An Ideal Launching Pad for Performance-Driven Home Theater

AV-3600

SILVER

TX-SR505

7.1-Channel A/V Surround Home Theater Receiver

• 160 W/Ch, continuous 6 Ω, 1 kHz, 1 channel driven, JEITA • DTS
Neo:6, DTS®96/24, Dolby®Digital EX™, Dolby®Pro Logic®IIx • 192 kHz/24-bit DACs for all
channels • HDTV-capable (50 MHz) component video switching (3 inputs and 1 output)

• H.C.P.S. (High Current Power Supply) massive high power transformer • WRAT (Wide Range
Amplifier Technology) • Advanced TI (Aureus
correct room acoustic problems and to calibrate speakers • 3 S-Video inputs and 2 outputs

• 4 digital inputs (2 optical and 2 coaxial) • A/V sync control function (up to 100 ms in 20 ms
steps) • Compatible with RI (Remote Interactive) Dock for the iPod

™

) 32-bit processing DSP chip • Audyssey 2EQ™to

®

-ES Discrete/Matrix, DTS

®

Home Theater Speakers

SKF-3600

2-Way Bass Reflex Speakers

• 8 cm cone woofer x 2 • 2.5 cm balanced-dome tweeter • Magnetically shielded • Max. input
power: 100 W • Frequency response: 55 Hz–35 kHz • WHD: 300 x 929 x 300 mm (with
speaker base), 104 x 913 x 138 mm (without speaker base) • 6.1 kg (with speaker base), 4.5 kg
(without speaker base)

SKS-3600

Center/Surround Speaker Package

Center Speaker

• 8 cm cone woofer x 2 • 2.5 cm balanced-dome tweeter • Wall-mounting capability

• Magnetically shielded • Max. input power: 100 W • Frequency response: 60 Hz–35 kHz

• WHD: 310 x 104 x 127 mm • 2.1 kg

Surround Speakers

• 8 cm cone woofer • 2.5 cm balanced-dome tweeter • Wall-mounting capability • Max. input
power: 100 W • Frequency response: 60 Hz–35 kHz • WHD: 104 x 169 x 127 mm • 1.1 kg

SKR-3600

Surround Back Speaker

• 8 cm cone woofer • 2.5 cm balanced-dome tweeter • Wall-mounting capability • Max. input
power: 100 W • Frequency response: 60 Hz–35 kHz • WHD: 104 x 169 x 127 mm • 1.1 kg

SL-107(S

)

Bass Reflex Powered Subwoofer

• Built-in 150 W amplifier • Auto-standby/On circuitry • 20 cm cone woofer • Aero Acoustic
Drive for powerful and natural sounding bass • Continuously variable crossover (50 Hz–200 Hz)

• Phase switch (0˚ or 180˚) • Speaker & line level inputs • Impedance: 65 kΩ (Line input),

1.2 kΩ (Speaker input) • Frequency response: 30 Hz–200 Hz • WHD: 230 x 435 x 401 mm

• 13.0 kg

TX-SR505, SKF-3600, SKS-3600,
SKR-3600, SL-107(S)

25

Do More with Your iPod—with Onkyo's Imaginative Sight and Sound

DS-A2X

DS-A2X

BLACKWHITE

Remote Interactive Dock

Superb Audio and Video Playback

Not just for music, but video and photos too

Control From Afar

Now with its own dedicated remote control

Charged and Ready to Go

Perfect as a charging station

Easier Viewing of Your Track Lists

Displays music track lists with information about
artists, albums, songs and genres

Remote Interactive (RI) Capabilities

Enables Auto Selector,Time Play/Sleep Timer,
Alarm functions

(September Issue 2005)

• WHD: 112 x 60 x 112 mm • 230 g

iPod Models Compatible with the DS-A2X (as of July 2007)

• 5th generation iPod • iPod nano • iPod photo • iPod mini

• 4th generation iPod with click wheel

(1st, 2nd and 3rd generation iPods are not supported.)

(iPod not included)

DS-A2

WHITE

Remote Interactive Dock

• WHD: 112 x 60 x 112 mm • 230 g

iPod Models Compatible with the DS-A2 (as of July 2006)

• 5th generation iPod • iPod nano • iPod photo • iPod mini

• 4th generation iPod with click wheel • 3rd generation iPod with
touch wheel

DS-A1

WHITE

Remote Interactive Dock

Control From Afar

RI-connectivity brings
effortless remote
control to your iPod’s
vast library of music—or digital
photos—without you having to budge
from the sofa.

Pristine Onkyo Playback

Put those earphones down
and give your iPod music a
turbo-boost.The DS-A1
provides the link to an
absorbing, room-filling sound
experience.

• Auto Selector Function • Time Play/Sleep Timer Function • Alarm
Function • JPEG Capable • All Cables Included (RI, S-Video, Audio,
Power) • WHD: 112 x 56 x 112 mm • 220 g

iPod Models Compatible with the DS-A1 (as of July 2006)

• 5th generation iPod • iPod nano • iPod photo • iPod mini • 4th
generation iPod with click wheel • 3rd generation iPod with touch wheel

(iPod not included)

Relive Those Magical Moments

Share those memorable
photos through your
home theater’s larger
display,by connecting your
photo-enabled iPod with the DS-A1.

Charged and Ready to Go

More than just a conduit to your
audio system, the DS-A1
also works as a charging
station. So, while you’re
powering up your favorite tunes, your
iPod’s powering up too.

26

iPod Accessory

GLOSSARY

DOLBY®TRUEHD

Dolby TrueHD is Dolby’s next-generation lossless
technology developed for high-definition disc-based
media. Dolby TrueHD audio is bit-for-bit identical to
the highest-resolution studio masters. Together with
high-definition video, it offers an unprecedented home theater experience.
Now listeners can enjoy sound as stunning as their high-definition pictures.
Dolby TrueHD is a mandatory standard for the HD DVD format and an
optional standard for Blu-ray Disc.

DOLBY®DIGITAL PLUS

Dolby Digital Plus provides the flexibility and efficiency
to deliver more channels of compelling surround
sound for high-definition video via cable and direct
broadcast satellite (DBS), via disc-based media, and via online content. The
superior coding efficiencies enable a high-quality multichannel audio
experience without negatively impacting bit budgets allocated for video
performance or additional feature sets.

DTS-HD®MASTER AUDIO

DTS-HD Master Audio is capable of delivering audio
that is bit-for-bit identical to the studio master.
DTS-HD Master Audio delivers audio at super-high
variable bit rates—24.5 mega-bits per second (Mbps) on Blu-ray Disc and

18.0 Mbps on HD DVD—that are significantly higher than on standard DVDs.
This bit stream is so fast, and the transfer rate so high, that it can deliver 7.1
audio channels that are identical to the studio master. With DTS-HD Master
Audio, you will be able to experience movies and music exactly as the artist
intended: clear, pure, and uncompromised.

DTS-HD®HIGH RESOLUTION AUDIO

DTS-HD High Resolution Audio can deliver up to

7.1 channels that are virtually indistinguishable from
the original. DTS-HD High Resolution Audio delivers
audio at high constant bit rates superior to those on standard DVDs—6.0
Mbps on Blu-ray Disc and 3.0 Mbps on HD DVD. It allows content creators
to deliver rich, high-definition audio on movies where disc space may not
allow for DTS-HD Master Audio.

CINEMAFILTER

The tonal balance of a film soundtrack can be
edgy and bright when played back over audio
equipment in your home—this is because film
soundtracks are designed to be played back in
large theaters, using commercial equipment. Onkyo has developed its own
solution that restores the correct tonal balance of a movie soundtrack in the
smaller environs of your home theater.

™

THEATER DIMENSIONAL

Onkyo's exclusive Theater Dimensional circuitry
takes the complexity out of conventional surround­sound set-ups and lets you experience the
excitement of surround sound from as few as two
ordinary speakers. Want more? Theater Dimensional's unique multi-speaker
modes let you place up to five speakers conveniently by the TV, for the most
realistic virtual-surround sound possible.

INTELLIVOLUME

More often than not, the components connected to your A/V receiver are
set at different volume levels.With IntelliVolume, you can customize the input
volume settings for all of the inputs connected to the A/V receiver.You can
vary the settings from -12dB to +12dB to achieve even levels when switching
from one component to another.

COLOR-CODED SPEAKER TERMINALS

These color-coded speaker terminals
take the guesswork out of matching
wires to the correct terminals. Simply
attach the color-coded label to the
speaker cable, and attach the cable to
the same-colored speaker terminal for
easy speaker connection.

MEETING THX™BENCHMARKS IN THX CERTIFICATION

From early design concepts to product rollout,
THX and Onkyo work together on selected A/V
receivers. Every detail is meticulously mapped to
THX performance standards: either THX™Ultra2™or THX™Select2™.THX
engineers spend countless hours testing and analyzing sound quality, usability
and interoperability. In addition, they perform qualitative evaluations on the
A/V receivers to ensure surround-sound presentations worthy of THX
certification.

OPTIMUM GAIN VOLUME CIRCUITRY

To produce volume at low levels, conventional amplifiers must initially drop a
signal close to the noise floor, permanently tainting it with a small amount of
noise. When amplified, both the signal and the unwanted noise are magnified.
Optimum Gain Volume Circuitry adjusts the gain so that less than half the
amount of attenuation is needed, ensuring the signal never comes close to
the noise floor.This protects the signal against noise, resulting in a dramatically
clearer sound.

PURE AUDIO MODE

Pure Audio Mode turns off the A/V receiver’s display and keeps video in the
digital domain (via HDMI) to ensure that the audio signal is protected against
interference from external circuitry.

CROSSOVER ADJUSTMENT

Depending on your choice of Onkyo A/V receiver, you can set the subwoofer
crossover at different frequencies. Being able to choose where the subwoofer
takes over bass-producing responsibilities from the front speakers gives you
more precise reproduction of movie soundtracks. It also means you can
select from a wider range of speaker packages, and match speakers with
differing crossover frequencies to your home theater system.

O

NKYOMICROFIBER

to heat. We then added an aramid layer to create New A-OMF.The evolution
has been taken a step further with A-OMF Monocoque—essentially sharing
the same material composition as New A-OMF but forming a single,
continuous cover over the cone.All four diaphragm types achieve improved
midrange clarity and imaging
for an astonishingly vivid,
natural sound.

(OMF),A-OMF & A-OMF M

Onkyo Micro Fiber (OMF), made from a pure
cotton weave to absorb vibrations, was first
developed to create a thick yet rigid diaphragm
that enables an extremely fast, accurate response.
The next stage saw the advent of A-OMF, which
incorporates a PEN (polyethylene naphthalate)
layer with a flexible cotton weave that makes
speaker cones even stronger and more resistant

ONOCOQUE

27

FEATURES

A/V RECEIVERS

HIGH-DEFINITION FEATURES

DOLBY®TRUEHD, DOLBY®DIGITAL PLUS
DTS-HD®MASTER AUDIO, DTS-HD®HIGH

RESOLUTION
HDMI VERSION
HDMI INPUTS/OUTPUTS
VIDEO PROCESSING
1080P VIDEO RESOLUTION
1080P VIDEO UPSCALING
RIHD

AMPLIFIER DESIGN

DUAL PUSH-PULL AMPLIFICATION
HIGH CURRENT LOW IMPEDANCE DRIVE
H.C.P.S.

IDE RANGE AMPLIFIER

WRAT (W
TECHNOLOGY)

VLSC (VECTOR LINEAR SHAPING CIRCUITRY)
NON-SCALING CONFIGURATION
192 kHZ/24-BIT AUDIO DACS
ALL DISCRETE OUTPUT STAGE CIRCUITRY
OPTIMUM GAIN VOLUME CIRCUITRY
BI-AMPING
BTL (BRIDGED TRANSLESS OR BRIDGING)

HOME THEATER/NETWORK
FEATURES

THX™CERTIFIED
ROOM CALIBRATION
NETWORK CONNECTIVITY
DTS®, DTS®-ES™DISCRETE/MATRIX,

DTS®NEO:6, DTS®96/24
DOLBY®DIGITAL, DOLBY®PRO LOGIC®IIX,

DOLBY®DIGITAL EX
HDMI UPCONVERSION
HDMI SWITCHING
COMPONENT VIDEO UPCONVERSION
COMPONENT V
COMPONENT VIDEO INPUTS/OUTPUT
32-BIT DSP CHIP
ZONE 2
ZONE 3
ON-SCREEN DISPLAY
CROSSOVER ADJUSTMENT
A/V SYNC
MULTICHANNEL INPUTS
AUDIO & A/V INPUTS
FRONT-PANEL VIDEO INPUT
S-VIDEO INPUTS/OUTPUTS
DIGITAL INPUTS
DIGITAL
USB PORT
i.LINK
PRE OUTS
SUBWOOFER PRE OUT

™

IDEO SWITCHING

OUTPUTS

OTHER FEATURES

HONO INPUT

P
HEADPHONE JACK
SPEAKER A/B DRIVE
RADIO TUNING
NEURAL-THX®SURROUND DECODER
PURE AUDIO MODE
INTELLIVOLUME
TONE CONTROL
DUAL BANANA PLUG-COMPATIBLE SPEAKER

POSTS
COLOR-CODED SPEAKER TERMINALS
RS232, IR, & 12V TRIGGER CONNECTIVITY
RI & iPOD DOCK CONNECTIVITY
RI REMOTE CONTROL
MACRO FUNCTION

OLOR

C

TX-NR1000

1.0
2/1

✓

✓

✓ (Toroidal)

✓

✓ (For all channels)

✓

®

Wolfson

✓
✓
✓
✓

✓ (Ultra2)

✓
✓

✓
✓

✓
✓
✓

4/2

✓
✓ (Audio/Video)
✓ (Audio/Video)

✓

✓

✓ (Up to 300 ms)

7.1 x 2
3/7

✓

7/4

7 Optical/6 Coaxial
2 Optical/2 Coaxial

✓

7 ch

✓ (2)

✓
✓
✓

Internet/FM/AM

✓
✓

7.1 ch

✓
✓

✓
✓

Prepro/Learning/Backlit

✓

Gold or Black

TX-NR905

✓
✓

1.3a
4/2

✓ (HQV Reon-VX)

✓
✓
✓

✓
✓

✓ (Toroidal)

✓

✓ (For all channels)

✓

Burr-Brown

✓
✓
✓
✓

✓ (Ultra2)

✓ (Audyssey MultEQ®XT)

✓
✓

✓
✓

✓
✓
✓

3/1

TI x 3

✓ (Audio/Video)

✓ (Audio)

✓
✓

✓ (Up to 250 ms)

7.1
2/6

✓

6/2

3 Optical/3 Coaxial

1 Optical

✓

7 ch

✓

✓
✓
✓

Internet/FM/AM

✓
✓
✓

7.1 ch

✓

(Customized, gold-plated)

✓
✓
✓

Prepro/Learning

✓

Gold or Silver

✓
✓

1.3a
4/1

✓ (HQV Reon-VX)

✓
✓
✓

✓
✓
✓
✓

✓ (For all channels)

✓

Burr-Brown

✓
✓
✓
✓

✓ (Ultra2)

✓ (Audyssey MultEQ®XT)

✓
✓
✓

✓
✓
✓

3/1

TI x 3

✓ (Audio/Video)

✓ (Audio)

✓
✓

✓ (Up to 250 ms)

7.1
2/6

✓

6/2

3 Optical/3 Coaxial

1 Optical

7 ch

✓

✓
✓

FM/AM

✓
✓
✓

7.1 ch

✓
✓

✓
✓

Prepro/Learning

✓

Gold or Silver

TX-SR805

✓
✓

1.3a
3/1

✓ (Faroudja DCDi Edge™)

✓

✓

✓
✓
✓
✓

✓

Burr-Brown

✓
✓
✓

✓ (Ultra2)

✓ (Audyssey MultEQ®XT)

✓
✓
✓

✓
✓
✓

3/1

TI x 3

✓ (Audio)
✓ (Audio)

✓
✓

✓ (Up to 250 ms)

7.1
2/6

✓

6/2

3 Optical/3 Coaxial

1 Optical

7 ch

✓

✓
✓

FM/AM

✓
✓
✓

7.1 ch

✓
✓

✓
✓

Prepro/Learning

✓

Gold or Silver

TX-SR705

✓
✓

1.3a
3/1

✓ (Faroudja DCDi Edge™)

✓

✓

✓
✓
✓

✓

Cirrus Logic

✓
✓
✓

✓ (Select2)

✓ (Audyssey MultEQ®XT)

✓
✓
✓

✓
✓
✓

3/1

TI x 3

✓ (Audio)

✓
✓

✓ (Up to 250 ms)

7.1
2/5

✓

5/2

3 Optical/3 Coaxial

1 Optical

7 ch

✓

✓
✓

FM/AM

✓
✓
✓

L/R

✓
✓

✓
✓

Prepro/Learning

✓

Gold, Black

or Silver

TX-SR605TX-SR875

✓
✓

1.3a
2/1

✓ (Faroudja DCDi Edge™)

✓

✓

✓
✓
✓

✓
✓
✓
✓
✓

✓ (Audyssey 2EQ™)

✓
✓
✓

✓
✓
✓

3/1

TI x 1

✓ (Audio)

✓
✓

✓ (Up to 100 ms)

7.1
2/5

✓

5/2

3 Optical/2 Coaxial

✓

✓

FM/AM

✓
✓

L/R

✓
✓

✓

Prepro

Gold, Black

or Silver

TX-SR505

✓

✓
✓
✓

✓
✓
✓
✓

✓ (Audyssey 2EQ™)

✓
✓

✓

3/1

TI x 1

✓

✓ (Up to 100 ms)

7.1
2/4

✓

3/2

2 Optical/2 Coaxial

✓

✓
✓

FM/AM

✓

L/R

✓

(Except SP-B)

✓

✓

Prepro

Gold, Black

or Silver

TX-SR304E

✓

✓

✓
✓

✓

(DTS®, Neo:6 5.1)

(Dolby®Digital,

Pro Logic®II)

✓

3/1

✓

✓

✓ (0/20/40 ms)

5.1
2/4

2 Optical/1 Coaxial

✓

✓
✓

FM/AM

L/R

✓

✓
✓

Silver

1

*

Discs that have not been properly finalized may only be partially playable or not playable at all. *2Channels are measured separately.

28

FEATURES

DVD/CD PLAYERS

THX™CERTIFIED
DVD-AUDIO PLAYBACK
SUPER AUDIO CD PLAYBACK
MP3 PLAYBACK
WMA PLAYBACK
DIVX®VIDEO PLAYABLE
CD-R/RW PLAYBACK CAPABILITY*
DVD-R/RW PLAYBACK CAPABILITY*
DTS®/DOLBY®DIGITAL AUDIO OUTPUT
DIRECT DIGITAL PATH
VLSC (VECTOR LINEAR SHAPING CIRCUITRY)
PROGRESSIVE SCAN (PAL/NTSC)
HD CONVERSION
HDMI OUTPUT
OPLUS®FLEXSCALE™VIDEO SCALING
i.LINK DIGITAL PORT
96 kHZ-48 kHZ SELECTABLE DIGITAL OUTPUT
COMPOSITE VIDEO OUTPUT
S-VIDEO OUTPUT
COMPONENT VIDEO OUTPUT
DIGITAL OUTPUTS
ANALOG AUDIO OUTPUT
RS232, IR & 12V CONNECTIVITY
AUDIO DAC
VIDEO DAC
VIDEO CIRCUIT ON/OFF CONTROL
DYNAMIC RANGE CONTROL
VIDEO BLACK LEVEL CONTROL
PROGRAMMED MEMORY PLAYBACK
MULTI-LANGUAGE ONSCREEN DISPLAY
COLOR

1

1

DV-SP1000

✓ (Ultra)

✓
✓
✓

✓
✓
✓

✓ (Dual)

✓
✓

✓
✓
✓

✓
✓ (2)
✓ (2)

2 (RCA/BNC)

2 Optical/2 Coaxial

✓

✓

192 kHz/24-Bit

216 MHz/14-Bit

✓

✓

✓

✓

✓

Gold or Black

DV-SP504

✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓

✓
✓
✓
✓

1 Optical/1 Coaxial

✓

192 kHz/24-Bit

108 MHz/14-Bit

✓
✓
✓
✓

Gold

HOME STYLE COMPONENTS DR-S501

RECEIVER SECTION

POWER OUTPUT*
DOLBY®DIGITAL
DTS®, DTS®96/24
HDMI VERSION
HDMI INPUTS/OUTPUTS
WRAT (WIDE RANGE AMPLIFIER TECHNOLOGY)
COMPONENT VIDEO OUTPUT
DIGITAL INPUTS
A/V INPUT
VIDEO OUTPUT
SUBWOOFER PRE OUT
PURE DIRECT MODE
AUDIO DAC
THEATER DIMENSIONAL
FM/AM RADIO PRESETS
RI & iPOD DOCK CONNECTIVITY
D

UALBANANAPLUG-COMPATIBLESPEAKERPOSTS

2

(

6 Ω, 1 kHz, JEITA

)

50 W/Ch

Pass-thru

1/1

1 Optical/ 1 Coaxial

192 kHz/24-Bit

DVD PLAYER SECTION

DVD-AUDIO PLAYBACK
SUPER AUDIO CD PLAYBACK
DIVX®VIDEO PLAYABLE
MP3 PLAYBACK
WMA PLAYBACK
PROGRESSIVE SCAN
VIDEO DAC

108 MHz/14-Bit

✓
✓

✓

1

2
1

✓
✓

✓

40

✓
✓

✓
✓
✓
✓
✓
✓

INTEGRATED AMPLIFIERS A-9755

2

(

TECHNOLOGY

IRECT MODE

RIVE

CD P

4 Ω, 1 kHz, JEITA

LAYERS

POWER OUTPUT*
VL DIGITAL
DISCRETE OUTPUT STAGE CIRCUITRY
AUDIO INPUTS/OUTPUTS
MAIN IN
PHONO INPUT
PURE D
SPEAKER A/B D
HEAVY-DUTY SPEAKER BINDING POSTS
HEADPHONE JACK
RI REMOTE CONTROL
COLOR

VLSC (VECTOR LINEAR SHAPING CIRCUITRY)
DIRECT DIGITAL PATH
SUPER HIGH-PRECISION CLOCK
MP3 PLAYBACK
DIGITAL OUTPUT ON/OFF
NUMBER OF REPEAT MODES
MEMORY PLAYBACK STEPS
SHUFFLE/RANDOM PLAY
DIGITAL OUTPUTS
ANALOG OUTPUT
HEADPHONE JACK WITH VOLUME CONTROL
RI REMOTE CONTROL
COLOR

)

DX-7555

1 Optical/1 Coaxial

300 W/Ch

✓

✓

6/2

✓

✓

✓

✓

✓

✓

✓

Gold

✓

✓

✓

✓

✓

4

25

By Remote

✓

✓

✓

Gold

A-9555

200 W/Ch

✓
✓

6/2

✓
✓
✓
✓
✓
✓

Gold

DX-7355

✓

✓

5

25

By Remote

1 Optical/1 Coaxial

✓
✓
✓

Gold or Black

A-9355

85 W/Ch

✓
✓

5/2

✓
✓
✓
✓
✓
✓

Gold or Black

29

SPECIFICATIONS

AMPLIFIER SECTION

1

Power Output*

Front L/R

Center

Surround L/R

Surround Back L/R

Video

FM
AM

2

Dynamic Power*

THD (Total Harmonic Distortion)
Damping Factor
Input Sensitivity and Impedance

Output Level and Impedance
Phono Overload
Frequency Response

Tone Control

Signal-to-Noise Ratio
Speaker Impedance

VIDEO SECTION

Input Sensitivity/Output Level and Impedance

Component Video Frequency Response

TUNER SECTION

Tuning Frequency Range

FM/AM Preset Memory

GENERAL

Power Supply

Power Consumption

Dimensions (W x H x D)
Weight

TX-NR1000

300 W + 300 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
250 W + 250 W (6 Ω, 1 kHz,
1 channel driven, IEC)
300 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
250 W (6 Ω, 1 kHz,
1 channel driven, IEC)
300 W + 300 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
250 W + 250 W (6 Ω, 1 kHz,
1 channel driven, IEC)
300 W + 300 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
250 W + 250 W (6 Ω, 1 kHz,
1 channel driven, IEC)

340 W (3 Ω, 2 ch)
260 W (4 Ω, 2 ch)
175 W (8 Ω, 2 ch)

0.05% (Rated power)
60 (Front, 1 kHz, 8 Ω)
200 mV/50 kΩ (Line)

2.5 mV/50 kΩ (Phono MM)
200 mV/470 Ω (Rec out)
120 mV (MM, 1 kHz, 0.5%)
5 Hz–100 kHz/+1 dB,

-3 dB (Direct mode)
±12 dB, 50 Hz (Bass)

±12 dB, 1 kHz (Mid)
±12 dB, 20 kHz (Treble)

95 dB (Line, IHF-A)
4 Ω–16 Ω or 6 Ω–16 Ω

1 Vp-p/75 Ω (Component and
S-Video Y)

0.7 Vp-p/75 Ω (Component P
P

R/CR)

0.28 Vp-p/75 Ω (S-Video C)
1 Vp-p/75 Ω (Composite)

5 Hz–100 MHz (-3 dB)

87.5 MHz–108 MHz
522 kHz–1,611 kHz
530 kHz–1,710 kHz

40 stations

AC 120 V, 60 Hz
AC 220–230 V, 50 Hz

1,200 W

435 x 220 x 480.5 mm

33.0 kg

280 W + 280 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
220 W + 220 W (6 Ω, 1 kHz,
1 channel driven, IEC)
280 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
220 W (6 Ω, 1 kHz,
1 channel driven, IEC)
280 W + 280 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
220 W + 220 W (6 Ω, 1 kHz,
1 channel driven, IEC)
280 W + 280 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
220 W + 220 W (6 Ω, 1 kHz,
1 channel driven, IEC)

400 W (3 Ω, 1 ch)
300 W (4 Ω, 1 ch)
180 W (8 Ω, 1 ch)

0.05% (Rated power)
60 (Front, 1 kHz, 8 Ω)
200 mV/47 kΩ (Line)

2.5 mV/47 kΩ (Phono MM)
200 mV/470 Ω (Rec out)
70 mV (MM, 1 kHz, 0.5%)
5 Hz–100 kHz/+1 dB,

-3 dB (Direct mode)
±10 dB, 20 Hz (Bass)

±10 dB, 20 kHz (Treble)
110 dB (Line, IHF-A)
4 Ω–16 Ω or 6 Ω–16 Ω

1 Vp-p/75 Ω (Component and
S-Video Y)

0.7 Vp-p/75 Ω (Component P

B/CB,

P

R/CR)

0.28 Vp-p/75 Ω (S-Video C)
1 Vp-p/75 Ω (Composite)

5 Hz–100 MHz (-3 dB)

87.5 MHz–108 MHz
522 kHz–1,611 kHz
530 kHz–1,710 kHz

40 stations

AC 120 V, 50/60 Hz
AC 220–240 V, 50/60 Hz

1,000 W

435 x 194 x 458.5 mm

24.3 kg

TX-SR875 TX-SR805TX-NR905 TX-SR705 TX-SR605A/V RECEIVERS

250 W + 250 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
200 W + 200 W (6 Ω, 1 kHz,
1 channel driven, IEC)
250 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
200 W (6 Ω, 1 kHz,
1 channel driven, IEC)
250 W + 250 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
200 W + 200 W (6 Ω, 1 kHz,
1 channel driven, IEC)
250 W + 250 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
200 W + 200 W (6 Ω, 1 kHz,
1 channel driven, IEC)

320 W (3 Ω, 1 ch)
270 W (4 Ω, 1 ch)
160 W (8 Ω, 1 ch)

0.05% (Rated power)
60 (Front, 1 kHz, 8 Ω)
200 mV/47 kΩ (Line)

2.5 mV/47 kΩ (Phono MM)
200 mV/470 Ω (Rec out)
70 mV (MM, 1 kHz, 0.5%)
5 Hz–100 kHz/+1 dB,

-3 dB (Direct mode)

—

±10 dB, 20 Hz (Bass)

±10 dB, 20 kHz (Treble)
110 dB (Line, IHF-A)
4 Ω–16 Ω or 6 Ω–16 Ω

1 Vp-p/75 Ω (Component and
S-Video Y)

0.7 Vp-p/75 Ω (Component P

B/CB,

P

R/CR)

0.28 Vp-p/75 Ω (S-Video C)
1 Vp-p/75 Ω (Composite)

5 Hz–100 MHz (-3 dB)

87.5 MHz–108 MHz
522 kHz–1,611 kHz
530 kHz–1,710 kHz

40 stations

AC 120 V, 50/60 Hz
AC 220–240 V, 50/60 Hz

870 W

435 x 194 x 458.5 mm

23.3 kg

—

230 W + 230 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
180 W + 180 W (6 Ω, 1 kHz,
1 channel driven, IEC)
230 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
180 W (6 Ω, 1 kHz,
1 channel driven, IEC)
230 W + 230 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
180 W + 180 W (6 Ω, 1 kHz,
1 channel driven, IEC)
230 W + 230 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
180 W + 180 W (6 Ω, 1 kHz,
1 channel driven, IEC)

300 W (3 Ω, 1 ch)
250 W (4 Ω, 1 ch)
150 W (8 Ω, 1 ch)

0.05% (Rated power)
60 (Front, 1 kHz, 8 Ω)
200 mV/47 kΩ (Line)

2.5 mV/47 kΩ (Phono MM)
200 mV/470 Ω (Rec out)
70 mV (MM, 1 kHz, 0.5%)
5 Hz–100 kHz/+1 dB,

-3 dB (Direct mode)
±10 dB, 20 Hz (Bass)

±10 dB, 20 kHz (Treble)
110 dB (Line, IHF-A)
4 Ω–16 Ω or 6 Ω–16 Ω

1 Vp-p/75 Ω (Component and
S-Video Y)

0.7 Vp-p/75 Ω (Component P

B/CB,

P

R/CR)

0.28 Vp-p/75 Ω (S-Video C)
1 Vp-p/75 Ω (Composite)

5 Hz–100 MHz (-3 dB)

87.5 MHz–108 MHz
522 kHz–1,611 kHz
530 kHz–1,710 kHz

40 stations

AC 120 V, 50/60 Hz
AC 220–240 V, 50/60 Hz

870 W

435 x 194 x 458.5 mm

23.3 kg

—

175 W + 175 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
160 W + 160 W (6 Ω, 1 kHz,
1 channel driven, IEC)
175 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
160 W (6 Ω, 1 kHz,
1 channel driven, IEC)
175 W + 175 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
160 W + 160 W (6 Ω, 1 kHz,
1 channel driven, IEC)
175 W + 175 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
160 W + 160 W (6 Ω, 1 kHz,
1 channel driven, IEC)

240 W (3 Ω, 1 ch)
210 W (4 Ω, 1 ch)
120 W (8 Ω, 1 ch)

0.08% (Rated power)
60 (Front, 1 kHz, 8 Ω)
200 mV/47 kΩ (Line)

2.5 mV/47 kΩ (Phono MM)
200 mV/470 Ω (Rec out)
70 mV (MM, 1 kHz, 0.5%)
5 Hz–100 kHz/+1 dB,

-3 dB (Direct mode)
±10 dB, 50 Hz (Bass)

±10 dB, 20 kHz (Treble)
106 dB (Line, IHF-A)
4 Ω–16 Ω or 6 Ω–16 Ω

1 Vp-p/75 Ω (Component and
S-Video Y)

0.7 Vp-p/75 Ω (Component P

B/CB,

P

R/CR)

0.28 Vp-p/75 Ω (S-Video C)
1 Vp-p/75 Ω (Composite)

5 Hz–50 MHz (-3 dB)

87.5 MHz–108 MHz
522 kHz–1,611 kHz
530 kHz–1,710 kHz

40 stations

AC 120 V, 50/60 Hz
AC 220–240 V, 50/60 Hz

600 W

435 x 174 x 377 mm

12.8 kg

—

175 W + 175 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
140 W + 140 W (6 Ω, 1 kHz,
1 channel driven, IEC)
175 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
140 W (6 Ω, 1 kHz,
1 channel driven, IEC)
175 W + 175 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
140 W + 140 W (6 Ω, 1 kHz,
1 channel driven, IEC)
175 W + 175 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
140 W + 140 W (6 Ω, 1 kHz,
1 channel driven, IEC)

210 W (3 Ω, 1 ch)
180 W (4 Ω, 1 ch)
110 W (8 Ω, 1 ch)

0.08% (Rated power)
60 (Front, 1 kHz, 8 Ω)
200 mV/47 kΩ (Line)

200 mV/470 Ω (Rec out)

5 Hz–100 kHz/+1 dB,

-3 dB (Direct mode)
±10 dB, 50 Hz (Bass)

±10 dB, 20 kHz (Treble)
106 dB (Line, IHF-A)
4 Ω–16 Ω or 6 Ω–16 Ω

1 Vp-p/75 Ω (Component and
S-Video Y)

0.7 Vp-p/75 Ω (Component P

B/CB,

P

R/CR)

0.28 Vp-p/75 Ω (S-Video C)
1 Vp-p/75 Ω (Composite)

5 Hz–50 MHz (-3 dB)

87.5 MHz–108 MHz
522 kHz–1,611 kHz
530 kHz–1,710 kHz

40 stations

AC 120/220–240 V, 50/60 Hz
AC 220–230 V, 50/60 Hz

630 W

435 x 174 x 377 mm

11.5 kg

—

—

B/CB,

A/V RECEIVERS

AMPLIFIER SECTION

1

Power Output*

Front L/R

Center

Surround L/R

Surround Back L/R

Video

UNER SECTION

FM
AM

2

Dynamic Power*

THD (Total Harmonic Distortion)
Damping Factor
Input Sensitivity and Impedance

Output Level and Impedance
Phono Overload
Frequency Response

Tone Control

Signal-to-Noise Ratio
Speaker Impedance

VIDEO SECTION

Input Sensitivity/Output Level and Impedance

Component Video Frequency Response

T

Tuning Frequency Range

FM/AM Preset Memory

GENERAL

Power Supply

Power Consumption

Dimensions (W x H x D)
Weight

TX-SR505

160 W + 160 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
130 W + 130 W (6 Ω, 1 kHz,
1 channel driven, IEC)
160 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
130 W (6 Ω, 1 kHz,
1 channel driven, IEC)
160 W + 160 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
130 W + 130 W (6 Ω, 1 kHz,
1 channel driven, IEC)
160 W + 160 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
130 W + 130 W (6 Ω, 1 kHz,
1 channel driven, IEC)

180 W (3 Ω, 1 ch)
160 W (4 Ω, 1 ch)
100 W (8 Ω, 1 ch)

0.08% (Rated power)
60 (Front, 1 kHz, 8 Ω)
200 mV/47 kΩ (Line)

200 mV/470 Ω (Rec out)

5 Hz–100 kHz/+1 dB,

-3 dB (Direct mode)
±10 dB, 50 Hz (Bass)

±10 dB, 20 kHz (Treble)
100 dB (Line, IHF-A)
4 Ω–16 Ω or 6 Ω–16 Ω

1 Vp-p/75 Ω (Component and
S-Video Y)

0.7 Vp-p/75 Ω (Component P
P

0.28 Vp-p/75 Ω (S-Video C)
1 Vp-p/75 Ω (Composite)

5 Hz–50 MHz (-3 dB)

87.5 MHz–108 MHz
522 kHz–1,611 kHz
530 kHz–1,710 kHz

40 stations

AC 120/220–240 V, 50/60 Hz
AC 220 V, 50/60 Hz

510 W
560 W

435 x 150 x 377 mm

10.5 kg/10.2 kg

—

—

R/CR)

TX-SR304E

120 W + 120 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
100 W + 100 W (6 Ω, 1 kHz,
1 channel driven, IEC)
120 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
100 W (6 Ω, 1 kHz,
1 channel driven, IEC)
120 W + 120 W (6 Ω, 1 kHz,
1 channel driven, JEITA)
100 W + 100 W (6 Ω, 1 kHz,
1 channel driven, IEC)

160 W (3 Ω, 1 ch)
125 W (4 Ω, 1 ch)
85 W (8 Ω, 1 ch)

0.9% (Rated power)
60 (Front, 1 kHz, 8 Ω)
200 mV/47 kΩ (Line)

200 mV/470 Ω (Rec out)

10 Hz–50 kHz/+1 dB,

-3 dB (Direct mode)
±10 dB, 80 Hz (Bass)

±10 dB, 20 kHz (Treble)
100 dB (Line, IHF-A)
6 Ω–16 Ω

1 Vp-p/75 Ω (Component)

0.7 Vp-p/75 Ω (Component P
P

B/CB,

R/CR)

1 Vp-p/75 Ω (Composite)

5 Hz–50 MHz

87.5 MHz–108 MHz
522 kHz–1,611 kHz

30 stations

AC 230–240 V, 50 Hz

220 W

435 x 150 x 369 mm

8.4 kg

Linear Velocity

Single layer
Dual layer

Frequency Range (Digital Audio

DVD-Audio
DVD Linear Sound

Audio CD

S/N Ratio (Digital Audio
Audio Dynamic Range (Digital Audio

—

THD (Digital Audio)(1 kHz
Wow and Flutter

)

)

)

Composite Video Output

S-Video Output

—

—

B/CB,

Component Video Output

Audio Output

Digital (Optical)
Digital (Coaxial)
Analog Audio

Power Consumption
Dimensions (W x H x D
Weight
Supplied Accessories

)

DV-SP1000

3.49 m/s

3.84 m/s

4 Hz-88 kHz (192 kHz)
4 Hz-44 kHz (96 kHz),
4 Hz-22 kHz (48 kHz)
4 Hz-20 kHz (44.1 kHz)

118 dB

)

100 dB

0.001 %
Below threshold of

measurability

1.0 V p-p, 75 Ω,
negative sync.
(Y)

1.0 V p-p 75 Ω,

(C)

0.286 V p-p 75 Ω,
negative sync.,
Mini DIN 4-pin
(Y)

1.0 V p-p, 75 Ω,
(

)/(

)

P

P

0.7 V p-p, 75 Ω

B

R

-

22.5 dBm x 2

0.5 V p-p, 75 Ω, pin jack x 2

2.0 V RMS, 320 Ω,
pin jack (5.1 ch)x 1,
pin jack (L/R)x 2

48 W
435 x 123 x 374 mm

12.1 kg
Audio/Video cable x 1,

S-Video cable x 1,
Remote control (RC-563DV)x 1,
HDMI cable x 1, i.LINK cable x 1

DV-SP504DVD PLAYERS

3.49 m/s

3.84 m/s

4 Hz-88 kHz (192 kHz)
4 Hz-44 kHz (96 kHz),
4 Hz-22 kHz (48 kHz)
4 Hz-20 kHz (44.1 kHz)

106 dB
96 dB

0.003 %
Below threshold of

measurability

1.0 V p-p, 75 Ω, negative
sync.
(Y)

1.0 V p-p, 75 Ω,

(C)

0.286 V p-p, 75 Ω,
negative sync.,
Mini DIN 4-pin
(Y)

1.0 V p-p, 75 Ω,
(

)/(

)

P

P

0.7 V p-p, 75 Ω

B

R

-

22.5 dBm x 1

0.5 V p-p, 75 Ω, pin jack x 1

2.0 V RMS, 440 Ω,
pin jack (5.1 ch)x 1,

)

pin jack (L/R
17 W
435 x81 x309 mm

3.7 kg
Audio/Video cable x1,

Coaxial cable x 1,
Remote control (RC-657DV

x

1

)

x

1

1

*

Channels are measured separately. *2Calculated on basis of IHF Dynamic headroom.

30

SPECIFICATIONS

HOME STYLE/MINI COMPONENTS

RECEIVER SECTION

AMPLIFIER SECTION

Power Output*
THD (Rated Power/1 W Output
Frequency Response
S/N Ratio

TUNER SECTION

Tuning Frequency Range

FM/AM Preset Memory

1

(

4 Ω, 1 kHz, JEITA

FM
AM

)

)

DVD/CD SECTION

Linear Velocity

Single Layer/Dual Layer

Frequency Range (Digital Audio

DVD-Audio
DVD Linear Sound

Audio CD

Wow and Flutter
Composite Video Output

S-Video Output

Component Video Output

GENERAL

Power Consumption
Dimensions (W x H x D
Weight
Supplied Accessories

1

(

Power Output*
Dynamic Power*

4 Ω/8 Ω

THD (1 kHz
Damping Factor (8 Ω, 1 kHz
Sensitivity and Impedance

Phono MM
CD, Tuner, Tape
Rec Out

Tone Controls

Bass
Treble
Loudness

Frequency Response
S/N Ratio (IHF-A

Phono MM
CD

Phono Overload (MM 1 kHz 0.5%
Dimensions (W x H x D
Weight

4 Ω, 1 kHz, JEITA

2

)

)

)

)

)

)

)

)

CD PLAYERS

Frequency Response
S/N Ratio
Dynamic Range

)

THD (1 kHz
Wow and Flutter
Dimensions (W x H x D
Weight

)

DR-S501

50 W/Ch (6 Ω)

0.9 %/0.08 %
10 Hz-100 kHz (±3 dB
100 dB (IHF-A

87.5 MHz–108 MHz
522 kHz–1,611 kHz
530 kHz–1,710 kHz

40 stations

3.49 m/s/3.84 m/s

4 Hz-88 kHz (192 kHz
4 Hz-44 kHz (96 kHz),
4 Hz-22 kHz (48 kHz
4 Hz-20 kHz (44.1 kHz

Below threshold of measurability

1.0 V p-p, 75 Ω,
negative sync.

(Y)

1.0 V p-p, 75 Ω,

(

)/(

P

P

B

R

115 W
435 x 90 x 415 mm

8.6 kg
Video cable x 1,

Remote control (RC-704S)x 1

)

—

)

0.7 V p-p, 75 Ω

)

)

)

)

A-9755INTEGRATED AMPLIFIERS

300 W/Ch

270 W/Ch/170 W/Ch

0.08 %
25

)

2.5 mV (50 kΩ
)

200 mV (50 kΩ

)

200 mV (2.2 kΩ

±

10 dB at 100 Hz

±

10 dB at 20 kHz

+

10 dB at 50 Hz/+2 dB at 10 kHz

10 Hz-60 kHz (+ 1 dB, - 3 dB

70 dB
100 dB

70 mV
435 x 144 x 431 mm

17.6 kg

)

DX-7555

2 Hz-20 kHz
111 dB
100 dB

0.0027 %

Below threshold of measurability
435 x 111 x 405 mm

8.0 kg

DR-UN7

26 W/Ch

5.0 %/0.4 %
10 Hz-100 kHz (±3 dB
100 dB (IHF-A

87.5 MHz–108 MHz
522 kHz–1,611 kHz
530 kHz–1,710 kHz

30 stations

3.49 m/s/3.84 m/s

4 Hz-88 kHz (192 kHz
4 Hz-44 kHz (96 kHz),
4 Hz-22 kHz (48 kHz
4 Hz-20 kHz (44.1 kHz

Below threshold of measurability

1.0 V p-p, 75 Ω,
negative sync.
(Y)

0.7 V p-p, 75 Ω,

(C)

0.286 V p-p, 75 Ω,

negative sync.,
Mini DIN 4-pin
(Y)

1.0 V p-p, 75 Ω,

(

)/(

)

P

P

B

R

79 W
205 x 147 x 353 mm

5.4 kg
Video cable x 1,

Remote control (RC-640S)x 1

)

)

)

0.7 V p-p, 75 Ω

)

)

A-9555

200 W/Ch

200 W/Ch/120 W/Ch

0.08 %
25

)

2.5 mV (50 kΩ
)

200 mV (50 kΩ

)

200 mV (2.2 kΩ

±

10 dB at 100 Hz

±

10 dB at 20 kHz

+

10 dB at 50 Hz/+2 dB at 10 kHz

10 Hz-60 kHz (+ 1 dB, - 3 dB

70 dB
100 dB

70 mV
435 x 148 x 431 mm

13.0 kg

)

DX-7355

4 Hz-20 kHz
106 dB
100 dB

0.0029 %
Below threshold of measurability
435 x 81 x 315 mm

4.4 kg

CR-B8

26 W/Ch

0.4 %/—
10 Hz-100 kHz (±3 dB
100 dB (IHF-A

87.5 MHz–108 MHz
522 kHz–1,611 kHz
530 kHz–1,710 kHz

30 stations

10 Hz-20 kHz (44.1 kHz

68 W
155 x 241 x 354 mm

4.6 kg
Remote control (RC-628S)x 1

)

)

—

—
—
—

) (CD)

—
—

—

—

A-9355

85 W/Ch

75 W/Ch/38 W/Ch

0.08 %
60

)

2.5 mV (50 kΩ
)

200 mV (50 kΩ

)

200 mV (2.2 kΩ

±

10 dB at 100 Hz

±

10 dB at 10 kHz

+

8 dB at 100 Hz/+4 dB at 10 kHz

10 Hz-60 kHz (+ 1 dB, - 3 dB

70 dB
100 dB

70 mV
435 x 124 x 344 mm

7.3 kg

)

HOME THEATER SYSTEMS

AMPLIFIER S

Power Output*
Dynamic Power*24 Ω/8 Ω(Front
THD (Rated Power
Frequency Response

Damping Factor
S/N Ratio
Tone Control

TUNER SECTION

Tuning Range

Usable Sensitivity

S/N Ratio

THD

FM Stereo Separation

GENERAL

Dimensions (W xH xD
Weight

ECTION

1

(

6 Ω, 1 kHz, JEITA

)

Bass/Treble

FM
AM

FM Mono
FM Stereo
AM

FM Mono/ FM Stereo/ AM

FM Mono/ FM Stereo/ AM

)

SPEAKERS

Speaker Type

Front
Center
Surround
Subwoofer

Drivers

Front

Center

Surround
Subwoofer

Frequency Response

Front
Center
Surround
Subwoofer

Output Sound Pressure Level

Front
Center
Surround
Subwoofer

Max. Input Power

Front
Center
Surround
Subwoofer

Nominal Impedance

Front
Center
Surround
Subwoofer

GENERAL

Dimensions (W x H x D

Front
Center
Surround
Subwoofer

Weight

Front
Center
Surround
Subwoofer

)

HT-SR600

)

120 W/Ch

)

140 W/Ch/ 95 W/Ch

0.9 %
10 Hz-50 kHz/ +1 dB,

-3 dB (Direct mode)
60 (Front, 1 kHz, 8 Ω)
100 dB (Line, IHF-A)

±

10 dB at 80 Hz/±10 dB at 20 kHz

87.5 to 108.0 MHz
530/522 to 1710/1611 kHz

15.2 dBf (75 Ω IHF

22.2 dBf (75 Ω IHF
300 µV

73 dB (IHF-A)/67 dB (IHF-A)/40 dB

0.3 %/ 0.5 %/ 0.7 %
40 dB at 1 kHz

435 x150 x369 mm

9.6 kg

2-Way, Bass Reflex
2-Way, Bass Reflex
Full-Range, Bass Reflex
Bass Reflex Passive

8 cm Cone Woofer,
2 cm Ceramic Tweeter
8 cm Cone Woofer,
2 cm Ceramic Tweeter
8 cm Cone
20 cm Cone

100 Hz-22 kHz
100 Hz-22 kHz
110 Hz-22 kHz
30 Hz-150 Hz

85 dB/W/m
85 dB/W/m
83 dB/W/m
84 dB/W/m

120 W
120 W
120 W
130 W

6 Ω
6 Ω
6 Ω
6 Ω

101 x 273 x 115 mm
273 x 101 x 102 mm
101 x 175 x 111 mm
230 x 425 x 372 mm

1.0 kg

1.0 kg

0.7 kg

6.7 kg

)
)

31

Onkyo Corporation

2-1 Nisshin-cho, Neyagawa-shi, Osaka 572-8540, JAPAN
Tel: [phone] Fax:[phone] http://www.onkyo.com/

Onkyo China Limited

Unit 1 & 12, 9/F, Ever Gain PlazaTower 1, 88, Container Port Road,
Kwai Chung, N.T., Hong Kong.
Tel: [phone] Fax:[phone] http://www.ch.onkyo.com/

Onkyo U.S.A. Corporation

18 Park Way, Upper Saddle River, N.J.07458, U.S.A.
Tel: [phone] Fax:[phone] http://www.onkyousa.com/

Onkyo Europe Electronics GmbH

Liegnitzerstrasse 6, 82194 Grobenzell, GERMANY
Tel: [phone] Fax:[phone] http://www.eu.onkyo.com/

Catalog No. 07C13

Export

GB

Printed in Japan
01-0709-30.2K-DT

Due to a policy of continuous product improvement, Onkyo reserves the right to change specifications and appearance
without notice.

THX, THX Ultra2, THX Select2, THX Ultra and THX Surround are trademarks of THX Ltd. THX may be registered in some
jurisdictions. All rights reserved.

THX Surround EX/Dolby Digital Surround EX is a joint development of Dolby Laboratories and THX Ltd.

Dolby, Pro Logic, Surround EX, TrueHD and the double-D symbol are trademarks of Dolby Laboratories.

Dolby Virtual Speaker and Dolby Headphone are trademarks of Dolby Laboratories.

DTS is a registered trademark & the DTS logos and Symbol are trademarks of DTS, Inc.

HQV is a registered trademark of Silicon Optix.

Manufactured under license from Audyssey Laboratories. U.S. and foreign patents pending. MultEQ XT is a trademark of
Audyssey Laboratories. 2EQ is a trademark of Audyssey Laboratories.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

Aureus is a trademark of Texas Instruments.

The Neural Surround name and related logos are trademarks owned by Neural Audio Corporation.

iPod is a trademark of Apple Inc., registered in the U.S. and other countries.

Faroudja DCDi Edge is a registered trademark of Genesis Microchip Inc.

The PlaysForSure logo, Windows Media and the Windows logo are trademarks or registered trademarks of Microsoft
Corporation in the United States and/or other countries.

NSV is a trademark of Analog Devices, Inc.

®

DivX

is a registered trademark of DivX, Inc.

Theater Dimensional, CinemaFILTER, Net-Tune, OR-EQ, VLSC, and OMF are trademarks of Onkyo Corporation.

All other trademarks and registered trademarks are the property of their respective holders.
