One for all URC 9910 User manual
IR/RF LCD 8-DEVICE WITH LEARNING
UNIVERSAL REMOTE CONTROL (URC-9910)
User’s Guide
Producer 2002 RF Mnl 4/4/02 10:15 AM Page 1
TABLE OF CONTENTS
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Setting The Clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Features And Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Key Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Programming Device Control
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Programming TV/VCR Combo Control
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Manufacturer’s Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setup Codes for Audio Amplifiers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setup Codes for Audio Cassette Decks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setup Codes for Audio Receivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setup Codes for Audio Turntables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setup Codes for Cable Converters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setup Codes for CD Players . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Setup Codes for DAT Recorders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setup Codes for DVD Players . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setup Codes for Home Automation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setup Codes for LD Players . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setup Codes for Misc. Audio Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setup Codes for Satellite Receivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setup Codes for TVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Setup Codes for TV/VCR Combos. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Setup Codes for VCRs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Setup Codes for Video Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Searching For Your Code. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Using Learning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Programming A Learning Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Deleting A Function From A Learning Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Using Volume Lock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Programming Volume Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Programming Volume Unlock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Using Macros
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Programming A Favorite Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Programming A Master Power Key With Instant Channel Selection. . . . . . . . . . . . . . . . . . 35
Clearing A Macro. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Re-Assigning Device Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Using Keymover
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Programming Keymover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Restoring Keymover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Using Channel Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Programming Favorite Channel Scan
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Using The Home Theater Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Control Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Programming The Home Theater Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Operating The Home Theater Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Using Commercial Skip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Programming Commercial Skip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Operating Commercial Skip. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Restoring Factory Default Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
About Upgrading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Using The IR/RF Command Center. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Setting Up The IR/RF Command Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Adding The IR Signal Extension Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Optimizing IR/RF Command Center Reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Error Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Compliance With FCC Rules And Regulations
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Key Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
2
Producer 2002 RF Mnl 4/4/02 10:15 AM Page 2
INTRODUCTION
The One For All IR/RF LCD 8-Device With Learning Universal
Remote Control (URC-9910) is our latest high-performance
universal remote control. It is designed to operate up to eight home
entertainment devices,including TV, video, and audio components.
Moreover, this remote control contains sophisticated technology that
will allow you to conveniently consolidate the clutter of all of the
original remote controls used in your home entertainment system.
It’s packed with easy-to-use features such as:
• Advanced Liquid Crystal Display (LCD) with 15 alphanumeric
characters,real-time clock, and icons for constant visual feedback
of operations and programming sequences
• A unique Home Theater mode that combines different device
controls under one mode for operating convenience
• Three macro keys for instant activation of favorite key sequences
• Four learning keys to capture unique functions from your
devices’ original remote controls
• Key Mover for copying keys from one device to another,or to a
different position in the same mode
• Code Search to help you program device codes without using the
code list (starting on page 14) or for brands or models not listed
• Favorite Channel Scan for easy channel surfing
• Mode reassignment to control duplicate types of devices
• Volu me Lo ck to assign volume controls to individual devices or to
one global device
• Commercial Skip feature allows you to channel surf during
commercial interruptions of your favorite programs
• Includes IR/RF Command Center to extend the remote control’s
signal range
• Pre-programmed database with the world’s largest and most
efficient group of infrared codes insures device compatibility
• Internal modem for upgrading device codes over the telephone
• A low battery icon to notify you when batteries are getting low
• Backlighting feature to aid operation in low ambient light
The One For All IR/RF LCD 8-Device With Learning Universal
Remote Control (URC-9910) requires four (4) new AAA alkaline
batteries (not included) and easy programming to control your
devices. For best results, please read and perform all instructions
listed here.Also, keep these instructions for future reference.
3
Producer 2002 RF Mnl 4/4/02 10:15 AM Page 3
INSTALLING BATTERIES
1. On the back of the URC-9910 remote control, push
the tab and lift off the battery cover.
2. Obtain four (4) new AAA alkaline batteries. Match
the + and – marks on the batteries to the + and –
marks in the case, and then insert the new batteries.
3. Align the cover key with the case opening and
replace the cover until it locks.
4. If batteries are inserted correctly,the entire LCD
will turn on. After 5 seconds of inactivity,the remote
control will turn itself off to conserve battery life.
5. Perform the steps in Setting The Clock (on the next
page) to set the correct time.
NOTE:When a battery icon appears in the display (see page 7,Key Charts,
LCD), the batteries are low. Simply replace them and the URC-9910 remote
control will be restored to full functionality, complete with your favorite settings.
4
❶
❸
❷
Producer 2002 RF Mnl 4/4/02 10:15 AM Page 4
SETTING THE CLOCK
1. On the URC-9910 remote control, press and hold
SET until you see the display change from the default
device and time to [CODE SET].
NOTE: Default values for device, its code,and time are
shown above.Your remote control settings may be different.
NOTE: If you wish to exit the programming mode at any
time, press EXIT once. You will see an [EXIT] message as the
remote control returns to normal operation.
NOTE: If you see an [INVALID] message, you have inadvertently pressed an incorrect key. Simply note your error and
continue programming.
2. (x 5) Press the ▲ key five times until you see the display
change to [CLOCK SET].
NOTE: If you go past [CLOCK SET],press the ▼key one or
more times to return to it.
3. Press SELECT once to begin programming.You will
see the display change to the current time.
4. Press the ▲ key one or more times until you see the
desired hour (a.m.or p.m.).
5. Press the ▼ key one or more times until you see the
desired minute.
6. Once the time is correctly set,press SELECT once to
accept the values. The display will confirm your
entry with [SUCCESS] and then [EXIT SETUP].
The URC-9910 remote control will return to
normal operation.
5
Producer 2002 RF Mnl 4/4/02 10:15 AM Page 5
FEATURES AND FUNCTIONS
Use the illustration below to locate features on the URC-9910 remote
control and then study the Key Charts (on the next three pages) to
learn how they function.
6
Producer 2002 RF Mnl 4/4/02 10:15 AM Page 6
Key Charts
The LED (red light) blinks to show that the
remote control is working and sending signals.
The LCD (Liquid Crystal Display)
provides 15 alphanumeric characters that display status messages
during remote control operation
and programming.Also,one or
more icons appear in the LCD to
indicate the following conditions:
or Morning or Afternoon Time
Low Battery
IR Signal Transmission
Press TV,VCR,DVD, AUX,SAT,CBL,
RCVR/AMP,or CD once to select a
desired home entertainment
device to control.
After programming, press HOME
THEATER once to select the home
theater mode.See Using The Home
Theater Mode on page 43.
Press POWER once to turn on or off the
selected device.
Use the cursor keys (▲,▼,,or) to move
the cursor in the program guide and menu
screens.Use SELECT to choose options from
your selected device’s menu or guide.
In the CD mode, use SELECT to select a
compact disc.Use ▲ (or ▼) to select the next
(or previous) CD.Use (or ) to select the
next (or previous) track.
In the RCVR/AMP mode, use SELECT to
set the surround sound.Use ▲ (or ▼) to
adjust the volume higher (or lower). Use
(or ) to adjust the balance left (or right).
Press MENU once to display your selected
device’s main menu.
Use GUIDE to display your selected device’s
program guide or setup menu.
continued on next page...
▲
▲
▲
▲
▲
▲
7
Producer 2002 RF Mnl 4/4/02 10:15 AM Page 7
FEATURES AND FUNCTIONS
Key Charts (continued)
Use EXIT to exit from your selected device’s
guide or menu.
Use INFO to display the current channel and
program information.
Use VOL+ (or VOL-) to raise (or lower) the
audio volume.
Press MUTE once to turn the audio off
or on.
In the TV, VCR,DVD, SAT,and CBL modes,
use FAV to scan favorite channels and/or all
channels. See Using Channel Scan and Program-
ming Favorite Channel Scan on page 41.
Use CH+ (or CH-) to select the next higher (or
lower) channel.
Press PREV once to recall the last-viewed
channel and to page back one screen on the
main menu.
In the CD mode, use PREV to turn random
play on or off.
In the RCVR/AMP mode, use PREV to select
the receiver band.
Use the keypad (1 ~ 9 and 0) to
directly select channels (e.g., 009 or
031).
In the RCVR/AMP mode, use the
keypad (1 ~ 9 and 0) to select audio
sources 1 through 10.
Press ENTER once after entering the channel
numbers on some TVs.
In the CD mode, use ENTER to add 10 to the
digit entry (e.g., ENTER and 7 is 17).
Use TV/VID to switch the TV’s input to view
TV or video programs.
8
Producer 2002 RF Mnl 4/4/02 10:15 AM Page 8
Use the transport keys to control your
VCR,DVD or CD player, or VOD (Video
On Demand) if available on your cable
or satellite service.
To record a VCR program, press REC
twice.
Use SLEEP to activate your device’s sleep
timer (not available for all devices).
After programming, press M1 ~ M3 once to
run a desired macro (see Using Macros on
page 34).
After programming,press L1 ~ L4
once to activate a learned function.
See Using Learning on page 30.
Use PIP to switch the Picture-In-Picture
feature on or off (if available on your TV).
Use MOVE to move the window picture
to different positions in the main picture.
Use SWAP to switch images and sound
between the main and window pictures.
After programming,use COM SKIP to skip
commercials on selected devices (i.e.,TV,VCR,
DVD, CBL,and SAT). See Using Commercial
Skip on page 48.
Use to turn on or off the key backlight.
When this feature is activated,keys will
remain backlit for 5 seconds after the last key
press.In the setup mode,backlighting
will remain on for 30 seconds.
Use SET for all programming sequences.
9
Producer 2002 RF Mnl 4/4/02 10:15 AM Page 9
PROGRAMMING DEVICE CONTROL
The URC-9910 remote control is preprogrammed at the factory to
operate an RCA TV and VCR,a Motorola (GI) cable converter, an RCA
satellite receiver, a Pioneer CD player,a Toshiba DVD player,a Pioneer
audio receiver/ amplifier,and a One For All home automation device.
To control devices other than the default brands,perform the following steps and repeat them as needed for each device to be programmed; otherwise skip this section:
NOTE: For TV/VCR Combo control, see “Programming TV/VCR Combo
Control”on page 12.
1. Turn on a device (e.g.,VCR or DVD player) and,if
applicable, insert media (e.g., cassette or disc).
NOTE: Please read steps 2 through 8 completely before
proceeding. Highlight or write down the codes and device
you wish to program before starting step 2.
2. On the URC-9910 remote control, press and hold
SET until you see the display change from the current device and time to [CODE SET].
NOTE: The device,its code, and time are examples.Your
remote control settings may be different.
NOTE: To exit programming at any time, press EXIT once or
allow 30 seconds of inactivity to lapse.You will see [EXIT
SETUP] as the remote control returns to normal operation.
NOTE: [INVALID] means you have inadvertently pressed an
incorrect key.Note your error and continue programming.
3. Press SELECT once to begin programming.You will
see the display change to the last-selected device
and its current code (e.g.,TV and 0051).
4. Press a desired device key once (e.g., VCR).You will
see the display change to the desired device and its
current code (e.g.,VCR and 0035).
NOTE: Use the AUX key to program control of home
automation devices, video accessories,audio services, and
other audio or video devices.Alternately, use the AUX key to
program control of a second device type (e.g., a second VCR;
see “Re-assigning Device Keys” on page 37).
5. Use the Manufacturer’s Codes (starting on page 14)
to locate the type of device and brand name. Then
use the keypad to enter the first four-digit code for
your device and press SELECT once.
10
Producer 2002 RF Mnl 4/4/02 10:15 AM Page 10
For example, to enter the first GE VCR code (on
page 24), press 0 twice, 6 once, 0 once, and then
SELECT once.
If the code is entered correctly, you will see the
[SUCCESS] message.
6. Press EXIT to exit the programming mode.You will
see an [EXIT SETUP] message as the URC-9910
remote control returns to normal operation.
7. To verify the code works, aim the URC-9910 remote
control at the desired device, press its device key
once and then press POWER once. The device should
turn off. If it does not respond,repeat steps 2
through 6,trying each code for your brand until you
find one that works. If it still does not work, try
Searching For Your Code on page 27.
NOTE: If the device does not have a POWER key, press the
(Play) key.
8. Repeat steps 1 through 7 for each device you want
to control. For future reference,write down each
working device code in the boxes below:
TV Code:
VCR Code:
DVD Code:
SAT Code:
CBL Code:
RCVR/AMP
Code:
CD Code:
AUX Code:
Aux.Device
Type:________________________________
11
Producer 2002 RF Mnl 4/4/02 10:15 AM Page 11
PROGRAMMING TV/VCR COMBO CONTROL
Perform the following instructions to control a TV/VCR Combo:
1. Turn on the TV/VCR Combo and insert a video
cassette.
NOTE: Please read steps 2 through 9 completely before proceeding.Highlight or write down the codes and device you
wish to program before starting step 2.
2. On the URC-9910 remote control, press and hold
SET until you see the display change from the current device and time to [CODE SET].
NOTE: The device, its code,and time are examples.Your
remote control settings may be different.
NOTE: To exit programming at any time, press EXIT once or
allow 30 seconds of inactivity to lapse.You will see [EXIT
SETUP] as the remote control returns to normal operation.
NOTE: [INVALID] means you have inadvertently pressed an
incorrect key.Note your error and continue programming.
3. Press SELECT once to begin programming.You will
see the display change to the last-selected device
and its current code (e.g.,TV and 0051)
4. Press VCR once.You will see the display change to
[VCR] and its current code.
5. Use the Setup Codes For TV/VCR Combos (on
page 22) to locate the type of device and brand
name. Then use the keypad to enter the first fourdigit code for your device and press SELECT once.
For example, to enter the first Sony TV/VCR Combo
code on page 23,press 0 four times and then
SELECT once.
If the code is entered correctly, you will see the
[SUCCESS] message.
NOTE: If your TV/VCR Combo has a separate TV code, you
will also need to perform step 6.
12
Producer 2002 RF Mnl 4/4/02 10:16 AM Page 12
6. (Optional) Skip this step if your TV/VCR Combo
does not have a separate TV code.Otherwise, press
TV once.You will see the display change to [TV] and
its current code.
Use the keypad to enter the separate TV code for
your device.
7. Press EXIT to exit the programming mode.You will
see [EXIT SETUP] as the URC-9910 remote control
returns to normal operation.
8. To verify the code works, aim the URC-9910 remote
control at the desired device, press VCR once and
then press POWER once. The TV/VCR Combo
should turn off. If it does not respond, repeat steps 2
through 8,trying each code for your brand until you
find one that works. If it still does not work, try
Searching For Your Code on page 27.
NOTE: If the device does not have a POWER key, press the
(Play) key.
NOTE: For VCR/TV Combos programmed with separate TV
codes, TV volume is controlled by pressing
VCR first and
then
TV. After that, use VOL+ (or VOL-) to raise (or lower)
the TV volume.For other alternatives on controlling volume
keys, see “Changing Volume Lock” on page 32 or “Using
Keymover”on page 38.
9. For future reference, write down the working
TV/VCR combo code in the below boxes:
TV/VCR Code:
TV Code
(if used):
13
Producer 2002 RF Mnl 4/4/02 10:16 AM Page 13
MANUFACTURER’S CODES
Setup Codes for Audio Amplifiers:
GE 0078
Harman/Kardon 0892
JVC 0331
Luxman 0165
Marantz 0321, 0892
Nakamichi 0321
Optimus 0395
Philips 0892
Polk Audio 0892
Realistic 0395
Sansui 0321
Sony 0689
Soundesign 0078
Victor 0331
Wards 0078
Yamaha 0354
Setup Codes For Audio Cassette Decks:
Sony 0243
Setup Codes for Audio Receivers:
ADC 0531
Aiwa 0121,1089, 1405
Bose 1229
Capetronic 0531
Carver 1089, 1189
Compaq 1136
Denon 1104, 1160
Harman/Kardon 0110
Hewlett Packard 1181
JBL 0110
JVC 0074
Kenwood 0186, 1027,1313, 1569, 1570
MCS 0039
Magnavox 0531, 1089, 1189
Marantz 0039, 1089,1189
Onkyo 0135
Optimus 0531, 0670,0186, 1023
Panasonic 0039, 1518
Philips 1089, 1189, 1269
Pioneer 0531, 0014, 0150,0630, 1023
Proscan 1254
Quasar 0039
RCA 0531, 1023, 1254
14
Producer 2002 RF Mnl 4/4/02 10:16 AM Page 14
Sansui 1089
Sharp 0186
Sony 1058, 1158, 1258
Soundesign 0670
Sunfire 1313
Technics 0039, 1308, 1309,1518
Thorens 1189
Victor 0074
Wards 0014
Yamaha 0176, 0186, 1176
Setup Codes For Audio Turntables:
Aiwa 0188
Carver 0188
Magnavox 0188
Marantz 0188
Philips 0188
Setup Codes for Cable Converters:
ABC 0003, 0017
Americast 0899
Bell South 0899
General Instrument 0476, 0810
GoldStar 0144
Hamlin 0009, 0273
Jerrold 0003, 0476, 0276,0810
Memorex 0000
Motorola 0476, 1106
Pace 0237
Panasonic 0000, 0107
Paragon 0000
Philips 0305, 0317
Pioneer 0144, 0533, 0877
Pulsar 0000
Quasar 0000
Regal 0273, 0279
Runco 0000
Samsung 0144
Scientific Atlanta 0477, 0017, 0877
Sony 1006
Starcom 0003
Supercable 0276
Toshiba 0000
Zenith 0000, 0525, 0899
15
Producer 2002 RF Mnl 4/4/02 10:16 AM Page 15
MANUFACTURER’S CODES (continued)
Setup Codes For CD Players:
Aiwa 0157,0124
Burmester 0420
California Audio Labs 0029, 0303
Carver 0157, 0179, 0437
DKK 0000
Denon 0003, 0873
Emerson 0305
Fisher 0179, 0174
Garrard 0420, 0393
Genexxa 0032, 0305
Harman/Kardon 0157, 0173
Hitachi 0032
JVC 0072
Kenwood 0028, 0037,0190, 0626, 0681,0826
Krell 0157
LXI 0305
Linn 0157
MCS 0029
MTC 0420
Magnavox 0157, 0305
Marantz 0029, 0157,0180, 0626
Mission 0157
NSM 0157
Nikko 0174
Onkyo 0101, 0868
Optimus 0000, 0032,0179, 0305, 0037,0420, 0145, 0468, 0437,1063
Panasonic 0029, 0303
Parasound 0420
Philips 0157, 0626
Pioneer 0032, 0305, 0468,1062, 1063
Polk Audio 0157
Proton 0157
QED 0157
Quasar 0029
RCA 0032, 0179, 0305, 0053,0468, 0764, 1062
Realistic 0179, 0420,0180
Rotel 0157, 0420
SAE 0157
Sansui 0157, 0305
Sanyo 0179
Scott 0305
Sears 0305
Sharp 0037, 0180, 0861
Sherwood 0180, 1067
Sonic Frontiers 0157
Sony 0000, 0185, 0490
16
Producer 2002 RF Mnl 4/4/02 10:16 AM Page 16
Soundesign 0145
Tascam 0420
Teac 0420, 0393, 0174,0180
Technics 0029, 0303
Victor 0072
Wards 0157, 0053
Yamaha 0036, 0187, 0888
Yorx 0461
Setup Codes For DAT (Digital Audio Tape) Recorders:
Carver 0158
Harman/Kardon 0158
Magnavox 0158
Marantz 0158
Philips 0158
Setup Codes For DVD Players:
Aiwa 0641
Apex 0672
Denon 0490, 0634
Emerson 0591
Fisher 0670
GE 0522, 0717
GPX 0769
Go Video 0715
Gradiente 0651
Harman/Kardon 0582
Hitachi 0573, 0664
Hiteker 0672
JVC 0558, 0623
Kenwood 0534, 0682
Konka 0711, 0719, 0720,0721
Magnavox 0503, 0675
Marantz 0539
Mitsubishi 0521
Onkyo 0503, 0627
Optimus 0571
Oritron 0651
Panasonic 0490, 0632
Philips 0503, 0539
Pioneer 0525, 0571, 0632
Princeton 0674
Proscan 0522
RCA 0522, 0571, 0704, 0717
Samsung 0573
Sanyo 0670
continued on next page...
17
Producer 2002 RF Mnl 4/4/02 10:16 AM Page 17
MANUFACTURER’S CODES (continued)
Setup Codes For DVD Players:
Sharp 0630
Sherwood 0633
Sony 0533
Technics 0490
Techwood 0692
Theta Digital 0571
Toshiba 0503
Yamaha 0490, 0545
Zenith 0503, 0591
Setup Codes For Home Automation:
GE 0240
One For All 0167
RadioShack 0240
Security System 0167
Universal X10 0167
X10 0167
Setup Codes For LD (Laser Disc) Players:
Denon 0059
Mitsubishi 0059
NAD 0059
Optimus 0059
Pioneer 0059
Setup Codes For Misc. Audio Services:
Jerrold 0459, 0520
Scientific Atlanta 0460
Starcom 0459
Setup Codes For Satellite Receivers:
AlphaStar 0772
Chaparral 0216
Echostar 0775, 1005
Expressvu 0775
GE 0566
General Instrument 0869
HTS 0775
Hitachi 0819
Hughes Network Sys. 0749, 1142,1749
JVC 0775
Magnavox 0724, 0722
18
Producer 2002 RF Mnl 4/4/02 10:16 AM Page 18
Memorex 0724
Mitsubishi 0749
Next Level 0869
Panasonic 0701, 0247
Philips 0749, 0724, 0722,1076, 1142
Proscan 0392
RCA 0566, 0143, 0392, 0855
RadioShack 0869
Samsung 1109
Sony 0639
Star Choice 0869
Toshiba 0749, 0790
Uniden 0724,0722
Zenith 0856
Setup Codes For TVs:
AOC 0030, 0019
Admiral 0093, 0463
Aiko 0092
Aiwa 0701
Akai 0030
Alaron 0179
Ambassador 0177
America Action 0180
Ampro 0751
Anam 0180
Audiovox 0451, 0180, 0092, 0623
Baysonic 0180
Belcor 0019
Bell & Howell 0154, 0016
Bradford 0180
Brockwood 0019
Broksonic 0236,0463
CXC 0180
Candle 0030, 0056
Carnivale 0030
Carver 0054
Celebrity 0000
Cineral 0451, 0092
Citizen 0060, 0030, 0056,0092
Concerto 0056
Contec 0180
Craig 0180
Crosley 0054
Crown 0180
Curtis Mathes 0047,0054,0154, 0051,0451, 0093,0060, 0030,0145, 0056,
0016, 0166, 0466,0747, 1147, 1347
Daewoo 0451, 0019,0092, 0623,0624
continued on next page...
19
Producer 2002 RF Mnl 4/4/02 10:16 AM Page 19
MANUFACTURER’S CODES
Setup Codes For TVs (continued):
Daytron 0019
Denon 0145
Dumont 0017, 0019
Dwin 0720, 0774
Electroband 0000
Emerson 0154, 0236, 0463,0180, 0178, 0019, 0179,0177,0623, 0624
Envision 0030
Fisher 0154
Fujitsu 0179, 0683
Funai 0180, 0179, 0171
Futuretech 0180
GE 0047, 0051, 0451,0093, 0178, 0021, 0747,1147, 1347
Gibralter 0017, 0030, 0019
GoldStar 0030, 0178,0019, 0056
Gradiente 0053, 0056
Grunpy 0180, 0179
Hallmark 0178
Harley Davidson 0179
Harman/Kardon 0054
Harvard 0180
Hitachi 0145, 0056,0016, 0151
Infinity 0054
Inteq 0017
JBL 0054
JCB 0000
JVC 0053
KEC 0180
KTV 0180, 0030
Kenwood 0030, 0019
Konka 0628, 0632, 0638,0703, 0707
LG 0056
LXI 0047, 0054, 0154, 0156,0178, 0747
Logik 0016
Luxman 0056
MGA 0150, 0030, 0178, 0019
MTC 0060, 0030, 0019, 0056
Magnavox 0054, 0030, 0179, 1254
Majestic 0016
Marantz 0054, 0030
Matsushita 0250
Megatron 0178,0145
Memorex 0154, 0250, 0463, 0150,0178, 0179,0056, 0016
Midland 0047, 0017,0051, 0747
Minutz 0021
Mitsubishi 0093, 0150, 0178, 0019
Motorola 0093
20
Producer 2002 RF Mnl 4/4/02 10:16 AM Page 20
Multitech 0180
NAD 0156, 0178,0166
NEC 0030, 0019, 0056
NTC 0092
Nikko 0030, 0178, 0092
Onwa 0180
Optimus 0154, 0250,0166
Optonica 0093
Orion 0236, 0463, 0179
Panasonic 0051, 0250
Penney 0047, 0156, 0051, 0060,0030, 0178, 0021, 0019,0056, 0747,
1347
Philco 0054, 0463, 0030,0145, 0019
Philips 0054
Pilot 0030, 0019
Pioneer 0166, 0679
Portland 0019, 0092
Princeton 0717
Prism 0051
Proscan 0047, 0747
Proton 0178, 0466
Pulsar 0017, 0019
Quasar 0051, 0250
RCA 0047, 0051, 0093, 0019,0090, 0679, 0747, 1047,1147, 1247,
1347, 1447
RadioShack 0047,0154, 0180,0030, 0178,0019, 0056,0747
Realistic 0154, 0180,0030, 0178,0019, 0056
Runco 0017, 0030, 0603
SSS 0180, 0019
Sampo 0030
Samsung 0060, 0030, 0178, 0019,0056
Sansei 0451
Sansui 0463
Sanyo 0154
Scimitsu 0019
Scotch 0178
Scott 0236, 0180,0178, 0019,0179
Sears 0047, 0054,0154, 0156,0178, 0179,0056, 0171,0747
Semivox 0180
Semp 0156
Sharp 0093, 0688
Shogun 0019
Signature 0016
Sony 0000
Soundesign 0180, 0178,0179
Squareview 0171
Starlite 0180
Supreme 0000
Sylvania 0054, 0030
continued on next page...
21
Producer 2002 RF Mnl 4/4/02 10:16 AM Page 21
MANUFACTURER’S CODES
Setup Codes For TVs (continued):
Symphonic 0180, 0171
TMK 0178, 0056, 0177
TNCi 0017
Tandy 0093
Technics 0051, 0250
Technol Ace 0179
Techwood 0051, 0056
Teknika 0054, 0180, 0150,0060, 0019, 0179,0056, 0016, 0092
Telefunken 0056
Toshiba 0154, 0156, 0060, 1256
Vector Research 0030
Victor 0053
Vidikron 0054
Vidtech 0178, 0019
Wards 0054, 0030, 0178, 0021, 0019,0179, 0056, 0016
White Westinghouse 0463, 0623, 0624
Yamaha 0030, 0019
Zenith 0017, 0463, 0016, 0092,0624
Setup Codes For TV/VCR Combos:
Broksonic 0002,0479 (for TV use 0463)
Citizen 0278
Colt 0072
Curtis Mathes 0035 (for TV use 0051)
Daewoo 0278 (for TV use 0624)
Emerson 0002, 0278 (for TV use 0624), 0294 (for TV use 0236),
0479 (for TV use 0463)
Funai 0000
GE 0035 (for TV use 0051), 0048 (for TV use 0093),
0060 (for TV use 0047), 0240
GoldStar 0037 (for TV use 0056)
Harley Davidson 0000
Hitachi 0000
Lloyd’s 0000
Magnasonic 0278, 0563
Magnavox 0000, 0081 (for TV use 0054)
Magnin 0240
Memorex 0037, 0162 (for TV use 0250),1037, 1162,1262
MGA 0240
Mitsubishi 0048 (for TV use 0093)
Optimus 0162 (for TV use 0250), 1162,1262
Orion 0000, 0479 (for TV use 0463)
Panasonic 0035 (for TV use 0051), 0162 (for TV use 0250),1162,
1262
Penney 0035 (for TV use 0051), 0037 (for TV use 0056),0240
Quasar 0035 (for TV use 0051), 0162 (for TV use 0250)
22
Producer 2002 RF Mnl 4/4/02 10:16 AM Page 22
RadioShack 1037
RCA 0035 (for TV use 0051), 0048 (for TV use 0093),
0060 (for TV use 0047), 0240
Sansui 0000, 0479 (for TV use 0463)
Sanyo 0240
Sears 0000,0037 (for TV use 0056)
Sharp 0048 (for TV use 0093)
Sony 0000, 0032 (for TV use 0000)
Sylvania 0081 (for TV use 0054)
Symphonic 0000, 0563
Thomas 0000
White Westinghouse 0278 (for TV use 0624)
Zenith 0000, 0637 (for TV use 0624)
Setup Codes For VCRs:
Admiral 0048, 0209
Adventura 0000
Aiko 0278
Aiwa 0037, 0000
Akai 0041
America Action 0278
American High 0035
Asha 0240
Audiovox 0037
Beaumark 0240
Bell & Howell 0104
Broksonic 0184,0121, 0209,0002, 0479
CCE 0072, 0278
Calix 0037
Canon 0035
Carver 0081
Cineral 0278
Citizen 0037, 0278
Colt 0072
Craig 0037, 0047,0240, 0072
Curtis Mathes 0060,0035,0041, 0162,0760
Cybernex 0240
Daewoo 0045, 0278
Denon 0042
Dynatech 0000
Electrohome 0037
Electrophonic 0037
Emerex 0032
Emerson 0037, 0184, 0000,0121, 0043, 0209, 0002,0278, 0479
Fisher 0047, 0104
Fuji 0035, 0033
Funai 0000
GE 0060, 0035, 0048,0240, 0760
continued on next page...
23
Producer 2002 RF Mnl 4/4/02 10:16 AM Page 23
MANUFACTURER’S CODES
Setup Codes For VCRs (continued):
Garrard 0000
Go Video 0432
GoldStar 0037, 0038
Gradiente 0000
HI-Q 0047
Harley Davidson 0000
Harman/Kardon 0081, 0038
Harwood 0072
Hitachi 0000, 0042, 0041
Hughes Network Sys. 0042
JVC 0067, 0041
Jensen 0041
KEC 0037, 0278
KLH 0072
Kenwood 0067, 0041,0038
Kodak 0035, 0037
LXI 0037
Lloyd’s 0000
Logik 0072
MEI 0035
MGA 0240, 0043
MGN Technology 0240
MTC 0240, 0000
Magnasonic 0278
Magnavox 0035, 0039, 0081, 0000,0149, 0563
Magnin 0240
Marantz 0035, 0081
Marta 0037
Matsushita 0035, 0162
Memorex 0035, 0037, 0048, 0039,0047, 0240,0000, 0104,0209, 0162,
0479, 1037, 1162,1262
Minolta 0042
Mitsubishi 0048, 0067, 0043
Motorola 0035, 0048
Multitech 0000, 0072
NEC 0104, 0067, 0041, 0038
Nikko 0037
Noblex 0240
Olympus 0035
Optimus 0037, 0048,0104, 0162, 0432,1048, 1062, 1162, 1262
Orion 0184, 0209, 0002,0479
Panasonic 0035, 0162, 0225,0616, 1062,1162, 1262, 1362
Penney 0035, 0037, 0240, 0042,0038
Pentax 0042
Philco 0035, 0209, 0479
Philips 0035, 0081, 0618,1081, 1181
Pilot 0037
24
Producer 2002 RF Mnl 4/4/02 10:16 AM Page 24
Loading...
