Onkyo HT-R557, HT-SR750 Instruction Manual

5.1ch Home Theater System

HT-SR750

AV Receiver (HT-R557) Front Speakers (SKF-645F) Center Speaker (SKC-645C) Surround Speakers (SKM-645S) Powered Subwoofer (SKW-540)

Instruction Manual

Contents

Introduction ..................................... 2

Connection .................................... 18

Turning On & First Time Setup..... 35

Basic Operation

Playing your AV components....... 41

Listening to the Radio.................. 43

Thank you for purchasing an Onkyo 5.1ch Home Theater System. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new 5.1ch Home Theater System. Please retain this manual for future reference.

Enjoying the Listening Modes ..... 47

Advanced Operation..................... 53

Troubleshooting ............................ 62

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not ﬁt into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories speciﬁed by the manufacturer.

12.

Use only with the cart, stand, tripod, bracket, or table speciﬁed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

PORTABLE CART WARNING

S3125A

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to

persons. The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

AVIS

RISQUE DE CHOC ELECTRIQUE

NE PAS

OUVRIR

15. Damage Requiring Service Unplug the apparatus from the wall outlet and refer servicing to qualiﬁed service personnel under the following conditions: A. When the power-supply cord or plug is damaged, B. If liquid has been spilled, or objects have fallen

into the apparatus,

C. If the apparatus has been exposed to rain or

water,

D. If the apparatus does not operate normally by

following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualiﬁed technician to restore the apparatus to its normal operation,

E. If the apparatus has been dropped or damaged in

any way, and

F. When the apparatus exhibits a distinct change in

performance this indicates a need for service.

16. Object and Liquid Entry Never push objects of any kind into the apparatus through openings as they may touch dangerous voltage points or short-out parts that could result in a ﬁre or electric shock. The apparatus shall not be exposed to dripping or splashing and no objects ﬁlled with liquids, such as vases shall be placed on the apparatus. Don’t put candles or other burning objects on top of this unit.

17. Batteries Always consider the environmental issues and follow local regulations when disposing of batteries.

18. If you install the apparatus in a built-in installation, such as a bookcase or rack, ensure that there is adequate ventilation. Leave 20 cm (8") of free space at the top and sides and 10 cm (4") at the rear. The rear edge of the shelf or board above the apparatus shall be set 10 cm (4") away from the rear panel or wall, creating a ﬂue-like gap for warm air to escape.

Precautions

1. Recording Copyright

only, recording copyrighted material is illegal without the permission of the copyright holder.

2. AC Fuse

serviceable. If you cannot turn on the unit, contact your Onkyo dealer.

3. Care

over with a soft cloth. For stubborn stains, use a soft cloth dampened with a weak solution of mild detergent and water. Dry the unit immediately afterwards with a clean cloth. Don’t use abrasive cloths, thinners, alcohol, or other chemical solvents, because they may damage the ﬁnish or remove the panel lettering.

4. Power WARNING

BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME, READ THE FOLLOWING SECTION CAREFULLY. AC outlet voltages vary from country to country.

Make sure that the voltage in your area meets the voltage requirements printed on the unit’s rear panel (e.g., AC 230–240 V, 50 Hz or AC 120 V, 60 Hz).

The power cord plug is used to disconnect this unit from the AC power source. Make sure that the plug is readily operable (easily accessible) at all times.

Pressing the [STANDBY/ON] button to select Standby mode does not fully shutdown the unit. If you do not intend to use the unit for an extended period, remove the power cord from the AC outlet.

5. Never Touch this Unit with Wet Hands

handle this unit or its power cord while your hands are wet or damp. If water or any other liquid gets inside this unit, have it checked by your Onkyo dealer.

6. Handling Notes

• If you need to transport this unit, use the original

• Do not leave rubber or plastic items on this unit

• This unit’s top and rear panels may get warm

• If you do not use this unit for a long time, it may

—The AC fuse inside the unit is not user-

—Occasionally you should dust the unit all

packaging to pack it how it was when you originally bought it.

for a long time, because they may leave marks on the case.

after prolonged use. This is normal.

not work properly the next time you turn it on, so be sure to use it occasionally.

—Unless it’s for personal use

—Never

For U.S. models

FCC Information for User

CAUTION:

The user changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

For Canadian Models

NOTE:

COMPLIES WITH CANADIAN ICES-003. For models having a power cord with a polarized plug:

CAUTION:

MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

THIS CLASS B DIGITAL APPARATUS

TO PREVENT ELECTRIC SHOCK,

Modèle pour les Canadien

REMARQUE:

LA CLASSE B EST CONFORME À LA NORME NMB-003 DU CANADA. Sur les modèles dont la ﬁche est polarisée:

ATTENTION:

TRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

CET APPAREIL NUMÉRIQUE DE

POUR ÉVITER LES CHOCS ÉLEC-

Speaker Precautions

Package Contents

Placement

• The speaker cabinets are made out of wood and are therefore sensitive to extreme temperatures and humidity, do not put them in locations subject to direct sunlight or in humid places, such as near an air conditioner, humidiﬁer, bathroom, or kitchen.

• Do not put water or other liquids close to the speakers. If liquid is spilled over the speakers, the drive units may be damaged.

• Speakers should only be placed on sturdy, ﬂat surfaces that are free from vibration. Putting them on uneven or unstable surfaces, where they may fall and cause damage, will affect the sound quality.

• Subwoofer is designed to be used in the upright vertical position only. Do not use it in the horizontal or tilted position.

• If the unit is used near a turntable, CD player or DVD player, howling or slipping of sound may occur. To prevent this, move the unit away from the turntable, CD player or DVD player otherwise lower the unit’s output level.

Using Close to a TV or Computer

TVs and computer monitors are magnetically sensitive devices and as such are likely to suffer discoloration or picture distortion when conventional speakers are placed nearby. To prevent this, the speakers feature internal magnetic shielding. In some situations, however, discoloration may still be an issue, in which case you should turn off your TV or monitor, wait 15 to 30 minutes, and then turn it back on again. This normally activates the degaussing function, which neutralizes the magnetic ﬁeld, thereby removing any discoloration effects. If discoloration problems persist, try moving the speakers away from your TV or monitor. Note that discoloration can also be caused by a magnet or demagnetizing tool that’s too close to your TV or monitor.

Input Signal Warning

The speakers can handle the speciﬁed input power when used for normal music reproduction. If any of the following signals are fed to them, even if the input power is within the speciﬁed rating, excessive current may ﬂow in the speaker coils, causing burning or wire breakage:

Interstation noise from an untuned FM radio.

Sound from fast-forwarding a cassette tape.

High-pitched sounds generated by an oscillator, electronic musical instrument, and so on.

Ampliﬁer oscillation.

Special test tones from audio test CDs and so on.

Thumps and clicks caused by connecting or disconnecting audio cables (Always turn off your ampliﬁer before connecting or disconnecting cables.)

Microphone feedback.

Make sure you have the following items:

AV receiver (HT-R557)

Remote controller and two batteries (AA/R6)

Indoor FM antenna

AM loop antenna

Speaker setup microphone

Speaker terminal tool

Package Contents

Front speakers (SKF-645F)

—Continued

Base for horizontal mounting (For the center speaker)

Center speaker (SKC-645C)

Surround speakers (SKM-645S)

Subwoofer (SKW-540)

(Red) (White)

Speaker cable for front speakers 15 ft. (4.5 m)

Rubber spacers [20] (For the speakers)

* In catalogs and on packaging, the letter at the end of the

product name indicates the color. Speciﬁcations and operation are the same regardless of color.

(Green)

Speaker cable for center speaker 10 ft. (3 m)

(Blue) (Gray)

Speaker cables for surround speakers 30 ft. (9 m)

RCA cable for subwoofer connection 10 ft. (3 m)

Features

Ampliﬁer

• 5-channel ampliﬁer

• 110 watts per channel rms into 8 ohms, 2 channels driven at 1 kHz, less than 0.9% total harmonic distortion (FTC rating)

• WRAT (Wide Range Ampliﬁer Technology)

• Non-Scaling Conﬁguration

• Massive High Current Power Supply (H.C.P.S.) transformer

• Optimum Gain Volume Circuitry

• Audyssey 2EQ room correction

Processing

• Dolby*2 Digital EX and Dolby Pro Logic II

• DTS, DTS-ES Matrix/Discrete, DTS Neo:6, and DTS

96/24

• Neural Surround

• Theater-Dimensional*5 virtual surround sound

• Linear PCM 192 kHz/24-bit D/A converters on all channels

•Powerful and highly accurate 32-bit DSP processing

Audio/Video

•2 HDMI*6 inputs, 1 output

• Adjustable crossover (40, 50, 60, 80, 100, 120, 150, 200 Hz)

• HDTV-capable component video (3 inputs, 1 output)

•3 S-Video inputs, 2 outputs

•4 assignable digital inputs (2 optical, 2 coaxial)

• Subwoofer pre out

• Color-coded 5.1 multichannel input for use with Super Audio CD and DVD-Audio

• Color-coded speaker terminal posts

Tuner

•XM*7 Satellite Radio

*XM Passport System required; sold separately.

• SIRIUS*8 Satellite Radio

• 40 radio presets

• AM/FM auto tuning

Manufactured under license from Audyssey Laboratories. U.S. and foreign patents pending. Audyssey 2EQ is a trademark of Audyssey Laboratories.

Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories.

“DTS” and “DTS-ES | Neo: 6” are registered trademarks of DTS, Inc. “96/24” is a trademark of DTS, Inc.

Neural Surround name and related logos are trademarks owned by Neural Audio Corporation.

Theater-Dimensional is a trademark of Onkyo Corporation.

HDMI, the HDMI logo and High Deﬁnition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC. This unit incorporates HDMI technology.

©2005 SIRIUS Satellite Radio Inc. “SIRIUS,” the SIRIUS dog logo, channel names and logos are trademarks of SIRIUS Satellite Radio Inc. Available only in the contiguous United States (excluding Alaska and Hawaii) and Canada.

is a registered trademark of XM Satellite

Remote Controller

• Preprogrammed for use with other AV components

Speaker

• Color-coded speaker terminals and speaker cables

• Subwoofer Auto standby function

• Magnetically shielded front, center, and surround speakers

Introduction

Important Safety Instructions ....................2

Precautions .................................................3

Speaker Precautions ..................................4

Package Contents.......................................4

Features .......................................................6

Getting to Know the AV Receiver..............9

Remote Controller.....................................12

Speakers ....................................................17

Connection

Connecting Your Speakers ......................18

Connecting Antennas...............................21

Connecting Your Components ................23

About AV Connections ................................23

Connecting Audio and Video Signals

to the AV Receiver .................................... 24

Which Connections Should I Use?..............24

TV or Projector DVD player

Components with HDMI ..............................28

VCR or DVD Recorder for Playback ...........29

VCR or DVD Recorder for Recording.......... 30

Camcorder, Games Console,

or Other Device.........................................30

Satellite, Cable, Set-top box,

or Other Video Source ..............................31

CD Player or Turntable................................32

RI Dock........................................................33

Cassette, CDR, MiniDisc,

or DAT Recorder.......................................33

Connecting Onkyo Components

Connecting the Power Cord ........................34

..........................................25

.................................................26

..........34

Turning On & First Time Setup

Turning On the AV Receiver ....................35

First Time Setup........................................36

Automatic Speaker Setup

(Audyssey 2EQ)........................................ 36

HDMI Video Setup.......................................39

Digital Audio Input Setup.............................40

Changing the Input Display .........................40

Basic Operation

Playing Your AV Components ................ 41

Basic AV Receiver Operation ..................... 41

Using the Multichannel DVD Input.............. 42

Displaying Source Information.................... 42

Listening to the Radio.............................. 43

Listening to AM/FM Stations....................... 43

Presetting AM/FM Stations ......................... 44

Common Functions.................................. 45

Setting the Display Brightness.................... 45

Adjusting the Bass and Treble.................... 45

Muting the AV Receiver .............................. 45

Using the Sleep Timer ................................ 46

Using Headphones ..................................... 46

Adjusting Speaker Levels ........................... 46

Enjoying the Listening Modes

Using the Listening Modes...................... 47

Selecting Listening Modes.......................... 47

About the Listening Modes ......................... 48

Using the Late Night Function

(Dolby Digital only) ................................... 50

Using the CinemaFILTER........................... 50

Using the Audio Adjust Settings ................. 50

Advanced Operation

Recording.................................................. 52

Advanced Setup ....................................... 53

Advanced Speaker Settings ....................... 53

Digital Input Signal Formats ....................... 58

Correcting Sound and Picture Sync ........... 58

Controlling Other Components............... 59

Entering Remote Control Codes................. 59

Remote Control Codes for Onkyo

Components Connected via .............. 60

Resetting REMOTE MODE Buttons ........... 60

Resetting the Remote Controller ................ 60

Troubleshooting ....................................... 62

If you can’t resolve an issue, try resetting the AV receiver by holding down the [VCR/DVR] button and pressing the [STANDBY/ON] button.

Specifications ........................................... 65

Getting Started in Five Easy Steps

1. Hookup

Connect the speakers and your AV components to the AV receiver.

☞ page 18

SIRIUS

HDMI

ASSIGNABLE

OUT

IN 1IN 2

ANTENNA

DIGITAL IN

ASSIGNABLE

COAXIAL

(DVD)

(CBL/SAT)

OPTICAL

(VCR/DVR)

(CD)

REMOTE CONTROL

OUT

CBL/SAT IN

VCR/DVR IN

DVD IN

COMPONENT VIDEO

OUT

IN IN

TAPE

FMAM75

MONITOR

CBL/SAT

VCR/DVR

DVD

OUT

B/PB

CR/PR

INININ

CBL/SAT

OUT

IN IN

FRONT

SURROUND

CENTER

OUT

SUB WOOFER

DVD

VCR/DVR

SURROUND

FRONT

CENTER

SPEAKERS

SPEAKER

PRE OUT

SUB

WOOFER

2. Turning On

With the hookup complete, you’re ready to switch on.

☞ page 35

3. First Time Setup

A few simple settings to get the very best from your system.

☞ page 36

HDMI Video

Setup

Automatic

Speaker Setup

4. Playing Your AV Components

Enjoying movies and music.

☞ page 41

5. Using the Listening Modes

Time to really enjoy your home theater system!

☞ page 47

Digital Input

Input Display

Getting to Know the AV Receiver

Front Panel

STANDBY/ON

STANDBY

3 5 6 74

TUNING

MASTER VOLUME

PRESET

DVD

TONE STEREO DIMMER MEMORY

PHONES

MULTI CH C D

DISPLAY

DIGITAL INPUT

For detailed information, see the pages in parentheses.

STANDBY/ON button (35)

Sets the AV receiver to On or Standby.

STANDBY indicator (35)

Lights up when the AV receiver is on Standby and ﬂashes while a signal is being received from the remote controller.

Remote-control sensor (12)

Receives control signals from the remote controller.

Display

See “Display” on page 10.

Input selector buttons (41)

Select the input sources. The [MULTI CH] button selects the multichannel

DVD input.

Arrow/TUNING/PRESET and ENTER buttons

When the tuner is selected, the TUNING [ ] [ ] buttons are used for radio tuning, and the PRESET

[] [ ] buttons are used to select radio presets (see page 44). With the setup menus, they work as arrow buttons and are used to select and set items. The ENTER button is also used with the setup menus.

MASTER VOLUME control (41)

Sets the volume of the AV receiver to MIN, 1 through 79, or MAX.

PHONES jack (46)

This 1/4-inch phone jack is for connecting a standard pair of stereo headphones for private listening.

DISPLAY button (42)

Displays various information about the currently selected input source.

AUXCBL/SATVCR/DVR

LISTENING MODE

TUNERTAPE

TUNING MODE

CLEAR

SETUP ENTER

SETUP MIC

RETURN

AUX INPUT

VIDEO

AUDIOLR

TKLM9J NOP8QSR

DIGITAL INPUT button (40, 58)

Used to assign the digital inputs and to specify the format of digital input signals.

TONE, [–], and [+] buttons (45)

Used to adjust the bass and treble.

STEREO button (47)

Selects the Stereo listening mode.

LISTENING MODE [ ]/[ ] buttons (47)

Select the listening modes.

DIMMER button (45)

Adjusts the display brightness.

MEMORY button (44)

Used when storing or deleting radio presets.

TUNING MODE button (43)

Selects the Auto or Manual tuning mode for AM and FM radio.

SETUP button

Used to access the setup menus.

SETUP MIC (37)

The automatic speaker setup microphone connects here.

RETURN button

Selects the previously displayed setup menu.

AUX INPUT (30, 52)

Used to connect a camcorder, games console, and so on. There are jacks for composite video and analog audio.

Getting to Know the AV Receiver

Display

—Continued

12 4

For detailed information, see the pages in parentheses.

MUTING indicator (45)

Flashes while the AV receiver is muted.

Input signal format indicators

Show the audio signal format of the current input source.

Listening mode indicators (48)

Show the selected listening mode.

Radio indicators

FM STEREO (43):

reo FM station.

AUTO (43):

Auto Tuning mode is selected, and disappears when Manual Tuning mode is selected.

TUNED (43):

tion.

SLEEP indicator (46)

Lights up when the Sleep function has been set.

Message area

Displays various information about the selected input source.

Audyssey indicator (36)

Lights up during automatic speaker setup.

Lights up when tuned to a ste-

For AM and FM radio, lights up when

Lights up when tuned to a radio sta-

Getting to Know the AV Receiver

Rear Panel

—Continued

FMAM75

IN IN

DVD

FRONT

7 8

SIRIUS

MONITOR

OUT

SURROUND

CENTER

WOOFER

DVD

SUB

1 2 53 6 9

DIGITAL IN

ASSIGNABLE

COAXIAL

(DVD)

(CBL/SAT)

OPTICAL

(VCR/DVR)

(CD)

REMOTE CONTROL

CBL/SAT IN

IN 1IN 2

B/PB

CR/PR

OUT

VCR/DVR IN

DVD IN

COMPONENT VIDEO

OUT

IN IN

TAPE

HDMI

ASSIGNABLE

OUT

ANTENNA

CBL/SAT

VCR/DVR

OUT

CBL/SAT

VCR/DVR

J K L M N O

DIGITAL IN OPTICAL 1, 2 and COAXIAL 1, 2

These optical and coaxial digital audio inputs are for connecting components with optical or coaxial digital audio outputs, such as CD and DVD players.

HDMI IN 1, 2, and OUT

These jacks are for connecting HDMI-compatible components. Audio and video signals received by the HDMI IN jacks pass through to the HDMI OUT jack.

COMPONENT VIDEO

A DVD player, TV, or other component that supports component video can be connected here.

AM ANTENNA

These push terminals are for connecting an AM antenna.

FM ANTENNA

This jack is for connecting an FM antenna.

MONITOR OUT

The S-Video or composite video output should be connected to a video input on your TV or projector.

SIRIUS antenna

This jack is for connecting a SIRIUS Satellite Radio antenna (see the separate SIRIUS instructions).

XM antenna

This jack is for connecting an XM Passport System, sold separately (see the separate XM instructions).

FRONT SPEAKERS, SURROUND SPEAKERS, and CENTER SPEAKER

These terminal posts are for connecting the front, center, and surround speakers.

SURROUND SPEAKERS

PRE OUT

SUB

WOOFER

FRONT

SPEAKERS

CENTER

SPEAKER

REMOTE CONTROL

This Remote Interactive jack can be connected to the jack on another -capable Onkyo component. To use , you must make an analog audio

connection (RCA) between the AV receiver and the other component, even if they are connected digitally.

CD IN

This analog audio input is for connecting a CD player’s analog audio output.

TAPE IN/OUT

This analog audio input and output are for connecting a recorder with an analog audio input and output, such as a cassette deck, MD recorder, etc.

CBL/SAT IN and VCR/DVR IN/OUT

The CBL/SAT inputs can be used to connect a cable/satellite receiver, set-top box, etc.

The VCR/DVR inputs and outputs can be used to connect a VCR or DVR (digital video recorder).

DVD IN

These jacks can be used to connect a DVD player with an analog multichannel audio output for SACD and DVD-Audio playback.

SUBWOOFER PRE OUT

A powered subwoofer can be connected here.

See pages 18–34 for hookup information.

Remote Controller

Installing the Batteries

To open the battery compartment, press

the small hollow and slide open the cover.

Insert the two supplied batteries (AA/R6)

in accordance with the polarity diagram inside the battery compartment.

Slide the cover shut.

Notes:

• If the remote controller doesn’t work reliably, try replacing the batteries.

• Don’t mix new and old batteries or different types of batteries.

• If you intend not to use the remote controller for a long time, remove the batteries to prevent damage from leakage or corrosion.

• Expired batteries should be removed as soon as possible to prevent damage from leakage or corrosion.

Aiming the Remote Controller

When using the remote controller, point it toward the AV receiver’s remote control sensor, as shown below.

Remote control sensor

AV receiver

STANDBY indicator

Approx. 16 ft. (5 m)

Notes:

• The remote controller may not work reliably if the AV receiver is subjected to bright light, such as direct sunlight or inverter-type ﬂuorescent lights. Keep this in mind when installing.

• If another remote controller of the same type is used in the same room, or the AV receiver is installed close to equipment that uses infrared rays, the remote controller may not work reliably.

• Don’t put anything on top of the remote controller, such as a book or magazine, because a button may be pressed continuously, thereby draining the batteries.

• The remote controller may not work reliably if the AV receiver is installed in a rack behind colored glass doors. Keep this in mind when installing.

• The remote controller will not work if there’s an obstacle between it and the AV receiver’s remote control sensor.

Remote Controller

—Continued

Using the Remote Controller

Including the AV receiver, the remote controller can be used to control up to seven different components. The remote controller has a speciﬁc operating mode for use with each type of component. Modes are selected by using the six REMOTE MODE buttons.

■

RECEIVER/TAPE Mode

In RECEIVER/TAPE mode, you can control the AV receiver and an Onkyo cassette recorder connected via .

■

DVD and CD/MD/CDR/DOCK Modes

With these modes, you can control a DVD player and CD player, MD recorder, CDR, or RI dock DS-A1X. By entering the appropriate remote control code, you can control Onkyo components or components made by other manufacturers (see page 59).

■

TV, VCR and SAT/CABLE Modes

With these modes, you can control a TV, VCR, and satellite or cable receiver. You must enter the appropriate remote control code ﬁrst (see page 59).

REMOTE MODE

RECEIVER

TAPE/AMP

Press one of the REMOTE MODE buttons to select a mode.

DVD

M D/CDR

DOCK

VCR

CABLE

SAT

RECEIVER

TAPE/AMP

DVD

M D/CDR

DOCK

VCR

CABLE

SAT

RECEIVER/TAPE Mode

RECEIVER/TAPE mode is used to control the AV receiver. It can also be used to control an Onkyo cassette recorder connected via .

RECEIVER

TAPE/AMP

STANDBY/ON

INPUT SELECTOR

123

VCR/DVR

456

AUX

789

10 11 12

D TUN

--/---

INPUT

GUIDE

TOP MENU

SP A / B

PLAYLIST/CAT PLAYLIST/CAT

SETUP RETURN

CBL/SAT

MULTI CH

DIMMER

VOL

REMOTE MODE

RECEIVER

TAPE/AMP

ENT

SLEEP

ALBUM

ENTER

DVD

C DTAPE TUNER

CLR

DISC

DVD

D/CDR

C D

DOCK

VCR

CABLE

SAT

VOL

MUTING

LISTENING MODE

SURROUND

STEREO

RANDOM

SUBTITLE

AUDIO REPEAT

TEST TONE

CH SEL

PLAY MODE

DISPLAY

LEVEL

L NIGHT

LEVEL

CINE FLTR

HDDDVDVCR

O P

Use the buttons supported by that mode to control the component.

RECEIVER/TAPE mode:

see right column

DVD mode:

see page 15

CD/MD/CDR/DOCK mode:

see page 16

TV, VCR, SAT/CABLE modes:

see page 61

Note:

Some of the remote controller operations described in this manual may not work as expected with other components.

681M

Buttons

1, 2, 3

, and 4 are used when the TUNER

or TAPE input is selected.

* The SP A/B function is not supported by this model.

Remote Controller

—Continued

For detailed information, see the pages in parentheses.

STANDBY/ON button (35)

Sets the AV receiver to On or Standby.

INPUT SELECTOR buttons (41)

Used to select the input sources.

MULTI CH button (42)

Selects the multichannel DVD input.

DIMMER button (45)

Adjusts the display brightness.

Arrow [ ]/[ ]/[ ]/[ ] and ENTER buttons

Used to select and adjust settings.

SETUP button

Used to access the setup menus.

LISTENING MODE buttons (47)

Used to select the listening modes. These buttons work in all remote controller modes.

STEREO button

Selects the Stereo listening mode.

SURROUND button

Selects the Dolby and DTS listening modes and the Neural Surround listening mode.

[ ]/[ ] buttons

Used to select the available listening modes.

TEST TONE, CH SEL, LEVEL-, and LEVEL+ buttons (46, 56)

Used to adjust the level of each speaker.

DISPLAY button (42)

Displays various information about the selected input source.

REMOTE MODE buttons (13)

Used to select the remote controller modes. When a remote controller button is pressed, the REMOTE MODE button for the currently selected mode lights up.

SLEEP button (46)

Used with the Sleep function.

VOL [ ]/[ ] button (41)

Adjusts the volume of the AV receiver regardless of the currently selected remote controller mode.

MUTING button (45)

Mutes or unmutes the AV receiver.

RETURN button

Selects the previously displayed setup menu.

CINE FLTR button (50)

Used with the CinemaFILTER function.

L NIGHT button (50)

Used with the Late Night function.

■

Buttons used when the TUNER input is selected

To select the Tuner (AM/FM) as the input source, press:

RECEIVER

Number, D TUN, and ENT buttons (44)

Used to select AM and FM radio stations directly.

CH +/– button (44)

Used to select radio presets.

Arrow [ ]/[ ] buttons

For AM and FM, the Up and Down [ ]/[ ] buttons are used for tuning.

■

Buttons used when the TAPE input is selected

To select your Cassette deck as the input source, press:

RECEIVER

Playback buttons

On twin cassette decks, only deck B can be controlled.

Play [ ] button

Starts playback.

Stop [ ] button

Stops playback.

Reverse Play [ ] button

Starts reverse playback.

Rewind and FF [ ]/[ ] buttons

The Rewind [ ] button starts rewind. The FF [] button starts fast forward.

TUNER

TAPE

Remote Controller

—Continued

DVD Mode

By default, the remote controller is set to control an Onkyo DVD player.

To select your DVD player as the input source, press:

DVD

REMOTE MODE

RECEIVER

TAPE/AMP

DVD

CLR

ENT

SLEEP

DISC

ALBUM

ENTER

MULTI CH

DVD

D/CDR

C D

DOCK

VCR

C DTAPE TUNER

CABLE

SAT

DVD

VOL

MUTING

RECEIVER

STANDBY/ON

INPUT SELECTOR

123

CBL/SAT

CR/DVR

456

AUX

MULTI CH

789

10 11 12

D TUN

--/---

DIMMER

VOL

INPUT

GUIDE

TOP MENU

SP A / B

PLAYLIST/CAT PLAYLIST/CAT

SETUP RETURN

LISTENING MODE

SURROUND

8 9

STEREO

RANDOM

SUBTITLE

AUDIO REPEAT

TEST TONE

CH SEL

PLAY MODE

DISPLAY

LEVEL

L NIGHT

LEVEL

CINE FLTR

HDDDVDVCR

N O

681M

STANDBY/ON button

Sets the DVD player to On or Standby.

Number buttons

Used to enter title, chapter, and track numbers and times for locating speciﬁc points.

DISC +/– button

Selects discs on a DVD changer.

TOP MENU button

Selects a DVD’s top menu.

Arrow [ ]/[ ]/[ ]/[ ] and ENTER buttons

Used to navigate DVD menus and the DVD player’s onscreen setup menus.

SETUP button

Used to access the DVD player’s onscreen setup menus.

Playback buttons

From left to right: Pause, Play, Stop, Fast Reverse, Fast Forward, Previous, and Next.

SUBTITLE button

Selects subtitles.

AUDIO button

Selects foreign language soundtracks and audio formats (e.g., Dolby Digital or DTS).

DISPLAY button

Displays information about the current disc, title, chapter, or track, including elapsed time, remaining time, total time, and so on.

CLR button

Cancels functions and clears entered numbers.

MENU button

Displays a DVD’s menu.

RETURN button

Exits the DVD player’s onscreen setup menus.

RANDOM button

Used with the random playback function.

REPEAT button

Used with the repeat playback functions.

VCR, DVD, and HDD buttons

Used to select VCR, HDD (hard disk drive), or DVD playback on a VCR/DVD recorder with a built-in hard disk drive.

PLAY MODE button

Selects play modes on components with selectable play modes.

Remote Controller

—Continued

CD/MD/CDR/DOCK Mode

By default, the remote controller is set to control an Onkyo CD player.

To select the input source, press:

C D

RECEIVER

TAPE

* If you’re using an MD, CDR, or the RI Dock, you must

change the Input Display (see page 40).

CD player

MD or CD recorder

RI Dock

CBL/SAT

In order to control an Onkyo MD recorder, CD recorder, or RI Dock, you must ﬁrst enter the appropriate remote control code (see page 60).

4 5

STANDBY/ON

INPUT SELECTOR

123

CR/DVR

456

AUX

789

10 11 12

D TUN

--/---

INPUT

GUIDE

TOP MENU

SP A / B

PLAYLIST/CAT PLAYLIST/CAT

SETUP RETURN

CBL/SAT

MULTI CH

DIMMER

VOL

TAPE/AMP

ENT

ENTER

RECEIVER

SLEEP

ALBUM

REMOTE MODE

DVD

D/CDR

C D

DOCK

DVD

VCR

C DTAPE TUNER

CABLE

SAT

CLR

DISC

VOL

MUTING

M D/CDR

C D

DOCK

LISTENING MODE

SURROUND

STEREO

RANDOM

SUBTITLE

AUDIO REPEAT

TEST TONE

CH SEL

PLAY MODE

DISPLAY

LEVEL

L NIGHT

LEVEL

CINE FLTR

HDDDVDVCR

K L

STANDBY/ON button

Sets the component to On or Standby.

Number buttons

Used to enter track numbers and times for locating speciﬁc points on CD/MD players.

DISC/ALBUM +/– button

Selects discs on a CD changer, or the next or previous album on an HDD-compatible component connected to an RI Dock.

TOP MENU button

Works as a Mode button when used with the DS-A2 RI Dock.

Arrow [ ]/[ ] and ENTER buttons

Used to navigate menus on an HDD-compatible component connected to the RI Dock.

Playback buttons

From left to right: Pause, Play, Stop, Fast Reverse, Fast Forward, Previous and Next.

DISPLAY button

Displays information about the current disc or track on a CD player or MD/CD recorder, including elapsed time, remaining time, total time, and so on. On an HDD-compatible component connected to the RI Dock, it turns on the back light for 30 seconds.

CLR button

Cancels functions and clears entered numbers on a CD player or MD/CD recorder.

MENU button

Used to navigate menus on an HDD-compatible component connected to the RI Dock.

PLAYLIST [ ]/[ ] buttons

Selects the previous or next playlist on an HDDcompatible component connected to the RI Dock.

RANDOM button

Used with the random/shufﬂe playback function.

REPEAT button

Used with the repeat playback functions.

PLAY MODE button

Used to select play modes on components with selectable play modes. Works as a Resume button when used with a DS-A2 RI Dock.

681M

Speakers

Subwoofer (SKW-540)

For detailed information, see the pages in parentheses.

■ Front

■ Rear

STANDBY/ON indicator

Red: Subwoofer in standby mode Green: Subwoofer on

With the Auto Standby function, the SKW-540 automatically turns on when an input signal is detected in Standby mode. When there’s no input signal for a while, the SKW-540 automatically enters Standby mode.

OUTPUT LEVEL control (41)

This control is used to adjust the volume of the subwoofer.

LINE INPUT (19)

This RCA input should be connected to the subwoofer pre out on the AV receiver with supplied RCA cable.

Note:

The Auto Standby function turns the subwoofer on when the input signal exceeds a certain level. If the Auto Standby function does not work reliably, try slightly increasing or decreasing the subwoofer output level on the AV receiver (page 56).

To AC outlet

Front, Center & Surround speakers (SKF-645F, SKC-645C, SKM-645S)

■ Rear

3 2

Keyhole slots

These keyhole slots can be used to wall-mount the speaker.

Speaker terminals

These push terminals are for connecting the speaker to your AV Receiver with the supplied speaker cables. The supplied speaker cables are color-coded for easy identiﬁcation. Simply connect each cable to the same-colored positive speaker terminal.

Speaker mount/bracket inserts

These threaded inserts can be used to attach the speaker either horizontally or vertically to a speaker mount or bracket.

Note:

Use commercially available 1/4" screws to attach the speaker to a speaker mount or bracket.

Connecting Your Speakers

Enjoying Home Theater

Thanks to the AV receiver’s superb capabilities, you can enjoy surround sound with a real sense of movement in your own home—just like being in a movie theater or concert hall. You can enjoy DVDs featuring DTS and Dolby Digital. With analog and digital TV, you can enjoy Dolby Pro Logic II and Onkyo’s own DSP surround listening modes.

Center speaker (SKC-645C)

This speaker enhances the front left and right speakers, making sound movements distinct and providing a full sound image. For movies it’s used mainly for dialog.

Position it close to your TV facing forward at about ear level, or at the same height as the front left and right speakers.

Subwoofer (SKW-540)

The subwoofer handles the bass sounds of the LFE (Low-Frequency Effects) channel. The volume and quality of the bass output from your subwoofer will depend on its position, the shape of your listening room, and your listening position. In general, a good bass sound can be obtained by installing the subwoofer in a front corner, or at one-third the way along the wall, as shown.

Tip: To ﬁnd the best position for your subwoofer, while playing a movie or some music with good bass, experiment by placing your subwoofer at various positions within the room, and choose the one that provides the most satisfying results.

Corner

Front left and right speakers (SKF-645F)

These output the overall sound. Their role in a home theater is to provide a solid anchor for the sound image. They should be positioned facing the listener at about ear level, and equally spaced from the TV. Angle them inward slightly so as to create a triangle, with the listener at the apex.

1/3 wall length

■ Using Rubber Spacers with the Speakers

We recommend using the supplied rubber spacers to achieve the best possible sound from your speakers. The rubber spacers prevent the speakers from moving, providing a more stable setup.

Surround left and right speakers (SKM-645S)

These speakers are used for precise sound positioning and to add realistic ambience.

Position them at the sides of the listener, or slightly behind, about 2–3 feet (60– 100 cm) above ear level. Ideally they should be equally spaced from the listener.

Rubber spacers

Bottom of the speaker

Connecting Your Speakers

—Continued

Speaker Connection Precautions

Read the following before connecting your speakers:

•You can connect speakers with an impedance of between 8 and 16 ohms. If you use speakers with a lower impedance, and use the ampliﬁer at high volume levels for a long period of time, the built-in amp protection circuit may be activated.

• Disconnect the power cord from the wall outlet before making any connections.

•Pay close attention to speaker wiring polarity. In other words, connect positive (+) terminals to only positive (+) terminals, and negative (–) terminals to only negative (–) terminals. If you get them the wrong way around, the sound will be out of phase and will sound unnatural.

• Unnecessarily long or very thin speaker cables may affect the sound quality and should be avoided.

• Be careful not to short the positive and negative wires. Doing so may damage the AV receiver.

• Don’t connect more than one cable to each speaker terminal. Doing so may damage the AV receiver.

• Don’t connect a speaker to several terminals.

Speaker terminal Color

Front left White

Front right Red

Center Green

Surround left Blue

Surround right Gray

On the AV receiver, unscrew the terminal. Fully

insert the bare wires. Make sure that the bare wire is touching the inside of the pole. Screw the terminal tight.

On the speakers, while pressing

the terminal lever, insert the wire into the hole, and then release the lever.

Using the supplied RCA cable, connect the AV

receiver’s SUBWOOFER PRE OUT to LINE INPUT on the subwoofer.

Make sure the cable is plugged all the way.

The following illustration shows which speaker should be connected to each pair of terminals.

Surround

right

speaker

Surround

left

speaker

Front right

speaker

Front left

speaker

Center

speaker

Using the Speaker Terminal Tool

The supplied speaker terminal tool makes it easy to tighten and loosen the speaker terminals. If you are using banana plugs, to ensure optimum sound quality, tighten the speaker terminal before inserting the banana plug.

Connecting Speakers

The AV receiver’s positive (+) speaker terminals and speaker’s positive (+) terminals are color-coded for ease of identiﬁcation. (The negative (–) speaker terminals are all black.) Match the color of each cable to the corresponding speaker terminal.

DIGITAL IN

ASSIGNABLE

COAXIAL

(DVD)

(CBL/SAT)

OPTICAL

(VCR/DVR)

CBL/SAT IN

(CD)

REMOTE CONTROL

SURROUND

SPEAKERS

HDMI

ASSIGNABLE

OUT

IN 1IN 2

B/PB

CR/PR

OUT

VCR/DVR IN

DVD IN

COMPONENT VIDEO

OUT

IN IN

TAPE

CBL/SAT

ANTENNA

OUT

INININ

OUT

VCR/DVR

FMAM75

DVD

IN IN

FRONT

PRE OUT

SIRIUS

MONITOR

OUT

SURROUND

CENTER

SUB

WOOFER

DVD

FRONT

SPEAKERS

SURROUND SPEAKERS

PRE OUT

SUB

WOOFER

Subwoofer

CENTER

SPEAKER

FRONT

CENTER

SPEAKERS

SPEAKER

Connecting Your Speakers

—Continued

Center Speaker Base

Use the center speaker base to mount the center speaker horizontally. If you place the speaker and its base on top of a TV or an entertainment center, adjust the angle of the speaker so that it faces toward the listening position.

The center speaker should be installed on the base securely. If the speaker is loose, try adjusting the position so that it sits securely on the base.

The cradle surface of the base features two stoppers to prevent the speaker from moving. Therefore, you can tilt the speaker toward the front by up to 15 degrees.

Base for horizontal mounting

■

Using the included rubber spacers

We recommend using the supplied rubber spacers to achieve the best possible sound from your speakers.

The rubber spacers prevent the speakers from moving, providing a more stable setup.

SKC-645C

Stoppers

Wall Mounting

The speakers can easily be wall mounted by using the keyhole slots. To prevent the speaker from vibrating against the wall, attach four of the supplied rubber spacers to the rear of each speaker.

■

Mounting vertically

To mount the speakers vertically, use the one keyhole slot shown to hang each speaker on the screw that is securely screwed into the wall.

Rubber spacer

Keyhole slot for wall mounting

■

Mounting horizontally

To mount the speakers horizontally, use the two keyhole slots shown to hang each speaker on two screws that are securely screwed into the wall.

Keyhole slot for wall mounting

Bottom of the base

Rubber spacer

Caution:

A mounting screw’s ability to support a speaker depends on how well it’s anchored to the wall. If you have hollow walls, screw each mounting screw into a stud. If there are no studs, or the walls are solid, use suitable wall anchors.

Use screws with a head diameter of 3/8" or less and a shank diameter of 1/8" or less. With hollow walls, use a cable/pipe detector to check for any power cables or water pipes before making any holes.

Leave a gap of between 1/4" and 5/16" between the wall and

Wall

the base of the screw head, as shown.

(We recommend that you consult a home installation professional.)

1/4" – 5/16"

Connecting Antennas

This section explains how to connect the supplied indoor FM antenna and AM loop antenna, and how to connect commercially available outdoor FM and AM antennas.

The AV receiver won’t pick up any radio signals without any antenna connected, so you must connect the antenna to use the tuner.

AM antenna push terminals FM antenna jack

OUT

ANTENNA

FMAM75

OUT

Connecting the Indoor FM Antenna

The supplied indoor FM antenna is for indoor use only.

Attach the FM antenna, as shown.

FM 75

Insert the plug fully into the jack.

Once your AV receiver is ready for use, you’ll need to tune into an FM radio station and adjust the position of the FM antenna to achieve the best possible reception.

Connecting the AM Loop Antenna

The supplied indoor AM loop antenna is for indoor use only.

Assemble the AM loop antenna, inserting

the tabs into the base, as shown.

Connect both wires of the AM loop

antenna to the AM push terminals, as shown.

(The antenna’s wires are not polarity sensitive, so they can be connected either way around).

Make sure that the wires are attached securely and that the push terminals are gripping the bare wires, not the insulation.

Push Insert wire Release

Use thumbtacks or something similar to

ﬁx the FM antenna into position.

Thumbtacks, etc.

Caution:

Be careful that you don’t injure yourself

when using thumbtacks.

If you cannot achieve good reception with the supplied indoor FM antenna, try a commercially available outdoor FM antenna instead (see page 22).

Once your AV receiver is ready for use, you’ll need to tune into an AM radio station and adjust the position of the AM antenna to achieve the best possible reception.

Keep the antenna as far away as possible from your AV receiver, TV, speaker cables, and power cords.

If you cannot achieve good reception with the supplied indoor AM loop antenna, try using it with a commercially available outdoor AM antenna (see page 22).

+ 47 hidden pages
