7008

1

Microprocessor

1. Worldwide model (MWT).

You can select AM band step 9kHz or 10kHz by the following operation. How to select? Press and hold down the TUNER , then press the MEMORY.

2. Except worldwide model.

2-1. Necessary to change as follows. R7003 Change to 10 kohms. (Refer to Fig-1) R7004 Change to 10 kohms. (Refer to Fig-1) 2-2. How to select? Press and hold down the TUNER , then press the MEMORY.

Fig-1 NADG-7401 (PREAMPLIFIER PC BOARD)

7. Changing the AM band step

component side

TX-SR402/8240/HT-R420

19181716151413

1

2

3 4 5 6 7

8

9 10 11 12

STANDBY/ON button

When STANDBY/ON button is pressed to ON, the display will light to show the current volume setting for about 5 seconds then show the current sound input source. Pressing the button again returns the unit to the standby state. This state turns off the display, disables control functions.

STANDBY indicator

Lights when the unit is in the standby state and flashes when a signal is received from the remote controller.

DIMMER button

Press to set the brightness of the front display. The brightness changes to normal, dim and very dim.

DIGITAL INPUT button

When digital components are connected to the DIGITAL INPUT jacks of the unit use this button to assign the DIGITAL INPUT jacks to them according to their forms of connection.

SUBWOOFER MODE button

Press to select the subwoofer mode.

MEMORY button

This button is used to assign the radio station that is currently tuned in to a preset channel or delete a previously preset station.

FM MODE button

Press to switch the reception mode between stereo and monaural. If audio is interrupted or noise interferes with audio during FM stereo broadcasting, press this button to switch to the monaural reception mode.

TUNING / buttons

Use these buttons to change the tuner frequency. When FM is selected, you can hold down one of the TUNING / buttons and then release it to activate the auto-search feature. It will search for a station in the direction of the button you pressed and stop when it tunes into one.

Remote control sensor

This sensor receives the control signals from the remote controller.

LISTENING MODE buttons

Press these buttons to select a listening mode for the current source. Press the DSP button to recall the Onkyo-original DSP modes in sequence. Press the DIRECT, STEREO or SURROUND button to recall the corresponding listening mode directly.

PRESET/ADJUST / buttons

These buttons make it possible to store desired radio stations under the desired preset numbers and recall them with an easy operation. Also, these buttons adjust the values and parameters of the mode selected using the AUDIO ADJUST, SPEAKER ADJUST or AUDIO SELECTOR button.

MASTER VOLUME dial

The MASTER VOLUME dial is used to control the volume level. Turn the dial clockwise to increase the volume level and counterclockwise to decrease it.

SPEAKERS A/B buttons

Press SPEAKERS A/B to turn on/off the speaker system A/B. The (SPEAKERS) A/B indicators corresponding to the selected speaker system light up. You can use SPEAKERS A and B simultaneously.

PHONES jack

This is a standard stereo jack for connecting stereo headphones. The audio for the front right and left speakers are sent to the headphone speakers.

1

8

9

10

11

12

13

14

2

3

4

5

6

7

DISPLAY button

Each time you press the DISPLAY button, the display changes.

AUDIO SELECTOR button

Press to select an audio input signal format other than FM and AM. Each time this button is pressed, the setting cycles.

Input selector buttons (DVD,VIDEO 1,VIDEO 2, VIDEO 3, TAPE, TUNER, and CD)

These buttons are used to select the input source. Pressing and holding the TAPE button for about 2 seconds allows the TAPE and MD sources to be switched.

SPEAKER ADJUST button

Press to select speaker setting item.

AUDIO ADJUST button

Press to adjust bass, treble, late night function, cinema filter, Panorama, Dimension and Center Width function setting.

15

16

17

18

19

PANEL VIEWS-1

FRONT PANEL

TX-SR402/8240/HT-R420

h

a

b

c

d

e

g

f

i

(SPEAKERS) A/B indicators

Shows the current speaker system in use.

MUTING indicator

Flashes when the mute function is active.

Source/Listening mode indicators

TUNED indicator

Lights up when a radio station is received.

MEMORY indicator

Lights up when the MEMORY button is pressed in the radio station preset operation.

AUTO indicator

Lights up to indicate auto reception mode (stereo/monaural). At this time, interstation noise will be muted (FM only). It extinguishes when the monaural reception mode is started by pressing the FM MODE button.

FM STEREO indicator

Lights up when an FM stereo broadcast station is received.

a

b

c

d

e

f

g

SLEEP indicator

Lights up when the sleep timer is active.

h

One of these indicators lights to show the format of the current source as "PCM", " DIGITAL" or "DTS". In addition, one of the listening mode indicators " PRO LOGIC II", "MULTI CH", "DSP", "STEREO" and "DIRECT" lights according to the current listening mode.

Multi function display

In usual operation, shows the current input source and volume. When the FM or AM input is selected, it shows the frequency and preset number. When the DISPLAY button is pressed, it shows the current input source and the listening mode.

i

PANEL VIEWS-2

DISPLAY

TX-SR402/8240/HT-R420

REMOTE CONTROL

RLRL

ININ

IN

COAXIAL

OPTICAL

IN

FRONT

SURR

CENTER

SUB WOOFER

VIDEO 2

VIDEO 1

OUT

IN

OUT

DIGITAL INPUT

VIDEO 2VIDEO 3

VIDEO 1

DVD MONITOR

OUT

VIDEO

S VIDEO

DVD

TAPE

CD

FRONT SPEAKERS A

FRONT SPEAKERS B

L

R

IN

VIDEO 3

RL

SURROUND SPEAKERS

CENTER SPEAKER

L

R

AC OUTLET

ANTENNA

FM 75

AM

SUBWOOFER PRE OUT

1 2 3 4 5

1211109876

ANTENNA

These terminals are for connecting the FM antenna and AM antenna.

FRONT SPEAKERS B

These terminals are for connecting the speaker system B.

FRONT SPEAKERS A, CENTER SPEAKER and SURROUND SPEAKERS

These terminals are for connecting the speaker system A, including the center and surround speakers.

AC OUTLET

The unit is supplied with AC outlet for connecting the power cord from other devices so that their power is supplied through the unit. By doing this, you can use the STANDBY/ON button on the unit to turn on and off the connected devices as well.

DIGITAL INPUT OPTICAL, COAXIAL

These are digital audio inputs. There is 1 optical jack and 1 coaxial jack. The inputs accept digital audio signals from DVD, LD, CD, or other digital source.

SUBWOOFER PRE OUT

This terminal is for connecting an active subwoofer.

Tip

The audio input jacks of the unit do not accept direct connection of an analog turnable. If you want to connect a turntable to the unit prepare a phono equalizer and connect it to the unused audio input jacks (IN L/R). Refer to the instruction manuals of the phono equalizer and turntable for details.

REMOTE CONTROL

Connect the Onkyo components that have connectors such as a CD player, and cassette tape deck using the cables provided with them. When these components are interconnected, they can be controlled from the remote controller provided with the unit. For correct operation, the audio connection cables must also be connected. This applies to both remote and standard operation.

1

2

3

4

5

6

7

CD IN

Connect the output terminal on the CD player to the CD IN L/R jacks on the unit.

TAPE IN/OUT

Connect the output terminals (PLAY) of the cassette tape deck or MD recorder to the TAPE IN L/R jacks on the unit and the input terminals (REC) to the TAPE OUT L/R jacks.

VIDEO 1 IN/OUT, VIDEO 2 IN, VIDEO 3 IN

Connect the output terminals (PLAY) of the video cassette recorder to the VIDEO 1 IN L/R jacks on the unit and the input terminals (REC) to the VIDEO 1 OUT jacks. Connect the output terminals of the video cassette player or satellite tuner to the VIDEO 2 IN or VIDEO 3 IN jacks on the unit.

DVD

Connect the DVD player. If the DVD player has 5.1 channel output terminals, connect each terminal to the FRONT L/R, CENTER, SUBWOOFER, and SURR L/R terminals on the unit. If the DVD player has only 2 channel output terminals, connect to the FRONT L/R terminals on the HT-R420.

MONITOR OUT

The monitor output includes both RCA type and S video configurations. This output is for connecting television monitors or projectors.

8

9

10

11

12

PANEL VIEWS-3

REAR PANEL

TX-SR402/8240/HT-R420

RC-518M (HT-R420 American model)

RC-479S (HT-R420 Except American models,TX-SR402,TX-SR8240)

1

10

11

12

13

14

15

16

10

11

12

13

14

15

16

2

3

4

5

6

7

8

9

1

2

3

4

5

6

7

8

9

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

SLEEP button

For setting the sleep time. This button is provided only on the remote controller.

STANDBY/ON button

Turns on the unit or put it in standby.

Listening mode buttons

Press to change the listening mode.

CINE FLTR button

Press to activate/deactivate Cinema Filter function.

LATE NIGHT button

Press to change the late night setting.

For setting the output levels for each speaker. These buttons are provided only on the remote controller.

AUDIO SEL button

Press to select an audio input signal format.

INPUT SELECTOR buttons

For selecting the input source.

MUTING button

Activates the mute function. This button is provided only on the remote controller.

For selecting a tuner preset channel.

DIMMER button

For adjusting the brightness of the front display.

Mode buttons

For selecting the component to be operated by the remote controller. The RC-518M remote controller has five mode buttons, the RC-479S has three.

SP A/SP B buttons

Press to switch the speaker systems.

AUDIO ADJUST button

Press to adjust bass, treble, late night function and cinema filter function setting.

Press to adjust the values and parameters of the mode selected using the AUDIO ADJUST, SPEAKER ADJUST or AUDIO SELECTOR button.

For adjusting the volume.

TEST/CH SEL/LEVEL / buttons

VOLUME / button

PRESET / button

ADJUST / button

REMOTE CONTROLLER

RC-518M/RC-479M

EXPLODED VIEWS-1

TX-SR402/8240/HT-R420

U4

U3

P7502

P7503

P7504

U2

F903

F902

F6902

F6901

U18

U19

U15

U1

U10

U25

U16

U9

U27

P101

U23

U8

P901

U12

T901

U11

U20

U17

P800

x 7

A028

A035

A020

x 6

A050

A051

x 6

A030

A021

A007

x 3

A005

x 10

A411

A004

A021

x 2

A036

x 2

A025

A024

A404

x 27 (MWT x 28)

A401

A402

TXSR402/8240 MGR Only

A026

A055

x 4

A010

A002

x 2

A421

x 3

A065

A413

A412

A414

A060

A420

A410

A424

A056

x 8

A057

x 4

A017

x 2

A017

A016

x 2

A015

A023

x 4

A425

HT-R420 MDD, MDC Only

A430

HT-R420 MDD, MDC Only

F901

Refer to <Fig-1> in EXPLODED VIEWS-2

Refer to <Fig-2> in EXPLODED VIEWS-2

Refer to <Fig-3> in EXPLODED VIEWS-2

TX-SR402/8240/HT-R420

EXPLODED VIEWS-2

TX-SR402/8240/HT-R420

Q6064

Q6063

Q6062

Q6061

Q6060

Q6050

Q6051

Q6052

Q6054

Q6053

Q6050A

x10

A037

x10

A416

(L=85mm)

A417

(L=160mm)

<Fig-2>

<Fig-3>

U21

U22

A022

U26

A022

<Fig-1>

HT-R420 MDD, MDCTX-SR402/8240

HT-R420 MPA, MPT,MWT

FRONT PANEL INSIDE VIEW

A416

(L=85mm)

BLACK MODELS ONLY

[HT-R420(B)MDC, (B)MDD, (B)MPA Only]

A415

(L=135mm)

BLACK MODELS ONLY

[HT-R420(B)MDC, (B)MDD, (B)MPA ONLY]

A418

(L=215mm)

BLACK MODELS ONLY

[HT-R420(B)MDC, (B)MDD, (B)MPA ONLY]

BLOCK DIAGRAM

A

1

2

3

4

5

BCDEFGH

Q

INPUT GAIN

0/6dB

INPUT GAIN

0/6dB

INPUT GAIN

0/6dB

INPUT GAIN

0/6dB

INPUT GAIN

0/6dB

INPUT GAIN

Q301 BD3811K

0/6dB

Q302(1/2)

10.5dB

Q302(2/2)

NC

VIDEO3

CD

L

R

L

R

L

R

L

R

L

R

L

R

L

R

L

R

L

R

CENTER

SUB WOOFER

TAPE IN

TAPE OUT

VIDEO-1 OUT

VIDEO-1 IN

VIDEO-2 IN

FRONT

SURROUND

DVD

BACK UP

Q7501

OPERATION KEY

16BT123GK

FL TUBE

STANDBY

D7507

INPUT ATT

-6dB

50KLPF

SW

50KLPF

C

50KLPF

SR

50KLPF

SL

50KLPF

R

50KLPF

L

DIR

2CH A/D

96/24

VIDEO SELECTOR

MAIN

MICROPROCESSOR

Q7008

MPD784225GC-XXX-8BT

SUB

MICROPROCESSOR

Q7502

MPD780232GC-XXX-8BT

Q701

CS493264

DSP

96/24

6CH D/A

Q801

AK4586

Q804

Q803

Q802

OPTICAL

U7501

REMOTE SENSOR

VIDEO

VIDEO2 IN

VIDEO1 IN

DVD IN

12.5MHZ

5MHZ

12.288MHZ

VIDEO

MUTE

Q202

MUTE

Q211

Q210

Q207

Q208

Q201

MONITOR OUT

VIDEO 1 OUT

OSC

+5V

-12VAF

+12VAF

+7V

-7V

+2.5V

DSP

POWER SUPPLY

COAXIAL

Q281 74HCU04

VIDEO3 IN

Y

C

S-VIDEO

MONITOR OUT

Y

C

VIDEO 2 IN

Y

C

S-VIDEO

VIDEO 1 IN

Y

C

VIDEO 1 OUT

Y

C

DVD IN

+3.3V

78

77

2

69 68

1

72

66 65

71

4

3

43 42

6

5

40 39

8

7

30 31

76

75

33 34

10

9

2321262528

27

24

22

12

18

11

14

20

13

16

15

17

19

RST.CS.INTREQ/CL/DA/SCDO

RST.CS/CL/DA/

CDTO/INT1.2.

CTLA/B

VMUT2

VMUT1

DIGITAL IN

Q7004 BA33C25

Q321 78L07

Q322 79L07

Q203 LA7956

Q213 LA7956

Q212 LA7956

TUNER UNIT

MAIN MICROPROCESSOR

TX-SR402/8240/HT-R420TX-SR402/8240/HT-R420

SUBWOOFER PREOUT

AC OUTLET

BASSBOOST

MUTING

OUTPUT GAIN

0-18dB

OUTPUT GAIN

0-18dB

OUTPUT GAIN

0-18dB

OUTPUT GAIN

0-18dB

OUTPUT GAIN

0-18dB

OUTPUT GAIN

0-18dB

Q305

15dB

RL6901

MASTER VOLUME

0,,-103dB

SEC2

BASS/TREBLE

AC IN

F901

P902

RL901

D921

-924

D9502

-9504

D6904D6903

RL6902

POWER AMP

D9509

-9512

PRI.

SEC1

T902

RI

SEC3

+B1L+B1H

PHONES

SEC1H/L CONTROL

Q4606 78M05

+5VDSP

Q6402 78M12

Q6403 79M12

-12VAF

VIDEO SECTION

PREAMPLIFIER SECTION

DSP SECTION

-VP

+12V

Q9501

FL TUBE

FLAC

RELAY +B2

SEC1H

+B1

-B1

Q6931

NJM78M56A

Q6405 78M12

+5.6V

MICROPROCESSOR

SUB MICROPROCESSOR

POWER

+5V

-12VAF

+12VAF

VOLTAGE LEVEL SENSOR

R6380

THERMAL

SENSOR

VOLH

PRO

D6704

DC VOLTAGE DETECTION OVER CURRENT DETECTION Q6701~6703

RI

INTERFACE

+27dB

POWER AMPLIFIER

L

R

FRONT SPEAKERS-A

FRONT SPEAKERS-B

SURROUND SPEAKERS

CENTER SPEAKER

L

R

L

R

55

57

38

37

35

36

SWPO

AMUT

SPF

SPCS

SPB

HPDET

SELMUT

SELDA

SELCL

Q307

MUTING

Q312

Q313

Q306

Q308

D6703

RL6603

RL6601

RL6604

RL6600

SUB

TRANSFORMER

T901

MAIN

TRANSFORMER

+BV

SCHEMATIC DIAGRAMS-1

PREAMPLIFIER SECTION

A

1

2

3

4

5

BCDEFGH

L805

NC

Q6402

78M12

G

IO

Q6406

78M05

G

IO

Q6405

78M12

G

IO

Q6403

79M12

G

IO

Q321

78L07

G

IO

Q322 79L07

G

IO

P302

VIDEO-3 IN

P261A

NC

P802

NC

P305

DVD

SURROUND R

SURROUND L

SUB WOOFER

CENTER

P304

VIDEO-1 OUT

VIDEO-1 IN

VIDEO-2 IN

P301

CD

TAPE IN

TAPE OUT

Q317

NC

Q319

NC

Q318

NC

TVDD

DVDD

VCOM

DFZ1

LOUT3

ROUT3

LOUT2

ROUT2

LOUT1

ROUT1

LIN

RIN

PVDD

VREFH

AVDD

AVSS

DFZ2

CSN

CCLK

CDTI

CDTO

INT1

INT0

SDTI3

SDTI2

PDN

RX1

I2C

RX2

TST

RX3

SLAVE

RX4

PVSS

R

SDTI1

SDTO

BICK

LRCK

MCKO

TX

DVSS

XTI

XTO

Q801

AK4586

1

2

3

4

5

6

7

8

9

10

11

1213141516171819202122

23

24

25

26

27

28

29

30

31

32

33

3435363738394041424344

X701 CSTCV12.2MTJ0C4

L804

022M

NCH-1471

L801

022M

L802

022M

L803

022M

X801

HC-49/U03C

12.288M

TC7WU04FU

GND4

1

Q304

NC

4066

13

12543

6

8

9

121110

GND

7

VCC

14

Q303

NC

4066

13

12543

6

8

9

121110

GND

7

VCC

14

LOGIC

BASS BOOST

DA

CL

MUT

VEE

VCC

BASS TREBLE

47k

Q301

BD3811K1

297032

41

44

49

51

53

54

67

56

58

62

60

61

59

47

46

45

66

69

33

40

43

30

10

77

78

21

22

79

80

23

24

1

2

3

4

5

6

7

8

9

11

12

272625

28

15

14

13

16

48

55

19

20

57

17

18

363738

35

71

72

737475

76

63

64

52

50

65

68

34

39

42

31

C375

472J

C373

472J

C374

472J

C372

472J

C371

472J

C376

472J

C849153J

C841

822J

C344

C342

C343

C341

C339

C338 563J

C337

C340 563J

Q314

NC

Q316

NC

Q315

NC

C816 104Z

D801

D802

C859

10/16

C858

10/16

C353

47/16

C354

47/16

C358

47/16

C357

NC

C356

NC

C355

NC

C854

10/16

C855

47/16

C856

10/16

C857

10/16

C832

10/16

C362

10/16

C349

10/16

C359

10/16

C6412

10/16

C6410

10/16

C6404

10/16

C6406

10/16

C833

10/16

C836

10/16

C837

10/16

C834

10/16

C835

10/16

C80910/16

C806

220/6.3

C364 10/16

C363 10/16

C801

47/16

C810

47/16

C348

C347

C331

10/16

C329

10/16

C330

10/16

C332 10/16

C333 10/16

C334 10/16

Q305

OR MPC4570

NJM4565M

3

2

4

1

Q302

OR MPC4570

NJM4565M

3

2

4

1

Q802

NJM4565M

5

6

4

7

Q804

NJM4565M

5

6

4

7

Q803

NJM4565M

5

6

4

7

Q305

OR MPC4570

NJM4565M

5

8

6

7

Q302

OR MPC4570

NJM4565M

5

8

6

7

Q802

NJM4565M

3

8

2

1

Q804

NJM4565M

3

8

2

1

Q803

NJM4565M

3

8

2

1

R801

47

NC

R803

47

R347

10K

R348

10K

R366

R365

R364 10K

R363 10K

R316

330

R318

330

R320

330

R339

R321

330

R343 R342

R319

330

R341 R340

R317

330

R338

R310

330

R314

330

R312

330

R333

R311

330

R332

R315

330

R337 R336

R313

330

R335 R334

R304

330

R300

330

R302

330

R306

330

R307

330

R324

R301

330

R323 R322

R303

330

R325R327R329 R328

R305

330

R326

R359

270

R360

270

R372

R331

470

R371

R330

470

R397

NC

R396

NC

R344

R373

470

R374

470

R375

470

R376

270

R821

470

R387

2.7K

R386

2.7K

R358

2.7K

R368

47K

R367

1K

R369

2.2K

R370

22K

R383 10K

R357

2.7K

R353

12K

R6410

2.2

1/2W

R6408

(NO USE)

R6403

33 1/2W

R6402

10

1/2W

R6407

3.3 1W

R393

100K

NC

R395

NC

R394

100K

NC

R392

2.2K

R390

12K

R391

2.2K

R389

12K

R356

12K

R354

12K

R352

2.2K

R350

2.2K

R349

2.2K

R351

2.2K

R355

12K

R361

10K

R362 10K

R346

470K

NC

R345

470K

NC

R816

330

R832

100K

R833

100K

R840

2.2K

R841

2.2K

R848

2.2K

R849

2.2K

R844

2.2K

R835

100K

R834

100K

R836

100K

R837

100K

R845

2.2K

R852

2.2K

R853

2.2K

R842

2.2K

R843

2.2K

R850

2.2K

R851

2.2K

R809 1K

R810 1K

R811 220

R812 220

R813 220

R814 220

R807 47

R808 47

R817

330

R818

330

R819

330

R820 10K

R804

47

R805

47

R806

47

R815

18K

C322

104Z

C308 103Z

C6405

223Z

C321 C320 C319 C318 C317 C316 C311 C310C315 C314 C313

101J

C312

101J

C302

101J

C301 C300C303

101J

C307 C306 C305 C304

C326

104Z

C325

104Z

C323

104Z

C817

150J

C803

150J

C350

221J

C351

330J

C336 332J

C335 332J

C848

152J

C840

821J

C6411

223Z

C6409

223Z

C6403

223Z

C367

104Z

C366

104Z

C327

330J

C328

330J

C808

104Z

C800

330J

C812

330J

C850152J

C851152J

C852152J

C853

152J

C845

821J

C844

821J

C843

821J

C842

821J

C807104Z

C811

104Z

C805

104Z

C804

104Z

C802

150J

C815

102K

C814

330J

C813

330J

C346

C345

+7V

CDR SEC3-1

+12VAF SEC3-2

-7V

CDL

TOR -12VAF

TUL

TUR

TOL POWER

+12VVD

V1OL

V1OR

TOL

TOR

V4R

V4L

TUL

TUR

TIR SPCS

+5VDSP

CDR

TIL PROTECT

CDL

TIR

V3IR

TIL HPIN

V3IR

V3IL

V2IR

V3IL

V2IL

OUT_L

V1IR

V1IL

OUT_R

DVDR SELCK

DVDL

OUT_L

MRS +7V SNONE MCMDA

MLS SWNONE MCSDA

MSW -7V CNONE MCRDY

V2IR

MC

ADCL SELMUT

SELCK

ADCR SELDA A151 232RXD

OUT_R FVCC

V2IL

DAC_R A171

V1OR OUT_RS

DMIXR DSPSCK

DAC_L DSPDO

DMIXL

V1OL

OUT_LS LSPO

OUT_C

V1IR

OUT_LS

OUT_RS

DAC_RS

DAC_LS

DAC_SW

DAC_C

OUT_C

OUT_SW

V1IL

OUT_C

DVDR

+12VAF

DAC_SW

DAC_LS

DAC_C

DVDL

SNONE

SWNONE

MRS

+7V

-12VAF

MLS

MSW

SNONE

-7V

MC

CNONE

DAC_L

SWNONE

DAC_RS

DAC_C

DAC_SW

CNONE

+7V

-7V

+7V

DAC_C

CDTO/SCDO[L]

DIRCS

DSPSCK

DSPDO

INT1[L]

INT0[L]

+3.3V

DAC_SW

GND

CDA SRDA LRDA

SDTO

BCK

LRCK

DAC_LS MCK2

DAC_RS

+5VDSP

DAC_L

DIRPD

GND

RX3

RX2

+5VDSP

RX1

TX

DAC_R

ADCL

ADCR

Refer to the following table about the parts displayed by mark" "

MGR 420MDD 420MWT MPA,MPT

C300 471J 101K 471J 471J

C301 471J 101K 471J 471J

C304 471J 101J 471J 471J

C305 471J 101J 471J 471J

C306 471J 101J 471J 471J

C307 471J 101J 471J 471J

C310 471J 101J 471J 471J

C311 471J 101J 471J 471J

C314 471J 101J 471J 471J

C315 471J 101J 471J 471J

C316 471J 101J 471J 471J

C317 471J 101J 471J 471J

C318 471J 101J 471J 471J

C319 471J 101J 471J 471J

C320 471J 101J 471J 471J

C321 471J 101J 471J 471J

R7003 10K 0 10K 10K

R7004 33K 1K 10K 33K

R7078 33K 33K 33K 33K

R7079 33K 33K 33K 33K

R7080 10K 10K 10K 10K

R7178 56K 56K 56K 56K

R7179 10K 10K 10K 10K

R7180 33K 33K 33K 33K

NO USE

U01

NADG-7401

PREAMPLIFIER PC BOARD

<Notes> NC=No mount of parts.

NOTE

.

THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY

REPLACE ONLY WITH PART NUMBER SPECIFIED. .

VOLTAGE (MEASURED WITHVOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL)

.

ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED.

.

ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED.

.

ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED.

.

ELECTROLYTIC CAPACITORS ( )ARE IN u F/WV.

.

ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.

EX) 030- 3pF 330- 33pF 331- 330pF333- 0.033uF .

ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.

.

THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.

EX) PRINTING SIDE .

CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.

.

IS DC VOLTAGE, AT NO INPUT SIGNAL.

TX-SR402/8240/HT-R420TX-SR402/8240/HT-R420

Q7004

BA33C25

2.5V 5

3.3V

4G3

NC

2

VI

1

P406

Q702

NC*

MX29LV040

A020

A119

A1031

A11 1

A1212

A13 4

A14 5

A1511

A1610

A17 6

A18/VPP9

A218

A317 A4 16

A515

A614

A713

A8 3

A9 2

DQ021

DQ122

DQ223

DQ325

DQ426

DQ527

DQ628

DQ729

VCC8

VSS24

CE30

OE32

WE/A18 7

P801

TO NAETC-7884

Q9501

2SA1015-GR

KTA1266-GR

P6403

P306

TO NAAF-7866

P410B

TO NAETC-7868

P7502B

TO NADIS-7403

P411B

TO NAETC-7868

Q7003

TC74HCT7007

12345678

9

1011121314

NC

FOR FLASH WRITER

P101

TO TUNER PACK

Q101

NC

T2

T1

VSS2

VDD2

XI

X0

T57

RCLK

CMP

VSS3

VSS1

VDD1

MUX

VREF

RDSDATA

QUAL

Q181 BU1923F

Q181 NC

1234567

89

10

11

12

13

14

15

16

Q7008

MPD784225

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21222324252627282930313233343536373839

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61626364656667686970717273747576777879

80

Q710

NC

74HC00/32

Q710 NC

1A1

1B2

1Y3

2A4

2B5

2Y6

3A 10

3B 9

3Y 8

4A 13

4B 12

4Y 11

GND7

VCC14

D7702 UDZ6.2B

D9508

UDZ27D

Q7007

KRC104S

OR RN1404

Q7006

KRC104S

OR RN1404

Q7001

KRC104S

RN1404

R743

1K

NC

R744

1K

NC

R745

1K

NC

R7000

100

R187

R186

R182NCR183

NC

R185

R184

NC

R747

10

NC

R742

10

NC

R740

1K

NC

R9508

15K

R9509 100K

R9506

22

(/2W

R9507

15K

Q703

Q703 NC

MPD441000LGU-B70X

IS62LV1024LL-70HI

MPD44200LGU-B70X

NC

A020

A119

A1031

A11 1

A1212

A13 4

A1411

A15 7

A1610

A218

A317 A416

A515

A614

A713

A8 3

A9 2

CE2 6

GND24

IO121

IO222

IO323

IO425

IO526

IO627

IO728

IO829

NC9

VCC8

CE130

OE32

WE5

Q701

CS493264-CL

A0/SCCLK

7

A1/SCDIN 6

AUDATA041

AUDATA1 40

AUDATA2

39

CLKIN30

CLKSEL31

CMPCLK/SCLKN2 28

CMPDAT/RCV958/SDATAN2 27

CMPREQ/ LRCLKN2

29 DATA0 17

DATA116

DATA215

DATA314

DATA411

DATA510

DATA6 9

DATA7 8DC38

DD37

FILT133

FILT232

LRCKN1 26LRCLK42

MCLK44

SCDIO/SCDOUT 19

SCLK43 SCLKN1/STCCLK2 25

SDTAN1 22

VDD11

VDD212

VDD3 23

VDDA34

VSS12

VSS213

VSS3 24

VSSA35

XMT9583

ABOOT/_INTREQ 20

CS 18

EXTMEM 21

RD/R/_W5

RESET36

WR/DA4

P7701

NC*

TO RS232C

X7001

CSTCV12.5MXJ

X701 CSTCV12.2MTJ0C4

L7002

022M

NCH-1471

L7001

470K

NCH-1479

L703 470M

NCH-1479

L706

BK1608LM182

L705

BK1608LM182

L181

L704 022M

NCH-1471

L701

022M

NCH-1471

L702

022M

NCH1471

X181

NC

HC-49/U03C

Q707

TC7WU04FU

GND4

1

63

72

5

VCC8

Q7002

TC74VHC541FT

A1 2

A2 3

A3 4

A4 5

A5 6

A6 7

A7 8

A8 9

GND10

VCC20

Y118

Y217

Y316

Y415

Y514

Y613

Y712

Y811

G1 1

G219

Q706

NC*

TC74VHC74FT

Q706 NC

1CK3

1D2

1Q5

2CK 11

2D 12

2Q 9

GND7

VCC14

1CLR1

1PR4

1Q6

2CLR 13

2PR 10

2Q 8

Q704

NC

TC74VHC574FT

Q704 NC

0D20Q19

1D31Q18

2D42Q17

3D53Q16

4D64Q15

5D75Q14

6D86Q13

7D97Q12

CK11GND10

OUTCTL1 VCC20

Q705

TC74VHC574FT

Q705 NC

0D20Q19

1D31Q18

2D42Q17

3D53Q16

4D64Q15

5D75Q14

6D86Q13

7D97Q12

CK11GND10

OUTCTL1 VCC20

C9503

104J

C6401

104J

C9502

104J

C9501 104J

P351

Q306

OR KRA102S

RN2402

Q307 RN1441

Q311

NO USE

NC

Q310

NO USE

NC

Q309

NC

Q308

RN1441

Q312

RN1441

Q313

RN1441

C7010104Z

C360

474K

C361

224K

D9512

D9504

D9505

D7003

D9511

D9510

D9509

D9506

1SR154-400

D9507

1SR154-400

D9502

D9503

D9502-9505: RL1N4003

D7002

D7004

1SS352

D7001

C7015

47/16

C7011

47/16

C7012

47/16

C101

3.3/50

C184

NC

C181

NC

C103

3.3/50

C9508

4700/16

C9510

220/63

C9507

220/35

C9506

470/35

C9505

2200/35

C7005

100/6.3

C7004

1/50

C7002

100/6.3

C7001

104F

C716

100/6.3

C706

100/6.3

C731

NC

R713 47

R714

330

R715 330

R716 330

R717 330

R7138

22K

R7839 22K

R103

22K

R102

22K

R7180

R7179

R7178

R7080

INIT3

R7004

BAND

R372

R331

470

R371

R330

470

R397

NC

R396

NC

R344

R373

470

R374

470

R375

470

R376

270

R7141

10K

R7041

10K

R821

470

R7083 220

R7085 220R7084

220

R7082

220

R7081

220

R7075220

R7074220

R7073220

R7072220

R7070220

R7069220

R7068220

R7067220

R181

NC

R71341KR7034

470

R7035

220

R7037

220

R7032

220

R7031

220

R7038

2.2K

R7040

220

R7039

2.2K

R7036

220

R104

100K

R105

680K

NC

R7030

220

R7029

220

R7028

220

R7027

220

1/2W

3.3 1W

R379

22K

R378

22K

R377

22K

R381

22K

R380

22K

R384

220K

R385

100

R382

22K

R388

100

R7079

INIT2

R7078

INIT1

R7077

R7055

220

R7054

220

R7062

220K

R106

3.3K

NC

R739 1M

R729

47

R7033

47K

R7060 47K

R7120

1K

R7043

220

R7059

220

R7058

1K

R7057

1K

R7056

1K

R7052

1K

R7053

220

R7047

220

R7051

1K

R7050

1K

R7049

1K

R7046

1K

R7048

220

R7045

1K

R7044

1K

R7042

220

R7071

4.7K

R7066

1K

R7076

R70651KR70641KR7063

1K

R7026

220

R7025

220

R7024

220

R7023

220

R7022

220

R7021

2.2K

R7020

220

R7019

220

R7018

82

R7017

82

R7016

82

R7015

82

R7012

220

R7011

1K

R7003

R7002

2.2K

R7001

2.2K

R746

10

R75010

R74910

R748

NC

R751

NC

R752

NC

R753

NC

R754

NC

R755

NC

R756

NC

R757

NC

R719330

R703

4.7K

R71110K

R70910K

R71010K

R732

NC

R731

NC

R712

47

R704

10K

R705

330

R702330

R70147

R730

R72847

R72747

R72647

R733

NC

R734

NC

R735

NC

R736

NC

R737

NC

R738

NC

R708 220

R707 220

R706

220

R72047

R7214.7K

R7221K

R7234.7K

R7244.7K

R72547

R71833K

C7014

104Z

C732NCC726NCC727NCC728

NC

C707

104Z

C7009

104Z

C188

470J

NC

C106

101J

C183

NC

C7006

104Z

C182

NC

C185

NC

C187NCC186

NC

C365

222J

C729

NC

C104

101J

C105 104Z

NC

C9511

223Z

C9512 223Z

C352

SUB WOOFER PREOUT

104Z

C715 104Z

C7007

104Z

C7008

104Z

C7003

104Z

C717

NC

C712104Z

C703

104Z

C705 101J

C702

101J

C701101J

C714

104Z

C730

104Z

NC

C709105K

C704

101J

C710105K

C711471J

C713101J

C708103K

C720

NC

C721

C722

NC

+22V

SEC1-1

GND

SEC1-2

-VP +12VVD

DET

SD

TMUT

TUR

TUL

TX

RX1

RX2

RX3

5.6S

+12VAF

+5VDSP

FMSIG

VMUT1

VMUT2

CTLB

CTLA

PLLCL

PLLDA

PLLSTB

+5VDSP

RI

STEREO

SPF

GND

+22V

SEC1H

STEREO

-22V SPB

VOLH

GND

TMUT

PLLCL

PLLDA

PLLSTB

CTLB

CTLA

POWER

SPF

SPCS

SD

VMUT1

VMUT2

SEC1H

SPB

RDSDET

+13V

RI

HPIN

MCRDY

AMUT

MCSDA

SELMUT

HPMUT

MCMDA

MCRST

MCCLK

SELDA

MCCLK

MCRST

HPMUT

-VP

DIRCS

DSPCS

MCRDY

ROM/RAM

232TXD

IC

LPO

A161

MPURST

GND

MCCLK

RPO

MCMDA

MCSDA

RSPO

DSPRST

GND

CDTO/SCDO

INT1

INT0

CPO

DIRPD

VOLH

PROTECT

POFF

RDSSCK

SWPO

INTREQ1

AMUT

RDSDATA

RDSSIG

CDTO/SCDO

INT1

INT0

INT0[L]

INT1[L]

RDSDET

DSPCS1[L]

FMEM/SRAM1[L]

A151[L]

A161[L]

A171[L]

DSPDA[3.3V]

DSPRST1[L]

CDTO/SCDO[L]

+5VDSP

DSPCL[3.3V]

+3.3V

DSPCS1[L]

INTREQ1

CDTO/SCDO[L]

A0 A8

A1 A9

A2 A10

A3 A11

A4 A12

RD

A5 A13

EXTMEM

RD

DSPMCK

BCK

SDTO

LRCK

BCK

SDTO

A6 A14

A16

A7 A15

GND

RD RD

LRCK

DSPMCK

A12A4A5A6A7

_WEF

A14A8A9WEA13

A11

A4A5A6

A7

A12

A15

A16

A14

A13

A8

A9

A11

A0

IO2

IO3

FMEM/SRAM1[L]

A3A2A1

A0

IO0

IO1

IO2

IO3

IO4

IO5

IO6

IO7

A3A2A1

IO0

IO1

IO4

IO5

IO6

IO7

A10

DSPRST1[L]

A171[L]

A161[L]

A151[L]

+2.5V

DSPCL[3.3V]

LRDA

MCK2

WE

RD

DSPDA[3.3V]

NO USE

GND

SCHEMATIC DIAGRAMS-2

DISPLAY & VIDEO SECTION

A

1

2

3

4

5

BCDEFGH

RL7501

NC

P7502A

R7581

100K X 14

R7582

100K X 13

C7512

474 MMT

C7523 102J

C7522 101J

F2F2NPNPP35

P34

P33

P32

P31

P30

P29

P28

P27

P26

P25

P24

P23

P22

P21

P20

P19

P18

P17

P16

P15

P14

P13

P12

P11

P10P9P8P7P6P5P4P3P2P116G

15G

14G

13G

12G

11G

10G9G8G7G6G5G4G3G2G1GNPNPF1

F1

Q7501

16BT123GK

123456789

101112131415161718192021222324252627282930313233343536373839404142434445464748495051525354

55

565758

59

JL7501B

JL7501A

S7615

SPEAKERS B

S7616 SPEAKERS A

S7614 STANDBY /ON

S7647

AUDIO

ADJUST

S7645

PRESET>

S7644

DSP

S7643

SURROUND

S7642

STEREO

S7641

DIRECT

S7646

<PRESET

S7635

MEMORY

S7634

TAPE

S7633

TUNER

S7632

CD

S7631

SP

ADJUST

S7636

TUNING<

S7637

TUNING>

S7627

FM MODE

S7625

VIDEO2

S7624

VIDEO1

S7623

DVD

S7622

AUDIO

SEL

S7621

DISPLAY

S7626

VIDEO3

S7613

DIMMER

S7612

SW MODE

S7611

DIGITAL

INPUT

P7503A

S7501

MASTER VOLUME

Q7504

RN2403

KRA103S

U7501

SPS4441E1

L7505

220K

NCH1477

Q7502

UPD780232GC-030-8BT

21:ANI1

21

22:ANI0

22

41:P45/FIP374142:P44/FIP364243:P43/FIP35

43

61:FIP19

61

ANI220

ANI319

AVDD24

AVSS18

FIP0

80

FIP1 79

FIP10 70

FIP11 69

FIP12 68

FIP13 67

FIP14 66

FIP15 65

FIP16 64

FIP17 63

FIP18 62

FIP2 78

FIP20 58

FIP21 57

FIP22 56

FIP23 55

FIP3 77

FIP4 76

FIP5 75

FIP6 74

FIP7 73

FIP8 72

FIP9 71

IC5

P01/INTP116

P02/TI17

P20/SCK314

P21/SO313

P2212

P2311

P24/BUSY10

P25SO19

P26/SI18

P27/SCK17 P30/FIP24 54

P31/FIP25 53

P32/FIP26 52

P33/FIP27 51

P34/FIP28 50

P35/FIP29 49

P36/FIP30 48

P37/FIP31 47

P40/FIP32 46

P41/FIP33 45

P42/FIP34 44

P46/FIP3840

P47/FIP3939

P50/FIP4038

P51/FIP4137

P52/FIP4236

P53/FIP4335

P54/FIP4434

P55/FIP4533

P56/FIP4632

P57/FIP4731

P60/FIP4830

P61/FIP4929

P62/FIP5028

P63/FIP5127

P64/FIP5226

POO/INTP015

VDD025

VDD11

VDD2 59

VLOAD 60

VSS023

VSS12

X13

X24

RESET6

R7519

100K

R7614

820

R7613

560

R7524 1K

R7646 2.2K

R7615

1.2K

R7531

220

R7641 330R7645 1.2K R7644 820 R7643 560 R7642 470

R7631 330R7632 470R7633 560R7634 820R7635 1.2KR7636 2.2K

R7626 2.2K R7621 330R7625 1.2K R7624 820 R7623 560 R7622 470

R7612 470 R7611 330

Q7507RN1402

KRC102S

NC

Q7506

RN1402

KRC102S

X7501

CST5.00MGW

Q7503

2SC2712

KTC3875

D7505

STANDBY

SLR56VRTB7

OR SEL411OR

D7505

D7502

UDZ5.1B

D7504

NO USE

1SS352

NC

D7507

1SS352

D7503

1SS352

C7514 100/6.3

C7502

C7513 104Z

C7515

104Z

C7516

104Z

C7517 102J

C7508 102J

C7509 102J

C7507

104Z

C7510 102J

C7511 102J

R7518

100K

R7517 1K

R7503

10K

R7520 2.7K

R7521 2.7K

R7504

47K

R7507 4.7K

R7506 4.7K

R7532

10K

R7527 10K

R7526 10K

R7530 1K

R7529 560

R7528 560

R7508 4.7K

R7509 4.7K

R7510 1K

R7511 1K

R7512 10K

R7513 10K

R7514 10K

R7515 10K

R7516 10K

R7522 2.7K

R7523 2.7K

R7505

220K

SYSOUT

IRF

VAJ

VBJ

STBYLED

SYSIN

K0

K1

K2

K3

SBMLDY

SBMDI

SBMDO

SBMCLK

SBMRST

K0K1K2

K3

GND

KEY0

SYSIN

HPDET

SBMLDY

SBMDI

SBMDO

SBMCLK

SBMRST

-VP

TO NADG-7401

U02

DISPLAY PC BOARD

U03

SWITCH PC BOARD

NADIS-7403

NASW-7404

FL TUBE

TX-SR402/8240/HT-R420TX-SR402/8240/HT-R420

P253A

P211B

P211A

TO NAVD-7873

P210B

TO NAVD-7867

P210A

P202

P201

Y

YC

C

P204

P281

DIGITAL INPUT

COAXIAL

DIGITAL INPUT

OPTICAL

YC

CY

P203

P206B

P206A

P801B

Q281

74HCU04

1

2

3

4

5

6

7

8

9

10

11

12

13

14

P282

U281

Q209

2SA933-S

*KTA1267-GR

Q204

2SA933-S

KTA1267-GR

VIDEO OUT

VCC

VIN4

VIN3

VIN2

GND

VIN1

B

A

Q213

LA7956

1

2

3

4

5

6

7

8

9

VIDEO OUT

VCC

VIN4

VIN3

VIN2

GND

VIN1

B

A

Q212

LA7956

1

2

3

4

5

6

7

8

9

VIDEO OUT

VCC

VIN4

VIN3

VIN2

GND

VIN1

B

A

Q203

LA7956

1

2

3

4

5

6

7

8

9

Q210

RN1241

Q208

RN1241

Q207

RN1241

Q211

RN1241

Q202

RN1241

Q201

RN1241

JL7502B

JL7502A

E7501

Q206

DTA114ES

KRA102M

Q205

DTA114ES

KRA102M

L281

220K

NCH-1452

L283

022M

L282

220KNCH-1452

L7504

220K

NCH1477

L7501 022M

NC

L7502 022M

NC

L7503 022M

NC

P7501

PHONES

100K

R7580 10K X 15

NC

D7501 UDZ8.2B

D202

D201

D7507

1SS352

C205

470/16

C207 2.2/50

C215

470/16

C209 2.2/50

C213 2.2/50

C223

47/16

C225

47/16

C211

470/16

C288

47/6.3

C285

47/6.3

C201

2.2/50

C217

2.2/50

C203

470/16

C202

2.2/50

C204

2.2/50

C221

47/16

C7521

220/6.3

C7502

33/50

C286 223Z

C220

223Z

C231

223Z

C232

223Z

C214

223Z

C208 223Z

C212 223Z

C226

223Z

C224 223Z

C210

223Z

C287

223Z

C283

223Z

C281

223Z

C284

080D

C282

101J

C227 223Z

C222 223Z

C7519

102J

C7520

102J

C7518

102J

C7506

104Z

C7501 104Z

C7503 104Z

C7505

473Z

C7504

473Z

R206

75

R216 75

R215

75

R212 75

R211 75

R225

680K

R221 75

R222 75

R217 100K

R218 100K R214 75

R213 75

R226

680K

R227

680K

R228

220

R230

680K

R224

100K

R223

100K

R219 75

R220 75

R282

470

R284

10K

R281

75

R210

220

R231

75

R205

75

R207

680K

R201

75

R208

680K

R202

75

R209

680K

R203

75

R204

100K

R7501 220

R7502 220

+12V GND

A

B

VMUT2

VMUT1

RI

OPT2

DGND

OPT1

+5V

COAX

OPTOUT

+12V

GND

A

B

VMUT2

VMUT1

RI

DGND

OPT1

+5V

COAX

GND

+12V

B

A

VM2

VM1

HPDET

GND

+12V

HPL

B

HPE

A

HPR

VM2

+5.6S

FAC2

FAC1

HPR

HPE

HPL

GND

NAVD-7873

DVD IN

MONITOR OUT

OUT

IN

VIDEO-2

S_VIDEO

VIDEO-1

RI

DVD IN

VIDEO-1

OUT

INVIDEO-2

IN

VIDEO-3

VIDEO

IN

MONITOR OUT

TO NAETC-7868

TO NADG-7401

TO NAETC-7884

TO NAVD-7867

U15

S VIDEO TERMINAL

PC BOARD

U16

TERMINAL PC BOARD

U25

TERMINAL PC BOARD

U04

HEADPHONE JACK PC BOARD

U09

VIDEO&OPT TERMINAL PC BOARD

NAETC-7884 NAVD-7867

NAETC-7874

NAETC-7405

NOTE

.

THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY REPLACE ONLY WITH PART NUMBER SPECIFIED.

.

VOLTAGE (MEASURED WITHVOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL) .

ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED. .

ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED. .

ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED. .

ELECTROLYTIC CAPACITORS ( )ARE IN u F/WV. .

ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED. EX) 030- 3pF 330- 33pF 331- 330pF333- 0.033uF

.

ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED. .

THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS. EX) PRINTING SIDE

.

CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT. .

IS DC VOLTAGE, AT NO INPUT SIGNAL.

<Notes> NC=No mount of parts.

SCHEMATIC DIAGRAMS-3

DRIVER AMPLIFIER SECTION

A

1

2

3

4

5

BCDEFGH

Q5013Q5003

Q5043

Q5053

Q5014Q5004

Q5044

Q5054

Q5034

R5013

56K

R5003 1K

R5023

330

R5063

1.2K

R5163

120 (1/4W)

R5133 18K

R5173 120(1/4W)

R5033 56K

R5083

3.3K

R5113 1K

R5093 82K [100K]

R5053

4.7K

R5073 560

R5103 100K

R5183 10 (1/4W)

R5193 10 (1/4W)

R5043

2.2K

R5014

56K

R5004 1K

R5024

330

R5064

1.2K

R5164

120 (1/4W)

R5134

18K

R5174

120(1/4W)

R5034

56K

R5084

3.3K

R5114

1K

R5094 82K [100K]

R5054

4.7K

R5074

560

R5104 100K

R5184 10 (1/4W)

R5194 10 (1/4W)

R5044

2.2K

C5013 22/16

C5043 220/16 [100/16]

C5053 47/50

C5113 10/63 [10/100]

C5103 10/63 [10/100]

C5023 10/50

C5014 22/16

C5044 220/16 [100/16]

C5054 47/50

C5114 10/63 [10/100]

C5104 10/63 [10/100]

C5024 10/50

C5003

101K

C5083 040D

C5093 101J

C5033

C5004 101K

C5084 040D

C5094 101J

C5034

P6003A

TO NAAF-7875

P6004A

TO NAAF-7875

C5073

C5074

D5003

MTZJ5.6B

D5004 MTZJ5.6B

48.9V

[62.1V]

-48.9V

[-62.1V]

47.5V

[60.7V]

48.1V [61.5V]

-43.3V

[-56.5V]

-48.1V

[-61.4V]

-44V

[-57.1V]

1.0V

[1.0V]

-47.5V

[-60.6V]

0V

[0V]

-0.1V

-1V

[-1V]

-0.7V

48.9V

[62.1V]

-48.9V

[-62.1V]

47.5V

[60.7V]

48.1V

[61.5V]

-43.3V

[-56.5V]

-48.1V

[-61.4V]

-44V

[-57.1V]

1.0V

[1.0V]

-47.5V

[-60.6V]

0V

[0V]

-0.1V

-1V

[-1V]

-0.7V

NO. TX-SR402/ TX-SR8240 HT-R420

Q5000-04,5010-14 KTC3200-BL OR 2SC1775A-E,F OR 2SC1845-E KTC3200-BL OR 2SC1775A-E,F OR 2SC1845-E Q5030-34 KTA1024-Y,O OR 2SA949-Y,O KTA1024-Y,O OR 2SA949-Y,O Q5040-44 KTC3206-Y,O OR 2SC2229-Y,O KTC3206-Y,O OR 2SC2229-Y,O Q5050-54 KTC3199-GR,2SC1740S-R,S,2SC2458-GR KTC3200-BL,GR OR 2SC1775A-E,F OR 2SC1845-E,F

SR

SL

NAAF-7866

NF

-B1

+B1

B+

B-

NF

-B1

+B1

B+

B-

U08

DRIVER AMPLIFIER PC BOARD

Refer to the following table about the parts displayed by mark" "

<Notes> NC=No mount of parts. [ ] Values are for HT-R420

NOTE

.

THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY

REPLACE ONLY WITH PART NUMBER SPECIFIED. .

VOLTAGE (MEASURED WITHVOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL)

.

ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED.

.

ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED.

.

ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED.

.

ELECTROLYTIC CAPACITORS ( )ARE IN u F/WV.

.

ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.

EX) 030- 3pF 330- 33pF 331- 330pF333- 0.033uF .

ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.

.

THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.

EX) PRINTING SIDE .

CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.

.

IS DC VOLTAGE, AT NO INPUT SIGNAL.

NC

TX-SR402/8240/HT-R420TX-SR402/8240/HT-R420

Q5012Q5002

Q5042

Q5052

Q5011Q5001

Q5041

Q5051

Q5010Q5000

Q5040

Q5050

Q5032

Q5031

Q5030Q5033

R5012

56K

R5002 1K

R5022

330

R5062

1.2K

R5162

120 (1/4W)

R5132

18K

R5172 120(1/4W)

R5032

56K

R5082

3.3K

R5112

1K

R5092

82K

[100K]

R5052

4.7K

R5072

560

R5102

100K

R5182

10

(1/4W)

R5192

10

(1/4W)

R5042

2.2K

R5011

56K

R5001 1K

R5021

330

R5061

1.2K

R5161

120 (1/4W)

R5131 18K

R5171

120(1/4W)

R5031 56K

R5081

3.3K

R5111

1K

R5091 82K [100K]

R5051

4.7K

R5071

560

R5101 100K

R5181 10 (1/4W)

R5191

10

(1/4W)

R5041

2.2K

R5010

56K

R5000 1K

R5020 330

R5060

1.2K

R5160

120 (1/4W)

R5130

18K

R5170

120(1/4W)

R5030

56K

R5080

3.3K

R5110 1K

R5090 82K [100K]

R5050

4.7K

R5070

560

R5100

100K

R5180

10

(1/4W)

R5190

10

(1/4W)

R50402.2K

C5012 22/16

C5042 220/16 [100/16]

C5052 47/50

C5112 10/63

[10/100]

C5102 10/63 [10/100]

C5022 10/50

C5011 22/16

C5041

220/16

[100/16]

C5051 47/50

C5111 10/63 [10/100]

C5101 10/63 [10/100]

C5021 10/50

C5010 22/16

C5040

220/16

[100/16]

C5050 47/50

C5110 10/63 [10/100]

C5100 10/63 [10/100]

C5020 10/50

C5002

101K

C5082

040D

C5092

101J

C5032

C5001

101K

C5081 040D

C5091

101J

C5031

C5000

101K

C5080 040D

C5090 101J

C5030

P6002A

TO NAAF-7875

P6001A

TO NAAF-7875

P6000A

TO NAAF-7875

C5072

C5071

C5070

D5002

MTZJ5.6B

D5001 MTZJ5.6B

D5000

MTZJ5.6B

48.9V

[62.1V]

-48.9V

[-62.1V]

47.5V

[60.7V]

48.1V

[61.5V]

-43.3V

[-56.5V]

-48.1V

[-61.4V]

-44V

[-57.1V]

1.0V

[1.0V]

-47.5V

[-60.6V]

0V

[0V]

-0.1V

-1V

[-1V]

-0.7V

48.9V

[62.1V]

-48.9V

[-62.1V]

47.5V

[60.7V]

48.1V

[61.5V]

-43.3V

[-56.5V]

-48.1V

[-61.4V]

-44V

[-57.1V]

1.0V

[1.0V]

-47.5V

[-60.6V]

0V

[0V]

-0.1V

-1V

[-1V]

-0.7V

48.9V

[62.1V]

-48.9V

[-62.1V]

47.5V

[60.7V]

48.1V

[61.5V]

-43.3V

[-56.5V]

-48.1V

[-61.4V]

-44V

[-57.1V]

1.0V

[1.0V]

-47.5V

[-60.6V]

0V

[0V]

-0.1V

-1V

[-1V]

-0.7V

P6011A

TO NAAF-7875

P306A

TO NADG-7401

ECESLESRERE

L

E E E E E E E E E

L

R

C

NF

-B1

+B1

B+

B-

NF

-B1

+B1

B+

B-

NF

-B1

+B1

B+

B-

NC

SCHEMATIC DIAGRAMS-4

POWER AMPLIFIER SECTION

A

1

2

3

4

5

BCDEFGH

P6011

JL6952A

TO NAPS-7878

JL6951A

TO NAPS-7878

F6901

F6902

RL6901

RL6902

D6903

RS603M

RBV602 D5SBA20

D6903,6904:

D6904

0.1V [0.1V]

0.8V

[0.8V]

-48.9V

[-62.1V]

-0.5V

[-0.5V]

0.5V

[0.5V]

1.1V

[1.1V]

-1.1V

[-1.1V]

-0.5V

[-0.5V]

1V

[1V]

0.2V

[0.2V]

-0.3V

[-0.3V]

-0.3V

[-0.3V]

48.9V

[62.1V]

0V

[0V]

0V

[0V]

0.5V

[0.5V]

-48.9V

[-62.1V]

-0.5V

[-0.5V]

0.5V

[0.5V]

1.1V

[1.1V]

-1.1V

[-1.1V]

-0.5V

[-0.5V]

1V

[1V]

0.2V

[0.2V]

-0.3V

[-0.3V]

-0.3V

[-0.3V]

48.9V

[62.1V]

0V

[0V]

0V

[0V]

0.5V

[0.5V]

Q6901

Q6034

Q6074

Q6024

Q6014

Q6054

Q6033

Q6073

Q6023

Q6013

Q6053

R6902 1K

R6054

3.9K

R6084

2.2

(1/4W)

R6074

100

[110]

(1/4W)

R6134

R6234

8.2 (1W)

R6014

3.9K

R6004

5.6K

R6034

1K

[390]

R6164

33K

R6094

2.2

(1/4W)

R6154

12K

R6144 22K

R6194

220K

[330K]

R6174 47K

R6184

47K

R6053

3.9K

R6083

2.2

(1/4W)

R6073

100

[110]

(1/4W)

R6133

R6233

8.2 (1W)

R6013

3.9K

R6003

5.6K

R6033

1K

[390]

R6163

33K

R6093

2.2

(1/4W)

R6153

12K

R6143 22K

R6193

220K

[330K]

R6173 47K

R6183

47K

C6902

C6901

8200/56

C6901, 6902 TX-SR402/ 8240 -----

10000/69HT-R420 ---------------

C6044 47/50

C6043 47/50

C6906 104J

C6907 104J

C6905 334J [334J /100]

C6904 334J [334J /100]

C6034

C6234

473J

C6033

C6233

473J

R6044

1K

IID

R6043

1K

IID

R6104

0.22 X2 (2W)

R6103

0.22 X2 (2W)

D6906

D6705

D6706

D6902

D6901

D6014

D6004

D6013

D6003

R6024

R6023

P6004

TO NAAF-7866

P6003

TO NAAF-7866

P931

TO NAPS-7877

Q6044

Q6064

Q6043

Q6063

C6903 104J

C6920

C6708 223Z

P6906

P6084

ID+

ID-

P6083

ID+

ID-

NF

-B1

E -B1

+B1

E +B1

B+

EB+

B-

EB-

E

NF NF

-B1 -B1

+B1 +B1

B+ B+

B- B-

+13VS SPF

+13VS +13VS PRO

MPUGND POWER

MPUGND +13VS

POWER POWER RLGND

F6901TYPE F6902

DD, DC 8A-UL,8A-T/UL-ST2 8A-UL,8A-T/UL-ST2

PA, PT 8A-EAK 8A-EAK

GR 8A-EAK 8A-EAK

WT 8A-EAK 8A-EAK

NO. TX-SR402/TX-SR8240 HT-R420

Q6010-6014 2SC1740S-R,S 2SC1740S-R,S

Q6020-6024 2SC1740S-R,S 2SC1740S-R,S

Q6030-6031 KTD2061-Y OR 2SC5171 KTD2061-Y OR 2SC5171

Q6040-6041 KTB1369-Y OR 2SA1930 KTB1369-Y OR 2SA1930

Q6032-6034 2SC5511-E OR KTD2061-Y OR 2SC5171 KTD2061-Y OR 2SC5171

Q6042-6044 2SA2005-E OR KTB1369-Y OR 2SA1930 KTB1369-Y OR 2SA1930

Q6050-6051 2SC5198-R,O OR MN130S-Y,P,O 2SC5242-R,O OR MN150S-Y,P,O

Q6052-6054 MN100S-Y,P,O OR KTD1047-Y,O KTC5242-O,R OR MN130S-Y,P,O OR 2SC5242-O,R

Q6060-6061 2SA1941-R,O OR MP130S-Y,P,O 2SA1962-R,O OR MP150S-Y,P,O

Q6062-6064 MP100P-Y,P,O OR KTB817-Y,O KTA1962-O,R OR MP130S-Y,P,O OR 2SA1962-O,R

Q6070-6074 KTC3200-BL,GR OR 2SC1775A-E,F OR 2SC1845-E,F 2SC2631-R,S

Q6601-6603,Q6901 KTC3199-GR,2SC1740S-R,S,2SC2458-GR KTC3199-GR,2SC1740S-R,S,2SC2458-GR

Q6701,6702 KTC3200-BL,GR OR 2SC1775A-E,F OR 2SC1845-E,F KTC3200-BL,GR OR 2SC1775A-E,F OR 2SC1845-E,F

Q6703 KTA1268-GR,BL OR 2SA992-E,F KTA1268-GR,BL OR 2SA992-E,F

Q6303 KTA1267-GR OR 2SA933S-R,S KTA1267-GR OR 2SA933S-R,S

SR

SL

NONE

NAAF-7875

NC

U17

POWER AMPLIFIER PC BOARD

Refer to the following table about the parts displayed by mark" "

<Notes> NC=No mount of parts. [ ] Varues are for HT-R420

Refer to the following table about the parts displayed by mark" "

NOTE

.

THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY

REPLACE ONLY WITH PART NUMBER SPECIFIED. .

VOLTAGE (MEASURED WITHVOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL)

.

ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED.

.

ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED.

.

ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED.

.

ELECTROLYTIC CAPACITORS ( )ARE IN u F/WV.

.

ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.

EX) 030- 3pF 330- 33pF 331- 330pF333- 0.033uF .

ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.

.

THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.

EX) PRINTING SIDE .

CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.

.

IS DC VOLTAGE, AT NO INPUT SIGNAL.

TX-SR402/8240/HT-R420TX-SR402/8240/HT-R420

P6011

TO NAAF-7866

JL6805A

TO NAETC-7870

P6931

TO NAETC-7868

JL6804A

TO NAETC-7870

JL6803A

TO NAETC-7870

D6703

MTZJ5.1B D6704

MTZJ5.1B

0V

24V

0.8V

24V

0V

[0V]

0V

[0V]

0.05V

50V

[63.1V]

48.9V

[62.1V]

48.9V

[62.1V]

-48.9V

[-62.1V]

-0.5V

[-0.5V]

1.1V

[1.1V]

-1.1V

[-1.1V]

-0.5V

[-0.5V]

1V

[1V]

0.2V

[0.2V]

-0.3V

[-0.3V]

-0.3V

[-0.3V]

48.9V

[62.1V]

0V

[0V]

0V

[0V]

0.5V

[0.5V]

-48.9V

[-62.1V]

-0.5V

[-0.5V]

1.1V

[1.1V]

-1.1V

[-1.1V]

1V

[1V]

0.2V

[0.2V]

-0.3V

[-0.3V]

-0.3V

[-0.3V]

48.9V

[62.1V]

0V

[0V]

0V

[0V]

-48.9V

[-62.1V]

-0.5V

[-0.5V]

0.5V

[0.5V]

1.1V

[1.1V]

-1.1V

[-1.1V]

1V

[1V]

0.2V

[0.2V]

-0.3V

[-0.3V]

-0.3V

[-0.3V]

48.9V

[62.1V]

0V

[0V]

0V

[0V]

0.5V

[0.5V]

Q6701 Q6702

Q6602Q6603Q6601

Q6032

Q6072

Q6022

Q6012

Q6052

Q6031

Q6071

Q6021

Q6011

Q6051

Q6030

Q6070

Q6020

Q6010

Q6050

R6308

4.7K

R6602

1K

R6603

1K

R6601

1K

R6704

47K

R6701

22K

R6702

10K

R6710

56K

[12K]

R6709 5.6K

R6706

220K

R6708

33K

R6850

390

(1/2W)

R6851

390

(1/2W)

R6306

10K

R6307

2.2K

R6052

3.9K

R6082

2.2

(1/4W)

R6072

100

[110]

(1/4W)

R6132

R6232

8.2 (1W)

R6012

3.9K

R6002

5.6K

R6032

1K

[390]

R6162

33K

R6092

2.2

(1/4W)

R6152

12K

R6142 22K

R6192

220K

[330K]

R6172 47K

R6182

47K

R6051

3.9K

R6081

2.2

(1/4W)

R6071

100

[110]

(1/4W)

R6131

R6231

8.2 (1W)

R6011

3.9K

R6001

5.6K

R6031

1K

[390]

R6161

33K

R6091

2.2

(1/4W)

R6151

12K

R6141 22K

R6191

220K

[330K]

R6171 47K

R6181

47K

R6050

3.9K

R6080

2.2

(1/4W)

R6070

100

[110]

(1/4W)

R6130

R6230

8.2 (1W)

R6010

3.9K

R6000

5.6K

R6030

1K

[390]

R6160

33K

R6090

2.2

(1/4W)

R6150

12K

R6140 22K

R6190

220K

[330K]

R6170 47K

R6180

47K

C6701

100/6.3

[220/6.3]

C6704

1/50

C6706

100/6.3

C6042 47/50

C6041 47/50

C6040 47/50

C6032

C6232

473J

C6031

C6231

473J

C6030

C6230

473J

R6042

1K

IID

R6041

1K

IID

R6040

1K

IID

R6102

0.22 X2 (2W)

R6101

0.22 X2 (2W)

R6100

0.22 X2 (2W)

D6702

D6701

D6307

D6306

D6012

D6002

D6011

D6001

D6010

D6000

R6022

R6021

R6020

P6002

TO NAAF-7866

P6001

TO NAAF-7866

P6000

TO NAAF-7866

Q6042

Q6062

Q6041

Q6061

Q6040

Q6060

Q6703

Q6303

C6703

223Z

R6380

PTFL04BE471Q 2N34B0(90)

THERMAL SENS.

R6380

PTFL04BE471Q 2N34B0(90)

THERMAL SENS.

P6082

ID+

ID-

P6081

ID+

ID-

P6080

ID+

ID-

P6301

TH1

COM

JL6402C

TX-SR8240 MGR TX-SR402 MGR HT-R420 MPA, MPT, MWT

JL6402B

HT-R420 MDC,MDD

JL6402A

NF

+24V

TH1

NF

-B1

+B1

B+

B-

BRLD

+B1

FRLD

CSRLD

+24V

HPL

HPR

E

+24V

MPUGND

VOLH/THPRO

SEC1H

SPB

SPCS

NAETC-8256

NAETC-7880

RSSPE

LSSPE

CSPE

RSPE

LSPE

RSSP

LSSP

CSP

RSP

LSP

C

R

L

U26

THERMAL SENSOR PC BOARD

U22

THERMAL SENSOR PC BOARD

0.5V

[0.5V]

-0.5V

[-0.5V]

24V

0V0V

0.5V

[0.5V]

0.5V

[0.5V]

-0.5V

[-0.5V]

SCHEMATIC DIAGRAM-5

SPEAKER TERMINAL & POWER SUPPLY SECTION

A

1

2

3

4

5

BCDEFGH

P6800

FRONT SPEAKERS-A

FRONT SPEAKERS-B

L

R

L

R

0.1V

[0.1V]

R923

1K

L6800 S1.3C

TX-SR402 ONLY

L6801 S1.3C

TX-SR402 ONLY

L6802 S1.3C

TX-SR402 ONLY

L6803 S1.3C

TX-SR402 ONLY

L6804 S1.3C

TX-SR402 ONLY

P931A

TO NNAF-7875

RL901

RL6600

RL6601

RL6603

RL6604

C923

223Z

C921

223Z

C6856

102K

C6855

102K

C6851

102K

C6850 102K

C6841 102J

C6840 102J

C901 103M /275VAC

C902 472M

/250VAC

NC

C6842 102J

P/W/G TYPE ONLY

C6843 102J

C6844 102J

C6852

102K

C6853

102K

C6854

102K

C6600 103J

C6601 103Z

C6604 103J

D924

D922

D923

D921-D924 GP104003E OR RL1N4003

D921

D925

D6600

D6601

D6604

J5320

J

HT-R420 ONLY

J

HT-R420 ONLY

J6306

J

HT-R420 ONLY

J

HT-R420 ONLY

J

HT-R420 ONLY

R924 82

(1/2W)

R926

4.7K

R921

R6810 22

R6800 22

R6811 22

R6801 22

R6812 22

R6802 22

R6813 22

R6803 22

R6814 22

R6804 22

F902

F903

T2.5AL250V

F902

F903

T2.5AL250V

F903

5A/125V

F901

F902

F901

F903

T2.5AL250V

C922

220/35

P911

P911A

P912AP912

P911

P911A

P912AP912

P911 P911A

P913A

P912A

P913

P912

P911A

P912A

P911

P918

P917

P918A

P917A

Q921

2SC2458-GR KTC3199-GR 2SC1740S-R,S

P901A

AC-H

AC-G

T902

PA, PT TYPE

T902

GR TYPE

T902

WT TYPE

T902

HT-R420

SEE LEFT DIAGRAM

FOR OTHER TYPE

P901

S906

POWER

NO USE

NC

S902

VOLTAGE

SELECTOR

220V

120V

T901

THERMAL FUSE

T901

THERMAL FUSE

T901

THERMAL FUSE

P6802

SPEAKER

CENTER

L

R

SURROUND SPEAKERS

JL6803B

TO NAAF-7875

JL6804B

TO NAAF-7875

JL6805B

TO NAAF-7875

E921

NOTE

.

THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY

REPLACE ONLY WITH PART NUMBER SPECIFIED. .

VOLTAGE (MEASURED WITHVOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL)

.

ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED.

.

ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED.

.

ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED.

.

ELECTROLYTIC CAPACITORS ( )ARE IN u F/WV.

.

ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.

EX) 030- 3pF 330- 33pF 331- 330pF333- 0.033uF .

ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.

.

THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.

EX) PRINTING SIDE .

CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.

.

IS DC VOLTAGE, AT NO INPUT SIGNAL.

THIS SYMBOL LOCATED NEAR THE FUSE INDICATES THAT THE FUSE USED IS SLOW OPERATING TYPE FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL

CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST E LENT. POUR UNE PROTECTION PERMANENTE,N'UTILISER QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE.

P902

AC OUTLET 100WMAX

P902

D:120W

AC OUTLET

1A MAX

P902

AC OUTLET

100WMAX

P902

AC OUTLET

100WMAX

LSP

RSP

CSP

LSSP

RSSP

BRLD

FRLD

CSRLD

+24V

LSPE

RSPE

CSPE

LSSPE

RSSPE

+13VS

MPUGND

POWER

7

1

3

7

HT-R420

TYPE F901

F902

DD, DC 8A/125VNONO

PA, PT T3.15AL250V

WT 8A/125V T3.15AL250V

TX-SR402/TX-SR8240

TYPE F901 F902

DD, DC - -

PA, PT - -

GR NO T3.15AL250V

JJ - -

WT - -

TYPE AC IN

DD, DC 120V 60HZ

PA, PT 230-240V 50HZ

GR 220V 50/60HZ

JJ -

WT 120V/220V 50/60HZ

T901

TYPE TX-SR402/8240 HT-R420 DD, DC PA, PT GR JJ WT

T902

TYPE

DD, DC NPT-1492D

PA, PT NPT-1358P

GR NPT-1358DG

JJ -

WT NPT-1358DG

NAPS-7876

NASW-7882

NAPS-7877

NAETC-7870

U12

SPEAKER TERMINAL PC BOARD

U18

TERMINAL PC BOARD

U19

POWER SUPPLY PC BOARD

Refer to the following table about the parts displayed by mark" "

<Notes> NC=No mount of parts.

[ ] VALUES ARE FOR HT-R420

Refer to the following table about the parts displayed by mark" "

TX-SR402/8240/HT-R420TX-SR402/8240/HT-R420

TO NNAF-7875

C6932

103Z

D6932

D6932,6933:

GP104003E OR

RL1N4003

D6933

C9513 223Z

R9501

1 (1/2W)

R9502

0.47 (1/2W)

R9521

2.7 [3.9] (1/2W)

R9503

0.22 (1/2W)

R6935

120

(2W)

F9501

NC

C6931

1000/25

C6933 10/16

8

9

10

11

12

13

14

P911A

P912A

18

17

16

15

19

Q6931

NJM78M56FA

G

IO

T901

THERMAL FUSE

JL6951B

TO NAAF-7875

JL6952B

TO NAAF-7875

P6931A

TO NAAF-7875

VA

FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH FUSE OF SAME TYPE AND RATING INDICATED.

CAUTION

ATTENTION

VA

AFIN D'ASSURER UNE PROTECTION PERMANENTE CONTRE LES RISQUES D'INCENDIE, REMPLACER UNIQUEMENT PAR UN FUSIBLE DE MEME TYPE ET CALIBRATION COMME INDIQUE.

JL9501

JL9501B

P411A

TO NADG-7401

P410A

TO NADG-7401

P7503B

TO NADIS-7403

FLAC1

FLAC2

MPUGND

HPL

AGND

HPR

+5.6V

+24V

S3

S3GND

S3

S2

+5.6V

POWER

SPF

SPCS

SE1H

SPB

VOLH/THPRO

PRO

MPUGND

+13VS

VOLH/THPRO

MPUGND

S3GND

+13VS

POWER

PRO

SPF

SPCS

SPB

SE1H

+24V

AGND

HPR

HPL

3

7

-

NPT-1491D

-

NPT-1491P

NPT-1463G -

--

-

NPT-1491DG

NAPS-7878

NAPS-7876

NAETC-7869

NAETC-7868

U10

REGULATOR PC BOARD

U11

TERMINAL PC BOARD

U20

TERMINAL PC BOARD

TX-SR402/8240/HT-R420

P101

P306

P801

P410B

P411B

P7502B

P305

P302P304

P301

JL6402B

JL6803A

JL6804A

P6011

P6931

P931

JL6952A

JL6951A

P6072A

JL6805A

JL6402A

C6902

C6901

P6004

P6003

P6002

P6001

P6000

P6073A

P6908

P7501

JL7502B

JL7501B

JL7502A

JL7501A

P7502A

P7503A

Q7501

S7501

U7501

P6931A

P7503B

P410A

P411A

JL9501

AC IN

TUNER UNIT

AM ANTFM ANT

P6072

P801B P206A

P210B

P211A

P901A

S902

P911

P931A

P912

P911A

P912A

JL6952B

JL6951B

JL9501B

U12

NAETC-7870

SPEAKER TERMINAL PC BOARD

U15

NAVD-7873

S VIDEO TERMINAL PC BOARD

U16

NAETC-7874

TERMINAL PC BOARD

U25

NAETC-7884

TERMINAL PC BOARD

U01

NADG-7401

PREAMPLIFIER PC BOARD

U08

NAAF-7866

DRIVER AMPLIFIER PC BOARD

U02

NADIS-7403

DISPLAY PC BOARD

U04

NAETC-7405

HEADPHONE JACK PC BOARD

U03

NASW-7404

SWITCH PC BOARD

U10

NAETC-7868

REGULATOR PC BOARD

U20

NAPS-7878

TERMINAL PC BOARD

U18

NAPS-7876

TERMINAL PC BOARD

U26

NAETC-8256

THERMAL SENSOR PC BOARD

U22

NAETC-7880

THERMAL SENSOR PC BOARD

U23

NAETC-7881

HOLDER PC BOARD

U19

NAPS-7877

POWER SUPPLY PC BOARD

U17

NAAF-7875

POWER AMPLIFIER PC BOARD

U11

NAETC-7869

TERMINAL PC BOARD

U09

NAVD-7867

VIDEO&OPT TERMINAL PC BOARD

JUMPER WIRE SOCKET

FLAT CABLE BOARD TO BOARD

P211B

P204

P203

RL6600

JL6805B

RL6603

JL6803B

JL6804B

P6801 P6800

P206B

P281

P210A

P202

P201

FL TUBE

POWER TRANSFORMER

P902P902

HT-R420 MDC,MDD ONLY

TX-SR8240 MGR HT-R420 MPA,MWT TX-SR402 MGR ONLY

P6011A

P6073

P6000A

P6001A

P6002A

P6003A

P6004A

P406A

P306A

P351

JL6402C

PC BOARD CONNECTION DIAGRAM

PRINTED CIRCUIT BOARD VIEWS-1

TX-SR402/8240/HT-R420

A

1

2

3

4

5

BCD

01

C10

103CC

C

000

C183

C184

5

C185

C186

C

C187

2

3

023

4

5

67890

3

2

21

6

C

327

C328

C329

C3

C330

C331

331

C333

C334

C335CC3

C336

C

C337

C338

C

C339

C340

C3412C342

C343C4

C344

C347

C

34834

C350

1

35

4

C360

C361

12C

C3673C

C

C371C3371

C372

72

C373

C

C374

C33737

37676C37

C7010C

1

2

C703

C04

CC70505CC70707

C

71

1

716

6

C720

C721

C726C77262

C727C2

7

C72828

99C772

C730

C

731

C732732

C800

C801

803

C806

806

0

C807

80

9

C811

C812

8133C

8144C

815

C

4 8

3

835

C8400C841CC842

2

C84CC843

3

C8444C

84545C84

2

640

9

00

1

2

4

7

C9508

C95

1

0C951

70

D77

0

2

95

0

0101

80

4

01

301

P34

30

5

306

51P

P351

1P

01

8

Q303

30

7

8

0

706

6

7003

700

4

9

1

2

3

888

8

R

300

0

3

7

2

7

20

321

24

32

R

34

5

6

3

4

2

385

2

7

0

7

05

706

6

7

789

7

0

1

2

3

4

5

6

7

1

72

5

1

2

3

4

5

3

746

748

749

0

75

5

7

5

8

0

816

81

8

819

R82

0

3

837

4

1

84

3845

1

853

64

0

64

0

64

0

700

412

5

6

7

8

9

000

3

0

70

705

8

06

07

0

07

7

9

5

95

0

9

80

1

0

1

5

1

0

7

Q7008

331344

39

6

74

374

C

1

U1 PREAMPLIFIER

PC BOARD (NADG-7401)

Both side view from component side

PRINTED CIRCUIT BOARD VIEWS-2

TX-SR402/8240/HT-R420

A

1

2

3

4

5

BCD

000

2

3

023

4

5

67890

3

2

321

3

6

2

7

332

50

35

1

4

360

365

7

2

711

716

6

9

173

73

2

803

3

4

5

4

836

3

4

2

853

4

09

08

5

0

95

1

0

1

801

770

2

950

4

D

9

4

0

P3

0

4

3

0305

306

1

351

80

1

P41

502BB

8

303

307

7

8

0

706

10

0

1

406

7004

9

0

123

5

6

300

0

3

2

7

20

R

3

21

32

3

4 48

3

67

6

8

69

7

0

8

38

2

385

705

1

7

1

72

5

748

75

5

7

5

80

6

7

816

R81

8R819

R82

0

R84

3

4

02

404

0

00

7004

1

2

5

6

7

9

000

3

0

7054

7

058

06

07

0

07

7

9

5

801

D9510

9511

22

7

0

7008

R

33

1

344

1

74

374

C

1

U1 PREAMPLIFIER

PC BOARD (NADG-7401)

Both side view from reverce side

PRINTED CIRCUIT BOARD VIEWS-3

TX-SR402/8240/HT-R420

A

1

2

3

4

5

BCD

C7502

C7512

C7514

C7521

D7505

JL7501A

JL7502A

P7502A

P7503A

Q7501

R7580

R7581

R7582

S7501

S7611 S7612

S7613 S7621

S7622

S7623S7624

S7625

S7626

S7627

S7631

S7632 S7633

S7634

S7635

S7636

S7637

S7641

S7642

S7643

S7644

S7645

S7646

S7647

X7501

J7501

J7502

J7503

J7504

J7506

J7507

J7508

J7509

J7510

J7511

J7512

J7513

J7514

J7515

J7516

J7517

J7518

J7519

J7520

J7521

J7522

J7523

J7524

J7525

J7526

J7527

J7528

J7529

J7530

J7531

J7532

J7533

J7534

J7535

J7536

J7537

J7538

J7539

J7540

J7541

J7542

J7543

J7544

J7545

J7546

J7547

J7548

J7549

STEREO DIRECT

DSP SURROUND

PRESET

AUDIO

ADJUST

SP

ADJUST

CD

TUNER TAPE

TUNING TUNING

MEMORY

FM

MODE

DIGITAL

INPUT

SW

MODE

DIMMER DISPLAY

DVDVIDEO1VIDEO2

VIDEO3

AUDIO

SELECTER

U7501

-VP

GND

SYSIN

HPDET

SBMLDY

SBMDI

SBMDO

SBMCLK

SBMRST

HPMUT

+5.6V

HPR HPE HPL GND

GND FLAC FLAC

NCDIS-7403

25137403B

1

RL7501

J7550

J7551

J7552

J7553

J7554

UP DOWN

ADJUST

HPR

HPE

HPL

GND

HPDET

2

2 2

22222

22

2 2 2

222

22

2 2

2

12

15

12

7

20

17

12

22

7

17

27

30

15

22

7

20

15

7

15

7

12

VOUT

VCC

GND

12

7

15

U2 DISPLAY PC BOARD

(NADIS-7403)

Component side view from soldering side

PRINTED CIRCUIT BOARD VIEWS-4

TX-SR402/8240/HT-R420

A

1

2

3

4

5

BCD

C7501

C7503

C7504

C7505

C7506

C7507

C7508

C7509

C7510

C7511

C7513

C7515

C7516

C7517

D7501

D7502

D7503

D7507

L7504

L7505

Q7502

Q7503

Q7504

Q7506

R7501

R7502

R7503

R7504

R7505

R7506

R7507

R7508

R7509

R7510

R7511

R7513

R7514

R7515

R7516

R7517 R7518

R7520

R7521

R7522

R7523

R7524

R7526

R7527

R7528

R7529

R7530

R7531

R7532

R7611

R7612

R7646

R7621

R7622

R7623

R7624

R7625

R7626

R7631

R7632

R7633

R7634

R7635

R7636

R7641

R7642

R7643

R7644

R7645

Q7507

R7512

1

21

41

61

-VP

HPMUT SBMRST SBMCLK SBMDO SBMDI

SBMLDY HPDET

SYSIN

GND

FLAC

GND

HPL

HPE

HPR

+5.6V

D7504

C7523

C7522

R7519

U2 DISPLAY PC BOARD

(NADIS-7403)

Soldering side view

PRINTED CIRCUIT BOARD VIEWS-5

TX-SR402/8240/HT-R420

A

1

2

3

4

5

BCD

R7613

R7614

R7615

L7503

L7502

L7501

C7519

C7520

C7518

R

L

S7616 S7615

S7614

JL7501B

STANDBY

SPA SPB

NCSW-7404

25137404

0

P7501

JL7502B

J7572

J7573

J7571

E7501

NCETC-7405

25137405

0

R

L

J7574

J5026

J5030J5038

J5041

P5001

J5025

NCAF-7866

25137866A

1

L

R

C

LS

RS

E

J5004

J5005

P6011A

J5001

J5010

J5009

J5011

J5008

J5006

J5014

J5007

J5016

J5012

J5013

J5017

J5018

J5015

J5019

J5020

J5027

J5031

J5032

J5023

J5037

J5024

P6073

C5040

C5010

R5010

R5000

R5020

C5030

R5030

C5080

Q5000

Q5010

R5160

C5070

R5050

Q5030

C5000

B

E

C5050

C5020

R5080

R5070

Q5040

R5170

P6000A

B-

B+

NF

+B1

-B1

R5190

R5180

C5100

C5110

J5002

R5110

R5130

C5090

BBE

E

Q5050

D5000

R5100

R5090

R5060

J5003

B

E

C5041

C5011

R5011

R5001

R5021

R5041

C5031

R5031

C5081

Q5001

Q5011

R5161

C5071

R5051

Q5031

C5001

B

E

C5051

C5021

R5081

R5071

Q5041

R5171

P6001A

B-

B+

NF

+B1

-B1

R5191

R5181

C5101

C5111

J5021

R5111

R5131

C5091

BBE

E

Q5051

D5001

R5101

R5091

R5061

J5022

B

E

C5042

C5012

R5012

R5002

R5022

R5042

C5032

R5032

C5082

Q5002

Q5012

R5162

C5072

R5052

Q5032

C5002

B

E

C5052

C5022

R5082

R5072

Q5042

R5172

P6002A

B-

B+

NF

+B1

-B1

R5192

R5182

C5102

C5112

J5028

R5112

R5132

C5092

BBE

E

Q5052

D5002

R5102

R5092

R5062

J5029

B

E

C5043

C5013

R5013

R5003

R5023

R5043

C5033

R5033

C5083

Q5003

Q5013

R5163

C5073

R5053

Q5033

C5003

B

E

C5053

C5023

R5083

R5073

Q5043

R5173

P6003A

B-

B+

NF

+B1

-B1

R5193

R5183

C5103

C5113

J5036

R5113

R5133

C5093

BBE

E

Q5053

D5003

R5103

R5093

R5063

J5035

B

E

C5044

C5014

R5014

R5004

R5024

R5044

C5034

R5034

C5084

Q5004

Q5014

R5164

C5074

R5054

Q5034

C5004

B

E

C5054

C5024

R5084

R5074

Q5044

R5174

P6004A

B-

B+

NF

+B1

-B1

R5194

R5184

C5104

C5114

J5040

R5114

R5134

C5094

BBE

E

Q5054

D5004

R5104

R5094

R5064

J5042

B

E

P406A

R5040

P306A P306A

J5033

J5034

J5039

2

LRCLSRS

30121717 20

20

30

307

7 30

30

12

7

22

302020 1715

12

U3 SWITCH PC BOARD

(NASW-7404)

U4 HEADPHONE JACK PC BOARD

(NAETC-7405)

U8 DRIVER AMPLIFIER PC BOARD

(NAAF-7866)

Component side view from soldering side

Soldering side view

Component side view from soldering side

PRINTED CIRCUIT BOARD VIEWS-6

TX-SR402/8240/HT-R420

A

1

2

3

4

5

BCD

P6931A

P7503B

HPL

HPR

AGND

+24V

MPUGND

VOLH

SE1H

SPB

SPCS

SPF

PRO

POWER

+13VS

RLGND

R6932

C6933

D6933

C6932

D6932

R6935

P410A

P411A

+24V

S2 S2 S2 S2 S3 S3GND S3GND S3

+5.6V

MPUGND MPUGND

PRO

VOLH

SPB SE1H SPCS

SPF

POWER

+13VS

J5208

IO

25137868

NCETC-7868

0

Q6931

J5209

C6931

JL9501

R6933

J5217

J5215

J5216

J5207

J5202

J5203

J5204

J5205

J5206

FLAC1

FLAC2 MPUGND MPUGND

HPL

HPR

AGND

+5.6V

J5210

J5201

J5214

J5213

J5212

J5211

S2S2S3

S3

S3E

S4

OI

14 13 12 11 10 9 8

JL9501B

NCETC-7869

25137869

0

F9501B

F9501A

R9503

R9501

R9502

R9521

C9513

1.6A/125V

F9501

C201 C202C203

C204

C205

C217

C220

C221

C222

C227

C281

C282

C283

C284

C285

C286

C287

C288

D201

D202

L282

P206B

P281

Q201

Q202

Q203

Q204

Q205

Q206

R201 R202

R203

R204

R205

R206

R207

R208

R209

R210

R223

R224

R230

R281

R282

L283

R284

U281

J213

J214

+12V

GND

A

B

OPTOUT

COAX

OPT2

OPT1

DGND

+5V

RI

VM1

VM2

NCVD-7867

25137867 0

Q281

1

L281

P202

P201

J215

J209

R231

J204

J203

J201

J210

J211

J208

J212

J206

J207

J205

P210A

J202

GND

+12V

B

A

VMUT2

VMUT1

P282

P253A

1

7

17

25

17

30

20

12

15

7

12

7

17

U9 VIDEO & OPT TERMINAL PC BOARD

(NAVD-7867)

U10 REGULATOR PC BOARD

(NAETC-7868)

U11 TERMINAL PC BOARD

(NAETC-7869)

Component side view from soldering side

PRINTED CIRCUIT BOARD VIEWS-7

TX-SR402/8240/HT-R420

A

1

2

3

4

5

BCD

P6801

P6800

RL6600

RL6604

D6604

L6800

R6801

R6811

R6813

R6803

L6804

R6814

L6801

R6800

R6810

JL6805B

C6850

C6841C6851

C6853

C6855

C6856

RL6601

RL6603

C6604

C6852

C6842

R6812

R6802

L6803

C6840

L6802

C6843

C6844

JL6803B

JL6804B

C6854

LSP

RSP

CSP

LSSP

RSSP

LSPE

RSPE

CSPE

LSSPE

RSSPE

+24V

CSRLD

FRLD

BRLD

R6804

L+

L-

R+

R-

L+

R+

C+

L-

LS+

RS+

LS-

RS-

NCETC-7870

25137870

1

C6600

D6600

D6601

C6601

J5322

J5320

J5321

J5304

J5302

J5309

J5308

J5310

J5312

J5311

J5305

J5306

J5326

J5329

J5330

J5327

J5325

J5318

J5319

J5324

J5323J5316

J5317

J5314

J5307

J5313

J5332

J5334

J5328

J5331

C-

R-

J5335

J5333

J5315

J5301

J5303

C206

C207

C208

C209

C210

C211

C212

C213

C214

C215

C231

C232

C223

C224

C225

C226

Q207

Q208

Q209

Q210

Q211

Q212

Q213

R211

R212

R213

R214

R215

R216

R217

R218

R219

R220

R221

R222

R225

R226

R227

R228NCVD-7873

25137873

0

P204

P203

J237

J233

P211B

VMUT1

VMUT2

A

B

+12V

GND

J236

J231

J241

J240

J238

J232

J239

J234

J235

P210B

P211A

+12V

GND

CTLA

CTLB

VMUT2

VMUT1

NCETC-7874

25137874

0

17

7

20

15

12

22

12

25

22

15

20

12

15

22

30

15

717

7

12

20

15

12

7

20

7

25

7

12

22

25

7

U12

SPEAKER TERMINAL PC BOARD (NAETC-7870)

U15

S VIDEO TERMINAL PC BOARD (NAVD-7873)

U16

TERMINAL PC BOARD (NAETC-7874)

Component side view from soldering side

PRINTED CIRCUIT BOARD VIEWS-8

TX-SR402/8240/HT-R420

A

1

2

3

4

5

BCD

P6903

J6011

J6008

JL6803A

JL6804A

J6014

J6016

J6153 J6136 J6110 J6073

J6052

J6053

J6106

J6107

J6129

J6130

J6150

J6151

P6011

D6903

D6904

J6081

J6080

J6064

J6065

RL6901

RL6902

P6931

P931

JL6952A

JL6951A

J6060

J6061

J6076

J6077

J6058

J6023

J6022

J6079

J6082

J6063

J6062

Q6603

R6603

Q6602

D6906

Q6901

C6920

J6004

R6902

D6706

D6705

C6708

D6901

C6903

D6902

C6904C6905

R6904

R6905

C6906

C6907

R6706

C6704

D6703

R6704

Q6703

R6702

C6703

J6085

R6513

R6851

R6523

J6164

C6513

C6523

R6701

AGND

+24V

MPUGND

VOLH

SE1H

+13VS

SPB

SPCS

SPF

POWER

PRO

J6101

J6099

J6100

J6026

J6042

J6102

J6103

J6056

R6850

F6901A F6901B

F6902B

F6902A

J6040

J6059

J6025

J6024

+13VS

MPUGND

POWER

P6907

+B1

-B1

+B1

J6086

P6909

F6901

F6902

8A 125V

R6521 R6511

C6511

C6512

R6512R6522

C6522

J6138

J6143

J6031

J6033

J6034

J6029J6087

J6092

J6091

J6089J6119

J6121

J6116

J6114

J6160

J6161

J6168

HPL

HPR

J6167

C6510

C6520

R6510

R6520

RLGND

J6084

J6140

J6030

J6074J6118

J6137

J6159

J6155

J6125

J6133

J6112

J6097 J6038

J6057

C6521

J6015J6075J6113J6139

J6152

J6149

J6148

J6131

J6126

J6127

J6134

J6105

J6104

J6109

J6108 J6054

J6055

J6049

J6050

J6071 J6027

J6010

J6009

J6013

J6012

J6093

J6094

J6095

J6122

J6123

J6124

J6144

J6145

J6146

J6035

J6036

J6037

J6163

J6165

J6166

E

B

E

B

R6708

NCAF-7875

25137875A

J6170

1

J6002

J6001

J6018

J6019

J6017

J6039

J010

R6100

Q6050Q6060

J6032J6051

R6101

Q6051Q6061

J6090J6096

R6102

Q6052Q6062

J6120J6128

R6103

Q6053Q6063

J6142J6147

R6104

Q6054Q6064

J6162

J6169

J6045

J6047

R6605

J6005

J6006

P6922

P6923

J6067

J6066

J6044

J6046

J6007

R6230

R6231

R6234

R6232

R6233

C6230

C6231

C6232

C6233

C6234

J6043

+24V

CSRLD

FRLD

BRLD

Q6601

R6601

J011

J011A J010A

J6111J6132J6154

J6083

J6020

J6041

J6003

J6021

P6072A

J6068

C6706

D6704

R6710

R6709

C6701

JL6805A

Q6701

D6702

Q6702

D6701

Q6303

D6307

D6306

R6306

R6307

R6308

P6301

J6069

J6070

JL6402A

COM

TH1

+24V

TH1

LSP

RSP

CSP

LSSP

RSSP

LSPE

RSPE

CSPE

LSSPE

RSSPE

R6604

R6602

BBB

E

P6802

E

B

J6098

J6078

L

RCLSRS

P995A

P997A

P996A

P6906

P6801

C6902

C6901

P995B

J6156

B-

B+

+B1

-B1

NF

P6004

B-

B+

+B1

-B1

NF

P6003

B-

B+

+B1

-B1

NF

P6002

B-

B+

+B1

-B1

NF

P6001

B-

B+

+B1

-B1

NF

P6000

P6073A

BE

Q6010

R6080

ID-

R6140

BE

Q6070

R6150

C6050

J6048

B

ID+

Q6040

Q6030

R6070

C6040

R6030

R6040

R6050

Q6020

P6080

D6000

R6160

R6180

R6170

R6020

E

BIAS

R6090

B

R6000

R6010

J6028

BE

Q6013

R6083

ID-

R6143

BE

Q6073

R6153

C6053

J6141

B

ID+

Q6043

Q6033

R6073

C6043

R6033

R6043

R6053

Q6023

P6083

D6003

R6163

R6183

R6173

R6023

E

BIAS

R6093

B

R6003

R6013

J6135

BE

Q6012

R6082

ID-

R6142

BE

Q6072

R6152

C6052

J6117

B

ID+

Q6042

Q6032

R6072

C6042

R6032

R6042

R6052

Q6022

P6082

D6002

R6162

R6182

R6172

R6022

E

BIAS

R6092

B

R6002

R6012

J6115

BE

Q6011

R6081

ID-

R6141

BE

Q6071

R6151

C6051

J6088

B

ID+

Q6041

Q6031

R6071

C6041

R6031

R6041

R6051

Q6021

P6081

D6001

R6161

R6181

R6171

R6021

E

BIAS

R6091

B

R6001

R6011

J6072

BE

Q6014

R6084

ID-

R6144

BE

Q6074

R6154

C6054

J6158

B

ID+

Q6044

Q6034

R6074

C6044

R6034

R6044

R6054

Q6024

P6084

D6004

R6164

R6184

R6174

R6024

E

BIAS

R6094

B

R6004

R6014

J6157

P6908

P6910

R6190R6191R6192R6193R6194

D6014

D6013 D6012 D6011 D6010

C6908

C6909

BCEBCEBCEBCEBCEBCEBCEBCEBCEBCE

25 25 25 25 25

1717

12

25252525

12

30

27

30

7

15

7

20

15

25

30

7

12

7

25

27

17

20

17

30

17

30

17

30

17

30

17

30

17

20

17

20202020

20

1717

20

30

15

17

7

20

20 25 25 25 25

20 20 20 12121212

22

15

12

22

1230 12

222222 22

22

1230 30 12

222222

17

20

30

15

25

27

22

7

77 7 7

30

25

12

27

22

12

20

22

12

7

U17

POWER AMPLIFIER PC BOARD (NAAF-7875)

Component side view from soldering side

PRINTED CIRCUIT BOARD VIEWS-9

TX-SR402/8240/HT-R420

A

1

2

3

4

5

BCD

P902

P901A

P909 P908

T902

6.3A125V

AC-G

S902

J6309

P917

F902B

F902A

J6313

F901B

F901A

F903A

F903B

P918

P911

P922

P923

J6311

J6312

E921

J6317

J6316

RL901

C901

J6310

R901

J6301

J6303

D924

D923

R921

D921

C921

D922

C922

D925

R924

Q921

R923

C923

AC-H

T2.5AL250V

T3.15AL250V

P931A

J6304

J6305

C902

J6307

120V220V

B

E

POWER

MPUGND

+13VS

F903

F901

F902

R926

J6320

P921A

P921

P922A

P923A

P913

P912

J6314

J6306

J6319

J6318

J6302

J6315

NCPS-7877

25137877

1

P926

P925

R922

J6308

NNLL

AC-GAC-H

JL6402C

R6380A

+24V

TH1

+24V

25137880

NCETC-7880

1

P801B

P206A

+12V

GND

GND CTLA CTLB

VMUT2 VMUT1

RI

+5V

DGND

OPT2

OPT1

COAX

OPTOUT

J299

NCETC-7884

25137884

0

R6380

NCETC8256

0

25138256

JL6402B

TH1

+24V

P6380

+24V

P6072

NCETC-7881

25137881

0

JL6952B

JL6951B

J6403

J6412

J6402

J6413

J6408

J6409

J6401

J6405

J6406

J6404

J6407

J6410

J6411

P995

1918171615

P996

P997

NCPS-7878

25137878

0

P911A

P912A

P913A

731

25137876 NCPS-7876

0

5

J6201

J6202

J6203

1234

578

56789

7

15

7

30

17

15

25

17

30

7

22

15

12

7

12

15

17

15

20

U18

TERMINAL PC BOARD (NAPS-7876)

U20

TERMINAL PC BOARD (NAPS-7878)

U23

HOLDER PC BOARD (NAETC-7881)

U25

TERMINAL PC BOARD (NAETC-7884)

U26

THERMAL SENSOR PC BOARD (NAETC-8256)

U22

THERMAL SENSOR PC BOARD (NAETC-7880)

U19

POWER SUPPLY PC BOARD (NAPS-7877)

Component side view from soldering side

TX-SR402 MGR, TX-SR8240 MGR HT-R420 MPA, MWT, MPT ONLY

HT-R420 MDD, MDC ONLY

TX-SR402/8240/HT-R420

S2 (Pin 2)

H L H L

S3 (Pin 3)

H H L L

Vin1 (Pin 4)

ON OFF OFF OFF

Vin2 (Pin 6)

OFF ON OFF OFF

Vin3 (Pin 8)

OFF OFF ON OFF

Vin4 (Pin 9)

OFF OFF OFF ON

driver control

6dB amp

video switch (4input 1output)

123 4

VIDEO

OUT

A B VINI5GND6VIN27VCC8VIN39VIN4

IC BLOCK DIAGRAM AND TERMINAL DESCRIPTIONS-1

Q213:LA7956(Video switch)

BLOCK DIAGRAM

TRUTH TABLE

TX-SR402/8240/HT-R420

VEE

VCC

47k

47k 47k 47k 47k

47k

29

70

32

41

44

49

51

53

54

67

56

58

62

60

61

59

47

46 45

66

69

33

40

43

30

10

77

78

21 22

79

80

23 24

1 2

3 4 5 6 7 8 9

11 12

27

26

25

28

15

14

13

16

48

55

19 20

57

17 18

IN72

IN1DSP

IN1MIX

IN2DSP

IN2MIX

IN31 IN32

IN41 IN42 IN51 IN52 IN61 IN62 IN71

IN81 IN82

INDVDC

INDVDSL

INDVDSR1

INDVDSW

OUT1+

OUT1-

OUT2+

OUT2-

36

37

38

35

71

72

73

74

75

76

63

64

52

50

65

68

AGND10

AGND9

GOUT1

GOUT2

IN11

IN12

IN21

IN22

ROUT11

ROUT12

ROUT21

ROUT22

ROUT31

ROUT32

VIN1

VIN2

34

39

42

AGND3

GOUTSR

AGND5

AGND6

AGND7

AGND8

BBNF1

BBNF2

BNF11

BNF12

BNF21

BNF22

DA

DGND AGND4

VINSR

MUTE

OUT1

OUT2

TNF1

TNF2

VCC

VEE

VINSR

31

AGND1

AGND2

GOUTC

GOUTSL

GOUTSW

INDSPC

INDSPSL

INDSPSR

INDSPSW

OUTC

OUTSL

OUTSR

OUTSW

VINC

VINSL

VINSW

LOGIC

BASS

BOOST

BASS

TREBLE

5.1ch mode SW2 DVD

5.1ch mode SW1

Input mute SW

REC SW3

REC SW2

REC SW1

REC

INSW

LINE

L/R

MIX

LINE

L/R

MIX

1 2 3

5.1ch mode SW2 DSP

IC BLOCK DIAGRAM AND TERMINAL DESCRIPTIONS-2

Q301:BD3811K1 (6CH Volume with 8ch input selector)-1 BLOCK DIAGRAM

TX-SR402/8240/HT-R420

26 27 28 29 30 31 32 33 34 35 36 37 38 39 40

41 42 43

44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60

No.

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25

INDSPSL INDSPC INDSPSW AGND1 GOUTSW VINSW AGND2 GOUTC VINC OUTSW OUTC OUTSL OUTSR VINSL GOUTSL

AGND3 VINSR GOUTSR

AGND4 DGND DA CL MUTE AGND5 VEE AGND6 VCC AGND7 AGND8 OUT1 BBNF1 OUT2 BBNF2 BNF22 BNF12

Terminal

IN31 IN32 IN41 IN42 IN51 IN52 IN61 IN62 IN71 IN72 IN81 IN82 INDVDSR INDVDSL INDVDC INDVDSW OUT2(+) OUT2(-) OUT1(+) OUT1(-) IN1DSP IN1MIX IN2DSP IN2MIX INDSPSR

DSP surround Lch input terminal DSP center input terminal DSP sub woofer input terminal Analog ground terminal Sub woofer input gain output terminal Sub woofer volume input terminal Analog ground terminal Center input gain output terminal Center volume input terminal Sub woofer output terminal Center output terminal Surround Lch output terminal Surround Rch output terminal Surround Lch volume input terminal Surround Lch input gain output terminal

Analog ground terminal Surround Rch volume input terminal Surround Rch input gain output terminal

Analog ground terminal Ground terminal for comparator Serial data and latch input terminal Serial clock input terminal Mute terminal Analog ground terminal (-) Power supply terminal Analog ground terminal (+) Power supply terminal Analog ground terminal Analog ground terminal 1ch output terminal 1ch bass boost filter terminal 2ch output terminal 2ch bass boost filter terminal 2ch bass filter terminal 2 2ch bass filter terminal 1

Description

No. Terminal Description

1ch input terminal 3 2ch input terminal 3 1ch input terminal 4 2ch input terminal 4 1ch input terminal 5 2ch input terminal 5 1ch input terminal 6 2ch input terminal 6 1ch input terminal 7 2ch input terminal 7 1ch input terminal 8 2ch input terminal 8 DVD surround Rch input terminal DVD surround Lch input terminal DVD center input terminal DVD sub woofer input terminal 2ch (+) A/D output terminal 2ch (-) A/D output terminal 1ch (+) A/D output terminal 1ch (-) A/D output terminal 1ch DSP input terminal 1ch DSP MIX input terminal 2ch DSP input terminal 2ch DSP MIX input terminal DSP surround Rch input terminal

61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80

BNF21 BNF11 TNF1 TNF2 VIN1 GOUT1 AGND9 VIN2 GOUT2 AGND10 ROUT11 ROUT12 ROUT21 ROUT22 ROUT31 ROUT32 IN11 IN12 IN21 IN22

1ch bass filter terminal 2 1ch bass filter terminal 1 1ch treble filter terminal 1 2ch treble filter terminal 1 1ch(Lch) volume input terminal 1ch(Lch) input gain output terminal Analog ground terminal 2ch(Rch) volume input terminal 2ch(Rch) input gain output terminal Analog ground terminal 1ch recording input/output terminal 1 2ch recording input/output terminal 1 1ch recording output terminal 2 2ch recording output terminal 2 1ch recording output terminal 3 2ch recording output terminal 3 1ch input terminal 1 2ch input terminal 1 1ch input terminal 2 2ch input terminal 2

IC BLOCK DIAGRAM AND TERMINAL DESCRIPTIONS-3

Q301:BD3811K1 (6CH Volume with 8ch input selector)-2 TERMINAL DESCRIPTION

TX-SR402/8240/HT-R420

COMPRESSED

DATA INPUT

INTERFACE

DIGITAL

AUDIO INPUT

INTERFACE

PLL

CLOCK MANAGER

FRAMER SHIFTER

INPUT

BUFFER

CONTROLLER

RAM INPUT

BUFFER

PARALLEL or SERIAL HOST INTERFACE

24-BIT

DSP PROCESSING

RAM

PROGRAM

MEMORY

ROM

PROGRAM

MEMORY

RAM

DATA

MEMORY

ROM

DATA

MEMORY

STC

RAM OUTPUT BUFFER

OUTPUT

FORMATTER

RESET

DATA7:0, EMAD7:0,

GPIO7:0

CS

RD,

R/W,

EMOE,

GPIO11

WR,

DS, EMWR, GPIO10

SCDIO,

SCDOUT,

PSEL,

GPIO9

A0,

SCCLK

A1,

SCDIN

ABOOT,

INTREQ

EXTMEM,

GPIO8

DD

DC

MCLK

SCLK

LRCLK

AUDATA[2.0]

XMT958/AUDATA3

FILT2 FILT1 VA AGND DGND(3:1) VD(3:1)

CMPDAT, SDATAN2

CMPCLK, SCLKN2

CMPREQ, LRCLKN2

SCLKN1, STCCLK2

LRCLKN1

SDATAN1

CLKIN

CLKSEL

7

8

9

10

11

12

13

14

15

16

17

1819202122232425262728

4443424140

39

38

37

36

35

34

33

32

31

30

29

65432

1

A1,SCDIN

RD,R/W,EMOE,GPIO11

WR,DS,EMWR,GPIO10

AUDATA3,XMT958

DGND1

VD1

MCLK

SCLK

LRCLK

AUDATA0

AUDATA1

AUDATA2

DC

DD

RESET

AGND

VA

FILT1

FILT2

CLKSEL

CLKIN

CMPREQ,LRCLKN2

CS

SCDIO,SCDOUT,PSEL,GPIO9

INTREQ,ABOOT

EXTMEM,GPIO8

SDATAN1

VD3

DGND3

SCLKN1,STCCLK2

LRCLKN1

CMPDAT,SDATAN2,RCV958

CMPCLK,SCLKN2

A0,SCCLK

DATA7,EMAD7,GPIO7

DATA6,EMAD6,GPIO6

DATA5,EMAD5,GPIO5

DATA4,EMAD4,GPIO4

VD2

DGND2

DATA3,EMAD3,GPIO3

DATA2,EMAD2,GPIO2

DATA1,EMAD1,GPIO1

DATA0,EMAD0,GPIO0

PIN LAYOUT

IC BLOCK DIAGRAM AND TERMINAL DESCRIPTIONS-4

Q701:CS493264(DSP IC)-1

BLOCK DIAGRAM

TX-SR402/8240/HT-R420

37

38

39

40

41

42

43

44

DD

DC

AUDATA2

AUDATA1

AUDATA0

LRCLK

SCLK

MCLK

Reserved.

Digital audio output 2.

Digital audio output 1.

Digital audio output 0.

Audio output sample rate clock.

Audio output bit clock.

Audio master clock.

No.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

Symbol

VD1

DGMD1

AUDATA3,XMT958

WR,DS,EMWR,GPIO10

RD,R/W,EMOE,GPIO11

A1,SCDIN

A0,SCCLK

DATA7

DATA6

DATA5

DATA4

VD2

DGND2

DATA3

DATA2

DATA1

DATA0

CS

SCDIO,SCDOUT,PSEL, GPIO9

INREQ,ABOOT

Description No. Symbol Description

Digital positive suppy

Digital suppy ground

SPDIF transmitter output. Digital audio output.

Host write strobe or host data strobe or external memory write enable general purpose input & output number 10.

Host parallel output enable or host parallel R/W or external memory output enable or general purpose input & output number 11.

Host address bit one or SPI serial control data input.

Host parallel address bit zero or serial control port clock.

In parallel host mode these pins provide a bi-directional databus. If a serial host mode is selected, these pins can provide a multiplexed address and data bus for connecting an 8-bit external memory. Otherwise, in serial data host mode, these pins can act as general-purpose input or output pins that can be individually configured and controlled by this DSP.

Digital positive supply.

Digital supply ground.

In parallel host mode these pins provide a bi-directional data bus. If a serial host mode is selected, these pins can provide a multiplexed address and data bus for connecting an 8-bit external memory. Otherwise, in serial data host mode, these pins can act as general-purpose input or output pins that canbe individually configured and controlled by this DSP.

Host parallel chip select, host serial SPI chip select.

Serial control port data input and output, parallel port type select.

Control port interrupt request, automatic boot enable.

21

22

23

EXTMEM,GPIO8

SDATAN1

VD3

External memory chip select or general purpose input & output number 8.

PCM audio data input number one.

Digital positive supply.

26

27

28

29

30

31

32

33

34

35

36

24

25

LRCLKN1

CMPDAT, SDATAN2

CMPCLK,SCLKN2

CMPREQ

LRCLKN2

CLKIN

CLKSEL

FILT2

FILT1

VA

AGND

RESET

DGND3

SCLK1,STCLK2

PCM audio input sample rate clock.

PCM audio data input number two.

PCM audio input sample rate clock.

PCM audio input bit clock.

Master clock input pin.

DSP clock select pin.

Phase locked loop filter.

Analog positive supply.

Analog supply ground.

Master reset input.

Digital supply ground.

PCM audio data input bit clock.

IC BLOCK DIAGRAM AND TERMINAL DESCRIPTIONS-5

Q701:CS493264(DSP IC)-2

TERMINAL DESCRIPTION

TX-SR402/8240/HT-R420

HPF

ADC

LPF

DAC

Audio

I/F

XTI

MCLK

LIN

RIN

LOUT1

ROUT1

LOUT2

ROUT2

LOUT3

ROUT3

SDOUT

SDIN1

SDIN2

SDIN3

SDTO

SDTI1

SDTI2 SDTI3

DATT

BLCK

LRCK

BLCK

LRCK

XTO

X'tal

Oscillator

uP I/F

Clock

Generator

Input

Selector

RX1

RX2 RX3

RX4

DAIF

Decoder

Clock

Recovery

DEM

TX

MCKO

SD OUT

CSN

CCLK

CDTI

CDTO

XTO

PDN

1

XTI/EXTCLK

44

2

DVDD 3

DVSS 4

TVDD 5

TX 6

MCKO 7

LRCK 8

BICK

9

SDTO 10

SDTI1 11

RX143I2C

42

41

40

RX339SLAVE38RX437PVSS36R

PVDD

34

SDTI212SDTI3

13

INT014INT1

15

CAD1/CDTO

16

17

SCL/CCLK

18

CAD0/CSN

19

DZF2/OVF

20

AVSS

21

AVDD

22

33

32

31

30

29

28

27

26

25

24

23

RIN

LIN

ROUT1

LOUT1

ROUT2

LOUT2

ROUT3

LOUT3

DZF1

VCOM

VREFH

AK4586VQ

Top View

SDA/CDTI

RX2

TST

35

IC BLOCK DIAGRAM AND TERMINAL DESCRIPTIONS-6

Q801: AK4586 (24-Bit 96kHz 6-channel CODEC with DIR)-1

BLOCK DIAGRAM

PIN LAYOUT

TX-SR402/8240/HT-R420

21 22

No.

1

2 3

4 5 6 7 8

9 10 11 12 13 14 15

16

17

18

19

20

O

-

O

I I

-

O O

I/O I/O

O

I

I O O

O

I

I/O

I

O

OVF

AVSS AVDD

Pin Name

XTO XTI EXTCLK DVDD DVSS TVDD TX MCKO LRCK BICK SDTO SDTI1 SDTI2 SDTI3 INT0 INT1

CDTO CAD1

CDTI

SDA

CCLK

SCL CSN

CAD0

DZF2

Analog Input Overflow Detect Pin This pin goes to "H" if the analog input of Lch or Rch is overflows.

Analog Ground Pin, 0V Analog Power Supply Pin, 4.5V 5.5V

FunctionI/O

X'tal Output Pin X'tal Input Pin External Master Clock Input Pin Digital Power Supply Pin, 4.5V 5.5V Digital Ground Pin, 0V Output Buffer Power Supply Pin, 2.7V 5.5V Transmit channel (through data) Output Pin Master Clock Output Pin Input/Output Channel Clock Pin Audio Serial Data Clock Pin Audio Serial Data Output Pin DAC1 Audio Serial Data Input Pin DAC2 Audio Serial Data Input Pin DAC3 Audio Serial Data Input Pin Interrupt 0 pin Interrupt 1 pin

Control Data Output Pin in 4-wire serial control mode

Chip Address 1 Pin in I2C bus control mode Control Data Input Pin in 4-wire serial

control mode Control Data Input/Output Pin in I

2

C bus

control mode Control Data Clock Pin in 4-wire serial

control mode Control Data Clock Pin in I

2

C bus control

mode Chip Select Pin in 4-wire serial control mode Chip Address 0 Pin in I

2

C bus control mode

Zero Input Detect 2 Pin When the input data of the group 1 follow total 8192 LRCKcycles with "0" input data, this pin goes to "H".

31 32 33 34

35 36

No.

O

I I

-

ROUT1 LIN RIN PVDD

R PVSS

Pin Name

DAC1 Rch Analog Output Pin Lch Analog Input Pin Rch Analog Input Pin PLL Power Supply Pin, 4.5V 5.5V External Resistor Pin

18k +/-1% resistor to PVSS externally. PLL Ground Pin, 0V

37 IRX4

Receiver Channel 4 Pin (Internal biased pin)

38 ISLAVE

Slave Mode Pin "L": Master mode or Slave mode, "H": Slave mode

39 IRX3

Receiver Channel 3 Pin (Internal biased pin)

40ITST

Test Pin This pin should be connected to DVSS.

41 IRX2

Receiver Channel 2 Pin (Internal biased pin)

42 II2C

Control Mode Select Pin "L": 4-wire Serial, "H": I2C Bus

43 IRX1

Receiver Channel 1 Pin (Internal biased pin)

44IPDN

Power-Down & Reset Pin When "L ", the AK4586 is powered-down, all output pins go to "L" and the control registers are reset to default state. If the state of CAD1-0 changes, then the AK4586must be reset by PDN.

FunctionI/O

23

24

25

26 27 28 29 30

I

O

O O O O O

VREFH

VCOM

DZF1

LOUT3 ROUT3 LOUT2 ROUT2 LOUT1

Positive Voltage Reference Input Pin, AVDD Common Voltage Output Pin, AVDD/2

Large external capacitor around 2.2 F is used to reduce power-supply noise.

Zero Input Detect 1 Pin When the input data of the group 1 follow total 8192 LRCK cycles with "0" input data,this pin goes to "H".

DAC3 Lch Analog Output Pin DAC3 Rch Analog Output Pin DAC2 Lch Analog Output Pin DAC2 Rch Analog Output Pin DAC1 Lch Analog Output Pin

IC BLOCK DIAGRAM AND TERMINAL DESCRIPTIONS-7

Q801: AK4586 (24-Bit 96kHz 6-channel CODEC with DIR)-2

TERMINAL DESCRIPTION

TX-SR402/8240/HT-R420

(1G-15G)

1-1

15G 14G 13G 12G 11G 10G 9G

16G

8G 7G 6G 5G 4G 3G 2G 1G

2-1 3-1 4-1 5-1

1-2 2-2 3-2 4-2 5-2

1-3 2-3 3-3 4-3 5-3

1-4 2-4 3-4 4-4 5-4

1-5 2-5 3-5 4-5 5-5

1-6 2-6 3-6 4-6 5-6

1-7 2-7 3-7 4-7 5-7

P1 P2 P3 P4 P5 P6 P7 P8

P9 P10 P11 P12 P13 P14 P15 P16 P17 P18

1-1 2-1 3-1 4-1 5-1

-

1-2 2-2 3-2 4-2 5-2 1-3 2-3 3-3 4-3 5-3 1-4 2-4 3-4

15G-1G

16G

P19 P20 P21 P22 P23 P24 P25 P26 P27 P28 P29 P30 P31 P32 P33 P34 P35

-

4-4 5-4 1-5 2-5 3-5 4-5 5-5 1-6 2-6 3-6 4-6 5-6 1-7 2-7 3-7 4-7 5-7

15G-1G

16G

FL TUBE VIEW

Q7501:16BT123GNK

TX-SR402/8240/HT-R420

MICROPROCESSOR CONNECTION DIAGRAMS-1

Q7008:MPD784225GC-XXX-8BT(MAIN MICROPROCESSOR)

Q7008

MPD784225GC

-XXX-8BT

MAIN MICRO

PRCESSOR

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

41

48

19 18 17 44

47 46

42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58

7071727374757677787980

X7001

12.5MHz

TUNER UNIT

Q801

DIR, 2CH A/D, 6CH D/A

CONVERTER

AK4586

RL901

F901

POWER TRANS.

FRONT-A SPEAKERS

AC IN

Q203 LA7956

Q212 LA7956 S_VIDEO (C SIGNAL)

VIDEO SELECTOR SWITCH

Q213 LA7956 S_VIDEO (Y SIGNAL)

Q6701,6702 DC DETECTION

R6380,Q6303 THERMAL DETECTION CIRCUIT

Q7502 SUB-MICRORPOCESSOR MPD70232GC-XXX-8BT

39

40

7 8 9

10

59 60

616263646566676869

Q301 SELECTOR/ VOLUME/ TONE CONTROL BD3811K1

OUTPUT LEVEL DETECTION

R7003,7004 DESTINATION SET UP

RL6601

FRONT-B SPEAKERS

Q701

DSP

CS493264

Q7003(1/2)

TC74HCT7007

Q7002

TC74VHC541FT

Q7001 RESET

Q7003

(2/2)

3

2

3

2

3

2

Q205

DRIVER

VIDEO

MUTE

Q201

COMPOSITE

C

Y

Q208

Q207

Q202

Q210

Q211

S-VIDEO

VIDEO-1 OUT

Q206

DRIVER

COMPOSITE

C

Y

S-VIDEO

OUT L

MONITOR OUT

Q306

DRIVER

Q921

RELAY

DRIVE

Q6601

RELAY

DRIVE

Q6602

RELAY

DRIVE

Q6901

RELAY

DRIVE

RL6901 RL6902

LOW

HIGHT

T901 POWER TRANS.

Q6603 RELAY DRIVE

Q307

Q312 Q313

SUB WOOFER PREOUT

OUT R

POWER AMPLIFIER CIRCUIT

Q308

RL6600

L

R

SURROUND SPEAKERS

RL6604

RL6603

L

R

CENER SPEAKER

L

R

+B

POWER SUPPLY FOR

AMPLIFIER SECTION

P7501 PHONES

DETECTION SWITCH

+5V

POWER AMPLIFIER

CIRCUIT DESTINATION SET UP

Q6070~6074 CURRENT DETECTION

Q6703 GATE CIRCUIT

R7080 R7081

R7179 R7079

R7178 R7078

POWER

FAILURE

DETECTION

16 15 14

POWRL

VCTRLA

VCTRLB

VMUT2

VMUT1

AMUT

PLLSTB

PLLSDO

PLLCLK

TUMUT

~SD

~STEREO

SELCLK SELSDO SNONE SWNONE CNONE ~DIRCS ~DSPCS ~ROM/RAM ADDR15 ADDR16 ADDR17 DSPCLK DSPSDO ~DSPRST DSPSDI DIRINT1 DIRINT0 ~DIRPD RESET

PROTECT

VOLH

BAND

NU

MCRDY

MCSDI

MCSDO

MCCLK

~MCRST

HPMUT

HPIN

SPBRL

SEC1H

SPACSRL

SPAFRL

SELMUT

AVSS

AVREF1

VSS1

NU

POFFNUNU

~INTREQ/~ABOOT

PROTHERM

~RDSCLK

VSS0

VDD0

X2

X1

INIT1

TEST/VPP

XT2

XT1

RDSDATA

RDSSIG

VDD0

AVDD

INIT2

INIT3

9

11

1118

7

36

9 7 6 5 4

3 2

16

17 18

13

8 10 12

19

20

21

+B

6

VOLTAGE SELECTOR

MUTE

Q7006

Q7007

TX-SR402/8240/HT-R420

MICROPROCESSOR CONNECTION DIAGRAMS-2

Q7502:MPD780232GC-XXX-8BT(SUB MICROPROCESSOR)

Q7502

SUB-MICRO PROCESSOR MPD780232G

21

22

414243

61

20

192418

80

79

70

69

68

67

66

65

64

63

62

78

58

56

77

76

75

74

73

72

71

5

16171413121110

987

545557

53

52

51

50

49

48

47

46

45

44

40 39 38 37 36 35 34 33 32 31 30 29 28 27

26

15

25

+5V +5V

+5V

-VP

1

59

60

23

234

6

Q7501

FL TUBE

16BT123GK

S7501 MASTER VOLUME

Q7504

BUFFER

S7627

FM

MODE

S7625

VIDEO2

S7624

VIDEO1

S7623

DVD

S7622

AUDIO

SEL

S7621

DISPLAY

S7626

VIDEO3

U7501 REMOTE SENSOR

Q7506

D7505

STANDBY

5MHz

15

16

17

18

19

P282

RI

S7647

AUDIO

ADJUST

S7645

PRESET>

PRESET<

S7644

DSP

S7643

SURROUND

S7642

STEREO

S7641

DIRECT

S7646

S7635

MEMORY

S7634

TAPE

S7633

TUNER

S7632

CD

S7631

SP

ADJUST

S7636

TUNING<

TUNING>

S7637

DIMMER

S7612

SW

MODE

S7611

DIGITAL

INPUT

~SYSIN

~SYSOUT

P35

P34

P33

P32

P31

P30

P29

P28

P27

P26

P25

P24

P23

P22

P21

P20

P19

P18

P17

P16

P15

P14

P13

P12

P11

P10

P9P8P7P6P5

VDD2

VLOAD

VDD1

VSS1

X1

X2

IC

~RESET

SUBCL/SCK

SUBDO/SDI

SUBDI/SDO

SUBRDY

VBJ

VAJ

SSCBJ

SSCAJ

~IRIN

~IRF

STBYLED

AVSS

K3

K2

K1

K0

VSS0

AVDD

VDDO

P4 P3 P2

P1 16G 15G 14G 13G 12G 11G 10G

9G 8G 7G 6G 5G 4G 3G 2G 1G

Q7008

MAIN

MICROPROCESSOR

TX-SR402/8240/HT-R420

MICROPROCESSOR TERMINAL DESCRIPTIONS-1

Q7008:MPD784225GC-XXX-8BT(MAIN MICROPROCESSOR)

26

27

28

29

30

34

35

36

37

39

40

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

No.

1

2

3

11

10

12

15

16

17

18

19

20

21

22

23

24

25

POWRL

VCTRLA

VCTRLB

VMUT2

VMUT1

AMUT

PLLSTB

PLLSDO

PLLCLK

~SD

~STEREO

O

I

I/O

SELCLK

SELSDO

SNONE

SWNONE

CNONE

~DIRCS

~DSPCS

~ROM/RAM

ADDR15

ADDR16

ADDR17

DSPCLK

DSPSDO

~DSPRST

DSPSDI

DIRINT1

DIRINT0

~DIRPD

RESET

Pin name I/O

PROTECT I

I

O

VOLH

BAND

NU

MCRDY

MCSDI

MCSDO

MCCLK

~MCRST

HPMUT

HPIN

SPBRL

SEC1H

SPACSRL

SPAFRL

Power source relay control output terminal.

Control signal-A output terminal for the video selector switch.

Control signal-B output terminal for the video selector switch.

Muting control-2 output terminal for the video section.

Muting control-1 output terminal for the video section.

Audio muting control output terminal.

Strobe signal output terminal to PLL IC.

Serial data output terminal to PLL IC.

Serial clock output terminal to PLL IC.

38 TUMUT

O

Muting control output terminal for the tuner section.

Broadcast detection input terminal more than a muting level.

41 SELMUT

O

Muting control output terminal for selector, volume and tone IC BD3811.

FM stereo broadcast detection input terminal.

Serial clock output terminal of

selector,

volume and tone IC BD3811.

Serial data and latch signal output terminal for selector, volume and tone IC BD3811.

Not used.

Chip select signal output terminal to DIR IC AK4586.

Chip select signal output terminal to DSP IC.

ROM/RAM select terminal. Not used.

DSP boot ROM address 15 select terminal. Not used.

DSP boot ROM address 16 select terminal. Not used.

DSP boot ROM address 17 select terminal. Not used.

Serial clock output terminal for DSP IC CS493264,DIR and CODEC IC AK4586.

Serial data output terminal for DSP IC CS493264,DIR and CODEC IC AK4586.

Reset signal output terminal to DSP IC.

Serial data input terminal from DSP IC CS493264,DIR and CODEC IC AK4586.

Input terminal to detect the status of DIR IC.

Input terminal to detect the unlock of DIR IC.

Power down terminal to DIR and CODEC ICs.

61

O

NU Not used.

63 ONU Not used.

Reset input terminal.

Description No. Pin name Description

Current detection and DC voltage detection input terminal.

Thermal detection and power amplifier output level detection input terminal.

Input terminal for destination setup.

4

I

AVSS Power supply terminal +5V.

7

I

AVREF1 Ground terminal for A/D converter.

IVSS1 Ground terminal.

Not used.

Data ready detection input terminal from the sub microprocessor.

Data input terminal from the sub microprocessor.

Data output terminal to the sub microprocessor.

Serial clock output terminal to the sub microprocessor.

Reset signal output terminal to the sub microprocessor.

Muting control output terminal for headphone amplifier. Not used.

Input terminal to detect the connection of headphone.

Speaker relay control output terminal for front B.

5

O

NU Not used.

8

O

NU Not used.

9

O

NU Not used.

O

13 NU Not used.O

14 NU Not used.O

31 NU Not used.O

32

33

NU Not used.O

NU Not used.

6

O

NU Not used.

Control output terminal for power supply voltage of power amplifier.

Speaker relay control output terminal for center and surround channels.

Speaker relay control output terminal for front-A channels.

62

64

65

66

69

70

71

72

73

76

77

POFF

~INTREQ/~ABOOT

PROTHERM

~RDSCLK

X2

X1

78 INIT1

TEST/VPP

XT2

XT1

RDSDATA

RDSSIG

Power failure detection input terminal.

Interrupter input terminal from DSP IC.

Not used.

RDS clock input terminal (European model only)

Connect the ceramic oscillator 12.5MHz.

Test terminal.

Not used.

I

74 VDD0 Power supply terminal +5V.

I

67 VSS0 Ground terminal.

I

68 VDD0 Power supply terminal +5V.

I75 AVDD

Power supply terminal for A/D converter +5V.

Data input terminal of RDS broadcast (European model only)

Input terminal to check the signal of RDS broadcast (European model only)

Input terminal-1 for destination setup.

I

79 INIT2 Input terminal-2 for destination setup.

I

80 INIT3 Input terminal-3 for destination setup.

I/O

TX-SR402/8240/HT-R420

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

No.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

~SYSIN

~SYSOUT

P35

P34

P33

P32

P31

P30

P29

P28

P27

P26

P25

P24

P23

P22

P21

P20

P19

P18

P17

P16

P15

P14

P13

P12

P11

P10

P9

P8

P7

P6

P5

VDD2

VLOAD

Pin name

VDD1

VSS1

X1

X2

IC

~RESET

SUBCL/SCK

SUBDO/SDI

SUBDI/SDO

SUBRDY

VBJ

VAJ

SSCBJ

SSCAJ

~IRIN

~IRF

STBYLED

AVSS

K3

K2

K1

K0

VSS0

AVDD

VDDO

System code input terminal.

System code output terminal.

Segment output terminal of P35.

Segment output terminal of P34.

Segment output terminal of P33.

Segment output terminal of P32.

Segment output terminal of P31.

Segment output terminal of P30.

Segment output terminal of P29.

Segment output terminal of P28.

Segment output terminal of P27.

Segment output terminal of P26.

Segment output terminal of P25.

Segment output terminal of P24.

Segment output terminal of P23.

Segment output terminal of P22.

Segment output terminal of P21.

Segment output terminal of P20.

Segment output terminal of P19.

Segment output terminal of P18.

Segment output terminal of P17.

Segment output terminal of P16.

Segment output terminal of P15.

Segment output terminal of P14.

Segment output terminal of P13.

Segment output terminal of P12.

Segment output terminal of P11.

Segment output terminal of P10.

Segment output terminal of P9.

Segment output terminal of P8.

Segment output terminal of P7.

Segment output terminal of P6.

Segment output terminal of P5.

Power supply terminal. Apply connect to +5V.

Negative power supply terminal of FL controller.

Description No. Pin name Description

Power supply terminal. Connect to 5V.

Ground terminal.

X'tal input terminal.

X'tal output terminal.

Connect to ground. Not used.

System reset signal input terminal.

Clock input terminal to transmit the signal from main microprocessor.

Data input terminal to transmit the signal from main microprocessor.

Data output terminal to transmit the signal to main microprocessor.

Data ready output terminal to transmit to the main microprocessor.

Pulse input terminal from the rotary encoder of volume.

Not used.

Signal input terminal from the remote controller.

Standby LED control output terminal.

Ground terminal for A/D converter.

Operation key connection terminal.

Ground terminal.

Power supply terminal for A/D converter.

Power supply terminal. Apply +5V.

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

P4

P3

P2

P1

16G

15G

14G

13G

12G

11G

10G

9G

8G

7G

6G

5G

4G

3G

2G

1G

Segment output terminal of P4.

Segment output terminal of P3.

Segment output terminal of P2.

Segment output terminal of P1.

Grid output terminal of 16G.

Grid output terminal of 15G.

Grid output terminal of 14G.

Grid output terminal of 13G.

Grid output terminal of 12G.

Grid output terminal of 11G.

Grid output terminal of 10G.

Grid output terminal of 9G.

Grid output terminal of 8G.

Grid output terminal of 7G.

Grid output terminal of 6G.

Grid output terminal of 5G.

Grid output terminal of 4G.

Grid output terminal of 3G.

Grid output terminal of 2G.

Grid output terminal of 1G.

I

O

I

O

O O

O

I/O I/O

MICROPROCESSOR TERMINAL DESCRIPTIONS-2

Q7502:MPD780232GC-030-8BT(SUB MICROPRCESSOR)

TX-SR402/8240/HT-R420

ADJUSTMENT PROCEDURES

IDLING CURRENT ADJUSTMENT

P6903

J6011

J6008

JL6803A

JL6804A

J6014

J6016

J6153J6136J6110J6073

J6052

J6053

J6106

J6107

J6129

J6130

J6150

J6151

P6011

D6903

D6904

J6081

J6080

J6064

J6065

RL6901

RL6902

P6931

P931

J

L

6

9

5

2

A

JL6951A

J6060

J6061

J6076

J6077

J6058

J6023

J6022

J6079

J6082

J6063

J6062

Q6603

R6603

Q6602

D6906

Q6901

C6920

J6004

R6902

D6706

D6705

C6708

D6901

C6903

D6902

C6904C6905

R6904

R6905

C6906

C6907

R6706

C6704

D6703

R6704

Q6703

R6702

C6703

J6085

R6513

R6851

R6523

J6164

C6513

C6523

R6701

AGND

+24V MPUGND MPUGND

VOLH

SE1H

+13VS

SPB

SPCS

SPF

POWER

PRO

J6101

J6099

J6100

J6026

J6042

J6102

J6103

J6056

R6850

F6901A F6901B

F6902B

F6902A

J6040

J6059

J6025

J6024

+13VS

MPUGND

POWER

P6907

+B1

-B1

+B1

J6086

P6909

F6901

F6902

8A 125V

R6521R6511

C6511

C6512

R6512 R6522

C6522

J6138

J6143

J6031

J6033

J6034

J6029 J6087

J6092

J6091

J6089 J6119

J6121

J6116

J6114

J6160

J6161

J6168

HPL

HPR

J6167

C6510

C6520

R6510

R6520

RLGND

J6084

J6140

J6030

J6074 J6118

J6137

J6159

J6155

J6125

J6133

J6112

J6097J6038

J6057

C6521

J6015 J6075 J6113 J6139

J6152

J6149

J6148

J6131

J6126

J6127

J6134

J6105

J6104

J6109

J6108J6054

J6055

J6049

J6050

J6071J6027

J6010

J6009

J6013

J6012

J6093

J6094

J6095

J6122

J6123

J6124

J6144

J6145

J6146

J6035

J6036

J6037

J6163

J6165

J6166

E

B

E

B

R6708

NCAF-7875 25137875A

J6170

1

J6002

J6001

J6018

J6019

J6017

J6039

J010

R6100

Q6050 Q6060

J6032 J6051

R6101

Q6051 Q6061

J6090 J6096

R6102

Q6052 Q6062

J6120 J6128

R6103

Q6053 Q6063

J6142 J6147

R6104

Q6054 Q6064

J6162

J6169

J6045

J6047

R6605

J6005

J6006

P6922

P6923

J6067

J6066

J6044

J6046

J6007

R6230

R6231

R6234

R6232

R6233

C6230

C6231

C6232

C6233

C6234

J6043

+24V

CSRLD

FRLD

BRLD

Q6601

R6601

J011

J011AJ010A

J6111 J6132 J6154

J6083

J6020

J6041

J6003

J6021

P6072A

J6068

C6706

D6704

R6710

R6709

C6701

JL6805A

Q6701

D6702

Q6702

D6701

Q6303

D6307

D6306

R6306

R6307

R6308

P6301

J6069

J6070

JL6402A

COM

TH1

+24V

TH1

LSP RSP

CSP

LSSP

RSSP

LSPE RSPE CSPE

LSSPE RSSPE

R6604

R6602

B

BEE

P6802

E

B

J6098

J6078

L

R C LS RS

P995A

P997A

P996A

P6906

P6801

C6902

C6901

P995B

J6156

B-

B+

+B1

-B1

NF

P6004

B-

B+

+B1

-B1

NF

P6003

B-

B+

+B1

-B1

NF

P6002

B-

B+

+B1

-B1

NF

P6001

B-

B+

+B1

-B1

NF

P6000

P6073A

BE

Q6010

R6080

ID-

R6140

BE

Q6070

R6150

C6050

J6048

B

ID+

Q6040

Q6030

R6070

C6040

R6030

R6050

Q6020

P6080

D6000

R6160

R6180

R6170

R6020

E

BIAS

R6090

B

R6000

R6010

J6028

BE

Q6013

R6083

ID-

R6143

BE

Q6073

R6153

C6053

J6141

B

ID+

Q6043

Q6033

R6073

C6043

R6033

R6043

R6053

Q6023

P6083

D6003

R6163

R6183

R6173

R6023

E

BIAS

R6093

B

R6003

R6013

J6135

BE

Q6012

R6082

ID-

R6142

BE

Q6072

R6152

C6052

J6117

B

ID+

Q6042

Q6032

R6072

C6042

R6032

R6042

R6052

Q6022

P6082

D6002

R6162

R6182

R6172

R6022

E

BIAS

R6092

B

R6002

R6012

J6115

BE

Q6011

R6081

ID-

R6141

BE

Q6071

R6151

C6051

J6088

B

ID+

Q6041

Q6031

R6071

C6041

R6031

R6041

R6051

Q6021

P6081

D6001

R6161

R6181

R6171

R6021

E

BIAS

R6091

B

R6001

R6011

J6072

BE

Q6014

R6084

ID-

R6144

BE

Q6074

R6154

C6054

J6158

B

ID+

Q6044

Q6034

R6074

C6044

R6034

R6054

Q6024

P6084

D6004

R6164

R6184

R6174

R6024

E

BIAS

R6094

B

R6004

R6014

J6157

P6908

P6910

R6190 R6191 R6192 R6193 R6194

D6014

D6013D6012D6011D6010

C6908

C6909

BCEBCEBCEBCEBCEBCEBCEBCEBCEBCE

25 25 25 25 25

1717

12

25252525

12

30

27

30

7

15

7

20

15

25

30

7

12

7

25

27

17

20

17

30

17

30

17

30

17

30

17

30

17

20

17

20

2020

20

1717

20

30

15

17

7

20

20 25 25 25 25

20 20 20 12121212

22

15

12

22

1230 12

22

22 22

22

1230 30 12

22

17

20

30

15

25

27

22

7

77 7 7

30

25

12

27

22

12

20

22

12

7

R6040 R6044

R6040 P6080

ID+ ID-

Trimming

resistor

Test

point

L

BIAS

R6041 P6081

ID+ ID-

Trimming

resistor

Test

point

R

BIAS

R6042 P6082

ID+ ID-

Trimming

resistor

Test

point

C

BIAS

R6043 P6083

ID+ ID-

Trimming

resistor

Test

point

LS

BIAS

R6044 P6084

ID+ ID-

Trimming

resistor

Test

point

RS

BIAS

U17

POWER AMPLIFIER PCB ASSY (NAAF-7875)

Front side

Fig-1

[Note] No load and No signal

Refer to Fig-1 about test points and adjustment points.

1. Before Idling adjustment, turn the trimming resistors R6040, R6041, R6042, R6043 and R6044 to counter clockwise.

2. Connect the DC voltmeter to test point P6080,P6081, P6082, P6083 and P6084. Connect 100-ohm resistance near the terminal of the two poles of a Jig terminal.

6. Wait for 4 - 5 minutes. (Heat raining)

7. Re-adjust the trimming resistors as following procedure.

Trimming resistor (Adjustment point)

R6040 R6041 R6042 R6043 R6044

Adjustment value

2.5 mV

1.5 mV

Test point (Measuring point)

P6080 P6081 P6082 P6083 P6084

Adjustment point

R6040, R6041, R6042

R6043, R6044

Adjustment value

7 mV Leave it as it is 9 mV 4 mV Leave it as it is 6 mV

Measured value

In case below 7 mV In case 7 - 9 mV In case over 9 mV In case below 4 mV In case 4 - 6 mV In case over 6 mV

3. Connect the AC power supply cord to wall outlet.

4. Press the STANDBY/ON button into the power ON state.

5. Adjust the trimming resistors as following procedure immediately after a power ON.

Channel

L R C SL SR

Channel

L, R, C

SL, SR

ID+ ID-

Test point

DC voltmeter

Jig terminal

Resistor 100 ohms 1/4watts

8. Disconnect the DC voltmeter.

9. Press the STANDBY/ON button into the power OFF state.

10. Disconnect the AC power supply cord.

OPERATION CHECK-1

DC VOLTAGE DETECTION PROTECTORS

CURRENT DETECTION PROTECTORS

TX-SR402/8240/HT-R420

1. Set the unit to test mode " Test-1-00 " . 1-1. Press and the hold down the CD button , then press the STANDBY/ON button when the unit is Power ON.

1-2. Press the DVD button, while the display of "Test - _" has come out. Unit will be in the state of " Test-1-00 ".

2. Apply DC voltage (+1.5 to +3V) to MULTI CHANNEL (FL, FR, SL, SR, C, SW) terminal, each channel.

3. Check that "protect" is display come out.

4. Apply DC voltage (-1.5 to -3V) to MULTI CHANNEL (FL, FR, SL, SR, C, SW) terminal, each channel.

5. Check that "protect" is display come out.

6. Press the STANDBY/ON button.

[NOTE1] Limit time to apply voltage is 0.5 - 1.0 seconds each channel. When protection operation does not occur at once, try several times. [NOTE2] Don't connect speakers or any load. Don't short speaker terminals.

[NOTE] In the state of testmode"Test-4-29", the pulse waveform for checking from speaker terminal outputs automatically. Therefore, oscllator is unnecessary.

Test - _

Test - 1-00

Clear

Disappears

1. Set the unit to test mode "Test-4-29" 1-1. Press and the hold down the CD button , then press the STANDBY/ON button when the unit is Power ON.

1-2. Press the VIDEO3 button, while the display of "Test - _" has come out. Unit will be in the state of "Test-4-00".

1-3. Repeat and press SPEAKERS B until the display of "Test-4-29" comes out.

2. Connect the lord resister (3ohms) to the speaker terminals.

3. Check the not displayed "PROTECT" and speaker relays not turn OFF.

4. Check the each speaker terminals.

5. Connect the lord resister (1.5ohms) to the speaker terminals.

6. Check the displayed "PROTECT" and speaker relays turn OFF immediately.

7. Check the each speaker terminals.

6. Press the STANDBY/ON button.

Test - _

Test - 4-00

Test - 4-29

Clear

Disappears

OPERATION CHECK-2

OUTPUT LEVEL & THERMAL DETECTION

TX-SR402/8240/HT-R420

RL6901

D6904

D6903

RL6902

POWER AMP.

PRI.

SEC1

Low

High

+B1

-B1

T901 MAIN

TRANSFORMER

Low

High

Q6303

THERMAL SENSER R6380

THERMAL DETECTION

OUTPUT LEVEL DETECTION

VOLH/ THPRO

Q7008 MAIN MICROPROCESSROR

Q6303

SEC1H

23

2

SPEAKER OUT

F6901

F6902

Low-voltage

TX-SR402 /8240

HT-R420

HIGH MODE

LOW MODE

+/- 52.0 V

+/- 28.4 V

+/- 63.0 V

+/- 29.0 V

High-voltage

Regarding the power supply system of this unit.

1. High-voltage mode Usually, the power supply supplies high voltage to the power amplifier circuit when the relay(RL6901) is turned on.

2. Low-voltage mode When as follows, a power supply changes to the state of supplying low voltage when the relay (RL6901) in turned off. (1) Excessive output signal is continuously outputted from power amplifier. (2) Temperature of a heat sink surpasses 80 degrees.

1. The loss which power amplifier generates is decreased. As a result, the miniaturization of a heat sink is realized.

2. Corresponds to a safety standard.

May not notice the fuse (F6901, F6902) broken in the case of repair. Because the power supply is continuing supplying voltage from the High side of SEC1 at high-voltage mode. When a power supply Ccircuit changes to low voltage mode, amplifier does not operate. Therefore, it is very important to check operation of this power supply system containing a fuse.

[NOTE2] Don't connect speakers or any load. Don't short speaker terminals. (1) Set the unit is Multi channel input state. (2) Set the master volume into the minimum. (3) Apply sine wave signal to MULTI CHANNEL INPUT (FL+FR+C+SL) terminals. (4) Connect an oscilloscope to speaker terminal of FL channel. (5) Adjust master volume so that a speaker output may become distortion about 5%.

(6) Check that the RL6901 is turned off after about 5 seconds. And the power supply changes to low-voltage mode.

(7) Adjust the master volume so that output voltage may become half.

(8) Check that the RL6901 is turned ON after 2 to 3 minutes. And the power supply returns to high-voltage mode.

OPERATION CHECK-3

OUTPUT LEVEL & THERMAL DETECTION

TX-SR402/8240/HT-R420

U17

NAAF-7875

POWER AMPLIFIER PC BOARD

P6908

P6301

TH1

COM

P6301

TH1

COM

Front side

Output level detection

1. Set the unit to test mode " Test-3-2 " 1-1. Press and the hold down the CD button , then press the STANDBY/ON button when the unit is Power ON.

1-2. Press the VIDEO2 button, while the display of " Test - _ " has come out. Unit will be in the state of "Test-3-00".

1-3. Repeat and press SPEAKERS B until the display of " Test-3-2 " comes out.

2. Apply signal (sine wave 1kHz, -1.5dBV) to MULTI CHANNEL (FL, FR, SL, SR, C) terminal, each channel.

3. Check that FM STEREO indicator is display come out.

6. Press the STANDBY/ON button, and exit from test mode.

Test - _

Test - 3-00

Test - 3-02

FM STEREO

Thermal detection

1. Set the unit to test mode " Test-3-2 " Refer to the clause of "OUTPUT LEVEL DETECTION".

2. Connect the resistor 2.7kohms /1W between "HT1" and "COM" terminals of P6301.

3. Check that FM STEREO indicator is display come out.

6. Press the STANDBY/ON button, and exit from test mode.

Test - 3-02

FM STEREO

2.7kohms 1W

The following is the procedure of checking detection operation of a microprocessor in false, by using test mode.

OPERATION CHECK-4

DSP DEBUG MODE

TX-SR402/8240/HT-R420

DSP Debug Mode

Version 30212a

E1A---0 -o 23 o

[Example]

Details

1 42 5 6 87 93

Regarding the DSP debug mode

TIn this test mode, the check with normal communication of a microcomputer and the data of DSP and DIR is possible. This information is a help to find the cause of failure.

UNLOCK

E = UNLOCK = LOCK

1

Digital Selecter

D = DIGITAL A = ANALOG 1 = COAX 2 = OPT1 3 = OPT2 4 = Others

2

Sampling Frequency

96 = 96kHz 48 = 48kHz 44 = 44kHz 32 = 32kHz = Not detect

3

MEMORY Address

0 = AC3+PLII 1 = AC3/PCM+T-D 2 = DTS/DTS-ES 3 = DTS 5 = AAC+PL"6" : COS 7 = FACTORY TEST MODE

6

Pre Emphasis

K = OFF e = ON

4

ROM/RAM Select/Download Status

H = RAM (Complete Auto Boot) L = ROM (Under Auto boot)

7

DSP Detect Format

[IEC61937] 00: Null 01: Dolby Digital 03: Pause 04: MPEG1 L1 05: MPEG1 L23/MPEG2 w/o 06: MPEG2 w/o 07: MPEG2 AAC 0B: DTS1 0C: DTS2 0D: DTS3 1B: MPEG2 AAC1 1C: MPEG2 AAC2

[Except IEC61937] 20: Silent 21: DTS LD 22: DTS CD 23: PCM

8

DSP Decode

0 = Decode OK X = Decode NG

- = Analog in

9

1. Press and hold down the DISPLAY button, then press the STANDBY button when the unit is power ON.

2. Press the DISPLAY button, while the display of "Version 30212a" has come out.

Press STANDBY/ON.

DIR

MEMORY/DOWNLOAD

DIR Status

0 = PCM/ANALOG 2 = DTS CD 5 = DD/DTS/AAC

5

DSP

PACKING PROCEDURES

TX-SR402/TX-SR8240 Only

TX-SR402/8240/HT-R420

RIGHT

BOTTOM

RIGHT

TOP

LEFT

BOTTOM

LEFT

TOP

Front

Left

Front

Left

SP-B

/

Zone 2

Left

SP-B

/

Zone 2

Left

Surround

Right

Surround

Right

Surround Back

Right

Surround Back

Right

Zone 2

Right

Zone 2

Right

Front

Left

Front

Left

SP-B

/

Zone 2

Left

SP-B

/

Zone 2

Left

Front

Right

Front

Right

SP-B

/

Zone 2

Right

SP-B

/

Zone 2

Right

Front

Right

Front

Right

SP-B

/

Zone 2

Right

SP-B

/

Zone 2

Right

Surround

Right

Surround

Right

Center

Surround

Left

Surround

Left

Surround

Left

Surround

Left

Surround Back

Right

Surround Back

Right

Zone 2

Right

Zone 2

Right

Surround Back

Left

Surround Back

Left

Zone 2

Left

Zone 2

Left

Surround Back

Left

Surround Back

Left

Zone 2

Left

Zone 2

Left

1

2

3

Speaker Cable

A610

A613

A611

A613

A625

A613

A655

A615

A650

A821

A820

A812

A801

A635

A811

<RB>

<LT>

<LB>

Front side

Front side marking

Right top side marking

Front side marking

Right bottom side marking

Front side marking

Left top side marking

Front side marking

Left bottom side marking

<Note>

HT-R420 ---> Refer to service manual of "HT-S670".

Keep LABEL(SP Cable) inside first page of Instruction manual.

A613

<RT>

A601

(LT & LB & RT & RB)

1/37 PAGE

EXPLODED VIEW PARTS LIST

<Notes> (S) : Silver model (B) : Black model (G) : Golden model <402> : TX-SR402 (Chinese model) <8240> : TX-SR8240 (Chinese model) <420> : HT-R420 (All destination) <DD> : HT-R420 (American model) <DC> : HT-R420 (Canadian model) <PA> : HT-R420 (Australian model) <PT> : HT-R420 （Asian model 230-240V) <WT> : HT-R420 （Worldwide model)

REF NO. NAME DESCRIPTION Q'TY PART NO. REMARKS

EXP.

A002 SCREW 3TTF+8B(BC) 2 835430088

EXP.

A004 SCREW 3TTB+8B 1 838130088

EXP.

A005 SCREW 3TTB+10B(BC) 10 838430108

EXP.

A007 SCREW 3TTB+10B(BC) 3 838430108

EXP.

A010 CHASSIS --- 1 27100416A

EXP.

A015 HOLDER KGLS-8RT 1 27190503A

EXP.

A016 HOLDER KGPS-10RF 2 27190813

EXP.

A017 HOLDER KGLS-10RT 3 27190428A

EXP.

A020 SCREW 3TTB+8B 6 838130088

EXP.

A021 SCREW 3TTB+8B 4 838130088

EXP.

A022 SCREW 3TTB+8B 1 838130088

EXP.

A023 SCREW 4TTC+8C(BC) 4 830440089

EXP.

A024 SCREW 3TTB+8B 1 838130088

EXP.

A025 RIVET P-RIVET NRP-345 1 880009

EXP.

A026 SCREW 3TTW+8B(BC) 1 831430088

EXP.

A028 BUSHING S-RELIEF #2271 1 27300750 !

EXP.

A030 HEAT SINK AS 1 27160501

EXP.

A035 SCREW 3TTB+8B 1 838130088

EXP.

A036 SCREW 3TTB+8B 2 838130088

EXP.

A037 SCREW 3SMS8W.SW+14B(BC) 10 801433

EXP.

A050 COVER --- 1 28184831 (B)

EXP.

A050 COVER --- 1 28184856 (S)

EXP.

A050 COVER --- 1 28184857 (G)

EXP.

A051 SCREW 3TTB+8B(BC) 6 838430088 (B)

EXP.

A051 SCREW 3TTB+8B(UN) 6 838930088 (S), (G)

EXP.

A055 LEG LEG 4 27175319B

EXP.

A056 CUSHION --- 8 28141494

EXP.

A057 SCREW 3TTB+8B 4 838130088

EXP.

A060 KNOB (VOL)AS 1 28325643 (G) <8240>

EXP.

A060 KNOB (VOL)AS 1 28326198 (S) <402>, <420>

EXP.

A060 KNOB (VOL)AS 1 28326199 (G) <402>

EXP.

A060 KNOB (VOL)AS 1 28326197 (B) <420>

EXP.

A065 CLEAR PLT --- 1 28191958 (S),(G)

EXP.

A065 CLEAR PLT --- 1 28191957 (B)

EXP.

A401 REAR PANEL --- 1 27123218 <402>

NOTE : THE COMPONENTS IDENTIFIED BY THE MARK ! ARE

CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE ONLY WITH PART NUMBER SPECIFIED.

TX-SR402/8240/HT-R420

2/37 PAGE

EXP.

A401 REAR PANEL --- 1 27123219B <DC>, <DD>

EXP.

A401 REAR PANEL --- 1 27123258 <8240>

EXP.

A401 REAR PANEL --- 1 27123259 <PA>

EXP.

A401 REAR PANEL --- 1 27123260 <WT>

EXP.

A401 REAR PANEL --- 1 27123285 <PT>

EXP.

A402 HOLDER (OUTLET) 1 27191143 <402>, <8240>

EXP.

A404 SCREW 3TTB+8B(BC) 27 838430088

EXP.

A410 F PANEL --- 1 27212617 (B) <DD>, <DC>,

EXP.

A410 F PANEL --- 1 27212617 (B) <PA>

EXP.

A410 F PANEL --- 1 27212618 (S) <DD>, <DC>

EXP.

A410 F PANEL --- 1 27212618 (S) <WT>, <PA>

EXP.

A410 F PANEL --- 1 27212618 (S) <PT>

EXP.

A410 F PANEL --- 1 27212619 (G) <402>

EXP.

A410 F PANEL --- 1 27212620 (S) <402>

EXP.

A410 F PANEL --- 1 27212642 (G) <8240>

EXP.

A411 KNOB (POW) 1 28326047 (B)

EXP.

A411 KNOB (POW) 1 28326048 (S)

EXP.

A411 KNOB (POW) 1 28326049 (G)

EXP.

A412 KNOB (MODE) 1 28326050 (B)

EXP.

A412 KNOB (MODE) 1 28326051 (S)

EXP.

A412 KNOB (MODE) 1 28326052 (G)

EXP.

A413 KNOB (SEL) 1 28326053 (B)

EXP.

A413 KNOB (SEL) 1 28326054 (S)

EXP.

A413 KNOB (SEL) 1 28326055 (G)

EXP.

A414 KNOB (PRE) 1 28326056A (B)

EXP.

A414 KNOB (PRE) 1 28326057A (S)

EXP.

A414 KNOB (PRE) 1 28326058A (G)

EXP.

A415 TAPE --- 1 29110161 (B)

EXP.

A416 TAPE (CU) 1 29110170

EXP.

A417 TAPE (CU) 1 29110171

EXP.

A418 TAPE (CU) 1 29110172 (B)

EXP.

A420 BADGE BADGE 1 28135244 (B)

EXP.

A420 BADGE BADGE 1 28135245 (G), (S)

EXP.

A421 SCREW 3TTW+8B(BC) 3 831430088

EXP.

A424 RETAINER (BRO) 1 27141873

EXP.

A425 LABEL HOOKUP-ONKYO 1 29363194 <DD>, <DC>

EXP.

A430 LABEL (POP) 1 29363606 <DD>, <DC>

EXP.

F6901 FUSE 8A-EAK FUSE 1 252099 <402>, <8240>

EXP.

F6901 FUSE 8A-EAK FUSE 1 252099 <PA>, <PT> F6901 FUSE 8A-EAK FUSE 1 252099 <WT>

EXP.

F6901 FUSE 8A-UL 1 252198 <DD>, <DC>

EXP.

F6901 or FUSE 8A-T/UL-ST2 ( 1) 252261

EXP.

F6902 FUSE 8A-EAK FUSE 1 252099 <402>, <8240>

EXP.

F6902 FUSE 8A-EAK FUSE 1 252099 <PA>, <PT>

EXP.

F6902 FUSE 8A-EAK FUSE 1 252099 <WT>

EXP.

F6902 FUSE 8A-UL 1 252198 <DD>, <DC>

EXP.

F6902 or FUSE 8A-T/UL-ST2 ( 1) 252261

EXP.

F901 FUSE 8A-UL 1 252198 <DD>, <DC>

EXP.

F901 or FUSE 8A-T/UL-ST2 ( 1) 252261

EXP.

F901 FUSE 8A-UL 1 252198 <WT>

EXP.

F901 or FUSE 8A-T/UL-ST2 ( 1) 252261

EXP.

F902 FUSE 3.15A-SE-EAK FUSE 1 252076 <402>, <8240>

EXP.

F902 or FUSE 3.15A-SE-TL250V ( 1) 252242

EXP.

F902 or FUSE 3.15A-SE-TL250V ( 1) 252276

EXP.

F902 FUSE 3.15A-SE-EAK FUSE 1 252076 <WT>, <PA>, <PT>

EXP.

F902 or FUSE 3.15A-SE-TL250V ( 1) 252242

EXP.

F902 or FUSE 3.15A-SE-TL250V ( 1) 252276

3/37 PAGE

EXP.

F903 FUSE 5A-UL/T-237 1 252164 <DD>, <DC>

EXP.

F903 or FUSE 5A-T/UL-ST2 ( 1) 252258

EXP.

F903 FUSE 2.5A-SE-EAK FUSE 1 252075 <402>, <8240>

EXP.

F903 or FUSE 2.5A-SE-TL250V ( 1) 252241

EXP.

F903 or FUSE 2.5A-SE-TL250V ( 1) 252275

EXP.

F903 FUSE 2.5A-SE-EAK FUSE 1 252075 <WT>, <PA>, <PT>

EXP.

F903 or FUSE 2.5A-SE-TL250V ( 1) 252241

EXP.

F903 or FUSE 2.5A-SE-TL250V ( 1) 252275

EXP.

P101 FFC NCFC7-151512 1 2047151512

EXP.

P7502 FFC NCFC5-102012 1 2045102012

EXP.

P7503 FFC NCFC7-081012 1 2047081012

EXP.

P7504 FASTON AS BLACK L=130 1 1F999018UL

EXP.

P800 WIRE TIE BINDER(CLAMPER)UL 7 260208

EXP.

P901 AC CORD AS-UC-2 1 253368LTK <DD>, <DC>

EXP.

P901 or AC CORD AS-UC-2 ( 1) 253332HIT

EXP.

P901 or AC CORD AS-UC-2 ( 1) 253333VOL

EXP.

P901 AC CORD AS-SAA 1 253197HIT <PA>

EXP.

P901 AC CORD AS-CEE-2 1 253374LTK <WT>, <PT>

EXP.

P901 or AC CORD AS-CEE-2 ( 1) 253233KAW

EXP.

P901 or AC CORD AS-CEE-2 ( 1) 253306VOL

EXP.

P901 AC CORD AS-CCC 1 253355VOL <402>, <8240>

EXP.

P901 or AC CORD AS-CCC ( 1) 253377LTK

EXP.

Q6050 TR 2SC5242-O 1 2202843 <420>

EXP.

Q6050 or TR 2SC5242-R ( 1) 2202842

EXP.

Q6050 or TR MN150S-O ( 1) 2203683

EXP.

Q6050 or TR MN150S-Y ( 1) 2203684

EXP.

Q6050 or TR MN150S-P ( 1) 2203686

EXP.

Q6050 TR 2SC5198-R 1 2203062 <402>, <8240>

EXP.

Q6050 or TR 2SC5198-O ( 1) 2203063

EXP.

Q6050 or TR MN130S-O ( 1) 2203663

EXP.

Q6050 or TR MN130S-Y ( 1) 2203664

EXP.

Q6050 or TR MN130S-P ( 1) 2203666

EXP.

Q6050A ISO SHEET AC238 10 223024

EXP.

Q6051 TR 2SC5242-O 1 2202843 <420>

EXP.

Q6051 or TR 2SC5242-R ( 1) 2202842

EXP.

Q6051 or TR MN150S-O ( 1) 2203683

EXP.

Q6051 or TR MN150S-Y ( 1) 2203684

EXP.

Q6051 or TR MN150S-P ( 1) 2203686

EXP.

Q6051 TR 2SC5198-R 1 2203062 <402>, <8240>

EXP.

Q6051 or TR 2SC5198-O ( 1) 2203063

EXP.

Q6051 or TR MN130S-O ( 1) 2203663

EXP.

Q6051 or TR MN130S-Y ( 1) 2203664

EXP.

Q6051 or TR MN130S-P ( 1) 2203666

EXP.

Q6052 or TR 2SC5242-R ( 1) 2202842 <420>

EXP.

Q6052 or TR 2SC5242-O ( 1) 2202843

EXP.

Q6052 or TR KTC5242-R ( 1) 2203562

EXP.

Q6052 TR KTC5242-O 1 2203563 <420>

EXP.

Q6052 or TR MN130S-O ( 1) 2203663

EXP.

Q6052 or TR MN130S-Y ( 1) 2203664

EXP.

Q6052 or TR MN130S-P ( 1) 2203666

EXP.

Q6052 TR KTD1047-Y 1 2203634 <402>, <8240>

EXP.

Q6052 or TR KTD1047-O ( 1) 2203633

EXP.

Q6052 or TR MN100S-O ( 1) 2203653

EXP.

Q6052 or TR MN100S-Y ( 1) 2203654

EXP.

Q6052 or TR MN100S-P ( 1) 2203656

EXP.

Q6053 TR KTC5242-O 1 2203563 <420>

EXP.

Q6053 or TR 2SC5242-R ( 1) 2202842

4/37 PAGE

EXP.

Q6053 or TR 2SC5242-O ( 1) 2202843

EXP.

Q6053 or TR KTC5242-R ( 1) 2203562

EXP.

Q6053 or TR MN130S-O ( 1) 2203663

EXP.

Q6053 or TR MN130S-Y ( 1) 2203664

EXP.

Q6053 or TR MN130S-P ( 1) 2203666

EXP.

Q6053 TR KTD1047-Y 1 2203634 <402>, <8240>

EXP.

Q6053 or TR KTD1047-O ( 1) 2203633

EXP.

Q6053 or TR MN100S-O ( 1) 2203653

EXP.

Q6053 or TR MN100S-Y ( 1) 2203654

EXP.

Q6053 or TR MN100S-P ( 1) 2203656

EXP.

Q6054 TR KTC5242-O 1 2203563 <420>

EXP.

Q6054 or TR 2SC5242-O ( 1) 2202843

EXP.

Q6054 or TR 2SC5242-R ( 1) 2202842

EXP.

Q6054 or TR KTC5242-R ( 1) 2203562

EXP.

Q6054 or TR MN130S-O ( 1) 2203663

EXP.

Q6054 or TR MN130S-P ( 1) 2203666

EXP.

Q6054 or TR MN130S-Y ( 1) 2203664

EXP.

Q6054 TR KTD1047-Y 1 2203634 <402>, <8240>

EXP.

Q6054 or TR KTD1047-O ( 1) 2203633

EXP.

Q6054 or TR MN100S-O ( 1) 2203653

EXP.

Q6054 or TR MN100S-Y ( 1) 2203654

EXP.

Q6054 or TR MN100S-P ( 1) 2203656

EXP.

Q6060 TR 2SA1962-O 1 2202833 <420>

EXP.

Q6060 or TR 2SA1962-R ( 1) 2202832 <420>

EXP.

Q6060 or TR MP150S-O ( 1) 2203693 <420>

EXP.

Q6060 or TR MP150S-Y ( 1) 2203694 <420>

EXP.

Q6060 or TR MP150S-P ( 1) 2203696 <420>

EXP.

Q6060 TR 2SA1941-R 1 2203052 <402>, <8240>

EXP.

Q6060 or TR 2SA1941-O ( 1) 2203053

EXP.

Q6060 or TR MP130S-O ( 1) 2203673

EXP.

Q6060 or TR MP130S-Y ( 1) 2203674

EXP.

Q6060 or TR MP130S-P ( 1) 2203676

EXP.

Q6061 TR 2SA1962-O 1 2202833 <420>

EXP.

Q6061 or TR 2SA1962-R ( 1) 2202832

EXP.

Q6061 or TR MP150S-O ( 1) 2203693

EXP.

Q6061 or TR MP150S-Y ( 1) 2203694

EXP.

Q6061 or TR MP150S-P ( 1) 2203696

EXP.

Q6061 TR 2SA1941-R 1 2203052 <402>, <8240>

EXP.

Q6061 or TR 2SA1941-O ( 1) 2203053

EXP.

Q6061 or TR MP130S-O ( 1) 2203673

EXP.

Q6061 or TR MP130S-Y ( 1) 2203674

EXP.

Q6061 or TR MP130S-P ( 1) 2203676

EXP.

Q6062 TR KTA1962-O 1 2203553 <420>

EXP.

Q6062 or TR 2SA1962-R ( 1) 2202832

EXP.

Q6062 or TR 2SA1962-O ( 1) 2202833

EXP.

Q6062 or TR KTA1962-R ( 1) 2203552

EXP.

Q6062 or TR MP130S-O ( 1) 2203673

EXP.

Q6062 or TR MP130S-Y ( 1) 2203674

EXP.

Q6062 or TR MP130S-P ( 1) 2203676

EXP.

Q6062 TR KTB817-Y 1 2203624 <402>, <8240>

EXP.

Q6062 or TR KTB817-O ( 1) 2203623 <402>, <8240>

EXP.

Q6062 or TR MP100S-O ( 1) 2203643 <402>, <8240>

EXP.

Q6062 or TR MP100S-Y ( 1) 2203644 <402>, <8240>

EXP.

Q6062 or TR MP100S-P ( 1) 2203646 <402>, <8240>

EXP.

Q6063 TR KTA1962-O 1 2203553 <420>

EXP.

Q6063 or TR 2SA1962-R ( 1) 2202832

EXP.

Q6063 or TR 2SA1962-O ( 1) 2202833

5/37 PAGE

EXP.

Q6063 or TR KTA1962-R ( 1) 2203552

EXP.

Q6063 or TR MP130S-O ( 1) 2203673

EXP.

Q6063 or TR MP130S-Y ( 1) 2203674

EXP.

Q6063 or TR MP130S-P ( 1) 2203676

EXP.

Q6063 TR KTB817-Y 1 2203624 <402>, <8240>

EXP.

Q6063 or TR KTB817-O ( 1) 2203623

EXP.

Q6063 or TR MP100S-O ( 1) 2203643

EXP.

Q6063 or TR MP100S-Y ( 1) 2203644

EXP.

Q6063 or TR MP100S-P ( 1) 2203646

EXP.

Q6064 TR KTA1962-O 1 2203553 <420>

EXP.

Q6064 or TR 2SA1962-R ( 1) 2202832

EXP.

Q6064 or TR 2SA1962-O ( 1) 2202833

EXP.

Q6064 or TR KTA1962-R ( 1) 2203552

EXP.

Q6064 or TR MP130S-O ( 1) 2203673

EXP.

Q6064 or TR MP130S-Y ( 1) 2203674

EXP.

Q6064 or TR MP130S-P ( 1) 2203676

EXP.

Q6064 TR KTB817-Y 1 2203624 <402>, <8240>

EXP.

Q6064 or TR KTB817-O ( 1) 2203623

EXP.

Q6064 or TR MP100S-O ( 1) 2203643

EXP.

Q6064 or TR MP100S-Y ( 1) 2203644

EXP.

Q6064 or TR MP100S-P ( 1) 2203646

EXP.

T901 P TRANS NPT-1463G 1 2301679 ! <402>, <8240>

EXP.

T901 P TRANS NPT-1491D 1 2301738 ! <DD>, <DC>

EXP.

T901 P TRANS NPT-1491P 1 2301754 ! <PA>. <PT>

EXP.

T901 P TRANS NPT-1491DG 1 2301755 ! <WT>

EXP.

U1 PREAMPLIFIER PCB AS NADG-7401-3A 1 1A978501-3A <402>, <8240>

EXP.

U1 PREAMPLIFIER PCB AS NADG-7401-3B 1 1A978501-3B <DD>, <DC>

EXP.

U1 PREAMPLIFIER PCB AS NADG-7401-3C 1 1A978501-3C <WT>

EXP.

U1 PREAMPLIFIER PCB AS NADG-7401-3D 1 1A978501-3D <PA>, <PT>

EXP.

U2 DISPLAY PCB AS NADIS-7403-3A 1 1A978503-3A <402>, <8240>

EXP.

U2 DISPLAY PCB AS NADIS-7403-3A 1 1A978503-3A <WT>, <PA>, <PT>

EXP.

U2 DISPLAY PCB AS NADIS-7403-3B 1 1A978503-3B <DD>, <DC>

EXP.

U3 SWITCH PCB AS NASW-7404-3A 1 1A978504-3A <402>, <8240>

EXP.

U3 SWITCH PCB AS NASW-7404-3A 1 1A978504-3A <WT>, <PA>, <PT>

EXP.

U3 SWITCH PCB AS NASW-7404-3B 1 1A978504-3B <DD>, <DC>

EXP.

U4 HEADPHONE JACK PCB AS NAETC-7405-3A 1 1A978505-3A <402>, <8240>

EXP.

U4 HEADPHONE JACK PCB AS NAETC-7405-3A 1 1A978505-3A <WT>, <PA>, <PT>

EXP.

U4 HEADPHONE JACK PCB AS NAETC-7405-3B 1 1A978505-3B <DD>, <DC>

EXP.

U8 DRIVER AMPLIFIER PCB AS NAAF-7866-2A 1 1A974566-2A <402>, <8240>

EXP.

U8 DRIVER AMPLIFIER PCB AS NAAF-7866-2B 1 1A978566-2B <DD>, <DC>

EXP.

U8 DRIVER AMPLIFIER PCB AS NAAF-7866-2C 1 1A978566-2C <WT>, <PA>, <PT>

EXP.

U9 VIDEO & OPT TERMINAL PCB AS NAVD-7867-2A 1 1A978567-2A <402>, <8240>

EXP.

U9 VIDEO & OPT TERMINAL PCB AS NAVD-7867-2B 1 1A978567-2B <DD>, <DC>

EXP.

U9 VIDEO & OPT TERMINAL PCB AS NAVD-7867-2C 1 1A978567-2C <WT>, <PA>, <PT>

EXP.

U10 REGULATOR PCB AS NAETC-7868-2A 1 1A978568-2A <402>, <8240>

EXP.

U10 REGULATOR PCB AS NAETC-7868-2B 1 1A978568-2B <DD>, <DC>

EXP.

U10 REGULATOR PCB AS NAETC-7868-2C 1 1A978568-2C <WT>, <PA>, <PT>

EXP.

U11 TERMINAL PCB AS NAETC-7869-2A 1 1A978569-2A <402>, <8240>

EXP.

U11 TERMINAL PCB AS NAETC-7869-2B 1 1A978569-2B <DD>, <DC>

EXP.

U11 TERMINAL PCB AS NAETC-7869-2C 1 1A978569-2C <WT>, <PA>, <PT>

EXP.

U12 SPEAKER TERMINAL PCB AS NAETC-7870-2A 1 1A978570-2A <402>, <8240>

EXP.

U12 SPEAKER TERMINAL PCB AS NAETC-7870-2B 1 1A978570-2B <DD>, <DC>

EXP.

U12 SPEAKER TERMINAL PCB AS NAETC-7870-2C 1 1A978570-2C <WT>, <PA>, <PT>

EXP.

U15 S VIDEO TERMINAL PCB AS NAVD-7873-2A 1 1A978573-2A <402>, <8240>

EXP.

U15 S VIDEO TERMINAL PCB AS NAVD-7873-2B 1 1A978573-2B <DD>, <DC>

EXP.

U15 S VIDEO TERMINAL PCB AS NAVD-7873-2C 1 1A978573-2C <WT>, <PA>, <PT>

EXP.

U16 TERMINAL PCB AS NAETC-7874-2A 1 1A978574-2A <402>, <8240>

6/37 PAGE

EXP.

U16 TERMINAL PCB AS NAETC-7874-2B 1 1A978574-2B <DD>, <DC>

EXP.

U16 TERMINAL PCB AS NAETC-7874-2C 1 1A978574-2C <WT>, <PA>, <PT>

EXP.

U17 POWER AMPLIFIER PCB AS NAAF-7875-2A 1 1A978575-2A <402>, <8240>

EXP.

U17 POWER AMPLIFIER PCB AS NAAF-7875-2B 1 1A978575-2B <DD>, <DC>

EXP.

U17 POWER AMPLIFIER PCB AS NAAF-7875-2C 1 1A978575-2C <PA>

EXP.

U17 POWER AMPLIFIER PCB AS NAAF-7875-2D 1 1A978575-2D <WT>

EXP.

U17 POWER AMPLIFIER PCB AS NAAF-7875-2E 1 1A978575-2E <PT>

EXP.

U18 TERMINAL PCB AS NAPS-7876-2A 1 1A978576-2A <402>, <8240>

EXP.

U18 TERMINAL PCB AS NAPS-7876-2B 1 1A978576-2B <DD>, <DC>

EXP.

U18 TERMINAL PCB AS NAPS-7876-2C 1 1A978576-2C <PA>

EXP.

U18 TERMINAL PCB AS NAPS-7876-2D 1 1A978576-2D <WT>

EXP.

U18 TERMINAL PCB AS NAPS-7876-2E 1 1A978576-2E <PT>

EXP.

U19 POWER SUPPLY PCB AS NAPS-7877-2A 1 1A978577-2A <402>, <8240>

EXP.

U19 POWER SUPPLY PCB AS NAPS-7877-2B 1 1A978577-2B <DD>, <DC>

EXP.

U19 POWER SUPPLY PCB AS NAPS-7877-2C 1 1A978577-2C <PA>

EXP.

U19 POWER SUPPLY PCB AS NAPS-7877-2D 1 1A978577-2D <WT>

EXP.

U19 POWER SUPPLY PCB AS NAPS-7877-2E 1 1A978577-2E <PT>

EXP.

U20 TERMINAL PCB AS NAPS-7878-2A 1 1A978578-2A <402>, <8240>

EXP.

U20 TERMINAL PCB AS NAPS-7878-2B 1 1A978578-2B <DD>, <DC>

EXP.

U20 TERMINAL PCB AS NAPS-7878-2C 1 1A978578-2C <PA>

EXP.

U20 TERMINAL PCB AS NAPS-7878-2D 1 1A978578-2D <WT>

EXP.

U20 TERMINAL PCB AS NAPS-7878-2E 1 1A978578-2E <PT>

EXP.

U21 HOLDER PCB AS NAETC-7879-2A 1 1A978579-2A

EXP.

U22 THERMAL SENSOR PCB AS NAETC-7880-2A 1 1A978580-2A <402>, <8240>

EXP.

U22 THERMAL SENSOR PCB AS NAETC-7880-2C 1 1A978580-2C <PA>

EXP.

U22 THERMAL SENSOR PCB AS NAETC-7880-2D 1 1A978580-2D <WT>

EXP.

U22 THERMAL SENSOR PCB AS NAETC-7880-2E 1 1A978580-2E <PT>

EXP.

U23 HOLDER PCB AS NAETC-7881-2A 1 1A978581-2A <402>, <8240>

EXP.

U23 HOLDER PCB AS NAETC-7881-2B 1 1A978581-2B <DD>, <DC>

EXP.

U23 HOLDER PCB AS NAETC-7881-2C 1 1A978581-2C <PA>

EXP.

U23 HOLDER PCB AS NAETC-7881-2D 1 1A978581-2D <WT>

EXP.

U23 HOLDER PCB AS NAETC-7881-2E 1 1A978581-2E <PT>

EXP.

U25 TERMINAL PCB AS NAETC-7884-2A 1 1A978584-2A <402>, <8240>

EXP.

U25 TERMINAL PCB AS NAETC-7884-2B 1 1A978584-2B <DD>, <DC>

EXP.

U25 TERMINAL PCB AS NAETC-7884-2C 1 1A978584-2C <PA>

EXP.

U25 TERMINAL PCB AS NAETC-7884-2D 1 1A978584-2D <WT>

EXP.

U25 TERMINAL PCB AS NAETC-7884-2E 1 1A978584-2E <PT>

EXP.

U26 THERMAL SENSOR PCB AS NAETC-8256-2B 1 1A978556-2B <DD>, <DC>

EXP.

U27 TUNER UNIT TFCE1U114B 1 240134A <DD>, <DC>

EXP.

U27 or TUNER UNIT ENG06501QR ( 1) 240138A

EXP.

U27 or TUNER UNIT FAE385-A02F ( 1) 240146

EXP.

U27 TUNER UNIT TFCE1E512A 1 240135 <402>, <8240>

EXP.

U27 or TUNER UNIT FAE485-E02F ( 1) 240147

EXP.

U27 or TUNER UNIT ENG07501QR ( 1) 240139A

EXP.

U27 TUNER UNIT TFCE1E512A 1 240135 <WT>, <PA>, <PT>

EXP.

U27 or TUNER UNIT FAE485-E02F ( 1) 240147

EXP.

U27 or TUNER UNIT ENG07501QR ( 1) 240139A

EXP.

<Notes>

EXP.

When replacement the following the transistor,made from the same HFE rank as the original type.

EXP.

Q6050 - Q6060, Q6051 - Q6061, Q6052 - Q6062, Q6053 - Q6063, Q6054 - Q6064

PC BOARD PARTS LIST

U1 PREAMPLIFIER PC BOAD(NADG-7401-3A/3B/3C/3D)

<Notes> <402> : TX-SR402 (Chinese model)

NOTE : THE COMPONENTS IDENTIFIED BY THE MARK ! ARE

TX-SR402/8240/HT-R420

7/37 PAGE

<8240> : TX-SR8240 (Chinese model) <420> : HT-R420 (All destination) <DD> : HT-R420 (American model) <DC> : HT-R420 (Canadian model) <PA> : HT-R420 (Australian model) <PT> : HT-R420 （Asian model 230-240V) <WT> : HT-R420 （Worldwide model)

REF NO. NAME DESCRIPTION Q'TY PART NO. REMARKS

PCB

Q301 IC BD3811K1 1 22241761R3

PCB

Q302 IC NJM4565M-D 1 22241383R2

PCB

Q302 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE

PCB

Q302 or IC NJM4565M ( 1) 22240581R2

PCB

Q305 IC NJM4565M-D 1 22241383R2

PCB

Q305 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE

PCB

Q305 or IC NJM4565M ( 1) 22240581R2

PCB

Q306 TR RN2402 1 2214530R2

PCB

Q306 or TR KRA102S ( 1) 2216220R2

PCB

Q307 TR RN1441 1 2215410R2

PCB

Q308 TR RN1441 1 2215410R2

PCB

Q312 TR RN1441 1 2215410R2

PCB

Q313 TR RN1441 1 2215410R2

PCB

Q321 IC(REGULATOR) 78L07(SMT) 1 222780073R2

PCB

Q322 IC(REGULATOR) 79L07(SMT) 1 222790073R2

PCB

Q701 IC CS493264 1 22241762R2

PCB

Q707 IC TC7WU04FU 1 22240935R2

PCB

Q801 IC AK4586 1 22241620R3

PCB

Q802 IC NJM4565M-D 1 22241383R2

PCB

Q802 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE

PCB

Q802 or IC NJM4565M ( 1) 22240581R2

PCB

Q803 IC NJM4565M-D 1 22241383R2

PCB

Q803 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE

PCB

Q803 or IC NJM4565M ( 1) 22240581R2

PCB

Q804 IC NJM4565M-D 1 22241383R2

PCB

Q804 or IC MPC4570G2-T1(MST) ( 1) 22240489R1NE

PCB

Q804 or IC NJM4565M ( 1) 22240581R2

PCB

Q6402 IC(REGURATOR) 7812HF(TA7812S) 1 222780124TOS

PCB

Q6402 or IC(REGULATOR) 78M12HF ( 1) 222780125

PCB

Q6402A SCREW 3P+10FN(BC) 1 82143010

PCB

Q6402B HEAT SINK RAD-183 1 27160526

PCB

Q6402C TAPE TAPE(CLOTH-16U) 1 29110083

PCB

Q6403 IC(REGURATOR) 79012HF(TA79012S) 1 222790124TOS

PCB

Q6403 or IC(REGULATOR) 79M12HF ( 1) 222790125

PCB

Q6405 IC(REGURATOR) 7812HF(TA7812S) 1 222780124TOS

PCB

Q6405 or IC(REGULATOR) 78M12HF ( 1) 222780125

PCB

Q6405A SCREW 3P+10FN(BC) 1 82143010

PCB

Q6406 IC(REGURATOR) 7805HF(TA7805S) 1 222780054TOS

PCB

Q6406 or IC(REGULATOR) 78M05HF ( 1) 222780055

PCB

Q6406A SCREW 3P+10FN(BC) 1 82143010

PCB

Q7001 TR RN1404 1 2214490R2

PCB

Q7001 or TR KRC104S ( 1) 2216210R2

PCB

Q7002 IC TC74VHC541FT 1 22274541ER2TO

PCB

Q7002 or IC SN74AHC541PWR ( 1) 22274541IR2TI

PCB

Q7003 IC TC74HCT7007AF 1 222740077R2TO

PCB

Q7004 IC BA33C25FP 1 22241778R2

PCB

Q7006 TR RN1404 1 2214490R2

PCB

Q7006 or TR KRC104S ( 1) 2216210R2

NOTE : THE COMPONENTS IDENTIFIED BY THE MARK

!

ARE

CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE ONLY WITH PART NUMBER SPECIFIED.

8/37 PAGE

PCB

Q7007 TR RN1404 1 2214490R2

PCB

Q7007 or TR KRC104S ( 1) 2216210R2

PCB

Q7008 IC MPD784225GC-249-8BT 1 22242149R3

PCB

Q9501 TR 2SA1015-GR 1 2211455

PCB

D801 C-DIODE 1SS352 1 223234R2

PCB

D801 or C-DIODE 1SS355 ( 1) 223269R2

PCB

D802 C-DIODE 1SS352 1 223234R2

PCB

D802 or C-DIODE 1SS355 ( 1) 223269R2

PCB

D7001 C-DIODE 1SS352 1 223234R2

PCB

D7001 or C-DIODE 1SS355 ( 1) 223269R2

PCB

D7002 C-DIODE 1SS352 1 223234R2

PCB

D7002 or C-DIODE 1SS355 ( 1) 223269R2

PCB

D7003 C-DIODE 1SS352 1 223234R2

PCB

D7003 or C-DIODE 1SS355 ( 1) 223269R2

PCB

D7004 C-DIODE 1SS352 1 223234R2

PCB

D7004 or C-DIODE 1SS355 ( 1) 223269R2

PCB

D7702 ZENER D UDZS6.2B 1 224550620R2

PCB

D7702 or ZENER D UDZ6.2B ( 1) 224490620R2

PCB

D7702 or ZENER D HZU6.2B ( 1) 224660624R2

PCB

D9502 DIODE RL1N4003 1 22380260

PCB

D9502 or DIODE GP104003E ( 1) 22380035

PCB

D9502 or DIODE 1SR139-100 ( 1) 22380032

PCB

D9503 DIODE RL1N4003 1 22380260

PCB

D9503 or DIODE GP104003E ( 1) 22380035

PCB

D9503 or DIODE 1SR139-100 ( 1) 22380032

PCB

D9504 DIODE RL1N4003 1 22380260

PCB

D9504 or DIODE GP104003E ( 1) 22380035

PCB

D9504 or DIODE 1SR139-100 ( 1) 22380032

PCB

D9505 DIODE RL1N4003 1 22380260

PCB

D9505 or DIODE GP104003E ( 1) 22380035

PCB

D9505 or DIODE 1SR139-100 ( 1) 22380032

PCB

D9506 DIODE RL1N4003 1 22380260

PCB

D9506 or DIODE GP104003E ( 1) 22380035

PCB

D9506 or DIODE 1SR139-100 ( 1) 22380032

PCB

D9507 DIODE RL1N4003 1 22380260

PCB

D9507 or DIODE GP104003E ( 1) 22380035

PCB

D9507 or DIODE 1SR139-100 ( 1) 22380032

PCB

D9508 ZENER D UDZS27B 1 224552700R2

PCB

D9508 or ZENER D UDZ27B ( 1) 224492700R2

PCB

D9508 or ZENER D HZU27B ( 1) 224662704R2

PCB

D9509 DIODE RL1N4003 1 22380260

PCB

D9509 or DIODE GP104003E ( 1) 22380035

PCB

D9509 or DIODE 1SR139-100 ( 1) 22380032

PCB

D9510 DIODE RL1N4003 1 22380260

PCB

D9510 or DIODE GP104003E ( 1) 22380035

PCB

D9510 or DIODE 1SR139-100 ( 1) 22380032

PCB

D9511 DIODE RL1N4003 1 22380260

PCB

D9511 or DIODE GP104003E ( 1) 22380035

PCB

D9511 or DIODE 1SR139-100 ( 1) 22380032

PCB

D9512 DIODE RL1N4003 1 22380260

PCB

D9512 or DIODE GP104003E ( 1) 22380035

PCB

D9512 or DIODE 1SR139-100 ( 1) 22380032

PCB

L701 CHOKE COIL NCH-1471 1 231237M022R2

PCB

L701 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2

PCB

L702 CHOKE COIL NCH-1471 1 231237M022R2

PCB

L702 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2

PCB

L704 CHOKE COIL NCH-1471 1 231237M022R2

9/37 PAGE

PCB

L704 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2

PCB

L705 EMIFIL BK1608LM182-T 1 230958R1

PCB

L706 EMIFIL BK1608LM182-T 1 230958R1

PCB

L801 CHOKE COIL NCH-1471 1 231237M022R2

PCB

L801 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2

PCB

L802 CHOKE COIL NCH-1471 1 231237M022R2

PCB

L802 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2

PCB

L803 CHOKE COIL NCH-1471 1 231237M022R2

PCB

L803 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2

PCB

L804 CHOKE COIL NCH-1471 1 231237M022R2

PCB

L804 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2

PCB

L7001 CHOKE COIL NCH-1479 1 231237K470R2

PCB

L7001 or CHOKE COIL NCH-1587-470K ( 1) 233533K470R2

PCB

L7002 CHOKE COIL NCH-1471 1 231237M022R2

PCB

L7002 or CHOKE COIL NCH-1587-022K ( 1) 233533K022R2

PCB

X701 CERA LOCK CSTCV12.2MTJ0C4 1 3010324R2

PCB

X7001 CERA LOCK CSTCE12M5G52-R0 1 3010361R2

PCB

C101 VR C CE04W50V-3.3M(VR) 1 394680337

PCB

C101 or ELECT C CE04W50V3.3M(SC) ( 1) 394780337

PCB

C103 VR C CE04W50V-3.3M(VR) 1 394680337

PCB

C103 or ELECT C CE04W50V3.3M(SC) ( 1) 394780337

PCB

C104 C-CERA C CC725CH1H-101J1 1 342101014R1

PCB

C106 C-CERA C CC725CH1H-101J1 1 342101014R1

PCB

C300 TF C ECQ-B50V-471J 1 374724714 <8240>, <402>

PCB

C300 TF C ECQ-B50V-471J 1 374724714 <PA>, <WT>, <PT>

PCB

C300 TF C ECQ-B50V-101K 1 374721015 <DD>, <DC>

PCB

C301 TF C ECQ-B50V-471J 1 374724714 <8240>, <402>

PCB

C301 TF C ECQ-B50V-471J 1 374724714 <PA>, <WT>, <PT>

PCB

C301 TF C ECQ-B50V-101K 1 374721015 <DD>, <DC>

PCB

C302 C-CERA C CC725CH1H-101J1 1 342101014R1

PCB

C303 C-CERA C CC725CH1H-101J1 1 342101014R1

PCB

C304 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402> C304 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

PCB

C304 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C305 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402>

PCB

C305 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

PCB

C305 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C306 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402>

PCB

C306 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

PCB

C306 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C307 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402>

PCB

C307 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

PCB

C307 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C308 CERA C CK45F50V-103Z 1 335621030

PCB

C310 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402>

PCB

C310 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

PCB

C310 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C311 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402>

PCB

C311 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

PCB

C311 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C312 C-CERA C CC725CH1H-101J1 1 342101014R1

PCB

C313 C-CERA C CC725CH1H-101J1 1 342101014R1

PCB

C314 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402>

PCB

C314 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

PCB

C314 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C315 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402>

PCB

C315 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

10/37 PAGE

PCB

C315 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C316 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402>

PCB

C316 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

PCB

C316 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C317 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402>

PCB

C317 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

PCB

C317 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C318 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402>

PCB

C318 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

PCB

C318 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C319 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402>

PCB

C319 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

PCB

C319 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C320 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402>

PCB

C320 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

PCB

C320 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C321 C-CERA C CC725CH1H-471J1 1 342104714R1 <8240>, <402>

PCB

C321 C-CERA C CC725CH1H-471J1 1 342104714R1 <PA>, <WT>, <PT>

PCB

C321 C-CERA C CC725CH1H-101J1 1 342101014R1 <DD>, <DC>

PCB

C322 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C323 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C325 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C326 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C327 C-CERA C CC725CH1H-330J1 1 342103304R1

PCB

C328 C-CERA C CC725CH1H-330J1 1 342103304R1

PCB

C329 VX C CE04W16V-10M(VX) 1 393341007

PCB

C330 VX C CE04W16V-10M(VX) 1 393341007

PCB

C331 VX C CE04W16V-10M(VX) 1 393341007

PCB

C332 VX C CE04W16V-10M(VX) 1 393341007

PCB

C333 VX C CE04W16V-10M(VX) 1 393341007

PCB

C334 VX C CE04W16V-10M(VX) 1 393341007

PCB

C335 C-FILM C ECHU16V-332J 1 373043324R2

PCB

C336 C-FILM C ECHU16V-332J 1 373043324R2

PCB

C338 C-FILM C ECHU16V-563J 1 373045634R2

PCB

C340 C-FILM C ECHU16V-563J 1 373045634R2

PCB

C347 VR C CE04W16V-100M(VR) 1 394641017

PCB

C347 or ELECT C CE04W16V100M(SC) ( 1) 394741017

PCB

C348 VR C CE04W16V-100M(VR) 1 394641017

PCB

C348 or ELECT C CE04W16V100M(SC) ( 1) 394741017

PCB

C349 VX C CE04W16V-10M(VX) 1 393341007

PCB

C350 C-CERA C CC725CH1H-221J1 1 342102214R1

PCB

C351 C-CERA C CC725CH1H-330J1 1 342103304R1

PCB

C352 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C353 VX C CE04W16V-47M(VX) 1 393344707

PCB

C354 VX C CE04W16V-47M(VX) 1 393344707

PCB

C358 VX C CE04W16V-47M(VX) 1 393344707

PCB

C359 VR C CE04W16V-10M(VR) 1 394641007

PCB

C359 or ELECT C CE04W16V10M(SC) ( 1) 394741007

PCB

C360 C-CERA C CK732B1C-474K 1 337394745R1

PCB

C362 VR C CE04W16V-10M(VR) 1 394641007

PCB

C362 or ELECT C CE04W16V10M(SC) ( 1) 394741007

PCB

C363 VX C CE04W16V-10M(VX) 1 393341007

PCB

C364 VX C CE04W16V-10M(VX) 1 393341007

PCB

C365 C-CERA C CC732CH1H-222J 1 347342224R2

PCB

C366 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C367 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C703 C-CERA C CK725F1E-104Z1 1 332161040R1

11/37 PAGE

PCB

C706 VR C CE04W6.3V-100M(VR) 1 394621017

PCB

C706 or ELECT C CE04W6.3V100M(SC) ( 1) 394721017

PCB

C707 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C708 C-CERA C CK725B1H-103K1 1 332101035R1

PCB

C709 C-CERA C CK732B1A-105K 1 337361055R2

PCB

C710 C-CERA C CK732B1A-105K 1 337361055R2

PCB

C711 C-CERA C CC725CH1H-471J1 1 342104714R1

PCB

C712 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C713 C-CERA C CC725CH1H-101J1 1 342101014R1

PCB

C714 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C715 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C716 VR C CE04W6.3V-100M(VR) 1 394621017

PCB

C716 or ELECT C CE04W6.3V100M(SC) ( 1) 394721017

PCB

C800 C-CERA C CC725CH1H-330J1 1 342103304R1

PCB

C801 VR C CE04W16V-47M(VR) 1 394644707

PCB

C801 or ELECT C CE04W16V47M(SC) ( 1) 394744707

PCB

C804 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C805 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C806 VR C CE04W6.3V-470M(VR) 1 394624717

PCB

C806 or ELECT C CE04W6.3V470M(SC) ( 1) 394724717

PCB

C807 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C808 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C809 VR C CE04W16V-10M(VR) 1 394641007

PCB

C809 or ELECT C CE04W16V10M(SC) ( 1) 394741007

PCB

C810 VR C CE04W16V-47M(VR) 1 394644707

PCB

C810 or ELECT C CE04W16V47M(SC) ( 1) 394744707

PCB

C811 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C812 C-CERA C CC725CH1H-330J1 1 342103304R1

PCB

C813 C-CERA C CC725CH1H-330J1 1 342103304R1

PCB

C814 C-CERA C CC725CH1H-330J1 1 342103304R1

PCB

C815 C-CERA C CC725CH1H-102J1 1 342101024R1

PCB

C816 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C817 C-CERA C CC725CH1H-150J1 1 342101504R1

PCB

C832 VX C CE04W16V-10M(VX) 1 393341007

PCB

C833 VX C CE04W16V-10M(VX) 1 393341007

PCB

C834 VX C CE04W16V-10M(VX) 1 393341007

PCB

C835 VX C CE04W16V-10M(VX) 1 393341007

PCB

C836 VX C CE04W16V-10M(VX) 1 393341007

PCB

C837 VX C CE04W16V-10M(VX) 1 393341007

PCB

C840 C-CERA C CC725CH1E-821J1 1 342118214R1

PCB

C841 C-FILM C ECHU16V-822J 1 373048224R2

PCB

C842 C-CERA C CC725CH1E-821J1 1 342118214R1

PCB

C843 C-CERA C CC725CH1E-821J1 1 342118214R1

PCB

C844 C-CERA C CC725CH1E-821J1 1 342118214R1

PCB

C845 C-CERA C CC725CH1E-821J1 1 342118214R1

PCB

C848 C-CERA C CC732CH1H-152J 1 347341524R1

PCB

C849 C-FILM C ECHU16V-153J 1 373041534R2

PCB

C850 C-CERA C CC732CH1H-152J 1 347341524R1

PCB

C851 C-CERA C CC732CH1H-152J 1 347341524R1

PCB

C852 TF C ECQ-B50V-152J 1 374721524

PCB

C853 TF C ECQ-B50V-152J 1 374721524

PCB

C854 VX C CE04W16V-10M(VX) 1 393341007

PCB

C855 VX C CE04W16V-47M(VX) 1 393344707

PCB

C856 VX C CE04W16V-10M(VX) 1 393341007

PCB

C857 VX C CE04W16V-10M(VX) 1 393341007

PCB

C858 VX C CE04W16V-10M(VX) 1 393341007

PCB

C859 VX C CE04W16V-10M(VX) 1 393341007

12/37 PAGE

PCB

C6401 TF C ECQ-V50V-104J 1 374721044

PCB

C6403 C-CERA C CK725F1H-223Z1 1 332152230R1

PCB

C6404 VR C CE04W16V-10M(VR) 1 394641007

PCB

C6404 or ELECT C CE04W16V10M(SC) ( 1) 394741007

PCB

C6405 C-CERA C CK725F1H-223Z1 1 332152230R1

PCB

C6406 VR C CE04W16V-10M(VR) 1 394641007

PCB

C6406 or ELECT C CE04W16V10M(SC) ( 1) 394741007

PCB

C6409 C-CERA C CK725F1H-223Z1 1 332152230R1

PCB

C6410 VR C CE04W16V-10M(VR) 1 394641007

PCB

C6410 or ELECT C CE04W16V10M(SC) ( 1) 394741007

PCB

C6411 C-CERA C CK725F1H-223Z1 1 332152230R1

PCB

C6412 VR C CE04W16V-10M(VR) 1 394641007

PCB

C6412 or ELECT C CE04W16V10M(SC) ( 1) 394741007

PCB

C7001 EDL C DX-5R5L104 1 3000078

PCB

C7001 or EDL C FMC0H104Z ( 1) 3000120

PCB

C7001 or EDL C SCDA5R5104A ( 1) 3000121

PCB

C7002 VR C CE04W6.3V-100M(VR) 1 394621017

PCB

C7002 or ELECT C CE04W6.3V100M(SC) ( 1) 394721017

PCB

C7003 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7004 VR C CE04W50V-1M(VR) 1 394680107

PCB

C7004 or ELECT C CE04W50V1.0M(SC) ( 1) 394780107

PCB

C7005 VR C CE04W6.3V-100M(VR) 1 394621017

PCB

C7005 or ELECT C CE04W6.3V100M(SC) ( 1) 394721017

PCB

C7006 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7007 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7008 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7009 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7010 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7011 VR C CE04W16V-47M(VR) 1 394644707

PCB

C7011 or ELECT C CE04W16V47M(SC) ( 1) 394744707

PCB

C7012 VR C CE04W16V-47M(VR) 1 394644707

PCB

C7012 or ELECT C CE04W16V47M(SC) ( 1) 394744707

PCB

C7014 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7015 VR C CE04W16V-47M(VR) 1 394644707

PCB

C7015 or ELECT C CE04W16V47M(SC) ( 1) 394744707

PCB

C9501 TF C ECQ-V50V-104J 1 374721044

PCB

C9502 TF C ECQ-V50V-104J 1 374721044

PCB

C9503 TF C ECQ-V50V-104J 1 374721044

PCB

C9505 VR C CE04W35V-2200M(VR) 1 394662227S

PCB

C9505 or ELECT C CE04W35V2200M(SC) ( 1) 394762227S

PCB

C9506 VR C CE04W35V-470M(VR) 1 394664717

PCB

C9506 or ELECT C CE04W35V470M(SC) ( 1) 394764717

PCB

C9507 VR C CE04W35V-220M(VR) 1 394662217

PCB

C9507 or ELECT C CE04W35V220M(SC) ( 1) 394762217

PCB

C9508 VR C CE04W16V-4700M(VR) 1 394644727S

PCB

C9508 or ELECT C CE04W16V4700M(SC) ( 1) 394744727S

PCB

C9510 VR C CE04W63V-220M(VR) 1 394672217

PCB

C9511 C-CERA C CK725F1H-223Z1 1 332152230R1

PCB

C9512 C-CERA C CK725F1H-223Z1 1 332152230R1

PCB

R102 C-CARBON R RN72K1J-223JE 1 435032234R1

PCB

R103 C-CARBON R RN72K1J-223JE 1 435032234R1

PCB

R104 C-CARBON R RN72K1J-104JE 1 435031044R1

PCB

R185 C-CARBON R RN72K1J-473JE 1 435034734R1

PCB

R186 C-CARBON R RN72K1J-473JE 1 435034734R1

PCB

R187 C-CARBON R RN72K1J-473JE 1 435034734R1

PCB

R300 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R301 C-CARBON R RN72K1J-331JE 1 435033314R1

13/37 PAGE

PCB

R302 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R303 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R304 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R305 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R306 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R307 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R310 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R311 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R312 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R313 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R314 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R315 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R316 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R317 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R318 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R319 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R320 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R321 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R330 C-CARBON R RN72K1J-471JE 1 435034714R1

PCB

R331 C-CARBON R RN72K1J-471JE 1 435034714R1

PCB

R347 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R348 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R359 C-CARBON R RN72K1J-271JE 1 435032714R1

PCB

R360 C-CARBON R RN72K1J-271JE 1 435032714R1

PCB

R361 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R362 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R363 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R364 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R367 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R368 C-CARBON R RN72K1J-473JE 1 435034734R1

PCB

R369 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R370 C-CARBON R RN72K1J-223JE 1 435032234R1

PCB

R373 C-CARBON R RN72K1J-471JE 1 435034714R1

PCB

R374 C-CARBON R RN72K1J-471JE 1 435034714R1

PCB

R375 C-CARBON R RN72K1J-471JE 1 435034714R1

PCB

R376 C-CARBON R RN72K1J-271JE 1 435032714R1

PCB

R377 C-CARBON R RN72K1J-223JE 1 435032234R1

PCB

R378 C-CARBON R RN72K1J-223JE 1 435032234R1

PCB

R379 C-CARBON R RN72K1J-223JE 1 435032234R1

PCB

R380 C-CARBON R RN72K1J-223JE 1 435032234R1

PCB

R381 C-CARBON R RN72K1J-223JE 1 435032234R1

PCB

R382 C-CARBON R RN72K1J-223JE 1 435032234R1

PCB

R383 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R384 C-CARBON R RN72K1J-224JE 1 435032244R1

PCB

R385 C-CARBON R RN72K1J-101JE 1 435031014R1

PCB

R386 C-CARBON R RN72K1J-272JE 1 435032724R1

PCB

R387 C-CARBON R RN72K1J-272JE 1 435032724R1

PCB

R388 C-CARBON R RN72K1J-101JE 1 435031014R1

PCB

R701 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R702 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R703 C-CARBON R RN72K1J-472JE 1 435034724R1

PCB

R704 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R705 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R706 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R707 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R708 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R709 C-CARBON R RN72K1J-103JE 1 435031034R1

14/37 PAGE

PCB

R710 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R711 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R712 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R713 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R714 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R715 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R716 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R717 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R718 C-CARBON R RN72K1J-333JE 1 435033334R1

PCB

R719 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R720 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R721 C-CARBON R RN72K1J-472JE 1 435034724R1

PCB

R722 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R723 C-CARBON R RN72K1J-472JE 1 435034724R1

PCB

R724 C-CARBON R RN72K1J-472JE 1 435034724R1

PCB

R725 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R726 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R727 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R728 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R729 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R739 C-CARBON R RN72K1J-105JE 1 435031054R1

PCB

R801 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R803 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R804 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R805 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R806 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R807 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R808 C-CARBON R RN72K1J-470JE 1 435034704R1

PCB

R809 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R810 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R811 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R812 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R813 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R814 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R815 C-CARBON R RN72K1J-183JE 1 435031834R1

PCB

R816 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R817 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R818 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R819 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R820 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R821 C-CARBON R RN72K1J-471JE 1 435034714R1

PCB

R832 C-CARBON R RN72K1J-104JE 1 435031044R1

PCB

R833 C-CARBON R RN72K1J-104JE 1 435031044R1

PCB

R834 C-CARBON R RN72K1J-104JE 1 435031044R1

PCB

R835 C-CARBON R RN72K1J-104JE 1 435031044R1

PCB

R836 C-CARBON R RN72K1J-104JE 1 435031044R1

PCB

R837 C-CARBON R RN72K1J-104JE 1 435031044R1

PCB

R840 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R841 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R842 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R843 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R844 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R845 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R848 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R849 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R850 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R851 C-CARBON R RN72K1J-222JE 1 435032224R1

15/37 PAGE

PCB

R852 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R853 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R6402 METAL O R RS1/2WBJ-10 1 442521004F

PCB

R6403 METAL O R RS1/2WBJ-33 1 442523304F

PCB

R6407 METAL R RNU1WCJ-3.3 1 452630334F

PCB

R6410 METAL R RNU1/2WCJ-2.2 1 453530224

PCB

R7000 C-CARBON R RN72K1J-101JE 1 435031014R1

PCB

R7001 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R7002 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R7003 C-CARBON R RN72K1J-103JE 1 435031034R1 <8240>, <402>

PCB

R7003 C-CARBON R RN72K1J-103JE 1 435031034R1 <PA>, <WT>, <PT>

PCB

R7003 C-CARBON R RN72K1J-000JE 1 435030004R1 <DD>, <DC>

PCB

R7004 C-CARBON R RN72K1J-333JE 1 435033334R1 <8240>, <402>

PCB

R7004 C-CARBON R RN72K1J-333JE 1 435033334R1 <PA>, <PT>

PCB

R7004 C-CARBON R RN72K1J-103JE 1 435031034R1 <WT>

PCB

R7004 C-CARBON R RN72K1J-102JE 1 435031024R1 <DD>, <DC>

PCB

R7011 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7012 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7015 C-CARBON R RN72K1J-820JE 1 435038204R1

PCB

R7016 C-CARBON R RN72K1J-820JE 1 435038204R1

PCB

R7017 C-CARBON R RN72K1J-820JE 1 435038204R1

PCB

R7018 C-CARBON R RN72K1J-820JE 1 435038204R1

PCB

R7019 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7020 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7021 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R7022 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7023 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7024 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7025 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7026 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7027 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7028 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7029 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7030 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7033 C-CARBON R RN72K1J-473JE 1 435034734R1

PCB

R7034 C-CARBON R RN72K1J-471JE 1 435034714R1

PCB

R7035 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7036 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7037 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7038 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R7039 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R7040 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7041 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R7042 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7043 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7044 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7045 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7046 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7047 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7048 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7049 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7050 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7051 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7052 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7053 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7054 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7055 C-CARBON R RN72K1J-221JE 1 435032214R1

16/37 PAGE

PCB

R7056 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7057 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7058 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7059 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7060 C-CARBON R RN72K1J-473JE 1 435034734R1

PCB

R7062 C-CARBON R RN72K1J-224JE 1 435032244R1

PCB

R7063 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7064 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7065 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7066 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7067 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7068 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7069 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7070 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7071 C-CARBON R RN72K1J-472JE 1 435034724R1

PCB

R7072 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7073 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7074 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7075 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7076 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7077 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7078 C-CARBON R RN72K1J-333JE 1 435033334R1

PCB

R7079 C-CARBON R RN72K1J-333JE 1 435033334R1

PCB

R7080 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R7081 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7082 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7083 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7084 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7085 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7120 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7134 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7138 C-CARBON R RN72K1J-223JE 1 435032234R1

PCB

R7178 C-CARBON R RN72K1J-563JE 1 435035634R1

PCB

R7179 C-CARBON R RN72K1J-472JE 1 435034724R1 <420>

PCB

R7179 C-CARBON R RN72K1J-103JE 1 435031034R1 <402>, <8240>

PCB

R7180 C-CARBON R RN72K1J-333JE 1 435033334R1

PCB

R7839 C-CARBON R RN72K1J-223JE 1 435032234R1

PCB

R9506 METAL O R RS1/2WBJ-22 1 443522204T

PCB

R9507 C-CARBON R RN72K1J-153JE 1 435031534R1

PCB

R9508 C-CARBON R RN72K1J-153JE 1 435031534R1

PCB

R9509 C-CARBON R RN72K1J-104JE 1 435031044R1

PCB

P101 SOCKET NSCT-15P2108 1 25052211

PCB

P101 or SOCKET NSCT-15P1811 ( 1) 25052024

PCB

P301 PIN JACK NPJ-6PDRW386 1 25045571

PCB

P301 or JACK NPJ-6PDBL159 ( 1) 25045300

PCB

P302 JACK NPJ-2PDBL185 1 25045333

PCB

P304 PIN JACK NPJ-6PDRW386 1 25045571

PCB

P304 or JACK NPJ-6PDBL159 ( 1) 25045300

PCB

P305 PIN JACK NPJ-6PWRLGGP493 1 25045697

PCB

P306 SOCKET AS NSAS-20P1004 1 2009990717UL

PCB

P351 PIN JACK NPJ-1PDP510 1 25045720

PCB

P410B PLUG NPLG-10P662 1 25055706

PCB

P411B PLUG NPLG-10P662 1 25055706

PCB

P412B PLUG NPLG-8P660 1 25055704

PCB

P6403 RETAINER KANAGU 1 27141059

PCB

P701 PWB NCDG-7401 1 25137401C

PCB

P7502B SOCKET NSCT-10P2473 1 25052576R2

17/37 PAGE

PCB

P801 PLUG NPLG-14P666 1 25055710

PCB

E300 RETAINER KANAGU 1 27141059

PCB PCB

U2 DISPLAY PC BOARD(NADIS-7403-3A/3B)

PCB

U3 SWITCH PC BOARD(NASW-7404-3A/3B)

PCB

U4 HEADPHONE JACK PC BOARD(NAETC-7405-3A/3B)

PCB

<Note> Parts are indicated collectively, without dividing for above-mentioned each substrate.

PCB

REF NO. NAME DESCRIPTION Q'TY PART NO. REMARKS

PCB

U7501 REMO SENS SPS-444-1-VP 1 241352

PCB

Q7501 FL TUBE 16BT123GK 1 212250

PCB

Q7501A HOLDER (FL) 1 27190989B

PCB

Q7502 IC MPD780232GC-030-8BT 1 22241571R3

PCB

Q7503 TR KTC3875-GR 1 2216175R2

PCB

Q7503 or TR 2SC2712-GR ( 1) 2213145R2

PCB

Q7504 TR KRA103S 1 2216230R2

PCB

Q7504 or TR RN2403 ( 1) 2214540R2

PCB

Q7506 TR KRC102S 1 2216190R2

PCB

Q7506 or TR RN1402 ( 1) 2214470R2

PCB

D7501 ZENER D UDZS8.2B 1 224550820R2

PCB

D7501 or ZENER D UDZ8.2B ( 1) 224490820R2

PCB

D7501 or ZENER D HZU8.2B ( 1) 224660824R2

PCB

D7502 ZENER D UDZS5.1B 1 224550510R2

PCB

D7502 or ZENER D UDZ5.1B ( 1) 224490510R2

PCB

D7502 or ZENER D HZU5.1B ( 1) 224660514R2

PCB

D7503 C-DIODE 1SS355 1 223269R2

PCB

D7503 or C-DIODE 1SS352 ( 1) 223234R2

PCB

D7505 LED SLR-56VRTB7 1 225431

PCB

D7505 or LED SEL4110R ( 1) 225290

PCB

D7507 C-DIODE 1SS355 1 223269R2

PCB

D7507 or C-DIODE 1SS352 ( 1) 223234R2

PCB

L7504 CHOKE COIL NCH-1477 1 231237K220R2

PCB

L7505 CHOKE COIL NCH-1477 1 231237K220R2

PCB

X7501 CERA LOCK CST5.00MGW 1 3010242

PCB

C253 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C261 C-CERA C CC725CH1H-101J1 1 342101014R1 <8240>, <402>

PCB

C261 C-CERA C CC725CH1H-101J1 1 342101014R1 <PA>, <WT>, <PT>

PCB

C261 C-CERA C CC725CH1H-471J1 1 342104714R1 <DD>, <DC>

PCB

C262 C-CERA C CC725CH1H-101J1 1 342101014R1 <8240>, <402>

PCB

C262 C-CERA C CC725CH1H-101J1 1 342101014R1 <PA>, <WT>, <PT>

PCB

C262 C-CERA C CC725CH1H-471J1 1 342104714R1 <DD>, <DC>

PCB

C263 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7501 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7502 ELECT C CE04W50V-33M 1 355783309T

PCB

C7503 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7504 C-CERA C CK725F1H-473Z1 1 332154730R1

PCB

C7505 C-CERA C CK725F1H-473Z1 1 332154730R1

PCB

C7506 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7507 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7508 C-CERA C CC725CH1E-102J1 1 342111024R1

PCB

C7509 C-CERA C CC725CH1E-102J1 1 342111024R1

PCB

C7510 C-CERA C CC725CH1E-102J1 1 342111024R1

PCB

C7511 C-CERA C CC725CH1E-102J1 1 342111024R1

PCB

C7513 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7514 VR C CE04W6.3V-100M(VR) 1 394621017

PCB

C7514 or ELECT C CE04W6.3V100M(SC) ( 1) 394721017

PCB

C7515 C-CERA C CK725F1E-104Z1 1 332161040R1

PCB

C7516 C-CERA C CK725F1E-104Z1 1 332161040R1

18/37 PAGE

PCB

C7517 C-CERA C CC725CH1E-102J1 1 342111024R1

PCB

C7518 C-CERA C CC725CH1E-102J1 1 342111024R1

PCB

C7519 C-CERA C CC725CH1E-102J1 1 342111024R1

PCB

C7520 C-CERA C CC725CH1E-102J1 1 342111024R1

PCB

C7521 ELECT C CE04W6.3V-220M 1 355722219

PCB

C7522 C-CERA C CC725CH1H-101J1 1 342101014R1

PCB

C7523 C-CERA C CC725CH1E-102J1 1 342111024R1

PCB

R7501 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7502 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7503 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R7504 C-CARBON R RN72K1J-473JE 1 435034734R1

PCB

R7505 C-CARBON R RN72K1J-224JE 1 435032244R1

PCB

R7506 C-CARBON R RN72K1J-472JE 1 435034724R1

PCB

R7507 C-CARBON R RN72K1J-472JE 1 435034724R1

PCB

R7508 C-CARBON R RN72K1J-472JE 1 435034724R1

PCB

R7509 C-CARBON R RN72K1J-472JE 1 435034724R1

PCB

R7510 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7511 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7512 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R7513 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R7514 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R7515 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R7516 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R7517 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7518 C-CARBON R RN72K1J-104JE 1 435031044R1

PCB

R7519 C-CARBON R RN72K1J-104JE 1 435031044R1

PCB

R7520 C-CARBON R RN72K1J-272JE 1 435032724R1

PCB

R7521 C-CARBON R RN72K1J-272JE 1 435032724R1

PCB

R7522 C-CARBON R RN72K1J-272JE 1 435032724R1

PCB

R7523 C-CARBON R RN72K1J-272JE 1 435032724R1

PCB

R7524 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7526 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R7527 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R7528 C-CARBON R RN72K1J-561JE 1 435035614R1

PCB

R7529 C-CARBON R RN72K1J-561JE 1 435035614R1

PCB

R7530 C-CARBON R RN72K1J-102JE 1 435031024R1

PCB

R7531 C-CARBON R RN72K1J-221JE 1 435032214R1

PCB

R7532 C-CARBON R RN72K1J-103JE 1 435031034R1

PCB

R7611 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R7612 C-CARBON R RN72K1J-471JE 1 435034714R1

PCB

R7613 C-CARBON R RN72K1J-561JE 1 435035614R1

PCB

R7614 C-CARBON R RN72K1J-821JE 1 435038214R1

PCB

R7615 C-CARBON R RN72K1J-122JE 1 435031224R1

PCB

R7621 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R7622 C-CARBON R RN72K1J-471JE 1 435034714R1

PCB

R7623 C-CARBON R RN72K1J-561JE 1 435035614R1

PCB

R7624 C-CARBON R RN72K1J-821JE 1 435038214R1

PCB

R7625 C-CARBON R RN72K1J-122JE 1 435031224R1

PCB

R7626 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R7631 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R7632 C-CARBON R RN72K1J-471JE 1 435034714R1

PCB

R7633 C-CARBON R RN72K1J-561JE 1 435035614R1

PCB

R7634 C-CARBON R RN72K1J-821JE 1 435038214R1

PCB

R7635 C-CARBON R RN72K1J-122JE 1 435031224R1

PCB

R7636 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

R7641 C-CARBON R RN72K1J-331JE 1 435033314R1

PCB

R7642 C-CARBON R RN72K1J-471JE 1 435034714R1

19/37 PAGE

PCB

R7643 C-CARBON R RN72K1J-561JE 1 435035614R1

PCB

R7644 C-CARBON R RN72K1J-821JE 1 435038214R1

PCB

R7645 C-CARBON R RN72K1J-122JE 1 435031224R1

PCB

R7646 C-CARBON R RN72K1J-222JE 1 435032224R1

PCB

P7501 ST JACK YKB21-5005 1 25045724

PCB

P7502A SOCKET NSCT-10P1679 1 25051892

PCB

P7502Aor SOCKET NSCT-10P2374 ( 1) 25052477

PCB

P7503A SOCKET NSCT-8P1841 1 25052054

PCB

P7503Aor SOCKET NSCT-8P1639 ( 1) 25051852

PCB

P7503Aor SOCKET NSCT-8P2138 ( 1) 25052241

PCB

S7501 R ENCODE EC12E2425 1 25065655

PCB

S7611 PUSH SW NPS-111-S681 1 25035718

PCB

S7611 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7612 PUSH SW NPS-111-S681 1 25035718

PCB

S7612 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7613 PUSH SW NPS-111-S681 1 25035718

PCB

S7613 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7614 PUSH SW NPS-111-S681 1 25035718

PCB

S7614 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7615 PUSH SW NPS-111-S681 1 25035718

PCB

S7615 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7616 PUSH SW NPS-111-S681 1 25035718

PCB

S7616 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7621 PUSH SW NPS-111-S681 1 25035718

PCB

S7621 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7622 PUSH SW NPS-111-S681 1 25035718

PCB

S7622 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7623 PUSH SW NPS-111-S681 1 25035718

PCB

S7623 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7624 PUSH SW NPS-111-S681 1 25035718

PCB

S7624 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7625 PUSH SW NPS-111-S681 1 25035718

PCB

S7625 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7626 PUSH SW NPS-111-S681 1 25035718

PCB

S7626 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7627 PUSH SW NPS-111-S681 1 25035718

PCB

S7627 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7631 PUSH SW NPS-111-S681 1 25035718

PCB

S7631 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7632 PUSH SW NPS-111-S681 1 25035718

PCB

S7632 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7633 PUSH SW NPS-111-S681 1 25035718

PCB

S7633 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7634 PUSH SW NPS-111-S681 1 25035718

PCB

S7634 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7635 PUSH SW NPS-111-S681 1 25035718

PCB

S7635 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7636 PUSH SW NPS-111-S681 1 25035718

PCB

S7636 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7637 PUSH SW NPS-111-S681 1 25035718

PCB

S7637 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7641 PUSH SW NPS-111-S681 1 25035718

PCB

S7641 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7642 PUSH SW NPS-111-S681 1 25035718

PCB

S7642 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7643 PUSH SW NPS-111-S681 1 25035718

PCB

S7643 or PUSH SW NPS-111-S677 ( 1) 25035714

20/37 PAGE

PCB

S7644 PUSH SW NPS-111-S681 1 25035718

PCB

S7644 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7645 PUSH SW NPS-111-S681 1 25035718

PCB

S7645 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7646 PUSH SW NPS-111-S681 1 25035718

PCB

S7646 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

S7647 PUSH SW NPS-111-S681 1 25035718

PCB

S7647 or PUSH SW NPS-111-S677 ( 1) 25035714

PCB

E7501 RETAINER KANAGU(ｱｰｽ) 1 27141059

PCB

JL7501A WIRE HOL NSCT-3P894 1 25051107

PCB

JL7501B WIRE HOL NSCT-3P894 1 25051107

PCB

JL7502A WIRE HOL NSCT-5P896 1 25051109

PCB

JL7502B WIRE HOL NSCT-5P896 1 25051109

PCB PCB PCB

U8 DRIVER AMPLIFIER PC BOARD(NAAF-7866-2A/2B/2C)

PCB

U9 VIDEO & OPT TERMINAL PC BOARD(NAVD-7867-2A/2B/2C)

PCB

U10 REGULATOR PC BOARD(NAETC-7868-2A/2B/2C)

PCB

U11 TERMINAL PC BOARD(NAETC-7869--2A/2B/2C)

PCB

U12 SPEAKER TERMINAL PC BOARD(NAETC-7870-2A/2B/2C)

PCB

U15 S VIDEO TERMINAL PC BOARD(NAVD-7873-2A/2B/2C)

PCB

U16 TERMINAL PC BOARD(NAETC-7874-2A/2B/2C)

PCB

<Note> Parts are indicated collectively, without dividing for above-mentioned each substrate.

PCB

REF NO. NAME DESCRIPTION QTY PART NO. REMARKS

PCB

U281 PHT CP TORX179L 1 24120101

PCB

Q201 TR RN1241-A 1 2213631

PCB

Q201 or TR RN1241-B ( 1) 2213632

PCB

Q202 TR RN1241-A 1 2213631

PCB

Q202 or TR RN1241-B ( 1) 2213632

PCB

Q203 IC LA7956 1 22241759

PCB

Q204 TR KTA1267-GR 1 2215995

PCB

Q204 or TR 2SA933S-R ( 1) 2213354

PCB

Q205 TR KRA102M 1 2215770

PCB

Q205 or TR DTA114ES ( 1) 2213510

PCB

Q206 TR KRA102M 1 2215770

PCB

Q206 or TR DTA114ES ( 1) 2213510

PCB

Q207 TR RN1241-A 1 2213631

PCB

Q207 or TR RN1241-B ( 1) 2213632

PCB

Q208 TR RN1241-A 1 2213631

PCB

Q208 or TR RN1241-B ( 1) 2213632

PCB

Q209 TR KTA1267-GR 1 2215995

PCB

Q209 or TR 2SA933S-R ( 1) 2213354

PCB

Q210 TR RN1241-A 1 2213631

PCB

Q210 or TR RN1241-B ( 1) 2213632

PCB

Q211 TR RN1241-A 1 2213631

PCB

Q211 or TR RN1241-B ( 1) 2213632

PCB

Q212 IC LA7956 1 22241759

PCB

Q213 IC LA7956 1 22241759

PCB

Q281 IC 74HCU04F 1 222740046R2

PCB

Q5000 TR KTC3200-BL 1 2215896

PCB

Q5000 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5000 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5000 or TR 2SC1845-E ( 1) 2211733

PCB

Q5001 TR KTC3200-BL 1 2215896

PCB

Q5001 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5001 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5001 or TR 2SC1845-E ( 1) 2211733

21/37 PAGE

PCB

Q5002 TR KTC3200-BL 1 2215896

PCB

Q5002 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5002 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5002 or TR 2SC1845-E ( 1) 2211733

PCB

Q5003 TR KTC3200-BL 1 2215896

PCB

Q5003 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5003 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5003 or TR 2SC1845-E ( 1) 2211733

PCB

Q5004 TR KTC3200-BL 1 2215896

PCB

Q5004 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5004 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5004 or TR 2SC1845-E ( 1) 2211733

PCB

Q5010 TR KTC3200-BL 1 2215896

PCB

Q5010 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5010 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5010 or TR 2SC1845-E ( 1) 2211733

PCB

Q5011 TR KTC3200-BL 1 2215896

PCB

Q5011 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5011 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5011 or TR 2SC1845-E ( 1) 2211733

PCB

Q5012 TR KTC3200-BL 1 2215896

PCB

Q5012 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5012 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5012 or TR 2SC1845-E ( 1) 2211733

PCB

Q5013 TR KTC3200-BL 1 2215896

PCB

Q5013 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5013 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5013 or TR 2SC1845-E ( 1) 2211733

PCB

Q5014 TR KTC3200-BL 1 2215896

PCB

Q5014 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5014 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5014 or TR 2SC1845-E ( 1) 2211733

PCB

Q5030 TR KTA1024-Y 1 2215844

PCB

Q5030 or TR KTA1024-O ( 1) 2215843

PCB

Q5030 or TR 2SA949-Y ( 1) 2211354

PCB

Q5030 or TR 2SA949-O ( 1) 2211353

PCB

Q5031 TR KTA1024-Y 1 2215844

PCB

Q5031 or TR KTA1024-O ( 1) 2215843

PCB

Q5031 or TR 2SA949-Y ( 1) 2211354

PCB

Q5031 or TR 2SA949-O ( 1) 2211353

PCB

Q5032 TR KTA1024-Y 1 2215844

PCB

Q5032 or TR KTA1024-O ( 1) 2215843

PCB

Q5032 or TR 2SA949-Y ( 1) 2211354

PCB

Q5032 or TR 2SA949-O ( 1) 2211353

PCB

Q5033 TR KTA1024-Y 1 2215844

PCB

Q5033 or TR KTA1024-O ( 1) 2215843

PCB

Q5033 or TR 2SA949-Y ( 1) 2211354

PCB

Q5033 or TR 2SA949-O ( 1) 2211353

PCB

Q5034 TR KTA1024-Y 1 2215844

PCB

Q5034 or TR KTA1024-O ( 1) 2215843

PCB

Q5034 or TR 2SA949-Y ( 1) 2211354

PCB

Q5034 or TR 2SA949-O ( 1) 2211353

PCB

Q5040 TR KTC3206-Y 1 2215854

PCB

Q5040 or TR KTC3206-O ( 1) 2215853

PCB

Q5040 or TR 2SC2229-Y ( 1) 2211634

PCB

Q5040 or TR 2SC2229-O ( 1) 2211633

PCB

Q5041 TR KTC3206-Y 1 2215854

22/37 PAGE

PCB

Q5041 or TR KTC3206-O ( 1) 2215853

PCB

Q5041 or TR 2SC2229-Y ( 1) 2211634

PCB

Q5041 or TR 2SC2229-O ( 1) 2211633

PCB

Q5042 TR KTC3206-Y 1 2215854

PCB

Q5042 or TR KTC3206-O ( 1) 2215853

PCB

Q5042 or TR 2SC2229-Y ( 1) 2211634

PCB

Q5042 or TR 2SC2229-O ( 1) 2211633

PCB

Q5043 TR KTC3206-Y 1 2215854

PCB

Q5043 or TR KTC3206-O ( 1) 2215853

PCB

Q5043 or TR 2SC2229-Y ( 1) 2211634

PCB

Q5043 or TR 2SC2229-O ( 1) 2211633

PCB

Q5044 TR KTC3206-Y 1 2215854

PCB

Q5044 or TR KTC3206-O ( 1) 2215853

PCB

Q5044 or TR 2SC2229-Y ( 1) 2211634

PCB

Q5044 or TR 2SC2229-O ( 1) 2211633

PCB

Q5050 TR KTC3200-BL 1 2215896 <420>

PCB

Q5050 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5050 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5050 or TR 2SC1845-F ( 1) 2211732

PCB

Q5050 or TR 2SC1845-E ( 1) 2211733

PCB

Q5050 or TR KTC3200-GR ( 1) 2215895

PCB

Q5050 TR KTC3199-GR 1 2215864 <402>, <8240>

PCB

Q5050 or TR 2SC2458-GR ( 1) 2212115

PCB

Q5050 or TR 2SC1740S-R ( 1) 2213284

PCB

Q5050 or TR 2SC1740S-S ( 1) 2213285

PCB

Q5051 TR KTC3200-BL 1 2215896 <420>

PCB

Q5051 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5051 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5051 or TR 2SC1845-F ( 1) 2211732

PCB

Q5051 or TR 2SC1845-E ( 1) 2211733

PCB

Q5051 or TR KTC3200-GR ( 1) 2215895

PCB

Q5051 TR KTC3199-GR 1 2215864 <402>, <8240>

PCB

Q5051 or TR 2SC2458-GR ( 1) 2212115

PCB

Q5051 or TR 2SC1740S-R ( 1) 2213284

PCB

Q5051 or TR 2SC1740S-S ( 1) 2213285

PCB

Q5052 TR KTC3200-BL 1 2215896 <420>

PCB

Q5052 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5052 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5052 or TR 2SC1845-F ( 1) 2211732

PCB

Q5052 or TR 2SC1845-E ( 1) 2211733

PCB

Q5052 or TR KTC3200-GR ( 1) 2215895

PCB

Q5052 TR KTC3199-GR 1 2215864 <402>, <8240>

PCB

Q5052 or TR 2SC2458-GR ( 1) 2212115

PCB

Q5052 or TR 2SC1740S-R ( 1) 2213284

PCB

Q5052 or TR 2SC1740S-S ( 1) 2213285

PCB

Q5053 TR KTC3200-BL 1 2215896 <420>

PCB

Q5053 or TR 2SC1775A-E ( 1) 2210755

PCB

Q5053 or TR 2SC1775A-F ( 1) 2210756

PCB

Q5053 or TR 2SC1845-F ( 1) 2211732

PCB

Q5053 or TR 2SC1845-E ( 1) 2211733

PCB

Q5053 or TR KTC3200-GR ( 1) 2215895

PCB

Q5053 TR KTC3199-GR 1 2215864 <402>, <8240>

PCB

Q5053 or TR 2SC2458-GR ( 1) 2212115

PCB

Q5053 or TR 2SC1740S-R ( 1) 2213284

PCB

Q5053 or TR 2SC1740S-S ( 1) 2213285

PCB

Q5054 TR KTC3200-BL 1 2215896 <420>

PCB

Q5054 or TR KTC3200-GR ( 1) 2215900

23/37 PAGE

PCB

Q5054 or TR 2SC1775A-E ( 1) 2215901

PCB

Q5054 or TR 2SC1775A-F ( 1) 2215902

PCB

Q5054 or TR 2SC1845-E ( 1) 2215903

PCB

Q5054 or TR 2SC1845-F ( 1) 2215904

PCB

Q5054 TR KTC3199-GR 1 2215864 <402>, <8240>

PCB

Q5054 or TR 2SC1740S-R ( 1) 2215897

PCB

Q5054 or TR 2SC1740S-S ( 1) 2215898

PCB

Q5054 or TR 2SC2458-GR ( 1) 2215899

PCB

Q6931 IC(REGURATOR) 78057HF(TA78057S) 1 222780574TOS

PCB

D5000 ZENER D MTZJ5.6B 1 224470562

PCB

D5001 ZENER D MTZJ5.6B 1 224470562

PCB

D5002 ZENER D MTZJ5.6B 1 224470562

PCB

D5003 ZENER D MTZJ5.6B 1 224470562

PCB

D5004 ZENER D MTZJ5.6B 1 224470562

PCB

D6600 DIODE 1SS133 1 223163

PCB

D6600 or DIODE 1SS270A ( 1) 223205

PCB

D6600 or DIODE WG713A ( 1) 223222

PCB

D6601 DIODE 1SS133 1 223163

PCB

D6601 or DIODE 1SS270A ( 1) 223205

PCB

D6601 or DIODE WG713A ( 1) 223222

PCB

D6604 DIODE 1SS133 1 223163

PCB

D6604 or DIODE 1SS270A ( 1) 223205

PCB

D6604 or DIODE WG713A ( 1) 223222

PCB

D6932 DIODE RL1N4003 1 22380260

PCB

D6932 or DIODE GP104003E ( 1) 22380035

PCB

D6933 DIODE RL1N4003 1 22380260

PCB

D6933 or DIODE GP104003E ( 1) 22380035

PCB

L281 CHOKE COIL NCH-1452 220K 1 233454K220

PCB

L281 or CHOKE COIL NCH-1561 220K ( 1) 233526K220

PCB

L282 CHOKE COIL NCH-1452 220K 1 233454K220

PCB

L282 or CHOKE COIL NCH-1561 220K ( 1) 233526K220

PCB

L283 CHOKE COIL NCH-1452 022M 1 233454M022

PCB

L283 or CHOKE COIL NCH-1561 022K ( 1) 233526K022

PCB

L6800 S COIL S-1.3C 1 231176

PCB

L6801 S COIL S-1.3C 1 231176

PCB

L6802 S COIL S-1.3C 1 231176

PCB

L6803 S COIL S-1.3C 1 231176

PCB

L6804 S COIL S-1.3C 1 231176

PCB

C201 VR C CE04W50V-2.2M(VR) 1 394680227

PCB

C201 or ELECT C CE04W50V2.2M(SC) ( 1) 394780227

PCB

C202 VR C CE04W50V-2.2M(VR) 1 394680227

PCB

C202 or ELECT C CE04W50V2.2M(SC) ( 1) 394780227

PCB

C203 VR C CE04W16V-470M(VR) 1 394644717

PCB

C203 or ELECT C CE04W16V470M(SC) ( 1) 394744717

PCB

C204 VR C CE04W50V-2.2M(VR) 1 394680227

PCB

C204 or ELECT C CE04W50V2.2M(SC) ( 1) 394780227

PCB

C205 VR C CE04W16V-470M(VR) 1 394644717

PCB

C205 or ELECT C CE04W16V470M(SC) ( 1) 394744717

PCB

C206 CERA C CK45F50V-223Z 1 335622230

PCB

C207 VR C CE04W50V-2.2M(VR) 1 394680227

PCB

C207 or ELECT C CE04W50V2.2M(SC) ( 1) 394780227

PCB

C208 CERA C CK45F50V-223Z 1 335622230

PCB

C209 VR C CE04W50V-2.2M(VR) 1 394680227

PCB

C209 or ELECT C CE04W50V2.2M(SC) ( 1) 394780227

PCB

C210 CERA C CK45F50V-223Z 1 335622230

PCB

C211 VR C CE04W16V-470M(VR) 1 394644717

PCB

C211 or ELECT C CE04W16V470M(SC) ( 1) 394744717

24/37 PAGE

PCB

C212 CERA C CK45F50V-223Z 1 335622230

PCB

C213 VR C CE04W50V-2.2M(VR) 1 394680227

PCB

C213 or ELECT C CE04W50V2.2M(SC) ( 1) 394780227

PCB

C214 CERA C CK45F50V-223Z 1 335622230

PCB

C215 VR C CE04W16V-470M(VR) 1 394644717

PCB

C215 or ELECT C CE04W16V470M(SC) ( 1) 394744717

PCB

C217 VR C CE04W50V-2.2M(VR) 1 394680227

PCB

C217 or ELECT C CE04W50V2.2M(SC) ( 1) 394780227

PCB

C220 CERA C CK45F50V-223Z 1 335622230

PCB

C221 VR C CE04W16V-47M(VR) 1 394644707

PCB

C221 or ELECT C CE04W16V47M(SC) ( 1) 394744707

PCB

C222 CERA C CK45F50V-223Z 1 335622230

PCB

C223 VR C CE04W16V-47M(VR) 1 394644707

PCB

C223 or ELECT C CE04W16V47M(SC) ( 1) 394744707

PCB

C224 CERA C CK45F50V-223Z 1 335622230

PCB

C225 VR C CE04W16V-47M(VR) 1 394644707

PCB

C225 or ELECT C CE04W16V47M(SC) ( 1) 394744707

PCB

C226 CERA C CK45F50V-223Z 1 335622230

PCB

C227 CERA C CK45F50V-223Z 1 335622230

PCB

C231 CERA C CK45F50V-223Z 1 335622230

PCB

C232 CERA C CK45F50V-223Z 1 335622230

PCB

C281 CERA C CK45F50V-223Z 1 335622230

PCB

C282 CERA C CC45SL50V-101J 1 345021014

PCB

C283 CERA C CK45F50V-223Z 1 335622230

PCB

C284 CERA C CC45SL50V-080D 1 345020802

PCB

C285 VR C CE04W6.3V-47M(VR) 1 394624707

PCB

C286 CERA C CK45F50V-223Z 1 335622230

PCB

C287 CERA C CK45F50V-223Z 1 335622230

PCB

C288 VR C CE04W6.3V-47M(VR) 1 394624707

PCB

C5000 TF C ECQ-B50V-101K 1 374721015

PCB

C5001 TF C ECQ-B50V-101K 1 374721015

PCB

C5002 TF C ECQ-B50V-101K 1 374721015

PCB

C5003 TF C ECQ-B50V-101K 1 374721015

PCB

C5004 TF C ECQ-B50V-101K 1 374721015

PCB

C5010 VX C CE04W16V-22M(VX) 1 393342207

PCB

C5011 VX C CE04W16V-22M(VX) 1 393342207

PCB

C5012 VX C CE04W16V-22M(VX) 1 393342207

PCB

C5013 VX C CE04W16V-22M(VX) 1 393342207

PCB

C5014 VX C CE04W16V-22M(VX) 1 393342207

PCB

C5020 VR C CE04W50V-10M(VR) 1 394681007

PCB

C5021 VR C CE04W50V-10M(VR) 1 394681007

PCB

C5022 VR C CE04W50V-10M(VR) 1 394681007

PCB

C5023 VR C CE04W50V-10M(VR) 1 394681007

PCB

C5024 VR C CE04W50V-10M(VR) 1 394681007

PCB

C5040 VX C CE04W16V-220M(VX) 1 393342217

PCB

C5041 VX C CE04W16V-220M(VX) 1 393342217

PCB

C5042 VX C CE04W16V-100M(VX) 1 393341017

PCB

C5043 VX C CE04W16V-100M(VX) 1 393341017

PCB

C5044 VX C CE04W16V-100M(VX) 1 393341017

PCB

C5050 VR C CE04W50V-47M(VR) 1 394684707

PCB

C5051 VR C CE04W50V-47M(VR) 1 394684707

PCB

C5052 VR C CE04W50V-47M(VR) 1 394684707

PCB

C5053 VR C CE04W50V-47M(VR) 1 394684707

PCB

C5054 VR C CE04W50V-47M(VR) 1 394684707

PCB

C5080 CERA C CC45SL50V-040D 1 345020402

PCB

C5080 or CERA C CC45SL50V-040C ( 1) 345020401

PCB

C5081 CERA C CC45SL50V-040D 1 345020402

25/37 PAGE

PCB

C5081 or CERA C CC45SL50V-040C ( 1) 345020401

PCB

C5082 CERA C CC45SL50V-040D 1 345020402

PCB

C5082 or CERA C CC45SL50V-040C ( 1) 345020401

PCB

C5083 CERA C CC45SL50V-040D 1 345020402

PCB

C5083 or CERA C CC45SL50V-040C ( 1) 345020401

PCB

C5084 CERA C CC45SL50V-040D 1 345020402

PCB

C5084 or CERA C CC45SL50V-040C ( 1) 345020401

PCB

C5090 CERA C CC45SL50V-101J 1 345021014

PCB

C5091 CERA C CC45SL50V-101J 1 345021014

PCB

C5092 CERA C CC45SL50V-101J 1 345021014

PCB

C5093 CERA C CC45SL50V-101J 1 345021014

PCB

C5094 CERA C CC45SL50V-101J 1 345021014

PCB

C5100 VR C CE04W63V-10M(VR) 1 394671007 <402>, <8240>

PCB

C5100 VR C CE04W100V-10M(VR) 1 394691007 <420>

PCB

C5101 VR C CE04W63V-10M(VR) 1 394671007 <402>, <8240>

PCB

C5101 VR C CE04W100V-10M(VR) 1 394691007 <420>

PCB

C5102 VR C CE04W63V-10M(VR) 1 394671007 <402>, <8240>

PCB

C5102 VR C CE04W100V-10M(VR) 1 394691007 <420>

PCB

C5103 VR C CE04W63V-10M(VR) 1 394671007 <402>, <8240>

PCB

C5103 VR C CE04W100V-10M(VR) 1 394691007 <420>

PCB

C5104 VR C CE04W63V-10M(VR) 1 394671007 <402>, <8240>

PCB

C5104 VR C CE04W100V-10M(VR) 1 394691007 <420>

PCB

C5110 VR C CE04W63V-10M(VR) 1 394671007 <402>, <8240>

PCB

C5110 VR C CE04W100V-10M(VR) 1 394691007 <420>

PCB

C5111 VR C CE04W63V-10M(VR) 1 394671007 <402>, <8240>

PCB

C5111 VR C CE04W100V-10M(VR) 1 394691007 <420>

PCB

C5112 VR C CE04W63V-10M(VR) 1 394671007 <402>, <8240>

PCB

C5112 VR C CE04W100V-10M(VR) 1 394691007 <420>

PCB

C5113 VR C CE04W63V-10M(VR) 1 394671007 <402>, <8240>

PCB

C5113 VR C CE04W100V-10M(VR) 1 394691007 <420>

PCB

C5114 VR C CE04W63V-10M(VR) 1 394671007 <402>, <8240>

PCB

C5114 VR C CE04W100V-10M(VR) 1 394691007 <420>

PCB

C6600 TF C ECQ-B50V-103J 1 374721034

PCB

C6601 CERA C CK45F50V-103Z 1 335621030

PCB

C6604 TF C ECQ-B50V-103J 1 374721034

PCB

C6840 TF C ECQ-B50V-102J 1 2215959 <420>

PCB

C6841 TF C ECQ-B50V-102J 1 2215961 <420>

PCB

C6842 TF C ECQ-B50V-102J 1 2215963 <420>

PCB

C6843 TF C ECQ-B50V-102J 1 2215965 <420>

PCB

C6844 TF C ECQ-B50V-102J 1 2215967 <420>

PCB

C6850 CERA C CK45B50V-102K 1 2215969 <420>

PCB

C6851 CERA C CK45B50V-102K 1 2215971 <420>

PCB

C6852 CERA C CK45B50V-102K 1 2215973 <420>

PCB

C6853 CERA C CK45B50V-102K 1 2215975 <420>

PCB

C6854 CERA C CK45B50V-102K 1 2215977 <420>

PCB

C6931 VR C CE04W25V-1000M(VR) 1 394651027S

PCB

C6932 CERA C CK45F50V-103Z 1 335621030

PCB

C6933 VR C CE04W16V-10M(VR) 1 394641007

PCB

C9513 CERA C CK45F50V-223Z 1 335622230

PCB

R201 CARBON R R16J-75 1 417347504

PCB

R202 CARBON R R16J-75 1 417347504

PCB

R203 CARBON R R16J-75 1 417347504

PCB

R204 CARBON R R16J-100K 1 417341044

PCB

R205 CARBON R R16J-75 1 417347504

PCB

R206 CARBON R R16J-75 1 417347504

PCB

R207 CARBON R R16J-680K 1 417346844

PCB

R208 CARBON R R16J-680K 1 417346844

26/37 PAGE

PCB

R209 CARBON R R16J-680K 1 417346844

PCB

R210 CARBON R R16J-220 1 417342214

PCB

R211 CARBON R R16J-75 1 417347504

PCB

R212 CARBON R R16J-75 1 417347504

PCB

R213 CARBON R R16J-75 1 417347504

PCB

R214 CARBON R R16J-75 1 417347504

PCB

R215 CARBON R R16J-75 1 417347504

PCB

R216 CARBON R R16J-75 1 417347504

PCB

R217 CARBON R R16J-100K 1 417341044

PCB

R218 CARBON R R16J-100K 1 417341044

PCB

R219 CARBON R R16J-75 1 417347504

PCB

R220 CARBON R R16J-75 1 417347504

PCB

R221 CARBON R R16J-75 1 417347504

PCB

R222 CARBON R R16J-75 1 417347504

PCB

R223 CARBON R R16J-100K 1 417341044

PCB

R224 CARBON R R16J-100K 1 417341044

PCB

R225 CARBON R R16J-680K 1 417346844

PCB

R226 CARBON R R16J-680K 1 417346844

PCB

R227 CARBON R R16J-680K 1 417346844

PCB

R228 CARBON R R16J-220 1 417342214

PCB

R230 CARBON R R16J-680K 1 417346844

PCB

R231 CARBON R R16J-75 1 417347504

PCB

R281 CARBON R R16J-75 1 417347504

PCB

R282 CARBON R R16J-470 1 417344714

PCB

R284 CARBON R R16J-10K 1 417341034

PCB

R5000 CARBON R R16J-1K 1 417341024

PCB

R5001 CARBON R R16J-1K 1 417341024

PCB

R5002 CARBON R R16J-1K 1 417341024

PCB

R5003 CARBON R R16J-1K 1 417341024

PCB

R5004 CARBON R R16J-1K 1 417341024

PCB

R5010 CARBON R R16J-56K 1 417345634

PCB

R5011 CARBON R R16J-56K 1 417345634

PCB

R5012 CARBON R R16J-56K 1 417345634

PCB

R5013 CARBON R R16J-56K 1 417345634

PCB

R5014 CARBON R R16J-56K 1 417345634

PCB

R5020 CARBON R R16J-330 1 417343314

PCB

R5021 CARBON R R16J-330 1 417343314

PCB

R5022 CARBON R R16J-330 1 417343314

PCB

R5023 CARBON R R16J-330 1 417343314

PCB

R5024 CARBON R R16J-330 1 417343314

PCB

R5030 CARBON R R16J-56K 1 417345634

PCB

R5031 CARBON R R16J-56K 1 417345634

PCB

R5032 CARBON R R16J-56K 1 417345634

PCB

R5033 CARBON R R16J-56K 1 417345634

PCB

R5034 CARBON R R16J-56K 1 417345634

PCB

R5040 CARBON R R16J-2.2K 1 417342224

PCB

R5041 CARBON R R16J-2.2K 1 417342224

PCB

R5042 CARBON R R16J-2.2K 1 417342224

PCB

R5043 CARBON R R16J-2.2K 1 417342224

PCB

R5044 CARBON R R16J-2.2K 1 417342224

PCB

R5050 CARBON R R16J-4.7K 1 417344724

PCB

R5051 CARBON R R16J-4.7K 1 417344724

PCB

R5052 CARBON R R16J-4.7K 1 417344724

PCB

R5053 CARBON R R16J-4.7K 1 417344724

PCB

R5054 CARBON R R16J-4.7K 1 417344724

PCB

R5060 CARBON R R16J-1.2K 1 417341224

PCB

R5061 CARBON R R16J-1.2K 1 417341224

27/37 PAGE

PCB

R5062 CARBON R R16J-1.2K 1 417341224

PCB

R5063 CARBON R R16J-1.2K 1 417341224

PCB

R5064 CARBON R R16J-1.2K 1 417341224

PCB

R5070 CARBON R R16J-560 1 417345614

PCB

R5071 CARBON R R16J-560 1 417345614

PCB

R5072 CARBON R R16J-560 1 417345614

PCB

R5073 CARBON R R16J-560 1 417345614

PCB

R5074 CARBON R R16J-560 1 417345614

PCB

R5080 CARBON R R16J-3.3K 1 417343324

PCB

R5081 CARBON R R16J-3.3K 1 417343324

PCB

R5082 CARBON R R16J-3.3K 1 417343324

PCB

R5083 CARBON R R16J-3.3K 1 417343324

PCB

R5084 CARBON R R16J-3.3K 1 417343324

PCB

R5090 CARBON R R16J-82K 1 417348234 <402>, <8240>

PCB

R5090 CARBON R R16J-100K 1 417341044 <420>

PCB

R5091 CARBON R R16J-82K 1 417348234 <402>, <8240>

PCB

R5091 CARBON R R16J-100K 1 417341044 <420>

PCB

R5092 CARBON R R16J-82K 1 417348234 <402>, <8240>

PCB

R5092 CARBON R R16J-100K 1 417341044 <420>

PCB

R5093 CARBON R R16J-82K 1 417348234 <402>, <8240>

PCB

R5093 CARBON R R16J-100K 1 417341044 <420>

PCB

R5094 CARBON R R16J-82K 1 417348234 <402>, <8240>

PCB

R5094 CARBON R R16J-100K 1 417341044 <420>

PCB

R5100 CARBON R R16J-100K 1 417341044

PCB

R5101 CARBON R R16J-100K 1 417341044

PCB

R5102 CARBON R R16J-100K 1 417341044

PCB

R5103 CARBON R R16J-100K 1 417341044

PCB

R5104 CARBON R R16J-100K 1 417341044

PCB

R5110 CARBON R R16J-1K 1 417341024

PCB

R5111 CARBON R R16J-1K 1 417341024

PCB

R5112 CARBON R R16J-1K 1 417341024

PCB

R5113 CARBON R R16J-1K 1 417341024

PCB

R5114 CARBON R R16J-1K 1 417341024

PCB

R5130 CARBON R R16J-18K 1 417341834

PCB

R5131 CARBON R R16J-18K 1 417341834

PCB

R5132 CARBON R R16J-18K 1 417341834

PCB

R5133 CARBON R R16J-18K 1 417341834

PCB

R5134 CARBON R R16J-18K 1 417341834

PCB

R5160 NF CARBON R R25J-120 1 415471214

PCB

R5161 NF CARBON R R25J-120 1 415471214

PCB

R5162 NF CARBON R R25J-120 1 415471214

PCB

R5163 NF CARBON R R25J-120 1 415471214

PCB

R5164 NF CARBON R R25J-120 1 415471214

PCB

R5170 NF CARBON R R25J-120 1 415471214

PCB

R5171 NF CARBON R R25J-120 1 415471214

PCB

R5172 NF CARBON R R25J-120 1 415471214

PCB

R5173 NF CARBON R R25J-120 1 415471214

PCB

R5174 NF CARBON R R25J-120 1 415471214

PCB

R5180 NF CARBON R R25J-10 1 415471004

PCB

R5181 NF CARBON R R25J-10 1 415471004

PCB

R5182 NF CARBON R R25J-10 1 415471004

PCB

R5183 NF CARBON R R25J-10 1 415471004

PCB

R5184 NF CARBON R R25J-10 1 415471004

PCB

R5190 NF CARBON R R25J-10 1 415471004

PCB

R5191 NF CARBON R R25J-10 1 415471004

PCB

R5192 NF CARBON R R25J-10 1 415471004

PCB

R5193 NF CARBON R R25J-10 1 415471004

28/37 PAGE

PCB

R5194 NF CARBON R R25J-10 1 415471004

PCB

R6800 CARBON R R16J-22 1 417342204

PCB

R6801 CARBON R R16J-22 1 417342204

PCB

R6802 CARBON R R16J-22 1 417342204

PCB

R6803 CARBON R R16J-22 1 417342204

PCB

R6804 CARBON R R16J-22 1 417342204

PCB

R6810 CARBON R R16J-22 1 417342204

PCB

R6811 CARBON R R16J-22 1 417342204

PCB

R6812 CARBON R R16J-22 1 417342204

PCB

R6812 CARBON R R16J-22 1 417342204

PCB

R6813 CARBON R R16J-22 1 417342204

PCB

R6814 CARBON R R16J-22 1 417342204

PCB

R6935 METAL O R RS2WBJ-120 1 441721214F

PCB

R9501 METAL R RNU1/2WCJ-1 1 453530104

PCB

R9502 METAL R RNU1/2WCJ-0.47 1 453534794

PCB

R9503 METAL R RNU1/2WCJ-0.22 1 453532294

PCB

R9521 METAL R RNU1/2WCJ-2.7 1 453530274 <402>, <8240>

PCB

R9521 METAL R RNU1/2WCJ-3.9 1 453530394 <420>

PCB

RL6600 RELAY NRL-2P5A-DC24-129 1 25065563

PCB

RL6600 or RELAY NRL-2P5A-DC24-142 ( 1) 25065586

PCB

RL6600 or RELAY NRL-2P5A-DC24-098 ( 1) 25065517

PCB

RL6601 RELAY NRL-2P5A-DC24-129 1 25065563

PCB

RL6601 or RELAY NRL-2P5A-DC24-142 ( 1) 25065586

PCB

RL6601 or RELAY NRL-2P5A-DC24-098 ( 1) 25065517

PCB

RL6603 RELAY NRL-2P5A-DC24-129 1 25065563

PCB

RL6603 or RELAY NRL-2P5A-DC24-142 ( 1) 25065586

PCB

RL6603 or RELAY NRL-2P5A-DC24-098 ( 1) 25065517

PCB

RL6604 RELAY NRL-2P5A-DC24-129 1 25065563

PCB

RL6604 or RELAY NRL-2P5A-DC24-142 ( 1) 25065586

PCB

RL6604 or RELAY NRL-2P5A-DC24-098 ( 1) 25065517

PCB

P201 JACK NPJ-3PDYE158 1 25045299

PCB

P202 JACK NPJ-3PDYE158 1 25045299

PCB

P203 SOCKET NSCT-8P1535 1 25051748

PCB

P204 SOCKET NSCT-12P1355 1 25051568

PCB

P206B SOCKET NSCT-14P1029 1 25051239

PCB

P210A PLUG NPLG-6P658 1 25055702

PCB

P210B SOCKET NSCT-6P1021 1 25051231

PCB

P211A PLUG NPLG-6P658 1 25055702

PCB

P211B SOCKET NSCT-6P1021 1 25051231

PCB

P281 PIN JACK NPJ-1PDBL291 1 25045473

PCB

P282 ST JACK LGY2502-0200C 1 25045696

PCB

P306A PLUG NPLG-10P357 1 25055374

PCB

P410A SOCKET NSCT-10P1025 1 25051235

PCB

P411A SOCKET NSCT-10P1025 1 25051235

PCB

P5001 BUS BAR BBL40 1 27141773

PCB

P6000A SOCKET NSCT-5P2185 1 25052288

PCB

P6001A SOCKET NSCT-5P2185 1 25052288

PCB

P6002A SOCKET NSCT-5P2185 1 25052288

PCB

P6003A SOCKET NSCT-5P2185 1 25052288

PCB

P6004A SOCKET NSCT-5P2185 1 25052288

PCB

P6011A SOCKET NSCT-9P2189 1 25052292

PCB

P6073 TRM NTM-1P233(M1969) 1 25060302

PCB

P6800 TRM NTM-8PDML254 1 25060323

PCB

P6801 TRM NTM-6PDML266 1 25060335

PCB

P6931A SOCKET NSCT-15P1030 1 25051240

PCB

P7503B SOCKET NSCT-8P2138 1 25052241

PCB

P7503Bor SOCKET NSCT-8P1101 ( 1) 25051312

29/37 PAGE

PCB

P7503Bor SOCKET NSCT-8P1841 ( 1) 25052054

PCB

P7503Bor SOCKET NSCT-8P1639 ( 1) 25051852

PCB

JL6803B SOCKET NSCT-5P97 1 25050269

PCB

JL6804B SOCKET NSCT-5P97 1 25050269

PCB

JL6805B SOCKET NSCT-4P96 1 25050268

PCB

JL9501A WIRE HOL NSCT-7P898 1 25051111

PCB

JL9501B WIRE HOL NSCT-7P898 1 25051111

PCB PCB

U17 POWER AMPLIFIER PC BOARD(NAAF-7875-2A/2B/2C/2D/2E)

PCB

U18 TERMINAL PC BOARD(NAPS-78762A/2B/2C/2D/2E)

PCB

U19 POWER SUPPLY PC BOARD(NAPS-7877-2A/2B/2C/2D/2E)

PCB

U20 TERMINAL PC BOARD(NAPS-7878-2A/2B/2C/2D/2E)

PCB

U21 HOLDER PC BOARD (NA79-7879-2A/2B/2C/2D/2E)

PCB

U22 THERMAL SENSOR PC BOARD(NAETC-7880-2A/2B/2C/2D/2E)

PCB

U23 HOLDER PC BOARD(NAETC-7881-2A/2B/2C/2D/2E)

PCB

U24 POWER SWITCH PC BOARD(NASW-7882-2A/2B/2C/2D/2E)

PCB

U25 TERMINAL PC BOARD(NAETC-7884-2A/2B/2C/2D/2E)

PCB

U26 THERMAL SENSOR PC BOARD(NAETC-8256-2A/2B/2C/2D/2E)

PCB

<Notes> Parts are indicated collectively, without dividing for above-mentioned each substrate.

PCB

REF NO. NAME DESCRIPTION QTY PART NO. REMARKS

PCB

Q921 TR KTC3199-GR 1 2215864

PCB

Q921 or TR 2SC1740S-R ( 1) 2213284

PCB

Q921 or TR 2SC1740S-S ( 1) 2213285

PCB

Q921 or TR 2SC2458-GR ( 1) 2212115

PCB

Q6010 TR 2SC1740S-R 1 2213284

PCB

Q6010 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6011 TR 2SC1740S-R 1 2213284

PCB

Q6011 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6012 TR 2SC1740S-R 1 2213284

PCB

Q6012 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6013 TR 2SC1740S-R 1 2213284

PCB

Q6013 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6014 TR 2SC1740S-R 1 2213284

PCB

Q6014 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6020 TR 2SC1740S-R 1 2213284

PCB

Q6020 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6021 TR 2SC1740S-R 1 2213284

PCB

Q6021 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6022 TR 2SC1740S-R 1 2213284

PCB

Q6022 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6023 TR 2SC1740S-R 1 2213284

PCB

Q6023 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6024 TR 2SC1740S-R 1 2213284

PCB

Q6024 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6030 TR KTD2061-Y 1 2203434

PCB

Q6030 or TR 2SC5171 ( 1) 2203010

PCB

Q6031 TR KTD2061-Y 1 2203434

PCB

Q6031 or TR 2SC5171 ( 1) 2203010

PCB

Q6032 TR 2SC5511-E 1 2203845 <402>, <8240>

PCB

Q6032 or TR KTD2061-Y ( 1) 2203434

PCB

Q6032 or TR 2SC5171 ( 1) 2203010

PCB

Q6032 TR KTD2061-Y 1 2203434 <420>

PCB

Q6032 or TR 2SC5171 ( 1) 2203010

PCB

Q6033 TR 2SC5511-E 1 2203845 <402>, <8240>

PCB

Q6033 or TR KTD2061-Y ( 1) 2203434

PCB

Q6033 or TR 2SC5171 ( 1) 2203010

30/37 PAGE

PCB

Q6033 or TR KTD2061-Y 1 2203434 <420>

PCB

Q6033 or TR 2SC5171 ( 1) 2203010

PCB

Q6034 TR 2SC5511-E 1 2203845 <402>, <8240>

PCB

Q6034 or TR KTD2061-Y ( 1) 2203434

PCB

Q6034 or TR 2SC5171 ( 1) 2203010

PCB

Q6034 or TR KTD2061-Y 1 2203434 <420>

PCB

Q6034 or TR 2SC5171 ( 1) 2203010

PCB

Q6040 TR KTB1369-Y 1 2203424

PCB

Q6040 or TR 2SA1930 ( 1) 2203000

PCB

Q6041 TR KTB1369-Y 1 2203424

PCB

Q6041 or TR 2SA1930 ( 1) 2203000

PCB

Q6042 TR KTB1369-Y 1 2203424 <420>

PCB

Q6042 or TR 2SA1930 ( 1) 2203000

PCB

Q6042 TR 2SA2005-E 1 2203835 <402>, <8240>

PCB

Q6042 or TR KTB1369-Y ( 1) 2203424

PCB

Q6042 or TR 2SA1930 ( 1) 2203000

PCB

Q6043 TR KTB1369-Y 1 2203424 <420>

PCB

Q6043 or TR 2SA1930 ( 1) 2203000

PCB

Q6043 TR 2SA2005-E 1 2203835 <402>, <8240>

PCB

Q6043 or TR KTB1369-Y ( 1) 2203424

PCB

Q6043 or TR 2SA1930 ( 1) 2203000

PCB

Q6044 TR KTB1369-Y 1 2203424 <420>

PCB

Q6044 or TR 2SA1930 ( 1) 2203000 <420>

PCB

Q6044 TR 2SA2005-E 1 2203835 <402>, <8240>

PCB

Q6044 or TR KTB1369-Y ( 1) 2203424

PCB

Q6044 or TR 2SA1930 ( 1) 2203000

PCB

Q6070 TR 2SC2631-R 1 2214984 <420>

PCB

Q6070 or TR 2SC2631-S ( 1) 2214985

PCB

Q6070 TR KTC3200-BL 1 2215896 <402>, <8240>

PCB

Q6070 or TR KTC3200-GR ( 1) 2215895

PCB

Q6070 or TR 2SC1775A-E ( 1) 2210755

PCB

Q6070 or TR 2SC1775A-F ( 1) 2210756

PCB

Q6070 or TR 2SC1845-E ( 1) 2211733

PCB

Q6070 or TR 2SC1845-F ( 1) 2211732

PCB

Q6071 TR 2SC2631-R 1 2214984 <420>

PCB

Q6071 or TR 2SC2631-S ( 1) 2214985

PCB

Q6071 TR KTC3200-BL 1 2215896 <402>, <8240>

PCB

Q6071 or TR KTC3200-GR ( 1) 2215895

PCB

Q6071 or TR 2SC1775A-E ( 1) 2210755

PCB

Q6071 or TR 2SC1775A-F ( 1) 2210756

PCB

Q6071 or TR 2SC1845-E ( 1) 2211733

PCB

Q6071 or TR 2SC1845-F ( 1) 2211732

PCB

Q6072 TR 2SC2631-R 1 2214984 <420>

PCB

Q6072 or TR 2SC2631-S ( 1) 2214985

PCB

Q6072 TR KTC3200-BL 1 2215896 <402>, <8240>

PCB

Q6072 or TR KTC3200-GR ( 1) 2215895

PCB

Q6072 or TR 2SC1775A-E ( 1) 2210755

PCB

Q6072 or TR 2SC1775A-F ( 1) 2210756

PCB

Q6072 or TR 2SC1845-E ( 1) 2211733

PCB

Q6072 or TR 2SC1845-F ( 1) 2211732

PCB

Q6073 TR 2SC2631-R 1 2214984 <420>

PCB

Q6073 or TR 2SC2631-S ( 1) 2214985

PCB

Q6073 TR KTC3200-BL 1 2215896 <402>, <8240>

PCB

Q6073 or TR KTC3200-GR ( 1) 2215895

PCB

Q6073 or TR 2SC1775A-E ( 1) 2210755

PCB

Q6073 or TR 2SC1775A-F ( 1) 2210756

PCB

Q6073 or TR 2SC1845-E ( 1) 2211733

31/37 PAGE

PCB

Q6073 or TR 2SC1845-F ( 1) 2211732

PCB

Q6074 TR 2SC2631-R 1 2214984 <420>

PCB

Q6074 or TR 2SC2631-S ( 1) 2214985

PCB

Q6074 TR KTC3200-BL 1 2215896 <402>, <8240>

PCB

Q6074 or TR KTC3200-GR ( 1) 2215895

PCB

Q6074 or TR 2SC1775A-E ( 1) 2210755

PCB

Q6074 or TR 2SC1775A-F ( 1) 2210756

PCB

Q6074 or TR 2SC1845-E ( 1) 2211733

PCB

Q6074 or TR 2SC1845-F ( 1) 2211732

PCB

Q6303 TR KTA1267-GR 1 2215995

PCB

Q6303 or TR 2SA933S-R ( 1) 2213354

PCB

Q6303 or TR 2SA933S-S ( 1) 2213355

PCB

Q6601 TR KTC3199-GR 1 2215864

PCB

Q6601 or TR 2SC1740S-R ( 1) 2213284

PCB

Q6601 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6601 or TR 2SC2458-GR ( 1) 2212115

PCB

Q6602 TR KTC3199-GR 1 2215864

PCB

Q6602 or TR 2SC1740S-R ( 1) 2213284

PCB

Q6602 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6602 or TR 2SC2458-GR ( 1) 2212115

PCB

Q6603 TR KTC3199-GR 1 2215864

PCB

Q6603 or TR 2SC1740S-R ( 1) 2213284

PCB

Q6603 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6603 or TR 2SC2458-GR ( 1) 2212115

PCB

Q6701 TR KTC3200-BL 1 2215896

PCB

Q6701 or TR KTC3200-GR ( 1) 2215895

PCB

Q6701 or TR 2SC1775A-E ( 1) 2210755

PCB

Q6701 or TR 2SC1775A-F ( 1) 2210756

PCB

Q6701 or TR 2SC1845-E ( 1) 2211733

PCB

Q6701 or TR 2SC1845-F ( 1) 2211732

PCB

Q6702 TR KTC3200-BL 1 2215896

PCB

Q6702 or TR KTC3200-GR ( 1) 2215895

PCB

Q6702 or TR 2SC1775A-E ( 1) 2210755

PCB

Q6702 or TR 2SC1775A-F ( 1) 2210756

PCB

Q6702 or TR 2SC1845-E ( 1) 2211733

PCB

Q6702 or TR 2SC1845-F ( 1) 2211732

PCB

Q6703 TR KTA1268-GR 1 2215885

PCB

Q6703 or TR KTA1268-BL ( 1) 2215886

PCB

Q6703 or TR 2SA992-E ( 1) 2211793

PCB

Q6703 or TR 2SA992-F ( 1) 2211792

PCB

Q6901 TR KTC3199-GR 1 2215864

PCB

Q6901 or TR 2SC1740S-R ( 1) 2213284

PCB

Q6901 or TR 2SC1740S-S ( 1) 2213285

PCB

Q6901 or TR 2SC2458-GR ( 1) 2212115

PCB

D921 DIODE RL1N4003 1 22380260

PCB

D921 or DIODE GP104003E ( 1) 22380035

PCB

D922 DIODE RL1N4003 1 22380260

PCB

D922 or DIODE GP104003E ( 1) 22380035

PCB

D923 DIODE RL1N4003 1 22380260

PCB

D923 or DIODE GP104003E ( 1) 22380035

PCB

D924 DIODE RL1N4003 1 22380260

PCB

D924 or DIODE GP104003E ( 1) 22380035

PCB

D925 DIODE 1SS133 1 223163

PCB

D925 or DIODE 1SS270A ( 1) 223205

PCB

D925 or DIODE WG713A ( 1) 223222

PCB

D6000 DIODE 1SS133 1 223163

PCB

D6000 or DIODE 1SS270A ( 1) 223205

32/37 PAGE

PCB

D6000 or DIODE WG713A ( 1) 223222

PCB

D6001 DIODE 1SS133 1 223163

PCB

D6001 or DIODE 1SS270A ( 1) 223205

PCB

D6001 or DIODE WG713A ( 1) 223222

PCB

D6002 DIODE 1SS133 1 223163

PCB

D6002 or DIODE 1SS270A ( 1) 223205

PCB

D6002 or DIODE WG713A ( 1) 223222

PCB

D6003 DIODE 1SS133 1 223163

PCB

D6003 or DIODE 1SS270A ( 1) 223205

PCB

D6003 or DIODE WG713A ( 1) 223222

PCB

D6004 DIODE 1SS133 1 223163

PCB

D6004 or DIODE 1SS270A ( 1) 223205

PCB

D6004 or DIODE WG713A ( 1) 223222

PCB

D6010 DIODE 1SS133 1 223163

PCB

D6010 or DIODE 1SS270A ( 1) 223205

PCB

D6010 or DIODE WG713A ( 1) 223222

PCB

D6011 DIODE 1SS133 1 223163

PCB

D6011 or DIODE 1SS270A ( 1) 223205

PCB

D6011 or DIODE WG713A ( 1) 223222

PCB

D6012 DIODE 1SS133 1 223163

PCB

D6012 or DIODE 1SS270A ( 1) 223205

PCB

D6012 or DIODE WG713A ( 1) 223222

PCB

D6013 DIODE 1SS133 1 223163

PCB

D6013 or DIODE 1SS270A ( 1) 223205

PCB

D6013 or DIODE WG713A ( 1) 223222

PCB

D6014 DIODE 1SS133 1 223163

PCB

D6014 or DIODE 1SS270A ( 1) 223205

PCB

D6014 or DIODE WG713A ( 1) 223222

PCB

D6306 DIODE 1SS133 1 223163

PCB

D6306 or DIODE 1SS270A ( 1) 223205

PCB

D6306 or DIODE WG713A ( 1) 223222

PCB

D6307 DIODE 1SS133 1 223163

PCB

D6307 or DIODE 1SS270A ( 1) 223205

PCB

D6307 or DIODE WG713A ( 1) 223222

PCB

D6701 DIODE 1SS133 1 223163

PCB

D6701 or DIODE 1SS270A ( 1) 223205

PCB

D6701 or DIODE WG713A ( 1) 223222

PCB

D6702 DIODE 1SS133 1 223163

PCB

D6702 or DIODE 1SS270A ( 1) 223205

PCB

D6702 or DIODE WG713A ( 1) 223222

PCB

D6703 ZENER D MTZJ5.1B 1 224470512

PCB

D6704 ZENER D MTZJ5.1B 1 224470512

PCB

D6903 DIODE D5SBA20 1 22380130F

PCB

D6903 or DIODE RS603M-B42 ( 1) 22380274F

PCB

D6903 or DIODE RBV602 ( 1) 22380038F

PCB

D6904 DIODE D5SBA20 1 22380130F

PCB

D6904 or DIODE RS603M-B42 ( 1) 22380274F

PCB

D6904 or DIODE RBV602 ( 1) 22380038F

PCB

D6906 DIODE 1SS133 1 223163

PCB

D6906 or DIODE 1SS270A ( 1) 223205

PCB

D6906 or DIODE WG713A ( 1) 223222

PCB

T902 P TRANS NPT-1358DG 1 2301383 ! <402>, <8240>

PCB

T902 P TRANS NPT-1358DG 1 2301383 ! <WT>

PCB

T902 P TRANS NPT-1492D 1 2301739 ! <DD>, <DC>

PCB

T902 P TRANS NPT-1358P 1 2301382 ! <PA>, <PT>

PCB

C901 IS C RE275V-103M 1 3500196S !

PCB

C6040 VR C CE04W50V-47M(VR) 1 394684707

33/37 PAGE

PCB

C6041 VR C CE04W50V-47M(VR) 1 394684707

PCB

C6042 VR C CE04W50V-47M(VR) 1 394684707

PCB

C6043 VR C CE04W50V-47M(VR) 1 394684707

PCB

C6044 VR C CE04W50V-47M(VR) 1 394684707

PCB

C6230 TF C ECQ-V50V-473J 1 374724734

PCB

C6231 TF C ECQ-V50V-473J 1 374724734

PCB

C6232 TF C ECQ-V50V-473J 1 374724734

PCB

C6233 TF C ECQ-V50V-473J 1 374724734

PCB

C6234 TF C ECQ-V50V-473J 1 374724734

PCB

C6701 VR C CE04W6.3V-220M(VR) 1 394622217 <420>

PCB

C6701 or ELECT C CE04W6.3V220M(SC) ( 1) 394722217

PCB

C6701 VR C CE04W6.3V-100M(VR) 1 394621017 <402>, <8240>

PCB

C6701 or ELECT C CE04W6.3V100M(SC) ( 1) 394721017

PCB

C6703 CERA C CK45F50V-223Z 1 335622230

PCB

C6704 VR C CE04W50V-1M(VR) 1 394680107

PCB

C6706 VR C CE04W6.3V-100M(VR) 1 394621017

PCB

C6706 or ELECT C CE04W6.3V100M(SC) ( 1) 394721017

PCB

C6708 TF C ECQ-B50V-223J 1 374722234

PCB

C6901 ELECT C CE69W69V-10000M 1 3504404 <420>

PCB

C6901 or ELECT C CE69W69V10000M ( 1) 3504392

PCB

C6901 ELECT C CE69W56V-8200M 1 3504402 <402>, <8240>

PCB

C6901 or ELECT C CE69W56V8200M ( 1) 3504396

PCB

C6902 ELECT C CE69W69V-10000M 1 3504404 <420>

PCB

C6902 or ELECT C CE69W69V10000M ( 1) 3504392

PCB

C6902 ELECT C CE69W56V-8200M 1 3504402 <402>, <8240>

PCB

C6902 or ELECT C CE69W56V8200M ( 1) 3504396

PCB

C6903 MY C MY92-50V-104J 1 371121044

PCB

C6904 TF C ECQ-V50V-334J 1 374723344 <402>, <8240>

PCB

C6905 TF C ECQ-V50V-334J 1 374723344 <402>, <8240>

PCB

C6904 TF C ECQ-V100-334J 1 374733344

PCB

C6905 TF C ECQ-V100-334J 1 374733344

PCB

C6906 MY C MY92-50V-104J 1 371121044

PCB

C6907 MY C MY92-50V-104J 1 371121044

PCB

C921 CERA C CK45F50V-223Z 1 335622230

PCB

C922 VR C CE04W35V-220M(VR) 1 394662217

PCB

C923 CERA C CK45F50V-223Z 1 335622230

PCB

R923 CARBON R R16J-1K 1 417341024

PCB

R924 METAL O R RS1/2WBJ-82 1 443528204

PCB

R926 CARBON R R16J-4.7K 1 417344724

PCB

R6000 CARBON R R16J-5.6K 1 417345624

PCB

R6001 CARBON R R16J-5.6K 1 417345624

PCB

R6002 CARBON R R16J-5.6K 1 417345624

PCB

R6003 CARBON R R16J-5.6K 1 417345624

PCB

R6004 CARBON R R16J-5.6K 1 417345624

PCB

R6010 CARBON R R16J-3.9K 1 417343924

PCB

R6011 CARBON R R16J-3.9K 1 417343924

PCB

R6012 CARBON R R16J-3.9K 1 417343924

PCB

R6013 CARBON R R16J-3.9K 1 417343924

PCB

R6014 CARBON R R16J-3.9K 1 417343924

PCB

R6030 CARBON R R16J-390 1 417343914 <402>, <8240>

PCB

R6030 CARBON R R16J-390 1 417343914 <420>

PCB

R6031 CARBON R R16J-390 1 417343914 <402>, <8240>

PCB

R6031 CARBON R R16J-390 1 417343914 <420>

PCB

R6032 CARBON R R16J-1K 1 417341024 <402>, <8240>

PCB

R6032 CARBON R R16J-390 1 417343914 <420>

PCB

R6033 CARBON R R16J-1K 1 417341024 <402>, <8240>

PCB

R6033 CARBON R R16J-390 1 417343914 <420>

34/37 PAGE

PCB

R6034 CARBON R R16J-1K 1 417341024 <402>, <8240>

PCB

R6034 CARBON R R16J-390 1 417343914 <420>

PCB

R6040 TRIM R N06HR1KBC 1 5210258

PCB

R6041 TRIM R N06HR1KBC 1 5210258

PCB

R6042 TRIM R N06HR1KBC 1 5210258

PCB

R6043 TRIM R N06HR1KBC 1 5210258

PCB

R6044 TRIM R N06HR1KBC 1 5210258

PCB

R6050 CARBON R R16J-3.9K 1 417343924

PCB

R6051 CARBON R R16J-3.9K 1 417343924

PCB

R6052 CARBON R R16J-3.9K 1 417343924

PCB

R6053 CARBON R R16J-3.9K 1 417343924

PCB

R6054 CARBON R R16J-3.9K 1 417343924

PCB

R6070 NF CARBON R R25J-100 1 415471014 <402>, <8240>

PCB

R6070 NF CARBON R R25J-110 1 415471114 <420>

PCB

R6071 NF CARBON R R25J-100 1 415471014 <402>, <8240>

PCB

R6071 NF CARBON R R25J-110 1 415471114 <420>

PCB

R6072 NF CARBON R R25J-100 1 415471014 <402>, <8240>

PCB

R6072 NF CARBON R R25J-110 1 415471114 <420>

PCB

R6073 NF CARBON R R25J-100 1 415471014 <402>, <8240>

PCB

R6073 NF CARBON R R25J-110 1 415471114 <420>

PCB

R6074 NF CARBON R R25J-100 1 415471014 <402>, <8240>

PCB

R6074 NF CARBON R R25J-110 1 415471114 <420>

PCB

R6080 NF CARBON R R25J-2.2 1 415470224

PCB

R6081 NF CARBON R R25J-2.2 1 415470224

PCB

R6082 NF CARBON R R25J-2.2 1 415470224

PCB

R6083 NF CARBON R R25J-2.2 1 415470224

PCB

R6084 NF CARBON R R25J-2.2 1 415470224

PCB

R6090 NF CARBON R R25J-2.2 1 415470224

PCB

R6091 NF CARBON R R25J-2.2 1 415470224

PCB

R6092 NF CARBON R R25J-2.2 1 415470224

PCB

R6093 NF CARBON R R25J-2.2 1 415470224

PCB

R6094 NF CARBON R R25J-2.2 1 415470224

PCB

R6100 CEMENT R RSS2WK-0.22 1 4800071

PCB

R6100 or OTHER R RGC22-0.22 OHMK ( 1) 4000131

PCB

R6100 or METAL PR MPC708-2WK-0.22 ( 1) 4500027

PCB

R6101 CEMENT R RSS2WK-0.22 1 4800071

PCB

R6101 or OTHER R RGC22-0.22 OHMK ( 1) 4000131

PCB

R6101 or METAL PR MPC708-2WK-0.22 ( 1) 4500027

PCB

R6102 CEMENT R RSS2WK-0.22 1 4800071

PCB

R6102 or OTHER R RGC22-0.22 OHMK ( 1) 4000131

PCB

R6102 or METAL PR MPC708-2WK-0.22 ( 1) 4500027

PCB

R6103 CEMENT R RSS2WK-0.22 1 4800071

PCB

R6103 or OTHER R RGC22-0.22 OHMK ( 1) 4000131

PCB

R6103 or METAL PR MPC708-2WK-0.22 ( 1) 4500027

PCB

R6104 CEMENT R RSS2WK-0.22 1 4800071

PCB

R6104 or OTHER R RGC22-0.22 OHMK ( 1) 4000131

PCB

R6104 or METAL PR MPC708-2WK-0.22 ( 1) 4500027

PCB

R6140 CARBON R R16J-22K 1 417342234

PCB

R6141 CARBON R R16J-22K 1 417342234

PCB

R6142 CARBON R R16J-22K 1 417342234

PCB

R6143 CARBON R R16J-22K 1 417342234

PCB

R6144 CARBON R R16J-22K 1 417342234

PCB

R6150 CARBON R R16J-12K 1 417341234

PCB

R6151 CARBON R R16J-12K 1 417341234

PCB

R6152 CARBON R R16J-12K 1 417341234

PCB

R6153 CARBON R R16J-12K 1 417341234

PCB

R6154 CARBON R R16J-12K 1 417341234

35/37 PAGE

PCB

R6160 CARBON R R16J-33K 1 417343334

PCB

R6161 CARBON R R16J-33K 1 417343334

PCB

R6162 CARBON R R16J-33K 1 417343334

PCB

R6163 CARBON R R16J-33K 1 417343334

PCB

R6164 CARBON R R16J-33K 1 417343334

PCB

R6170 CARBON R R16J-47K 1 417344734

PCB

R6171 CARBON R R16J-47K 1 417344734

PCB

R6172 CARBON R R16J-47K 1 417344734

PCB

R6173 CARBON R R16J-47K 1 417344734

PCB

R6174 CARBON R R16J-47K 1 417344734

PCB

R6180 CARBON R R16J-47K 1 417344734

PCB

R6181 CARBON R R16J-47K 1 417344734

PCB

R6182 CARBON R R16J-47K 1 417344734

PCB

R6183 CARBON R R16J-47K 1 417344734

PCB

R6184 CARBON R R16J-47K 1 417344734

PCB

R6190 CARBON R R16J-330K 1 417343344 <420>

PCB

R6191 CARBON R R16J-330K 1 417343344 <420>

PCB

R6192 CARBON R R16J-330K 1 417343344 <420>

PCB

R6193 CARBON R R16J-330K 1 417343344 <420>

PCB

R6194 CARBON R R16J-330K 1 417343344 <420>

PCB

R6190 CARBON R R16J-220K 1 417342244 <402>, <8240>

PCB

R6191 CARBON R R16J-220K 1 417342244 <402>, <8240>

PCB

R6192 CARBON R R16J-220K 1 417342244 <402>, <8240>

PCB

R6193 CARBON R R16J-220K 1 417342244 <402>, <8240>

PCB

R6194 CARBON R R16J-220K 1 417342244 <402>, <8240>

PCB

R6230 METAL R RNU1WCJ-8.2 1 453630824

PCB

R6231 METAL R RNU1WCJ-8.2 1 453630824

PCB

R6232 METAL R RNU1WCJ-8.2 1 453630824

PCB

R6233 METAL R RNU1WCJ-8.2 1 453630824

PCB

R6234 METAL R RNU1WCJ-8.2 1 453630824

PCB

R6306 CARBON R R16J-10K 1 417341034

PCB

R6308 CARBON R R16J-4.7K 1 417344724

PCB

R6380 RESISTOR

PTFL04BF471Q2N34B0 (80）

1 4000217 <DD>, <DC>

PCB

R6380 THERMISTOR PTH9M04BF222TS2F333 1 4000153 <402>, <8240>

PCB

R6380 THERMISTOR PTH9M04BF222TS2F333 1 4000153 <PA>, <PT>, <WT>

PCB

R6601 CARBON R R16J-1K 1 417341024

PCB

R6602 CARBON R R16J-1K 1 417341024

PCB

R6603 CARBON R R16J-1K 1 417341024

PCB

R6701 CARBON R R16J-22K 1 417342234

PCB

R6702 CARBON R R16J-10K 1 417341034

PCB

R6704 CARBON R R16J-47K 1 417344734

PCB

R6706 CARBON R R16J-220K 1 417342244

PCB

R6708 CARBON R R16J-33K 1 417343334

PCB

R6709 CARBON R R16J-5.6K 1 417345624

PCB

R6710 CARBON R R16J-56K 1 417345634 <402>, <8240>

PCB

R6710 CARBON R R16J-12K 1 417341234 <DD>, <DC>

PCB

R6710 CARBON R R16J-12K 1 417341234 <PA>, <PT>, <WT>

PCB

R6850 METAL O R RS1/2WBJ-390 1 443523914

PCB

R6851 METAL O R RS1/2WBJ-390 1 443523914

PCB

R6902 CARBON R R16J-1K 1 417341024

PCB

RL901 RELAY SW NRL-1P5A-DC12-102 1 25065526

PCB

RL901 or RELAY NRL-1P5A-DC12-127 ( 1) 25065561

PCB

RL901 or RELAY NRL-1P5A-DC12-096 ( 1) 25065515

PCB

RL901 or RELAY NRL-1P10A-DC12-093 ( 1) 25065508

PCB

RL6901 RELAY SW NRL-1P5A-DC12-102 1 25065526

PCB

RL6901 or RELAY NRL-1P5A-DC12-127 ( 1) 25065561

PCB

RL6901 or RELAY NRL-1P5A-DC12-096 ( 1) 25065515

36/37 PAGE

PCB

RL6901 or RELAY NRL-1P10A-DC12-093 ( 1) 25065508

PCB

RL6902 RELAY SW NRL-1P5A-DC12-102 1 25065526

PCB

RL6902 or RELAY NRL-1P5A-DC12-127 ( 1) 25065561

PCB

RL6902 or RELAY NRL-1P5A-DC12-096 ( 1) 25065515

PCB

RL6902 or RELAY NRL-1P10A-DC12-093 ( 1) 25065508

PCB

P206A PLUG NPLG-14P666 1 25055710

PCB

P801B SOCKET NSCT-14P1029 1 25051239

PCB

P931 PLUG NPLG-5P657 1 25055701

PCB

P931A SOCKET NSCT-5P1020 1 25051230

PCB

P6000 PLUG NPLG-5P0960 1 25056010

PCB

P6001 PLUG NPLG-5P0960 1 25056010

PCB

P6002 PLUG NPLG-5P0960 1 25056010

PCB

P6003 PLUG NPLG-5P0960 1 25056010

PCB

P6004 PLUG NPLG-5P0960 1 25056010

PCB

P6011 PLUG NPLG-9P0964 1 25056014

PCB

P6072 TRM NTM-1P233(M1969) 1 25060302

PCB

P6072A TRM NTM-1P232(M1700) 1 25060301

PCB

P6073A TRM NTM-1P232(M1700) 1 25060301

PCB

P6080 PLUG NPLG-2P29 1 25055038

PCB

P6081 PLUG NPLG-2P29 1 25055038

PCB

P6082 PLUG NPLG-2P29 1 25055038

PCB

P6083 PLUG NPLG-2P29 1 25055038

PCB

P6084 PLUG NPLG-2P29 1 25055038

PCB

P6301 PLUG NPLG-2P29 1 25055038

PCB

P6801 WS CLAMP CP-2S 1 260226

PCB

P6903 BUS BAR BBL25 1 27141806

PCB

P6906 RETAINER KANAGU(ｱｰｽ) 1 27141059

PCB

P6907 TRM(SCREW) NEGITANSI M3 1 25065425

PCB

P6931 PLUG NPLG-15P667 1 25055711

PCB

F901A FUSE HOL NSCT-1P2031 1 25052133 <DD>, <DC>, <WT>

PCB

F901B FUSE HOL NSCT-1P2031 1 25052133 <DD>, <DC>, <WT>

PCB

F901C LABEL LABEL 1 29360842 <DD>, <DC>

PCB

F902A FUSE HOL NSCT-1P2031 1 25052133 <402>, <8240>

PCB

F902A FUSE HOL NSCT-1P2031 1 25052133 <PA>, <WT>

PCB

F902B FUSE HOL NSCT-1P2031 1 25052133 <402>, <8240>

PCB

F902B FUSE HOL NSCT-1P2031 1 25052133 <PA>, <WT>

PCB

F903A FUSE HOL NSCT-1P2031 1 25052133

PCB

F903B FUSE HOL NSCT-1P2031 1 25052133

PCB

F903C LABEL 5A/125V 1 29360462 <DD>, <DC>

PCB

F6901A FUSE HOL NSCT-1P2031 1 25052133

PCB

F6901B FUSE HOL NSCT-1P2031 1 25052133

PCB

F6901C FUSE LABEL T8AL250V 1 29362800 <402>, <8240>

PCB

F6901C FUSE LABEL T8AL250V 1 29362800 <PA>, <PT>, <WT>

PCB

F6902A FUSE HOL NSCT-1P2031 1 25052133

PCB

F6902B FUSE HOL NSCT-1P2031 1 25052133

PCB

JL6402B WIRE HOL NSCT-3P874 1 25051087 <DD>, <DC>

PCB

JL6403C WIRE HOL NSCT-3P874 1 25051087 <402>, <8240>

PCB

JL6403C WIRE HOL NSCT-3P874 1 25051087 <PA>, <PT>, <WT>

PCB

P901A PLUG NPLG-2P631 1 25055675 <402>, <8240>

PCB

P901A PLUG NPLG-2P631 1 25055675 <DD>, <DC>, <WT>

PCB

P902 AC OUTLET NSCT-2P2560 1 25052664 <402>, <8240>

PCB

P902 AC OUTLET NSCT-2P2013 1 25052115 <PA>

PCB

P902 SOCKET NSCT-2P1358 1 25051571 <DD>, <DC>

PCB

P902 SOCKET NSCT-2P1359 1 25051572 <WT>, <PT>

PCB

P911 CRIMP AS CRIMP AS 1 2069943259UL

PCB

P912 CRIMP AS CRIMP AS 1 2069943224UL

PCB

P913 CRIMP AS CRIMP AS 1 2069943206UL <WT>

37/37 PAGE

PCB

P921 CRIMP AS CRIMP-AS 1 2069943101UL <WT>

PCB

P922 CRIMP AS CRIMP-AS 1 2069943103UL <WT>

PCB

P923 CRIMP AS CRIMP AS 1 2069943106UL <WT>

PCB

P6380 SHLD CASE (THERMISTOR) 1 27225154A <WT>

PCB

S902 SLIDE SW NSS-22157P 1 25065437 <WT>

PCB

J010 CRIMP AS CRIMP AS 1 2069925149UL

PCB

J011 CRIMP AS CRIMP AS 1 2069925226UL

PCB

JL6402A WIRE HOL NSCT-3P874 1 25051087

PCB

JL6803A WIRE HOL NSCT-5P896 1 25051109

PCB

JL6804A WIRE HOL NSCT-5P896 1 25051109

PCB

JL6805A WIRE HOL NSCT-4P895 1 25051108

PCB

JL6951A WIRE HOL NSCT-5P896 1 25051109

PCB

JL6951B WIRE HOL NSCT-5P896 1 25051109

PCB

JL6952A WIRE HOL NSCT-5P896 1 25051109

PCB

JL6952B WIRE HOL NSCT-5P896 1 25051109

<Notes>

When replacement the following the capacitor, made from the same Parts No. as the original type. C6901 - C6902

PACKING PROCEDURES PARTS LIS

T

<Notes> (S) : Silver model (B) : Black model (G) : Golden model <402> : TX-SR402 (Chinese model) <8240> : TX-SR8240 (Chinese model)

REF NO. NAME DESCRIPTION Q'TY PART NO. REMARKS

PKG

A601 PAD AS 1 29092087A

PKG

A610 POLY BAG POLY BAG(850 x 650) 1 29100034-1A

PKG

A611 SHEET --- 1 29095906

PKG

A613 TAPE (SEROHAN)NITTO NO.29 1 29110149

PKG

A615 PP TAPE W48 OPP TAPE 1 29110148

PKG

A625 POLY BAG 350 x 250 1 29100097-1A

PKG

A635 LABEL (SP CABLE) 1 29363059A

PKG

A650 CARTON --- 1 29054167 <8240>, (G)

PKG

A650 CARTON --- 1 29054136 <402>, (S)

PKG

A650 CARTON --- 1 29054135 <402>, (G)

PKG

A655 EAN LABEL --- 1 29363683 <8240>, (G)

PKG

A655 EAN LABEL --- 1 29363598 <402>, (G)

PKG

A655 EAN LABEL --- 1 29363597 <402>, (S)

PKG

A801 INS MANUAL Cs(TX-SR402) 1 29343626 <402>, <8240>

PKG

A811 REMO CON RC-479S 1 24140479

PKG

A812 BATTERY R6/AA(UM-3) 2 3010054

PKG

A820 ANT COIL NMA-3057 1 232140

PKG

A821 FM ANT AS Type W 1 292191

TX-SR402/8240/HT-R420

ONKYO U.S.A. CORPORATION

18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.onkyousa.com

ONKYO EUROPE ELECTRONICS GmbH

Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.onkyo.net

ONKYO CHINA LIMITED

Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung, N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039

Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8124

ONKYO CORPORATION

http://www.onkyo.com/

HOMEPAGE

Onkyo HT-R420, TX-SR8240, RC-518M, RC-479S Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
