Onkyo 29344937 User Manual

7.1ch Home Theater System

HT-S6200

Contents

Introduction ...................................2

Connection ..................................19

AV Receiver (HT-R670) Speaker Package (HTP-670)

Front Speakers (SKF-670) Center Speaker (SKC-670) Surround Speakers (SKR-670) Surround Back Speakers (SKB-670) Powered Subwoofer (SKW-770)

Dock for iPod (UP-A1)

Instruction Manual

Thank you for purchasing an Onkyo 7.1ch Home Theater System. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new 7.1ch Home Theater System. Please retain this manual for future reference.

Turning On & First Time Setup

Basic Operations.........................49

Using the Listening Modes ........61

Advanced Setup ..........................68

Zone 2

...........................................80

Controlling Other Components

Others...........................................93

...40

...84

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12.

Use only with the cart, stand,

PORTABLE CART WARNIN

tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to

S3125A

avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to

persons. The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

AVIS

RISQUE DE CHOC ELECTRIQUE

NE PAS

OUVRIR

15. Damage Requiring Service Unplug the apparatus from the wall outlet and refer servicing to qualified service personnel under the following conditions: A. When the power-supply cord or plug is dam-

aged,

B. If liquid has been spilled, or objects have fallen

into the apparatus,

C. If the apparatus has been exposed to rain or

water,

D. If the apparatus does not operate normally by

following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the apparatus to its normal operation,

E. If the apparatus has been dropped or damaged in

any way, and

F. When the apparatus exhibits a distinct change in

performance this indicates a need for service.

16. Object and Liquid Entry Never push objects of any kind into the apparatus through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases shall be placed on the apparatus. Don’t put candles or other burning objects on top of this unit.

17. Batteries Always consider the environmental issues and follow local regulations when disposing of batteries.

18. If you install the apparatus in a built-in installation, such as a bookcase or rack, ensure that there is adequate ventilation.

Leave 20 cm (8") of free space at the top and sides and 10 cm (4") at the rear. The rear edge of the shelf or board above the apparatus shall be set 10 cm (4") away from the rear panel or wall, creating a fluelike gap for warm air to escape.

Precautions

1. Recording Copyright—Unless it’s for personal use only, recording copyrighted material is illegal without the permission of the copyright holder.

2. AC Fuse—The AC fuse inside the unit is not userserviceable. If you cannot turn on the unit, contact your Onkyo dealer.

3. Care—Occasionally you should dust the unit all over with a soft cloth. For stubborn stains, use a soft cloth dampened with a weak solution of mild detergent and water. Dry the unit immediately afterwards with a clean cloth. Don’t use abrasive cloths, thinners, alcohol, or other chemical solvents, because they may damage the finish or remove the panel lettering.

4. Power WARNING

BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME, READ THE FOLLOWING SECTION CAREFULLY. AC outlet voltages vary from country to country. Make sure that the voltage in your area meets the voltage requirements printed on the unit’s rear panel (e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz).

The power cord plug is used to disconnect this unit from the AC power source. Make sure that the plug is readily operable (easily accessible) at all times.

For North American model Pressing the [ON/STANDBY] button to select Standby mode does not fully shutdown the unit. If you do not intend to use the unit for an extended period, remove the power cord from the AC outlet.

5. Preventing Hearing Loss Caution

Excessive sound pressure from earphones and headphones can cause hearing loss.

6. Batteries and Heat Exposure War nin g

Batteries (battery pack or batteries installed) shall not be exposed to excessive heat as sunshine, fire or the like.

7. Never Touch this Unit with Wet Hands—Never handle this unit or its power cord while your hands are wet or damp. If water or any other liquid gets inside this unit, have it checked by your Onkyo dealer.

8. Handling Notes

• If you need to transport this unit, use the original

packaging to pack it how it was when you originally bought it.

• Do not leave rubber or plastic items on this unit

for a long time, because they may leave marks on the case.

• This unit’s top and rear panels may get warm

after prolonged use. This is normal.

• If you do not use this unit for a long time, it may

not work properly the next time you turn it on, so be sure to use it occasionally.

For U.S. models

FCC Information for User

CAUTION:

The user changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

For Canadian Models

NOTE: THIS CLASS B DIGITAL APPARATUS

COMPLIES WITH CANADIAN ICES-003. For models having a power cord with a polarized plug:

CAUTION: TO PREVENT ELECTRIC SHOCK,

MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

Modèle pour les Canadien

REMARQUE: CET APPAREIL NUMÉRIQUE DE

LA CLASSE B EST CONFORME À LA NORME NMB-003 DU CANADA.

Sur les modèles dont la fiche est polarisée:

AT TE NT IO N : POUR ÉVITER LES CHOCS ÉLEC-

TRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

Speaker Precautions

Package Contents

Placement

• The subwoofer cabinet is made out of wood and is therefore sensitive to extreme temperatures and humidity, do not put it in locations subject to direct sunlight or in humid places, such as near an air conditioner, humidifier, bathroom, or kitchen.

• Do not put water or other liquids close to the speakers. If liquid is spilled over the speakers, the drive units may be damaged.

• Speakers should only be placed on sturdy, flat surfaces that are free from vibration. Putting them on uneven or unstable surfaces, where they may fall and cause damage, will affect the sound quality.

• Subwoofer is designed to be used in the upright vertical position only. Do not use it in the horizontal or tilted position.

• If the unit is used near a turntable, CD player or DVD/ BD player, howling or slipping of sound may occur. To prevent this, move the unit away from the turntable, CD player or DVD/BD player, otherwise lower the unit’s output level.

Using Close to a TV or Computer

TVs and computer monitors are magnetically sensitive devices and as such are likely to suffer discoloration or picture distortion when conventional speakers are placed nearby. In such situations, try moving the speakers away from your TV or monitor. If discoloration should occur, turn off your TV or monitor, wait 15 to 30 minutes, and then turn it back on again. This normally activates the degaussing function, which neutralizes the magnetic field, thereby removing any discoloration effects. Note that discoloration can also be caused by a magnet or demagnetizing tool that’s too close to your TV or monitor.

Make sure you have the following items:

AV receiver HT-R670

HT-R670

Remote controller and two batteries (AA/R6)

Speaker setup microphone

Indoor FM antenna

Input Signal Warning

The speakers can handle the specified input power when used for normal music reproduction. If any of the following signals are fed to them, even if the input power is within the specified rating, excessive current may flow in the speaker coils, causing burning or wire breakage:

1. Interstation noise from an untuned FM radio.

2. Sound from fast-forwarding a cassette tape.

3. High-pitched sounds generated by an oscillator,

electronic musical instrument, and so on.

4. Amplifier oscillation.

5. Special test tones from audio test CDs and so on.

6. Thumps and clicks caused by connecting or discon-

necting audio cables (always turn off your amplifier before connecting or disconnecting cables).

7. Microphone feedback.

AM loop antenna

* In catalogs and on packaging, the letter at the end of the product

name indicates the color. Specifications and operation are the same regardless of color.

Package Contents—Continued

Speaker Package HTP-670

Front speakers (SKF-670)

Center speaker (SKC-670)

Surround speakers (SKR-670)

Surround back speakers (SKB-670)

Powered Subwoofer (SKW-770)

28 rubber stoppers

Power-plug adapter (SKW-770)

Only supplied in certain countries. Use this adapter if your AC outlet does not match with the plug on the AV receiver’s power cord (adapter varies from country to country).

*How to mount the AC plug:

Dock for iPod UP-A1

(Red) (White) (Green)

Speaker cable for front speakers and center speaker Front speakers 11 ft (3.5 m) Center speaker 10 ft (3.0 m)

(Blue) (Gray) (Brown) (Tan)

Speaker cables for surround and surround back speakers 26 ft (8 m)

RCA cable for subwoofer connection 10 ft (3 m)

4 floor pads for the subwoofer

*In catalogs and on packaging, the letter at the end of the product

name indicates the color. Specifications and operation are the same regardless of color.

Contents

Introduction

Important Safety Instructions.....................................2

Precautions................................................................ 3

Speaker Precautions .................................................4

Package Contents .....................................................4

AV receiver HT-R670............................................. 4

Speaker Package HTP-670 ................................... 5

Dock for iPod UP-A1.............................................. 5

Features ....................................................................7

AV Receiver HT-R670 ...........................................7

Speaker Package HTP-670 ................................... 7

Dock for iPod UP-A1.............................................. 8

Multiroom Capability .................................................. 9

Front & Rear Panels ................................................ 10

Front Panel ..........................................................10

Display ................................................................. 11

Rear Panel...........................................................12

Speaker Package ....................................................14

Subwoofer (SKW-770)......................................... 14

Front, Center, Surround, Surround Back speakers

(SKF-670, SKC-670, SKR-670, SKB-670) ........15

Remote Controller ...................................................16

Installing the Batteries .........................................16

Aiming the Remote Controller.............................. 16

Controlling the AV receiver .................................. 17

About Home Theater ...............................................18

Enjoying Home Theater ....................................... 18

Connection

Connecting the AV receiver.....................................19

Connecting Your Speakers..................................19

Wall Mounting ...................................................... 21

Using the Rubber Stoppers for

a More Stable Platform .....................................21

Using the Floor Pads for Subwoofer.................... 21

Bi-amping the Front Speakers ............................. 22

Connecting Antenna ............................................23

About AV Connections......................................... 25

Connecting Both Audio & Video ..........................26

Which Connections Should I Use? ......................26

Connecting Components with HDMI.................... 27

Connecting a TV or Projector ..............................29

Connecting a DVD/BD Player.............................. 30

Connecting a VCR or DVR for Playback .............31

Connecting a VCR or DVR for Recording............ 32

Connecting a Satellite, Cable, Terrestrial

Set-top box, or Other Video Source .................. 33

Connecting a Camcorder,

Game Console, or Other Device .......................34

Connecting a Portable Audio player ....................34

Connecting a CD Player or Turntable.................. 35

Connecting a Cassette, CDR,

MiniDisc, or DAT Recorder ...............................36

Connecting an RI Dock........................................ 37

Connecting a Dock with the

Universal Port connector................................... 38

Connecting Onkyo u Components.................... 39

Connecting the Power Cord................................. 39

Turning On & First Time Setup

Turning On the AV receiver ..................................... 40

Turning On and Standby...................................... 40

First Time Setup ......................................................41

HDMI Input Setup ................................................41

Component Video Input Setup............................. 42

Digital Input Setup ...............................................43

Speaker Settings .................................................44

Changing the Input Display.................................. 45

Audyssey 2EQ™ Room Correction and

Speaker Setup ..................................................46

Basic Operations

Basic Operations .....................................................49

Basic AV receiver Operation................................49

Adjusting the Bass & Treble.................................50

Displaying Source Information .............................50

Setting the Display Brightness .............................51

Muting the AV receiver.........................................51

Using the Sleep Timer .........................................51

Using Headphones ..............................................51

Using the Music Optimizer ...................................52

Specifying the Digital Signal Format ....................52

Listening to the Radio ..............................................53

AM/FM Frequency Step Setup.............................53

Using the Tuner ...................................................54

Presetting AM/FM Stations ..................................56

UP-A1 series Dock for iPod/iPhone.........................57

About the UP-A1 series Dock ..............................57

Compatible iPod/iPhone models..........................57

Putting Your iPod/iPhone in the Dock..................57

Function Overview ...............................................57

Controlling iPod/iPhone .......................................58

Recording ................................................................60

Using the Listening Modes

Using the Listening Modes ......................................61

Selecting Listening Modes ...................................61

Listening Modes Available for Each Source Format

About the Listening Modes ..................................66

...62

Advanced Setup

Advanced Setup ......................................................68

Common Procedures in Setup Menu...................68

Speaker Setup .....................................................68

Audio Adjust.........................................................71

Using the Audio Settings......................................73

Assigning Listening Modes to Input Sources .......75

Source Setup .......................................................76

Miscellaneous (Volume) Setup ............................77

Hardware Setup ...................................................78

Zone 2

Zone 2......................................................................80

Connecting Zone 2...............................................80

Setting the Powered Zone 2 ................................81

Using Zone 2........................................................82

Controlling Other Components

Controlling Other Components ................................84

Preprogrammed Remote Control Codes .............84

Entering Remote Control Codes ..........................84

Remote Control Codes for Onkyo

Components Connected via u ........................85

Resetting REMOTE MODE Buttons ....................85

Resetting the Remote Controller..........................85

Controlling a TV ...................................................86

Controlling a DVD Player, or DVD Recorder .......87

Controlling a VCR or PVR....................................88

Controlling a Satellite Receiver or Cable Receiver

Controlling a CD Player .......................................90

Controlling an RI Dock .........................................91

Controlling a Cassette Recorder..........................92

....89

Others

Troubleshooting .......................................................93

Specifications...........................................................97

* To reset the AV receiver to its factory defaults, turn it on and,

while holding down the [VCR/DVR] button, press the [ON/ STANDBY] button (see page 93).

Features

AV Receiver HT-R670

Amplifier

• 130 Watts/Channel @ 6 ohms

• 160 Watts/Channel @ 6 ohms (JEITA)

• WRAT-Wide Range Amplifier Technology

• High-Current Low-Impedance Drive

• Optimum Gain Volume Circuitry

• H.C.P.S. (High Current Power Supply) Massive High Power Transformer

Processing

• Dolby TrueHD*1 and DTS*2-HD Master Audio Decoding

• Dolby Pro Logic IIz*1 (with “Front High” Direction Mode)

• Pure Audio Mode (Asian models)

• Direct Mode

• Music Optimizer

• CinemaFILTER

• Non-Scaling Configuration

• A-Form Listening Mode Memory

• 192 kHz/24-bit D/A Converters

• Powerful and Highly Accurate 32-bit DSP Processing

Connections

• 4 HDMI*4 Inputs and 1 Output (ver.1.3a to Support Deep Color, x.v. Color*, Lip Sync, DTS-HD Master Audio, DTS-HD High Resolution Audio, Dolby TrueHD, Dolby Digital Plus, DSD and Multichannel PCM)

• Onkyo for System Control

• HDTV-Ready Component Video Switching (2 Inputs/1 Output)

• Front “Portable” Input for iPod* and MP3 Players

• Universal Port for the Dock for the iPod* / HD Radio™

• 4 Digital Inputs (2 Optical/2 Coaxial)

• Color-Coded Banana Plug Speaker Posts

• Powered Zone 2 and Zone 2 Line Out

• Subwoofer Pre Out

• Bi-Amp Capability for Music and Movie Sound Effects

for Compressed Music

Dock (North American models)

Miscellaneous

• 40 AM/FM Presets

• Audyssey Dynamic EQ™

• Audyssey 2EQ™ Problems

• Audyssey Dynamic Volume*6 to Maintain Optimal Listening Level and Dynamic Range

• Crossover Adjustment (40/50/60/70/80/90/100/120/150/200 Hz)

• A/V Sync Control Function (up to 100 ms in 10 ms Steps)

• Theater Dimensional Virtual Surround Function

• Compatible with RI Dock for iPod

• Preprogrammed u-Compatible Remote

for Loudness Correction

to Correct Room Acoustic

Speaker Package HTP-670

SKF-670 L/R 2-Way Front Speakers

• 4" (10 cm) cone woofer

• 1" (2.5 cm) Balanced dome tweeter

• Max. input power:130 W

•Gloss Finished

• 6-ohm impedance

• Color-coded speaker terminals and speaker cable

SKC-670 2-Way Center Speaker

• 4" (10 cm) cone woofer

• 1" (2.5 cm) Balanced dome tweeter

• Max. input power:130 W

•Gloss Finished

• 6-ohm impedance

• Color-coded speaker terminals and speaker cable

SKR-670 L/R Full-Range Surround Speakers

SKB-670 L/R Full-Range Surround Back Speakers

• 3-1/4" (8 cm) Full-Range Speaker

• Max. input power:130 W

•Gloss Finished

• 6-ohm impedance

• Color-coded speaker terminals and speaker cable

SKW-770 Bass Reflex Powered Subwoofer

• 10" (25 cm) cone

• Output Level Control

• Max. power:290 W

Features—Continued

Dock for iPod UP-A1

• Easily links all iPhone, iPod Touch (1G, 2G), iPod Classic, iPod (4G, 5G), iPod nano (1G, 2G, 3G, 4G), iPod mini with Onkyo A/V Systems

Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories.

*2.

Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567 & other U.S. and worldwide patents issued & pending. DTS is a registered trademark and the DTS logos, Symbol, DTS-HD and DTS-HD Master Audio are trademarks of DTS, Inc. ©1996-2008 DTS, Inc. All Rights Reserved.

*3 Music Optimizer™ is a trademark of Onkyo Corporation.

HDMI, the HDMI logo and High Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC.

*5 HD Radio™ and the HD Radio Ready logo are proprietary

trademarks of iBiquity Digital Corporation. To receive HD Radio broadcasts, you must install an Onkyo UP-HT1 HD Radio tuner module (sold separately).

*6.

Manufactured under license from Audyssey Laboratories. U.S. and foreign patents pending. Audyssey 2EQ™, Audyssey Dynamic Volume™ and Audyssey Dynamic EQ™ are trademarks of Audyssey Laboratories.

Theater-Dimensional is a trademark of Onkyo Corporation.

* iPod is trademark of Apple Inc., registered in the U.S. and other

countries. * iPhone is trademark of Apple Inc. * “Made for iPod” means that an electronic accessory has been

designed to connect specifically to iPod and has been certified

by the developer to meet Apple performance standards.

“Works with iPhone” means that an electronic accessory has

been designed to connect specifically to iPhone and has been

certified by the developer to meet Apple performance standards.

Apple is not responsible for the operation of this device or its

compliance with safety and regulatory standards.

* “x.v.Color” is a trademark of Sony Corporation.

Multiroom Capability

You can use two speaker systems with this AV receiver—a surround-sound speaker system (up to 7.1 channels) in your main listening room, a stereo speaker system in a second room, or Zone 2, as we call it. And, you can select a different audio source for each room.

Main Room: In your main listening room, you can enjoy up to 7.1-channel playback (see page 18). You can enjoy the various listening modes such as Dolby and DTS (see pages 61–67). * While Powered Zone 2 is being used, playback is reduced to 5.1-channels (see page 80). Zone 2: In your Zone 2 room, you can enjoy 2-channel stereo playback (see page 80). * The listening modes cannot be used with Zone 2.

Main Room

Front high left and right speakers (Optional)

* When you connect the front high left and

right speakers, preparate it separately.

* While Powered Zone 2 is being used,

nothing is output by these speakers (page 81).

* Front high and surround back speakers

produce no sound at the same time.

Front left and right speakers

Surround back left and right speakers

* While Powered Zone 2 is

being used, nothing is output by these speakers (page 81).

* Front high and surround

back speakers produce no sound at the same time.

Subwoofer

Center speaker

Surround left and right speakers

Zone 2 Room

Left and right stereo speakers

Front & Rear Panels

Front Panel

North American models

e fa b

qpong hi j kl m

usr

Asian models

The actual front panel has various logos printed on it. They are not shown here for clarity.

The page numbers in parentheses show where you can find the main explanation for each item.

a ON/STANDBY button (40)

Sets the AV receiver to On or Standby.

b STANDBY indicator (40)

Lights up when the AV receiver is on Standby and flashes while a signal is being received from the remote controller.

c ZONE 2 indicator (82)

Flashes when Zone 2 is being set. Lights up when Zone 2 is on.

d ZONE 2 LEVEL/TONE LEVEL buttons

ZONE 2 and OFF buttons (82)

The [ZONE 2] button is used to turn on the output of Zone 2. The [OFF] button is used to turn off the output of Zone 2.

[–] & [+] buttons (50, 83)

Used to adjust the tone (bass and treble) and the level of Zone 2.

TONE button (50)

Used to select either bass or treble.

e Remote-control sensor (16)

Receives control signals from the remote controller.

f Display

See “Display” on page 11.

g MOVIE/TV button (61)

Selects the listening modes intended for use with movies and TV.

h MUSIC button (61)

Selects the listening modes intended for use with music.

Front & Rear Panels—Continued

For detailed information, see the pages in parentheses.

i GAME button (61)

Selects the listening modes intended for use with video games.

j DIMMER button (51)

Adjusts the display brightness.

k MEMORY button (56)

Used when storing or deleting radio presets.

l TUNING MODE button (54)

Selects the Auto or Manual tuning mode for AM and FM radio.

m DISPLAY button (50)

Displays various information about the currently selected input source.

n SETUP button

Opens and closes the setup menus.

o TUNING, PRESET, Arrow, and ENTER

buttons

When AM or FM is selected, the TUNING [q]/[w] buttons are used for radio tuning, and the PRESET [e]/[r] buttons are used to select radio presets (see pages 54, 56). With the setup menus, they work as arrow buttons and are used to select and set items. The [ENTER] button is also used with the setup menus.

p RETURN button

Selects the previously displayed setup menu.

q MASTER VOLUME control (49)

Sets the volume of the AV receiver to Min, 1 through 79, or Max.

r PHONES jack (51)

This 1/4-inch phone jack is for connecting a standard pair of stereo headphones for private listening.

s MUSIC OPTIMIZER button (52)

(North American models)

Turns the Music Optimizer on or off.

t PURE AUDIO button and indicator (61)

(Asian models)

Selects the Pure Audio listening mode. The indicator lights up when this mode is selected. Pressing this button again selects the previous listening mode.

u Input selector buttons (49)

Select the following input sources: DVD/BD, VCR/DVR, CBL/SAT, AUX, TV/TAPE, TUNER, CD, PORT.

v AUX INPUT (34, 60)

Used to connect a camcorder, game console, and so on. There are input jacks for composite video and analog audio.

PORTABLE (34):

Used to connect a portable Audio Player.

w SETUP MIC (46)

The Audyssey 2EQ™ Room Correction and Speaker Setup microphone connects here.

Display

a bc d

For detailed information, see the pages in parentheses.

a SLEEP indicator (51)

Lights up when the Sleep function has been set.

b MUTING indicator (51)

Flashes while the AV receiver is muted.

c Listening mode and format indicators (61)

Show the selected listening mode and audio input signal format.

d Tuning indicators (54)

FM STEREO (54):

Lights up when tuned to a stereo FM station.

AUTO (54) :

Lights up when Auto Tuning mode is selected for AM or FM radio. Goes off when Manual Tuning mode is selected.

TUNED (54):

Lights up when tuned to a radio station.

e Message area

Displays various information.

f Audio input indicators

Indicate the type of audio input that’s selected as the audio source: PCM, MULTI CH, or HDMI.

g Audyssey indicator (47, 70)

Flashes during Audyssey 2EQ™ Room Correction and Speaker Setup. Lights up when the “Equalizer Settings” is set to “Audyssey”.

Front & Rear Panels—Continued

Rear Panel

c d e ga h if

j k l m n o pq r

a DIGITAL IN COAXIAL 1 and 2

These coaxial digital audio inputs are for connecting components with a coaxial digital audio output, such as a CD player or DVD/BD player. They’re assignable, which means you can assign each one to an input selector to suit your setup. See “Digital Input Setup” on page 43.

b DIGITAL IN OPTICAL 1 and 2

These optical digital audio inputs are for connecting components with an optical digital audio output, such as a CD player or DVD/BD player. They’re assignable, which means you can assign each one to an input selector to suit your setup. See “Digital Input Setup” on page 43.

c COMPONENT VIDEO IN 1 and 2

These RCA component video inputs are for connecting components with a component video output, such as a DVD/BD player, DVD/BD recorder, or DVR (digital video recorder). They’re assignable, which means you can assign each one to an input selector to suit your setup. See “Component Video Input Setup” on page 42.

d COMPONENT VIDEO OUT

This RCA component video output is for connecting a TV or projector with a component video input.

e HDMI IN 1–4 and OUT

f AM and FM ANTENNA

g MONITOR OUT

h UNIVERSAL PORT

i FRONT L/R, CENTER, SURR L/R, and SURR

HDMI (High Definition Multimedia Interface) connections carry digital audio and digital video. The HDMI inputs are for connecting components with an HDMI output, such as a DVD/BD player, DVD/BD recorder, or DVR (digital video recorder). They’re assignable, which means you can assign each one to an input selector to suit your setup. See “HDMI Input Setup” on page 41. The HDMI outputs are for connecting a TV or projector with an HDMI input.

The AM push terminals are for connecting an AM antenna. The FM jack is for connecting an FM antenna.

The composite video jack should be connected to a video input on your TV or projector.

This jack is for connecting the component with the Universal Port connector such as UP-A1 series Dock.

BACK L/R SPEAKERS

These terminal posts are for connecting the front L/R, center, surround L/R, and surround back L/R speakers. The FRONT L/R and SURR BACK L/R terminal posts can be used with front speakers and surround back speakers, respectively, or used to bi-amp front Speakers. See “Bi-amping the Front Speakers” on page 22. The SURR BACK L/R terminals can be used to connect the front high L/R speakers. See “Speaker Settings” on page 44.

Front & Rear Panels—Continued

j u REMOTE CONTROL

This u (Remote Interactive) jack can be connected to the u jack on another u-capable Onkyo component for remote and system control. To use u, you must make an analog audio connection (RCA) between the AV receiver and the other component, even if they are connected digitally.

k CD IN

This analog audio input is for connecting a CD player’s analog audio output.

l TV/TAPE IN/OUT

These analog audio input and output jacks are for connecting a recorder with an analog audio input and output, such as a cassette deck, MD recorder, etc.

m CBL/SAT IN

A cable or satellite receiver can be connected here. There is composite video input jack for connecting the video signal, and there are analog audio input jacks for connecting the audio signal.

n VCR/DVR IN/OUT

A video component, such as a VCR or DVR, can be connected here for recording and playback. There is composite video input and output jack for connecting the video signal, and there are analog audio input jacks for connecting the audio signal.

o DVD/BD IN

This input is for connecting a DVD/BD player. There is composite video input jack for connecting the video signal.

p ZONE 2 LINE OUT L/R

These analog audio outputs can be connected to the line inputs on amplifiers in Zone 2.

q SUBWOOFER PRE OUT

This analog audio output can be connected to a powered subwoofer.

r FRONT HIGH L/R speakers

These terminals are for connecting the front high L/R speakers. The FRONT HIGH L/R terminal can be used with front high speakers respectively, or used to connect the speakers in Zone 2. See “Connecting Zone 2” on page 80.

See pages 19–39 for hookup information.

Speaker Package

Subwoofer (SKW-770)

For detailed information, see the pages in parentheses.

■ Front

■ Rear

Asian models

POWER

OFF

SKW-770

a STANDBY/ON indicator

Red: Subwoofer in standby mode

Blue: Subwoofer on With the Auto Standby function, the SKW-770 automatically turns on when an input signal is

detected in Standby mode. When there’s no input signal for a while, the SKW-770 automatically enters Standby mode.

b POWER switch (Asian models)

Press this switch to the ON position to turn on the power. Press it to the OFF position to turn off the power.

c OUTPUT LEVEL control (49)

This control is used to adjust the volume of the subwoofer.

d LINE INPUT (20)

This RCA input should be connected to the subwoofer pre out on the AV receiver with supplied RCA cable.

Note:

The Auto Standby function turns the subwoofer on when the input signal exceeds a certain level. If the Auto Standby function does not work reliably, try slightly increasing or decreasing the subwoofer output level on the AV receiver (page 70).

To AC outlet

Speaker Package—Continued

Front, Center, Surround, Surround Back speakers (SKF-670, SKC-670, SKR-670, SKB-670)

■ Rear

SKF-670 SKR-670/SKB-670

a

b

a

a Keyhole slots

These keyhole slots can be used to wall-mount the speaker. See page 21 for mounting instructions.

b Speaker terminals

These push terminals are for connecting the speaker to the HT-R670 with the supplied speaker cables. The supplied speaker cables are color-coded for easy identification. Simply connect each cable to the same-colored positive speaker terminal.

SKC-670

a ab

Remote Controller

Installing the Batteries

To open the battery compartment, press

the small lever and remove the cover.

Insert the two supplied batteries (AA/R6)

in accordance with the polarity diagram inside the battery compartment.

Replace the cover and push it shut.

Notes:

• If the remote controller doesn’t work reliably, try replacing the batteries.

• Don’t mix new and old batteries or different types of batteries.

• If you intend not to use the remote controller for a long time, remove the batteries to prevent damage from leakage or corrosion.

• Expired batteries should be removed as soon as possible to prevent damage from leakage or corrosion.

Aiming the Remote Controller

When using the remote controller, point it toward the AV receiver’s remote control sensor, as shown below.

Remote control sensor

AV r ecei ver

30°

Approx. 16 ft. (5 m)

Notes:

• The remote controller may not work reliably if the AV receiver is subjected to bright light, such as direct sunlight or inverter-type fluorescent lights. Keep this in mind when installing.

• If another remote controller of the same type is used in the same room, or the AV receiver is installed close to equipment that uses infrared rays, the remote controller may not work reliably.

• Don’t put anything on top of the remote controller, such as a book or magazine, because a button may be pressed continuously, thereby draining the batteries.

• The remote controller may not work reliably if the AV receiver is installed in a rack behind colored glass doors. Keep this in mind when installing.

• The remote controller will not work if there’s an obstacle between it and the AV receiver’s remote control sensor.

• When the remote control codes have been registered and you want to operate another component (page 84), or when you want to operate an Onkyo component without u connection, point the remote controller at the other component to use it.

• When you want to operate an Onkyo component with u connection or an -compatible compo- nent connected via HDMI (pages 86, 87), point the remote controller at the AV receiver’s remote control sensor.

Remote Controller—Continued

Controlling the AV receiver

To control the AV receiver, press the [RECEIVER] button to select Receiver mode.

You can also use the remote controller to control your DVD/BD player, CD player, and other components. See page 84 for more details.

RECEIVER

TUNER

h i

j k

d SETUP button

Used to change settings.

e LISTENING MODE buttons (61)

Used to select the listening modes.

f DIMMER button (51)

Adjusts the display brightness.

g DISPLAY button (50)

Displays information about the current input source.

h MUTING button (51)

Mutes or unmutes the AV receiver.

i VOL [q]/[w] button (49)

Adjusts the volume of the AV receiver regardless of the currently selected remote controller mode.

j RETURN button

Returns to the previous display when changing settings.

k AUDIO button (73)

Used to change audio settings. When the “AudioTVOut” setting is set to “On” (page 78), this button is disabled.

l SLEEP button (51)

Used with the Sleep function.

■ Controlling the tuner

To control the AV receiver’s tuner, press the [TUNER] (or [RECEIVER]) button.

You can select AM or FM by pressing the [TUNER] button repeatedly.

For detailed information, see the pages in parentheses.

a ON/STANDBY button (40)

Sets the AV receiver to On or Standby.

b REMOTE MODE/INPUT SELECTOR buttons

(49, 58, 86–92)

Selects the remote controller modes and the input sources.

c Arrow [q]/[w]/[e]/[r] and ENTER buttons

Used to select and adjust settings.

1 Arrow [q]/[w] buttons

Used to tune into radio stations.

2 D.TUN button (55)

Selects the Direct tuning mode.

3 DISPLAY button (55)

Displays information about the band, frequency, preset number, and so on.

4 CH +/– button (56)

Selects radio presets.

5 Number buttons (55)

Used to select radio stations directly in the Direct tuning mode. Also you can select a preset directly.

* To control component, you must first enter remote

control code. For details on entering a remote control code for a different component, see page 84.

Note:

An Onkyo cassette recorder connected via u can also be controlled in Receiver mode (see page 92).

About Home Theater

Enjoying Home Theater

Thanks to the AV receiver’s superb capabilities, you can enjoy surround sound with a real sense of movement in your own home—just like being in a movie theater or concert hall. You can enjoy DVDs featuring Dolby Digital or DTS. With analog or digital TV, you can enjoy Dolby Pro Logic IIx, DTS Neo:6, or Onkyo’s original DSP listening modes.

Front left and right speakers

These output the overall sound. Their role in a home theater is to provide a solid anchor for the sound image. They should be positioned facing the listener at about ear level, and equidistant from the TV. Angle them inward so as to create a triangle, with the listener at the apex.

Front high left and right speakers (Optional)

These speakers are necessary to enjoy Dolby Pro Logic IIz Height, etc. They enhance significantly the spatial experience. Position them at least 3.3 ft (100 cm) above the front left and right speakers (and as high as possible). Although it is acceptable to place left and right at an angle slightly wider than the front left and right speakers. Ideally they should be positioned directly above the front left and right speakers. Front high and surround back speakers produce no sound at the same time. When you connect the front high left and right speakers, preparate it separately.

Center speaker

This speaker enhances the front left and right speakers, making sound movements distinct and providing a full sound image. In movies it’s used mainly for dialog. Position it close to your TV facing forward at about ear level, or at the same height as the front left and right speakers.

Surround back left and right speakers

These speakers are necessary to enjoy Dolby Digital EX, DTS-ES Matrix, DTS-ES Discrete, etc. They enhance the realism of surround sound and improve sound localization behind the listener. Position them behind the listener about 2–3 ft (60–100 cm) above ear level. Front high and surround back speakers produce no sound at the same time.

Subwoofer

The subwoofer handles the bass sounds of the LFE (Low-Frequency Effects) channel. The volume and quality of the bass output from your subwoofer will depend on its position, the shape of your listening room, and your listening position. In general, a good bass sound can be obtained by installing the subwoofer in a front corner, or at one-third the width of the wall, as shown. Tip: To find the best position for your subwoofer, while playing a movie or some music with good bass, experiment by placing your subwoofer at various positions within the room, and choose the one that provides the most satisfying results.

Surround left and right speakers

These speakers are used for precise sound positioning and to add realistic ambience. Position them at the sides of the listener, or slightly behind, about 2–3 ft (60–100 cm) above ear level. Ideally they should be equidistant from the listener.

Corner position

1/3 of wall position

Connecting the AV receiver

Connecting Your Speakers

Speaker Configuration

For 7.1-channel surround-sound playback, you need seven speakers and a powered subwoofer.

The following table shows which channels you should use based on the number of speakers you have.

Number of speakers: 234567789

Front left ✓✓✓✓✓✓✓✓✓

Front right ✓✓✓✓✓✓✓✓✓

Center ✓ ✓✓✓✓✓✓

Surround left ✓✓✓✓✓✓✓

Surround right ✓✓✓✓✓✓✓

Surround back

Surround back left ✓✓

Surround back right ✓✓

Front high left ✓✓✓

Front high right ✓✓✓

*1 If you’re using only one surround back speaker, connect it to the

power amplifier’s left terminals.

No matter how many speakers you use, a powered subwoofer is recommended for a powerful and solid bass. To get the best from your surround-sound system, you must set the speaker settings. You can do this automatically (see page 46) or manually (see page 68).

Notes:

• Front high and surround back speakers produce no sound at the same time.

• When you connect the front high left and right speakers, preparate it separately.

✓✓

Speaker Connection Precautions

Read the following before connecting your speakers:

• North American models: You can connect speakers with an impedance of between 6 and 16 ohms. If you use speakers with a lower impedance, and use the amplifier at high volume levels for a long period of time, the built-in amp protection circuit may be activated.

• Asian models: You can connect speakers with an impedance of between 4 and 16 ohms. If the impedance of any of the connected speakers is 4 ohms or more, but less than 6 ohms, be sure to set the minimum speaker impedance to “4 ohms” (see page 44). If you use speakers with a lower impedance, and use the amplifier at high volume levels for a long period of time, the built-in amp protection circuit may be activated.

• Disconnect the power cord from the wall outlet before making any connections.

• Read the instructions supplied with your speakers.

• Pay close attention to speaker wiring polarity. Connect positive (+) terminals to only positive (+) terminals, and negative (–) terminals to only negative (–) terminals. If you get them the wrong way around, the sound will be out of phase and will sound unnatural.

• Unnecessarily long or very thin speaker cables may affect the sound quality and should be avoided.

• Be careful not to short the positive and negative wires. Doing so may damage the AV receiver.

• Don’t connect more than one cable to each speaker terminal. Doing so may damage the AV receiver.

• Don’t connect a speaker to several terminals.

Connecting the AV receiver—Continued

Connecting the Speaker Cables

Terminal posts

Strip 1/2"-5/8" (12-

15 mm) of insulation from the ends of the speaker cables. (Supplied speaker cables are already stripped.)

Unscrew the terminal. Fully insert the bare wire,

making sure that it’s touching the threaded shaft in the center. Screw the terminal tight.

1/2"-5/8" (12-15 mm)

Push terminals

Strip 3/8"-1/2"

(10-12 mm) of insulation from the ends of the speaker cables, and twist the bare wires tightly, as shown.

While pressing the lever, insert

the wire into the hole, and then release the lever. Make sure that the terminals are gripping the bare wires, not the insulation.

3/8"-1/2" (10-12 mm)

The following illustration shows which speaker should be connected to each pair of terminals for up to 7.1-channel playback.

If you’re using only one surround back speaker, connect it to the power amplifier’s left terminals.

Blue

Surround

back left

speaker

Surround

back right

speaker

Surround

left

speaker

Surround

right

speaker

Brown

Ta n

Center

speaker

Powered

Subwoofer

Front high

left speaker

(Optional)

Front high

right speaker

(Optional)

Front left

speaker

White

Front right

speaker

Red

Notes:

• The speakers are configured by using the “Speaker Settings” on page 44 and “Speaker Setup” on page 68.

• When you connect the front high left and right speakers, preparate it sepalately.

Gray

Green

Connecting the AV receiver—Continued

Wall Mounting

The speakers can easily be wall mounted by using the keyhole slots.

To mount the front or surround speakers vertically, use the keyhole slot shown to hang each speaker on a screw that’s securely screwed into the wall.

Front speakers (SKF-670)

Surround speakers/Surround back speakers (SKR-670/SKB-670)

Keyhole slot for wall mounting

Rubber

stoppers

To mount the center speaker horizontally, use the two keyhole slots shown to hang each speaker on two screws that are securely screwed into the wall.

Center speaker (SKC-670)

Keyhole slot for wall mounting

Caution:

A mounting screw’s ability to support a speaker depends on how well it’s anchored to the wall. If you have hollow walls, screw each mounting screw into a stud. If there are no studs, or the walls are solid, use suitable wall anchors. Use screws with a head diameter of 5/16" (8 mm) or less and a shank diameter of 5/32" (4 mm) or less. With hollow walls, use a cable/pipe detector to check for any power cables or water pipes before making any holes.

Leave a gap of between 5/32" (4 mm) and 5/16" (8 mm)

Wall

between the wall and the base of the screw head, as shown.

(We recommend that you consult a home installation professional.)

5/32" – 5/16" (4 mm) – (8 mm)

Using the Rubber Stoppers for a More Stable Platform

We recommend using the provided rubber stoppers to achieve the best possible sound from your speakers. The rubber stoppers prevent the speakers from moving, providing a more stable platform.

Rubber stoppers

Rubber

stoppers

6-15/32" (164 mm)

Tip:

If the center speaker is tilted, loosen the screw on the declined side to move upward so that the speaker could be adjusted vertically.

Bottom of the SKF-670 SKR-670 SKB-670

Bottom of the SKC-670

3/8" (10 mm)

3-1/8" (80 mm)

Using the Floor Pads for Subwoofer

If the subwoofer is placed on a hard floor (wood, vinyl, tile, etc.) and playback is very loud, the subwoofer’s feet may damage the flooring. To prevent this, place the supplied pads underneath the subwoofer’s feet. The pads also provide a stable base for the subwoofer.

Pad

Connecting the AV receiver—Continued

Bi-amping the Front Speakers

The FRONT L/R and SURR BACK L/R terminal posts can be used with front speakers and surround back speakers respectively, or bi-amped to provide separate tweeter and woofer feeds for front speakers, providing improved bass and treble performance.

• When bi-amping is used, the AV receiver is able to drive up to 5.1 speakers in the main room.

• For bi-amping, the FRONT L/R terminal posts connect to the front speakers’ woofer terminals. And the SURR BACK L/R terminal posts connect to the front speakers’ tweeter terminals.

• Once you’ve completed the bi-amping connections shown below and turned on the AV receiver, you must set the “Sp Type” setting to “Bi-Amp” to enable biamping (see page 44).

Important:

• When making the bi-amping connections, be sure to remove the jumper bars that link the speakers’ tweeter (high) and woofer (low) terminals.

• Bi-amping can only be used with speakers that support bi-amping. Refer to your speaker manual.

Bi-amping Speaker Hookup

Connect the AV receiver’s FRONT R positive (+)

terminal to the right speaker’s positive (+) woofer (low) terminal. And connect the AV receiver’s FRONT R negative (–) terminal to the right speaker’s negative (–) woofer (low) terminal.

Connect the AV receiver’s SURR BACK R

positive (+) terminal to the right speaker’s positive (+) tweeter (high) terminal. And connect the AV receiver’s SURR BACK R negative (–) terminal to the right speaker’s negative (–) tweeter (high) terminal.

Connect the AV receiver’s FRONT L positive (+)

terminal to the left speaker’s positive (+) woofer (low) terminal. And connect the AV receiver’s FRONT L negative (–) terminal to the left speaker’s negative (–) woofer (low) terminal.

Connect the AV receiver’s SURR BACK L

positive (+) terminal to the left speaker’s positive (+) tweeter (high) terminal. And connect the AV receiver’s SURR BACK L negative (–) terminal to the left speaker’s negative (–) tweeter (high) terminal.

Left speaker

(Optional)

Right speaker

(Optional)

Tweeter (high) Woofer (low)

FRONT SPEAKERS

Connecting the AV receiver—Continued

Connecting Antenna

This section explains how to connect the supplied indoor FM antenna and AM loop antenna, and how to connect commercially available outdoor FM and AM antennas.

The AV receiver won’t pick up any radio signals without any antenna connected, so you must connect the antenna to use the tuner.

AM ANTENNA push terminals

FM ANTENNA jack

Connecting the Indoor FM Antenna

The supplied indoor FM antenna is for indoor use only.

Attach the FM antenna, as shown.

■ North American models

If you cannot achieve good reception with the supplied indoor FM antenna, try a commercially available outdoor FM antenna instead (see page 24).

Connecting the AM Loop Antenna

The supplied indoor AM loop antenna is for indoor use only.

Assemble the AM loop antenna, inserting

the tabs into the base, as shown.

Connect both wires of the AM loop

antenna to the AM push terminals, as shown.

(The antenna’s wires are not polarity sensitive, so they can be connected either way around.)

Make sure that the wires are attached securely and that the push terminals are gripping the bare wires, not the insulation.

Insert the plug fully into the jack.

■ Asian models

Insert the plug fully into the jack.

Once your AV receiver is ready for use, you’ll need to tune into an FM radio station and adjust the position of the FM antenna to achieve the best possible reception.

Use thumbtacks or something similar to

fix the FM antenna into position.

Thumbtacks, etc.

Push Insert wire Release

Once your AV receiver is ready for use, you’ll need to tune into an AM radio station and adjust the position of the AM antenna to achieve the best possible reception. Keep the antenna as far away as possible from your AV receiver, TV, speaker cables, and power cords.

If you cannot achieve good reception with the supplied indoor AM loop antenna, try using it with a commercially available outdoor AM antenna (see page 24).

Caution: Be careful that you don’t injure yourself when using thumbtacks.

Connecting the AV receiver—Continued

Connecting an Outdoor FM Antenna

If you cannot achieve good reception with the supplied indoor FM antenna, try a commercially available outdoor FM antenna instead.

Notes:

• Outdoor FM antennas work best outside, but usable results can sometimes be obtained when installed in an attic or loft.

• For best results, install the outdoor FM antenna well away from tall buildings, preferably with a clear line of sight to your local FM transmitter.

• Outdoor antenna should be located away from possible noise sources, such as neon signs, busy roads, etc.

• For safety reasons, outdoor antenna should be situated well away from power lines and other high-voltage equipment.

• Outdoor antenna must be grounded in accordance with local regulations to prevent electrical shock hazards.

Connecting an Outdoor AM Antenna

If good reception cannot be achieved using the supplied AM loop antenna, an outdoor AM antenna can be used in addition to the loop antenna, as shown.

Outdoor antenna

AM loop antenna

Outdoor AM antennas work best when installed horizontally outside, but good results can sometimes be obtained indoors by mounting horizontally above a window. Note that the AM loop antenna should be left connected. Outdoor antenna must be grounded in accordance with local regulations to prevent electrical shock hazards.

Insulated antenna cable

■ Using a TV/FM Antenna Splitter

It’s best not to use the same antenna for both FM and TV reception, as this can cause interference problems. If circumstances demand it, use a TV/FM antenna splitter, as shown.

TV/FM antenna splitter

To AV r ec e ive r To T V (o r VC R)

Connecting the AV receiver—Continued

About AV Connections

• Before making any AV connections, read the manuals supplied with your other AV components.

• Don’t connect the power cord until you’ve completed and double-checked all AV connections.

Optical Digital Jacks

The AV receiver’s optical digital jacks have shutter-type covers that open when an optical plug is inserted and close when it’s removed. Push plugs in all the way.

Caution: To prevent shutter damage, hold the optical plug straight when inserting and removing.

AV Cables and Jacks

Video / Audio

Cable Jack Description

HDMI

AV Connection Color Coding

RCA-type AV connections are usually color coded: red, white, and yellow. Use red plugs to connect rightchannel audio inputs and outputs (typically labeled “R”). Use white plugs to connect left-channel audio inputs and outputs (typically labeled “L”). And use yellow plugs to connect composite video inputs and outputs.

Left (white)

Right (red) Right (red)

(Yellow)

• Push plugs in all the way to make good connections (loose connections can cause noise or malfunctions).

• To prevent interference, keep audio and video cables away from power cords and speaker cables.

HDMI

HDMI connections can carry uncompressed standard- or high-definition digital video and audio and offer the best picture and sound quality.

Analog audio

Composite video

Left (white)

(Yellow)

Right!

Wrong!

Video

Component video cable

Composite video cable

Audio

Optical digital audio cable

Coaxial digital audio cable

Analog audio cable (RCA)

Stereo mini plug cable

B/CB

PR/CR

B/CB

PR/CR

CB/P

CR/P

OPTICAL

COAXIAL

Note: The AV receiver does not support SCART connections.

Component video separates the luminance (Y) and color difference signals (P

R, PB), providing the best

picture quality. (Some TV manufacturers label their component video jacks slightly differently.)

Composite video is commonly used on TVs, VCRs, and other video equipment.

This offers the best sound quality and allows you to enjoy Dolby Digital and DTS. The audio quality is the same as for coaxial.

This offers the best sound quality and allows you to enjoy Dolby Digital and DTS. The audio quality is the same as for optical.

This cable carries analog audio. It’s the most common connection format for analog audio and can be found on virtually all AV components.

This cable carries analog audio.

Connecting the AV receiver—Continued

Connecting Both Audio & Video

By connecting both the audio and video outputs of your DVD player and other AV components to the AV receiver, you can switch the audio and video signals simultaneously simply by changing the input source on the AV receiver.

: Signal Flow

Video

Audio

DVD player, etc.

Speakers (see page 20 for hookup details)

Audio

TV, projector,

etc.

Which Connections Should I Use?

The AV receiver supports several connection formats for compatibility with a wide range of AV equipment. The format you choose will depend on the formats supported by your other components. Use the following sections as a guide.

Video Signal Flow Chart

Video Connection Formats

Video equipment can be connected to the AV receiver by using any one of the following video connection formats: composite video, component video, or HDMI, the latter offering the best picture quality. When choosing a connection format, bear in mind that the AV receiver doesn’t convert between formats, so only outputs of the same format as the input will output the signal.

DVD player, etc.

AV receiver

Composite

Composite Component

Component

MONITOR OUT

HDMI

TV, projector, etc.

Audio Connection Formats

Audio Signal Flow Chart

DVD player, etc.

Audio equipment can be connected to the AV receiver by using any of the following audio connection formats: analog, optical, coaxial, or HDMI.

Analog

Optical Coaxial HDMI

When you connect audio equipment to an HDMI, OPTICAL, or COAXIAL input, you must assign that input to an input selector (see pages 41 and 43).

AV receiver

TV, projector, etc.

OUT

Analog

*1 Depends on the “AudioTVOut” setting (see page 78)

and Digital Input Setup (see page 43). And, the audio signal can be output only when the input video signal is from HDMI IN. Do not connect the optical or coaxial audio cable when you want to output the analog audio signal.

If signals are present at more than one input, the inputs will be selected automatically in the following order of priority: HDMI, digital, analog.

HDMI

Connecting the AV receiver—Continued

Connecting Components with HDMI

About HDMI

Designed to meet the increased demands of digital TV, HDMI (High Definition Multimedia Interface) is a new digital interface standard for connecting TVs, projectors, DVD players, set-top boxes, and other video components. Until now, several separate video and audio cables have been required to connect AV components. With HDMI, a single cable can carry control signals, digital video, and up to eight channels of digital audio (2-channel PCM, multichannel digital audio, or multichannel PCM).

The HDMI video stream (i.e., video signal) is compatible with DVI (Digital Visual Interface)*1, so TVs and displays with a DVI input can be connected by using an HDMI-to-DVI adapter cable. (This may not work with some TVs and displays, resulting in no picture.) The AV receiver uses HDCP (High-bandwidth Digital Content Protection), so only HDCP-compatible components will display a picture.

The AV receiver’s HDMI interface is based on the following standard:

Deep Color, x.v. Color, Lip Sync, DTS-HD Master Audio, DTS-HD High Resolution Audio, Dolby TrueHD, Dolby Digital Plus, DSD and Multichannel PCM

Supported Audio Formats

• 2-channel linear PCM (16/20/24 bit/32–192 kHz)

• Multichannel linear PCM (7.1 ch, 32–192 kHz)

• Bitstream (DSD, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS, DTS-HD High Resolution Audio, DTS-HD Master Audio)

Your DVD player must be able to output these formats from its HDMI OUT.

■ Onkyo for System Control

, which stands for Remote Interactive over HDMI, is the name of the system control function found on Onkyo components. The AV receiver can be used with CEC (Consumer Electronics Control), which allows system control over HDMI and is part of the HDMI standard. CEC provides interoperability between various components, however, operation with components other than -compatible components cannot be guaranteed.

• Set “HDMI Ctrl” to “On” (page 79).

• See “Controlling a TV” (page 86) and “Controlling a DVD Player, or DVD Recorder” (page 87) for operation.

Note:

Do not connect the -compatible component more than the following number to the HDMI input terminal so that the linked operations work properly.

• DVD/BD player is up to three.

• DVD/BD recorder is up to three.

• Cable/Satellite Set-top box is up to four.

Do not connect the AV receiver to the other AV receiver /AV amplifier via HDMI. When the -compatible component more than the above-mentioned is connected, the linked operations are not

guaranteed.

About Copyright Protection

The AV receiver supports HDCP (High-bandwidth Digital Content Protection)*2, a copy-protection system for digital video signals. Other devices connected to the AV receiver via HDMI must also support HDCP.

*1 DVI (Digital Visual Interface): The digital display interface standard set by the DDWG*3 in 1999. *2 HDCP (High-bandwidth Digital Content Protection): The video encryption technology developed by Intel for HDMI/DVI. It’s designed to

protect video content and requires a HDCP-compatible device to display the encrypted video.

*3 DDWG (Digital Display Working Group): Led by Intel, Compaq, Fujitsu, Hewlett Packard, IBM, NEC, and Silicon Image, this open

industry group’s objective is to address the industry’s requirements for a digital connectivity specification for high-performance PCs and digital displays.

Connecting the AV receiver—Continued

Making HDMI Connections

Step 1:

Use HDMI cables to connect the AV receiver’s HDMI jacks to your HDMI-compatible DVD/BD player, TV, projector, and so on.

Step 2:

Assign each HDMI IN to an input selector in the HDMI Input Setup (see page 41).

■ Video Signals

Digital video signals received by the HDMI IN jacks are normally output by the HDMI OUT for display on your TV.

■ Audio Signals

Digital audio signals received by the HDMI IN jacks are output by the speakers and headphones connected to the AV receiver. Normally, they are not output by the HDMI OUT, unless the “AudioTVOut” setting is set to “On” (see page 78).

Hint!

To listen to audio received by the HDMI IN jacks through your TV’s speakers, set the “AudioTVOut” setting to “On” (see page 78), and set your DVD player’s HDMI audio output setting to PCM.

DVD/BD player

HDMI

ASSIGNABLE

HDMI

OUT

HDMI

Notes:

• The HDMI video stream is compatible with DVI (Digital Visual Interface), so TVs and displays with a DVI input can be connected by using an HDMI-to-DVI adapter cable. (Note that DVI connections only carry video, so you’ll need to make a separate connection for audio.) However, reliable operation with such an adapter is not guaranteed. In addition, video signals from a PC are not supported.

• When listening to an HDMI component through the AV receiver, set the HDMI component so that its video can be seen on the TV screen (on the TV, select the input of the HDMI component connected to the AV receiver). If the TV power is off or the TV is set to another input source, this may result in no sound from the AV receiver or the sound may be cut off.

• When the “AudioTVOut” setting is set to “On” (see page 78), or “TV Ctrl” is set to “On” (see page 79) and you’re listening through your TV’s speakers, if you turn up the AV receiver volume control, the sound will be output by the AV receiver’s speakers. To stop the AV receiver’s speakers producing sound, change the settings, change your TV’s settings, or turn down the AV receiver’s volume.

• The HDMI audio signal (sampling rate, bit length, etc.) may be restricted by the connected source component. If the picture is poor or there’s no sound from a component connected via HDMI, check its setup. Refer to the connected component’s instruction manual for details.

Connecting the AV receiver—Continued

Connecting a TV or Projector

Step 1: Video Connection

Choose a video connection that matches your TV ( or ), and then make the connection.

Step 2: Audio Connection

Choose an audio connection that matches your TV ( , , or ), and then make the connection.

A B

a b c

• With connection , you can listen to and record audio from your TV or listen in Zone 2.

• To enjoy Dolby Digital and DTS, use connection or . (To record or listen in Zone 2 as well, use and , or and .)

b c a b a

Connection AV receiver Signal flow TV

COMPONENT VIDEO OUT ⇒ Component video input

MONITOR OUT V ⇒ Composite video input

TV/TAPE IN L/R ⇐ Analog audio L/R output

DIGITAL IN COAXIAL 2 (CBL/SAT) ⇐ Digital coaxial output

DIGITAL IN OPTICAL 1 (TV/TAPE) ⇐ Digital optical output

OPTICAL

OUT

Connect one or the other Connection must be assigned

(see page 43)

If your TV has no audio outputs, connect an audio output from your VCR or cable or satellite receiver

Hint!

to the AV receiver and use its tuner to listen to TV programs through the AV receiver (see pages 31 and

33).

OUT

YCOAXIAL

COMPONENT VIDEO IN

TV, projector,

etc.

AUDI O

OUT

VIDEO

Connecting the AV receiver—Continued

Connecting a DVD/BD Player

Step 1: Video Connection

Choose a video connection that matches your DVD/BD player ( or You must connect the AV receiver to your TV with the same type of connection.

Step 2: Audio Connection

Choose an audio connection that matches your DVD/BD player ( , , or ), and then make the connection.

), and then make the connection.

A B

a b c

• With connection , you can listen to and record audio from a DVD or listen in Zone 2.

• To enjoy Dolby Digital and DTS, use connection or . (To record or listen in Zone 2 as well, use and , or and .)

b c a b a

• If your DVD player has main left and right outputs and multichannel left and right outputs, be sure to use the main left and right outputs for connection .

Connection AV receiver Signal flow DVD/BD player

COMPONENT VIDEO IN 1 (DVD/BD) ⇐ Component video output

DVD/BD IN V ⇐ Composite video output

DVD/BD IN L/R ⇐ Analog audio L/R output

DIGITAL IN COAXIAL 1 (DVD/BD) ⇐ Digital coaxial output

DIGITAL IN OPTICAL 1 (TV/TAPE) ⇐ Digital optical output

OPTICAL

OUT

Connect one or the other Connection must be

assigned (see page 43)

OUT

YCOAXIAL

COMPONENT VIDEO OUT

AUDI O

OUT

DVD/BD player

VIDEO

OUT
