Onkyo HTP-L50 User Manual

Home Theater Speaker System

HTP-L50

Instruction Manual

English

Contents

Important Safeguards........................ 2

Precautions ....................................... 3

Supplied Accessories........................ 3

Feature .............................................. 4

Control positions and names ............ 4

Speaker placement............................ 5

Connecting the speakers ................... 6

Adjustment procedure ...................... 7

When using only the subwoofer

(SL-105)........................................ 7

Precaution on use.............................. 8

Troubleshooting guide...................... 8

Specifications ................................... 9

Thank you for purchasing the Onkyo home theater speaker
system.
Please read this manual thoroughly before using it.
Following the instructions in this manual will enable you to
obtain optimum performance and listening enjoyment from
your new home theater speaker system.
Please retain this manual for future reference.

1.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.

Important Safeguards

Read Instructions – All the safety and operating instructions

should be read before the appliance is operated.

2. Retain Instructions – The safety and operating instructions
should be retained for future reference.

3.

Heed Warnings

operating instructions should be adhered to.

4.

Follow Instructions

should be followed.

5.

Cleaning

cleaning. The appliance should be cleaned only as recom­mended by the manufacturer.

6.

Attachments

the appliance manufacturer as they may cause hazards.

7.

Water and Moisture

example, near a bath tub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a swimming pool; and the like.

8.

Accessories

stand, tripod, bracket, or table. The appliance may fall, causing
serious injury to a child or adult, and serious damage to the
appliance. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the appliance.
Any mounting of the appliance
should follow the manufac­turer’s instructions, and should
use a mounting accessory rec­ommended by the manufacturer.

9. An appliance and cart combina­tion should be moved with care.
Quick stops, excessive force,
and uneven surfaces may cause
the appliance and cart combina­tion to overturn.

10.

Ventilation

for ventilation and to ensure reliable operation of the appliance
and to protect it from overheating, and these openings must not
be blocked or covered. The openings should never be blocked
by placing the appliance on a bed, sofa, rug, or other similar
surface. The appliance should not be placed in a built-in instal­lation such as a bookcase or rack unless proper ventilation is
provided. There should be free space of at least 20 cm (8 in.)
and an opening behind the appliance.

11.

Power Sources

the type of power source indicated on the marking label. If you
are not sure of the type of power supply to your home, consult
your appliance dealer or local power company.

12.

Grounding or Polarization

with a polarized alternating current line plug (a plug having
one blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician
to replace your obsolete outlet. Do not defeat the safety pur­pose of the polarized plug.

2

– All warnings on the appliance and in the

– All operating and use instructions

– Unplug the appliance from the wall outlet before

– Do not use attachments not recommended by

– Do not use the appliance near water –for

– Do not place the appliance on an unstable cart,

PORTABLE CART WARNING

S3125A

– Slots and openings in the cabinet are provided

– The appliance should be operated only from

– The appliance may be equipped

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.

13.

Power-Cord Protection

routed so that they are not likely to be walked on or pinched by
items placed upon or against them, paying particular attention
to cords at plugs, convenience receptacles, and the point where
they exit from the appliance.

14.

Lightning

lightning storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet and discon­nect the antenna or cable system. This will prevent damage to
the appliance due to lightning and power-line surges.

15.

Overloading

or integral convenience receptacles as this can result in a risk of
fire or electric shock.

16.

Object and Liquid Entry

into the appliance through openings as they may touch danger­ous voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the appliance.

17.

Servicing

opening or removing covers may expose you to dangerous v olt­age or other hazards. Refer all servicing to qualified service
personnel.

18.

Damage Requiring Service

wall outlet and refer servicing to qualified service personnel
under the following conditions:
A. When the power-supply cord or plug is damaged,

B. If liquid has been spilled, or objects have fallen into the

C. If the appliance has been exposed to rain or water,
D. If the appliance does not operate normally by following the

E. If the appliance has been dropped or damaged in any way,

F. When the appliance exhibits a distinct change in perfor-

19.

Replacement Parts

sure the service technician has used replacement parts specified
by the manufacturer or have the same characteristics as the
original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.

20.

Safety Check

appliance, ask the service technician to perform safety checks to
determine that the appliance is in proper operation condition.

21.

Wall or Ceiling Mounting

to a wall or ceiling only as recommended by the manufacturer.

22.

Heat

sources such as radiators, heat registers, stoves, or other appli­ances (including amplifiers) that produce heat.

23.

Liquid Hazards

dripping or splashing and no objects filled with liquids, such as
vases should be placed on the appliance.

– For added protection for the appliance during a

– Do not overload wall outlets, extension cords,

– Do not attempt to service the appliance yourself as

appliance,

operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the appliance to its normal operation,

and

mance – this indicates a need for service.

– Upon completion of any service or repairs to the

– The appliance should be situated away from heat

– Power-supply cords should be

– Never push objects of any kind

– When replacement parts are required, be

– The appliance should be mounted

– The appliance should not be exposed to

AVIS

RISQUE DE CHOC ELECTRIQUE

– Unplug the appliance form the

OUVRIR

NE PAS

Precautions

1. Recording Copyright

Recording of copyrighted material for other than personal use is
illegal without permission of the copyright holder.

2. AC Fuse

The fuse is located inside the chassis and is not user-serviceable. If
power does not come on, contact your Onkyo authorized service station.

3. Care

From time to time you should wipe the front and rear panels and the
cabinet with a soft cloth. For heavier dirt, dampen a soft cloth in a
weak solution of mild detergent and water, wring it out dry, and
wipe off the dirt. Following this, dry immediately with a clean cloth.
Do not use rough material, thinners, alcohol or other chemical sol­vents or cloths since these could damage the finish or remove the
panel lettering.

4. Power

WARNING

BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME,
READ THE FOLLOWING SECTION CAREFULLY.

The voltage of the available power supply differs according to
country or region. Be sure that the power supply voltage of the area
where this unit will be used meets the required voltage (e.g., AC
230 V, 50 Hz or AC 120 V, 60 Hz) written on the rear panel.

For Canadian model

For models having a power cord with a polarized plug:

CAUTION:

WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

Modèle pour les Canadien

Sur les modèles dont la fiche est polarisée:

ATTENTION:

TRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA
FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE
ET POUSSER JUSQU’AU FOND.

TO PREVENT ELECTRIC SHOCK, MATCH

POUR ÉVITER LES CHOCS ÉLEC-

For European model

Declaration of Conformity

We,

ONKYO EUROPE
ELECTRONICS GmbH
LIEGNITZERSTRASSE 6,
82194 GROEBENZELL,
GERMANY

declare in own responsibility, that the ONKYO product described
in this instruction manual is in compliance with the corresponding
technical standards such as EN60065, EN55013, EN55020 and
EN61000-3-2, -3-3.

GERMERING, GERMANY

I. MORI

ONKYO EUROPE ELECTRONICS GmbH

For British model

Replacement and mounting of an AC plug on the power supply cord
of this unit should be performed only by qualified service personnel.

IMPORTANT

The wires in the mains lead are coloured in accordance with the
following code:

Blue : Neutral
Brown : Live

As the colours of the wires in the mains lead of this apparatus may
not correspond with the coloured markings identifying the termi­nals in your plug, proceed as follows:
The wire which is coloured blue must be connected to the terminal
which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the termi­nal which is marked with the letter L or coloured red.

IMPORTANT

A 5 ampere fuse is fitted in this plug. Should the fuse need to be
replaced, please ensure that the replacement fuse has a rating of 5
amperes and that it is approved by ASTA or BSI to BS1362. Check
for the ASTA mark or the BSI mark on the body of the fuse.
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE
SOCKET OUTLET IN YOUR HOME THEN THE FUSE
SHOULD BE REMOVED AND THE PLUG CUT OFF AND DIS­POSED OF SAFELY. THERE IS A DANGER OF SEVERE
ELECTRICAL SHOCK IF THE CUT OFF PLUG IS INSERTED
INTO ANY 13 AMPERE SOCKET.
If in any doubt, please consult a qualified electrician.

Supplied Accessories

Make sure your box contains everything listed below. The number of accessories is indicated in brackets.

• Subwoofer (SL-105) [1] • Satelite speakers (D-L1) [5] • Spacers for subwoofer [4] • Spacers for satelite speakers [20]

• Speaker cable for L/R front and
center speakers, 3.5 m [3]

(Red) (White) (Green) (Blue) (Gray)

speakers, 8 m [2]

• Pin cord [1]• Speaker cable for surround

3

Feature

The HTP-L50 is a 5.1-channel speaker package that consists
of five satellite speakers and one subwoofer with an internal
amplifier.

The HTP-L50 features the SL-105 subwoofer with L/R
mixing circuits and a built-in cut-off filter as the subwoofer
and the D-L1 speakers with MDF (Medium Density

Fiberboard) cabinet and OMF-cone as the five satellite
speakers. Simply connect the speakers to your AV amplifier
or receiver for superb surround audio playback.

The speaker cables and satellite speaker terminals are color­coded to facilitate connection. Connect each cable to the
matching-colored terminal.

Control positions and names

■ Subwoofer SL-105

Front panel

SL-105

23

POWERED SUBWOOFER

OUTPUT

Hz

LEVEL

MIN MAX

POWER

FREQUENCY

50

Hz

200

1

Rear panel

SL-105

INPUT

FROM

AMP/RECEIVER

OUTPUT

TO SPEAKERS

To AC outlet

SPEAKER LEVEL

_

R

+

_

R

+

C

LINE

_

_

INPUT

L

+

L

(MONO)

R

L

+

DAB

AUTO STANDBY

OFF ON

4

1 POWER switch and indicator

Pressing this button turns the power on (the indicator
lights). Pressing the button again turns the power off (the
indicator goes out).

Red: Unit is in standby mode
Green: Unit is in operation

2 FREQUENCY knob

Use this knob to select the high-frequency range at which
you wish to cut off the signal to the subwoofer. You can
select any frequency between 50 Hz and 200 Hz depending
on the characteristics of the speaker system being used with
the SL-105.

3 OUTPUT LEVEL knob

Use this knob to adjust the output level of the subwoofer.

ALINE INPUT jacks

Connect these jacks to the LINE OUT jacks of the
amplifier etc.

B AUTO STANDBY switch

This switch is used to turn on and off the auto standby
function.

ON: This activates the auto standby function.

If a constant level signal is not received from the amplifier
(or receiver) over a period of a few minutes, the SL-105
automatically enters the standby state. If a constant level
signal is later received from the amplifier (or receiver), the
power is automatically turned back on.

OFF: Deactivates the auto standby function.

Notes:

• The auto standby function operates on the existence or
absence of a constant level input signal. If the auto
standby function does not operate properly, try slightly
increasing (or decreasing) the output level of the
amplifier or receiver.
(Note that output levels of some amplifiers and receivers
cannot be adjusted. For more details regarding your
components, refer to the instruction manual supplied
with them.)

• If noise from peripheral components causes the incorrect
operation of the auto standby function, or if outputting
low volumes (i.e., during the nighttime) causes the auto
standby function to activate, turn off the auto standby
function.

• The auto standby function only operates while the power
switch for the SL-105 is turned on.

C SPEAKER LEVEL INPUT terminals

Connect these input terminals to the speaker output
terminals of your amplifier or receiver.

D SPEAKER LEVEL OUTPUT terminals

The speaker-level signal to the front speakers is output
from these terminals.

Speaker placement

■ Layout of your speaker system

Satellite speakers

• Front left/right speakers and center speakers

These three speakers should be placed in front of the
listener.

All three speakers should be placed at the same level.
Placement should be such so that the speakers all aim at the

ears of the listener when the listener is listening to music or
watching the screen. The center speakers enhance the sound
effects from the two front speakers and add clarity to
movements in the sound for a much richer sound image.

• Surround left/right speakers

Surround speakers should be placed to the side of the
listener or behind the listener. These speakers produce
sound movements in all directions, create a sound
environment that reflects the background, and create the
sensation of being in the middle of the action.

Subwoofer

The subwoofer can be installed anywhere in the room, but in
most situations you will obtain the best results by placing the
subwoofer to the side near a corner of the room. The quality
and level of the bass sounds from the subwoofer will differ
depending on the location where the subwoofer is placed and
the layout of the room, so it is recommended to place the
subwoofer in several locations and find the position that
provides the best results.

■ Satellite speaker

Installation using commercially-available stands and
fixtures

The speaker bottom and rear are equipped with screw holes so
that you can attach commercially-available stands or
mounting fixtures for a variety of mounting options. (Two M5
screw holes, 60 mm pitch on the bottom and one M5 screw
hole on the rear.)

Note:

When attaching an accessory item
to a speaker, be careful of the
length of the screws used. Use
only screws that provide the
required strength with a screw
length between 7 and 12 mm.

M5 screw

5 mm

7 to 12 mm

■ Using spacers

Attaching the supplied spacers is recommended for obtaining
the best sound quality. Also, by attaching the provided
spacers, the speakers will not slide easily for a more stable
installation.

• Positioning vertically

Spacer

Front left
speaker
D-L1

Surround

left speaker

D-L1

TV or

Screen

Listener

Center
speaker
D-L1

Subwoofer
SL-105

Front right
speaker
D-L1

Surround

right speaker

D-L1

Bottom
of D-L1

• Positioning horizontally

Spacer

Side
of D-L1

5

Connecting the speakers

For safety reasons, do not turn on any devices or components
until you have completed all wiring procedures.

■ Connecting the satellite speakers

Note:

The nominal impedance of this speaker system is 6 Ω. Use
only amplifiers capable of handling this impedance.

SURROUND
SPEAKERS

R

Center

speaker

(GRN) (WHT)

Green

FRONT SPEAKERS

CENTER

L

R

L

Front left

speaker

-

MODEL D

L1MODEL D-L1

White

Surround left

speaker

Front right

speaker

-

MODEL D

L1

(RED)

Red

Surround right

speaker

-

MODEL D

L1 MODEL D-L1

(GRY) (BLU)

• Connect the input terminals on the rear of the satellite
speakers to the speaker output terminals on the AV
amplifier or receiver using the supplied speaker cables as
shown in the diagram to the left.

• Each speaker cable should be connected to the speaker
terminal of the same color.
The speaker’s terminals are colored as follows.

Front left speaker (+) : white
Front right speaker (+) : red
Center speaker (+) : green
Surround left speaker (+) : blue
Surround right speaker (+): gray

Notes:

• Make sure that the positive (+)
and negative (–) speaker cables
do not contact each other. If they
do, a short-circuit may occur,
causing damage to the amplifier.

• Be sure to connect the speaker cables with the correct
polarity (+ and –) and with the proper left-right speaker
orientation. If connected incorrectly, the resulting sound
space with sound unnatural.

• Pull the speaker cable lightly to ensure that it is connected
firmly.

Gray

AUDIO

PREOUT

SUB
WOOFER

DIGITAL

OPTICAL

OUT

OUT

IN IN

MD/CDR/TAPE

TV/LINE

S VIDEO VIDEO COMPONENT

IN

L

REMOTE

ANTENNA

CONTROL

R

VIDEO OUTPUT

YP

AM

BPR

SURROUND

ANTENNA

FM

75

FRONT SPEAKERS

SPEAKERS

L

R

AC INLET

CENTER

L

R

Before connecting

Prepare the supplied speaker cables as shown below.

Strip off the end of the
speaker cable insulation.

Twist together the exposed
wires strands.

Connecting to the speaker terminals

Blue

■ Connecting the subwoofer

When used together with an AV amplifier or receiver with
surround playback capabilities, be sure to connect its SUB
WOOFER PREOUT terminal to the subwoofer SL-105 using
the supplied pin-cord.
If you connect the subwoofer SL-105 using speaker cables,
depending on the settings at the AV amplifier or receiver, bass
signals may be cut for an unsatisfactory bass output. For more
details regarding connection procedures, refer to the manuals
that came with your AV amplifier or receiver.

PREOUT

AUDIO

SUB
WOOFER

AUDIO

INPUT

FROM

AMP/RECEIVER

OUTPUT

TO SPEAKERS

DIGITAL

OPTICAL

OUT

IN IN

TV/LINE

IN

PREOUT

SUB
WOOFER

L

REMOTE
CONTROL

R

OUT

MD/CDR/TAPE

VIDEO OUTPUT

YP

BPR

S VIDEO VIDEO COMPONENT

SPEAKER LEVEL

_

R

+

_

R+

ANTENNA

AM

_

L +

_

L +

SURROUND

ANTENNA

FM

75

FRONT SPEAKERS

SPEAKERS

R

L

R

(Supplied pin-cord)

LINE

AUTO STANDBY

INPUT

L

(MONO)

OFF ON

R

AC INLET

CENTER

L

6

Push down the lever. Insert the

exposed wires
into the hole.

Connect the SUB WOOFER PREOUT terminal on your AV
amplifier or receiver to the subwoofer rear panel using the
supplied pin-cord as shown in the diagram above.

Release the lever.

Note:

If the amplifier has a subwoofer terminal, since its output is
monaural, connect it to the low level LINE INPUT L(MONO)
terminal on the subwoofer SL-105.

Adjustment procedure

■ Adjusting the cut-off frequency and volume

Use the cut-off frequency (FREQUENCY) and volume
(OUTPUT LEVEL) knobs on the front of the subwoofer (SL-

105) and adjust the levels to the desired level in accordance
with the layout of your room and the positioning of all your
components. If the playback frequency range and volume of
the subwoofer are not set to proper levels, distortions in the
playback characteristics can result.

Although it is recommended to set the cut-off frequency and
output level settings as high as possible, it is difficult to notice
the extremely low frequency bass sounds. This makes it
possible to accidentally set the volume level too high. In order
to prevent this, back the levels down just a bit to ensure the
proper balance.

Note:

Make sure that the input levels do not reach excessive levels.
The HTP-L50 is designed for playing back music at a normal

POWERED SUBWOOFER

FREQUENCY

OUTPUT

LEVEL

volume, but if the input levels are set to enormous levels, it
may damage the speakers. Also, always first lower the volume
at the amplifier before changing the settings of any switches
to prevent accidental damage.

50Hz

200Hz

MIN MAX

Recommended level for the HTP-L50 package system

When using only the subw oof er (SL-105)

■ Connection with a preamplifier

Preamplifier

Output terminals

L

R

To power amplifier

(Not supplied)

■ Connection to amplifier’s (receiver’s) speaker

terminals

1. Using speaker cables and the speaker cables that came
with your speakers, connect the SL-105’s SPEAKER
LEVEL INPUT terminals and the amplifier’s speaker
terminals.

2. Connect the Right and Left speakers to the SL-105’s
SPEAKER LEVEL OUTPUT terminals.

LINE

AUTO STANDBY

INPUT

L +

L

(MONO)

OFF ON

R

L +

INPUT

AMP/RECEIVER

OUTPUT

TO SPEAKERS

FROM

SPEAKER LEVEL

_

R

+

_

R+

_

_

SL-105

Note:

With an ordinary preamplifier having two output channels,
connect both the Right and Left jacks.

Speaker (R) Speaker (L)

(Receiver)

Speaker terminals

_

_

R

+

L

+

SPEAKER LEVEL

_

_

R

+

L

INPUT

AMP/RECEIVER

OUTPUT

TO SPEAKERS

FROM

+

+

_

_

R

L

+

LINE

AUTO STANDBY

INPUT

L

(MONO)

OFF ON

R

SL-105

For details on how to connect the speaker cables, see the
previous page.

Notes:

•When connecting the speaker cables, be sure not to mistake
the (+) and (–) and the L (left) and R (left). If the speaker
cables are connecting incorrectly, there will be a loss of
fidelity in the bass sound ranges.

• The speakers connected to the SL-105 SPEAKER LEVEL
OUTPUT terminals must have an impedance equal to or
greater than the rating indicated on the amplifier connected
to the SPEAKER LEVEL INPUT terminals. Otherwise,
amplifier damage may occur.

• Do not use BTL (Balanced Transformer-Less) type
amplifiers. Using a BTL amplifier may cause damage to
both the amplifier and the subwoofer. Ordinary amplifiers
are not BTL amplifiers. For details, see the amplifier’s
instruction manual.

Amplifier

7

Precaution on use

■ Placement

• The enclosure is made of wood and therefore sensitive to
extreme temperatures and humidity. Avoid placing the unit
in locations subjected to direct sunlight or in humid places
such as near an air conditioner, bathroom or kitchen, as
well as in locations subjected to soot or steam such as near
a kitchen table and humidifier. Otherwise, damage may
occur.

• Keep water or other liquids away from the unit. If water is
spilled into the unit, not only the unit but also the
connected amplifier (receiver) may be damaged.

•Place the unit on a level and rigid surface free from
vibration.

• Slip-proof spacers are provided with the SL-105. If the SL­105 is to be placed on flooring or other similar surfaces,
attach these spacers to the bottom surface at the corners.
This will not only prevent scratching, but also provide a
stable footing. However, note that depending on the
surface, the spacers may leave markings.

• This unit is designed to be used in the upright vertical
position only. Do not use it in the horizontal or tilted
position.

• If the unit is used near a turntable or CD player, howling or
skipping of sound may occur. To prevent this, move the
unit away from the turntable or CD player or otherwise
lower the unit’s output level.

• This unit can handle the specified input power when it is
used for ordinary music reproduction. If the following
abnormal signals are fed to the unit, however, an
overcurrent may flow in the internal circuits, causing
burning or breakage of the wires even if the input power is
below the specified rating.

1. Special test signals produced by audio checking CD, etc.

2. Sound produced when connecting or disconnecting

audio connection cables.
(Always turn off the amplifier’s power before
connecting or disconnecting cables.)

3. Howling when a microphone is used.

4. Abnormal sound produced when bass-range signals are

excessively boosted by using the amplifier’s (receiver’s)
tone controls, a graphic equalizer, etc., or when a source
whose bass range is abnormally boosted is being played.
This state called “rattling” occurs when the signal is
beyond the driver’s reproduction capacity. Although it is
not a sign of damage, decrease the speaker output level
to prevent damage to the driver.

Troubleshooting guide

■ Subwoofer SL-105

Symptom

The unit does not turn on.

No sound output

Small sound output

Hum noise

• The power plug is not fully inserted.

• The OUTPUT LEVEL knob is set to the
MIN level.

• Pin-connector cable(s) are disconnected
at the LINE INPUT jacks.

• Speaker cables are not properly con­nected to the SPEAKER LEVEL INPUT
terminals.

• The speaker setting at the amplifier (or
receiver) is set to “Subwoofer No.”

• The input signal is so small that the unit
entered the standby state.

• Speaker cables are connected to the
SPEAKER LEVEL INPUT terminals
with reversed phase.

• Playing source does not include
superbass sound.

•Pin-connector cable is not inserted
completely.

• External leakage flux (induction noise
by TV etc.) occurs.

Cause

Remedy

• Insert the power plug fully into the power
outlet.

• Set the OUTPUT LEVEL knob properly.

• Connect cable(s) to the LINE INPUT jacks.

• Connect the speaker cables properly.

• Check the settings at the amplifier (or receiver).

• Slightly increase the output level at the ampli­fier (or receiver).

• Set the AUTO STANDBY switch to OFF.

• Connect the speaker cables properly.

• Play sources with superbass sound.

• Fully insert the pin-connector cable.

• Separate from the noise source and connect.

8

■ Satellite speaker D-L1

Symptom

No sound output

Cause

• Speaker cables are not properly con­nected.

Remedy

• Connect the speaker cables properly.

Specifications

■ Subwoofer SL-105

Type Bass-reflex with built-in power

amplifier
Use For superbass-range reproduction
Frequency response 30-200 Hz (at maximum cross-

over frequency)
Crossover frequency 50-200 Hz (variable)
Maximum output power 60 W
Input impedance 4.7 kΩ (for speaker-level input

terminals)

12 kΩ (for low-level input jacks)

Sensitivity Speaker-Level 2 V

Line 45 mV
Speaker 20-cm woofer
Power supply AC 120 V, 60 Hz

AC 220 - 230 V, 50/60 Hz

AC 230 - 240 V, 50 Hz
Power consumption 70 W (AC 120 V, 60 Hz)

42 W (AC 220 - 230 V, 50/60 Hz,

AC 230 - 240 V, 50 Hz)

Dimensions (W × H × D) 235 × 416 × 404 mm

Weight 12.5 kg 27.6 lbs.
Others AUTO STANDBY ON/OFF

1

/4" × 16-3/8" × 15-7/8"

9-

(with CANCELLING Switch)

■ Satellite speaker D-L1

Type Air suspension
Frequency response 125 Hz - 25 kHz
Maximum input power 30 W
Output sound pressure level 83 dB/W/m
Impedance 6 Ω
Speaker 8-cm OMF cone
Cabinet capacity 0.6 L
Dimensions (W × H × D) 85 × 120 × 112 mm

Weight 0.7 kg 1.5 lbs.
Others Magnetic shielding

Specifications and appearance may subject to change for improvement
without prior notice.

3

3-

/8" × 4-3/4" × 4-7/

16

9
