SERVICE MANUAL
SERVICE MANUAL
DVD PLAYER
MODEL DV-SP1000
Ref. No. 3791
ON STANDBY
T
V
INPUT
I
AMP INPUT
V1 V2
M
P
O
T
R
E
T
U
STEP/SLOW
SBTTL
A-B
V OFFV IN
RC-563DV
+
T V CH
-
T
V VOL
CLEAR
DMS
INPUT
V3
MODE
TVDVD AMP VCR
CONTROL
M
U
N
E
E
N
U
ENTER
VOL
P
U
T
R
E
N
S
MUTING
RANDOM
ANGLESUBTITLEAUDIO
RESOLUTION
RSLTNANGLE
ASPECTA-BREPEAT
ASPECT
LEARNING
L2L1
L4
L3
123
456
789
+
10 0
SEARCH MEMORY DIMMER AMP INPUT
DVD
ZOOM ON
AUDIO
SEL
+
CH
ZOOM
L MODE
-
DISPLAY
LAST
MEMORY
REC
LM RD
AUDIO
REPEAT
VIDEO INPUT VIDEO OFF
OPEN/CLOSE
DV-SP1000
122004
Black, Silver and Golden models
BUDC1N, SUDC1N
BUPP2P, SUPP2P
GUGK3P
GUGR6P, GUWT3P
120V AC, 60Hz
230-240V AC, 50Hz
220-230V AC, 50/60Hz
120/220-230V AC, 50/60Hz
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
RC-563DV
Page 2
SERVICE PROCEDURES-1
DV-SP1000
This set employs a laser. Therefore, be sure to follow
carefully the instructions below when servicing.
WARNING!!
SERVICE WARNING : DO NOT APPROACH THE
LASER EXIT WITH THE EYE TOO CLOSELY.
IN CASE IT IS NECESSARY TO CONFIRM LASER
BEAM EMISSION, BE SURE TO OBSERVE FROM
A DISTANCE OF MORE THAN 30cm FROM THE
SURFACE OF THE OBJECTIVE LENS ON THE
OPTICAL PICKUP BLOCK.
WARNING
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
LASER WARNING
This unit contains a semiconductor laser system and is classified
as a "CLASS 1 LASER PRODUCT". So, to use this model
properly, read this Instruction Manual carefully. In case of any
trouble, please contact the store where you purchased the unit.
To prevent being exposed to the laser beam, do not try to open
the enclosure.
CAUTION:
VISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK
FAILED OR DEFEATED. DO NOT STARE INTO BEAM.
CAUTION:
THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MA
HAZARDOUS RADIATION EXPOSURE.
Y RESULT IN
Laser Diode Properties
CD
Wavelength:
Laser output:
650 nm
0.43 mW
DVD
Wavelength:
Laser output:
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
The label on the right
is applied on the rear
panel except for USA
and Canadian
models.
1. This unit is a CLASS 1 LASER PRODUCT and employs a
laser inside the cabinet.
2. To prevent the laser from being exposed, do not remove
the cover. Refer servicing to qualified personnel.
780 nm
0.14 mW
AVIS
RISQUE DE CHOC ELECTRIQUE
NE PAS
OUVRIR
"CLASS 1 LASER
PRODUCT "
SERVICE PROCEDURE
1. Replacing the fuses
This symbol located near the fuse indicates that the
fuse used is show operating type, For continued protection against
fire hazard, replace with same type fuse , For fuse rating, refer to
the marking adjest to the symbol.
Ce symbole indique que le fusible utilise est e lent.
Pour une protection permanente, n'utiliser que des fusibles de meme
type. Ce demier est indique la qu le present symbol est apposre.
REF. NO.
F001 or
PART NO.
252158
252252
F001 or
252075
252275
F9001 or 252160
252254
F9001 or
252075
252275
DESCRIPTION
1.6A-UL/T-237
1.6A-T/UL-ST2
2.5A-SW-EAK
2.5A-SE-TL250V
2.5A-UL/T-237
2.5A-T/UL-ST2
2.5A-SE-EAK
2.5A-SE-TL250V
Only <DC1N>
Only <DC1N>
Except <DC1N>
Except <DC1N>
Only <DC1N>
Only <DC1N>
Except <DC1N>
Except <DC1N>
LASER BEAM CAUTION LABEL
NOTE:
<DC1N>: U.S.A., Canadian region
Page 3
SERVICE PROCEDURES-2
2. Safety-check out
(Only U.S.A. model)
After correcting the original service problem perform the
following safety check before releasing the set to the customer
Connect the insulating-resistance tester between the plug of
power supply cord and terminal GND on the back panel.
Specifications: More than 10M ohm at 500V
INITIALIZING
Factory-shipped condition
Push button "ON" (Mechanical SW) Except <DC1N>
Press the [STOP] and [STANDBY] same time.
(Wait until FL display "No Disc") .
Push button "STANDBY".
DV-SP1000
Others
SURR. MODE Switch -------- "1" position
Mechanical power switch ---- ON
Page 4
EXPLODED VIEW-1
OVERALL
A
1
2
3
4
5
BCDEFGH
P4204B
P6302B
P6005B
P6303B
P6703A
P6551B
P5402B
P7010B
Voltage select
P1101A
U01
U05
U09
U08
U21
U13
U12
P9604
F001
F9001
P9102
P9104
U18
A77
x 4
A75
x 11
A45
x 2
A10
x 2
A43
x 2
A53
x 2
A35
x 2
A625
x 4
Z701
x 4
A33
x 2
A05
x 3
L902-
L905
x 4
A05
x 2
A29
x 2
A423
x 2
A10
x 4
A09
x 2
A05
x 28
A95
x 2
A06
x 4
A04
x 2
A45
x 2
A05
x 2
A49
x 2
A58
A10
x 4
A57
x 4
A79
x 4
A81
x 4
A80
T901
A05
A47
A619
A427
A01
A73
A16
A08
A13
A14
A12
A44
A999
Z711
E1001
x 5
A51
A429
Z723
A31
A621
A05
A58
A58
A60
A05
A02
A24
P4202
P4203
P4950
P4005
P4003
P3002
P1302
P1301
P2001
P2002
P2003
P2004
P9601
P9602
A300
A39
A41
(Except <GR>)
E1001
A425
A999
A623
L901
P1001A
From Pickup
P4204
P6703
U04
P7010
Except <DC>
<DC> only
Z723
Z713
x 2
Z714
x 2
Tra y
Z725
A10
x 2
Cloth
tape
x2
Cloth
tape
A39
Page 5
DV-SP1000
A311
P5001A
P5401A
P5402A
P5002A
U07
U02
U03
U06
U15
U19/U20
U10
A05
x 3
A411
A215
x 4
A227
x 2
A221
x 2
A17
x 2
A05
x 11
A10
x 3
A203
x 2
A221
x 2
Included A11
x 10
A91
x 4
A87
x 2
A95
x 2
A95
x 2
A97
x 7
A95
x 2
A63
x 2
A71
x 6
A67
x 3
A89
x 4
A91
x 4
A55
x 8
A05
x 5
A22
x 2
A23
x 2
A421
x 10
A325
x 3
A11
A21
A18
A207
A205
A217
A213
A617
A95
A37
A15
A19
A16
A101
A20
A211
P7201
P9103
P6551
P6005
P4571
P2901
P4008
P2701
A201
A05
E1001
A301
A323
A317
A83
A85
Cloth tape
A427
A50
A65
A93
A07
only <GK, WT, PP>
Powe SW
A331
A401
A403
A405
A407
A409
A05
x 3
A615
A613
Tape
P5402
P6302
Tape
P7010A
U14
i.Link/ RS-232C
HDMI
Z713
x 2
A615
x 2
Cloth tape
Cloth tape
Cloth
tape
Page 6
EXPLODED VIEW-2
DVD LOADER MECHANISM Z711: MGD-33
Parts No. 24801022
20
Z727
DV-SP1000
Z720
x 2
20
15
6
28
5
18
17
9
11
16
Z720
20
Z715
(BLUE)
Z710
Traverse Mecha.
KHM-280AAA
13
Z720
20
34
12
20
35
14
Z716
(BLK)
x 2
7
4
24
16
Z720
Z720
1
Z717
x 2
Z715
(BLUE)
Z712
8
Page 7
EVGND
TRG
R7202
EV5
To DVD Main board
NADG-8257 (4/4)
NADG-8259
U03 : DVD MAIN CPU PC BOARD (1/2) NADG-8259
AMUTE M
PWRCNT
To NADIS-8264 Display PC board (3/18)
Q7401 BA6288FS
Q7001
M30624MGP
MAIN CPU SECTION
To Loader Mecha.
RDV-1.1
DPS-10.5
DV-SP1000
DV-SP1000 (DC1N)
R7060 R7059
NC
56 k ohm
68 k ohm
33 k ohm
0 ohm
10 k ohm
27 k ohm
27 k ohm
JJ2N
DD1N
PA 4P
PP2P
GK3P
WT3P
GR6P
R7063 R7062
NC
56 k ohm
68 k ohm
5.6 k ohm
4.7 k ohm
5.6 k ohm
10 k ohm
0 ohm
10 k ohm
27 k ohm
8.2 k ohm
12 k ohm
33 k ohm
NC
NOTE:
NOTE:
System Control
Microprocessor
DV-SP1000
SCHEMATIC DIAGRAM 1/18
A
1
2
3
4
5
BCDEFGH
Page 8
NADG-8259
VIDEO ENCODER
VIDEO ENCODER
HDMI
IEEE1394
From NAPS-8270 Power supply-2 PC board
To NAVD-8265 Component/
D-terminal/ SCART terminal board
To NAVD-8258
To NAVD-8258
To NAVD-8273
To NADG-8272-1
Digital video processor section
To NADG-8272-5
Video MPU section
To NADG-8257
DVD Main board
B/E section
To Main CPU section-1
To NAAF-8266
Audio output board
U03 : DVD MAIN CPU PC BOARD
NADG-8259 (2/2)
MAIN CPU SECTION
To NADG-8262
To NAAR-8263
To NADG-8272-1
Digital video processor section
DV-SP1000
SCHEMATIC DIAGRAM 2/18
A
1
2
3
4
5
BCDEFGH
Page 9
P7801B
P7801A
S7704
1
2
3
P7201B
D7507
1SS352
Q7502 13-BT-211GNK
10G45
11G44
12G43
13G42
1G54
2G53
3G52
4G51
5G50
6G49
7G48
8G47
9G46
F+57
F-1
NC140
NC241
P14
P1013
P1114
P1215
P1316
P1417
P1518
P1619
P1720
P1821
P1922
P25
P2023
P2124
P2225
P2326
P2427
P2528
P2629
P2730
P2831
P2932
P36
P3033
P3134
P3235
P3336
P3437
P3538
P3639
P47
P58
P69
P710
P811
P912
U7501
REMSENS
C7531
104Z
C7532
104Z
C7530
104Z
C7533
104Z
C7504
104Z
C7503 104Z
C7502 104Z
C7501
104Z
C7527
104Z
C7701104Z
C7702
104Z
C7529
104Z
S7506
PLAY
S7505
STOP
S7504
OP/CL
S7503
DISPLAY
S7502
DOWN
S7501
UP
S7705
VIDEOIN
S7703
VIDEOOFF
S7701
STANDBY
D7511
SEL2E10C
D7512
SEL2E10C
D7510
SEL2E10C
D7513
SEL2E10C
D7502
NC
D7501 SEL2E10C
D7504
NC
D7503 SEL2E10C
D7506
NC
D7505
SEL2E10C
D7509
SEL2E10C
D7703
SEL4410R
D7701
NC
D7702
SEL2E10C
Q7515
IMX1A
2
6
1
Q7515
IMX1A
5
3
4
Q7513
IMX1A
2
6
1
Q7513IMX1A
5
3
4
Q7517
IMX1A
2
6
1
Q7517IMX1A
5
3
4
Q7505
IMX1A
5
3
4
Q7505
IMX1A
2
6
1
Q7506
IMX1A
5
3
4
Q7506
2
6
1
Q7507
IMX1A
5
3
4
Q7507
2
6
1
Q7511
IMX1A
2
6
1
Q7511IMX1A
5
3
4
Q7701
IMX1A
2
6
1
Q7701
IMX1A
5
3
4
R7558
0
R7550
0
R7568 100K
R7567 100K
R7565 100K
R7566 100K
R755310K
R7557
1.2K
R755910K
R7554
0
R7552
0
R7555
390
R7556
56
R755110K
R7547
390
R7548
56
R7549
1.2K
R7562
1.2K
R756410K
R7560
390
R7561
56
R7563
NC
R7505
1.8K
R7504
1K
R7503
820
R7502
470
R7501
390
R7507
56
R7508
1.2K
R7506
390
R7509
R7512
56
R7513
1.2K
R7511
390
R7514
R7518
56
R7517
1.2K
R7516
390
R7519
R7520 10K
R7515 10K
R7510 10K
R7542
1.2K
R754410K
R7540
390
R7541
56
R7543
NC
R7546
470
R7545
390
R7705
560
R7706
10K
R7702
56
R7703
1.2K
R7701
390
R7704
NC
Q7514
RN1407
Q7516
RN1407
Q7518
RN1407
Q7508
RN1407
Q7509
RN1407
Q7510
RN1407
Q7512
RN1407
Q7703
RN1407
Q7702
RN1407
Q7503
2SC2712
Q7504
2SC2712
D7508
5.6B
C7525
330
C7524
330
C7522
330
C7526
330
C7523
330
C7518
104Z
C7519
104Z
C7506
223Z
C7507
223Z
C7510
104Z
C7511
104Z
C7508
223Z
C7509
104Z
C7513 104Z
C7517 104Z
C7512
104Z
C7505 100/6.3
C7703
100/6.3
C7520
100/50
C7521
10/50
C7528
100/6.3
C7516
10/16
C7515
2.2/50
R7532
10K
R7531
22K
R7528
100K
R7527
100K
R7530 100K
R7529 100K
R7522
2.7K
R7521
2.7K
R7523
2.7K
R7537
22
R7536
22
R7538
1
R7533
22
R7535
22
R7534
22
R7524
2.7K
R7526
4.7K
R7525
4.7K
X7501
5MHZ
Q7501
MPD780232GC-070-8BT
-VDISP 60
10G71
11G70
12G69
13G68
1G80
2G79
3G78
4G77
5G76
6G75
7G74
8G73
9G72
AVDD+5V 24
AVSS18
FRAIC5
GND2
JOGA26
JOGB27
KEY0 22
KEY1 21
KEY220
KEY319
LED114
LED216
LED317
LED411
LED512
NC166
NC267
P164
P10 53
P11 52
P12 51
P13 50
P14 49
P15 48
P16 47
P17 46
P18 45
P19 44
P263
P20 43
P21 42
P22 41
P23 40
P24 39
P25 38
P26 37
P27 36
P28 35
P29 34
P362
P30 33
P31 32
P32 31
P33 30
P34 29
P35 28
P3665
P461
P5 58
P6 57
P7 56
P8 55
P9 54
STBYLED13
SUBCL7
SUBREQ10
SUBSI8
SUBSO9
VDD+5V1
VDD0+5V 25
VDD2+5V 59
VSS23
X13
X24
IRIN15
RESET6
SSCBJ
SSCAJ
EVGND
F-
P1P2P3P4P5P6P7P8P9
P10
P11
P12
P13
P14
P15
P16
P17
P18
P19
P20
P21
P22
P23
P24
P25
P26
P27
P28
P29
P30
P31
P32
P33
P34
P35
P36
13G
12G
11G
10G
9G8G7G6G5G4G3G2G1G
F+
F+
KEY1 KEY1
LED+B LED+B
STBYLED STBYLED
PWRLED PWRLED
LEDGND
P5P6P7P8P9
P10
P11
P12
P13
P14
P15
P16
P17
P18
P19
P20
P21
P22
PWRLED PWRLED
13G STBYLED STBYLED
12G VDOFFLED VDOFFLED
P4 P23 HDMILED HDMILED
P3 P24 EXTLED EXTLED
P2 P25 DVDLED DVDLED
P1 P26 KEY1 KEY1
P36 P27 LED+B LED+B
P28 SSCAJ SSCAJ
P29 LEDGND LEDGND
P30 SSCBJ SSCBJ
P31 EVGND
11G P32
10G P33
9G P34
8G P35
7G
6G
5G
4G
3G
2G
1G KEY1 KEY1
EVGND
KEY0
SUBRST
SUBCL
SUBSI
SUBSO
SUBREQ
RMCN_IN
F+
F-
-VP
-VPGND
EV5 EV5
EV5
RMCN_IN
LEDGND
EVGND
LED+B
EVGND
LED+B
LED+B
PLAYLED
LEDGND
LEDGND
SUBRST
VDOFFLED
SUBCL
PWRLED
SUBREQ
STBYLED
SUBSO HDMILED
SUBSI EXTLED
STOPLED
OPCLLED DVDLED
STOPLED
PLAYLED
STBYLED
KEY0
PWRLED
VDOFFLED
HDMILED
OPCLLED
EXTLED
DVDLED
LEDGND
0 ohm00 ohm NCR7550
NCD7703 RED NC
REDRED NCD7701
DPS-10.5
D7510 ORANGEORANGE NC
NCD7513 NC BLUE
0 ohmNCR7554
NCNC BLUED7512
RDV-1.1DVSP1000
NCNC 0 ohmR7552
ORANGEORANGE BLUED7511
DVD/EXT
HDMI
EXT
DVD
VIDEO OFF
NCNCR7558 0 ohm
DISPLAY SECTION
0 ohm
NOTE:
FL Tube
Display
Microprocessor
To NADG-8259
R7552
R7554
D7510
D7511
D7512
D7513
D7701
D7703
R7550
R7558
NC
0 ohm
ORANGE
ORANGE
NC
NC
RED
NC
0 ohm
NC
VALUE
DV-SP1000
SCHEMATIC DIAGRAM 3/18
U07 : DISPLAY PC BOARD NADIS-8264 U10 : JOG SWITCH PC BOARD NASW-8267
A
1
2
3
4
5
BCDEFGH
Page 10
J9021
J9020
R9609 R9608
0
R9606
150
R9111
0.22
1/2W
R9112
0.22
1/2W
R9113
0.22
1/2W
R9114
0.22
1/2W
R9110
0.22
1/2W
R9104
0.22
1/2W
R9103
0.22
1/2W
R9102
0.22
1/2W
R9101
0.22
1/2W
R9107
0.22
1/2W
R9106
0.22
1/2W
R9105
0.22
1/2W
R9109
0.22
1/2W
R9115
22K
R9108
10K
R9117
680
R9602
1K
R9116
1.8K
R9605
100
R9601
100
R9603
4.7K
R9604
100
R9607
3.3K
C9112
2200/25
C9111
2200/25
C9110
2200/16
C9109
2200/16
C9113
2200/25
C9115
47/6.3
C9108
3300/35
C9114
4.7/50
C9129
47/35
C9117
47/35
C9122
470/6.3
C9127
470/6.3
C9118
47/35
C9123
470/6.3
C9601
470/16
C9603
470/16
D9126
RK46
D9125
RK46
D9108
D9109
D9111
D9104
1SR154-400
D9105
D9106
D9107
D9114
D9115
D9110
D9116
D9112
D9113
D9103
D9101
1SS352
D9120
1SS352
D9123
RK16
D9121
1SS352
D9124
RK16
D9122
1SS352
D9601
RB051L-40
D9602
RB051L-40
D9604
RB051L-40
D9603
RB051L-40
D9606
1SS352
C9103
334
C9104
334
C9101
334
C9102
334
C9105
334
C9116
104
C9107
334
C9106
334
C9119
104
C9120
104
C9125
104
C9124
104
C9128 104
C9121
104
C9126
104
C9001 472M
C9002
472M
S9002
L9001
NCH-3567
OR NCH-3489
1
23
4
P9006
ORANGE
WHITE
P9005
YELLOW
WHITE
P9001A
P9001
P9105BP9105A
P9004AP9003A
P9004B
P9003B
P9503A P9503B
P9007
P9007A
P9102A
T9001
Q9101 MPC29M05HF
G
IO
P9008
P9008A
S9001
C9003
C9602
104Z
F9001
Q9102
SI-8015JF
GND3ON5S
4
VI1VO
2
Q9103
SI-8050JF
GND3ON5S
4
VI1VO
2
Q9104
SI-8033S
GND3ON5S
4
VI1VO
2
L9101
101
L9102
101
L9103
101
D9102
RBV602
P9604A
P9601A
TO VIDEO_BASE
P9104A
P9104B
P9103A
Q9601
RN1407
Q9603
RN1407
Q9602
RN2403
Q9604
2SC2120
D9605
UDZS4.7B
E LENT.POUR UNE PROTECTION PERMANENTE,N'UTILISER
INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE.
QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST
CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST
FOR CONTINUED PROTECTION AGAINST FIRE
RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL.
HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE
THIS SYMBOL LOCATED NEAR THE FUSE INDICATES
THAT THE FUSE USED IS SLOW OPERATING TYPE
VA
FOR CONTINUED PROTECTION
AGAINST FIRE HAZARD,REPLACE
ONLY WITH FUSE OF SAME TYPE
AND RATING INDICATED.
CAUTION
P9005AP9006A
P9602A
TO VIDEO_BASE
V+B
A+B
AGND
VGND A-B
ADAC+B
AGND
V-B APG+B
APGGND
A+B P-OFF
AGND
V+B
VGND
V-B
A-B
P-OFF
ADAC+B
SW+3.3
AGND
SW+5
P-OFF
SWM8V
APG+B
EV5.6
APGGND
GND
-VDISP
VDISPGND
PWRCNT
EV5.6V
F+
F-
APGGND
SW+5V
FLOFF
SW+5V
APGGND
APGGND
SW+3.3V
SW+3.3V
APGGND
APGGND
PWR_CONT
5V
-VDISP
APG_GND
SWM8V
3.3V
PWRCNT
U21 : SWITCHING POWER SUPPLY UNIT
(NAPS-0037)
NAPS-8270
Except <DC1N>
<UDC1N> ONLY
NASW-8271
ATTENTION
ET CALIBRATION COMME INDIQUE.
D'INCENDIE, REMPLACER UNIQUEMENT
PERMANENTE CONTRE LES RISQUES
AFIN D'ASSURER UNE PROTECTION
PAR UN FUSIBLE DE MEME TYPE
VA
NAPS-8269
NOTE
REPLACE ONLY WITH PART NUMBER SPECIFIED.
VOLTAGE (MEASURED WITH VOLTMETER) IS DC VOLTAGE (NO INPUT SIGNAL).
ELECTROLYTIC CAPACITORS ( ) ARE IN uF/WV.
ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.
THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.
CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.
THE COMPONENTS
IDENTIFIED BY MARK
ARE CRITICAL FOR
SAFETY
EX) 030 3pF 330 33pF 331 330pF 333 0.033uF
EX) PRINTING SIDE
U14 : POWER SWITCH
PC BOARD
To NAAR-8263
To NAAR-8274
DV-SP1000
SCHEMATIC DIAGRAM 4/18
A
1
2
3
4
5
BCDEFGH
U12 : POWER SUPPLY PC BOARD-1 NAPS-8269
U13 : POWER SUPPLY PC BOARD-2 NAPS-8270
To DVD Main CPU PC board
NADG-8259
To NADG-8259
Main CPU section-2
Page 11
AUDIO/ DSP SECTION
Q4012
MB86344
3.3V
NAAR-8263
To NADG-8257
To NADG-8262
To NADG-8272
To NADG-8257
To NAAF-8266
To NADG-8259
To NAPS-826
To NAAF-8266
SRAM
Audio DSP
2nd PLL
LRCK_5V
Used Other
Model
Used Other Model
DV-SP1000
SCHEMATIC DIAGRAM 5/18
U18 : AUDIO DAC PC BOARD (1/2) NAAR-8263
A
1
2
3
4
5
BCDEFGH
Page 12
To Audio output terminal
NAAF-8266
From Audio DAC section
NAAR-8263
NAAR-8263
To Audio output terminal
NAAF-8266
To SCART Section
SW
C
SR
SL
RO/RT
LO/LT
VLSC x 8 channel
Wolfson 8 channel Stereo DAC
x 4
DMXL
DMXR
DV-SP1000
SCHEMATIC DIAGRAM 6/18
AUDIO/ DAC SECTION
U18 : AUDIO DAC PC BOARD-2 NAAR-8263
A
1
2
3
4
5
BCDEFGH
Page 13
P4961
SW
3
P4961
SR
6
P4961
FR
9
P4964
SR
3
P4960
DMXR
3
P4950B
D4201
UDZ12B
D4202
UDZ12B
C4755
104Z
C4986
104Z
C4985
4.7/50
R4777
2.7K
R4778
47K
R4995
0
R4997
0
R4996
0
P4571B
FROM MAIN CPU
P4005B
L4956
617CM-1430
Q4756
2SC2712
Q4755
2SC2712
Q4202
2SD2394-E
Q4203
2SC2712-GR
Q4858
2SC2712
Q4857
2SC2712
P4962A
P4962B
P4959
P4958
P4955
RI
1
3
2
4
T4951
TRNS_
P4957
+
-
G
SG
Q4758
RN1404
Q4208
RN1407
Q4954
RN1402
Q4953
RN1402
Q4207
RN1407
Q4205
NC
P4956
IR_IN/OUT
Q4955
PC817X
Q4853
HN1C03F
5
3
4
Q4852
HN1C03F
2
6
1
Q4902
HN1C03F
2
6
1
Q4903
HN1C03F
5
3
4
Q4802
HN1C03F
2
6
1
Q4803
HN1C03F
5
3
4
Q4753
HN1C03F
5
3
4
Q4752
HN1C03F
2
6
1
Q4702
HN1C03F
2
6
1
Q4703
HN1C03F
5
3
4
Q4753
HN1C03F
2
6
1
Q4752
HN1C03F
5
3
4
Q4802
HN1C03F
5
3
4
Q4803
HN1C03F
2
6
1
Q4852
HN1C03F
5
3
4
Q4853
HN1C03F
2
6
1
Q4902
HN1C03F
5
3
4
Q4903
HN1C03F
2
6
1
Q4702
HN1C03F
5
3
4
Q4703
HN1C03F
2
6
1
P4961
CENTER
1
2
P4961
FL
7
8
P4964
SL
1
2
P4961
SL
4
5
P4960
DMXL
1
2
Q4952
74HCU04F
34
Q4952
74HCU04F
13
12
Q4951
74HCU04F
34
Q4952
74HCU04F
11 10
Q4952
56
Q4952
74HCU04F
98
Q4951
74HCU04F
12
Q4951
13 12
Q4952
74HCU04F
12
Q4951
74HCU04F
11 10
Q4951
98
Q4951
56
Q4952
74HCU04F
GND7
VCC14
Q4951
74HCU04F
GND7
VCC14
Q4956
1
3
2
Q4957
1
3
2
R4999
NC
R4984
0
R4717
680K
R4715
1M
R4921 10K
R4923
1M
R4924
680K
R4922
10K
R4980 10K
R4982
1M
R4983
680K
R4981
10K
R4703 1K
R4701
1K
R4910
100
R4909
100
R4859
100
R4860
100
R4858
2.2K
R4857
2.2K
R4246
2.2 1/2W
R4975
100
R4973
180
R4971
180
R4968
330
R4985
0
R4969
100
R4964
10K
R4963
10K
R4961
3.3K
R4962
470
R4702
1K
R4767
2.7K
R4765
10K
R4766
10K
R4768
2.7K
R4241
100
R4242
100
R4236
470
R4234
10K
R4232 10K
R4230 10K
R4235
470
R4233
10K
R4231
10K
R4229
10K
R4244
22K
R4247
10K
R4245
2.2 1/2W
R4243
10K
R4966 220
R4965 220
R4853
1K
R4854
1K
R4803
1K
R4804
1K
R4751
1K
R4752
1K
R4754 1K
R4753
1K
R4704
1K
R4915
1M
R4917
680K
R4916
1M
R4918
680K
R4908
2.2K
R4907
2.2K
R4809
100
R4810
100
R4808
2.2K
R4807
2.2K
R4758
2.2K
R4760
220
R4757
2.2K
R4759
220
R4979
10K
R4708
2.2K
R4707
2.2K
R4709
100
R4710
100
R4978 10K
R4762
2.2K
R4764
220
R4761
2.2K
R4763
220
R4813
220
R4814
220
R4812
2.2K
R4811
2.2K
R4863
220
R4864
220
R4861
2.2K
R4862
2.2K
R4912
2.2K
R4911
2.2K
R4913
220
R4914
220
R4712
2.2K
R4713
220
R4714
220
R4711
2.2K
R4773 1M
R4774 680K
R4801
1K
R4802
1K
R4852
1K
R4851
1K
R4872
2.7K
R4871
2.7K
R4870
10K
R4869
10K
R4901
1K
R4902
1K
R4903
1K
R4904
1K
R4775
1.8K
R4776
1.8K
R4770 1M
R4772 680K
R4769 1M
R4771 680K
R4756
47K
R4755
47K
R4805
47K
R4806
47K
R4815
1M
R4817
680K
R4816
1M
R4818
680K
R4855
47K
R4856
47K
R4865
1M
R4867
680K
R4866
1M
R4868
680K
R4905
47K
R4906
47K
R4716 1M
R4718 680K
R4976
1M
R4977
680K
R4705
47K
R4706
47K
R4954
0
R4953
R4960
22K
R4958
150K
R4957
100K
R4974
100
R4952
R4951
0
R4959
22K
R4956
150K
R4955
100K
R4967
330
R4970
180
R4972
180
C4921 470/6.3
C4978 470/6.3
C4706
47/50
C4705
47/50
C4205
220/16
C4206
220/16
C4203
470/6.3
C4968
100/6.3
C4958
100/6.3
C4202
470/25
C4201 470/25
C4204
470/6.3
C4702
47/16
C4701 47/16
C4754
47/50
C4753
47/50
C4803
47/50
C4804
47/50
C4853
47/50
C4854
47/50
C4903
47/50
C4904
47/50
C4977
470/6.3
C4956
100/6.3
C4966
100/6.3
C4955
100/6.3
Q4701
BA15532F
3
+B
8
2
1
Q4851
BA15532F
3
+B
8
2
1
Q4801
BA15532F
3
+B
8
2
1
Q4751
BA15532F
3
+B
8
2
1
Q4901
BA15532F
3
+B
8
2
1
Q4851
BA15532F
5
6
-B
4
7
Q4801
BA15532F
5
6
-B
4
7
Q4751
BA15532F
5
6
-B
4
7
Q4701
BA15532F
5
6
-B
4
7
Q4901
BA15532F
5
6
-B
4
7
L4999
NC
L4955
022
L4953
022
L4952
022
L4954
022
L4951
022
P4203B
P4202B
Q4206
NC
Q4805
RN2403
Q4804
RN2403
Q4855
RN2403
Q4854
RN2403
Q4905
RN2403
Q4904
RN2403
Q4704
RN2403
Q4705
RN2403
Q4757
2SA1162-GR
Q4921
2SA1162-GR
Q4959
2SA1162-GR
Q4204
2SA1162-GR
Q4201
2SB1565-E
Q4958
2SA1162-GR
C4979
NC
C4987
NC
C4999
NC
C4976
220
C4967
104Z
C4974
104Z
C4972 104Z
C4971 104Z
C4970 104Z
C4969 104Z
C4959
223
C4957
104Z
C4752
104Z
C4802
104Z
C4902
104Z
C4901
104Z
C4852
104Z
C4851
104Z
C4801
104Z
C4751
104Z
C4704
104Z
C4703
104Z
C4954
103K
C4952
104Z
C4962 330
C4953
103K
C4973
104Z
C4951
104Z
C4961 330
C4975
220
C4965
104Z
C4960 330
D4921 1SS352
D4952 1SS352
D4953
1SS352
D4851
1SS352
D4852
1SS352
D4751 1SS352
D4752 1SS352
D4951
1SS352
DAC_MUTE
5V_MUTE
DOGND
DIG1
MUT.DMXL
DO+5
DMXL
DIG1
DMXL
AGND1
DIG2 DIG2
DMXR
LO/LT DMXR
AGND1
MUTEDRV1
RO/RT
SL
AGND1
RI
SR
MUT.DMXR
CENTER +12V
AGND1
EV5GND
SW
IRIN
EV5
3DB_CTRL
DIG2
DIG1
5V_MUTE
MUT.LO
MUT.RO
MUT.SL SL
MUT.SR
MUT.C
MUT.SW
AMUTE
-12V
EVGND
+12V
12VGND
AGND1
MUT.DMXL
MUT.DMXR
AMUTE
+12V
12VGND
EV5GND
-12V
EV5.6 SR
AGND1
AGND1
EVGND EV5 EV5
IRIN
IRIN
PWRCTR
EV5GND
RI
MUT.LO
PWRCTR
LO/LT
AGND1
A+B
RO/RT
MUT.RO
MUTEDRV3
MUT.SL
A+B
SL
A-B
PWRCTR
AGND1
SR
A-B
MUT.SR
PWRCTR
PWRCTR
MUT.C
CENTER
AGND1
SW
MUT.SW
NAAF-8266
U11 : Digital output
PC board
NADG-8268
AUDIO OUTPUT SECTION
U09 : AUDIO OUTPUT PC BOARD NAAF-8266
Not used
DV-SP1000
SCHEMATIC DIAGRAM-7/18
A
1
2
3
4
5
BCDEFGH
To NADG-8259 To NAAR-8263
To NAAR-8263To NAAR-8263To NAAR-8263
Page 14
VIDEO OUTPUT SECTION (1/3)
Q6003
SiI504
Video Interface to
Progressive Converter
Except DV-SP1000 <DC1N>
To NADG-8257
To NADG-8257
To NADG-8259
NAVD-8265
DV-SP1000
SCHEMATIC DIAGRAM 8/18
U02 : VIDEO OUTPUT TERMINAL PC BOARD
NAVD-8258 (1/3)
A
1
2
3
4
5
BCDEFGH
NAVD-8258
Page 15
DV-SP1000
SCHEMATIC DIAGRAM 9/18
U02 : VIDEO OUTPUT TERMINAL PC BOARD
NAVD-8258 (2/3)
A
1
2
3
4
5
BCDEFGH
VIDEO OUTPUT SECTION (2/3)
Not put on parts
Except DV-SP1000E <UPP>, RDV-1.1 <UPP>,
RDV-1.1 <UJJ>
NAVD-8258
Q6101
ADV7314
Video Encoder
14 Bit DACs
VDA+5V
SC. B
Page 16
Q6501
ADV7314
NAVD-8258
NAPS-8274
To NAETC-8261
To NAPS-8269
Video Encoder
DV-SP1000
SCHEMATIC DIAGRAM 10/18
VIDEO OUTPUT SECTION (3/3)
U02 : VIDEO OUTPUT TERMINAL PC BOARD NAVD-8258 (3/3)
U06 : POWER SUPPLY PC BOARD-3 NAPS-8274
A
1
2
3
4
5
BCDEFGH
Page 17
P6707
P6302B
PLUG_7
ENCORDER
P6303B
PLUG_6
ENCORDER
P7010B
FROM MAIN CPU
P4204B
PLUG_10
P6703B
P5402B
FROM DECODER
PLUG_10
P6703A
PLUG_10
P6706P6704 P6705
P6702
2
5
P6702
1
4
P6701
2
P6701
P6781
Q6783
PC817X
Q6909
NJM4565M-D
5
6
4
7
Q6909
NJM4565M-D
3
8
2
1
P6551C
FROM ENCORDER
PLUG_9
P6551B
FROM ENCORDER
PLUG_9
P6005C
PLUG_08
FROM ENCORDER
P6005B PLUG_08
Q6910
HN1C03F
5
3
4
Q6910
HN1C03F
2
6
1
Q6908
HN1C01F-GR
2
6
1
Q6908
HN1C01F-GR
5
3
4
D6903
1SS226
D6901
1SS226
D6902
1SS226
D6905
1SS226
D6904
1SS226
Q6781
2SA1162-GR
Q6911
2SA1162-GR
D6781
1SS352
D6906
1SS352
Q6907
2SC2712-GR
Q6809
RN2403
Q6811
RN2403
Q6782
RN1402
Q6810
RN1407
Q6808
RN1407
P6901
SCART
1B_OUT7
AUDIO_GND4
AUDIO_LCH_OUT3
AUDIO_RCH_OUT1
BLANK16
CONTROL10
G_OUT11
NC12
NC26
NC312
NC420
R/C_OUT15
SQUEEZE8
V/Y_OUT19
VIDEO_GND15
VIDEO_GND29
VIDEO_GND313
VIDEO_GND414
VIDEO_GND517
VIDEO_GND618
VIDEO_GND721
L6709
L
L6708
L
L6707
L
L6706
L
L6705
L
L6704
L
L6701
L
L6702
L
L6703
L
L6801
L
L6802
L
L6803
L
L6905
L
L6904
L
L6903
L
L6901
L
L6902
L
L6805
L
L6804
L
L6806
L
Q6803
TC7SET04FU
GND
3
2
NC
1
4
VCC
5
Q6904
TC7SET04FU
GND
3
2
NC
1
4
VCC
5
Q6704
TC7SET04FU
GND
3
2
NC
1
4
VCC
5
Q6805
TC7SET08FU
312
4
5
Q6804
TC7SET08FU
312
4
5
Q6807
TC7SET08FU
312
4
5
Q6912
TC7SET08FU
312
4
5
Q6906
TC7SET08FU
312
4
5
Q6706
TC7SET08FU
312
4
5
Q6705
TC7SET08FU
312
4
5
Q6905
TC7SET08FU
312
4
5
Q6903
TC7SET08FU
312
4
5
14 8
7
1
P6801
D2
C6721
100/6.3
C6719
100/6.3
C6725
100/6.3
C6723
100/6.3
C6717
1000/6.3
C6718
1000/6.3
C6716
1000/6.3
C6703
100/6.3
C6701
100/6.3
C6705
100/6.3
C6714
100/6.3
C6712
100/6.3
C6707
100/6.3
C6917
47/16
C6919
47/16
C6912
1000/6.3
C6910
1000/6.3
C6911
1000/6.3
C6909
1000/6.3
C6907
100/6.3
C6905
100/6.3
C6803
100/6.3
C6926
10/16
C6927
10/16
C6928
470/6.3
C6901
100/6.3
C6903
100/6.3
C6807
100/6.3
C6805
100/6.3
C6801
100/6.3
C6811
104Z
C6813
104Z
C6722
104Z
C6720
104Z
C6781
104Z
C6914
104Z
C6929
104Z
C6726
104Z
C6724
104Z
C6711
104Z
C6709
104Z
C6710
104Z
C6704
104Z
C6702
104Z
C6715
104Z
C6713
104Z
C6708
104Z
C6706
104Z
C6915
104Z
C6920
104Z
C6918
104Z
C6924
101
C6923
102J
C6906
104Z
C6908
104Z
C6904
104Z
C6902
104Z
C6804
104Z
C6802
104Z
C6806
104Z
C6808
104Z
C6922
104Z
C6810
104Z
C6913
104Z
C6925
101
C6916
104Z
C6809
104Z
R6797
470
R6796
470
R676133R6762
15
R675933R6760
15
R675733R6758
15
R6718
75
R6717
75
R6716
75
R6780
75
R6779
75
R6778
75
R6868
75
R6867
75
R6866
75
R6897
NC
R6898
NC
R6899
NC
R6774
1K
R6773 1K
R6772
1M
R6771
1M
R6770
24
R6766
1K
R6895 NC
R6894 NC
R6896 NC
R6862 1K
R6861
1K
R6860
1M
R6859 1M
R6858
24
R6854 1K
R6878 NC
R6879 NC
R6832
1K
R6877 NC
R6831
1K
R6830
1M
R6829
1M
R6827
24
R6828
27
R6882 NC
R6822
1K
R6813
1K
R6811 1M
R6812 1M
R6881 NC
R6880 NC
R6814 1K
R6809
24
R6810
27
R6891 NC
R6804
1K
R6892 NC
R6893 NC
R6750 1K
R6749 1K
R6748 1M
R6747 1MR6746
24
R6888 NC
R6742 1K
R6732 1K
R6890 NC
R6889 NC
R6731 1K
R6730
1M
R6729 1MR6728
24
R6887
NC
R6724 1K
R6886
NC
R6885
NC
R6712 1K
R6711 1K
R6710
1M
R6709 1M
R6708
24
R6704
1K
R6995 NC
R6994 NC
R6996 NC
R6931
1K
R6929 1MR6927
24
R6930 1M
R6928
27
R6932 1K
R6997 NC
R6922
1K
R6914
1K
R6998 NC
R6913
1K
R6912 1M
R6911
1M
R6909
24
R6910
27
R6915
1M
R6917
1M
R6916
24
R6908
27
R6918
27
R6999
NC
R6904
1K
R6875
0
R6876
0
R6849
1.5K
R6869
470
R6870
470
R6871
470
R6872
470
R6873
470
R6874
470
R6765
10K
R6764
10K
R6763
10K
R6768
1M
R6767
24
R6769
1M
R6775
1M
R6776
1M
R6777
24
R6785
1K
R6783
100K
R6784
4.7K
R6782
100K
R6781
4.7K
R6788
470
R6791
470
R6795
470
R6794
470
R6793
470
R6792
470
R6789
470
R6787
470
R6790
470
R6786
470
R6853
10K
R6852
10K
R6851
10K
R6856
1M
R6855
24
R6863
1M
R6864
1M
R6865
24
R6857
1M
R67271MR6726
1M
R6736
27
R6737
27
R6847
10K
R6848
1K
R6754
27
R6755
27
R6735 2.2K
R6733 2.2K
R6725
24
R6723
10K
R6722
10K
R6721
10K
R6734
470
R6756
27
R6738
27
R6703
10K
R6702
10K
R6701
10K
R6707
1M
R6705
24
R6713
2.2K
R6715
2.2K
R6714
470
R6706
1M
R6753
2.2K
R6751 2.2K
R67441MR6745
1M
R6743
24
R6741 10K
R6740
10K
R6739 10K
R6752
470
R6950
1
R6951
1K
R6982
22
R6981
22
R6980
22
R6979
22
R6966
1K
R6977
1M
R6978
1M
R6974
10K
R6973
10K
R6961
1K
R6960
10K
R6959
5.1K
R6948
0
R6946
0
R6945
0
R6938
15
R6935
1M
R6933
1M
R6833 1M
R6834
1M
R6817
1M
R6815 1M
R68071MR6806
1M
R6952
1
R694333R6944
15
R694133R6942
15
R693933R6940
15
R6937
33
R684333R6844
15
R684033R6841
15
R683733R6838
15
R6953
150
R6954
150
R6962
10K
R6926
27
R6936
27
R6958
6.8K
R6957
150K
R6956
22K
R6955
100
R6965
1K
R6970
47K
R6969
47K
R6971
470
R6972
470
R6964
1K
R6968
1M
R6963
1K
R6967
1M
R6975
10K
R6976
47K
R6947
0
R69251MR6924
1M
R6923
24
R6921
10K
R6920
10K
R6919
10K
R6934
24
R69061MR6905
1M
R6907
24
R6903
10K
R6902
10K
R6901
10K
R6846
10K
R6845
0
R6839
0
R6842
0
R6826 27
R6836
27
R6818
27
R6808
27
R68251MR6824
1M
R6823
24
R6821
10K
R6820
10K
R6819
10K
R6835
24
R6805
24
R6803
10K
R6802
10K
R6801
10K
R6816
24
Q6707
MAX4218
ENA1
ENB3
ENC2
INA+5
INA-6
INB+ 10
INB- 9
INC+ 12
INC- 13
OUTA7 OUTB 8
OUTC14
VCC4 VEE11
Q6708
MAX4218
ENA1
ENB3
ENC2
INA+5
INA-6
INB+ 10
INB- 9
INC+ 12
INC- 13
OUTA7 OUTB 8
OUTC14
VCC4 VEE11
Q6702
MAX4218
ENA1
ENB3
ENC2
INA+5
INA-6
INB+ 10
INB- 9
INC+ 12
INC- 13
OUTA7 OUTB 8
OUTC14
VCC4 VEE11
Q6701
MAX4218
ENA1
ENB3
ENC2
INA+5
INA-6
INB+ 10
INB- 9
INC+ 12
INC- 13
OUTA7 OUTB 8
OUTC14
VCC4 VEE11
Q6703
MAX4218
ENA1
ENB3
ENC2
INA+5
INA-6
INB+ 10
INB- 9
INC+ 12
INC- 13
OUTA7 OUTB 8
OUTC14
VCC4 VEE11
Q6902
MAX4018
ENA1
ENB3
ENC2
INA+5
INA-6
INB+ 10
INB- 9
INC+ 12
INC- 13
OUTA7 OUTB 8
OUTC14
VCC4 VEE11
Q6901
MAX4018
ENA1
ENB3
ENC2
INA+5
INA-6
INB+ 10
INB- 9
INC+ 12
INC- 13
OUTA7 OUTB 8
OUTC14
VCC4 VEE11
Q6802
MAX4218
ENA1
ENB3
ENC2
INA+5
INA-6
INB+ 10
INB- 9
INC+ 12
INC- 13
OUTA7OUTB8
OUTC14
VCC4 VEE11
Q6801
MAX4218
ENA1
ENB3
ENC2
INA+5
INA-6
INB+ 10
INB- 9
INC+ 12
INC- 13
OUTA7OUTB8
OUTC14
VCC4 VEE11
VEE VEE
VCC VCC
EXT_THRU
VDOFF
VGND
VEE
VDOFF
PR
VCC
PB
PR PY
VGND
SCSYCV
PB
CR/R
CB/B
Y/G
VCC
VEE
PY
VGND
PR1
PR
PB
PY
VGND
EXT_THRU2
EXT_PY
VDOFF
VGND
EXT_PR
EXT_PB PB1
EXT_PB
VGND
EXT_PY
SC
EXT_PR
S/NSX
PY1
SY
VCC
VEE
PR2
EXT_THRU2
CV
PB2
PY2
CR/R
VGND
CB/B
Y/G
A_LCH
CV
A_RCH
CR/R
SY
CB/B
SC
EXT_THRU2
Y/G
EXT_THRU
EXT_OE
VDOFF
S/NSX
RGBON
P/IX
SQEEZE
LETTER
LETTER
VGND
-12V
CR/R
12VGND
CB/B
+12V
Y/G
EVGND
PR
EV6
PB
DMIX_LT
PY
SW12V
FSW
VGND
DMIX_RT
AGND VEE
MUTE_
PY
A_LCH
VDOFF
DMIX_LT
Y/G
P/IX
PB
DMIX_RT
A_RCH
EVGND
EV6
P/IX
EXT_OE
MUTE_
CB/B
CR/R PR
SQEEZE
LETTER
VEE
VEE
ASPECT
VCC
PR1
PR1
VCC
VDOFF
VGND
VGND
PR
PR
EV5V
PB
EV5VGND
PB
12VTRG_IN_SW
PY
12VTRG_IN
PB1
PY
PB1
VDOFF
PY1
PY1
NAETC-8261
NAETC-8260
NAVD-8265
COMPONENT/ D-TERMINAL/ SCART SECTION
U14 : COMPONENT OUTPUT
TERMINAL BOARD Except <DC1N>
To NAVD-8258
To NAAR-8263
To NAVD-8258
Except <DC1N>
U14 : COMPONENT OUTPUT
TERMINAL BOARD Only <DC1N>
U08 : COMPONENT/ D-TERMINAL/
SCART TERMINAL PC BOARD NAVD-8265
DV-SP1000
SCHEMATIC DIAGRAM 11/18
A
1
2
3
4
5
BCDEFGH
Page 18
Q3502
HD64F2367VF33
Q3004
TSB43CA42A
IEEE SECTION
L3507
L3508
L3509
L3510
BLM21B222S232
BLM21B222S232
BLM21B222S232
BLM21B222S232
PT-TXD
PT-RTS
PT-RXD
PT-CTS
NADG-8262
To NADG-8259
IEEE 1394 Control
Microprocessor
To NAAR-8263
RS-232C PHAST
IEEE 1394 Controller
SACD IN
To NADG-8257
MLPCM IN
NOTE:
is only <GR6P> area.
(U19: NADG-8468)
BLM41P750SPT
BLM41P750SPT
L3003
L3004
DV-SP1000
SCHEMATIC DIAGRAM 12/18
U19/ U20 : IEEE1394 TERMINAL PC BOARD NADG-8262
i-Link
i-Link
A
1
2
3
4
5
BCDEFGH
Page 19
NADG-8272
Q8001
SiI504
Interlace to Progressive
Video Scan Converter
To NADG-8259To NADG-8259
DV-SP1000
SCHEMATIC DIAGRAM 14/18
I/P CONVERTER SECTION
U15 : DIGITAL VIDEO PROCESSOR PC BOARD (1/5) NADG-8272
A
1
2
3
4
5
BCDEFGH
Page 20
NADG-8272
SCALER SECTION
P8101
RN-1A
Q8101
Graphics Input port
Q8101
RM-1A
Memory port
RM-1A
Q8101
Video input port
Q8101
RM-1A
Display port
Q8101
RM-1A
Power port
Q8101
RM-1A
Control port
DV-SP1000
SCHEMATIC DIAGRAM 15/18
U15 : DIGITAL VIDEO PROCESSOR PC BOARD (2/5) NADG-8272
A
1
2
3
4
5
BCDEFGH
Page 21
NADG-8272
DV-SP1000
SCHEMATIC DIAGRAM 16/18
MEMORY SECTION
U15 : DIGITAL VIDEO PROCESSOR PC BOARD (3/5) NADG-8272
A
1
2
3
4
5
BCDEFGH
Page 22
For Other Models
To NAAR-8263
Audio DAC section
HDMI Output Plug
NADG-8272
Q8501
SiI161B
Q8401
SII160
Q8301
SII9190
HDMI SECTION
HDMI Reciever
HDMI Transmitter
R8505
R8507
C8501
R8502
HDMI in Plug
For HDMI input
For HDMI input
HDMI Transmitter
DV-SP1000
SCHEMATIC DIAGRAM 17/18
U15 : DIGITAL VIDEO PROCESSOR PC BOARD (4/5) NADG-8272
A
1
2
3
4
5
BCDEFGH
Page 23
NADG-8272
P98/SOB151
P97/SIB150
76 PDL5/FLMD
77 PDL6/AD6
To NADG-8259
DVD Main CPU section-2
Q8701
V850
Video Microprocessor
1. AVREF0
25. P30TXDA0
DV-SP1000
SCHEMATIC DIAGRAM 18/18
VIDEO MPU SECTION
U15 : DIGITAL VIDEO PROCESSOR PC BOARD (5/5) NADG-8272
A
1
2
3
4
5
BCDEFGH
Page 24
DV-SP1000
SCHEMATIC
DIAGRAM
U01 : DVD MAIN BOARD NADG-8257 (1/4) F/E section
A
1
2
3
4
5
BCDEFGH
To DVD Mechanism
Pick up
Sled MotorLoading Motor
Motor Driver
RF Amp.
Page 25
U01 : DVD MAIN BOARD NADG-8257 (2/4) SACD Section
To Audio DAC section NAAR-8263
To NADG-8262 i-Link terminal PC board
DV-SP1000
SCHEMATIC DIAGRAM
A
1
2
3
4
5
BCDEFGH
Page 26
To NAVD-8258 (1/3)To NAVD-8258 (1/3)
DVD Back end Decoder
To NADG-8259
Main CPU section
DV-SP1000
SCHEMATIC DIAGRAM-3
U01 : DVD MAIN BOARD NADG-8257 (3/4) B/E section
A
1
2
3
4
5
BCDEFGH
Page 27
To NADG-8259
Main CPU Section
32-Bit Microprocessor
MCA12
P213
Q2101
M32102S6FP
DV-SP1000
SCHEMATIC DIAGRAM
U01 : DVD MAIN BOARD NADG-8257 (4/4) MPU section
A
1
2
3
4
5
BCDEFGH
Page 28
P10010P
001
P100
P1101
P110
Q100
Q1001
Q1001
Q
100
R100
R1002
R1002
R1003
008
1
1
C
C1020
C10
C1021CC1
C1023C
C1
7
C1027
C10300C1
C1035
C103
1C00
C10
C1002
C100
702R10
Q100
04
R1004
RR100
R1R00
R1013
15
R1012R1R1
1
1
8
9
9
R102
R102
0
0
4
C10
C105
3
4
005
Q
0
Q
00710
0
100
L10
A
P2901A
10101101R1R1
R
R1
R1103R1R1105
R1106
07
R11
1
1
01R
01R
11R1
R1115
R1116
R11
R1
R
R
22
R
121
R1
R112R23
11
1125R11CCCC1
C1102CC1103
110
110
C1110
C11
C
1
2
9
29
2
92
92
Q12
1
Q1201
2
20
1203
3
0
R1205RR
0
R1206RR
R12
208
0
2
2
C1201
C1202
C12
C1205
C1209
C1209
R
R82R12
1
R1221
R
C1210
C121122C12
1
C1
4
C12
1C5
6
C12
2
R
R12
2
1212228
R1
R1229
R1231
R
C
C1
222222
C1227
C1227
C
C1228
C8
C1229CC1229
R1239
R
R1240
2
C1232
C1233
X1201
C1CC125
C1C125830301R1
0
R
R132
325
1325
336RR1335
1
333
0
R1
30
R1303
30
R1304
30
R1305
30
R1307
0
R1308
37
333
3
38
Q1
Q1371
Q1371
390
3
2
C1311
C
C1315
C1315
C1323
323
C13
6
6
3
3
C1347
L1307
1307
2
1
1
3
378
R1378
R1379
R1379
R1379
9
R13
R1
81
R138
R
381
R
8
RRR
1382
R13
382
381
R
3888133RR
R
1389381
3RR
8RR
3
37
R
P
30333
P1303
R201320
3
C2043
0
3
R201120
C2027
C02
3
9
32
2022022
R2
L2004004
2
0
0
00
0
02
0
06
R2062
00
C2014CC2
2020
R2
2
C202
C2007C2C
0
C
R2
R2
C22
2
2005
C2013C2C
3
C21212
C2
C2
C212C2009C2
0
C20C211CC
C20
C
202002
C2008C20
00
C2010C200
0
Q
C2019919
20
2C26
P2005A
0
P2005A
5
X260
6
R2601
R2609
R
60
C2605
R2603
R2105
R
Q
1
Q
1
R214912
9
51
51
2
1
1
2
2
53
R213R2R21322
1
R2138R8
38RR2140
1
R
4
R2103
133R2
2108
210
32
3212
R
29
291R
C
3
C
2
Q
7
R2191
R
30
3012
R
2727R2271
2828R21
R212828
8
0
R2169
C2125
3
3112
R
R2162
2108
R2
0
4
R21R21
R2167
C2124
C
5
R212R212C2193
R21RR2
R
1020R2
44
1RR2
9
R2
R211
R2166
56
R2156
R2
R2117117
R2R2
R2164
65
C2192
R21
R
5
21
R21116R
R2903
2
8
90
R2907
09
0
R2
904
R290
R2
9
219
D1301
306
R1338
C
C2908CC2908
R10R
R1
R1025
R
0
0
3
3
0
R1309
132
13
2
2
31
8
348
C20
C2046
C
2047
633R2060620
C2610
L2601
C2130
Q2QQ
2109
Q2109Q2109
Q2109
L2902
L290
C290
C2901
C2901
1
1
1
1
1
1
2
758G-
BB5757
382
251382
1
P8V
S
DG
1
3
3.3V
1.8V
5VS
D
C
C
B
AA
A
D
D
C
RFP
RFDC
RFSIN
RFO
AIN
A
R
RFAC
R
E
C16
MP
LDON
LDON
LDON
VCCVC
CD
_F
CD_F_CD_F
VD
CD/DVDCD/D
A5V
A
F+
PD-
+
TS
LDM
LDM
M1
S
SPD
LDRSP
SLD
SL
SLSSTST
FS
FS
0
SPD0
1WSPWM1
XCSI
XRD
X
XRDYXRXRDY
XINT
MC
MCK
VDT33VD
VDT
D
VD
VD
VDT0
VDT
XHAC
XHAXHXACA
VEFG
VE
XSHD
DCK
DRVIRQVRDQ
DRVRST
DRVRS
DRVR
DRDS
X
DRVR
D
VCLKVDRV
DR
DRVRDYDRYRVR
DTD
D
TX
L
CKB
J
ATC
VCOI
VCOI
HF
F
PLC
345
6
8899101010
11121
EDCNG
EDC
CLVLOCKCLC
K
SYNCK
SY
CD/XDVD
C
LDON
LDO
XFTSMUTEMXST
E
MXP
S
ST1
ST2
ST2
STTS
T
ST4
TSD-MM-MT
TS
K
V
BUFEBUBBB
TRST
TMS
LRCK
RCK
LRCK
MNT0NT0
MNT1
MNT3
DS
T
RFAC
+
LDN
LDNG-
AVDS
.8VDSP
C1325
5
C
C1358
R
R1359CFROMCS
FROMCS
attern
yVy
1
3
R1363
3
C
DV-SP1000
A
PRINTED CIRCUIT BOARD VIEW
U01 : DVD MAIN PC BOARD NADG-8257
A-side pattern and A-side silk
1
24
2
202
2R
20
2
C2044
BCD
R136
2902
Q290
D2.
1
C1
3
1
R
41
C1305
1
3
3
3
139
3
210
2168
R21
2
0
2
L21
1
12
12
C1
R21
210
210
R
2
0
0
R
7
12
4
210
90
9
1
ND
P2901
PGND
R
10071
1
2
47
100
Q100
1
E
A-SIDE PATTERN
5
B-SIDE PATTERN
Page 29
013
013
0
4
C1015
015
C101
C1016CC1017
C
2C0
0C26
1
005
0
6CC
C
03
R
55R
R
9
1
R
110RR
014
R
9
R102
2
C1
C10
C1045
C1046
Q1101
Q1101
Q1102
L
5
R112
127
128
11
C111C11C1
C1
5
C11
116
C1
C25
Q1
Q1251
RRR125121
2
R1252
252
R1
R1252R2R12
R1
29
R12
1
R12352312
R
R12
R
82828
1
2
13
206
02C
C1208
C1208
R
1
1
1
2
R122
2
7
8
C
1
C
C
3
22C
2
C123
C123
C1
C1
C1235
C123828CC1
2004L1204
5
4
5
C1242
C
C
L1201
L1202
R1329
R1328
P130
P1301AP301A
Q30
0
Q13Q3
P1302A
P1302A30P
P1302A
328
C1330
C133
Q201Q200
Q
350
C1346
Q1304
1
R1347
R1
R1346
C1343
56
C1356
2
C135
334
337
R1337
C1321
C
0
303
1350
C1
3
0
2
C133
L1306L1L
3
9
4334R1R1R
344
34
3
6
22
3
4
L130
1
C13
L
30
3
0
C135252
C13
C
3
C1380
C1379
C1379
C1378
3
C1374
C1374
C
C1373
C1375C7
3
C
C137C
C
C138
C13
C1376
C1376
8
6
01
01
1
3PP
A
P20
0
P2001A
P2001A0100AP
P2004A
P2004A
P2004A
R2014
R2014R22R
2RR
92R
8
06
R2067
9
C2049
C
069
R2
R
R200
R2
C2601
C2601
2
2
9
0
4R2
R205R5
R205R5
R
2
0
55R205R5
RR2
2
RR2
R
R
2
5R2
R2002
2
L2003
10
0
Q
QQQ
C
C2108
CCC2110
C2112
112
C2112
2
06
06
C219
C2191
C2115
C21
15
C2114C214
C2117
C
C2116
2
C
2
2906C6
C2904
C2904
C
L1004
3
Q2104
Q0
R
36
135
R
222
2
C21111
1
L210LL2
01
RRR
R2160
R2160
CC120
C21
9
C21
C2127
C22CC2
9
111
P1P1020000
P
20
222
2
2
R1306
R1
C1302C1C1303
30
6
307
3
C1345
P2002A
P2002AP2P
A
C2
C2
4
C134
334
D2
901
1
1
1
1
1
1
3
1
1
0
7
R2170
1
1
FROMCS
MCSFRO
R
3
3
202202SACDSSACD
16P16161611
IEEEIEIEE
VideoCntoCeoViV
15P155P1V
VideoStream
eVVideoStream
200AudAuu
n
6P
e
A
r
DV-SP1000
A
PRINTED CIRCUIT BOARD VIEW
U01 : DVD MAIN PC BOARD NADG-8257
B-side pattern and B-side silk
1
R1
1
1305
C1344
7
2
2
1
L1302
4
1345
L1
1349
1A
1332
R1
1327
BCD
2
1
udioSt
C204
C
1
1
5
1
40
3
C1
3
12
6
R12
0
122
C122
125
100
4
1
1
100
0
290
C1054
10C29
P21
5
A-SIDE PATTERN
B-SIDE PATTERN
Page 30
C87
706
3
4
8211818
3
388
C8053
CCCCC
2
8
2
02
Q8
C8332
C
8
8
C8242
6
9
8
85
8
31
3
Q8
55
22
33
3388
Q8704
Q8506
C8050
2
C8015
C8049
C8509
C840
1
C8421
C84
C
C8005
3
77828
C8510
0C8C8
C8509
C8509
9
9
82
8082082
803
8
313
C
50811005
0
8
8
8
66666
6
C8057
3
C8317
C814C1
C831
C
8
Q
Q8101
6
6466
Q8304
Q8304
C8006
3
3
5
3
3
C
C8403
83 683 6
6
5
45
81
C
C8512
2CC8
12
C8508
C85
3
3
043
R8339
R8339
R833
24242244338
CC383
C8056
6C8C8
C80
C805
0C80
Q
Q
C80
47
C848
0
0
8125
820
C87
C8511
1
C851C8
C8055
C8
4
9
1
151
5
5
1
1
5
58
5
51
8
8
3333333
3
803Q
4
4
8
C8
C
0C4
C8052
8
08
5
8
7
Q8
5
555
5
C8054
C8404
C8404
13
13
1111111
6
6
C8710
C
C8302
C8320
C8
C8045
0
C8135
0
10
Q
C8319
C8
83
42
2
3
3
02
6
048
048
57
C8412
X8002
C80
80 880 8
8
1
3
C840
8CC
8
8608
CCC
8
C8323
C8322
139
C813C839
3
52
53
53
5667
2020208
A
88004
00
0
834
4
C8104
7
C8113
8
1
37
C84
6
7
C
C8126
C8 6
3
83
7
C8102
C8022
C
C8
C
85
C85
CC0
C8236
C
C8236
C8236
999
9
5
1
29
C82
C82
C
23
C8023
C8023
C8078
C8044
4
3
4
C8230
802
C8127
C8127
C8121
C8
484
C
C8124
Q8007
22
Q8502
C8101
C8
01
C8063
888
8
777
7
C
4
30
C8311
C
CCC
C8310
C8035
C
036
B
09
0
5
C8043
11
9
8
8
8017
79999
80
8415CC
5
C
C
101C
8
C84
777
44
4
8
2
03
C8131
C813
1
1
1
1
99
7
C8517
2
8
08
3
X8701
730
C8130
C
C8130
Q8005
CC1
8
888
202
22
1
Q870
8
5
5
8
8
2
8535
21
21
21
888
8
3
3
555
C8080
2
Q8006
4
C8
8520
C8002
2
1
8
8
80
22
8080
C8231
C8
15
C
CC
C
C804
C8206
40QQ
85
85
Q803
C8125
Q8504
30
6
33
3
C
C8214
11Q850
8
8188120
830
8
8
C8204
C8220
4
5
5
8
21C8
C8003
C8133
C8
2
C803
87
C8
C8020
802
802
802
8055
C83
C8318
8001
3
87
A80A
C8524
Q
Q
111
1
99
5
4
83183831
83
0
0
C841
C8527
0
C8210
0
80368036
C8232
C8
C8142
4C8
8
8212
7
7
C8004
C8116
8
C
5
8
1
77
3
C8202
202
C8
C8238
000
0
1414
0202
34
C8134
00
7027788
C8701
180
64477
7
44
44
8
C
C
41
C8
Q
1
6331188
C8237
77
C806
8061
00
88
C8106
C11
4
77
C8136
C
13
88888
88
C8
C84
C
038
8844C8213C8213
3
C82C82
11
C81C88
8
152
15255
111
111
4
8
25
80
80
4
48
25
2
5
00
2
3
3
CD8
2
25138272B
25138272B
25138272B
25138272B
HDMI-OUT
D
HDMI OUT
I-OUT
Q8706
Q8706
83
Version
CLPX
X
VINPIXC
NNN
CLKLK/DVDOE
//D/D
/EXTOE
VGND_D__
SISI
SOSO
/FWR
CC
/FWS/FWS
LMDO
D
ESETESETTEE
L
L
PRINTED CIRCUIT BOARD VIEW
U13 DIGITAL VIDEO PROCESSOR PC BOARD NADG-8272
A
1
2
3
4
5
BCDEFGH
Page 31
C87
706
3
4
8211818
3
388
8
2
02
Q8
C8332
C8C8242
9
8
85
3
Q8
55
22
33
3388
Q8704
Q8506
C8509
C840
C8421
C84
C
77828
C8510
0C8C8
C8509
C8509
9
9
8
313
C
8
66666
6
3
C8317
C814C1
C831
C
Q
Q8101
6
6466
Q8304
Q8304
3
3
5
3
3
C
C8403
83 683 6
6
5
45
81
C
C8512
2CC8
12
C8508
C85
3
3
R8339
R8339
R833
24242244338
CC383
0C80
Q
Q
C848
0
0
820
C87
C8511
1
C851C8
C8
4
9
1
151
5
5
1
1
5
58
5
51
8
3333333
3
4
4
C8
C
0C4
8
08
5
8
7
Q8
5
555
C8404
C8404
13
13
1111111
6
6
C8710
C8302
C8320
C8
0
C8135
0
10
Q
C8319
C8
83
42
2
3
3
02
57
C8412
8
1
3
C840
8CC
8
8608
CCC
8
C8323
C8322
139
C813C839
3
0
834
4
C8104
1
37
7
C
C8102
C8022
C
C8
C
0
999
9
23
C8023
C8023
C8078
C8044
4
802
484
Q8007
C8101
C8
01
C8063
888
8
777
7
CCC
C8035
C
036
C8043
8
8
8017780
9
9
9
9
80
8
777
444
Q8005
CC1
8
2
21
21
21
888
C8080
Q8006
4
C8002
2
1
C
CC
C
C804
C8206
C8125
C
C8214
8
C8204
C8220
4
5
5
C8003
2
C803
C8020
802
802
802
8001
A80A
C8210
0
80368036
C8004
C8202
202
000
0
1414
00
41
C8
Q
1
63311
C806
8061
C8106
C11
C8136
C
13
038
C8213C8213
3
C82C82
11
4
8
25
80
80
4
48
25
2
CD8
2
25138272B
25138272B
25138272B
25138272B
83
VINPIXC
NNN
CLKLK/DVDOE
//D/D
/EXTOE
DV-SP1000
A-SIDE VIEW
B-SIDE VIEW
Page 32
C
C4
C470C4C47
704
4
C
C4752
C48
2
C4802
C4851
C48
C
C49
C49024C
21
D4
4
4
D4
4
D851
D4
4
4960
60
6
0
0
4
Q470
Q
Q47
Q475
Q4QQ
Q4
Q4
55QQ4
Q4756
Q
Q4802
Q48
000
4851
5
3
48
57Q
85
Q4858
Q
Q
49
01
2
0
7
4
705
2
3
3
7
58
4767
5
5
6
8
80
809
809
8
8
1
1
2
1
854
5
48
4857
58
65
867
48
5
90
2
9
3
9
4
98
C
C4952
5
59C4
C
C495749C4
C4959C4959
2
965
C4966
C
96
C496
9
0
C4971
C4973
C
C4974
7
95
L4953
3
4
96
A
Q4954
4954
Q49
Q4955
Q4956
Q4956
Q49
Q4957495
953
954
956
95
96
9
965
6
974
5
98
T4951
T4
4951
L
6
959
L
9
9
C
25138266
P4950B
950
P4
0B
2
C4
C4205
4202
Q
Q420
Q4203
Q4203
Q4204
36
42
2
3
C42
C4204
2
Q4207
42
5
6
Q4
Q4757
986
995
996
98
3
60
2
603
604
4208
PRINTED CIRCUIT BOARD VIEW
DV-SP1000
U09 : AUDIO OUTPUT PC BOARD NAAF-8266
4961
47
52
22
4
2
492
4
4
R491
751
4901
1
1
1
4
4
8
A-SIDE VIEW
4955
4979
7
4
4
499
1
R4
4
R477
4
4
4975
4
4
L495
424
424
4
49
4
4
4
1
4954
496
4
4
4
4
42442
7
4
P4959
7
4
6
49
7
4
4
2
4
4
420
47
D420
1
4
A-SIDE PATTERN
B-SIDE PATTERN
DV-SP1000
Page 33
C4701
02
470CC4
C47
C4
C4752
C47
C
801
C
C4
C
3
4
C4851
C488C4
0
C4902C
21
511D472D47
D4851485
2
D48
0
961
2
4
Q4
4703
Q4
5
57Q
Q475
5Q455
Q4756
475Q44
6
Q4802
Q
Q48
000
4
5
48
4QQ
48
Q4858
Q4858
Q
8
Q
1
2
7
47
2
3
3
7
47475
4767
8
8
6
4
809
809
8
8
1
1
2
1
8
54
48
5
65
867
48
07
4907
90
9
2
4
9
3
4
8
9R49
98
95
C
C4952
95
C4959C4956
C495795C
C4959C4959
2
5
C
C4
0
C4971
C497
C
C4974
C
97
953
L
954
5
Q4954
Q49
Q49QQ4955
Q4956
Q4956
Q4957957
95
953
4
5
6
9
496
965
974
97
T4951
T495
L
8
5
959
L
99
C499
25138266
P4950B
P4
0B
02
C420
C4205
Q4202
Q420
Q
Q4203
Q4
3
C4
C
Q
5
6
Q
Q
7
995
996
3
603
4
9
9
PRINTED CIRCUIT BOARD VIEW
U09 : AUDIO OUTPUT PC BOARD NAAF-8266
DV-SP1000
B-SIDE VIEW
4
4962A
495
4
P49
4987
4
C4967
4
4966
4
E4
4202
4986
42442
P495
4975
4
E460
49549
4956
496
1
4
4
4
4
R495
424
424
42
495
4
R4984
4
475
497
R49
4
495
497
7
4
4776
7
4
1
4
4
4
4
1
4
1
4
8
4
4901
R
R4922
2
4
492
1
4601
R470
A-SIDE PATTERN
B-SIDE PATTERN
DV-SP1000
Page 34
4001
C
C400
004
4005
05
C4005
5
5
5
C4005
C40
00
C400
0
C
C
008
00
08
00
08
08
8
8
08
0
808C40040C400
C400
C
C
0
0
0
09
9
09
009
009
009
C4
C4
C4
C4040C4C4CC44
0100100
C4010
C4010
C
C
C40
C40
C40
C40
013
013
013
013
C4
C4
C4
4
C4016
401
166C
0
016
C
C48C4018
C
8
8
C4019
C4919
019
401
119C
C4021
C4021
C
C4021
C4021
C4021
C4021
C402
C402
C
CCC402222022C
C4
C4023C4C403022
C4027
C4027
88C4028CC404
C4030C4030
C40333C4033
C403
C
7
C4041
C40
C
434333C4043
4
4
4
04
C404440C4
4044044
44
C
C4045
C45C400445545
C4040C
C4
C404
C04C
C40
0454504
4
C
C
C
404046
446C4C4C40404
4
C
C
C
46
46
6
C4047
04747C40
047
047
C40
C0048
C4499C404
C
C4051
C4051
5
0
430
4
30330C434C
C430C055C43
077077C4307CC4
4308CC
C4309
C43
309
C43
C4
C
2
22
3
3
3
4
C4325
43
C4325
C43
C4326
3
C4326
C43
43
43
4
C4343
C4343
C4343
C4343
C4344
C4344
C4339
C433
C
C9C4339
C4339
C4339
C433
C4340
C4340
C434CC
4341
C4341
C4341
C4
C4342
C4342
4403
C44005C440
C4407CC4407
C4408044
40
08
408
C4409C44409C4C
C
2
442144242C4
C4
C4425
C442
C4425
C4426424424C
4424427
C4
C4428
C4428
C4428
C4443
C4443
C4444
C4444
C4439
C4439
C4440
C4440
C4441
C4441
C4442
C4442
5
5
505C4
C
C
4508
4508
508C4C
4508
450
C4509
C45CC
C4512
C4512
5
3
5
C4525
C4525
C4525
C452
C4526
C45
C4526
C4
4527
427C4
C4
9
4531
4531
C4543
C4543
C4543
C4544
C4544
C4544
C4539CC4539
C4539
C4540
C454
C4540
C
C
C
40
40
40
54
54
54
4
4
4
00C4541
4154
C4542
C4542
6
60505C46
C4607
C
C
C4607
C4607
C4607
C
C4608808
C460
0
C4609C4609
C46C446
C4612
C4621
C462C4C4
C4623
3
4
C4625
4
C4625
C4
C4626
C4
C4626
C4626
C4627
C
7
9
62
C4643
C4643
C4643
C4643
C4644
C4644
C4644
C4644
C4644
C4639
C4639
C4639
C4640
C4640
C4640
C4641
C4641
C4641
C4641
C4642
C4642
C4642
C4642
2
D400440D44D40002202002
D40
400D
44D400003
0330
1
2
E4001
R4145
R4145
R4145
414
41455
5
02B0P9
10
02B
P9102B
P910
P910
P3002B
P3002B
P3002B
P3002B
3
00
B
0000BBP
3002302
P
P
P4003A
P400
P4003A
P4003A
P4003
A
P4003A
P4003A
P4003
400
P4003
P4003A
P4003A
P
P4003A
P2004B
P2004B
P2004B
P2004B
04
B
20
P2004B
0
B
20
P2
000200420
P4005A
005A
P400
05A
P2003B
BP0P203
P2003B
B2P0300
B
P1302B
P1302B
P1302B
130230P1
02B
P
302302B
1302
30
2B
A
4001
Q40QQ
Q40088Q400808400
Q4008
8
Q4010
1
Q4010
Q40
0
Q4010Q40
40
40100Q4
Q4010QQ4040
Q4010Q0
Q4
12
2
Q4013
Q4013Q013
Q4015
415Q401
40
15
01Q7
Q401740017
Q4
0
40
1
Q4018
1QQ4018
0
0
Q430222
Q4302Q430Q
2
Q4
QQ4Q
0202
Q4321
Q432
QQ4321
4
Q43224Q4322
QQ322
322
Q4402
2
Q
Q4402
402
Q44
Q442200
Q4421
Q4
Q4421
QQ4421
4
Q4422
Q4422
QQ4422
442
Q4502
02
Q
Q4502Q45002QQQ
Q4521Q4Q4521
Q4
Q4522
Q452
452245Q
Q
Q4602
460
Q4602Q4602
460
4
2
2
Q4621
Q462
QQ4621
462
Q4622
Q4
Q46
QQQ4622
Q4
2
3
4
40
R40
00940R4
R40
4009
R
12
5
7
1
0
0
21
2
566778899
R4045
R40
R4045
R4047
47
40
1
2
5
5
6
8
9
0
1
6
66R4066RR404
22R4072RR404
55R4075RR440R4
R4R40787807R4400RRRR444081
4081
1
080800R4R44
4
R
R
R
R
R
R
R
R
4
4
4
4
4082404082
4082
2208
08
08
08
0
0
0
0
R4
R4
R4
R4
4
4
4
4
R
R
R
R
R
R
R
4
4
4
40834083340833308
8
08
0
0
0
0
R4
R4
R4
4
4
4
55R4085
R40
085
408
85
666
R4086
R40R4866408
777
R4087R40887087
R4
8
8
8
R4088R4408
R40R8
088
000
R4090
R4R900940
0
11R4091R409
R40R4091
91
R40
R40
0
R
RR4R
R404R090
09
9
9229922229
0922099409
40
09
R4093R44093
4R44093
R4094R409
R40R4094
4
R4R4R4
R
R
R
0909
5
5
99990
004045
5
R40960R4R09966
R44R4R0099990040477
R44R4RR009999004048
8
R4099
R40R09999
R44R4RR10000114140000
1
0
R4102RR4
410
102
02
R4105RR4
R41
410
05
R41RR4106
R410070410777
R4
4
0
099R4RR4
109
RRR
41101411000R4R4
R4
4111
11
R4R411
R
RR41141421
444111222
R4
4
R4
RR4114141314
44111333R4
R4
4
14
556778525
626667
7
32
R4133
R4133
R413335R
R4136
3
R413848
3
4
R4141441R44R41141141
4
1
1
2
4
42
4
4
5
1
5
6
9
39
0011223
3
432322121R4
R4
R4322R22
32323
2323R4343R4
R
RRRR4323224244
4
R43R4325
6
R
432734R4R
R4R44RR4R44
R
R
R
328343
4
43
4330
R433131R
4332
R4332
R4341434R44
341
43
R43423442
R434
34
42
42
R434
34435
R4345
4
R4346
4
R4346
4
43
R4346
4
5
R442
R442RR2121
R
4423234
R
R442442
2424R44
R4425
R4425
R4426
R4426
R4427
7
R4428844R4RR444
4
29
R4431
4431
R
R4432
R4432
R4432
R4432
R4432
R44414444
R44
4
441
44
R4442444
R4444442
44
R4445
R44
R4445
44
44
R4445
44
R4446
R44
R4R4
46
46
R452
R452
R4
21
21
R4522252R452
2
R452323R45
R452452
2424R4455
R4525
R4525
R4525
R4525
R4525
6
R4527R4527
7
7
R45284R4R5
5
R4531
R4531
R4532
R4532
32
R45414454
45
4
541
54
R4542454
R45
4
542
5
R4545
R454
R454
54
R4546
R4545454
60
6
60
123
4
R4626221
21
R4622
R4622
R462
R4622323
R4R6262242446
46
R4625
R4625
R
R4626
R4626
R4626
R4626
R4627
627
462727R46
R46
R4R4R
628626
6
R4631
4631
R
R4632
R463
R4641R46
R4R464146R4642464
R
4642
6
4642464
R4645
R464646
5
R4645
64
R464
R464646
46
4
C
C4242CC42
207
8
C4208
2C422208
8
2
4
20
C4
C40909C9C420420
C4210
C4210
C
C4210
1
P4012
P4012
7
0
6
7
0
1
1
1
1
1
1
1
R
63
8
8
4
1
22R4142RR414
33R4143RR414
4444444
R414R4
R
Q4019
Q401
9
Q4019
Q
Q
Q
950
1
1
B
B
A
A+B
A
A_+B
A_G
_GND
PW
WRCTRWRWRCTR
TR
P
-11222VV
12
2V
GNDGDDN
+12V
V
12
A_ B
A_-B
B
L
L4012
L40
46
R414
+12V22V+1+VV
V
A_GND
GNDAGGA_DD
N
12V22VV12-
V
NNG
G
G
G
G
DDD
NND
S_MUT
S_
_MS_MUT
MUTS_MUT
MUT
SW1SSSWWWWWS
SS2V2V12V
2V
DWDDWWWWWDDXR
WX
DWXL
DDWWWXXXLLXWXW
W
X
D
D
DW
D
W
EV_5.6
_5.EV_EV6665
EV_GN
_GGEV_EVNDDNN
G
63C
8
50
R149
R
5
5
20
2
20
C4064
C4064
C4064
C4064
C4064
C4064
C4064
R4153
1
R4153
1
R4153
1
1
1
1
Q405
051QQ4
40
1
Q40
4051QQ4
5
B
JL4006A
B
901
D4
90
D4
DV-SP1000
A
PRINTED CIRCUIT BOARD VIEW
1
U18 : AUDIO DAC PC BOARD NAAR-8263
2
2
C462
2
4202
4
R452
4
BCD
C40
1
4005
R
4
4507
45
403
C40
1
Q4017
4
C401
4012
4006
450
2
4
4422
3
1
4424
4207
R432
4
P401
2
4
+
C
2
4
441
C
14
431
406
0
06060
4012
0
4
4
A-SIDE PATTERN
5
B-SIDE PATTERN
Page 35
4
4002
C4
C
1
C4015
C
C4020
C402
C4025
C4029
C4
0
01
430
0
0
C4306
003C1
C311
C4313
3
C
333
34
C4334
C
C
335
C
C43
C
C4336
40
01
C44
C
1
C4
C
4406
C
0
C44
4
4C411
C4413
C
33
C
34
C4
4
35
C
C4
C
4
36
01
0
0
50
01
C4
450
C
50C45
450
506
C4
50606C45
C4510
C4
C411
C413
3
C
3
53
34
5
45
4
5
5
C4
C
4
6
460
C
C
C4
C
0
C4604
C
C
10
C46
0
11C46
C
3
33
C
63
3
34
4
C
3
C4
4635
C
C4
4
C
0
1
D4
D
40
D4203
D4203
D
D
D4204
D
D
D
05
D
D
D
L4001
L4
L4002
L4
L
0
4
02
L4003
L4003
00
05
5
L400
L400
L4005
L4005
L4
L
4007
8
L4008
L
8
L4009
L4009
L4010
0
L4
011
L
L4
30
1
L43
0
3
L4
L4302
L4303
430
L43
303
L4
L4304
L
4
430
4
0
L4304
4
440
01
4
44
44
4
L4
L
L4
2
L4402
4403
44
L4
L
L4403
4
L
403
4
0
0
0040
4
4
44
4
L
L
L44
1
50
5
0
L
L
L45
50
1
4
L4
502
502
L4
L4503
4
L
L
504
6
0
L
L
6
0
6
6
L4602
L4602
L460
L4603
L4603
0
60
3
46
4
0
0
L4
46
04
60
6
Q4002
3
Q4003
Q004
Q
7
Q4007
Q400
Q40
009
Q4
Q4208
0
43
30
4
3
Q43
Q
Q4323
24
Q43
43242Q4324
4
401
Q44
Q4
Q4423
424
Q4
Q4424
4424
5
50
Q45
01
Q4
Q4523Q4Q
4524
Q4524
0
01
Q46
0
01
46
62Q4Q
Q4623
Q4623
Q
Q
Q
Q
05
0
4
R4
5
400
0
40
06
0
4
4
6
00
0
40
007
0
R40
R4
07
00
0
40
011
1
R
0
4
R404
44
04
R40
44
048
R40
R
R
4049
068
R4069
R4070
R
6
R
720420
R4
R
024
R
R4220
4220
21
422
2
R
R4
1
223424
R42
3
R422424R4226
R42
282R422
28
7
R4247
R4
2
4302
4302
R43
R4
R
R4314
R4314
R4315
R43
R4
15
R4316
R
43
R4
R4333
R4334
R4334
43
5
335
R4
R
336
R4337
R4338
R4338
R43
R43
38
38
R
R4339
R4340
R4347
R43
R4348
R43RR
49
350
R
R4351
R4352
R4353
R
353
R4354
35
R4355
R4355
R4356
R435
R4357
8
R4358
4359
R4359
R
R4369
R
R4369
R
R4370
R4370
R4371
R4
R
R4372
R437
R44
R4
R4402
R4414
R4415
R4415
6
R
6
R4433
R4433
4
4
R
R
R4434
R4434
35
R4436
R4436
R4437
4
R44
R44
437
437
38
38
R443
R44
R
R4
4438
R
R4439
R
R4440RR4440
R4447
R4
R4448
R
R44
R
9
RRR4450
R4451
R4452
R4453
R4454
R
R4455
R
R4457
5
R4458
R44
R4459
R4460
R4469
R4469
470
R44
R44
R447
R44
R4471
R44
R4472
R4
2
R4
4
4502
R4514
R4514
4
R4514
R4515
R4
515
1
6
R4
451
R
R4533
R4533
R4534
R4534
R4535
36
6
R453
36
6
R453
53
5
R45
R45
37
37
R453
R453
R45
R45
38
38
R4
R
4539
R
R4540RR4540
R4547RR4547
R4548
RR4R
R4549
R4550
R4551
R4552
3
R4553R4
R4555
R4556
R45
R4557
R4558
R4558
R4559
R
R456
R4569
R4569
R4570
R4570
R4571
R4
1
R4572
R4
4
0
R
R
R4
0
4614
R4
6
R4615
R4
4615
5
R
R4616
R4633
634
34
R463
5
R
635
R4
4636
R
R463
R46
37
R46
R4
638
463
63
R4
38
R
R4639
R
64
R464
40
4647
47
R46
R
R464
R
R4648
R4
R46
4
R4649
R4650
R
R4652
R4653
653
R4654
R4654
65
R4655
R4656
R4657
R4
R4658
R4658
R
R466
R4669R4669
R4670
R467
70
0
R4671
R46
R
R4672
R46
1
1
1
111
1
1
100
0
1818
19
25
3
36
424R4
R42
Q4213Q4213
Q4
R4250
R
6
4
R4673
5
R4573
3
R4474
4
R
3
R4374
R
R4373
21
1
0
0
4
40
40
02
Q4
Q
Q
Q4
4
4
5
41
41
R
R
R4
R
5
5
4
4
65
65
5
0
4
4
06
C
R4155
D490
04
D4
4
D4903
D4
9
D4907
D
D
8
D4908
9
D4
8
DV-SP1000
A
PRINTED CIRCUIT BOARD VIEW
1
U18 : AUDIO DAC PC BOARD NAAR-8263
4
R4
2
400
L4
4
401
0
R
BCD
B-SIDE VIEW
4
1
6
1
2
407
4
461
636
1
4651
46
4
7
4
4
53
C4
R4
74
42
C
3
453
4206
3
C43
4
Q
1
441
4
444
R4
4
44
4
R44
44
447
4360
4
4
4
A-SIDE PATTERN
5
B-SIDE PATTERN
Page 36
2
S7301
P7401A
AP740
40
P
P7401A
P7401A
740
7
C740C7C740
05
0
01
C7202
C7
05
10
07
10
C7110
711
C7111
C71
12
C
0
000
002
X70
X7002
1
0
B1800
2
3
03
C
Q7101
Q7102
C7109
C7305
7105
C7
06
C7107
C7108
P2901B
P2901B
P2901B
PPP2901B
P2901B
0
R7201
R720
R7201
1
R
R7201
01
111
19
73
25138259
3
6003B
_
L
X
L
D
HD
LE
VDO
LE
ST
STOPLED
OP_CLLED
SUB_SO0
0
SO
SUB_SI0
SI
SUB_REQ0
SUB_CL0
SUB
SUBRST0
0
S
LEDGNDL
D
D
LEDGN
D
LED+B
+B
LED
LED
-VPGND
-V
-VP
3
VG
W+8V
ND
WGND
G
G
V
T
AAATE
U
NGN
_
_O
_
_
_
_
1
P7302
9602B
960
G
3
LU
PRINTED CIRCUIT BOARD VIEW
U03 DVD MAIN CPU PC BOARD NADG-8259
A-SIDE VIEW
A
1
2
3
4
5
BCDEFGH
Page 37
2
S7301
P7401A
AP740
40
P
P7401A
P7401A
740
7
C740C7C740
05
0
01
05
10
07
10
C7110
711
C7111
C71
12
C
0
000
002
X70
X7002
1
0
B1800
2
C7305
19
73
3
6003B
_
L
X
L
D
HD
LE
VDO
LE
ST
STOPLED
OP_CLLED
SUB_SO0
0
SO
SUB_SI0
SI
SUB_REQ0
SUB_CL0
SUB
SUBRST0
0
S
LEDGNDL
D
D
LEDGN
D
LED+B
+B
LED
LED
-VPGND
-V
-VP
U
NGN
_
_O
_
_
_
_
1
P7302
LU
DV-SP1000
A-SIDE PATTERN
B-SIDE PATTERN
Page 38
D
C700200C7
02
C730
R730CR730
R
R
C7311
C73
C73
04
30
4
08
30
2
R73
7R0
005
0
R700
9
R70
0
R701
11
R70
R7013
R7014
R7015
R7016
R7017
R701881
R7019
R70
19
R702002
R7041
R7042
R7043
R7044
R7045
R7046
R7047
R7048
R7049
R7050
R7051
R7052
2
R
4
R7
70
05
5
0
R70
R7059
R7060
1
1
R7062
3
R706
0
R730
2
730D0
173D
0
Q
Q72
C7203
3
0
R7207
R72
R7
R7208
R7209
R7210
212
R721
3
R72
155R72
6
R72
2
C
C7009
R7101
R7102
R7123
R7124
R7125
R7127
R7126
R
R7128
4
R7012
C7003
C70
Q7
Q7201
Q7201
Q
Q7202
Q7202
R7121
R7120
R7118
R7119
R7116
R7115
R71
R7113
R71
8
8
1
1
1
001
0
R7068
R7070
R7072
R7074
R7076
R7077
R7075
R7073
R7071
R7069
7
7
218
8
R779R707
08
R7
PRINTED CIRCUIT BOARD VIEW
U03 DVD MAIN CPU PC BOARD NADG-8259
FROM B-SIDE VIEW
A
1
2
3
4
5
BCDEFGH
Page 39
D
C700200C7
02
C730
R730CR730
C73
C73
R73
005
0
R700
9
R70
0
R701
11
R70
R7013
R7014
R7015
R7016
R7017
R701881
R7019
R70
19
R702002
70
05
5
0
R70
R7059
R7060
1
1
R7062
3
R706
0
2
C7009
R7101
R7102
4
R7012
C7003
C70
001
0
R7068
R7070
R7072
R7074
R7076
R7077
R7075
R7073
R7071
R7069
7
7
R779R707
08
R7
DV-SP1000
A-SIDE PATTERN
B-SIDE PATTERN
Page 40
6
6
P3019
9
0
Q30
Q300403
1523R
35
313
1
1
3
1
1
3
1
6
1
5
28
Q3509
Q
Q
C3534
7
0
1
515553R3R35545435
R3564
356556
R
R3004R04
R30055003
R30060063
R
3
R
R3009
30003
R3009
0
2
3
3
47
R
5
A
B
3
2
222
Q3010
Q
8
00000
0
Q30063Q
8
R351
R3517
9
Q
7
35
0
R3
R3109
C305
C3044
C
9
R309
R3096
C3060
2
Q301Q3Q30
3
3
1
35
35
555
R3084
4
4CC3024
3
30
5
1
R3
R3
R
R3086
0
81
R308
0606R3R
2
277RR
R30
059
R3
R3055C119
930
2
C
1
R
R
3099
R3099
R3100
R31007P
9
P3
000
3
3
3
350
3509
2
R3510RR35100351
1
R3531
R3532
R3532
6
R3536
R3
R3541
35
Q3511
6
C3510
0
C3510
C35C3C
Q3503
Q
8
355
R
R3553
C
C3524
3
C30150C3
C3015
02
0
3
R350130
5
10
20
558
8
132
13
5
0
0
39646
103
10
28
128
3
25138262B
DV-SP1000
A
PRINTED CIRCUIT
BOARD VIEW
U20
IEEE1394 TERMINAL
1
PC BOARD
NADG-8262
EXCEPT <GR6P>
2
BCD
FROM A-SIDE VIEW
350
1
0
11
3
4
11
350
3046
3097
300
1301
P3002
3005
1
35
301
04
7
05
0
350
2
R
3001
3003
R3003
R300
R3028
1
5
3509
350
P350
300
1
R3107
P350
1
P301
4
3094
3105
12
P3020
L301
2
302
R
P302
A-SIDE PATTERN
B-SIDE PATTERN
Page 41
R3567
C3531
C3
30
C3533
C
2
3
C3016
C30
3016
Q
5111
L351
39
0
2
1
C
2
C3008C0088C
C3010300
4
C
C302530C3
10
R
R
R3021
2
R3041
4
R3
5
5
R3055
R30
55R3058
R
R3079
R3019
1
R3015
1
05
R
R3057
R
R3062
R
9
00
0
3
3017
R
R3022
R3022
5
R3093
062
C306
C3017
R3573
R3573
C306
C
R3061
C3018
R3112
555
R3539
R3
C3004
4
C300
C352
C3525
R3054
C30
C30050
R3576
R3575RR3575
R3575
6
555
526
0
5
5
0
R3574
R
3
RR5
7
R
R
R3558
R3558
4
0
2
2
L3512L3512
3
R
R35040354
3
114
5
8
DV-SP1000
A
PRINTED CIRCUIT
BOARD VIEW
U20
IEEE1394 TERMINAL
1
PC BOARD
NADG-8262
EXCEPT <GR6P>
2
BCD
FROM B-SIDE VIEW
3
35
R353
4
71
1
3011
4
5
R3001
C3021
C3011
301
304
4
304
304
7
353
A-SIDE PATTERN
308
C30
B-SIDE PATTERN
Page 42
P3019
019
P3
0
P302
P35066P3506
Q
Q30043Q
Q
5
Q
3
R
R35333
R3539
3
R3
9
R3540RR3
5442R
455435
R
475435
R
RR5
R3554
R35646R
R3565
35
R3005R05
006RR
06
R300703
R3008R08
R30093000
R3020R32
R30
0
089
R3089
R
R03
0
005
333
9
008
3503
Q35
9
P
P3
7
7
5
07
30
0
R
01
R
4
6
30
7
1
3
0
3
08
1
50
5
R350R5
R3502
02
R3503
R350
506
35
0
R33100
9
030R99
R
R3098
097
R
R
95
94
35R550
0
7
3508
35
0
4
5
11
7
0
30R3
0
06
3
6
C
C3530
C35
C3533
C3534C34
C3537
6
35
3
34
R
2
R3083
C30
3C8
C326C322262
R30
7
R30
R3
4993
R
443C3
C12
2
03
1
R3517
R3022
35
5
8
018C33
0133CC
7
C3
6
3
R3030R30
R
C3015CC3
L3002
055R33
056R33
058R33
C301
C3019
RR1
5
7
8
9
R30404
3
04
4
R
R305250
3
RRR3080
3
53
3
3536
R353
7
R35413R
4
R3543
R3543
R354
R
R3552
R3
3556
R
R3563
6
R3560C
C3
0553
C
30030Q
3
8
8
0
C
C
C3029
777
4
4
4
4
3
C304
44
C3051
C3051
C
C3055
C
C3501
C3501
0
0
C
0CC
C351C1
0QQ
05
5050Q
Q
0650Q35
Q
1
C3514
C3514
C3516
1
C351771
C
C3518C18
C
C3521
C
C353
C
88C353CC353
333
9
9
4
L3512L312
50333QQ
3
2
1
2
2
2
35
0
G
35
3
R3571R3571
P
P35
A
C3
C
4
8
3
P3509
P350
P3507P3509
1
1
11
1
44
44
89
89
132
132
132
33
6
6
7
1124
25
48
8
8
0
5
0
39
64
1
128
2
R3573R3R355757RR
R357
R3
CC33500
DV-SP1000
A
PRINTED CIRCUIT
BOARD VIEW
U19
1
IEEE1394 TERMINAL
PC BOARD
NADG-8468
ONLY <GR6P>
2
BCD
FROM A-SIDE VIEW
8
-846NCD
846
51
12
3512
1
P
1
P
7
3510
351
350
350
351
3569
3502
P
3
5
4
1
302
2
2
R3512
1
6
R
3511
353
3004
Q300
5
350
1
3509
350
L
L
3039
1
1
1
1
3110
L
32
30
1
R
310
P302
3023
302
300
1
4
2
302
1
308
1
1
301
R
R
A-SIDE PATTERN
B-SIDE PATTERN
Page 43
C7501
C7502C7502
C7503C503
0
C7517
76C
5
7520
C
2
999
9
7507
7507
A
0
Q7502
Q7
Q7502
Q7502Q7Q
Q7503QQ
Q7504
Q7507
Q7510
500375
1
520
255
7
8
S7501
S7
503
S750
S7504
S7505
S7506
1
01
25138264C
02
75
7
2
222
2
2
2
222
2
2
2
222
2
PRINTED CIRCUIT BOARD VIEW
U07 DISPLAY PC BOARD NADIS-8264
A-SIDE VIEW
A-SIDE PATTERN
B-SIDE PATTERN
A
1
2
3
4
5
BCDEFGH
Page 44
C7501
C7502
C7502
C7503C503
0
C7517
76C
5
7520
C
2
999
9
7507
7507
0
Q7503QQ
Q7504
Q7507
Q7510
500375
1
520
255
7
8
S7501
S7
503
S750
S7504
S7505
S7506
1
01
25138264C
02
75
7
2
222
2
2
2
222
2
2
2
222
2
DV-SP1000
Page 45
603
Q6708
Q6708
C6
C672
C6723
86
6860R6859
7
6
68R685
6851
C
C67
C6724
07
25138260
6
5
5
0
0
Q6707
Q6707
C6721
C672
C6719
6
8
80
9
6777
1
0
6
69
8
67
CCC67
C6720
6005C
3
2
0
61
1
6897
Q6708
C6725
C
C6723
6859
7
6
6855
68
685
6851
724
C6724
7
2
6
4
5
Q6707
C6721
C
C6719
9
6777
1
9
6
68
6
67
C6720
6005C
4
4
373
2
0
1
2
6
03
PRINTED CIRCUIT BOARD VIEW
U04 COMPONENT OUTPUT TERMINAL BOARD
NAETC-8260 <WT3P>,<PP2P>,<GR6P> ONLY
DV-SP1000
U05 COMPONENT OUTPUT TERMINAL BOARD
NAETC-8261 <DC1N> ONLY
ETC-82
2513826
6874
7
687
R687
6780
6896
7
6868
7
6801
685
685
77
R
772
77
R
7
L6701
77
7
7
676
R
R
689
A-SIDE VIEW A-SIDE VIEW
P670
6778
6897
ETC-826
687
7
687
77
7
7
676
R
R
7
L
77277
6868
6801
670
7
R
685
685
R
6895
6896
DV-SP1000
B-SIDE VIEW B-SIDE VIEW
A- SIDE PATTERN
B- SIDE PATTERN
Page 46
DV-SP1000
A
PRINTED CIRCUIT BOARD VIEW
U12 POWER SUPPLY PC BOARD-1 NAPS-8269
R9112
E9004
C9108
J9025
C9110
D9102
7
Q9104
C9103
C9104
C9108
J9013
Q9104
L9103
C9110
20
J9010
R9114
C9113
C9114
C9115
J9014
Q9103
7
7
C9117
C9122
D9124
L9102 L9101
R9605
P9104A
R9113
1
P9105B
R9102
R9103
R9104
C9105
R9105
C9107
C9106
C9102C9101
7
C9123
J9022
C9109
J9017
R9109
J9011
D9125
15
D9126
P9103A
J9012
C9118
J9018
12
P9008A
P9008A
2
R9106
R9101
P9007A
R9107
R9111
P9007A
R9110
C9109
3
BCD
Q9103
R9604
C9113
C9129
C9127
7
P9105A
Q9101
C9111
C9111
C9112
J9023
J9015
J9016
D9123
30
P-OFF
J9019
P9102A
Q9102
V-B
VGND
Q9102
V+B
J9024
25138269B
PWR-CONT
APGGND
FROM A-SIDE VIEW
C9112
12
NCPS-8269
SW+3.3V
SW+3.3V
APGGND
APGGND
APGGND
SW+5V
SW+5V
2
EV5.6V
APGGND
APGGND
APG+B
POFF
T2.5AL250V
ADACGND
ADAC+B
AGND
A-B
A+B
F9001
E9001
P9003A
P9004A
J9002
J9001
P9005AP9006A
F9001AF9001B
P9503A
L9001
AC-HAC-G
J9020
J9021
BLUE
C9002
223 OR6
L9001
27
27
J9003
J9004
E9003
NL
P9001A
WHITE
C9001
S9002
P9001A
P9503B
120V
S9002
220-230V
D9108
D9109
D9110
D9111
D9113
D9112
D9115
R9108
C9120
R9609
R9115
D9103
D9101
R9608
D9114
C9125
D9122
C9121
R9606
R9607
C9126
D9105
D9104
D9107
D9106
D9120
C9119
R9117
C9128
D9116
R9116
C9124
C9116
D9121
4
5
R9120 R9121
FROM B-SIDE VIEW
Page 47
DV-SP1000
A
PRINTED CIRCUIT BOARD VIEW
FROM TOP VIEW
1
C9601
C9601
J9604
15
J9602
27
P9602A
J9601
2
P9601A
15
E9604
SW+5V
SW+5V
GND
GND
SW+3.3V
SW+3.3V
SW+3.3V
SW+3.3V
GND
GND
GND
GND
Q9604
J9603
7
P9604A
FLOFF
PWRCNT
F+
FVDISPGND
-VDIP
GND
GND
EV5.6V
EV5.6V
GND
GND
SMW8V
SMW8V
P-ON
EV+5V
SW+5V
GND
J9605
27
P9104B
GND
J9606
7
SW+3.3V
SW+8V
J9609
25
20
J9610
PWR-CNT
SW+8V
GND
J9607
J9608
20
APGGND
EV+12V
SW+3.3V
APGGND
BCD
U13 POWER SUPPLY PC BOARD-2 NAPS-8270
GND
EV-12V
SW+3.3V
EV-30V
AC5V
J9611
APGGND
APGGND
SW+5V
AC5V
SW+5V
C9603
EV5.6V
APGGND
C9603
NCPS-8270
25138270
1
E9601E9603
E9602
3
Q9602
Q9603
R9603
R9601
Q9601
C9602
D9605
R9602
D9606
4
D9604
D9601
D9603
D9602
FROM BOTTOM VIEW
U14 POWER SWITCH PC BOARD
5
NASW-7271
P9003B
EXCEPT <DC1N>
C9003
P9004B
S9001
S9001
0
FROM TOP VIEW
25138271
NCSW-8271
Page 48
530
531
2
533
702
C7
7
3
Q
1
2
Q7
Q7
Q7514
Q
Q
Q7516
75
7
Q75
75
701
Q
Q7702
Q7
5
5
5
6
7
5
551
55
7554
56
02
3
06
1
S770
S7703
S
4
4
S7705
3826
5
1
9
9
7
01
530
53
533
C77
7
03
Q
1
Q751213
Q75
Q7514
Q
Q7516
7
Q751
Q
Q7707Q77
Q7702
Q770
5
5
6
5
551
55
7554
562
02
3
06
561
S7701
S7703
S
4
S
4
S
5
CS
7
1
222
2
DV-SP1000
A
PRINTED CIRCUIT BOARD VIEW
1
CSW-8267
7
2
FROM A-SIDE VIEW
BCD
U10 JOG SWITCH PC BOARD NASW-8267
R77
2
7
756
01
751
770
7
4
R7
70
7515
7
7
753
7
751
754
48
7
2
7
7
770
S770
3
W-826
77
7
7
4
7
7532
7515
R7
7
7
770
01
751
7
751
R7547
48R
1
7
7
2
7
4
7
FROM B-SIDE VIEW
A-SIDE PATTERN
B-SIDE PATTERN
N
5
770
770
770
Page 49
C6
C
C6706
C67
7
0
3
4
C6716
C
C6
C6
C671
C6718
C6
C6718
C68
C6802
C68
C
C6806
C680C6C6810
C
C6
6903
69
04
6
6907
9
6913
C6914
C6
C
C6
C6916
C6917
C6918
C6919
C6C6
C6922
C6923
C69 3
6926
6
C6927
C69
C6928
C6928
6
690
690
690
P4204B
P
2
4
P4204B
P
2
4
P420
0
P
42
P42
P42204B
04BB
B
5
60
B
B
302B
6
63
63
B
51
B
51B
6
Q6701
Q6701
Q6Q6Q6703
Q670
05
Q
0
Q6782
Q6801
Q6801
Q68
Q6802
Q6802
Q6803
QQ6Q
04QQ68Q6808
Q68
Q680
0
Q6901
Q6901
Q690
Q6902
Q6902
Q6903
Q6904
Q6905
0
Q6906Q66Q
8
Q6908
Q69
Q6908
5
6
63
6
672
6
7
6
7
6
43
674
674
52
683
6
6
0
70780
9
0
1
2
68
8
68
9
9
68
6288
2
2
68
6836
68 0
68 6
6
616
6
6
69 6
6
934
94
0
695
5
4
6
4
55
6960
62
3
696
4
67
7
80
6
Q6704
65
251382
3
3
6
93
C6
C68
68 6
68 5
80
68
6
998
99
R699
994R6
94
6
6
6891
8
6890
R6888
R68
606
PRINTED CIRCUIT BOARD VIEW OVERALL
U08 COMPONENT/ D-TERMINAL/
SCART TERMINAL PC BOARD
NAVD-8265
FROM A-SIDE VIEW
A
1
2
3
4
5
BCDEFGH
Page 50
C6806
C6
6903
69
04
6
6907
9
6913
C6914
C6
C
C6
C6916
C6917
C6918
C6919
C6C6
C6922
C6923
C69 3
6926
6
C6927
C69
C6928
C6928
6
690
690
690
P4204B
P
2
4
P4204B
P
2
4
P420
0
P
42
P42
P42204B
04BB
B
60
B
B
302B
6
63
63
6
Q6802
Q6802
Q68Q6808
Q68
Q680
0
Q6901
Q6901
Q690
Q6902
Q6902
Q6903
Q6904
Q6905
0
Q6906
Q66Q
8
Q6908
Q69
Q6908
0
70780
68
68
9
9
68
6288
2
2
68
6836
68 6
6
616
6
6
69 6
6
934
94
0
695
5
4
6
4
55
6960
62
3
696
4
67
7
80
6
C6
C68
68 6
68 5
68
6
998
99
R699
994R6
94
DV-SP1000
A-SIDE PATTERN
B-SIDE PATTERN
Page 51
C6
702
6C6C6
0
3
4
C
6
C6
71
C6
717
C
C6718
C6718C6718
802
C6802
C6806
C6806
C68C68
C681
C6810
C6C381690202C6
6903
69
6
6907
9
912
6913
C6914
C6915
C6916
C
C6918
C691
C69
C
69
C6922
C6923
C69 3
6926
6
C6927
C6928
C6928
90
04
67
6
P4204
0
4
B
B
P4204B
B
0
4
20204
B
B
04B
B04P420
42
P
P
B
6
0303B
630
BB5
B
A
A
10B
Q6701
Q6701
Q67
Q67
Q67
Q6703
Q
Q6705
70
5
Q6782
Q
Q6801
Q6801
Q6802
QQQ
Q6802
Q6
Q6
Q
80
Q680
0
Q6901
Q6901
Q
Q6
Q
Q6902
Q6903
Q6904
Q6905
Q
Q6906
Q
Q6908
908
Q6908
91
8
9
0
67
67
67
6728
673
674
674
151
3
781
67
78
80
807
68
81
81
817
7
9
28
68 0
09
9
1111
1
2
1
69 6
923
933
34
5
6
40
4
4
95
69
6960
62
6963
4
5
96
7
80
Q6704Q6704
382
25138265
3
C6811
6878
99
6994
69R694
R
9
9
6891
8
89
9
0
8
R6888
R6888
R6888
6
7
9
PRINTED CIRCUIT BOARD VIEW
U08 COMPONENT/ D-TERMINAL/
SCART TERMINAL PC BOARD
NAVD-8265
FROM B-SIDE VIEW
A
1
2
3
4
5
BCDEFGH
Page 52
C6
702
6C6C6
0
3
4
C
6
C6
71
C6
717
C
C6718
C6718C6718
802
C6802
C68
C68
C681
C6810
C6C3
81
67
B
BB5
B
A
A
10B
Q6701
Q6701
Q67
Q67
Q67
Q6703
Q
Q6705
70
5
Q6782
Q
Q6801
Q6801
Q6
Q6
Q
80
8
9
0
67
67
67
6728
673
674
674
151
3
781
67
78
80
807
68
81
81
817
7
28
68 0
Q6704
Q6704
382
25138265
3
9
9
6891
8
89
9
0
8
R6888
R6888
R6888
6
7
9
DV-SP1000
A-SIDE PATTERN
B-SIDE PATTERN
Page 53
4
7
52
56
61
62
52
2
51645
C645
54
C6453
B
Q6451
Q64
451
451
2
2
DV-SP1000
A
PRINTED CIRCUIT BOARD VIEW
U06 POWER SUPPLY PC BOARD-3 NAPS-8274
1
2
BCD
645
5138274
P9103
FROM A-SIDE VIEW
3
645
6451
6455
4
6453
5
4
4
4
645
4
6465
4
FROM B-SIDE VIEW
5
Page 54
P6151
P6151
P6301
P6301
01B
B
P2001
1B
P200
1
P200
0
P200
0
1B
1B
P200
P
0
P2
1
C6093
2
9
9
9
0
2
9
2
0
60
6
C
C
6
C
C6
0
C6091
R
R
R
91
1
R609
R
R
R
92
2
R609
R
R
R
93
3
R609
R
R
R
94
4
R609
Q6091
Q6091
4
4
7
74
R607
07
0
7
7
4
4
6
4
4
6
R
5
5
7
75
R607
07
0
7
7
5
5
6
5
5
6
R
C
C6003
C6003
C6004
C6004
C6005
C6005
C600
C600
C6006
04QQ6
Q
2
062
62
2
C606
C606
C
L6006
C6064
C
C
4
6
60
0
6
C
4
C
C6065
5
6
60
0
6
C
5
C
C
C6066
C
C6067
C
C6
6068
C
C
C6069
C
C6070
C
C6071
C6072
C
6
0
6
0
7
72
2
C6072
C
6
0
6
0
7
72
2
73
07
0
C60
C
C
C
0
0
C
6
6
6
C
C
7
3
4
4
074
07
0
C60
C6
6
07
4
74
0
0
C
C
5CC6
L60
L60
L
0
L600
6
C
C6046
C
6
0
4
6
C
47
C60C6
C6048
6048
C60
00
6
6
302
0
2A
P63
A
02A
630
02A
2A
P63
A
R6
R6
R6151
R6
R6
R
152
R6
R6
R
R
6201
6201
R6
R
R
6202
51
51
R6251
R6251
R6252
01
0
R6301
2
0
02
2
R63
R6351
R6352
2
R
R6352
R
6
6401
640
64
R
6
6
6402
64
02
402
R
R
Q6151
2
C
C
C615
C
C6
C
52
153
5
15
5
Q61
153
5
Q6
Q6153
Q6153
303
3
30
0
Q63
303
0
3
Q630
Q63
Q6303
Q6
630
Q
Q6401
6
C
C6
C
C
C
6
C
402
Q6
Q6351
Q
2
635
3
5
C6
C
5
52
Q6301
2
C
C
C630
C
02
Q62
Q6201
C62
C6
252
2
C620
620
C6
20
C6
C6
C
02
6154Q6
Q6
15454
Q6154
Q6155QQ6
15555Q6155
04
Q63
Q
Q630
Q63
Q6304
6166
166
R6177
C6253
C
C
C6
6253
C
C62
253
6255
255
C6255
71
6309
64
6176
23
4
6744
75
2
64
6
1466259
6310
41
R6142
0
6
Q600
Q60
0
Q600
Q610
Q60
33036
C6
C
065
6
0
R
R
48
8
R6048
R
R
R
R
R
R6051
R
R
R
R60
R6
R6050
R
R
6049
04
R6049
05
C60
053
C6052
C6052
C
C6050
C6050
5
51
C605
X
5
0
0
8
8
0
0
Q600
0
0
0
0
8
8
6
8
8
6
Q
R608
60
08
R
6
R
83
R607
60
07
R
6
R
77
R607
60
07
R
6
R
76
Q
6009
04
04
L6004
C6
5
Q6005
Q6005Q60
C6054
C6054
R6086
R6088
R6087
R6087
35
5
R603
035
56
6
C645
55
5
C645
L6503
L
650
3
4
4
4
4
C
C650
4
4
C
C6
1
1
L
L
L6
L
6501
1
C650
C
C6516
C651
6
6
6
R64RR64
4
4
69
69
R6468
467
67
R64
R6568
R6568
C65515C6
CC6
CC6
Q6553
R6558
R6558
D6551
D6
QQ6
7
7
R6608
R6
D6601
660
01
6
6
18
R661
Q6653
Q
R6658
R6658
D6651
D6651
6
0
6
Q6101
Q6
Q6
Q
Q
Q
Q
Q
Q
6101
01
610
61
7
7
R6107
610
7
R
R
R
7
C655355C65C63
C6528
C
29
C65
C
529
65
9
Q6522
65
65
25
C6
6526
6
6
65
R6
6
6525
R6
5
6
6523
C6
C65
24
652
24
C
Q6
B
B
00
00
B
P2002B
B
2
00
P20
P
P2002BPP2002B
C639
C6
99
C6397
C
C6297
629
C
6
299
C6
C6197
C61
6197
C
6199
199
C6199
18
18
11
61
6
R
11
1
18
R6
6
R
9
1
1
1
6
6
R
1
1
1
9
R6
9
6
R
R6104
6104
4
R
R
R6102
6102
2
R
R
R
R6106
610
6
R
R
R
R6105
610
5
R
R
R
15
11
61
1
1
5
R6
5
0
5
C6105
C610
C
5
5
R6
6101
R
R
R
6
082C6
C
17
7
117
7
611
1
R61
1
17
7
61
1
11
1
R6
R6
16
6
116
6
16
6
R611
R611
C
C6106
C6110
C6111
C6112
C6112
C6112
6
3
3
2
2
62
62
R6
R6
23
23
2
2
33
33
3
13
13
3
33
3
33
R61
0
R
0
R6140
Q61QQ
2
1
3
1
R6132
32
R
613
6
C
6
C6126
Q6110
C
C6128
Q
1
C6125
Q611
Q61Q6Q6112
R
R6141
R6131
31
613
R6
C6127
C6127
C
R6136
R
613
6
R6134
61
34
R
R6135
R6
R
R
613
61
5
1
1
Q6113
R6120
6
Q6
17
7
C61
7
1
C6118
C611
C61
5
L62
CC
C
C
C
6116
6
6
6116
C6104
R6103
610
3
R
R
R
C6101
C6101
C
61
6139
R6139
R
6139
R
C626120
C6195
C6195C6193
R6315
R6365
R6415
C6395CC66
0
R6178
R6179
79
R6
180
6
6
R6
2
48
8
28
43
43
6
8
32
34849
6
9
0
0
Q6010
6452B
6452B
P6
P
P6452B
P
D6007
R
R
R6085
155Q6Q6
A050
25138258C
3
C6056
C
56
C
6
605
C6080
6
6
R
R
6574
6574
R657R657
R657
75
051
A051
6
76
76
6
R657
R66
6
6
626
7
7
R66
R66
67
67
76
76
R6317
R6367
R6417
67
7
R616
C6160
C6172
PRINTED CIRCUIT BOARD VIEW
U02 VIDEO OUTPUT TERMINAL BOARD NAVD-8258
A SIDE PATTERN AND A SIDE SILK SCREEN
A
1
2
3
4
5
BCDEFGH
Page 55
01B
B
P2001
1B
P200
1
P200
0
P200
0
1B
1B
P200
P
0
P2
1
C6093
2
9
9
9
0
2
9
2
0
60
6
C
C
6
C
C6
0
C6091
R
R
R
91
1
R609
R
R
R
92
2
R609
R
R
R
93
3
R609
R
R
R
94
4
R609
Q6091
Q6091
4
4
7
74
R607
07
0
7
7
4
4
6
4
4
6
R
5
5
7
75
R607
07
0
7
7
5
5
6
5
5
6
R
C
C6003
C6003
C6004
C6004
C6005
C6005
C600
C600
C6006
04QQ6
Q
2
062
62
2
C606
C606
C
L6006
C6064
C
C
4
6
60
0
6
C
4
C
C6065
5
6
60
0
6
C
5
C
C
C6066
C
C6067
C
C6
6068
C
C
C6069
C
C6070
C
C6071
C6072
C
6
0
6
0
7
72
2
C6072
C
6
0
6
0
7
72
2
73
07
0
C60
C
C
C
0
0
C
6
6
6
C
C
7
3
4
4
074
07
0
C60
C6
6
07
4
74
0
0
C
C
5CC6
L60
L60
L
0
L600
6
C
C6046
C
6
0
4
6
C
47
C60
C6
C6048
6048
C60
00
6
0
6
Q600
Q60
0
Q600
Q610
Q60
33036
C6
C
065
6
0
R
R
48
8
R6048
R
R
R
R
R
R6051
R
R
R
R60
R6
R6050
R
R
6049
04
R6049
05
C60
053
C6052
C6052
C
C6050
C6050
5
51
C605
X
5
0
0
8
8
0
0
Q600
0
0
0
0
8
8
6
8
8
6
Q
R608
60
08
R
6
R
83
R607
60
07
R
6
R
77
R607
60
07
R
6
R
76
Q
6009
04
04
L6004
C6
5
Q6005
Q6005
Q60
C6054
C6054
R6086
R6088
R6087
R6087
35
5
R603
035
L6503
L
650
3
4
4
4
4
C
C650
4
4
C
C6
1
1
L
L
L6
L
6501
1
C650
C
C6516
C651
6
R6568
R6568
C65515C6
CC6
CC6
QQ6
7
7
R6608
R6
D6601
660
01
6
6
18
R661
Q6653
Q
R6658
R6658
D6651
D6651
6
0
6
C655355C65C63
B
B
00
00
B
P2002B
B
2
00
P20
P
P2002BPP2002B
2
48
8
28
43
43
6
8
9
0
0
Q6010
D6007
R
R
R6085
155Q6Q6
C6056
C
56
C
6
605
C6080
6
6
R
R
6574
6574
R657
R657
R657
75
DV-SP1000
A SIDE PATTERN
B SIDE PATTERN
Page 56
Q6501
Q6501
Q6501
Q650
8
C6058
C6059
C6
6
0
9
59
C
5
0
C6061
6
6076
C6
60
6076
C6
C6077
Q6006
Q
X6131
C6079
6
C
6079
L600
L6
0
0
05
L60
5
57
C605
C6011
11
5
6
09
0
0
012
12
C6012
3
C601
4
C601
55C
360366
C60C66
4
018
C
C6019
C6020
0
020
6020
0
0
022
0
02
022
22
2
2
6
R6
2
2
60
6
R6
R6
21
0
021
21
1
1
0
60
R60
60
60
R
21
0
0
02
R6
R
20
0
020
6
R6
602
20
020
02
R6
019
601986
0
1
C
2
2
C
R6023
3
23
02
R6024
R
4
24
02
R6024
R6
4
24
02
R6025
6025
60
5
25
02
R6025
6025
0
5
25
2
6026
6
026
0
6
26
2
R6026
R
6026
0
6
6
26
6026
R6
R6
R
C6023
3
6
C
C
3
3
C6023
C6023
C
C6023
3
6
C
R6027
R
2
7
7
R6
R6027
R
2
7
7
R6
4
4
C6
C
6024
C6
C
6025
C60
C60
C6028C6028
C60
0
C603
03
1303
C6
C6032
C6032
C6033
C6034
C
C
C6
0
34
4
3
0
6
C6035
C
C6
C60
035
5
35
603
6036
6
C
C
C
6
6
0
6
6
3
3
60
1
1
D600
D
D
6
0
01
0
0
6
2
2
D600
D
D
6
0
02
0
0
6
3
3
D600
D
D
6
0
03
0
0
6
039
039
R6
R
R6
9
7
037
037
C6
C
7
038
038
C603
C
C
C6
8
60
03
C
C6
C
39
9
C6039
CCC
C6
039
39
603
60
C
C6040
C
C
04
C
C
C6
0
40
040
60
0
6041
R
R
R6
41
R60
604
41
C
C
C6041
R604
R6042
043
C60424C
C
R6028
C6078
Q
Q
C61
Q6
Q6109
09
610
08
Q610
08
4
54
4
C6254
6
R
R6266
7
R
R6267
R6268R6R6268
69
9
9
62
6
2
62
26
6
R6
C6256
C6256
R6278
R6279
C6194C6194
C6192
C6392
C6394
639
4
C6
C639663C
C6398
63
C6191
C
C6121
Q6551
Q
51QQ6
CCC65050
6
6
05
5
0
5
R650
06
6
0
6
R650
07
7
0
7
R650
06
6
0
6
C650
09
9
0
9
R650
6508
5
R6
R
6
8
8
0
50
6
2
1
1
5
5
5
6
6
R6
65
R
6
R
1
1
5
2
5
5
5
1
1
5
5
5
5
6
R6
65
R
6
R
1
5
5
5
1
5
5
6
6
6
1
R65
65
R
6
R
1
5
6
7
7
7
7
1
1
5
5
5
5
6
6
6
6
R
R
R
R
R
R
5
5
R6
R6
6
6
R
R
1
1
5
5
7
7
R6518
6651
6
652
5
5
45
5
5
5
5
6
6
R6
65
R
6
R
4
5
5
5
4
5
6
6
46
5
5
5
6
6
R6
6
R
6
R
54
5
6
6
4
6
R6554
Q6524
652
Q
65
65
Q6552
65
65
R6555
C6552
656666
6604
60
R66
04
660
60
02
Q6
60
60
05
05
R6
C6602
C6652
R6654
5
5
R6655
6
66
6666
52
52
Q6
6
6
62
6666
2
6
R6531
6
R6
5
5
R
3
3
R
1
2
3
3
53
5
R65
3
3
5
5
32
65
6
R
R
2
R6533
6
R6
5
5
R
3
33
R
3
R6530
6
R6
5
5
R
3
30
R
0
4
3
3
53
5
R65
3
3
5
5
34
65
6
R
R
4
6507
5
C6
C
C
6
7
7
0
50
6
6508
5
C6
C
C
6
8
8
0
50
6
6509
5
C6
C
C
6
9
9
0
50
6
C6
C
C65
C6513
51
1
65
5
C65
65
C6
C6
C
C
C
C
65
5
C
C
C65
65
C6
C6
51
1
14
4
C65155C6515
L
C6002
L6001
0
60
L
L
6
001
C6001C
Q6003
003
Q60
Q
3
333
0
0
60
60
6
6
Q
Q
0
0
0
Q
3
6
Q
0
C
Q60
Q60
Q6002
Q
002
C6008
077CC
C6009
C6010
C6010
R6070
0
R6068
68
8
R6067
67
7
R6069
69
9
D6005
05
5
R6063
R6063
6
D6006
2
2
R6062
R
R6
RR6R
062
62
606
60
R
4
64
06
6
R6
R
R6
606
64
R
4
064
R6061
1
1
R
61
0
60
06
06
60
R6
60
06
60
R
6
0
6
59
9
059
R60
059
59
R
605
9
L
L6551
L6601
L6
L6651
651
L6651
C6502
50
2
02
QQQ
Q65
C6518
C6517
R6523
23
R652
3
R6523
23
R652
3
Q65
Q
Q
Q
R6
6
6
5226522
6
R6
R
6
6
5
6
6
6
C
C
C
C
6
6
C
5
C
C
526
522
2
22
2
C65C65
2
21
9
2
2
52
5
R65
2
2
5
5
29
65
6
R
R
9
7
2
2
52
5
R65
2
2
5
5
27
65
6
R
R
7
8
2
2
52
5
R65
2
2
5
5
28
65
6
R
R
8
65
65
R6561
Q6
5
54
Q655
54
R66
R66
6611
R
6
6
66
6
61
R6
R6
631
R
R63
6316
631
R63
316
16
31
R6
6416
6416
416
416
R
R
R6
416
16
16
R
416
6366
6366
366
66
6366
6366
R6366
R6
3
1
C
52
5
5
2
Q
Q
Q61
R6154
4
R6155
R6155
R
R6155
5
R61
D
D
D6151
51
D61
R6156
R
R6157
R6
0
4
0
4
4
4
0
6
6
D6
6
64
1
05
4
40
4
4
4
0
6
6
R
6
6
05
R6407
R6406
04
R640
Q6402QQ6402
C6401
C64
2
2
Q6352
2
3
C
3
D6351
R6355
R6
6355
R6354
R635
54
R
R63
357
R63
R
R6356
R6356
6
R
D6301
D630
01
D
07
R6307
R6305
R6
R6305
R6304
R6304
R6306
02
2
Q630
C630C51
C
Q6252
53
62
2
R6
R
6R66
62
6255
55
R
R
R
5
D625
D
D
6
1
62
5
5
57
R625
5
54
R625
5
56
R625
5
56
R625
6201
1
20
2
6
0
D
D
D
6205
05
20
62
5
R
R
R6
R6207
7
620
R6206
6
06
R62
20
R6
204
4
4
2
0
R
R6
R
Q
Q
Q6202
C
C
57
C65
C
L6202
L62
2
4
14
C611
4
4
C6
L
0
10
C6
C
C61
0
1
02
0
C
C6123
29
9
C612
22
2
C612
22
2
C6122C612
C
24
4
2
549
5
548
R6122
Q6106
Q610
Q
07
7
7
61
61
Q6Q6Q6
61
61
0
21
1
1
61
6
6
1
61
2
6
R6
4
Q6
0
4
4
61
61
Q6
0
5
05
0
Q61
145
8
0
6158
CC6196
C6198
3
2
2
3
R61
3
24
R612
R612
24
R61
4
1
1
R647
R6470
0
R6470
R6
R
6472
R647
1
2422
4
2522
5
8848
8
8
48
8
8
48
4
111
5555255552
53
111044040
1
0550
105
5
0
1
156
156
156
156
157
157
1
16
17
17
17
2232
33
4884
48
8
4949
4
6
64
1
1
1
1
1
1
1
1
1
1
7
8
8
88
1
1
111
1
8
8
1
1
1
Q6523
Q6523
Q6523
1
Q6
1
1
1
61
C6661
661
61
11
C6
65
65
C6561
C6532
53
C653153C6
61
100
00
1
1
1
1
1
2
57
6
6573
54
4
4
62
6
2
62
25
6
Q6
Q6253
Q625
Q
R6640
R6639
R6638
R6637
R6636
PRINTED CIRCUIT BOARD VIEW
U02
VIDEO OUTPUT TERMINAL BOARD NAVD-8258
B SIDE PATTERN AND B SIDE SILK SCREEN
A
1
2
3
4
5
BCDEFGH
Page 57
Q
Q
C61
Q6
Q6109
09
610
08
Q610
08
4
54
4
C6254
6
R
R6266
7
R
R6267
R6268R6R6268
69
9
9
62
6
2
62
26
6
R6
C6256
C6256
R6278
R6279
C6194
C6194
C6192
C6392
C6394
639
4
C6
C639663C
C6398
63
C6191
C
C6121
Q6524
652
Q
65
65
Q6552
65
65
R6555
C6552
656666
660
60
02
Q6
60
60
05
05
R6
C6602
C6652
5
5
R6655
6
6
6
66
66
52
52
Q6
6
6
62
6666
2
6
R6531
6
R6
5
5
R
3
3
R
1
2
3
3
53
5
R65
3
3
5
5
32
65
6
R
R
2
R6533
6
R6
5
5
R
3
33
R
3
R6530
6
R6
5
5
R
3
30
R
0
4
3
3
53
5
R65
3
3
5
5
34
65
6
R
R
4
L6551
L6601
L6
L6651
651
L6651
Q65
Q
Q
Q
6
6
5
6
6
6
C
C
C
C
6
6
C
5
C
C
526
522
2
22
2
C65C65
2
21
9
2
2
52
5
R65
2
2
5
5
29
65
6
R
R
9
7
2
2
52
5
R65
2
2
5
5
27
65
6
R
R
7
8
2
2
52
5
R65
2
2
5
5
28
65
6
R
R
8
65
65
R6561
Q6
5
54
Q655
54
R66
R66
6611
R
6
6
66
6
61
R6
R6
631
R
R63
6316
631
R63
316
16
31
R6
6416
6416
416
416
R
R
R6
416
16
16
R
416
6366
6366
366
66
6366
6366
R6366
R6
3
1
C
52
5
5
2
Q
Q
Q61
R6154
4
R6155
R6155
R
R6155
5
R61
D
D
D6151
51
D61
R6156
R
R6157
R6
0
4
0
4
4
4
0
6
6
D6
6
64
1
05
4
40
4
4
4
0
6
6
R
6
6
05
R6407
R6406
04
R640
Q6402QQ6402
C6401
C64
2
2
Q6352
2
3
C
3
D6351
R6355
R6
6355
R6354
R635
54
R
R63
357
R63
R
R6356
R6356
6
R
D6301
D630
01
D
07
R6307
R6305
R6
R6305
R6304
R6304
R6306
02
2
Q630
C630C51
C
Q6252
53
62
2
R6
R
6R66
62
6255
55
R
R
R
5
D625
D
D
6
1
62
5
5
57
R625
5
54
R625
5
56
R625
5
56
R625
6201
1
20
2
6
0
D
D
D
6205
05
20
62
5
R
R
R6
R6207
7
620
R6206
6
06
R62
20
R6
204
4
4
2
0
R
R6
R
Q
Q
Q6202
C
C
57
C65
C
L6202
L62
2
4
14
C611
4
4
C6
L
0
10
C6
C
C61
0
1
02
0
C
C6123
29
9
C612
22
2
C612
22
2
C6122C612
C
24
4
2
549
5
548
R6122
Q6106
Q610
Q
07
7
7
61
61
Q6Q6Q6
61
61
0
21
1
1
61
6
6
1
61
2
6
R6
4
Q6
0
4
4
61
61
Q6
0
5
05
0
Q61
145
8
0
6158
C
C6196
C6198
3
2
2
3
R61
3
24
R612
R612
24
R61
4
1
1
R647
R6470
0
R6470
R6
R
6472
R647
1
1
1
1
1
1
1
1
1
1
7
8
888
1
1
111
1
8
8
1
1
1
Q6523
Q6523
Q6523
1
1
1
61
C6661
661
61
11
C6
65
65
C6561
54
4
4
62
6
2
62
25
6
Q6
Q6253
Q625
Q
DV-SP1000
A SIDE PATTERN
B SIDE PATTERN
Page 58
MGD-33 DVD MECHANISM PARTS LIST
ONKYO
Item Part No. Description
1-a 24802052 CHASSIS
1-b 24828039 SHAFT(A)
1-c 24828040 SHAFT(B)
1 A10-3322 CHASSIS AS
2 24810094 GEAR(CARRIER)
3 24810095 GEAR IDLER
4 24810096 GEAR(MAIN)
5 24802055 A SUB CHASSIS(FRAME T)
6 24802057 TRAY
7 24810092 GEAR(CENTER)
8 24840164-1 SLIDER
9 24826030 RETAINER(L)
10 24810093 GEAR(PULLEY)
11 24826031 A RETAINER(R)
12 24810091 MOTOR PULLEY
13 24802054-1 SUB CHASSIS(CLAMP)
14 24840163 SLIDER
15 24824006-1 CAP(CHC)
16 24828041 ROD (GUIDE) H
17 24828043 SHAFT (TRAY R) H
18 24828042 SHAFT(TRAY L) H
20 801593 BIND TAP TITE(P)SC M2.6*8
21 24834044 FLAT WSHR 2.6*4.7*0.5 CUT
22 801596 SCREW 2.6*6 SWCH 16A
23 801610 FLAT TAP TITE SCREW 2.6*6
24 24816040 BELT
26 24836043 NON WOVEN FABRIC
27 24830004-1 YOKE(CHB)
28 24832006-1 MAGNET(CHB)
29 24840169 MIRROR TAPE
30 24834049 WASHER
31 28141581 SHEET
32 24840166 WIRING HARNESS
33 24834050 A SPACER
34 24804048 DC MOTOR MSN5G543C
35 24840167 DETECT SWITCH SSS23
Page 59
DV-SP1000
Q'TY
Material pcs
ABS T250(B)
SUS420J2 D3.15
SUS420J2 D3.15
POM M90-44(N) 1
POM LA-531(N) 2
POM M90-44(B) 1
ABS T250(B) 1
ABS 450 (B) 1
POM M90-44(N) 1
POM TR-20(B) 1
POM TR-20(B) 1
TPE 6333N 1
POM TR-20(B) 1
POM M90-44(B) 1
A5052P t1.5 1
POM TR-5(B) 1
POM M90-44(B) 1
SUS420J2 D3.15 1
SUS420J2 D4.15 1
SUS420J2 D4.15 1
ETO 8
ETO 2
ETO 3
ETO 2
YAMAUCHI 1
NISSHO 1
CHEONGWAH 1
JINBAO 1
--- 3
ETO 1
NISSHO 1
SAKURA 1
--- 1
PSI 1
SHINMEI 1
(1)
(1)
(1)
1
Page 60
PWB
DG8257 P002 PWB NCDG-8257
VD8258 P002 PWB NCVD-8258 1
VD8258-1P P002 PWB NCVD-8258 1
VD8258 P011 PWB NCDG-8259 { 1}
VD8258 P012 PWB NCETC-8260 { 0}
VD8258-1J P012 PWB NCETC-8260 { 1}
VD8258-1P P012 PWB NCETC-8260 { 1}
VD8258-1H P012 PWB NCETC-8260 { 1}
VD8258 P013 PWB NCETC-8261 { 0}
VD8258-1G P013 PWB NCETC-8261 { 1}
VD8258 P014 PWB NCPS-8274 { 1}
DIS8264 P001 PWB NCDIS-8264 { 1}
DIS8264 P002 PWB NCVD-8265 { 0}
DIS8264-1D P002 PWB NCVD-8265 1
DIS8264-1E P002 PWB NCVD-8265 { 1}
DIS8264-1F P002 PWB NCVD-8265 { 1}
DIS8264 P003 PWB NCAF-8266 { 1}
DIS8264 P004 PWB NCSW-8267 { 1}
DIS8264 P005 PWB NCDG-8268 { 0}
DIS8264-1F P005 PWB NCDG-8268 { 0}
PS8269 P004 PWB NCPS-8269 1
PS8269 P005 PWB NCPS-8270 { 1}
PS8269-1G P006 PWB NCSW-8271 { 0}
PS8269-1B P006 PWB NCSW-8271 { 1}
PS8269-1C P006 PWB NCSW-8271 { 1}
PS8269-1I P006 PWB NCSW-8271 { 1}
DG8272-1B P0010 PWB NCVD-8273 { 0}
DG8272-1C P0010 PWB NCVD-8273 { 0}
DG8272 P005 PWB NCDG-8272 1
AR8263 P001 PWB NCAR-8263 1
AR8263 P002 PWB NCDG-8262 { 0}
AR8263-1G P002 PWB NCDG-8468 { 1}
DG8262 P002 PWB NCDG-8262 1
1
Page 61
PRINTED CIRCUIT BOARD PARTS LIST
a
o
n
g
n
1/140 PAGE
PWB NO.
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
NOTE:
The components identifies by mark ! are
critical for risk of fire and electric shock.
Replace only with part number specified.
NOTE: ! : Safety parts
<DC1N>: North Americ
<PP2P>: European regi
<GK3P>: Korean regio
<WT3P>: East Asian re
<GR6P>: Chinese regio
U01 : DVD MAIN BOARD NADG-8257
CIRCUIT NO. PART NAME DESCRIPTION PART NO.
C1001 C-CERA C CK725B1C-104K1 1 332121045R1
C1002 C-CERA C CK725B1C-104K1 1 332121045R1
C1003 C-CERA C CC725CH1H-220J1 1 342102204R1
C1004 C-CERA C CC725CH1H-220J1 1 342102204R1
C1005 C-CERA C CC725CH1H-220J1 1 342102204R1
C1006 C-CERA C CC725CH1H-220J1 1 342102204R1
C1007 C-CERA C CK725B1H-222K1 1 332102225R1
C1008 C-CERA C CK725B1H-222K1 1 332102225R1
C1009 C-CERA C CK725B1H-222K1 1 332102225R1
C1010 C-CERA C CK725B1H-222K1 1 332102225R1
C1011 C-CERA C CC725CH1H-331J1 1 342103314R1
C1012 C-CERA C CK725F1E-104Z1 1 332161040R1
C1013 CHIP ELECT C CEWX16V-22M 1 356742209R2
C1014 C-CERA C CK725F1E-104Z1 1 332161040R1
C1015 C-CERA C CK725B1E-333K1 1 332113335R1
C1016 C-CERA C CK725B1E-333K1 1 332113335R1
C1017 C-CERA C CC725CH1H-151J1 1 342101514R1
C1018 C-CERA C CK725B1A-474K1 1 332134745R1
C1019 C-CERA C CK725B1A-474K1 1 332134745R1
C1020 C-CERA C CK725B1C-104K1 1 332121045R1
C1021 C-CERA C CK725F1E-104Z1 1 332161040R1
C1022 CHIP ELECT C CEWX16V-22M 1 356742209R2
C1023 C-CERA C CK725F1E-104Z1 1 332161040R1
C1024 C-CERA C CK725B1H-473K1 1 332104735R1
C1025 C-CERA C CK725F1E-104Z1 1 332161040R1
C1026 CHIP ELECT C CEWX16V-22M 1 356742209R2
C1027 C-CERA C CC725CH1E-102J1 1 342111024R1
C1028 C-CERA C CK725B1C-104K1 1 332121045R1
C1029 C-CERA C CK725B1C-104K1 1 332121045R1
C1030 C-CERA C CK725B1C-104K1 1 332121045R1
C1031 C-CERA C CK725F1E-104Z1 1 332161040R1
C1032 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C1033 C-CERA C CK725B1C-104K1 1 332121045R1
C1034 C-CERA C CK725B1C-104K1 1 332121045R1
C1035 C-CERA C CK725B1H-103K1 1 332101035R1
C1036 C-CERA C CC725CH1H-100D1 1 342101002R1
C1037 C-CERA C CC725CH1H-100D1 1 342101002R1
C1038 C-CERA C CK725F1E-104Z1 1 332161040R1
C1039 CHIP ELECT C CEWX6.3V-47M 1 356724709R2
C1040 C-CERA C CC725CH1E-102J1 1 342111024R1
C1041 CHIP ELECT C CEWX16V-10M 1 356741009R2
C1042 CHIP ELECT C CEWX16V-10M 1 356741009R2
Page 62
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
C1043 CHIP ELECT C CEWX6.3V-47M 1 356724709R2
C1044 C-CERA C CC725CH1E-102J1 1 342111024R1
C1045 CHIP ELECT C CEWX16V-10M 1 356741009R2
C1046 CHIP ELECT C CEWX16V-10M 1 356741009R2
C1047 CHIP ELECT C CEWX16V-22M 1 356742209R2
C1048 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C1049 C-CERA C CK725F1E-104Z1 1 332161040R1
C1050 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C1051 C-CERA C CK725F1E-104Z1 1 332161040R1
C1052 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C1053 CHIP ELECT C CEWX50V-1M 1 356780109R2
C1054 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C1101 C-CERA C CC725CH1H-221J1 1 342102214R1
C1102 C-CERA C CC725CH1H-101J1 1 342101014R1
C1103 C-CERA C CC725CH1E-102J1 1 342111024R1
C1104 C-CERA C CK725F1E-104Z1 1 332161040R1
C1105 C-CERA C CK725F1E-104Z1 1 332161040R1
C1106 CHIP ELECT C CEWX16V-22M 1 356742209R2
C1107 C-CERA C CK725F1E-104Z1 1 332161040R1
C1108 C-CERA C CK725F1E-104Z1 1 332161040R1
C1109 CHIP ELECT C CEWX16V-22M 1 356742209R2
C1110 C-CERA C CK725F1E-104Z1 1 332161040R1
C1111 CHIP ELECT C CEWX16V-10M 1 356741009R2
C1112 CHIP ELECT C CEWX16V-10M 1 356741009R2
C1113 C-CERA C CK725B1H-223K1 1 332102235R1
C1114 C-CERA C CK725B1H-223K1 1 332102235R1
C1115 C-CERA C CK725B1E-473K1 1 332114735R1
C1116 C-CERA C CK725B1E-473K1 1 332114735R1
C1117 C-CERA C CK725F1E-104Z1 1 332161040R1
C1201 C-CERA C CK725F1A-105Z1 1 332181050R1
C1202 C-CERA C CK725F1A-105Z1 1 332181050R1
C1203 C-CERA C CK725F1A-105Z1 1 332181050R1
C1206 C-CERA C CK725F1A-105Z1 1 332181050R1
C1207 C-CERA C CK725F1A-105Z1 1 332181050R1
C1208 C-CERA C CK725F1A-105Z1 1 332181050R1
C1209 C-CERA C CK725B1E-223K1 1 332112235R1
C1210 C-CERA C CC725CH1H-151J1 1 342101514R1
C1211 C-CERA C CK725B1E-223K1 1 332112235R1
C1212 C-CERA C CK725B1C-104K1 1 332121045R1
C1213 C-CERA C CC725CH1H-101J1 1 342101014R1
C1214 C-CERA C CK725B1E-223K1 1 332112235R1
C1215 C-CERA C CC725CH1H-101J1 1 342101014R1
C1216 C-CERA C CK725B1A-154K1 1 332131545R1
C1217 C-CERA C CK725F1A-105Z1 1 332181050R1
C1218 C-CERA C CK725F1A-105Z1 1 332181050R1
C1219 C-CERA C CC725CH1H-331J1 1 342103314R1
C1220 C-CERA C CC725CH1H-331J1 1 342103314R1
C1221 C-CERA C CK725F1A-105Z1 1 332181050R1
C1222 C-CERA C CK725F1E-104Z1 1 332161040R1
C1223 C-CERA C CK725F1A-105Z1 1 332181050R1
C1224 C-CERA C CK725B1H-473K1 1 332104735R1
C1225 C-CERA C CK725F1A-105Z1 1 332181050R1
C1226 C-CERA C CK725B1H-103K1 1 332101035R1
C1227 C-CERA C CK725F1A-105Z1 1 332181050R1
C1228 C-CERA C CK725F1A-105Z1 1 332181050R1
C1229 C-CERA C CK725F1A-105Z1 1 332181050R1
2/140 PAGE
Page 63
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
C1230 C-CERA C CK725F1A-105Z1 1 332181050R1
C1232 C-CERA C CK725F1A-105Z1 1 332181050R1
C1233 C-CERA C CK725F1A-105Z1 1 332181050R1
C1234 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C1235 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C1236 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C1237 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C1238 CHIP ELECT C CEWX16V-10M 1 356741009R2
C1239 C-CERA C CK725F1A-105Z1 1 332181050R1
C1240 C-CERA C CC725CH1H-560J1 1 342105604R1
C1241 C-CERA C CK725F1A-105Z1 1 332181050R1
C1242 C-CERA C CK725F1A-105Z1 1 332181050R1
C1243 C-CERA C CK725F1A-105Z1 1 332181050R1
C1251 C-CERA C CC725CH1H-471J1 1 342104714R1
C1252 C-CERA C CK725F1E-104Z1 1 332161040R1
C1253 C-CERA C CC725CH1H-471J1 1 342104714R1
C1254 C-CERA C CK725F1E-104Z1 1 332161040R1
C1255 C-CERA C CC725CH1H-471J1 1 342104714R1
C1256 C-CERA C CK725F1E-104Z1 1 332161040R1
C1257 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C1258 C-CERA C CK725F1A-105Z1 1 332181050R1
C1301 C-CERA C CK725F1A-105Z1 1 332181050R1
C1302 C-CERA C CC725CH1E-102J1 1 342111024R1
C1304 C-CERA C CK725F1A-105Z1 1 332181050R1
C1305 C-CERA C CK725F1A-105Z1 1 332181050R1
C1306 C-CERA C CK725F1A-105Z1 1 332181050R1
C1307 C-CERA C CK725F1A-105Z1 1 332181050R1
C1308 C-CERA C CK725F1A-105Z1 1 332181050R1
C1309 C-CERA C CK725F1A-105Z1 1 332181050R1
C1310 C-CERA C CK725F1A-105Z1 1 332181050R1
C1311 C-CERA C CK725F1A-105Z1 1 332181050R1
C1312 C-CERA C CK725F1A-105Z1 1 332181050R1
C1313 C-CERA C CK725F1A-105Z1 1 332181050R1
C1314 C-CERA C CK725F1A-105Z1 1 332181050R1
C1315 C-CERA C CK725F1A-105Z1 1 332181050R1
C1316 C-CERA C CK725F1A-105Z1 1 332181050R1
C1317 C-CERA C CK725F1A-105Z1 1 332181050R1
C1318 C-CERA C CK725F1A-105Z1 1 332181050R1
C1319 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C1320 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C1321 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C1322 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C1323 C-CERA C CK725F1A-105Z1 1 332181050R1
C1324 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C1325 C-CERA C CK725F1A-105Z1 1 332181050R1
C1326 C-CERA C CK725F1A-105Z1 1 332181050R1
C1327 C-CERA C CK725F1A-105Z1 1 332181050R1
C1328 C-CERA C CK725F1A-105Z1 1 332181050R1
C1329 C-CERA C CK725F1A-105Z1 1 332181050R1
C1330 C-CERA C CK725F1A-105Z1 1 332181050R1
C1331 C-CERA C CK725F1A-105Z1 1 332181050R1
C1332 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C1333 CHIP ELECT C CEWX16V-22M 1 356742209R2
C1334 CHIP ELECT C CEWX16V-22M 1 356742209R2
C1335 C-CERA C CK725F1A-105Z1 1 332181050R1
C1336 C-CERA C CK725F1A-105Z1 1 332181050R1
3/140 PAGE
Page 64
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
C1337 C-CERA C CK725B1H-103K1 1 332101035R1
C1338 C-CERA C CC725CH1H-020C1 1 342100201R1
C1339 C-CERA C CC725CH1H-020C1 1 342100201R1
C1340 C-CERA C CK725F1A-105Z1 1 332181050R1
C1341 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C1342 C-CERA C CK725F1A-105Z1 1 332181050R1
C1343 C-CERA C CC725CH1H-100D1 1 342101002R1
C1344 C-CERA C CC725CH1H-100D1 1 342101002R1
C1345 C-CERA C CK725F1A-105Z1 1 332181050R1
C1347 C-CERA C CK725F1A-105Z1 1 332181050R1
C1348 C-CERA C CK725F1A-105Z1 1 332181050R1
C1349 C-CERA C CK725F1A-105Z1 1 332181050R1
C1350 C-CERA C CK725F1A-105Z1 1 332181050R1
C1351 C-CERA C CK725F1A-105Z1 1 332181050R1
C1352 C-CERA C CK725F1A-105Z1 1 332181050R1
C1358 C-CERA C CK725F1A-105Z1 1 332181050R1
C1359 C-CERA C CK725F1A-105Z1 1 332181050R1
C1360 C-CERA C CK725F1A-105Z1 1 332181050R1
C1371 CHIP ELECT C CEWX16V-22M 1 356742209R2
C1372 C-CERA C CK725F1A-105Z1 1 332181050R1
C1373 C-CERA C CK725F1A-105Z1 1 332181050R1
C1374 C-CERA C CK725F1A-105Z1 1 332181050R1
C1375 C-CERA C CK725F1A-105Z1 1 332181050R1
C1376 C-CERA C CK725F1A-105Z1 1 332181050R1
C1377 C-CERA C CK725F1A-105Z1 1 332181050R1
C1378 C-CERA C CK725F1A-105Z1 1 332181050R1
C1379 C-CERA C CC725CH1E-102J1 1 342111024R1
C1380 C-CERA C CK725F1A-105Z1 1 332181050R1
C1381 C-CERA C CK725F1A-105Z1 1 332181050R1
C2001 C-CERA C CK725F1A-105Z1 1 332181050R1
C2002 C-CERA C CK725F1A-105Z1 1 332181050R1
C2003 C-CERA C CK725F1A-105Z1 1 332181050R1
C2004 C-CERA C CK725F1A-105Z1 1 332181050R1
C2005 C-CERA C CK725F1A-105Z1 1 332181050R1
C2006 C-CERA C CK725F1A-105Z1 1 332181050R1
C2007 C-CERA C CK725F1A-105Z1 1 332181050R1
C2008 C-CERA C CK725F1A-105Z1 1 332181050R1
C2009 C-CERA C CK725F1A-105Z1 1 332181050R1
C2010 C-CERA C CK725F1A-105Z1 1 332181050R1
C2011 C-CERA C CK725F1A-105Z1 1 332181050R1
C2012 C-CERA C CK725F1A-105Z1 1 332181050R1
C2013 C-CERA C CK725F1A-105Z1 1 332181050R1
C2014 C-CERA C CK725F1A-105Z1 1 332181050R1
C2015 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C2016 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C2017 C-CERA C CK725F1A-105Z1 1 332181050R1
C2018 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C2019 C-CERA C CK725F1A-105Z1 1 332181050R1
C2020 C-CERA C CK725F1A-105Z1 1 332181050R1
C2021 C-CERA C CK725F1A-105Z1 1 332181050R1
C2022 C-CERA C CK725F1A-105Z1 1 332181050R1
C2023 C-CERA C CK725F1A-105Z1 1 332181050R1
C2024 C-CERA C CK725F1A-105Z1 1 332181050R1
C2025 C-CERA C CK725F1A-105Z1 1 332181050R1
C2026 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C2027 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
4/140 PAGE
Page 65
DG8257-1A
DG8257
DG8257
DG8257-1A
DG8257-1A
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
C2028 CHIP ELECT C CEWX16V-47M 1 356744709R2
C2030 C-CERA C CK725F1A-105Z1 1 332181050R1
C2031 C-CERA C CK725F1A-105Z1 1 332181050R1
C2032 C-CERA C CK725F1A-105Z1 1 332181050R1
C2033 C-CERA C CK725F1A-105Z1 1 332181050R1
C2034 C-CERA C CK725F1A-105Z1 1 332181050R1
C2035 C-CERA C CK725F1A-105Z1 1 332181050R1
C2038 C-CERA C CK725F1A-105Z1 1 332181050R1
C2039 C-CERA C CK725F1A-105Z1 1 332181050R1
C2040 C-CERA C CK725F1A-105Z1 1 332181050R1
C2041 C-CERA C CK725F1A-105Z1 1 332181050R1
C2043 C-CERA C CK725F1A-105Z1 1 332181050R1
C2044 C-CERA C CK725F1A-105Z1 1 332181050R1
C2045 C-CERA C CC725CH1E-102J1 1 342111024R1
C2046 C-CERA C CK725F1A-105Z1 1 332181050R1
C2047 C-CERA C CK725F1A-105Z1 1 332181050R1
C2048 C-CERA C CK725F1A-105Z1 1 332181050R1
C2049 C-CERA C CK725F1A-105Z1 1 332181050R1
C2051 C-CERA C CK725F1A-105Z1 1 332181050R1
C2052 C-CERA C CK725F1A-105Z1 1 332181050R1
C2101 C-CERA C CK725F1A-105Z1 1 332181050R1
C2102 C-CERA C CK725F1A-105Z1 1 332181050R1
C2103 C-CERA C CC725CH1E-102J1 1 342111024R1
C2104 C-CERA C CK725F1A-105Z1 1 332181050R1
C2105 C-CERA C CK725F1A-105Z1 1 332181050R1
C2106 C-CERA C CK725F1A-105Z1 1 332181050R1
C2107 C-CERA C CK725F1A-105Z1 1 332181050R1
C2108 C-CERA C CK725F1A-105Z1 1 332181050R1
C2109 C-CERA C CK725F1A-105Z1 1 332181050R1
C2110 C-CERA C CK725F1A-105Z1 1 332181050R1
C2111 C-CERA C CK725F1A-105Z1 1 332181050R1
C2112 C-CERA C CK725F1A-105Z1 1 332181050R1
C2113 C-CERA C CK725F1A-105Z1 1 332181050R1
C2114 C-CERA C CK725F1A-105Z1 1 332181050R1
C2115 C-CERA C CK725F1A-105Z1 1 332181050R1
C2116 C-CERA C CK725F1A-105Z1 1 332181050R1
C2117 C-CERA C CK725F1A-105Z1 1 332181050R1
C2118 C-CERA C CK725F1A-105Z1 1 332181050R1
C2119 C-CERA C CK725F1A-105Z1 1 332181050R1
C2120 C-CERA C CC725CH1E-102J1 1 342111024R1
C2121 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C2122 C-CERA C CK725F1A-105Z1 1 332181050R1
C2123 C-CERA C CK725F1A-105Z1 1 332181050R1
C2124 C-CERA C CK725F1A-105Z1 1 332181050R1
C2125 C-CERA C CK725F1A-105Z1 1 332181050R1
C2126 C-CERA C CK725F1A-105Z1 1 332181050R1
C2127 C-CERA C CK725F1A-105Z1 1 332181050R1
C2128 C-CERA C CK725F1A-105Z1 1 332181050R1
C2129 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C2130 C-CERA C CK725B1H-103K1 1 332101035R1
C2131 C-CERA C CK725B1A-474K1 1 332134745R1
C2191 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C2192 C-CERA C CK725F1A-105Z1 1 332181050R1
C2193 C-CERA C CK725F1A-105Z1 1 332181050R1
C2601 CHIP ELECT C CEWX16V-22M 1 356742209R2
C2602 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
5/140 PAGE
Page 66
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257-1A
DG8257
DG8257
C2603 C-CERA C CK725F1A-105Z1 1 332181050R1
C2604 C-CERA C CK725F1A-105Z1 1 332181050R1
6/140 PAGE
C2605 C-CERA C CK725F1A-105Z1 1 332181050R1
C2606 C-CERA C CC725CH1H-120J1 1 342101204R1
C2608 C-CERA C CC725CH1H-120J1 1 342101204R1
C2610 C-CERA C CK725F1A-105Z1 1 332181050R1
C2611 C-CERA C CK725F1A-105Z1 1 332181050R1
C2612 C-CERA C CC725CH1H-560J1 1 342105604R1
C2901 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C2902 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C2903 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C2904 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C2905 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C2906 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C2907 CHIP ELECT C CEWX16V-10M 1 356741009R2
C2908 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C2909 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C2910 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
D1301 LED SEC1801C 1 225386R2
D2101 C-DIODE 1SS352 1 223234R2
D2901 LED SEC1801C 1 225386R2
L1001 CHOKE COIL NCH-1479 1 231237K470R2
L1002 CHOKE COIL NCH-1479 1 231237K470R2
L1003 CHOKE COIL NCH-1471 1 231237M022R2
L1004 CHOKE COIL NCH-1471 1 231237M022R2
L1005 CHOKE COIL NCH-1471 1 231237M022R2
L1201 CHOKE COIL NCH-1471 1 231237M022R2
L1202 CHOKE COIL NCH-1471 1 231237M022R2
L1203 CHOKE COIL NCH-1471 1 231237M022R2
L1204 CHOKE COIL NCH-1471 1 231237M022R2
L1251 CHOKE COIL NCH-1471 1 231237M022R2
L1301 CHOKE COIL NCH-1471 1 231237M022R2
L1302 CHOKE COIL NCH-1471 1 231237M022R2
L1303 CHOKE COIL NCH-1471 1 231237M022R2
L1304 CHOKE COIL NCH-1471 1 231237M022R2
L1305 CHOKE COIL NCH-1471 1 231237M022R2
L1306 CHOKE COIL NCH-1471 1 231237M022R2
L1307 CHOKE COIL NCH-1471 1 231237M022R2
L1371 CHOKE COIL NCH-1471 1 231237M022R2
L2001 CHOKE COIL NCH-1471 1 231237M022R2
L2002 CHOKE COIL NCH-1471 1 231237M022R2
L2003 CHOKE COIL NCH-1471 1 231237M022R2
L2004 CHOKE COIL NCH-1471 1 231237M022R2
L2005 CHOKE COIL NCH-1471 1 231237M022R2
L2101 CHOKE COIL NCH-1471 1 231237M022R2
L2102 CHOKE COIL NCH-1471 1 231237M022R2
L2601 CHOKE COIL NCH-1473 1 231237M047R2
L2602 CHOKE COIL NCH-1473 1 231237M047R2
L2901 CHOKE COIL NCH-1471 1 231237M022R2
L2902 CHOKE COIL NCH-1471 1 231237M022R2
L2903 CHOKE COIL NCH-1471 1 231237M022R2
P1001 SOCKET NSCT-26P2671 1 25052775R2
P1101 PLUG NPLG-6P932 1 25055979R2
P1301A PLUG SM16B-SURS-TF 1 25056399R2 N
P1302A PLUG SM20B-SURS-TF 1 25056401R2 N
P2001A PLUG SM14B-SURS-TF 1 25056397R2 N
Page 67
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
P2002A PLUG SM15B-SURS-TF 1 25056398R2 N
P2003A PLUG SM20B-SURS-TF 1 25056401R2 N
7/140 PAGE
P2004A PLUG SM16B-SURS-TF 1 25056399R2 N
P2101 SOCKET NSCT-14P2665 1 25052769R2
P2701A PLUG NPLG-7P933 1 25055980R2
P2901A PLUG NPLG-6P932 1 25055979R2
Q1001 IC CXD1881BR 1 22241902R3
Q1002 IC NJM2115V 1 22241676R2
Q1003 TR 2SK3019 1 2216520R2
Q1004 TR 2SK3019 1 2216520R2
Q1005 TR 2SK3019 1 2216520R2
Q1006 TR 2SB1132 1 2216400R2
Q1007 TR 2SB1132 1 2216400R2
Q1101 IC FAN8042 1 22241905R3
Q1102 IC BA4510FV 1 22241907R2
Q1201 IC CXD1885Q 1 22241903R3
Q1202 IC 74LVC1G08GW 1 22242071R2PH N
Q1202 or IC TC7SZ08FU ( 1) 22242071R2TO N
Q1251 IC IC41LV16100-50T 1 22241909R2
Q1251 or IC IC41LV16100-50T ( 1) 22241909R3
Q1301 IC CXD2753R 1 22241829R3
Q1302 IC AD8062 1 22242066R2 N
Q1303 IC IC42S16100-7T 1 22242046R3 N
Q1303 or IC IC42S16100-7T ( 1) 22242046R2 N
Q1304 IC TC7SZU04F 1 22242073R2TO N
Q1305 IC 74LVC2G241DP 1 22242076R2PH N
Q1305 or IC TC7WH241FU ( 1) 22242076R2TO N
Q1306 TR 2SK3019 1 2216520R2
Q1307 IC TC7SZ08FU 1 22242071R2TO N
Q1308 IC TC7SZ08FU 1 22242071R2TO N
Q1309 IC TC7SZ08FU 1 22242071R2TO N
Q1310 IC TC7SZ125FU 1 22241895R2
Q1371 IC EPM3128A-Harmony-8LI 1 22242067R3 N
Q2001 IC M65776CFP 1 22242044R3 N
Q2002 IC IC42S16400-7T 1 22241910R2
Q2002 or IC IC42S16400-7T ( 1) 22241910R3
Q2007 IC 74LVC2G241DP 1 22242076R2PH N
Q2007 or IC TC7WH241FU ( 1) 22242076R2TO N
Q2008 IC TC7SZ125FU 1 22241895R2
Q2101 IC M32102S6FP 1 22242045R3 N
Q2102 IC TC74VHCT374AFT 1 22274374GR2TO
Q2103 IC 74LVC1G32GW 1 22242077R2PH N
Q2103 or IC TC7SZ32FU ( 1) 22242077R2TO N
Q2104 IC BR24L08FV-W 1 22242070R2 N
Q2105 IC 74LVC1G04GW 1 22242074R2PH N
Q2105 or IC TC7SZ04FU ( 1) 22242074R2TO N
Q2106 IC MX29LV320ABTC-90 1 22241862R3
Q2107 IC S-80127CNMC-JKM-T2 1 22241642R2
Q2108 IC TC7SZ125FU 1 22241895R2
Q2109 IC 74AHCT125PW 1 22241894R2PH N
Q2191 IC NJM2880U25 1 22242085R2 N
Q2601 IC BU2288FV 1 22241911R2
Q2901 IC BA33B00FP 1 22242086R2 N
Q2902 IC LM1117MPX-ADJ 1 22241648R2
Q2903 IC(REGURATOR) MPC2918T 1 22278018ER2NE
R1001 C-R NET RM7LJ152X04 1 43484715204R2 N
Page 68
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
R1002 C-R NET RM7LJ000X04 1 43484700004R2 N
R1003 C-CARBON R RN72K1J-123FE 1 435031232R1
8/140 PAGE
R1004 C-CARBON R RN72K1J-103JE 1 435031034R1
R1005 C-CARBON R RN72K1J-223JE 1 435032234R1
R1006 C-CARBON R RN72K1J-223JE 1 435032234R1
R1007 C-CARBON R RN72K1J-223JE 1 435032234R1
R1009 C-CARBON R RN72K1J-103JE 1 435031034R1
R1010 C-CARBON R RN72K1J-223JE 1 435032234R1
R1011 C-CARBON R RN72K1J-223JE 1 435032234R1
R1012 C-CARBON R RN72K1J-223JE 1 435032234R1
R1014 C-CARBON R RN72K1J-103JE 1 435031034R1
R1015 C-CARBON R RN72K1J-102JE 1 435031024R1
R1016 C-CARBON R RN72K1J-330JE 1 435033304R1
R1017 C-CARBON R RN72K1J-330JE 1 435033304R1
R1018 C-CARBON R RN72K1J-102JE 1 435031024R1
R1019 C-CARBON R RN72K1J-330JE 1 435033304R1
R1020 C-CARBON R RN72K1J-330JE 1 435033304R1
R1021 C-CARBON R RN72K1J-000JE 1 435030004R1
R1022 C-CARBON R RN72K1J-101JE 1 435031014R1
R1023 C-CARBON R RN72K1J-000JE 1 435030004R1
R1027 C-CARBON R RN72K1J-102JE 1 435031024R1
R1028 C-CARBON R RN72K1J-392JE 1 435033924R1
R1029 C-CARBON R RN72K1J-104JE 1 435031044R1
R1101 C-CARBON R RN72K1J-563FE 1 435035632R1
R1102 C-CARBON R RN72K1J-153JE 1 435031534R1
R1103 C-CARBON R RN72K1J-563JE 1 435035634R1
R1104 C-CARBON R RN72K1J-333JE 1 435033334R1
R1105 C-CARBON R RN72K1J-563JE 1 435035634R1
R1106 C-CARBON R RN72K1J-333JE 1 435033334R1
R1107 C-CARBON R RN72K1J-000JE 1 435030004R1
R1108 C-CARBON R RN72K1J-103JE 1 435031034R1
R1109 C-CARBON R RN72K1J-103JE 1 435031034R1
R1110 C-CARBON R RN72K1J-103JE 1 435031034R1
R1111 C-CARBON R RN72K1J-103JE 1 435031034R1
R1112 C-CARBON R RN72K1J-000JE 1 435030004R1
R1113 C-CARBON R RN72K1J-333JE 1 435033334R1
R1114 C-CARBON R RN72K1J-752JE 1 435037524R1
R1115 C-CARBON R RN72K1J-333JE 1 435033334R1
R1116 C-CARBON R RN72K1J-752JE 1 435037524R1
R1117 C-CARBON R RN72K1J-103FE 1 435031032R1
R1118 C-CARBON R RN72K1J-103FE 1 435031032R1
R1119 C-CARBON R RN72K1J-223JE 1 435032234R1
R1120 C-CARBON R RN72K1J-103JE 1 435031034R1
R1121 C-CARBON R RN72K1J-103JE 1 435031034R1
R1122 C-CARBON R RN72K1J-104JE 1 435031044R1
R1123 C-CARBON R RN72K1J-223JE 1 435032234R1
R1124 C-CARBON R RN72K1J-103JE 1 435031034R1
R1125 C-CARBON R RN72K1J-103JE 1 435031034R1
R1126 C-CARBON R RN72K1J-104JE 1 435031044R1
R1127 C-CARBON R RN72K1J-000JE 1 435030004R1
R1128 C-CARBON R RN72K1J-000JE 1 435030004R1
R1202 C-CARBON R RN72K1J-000JE 1 435030004R1
R1205 C-R NET RM7LJ101X04 1 43484710104R2 N
R1206 C-R NET RM7LJ101X04 1 43484710104R2 N
R1207 C-CARBON R RN72K1J-181JE 1 435031814R1
R1208 C-R NET RM7LJ101X04 1 43484710104R2 N
Page 69
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
R1209 C-R NET RM7LJ330X04 1 43484733004R2 N
R1210 C-R NET RM7LJ101X04 1 43484710104R2 N
9/140 PAGE
R1211 C-R NET RM7LJ101X04 1 43484710104R2 N
R1212 C-R NET RM7LJ181X04 1 43484718104R2 N
R1213 C-R NET RM7LJ103X04 1 43484710304R2 N
R1214 C-CARBON R RN72K1J-473FE 1 435034732R1
R1215 C-CARBON R RN72K1J-473FE 1 435034732R1
R1216 C-CARBON R RN72K1J-154FE 1 435031542R1
R1217 C-CARBON R RN72K1J-471FE 1 435034712R1
R1218 C-CARBON R RN72K1J-683FE 1 435036832R1
R1219 C-CARBON R RN72K1J-473FE 1 435034732R1
R1220 C-CARBON R RN72K1J-104FE 1 435031042R1
R1221 C-CARBON R RN72K1J-182FE 1 435031822R1
R1222 C-CARBON R RN72K1J-182FE 1 435031822R1
R1223 C-CARBON R RN72K1J-223FE 1 435032232R1
R1224 C-CARBON R RN72K1J-000JE 1 435030004R1
R1225 C-CARBON R RN72K1J-103JE 1 435031034R1
R1226 C-CARBON R RN72K1J-000JE 1 435030004R1
R1227 C-CARBON R RN72K1J-103JE 1 435031034R1
R1228 C-CARBON R RN72K1J-000JE 1 435030004R1
R1229 C-CARBON R RN72K1J-000JE 1 435030004R1
R1230 C-CARBON R RN72K1J-000JE 1 435030004R1
R1231 C-CARBON R RN72K1J-333JE 1 435033334R1
R1232 C-CARBON R RN72K1J-152JE 1 435031524R1
R1233 C-CARBON R RN72K1J-333JE 1 435033334R1
R1234 C-R NET RM7LJ101X04 1 43484710104R2 N
R1235 C-R NET RM7LJ101X04 1 43484710104R2 N
R1236 C-R NET RM7LJ101X04 1 43484710104R2 N
R1237 C-R NET RM7LJ101X04 1 43484710104R2 N
R1238 C-R NET RM7LJ101X04 1 43484710104R2 N
R1239 C-CARBON R RN72K1J-220JE 1 435032204R1
R1240 C-CARBON R RN72K1J-103JE 1 435031034R1
R1241 C-R NET RM7LJ101X04 1 43484710104R2 N
R1242 C-CARBON R RN72K1J-000JE 1 435030004R1
R1243 C-CARBON R RN72K1J-000JE 1 435030004R1
R1244 C-CARBON R RN72K1J-000JE 1 435030004R1
R1251 C-R NET RM7LJ101X04 1 43484710104R2 N
R1252 C-R NET RM7LJ101X04 1 43484710104R2 N
R1253 C-R NET RM7LJ101X04 1 43484710104R2 N
R1254 C-R NET RM7LJ101X04 1 43484710104R2 N
R1291 C-R NET RM6KJ103X08 1 43474610308R1
R1292 C-R NET RM6KJ103X08 1 43474610308R1
R1293 C-R NET RM6KJ103X08 1 43474610308R1
R1301 C-CARBON R RN72K1J-470JE 1 435034704R1
R1302 C-CARBON R RN72K1J-470JE 1 435034704R1
R1303 C-CARBON R RN72K1J-470JE 1 435034704R1
R1304 C-CARBON R RN72K1J-470JE 1 435034704R1
R1305 C-CARBON R RN72K1J-470JE 1 435034704R1
R1306 C-CARBON R RN72K1J-103JE 1 435031034R1
R1307 C-CARBON R RN72K1J-102JE 1 435031024R1
R1308 C-CARBON R RN72K1J-000JE 1 435030004R1
R1309 C-CARBON R RN72K1J-220JE 1 435032204R1
R1310 C-CARBON R RN72K1J-000JE 1 435030004R1
R1311 C-CARBON R RN72K1J-000JE 1 435030004R1
R1312 C-CARBON R RN72K1J-000JE 1 435030004R1
R1313 C-CARBON R RN72K1J-220JE 1 435032204R1
Page 70
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
R1314 C-CARBON R RN72K1J-220JE 1 435032204R1
R1315 C-CARBON R RN72K1J-000JE 1 435030004R1
10/140 PAGE
R1316 C-CARBON R RN72K1J-000JE 1 435030004R1
R1317 C-CARBON R RN72K1J-000JE 1 435030004R1
R1318 C-CARBON R RN72K1J-000JE 1 435030004R1
R1319 C-CARBON R RN72K1J-000JE 1 435030004R1
R1320 C-CARBON R RN72K1J-000JE 1 435030004R1
R1321 C-R NET RM7LJ220X04 1 43484722004R2 N
R1322 C-R NET RM7LJ220X04 1 43484722004R2 N
R1323 C-CARBON R RN72K1J-103JE 1 435031034R1
R1324 C-CARBON R RN72K1J-103JE 1 435031034R1
R1325 C-R NET RM7LJ470X04 1 43484747004R2 N
R1326 C-R NET RM7LJ470X04 1 43484747004R2 N
R1327 C-R NET RM7LJ470X04 1 43484747004R2 N
R1328 C-R NET RM7LJ103X04 1 43484710304R2 N
R1329 C-R NET RM7LJ103X04 1 43484710304R2 N
R1330 C-CARBON R RN72K1J-220JE 1 435032204R1
R1331 C-CARBON R RN72K1J-220JE 1 435032204R1
R1332 C-CARBON R RN72K1J-220JE 1 435032204R1
R1333 C-CARBON R RN72K1J-220JE 1 435032204R1
R1334 C-CARBON R RN72K1J-220JE 1 435032204R1
R1335 C-R NET RM7LJ470X04 1 43484747004R2 N
R1336 C-R NET RM7LJ470X04 1 43484747004R2 N
R1337 C-R NET RM7LJ470X04 1 43484747004R2 N
R1338 C-CARBON R RN72K1J-102JE 1 435031024R1
R1339 C-CARBON R RN72K1J-103FE 1 435031032R1
R1340 C-CARBON R RN72K1J-103FE 1 435031032R1
R1341 C-CARBON R RN72K1J-202JE 1 435032024R1
R1342 C-CARBON R RN72K1J-222JE 1 435032224R1
R1343 C-CARBON R RN72K1J-202JE 1 435032024R1
R1344 C-CARBON R RN72K1J-222JE 1 435032224R1
R1345 C-CARBON R RN72K1J-105JE 1 435031054R1
R1346 C-CARBON R RN72K1J-821FE 1 435038212R1
R1347 C-CARBON R RN72K1J-220JE 1 435032204R1
R1348 C-CARBON R RN72K1J-220JE 1 435032204R1
R1349 C-CARBON R RN72K1J-220JE 1 435032204R1
R1350 C-CARBON R RN72K1J-220JE 1 435032204R1
R1351 C-CARBON R RN72K1J-101JE 1 435031014R1
R1354 C-CARBON R RN72K1J-000JE 1 435030004R1
R1355 C-CARBON R RN72K1J-000JE 1 435030004R1
R1356 C-CARBON R RN72K1J-000JE 1 435030004R1
R1357 C-CARBON R RN72K1J-101JE 1 435031014R1
R1358 C-CARBON R RN72K1J-100JE 1 435031004R1
R1359 C-CARBON R RN72K1J-100JE 1 435031004R1
R1360 C-CARBON R RN72K1J-000JE 1 435030004R1
R1361 C-CARBON R RN72K1J-000JE 1 435030004R1
R1362 C-CARBON R RN72K1J-000JE 1 435030004R1
R1363 C-CARBON R RN72K1J-470JE 1 435034704R1
R1371 C-CARBON R RN72K1J-470JE 1 435034704R1
R1374 C-CARBON R RN72K1J-000JE 1 435030004R1
R1375 C-R NET RM7LJ103X04 1 43484710304R2 N
R1376 C-R NET RM7LJ101X04 1 43484710104R2 N
R1377 C-R NET RM7LJ101X04 1 43484710104R2 N
R1378 C-CARBON R RN72K1J-101JE 1 435031014R1
R1379 C-CARBON R RN72K1J-101JE 1 435031014R1
R1380 C-CARBON R RN72K1J-101JE 1 435031014R1
Page 71
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257-1A
DG8257
DG8257
DG8257-1A
DG8257-1A
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
R1381 C-CARBON R RN72K1J-101JE 1 435031014R1
R1382 C-CARBON R RN72K1J-220JE 1 435032204R1
11/140 PAGE
R1383 C-CARBON R RN72K1J-101JE 1 435031014R1
R1384 C-CARBON R RN72K1J-470JE 1 435034704R1
R1387 C-R NET RM7LJ101X04 1 43484710104R2 N
R1388 C-CARBON R RN72K1J-000JE 1 435030004R1
R1389 C-CARBON R RN72K1J-102JE 1 435031024R1
R1390 C-R NET RM7LJ101X04 1 43484710104R2 N
R1391 C-CARBON R RN72K1J-101JE 1 435031014R1
R1393 C-CARBON R RN72K1J-101JE 1 435031014R1
R2001 C-CARBON R RN72K1J-103JE 1 435031034R1
R2002 C-CARBON R RN72K1J-103JE 1 435031034R1
R2003 C-R NET RM7LJ150X04 1 43484715004R2 N
R2004 C-R NET RM7LJ150X04 1 43484715004R2 N
R2005 C-R NET RM7LJ150X04 1 43484715004R2 N
R2006 C-R NET RM7LJ150X04 1 43484715004R2 N
R2007 C-CARBON R RN72K1J-150JE 1 435031504R1
R2009 C-CARBON R RN72K1J-150JE 1 435031504R1
R2010 C-CARBON R RN72K1J-150JE 1 435031504R1
R2011 C-CARBON R RN72K1J-150JE 1 435031504R1
R2012 C-CARBON R RN72K1J-150JE 1 435031504R1
R2013 C-CARBON R RN72K1J-150JE 1 435031504R1
R2014 C-CARBON R RN72K1J-150JE 1 435031504R1
R2015 C-R NET RM7LJ150X04 1 43484715004R2 N
R2016 C-R NET RM7LJ150X04 1 43484715004R2 N
R2017 C-R NET RM7LJ150X04 1 43484715004R2 N
R2018 C-R NET RM7LJ150X04 1 43484715004R2 N
R2019 C-CARBON R RN72K1J-000JE 1 435030004R1
R2023 C-CARBON R RN72K1J-000JE 1 435030004R1
R2024 C-CARBON R RN72K1J-000JE 1 435030004R1
R2025 C-CARBON R RN72K1J-000JE 1 435030004R1
R2030 C-CARBON R RN72K1J-102JE 1 435031024R1
R2031 C-CARBON R RN72K1J-102JE 1 435031024R1
R2041 C-CARBON R RN72K1J-000JE 1 435030004R1
R2042 C-CARBON R RN72K1J-000JE 1 435030004R1
R2043 C-CARBON R RN72K1J-000JE 1 435030004R1
R2047 C-CARBON R RN72K1J-220JE 1 435032204R1
R2048 C-R NET RM7LJ220X04 1 43484722004R2 N
R2049 C-CARBON R RN72K1J-220JE 1 435032204R1
R2050 C-CARBON R RN72K1J-220JE 1 435032204R1
R2051 C-CARBON R RN72K1J-000JE 1 435030004R1
R2052 C-CARBON R RN72K1J-220JE 1 435032204R1
R2053 C-CARBON R RN72K1J-220JE 1 435032204R1
R2054 C-CARBON R RN72K1J-103JE 1 435031034R1
R2055 C-CARBON R RN72K1J-220JE 1 435032204R1
R2056 C-CARBON R RN72K1J-220JE 1 435032204R1
R2058 EMIFIL BK1608LL241-T 1 230959R1
R2059 C-R NET RM7LJ150X04 1 43484715004R2 N
R2060 C-R NET RM7LJ150X04 1 43484715004R2 N
R2061 C-CARBON R RN72K1J-000JE 1 435030004R1
R2062 C-CARBON R RN72K1J-000JE 1 435030004R1
R2063 C-CARBON R RN72K1J-102JE 1 435031024R1
R2064 C-CARBON R RN72K1J-220JE 1 435032204R1
R2065 C-CARBON R RN72K1J-101JE 1 435031014R1
R2066 C-CARBON R RN72K1J-000JE 1 435030004R1
R2067 C-CARBON R RN72K1J-101JE 1 435031014R1
Page 72
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
R2068 C-CARBON R RN72K1J-220JE 1 435032204R1
R2069 C-CARBON R RN72K1J-000JE 1 435030004R1
12/140 PAGE
R2101 C-CARBON R RN72K1J-103JE 1 435031034R1
R2102 C-CARBON R RN72K1J-101JE 1 435031014R1
R2103 C-R NET RM7LJ470X04 1 43484747004R2 N
R2104 C-R NET RM7LJ470X04 1 43484747004R2 N
R2105 C-R NET RM7LJ103X04 1 43484710304R2 N
R2106 C-CARBON R RN72K1J-273JE 1 435032734R1
R2107 C-CARBON R RN72K1J-471JE 1 435034714R1
R2108 C-CARBON R RN72K1J-105JE 1 435031054R1
R2109 C-CARBON R RN72K1J-220JE 1 435032204R1
R2110 C-CARBON R RN72K1J-220JE 1 435032204R1
R2111 C-CARBON R RN72K1J-220JE 1 435032204R1
R2112 C-CARBON R RN72K1J-220JE 1 435032204R1
R2113 C-R NET RM7LJ220X04 1 43484722004R2 N
R2114 C-R NET RM7LJ470X04 1 43484747004R2 N
R2115 C-CARBON R RN72K1J-220JE 1 435032204R1
R2116 C-CARBON R RN72K1J-220JE 1 435032204R1
R2117 C-CARBON R RN72K1J-220JE 1 435032204R1
R2118 C-CARBON R RN72K1J-220JE 1 435032204R1
R2119 C-CARBON R RN72K1J-220JE 1 435032204R1
R2120 C-CARBON R RN72K1J-220JE 1 435032204R1
R2121 C-CARBON R RN72K1J-220JE 1 435032204R1
R2122 C-CARBON R RN72K1J-220JE 1 435032204R1
R2123 C-CARBON R RN72K1J-220JE 1 435032204R1
R2124 C-CARBON R RN72K1J-220JE 1 435032204R1
R2125 C-CARBON R RN72K1J-220JE 1 435032204R1
R2126 C-R NET RM7LJ470X04 1 43484747004R2 N
R2127 C-CARBON R RN72K1J-470JE 1 435034704R1
R2128 C-CARBON R RN72K1J-470JE 1 435034704R1
R2129 C-CARBON R RN72K1J-470JE 1 435034704R1
R2130 C-CARBON R RN72K1J-470JE 1 435034704R1
R2131 C-CARBON R RN72K1J-470JE 1 435034704R1
R2132 C-CARBON R RN72K1J-470JE 1 435034704R1
R2133 C-CARBON R RN72K1J-222JE 1 435032224R1
R2134 C-CARBON R RN72K1J-222JE 1 435032224R1
R2135 C-CARBON R RN72K1J-000JE 1 435030004R1
R2136 C-CARBON R RN72K1J-000JE 1 435030004R1
R2137 C-R NET RM7LJ150X04 1 43484715004R2 N
R2138 C-R NET RM7LJ150X04 1 43484715004R2 N
R2139 C-R NET RM7LJ150X04 1 43484715004R2 N
R2140 C-R NET RM7LJ150X04 1 43484715004R2 N
R2141 C-CARBON R RN72K1J-103JE 1 435031034R1
R2142 C-CARBON R RN72K1J-103JE 1 435031034R1
R2143 C-CARBON R RN72K1J-103JE 1 435031034R1
R2144 C-CARBON R RN72K1J-220JE 1 435032204R1
R2145 C-CARBON R RN72K1J-470JE 1 435034704R1
R2146 C-CARBON R RN72K1J-470JE 1 435034704R1
R2147 C-CARBON R RN72K1J-470JE 1 435034704R1
R2148 C-CARBON R RN72K1J-220JE 1 435032204R1
R2149 C-R NET RM7LJ470X04 1 43484747004R2 N
R2150 C-CARBON R RN72K1J-220JE 1 435032204R1
R2151 C-R NET RM7LJ150X04 1 43484715004R2 N
R2152 C-R NET RM7LJ150X04 1 43484715004R2 N
R2153 C-R NET RM7LJ150X04 1 43484715004R2 N
R2154 C-R NET RM7LJ150X04 1 43484715004R2 N
Page 73
DG8257
8
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
DG8257
R2155 C-R NET RM7LJ150X04 1 43484715004R2 N
R2156 C-CARBON R RN72K1J-150JE 1 435031504R1
13/140 PAGE
R2157 C-CARBON R RN72K1J-470JE 1 435034704R1
R2158 C-CARBON R RN72K1J-472JE 1 435034724R1
R2159 C-CARBON R RN72K1J-103JE 1 435031034R1
R2160 C-CARBON R RN72K1J-103JE 1 435031034R1
R2161 C-CARBON R RN72K1J-102JE 1 435031024R1
R2162 C-CARBON R RN72K1J-472JE 1 435034724R1
R2163 C-CARBON R RN72K1J-000JE 1 435030004R1
R2164 C-CARBON R RN72K1J-220JE 1 435032204R1
R2165 C-CARBON R RN72K1J-220JE 1 435032204R1
R2166 C-CARBON R RN72K1J-220JE 1 435032204R1
R2167 C-CARBON R RN72K1J-220JE 1 435032204R1
R2168 C-CARBON R RN72K1J-000JE 1 435030004R1
R2169 C-CARBON R RN72K1J-000JE 1 435030004R1
R2191 C-CARBON R RN72K1J-103JE 1 435031034R1
R2601 C-CARBON R RN72K1J-561FE 1 435035612R1
R2602 C-CARBON R RN72K1J-220JE 1 435032204R1
R2603 C-CARBON R RN72K1J-101JE 1 435031014R1
R2604 C-CARBON R RN72K1J-101JE 1 435031014R1
R2605 C-CARBON R RN72K1J-220JE 1 435032204R1
R2608 C-CARBON R RN72K1J-000JE 1 435030004R1
R2609 C-CARBON R RN72K1J-000JE 1 435030004R1
R2901 C-CARBON R RN72K1J-000JE 1 435030004R1
R2902 C-CARBON R RN72K1J-000JE 1 435030004R1
R2903 C-CARBON R RN72K1J-000JE 1 435030004R1
R2906 C-CARBON R RN72K1J-102JE 1 435031024R1
R2907 C-CARBON R RN72K1J-333FE 1 435033332R1
R2908 C-CARBON R RN72K1J-133FE 1 435031332R1
R2909 C-CARBON R RN72K1J-911FE 1 435039112R1 N
R2910 C-CARBON R RN72K1J-121FE 1 435031212R1
R2911 C-CARBON R RN72K1J-121FE 1 435031212R1
X1301 CRYSTAL FCX03-33.868MHz 1 3010391R2 N
X2601 CRYSTAL FCX-03-27MHz 1 3010353R2
PWB NO.
VD8258
VD8258
VD8258
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
PRINTED CIRCUIT BOARD PARTS LIST
U02: VIDEO OUTPUT TERMINAL PC BOARD NAVD-8258
U03: DVD MAIN CPU PC BOARD NADG-8259
U04: COMPONENT OUTPUT TERMINAL PC BOARD NAETC-8260 <WT3P><PP2P><G
U05: COMPONENT OUTPUT TERMINAL PC BOARD NAETC-8261 <DC1N>
U06: POWER SUPPLY PC BOARD-3 NAPS-8274DVD MAIN CPU PC BOARD NADG-
CIRCUIT NO. PART NAME DESCRIPTION PART NO.
A051 HOLDER HOLDER(CLAMP) 1 27190540-1
C6001 C-CERA C CK725F1A-105Z1 1 332181050R1
C6002 CHIP ELECT C CEWX16V-22M 1 356742209R2
C6003 C-CERA C CK725F1A-105Z1 1 332181050R1
C6003 C-CERA C CK725F1A-105Z1 1 332181050R1
C6003 C-CERA C CK725F1A-105Z1 1 332181050R1
C6004 C-CERA C CK725F1A-105Z1 1 332181050R1
C6004 C-CERA C CK725F1A-105Z1 1 332181050R1
C6004 C-CERA C CK725F1A-105Z1 1 332181050R1
C6005 C-CERA C CK725F1A-105Z1 1 332181050R1
C6005 C-CERA C CK725F1A-105Z1 1 332181050R1
C6005 C-CERA C CK725F1A-105Z1 1 332181050R1
Page 74
VD8258-1J
VD8258-1P
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
C6006 C-CERA C CK725F1A-105Z1 1 332181050R1
C6006 C-CERA C CK725F1A-105Z1 1 332181050R1
C6006 C-CERA C CK725F1A-105Z1 1 332181050R1
C6007 C-CERA C CK725F1A-105Z1 1 332181050R1
C6008 C-CERA C CK725F1A-105Z1 1 332181050R1
C6009 C-CERA C CK725F1A-105Z1 1 332181050R1
C6010 C-CERA C CK725F1A-105Z1 1 332181050R1
C6011 C-CERA C CK725F1A-105Z1 1 332181050R1
C6012 C-CERA C CK725F1A-105Z1 1 332181050R1
C6013 C-CERA C CK725F1A-105Z1 1 332181050R1
C6014 C-CERA C CK725F1A-105Z1 1 332181050R1
C6015 C-CERA C CK725F1A-105Z1 1 332181050R1
C6020 C-CERA C CK725F1A-105Z1 1 332181050R1
C6021 C-CERA C CK725F1A-105Z1 1 332181050R1
C6022 C-CERA C CK725F1A-105Z1 1 332181050R1
C6023 C-CERA C CK725F1A-105Z1 1 332181050R1
C6024 C-CERA C CK725F1A-105Z1 1 332181050R1
C6029 C-CERA C CK725F1A-105Z1 1 332181050R1
C6030 C-CERA C CK725F1A-105Z1 1 332181050R1
C6031 C-CERA C CK725F1A-105Z1 1 332181050R1
C6032 C-CERA C CK725F1A-105Z1 1 332181050R1
C6033 C-CERA C CK725F1A-105Z1 1 332181050R1
C6034 C-CERA C CK725F1A-105Z1 1 332181050R1
C6035 C-CERA C CK725F1A-105Z1 1 332181050R1
C6036 C-CERA C CK725F1A-105Z1 1 332181050R1
C6037 C-CERA C CK725F1A-105Z1 1 332181050R1
C6038 C-CERA C CK725F1A-105Z1 1 332181050R1
C6039 C-CERA C CK725F1A-105Z1 1 332181050R1
C6040 C-CERA C CC725CH1E-102J1 1 342111024R1
C6041 C-CERA C CK725F1A-105Z1 1 332181050R1
C6042 CHIP ELECT C CEWX16V-22M 1 356742209R2
C6043 C-CERA C CK725F1A-105Z1 1 332181050R1
C6044 C-CERA C CC725CH1H-101J1 1 342101014R1
C6045 C-CERA C CK725F1A-105Z1 1 332181050R1
C6046 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C6047 C-CERA C CK725F1A-105Z1 1 332181050R1
C6048 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C6049 C-CERA C CC725CH1E-102J1 1 342111024R1
C6051 C-CERA C CC725CH1H-050C1 1 342100501R1
C6052 C-CERA C CC725CH1H-050C1 1 342100501R1
C6054 C-CERA C CK725F1A-105Z1 1 332181050R1
C6055 C-CERA C CK725F1A-105Z1 1 332181050R1
C6056 CHIP ELECT C CEWX16V-100M 1 356741019R2
C6062 C-CERA C CK725F1A-105Z1 1 332181050R1
C6063 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C6064 C-CERA C CK725F1A-105Z1 1 332181050R1
C6065 C-CERA C CK725F1A-105Z1 1 332181050R1
C6066 C-CERA C CK725F1A-105Z1 1 332181050R1
C6067 C-CERA C CK725F1A-105Z1 1 332181050R1
C6068 C-CERA C CK725F1A-105Z1 1 332181050R1
C6069 C-CERA C CK725F1A-105Z1 1 332181050R1
C6070 C-CERA C CK725F1A-105Z1 1 332181050R1
C6071 C-CERA C CK725F1A-105Z1 1 332181050R1
C6072 C-CERA C CK725F1A-105Z1 1 332181050R1
C6073 C-CERA C CK725F1A-105Z1 1 332181050R1
C6074 C-CERA C CK725F1A-105Z1 1 332181050R1
14/140 PAGE
Page 75
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
C6075 C-CERA C CK725F1A-105Z1 1 332181050R1
C6080 C-CERA C CC725CH1H-050C1 1 342100501R1
C6091 CHIP ELECT C CEWX16V-10M 1 356741009R2
C6092 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6093 CHIP ELECT C CEWX16V-10M 1 356741009R2
C6101 C-CERA C CK725F1A-105Z1 1 332181050R1
C6102 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C6103 C-CERA C CK725F1A-105Z1 1 332181050R1
C6104 C-CERA C CK725F1A-105Z1 1 332181050R1
C6105 C-CERA C CC725CH1E-102J1 1 342111024R1
C6106 C-CERA C CK725B1H-392K1 1 332103925R1
C6107 C-CERA C CC725CH1E-821J1 1 342118214R1
C6108 C-CERA C CK725B1C-104K1 1 332121045R1
C6109 C-CERA C CK725F1A-105Z1 1 332181050R1
C6110 C-CERA C CK725B1C-104K1 1 332121045R1
C6111 C-CERA C CK725F1A-105Z1 1 332181050R1
C6112 C-CERA C CK725F1A-105Z1 1 332181050R1
C6113 C-CERA C CK725F1A-105Z1 1 332181050R1
C6114 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C6115 C-CERA C CK725F1A-105Z1 1 332181050R1
C6116 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C6117 C-CERA C CK725F1A-105Z1 1 332181050R1
C6118 CHIP ELECT C CEWX16V-47M 1 356744709R2
C6119 C-CERA C CK725F1A-105Z1 1 332181050R1
C6120 CHIP ELECT C CEWX16V-10M 1 356741009R2
C6121 C-CERA C CK725F1A-105Z1 1 332181050R1
C6122 CHIP ELECT C CEWX16V-47M 1 356744709R2
C6123 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6124 C-CERA C CK725F1A-105Z1 1 332181050R1
C6125 CHIP ELECT C CEWX50V-1M 1 356780109R2
C6126 C-CERA C CK725F1A-105Z1 1 332181050R1
C6127 C-CERA C CK725F1A-105Z1 1 332181050R1
C6128 C-CERA C CK725F1A-105Z1 1 332181050R1
C6129 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6151 C-CERA C CK725F1A-105Z1 1 332181050R1
C6152 CHIP ELECT C CEWX50V-1M 1 356780109R2
C6160 C-CERA C CC725CH1H-030C1 1 342100301R1
C6172 C-CERA C CC725CH1H-030C1 1 342100301R1
C6191 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6192 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6193 C-CERA C CK725F1A-105Z1 1 332181050R1
C6194 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6195 C-CERA C CK725F1A-105Z1 1 332181050R1
C6196 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6197 C-CERA C CK725F1A-105Z1 1 332181050R1
C6198 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6199 C-CERA C CK725F1A-105Z1 1 332181050R1
C6201 C-CERA C CK725F1A-105Z1 1 332181050R1
C6202 CHIP ELECT C CEWX50V-1M 1 356780109R2
C6251 C-CERA C CK725F1A-105Z1 1 332181050R1
C6252 CHIP ELECT C CEWX50V-1M 1 356780109R2
C6253 C-CERA C CK725B1C-104K1 1 332121045R1
C6254 C-CERA C CK725B1H-103K1 1 332101035R1
C6255 C-CERA C CK725B1C-104K1 1 332121045R1
C6256 C-CERA C CK725B1H-103K1 1 332101035R1
C6297 C-CERA C CK725F1A-105Z1 1 332181050R1
15/140 PAGE
Page 76
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
C6299 C-CERA C CK725F1A-105Z1 1 332181050R1
C6301 C-CERA C CK725F1A-105Z1 1 332181050R1
C6302 CHIP ELECT C CEWX50V-1M 1 356780109R2
C6351 C-CERA C CK725F1A-105Z1 1 332181050R1
C6352 CHIP ELECT C CEWX50V-1M 1 356780109R2
C6392 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6393 C-CERA C CK725F1A-105Z1 1 332181050R1
C6394 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6395 C-CERA C CK725F1A-105Z1 1 332181050R1
C6396 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6397 C-CERA C CK725F1A-105Z1 1 332181050R1
C6398 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6399 C-CERA C CK725F1A-105Z1 1 332181050R1
C6401 C-CERA C CK725F1A-105Z1 1 332181050R1
C6402 CHIP ELECT C CEWX50V-1M 1 356780109R2
C6451 CHIP ELECT C CEWX16V-47M 1 356744709R2
C6452 CHIP ELECT C CEWX16V-47M 1 356744709R2
C6453 CHIP ELECT C CEWX16V-47M 1 356744709R2
C6454 CHIP ELECT C CEWX16V-47M 1 356744709R2
C6455 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6456 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6501 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C6502 C-CERA C CK725F1A-105Z1 1 332181050R1
C6503 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C6504 C-CERA C CK725F1A-105Z1 1 332181050R1
C6505 C-CERA C CK725F1A-105Z1 1 332181050R1
C6506 C-CERA C CC725CH1E-102J1 1 342111024R1
C6507 C-CERA C CK725B1H-392K1 1 332103925R1
C6508 C-CERA C CC725CH1E-821J1 1 342118214R1
C6509 C-CERA C CK725B1C-104K1 1 332121045R1
C6510 C-CERA C CK725F1A-105Z1 1 332181050R1
C6511 C-CERA C CK725B1C-104K1 1 332121045R1
C6512 C-CERA C CK725F1A-105Z1 1 332181050R1
C6513 C-CERA C CK725F1A-105Z1 1 332181050R1
C6514 CHIP ELECT C CEWX4V-220M 1 3567A2219R2
C6515 C-CERA C CK725F1A-105Z1 1 332181050R1
C6516 C-CERA C CK725F1A-105Z1 1 332181050R1
C6517 C-CERA C CK725F1A-105Z1 1 332181050R1
C6518 CHIP ELECT C CEWX16V-47M 1 356744709R2
C6522 CHIP ELECT C CEWX50V-1M 1 356780109R2
C6523 C-CERA C CK725F1A-105Z1 1 332181050R1
C6524 C-CERA C CK725F1A-105Z1 1 332181050R1
C6525 C-CERA C CK725F1A-105Z1 1 332181050R1
C6526 CHIP ELECT C CEWX16V-47M 1 356744709R2
C6527 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6528 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6529 C-CERA C CK725F1A-105Z1 1 332181050R1
C6531 C-CERA C CC725CH1H-100D1 1 342101002R1
C6532 C-CERA C CC725CH1H-100D1 1 342101002R1
C6551 C-CERA C CK725F1A-105Z1 1 332181050R1
C6552 CHIP ELECT C CEWX50V-1M 1 356780109R2
C6553 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6554 C-CERA C CK725F1A-105Z1 1 332181050R1
C6555 C-CERA C CK725F1A-105Z1 1 332181050R1
C6556 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6557 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
16/140 PAGE
Page 77
VD8258
VD8258
VD8258
VD8258
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
C6601 C-CERA C CK725F1A-105Z1 1 332181050R1
C6602 CHIP ELECT C CEWX50V-1M 1 356780109R2
C6651 C-CERA C CK725F1A-105Z1 1 332181050R1
C6652 CHIP ELECT C CEWX50V-1M 1 356780109R2
C6719 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6720 C-CERA C CK725F1E-104Z1 1 332161040R1
C6721 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6722 C-CERA C CK725F1E-104Z1 1 332161040R1
C6723 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6723 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6723 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6724 C-CERA C CK725F1E-104Z1 1 332161040R1
C6724 C-CERA C CK725F1E-104Z1 1 332161040R1
C6724 C-CERA C CK725F1E-104Z1 1 332161040R1
C6725 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6725 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6725 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C6726 C-CERA C CK725F1E-104Z1 1 332161040R1
C6726 C-CERA C CK725F1E-104Z1 1 332161040R1
C6726 C-CERA C CK725F1E-104Z1 1 332161040R1
C7001 C-CERA C CK725F1E-104Z1 1 332161040R1
C7002 C-CERA C CK725F1E-104Z1 1 332161040R1
C7003 C-CERA C CC725CH1H-220J1 1 342102204R1
C7004 C-CERA C CK725F1E-104Z1 1 332161040R1
C7005 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C7006 C-CERA C CK725F1E-104Z1 1 332161040R1
C7007 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C7008 C-CERA C CK725F1E-104Z1 1 332161040R1
C7009 C-CERA C CK725F1E-104Z1 1 332161040R1
C7010 C-CERA C CK725F1E-104Z1 1 332161040R1
C7101 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C7102 C-CERA C CK725F1E-104Z1 1 332161040R1
C7103 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C7104 C-CERA C CK725F1E-104Z1 1 332161040R1
C7105 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C7106 C-CERA C CK725F1E-104Z1 1 332161040R1
C7107 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C7108 C-CERA C CK725F1E-104Z1 1 332161040R1
C7109 C-CERA C CK725F1E-104Z1 1 332161040R1
C7110 CHIP ELECT C CEWX6.3V-47M 1 356724709R2
C7111 C-CERA C CK725F1E-104Z1 1 332161040R1
C7112 CHIP ELECT C CEWX6.3V-47M 1 356724709R2
C7113 C-CERA C CK725F1E-104Z1 1 332161040R1
C7201 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C7202 C-CERA C CK725F1E-104Z1 1 332161040R1
C7203 C-CERA C CK725F1E-104Z1 1 332161040R1
C7204 C-CERA C CK725F1E-104Z1 1 332161040R1
C7301 C-CERA C CK725F1E-104Z1 1 332161040R1
C7302 C-CERA C CK725F1E-104Z1 1 332161040R1
C7303 C-CERA C CK725B1H-103K1 1 332101035R1
C7304 C-CERA C CK725B1H-103K1 1 332101035R1
C7305 CHIP ELECT C CEWX6.3V-100M 1 356721019R2
C7306 C-CERA C CK725F1E-104Z1 1 332161040R1
C7310 C-CERA C CK725F1E-104Z1 1 332161040R1
C7311 C-CERA C CK725F1E-104Z1 1 332161040R1
C7312 C-CERA C CK725F1E-104Z1 1 332161040R1
17/140 PAGE
Page 78
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1J
VD8258-1P
VD8258-1H
C7401 CHIP ELECT C CEWX16V-100M 1 356741019R2
C7402 C-CERA C CK725F1E-104Z1 1 332161040R1
18/140 PAGE
C7403 CHIP ELECT C CEWX16V-10M 1 356741009R2
C7404 C-CERA C CK725F1E-104Z1 1 332161040R1
C7405 C-CERA C CK725F1E-104Z1 1 332161040R1
D6001 LED SEC1401C 1 225383R2
D6002 LED SEC1401C 1 225383R2
D6003 LED SEC1401C 1 225383R2
D6004 LED SEC1401C 1 225383R2
D6005 LED SEC1401C 1 225383R2
D6006 LED SEC1401C 1 225383R2
D6151 C-DIODE 1SS352 1 223234R2
D6201 C-DIODE 1SS352 1 223234R2
D6251 C-DIODE 1SS352 1 223234R2
D6301 C-DIODE 1SS352 1 223234R2
D6351 C-DIODE 1SS352 1 223234R2
D6401 C-DIODE 1SS352 1 223234R2
D6451 ZENER D UDZS5.6B 1 224550560R2
D6452 ZENER D UDZS5.6B 1 224550560R2
D6551 C-DIODE 1SS352 1 223234R2
D6601 C-DIODE 1SS352 1 223234R2
D6651 C-DIODE 1SS352 1 223234R2
D7201 ZENER D UDZS5.6B 1 224550560R2
D7202 C-DIODE 1SS352 1 223234R2
D7301 C-DIODE 1SS352 1 223234R2
D7302 C-DIODE 1SS352 1 223234R2
D7303 C-DIODE 1SS352 1 223234R2
D7304 C-DIODE 1SS352 1 223234R2
D7305 C-DIODE 1SS352 1 223234R2
D7310 LED SEC1201C 1 225385R2
D7401 C-DIODE 1SR154-400 1 22380284R2
D7402 ZENER D UDZS3.6B 1 224550360R2
E7111 RETAINER E PLATE 1 2714059
E7112 RETAINER E PLATE 1 2714059
F6451 FUSE ICP-S1.0 1 252223R2
F6452 FUSE ICP-S1.0 1 252223R2
L6001 CHOKE COIL NCH-1471 1 231237K022R2
L6002 CHOKE COIL NCH-1471 1 231237K022R2
L6003 CHOKE COIL NCH-1471 1 231237K022R2
L6004 CHOKE COIL NCH-1471 1 231237K022R2
L6006 CHOKE COIL NCH-1471 1 231237K022R2
L6201 CHOKE COIL NCH-1471 1 231237K022R2
L6202 CHOKE COIL NCH-1471 1 231237K022R2
L6203 CHOKE COIL NCH-1471 1 231237K022R2
L6501 CHOKE COIL NCH-1471 1 231237K022R2
L6502 CHOKE COIL NCH-1471 1 231237K022R2
L6503 CHOKE COIL NCH-1471 1 231237K022R2
L6551 LC BLOCK CY4W(15MHz) 1 3030049R2 N
L6601 LC BLOCK CY4W(15MHz) 1 3030049R2 N
L6651 LC BLOCK CY4W(15MHz) 1 3030049R2 N
L6701 CORE N1608Z601T01 1 230981R2 N
L6702 CORE N1608Z601T01 1 230981R2 N
L6703 CORE N1608Z601T01 1 230981R2 N
L6801 CORE N1608Z601T01 1 230981R2
L6801 CORE N1608Z601T01 1 230981R2
L6801 CORE N1608Z601T01 1 230981R2
Page 79
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1G
VD8258
VD8258
VD8258-1H
VD8258-1H
VD8258
VD8258
VD8258
VD8258-1G
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1J
VD8258-1P
VD8258-1H
VD8258
VD8258
L6802 CORE N1608Z601T01 1 230981R2
L6802 CORE N1608Z601T01 1 230981R2
19/140 PAGE
L6802 CORE N1608Z601T01 1 230981R2
L6803 CORE N1608Z601T01 1 230981R2
L6803 CORE N1608Z601T01 1 230981R2
L6803 CORE N1608Z601T01 1 230981R2
P2001B PLUG SM14B-SURS-TF 1 25056397R2 N
P2002B PLUG SM15B-SURS-TF 1 25056398R2 N
P2701B PLUG NPLG-7P920 1 25055967R2
P2901B PLUG NPLG-6P919 1 25055966R2
P3503B SOCKET(B to B) IMSA-9850S-22Y900 1 25052814R2 N
P4008B PLUG NPLG-5P918 1 25055965R2
P4571A PLUG NPLG-8P1105 1 25056166R2 N
P5001B SOCKET(B to B) IMSA-9850S-22Y900 1 25052814R2 N
P5401B SOCKET CPB8148-0211 1 25053023R2 N
P6001A PLUG(B to B) IMSA-9850B-16Y900 1 25056203R2 N
P6001B SOCKET(B to B) IMSA-9850S-16Y900 1 25052811R2 N
P6003A PLUG(B to B) IMSA-9850B-28Y900 1 25056209R2 N
P6003B SOCKET(B to B) IMSA-9850S-28Y900 1 25052817R2 N
P6005A PLUG NPLG-8P1105 1 25056166R2 N
P6005C PLUG NPLG-8P1105 1 25056166R2 N
P6151 PIN JACK NPJ-10PDBY459 1 25045660
P6301 PIN JACK NPJ-3PDGLR429 1 25045622
P6302A PLUG NPLG-7P1104 1 25056165R2
P6303A PLUG NPLG-6P1103 1 25056164R2
P6452A PLUG(B to B) IMSA-9852B-08Y900 1 25056366R2 N
P6452B SOCKET(B to B) IMSA-9850S-08Y900 1 25052807R2
P6551A PLUG NPLG-9P1106 1 25056167R2 N
P6551C PLUG NPLG-9P1106 1 25056167R2 N
P6703B PLUG NPLG-10P1107 1 25056168R2
P6703B PLUG NPLG-10P1107 1 25056168R2
P6703B PLUG NPLG-10P1107 1 25056168R2
P6704 PIN JACK NPJ-1PDG541 1 25045756 N
P6705 PIN JACK NPJ-1PDL540 1 25045755 N
P6706 PIN JACK NPJ-1PDR539 1 25045754 N
P6707 BNC JACK P2298-C 1 25045760
P6707 BNC JACK P2298-C 1 25045760
P6707 BNC JACK P2298-C 1 25045760
P7010A PLUG NPLG-4P1101 1 25056162R2
P7010A PLUG NPLG-4P1101 1 25056162R2
P7010A PLUG NPLG-4P1101 1 25056162R2
P7201A SOCKET NSCT-26P2696 1 25052800R2 N
P7302 PLUG NPLG-8P660 1 25055704
P7401A PLUG NPLG-7P920 1 25055967R2
P8001B SOCKET(B to B) IMSA-9850S-28Y900 1 25052817R2 N
P8002B SOCKET(B to B) IMSA-9850S-20Y900 1 25052813R2 N
P8603B SOCKET CPB8148-0211 1 25053023R2 N
P8701B SOCKET(B to B) IMSA-9850S-10Y900 1 25052808R2 N
P9103B PLUG NPLG-4P917 1 25055964R2
P9601B PLUG NPLG-12P925 1 25055972R2
P9602B PLUG NPLG-14P927 1 25055974R2 N
Q6001 IC TC74VCX162244FT 1 2227C244DR2TO
Q6001 IC TC74VCX162244FT 1 2227C244DR2TO
Q6001 IC TC74VCX162244FT 1 2227C244DR2TO
Q6002 IC TC74VCX162244FT 1 2227C244DR2TO N
Q6003 IC Sil504 1 22242049R3
Page 80
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1G
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
Q6004 IC IC42S32200L-7TG 1 22242056R2 N
Q6004 or IC IS42S32200B-7T ( 1) 22242031R3
20/140 PAGE
Q6005 IC MC504 1 22242050R9 N
Q6008 TR NDC7002N 1 2216870R2 N
Q6009 TR DTC114EE 1 2216730R2
Q6010 TR 2SK3019 1 2216520R2
Q6011 TR NDC7002N 1 2216870R2 N
Q6091 IC LM1117MPX-ADJ 1 22241648R2
Q6101 IC ADV7310 1 22242058R3 N
Q6102 IC NJM2880U25 1 22242085R2 N
Q6103 IC 74AHCT1G08GW 1 22242072R2PH N
Q6103 or IC TC7SET08FU ( 1) 22242072R2TO N
Q6104 TR DTC144EE 1 2216390R2
Q6105 TR DTC144EE 1 2216390R2
Q6106 TR DTA144EE 1 2216380R2
Q6107 TR DTA144EE 1 2216380R2
Q6108 IC 74AHCT1G04GW 1 22242079R2PH N
Q6108 or IC TC7SET04FU ( 1) 22242079R2TO N
Q6109 IC 74AHCT1G08GW 1 22242072R2PH N
Q6109 or IC TC7SET08FU ( 1) 22242072R2TO N
Q6110 IC TK15420M 1 22241443R2
Q6111 IC TK15420M 1 22241443R2
Q6112 IC NJM2373AF 1 22241897R2
Q6113 IC EL4581CS 1 22241527R2
Q6114 IC 74AHCT1G02GW 1 22242089R2PH N
Q6114 or IC TC7SET02FU ( 1) 22242089R2TO N
Q6115 IC TC7SZ125FU 1 22241895R2
Q6151 TR 2SA1162-GR 1 2214375R2
Q6152 TR 2SC2712-GR 1 2213145R2
Q6153 IC LA7106MFP 1 22241465R2
Q6154 IC MAX4018ESD 1 22241440R2
Q6155 IC MAX4018ESD 1 22241440R2
Q6201 TR 2SA1162-GR 1 2214375R2
Q6202 TR 2SC2712-GR 1 2213145R2
Q6251 TR 2SA1162-GR 1 2214375R2
Q6252 TR 2SC2712-GR 1 2213145R2
Q6253 TR DTA144EE 1 2216380R2
Q6254 TR DTA144EE 1 2216380R2
Q6301 TR 2SA1162-GR 1 2214375R2
Q6302 TR 2SC2712-GR 1 2213145R2
Q6303 IC LA7106MFP 1 22241465R2
Q6304 IC MAX4018ESD 1 22241440R2
Q6351 TR 2SA1162-GR 1 2214375R2
Q6352 TR 2SC2712-GR 1 2213145R2
Q6401 TR 2SA1162-GR 1 2214375R2
Q6402 TR 2SC2712-GR 1 2213145R2
Q6451 TR 2SB1565-E 1 2202715
Q6451 or TR 2SB1565-F ( 1) 2202716
Q6451A HEAT SINK SP211K 1 27160442
Q6451B SCREW 3P+10FN(BC) 1 82143010
Q6451C NUT N-3FN(BC) 1 863430
Q6451Cor NUT N-3FN ( 1) 863130
Q6452 TR 2SD2394-E 1 2202705
Q6452 or TR 2SD2394-F ( 1) 2202706
Q6452A HEAT SINK SP211K 1 27160442
Q6452B SCREW 3P+10FN(BC) 1 82143010
Page 81
VD8258
M30624FGPFP(DVSP1000
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1G
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
Q6452C NUT N-3FN(BC) 1 863430
Q6452Cor NUT N-3FN ( 1) 863130
21/140 PAGE
Q6453 TR 2SC2712-GR 1 2213145R2
Q6454 TR 2SA1162-GR 1 2214375R2
Q6455 TR DTC144EE 1 2216390R2
Q6456 TR DTA144EE 1 2216380R2
Q6501 IC ADV7314 1 22242057R2 N
Q6502 IC NJM2880U25 1 22242085R2 N
Q6521 IC EL4581CS 1 22241527R2
Q6522 IC 74AHCT1G02GW 1 22242089R2PH N
Q6522 or IC TC7SET02FU ( 1) 22242089R2TO N
Q6523 IC NJM2373AF 1 22241897R2
Q6524 IC TK15420M 1 22241443R2
Q6525 IC TK15420M 1 22241443R2
Q6551 TR 2SA1162-GR 1 2214375R2
Q6552 TR 2SA1162-GR 1 2214375R2
Q6553 TR 2SC2712-GR 1 2213145R2
Q6554 IC MAX4018ESD 1 22241440R2
Q6601 TR 2SA1162-GR 1 2214375R2
Q6602 TR 2SA1162-GR 1 2214375R2
Q6603 TR 2SC2712-GR 1 2213145R2
Q6651 TR 2SA1162-GR 1 2214375R2
Q6652 TR 2SA1162-GR 1 2214375R2
Q6653 TR 2SC2712-GR 1 2213145R2
Q6707 IC MAX4218ESD 1 22241442R2
Q7001 IC
1 222W0007R3 N
Q7101 IC(REGULATOR) SI-3033LUS 1 22278033CR2
Q7102 IC NJM2370U05 1 22241289R2
Q7201 IC 74AHCT125PW 1 22241894R2PH N
Q7202 IC 74LV125PW 1 22274125CR2PH N
Q7203 TR RN2403 1 2214540R2
Q7301 IC S-80127CNMC-JKM-T2 1 22241642R2
Q7302 IC TC7WU04FU 1 22240935R2
Q7303 IC TC7W74FU 1 22241408R2
Q7304 IC TC7SH08FU 1 22241830R2TO
Q7305 IC 74LVC1G04GW 1 22242074R2PH N
Q7305 or IC TC7SZ04FU ( 1) 22242074R2TO N
Q7401 IC BA6288FS 1 22241656R2
R6001 C-CARBON R RN72K1J-220FE 1 435032202R1
R6002 C-CARBON R RN72K1J-220FE 1 435032202R1
R6003 C-CARBON R RN72K1J-220FE 1 435032202R1
R6004 C-R NET RM7LJ100X04 1 43484710004R2 N
R6005 C-R NET RM7LJ100X04 1 43484710004R2 N
R6006 C-R NET RM7LJ100X04 1 43484710004R2 N
R6007 C-R NET RM7LJ100X04 1 43484710004R2 N
R6008 C-R NET RM7LJ100X04 1 43484710004R2 N
R6009 C-R NET RM7LJ100X04 1 43484710004R2 N
R6010 C-R NET RM7LJ100X04 1 43484710004R2 N
R6011 C-R NET RM7LJ100X04 1 43484710004R2 N
R6012 C-R NET RM7LJ100X04 1 43484710004R2 N
R6019 C-CARBON R RN72K1J-472FE 1 435034722R1
R6020 C-CARBON R RN72K1J-472FE 1 435034722R1
R6023 C-CARBON R RN72K1J-000JE 1 435030004R1
R6024 C-CARBON R RN72K1J-000JE 1 435030004R1
R6025 C-CARBON R RN72K1J-000JE 1 435030004R1
R6026 C-CARBON R RN72K1J-000JE 1 435030004R1
Page 82
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258
VD8258
VD8258
VD8258
R6027 C-CARBON R RN72K1J-000JE 1 435030004R1
R6028 C-CARBON R RN72K1J-000JE 1 435030004R1
22/140 PAGE
R6031 C-CARBON R RN72K1J-103FE 1 435031032R1
R6032 C-CARBON R RN72K1J-103FE 1 435031032R1
R6033 C-R NET RM7LJ103X04 1 43484710304R2 N
R6034 C-R NET RM7LJ103X04 1 43484710304R2 N
R6035 C-CARBON R RN72K1J-104FE 1 435031042R1
R6036 C-CARBON R RN72K1J-222FE 1 435032222R1
R6037 C-CARBON R RN72K1J-222FE 1 435032222R1
R6038 C-CARBON R RN72K1J-222FE 1 435032222R1
R6039 C-CARBON R RN72K1J-000JE 1 435030004R1
R6040 C-CARBON R RN72K1J-102FE 1 435031022R1
R6043 C-CARBON R RN72K1J-101FE 1 435031012R1
R6044 C-CARBON R RN72K1J-472FE 1 435034722R1
R6046 C-CARBON R RN72K1J-472FE 1 435034722R1
R6047 C-CARBON R RN72K1J-472FE 1 435034722R1
R6049 C-CARBON R RN72K1J-472FE 1 435034722R1
R6052 C-CARBON R RN72K1J-102FE 1 435031022R1
R6053 C-CARBON R RN72K1J-105FE 1 435031052R1
R6054 C-CARBON R RN72K1J-000JE 1 435030004R1
R6055 C-CARBON R RN72K1J-472FE 1 435034722R1
R6056 C-CARBON R RN72K1J-472FE 1 435034722R1
R6057 C-CARBON R RN72K1J-222FE 1 435032222R1
R6058 C-CARBON R RN72K1J-222FE 1 435032222R1
R6059 C-CARBON R RN72K1J-222FE 1 435032222R1
R6060 C-CARBON R RN72K1J-000JE 1 435030004R1
R6061 C-CARBON R RN72K1J-103FE 1 435031032R1
R6062 C-CARBON R RN72K1J-102FE 1 435031022R1
R6063 C-CARBON R RN72K1J-103FE 1 435031032R1
R6064 C-CARBON R RN72K1J-102FE 1 435031022R1
R6065 C-CARBON R RN72K1J-222FE 1 435032222R1
R6066 C-CARBON R RN72K1J-222FE 1 435032222R1
R6069 C-CARBON R RN72K1J-472FE 1 435034722R1
R6074 C-CARBON R RN72K1J-000JE 1 435030004R1
R6075 C-CARBON R RN72K1J-000JE 1 435030004R1
R6076 C-CARBON R RN72K1J-222FE 1 435032222R1
R6077 C-CARBON R RN72K1J-222FE 1 435032222R1
R6078 C-CARBON R RN72K1J-471FE 1 435034712R1
R6079 C-CARBON R RN72K1J-000JE 1 435030004R1
R6080 C-CARBON R RN72K1J-000JE 1 435030004R1
R6081 C-CARBON R RN72K1J-000JE 1 435030004R1
R6082 C-CARBON R RN72K1J-100FE 1 435031002R1 N
R6083 C-CARBON R RN72K1J-000JE 1 435030004R1
R6086 C-CARBON R RN72K1J-000JE 1 435030004R1
R6086 C-CARBON R RN72K1J-000JE 1 435030004R1
R6086 C-CARBON R RN72K1J-000JE 1 435030004R1
R6087 C-CARBON R RN72K1J-000JE 1 435030004R1
R6087 C-CARBON R RN72K1J-000JE 1 435030004R1
R6087 C-CARBON R RN72K1J-000JE 1 435030004R1
R6088 C-CARBON R RN72K1J-000JE 1 435030004R1
R6088 C-CARBON R RN72K1J-000JE 1 435030004R1
R6088 C-CARBON R RN72K1J-000JE 1 435030004R1
R6089 C-CARBON R RN72K1J-000JE 1 435030004R1
R6090 C-CARBON R RN72K1J-000JE 1 435030004R1
R6091 C-CARBON R RN72K1J-121FE 1 435031212R1
R6094 C-CARBON R RN72K1J-241FE 1 435032412R1
Page 83
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1H
VD8258-1H
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
R6095 C-CARBON R RN72K1J-000JE 1 435030004R1
R6097 C-CARBON R RN72K1J-000JE 1 435030004R1
R6098 C-CARBON R RN72K1J-000JE 1 435030004R1
R6099 C-CARBON R RN72K1J-472FE 1 435034722R1
R6101 C-CARBON R RN72K1J-103FE 1 435031032R1
R6103 C-CARBON R RN72K1J-472FE 1 435034722R1
R6104 C-CARBON R RN72K1J-472FE 1 435034722R1
R6105 C-CARBON R RN72K1J-103FE 1 435031032R1
R6106 C-CARBON R RN72K1J-000JE 1 435030004R1
R6107 C-CARBON R RN72K1J-102FE 1 435031022R1
R6108 C-CARBON R RN72K1J-681FE 1 435036812R1
R6109 C-CARBON R RN72K1J-681FE 1 435036812R1
R6110 C-CARBON R RN72K1J-681FE 1 435036812R1
R6111 C-CARBON R RN72K1J-272FE 1 435032722R1
R6112 C-CARBON R RN72K1J-272FE 1 435032722R1
R6113 C-CARBON R RN72K1J-681FE 1 435036812R1
R6114 C-CARBON R RN72K1J-681FE 1 435036812R1
R6115 C-CARBON R RN72K1J-103FE 1 435031032R1
R6117 C-CARBON R RN72K1J-000JE 1 435030004R1
R6119 C-CARBON R RN72K1J-000JE 1 435030004R1
R6120 C-CARBON R RN72K1J-473FE 1 435034732R1
R6121 C-CARBON R RN72K1J-122FE 1 435031222R1
R6122 C-CARBON R RN72K1J-122FE 1 435031222R1
R6123 C-CARBON R RN72K1J-102FE 1 435031022R1
R6124 C-CARBON R RN72K1J-102FE 1 435031022R1
R6125 C-CARBON R RN72K1J-102FE 1 435031022R1
R6127 C-CARBON R RN72K1J-102FE 1 435031022R1
R6128 C-CARBON R RN72K1J-102FE 1 435031022R1
R6129 C-CARBON R RN72K1J-102FE 1 435031022R1
R6130 C-CARBON R RN72K1J-102FE 1 435031022R1
R6133 C-CARBON R RN72K1J-152FE 1 435031522R1
R6134 C-CARBON R RN72K1J-103FE 1 435031032R1
R6135 C-CARBON R RN72K1J-000JE 1 435030004R1
R6136 C-CARBON R RN72K1J-224FE 1 435032242R1
R6137 C-CARBON R RN72K1J-221FE 1 435032212R1
R6138 C-CARBON R RN72K1J-000JE 1 435030004R1
R6140 C-CARBON R RN72K1J-564FE 1 435035642R1
R6142 C-CARBON R RN72K1J-102FE 1 435031022R1
R6143 C-CARBON R RN72K1J-102FE 1 435031022R1
R6144 C-CARBON R RN72K1J-102FE 1 435031022R1
R6146 C-CARBON R RN72K1J-101FE 1 435031012R1
R6147 C-CARBON R RN72K1J-101FE 1 435031012R1
R6148 C-CARBON R RN72K1J-000JE 1 435030004R1
R6149 C-CARBON R RN72K1J-000JE 1 435030004R1
R6150 C-CARBON R RN72K1J-000JE 1 435030004R1
R6151 C-CARBON R RN72K1J-331FE 1 435033312R1
R6152 C-CARBON R RN72K1J-332FE 1 435033322R1
R6153 C-CARBON R RN72K1J-102FE 1 435031022R1
R6154 C-CARBON R RN72K1J-471FE 1 435034712R1
R6155 C-CARBON R RN72K1J-273FE 1 435032732R1
R6156 C-CARBON R RN72K1J-273FE 1 435032732R1
R6157 C-CARBON R RN72K1J-332FE 1 435033322R1
R6158 C-CARBON R RN72K1J-151FE 1 435031512R1
R6159 C-CARBON R RN72K1J-102FE 1 435031022R1
R6160 C-CARBON R RN72K1J-203FE 1 435032032R1
R6162 C-CARBON R RN72K1J-240FE 1 435032402R1
23/140 PAGE
Page 84
VD8258
VD8258
VD8258
VD8258
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1H
VD8258-1H
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1H
VD8258
VD8258
R6164 C-CARBON R RN72K1J-103FE 1 435031032R1
R6165 C-CARBON R RN72K1J-750FE 1 435037502R1
R6166 C-CARBON R RN72K1J-000JE 1 435030004R1
R6167 C-CARBON R RN72K1J-000JE 1 435030004R1
R6170 C-CARBON R RN72K1J-000JE 1 435030004R1
R6171 C-CARBON R RN72K1J-102FE 1 435031022R1
R6172 C-CARBON R RN72K1J-203FE 1 435032032R1
R6174 C-CARBON R RN72K1J-240FE 1 435032402R1
R6176 C-CARBON R RN72K1J-103FE 1 435031032R1
R6177 C-CARBON R RN72K1J-750FE 1 435037502R1
R6178 C-CARBON R RN72K1J-000JE 1 435030004R1
R6179 C-CARBON R RN72K1J-000JE 1 435030004R1
R6180 C-CARBON R RN72K1J-000JE 1 435030004R1
R6191 C-CARBON R RN72K1J-101JE 1 435031014R1
R6201 C-CARBON R RN72K1J-331FE 1 435033312R1
R6202 C-CARBON R RN72K1J-332FE 1 435033322R1
R6203 C-CARBON R RN72K1J-102FE 1 435031022R1
R6204 C-CARBON R RN72K1J-471FE 1 435034712R1
R6205 C-CARBON R RN72K1J-273FE 1 435032732R1
R6206 C-CARBON R RN72K1J-273FE 1 435032732R1
R6207 C-CARBON R RN72K1J-332FE 1 435033322R1
R6208 C-CARBON R RN72K1J-151FE 1 435031512R1
R6209 C-CARBON R RN72K1J-102FE 1 435031022R1
R6210 C-CARBON R RN72K1J-223FE 1 435032232R1
R6212 C-CARBON R RN72K1J-240FE 1 435032402R1
R6214 C-CARBON R RN72K1J-103FE 1 435031032R1
R6215 C-CARBON R RN72K1J-750FE 1 435037502R1
R6216 C-CARBON R RN72K1J-000JE 1 435030004R1
R6217 C-CARBON R RN72K1J-000JE 1 435030004R1
R6220 C-CARBON R RN72K1J-000JE 1 435030004R1
R6221 C-CARBON R RN72K1J-102FE 1 435031022R1
R6222 C-CARBON R RN72K1J-223FE 1 435032232R1
R6224 C-CARBON R RN72K1J-240FE 1 435032402R1
R6226 C-CARBON R RN72K1J-103FE 1 435031032R1
R6227 C-CARBON R RN72K1J-750FE 1 435037502R1
R6233 C-CARBON R RN72K1J-000JE 1 435030004R1
R6251 C-CARBON R RN72K1J-331FE 1 435033312R1
R6252 C-CARBON R RN72K1J-332FE 1 435033322R1
R6253 C-CARBON R RN72K1J-102FE 1 435031022R1
R6254 C-CARBON R RN72K1J-471FE 1 435034712R1
R6255 C-CARBON R RN72K1J-273FE 1 435032732R1
R6256 C-CARBON R RN72K1J-273FE 1 435032732R1
R6257 C-CARBON R RN72K1J-332FE 1 435033322R1
R6258 C-CARBON R RN72K1J-151FE 1 435031512R1
R6259 C-CARBON R RN72K1J-102FE 1 435031022R1
R6260 C-CARBON R RN72K1J-223FE 1 435032232R1
R6262 C-CARBON R RN72K1J-240FE 1 435032402R1
R6264 C-CARBON R RN72K1J-103FE 1 435031032R1
R6265 C-CARBON R RN72K1J-750FE 1 435037502R1
R6266 C-CARBON R RN72K1J-822FE 1 435038222R1
R6267 C-CARBON R RN72K1J-122FE 1 435031222R1
R6268 C-CARBON R RN72K1J-122FE 1 435031222R1
R6269 C-CARBON R RN72K1J-122FE 1 435031222R1
R6270 C-CARBON R RN72K1J-000JE 1 435030004R1
R6271 C-CARBON R RN72K1J-102FE 1 435031022R1
R6272 C-CARBON R RN72K1J-223FE 1 435032232R1
24/140 PAGE
Page 85
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
R6274 C-CARBON R RN72K1J-240FE 1 435032402R1
R6276 C-CARBON R RN72K1J-103FE 1 435031032R1
R6277 C-CARBON R RN72K1J-750FE 1 435037502R1
R6278 C-CARBON R RN72K1J-822FE 1 435038222R1
R6279 C-CARBON R RN72K1J-122FE 1 435031222R1
R6286 C-CARBON R RN72K1J-000JE 1 435030004R1
R6287 C-CARBON R RN72K1J-000JE 1 435030004R1
R6301 C-CARBON R RN72K1J-331FE 1 435033312R1
R6302 C-CARBON R RN72K1J-332FE 1 435033322R1
R6303 C-CARBON R RN72K1J-102FE 1 435031022R1
R6304 C-CARBON R RN72K1J-471FE 1 435034712R1
R6305 C-CARBON R RN72K1J-273FE 1 435032732R1
R6306 C-CARBON R RN72K1J-273FE 1 435032732R1
R6307 C-CARBON R RN72K1J-332FE 1 435033322R1
R6308 C-CARBON R RN72K1J-151FE 1 435031512R1
R6309 C-CARBON R RN72K1J-102FE 1 435031022R1
R6310 C-CARBON R RN72K1J-203FE 1 435032032R1
R6312 C-CARBON R RN72K1J-240FE 1 435032402R1
R6314 C-CARBON R RN72K1J-103FE 1 435031032R1
R6315 C-CARBON R RN72K1J-750FE 1 435037502R1
R6316 C-CARBON R RN72K1J-000JE 1 435030004R1
R6317 C-CARBON R RN72K1J-000JE 1 435030004R1
R6351 C-CARBON R RN72K1J-331FE 1 435033312R1
R6352 C-CARBON R RN72K1J-332FE 1 435033322R1
R6353 C-CARBON R RN72K1J-102FE 1 435031022R1
R6354 C-CARBON R RN72K1J-471FE 1 435034712R1
R6355 C-CARBON R RN72K1J-273FE 1 435032732R1
R6356 C-CARBON R RN72K1J-223FE 1 435032232R1
R6357 C-CARBON R RN72K1J-000JE 1 435030004R1
R6358 C-CARBON R RN72K1J-151FE 1 435031512R1
R6359 C-CARBON R RN72K1J-102FE 1 435031022R1
R6360 C-CARBON R RN72K1J-243FE 1 435032432R1
R6362 C-CARBON R RN72K1J-240FE 1 435032402R1
R6364 C-CARBON R RN72K1J-103FE 1 435031032R1
R6365 C-CARBON R RN72K1J-750FE 1 435037502R1
R6366 C-CARBON R RN72K1J-000JE 1 435030004R1
R6367 C-CARBON R RN72K1J-000JE 1 435030004R1
R6401 C-CARBON R RN72K1J-331FE 1 435033312R1
R6402 C-CARBON R RN72K1J-332FE 1 435033322R1
R6403 C-CARBON R RN72K1J-102FE 1 435031022R1
R6404 C-CARBON R RN72K1J-471FE 1 435034712R1
R6405 C-CARBON R RN72K1J-273FE 1 435032732R1
R6406 C-CARBON R RN72K1J-223FE 1 435032232R1
R6407 C-CARBON R RN72K1J-000JE 1 435030004R1
R6408 C-CARBON R RN72K1J-151FE 1 435031512R1
R6409 C-CARBON R RN72K1J-102FE 1 435031022R1
R6410 C-CARBON R RN72K1J-243FE 1 435032432R1
R6412 C-CARBON R RN72K1J-240FE 1 435032402R1
R6414 C-CARBON R RN72K1J-103FE 1 435031032R1
R6415 C-CARBON R RN72K1J-750FE 1 435037502R1
R6416 C-CARBON R RN72K1J-000JE 1 435030004R1
R6417 C-CARBON R RN72K1J-000JE 1 435030004R1
R6455 C-CARBON R RN72K1J-222FE 1 435032222R1
R6456 C-CARBON R RN72K1J-222FE 1 435032222R1
R6457 C-CARBON R RN72K1J-222FE 1 435032222R1
R6458 C-CARBON R RN72K1J-222FE 1 435032222R1
25/140 PAGE
Page 86
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
R6459 C-CARBON R RN72K1J-471FE 1 435034712R1
R6460 C-CARBON R RN72K1J-471FE 1 435034712R1
R6461 C-CARBON R RN72K1J-101FE 1 435031012R1
R6462 C-CARBON R RN72K1J-101FE 1 435031012R1
R6465 C-CARBON R RN72K1J-103FE 1 435031032R1
R6466 C-CARBON R RN72K1J-223FE 1 435032232R1
R6467 C-CARBON R RN72K1J-000JE 1 435030004R1
R6468 C-CARBON R RN72K1J-000JE 1 435030004R1
R6469 C-CARBON R RN72K1J-000JE 1 435030004R1
R6470 C-CARBON R RN72K1J-000JE 1 435030004R1
R6471 C-CARBON R RN72K1J-000JE 1 435030004R1
R6472 C-CARBON R RN72K1J-000JE 1 435030004R1
R6501 C-CARBON R RN72K1J-103FE 1 435031032R1
R6503 C-CARBON R RN72K1J-122FE 1 435031222R1
R6504 C-CARBON R RN72K1J-122FE 1 435031222R1
R6505 C-CARBON R RN72K1J-103FE 1 435031032R1
R6506 C-CARBON R RN72K1J-000JE 1 435030004R1
R6507 C-CARBON R RN72K1J-102FE 1 435031022R1
R6508 C-CARBON R RN72K1J-681FE 1 435036812R1
R6509 C-CARBON R RN72K1J-272FE 1 435032722R1
R6510 C-CARBON R RN72K1J-681FE 1 435036812R1
R6511 C-CARBON R RN72K1J-681FE 1 435036812R1
R6512 C-CARBON R RN72K1J-272FE 1 435032722R1
R6513 C-CARBON R RN72K1J-681FE 1 435036812R1
R6514 C-CARBON R RN72K1J-681FE 1 435036812R1
R6515 C-CARBON R RN72K1J-103FE 1 435031032R1
R6516 C-CARBON R RN72K1J-103FE 1 435031032R1
R6517 C-CARBON R RN72K1J-103FE 1 435031032R1
R6518 C-CARBON R RN72K1J-000JE 1 435030004R1
R6519 C-CARBON R RN72K1J-473FE 1 435034732R1
R6521 C-CARBON R RN72K1J-152FE 1 435031522R1
R6522 C-CARBON R RN72K1J-153FE 1 435031532R1
R6523 C-CARBON R RN72K1J-000JE 1 435030004R1
R6524 C-CARBON R RN72K1J-104FE 1 435031042R1
R6525 C-CARBON R RN72K1J-564FE 1 435035642R1
R6526 C-CARBON R RN72K1J-684FE 1 435036842R1
R6527 C-CARBON R RN72K1J-000JE 1 435030004R1
R6529 C-CARBON R RN72K1J-221FE 1 435032212R1
R6530 C-CARBON R RN72K1J-102FE 1 435031022R1
R6531 C-CARBON R RN72K1J-102FE 1 435031022R1
R6532 C-CARBON R RN72K1J-102FE 1 435031022R1
R6533 C-CARBON R RN72K1J-102FE 1 435031022R1
R6541 C-CARBON R RN72K1J-331FE 1 435033312R1
R6542 C-CARBON R RN72K1J-332FE 1 435033322R1
R6543 C-CARBON R RN72K1J-331FE 1 435033312R1
R6544 C-CARBON R RN72K1J-332FE 1 435033322R1
R6545 C-CARBON R RN72K1J-331FE 1 435033312R1
R6546 C-CARBON R RN72K1J-332FE 1 435033322R1
R6547 C-CARBON R RN72K1J-000JE 1 435030004R1
R6548 C-CARBON R RN72K1J-000JE 1 435030004R1
R6549 C-CARBON R RN72K1J-000JE 1 435030004R1
R6551 C-CARBON R RN72K1J-331FE 1 435033312R1
R6552 C-CARBON R RN72K1J-332FE 1 435033322R1
R6553 C-CARBON R RN72K1J-102FE 1 435031022R1
R6554 C-CARBON R RN72K1J-471FE 1 435034712R1
R6555 C-CARBON R RN72K1J-103FE 1 435031032R1
26/140 PAGE
Page 87
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1J
VD8258-1P
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
R6556 C-CARBON R RN72K1J-102FE 1 435031022R1
R6557 C-CARBON R RN72K1J-471FE 1 435034712R1
27/140 PAGE
R6558 C-CARBON R RN72K1J-273FE 1 435032732R1
R6559 C-CARBON R RN72K1J-562FE 1 435035622R1
R6560 C-CARBON R RN72K1J-821FE 1 435038212R1
R6561 C-CARBON R RN72K1J-101FE 1 435031012R1
R6562 C-CARBON R RN72K1J-471FE 1 435034712R1
R6563 C-CARBON R RN72K1J-681FE 1 435036812R1
R6564 C-CARBON R RN72K1J-682FE 1 435036822R1
R6565 C-CARBON R RN72K1J-103FE 1 435031032R1
R6566 C-CARBON R RN72K1J-122FE 1 435031222R1
R6567 C-CARBON R RN72K1J-122FE 1 435031222R1
R6568 C-CARBON R RN72K1J-101FE 1 435031012R1
R6571 C-CARBON R RN72K1J-222FE 1 435032222R1
R6572 C-CARBON R RN72K1J-222FE 1 435032222R1
R6573 C-CARBON R RN72K1J-222FE 1 435032222R1
R6574 C-CARBON R RN72K1J-000JE 1 435030004R1
R6574 C-CARBON R RN72K1J-000JE 1 435030004R1
R6574 C-CARBON R RN72K1J-000JE 1 435030004R1
R6575 C-CARBON R RN72K1J-000JE 1 435030004R1
R6576 C-CARBON R RN72K1J-270FE 1 435032702R1 N
R6601 C-CARBON R RN72K1J-331FE 1 435033312R1
R6602 C-CARBON R RN72K1J-332FE 1 435033322R1
R6603 C-CARBON R RN72K1J-102FE 1 435031022R1
R6604 C-CARBON R RN72K1J-471FE 1 435034712R1
R6605 C-CARBON R RN72K1J-103FE 1 435031032R1
R6606 C-CARBON R RN72K1J-102FE 1 435031022R1
R6607 C-CARBON R RN72K1J-471FE 1 435034712R1
R6608 C-CARBON R RN72K1J-273FE 1 435032732R1
R6609 C-CARBON R RN72K1J-682FE 1 435036822R1
R6610 C-CARBON R RN72K1J-101FE 1 435031012R1
R6611 C-CARBON R RN72K1J-101FE 1 435031012R1
R6612 C-CARBON R RN72K1J-471FE 1 435034712R1
R6613 C-CARBON R RN72K1J-181FE 1 435031812R1
R6614 C-CARBON R RN72K1J-821FE 1 435038212R1
R6615 C-CARBON R RN72K1J-103FE 1 435031032R1
R6616 C-CARBON R RN72K1J-122FE 1 435031222R1
R6617 C-CARBON R RN72K1J-122FE 1 435031222R1
R6618 C-CARBON R RN72K1J-101FE 1 435031012R1
R6626 C-CARBON R RN72K1J-270FE 1 435032702R1 N
R6631 C-CARBON R RN72K1J-000JE 1 435030004R1
R6632 C-CARBON R RN72K1J-000JE 1 435030004R1
R6633 C-CARBON R RN72K1J-000JE 1 435030004R1
R6634 C-CARBON R RN72K1J-000JE 1 435030004R1
R6635 C-CARBON R RN72K1J-000JE 1 435030004R1
R6636 C-CARBON R RN72K1J-000JE 1 435030004R1
R6637 C-CARBON R RN72K1J-000JE 1 435030004R1
R6638 C-CARBON R RN72K1J-000JE 1 435030004R1
R6639 C-CARBON R RN72K1J-000JE 1 435030004R1
R6640 C-CARBON R RN72K1J-000JE 1 435030004R1
R6651 C-CARBON R RN72K1J-331FE 1 435033312R1
R6652 C-CARBON R RN72K1J-332FE 1 435033322R1
R6653 C-CARBON R RN72K1J-102FE 1 435031022R1
R6654 C-CARBON R RN72K1J-471FE 1 435034712R1
R6655 C-CARBON R RN72K1J-103FE 1 435031032R1
R6656 C-CARBON R RN72K1J-102FE 1 435031022R1
Page 88
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
R6657 C-CARBON R RN72K1J-471FE 1 435034712R1
R6658 C-CARBON R RN72K1J-273FE 1 435032732R1
28/140 PAGE
R6659 C-CARBON R RN72K1J-682FE 1 435036822R1
R6660 C-CARBON R RN72K1J-101FE 1 435031012R1
R6661 C-CARBON R RN72K1J-101FE 1 435031012R1
R6662 C-CARBON R RN72K1J-471FE 1 435034712R1
R6663 C-CARBON R RN72K1J-331FE 1 435033312R1
R6664 C-CARBON R RN72K1J-472FE 1 435034722R1
R6665 C-CARBON R RN72K1J-103FE 1 435031032R1
R6666 C-CARBON R RN72K1J-122FE 1 435031222R1
R6667 C-CARBON R RN72K1J-122FE 1 435031222R1
R6676 C-CARBON R RN72K1J-270FE 1 435032702R1 N
R6763 C-CARBON R RN72K1J-103JE 1 435031034R1
R6764 C-CARBON R RN72K1J-103JE 1 435031034R1
R6765 C-CARBON R RN72K1J-103JE 1 435031034R1
R6766 C-CARBON R RN72K1J-102JE 1 435031024R1
R6767 C-CARBON R RN72K1J-240FE 1 435032402R1
R6768 C-CARBON R RN72K1J-105JE 1 435031054R1
R6769 C-CARBON R RN72K1J-105JE 1 435031054R1
R6770 C-CARBON R RN72K1J-240FE 1 435032402R1
R6771 C-CARBON R RN72K1J-105JE 1 435031054R1
R6772 C-CARBON R RN72K1J-105JE 1 435031054R1
R6773 C-CARBON R RN72K1J-102JE 1 435031024R1
R6774 C-CARBON R RN72K1J-102JE 1 435031024R1
R6775 C-CARBON R RN72K1J-105JE 1 435031054R1
R6776 C-CARBON R RN72K1J-105JE 1 435031054R1
R6777 C-CARBON R RN72K1J-240FE 1 435032402R1
R6778 C-CARBON R RN72K1J-750JE 1 435037504R1
R6779 C-CARBON R RN72K1J-750JE 1 435037504R1
R6780 C-CARBON R RN72K1J-750JE 1 435037504R1
R6851 C-CARBON R RN72K1J-103JE 1 435031034R1
R6851 C-CARBON R RN72K1J-103JE 1 435031034R1
R6851 C-CARBON R RN72K1J-103JE 1 435031034R1
R6852 C-CARBON R RN72K1J-103JE 1 435031034R1
R6852 C-CARBON R RN72K1J-103JE 1 435031034R1
R6852 C-CARBON R RN72K1J-103JE 1 435031034R1
R6853 C-CARBON R RN72K1J-103JE 1 435031034R1
R6853 C-CARBON R RN72K1J-103JE 1 435031034R1
R6853 C-CARBON R RN72K1J-103JE 1 435031034R1
R6854 C-CARBON R RN72K1J-102JE 1 435031024R1
R6854 C-CARBON R RN72K1J-102JE 1 435031024R1
R6854 C-CARBON R RN72K1J-102JE 1 435031024R1
R6855 C-CARBON R RN72K1J-240FE 1 435032402R1
R6855 C-CARBON R RN72K1J-240FE 1 435032402R1
R6855 C-CARBON R RN72K1J-240FE 1 435032402R1
R6856 C-CARBON R RN72K1J-105JE 1 435031054R1
R6856 C-CARBON R RN72K1J-105JE 1 435031054R1
R6856 C-CARBON R RN72K1J-105JE 1 435031054R1
R6857 C-CARBON R RN72K1J-105JE 1 435031054R1
R6857 C-CARBON R RN72K1J-105JE 1 435031054R1
R6857 C-CARBON R RN72K1J-105JE 1 435031054R1
R6858 C-CARBON R RN72K1J-240FE 1 435032402R1
R6858 C-CARBON R RN72K1J-240FE 1 435032402R1
R6858 C-CARBON R RN72K1J-240FE 1 435032402R1
R6859 C-CARBON R RN72K1J-105JE 1 435031054R1
R6859 C-CARBON R RN72K1J-105JE 1 435031054R1
Page 89
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258-1G
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
R6859 C-CARBON R RN72K1J-105JE 1 435031054R1
R6860 C-CARBON R RN72K1J-105JE 1 435031054R1
R6860 C-CARBON R RN72K1J-105JE 1 435031054R1
R6860 C-CARBON R RN72K1J-105JE 1 435031054R1
R6861 C-CARBON R RN72K1J-102JE 1 435031024R1
R6861 C-CARBON R RN72K1J-102JE 1 435031024R1
R6861 C-CARBON R RN72K1J-102JE 1 435031024R1
R6862 C-CARBON R RN72K1J-102JE 1 435031024R1
R6862 C-CARBON R RN72K1J-102JE 1 435031024R1
R6862 C-CARBON R RN72K1J-102JE 1 435031024R1
R6863 C-CARBON R RN72K1J-105JE 1 435031054R1
R6863 C-CARBON R RN72K1J-105JE 1 435031054R1
R6863 C-CARBON R RN72K1J-105JE 1 435031054R1
R6864 C-CARBON R RN72K1J-105JE 1 435031054R1
R6864 C-CARBON R RN72K1J-105JE 1 435031054R1
R6864 C-CARBON R RN72K1J-105JE 1 435031054R1
R6865 C-CARBON R RN72K1J-240FE 1 435032402R1
R6865 C-CARBON R RN72K1J-240FE 1 435032402R1
R6865 C-CARBON R RN72K1J-240FE 1 435032402R1
R6866 C-CARBON R RN72K1J-750JE 1 435037504R1
R6866 C-CARBON R RN72K1J-750JE 1 435037504R1
R6866 C-CARBON R RN72K1J-750JE 1 435037504R1
R6867 C-CARBON R RN72K1J-750JE 1 435037504R1
R6867 C-CARBON R RN72K1J-750JE 1 435037504R1
R6867 C-CARBON R RN72K1J-750JE 1 435037504R1
R6868 C-CARBON R RN72K1J-750JE 1 435037504R1
R6868 C-CARBON R RN72K1J-750JE 1 435037504R1
R6868 C-CARBON R RN72K1J-750JE 1 435037504R1
R6869 C-CARBON R RN72K1J-471JE 1 435034714R1
R6870 C-CARBON R RN72K1J-471JE 1 435034714R1
R6871 C-CARBON R RN72K1J-471JE 1 435034714R1
R6872 C-CARBON R RN72K1J-471JE 1 435034714R1
R6873 C-CARBON R RN72K1J-471JE 1 435034714R1
R6874 C-CARBON R RN72K1J-471JE 1 435034714R1
R7001 C-CARBON R RN72K1J-220FE 1 435032202R1
R7002 C-CARBON R RN72K1J-220FE 1 435032202R1
R7003 C-CARBON R RN72K1J-220FE 1 435032202R1
R7004 C-CARBON R RN72K1J-220FE 1 435032202R1
R7005 C-CARBON R RN72K1J-220FE 1 435032202R1
R7006 C-CARBON R RN72K1J-220FE 1 435032202R1
R7007 C-CARBON R RN72K1J-220FE 1 435032202R1
R7008 C-CARBON R RN72K1J-103FE 1 435031032R1
R7009 C-CARBON R RN72K1J-103FE 1 435031032R1
R7010 C-CARBON R RN72K1J-220FE 1 435032202R1
R7011 C-CARBON R RN72K1J-220FE 1 435032202R1
R7012 C-CARBON R RN72K1J-220FE 1 435032202R1
R7013 C-CARBON R RN72K1J-102FE 1 435031022R1
R7014 C-CARBON R RN72K1J-102FE 1 435031022R1
R7015 C-CARBON R RN72K1J-220FE 1 435032202R1
R7016 C-CARBON R RN72K1J-220FE 1 435032202R1
R7017 C-CARBON R RN72K1J-220FE 1 435032202R1
R7018 C-CARBON R RN72K1J-103FE 1 435031032R1
R7020 C-CARBON R RN72K1J-102FE 1 435031022R1
R7021 C-CARBON R RN72K1J-220FE 1 435032202R1
R7022 C-CARBON R RN72K1J-220FE 1 435032202R1
R7023 C-CARBON R RN72K1J-220FE 1 435032202R1
29/140 PAGE
Page 90
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1G
VD8258-1J
VD8258-1P
VD8258-1H
VD8258
VD8258-1G
VD8258-1J
VD8258-1H
VD8258-1G
VD8258-1J
VD8258-1P
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
R7024 C-CARBON R RN72K1J-220FE 1 435032202R1
R7025 C-CARBON R RN72K1J-220FE 1 435032202R1
R7026 C-CARBON R RN72K1J-220FE 1 435032202R1
R7027 C-CARBON R RN72K1J-220FE 1 435032202R1
R7028 C-CARBON R RN72K1J-103FE 1 435031032R1
R7029 C-CARBON R RN72K1J-220FE 1 435032202R1
R7030 C-CARBON R RN72K1J-103FE 1 435031032R1
R7031 C-CARBON R RN72K1J-220FE 1 435032202R1
R7032 C-CARBON R RN72K1J-220FE 1 435032202R1
R7033 C-CARBON R RN72K1J-103FE 1 435031032R1
R7034 C-CARBON R RN72K1J-220FE 1 435032202R1
R7035 C-CARBON R RN72K1J-103FE 1 435031032R1
R7036 C-CARBON R RN72K1J-220FE 1 435032202R1
R7037 C-CARBON R RN72K1J-220FE 1 435032202R1
R7038 C-CARBON R RN72K1J-220FE 1 435032202R1
R7039 C-CARBON R RN72K1J-220FE 1 435032202R1
R7040 C-CARBON R RN72K1J-220FE 1 435032202R1
R7041 C-CARBON R RN72K1J-102FE 1 435031022R1
R7042 C-CARBON R RN72K1J-102FE 1 435031022R1
R7043 C-CARBON R RN72K1J-102FE 1 435031022R1
R7044 C-CARBON R RN72K1J-102FE 1 435031022R1
R7045 C-CARBON R RN72K1J-102FE 1 435031022R1
R7046 C-CARBON R RN72K1J-102FE 1 435031022R1
R7047 C-CARBON R RN72K1J-102FE 1 435031022R1
R7048 C-CARBON R RN72K1J-102FE 1 435031022R1
R7049 C-CARBON R RN72K1J-221FE 1 435032212R1
R7050 C-CARBON R RN72K1J-221FE 1 435032212R1
R7051 C-CARBON R RN72K1J-221FE 1 435032212R1
R7052 C-CARBON R RN72K1J-221FE 1 435032212R1
R7053 C-CARBON R RN72K1J-221FE 1 435032212R1
R7054 C-CARBON R RN72K1J-221FE 1 435032212R1
R7055 C-CARBON R RN72K1J-472FE 1 435034722R1
R7056 C-CARBON R RN72K1J-472FE 1 435034722R1
R7057 C-CARBON R RN72K1J-472FE 1 435034722R1
R7058 C-CARBON R RN72K1J-472FE 1 435034722R1
R7059 C-CARBON R RN72K1J-273FE 1 435032732R1
R7060 C-CARBON R RN72K1J-333FE 1 435033332R1
R7060 C-CARBON R RN72K1J-683FE 1 435036832R1
R7060 C-CARBON R RN72K1J-683FE 1 435036832R1
R7060 C-CARBON R RN72K1J-683FE 1 435036832R1
R7061 C-CARBON R RN72K1J-472FE 1 435034722R1
R7062 C-CARBON R RN72K1J-103FE 1 435031032R1
R7062 C-CARBON R RN72K1J-333FE 1 435033332R1
R7062 C-CARBON R RN72K1J-822FE 1 435038222R1
R7063 C-CARBON R RN72K1J-563FE 1 435035632R1
R7063 C-CARBON R RN72K1J-562FE 1 435035622R1
R7063 C-CARBON R RN72K1J-103FE 1 435031032R1
R7063 C-CARBON R RN72K1J-562FE 1 435035622R1
R7064 C-CARBON R RN72K1J-220FE 1 435032202R1
R7069 C-CARBON R RN72K1J-103FE 1 435031032R1
R7071 C-CARBON R RN72K1J-103FE 1 435031032R1
R7073 C-CARBON R RN72K1J-103FE 1 435031032R1
R7075 C-CARBON R RN72K1J-103FE 1 435031032R1
R7077 C-CARBON R RN72K1J-103FE 1 435031032R1
R7078 C-CARBON R RN72K1J-103FE 1 435031032R1
R7079 C-CARBON R RN72K1J-472FE 1 435034722R1
30/140 PAGE
Page 91
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258-1J
VD8258-1P
VD8258-1H
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
R7080 C-CARBON R RN72K1J-472FE 1 435034722R1
R7101 C-CARBON R RN72K1J-000JE 1 435030004R1
R7102 C-CARBON R RN72K1J-000JE 1 435030004R1
R7103 C-CARBON R RN72K1J-000JE 1 435030004R1
R7104 C-CARBON R RN72K1J-000JE 1 435030004R1
R7105 C-CARBON R RN72K1J-000JE 1 435030004R1
R7106 C-CARBON R RN72K1J-000JE 1 435030004R1
R7107 C-CARBON R RN72K1J-000JE 1 435030004R1
R7108 C-CARBON R RN72K1J-000JE 1 435030004R1
R7109 C-CARBON R RN72K1J-000JE 1 435030004R1
R7110 C-CARBON R RN72K1J-000JE 1 435030004R1
R7111 C-CARBON R RN72K1J-000JE 1 435030004R1
R7112 C-CARBON R RN72K1J-000JE 1 435030004R1
R7113 C-CARBON R RN72K1J-000JE 1 435030004R1
R7114 C-CARBON R RN72K1J-000JE 1 435030004R1
R7115 C-CARBON R RN72K1J-000JE 1 435030004R1
R7116 C-CARBON R RN72K1J-000JE 1 435030004R1
R7117 C-CARBON R RN72K1J-000JE 1 435030004R1
R7118 C-CARBON R RN72K1J-000JE 1 435030004R1
R7119 C-CARBON R RN72K1J-000JE 1 435030004R1
R7120 C-CARBON R RN72K1J-000JE 1 435030004R1
R7121 C-CARBON R RN72K1J-000JE 1 435030004R1
R7122 C-CARBON R RN72K1J-000JE 1 435030004R1
R7123 C-CARBON R RN72K1J-000JE 1 435030004R1
R7124 C-CARBON R RN72K1J-000JE 1 435030004R1
R7125 C-CARBON R RN72K1J-000JE 1 435030004R1
R7126 C-CARBON R RN72K1J-000JE 1 435030004R1
R7127 C-CARBON R RN72K1J-000JE 1 435030004R1
R7128 C-CARBON R RN72K1J-000JE 1 435030004R1
R7129 C-CARBON R RN72K1J-000JE 1 435030004R1
R7130 C-CARBON R RN72K1J-000JE 1 435030004R1
R7131 C-CARBON R RN72K1J-000JE 1 435030004R1
R7132 C-CARBON R RN72K1J-000JE 1 435030004R1
R7133 C-CARBON R RN72K1J-000JE 1 435030004R1
R7134 C-CARBON R RN72K1J-000JE 1 435030004R1
R7201 C-CARBON R RN72K1J-220FE 1 435032202R1
R7202 C-CARBON R RN72K1J-220FE 1 435032202R1
R7202 C-CARBON R RN72K1J-220FE 1 435032202R1
R7202 C-CARBON R RN72K1J-220FE 1 435032202R1
R7203 C-CARBON R RN72K1J-220FE 1 435032202R1
R7203 C-CARBON R RN72K1J-220FE 1 435032202R1
R7203 C-CARBON R RN72K1J-220FE 1 435032202R1
R7204 C-CARBON R RN72K1J-220FE 1 435032202R1
R7204 C-CARBON R RN72K1J-220FE 1 435032202R1
R7204 C-CARBON R RN72K1J-220FE 1 435032202R1
R7205 C-CARBON R RN72K1J-472FE 1 435034722R1
R7205 C-CARBON R RN72K1J-472FE 1 435034722R1
R7205 C-CARBON R RN72K1J-472FE 1 435034722R1
R7206 C-CARBON R RN72K1J-224FE 1 435032242R1
R7207 C-CARBON R RN72K1J-473FE 1 435034732R1
R7208 C-CARBON R RN72K1J-000JE 1 435030004R1
R7209 C-CARBON R RN72K1J-000JE 1 435030004R1
R7210 C-CARBON R RN72K1J-000JE 1 435030004R1
R7211 C-CARBON R RN72K1J-000JE 1 435030004R1
R7212 C-CARBON R RN72K1J-000JE 1 435030004R1
R7213 C-CARBON R RN72K1J-000JE 1 435030004R1
31/140 PAGE
Page 92
VD8258
)
)
)
)
)
)
)
)
)
)
)
)
VD8258
VD8258
VD8258
VD8258
VD8258-1G
VD8258-1G
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
VD8258
R7214 C-CARBON R RN72K1J-000JE 1 435030004R1
R7215 C-CARBON R RN72K1J-000JE 1 435030004R1
32/140 PAGE
R7216 C-CARBON R RN72K1J-000JE 1 435030004R1
R7217 C-CARBON R RN72K1J-000JE 1 435030004R1
R7218 C-CARBON R RN72K1J-471JE 1 435034714R1
R7219 C-CARBON R RN72K1J-472JE 1 435034724R1
R7220 C-CARBON R RN72K1J-472JE 1 435034724R1
R7301 C-CARBON R RN72K1J-103FE 1 435031032R1
R7302 C-CARBON R RN72K1J-223FE 1 435032232R1
R7303 C-CARBON R RN72K1J-223FE 1 435032232R1
R7304 C-CARBON R RN72K1J-103FE 1 435031032R1
R7305 C-CARBON R RN72K1J-102FE 1 435031022R1
R7306 C-CARBON R RN72K1J-104FE 1 435031042R1
R7310 C-CARBON R RN72K1J-103FE 1 435031032R1
R7311 C-CARBON R RN72K1J-103FE 1 435031032R1
R7312 C-CARBON R RN72K1J-103FE 1 435031032R1
R7313 C-CARBON R RN72K1J-103FE 1 435031032R1
R7314 C-CARBON R RN72K1J-102FE 1 435031022R1
R7315 C-CARBON R RN72K1J-103FE 1 435031032R1
R7317 C-CARBON R RN72K1J-470FE 1 435034702R1
R7318 C-CARBON R RN72K1J-470FE 1 435034702R1
R7319 C-CARBON R RN72K1J-470FE 1 435034702R1
R7320 C-CARBON R RN72K1J-470FE 1 435034702R1
R7321 C-CARBON R RN72K1J-470FE 1 435034702R1
R7322 C-CARBON R RN72K1J-470FE 1 435034702R1
R7401 C-CARBON R RN72K1J-152FE 1 435031522R1
R7402 C-CARBON R RN72K1J-152FE 1 435031522R1
R7403 C-CARBON R RN72K1J-000JE 1 435030004R1
R7404 C-CARBON R RN72K1J-000JE 1 435030004R1
R7405 C-CARBON R RN72K1J-000JE 1 435030004R1
R7406 C-CARBON R RN72K1J-224FE 1 435032242R1
S4751 SLIDE SW NSS-22155 1 25065414
S7301 PUSH SW NPS-111-S681 1 25035718
X6151 CRYSTAL FCX03-20.000MHz 1 3010389R2 N
X7001 CERA LOCK CSTCE12M0G 1 3010395R2 N
X7002 PIEZO PKM13EPY-4002 1 3010309
PRINTED CIRCUIT BOARD PARTS LIST
U07: DISPLAY PC BOARD NADIS-8264
U08: HD-COMPONENT OUTPUT PC BOARD NAVD-8265
U09: AUDIO OUTPUT PC BOARD NAAF-8266
U10: JOG SWITCH PC BOARD NASW-8267
PWB NO.
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
CIRCUIT NO. PART NAME DESCRIPTION PART NO.
C4201 VX C CE04W25V-470M(VX) 1 393354717
C4202 VX C
C4203 VX C
C4204 VX C
C4205 VX C
C4206 VX C
C4701 VX C
C4702 VX C
C4705 RFS C
C4706 RFS C
C4753 VX C
C4754 VX C
C4755 C-CERA C
C4803 RFS C
CE04W25V-470M(VX
CE04W16V-220M(VX
CE04W16V-220M(VX
CE04W16V-220M(VX
CE04W16V-220M(VX
CE04W16V-47M(VX
CE04W16V-47M(VX
CE04W25V-47M(RFS
CE04W25V-47M(RFS
CE04W50V-47M(VX
CE04W50V-47M(VX
CK725F1E-104Z1
CE04W25V-47M(RFS
1 393354717
1 393342217
1 393342217
1 393342217
1 393342217
1 393344707
1 393344707
1 395954707 N
1 395954707 N
1 393384707
1 393384707
1 332161040R1
1 395954707 N
Page 93
DIS8264
)
)
)
)
)
)
)
)
)
K
)
)
)
)
M
M
M
M
M
M
M
M
M
M
M
M
M
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264
C4804 RFS C
C4853 VX C
C4854 VX C
C4903 VX C
C4904 VX C
C4921 VX C
C4951 C-CERA C
C4952 C-CERA C
C4953 C-CERA C
C4954 C-CERA C
C4955 VX C
C4956 VX C
C4957 C-CERA C
CE04W25V-47M(RFS
CE04W50V-47M(VX
CE04W50V-47M(VX
CE04W50V-47M(VX
CE04W50V-47M(VX
CE04W6.3V-470M(VX
CK725F1E-104Z1
CK725F1E-104Z1
CK725B1H-103K1
CK725B1H-103K1
CE04W6.3V-100M(VX
CE04W6.3V-100M(VX
CK725F1E-104Z1
1 395954707 N
1 393384707
1 393384707
1 393384707
1 393384707
1 393324717
1 332161040R1
1 332161040R1
1 332101035R1
1 332101035R1
1 393321017
1 393321017
1 332161040R1
C4957 C-CERA C CK725F1E-104Z1 1 332161040R1
C4958 VX C
CE04W6.3V-100M(VX
1 393321017
C4958 VX C CE04W6.3V-100M(VX) 1 393321017
C4959 C-CERA C
C4960 C-CERA C
C4961 C-CERA C
C4962 C-CERA C
C4965 C-CERA C
C4966 VX C
C4967 C-CERA C
C4968 VX C
C4969 C-CERA C
C4970 C-CERA C
C4971 C-CERA C
C4972 C-CERA C
C4973 C-CERA C
C4974 C-CERA C
C4975 C-CERA C
C4976 C-CERA C
C4977 VX C
C4978 VX C
C4999 C-CERA C
C6781 C-CERA C
CK732B1H 223
CC725CH1H-330J1
CC725CH1H-330J1
CC725CH1H-330J1
CK725F1E-104Z1
CE04W6.3V-100M(VX
CK725F1E-104Z1
CE04W6.3V-100M(VX
CK725F1E-104Z1
CK725F1E-104Z1
CK725F1E-104Z1
CK725F1E-104Z1
CK725F1E-104Z1
CK725F1E-104Z1
CC725CH1H-220J1
CC725CH1H-220J1
CE04W6.3V-470M(VX
CE04W6.3V-470M(VX
CK725F1E-104Z1
CK725F1E-104Z1
1 337322235R1
1 342103304R1
1 342103304R1
1 342103304R1
1 332161040R1
1 393321017
1 332161040R1
1 393321017
1 332161040R1
1 332161040R1
1 332161040R1
1 332161040R1
1 332161040R1
1 332161040R1
1 342102204R1
1 342102204R1
1 393324717
1 393324717
1 332161040R1
1 332161040R1
C6781 C-CERA C CK725F1E-104Z1 1 332161040R1
C6901 CHIP ELECT C
C6902 C-CERA C
C6903 CHIP ELECT C
C6904 C-CERA C
C6905 CHIP ELECT C
C6906 C-CERA C
C6907 CHIP ELECT C
C6908 C-CERA C
C6909 CHIP ELECT C
C6910 CHIP ELECT C
C6911 CHIP ELECT C
C6912 CHIP ELECT C
C6913 C-CERA C
C6914 C-CERA C
C6915 C-CERA C
C6916 C-CERA C
C6917 CHIP ELECT C
C6918 C-CERA C
C6919 CHIP ELECT C
C6920 C-CERA C
C6922 C-CERA C
C6923 C-CERA C
C6924 C-CERA C
C6925 C-CERA C
C6926 CHIP ELECT C
C6927 CHIP ELECT C
C6928 CHIP ELECT C
C6929 C-CERA C
C7501 C-CERA C
CEWX6.3V-100
CK725F1E-104Z1
CEWX6.3V-100
CK725F1E-104Z1
CEWX6.3V-100
CK725F1E-104Z1
CEWX6.3V-100
CK725F1E-104Z1
CEWT6.3V-1000
CEWT6.3V-1000
CEWT6.3V-1000
CEWT6.3V-1000
CK725F1E-104Z1
CK725F1E-104Z1
CK725F1E-104Z1
CK725F1E-104Z1
CEWX16V-47
CK725F1E-104Z1
CEWX16V-47
CK725F1E-104Z1
CK725F1E-104Z1
CC725CH1E-102J1
CC725CH1H-101J1
CC725CH1H-101J1
CEWX16V-10
CEWX16V-10
CEWT6.3V-470
CK725F1E-104Z1
CK725F1E-104Z1
1 356721019R2
1 332161040R1
1 356721019R2
1 332161040R1
1 356721019R2
1 332161040R1
1 356721019R2
1 332161040R1
1 395721027R2
1 395721027R2
1 395721027R2
1 395721027R2
1 332161040R1
1 332161040R1
1 332161040R1
1 332161040R1
1 356744709R2
1 332161040R1
1 356744709R2
1 332161040R1
1 332161040R1
1 342111024R1
1 342101014R1
1 342101014R1
1 356741009R2
1 356741009R2
1 395724717R2
1 332161040R1
1 332161040R1
33/140 PAGE
Page 94
DIS8264
M
M
M
M
M
M
M
B
B
B
6
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264-1E
C7502 C-CERA C
C7503 C-CERA C
C7504 C-CERA C
C7505 CHIP ELECT C
C7506 C-CERA C
C7507 C-CERA C
C7508 C-CERA C
C7509 C-CERA C
C7510 C-CERA C
C7511 C-CERA C
C7512 C-CERA C
C7513 C-CERA C
C7515 CHIP ELECT C
C7516 CHIP ELECT C
C7517 C-CERA C
C7518 C-CERA C
C7519 C-CERA C
C7520 CHIP ELECT C
C7521 CHIP ELECT C
C7522 C-CERA C
C7528 CHIP ELECT C
C7529 C-CERA C
C7530 C-CERA C
CK725F1E-104Z1
CK725F1E-104Z1
CK725F1E-104Z1
CEWX6.3V-100
CK725B1H-223K1
CK725B1H-223K1
CK725B1H-223K1
CK725F1E-104Z1
CK725F1E-104Z1
CK725F1E-104Z1
CK725F1E-104Z1
CK725F1E-104Z1
CEWX50V-2.2
CEWX16V-10
CK725F1E-104Z1
CK725F1E-104Z1
CK725F1E-104Z1
CEWX16V-100
CEWX50V-10
CC725CH1H-330J1
CEWX6.3V-100
CK725F1E-104Z1
CK725F1E-104Z1
1 332161040R1
1 332161040R1
1 332161040R1
1 356721019R2
1 332102235R1
1 332102235R1
1 332102235R1
1 332161040R1
1 332161040R1
1 332161040R1
1 332161040R1
1 332161040R1
1 356780229R2
1 356741009R2
1 332161040R1
1 332161040R1
1 332161040R1
1 356741019R2
1 356781009R2
1 342103304R1
1 356721019R2
1 332161040R1
1 332161040R1
C7530 C-CERA C CK725F1E-104Z1 1 332161040R1
C7531 C-CERA C
CK725F1E-104Z1
1 332161040R1
C7531 C-CERA C CK725F1E-104Z1 1 332161040R1
C7702 C-CERA C
C7703 CHIP ELECT C
D4201 ZENER D
D4202 ZENER D
D4751 C-DIODE
D4751 or C-DIODE
D4752 C-DIODE
D4752 or C-DIODE
D4851 C-DIODE
D4851 or C-DIODE
D4852 C-DIODE
D4852 or C-DIODE
D4921 C-DIODE
D4921 or C-DIODE
D4951 C-DIODE
D4951 or C-DIODE
D4952 C-DIODE
D4952 or C-DIODE
D4953 C-DIODE
D4953 or C-DIODE
D6781 C-DIODE
CK725F1E-104Z1
CEWX6.3V-100
UDZS13
UDZS13
1SS352
1SS355
1SS352
1SS355
1SS352
1SS355
1SS352
1SS355
1SS352
1SS355
1SS352
1SS355
1SS352
1SS355
1SS352
1SS355
1SS352
1 332161040R1
1 356721019R2
1 224551300R2 N
1 224551300R2 N
1 223234R2
( 1) 223269R2
1 223234R2
( 1) 223269R2
1 223234R2
( 1) 223269R2
1 223234R2
( 1) 223269R2
1 223234R2
( 1) 223269R2
1 223234R2
( 1) 223269R2
1 223234R2
( 1) 223269R2
1 223234R2
( 1) 223269R2
1 223234R2
D6781 C-DIODE 1SS352 1 223234R2
D6781 or C-DIODE
1SS355
( 1) 223269R2
D6781 or C-DIODE 1SS355 ( 1) 223269R2
D6901 C-DIODE
D6902 C-DIODE
D6903 C-DIODE
D6904 C-DIODE
D6905 C-DIODE
D6906 C-DIODE
D6906 or C-DIODE
D7501 LED
D7503 LED
D7505 LED
D7507 C-DIODE
D7507 or C-DIODE
D7508 ZENER D
D7509 LED
D7510 LED
1SS226
1SS226
1SS226
1SS226
1SS226
1SS352
1SS355
SEL2E10C
SEL2E10C
SEL2E10C
1SS352
1SS355
UDZ2.4
SEL2E10C
SEL2910A-TP
1 223266R2
1 223266R2
1 223266R2
1 223266R2
1 223266R2
1 223234R2
( 1) 223269R2
1 225374
1 225374
1 225374
1 223234R2
( 1) 223269R2
1 224490240R2
1 225374
1 225390
34/140 PAGE
Page 95
DIS8264-1F
6
R
S
S
(
T
9
B
6
4
6
7
6
E
F
7
E
F
7
R
R
A
A
DIS8264-1E
DIS8264-1F
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264-1E
DIS8264-1F
DIS8264
DIS8264-1E
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264-1E
DIS8264
DIS8264
DIS8264
DIS8264-1E
DIS8264-1F
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1E
DIS8264-1F
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
D7510 LED SEL2910A-TP6 1 225390
D7511 LED
SEL2910A-TP
1 225390
D7511 LED SEL2910A-TP6 1 225390
D7701 LED
E4602 CLAMP
E4603 CLAMP
E4953 RETAINER
L4951 CHOKE COIL
L4952 CHOKE COIL
L4953 CHOKE COIL
L4954 CHOKE COIL
L4955 CHOKE COIL
L4956 CHOKE COIL
SEL4110
WS-2N
WS-2N
KANAGU
NCH-1471
NCH-1471
NCH-1471
NCH-1471
NCH-1471
NCH-1571
ｱｰｽ)
1 225290
1 27300833
1 27300833
1 27141059
1 231237M022R2
1 231237M022R2
1 231237M022R2
1 231237M022R2
1 231237M022R2
1 233530R2
L4956 CHOKE COIL NCH-1571 1 233530R2
L4999 EMIFIL
L6905 CHOKE COIL
P4005B PLUG
P4011 BUS BAR
P4202B PLUG
P4203B PLUG
P4204B PLUG
P4571B PLUG
P4950B PLUG
P4955 PIN JACK
P4956 ST JACK
BK1608LM182NCH-1471
NPLG-5P11
BBL40
BM15B-SRSS-T
NPLG-14P1111
NPLG-10P923
NPLG-8P1105
NPLG-7P135
NPJ-2PDB400
HSJ1002-01-1020
1 230958R1
1 231237M022R2
1 25055135
1 27141867
1 25056378R2 N
1 25056172R2 N
1 25055970R2
1 25056166R2 N
1 25055151
1 25045589
1 25045647
P4956 ST JACK HSJ1002-01-1020 1 25045647
P4958 PIN JACK
P4959 PIN JACK
P4960 PIN JACK
P4961 PIN JACK
P4964 PIN JACK
P6005B PLUG
NPJ-1PDOR442
NPJ-1PDOR442
NPJ-2PDWR404
NPJ-6PDWRLEGP50
NPJ-2PDLE507
NPLG-8P1105
1 25045636
1 25045636
1 25045593
1 25045715
1 25045716
1 25056166R2
P6005B PLUG NPLG-8P1105 1 25056166R2
P6302B PLUG
P6303B PLUG
P6551B PLUG
NPLG-7P110
NPLG-6P1103
NPLG-9P110
1 25056165R2
1 25056164R2
1 25056167R2
P6551B PLUG NPLG-9P1106 1 25056167R2
P6703A PLUG
NPLG-10P110
1 25056168R2
P6703A PLUG NPLG-10P1107 1 25056168R2
P6781 ST JACK
HSJ1501-011010
1 25045581R2
P6781 ST JACK HSJ1501-011010 1 25045581R2
P6901 SOCKET
P7010B PLUG
YKF-41-5051
NPLG-4P1101
1 25052957
1 25056162R2
P7010B PLUG NPLG-4P1101 1 25056162R2
P7201B SOCKET
P7801A WIRE HOL
P7801B WIRE TRAP
P7801C JUMPER LEAD
Q4201 TR
Q4201 or TR
Q4201A HEAT SINK
Q4201B SCREW
Q4202 TR
Q4202 or TR
Q4202A HEAT SINK
Q4202B SCREW
Q4203 TR
Q4204 TR
Q4207 TR
Q4207 or TR
Q4208 TR
NSCT-26P269
NSCT-12P883
NPLG-12P595
UL2651#26
2SB15652SB1565RAD-15
3P+10FN(BC)
2SD23942SD2394RAD-15
3P+10FN(BC)
2SC2712-G
2SA1162-G
RN1407
DTC114YK
DTC114YK
1 25052800R2 N
1 25051096
1 25055633
1 2J100606B15
1 2202715
( 1) 2202716
1 27160491
1 82143010
1 2202705
( 1) 2202706
1 27160491
1 82143010
1 2213145R2
1 2214375R2
1 2216260R2
( 1) 2216470R2
1 2216470R2
35/140 PAGE
Page 96
DIS8264
B
B
A
A
B
B
R
R
R
A
B
B
A
A
B
B
A
A
R
R
B
B
A
A
R
F
F
A
A
9
9
R
R
R
A
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
Q4701 IC
Q4702 TR
Q4703 TR
Q4704 TR
Q4704 or TR
Q4705 TR
Q4705 or TR
Q4751 IC
Q4752 TR
Q4753 TR
Q4755 TR
Q4756 TR
Q4757 TR
Q4758 TR
Q4758 or TR
Q4801 IC
Q4802 TR
Q4803 TR
Q4804 TR
Q4804 or TR
Q4805 TR
Q4805 or TR
Q4851 IC
Q4852 TR
Q4853 TR
Q4854 TR
Q4854 or TR
Q4855 TR
Q4855 or TR
Q4857 TR
Q4858 TR
Q4901 IC
Q4902 TR
Q4903 TR
Q4904 TR
Q4904 or TR
Q4905 TR
Q4905 or TR
Q4921 TR
Q4951 IC
Q4952 IC
Q4953 TR
NJM4580M-D
HN1C03FHN1C03FRN2403
DTA124EK
RN2403
DTA124EK
NJM4580M-D
HN1C03FHN1C03F2SC2712-G
2SC2712-G
2SA1162-G
RN1407
DTC114YK
NJM4580M-D
HN1C03FHN1C03FRN2403
DTA124EK
RN2403
DTA124EK
NJM4580M-D
HN1C03FHN1C03FRN2403
DTA124EK
RN2403
DTA124EK
2SC2712-G
2SC2712-G
NJM4580M-D
HN1C03FHN1C03FRN2403
DTA124EK
RN2403
DTA124EK
2SA1162-G
74HCU04
74HCU04
RN1402
1 22241448R2
1 2216141R2
1 2216141R2
1 2214540R2
( 1) 2216240R2
1 2214540R2
( 1) 2216240R2
1 22241448R2
1 2216141R2
1 2216141R2
1 2213145R2
1 2213145R2
1 2214375R2
1 2216260R2
( 1) 2216470R2
1 22241448R2
1 2216141R2
1 2216141R2
1 2214540R2
( 1) 2216240R2
1 2214540R2
( 1) 2216240R2
1 22241448R2
1 2216141R2
1 2216141R2
1 2214540R2
( 1) 2216240R2
1 2214540R2
( 1) 2216240R2
1 2213145R2
1 2213145R2
1 22241448R2
1 2216141R2
1 2216141R2
1 2214540R2
( 1) 2216240R2
1 2214540R2
( 1) 2216240R2
1 2214375R2
1 222740046R2
1 222740046R2
1 2214470R2
Q4953 TR RN1402 1 2214470R2
Q4953 or TR
DTC114EK
( 1) 2216250R2
Q4953 or TR DTC114EKA ( 1) 2216250R2
Q4954 TR
RN1402
1 2214470R2
Q4954 TR RN1402 1 2214470R2
Q4954 or TR
DTC114EK
( 1) 2216250R2
Q4954 or TR DTC114EKA ( 1) 2216250R2
Q4955 PHT CP
PC817X
1 24120080
Q4955 PHT CP PC817X 1 24120080
Q4956 PHT CP
Q4957 PHT CP
Q4958 TR
Q4959 TR
Q6781 TR
TOTX17
TOTX17
2SA1162-G
2SA1162-G
2SA1162-G
1 24120094
1 24120094
1 2214375R2
1 2214375R2
1 2214375R2
Q6781 TR 2SA1162-GR 1 2214375R2
Q6782 TR
RN1402
1 2214470R2
Q6782 TR RN1402 1 2214470R2
Q6782 or TR
DTC114EK
( 1) 2216250R2
Q6782 or TR DTC114EKA ( 1) 2216250R2
36/140 PAGE
Page 97
DIS8264-1E
W
U
W
U
W
U
W
U
R
R
B
R
W
U
T
K
R
R
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
DIS8264-1F
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264-1D
DIS8264-1E
DIS8264-1F
DIS8264-1D
DIS8264-1E
DIS8264-1F
DIS8264-1D
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
Q6783 PHT CP
PC817X
1 24120080
Q6783 PHT CP PC817X 1 24120080
Q6901 IC
Q6902 IC
Q6903 IC
Q6903 or IC
Q6904 IC
Q6904 or IC
Q6905 IC
Q6905 or IC
Q6906 IC
Q6906 or IC
Q6907 TR
Q6908 TR
Q6909 IC
Q6910 TR
Q6911 TR
Q6912 IC
Q6912 or IC
Q7501 IC
Q7502 FL TUBE
Q7502A HOLDER
Q7503 TR
Q7504 TR
Q7505 TR
Q7506 TR
Q7507 TR
Q7508 TR
Q7508 or TR
Q7509 TR
Q7509 or TR
Q7510 TR
Q7510 or TR
Q7511 TR
Q7511 TR
MAX4018ESD
MAX4018ESD
74AHCT1G08G
TC7SET08F
74AHCT1G04G
TC7SET04F
74AHCT1G08G
TC7SET08F
74AHCT1G08G
TC7SET08F
2SC2712-G
HN1C01F-G
NJM4565M-D
HN1C03F2SA1162-G
74AHCT1G08G
TC7SET08F
MPD780232GC-091-8B
13-BT-211GN
(FL)
2SC2712-G
2SC2712-G
IMT1
IMT1
IMT1
RN1407
DTC114YK
RN1407
DTC114YK
RN1407
DTC114YK
IMT1
IMT1
1 22241440R2
1 22241440R2
1 22242072R2PH
( 1) 22242072R2TO
1 22242079R2PH
( 1) 22242079R2TO
1 22242072R2PH
( 1) 22242072R2TO
1 22242072R2PH
( 1) 22242072R2TO
1 2213145R2
1 2215925R2
1 22241383R2
1 2216141R2
1 2214375R2
1 22242072R2PH
( 1) 22242072R2TO
1 22241989R3
1 212247 N
1 27191114
1 2213145R2
1 2213145R2
1 2216270R2
1 2216270R2
1 2216270R2
1 2216260R2
( 1) 2216470R2
1 2216260R2
( 1) 2216470R2
1 2216260R2
( 1) 2216470R2
1 2216270R2
1 2216270R2
Q7511 TR IMT1A 1 2216270R2
Q7512 TR
Q7512 TR
RN1407
RN1407
1 2216260R2
1 2216260R2
Q7512 TR RN1407 1 2216260R2
Q7512 or TR
Q7512 or TR
DTC114YK
DTC114YK
( 1) 2216470R2
( 1) 2216470R2
Q7512 or TR DTC114YKA ( 1) 2216470R2
Q7513 TR
IMT1
1 2216270R2
Q7513 TR IMT1A 1 2216270R2
Q7514 TR
RN1407
1 2216260R2
Q7514 TR RN1407 1 2216260R2
Q7514 or TR
DTC114YK
( 1) 2216470R2
Q7514 or TR DTC114YKA ( 1) 2216470R2
Q7515 TR
IMT1
1 2216270R2
Q7515 TR IMT1A 1 2216270R2
Q7516 TR
RN1407
1 2216260R2
Q7516 TR RN1407 1 2216260R2
Q7516 or TR
DTC114YK
( 1) 2216470R2
Q7516 or TR DTC114YKA ( 1) 2216470R2
Q7517 TR
IMT1
1 2216270R2
Q7517 TR IMT1A 1 2216270R2
Q7518 TR
RN1407
1 2216260R2
Q7518 TR RN1407 1 2216260R2
37/140 PAGE
Page 98
DIS8264-1E
A
A
DIS8264-1F
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
Q7518 or TR
DTC114YK
( 1) 2216470R2
Q7518 or TR DTC114YKA ( 1) 2216470R2
Q7703 TR
Q7703 or TR
R4229 C-CARBON R
R4230 C-CARBON R
R4231 C-CARBON R
R4232 C-CARBON R
R4233 C-CARBON R
R4234 C-CARBON R
R4235 C-CARBON R
R4236 C-CARBON R
R4241 C-CARBON R
R4242 C-CARBON R
R4243 C-CARBON R
R4244 C-CARBON R
R4245 METAL O R
R4246 METAL O R
R4247 C-CARBON R
R4701 C-CARBON R
R4702 C-CARBON R
R4703 C-CARBON R
R4704 C-CARBON R
R4705 C-CARBON R
R4706 C-CARBON R
R4707 C-CARBON R
R4708 C-CARBON R
R4709 C-CARBON R
R4710 C-CARBON R
R4711 C-CARBON R
R4712 C-CARBON R
R4713 C-CARBON R
R4714 C-CARBON R
R4715 C-CARBON R
R4716 C-CARBON R
R4717 C-CARBON R
R4718 C-CARBON R
R4751 C-CARBON R
R4752 C-CARBON R
R4753 C-CARBON R
R4754 C-CARBON R
R4755 C-CARBON R
R4756 C-CARBON R
R4757 C-CARBON R
R4758 C-CARBON R
R4759 C-CARBON R
R4760 C-CARBON R
R4761 C-CARBON R
R4762 C-CARBON R
R4763 C-CARBON R
R4764 C-CARBON R
R4765 C-CARBON R
R4766 C-CARBON R
R4767 C-CARBON R
R4768 C-CARBON R
R4769 C-CARBON R
R4770 C-CARBON R
R4771 C-CARBON R
R4772 C-CARBON R
R4773 C-CARBON R
R4774 C-CARBON R
R4775 C-CARBON R
R4776 C-CARBON R
R4777 C-CARBON R
R4778 C-CARBON R
R4801 C-CARBON R
R4802 C-CARBON R
R4803 C-CARBON R
RN1407
DTC114YK
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-471JE
RN72K1J-471JE
RN72K1J-101JE
RN72K1J-101JE
RN72K1J-103JE
RN72K1J-223JE
RS1/2WBJ-2.2
RS1/2WBJ-2.2
RN72K1J-103JE
RN72K1J-102JE
RN72K1J-102JE
RN72K1J-102JE
RN72K1J-102JE
RN72K1J-473JE
RN72K1J-473JE
RN72K1J-222JE
RN72K1J-222JE
RN72K1J-101JE
RN72K1J-101JE
RN72K1J-222JE
RN72K1J-222JE
RN72K1J-221JE
RN72K1J-221JE
RN72K1J-105JE
RN72K1J-105JE
RN72K1J-684JE
RN72K1J-684JE
RN72K1J-102JE
RN72K1J-102JE
RN72K1J-102JE
RN72K1J-102JE
RN72K1J-473JE
RN72K1J-473JE
RN72K1J-222JE
RN72K1J-222JE
RN72K1J-221JE
RN72K1J-221JE
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-221JE
RN72K1J-221JE
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-272JE
RN72K1J-272JE
RN72K1J-105JE
RN72K1J-105JE
RN72K1J-684JE
RN72K1J-684JE
RN72K1J-105JE
RN72K1J-684JE
RN72K1J-182JE
RN72K1J-182JE
RN72K1J-272JE
RN72K1J-473JE
RN72K1J-102JE
RN72K1J-102JE
RN72K1J-102JE
1 2216260R2
( 1) 2216470R2
1 435031034R1
1 435031034R1
1 435031034R1
1 435031034R1
1 435031034R1
1 435031034R1
1 435034714R1
1 435034714R1
1 435031014R1
1 435031014R1
1 435031034R1
1 435032234R1
1 443520224
1 443520224
1 435031034R1
1 435031024R1
1 435031024R1
1 435031024R1
1 435031024R1
1 435034734R1
1 435034734R1
1 435032224R1
1 435032224R1
1 435031014R1
1 435031014R1
1 435032224R1
1 435032224R1
1 435032214R1
1 435032214R1
1 435031054R1
1 435031054R1
1 435036844R1
1 435036844R1
1 435031024R1
1 435031024R1
1 435031024R1
1 435031024R1
1 435034734R1
1 435034734R1
1 435032224R1
1 435032224R1
1 435032214R1
1 435032214R1
1 435031034R1
1 435031034R1
1 435032214R1
1 435032214R1
1 435031034R1
1 435031034R1
1 435032724R1
1 435032724R1
1 435031054R1
1 435031054R1
1 435036844R1
1 435036844R1
1 435031054R1
1 435036844R1
1 435031824R1
1 435031824R1
1 435032724R1
1 435034734R1
1 435031024R1
1 435031024R1
1 435031024R1
38/140 PAGE
Page 99
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264-1E
R4804 C-CARBON R
R4805 C-CARBON R
R4806 C-CARBON R
R4807 C-CARBON R
R4808 C-CARBON R
R4809 C-CARBON R
R4810 C-CARBON R
R4811 C-CARBON R
R4812 C-CARBON R
R4813 C-CARBON R
R4814 C-CARBON R
R4815 C-CARBON R
R4816 C-CARBON R
R4817 C-CARBON R
R4818 C-CARBON R
R4851 C-CARBON R
R4852 C-CARBON R
R4853 C-CARBON R
R4854 C-CARBON R
R4855 C-CARBON R
R4856 C-CARBON R
R4857 C-CARBON R
R4858 C-CARBON R
R4859 C-CARBON R
R4860 C-CARBON R
R4861 C-CARBON R
R4862 C-CARBON R
R4863 C-CARBON R
R4864 C-CARBON R
R4865 C-CARBON R
R4866 C-CARBON R
R4867 C-CARBON R
R4868 C-CARBON R
R4869 C-CARBON R
R4870 C-CARBON R
R4871 C-CARBON R
R4872 C-CARBON R
R4901 C-CARBON R
R4902 C-CARBON R
R4903 C-CARBON R
R4904 C-CARBON R
R4905 C-CARBON R
R4906 C-CARBON R
R4907 C-CARBON R
R4908 C-CARBON R
R4909 C-CARBON R
R4910 C-CARBON R
R4911 C-CARBON R
R4912 C-CARBON R
R4913 C-CARBON R
R4914 C-CARBON R
R4915 C-CARBON R
R4916 C-CARBON R
R4917 C-CARBON R
R4918 C-CARBON R
R4921 C-CARBON R
R4922 C-CARBON R
R4923 C-CARBON R
R4924 C-CARBON R
R4951 C-CARBON R
R4954 C-CARBON R
R4955 C-CARBON R
R4956 C-CARBON R
R4957 C-CARBON R
R4958 C-CARBON R
R4959 C-CARBON R
R4960 C-CARBON R
R4961 C-CARBON R
RN72K1J-102JE
RN72K1J-473JE
RN72K1J-473JE
RN72K1J-222JE
RN72K1J-222JE
RN72K1J-101JE
RN72K1J-101JE
RN72K1J-222JE
RN72K1J-222JE
RN72K1J-221JE
RN72K1J-221JE
RN72K1J-105JE
RN72K1J-105JE
RN72K1J-684JE
RN72K1J-684JE
RN72K1J-102JE
RN72K1J-102JE
RN72K1J-102JE
RN72K1J-102JE
RN72K1J-473JE
RN72K1J-473JE
RN72K1J-222JE
RN72K1J-222JE
RN72K1J-101JE
RN72K1J-101JE
RN72K1J-222JE
RN72K1J-222JE
RN72K1J-221JE
RN72K1J-221JE
RN72K1J-105JE
RN72K1J-105JE
RN72K1J-684JE
RN72K1J-684JE
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-272JE
RN72K1J-272JE
RN72K1J-102JE
RN72K1J-102JE
RN72K1J-102JE
RN72K1J-102JE
RN72K1J-473JE
RN72K1J-473JE
RN72K1J-222JE
RN72K1J-222JE
RN72K1J-101JE
RN72K1J-101JE
RN72K1J-222JE
RN72K1J-222JE
RN72K1J-221JE
RN72K1J-221JE
RN72K1J-105JE
RN72K1J-105JE
RN72K1J-684JE
RN72K1J-684JE
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-105JE
RN72K1J-684JE
RN72K1J-000JE
RN72K1J-000JE
RN72K1J-104JE
RN72K1J-154JE
RN72K1J-104JE
RN72K1J-154JE
RN72K1J-223JE
RN72K1J-223JE
RN72K1J-332JE
1 435031024R1
1 435034734R1
1 435034734R1
1 435032224R1
1 435032224R1
1 435031014R1
1 435031014R1
1 435032224R1
1 435032224R1
1 435032214R1
1 435032214R1
1 435031054R1
1 435031054R1
1 435036844R1
1 435036844R1
1 435031024R1
1 435031024R1
1 435031024R1
1 435031024R1
1 435034734R1
1 435034734R1
1 435032224R1
1 435032224R1
1 435031014R1
1 435031014R1
1 435032224R1
1 435032224R1
1 435032214R1
1 435032214R1
1 435031054R1
1 435031054R1
1 435036844R1
1 435036844R1
1 435031034R1
1 435031034R1
1 435032724R1
1 435032724R1
1 435031024R1
1 435031024R1
1 435031024R1
1 435031024R1
1 435034734R1
1 435034734R1
1 435032224R1
1 435032224R1
1 435031014R1
1 435031014R1
1 435032224R1
1 435032224R1
1 435032214R1
1 435032214R1
1 435031054R1
1 435031054R1
1 435036844R1
1 435036844R1
1 435031034R1
1 435031034R1
1 435031054R1
1 435036844R1
1 435030004R1
1 435030004R1
1 435031044R1
1 435031544R1
1 435031044R1
1 435031544R1
1 435032234R1
1 435032234R1
1 435033324R1
39/140 PAGE
Page 100
DIS8264-1F
E
E
DIS8264
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264
DIS8264
DIS8264-1E
DIS8264-1F
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1F
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
DIS8264-1E
R4961 C-CARBON R RN72K1J-332JE 1 435033324R1
R4962 C-CARBON R
R4963 C-CARBON R
RN72K1J-471JE
RN72K1J-103JE
1 435034714R1
1 435031034R1
R4963 C-CARBON R RN72K1J-103JE 1 435031034R1
R4964 C-CARBON R
RN72K1J-103JE
1 435031034R1
R4964 C-CARBON R RN72K1J-103JE 1 435031034R1
R4967 C-CARBON R
R4968 C-CARBON R
R4969 C-CARBON R
RN72K1J-331JE
RN72K1J-331JE
RN72K1J-101JE
1 435033314R1
1 435033314R1
1 435031014R1
R4969 C-CARBON R RN72K1J-101JE 1 435031014R1
R4970 C-CARBON R
R4971 C-CARBON R
R4972 C-CARBON R
R4973 C-CARBON R
R4974 C-CARBON R
R4975 C-CARBON R
R4976 C-CARBON R
R4977 C-CARBON R
R4978 C-CARBON R
R4979 C-CARBON R
R4980 C-CARBON R
R4981 C-CARBON R
R4982 C-CARBON R
R4983 C-CARBON R
R6781 C-CARBON R
RN72K1J-181JE
RN72K1J-181JE
RN72K1J-181JE
RN72K1J-181JE
RN72K1J-101JE
RN72K1J-101JE
RN72K1J-105JE
RN72K1J-684JE
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-105JE
RN72K1J-684JE
RN72K1J-472JE
1 435031814R1
1 435031814R1
1 435031814R1
1 435031814R1
1 435031014R1
1 435031014R1
1 435031054R1
1 435036844R1
1 435031034R1
1 435031034R1
1 435031034R1
1 435031034R1
1 435031054R1
1 435036844R1
1 435034724R1
R6781 C-CARBON R RN72K1J-472JE 1 435034724R1
R6782 C-CARBON R
RN72K1J-104JE
1 435031044R1
R6782 C-CARBON R RN72K1J-104JE 1 435031044R1
R6783 C-CARBON R
RN72K1J-104JE
1 435031044R1
R6783 C-CARBON R RN72K1J-104JE 1 435031044R1
R6784 C-CARBON R
RN72K1J-472JE
1 435034724R1
R6784 C-CARBON R RN72K1J-472JE 1 435034724R1
R6785 C-CARBON R
RN72K1J-102JE
1 435031024R1
R6785 C-CARBON R RN72K1J-102JE 1 435031024R1
R6786 C-CARBON R
RN72K1J-471JE
1 435034714R1
R6786 C-CARBON R RN72K1J-471JE 1 435034714R1
R6788 C-CARBON R
RN72K1J-471JE
1 435034714R1
R6788 C-CARBON R RN72K1J-471JE 1 435034714R1
R6790 C-CARBON R
RN72K1J-471JE
1 435034714R1
R6790 C-CARBON R RN72K1J-471JE 1 435034714R1
R6792 C-CARBON R
RN72K1J-471JE
1 435034714R1
R6792 C-CARBON R RN72K1J-471JE 1 435034714R1
R6794 C-CARBON R
RN72K1J-471JE
1 435034714R1
R6794 C-CARBON R RN72K1J-471JE 1 435034714R1
R6796 C-CARBON R
RN72K1J-471JE
1 435034714R1
R6796 C-CARBON R RN72K1J-471JE 1 435034714R1
R6901 C-CARBON R
R6902 C-CARBON R
R6903 C-CARBON R
R6904 C-CARBON R
R6905 C-CARBON R
R6906 C-CARBON R
R6907 C-CARBON R
R6908 C-CARBON R
R6909 C-CARBON R
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-103JE
RN72K1J-102JE
RN72K1J-105JE
RN72K1J-105JE
RN72K1J-240F
RN72K1J-270JE
RN72K1J-240F
1 435031034R1
1 435031034R1
1 435031034R1
1 435031024R1
1 435031054R1
1 435031054R1
1 435032402R1
1 435032704R1
1 435032402R1
40/140 PAGE
Loading...
