DVD Player
DV-SP404
DV-SP404E
Contents
Overview ..............................................2
Connections ......................................17
Instruction Manual
Thank you for purchasing an Onkyo DVD
Player. Read this manual carefully before using
your new DVD Player. A good understanding of
its features and operation will allow you to
achieve optimum performance and enjoyment.
Keep this manual for future reference.
Getting Started and Setting up ........24
Basic Playback ..................................26
Playback Techniques ........................30
Detailed Settings ...............................40
Miscellaneous Information...............49
En
DV-SP404.404E_En.book Page 2 Wednesday, June 7, 2006 1:50 PM
1.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
RISQUE DE CHOC ELECTRIQUE
NE PAS
Important Safety Instructions
Read Instructions – All the safety and operating
instructions should be read before the appliance is
operated.
2. Retain Instructions – The safety and operating
instructions should be retained for future reference.
3. Heed Warnings – All warnings on the appliance
and in the operating instructions should be adhered
to.
4. Follow Instructions – All operating and use
instructions should be followed.
5. Cleaning —Unplug the appliance from the wall outlet before cleaning. The appliance should be cleaned
only as recommended by the manufacturer.
6. Attachments —Do not use attachments not recommended by the appliance manufacturer as they may
cause hazards.
7. Water and Moisture —Do not use the appliance
near water –for example, near a bath tub, wash bowl,
kitchen sink, or laundry tub; in a wet basement; or
near a swimming pool; and the like.
8. Accessories —Do not place the appliance on an
unstable cart, stand, tripod, bracket, or table. The
appliance may fall, causing serious injury to a child
or adult, and serious damage to the appliance. Use
only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the
appliance. Any mounting of the appliance should
follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the manufacturer.
9. An appliance and cart combination should be moved with
care. Quick stops, excessive
force, and uneven surfaces
may cause the appliance and
cart combination to overturn.
10. Ventilation —Slots and openings in the cabinet are
provided for ventilation and to ensure reliable operation of the appliance and to protect it from overheating, and these openings must not be blocked or
covered. The openings should never be blocked by
placing the appliance on a bed, sofa, rug, or other
similar surface. The appliance should not be placed
in a built-in installation such as a bookcase or rack
PORTABLE CART WARNING
S3125A
unless proper ventilation is provided. There should
be free space of at least 5 cm (2 in.) and an opening
behind the appliance.
11. Power Sources —The appliance should be operated
only from the type of power source indicated on the
marking label. If you are not sure of the type of
power supply to your home, consult your appliance
dealer or local power company.
12. Grounding or Polarization —The appliance may
be equipped with a polarized alternating current line
plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way.
This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the
plug should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
13. Power Cord Protection —Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where
they exit from the appliance.
14. Lightning —For added protection for the appliance
during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the appliance
due to lightning and power-line surges.
15. Overloading —Do not overload wall outlets, extension cords, or integral convenience receptacles as
this can result in a risk of fire or electric shock.
16. Object and Liquid Entry —Never push objects of
any kind into the appliance through openings as they
may touch dangerous voltage points or short-out
parts that could result in a fire or electric shock.
Never spill liquid of any kind on the appliance.
17. Servicing —Do not attempt to service the appliance
yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
18. Damage Requiring Service —Unplug the appliance
form the wall outlet and refer servicing to qualified
service personnel under the following conditions:
AVIS
OUVRIR
2
DV-SP404.404E_En.book Page 3 Wednesday, June 7, 2006 1:50 PM
Important Safety Instructions —Continued
A. When the power-supply cord or plug is damaged,
B. If liquid has been spilled, or objects have fallen
into the appliance,
C. If the appliance has been exposed to rain or water,
D. If the appliance does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the appliance to its normal operation,
E. If the appliance has been dropped or damaged in
any way, and
F. When the appliance exhibits a distinct change in
performance – this indicates a need for service.
19. Replacement Parts —When replacement parts are
required, be sure the service technician has used
replacement parts specified by the manufacturer or
Precautions
1. Recording Copyright —Unless it’s for personal use
only, recording copyrighted material is illegal without the permission of the copyright holder.
2. AC Fuse —The AC fuse inside the unit is not user-
serviceable. If you cannot turn on the unit, contact
your Onkyo dealer.
3. Care —Occasionally you should dust the unit all
over with a soft cloth. For stubborn stains, use a soft
cloth dampened with a weak solution of mild detergent and water. Dry the unit immediately afterwards
with a clean cloth. Don’t use abrasive cloths, thinners, alcohol, or other chemical solvents, because
they may damage the finish or remove the panel lettering.
4. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE
FIRST TIME, READ THE FOLLOWING SECTION CAREFULLY.
AC outlet voltages vary from country to country.
Make sure that the voltage in your area meets the
voltage requirements printed on the unit’s rear panel
(e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz).
The power cord plug is used to disconnect this unit
from the AC power source. Make sure that the plug
is readily operable (easily accessible) at all times.
Pressing the [STANDBY/ON] button to select
Standby mode does not fully shutdown the unit. If
you do not intend to use the unit for an extended
period, remove the power cord from the AC outlet.
5. Never Touch this Unit with Wet Hands —Never
handle this unit or its power cord while your hands
are wet or damp. If water or any other liquid gets
inside this unit, have it checked by your Onkyo
dealer.
have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
20. Safety Check —Upon completion of any service or
repairs to the appliance, ask the service technician to
perform safety checks to determine that the appliance is in proper operation condition.
21. Wall or Ceiling Mounting —The appliance should
be mounted to a wall or ceiling only as recommended by the manufacturer.
22. Heat —The appliance should be situated away from
heat sources such as radiators, heat registers, stoves,
or other appliances (including amplifiers) that produce heat.
23. Liquid Hazards —The appliance should not be
exposed to dripping or splashing and no objects
filled with liquids, such as vases should be placed on
the appliance.
6. Handling Notes
• If you need to transport this unit, use the original
packaging to pack it how it was when you originally bought it.
• Do not leave rubber or plastic items on this unit
for a long time, because they may leave marks on
the case.
• This unit’s top and rear panels may get warm
after prolonged use. This is normal.
• If you do not use this unit for a long time, it may
not work properly the next time you turn it on, so
be sure to use it occasionally.
• When you’ve finished using this unit, remove all
discs and turn off the power.
7. Installing this Unit
• Install this unit in a well-ventilated location.
• Ensure that there’s adequate ventilation all
around this unit, especially if it’s installed in an
audio rack. If the ventilation is inadequate, the
unit may overheat, leading to malfunction.
• Do not expose this unit to direct sunlight or heat
sources, because its internal temperature may
rise, shortening the life of the optical pickup.
•Avoid damp and dusty places, and places subject
to vibrations from loudspeakers. Never put the
unit on top of, or directly above a loudspeaker.
• Install this unit horizontally. Never use it on its
side or on a sloping surface, because it may cause
a malfunction.
• If you install this unit near a TV, radio, or VCR,
the picture and sound quality may be affected. If
this occurs, move this unit away from the TV,
radio, or VCR.
3
DV-SP404.404E_En.book Page 4 Wednesday, June 7, 2006 1:50 PM
Precautions —Continued
8. To Obtain a Clear Picture —This unit is a high-
tech, precision device. If the lens on the optical
pickup, or the disc drive mechanism becomes dirty
or worn, the picture quality may be affected. To
maintain the best picture quality, we recommend
regular inspection and maintenance (cleaning or
worn part replacement) every 1,000 hours of use
depending on the operating environment. Contact
your Onkyo dealer for details.
9. Moisture Condensation
Moisture condensation may damage this unit.
Read the following carefully:
Moisture may condense on the lens of the optical
pickup, one of the most important parts inside this
unit.
• Moisture condensation can occur in the following
situations:
– The unit is moved from a cold place to a warm
place.
–A heater is turned on, or cold air from an air
conditioner is hitting the unit.
– In the summer, when this unit is moved from
an air conditioned room to a hot and humid
place.
– The unit is used in a humid place.
• Do not use this unit when there’s the possibility
of moisture condensation occurring. Doing so
may damage your discs and certain parts inside
this unit.
If condensation does occur, remove all discs and
leave this unit turned on for two to three hours. By
this time, the unit will have warmed up and any condensation will have evaporated.
10. Region Numbers —The DVD standard uses region
numbers to control how discs can be played around
the world, the world being divided into six regions.
This unit will only play DVD discs that match its
region number, which can be found on its rear panel
ALL
1
(e.g., , ).
11. About this Manual —This manual explains how to
use all of this unit’s functions. Although the DVD
standard offers many special features, not all discs
use them all, so depending on the disc being played,
this unit may not respond to certain functions. See
the disc’s sleeve notes for supported features.
This unit contains a semiconductor laser system and is
classified as a “CLASS 1 LASER PRODUCT”. So, to
use this model properly, read this Instruction Manual
carefully. In case of any trouble, please contact the store
where you purchased the unit.
To prevent being exposed to the laser beam, do not try
to open the enclosure.
DANGER:
VISIBLE AND/OR INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCK FAILED OR
DEFEATED. DO NOT STARE INTO BEAM.
CAUTION:
THIS PRODUCT UTILIZES A LASER. USE OF
CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
The label on the right is
applied on the rear panel.
1. This unit is a CLASS 1
LASER PRODUCT and
employs a laser inside the cabinet.
2. To prevent the laser from being exposed, do not remove the
cover. Refer servicing to qualified personnel.
WARNING
To prevent a fire hazard, do not place any naked
flame sources (such as a lighted candle) on the equipment.
When disposing of used batteries, please comply
with governmental regulations or environmental
public instruction’s rules that apply in your country/area.
4
DV-SP404.404E_En.book Page 5 Wednesday, June 7, 2006 1:50 PM
Precautions —Continued
For U.S. models
FCC Information for User
CAUTION:
The user changes or modifications not expressly
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
For British models
Replacement and mounting of an AC plug on the power
supply cord of this unit should be performed only by
qualified service personnel.
IMPORTANT
The wires in the mains lead are coloured in accordance
with the following code:
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead of this
apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as
follows:
The wire which is coloured blue must be connected to
the terminal which is marked with the letter N or
coloured black.
The wire which is coloured brown must be connected to
the terminal which is marked with the letter L or
coloured red.
IMPORTANT
The plug is fitted with an appropriate fuse. If the fuse
needs to be replaced, the replacement fuse must
approved by ASTA or BSI to BS1362 and have the
same ampere rating as that indicated on the plug. Check
for the ASTA mark or the BSI mark on the body of the
fuse.
If the power cord’s plug is not suitable for your socket
outlets, cut it off and fit a suitable plug. Fit a suitable
fuse in the plug.
For Canadian Models
NOTE:
COMPLIES WITH CANADIAN ICES-003.
For models having a power cord with a polarized plug:
CAUTION:
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
THIS CLASS B DIGITAL APPARATUS
TO PREVENT ELECTRIC SHOCK,
Modèle pour les Canadien
REMARQUE:
LA CLASSE B EST CONFORME À LA NORME
NMB-003 DU CANADA.
Sur les modèles dont la fiche est polarisée:
ATTENTION:
TRIQUES, INTRODUIRE LA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQU’AU FOND.
CET APPAREIL NUMÉRIQUE DE
POUR ÉVITER LES CHOCS ÉLEC-
For European Models
Declaration of Conformity
We,
ONKYO EUROPE
ELECTRONICS GmbH
LIEGNITZERSTRASSE 6,
82194 GROEBENZELL,
GERMANY
declare in own responsibility, that the ONKYO product
described in this instruction manual is in compliance with the
corresponding technical standards such as EN60065,
EN55013, EN55020 and EN61000-3-2, -3-3.
GROEBENZELL, GERMANY
K. MIYAGI
ONKYO EUROPE ELECTRONICS GmbH
5
DV-SP404.404E_En.book Page 6 Wednesday, June 7, 2006 1:50 PM
Table of Contents
Basic Operation
Overview
Important Safety Instructions.............................. 2
Precautions ........................................................ 3
Introduction......................................................... 7
Supplied Accessories ..................................... 7
Features ......................................................... 7
Disc Notes ...................................................... 8
Before Using the DV-SP404/DV-SP404E ........ 11
Installing the Batteries .................................. 11
Using the Remote Controller ........................ 11
Front & Rear Panels......................................... 12
Front Panel ................................................... 12
Display.......................................................... 13
Rear Panel.................................................... 14
Remote Controller ........................................ 15
Connections
Connecting the DV-SP404/DV-SP404E........... 17
Before Making Any Connections .................. 17
AV Cables & Connectors.............................. 17
Basic Setup .................................................. 18
Connecting Your TV ..................................... 20
Connecting to an AV Receiver ..................... 22
Connecting the Power/Turning on the
DV-SP404/DV-SP404E.............................. 23
Getting Started and Setting up
Getting Started ................................................. 24
Using the on-screen displays ....................... 24
Setting up the player for your TV.................. 24
Setting the language of this player’s
on-screen displays ..................................... 25
Basic Playback
Playing discs................................................. 26
Basic playback controls ................................ 27
Resume and Last Memory ........................... 27
DVD-Video disc menus ................................ 28
Video CD PBC menus .................................. 28
Advanced Operation
Playback Techniques
Playing discs .....................................................30
Scanning discs..............................................30
Playing in slow motion................................... 30
Frame advance/frame reverse......................31
Viewing a JPEG slideshow ...........................31
Browsing video content with the Disc Navigator
Browsing WMA, MP3, DivX Video and
JPEG files with the Disc Navigator ............. 33
Looping a section of a disc............................ 34
Using repeat play .......................................... 34
Using random play ........................................ 35
Creating a program list.................................. 36
Other functions available from the program menu
Searching a disc............................................ 37
Switching subtitles......................................... 38
Switching audio language/channel................ 38
Zooming the screen ......................................39
Switching camera angles .............................. 39
Displaying disc information ...........................39
Detailed Settings
Audio Settings and Video Adjust menus........... 40
Audio Settings menu.....................................40
Dialog............................................................40
Equalizer ....................................................... 40
Audio DRC .................................................... 40
Virtual Surround ............................................ 40
Video Adjust menu........................................41
Initial Settings menu.......................................... 42
Using the Initial Settings menu...................... 42
Digital Audio Out settings.............................. 43
Video Out settings......................................... 44
Language settings......................................... 45
Display settings.............................................45
Optional settings ...........................................45
Parental Lock ................................................ 46
Registering a new password.........................46
Changing your password ..............................46
Setting/changing the Parental Lock ..............46
Setting/changing the Country/Area code ......47
Country/Area code list................................... 47
About DivX
Displaying your DivX VOD registration code
Playing DivX
®
VOD content ............................48
®
VOD content .......................... 48
... 32
.. 37
.. 48
Miscellaneous Information
Additional information .......................................49
Screen sizes and disc formats ...................... 49
Resetting the player ...................................... 49
Setting the TV system (Not North American model)
Titles, chapters and tracks ............................ 50
DVD-Video regions .......................................50
Selecting languages using the language code list
Language code list........................................51
Glossary............................................................ 52
Troubleshooting ................................................ 54
HDMI troubleshooting ...................................57
6
Specifications.................................................... 58
.. 49
.. 50
DV-SP404.404E_En.book Page 7 Wednesday, June 7, 2006 1:50 PM
Introduction
Supplied Accessories
Make sure you have the following accessories:
RC-616DV
Remote controller & 2 batteries (AA)
AV cable (RCA/phono)
Coaxial cable
Features
Highlights
• Dolby
*1
Digital and DTS
•DVD-Video/Video CD/Audio CD playback
• CD-R, CD-RW (Video CD, audio CD, MP3/WMA
JPEG/DivX Video
•DVD-R (DVD-Video)
•DVD-RW (DVD-Video, VR format)
Video
• Advanced 54 MHz/10-bit video D/A converter
• Progressive Scan Video (PAL/NTSC)
• Component video output
• HDMI
• Frame-by-frame playback
• Slow motion playback
•Fast forward and reverse
• Repeat playback
• Random playback
• Supports 4:3 and 16:9 aspect ratio TVs
• Multiple camera angle support
•Parental Lock function
• Screen Saver function
*5
digital interface
*2
*4
)
*3
/
Power cord (Not North American model)
(plug type varies from country to country)
The letter displayed at the end of the product name found in
catalogs and on package represents the color of the DV-SP404/
DV-SP404E DVD player. Though the color varies, the specifications and operations are the same.
Audio
• 96 kHz/24-bit D/A converter
• Coaxial digital output
• Optical digital output (Oceanian model only)
Others
• Dynamic Range Control setting
• Full-function remote controller
*1. Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.
*2. “DTS” and “DTS Digital Out” are trademarks of Digital The-
ater Systems, Inc.
*3. Windows Media, and the Win-
dows logo are trademarks, or
registered trademarks of
Microsoft Corporation in the
United States and/or other countries.
*4. DivX, DivX Certified, and asso-
ciated logos are trademarks of
DivX, Inc. and are used under
license.
*5. HDMI, the HDMI logo and High-Definition Multimedia Inter-
face are trademarks or registered trademarks of HDMI licensing LLC.
7
DV-SP404.404E_En.book Page 8 Wednesday, June 7, 2006 1:50 PM
Introduction —Continued
Disc Notes
Supported Discs
The DV-SP404/DV-SP404E supports the following
discs.
Disc Logo Format or file type
DVD-Video
DVD-R
DVD-RW
Video CD
Audio CD
CD-R
CD-RW
JPEG CD
• Some audio CDs feature copy protection that doesn’t
conform to the official CD standard. Since these are
nonstandard discs, they may not play properly in the
DV-SP404/DV-SP404E.
• The DV-SP404/DV-SP404E supports CD-R and
CD-RW discs recorded in Video CD format, audio CD
format, or ISO 9660 Level 1 or 2 format with MP3,
WMA, and JPEG files. It also supports DVD-R and
DVD-RW discs recorded in DVD-Video format. However, some CD-R, CD-RW, DVD-R, and DVD-RW
discs may not work properly for any of the following
reasons: incomplete disc finalization, disc burner
characteristics, disc characteristics, the disc is damaged or dirty. See the manual supplied with your disc
burner for more information. Condensation or dirt on
the optical pickup lens can also affect playback.
• The DV-SP404/DV-SP404E supports 8 cm and 12 cm
discs.
• The DV-SP404/DV-SP404E does not support disc
types not listed.
• Don’t use discs with an unusual shape, such as those
shown below, because you may damage the DVSP404/DV-SP404E.
See page 50 for
region information.
DVD-Video
DVD-Video,
VR format
Including PBC
PCM and DTS
Video CD, audio CD,
MP3, WMA, JPEG,
DivX Video
Video CD, audio CD,
MP3, WMA, JPEG,
DivX Video
JPEG
• Don’t use discs that have residue from adhesive tape,
rental discs with peeling labels, or discs with custommade labels or stickers. Doing so may damage the DVSP404/DV-SP404E and you may not be able to
remove the disc properly.
Discs Made on Personal Computers
Discs made on personal computers, including those of a
compatible format, may not work properly in the DVSP404/DV-SP404E because of incorrect settings in the
disc burning software. Check the manuals supplied with
your disc burning software for additional compatibility
information.
CD-R/RW compatibility
• Compatible formats: CD-Audio, Video CD, ISO 9660
CD-ROM* containing MP3, WMA or JPEG files,
DivX video files
* ISO 9660 Level 1 or 2 compliant. CD physical format:
Mode1, Mode2 XA Form1. Romeo and Joliet file systems
are both compatible with this player.
• Multi-session playback: No
• Unfinalized disc playback: No
DVD-R/RW compatibility
• Compatible formats: DVD-Video, Video Recording
(VR)*
* Edit points may not play exactly as edited; screen may go
momentarily blank at edited points.
• Unfinalized playback: No
• WMA/MP3/JPEG file playback on DVD-R/RW: No
DVD+R/DVD+RW compatibility
Only DVD+R/DVD+RW discs recorded in “Video
Mode (DVD Video Mode)” which have been finalized,
can be played back. However, some editing made during
the recording may not be played back accurately.
Compressed audio compatibility
• Compatible formats: MPEG-1 Audio Layer 3 (MP3),
Windows Media Audio (WMA)
• Sampling rates: 32, 44.1 or 48kHz
• Bit-rates: Any (128Kbps or higher recommended)
• VBR (variable bit rate) MP3 playback: No
• VBR WMA playback: No
• WMA lossless encoding compatible: No
• DRM (Digital Rights Management) compatible: Yes
(DRM-protected audio files will not play in this
player—see also DRM in the “Glossary” on page 52)
• File extensions: .mp3, .wma (these must be used for
the player to recognize MP3 and WMA files – do not
use for other file types)
8
DV-SP404.404E_En.book Page 9 Wednesday, June 7, 2006 1:50 PM
Introduction —Continued
About WMA
WMA is an acronym for Windows Media Audio and
refers to an audio compression technology developed by
Microsoft Corporation. WMA content can be encoded
by using Windows Media
dows Media
Media
®
Player for Windows
®
Player 9 Series.
®
Player version 7, 7.1, Win-
®
XP, or Windows
Microsoft, Windows Media, and the Windows logo are
trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.
About DivX
DivX is a compressed digital video format created by the
®
DivX
video codec from DivX, Inc. This player can play
DivX video files burned on CD-R/RW/ROM discs.
Keeping the same terminology as DVD-Video, individual DivX video files are called “Titles”. When naming
files/titles on a CD-R/RW disc prior to burning, keep in
mind that by default they will be played in alphabetical
order.
Displaying DivX subtitle files
The font sets listed below are available for DivX external
subtitle files. You can see the proper font set on-screen by
setting the Subtitle Language (in Language settings on
page 45) to match the subtitle file.
This player supports the following language groups:
Group 1: Albanian (sq), Basque (eu), Catalan (ca), Dan-
ish (da), Dutch (nl), English (en), Faroese (fo), Finnish
(fi), French (fr), German (de), Icelandic (is), Irish (ga),
Italian (it), Norwegian (no), Portuguese (pt), RhaetoRomanic (rm), Scottish (gd), Spanish (es), Swedish (sv)
Group 2: Albanian (sq), Croatian (hr), Czech (cs), Hun-
garian (hu), Polish (pl), Romanian (ro), Slovak (sk), Slovenian (sl)
Group 3: Bulgarian (bg), Byelorussian (be), Mace-
donian (mk), Russian (ru), Serbian (sr), Ukrainian (uk)
Group 4: Hebrew (iw), Yiddish (ji)
Group 5: Turkish (tr)
DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under license.
• Some external subtitle files may be displayed incor-
rectly or not at all.
•For external subtitle files the following subtitle format
filename extensions are supported (please note that
these files are not shown within the disc navigation
menu): .srt, .sub, .ssa, .smi
• The filename of the movie file has to be repeated at the
beginning of the filename for the external subtitle file.
• The number of external subtitle files which can be
switched for the same movie file is limited to a maximum of 10.
DivX video compatibility
•Official DivX
• Plays all versions of DivX
6) with standard playback of DivX
• File extensions: .avi and .divx (these must be used for
the player to recognize DivX video files). Note that all
files with the .avi extension are recognized as MPEG4,
but not all of these are necessarily DivX video files
and therefore may not be playable on this player.
DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under license.
®
Certified product.
®
video (including DivX
®
media files.
®
JPEG file compatibility
• Compatible formats: Baseline JPEG and EXIF 2.2*
still image files up to a resolution of 3072 x 2048.
* File format used by digital still cameras
• Progressive JPEG compatible: No
• File extensions: .jpg (must be used for the player to
recognize JPEG files – do not use for other file types)
• File structure: Up to 299 folders; up to 648 folders and
files combined
PC-created disc compatibility
Discs recorded using a personal computer may not be
playable in this unit due to the setting of the application
software used to create the disc. In these particular
instances, check with the software publisher for more
detailed information.
Discs recorded in packet write mode (UDF format) are
not compatible with this player.
Check the DVD-R/RW or CD-R/RW software disc
boxes for additional compatibility information.
Copyright
It is forbidden by law to copy, broadcast, show, broadcast
on cable, play in public, or rent copyrighted material
without permission.
DVD-Video discs are copy-protected, and any recordings made from these discs will be distorted.
This product incorporates copyright protection technology that is protected by method claims of certain U.S.
patents and other intellectual property rights owned by
Macrovision Corporation and other rights owners. Use
of this copyright-protection technology must be authorized by Macrovision Corporation, and is intended for
home and other limited viewing uses only, unless otherwise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
9
DV-SP404.404E_En.book Page 10 Wednesday, June 7, 2006 1:50 PM
Introduction —Continued
Handling Discs
•Never touch the underside of a disc. Always hold discs
by the edge, as shown.
Underside
•Never attach adhesive tape or sticky labels to discs.
Cleaning Discs
•For best results, keep your discs clean. Fingerprints
and dust can affect the sound and picture quality and
should be removed as follows. Using a clean soft
cloth, wipe from the center outwards, as shown. Never
wipe in a circular direction.
Storing Discs
• Don’t store discs in places subject to direct sunlight,
or near heat sources.
• Don’t store discs in places subject to moisture or dust,
such as in a bathroom or near a humidifier.
•Always store discs in their cases and vertically. Stacking, or putting objects on unprotected discs may cause
warping, scratches, or other damage.
✔
•To remove stubborn dust or dirt, wipe the disc with a
damp soft cloth, and then dry it with a dry cloth.
•Never use solvent-based cleaning fluids, such as thinner or benzine, commercially available cleaners, or
antistatic sprays intended for vinyl records, because
they may damage the disc.
10
DV-SP404.404E_En.book Page 11 Wednesday, June 7, 2006 1:50 PM
Before Using the DV-SP404/DV-SP404E
Installing the Batteries
Open the battery compartment, as shown.
1
Insert the two supplied batteries (AA) in
2
accordance with the polarity diagram
inside the battery compartment.
Close the battery compartment.
3
Notes:
• If the remote controller doesn’t work reliably, try
replacing both batteries.
• Don’t mix new and old batteries, or different types of
batteries.
• If you intend not to use the remote controller for a long
time, remove the batteries to prevent possible leakage
and corrosion.
• Flat batteries should be removed as soon as possible to
prevent possible leakage and corrosion.
Using the Remote Controller
To use the remote controller, point it at the DV-SP404/
DV-SP404E’s remote control sensor, as shown below.
Remote control sensor
DV-SP404/DV-SP404E
30˚
Notes:
• The remote controller may not work reliably if the
DV-SP404/DV-SP404E is subjected to bright light,
such as direct sunlight or inverter-type fluorescent
lights. Keep this in mind when installing the DVSP404/DV-SP404E.
• If another remote controller of the same type is used
in the same room, or the DV-SP404/DV-SP404E is
installed close to equipment that uses infrared rays,
the remote controller may not work reliably.
• Don’t put anything, such as a book, on the remote controller, because the buttons may be pressed inadvertently, thereby draining the batteries.
• The remote controller may not work reliably if the
DV-SP404/DV-SP404E is installed in a rack behind
colored glass doors. Keep this in mind when installing
the DV-SP404/DV-SP404E.
• The remote controller will not work if there’s an
obstacle between it and the DV-SP404/DV-SP404E’s
remote control sensor.
30˚
Approx. 5 m
11
DV-SP404.404E_En.book Page 12 Wednesday, June 7, 2006 1:50 PM
Front & Rear Panels
For detailed information, refer to the pages in brackets.
Front Panel
1 3 4 5672
A
STANDBY/ON button [23, 26]
This button is used to set the DV-SP404/DVSP404E to On or Standby.
B
HDMI indicator
Lights when the DV-SP404/DV-SP404E is recognized by another HDMI or DVI/HPCP compatible
component.
C
Disc tray [26]
Discs are loaded here.
D
Remote control sensor [11]
This sensor receives control signals from the remote
controller.
E
TOP MENU button [28]
This button is used to display the top menu on a
DVD-Video disc.
F
Cursor & ENTER button [24]
These buttons are used to navigate onscreen menus.
MENU button [28]
G
This button is used to display the menu on a
DVD-Video disc or to open the Disc Navigator
when using a Video CD, audio CD, DivX Video,
WMA/MP3/JPEG disc, or VR format DVD-RW
disc.
8
9 J K L M N
H
I
J
K
L
M
N
/ (previous/next) buttons [27]
The Previous button is used to select the previous
chapter or track. During playback it selects the
beginning of the current chapter or track.
The Next button is used to select the next chapter or
track.
(stop) button [27]
This button is used to stop playback.
(pause) button [27]
This button is used to pause playback.
(PLAY) button [26, 27]
This button is used to start playback.
(OPEN/CLOSE) button [26]
This button is used to open and close the disc tray.
SETUP button [24]
This button is used to open and close the onscreen
setup menus.
RETURN button [24]
This button is used to return to the main menu without saving your changes.
12
DV-SP404.404E_En.book Page 13 Wednesday, June 7, 2006 1:50 PM
Front & Rear Panels —Continued
Display
2 3 4 5 6 7 81
9
Pause indicator
1
This indicator appears when playback is paused.
Play indicator
2
This indicator is shown during playback.
CHP indicator
3
This indicator appears while the number of the current chapter is being displayed.
TITLE indicator
4
While stopped, the total number of titles on the current DVD-Video disc is displayed here. During
playback, the number of the current title is displayed.
Camera angle indicator
5
This indicator appears if the DVD-Video disc being
played features multiple camera angles.
6
PRGSVE (Progressive) indicator
This indicator appears when the component video
output is outputting progressive video.
7
Repeat indicator
This indicator appears when A–B playback or
repeat playback is used.
8
REMAIN indicator
This indicator appears while the remaining time is
being displayed.
9
Message & time area
Time information, such as total time, remaining
time, and so on, is displayed here in hours, minutes,
and seconds. Other messages are also displayed.
13
DV-SP404.404E_En.book Page 14 Wednesday, June 7, 2006 1:50 PM
Front & Rear Panels —Continued
Rear Panel
DV-SP404 North American model
31 4 65
9
DV-SP404 Oceanian model
31 2 4 65
8
9
DV-SP404E European model
31 4 65
A
HDMI OUT [21]
This connector can be used to connect a TV or projector with an HDMI input. This connector outputs
digital audio and digital video.
OPTICAL DIGITAL AUDIO OUT [22] (not
B
North American and European models)
This optical digital audio output can be connected
to an optical digital audio input on a hi-fi amp, AV
receiver, or surround sound decoder (Dolby Digital,
DTS).
C
COAXIAL DIGITAL AUDIO OUT [22]
This coaxial digital audio output can be connected
to a coaxial digital audio input on a hi-fi amp, AV
receiver, or surround sound decoder (Dolby Digital,
DTS).
COMPONENT VIDEO OUT [20]
D
These sockets output component video and can be
connected to an component video input on a TV or
projector.
E
VIDEO OUT [18]
This RCA/phono connector can be used to connect
a TV or projector with a composite video input.
F
ANALOG AUDIO OUT [18]
These RCA/phono connectors can be connected to
analog audio inputs on your TV, hi-fi amp, or AV
receiver.
AV CONNECTOR [20] (European model only)
G
This SCART output can be connected to a TV or
projector with a SCART input. This SCART connector outputs 2-channel stereo audio, composite
video, and RGB video.
H
AC INLET [23] (not North American model)
The supplied power cord is connected here. The
other of the power cord should be connected to a
suitable wall outlet.
I
S VIDEO VIDEO OUT [20] (not European
model)
This connector can be used to connect a TV or projector with an S-Video input.
87
14
DV-SP404.404E_En.book Page 15 Wednesday, June 7, 2006 1:50 PM
Front & Rear Panels —Continued
Remote Controller
1
2
3
4
5
6
7
8
9
J
K
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
0
ENTER
RC-616DV
6
CLEAR
OPEN/
CLOSE
DISPLAY
PLAY
MODE
MENU
SETUP
L
M
N
O
P
Q
R
S
T
U
V
W
STANDBY button [23]
A
This button is used to set the DV-SP404/DVSP404E to Standby.
ON button [23]
B
This button is used to turn on the DV-SP404/DVSP404E.
Don’t turn on the DV-SP404/DV-SP404E until
you’ve completed, and double checked all connections (pages 17–22).
C
Number buttons [27–28, 37, 46]
These buttons are used to enter title, chapter, and
track numbers and to enter times for locating specific points in time.
D
TOP MENU button [28]
This button is used to display the top menu on a
DVD-Video disc.
Cursor /// buttons [24]
E
These buttons are used to navigate onscreen menus.
RETURN button [24, 28]
F
This button is used to return to the main menu without saving your changes.
AUDIO button [38]
G
This button is used to select foreign language
soundtracks and audio formats (e.g., Dolby Digital
or DTS) on DVD-Video discs.
For Video CDs you can select left-channel, rightchannel, or stereo.
H
ANGLE button [39]
This button is used to select camera angles on
DVD-Video discs.
Stop button [27]
I
This button is used to stop playback.
Fast Reverse /( ) button [27, 30, 31]
J
This button is used for fast reverse, reverse slow
motion, and reverse frame-by-frame playback.
15
DV-SP404.404E_En.book Page 16 Wednesday, June 7, 2006 1:50 PM
Front & Rear Panels —Continued
K
Fast Forward /( ) button [27, 30,
31]
This button is used for fast forward, slow motion,
and frame-by-frame playback.
L
OPEN/CLOSE button [26]
This button is used to open and close the disc tray.
PLAY MODE button [34–37]
M
This button is used to open and close the Play Mode
menu.
DISPLAY button [39]
N
This button is used to display information about the
current disc, title, chapter, or track, including the
elapsed time, remaining time, total time, and so on.
Press it repeatedly to display more information.
O
CLEAR [36]
This button is used to cancel various functions.
P
MENU button [28]
This button is used to display the menu on a
DVD-Video disc or to open the Disc Navigator
when using a Video CD, audio CD, DivX Video,
WMA/MP3/JPEG disc, or VR format DVD-RW
disc.
ENTER button [24]
Q
This button is used to start playback of the selected
title, chapter, or track, and to confirm settings.
SETUP button [24, 40–42]
R
This button is used to open and close the onscreen
setup menus.
ZOOM button [39]
S
This button is used with the Zoom function.
T
SUBTITLE button [38]
This button is used to select subtitles on
DVD-Video discs.
U
Pause button [27, 30, 31]
This button is used to pause playback.
V
Previous/Next / buttons [27]
The Previous button is used to select the previous
chapter or track. During playback it selects the
beginning of the current chapter or track.
The Next button is used to select the next chapter or
track.
W
Play button [27]
This button is used to start playback.
16
DV-SP404.404E_En.book Page 17 Wednesday, June 7, 2006 1:50 PM
Connecting the DV-SP404/DV-SP404E
Before Making Any Connections
• Read the manuals supplied with your AV components.
• Don’t connect the power cord until you’ve completed
all audio and video connections.
Optical Digital Output (not North American
and European models)
The optical digital connector is fitted with protective cap.
Before connecting a cable, remove the cap and keep it
safely. When you disconnect the cable, put the cap back
in.
AV Cables & Connectors
Video
C
R
P
R
//
C
B
P
B
Y
Component
video
R
P/ /
R
C
C
B
P
B
Y
RCA/phono AV Connection Color Coding
RCA/phono AV connections are usually color coded:
red, white, and yellow. Use red plugs to connect rightchannel audio inputs and outputs (typically labeled “R”).
Use white plugs to connect left-channel audio inputs and
outputs (typically labeled “L”). And use yellow plugs to
connect composite video inputs and outputs.
Right (red)
Left (white)
(Yellow)
• Push each plug in all the way to
make a good connection (loose
connections can cause noise or
malfunctions).
•To prevent interference, keep
audio and video cables away from
power cords and speaker cables.
Component video separates the luminance (Y) and
color difference signals (P
picture quality. Some TV manufacturers label their
component video inputs differently.
Analog audio
Composite video
R
B
, P
Right (red)
Left (white)
(Yellow)
Right!
Wrong!
), providing the best
S-Video
(not European
model)
Composite
video
Scart
(European
model only)
Audio
Optical digital
(Oceanian
model only)
Coaxial digital
Analog
S-Video provides better picture quality than composite video.
Composite video can be found on virtually all TVs,
VCRs, and video equipment.
SCART connections carry audio and video (composite, S-Video, RGB) all in one cable.
Optical digital audio connections provide better
audio quality than analog connections.
Coaxial digital audio connections provide better
audio quality than analog connections.
RCA/phono analog audio connectors can be found
on virtually all AV components.
17
DV-SP404.404E_En.book Page 18 Wednesday, June 7, 2006 1:50 PM
Connecting the DV-SP404/DV-SP404E —Continued
Basic Setup
The setup described here is a basic setup that allows you to play discs using just the supplied AV cable (RCA/phono).
In this setup, stereo audio is played through the speakers in your TV.
VIDEO IN
TV
L
R
ANALOG
INPUT
Important:
• This player is equipped with copy protection technology. Do not connect this player to your TV via a VCR
using AV cables, as the picture from this player will
not appear properly on your TV. (This player may also
not be compatible with some combination TV/VCRs
for the same reason; refer to the manufacturer for
more information.)
• When connecting to your TV as shown above, do not
set the “Component Out” setting (page 44) to “Progressive.”
To power outlet
Notes:
• Before unplugging the player from the power outlet,
make sure you first switch it into standby using either
the front panel STANDBY/ON button, or the remote
controller, and wait of the “OFF” message to disappear from the player’s display.
•For the above reasons, do not plug this player into a
switched power supply found on some amplifiers and
AV receivers.
1. Connect the VIDEO OUT and AUDIO OUT
ANALOG L/R jacks to a set of A/V inputs on
your TV.
Use the supplied AV cable (RCA/phono), connecting
the red and white plugs to the audio outputs and the
yellow plug to the video output. Make sure you
match up the left and right audio outputs with their
corresponding inputs for correct stereo sound.
See page 20 if you want to use a component, SVideo cable or SCART cable for the video connection.
2. Oceanian and European models:
Connect the supplied AC power cord to the AC
INLET, then plug into a power outlet.
North American model:
Connect the power cord to power outlet.
18
DV-SP404.404E_En.book Page 19 Wednesday, June 7, 2006 1:50 PM
Connecting the DV-SP404/DV-SP404E —Continued
Switching the video output to interlace
using the front panel controls
Switch the player to standby then, using the front panel
controls, press STANDBY/ON while pressing to
switch the player back to Interlace.
• If the player is connected using HDMI, disconnect the
HDMI cable before resetting the player to interlace
output. (If left connected, the HDMI output resolution
will be reset to its default—see Resetting the output
resolution to the default setting with HDMI connection on page 21.)
STANDBY/ON
Note:
• If you connect a TV that is not compatible with a progressive scan signal and switch the player to progressive, you will not be able to see any picture at all. In
this case, switch everything off and reconnect using
the supplied video cable, then switch back to Interlace.
Notes for North American model:
• When Component Out (page 44) is set to Progressive,
there is no video output from the VIDEO OUT (composite) and S VIDEO OUT jacks.
• If you want to display video on more than one monitor
simultaneously, make sure the player is set to Interlace.
Compatibility of this player with
progressive-scan and high-definition TVs
This player is compatible with progressive video Macro
Vision System Copy Guard.
Consumers should note that not all high-definition television sets are fully compatible with this product and
may cause artifacts to be displayed in the picture. In case
of 525 progressive scan picture problems, it is recommended that the user switch the connection to the “standard definition” output (Interlace). If there are questions
regarding our TV set compatibility with this model,
please contact our customer service center.
19
DV-SP404.404E_En.book Page 20 Wednesday, June 7, 2006 1:50 PM
Connecting the DV-SP404/DV-SP404E —Continued
Connecting Your TV
• Connect the DVD Player to the TV directly. If you
connect the DVD Player to a VCR, TV/VCR combination, or video selector, the playback picture may be
distorted as DVD videos are copy protected.
Using S-Video (not European model)
If your TV (or other equipment) has an S-Video input,
you can use this instead of the standard (composite) output for a better quality picture.
• Use an S-Video cable (not supplied) to connect the S
VIDEO OUT to an S-Video input on your TV (or
monitor or AV receiver).
Line up the small triangle above the jack with the same
mark on the plug before plugging in.
TV
S VIDEO IN
Note:
•To set up the player for use with a progressive scan TV,
see “Video Out settings – Component Out” on
page 44.
Using SCART (European model only)
If your TV has a SCART-type AV input, you can use a
SCART cable to connect this player to your TV. This
type of connection carries both the sound and the picture, so there’s no need to connect up the AUDIO OUT
L/R and VIDEO OUT jacks.
• Use a SCART cable (not supplied) to connect the AV
CONNECTOR to an AV input on your TV.
Using Component Video
You can use the component video output instead of the
standard video out jack to connect this player to your TV
(or other equipment).
This should give you a better quality picture than an SVideo connection.
• Use a component video cable (not supplied) to connect the COMPONENT VIDEO OUT jacks to a component video input on your TV, monitor or AV
receiver.
YPB PR
COMPONENT
VIDEO IN
TV
TV
SCART
This connector can output composite video, or RGB
video. The default setting is composite, which should
work with all TVs. Consult the manual that came with
your TV to see if you can use one of the higher quality
settings. See page 44 for how to change the video output.
20
DV-SP404.404E_En.book Page 21 Wednesday, June 7, 2006 1:50 PM
Connecting the DV-SP404/DV-SP404E —Continued
Using HDMI
If you have a HDMI equipped monitor or display, you
can connect it to this player using a commercially available HDMI cable.
The HDMI connector outputs uncompressed digital
video, as well as almost every kind of digital audio that
the player is compatible with, including DVD-Video,
Video CD, CD and MP3.
• Use an HDMI cable to connect the HDMI OUT interconnect on this player to an HDMI interconnect on a
HDMI-compatible monitor.
HDMI
connector
HDMI-compatible display
• The arrow on the cable connector body should be face
up for correct alignment with the connector on the
player.
About HDMI
HDMI (High Definition Multimedia Interface) supports
both video and audio on a single digital connection for
use with DVD players, DTV, set-top boxes, and other AV
components. HDMI was developed to provide the technologies of High Bandwidth Digital Content Protection
(HDCP) as well as Digital Visual Interface (DVI) in one
specification. HDCP is used to protect digital content
transmitted and received by DVI-compliant displays.
HDMI has the capability to support standard, enhanced,
or high-definition video plus standard to multi-channel
surround-sound audio. HDMI features include uncompressed digital video, a bandwidth of up to 2.2 gigabytes
per second (with HDTV signals), one connector (instead
of several cables and connectors), and communication
between the AV source and AV components such as
DTVs.
HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of
HDMI licensing LLC.
Resetting the output resolution to the default setting
with HDMI connection
Switch the player to standby then, using the front panel
controls, press STANDBY/ON while pressing to
switch the player back to 576P/480P.
STANDBY/ON
Notes:
• The player has been designed to be compliant with
HDMI (High Definition Multimedia Interface).
Depending on the component you have connected,
using a DVI connection may result in unreliable signal
transfers.
• When you change the component connected to the
HDMI output, you will also need to change the HDMI
settings to match the new component (see HDMI Out
on page 43, HDMI Resolution on page 44 and HDMI
Color on page 44 to do this).
However, the settings for each component are then
stored in memory (for up to 2 components).
• The HDMI connection is compatible with 44.1 kHz/
48 kHz, 16 bit/20 bit/24 bit 2 channel linear PCM signals, as well as Doldy Digital, DTS and MPEG audio
bitstream.
.
21
DV-SP404.404E_En.book Page 22 Wednesday, June 7, 2006 1:50 PM
Connecting the DV-SP404/DV-SP404E —Continued
Connecting to an AV Receiver
Although you can reproduce the DVD Player’s sound
from the TV speakers with the connections on page 18,
connecting with an amplifier provides you high quality
dynamic sounds.
To reproduce Dolby Digital surround and DTS surround
sound, you need to connect to an amplifier with a Dolby
Digital and DTS decoder respectively.
Before connecting
• When you connect the DVD Player to the amplifier, be
sure to turn off the power and unplug both units from
the mains before making any connections. Otherwise,
the speakers may be damaged.
• Connect the plugs securely.
To enjoy surround sound you need to connect this player
to an AV receiver using a digital output.
Oceanian model has both coaxial and optical digital
jacks; use whichever is convenient.
North American and European models have only coaxial
digital jack.
In addition to a digital connection, we recommend also
connecting using the stereo analog connection.
To record the audio from a CD-R disc etc. to a cassette
or CDR recorder that’s connected to the AV receiver, and
when your AV receiver has Zone2, you must connect the
DV-SP404/DV-SP404E’s analog audio outputs to the AV
receiver.
You’ll probably also want to connect a video output to
your AV receiver. You can use any of the video outputs
available on this player (the illustration shows a standard
(composite) connection).
1. Connect the DIGITAL AUDIO OUT jack on this
player to a digital input on your AV receiver.
This enables you to listen to surround sound.
For a coaxial connection, use a coaxial cable (supplied)
to connect the “COAXIAL DIGITAL AUDIO OUT”
jack to a coaxial input on your AV receiver.
For an optical connection (Oceanian model only), use an
optical cable (not supplied) to connect the “OPTICAL
DIGITAL AUDIO OUT” jack to an optical input on your
AV receiver.
2. Connect the ANALOG AUDIO OUT L/R and
VIDEO OUT jacks on this player to a set of analog audio and video inputs on your AV receiver.
AV receiver
DVD
IN
FRONT
L
R
The diagram shows standard video connections, but you
can alternatively use the S-Video or component video
connections if they’re available.
3. Connect the AV receiver’s video output to a video
input on your TV.
Tip:
•You usually have to connect the same kind of video
cable between your DVD player and AV receiver, and
between your AV receiver and TV.
OPTICAL
Connect one
or the other
AV receiver
Note:
• North American and European models have only
coaxial digital jack.
22
COAXIAL
DV-SP404.404E_En.book Page 23 Wednesday, June 7, 2006 1:50 PM
Connecting the Power/Turning on the DV-SP404/
DV-SP404E
Before connecting
• Make sure that all the connections on pages 17 – 22
are complete (the connection to a TV is required).
STANDBY/ON
ON
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
CLEAR
0
MENU
ENTER
SETUP
1
North American model:
Connect the power cord into the
power outlet on the wall.
Oceanian and European model;
Plug the supplied power cord into
the AC INLET and then into the
power outlet on the wall.
• Do not use a power cord other than the
one supplied with the DV-SP404/DVSP404E. The power cord supplied is
designed for use with the DV-SP404/
DV-SP404E and should not be used
with any other device.
•Never have the power cord disconnected from the DV-SP404/DVSP404E while the other end is plugged
into the wall outlet. Doing so may
cause an electric shock. Always connect by plugging into the wall outlet
last and disconnect by unplugging
from the wall outlet first.
To a wall
outlet
RC-616DV
2
Press STANDBY/ON on the DVSP404/DV-SP404E or ON on the
remote controller.
The DVD Player turns on.
•To put the DV-SP404/DV-SP404E in
Remote
controller
ON
the standby mode, press STANDBY/
ON on the DV-SP404/DV-SP404E, or
STANDBY on the remote controller.
Be sure to set the volume to minimum
before putting the DV-SP404/DVSP404E in the standby mode for the
next use to avoid sudden loud sound
reproduction.
• Setting the STANDBY/ON button to
standby does not shut off the power
completely.
Note:
• This player features a screen saver and an auto power
off function. If the player is stopped and no button is
pressed for five minutes, the screen saver starts. If the
disc tray is closed but no disc is playing and no control
is pressed for 30 minutes, the player automatically
goes into standby.
23
SETUP
SETUP
DV-SP404.404E_En.book Page 24 Wednesday, June 7, 2006 1:50 PM
Getting Started
•
Using the on-screen displays
For ease of use, this player makes extensive use of
graphical on-screen displays (OSDs).
All the screens are navigated in basically the same way,
using the cursor (///) buttons to change the
highlighted item and pressing ENTER to select it.
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
0
ENTER
RC-616DV
CLEAR
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
MENU
///
ENTER
SETUP
SETUPRETURN
Cursor, ENTER
Setting up the player for your TV
If you have a widescreen (16:9) TV, you should setup the
player so that the picture will be presented correctly. If
you have a conventional (4:3) TV, you can leave the
player on the default setting and move on to the next section.
1
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
Press SETUP and select “Initial
Settings”.
0
ENTER
CLEAR
OPEN/
CLOSE
6
PLAY
MODE
DISPLAY
MENU
SETUP
Initial Settings
SETUP
SETUP RETURN
Note:
From here on in this manual, the word “select”
generally means use the cursor buttons to highlight
an item on-screen, then press ENTER.
Button
Front Panel
Remote
Controller
SETUP
ENTER
ENTER
RETURN
What it does
Display/exit the onscreen display.
Changes the highlighted menu item.
Selects the highlighted
menu item (both
ENTER buttons on the
remote work in exactly
the same way).
Returns to the main
menu without saving
changes.
2
3
4
Select “TV Screen” from the
“Video Output” settings.
Initial Settings
Digital Audio Out
Video Output
Language
Display
Options
TV Screen
Component Out
4:3 (Letter Box)
4:3 (Pan&Scan)
16:9 (Wide)
If you have a widescreen (16:9) TV,
select “16:9 (Wide)”.
If you have a conventional (4:3) TV, you
can change the setting from 4:3 (Letter
Box) to 4:3 (Pan & Scan) if you prefer.
See “Video Out settings” on page 44 for
more details.
Press SETUP to exit the menu
screen.
24
DV-SP404.404E_En.book Page 25 Wednesday, June 7, 2006 1:50 PM
Getting Started —Continued
Setting the language of this player’s
on-screen displays
This sets the language of this system’s on-screen displays.
1
2
SETUP
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
CLEAR
0
MENU
ENTER
SETUP
SETUP
Press SETUP and select “Initial
Settings”.
Initial Settings
Select “OSD Language” from the
“Display” settings.
Initial Settings
Digital Audio Out
Video Output
Language
Display
Options
OSD Language
Angle Indicator
English
français
Deutsch
Italiano
Español
3
4
SETUP
Select a language.
The on-screen language will change
according to your selection.
Press SETUP to exit the menu
screen.
25
Remote
controller
DV-SP404.404E_En.book Page 26 Wednesday, June 7, 2006 1:50 PM
Getting Started —Continued
Playing discs
The basic playback controls for playing DVD, CD,
Video CD, DivX Video and MP3/WMA discs are covered here. Further functions are detailed in the next chapter.
For details on playing JPEG picture discs, see “Viewing
a JPEG slideshow” on page 31.
STANDBY/ON
1
controller
Remote
ON
ON
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
If the player isn’t already on, press
STANDBY/ON to switch it on.
If you’re playing a DVD disc containing
DivX video files or Video CD, also turn
on your TV and make sure that it is set to
the correct video input.
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
CLEAR
0
MENU
ENTER
SETUP
OPEN/
CLOSE
3
Load a disc.
Load a disc with the label side facing up,
using the disc tray guide to align the disc
(if you’re loading a double-sided DVD
disc, load it with the side you want to
play face down).
4
Press (play) to start playback.
If you’re playing a DVD or Video CD, an
on-screen menu may appear. See “DVDVideo disc menus” on page 28 and
“Video CD PBC menus” on page 28 for
more on how to navigate these.
• If you’re playing a containing DivX
video files or MP3/WMA audio files, it
may take a few seconds before playback starts. This is normal.
Notes:
•You may find with some DVD discs that some playback controls don’t work in certain parts of the disc.
This is not a malfunction.
• If a disc contains a mixture of DivX video and other
media file types (MP3, for example), first select
whether to play the DivX video files (DivX) or the
other media file types (MP3/WMA/JPEG) from the
on-screen display.
26
2
controller
Remote
OPEN/
CLOSE
Press OPEN/CLOSE to open the
disc tray.
DV-SP404.404E_En.book Page 27 Wednesday, June 7, 2006 1:50 PM
Getting Started —Continued
Basic playback controls
The table below shows the basic controls on the remote
for playing discs. The following chapter covers other
playback features in more detail.
ON STANDBY
123
Numbers
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
/
Button What it does
Starts playback.
If the display shows RESUME or LAST
MEM playback starts from the resume
or last memory point (see also
“Resume and Last Memory” on the
adjacent column.)
Pauses a disc that’s playing, or
restarts a paused disc.
Stops playback.
See also “Resume and Last Memory”
on the adjacent column.
Press to start fast reverse scanning.
(remote
controller
Press (play) to resume normal
playback.
only)
Press to start fast forward scanning.
(remote
controller
Press (play) to resume normal
playback.
only)
Skips to the start of the current track or
chapter, then to previous tracks/chapters.
Skips to the next track or chapter.
Use to enter a title/chapter/track number.
Press ENTER to select.
Numbers
(remote
controller
only)
• If the disc is stopped, playback starts
from the selected title (for DVD) or
track (for CD/Video CD).
• If the disc is playing, playback jumps
to the start of the selected title (VR
mode DVD-RW), chapter (DVDVideo) or track (CD/Video CD)
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
CLEAR
0
MENU
ENTER
SETUP
/
Resume and Last Memory
When you stop playback of a disc, RESUME is shown
in the display indicating that you can resume playback
again from that point.
If the disc tray is not opened, the next time you start
playback the display shows RESUME and playback
resumes from the resume point.
With DVDs and Video CDs, if you take the disc out of
the player, the play position is stored in memory. If the
next disc you load is the same one, the display shows
LAST MEM and playback will resume.
If you want to clear the resume point, press (stop)
while RESUME is displayed.
Notes:
• The Last Memory function doesn’t work with VR format DVD-RW discs.
• If you don’t need the Last Memory function when you
stop a disc, you can press (stop) button again to stop
playback and then press
the disc tray.
OPEN/CLOSE to open
27
DV-SP404.404E_En.book Page 28 Wednesday, June 7, 2006 1:50 PM
Getting Started —Continued
DVD-Video disc menus
Many DVD-Video discs feature menus from which you
can select what you want to watch. They may also give
access to additional features, such as subtitle and audio
language selection, or special features such as slideshows. See the disc packaging for details.
Sometimes DVD-Video menus are displayed automatically when you start playback; others only appear when
you press MENU or TOP MENU.
ON STANDBY
OPEN/
CLOSE
PLAY
123
Numbers
TOP MENU
RETURN
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
Button What it does
TOP MENU
Displays the “top menu” of a DVD
disc—this varies with the disc.
Displays a DVD disc menu—this var-
MENU
ies with the disc and may be the same
as the “top menu”.
///
ENTER
RETURN
Numbers
(remote
controller
Moves the cursor around the screen.
Selects the current menu option.
Returns to the previously displayed
menu screen.
Highlights a numbered menu option
(some discs only).
Press ENTER to select.
only)
MODE
DISPLAY
6
CLEAR
0
MENU
ENTER
SETUP
///
MENU
ENTER
Video CD PBC menus
Some Video CD have menus from which you can choose
what you want to watch. These are called PBC (Playback
control) menus.
You can play a PBC Video CD without having to navigate the PBC menu by starting playback using a number
button to select a track, rather than the (play) button.
ON STANDBY
123
Numbers
RETURN
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
Button What it does
RETURN
Numbers
(remote
Displays the PBC menu.
Use to enter a numbered menu option.
Press ENTER to select.
controller
only)
Displays the previous menu page (if
there is one).
Displays the next menu page (if there
is one).
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
CLEAR
0
MENU
ENTER
SETUP
ENTER
/
28
DV-SP404.404E_En.book Page 29 Wednesday, June 7, 2006 1:50 PM
Getting Started —Continued
Hint:
• After I load a DVD disc, it ejects automatically after a
few seconds!
Most likely, the disc is the wrong region for your
→
player. The region number should be printed on
the disc; check it against the region number of the
player (which you can find on the rear panel). See
also DVD-Video regions on page 50.
→
If the region number is OK, it may be that the disc
is damaged or dirty. Clean the disc and look for
signs of damage. See also Taking care of your
player and discs on page 10.
•Why won’t the disc I loaded play?
→
First check that you loaded the disc the right way
up (label side up), and that it’s clean and undamaged. See Taking care of your player and discs on
page 10 for information on cleaning discs.
→
If a disc loaded correctly won’t play, it’s probably
an incompatible format or disc type, such as
DVD-Audio or DVD-ROM. See Supported Discs
on page 8 for more on disc compatibility.
•I have a widescreen TV so why are there black bars at
the top and bottom of the screen when I play some
discs?
→
Some movie formats are such that even when
played on a widescreen TV, black bars are necessary at the top and bottom of the screen. This is not
a malfunction.
•I have a standard (4:3) TV and set the player to show
widescreen DVDs in pan & scan format, so why do I
still get black bars top and bottom with some discs?
Some discs override the display preferences of the
→
player, so even if you have 4:3 (Pan & Scan)
selected, those discs will still be shown in letter
box format.
This is not a malfunction.
•I’ve connected to a HDMI compatible component but
I can’t get any signal and the front panel HDMI indicator won’t light!
→
Make sure that you’ve selected this player as the
HDMI input in the settings for the component
you’re using. You may need to refer to the instruction manual of the component to do this. See Connecting using HDMI on page 21 for more on
HDMI compatibility.
• There’s no picture from the HDMI output!
This player cannot display pictures from DVI
→
compatible sources. See Connecting using HDMI
on page 21 for more on HDMI compatibility.
Make sure the resolution on this player matches
that of the component you have connected using
HDMI. See HDMI Resolution on page 44 to
change the HDMI resolution.
29
DV-SP404.404E_En.book Page 30 Wednesday, June 7, 2006 1:50 PM
Playing discs
Notes:
• Many of the functions covered in this chapter apply to
DVD discs, Video CDs, CDs, DivX Video and MP3/
JPEG discs, although the exact operation of some varies slightly with the kind of disc loaded.
• Some DVDs restrict the use of some functions (random or repeat, for example) in some or all parts of the
disc. This is not a malfunction.
• When playing Video CD, some of the functions are
not available during PBC playback. If you want to use
them, start the disc playing using a number button to
select a track.
Scanning discs
You can fast-scan discs forward or backward at four different speeds (DivX video only one speed).
1
2
3
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
/
During playback, press or
to start scanning.
• There is no sound while scanning
DVDs, DivX Video and Video CDs.
Press repeatedly to increase the
scanning speed.
• The scanning speed is shown onscreen.
To resume normal playback, press
(play).
• When scanning a Video CD playing in
PBC mode or a WMA/MP3 track,
playback automatically resumes at the
end or beginning of the track.
• Depending on the disc, normal playback may automatically resume when
a new chapter is reached on a DVD
disc.
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
CLEAR
0
MENU
ENTER
SETUP
Playing in slow motion
You can play DVDs at four different slow motion speeds,
forwards and backwards. Video CD and DivX Video can
be played at four different forward slow motion speeds.
ON STANDBY
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
/
1
2
During playback, press (pause).
Press and hold or
until slow motion playback starts.
• The slow motion speed is shown onscreen.
• There is no sound during slow motion
playback.
3
4
Press repeatedly to change the
slow motion speed.
To resume normal playback, press
(play).
• Depending on the disc, normal playback may automatically resume when
a new chapter is reached.
Note:
• Backward slow-motion playback does not work with
Video CD and DivX Video.
123
6
45
789
CLEAR
0
ENTER
OPEN/
CLOSE
MODE
DISPLAY
MENU
SETUP
PLAY
30
DV-SP404.404E_En.book Page 31 Wednesday, June 7, 2006 1:50 PM
Playing discs —Continued
/
/
Frame advance/frame reverse
You can advance or back up DVD discs frame-by-frame.
With Video CD and DivX Video you can only use frame
advance.
1
2
ON STANDBY
123
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
/
During playback, press (pause).
Press or to reverse
or advance a frame at a time.
45
6
789
CLEAR
0
ENTER
OPEN/
CLOSE
DISPLAY
MENU
SETUP
PLAY
MODE
Viewing a JPEG slideshow
After loading a CD/CD-R/RW containing JPEG picture
files, press (play) to start a slideshow from the first
folder/picture on the disc. The player displays the pictures in each folder in alphabetical order.
• If the folder contains WMA/MP3 files, playback of
the slideshow and WMA/MP3 files repeats. During
the audio playback, you can still use the skip ( /
), scan( / ) and pause ( ) functions.
Pictures are automatically adjusted so that they fill as
much of the screen as possible (if the aspect ratio of the
picture is different to your TV screen you may notice
black bars at the sides, or at the top and bottom of the
screen).
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
CLEAR
0
MENU
ENTER
SETUP
///
MENU
ZOOM
/
3
To resume normal playback, press
(play).
• Depending on the disc, normal playback may automatically resume when
a new chapter is reached.
Note:
• Backward frame-by-frame playback does not work
with Video CD and DivX Video.
While the slideshow is running:
Button What it does
Pauses the slideshow; press again to
restart.
Displays the previous picture.
Displays the next picture.
Pauses the slideshow and rotates the
displayed picture 90˚ (counter)clockwise. (Press (play) to restart slideshow).
Pauses the slideshow and flips the displayed picture horizontally or vertically.
(Press (play) to restart slideshow).
Pauses the slideshow and zooms the
ZOOM
picture. Press again to toggle between
1x, 2x and 4x zoom. (Press (play)
to restart slideshow).
MENU
Displays the Disc Navigator screen
(see below).
Notes:
• The time it takes for the player to load a file increases
with large file sizes.
31
ENTER
DV-SP404.404E_En.book Page 32 Wednesday, June 7, 2006 1:50 PM
Playing discs —Continued
•
Browsing video content with the Disc
Navigator
Use the Disc Navigator to browse through the contents
of a DVD or Video CD disc to find the part you want to
play.
Important:
•You can’t use the Disc Navigator with Video CD in
PBC mode.
1
SETUP
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
During playback, press SETUP
and select “Disc Navigator” from
the on-screen menu.
CLEAR
0
ENTER
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
MENU
SETUP
Disc Navigator
SETUP
/
3
Play List: Title – Playlist titles from a
VR mode DVD-RW disc.
• Original: Time – Thumbnails from
the Original content at 10 minute intervals.
• Play List: Time – Thumbnails from
the Playlist at 10 minute intervals.
The screen shows up to six moving
thumbnail images displayed one after
another. To display the previous/next six
thumbnails, press / (you don’t
have to wait for all the thumbnails to finish playing to display the previous/next
page).
Select the thumbnail image for
what you want to play.
01
04
Disc Navigator: Title
01- 49: - -
02
05
03
06
You can use either the cursor (///
) buttons and ENTER to select a
thumbnail, or the number buttons.
To select using the number buttons, enter
a two-digit number then press ENTER.
32
2
Select a view option.
Disc Navigator
Title
Chapter
The options available depend on the kind
of disc loaded and whether the disc is
playing or not, but include:
• Title – Titles from a DVD-Video
disc.
• Chapter – Chapters from the current
title of a DVD-Video disc.
• Track – Tracks from a Video CD
disc.
• Time – Thumbnails from a Video CD
disc at 10 minute intervals.
• Original: Title – Original titles from
a VR mode DVD-RW disc.
Tip:
• Another way to find a particular place on a disc is to
use one of the search modes. See “Searching a disc”
on page 37.
DV-SP404.404E_En.book Page 33 Wednesday, June 7, 2006 1:50 PM
Playing discs —Continued
Browsing WMA, MP3, DivX Video and
JPEG files with the Disc Navigator
Use the Disc Navigator to find a particular file or folder
by filename. Note that if there are other types of files on
the same disc, these will not be displayed in the Disc
Navigator.
1
SETUP
ON STANDBY
123
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
Press SETUP and select “Disc
Navigator” from the on-screen
menu.
00:00/ 00:00 0kbps
45
6
789
CLEAR
0
ENTER
OPEN/
CLOSE
DISPLAY
MODE
MENU
SETUP
PLAY
///
ENTER
SETUP
3
To play the highlighted track or
DivX Video file, or to display the
highlighted JPEG file, press
ENTER
ENTER.
• When a WMA/MP3 or DivX Video
file is selected, playback begins, starting with the selected track, and continues until the end of the folder.
• When a JPEG file is selected, a slideshow begins, starting with that file, and
continues to the end of the folder.
Tip:
•To play the contents of the whole disc rather than just
the current folder, exit the Disc Navigator and start
playback using the (play) button.
•You can also play a JPEG slideshow while listening to
WMA/MP3 playback. Simply select the audio file you
want to listen to followed by the JPEG from which
you want the slideshow to start. Playback of both the
slideshow and the audio files repeats.
Playback controls are effective for the JPEG slideshow only.
2
ENTER
Folder1
Folder2
Folder3
Folder4
Use the cursor (///) buttons and ENTER to navigate.
Use the cursor up/down ( / ) buttons
to move up and down the folder/file list.
Use the cursor left ( ) button to return
to the parent folder.
Use ENTER or cursor right ( ) button
to open a highlighted folder.
•You can also return to the parent folder
by going to the top of the list to the “ .. ”
folder, then pressing ENTER.
• When a JPEG file is highlighted, a
thumbnail image is displayed on the
right.
00:00/ 00:00 0kbps
Folder2
File1
File2
File3
File4
File5
33
PLAY
MODE
DV-SP404.404E_En.book Page 34 Wednesday, June 7, 2006 1:50 PM
Playing discs —Continued
Looping a section of a disc
The A-B Repeat function allows you to specify two
points (A and B) within a track (CD, Video CD) or title
(DVD) that form a loop which is played over and over.
•You can’t use A-B Repeat with Video CD in PBC
mode, or WMA/MP3/DivX Video files.
1
2
3
4
PLAY
MODE
ENTER
ENTER
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
During playback, press PLAY
MODE and select “A-B Repeat”
from the list of functions on the
left.
Play Mode
A-B Repeat
Repeat
Random
Program
Search Mode
Press ENTER on “A(Start Point)”
to set the loop start point.
Press ENTER on “B(End Point)” to
set the loop end point.
After pressing ENTER, playback jumps
back to the start point and plays the loop.
To resume normal playback, select
“Off” from the menu.
0
CLEAR
ENTER
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
MENU
SETUP
A(Start Point)
B(End Point)
Off
PLAY MODE
ENTER
Using repeat play
There are various repeat play options, depending on the
kind of disc loaded. It’s also possible to use repeat play
together with program play to repeat the tracks/chapters in
the program list (see “Creating a program list” on page 36).
Important:
•You can’t use Repeat play with Video CD in PBC
mode, or with WMA/MP3 discs.
•You can’t use repeat and random play at the same time.
1
2
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
During playback, press PLAY
MODE and select “Repeat” from
the list of functions on the left.
Play Mode
A-B Repeat
Repeat
Random
Program
Search Mode
Select a repeat play option.
If program play is active, select Program
Repeat to repeat the program list, or
Repeat Off to cancel.
The repeat options available depend on
the kind of disc loaded. For example, for
DVD discs, you can select Title Repeat
or Chapter Repeat (or Repeat Off).
Play Mode
A-B Repeat
Repeat
Random
Program
Search Mode
0
ENTER
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
CLEAR
MENU
SETUP
Title Repeat
Chapter Repeat
Repeat Off
Title Repeat
Chapter Repeat
Repeat Off
PLAY MODE
•For CDs and Video CD, select Disc
Repeat or Track Repeat (or Repeat
Off).
•For DivX video discs, select Title
Repeat (or Repeat Off).
34
DV-SP404.404E_En.book Page 35 Wednesday, June 7, 2006 1:50 PM
Playing discs —Continued
•
Using random play
Use the random play function to play titles or chapters
(DVD-Video) or tracks (CD, Video CD) at random.
(Note that the same track/title/chapter may play more
than once.)
You can set the random play option when a disc is playing or stopped.
Important:
• Random play remains in effect until you select Random Off from the random play menu options.
•You can’t use random play with VR format DVD-RW
discs, Video CD playing in PBC mode, WMA/MP3
discs, or while a DVD disc menu is being displayed.
•You can't use random play together with program or
repeat play.
ON STANDBY
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
123
45
6
789
CLEAR
0
ENTER
RC-616DV
OPEN/
CLOSE
MODE
DISPLAY
MENU
SETUP
PLAY
PLAY MODE
/
1
2
PLAY
MODE
Press PLAY MODE and select
“Random” from the list of functions on the left.
Play Mode
A-B Repeat
Repeat
Random
Program
Search Mode
Random Title
Random Chapter
Random Off
Select a random play option.
The random play options available
depend on the kind of disc loaded. For
example, for DVD discs, you can select
Random Title or Random Chapter, (or
Random Off).
Play Mode
A-B Repeat
Repeat
Random
Program
Search Mode
Random Title
Random Chapter
Random Off
•For CDs and Video CD, select On or
Off to switch random play on or off.
Tip:
Use the following controls during random play:
Button What it does
Selects a new track/title/chapter at
random.
Returns to the beginning of the current
track/title/chapter; further presses
select another random track/title/chapter.
35
DV-SP404.404E_En.book Page 36 Wednesday, June 7, 2006 1:50 PM
Playing discs —Continued
•
Creating a program list
This feature lets you program the play order of titles/
chapters/tracks on a disc.
Important:
•You can’t use Program play with VR format DVD-RW
discs, Video CD playing in PBC mode, WMA/MP3
discs, or while a DVD disc menu is being displayed.
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
0
RC-616DV
ENTER
CLEAR
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
MENU
SETUP
PLAY MODE
///
ENTER
3
4
Use the cursor (///) buttons and ENTER to select a title,
chapter or track for the current
step in the program list.
For a DVD disc, you can add a title or a
chapter to the program list.
Program
Program Step
01. 01
02.
03.
04.
05.
06.
07.
08.
Title 1~38
Title 01
Title 02
Title 03
Title 04
Title 05
Title 06
Title 07
Title 08
Chapter 1~004
Chapter 001
Chapter 002
Chapter 003
Chapter 004
•For a CD or Video CD, select a track to
add to the program list.
After pressing ENTER to select the title/
chapter/track, the step number automatically moves down one.
Repeat step 3 to build up a program list.
A program list can contain up to 24 titles/
chapters/tracks.
•You can insert steps into the middle of
a program list by just highlighting the
position where you want the new step
to appear and entering a title/chapter/
track number.
•To delete a step, highlight it and press
CLEAR.
1
2
PLAY
MODE
Press PLAY MODE and select
“Program” from the list of functions on the left.
Play Mode
A-B Repeat
Repeat
Random
Program
Search Mode
Create/Edit
Playback Start
Playback Stop
Program Delete
Select “Create/Edit” from the list of
program options.
5
To play the program list, press
(play).
Program play remains active until you
turn off program play (see below), erase
the program list (see below), eject the
disc or switch off the player.
Tip:
Use the following controls during program play:
Button What it does
Save the program list and exit the pro-
PLAY MODE
gram edit screen without starting playback (SETUP does the same).
Skip to the next step in the program list.
36
DV-SP404.404E_En.book Page 37 Wednesday, June 7, 2006 1:50 PM
Playing discs —Continued
Other functions available from the
program menu
There are a number of other options in the program
menu in addition to Create/Edit.
• Playback Start – Starts playback of a saved program
list
• Playback Stop – Turns off program play, but does not
erase the program list
• Program Delete – Erases the program list and turns
off program play
Searching a disc
You can search DVD discs by title or chapter number, or
by time; CDs and Video CD by track number or time;
DivX Video discs by time.
Important:
• Search functions are not available with Video CD in
PBC mode, or with WMA/MP3 discs.
ON STANDBY
Numbers
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
123
45
6
789
CLEAR
0
ENTER
OPEN/
CLOSE
PLAY
MODE
DISPLAY
MENU
SETUP
PLAY MODE
ENTER
3
123
45
789
0
4
ENTER
Use the number buttons to enter a
title, chapter or track number, or a
time.
6
Play Mode
A-B Repeat
Repeat
Random
Program
Search Mode
Title Search
Chapter Search
Time Search
Input Chapter
0 0 1
•For a time search, enter the number of
minutes and seconds into the currently
playing title (DVD) or track (CD/
Video CD) you want playback to
resume from. For example, press 4, 5,
0, 0 to have playback start from 45
minutes into the disc. For 1 hour, 20
minutes and 30 seconds, press 8, 0, 3,
0.
Press ENTER to start playback.
1
2
PLAY
MODE
RC-616DV
Press PLAY MODE and select
“Search Mode” from the list of
functions on the left.
The search options available depend on
the kind of disc loaded.
Select a search mode.
• The disc must be playing in order to
use time search.
37
AUDIO
DV-SP404.404E_En.book Page 38 Wednesday, June 7, 2006 1:50 PM
Playing discs —Continued
Switching subtitles
Some DVD or DivX Video discs have subtitles in one or
more languages; the disc box will usually tell you which
subtitle languages are available. You can switch subtitle
language during playback.
ON STANDBY
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
1
SUBTITLE
Press SUBTITLE repeatedly to
select a subtitle option.
Subtitle English1/2
Notes:
• Some discs only allow you to change
subtitle language from the disc menu.
Press TOP MENU or MENU to
access.
•To set subtitle preferences, see “Language settings” on page 45.
• See Displaying DivX subtitle files on page 9 for more
on DivX subtitle.
123
45
6
789
CLEAR
0
ENTER
Current / Total
OPEN/
CLOSE
MODE
DISPLAY
MENU
SETUP
PLAY
SUBTITLE
Switching audio language/channel
When playing a DVD or DivX Video disc recorded with
dialog in two or more languages, you can switch audio
language during playback.
When playing a VR format DVD-RW disc recorded with
dual-mono audio, you can switch between the main, sub,
and mixed channels during playback.
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO
AUDIO ANGLE SUBTITLE ZOOM
When playing a Video CD, you can switch between stereo, just the left channel or just the right channel.
1
Press AUDIO repeatedly to select
an audio language/channel option.
The language/channel information is
shown on-screen.
Notes:
• Some DVD discs only allow you to
change audio language from the disc
menu. Press TOP MENU or MENU to
access.
•To set DVD audio language preferences, see “Language settings” on
page 45.
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
CLEAR
0
MENU
ENTER
SETUP
38
MODE
DV-SP404.404E_En.book Page 39 Wednesday, June 7, 2006 1:50 PM
Playing discs —Continued
Zooming the screen
Using the zoom feature you can magnify a part of the
screen by a factor of 2 or 4, while watching a DVD, DivX
Video title or Video CD, or playing a JPEG disc.
1
ZOOM
2
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
DISPLAY
6
CLEAR
0
MENU
ENTER
SETUP
///
ZOOM
During playback, use the ZOOM
button to select the zoom factor
(Normal, 2x or 4x).
• Since DVD, DivX Video title, Video
CD and JPEG pictures have a fixed
resolution, picture quality will deteriorate, especially at 4x zoom. This is not
a malfunction.
Use the cursor (///) buttons to change the zoomed area.
You can change the zoom factor and the
zoomed area freely during playback.
• If the navigation square at the top of
the screen disappears, press ZOOM
again to display it.
Switching camera angles
Some DVD discs feature scenes shot from two or more
angles—check the disc box for details.
When a multi-angle scene is playing, a icon appears
on screen to let you know that other angles are available
(this can be switched off if you prefer—see “Display settings” on page 45).
ANGLE
1
ANGLE
During playback, press ANGLE to
switch angle.
CLEAR
0
TOP MENU
ENTER
RETURN
AUDIO ANGLE SUBTITLE ZOOM
MENU
SETUP
Displaying disc information
Various track, chapter and title information, such as the
elapsed and remaining playing time can be displayed onscreen while a disc is playing.
ON STANDBY
123
45
789
TOP MENU
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
CLEAR
0
MENU
DISPLAY
1
DISPLAY
To show/switch/hide the information displayed, press DISPLAY
repeatedly.
• When a disc is playing, the information appears at the top of the screen.
39
DV-SP404.404E_En.book Page 40 Wednesday, June 7, 2006 1:50 PM
Audio Settings and Video Adjust menus
Audio Settings menu
The Audio Settings menu offers features for adjusting
the way discs sound.
1
2
SETUP
ON STANDBY
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
Press SETUP and select “Audio
Settings” from the on-screen display.
Select and change settings using
the cursor (///) buttons,
123
45
6
789
CLEAR
0
ENTER
OPEN/
CLOSE
PLAY
MODE
DISPLAY
MENU
SETUP
Audio Settings
///
ENTER
SETUP
and ENTER.
ENTER
Audio Settings
Equalizer
Virtual Surround
Audio DRC
Dialog
On
Off
Dialog
• Settings: High, Medium, Low, Off (default)
The Dialog feature is designed to make the dialog stand
out from other background sounds in the soundtrack.
Audio DRC
• Settings: High, Medium, Low, Off (default)
When watching Dolby Digital DVDs at low volume, it’s
easy to lose the quieter sounds completely—including
some of the dialog. Switching Audio DRC (Dynamic
Range Control) to on can help by bringing up the quieter
sounds, while controlling loud peaks.
How much of a difference you hear depends on the material you’re listening to. If the material doesn’t have wide
variations in volume, you may not notice much change.
Notes:
• Audio DRC is only effective with Dolby Digital audio
sources.
• Audio DRC is only effective through the digital output
when Digital Out is set to On, and Dolby Digital Out
is set to Dolby Digital > PCM (see “Digital Audio Out
settings” on page 43).
• The effect of Audio DRC depends on your speakers
and AV receiver settings.
Virtual Surround
• Settings: On, Off (default)
Switch on Virtual Surround to enjoy realistic
surround sound effects from just two speakers.
Notes:
•Virtual Surround doesn’t work with DTS, through
either the analog or digital outputs.
• 96kHz linear PCM audio is automatically downsampled to 48kHz if Virtual Surround is switched on.
• If the player is outputting Dolby Digital, DTS or
MPEG bitstream audio (in other words, no conversion
to PCM), Virtual Surround has no effect on the audio
from the digital output. See Digital Audio Out settings
on page 43 for how to set up the digital output formats.
•How good the surround effect is varies with the disc.
Equalizer
• Settings: Rock, Pop, Live, Dance, Techno, Classic,
Soft, Off (default)
The various preset EQ curves are designed to suit various styles of music.
Note:
• 96kHz linear PCM audio is automatically downsampled to 48kHz if the Equalizer is switched on.
40
DV-SP404.404E_En.book Page 41 Wednesday, June 7, 2006 1:50 PM
Audio Settings and Video Adjust menus —Continued
Video Adjust menu
From the Video Adjust screen you can adjust various settings that affect how the picture is presented.
1
SETUP
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
Press SETUP and select “Video
Adjust” from the on-screen display.
0
ENTER
RC-616DV
OPEN/
CLOSE
DISPLAY
6
CLEAR
Video Adjust
MENU
MODE
SETUP
PLAY
///
ENTER
SETUP
2
3
ENTER
ENTER
Make settings using the cursor
(///) buttons, and ENTER.
Video Adjust
Sharpness
Brightness
Contrast
Gamma
Hue
Chroma Level
Standard
0
0
Off
0
0
You can adjust the following picture
quality settings:
• Sharpness – Adjusts the sharpness
of edges in the picture (Fine, Standard, Soft).
• Brightness – Adjusts the overall
brightness (–20 to +20).
• Contrast – Adjusts the contrast
between light and dark (–16 to +16).
• Gamma – Adjusts the “warmth” of
the picture (High, Medium, Low,
Off).
• Hue – Adjusts the red/green balance
(green 9 to red 9).
• Chroma Level – Adjusts how saturated colors appear (–9 to +9).
Adjust the Brightness, Contrast, Hue and
Chroma Level settings using the cursor
left/right ( / ) buttons.
Brightness min max
0
Press ENTER to save your settings and exit the Video Adjust
screen.
Notes:
• Depending on your TV, the picture may appear distorted if the brightness is set too high. If this happens,
lower the brightness.
• These settings for progressive scan apply to only component output.
41
DV-SP404.404E_En.book Page 42 Wednesday, June 7, 2006 1:50 PM
Initial Settings menu
Using the Initial Settings menu
The Initial Settings menu provides audio and video output settings, parental lock settings, and display settings,
among others.
If an option is grayed out it means that it cannot be
changed at the current time. This is usually because a
disc is playing. Stop the disc, then change the setting.
• The Digital Audio Out, Component Out and AV Connector Out settings cannot be set if the player is connected to an HDMI compatible component using the
HDMI connector.
1
2
SETUP
ENTER
ON STANDBY
123
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
45
6
789
CLEAR
0
ENTER
OPEN/
CLOSE
DISPLAY
MENU
SETUP
PLAY
MODE
///
ENTER
SETUP
Press SETUP and select “Initial
Settings”.
Initial Settings
Use the cursor (///) buttons and ENTER to select the setting and option you want to set.
All the settings and options are explained
on the following pages.
Notes:
• In the table on next pages, the default setting is shown
in bold: other settings are shown in italics.
• The Digital Audio Out settings only need to be set if
you have connected the digital output of this player to
an AV receiver, or other equipment.
• Check the operating instructions supplied with your
other equipment to see which digital audio formats it’s
compatible with.
• Some settings, such as TV Screen, Audio Language
and Subtitle Language may be overridden by the DVD
disc. Often these settings can also be made from the
DVD disc menu.
• The HDMI Out, HDMI Resolution and HDMI Color
settings only need to be set if you connected this
player to an HDMI compatible component using the
HDMI connector.
42
DV-SP404.404E_En.book Page 43 Wednesday, June 7, 2006 1:50 PM
Initial Settings menu —Continued
Digital Audio Out settings
Setting Option What it means
Digital Out
Dolby Digital Out
DTS Out
96 kHz PCM Out
MPEG Out
HDMI Out
On
Off No digital audio output.
Dolby Digital
Dolby Digital > PCM
DTS
Off No digital audio is output when playing a DTS disc.
96kHz > 48kHz
96kHz 96kHz digital audio is output as is at 96kHz.
MPEG > PCM
MPEG MPEG encoded digital audio is output as is.
LPCM (2 CH)
Auto
Off No digital audio output.
Digital audio is output from the digital outputs.
Dolby Digital encoded digital audio is output when playing a
Dolby Digital DVD disc.
Dolby Digital audio is converted to PCM audio before being
output.
DTS encoded digital audio is output when playing a DTS disc.
(Noise will be output if your amplifier/receiver is not compatible with DTS audio.)
96kHz digital audio is converted to 48kHz for digital output.
MPEG encoded digital audio is converted to PCM audio for
digital output.
Set if your monitor or device only accepts stereo input. On this
setting multichannel audio is downmixed to 2 channels for stereo linear PCM output. (In case of DTS source, the HDMI
audio output is turned off.)
Dolby Digital, DTS and MPEG sources are processed according to how they were encoded, but if your amplifier/monitor is
not compatible with DTS audio, DTS audio output from HDMI
is turned off. Linear PCM sources are heard as is.
43
DV-SP404.404E_En.book Page 44 Wednesday, June 7, 2006 1:50 PM
Initial Settings menu —Continued
Video Out settings
Setting Option What it means
TV Screen
(This setting effective
for analog and HDMI
video output. See also
“Screen sizes and disc
formats” on page 49.)
Component Out
AV Connector Out
(European model only)
HDMI Resolution
(Default changes with
TV format (PAL/NTSC).)
HDMI Color
(Default changes
depending on device
connected.)
4:3 (Letter Box)
4:3 (Pan & Scan)
16:9 (Wide) Set if you have a widescreen TV.
Interlace
Progressive
Video
RGB
1920x1080i Set if your TV supports 1920 x 1080 pixel interlace video.
1280x720p
720x480p (NTSC)/
720x576p (PAL)
720x480i (NTSC)/
720x576i (PAL)
Full range RGB If colors are weak, this gives brighter colors and deeper black.
RGB
Component
Set if you have a conventional 4:3 TV. Widescreen movies are
shown with black bars top and bottom.
Set if you have a conventional 4:3 TV. Widescreen movies are
shown with the sides cropped so that the image fills the screen.
Set if your TV is not compatible with progressive scan video.
Set if your TV is compatible with progressive scan video (see
your TV’s instruction manual for details). See also “Switching
the video output to interlace using the front panel controls” on
page 19.
Note that progressive scan video is only output from the component video jacks and that there is no output from the composite and S-video jacks when this setting is selected.
Ordinary (composite) video output, compatible with all TVs.
If your TV is compatible, this setting gives the best picture
quality.
Note that there is no output from the component jacks when
this setting is selected.
Set if your TV supports 1280 x 720 pixel progressive-scan
video.
Set if your TV supports 720 x 480 pixel (NTSC)/720 x 576
pixel (PAL) progressive-scan video.
Set if your TV supports 720 x 480 pixel (NTSC)/720 x 576
pixel (PAL) interlace video.
Use this setting if colors appear overly rich on the Full Range
RGB setting.
Outputs component video format (default setting for HDMIcompatible devices).
44
DV-SP404.404E_En.book Page 45 Wednesday, June 7, 2006 1:50 PM
Initial Settings menu —Continued
Language settings
Setting Option What it means
English
Audio Language
Subtitle Language
(See also Displaying
DivX subtitle files on
page 9.)
DVD Menu Lang.
Subtitle Display
*1 This setting is your preferred audio language for DVD discs.
You can switch between the languages recorded on a DVD disc during playback using the AUDIO button.
Some DVD discs set the audio language automatically when loaded, overriding the “Audio Language” setting.
Discs with two or more audio languages usually allow you to select the audio language from the disc menu. Press MENU to access
the disc menu.
*2 This setting is your preferred subtitle language for DVD discs.
You can change or switch off the subtitles on a DVD disc during playback using the SUBTITLE button.
Some DVD discs set the subtitle language automatically when loaded, overriding the “Subtitle Language” setting.
Discs with two or more subtitle languages usually allow you to select the subtitle language from the disc menu. Press MENU to
access the disc menu.
*3 Some multilingual discs have disc menus in several languages. This setting specifies in which language the disc menus should
appear. Leave on the default setting for menus to appear in the same language as your “Subtitle Language”.
*1
*3
Languages as displayed
Other Language
English
*2
Languages as displayed
Other Language
w/Subtitle Lang.
Languages as displayed
Other Language
On
Off
If there is an English soundtrack on the disc then it will be played.
If there is the language selected on the disc, then it will be played.
Select to choose a language other than the ones displayed
(see page 50).
If there is are English subtitles on the disc then they will be
displayed.
If there is the subtitle language selected on the disc, then it
will be displayed.
Select to choose a language other than the ones displayed
(see page 50).
DVD disc menus will be displayed in the same language as
your selected subtitle language, if possible.
DVD disc menus will be displayed in the selected language, if
possible.
Select to choose a language other than the ones displayed
(see page 50).
Subtitles are displayed according to your selected subtitle language (see above).
Subtitles are always off by default when you play a DVD disc
(note that some discs override this setting).
Display settings
Setting Option What it means
OSD Language
Angle Indicator
Optional settings
Setting Option What it means
Parental Lock
DivX VOD
English
Languages as displayed On-screen displays are shown in the language selected.
On
Off No multi-angle indication is shown.
- See Parental Lock on page 46.
Display See About DivX
On-screen displays of the player are in English.
A camera icon is displayed on-screen during multi-angle
scenes on a DVD disc.
®
VOD content on page 48.
45
ENTER
ENTER
123
6
789
0
45
ENTER
DV-SP404.404E_En.book Page 46 Wednesday, June 7, 2006 1:50 PM
Initial Settings menu —Continued
Parental Lock
• Default level: Off; Default password: none; Default
Country/Area code: us (2119)
To give you some control over what your children watch
on your DVD player, some DVD-Video discs feature a
Parental Lock level. If your player is set to a lower level
than the disc, the disc won’t play.
Some discs also support the Country/Area Code feature.
The player does not play certain scenes on these discs,
depending on the Country/Area code you set.
Notes:
• Not all discs use Parental Lock, and will play without
requiring the password first.
• If you forget your password, you’ll need to reset the
player to register a new password. (see page 49)
Registering a new password
You must register a password before you can change the
Parental Lock level or enter a Country/Area code.
1
Select “Password”.
Initial Settings
Digital Audio Out
Video Output
Language
Display
Options
Parental Lock
DivX VOD
Password
Level Change
Country Code
Changing your password
To change your password, confirm your existing password then enter a new one.
1
2
3
Select “Password Change”.
Use the number buttons to enter
your existing password, then
press ENTER.
Enter a new password and press
ENTER.
This registers the new password and you
will return to the Options menu screen.
Setting/changing the Parental Lock
1
2
Select “Level Change”.
Use number buttons to enter your
password, then press ENTER.
46
2
123
45
789
0
3
ENTER
Use the number buttons to enter a
4-digit password.
The numbers you enter show up as aster-
6
isks (*) on-screen.
Press ENTER to register the password.
You will return to the Options menu
screen.
3
Select a new level and press
ENTER.
• Press the cursor left ( ) button
repeatedly to lock more levels (more
discs will require the password); press
the cursor right ( ) button to unlock
levels. You can’t lock level 1.
This sets the new level and you will
return to the Options menu screen.
DV-SP404.404E_En.book Page 47 Wednesday, June 7, 2006 1:50 PM
Initial Settings menu —Continued
Setting/changing the Country/Area
code
You can find the Country/Area code list in the adjacent
column.
1
2
123
45
789
0
3
ENTER
Select “Country Code”.
Use number buttons to enter your
password, then press ENTER.
6
Select a Country/Area code and
press ENTER.
There are two ways you can do this:
• Select by code letter: Use the cursor
up/down ( / ) buttons to change the
Country/Area code.
• Select by code number: Press the cursor right ( ) button then use the number buttons to enter the 4-digit
Country/Area code.
The new Country/Area code is set and
you will return to the Options menu
screen. Note that the new Country/Area
code doesn’t take effect until the next
disc is loaded (or the current disc is
reloaded).
Country/Area code list
Country/Area
Argentina 0118 ar
Australia 0121 au
Austria 0120 at
Belgium 0205 be
Brazil 0218 br
Canada 0301 ca
Chile 0312 cl
China 0314 cn
Denmark 0411 dk
Finland 0609 fi
France 0618 fr
Germany 0405 de
Hong Kong 0811 hk
India 0914 in
Indonesia 0904 id
Italy 0920 it
Japan 1016 jp
Korea, Republic of 1118 kr
Malaysia 1325 my
Mexico 1324 mx
Netherlands 1412 nl
New Zealand 1426 nz
Norway 1415 no
Pakistan 1611 pk
Philippines 1608 ph
Por tugal 1620 pt
Russian Federation 1821 ru
Singapore 1907 sg
Spain 0519 es
Sweden 1905 se
Switzerland 0308 ch
Taiwan 2023 tw
Thailand 2008 th
United Kingdom 0702 gb
USA 2119 us
Country/Area
code
Country/Area
code letter
47
DV-SP404.404E_En.book Page 48 Wednesday, June 7, 2006 1:50 PM
Initial Settings menu —Continued
About DivX
®
VOD content
In order to play DivX VOD (video on demand) content
on this player, you first need to register the player with
your DivX VOD content provider. You do this by generating a DivX VOD registration code, which you submit
to your provider.
Important:
•DivX VOD content is protected by a DRM (Digital
Rights Management) system. This restricts playback
of content to specific, registered devices.
• If you load a disc that contains DivX VOD content not
authorized for your player, the message Authorization
Error is displayed and the content will not play.
• Resetting the player (as described in Resetting the
player in the main Operating Instructions) will not
cause you to lose your registration code.
Displaying your DivX VOD
registration code
1
SETUP
Press SETUP and select “Initial
Settings”.
Playing DivX
®
VOD content
Some DivX VOD content may only be playable a fixed
number of times. When you load a disc containing this
type of DivX VOD content, the remaining number of
plays is shown on-screen and you then have the option of
playing the disc (thereby using up one of the remaining
plays), or stopping. If you load a disc that contains
expired DivX VOD content (for example, content that
has zero remaining plays), the message Rental Expired
is displayed.
If your DivX VOD content allows an unlimited number
of plays, then you may load the disc into your player and
play the content as often as you like, and no message will
be displayed.
2
3
Select “Options”, then “DivX
VOD”.
Initial Settings
Digital Audio Out
Video Output
Language
Display
Options
Parental Lock
DivX VOD
Display
Select “Display”.
Your 8-digit registration code is displayed.
Initial Settings
Digital Audio Out
Video Output
Language
Display
Options
DivX (R) Video On Demand
Your registration code is:
To learn more visit www.divx.com/vod
0 1 2 3 4 5 6 7
Done
Make a note of the code as you will need
it when you register with a DivX VOD
provider.
48
DV-SP404.404E_En.book Page 49 Wednesday, June 7, 2006 1:50 PM
Additional information
Screen sizes and disc formats
DVD-Video discs come in several different screen aspect
ratios, ranging from TV programs, which are generally
4:3, to Cinema- Scope widescreen movies, with an
aspect ratio of up to about 7:3.
Televisions, too, come in different aspect ratios; “standard” 4:3 and widescreen 16:9.
Widescreen TV users
If you have a widescreen TV, the TV Screen setting
(page 44) of this player should be set to “16:9 (Wide)”.
When you watch discs recorded in 4:3 format, you can
use the TV controls to select how the picture is presented. Your TV may offer various zoom and stretch
options; see the instructions that came with your TV for
details.
Please note that some movie aspect ratios are wider than
16:9, so even though you have a widescreen TV, these
discs will still play in a “letter box” style with black bars
at the top and bottom of the screen.
Standard TV users
If you have a standard TV, the “TV Screen” setting
(page 44) of this player should be set to “4:3 (Letter
Box)” or “4:3 (Pan&Scan)”, depending on which you
prefer.
Set to “4:3 (Letter Box)”, widescreen discs are shown
with black bars top and bottom.
Resetting the player
Use this procedure to reset all the player’s settings to the
factory default.
1
2
Switch the player into standby.
Using the front panel buttons, hold
down the button and press
STANDBY/ON to switch the player
back on.
All the player’s settings are now reset.
Setting the TV system (Not North
American model)
The default setting of this player is “AUTO”, and unless
you notice that the picture is distorted when playing
some discs, you should leave it set to “AUTO”. If you
experience picture distortion with some discs, set the TV
system to match your country or region’s system. Doing
this, however, may restrict the kinds of disc you can
watch. The table below shows what kinds of disc are
compatible with each setting (“AUTO” , “PAL” and
“NTSC”).
Set to “4:3 (Pan&Scan)”, widescreen discs are shown
with the left and right sides cropped.
Although the picture looks larger, you don’t actually see
the whole picture.
Please note that many widescreen discs override the
player’s settings so that the disc is shown in letter box
format regardless of the setting.
Note:
• Using the “16:9 (Wide)” setting with a standard 4:3
TV, or either of the “4:3” settings with a widescreen
TV, will result in a distorted picture.
STANDBY/ON
1
2
If the player is on, press
ON to switch it to standby.
Using the front panel controls,
hold down then press
STANDBY/ON to switch the TV system.
The TV system changes as follows:
AUTO NTSC PAL
STANDBY/
49
ENTER
ENTER
DV-SP404.404E_En.book Page 50 Wednesday, June 7, 2006 1:50 PM
Additional information —Continued
Note:
•You have to switch the player into standby (press
STANDBY/ON) before each change.
Disc Player setting
Type Format NTSC PAL AUTO
DVD,
NTSC
NTSC PAL NTSC
Video CD,
DivX video
CD/MP3/
WMA/JPEG/
no disc
PA L
–
NTSC PAL PAL
NTSC PAL
NTSC or
PA L
Titles, chapters and tracks
DVD discs are generally divided into one or more titles.
Titles may be further subdivided into chapters.
Title 1 Title 2 Title 3
Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 1 Chapter 2
CDs and Video CDs are divided into tracks.
DVD-Video regions
All DVD-Video discs carry a region mark on the case
somewhere that indicates which region(s) of the world
the disc is compatible with. Your DVD player also has a
region mark, which you can find on the rear panel. Discs
from incompatible regions will not play in this player.
Discs marked “ALL” will play in any player.
The diagram below shows the various DVD regions of
the world.
1
2
4
2
5
6
3
5
1
2
4
Selecting languages using the
language code list
Some of the language options (such as “DVD Language”
in the Setup Navigator) allow you to set your prefered
language from any of the 136 languages listed in the language code list on page 51.
Tra c k 1 Track 2 Track 3 Track 4 Track 5 Track 6
CD-ROMs contain folders and files. MP3 and WMA
files are referred to as tracks. Folders may contain further
folders.
.jpg
.mp3
Folder A Folder B Folder C
Track 1 Track 2 Track 3 Track 1 File 1 File 2
.mp3
.mp3
.mp3
.jpg
1
2
3
ON STANDBY
123
45
789
TOP MENU
RETURN
AUDIO ANGLE SUBTITLE ZOOM
OPEN/
CLOSE
PLAY
MODE
DISPLAY
6
CLEAR
0
MENU
ENTER
SETUP
///
Select “Other Language”.
Use the cursor left/right (
/)
buttons to select either a code letter or a code number.
Use the cursor up/down (
/)
buttons to select a code letter or a
code number.
See “Language code list” on page 51 for
a complete list of languages and codes.
50
DV-SP404.404E_En.book Page 51 Wednesday, June 7, 2006 1:50 PM
Additional information —Continued
Language code list
Language
Japanese ja 1001
English en 0514
French fr 0618
German de 0405
Italian it 0920
Spanish es 0519
Chinese zh 2608
Dutch nl 1412
Por tuguese pt 1620
Swedish sv 1922
Russian ru 1821
Korean ko 1115
Greek el 0512
Afar aa 0101
Abkhazian ab 0102
Afrikaans af 0106
Amharic am 0113
Arabic ar 0118
Assamese as 0119
Aymara ay 0125
Azerbaijani az 0126
Bashkir ba 0201
Byelorussian be 0205
Bulgarian bg 0207
Bihari bh 0208
Bislama bi 0209
Bengali bn 0214
Tibetan bo 0215
Breton br 0218
Catalan ca 0301
Corsican co 0315
Czech cs 0319
Welsh cy 0325
Danish da 0401
Bhutani dz 0426
Esperanto eo 0515
Estonian et 0520
Basque eu 0521
Persian fa 0601
Finnish fi 0609
Fiji fj 0610
Faroese fo 0615
Frisian fy 0625
Irish ga 0701
Scots-Gaelic gd 0704
Galician gl 0712
Guarani gn 0714
Gujarati gu 0721
Hausa ha 0801
Hindi hi 0809
Croatian hr 0818
Language
code
letter
Language
code
Language
Hungarian hu 0821
Armenian hy 0825
Interlingua ia 0901
Interlingue ie 0905
Inupiak ik 0911
Indonesian in 0914
Icelandic is 0919
Hebrew iw 0923
Yiddish ji 1009
Javanese jw 1023
Georgian ka 1101
Kazakh kk 1111
Greenlandic kl 1112
Cambodian km 1113
Kannada kn 1114
Kashmiri ks 1119
Kurdish ku 1121
Kirghiz ky 1125
Latin la 1201
Lingala ln 1214
Laothian lo 1215
Lithuanian lt 1220
Latvian lv 1222
Malagasy mg 1307
Maori mi 1309
Macedonian mk 1311
Malayalam ml 1312
Mongolian mn 1314
Moldavian mo 1315
Marathi mr 1318
Malay ms 1319
Maltese mt 1320
Burmese my 1325
Nauru na 1401
Nepali ne 1405
Norwegian no 1415
Occitan oc 1503
Oromo om 1513
Oriya or 1518
Panjabi pa 1601
Polish pl 1612
Pashto,Push
to
Quechua qu 1721
RhaetoRomance
Kirundi rn 1814
Romanian ro 1815
Kinyarwanda rw 1823
Sanskrit sa 1901
Sindhi sd 1904
Language
code
letter
Language
code
ps 1619
rm 1813
Language
Sangho sg 1907
SerboCroatian
Sinhalese si 1909
Slovak sk 1911
Slovenian sl 1912
Samoan sm 1913
Shona sn 1914
Somali so 1915
Albanian sq 1917
Serbian sr 1918
Siswati ss 1919
Sesotho st 1920
Sundanese su 1921
Swahili sw 1923
Tamil ta 2001
Telugu te 2005
Tajik tg 2007
Thai th 2008
Tigrinya ti 2009
Tu r kmen tk 2011
Tagalog tl 2012
Setswana tn 2014
Tonga to 2015
Tu r kish tr 2018
Tsonga ts 2019
Tatar tt 2020
Tw itw2023
Ukrainian uk 2111
Urdu ur 2118
Uzbek uz 2126
Vietnamese vi 2209
Volapük vo 2215
Wolof wo 2315
Xhosa xh 2408
Yo r uba yo 2515
Zulu zu 2621
Language
code
letter
Language
code
sh 1908
51
DV-SP404.404E_En.book Page 52 Wednesday, June 7, 2006 1:50 PM
Glossary
Analog audio
An electrical signal that directly represents sound. Compare this to digital audio which can be an electrical signal, but is an indirect representation of sound. See also
“Digital audio”.
Aspect ratio
The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the screen is almost
square); widescreen models are 16:9 (the screen is
almost twice as wide as it is high).
Digital audio
An indirect representation of sound by numbers. During
recording, the sound is measured at discrete intervals
(44,100 times a second for CD audio) by an analog-todigital converter, generating a stream of numbers.
On playback, a digital-to-analog converter generates an
analog signal based on these numbers. See also “Sampling frequency” and “Analog audio”.
*1
DivX
DivX is a media technology created by DivX,
Inc. DivX media files contain compressed video. DivX
files can also include advanced media features like
menus, subtitles, and alternate audiotracks.
Dolby Digital
*2
Using a maximum of 5.1 channels of audio,
this high quality surround system is used in many of the
finer movie theaters around the world.
The on-screen display shows which channels are active,
for example showing 3/2.1. The 3 being the two front
channels and the center channel; the 2 being the surround channels, and the .1 being the LFE channel.
DRM
DRM (digital rights management) is a type of server
software developed to enable secure distribution of paid
content over the web, recently incorporated by WMA
(Windows Media Audio).
*3
DTS
DTS stands for Digital Theater Systems. DTS is
a surround system different from Dolby Digital that has
become a popular surround sound format for movies.
Dynamic range
The difference between the quietest and loudest sounds
possible in an audio signal (without distorting or getting
lost in noise).
Dolby Digital and DTS soundtracks are capable of a
very wide dynamic range, delivering dramatic cinemalike effects.
*1. DivX, DivX Certified, and associated logos are trademarks of
DivX, Inc. and are used under license.
*2. Manufactured under license from Dolby Laboratories. “Dolby”
and the double-D symbol are trademarks of Dolby Laboratories.
*3. “DTS” and “DTS Digital Out” are registered trademarks of
Digital Theater Systems, Inc.
52
EXIF (Exchangeable Image File)
A file format developed by Fuji Photo Film for digital
still cameras. Digital cameras from various manufacturers use this compressed file format which carries date,
time and thumbnail information, as well as the picture
data.
File extension
A tag added to the end of a filename to indicate the type
of file. For example, “.mp3” indicates an MP3 file.
*4
HDMI
HDMI (High-Definition Multimedia Interface) is a highspeed digital interface which has the capability to support standard, enhanced, or highdefinition video plus
standard to multichannel surround-sound audio on a single digital connection. HDMI features include uncompressed digital video, a bandwidth of up to 5 gigabytes
per second and communication between the AV source
and AV devices such as DTVs.
ISO 9660 format
International standard for the volume and file structure
of CD-ROM discs.
JPEG
A file format used for still images, such as photographs
and illustrations. JPEG files are identified by the file
extension “.jpg” or “.JPG”. Most digital cameras use this
format.
MP3
MP3 (MPEG1 audio layer 3) is a compressed audio file
format. Files are recognized by their file extension
“.mp3” or “.MP3”.
MPEG audio
An audio format used on Video CDs and some DVD
discs. This unit can convert MPEG audio to PCM format
for wider compatibility with digital recorders and AV
amplifiers. See also “PCM (Pulse Code Modulation)”.
MPEG video
The video format used for Video CDs and DVDs. Video
CD uses the older MPEG-1 standard, while DVD uses
the newer and much better quality MPEG-2 standard.
PBC (PlayBack Control) (Video CD only)
A system of navigating a Video CD through on-screen
menus recorded onto the disc. Especially good for discs
that you would normally not watch from beginning to
end all at once—karaoke discs, for example.
PCM (Pulse Code Modulation)
The most common system of encoding digital audio,
found on CDs and DAT. Excellent quality, but requires a
lot of data compared to formats such as Dolby Digital
and MPEG audio. For compatibility with digital audio
recorders (CD, MD and DAT) and AV amplifiers with
digital inputs, this unit can convert Dolby Digital, DTS
and MPEG audio to PCM. See also “Digital audio”.
*4. HDMI, the HDMI logo and High-Definition Multimedia Inter-
face are trademarks or registered trademarks of HDMI licensing LLC.
DV-SP404.404E_En.book Page 53 Wednesday, June 7, 2006 1:50 PM
Glossary —Continued
Progressive scan video
All the lines that make up a video picture are updated in
one pass (compared to interlace which takes two passes
to update the whole picture).
Regions (DVD-Video only)
These associate discs and players with particular areas of
the world. This unit will only play discs that have compatible region codes. You can find the region code of
your unit by looking on the rear panel. Some discs are
compatible with more than one region (or all regions).
Sampling frequency
The rate at which sound is measured to be turned into
digital audio data. The higher the rate, the better the
sound quality, but the more digital information is generated. Standard CD audio has a sampling frequency of
44.1kHz, which means 44,100 samples (measurements)
per second. See also “Digital audio”.
WMA
WMA is short for Windows Media Audio and refers to
an audio compression technology developed by
Microsoft Corporation. WMA data can be encoded by
using Windows Media Player version 8 or Windows
Media Player for Windows XP.
53
DV-SP404.404E_En.book Page 54 Wednesday, June 7, 2006 1:50 PM
Troubleshooting
If you have any trouble using your DV-SP404/DV-SP404E, check the following table for possible causes and remedies.
If you still can’t resolve the issue yourself, please contact your Onkyo dealer.
Symptoms Causes Remedies
Connect the power cord to a suitable wall outlet
(page 23).
Turn off the DV-SP404/DV-SP404E, wait five seconds, then try turning it on again. If that fails, disconnect the power cord from the wall outlet, wait
five seconds, reconnect it, then try turning it on
again.
Place the disc in the center of the disc tray
(page 26).
Use only compatible discs (page 8).
Place the disc in the center of the disc tray
(page 26).
Turn off the Parental Lock function (page 46).
If the region number on the disc does not match
the region number on the DV-SP404/DV-SP404E,
the disc can’t be played (page 50).
A little picture distortion may occur when using
these functions. This is normal.
Connect the DV-SP404/DV-SP404E directly to
your TV (page 18).
On your TV, select the input to which the DVSP404/DV-SP404E is connected.
Check the video cable and correct as necessary
(page 18).
Before you disconnect the power cord, set the DVSP404/DV-SP404E to Standby by pressing the
[STANDBY/ON] button, and wait until “OFF”
has disappeared from the display.
Connect the DV-SP404/DV-SP404E directly to
your TV (page 18).
Reset the DV-SP404/DV-SP404E to its initial settings (page 42).
Select normal playback (pages 34–36).
Turn off the DV-SP404/DV-SP404E, wait five seconds, then turn it on again. If that doesn’t resolve
the issue, disconnect the power cord from the wall
outlet, wait five seconds, reconnect it, then try
again.
Can’t turn on the DVSP404/DV-SP404E?
The disc tray won’t
close properly?
Can’t start playback?
The picture distorts
occasionally?
Picture instability or
DVD Player
noise?
No picture?
Settings are not saved?
Brightness is unstable
or the picture is noisy?
Chapters or tracks don’t
play in the correct
order?
Buttons on the DVSP404/DV-SP404E and
remote controller don’t
work?
The power cord is not connected.
External interference is affecting the DVSP404/DV-SP404E’s digital circuitry.
The disc is not centered in the disc tray.
The disc is dirty. Remove the disc and clean it (page 10).
No disc is loaded. Load a disc (page 26).
The disc cannot be played because it’s
incompatible.
The disc is upside down. Load the disc the correct way up (page 26).
The disc is not centered in the disc tray.
The disc is dirty. Remove the disc and clean it (page 10).
The disc uses parental lock and the Paren-
tal Lock function is on.
The DVD-Video disc is intended for use
in another region.
The disc is dirty. Remove the disc and clean it (page 10).
You’re using the Fast Forward or Fast
Reverse function.
The DV-SP404/DV-SP404E is connected
to your TV via a VCR or other video
equipment and a copy-protection system
is affecting the picture.
The wrong input source is selected on
your TV.
The video cable is not connected properly.
If there’s a power failure, or the power
cord is disconnected inadvertently, any
settings are lost.
The DV-SP404/DV-SP404E is connected
to your TV via a VCR or other video
equipment and a copy-protection system
is affecting the picture.
Your TV doesn’t support progressive
scanning.
You are using repeat playback, program
playback, or random playback.
Power supply voltage fluctuations and
other anomalies, such as static electricity,
can interfere with normal operation.
54
DV-SP404.404E_En.book Page 55 Wednesday, June 7, 2006 1:50 PM
Troubleshooting —Continued
No sound?
The picture appears
stretched or the wrong
shape?
Audio CD playback
skips or jumps or is
noisy?
An audio CD is loaded
DVD Player
but the DV-SP404/DVSP404E displays “NO
DISC”?
The first track doesn’t
play?
Locating a specific
point takes longer than
usual?
Playback starts in the
middle of a track?
Some sections of a
track are skipped?
Playback stops in the
middle of a track?
The DV-SP404/DVSP404E displays the
wrong messages?
Some MP3 files don’t
play?
The 96 kHz PCM Out setting is set to
“96 kHz.”
The Digital Out setting is set to “Off.” Change the Digital Out setting to “On” (page 43).
The wrong input source is selected on
your TV, hi-fi amp, or AV receiver.
The audio cable is not connected properly. Check the audio cable and correct as necessary.
The TV, hi-fi amp, or AV receiver con-
nected to the DV-SP404/DV-SP404E’s
audio outputs is either not on or its volume
is turned down.
A DV-SP404/DV-SP404E Digital Audio
Out setting is set incorrectly.
Playback is paused. Resume playback (page 27).
The DVD-Video disc or CD uses the DTS
audio format and you are using the analog
outputs.
The TV Screen setting is wrong.
The loaded audio CD uses copy control.
MP3 files without a “.mp3” or “.MP3”
filename extension are not recognized.
The MP3 disc is a multisession disc.
Change the 96 kHz PCM Out setting to “96 kHz >
48 kHz,” or use analog connections (page 43).
On your TV, hi-fi amp, or AV receiver, select the
input to which the DV-SP404/DV-SP404E is connected.
Turn on the TV, hi-fi amp, or AV receiver and set
its volume as appropriate.
Check the Digital Audio Out settings and correct
as necessary (page 43).
DTS audio is only output by the digital outputs. To
play DTS material you need to connect one of the
DV-SP404/DV-SP404E’s digital outputs to a digital input on a hi-fi amp or AV receiver that has a
DTS decoder built-in (page 22).
Set the TV Screen setting to match the aspect ratio
of your TV (page 44).
Copy-controlled CDs are special discs that don’t
conform to the audio CD standard and, therefore,
may not work properly with the DV-SP404/DVSP404E.
Use the correct filename extension (page 8).
The DV-SP404/DV-SP404E doesn’t fully support
multisession discs. Only files in the first session
can be played (page 8).
55
DV-SP404.404E_En.book Page 56 Wednesday, June 7, 2006 1:50 PM
Troubleshooting —Continued
Can’t play MP3/WMA/
JPEG discs?
Can’t select MP3 files?
Can’t play WMA files?
DVD Player
Can’t view JPEG files?
Buttons on the DVSP404/DV-SP404E work
OK but those on the
remote controller
don’t?
Remote Controller
The disc is not ISO 9660 Level 1 or 2 format.
The disc has not been finalized. Finalize the disc (page 8).
MP3 files without a “.mp3” or “.MP3”
filename extension are not recognized.
WMA files without a “.wma” or “.WMA”
filename extension are not recognized.
The WMA file’s copyright option is on. Don’t use the copyright option (page 9).
JPEG files without a “.jpg” or “.JPG” file-
name extension are not recognized.
Only Baseline JPEG files are supported.
Progressive JPEG files are not.
There are no batteries in the remote
controller.
The batteries are flat. Replace with new batteries (page 11).
The batteries are installed incorrectly.
You’re not pointing the remote controller
at the DV-SP404/DV-SP404E’s remote
sensor.
You’re too far away from the DV-SP404/
DV-SP404E.
A strong light source is interfering with
the DV-SP404/DV-SP404E’s remote sensor.
If the DV-SP404/DV-SP404E is installed
in a cabinet with colored glass doors, the
remote controller may not work reliably
when the doors are closed.
Correct format should be used when recording is
ISO 9660 and closed session (page 8).
Use the correct filename extension (page 8).
Use the correct filename extension (page 8).
Use the correct filename extension (page 8).
Use Baseline JPEG files (page 9).
Install new batteries (page 11).
Check the batteries and correct as necessary
(page 11).
Point the remote controller at the DV-SP404/DVSP404E’s remote sensor (page 11).
Use the remote controller closer to the DV-SP404/
DV-SP404E (page 11). The remote controller has
a range of approximately 5 meters.
Make sure that the DV-SP404/DV-SP404E is not
subjected to direct sunshine or inverter-type fluorescent lights. Relocate if necessary.
Open the doors, or use a cabinet without colored
glass.
56
DV-SP404.404E_En.book Page 57 Wednesday, June 7, 2006 1:50 PM
Troubleshooting —Continued
HDMI troubleshooting
Incorrect operation is often mistaken for trouble or malfunction. If you think that there is something wrong with this
component, check the points below. Sometimes the trouble may lie in another component. Inspect the other components
and electrical appliances being used. If the trouble cannot be rectified after checking the items below, ask our customer
center or your dealer to carry out repair work.
Problem Remedy
• This unit has been designed to be compliant with HDMI (High Definition Multimedia Interface). Depending on the component you have connected, unreliable signal
transfers may result.
• If the front panel HDMI indicator is lit:
You won’t hear any sound from the HDMI output if the source component is
→
only DVI/HDCP-compatible.
No HDMI audio output.
No HDMI video output
No multichannel HDMI audio.
A connected DVI component (with
HDCP) doesn’t work with this
player.
Note:
• Static electricity or other external influences may cause malfunctioning of this unit. In this case, unplug the power
cord and then plug back in. This will usually reset the unit for proper operation. If this does not correct the problem,
please consult your nearest our customer center.
• If the front panel HDMI indicator is unlit then:
→
Make sure that you’ve selected this player as the HDMI input in the settings for
the component you’re using. You may need to refer to the instruction manual of
the component to do this.
Check that the HDMI cable is connected properly and that the cable isn’t dam-
→
aged.
Check that components connected using the HDMI interface are switched on
→
and HDMI compatible.
• Make sure that you’ve selected this player as the HDMI input in the settings for the
component you’re using. You may need to refer to the instruction manual of the component to do this.
• Check that the HDMI cable is connected properly and that the cable isn’t damaged.
• Check that components connected using the HDMI interface are switched on and
HDMI compatible.
• This unit has been designed to be compliant with HDMI (High Definition Multimedia Interface). Depending on the component you have connected, using a DVI connection may result in unreliable signal transfers.
• Make sure the resolution on this player matches that of the component you have
connected using HDMI. See HDMI Resolution on page 44 to change the HDMI resolution. See Resetting the output resolution to the default setting with HDMI connection on page 21 if you want to reset the output resolution.
• Make sure the HDMI OUT setting is set to Auto (see HDMI Out on page 43 to do
this).
• This unit has been designed to be compliant with HDMI (High Definition Multimedia Interface). Depending on the component you have connected, using a DVI connection may result in unreliable signal transfers.
The DV-SP404/DV-SP404E contains a microcomputer for signal processing and control functions. In very rare situations, severe interference, noise from an external source, or static electricity may cause it to lockup. In the unlikely
even that this should happen, unplug the power cord from the wall outlet, wait at least five seconds, and then plug it
back in again.
57
DV-SP404.404E_En.book Page 58 Wednesday, June 7, 2006 1:50 PM
Specifications
■
Signal System
Composite Video Output/Impedance
S-Video Output/Impedance (not European model)
Component Video Output/Impedance
HDMI Out
AV Connector (European model only)
Frequency response
S/N Ratio
Audio Dynamic Range
THD (Total Harmonic Distortion)
Wow and Flutter
Audio Output (Digital Optical)
Audio Output/Impedance (Digital Coaxial)
Audio Output/Impedance (Analog)
DVD Linear Sound
Audio CD 4 Hz–20 kHz (44.1 kHz)
General
Power Supply
Power Consumption
Stand-by Power Consumption
Dimensions (W x H x D)
Weight
Operation Condition Temperature
Disc Compatibility
NTSC/PAL/AUTO
1.0 V (p-p)/75 Ω negative sync, RCA/phono
Y: 1.0 V (p-p)/75 Ω negative sync, 4-pin mini DIN
C: 0.286 V (p-p)/75 Ω
Y: 1.0 V (p-p)/75 Ω
PB/PR: 0.7 V (p-p)/75 Ω RCA/phono
19 pin connector
1.0 V (p-p)/75 Ω , 21 pin connector
4 Hz–44 kHz (96 kHz)
4 Hz–22 kHz (48 kHz)
115 dB
88 dB
0.0065 % (1 kHz)
Below threshold of measurability
–22.5 dBm (Oceanian model only)
0.5 V (p-p)/75 Ω
2.0 V (rms)/440 Ω
AC 120 V, 60 Hz (North American model)
AC 110–240 V, 50 Hz/60 Hz (Oceanian model)
AC 220–240 V, 50 Hz/60 Hz (European model)
7 W
0.5 W (North American model)
0.7 W (European and Oceanian models)
435 W x 61 H x 215.5 D mm
1.9 kg
+5˚ C to +40˚ C
DVD-video, DVD-R/RW, DVD+R/RW, Audio CD, CD-R/RW,
Video CD, MP3, WMA, JPEG, DivX Video
Disc that have not been property finalized may only be partially
playable or not playable at all
Specifications and features subject to change without notice.
