Datasheet E5CSV Datasheet (OMRON)

Temperature Controllers

E5CSV

Easy Setting Using DIP Switch and Simple
Functions in DIN 48 × 48 mm-size
Temperature Controllers

• Easy setting using DIP and rotary switches.

• Models with two alarms added to Series, ideal for temperature
alarm applications.

• Multi-input (thermocouple/platinum resistance thermometer)
models also available.

• Clearly visible digital display with character height of 13.5 mm.

• Models available with black or white cases.

• RoHS compliant.

Model Number Structure

■ Model Number Legend

Models with Terminal Blocks

E5CSV-@@@@-@

1 2 3 4 5

1. Output type

R: Relay
Q: Voltage for driving SSR

2. Number of alarms

Blank: No alarm
1: 1 alarm
2: 2 alarms

Note: A functional explanation is provided here for illustration, but models are not necessarily available for all possible combinations. Refer to

Ordering Information when ordering.

Examples

• Relay control output, without alarm, thermocouple input, light gray case: E5CSV-RKJ-W

• Relay control output, one alarm output, multi-input, black case: E5CSV-R1T

3. Input type

KJ: Thermocouple
P: Platinum resistance thermometer
T: Thermocouple/platinum resistance

thermometer (multi-input)

4. Power supply voltage

Blank: 100 to 240 VAC
D: 24 VAC/VDC

5. Case color

Blank: Black
W: Light gray

Temperature Controllers E5CSV 1

Ordering Information

■ List of Models

Size Power supply

1/16 DIN

× 48 × 78 mm

48

× H × D)

(W

voltage

100 to 240 VAC 0 Relay E5CSV-RT --- ---

24 VAC/VDC 0 Relay E5CSV-RTD --- ---

Number of

alarm points

1 Relay E5CSV-R1T E5CSV-R1KJ-W E5CSV-R1P-W

2 (See note.) Relay E5CSV-R2T --- ---

1 Relay E5CSV-R1TD --- ---

2 (See note.) Relay E5CSV-R2TD --- ---

Control output TC/Pt multi-input

Voltage (for driving SSR) E5CSV-QT --- ---

Voltage (for driving SSR) E5CSV-Q1T E5CSV-Q1KJ-W E5CSV-Q1P-W

Voltage (for driving SSR) E5CSV-Q2T --- ---

Voltage (for driving SSR) E5CSV-QTD --- ---

Voltage (for driving SSR) E5CSV-Q1TD --- ---

Voltage (for driving SSR) E5CSV-Q2TD --- ---

Case color: Black

Note: Models with two alarm outputs always use the upper limit alarm mode for the alarm 2 output.

■ Accessories (Order Separately)

Protective Cover

Typ e Mo de l

Hard Protective Cover Y92A-48B

Terminal Cover

Model

E53-COV10

TC input

Case color: Light gray

Pt input

Case color: Light gray

Specifications

■ Ratings

Supply voltage 100 to 240 VAC, 50/60 Hz 24 VAC/VDC, 50/60 Hz

Operating voltage range 85% to 110% of rated supply voltage

Power consumption 5 VA 3 VA/2 W

Sensor input Thermocouple input type: K, J, L

Control
output

Control method ON/OFF or 2-PID (with auto-tuning)

Alarm output SPST-NO, 250 VAC, 1A (resistive load)

Setting method Digital setting using front panel keys

Indication method 3.5 digit, 7-segment digital display (character height: 13.5 mm) and deviation indicators

Other functions

Ambient temperature

Ambient humidity 25% to 85%

Storage temperature

Relay output SPST-NO, 250 VAC, 3A (resistive load)

Voltage output (for driving the SSR) 12 VDC, 21 mA (with short-circuit protection circuit)

Platinum resistance ther mometer input type: Pt100, JPt100
Multi-input (thermocouple/platinum resistance thermometer) type: K, J, L, T, U, N, R, Pt100, JPt100

• Setting change prohibit (key protection)

• Input shift

• Temperature unit change (°C/°F)

• Direct/reverse operation

• Temperature range, Sensor switching (K/J/L, Pt100/JPt100)

• Switching is performed between a thermocouple and platinum resistance thermometer for multi-input models.

• Control period switching

• 8-mode alarm output

• Sensor error detection

−10 to 55°C (with no condensation or icing)

−25 to 65°C (with no condensation or icing)

2 Temperature Controllers E5CSV

■ Characteristics

Setting accuracy Thermocouple (See note 1.): (±0.5% of indication value or ±1°C, whichever is greater) ±1 digit max.

Indication accuracy
(ambient temperature of 23

Influence of temperature R thermocouple inputs: (±1% of PV or ±10

Influence of voltage

Platinum resistance ther mometer (See note 2.): (±0.5% of indication value or ±1

°C)

°C, whichever is greater) ±1 digit max.

Other thermocouple inputs: (±1% of PV or ±4
Platinum resistance ther mometer inputs: (±1% of PV or ±2

°C, whichever is greater) ±1 digit max.
°C, whichever is greater) ±1 digit max.

Hysteresis (for ON/OFF control) 0.2% FS (0.1% FS for multi-input (thermocouple/platinum resistance thermometer) models)

Proportional band (P) 1 to 999

°C (automatic adjustment using auto-tuning/self-tuning)

Integral time (I) 1 to 1,999 s (automatic adjustment using auto-tuning/self-tuning

Derivative time (D) 1 to 1,999 s (automatic adjustment using auto-tuning/self-tuning)

Alarm output range Absolute-value alarm: Same as the control range

Other: 0% to 100% FS
Alarm hysteresis: 0.2

°C or °F (fixed)

Control period 2/20 s

Sampling period 500 ms

Insulation resistance 20 M

Ω min. (at 500 VDC)

Dielectric strength 2,000 VAC, 50/60 Hz for 1 min between current-carrying ter minals of different polarity

Vibration
resistance

Malfunction

Destruction 10 to 55 Hz, 0.75-mm single amplitude for 2 hr each in X, Y, and Z directions

Shock resistance Malfunction

Destruction

10 to 55 Hz, 20 m/s

2

min., 3 times each in 6 directions

100 m/s

2

300 m/s

min., 3 times each in 6 directions

2

for 10 min each in X, Y, and Z directions

Life expectancy Electrical 100,000 operations min. (relay output models)

Weight Approx. 120 g (Controller only)

Degree of protection Front panel: Equivalent to IP66; Rear case: IP20; Terminals: IP00

Memory protection EEPROM (non-volatile memory) (number of writes: 1,000,000)

EMC EMI Radiated: EN 55011 Group 1 Class A

EMI Conducted: EN 55011 Group 1 Class A
ESD Immunity: EN 61000-4-2: 4 kV contact discharge (level 2)

Radiated Electromagnetic Field Immunity: EN 61000-4-3: 10 V/m (80-1000 MHz, 1.4-2.0 GHz amplitude modulated) (level 3)

8 kV air discharge (level 3)

10 V/m (900 MHz pulse modulated)
Conducted Disturbance Immunity: EN 61000-4-6: 3 V (0.15 to 80 MHz) (level 2)
Noise Immunity (First Transient Burst Noise): EN 61000-4-4
Burst Immunity: 2 kV power-line (level 3), 1 kV I/O signal-line (level 3)
Surge Immunity: EN 61000-4-5: Power line: Normal mode 1 kV; Common mode 2 kV

Output line (relay output): Nor mal mode 1 kV; Common mode 2 kV
Voltage Dip/Interrupting Immunity: EN 61000-4-11 0.5 cycle, 100% (rated voltage)

Approved standards UL 61010C-1 (listing)

CSA C22.2 No.1010-1

Conformed standards EN 61326, EN 61010-1, IEC 61010-1

VDE 0106 Part 100 (finger protection), when the terminal cover is mounted.

Note: 1. The following exceptions apply to thermocouples.

• U, L: ±2°C ±1 digit max.

• R: ±3°C ±1 digit max. at 200°C or less

2. The following exceptions apply to platinum resistance thermometers.
Input set values 0, 1, 2, 3 for E5CSV: 0.5% FS ±1 digit max.
Input set value 1 for E5CSV: 0.5% FS ±1 digit max.

°C, whichever is greater) ±1 digit max.

■ Electrical Life Expectancy Curve for Relays (Reference Values)

500

300

operations)

4

100

10

×

50

Life (

30

10

5

E5CSV
250 VAC, 30 VDC

3

(resistive load)
cosφ = 1

1

0123456

Switching current (A)

Temperature Controllers E5CSV 3

■ Temperature Range

Thermocouple Input Models

9

8

7

6

2

4

5

range

3

(selected
using switch)

Temperature

0

1

(Default setting: 2)

Minimum setting unit 1°C1°C

Input K J/L

1,000

900
800
700
600
500
400
300
200
100

Setting number

500 500

400 400

300 300

200 200

0

0000000000

0123456789

999

600

The shaded value indicates the d efault

setting status.

Platinum Resistance Thermometer Input Models

9

8

7

6

2

4

5

range

3

(selected
using switch)

Temperature

0

1

(Default setting: 3)

Minimum setting unit 1°C0.1°C1°C0.1°C1°C0.1°C

Setting number

Input JPt100/Pt100

500
400
300
200

50 50.0 80 99.9

100

−100

0

0.0 0.0000000.0

−50 −20

200 199.9

400 400

300 300

0123456789

The shaded value indicates the d efault

setting status.

Multi-input (Thermocouple/Platinum Resistance Thermometer) Models

• Using Thermocouple Sensors, Control Mode Switch 5: OFF

Input K J L T UNR

1,700
1,600
1,500
1,400

1,300 1,300

9

8

7

6

2

4

5

range
(selected

3

using switch)

Temperature

0

1

(Default setting: 0)

Setting number

1,300
1,200
1,100
1,000

900
800
700
600
500
400
300
200
100

0

−100

−99 −99 −99 −99 −99 −99

850 850

400 400

199.9 199.9 199.9

0.0 0.0 0.0 0

0123456789

Minimum setting unit 1°C0.1°C1°C0.1°C1°C0.1°C1°C

• Using Platinum Resistance Thermometers, Control Mode Switch 5: ON

Input Pt100 JPt100

9

8

7

6

2

4

5

range
(selected

3

using switch)

Temperature

0

1

(Default setting: 0)

Minimum setting unit 1°C0.1°C1°C0.1°C1°C

Setting number

1,000

850

900
800
700
600
500
400
300
200
100

−100

0

199.9 200 199.9 200
99 99

0.0000.000

−99 −99 −99 −99

500

400 400

0123456789

1,700

The shaded value indicates the d efault

setting status.

The shaded value indicates the defaul t

setting status.

4 Temperature Controllers E5CSV

External Connection Diagram

)

)

Voltage output

models

(See note 1.)

Relay output

models

Relay outputVoltage output

Alarm output

11

12 VDC,

21 mA

2

A

3

B

4

B

5

Platinum resistance

thermometer input

platinum resistance thermometer multi-input

Thermocouple/

1

2

2

3

4

5

Thermocouple

input

6

7

8

9

100 to 240 VAC, 50/60 Hz
(24 VAC/VDC)
(See note 2.)

10

Alarm output 2 (See note 3.

Alarm output 1 (See note 3.

Note: 1. The voltage output (12 VDC, 21 mA) is not electrically isolated from the internal circuits. When using a grounding thermocouple, do not

connect output terminals 1 or 2 to ground. Otherwise, unwanted current paths will cause measurement errors.

2. Models with 100 to 240 VAC and 24 VAC/VDC are separate. Models using 24 VDC have no polarity.

3. The number of alarm outputs depends on the model.

Nomenclature

E5CSV Models with Terminal Blocks

Deviation indicators

Mode indicators

Mode Key

Lock Release Key

Output indicator

Temperature display

Alarm indicators

Up Key

Down Key

Temperature Controllers E5CSV 5

Operation

E5CSV

Deviation indicators

The indicator lights when the PV is greater than
the SP and the indicator lights when the PV is
less than the SP. The indicator (green) lights
when the deviation is less than 1% FS (0.25% FS
for multi-input models). These indicators flash
during ST (self-tuning)/AT (auto-tuning).

Mode indicators

The SP indicator lights when the setting
temperature is being displayed. The ALM
indicator lights when the alarm value 1 is
being displayed and flashes when the alarm
value 2 is being displayed.

Mode Key

When the power is turned ON, normally the
display will use the display items in the following
order each time the Mode Key is pressed.

Power ON

PV

Press the Key.

SP

Press the Key.

Alarm value 1

Press the Key.

Alarm value 2

Press the Key.

Input shift value

Press the Key.

This item is not displayed when
the Control Mode Switch 4 is OFF.

Lock Release Key

When the protect switch is ON, the set
value can be changed by pressing the Up
and Down Keys while holding down the
Lock Release Key.

PV, SP, Alarm Value, Input Shift Display

The display switches each time the
Key is pressed.

Output indicator

Lights when the control output is ON.

Alarm indicators

ALM1 (Alarm 1): Lights when the alarm 1

output is ON.

ALM2 (Alarm 2): Lights when the alarm 2

output is ON.

Up Key

Pressing the Up Key increases the
SP/alarm value display. Keeping the Up
Key pressed continues to increase the
display value. When the internal protect
switch is ON, press the Up Key while
holding down the Lock Release Key.

Down Key

Pressing the Down Key decreases the
SP/alarm value display. Keeping the Down
Key pressed continues to decrease the
display value. When the internal protect
switch is ON, press the Down Key while
holding down the Lock Release Key.

Settings before Turning ON the Power

E5CSV

Remove the E5CSV from the case to make the settings.

1. Insert the tool into the two tool insertion holes (one on the top and
one on the bottom) and release the hooks.

Tool insertion hole

Flat-blade screwdriver
(Unit: mm)

20 min.

0.4 2.0

(3)

(2)

(1)

(1)

2. Insert the tool in the gap between the front panel and rear case,
and pull out the front panel slightly. Grip the front panel and pull
out fully. Be sure not to impose excessive force on the panel.

3. When inserting the E5CSV, check to make sure that the sealing
rubber is in place and push the E5CSV toward the rear case until
it snaps into position. While pushing the E5CSV into place, push
down on the hooks on the top and bottom surfaces of the rear
case so that the hooks are securely locked in place. Make sure
that electronic components do not come into contact with the
case.

Control mode switches

ON

PONX123456

Note: 1. The alarm mode switch is not provided on models without alarms.

Alarm 2 is always set to the upper limit in models with two alarms.
A setting switch is not provided for alarm 2.

2. The INIT switch is always OFF during normal operation.

INIT switch
(See note 2.)

Protect switch

Alarm mode switch (See note 1.)

Temperature range switch

6 Temperature Controllers E5CSV

1. Sensor Type Specification

Select the number on the temperature range switch to change
the temperature range.

Thermocouple (The default is 2.)

Input K J/L

1,000

900
800
700

SP
range

Setting number

• The control range is

Note: The input indication range is the range that can be displayed for the

600
500
400
300
200
100

300 300

200 200

0

0000000000

500 500

400 400

0123456789

−10% to +10% FS for each temperature range.

control range (
but exceeds the display range (
be displayed as “[[[“ and values above 1,999 will be displayed as
“]]].”

−99 to 1999). If the input is within the control range

Platinum Resistance Thermometer

(The default is 3.)

Input JPt100/Pt100

500
400

SP
range

Setting number

• The control range is

Note: 1. The input indication range is the range that can be displayed for

300
200

50 50. 0 80 99.9

100

0

−100

0.0 0.0000000.0

−50 −20

0123456789

−10% to +10% FS for each temperature range.

the control range (
range but exceeds the display range (

−99 will be displayed as “[[[“ and values above 1,999

below
will be displayed as “]]].”

2. If the unit is changed to 1 degree when the SP and alarm value
for the temperature range are displayed in 0.1-units from 0.0 to

199.9 or 0.0 to 99.9, the values will be multiplied by 10 (e.g., 0.5
becomes 5). If the unit is changed in the reverse direction, the
values will be divided by 10. After changing the range, set the
SP and alarm value again.

3. The temperature range for setting numbers 5 and 6 are the
same as for 7 and 8, respectively.

−99 to 1999). If the input is within the control

999

600

−99 to 1999), values below −99 will

400 400

300 300

200 199.9

−99 to 1999), values

Multi-input (Thermocouple/Platinum
Resistance Thermometer) Models

• Using Thermocouple Sensors, Control Mode Switch 5: OFF

Input K J L T U N R

1,700
1,600
1,500
1,400

1,300 1,300

1,300
1,200
1,100

SP
range

1,000

900
800
700
600
500
400
300
200
100

0

−100

−99 −99 −99 −99 −99 − 99

850 850

400 400

199.9 199.9 199.9

0.0 0.0 0.0 0

Setting number 0123456789

• The control range is

−20°C to +20°C of the input temperature

range.

Note: 1. The input indication range is the range that can be displayed for

the control range (
range but exceeds the display range (

−99 will be displayed as “[[[“ and values above 1,999

below
will be displayed as “]]].”

2. If unit is changed to 1 degree when the SP and alarm value for
the temperature range are displayed in 0.1-units from 0.0 to

199.9 or 0.0 to 99.9, the values will be multiplied by 10 (e.g., 0.5
becomes 5). If the unit is changed in the reverse direction, the
values will be divided by 10. After changing the range, set the
SP and alarm value again.

−99 to 1999). If the input is within the control

−99 to 1999), values

• Using Platinum Resistance Thermometers,
Control Mode Switch 5: ON

Input Pt100 JPt100

1,000

850

900
800
700

SP
range

Setting number

600
500
400
300
200
100

0

−100

−99 −99 −99 −99

0123456789

• The control range is

199.9 200 199.9 200
99 99

0.0 0 0 0.0 0 0

−20°C to +20°C of the input temperature

500

400 400

range.

Note: 1. The input indication range is the range that can be displayed for

the control range (
range but exceeds the display range (

−99 will be displayed as “[[[“ and values above 1,999

below
will be displayed as “]]].”

2. If unit is changed to 1 degree when the SP and alarm value for
the temperature range are displayed in 0.1-units from 0.0 to

199.9 or 0.0 to 99.9, the values will be multiplied by 10 (e.g., 0.5
becomes 5). If the unit is changed in the reverse direction, the
values will be divided by 10. After changing the range, set the
SP and alarm value again.

−99 to 1999). If the input is within the control

−99 to 1999), values

1,700

Mode Key Display Order

Power ON

PV

Press the Key.

SP

Press the Key.

Alarm value 1

Press the Key.

Alarm value 2

Press the Key.

Input shift value

Press the Key.

Temperature Controllers E5CSV 7

• If the SP falls outside the temperature
range when the temperature range is
changed, the SP will be displayed first.
The SP will be changed automatically
either to the minimum value or the
maximum value, whichever is nearest.

• If the alarm value falls outside the
temperature range when the
temperature range is changed, the
alarm value will be displayed first. The
alarm value will be changed
automatically to the maximum value in
the new temperature range.

2. Operation Settings

Use the control mode switches ( ) to change the

control mode. (All switches are OFF for the default settings.)

Function selection 1 2 3 4 5 6

ON/OFF
PID

Control
period

Direct/
reverse
opera­tion

Input
shift
display

Tempera­ture
Sensor
selection

Tempe r­ature
unit

PID control

ON/OFF control

2 s

20 s

Direct operation
(cooling)

Reverse operation
(heating)

Enabled

Disabled

Thermo­couple

Platinum
resistance
thermome­ter

Multi-input
(thermo­couple/
platinum
resistance
thermome­ter)

K, L

K, J

Pt100

JPt100

Platinum
resis­tance
thermom­eter
input

Thermo­couple
input

°F

°C

Note: The previous name Pt100 has been changed to JPt100 in

accordance with revisions to JIS. The previous name J-DIN has
been changed to L in accordance with revisions to DIN
standards.

ON

654321

ON

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON

OFF

654321

ON

OFF

3. Alarm Modes

0

1

9

2

8

SP

OFF

ON

3

7

4

6

5

XSPX

SP

X

SP

XSPX

XSPX

SP

X

SP

0

X

X

Y

Select the number of the alarm mode switch when changing

the alarm mode. (The default is 2).

Set

Alarm type Alarm output operation

value

0, 9 Alarm function OFF OFF

Upper- and lower-

1

limit

Upper-limit

2

Lower-limit

3

Upper- and lower-

4

limit range

ON

OFF

ON

OFF

ON

OFF

ON

OFF

Upper- and lower­limit with standby

5

sequence (See note

ON

OFF

2.)

Upper-limit with

6

standby sequence
(See note 2.)

Lower-limit with

7

standby sequence
(See note 2.)

Absolute-value

8

upper-limit

ON

OFF

ON

OFF

ON

OFF

Note: 1. No alarm. The alarm value (alarm operation display) will not

be displayed when the setting is 0 or 9 even if the selection
key is pressed.
Alarm Setting Range
X: 0 to FS (full scale); Y: Within temperature range
The value of X is the deviation setting for the SP (set point).

2. Standby Sequence Function (The standby sequence
operates when the power is turned ON.)

Rising Temperature

Upper-limit
alarm

SP

Lower-limit
alarm

Alarm

ON

output

OFF

Dropping Temperature

Upper-limit
alarm

Lower-limit
alarm

Alarm
output

Note: Turn OFF the power before changing the DIP switch settings on the E5CSV. Each of the switch settings will be enabled after the power is

turned ON.

For details on the position of the temperature range switch, control mode switches, and alarm mode switch, refer to page 6.

8 Temperature Controllers E5CSV

4. Using the Control Mode Switches

(1) Using ON/OFF Control and PID Control

ON/OFF Control

The control mode is set to ON/OFF control as the default setting. To perform cooling control of freezers, etc., turn ON switch 3.

ON

ON

654321

Switch 1 OFF: ON/OFF control

ONControl output

OFF

SP

PID Control

Turn ON switch 1 to use PID control.

ON

654321

Switch 1 ON: PID control

1. Set the control period.
Performing Control via Relay Output, External Relay, or
Conductor

Switch 2: OFF (control period: 20 s)

ON

654321

ONControl output

OFF

20 s

Quick Control Response Using an SSR

Switch 2: ON (control period: 2 s)

ON

654321

ONControl output

OFF

SP

2. Set direct/reverse operation for the output.
Performing Heating Control for Heaters

Switch 3: OFF

ON

654321

Output level

100%

0%

SP

Performing Cooling Control for Freezers

Switch 3: ON

ON

654321

ONControl output

OFF

2 s

ST (Self-tuning) Features

ST (self-tuning) is a function that finds PID constants by
using step response tuning (SRT) when Controller
operation begins or when the set point is changed. Once
the PID constants have been calculated, ST is not
executed when the next control operation is started as
long as the set point remains unchanged. When the ST
function is in operation, be sure to turn ON the power
supply of the load connected to the control output
simultaneously with or before starting Controller
operation.

654321

Output level

100%

0%

SP

Executing AT (Auto-tuning)

AT (auto-tuning) is executed by pressing the U Up and D Down Keys for at
least 2 s while the PV is displayed. The deviation indicators flash during auto­tuning (AT) execution. AT will be cancelled by performing the same operation
that AT is executing during AT operation. Flashing stops when AT is completed.

AT execution

UD

Press for

at least 2 s.

AT execution in progress

AT cancelled

UD

Press for

AT execution in progress

Note: One of the deviation indicators (▲■▼) will flash.

Temperature Controllers E5CSV 9

at least 2 s.

(2) Using the E5CSV in Devices for Fahrenheit-scale Users

(Displaying in °F)

Turn ON switch 6 to display temperatures in

ON

°F.

654321

Temperature Range for °F

The temperature is set to °F using the same temperature range switch as °C.

Thermocouple Platinum Resistance

Set­ting

0 K 0 to 200 0 JPt100

1 0 to 300 1 0.0 to 50.0 1 0.0 to 199.9 1 0.0 to 199.9

2 0 to 400 2

3 0 to 500 3 0.0 to 99.9 3 0.0 to 199.9 3 0 to 200

4 0 to 600 4 0 to 200 4 L

5 0 to 999 5 0 to 300 5 T

6 J/L 0 to 999 6 0 to 400 6 0.0 to 199.9 6 0.0 to 199.9

7 0 to 300 7 0 to 600 7 U

8 0 to 400 8 0 to 800 8 N

9 0 to 500 9 0.0 to 199.9 9 R 0 to 1999 9 0 to 400

°FSet-

Thermometer

ting

or
Pt100

°FSet-

−50 to 50 0 K −99 to 1999 0 Pt100 −99 to 1500

−20 to 80 2 J −99 to 1500 2 −99 to 99

Multi-input (Thermocouple/
Platinum Resistance
Thermometer)

Control mode switch 5: OFF

°FSet-

ting

−99 to 1500 4 0 to 400

−99 to 700 5 JPt100 −99 to 900

−99 to 700 7 −99 to 99

−99 to 1999 8 0 to 200

Multi-input (Thermocouple/
Platinum Resistance
Thermometer)

Control mode switch 5: ON

°F

ting

Note: The control range for a thermocouple input or platinum resistance thermometer input is

The control range for multi-input (thermocouple/platinum resistance thermometer) models is

Using K, L/Pt100 Thermometers

Turn ON switch 5 when using K, L/Pt100 Thermometers.

ON

654321

Note: The previous name J-DIN has been changed to L in accordance with revisions to DIN standards.

−10% to +10% FS for each temperature range.

−40 to +40°F of each temperature range.

(3) Setting Input Shift

Turn ON switch 4, and after turning ON the power, press the Mode
Key until h0 (indicates input shift of 0) is displayed. Press the Up and
Down Keys to set the shift value.

ON

654321

Shift Example

Input shift display Measured temperature Temperature

h0 (no shift) 100

h9 (+9

°C shift) 100°C 109°C

l9 (

−9°C shift) 100°C91°C

Note: When control mode switch 4 is turned OFF (no input shift

display), the input shift is not displayed but the shift value is
enabled. To disable input shift, set the input shift value to h0.
The shift range depends on the setting unit.

Setting unit 1

Compensation range

Input shift display L99 to H99 L9.9 to H9.9

display

°C 100°C

°C0.1°C

−99 to +99°C −9.9 to +9.9°C

10 Temperature Controllers E5CSV

5. Protect Switch

p

g

Protect Switch

PONX123456

When the protect switch is ON, Up Key and Down Key operations are prohibited to prevent setting mistakes.

Installation

• All models in the E5CSV Series conform to DIN 43700 standards.

• The recommended panel thickness is 1 to 4 mm.

• Be sure to mount the E5CSV horizontally.

Mounting the E5CSV

1. For waterproof mounting, waterproof packing must be installed on the Controller. Waterproofing is not possible when group mounting several

Controllers.

2. Insert the E5CSV into the mounting hole in the panel.

3. Push the adapter from the terminals up to the panel, and temporarily fasten the E5CSV.

4. Tighten the two fastening screws on the adapter. Alternately tighten the two screws little by little to maintain a balance. Tighten the screws to a

torque of 0.29 to 0.39 N·m.

Adapter

Tightening screw

roof packin

PanelWater

Tightening screw

Temperature Controllers E5CSV 11

Error Displays and Causes

In addition to the alarm indicator, errors notification is provided on the display. Be sure to remove the cause of the error promptly.

Display status Cause Control output

PV displayed as

fff

PV displayed as

---

fff flashing (1) Thermocouple models and platinum resistance thermometer models:

The process value is higher than the control temperature range (overflow). Heating control (reverse operation): OFF

Cooling control (direct operation): ON

The process value is lower than the control temperature range (underflow). Heating control (reverse operation): ON

Cooling control (direct operation): OFF

OFF
The process value is higher than the overflow temperature, or a Sensor error has
occurred.

(2)Multi-input (Thermocouple/platinum resistance thermometer) models:

The process value is higher than the control temperature range or a Sensor error
has occurred.

--- flashing (1) Thermocouple and platinum resistance thermometer input:

OFF
The process value is lower than the underflow temperature, or a Sensor error has
occurred.

(2) Thermocouples: The polarity is reversed.
(3)Multi-input (Thermocouple/platinum resistance thermometer) models:

The process value is lower than the control temperature range or a Sensor error has
occurred.

e11 is
displayed

Note: In models with an alarm, fff appears or flashes on the display to indicate that the temperature has exceeded the maximum display temperature and the output

is set according to the alarm mode. In the same way, --- appears or flashes on the display to indicate that the temperature has exceeded the minimum display
temperature and the output is set according to the alarm mode.

A memory error (E11) has occurred. Turn the power ON again. If the display remains
the same, the Controller must be repaired.

The control outputs and alarm outputs

turn OFF.

Sensor Error Displays and Causes

■ Thermocouple

Status Display Control output

Burnout fff flashing OFF

Note: The room temperature is displayed if an input short-circuit occurs.

■ Platinum Resistance Thermometer

Status Display Control output

Burnout fff flashing OFF

2 or 3 wires disconnected fff flashing OFF

Short-circuit --- flashing OFF

3

4

5

3

4

5

3

4

5

--- flashing OFF

Note: The resistance value for platinum resistance thermometers is 100 Ω at 0°C and 140 Ω at 100°C.

12 Temperature Controllers E5CSV

Comparison with E5CS-X

■ Model Number Legend

Previous model E5CSV

E5CS-@@@X

1 2 3

Classification Symbol Meaning Classification Symbol Meaning

1 Control output R

Q

2 Alarm output Blank

1

3 Input type KJ

P

Terminal
appearance

Main Differences

Terminal block models use the model number E5CSV.
The suffix “D” is added to models with a supply voltage of
24 VAC/VDC.
The suffix “W” is added to models with a light gray case color.

X Model with terminal block

Relay: SPDT (single-pole,
double-throw)

Voltage

No alarms
One alarm

Thermocouple (K, J)
Platinum resistance

thermometer (Pt100,
JPt100)

E5CSV-@@@@-@

1 2 3

4 5

1 Control output R

Q

2 Alarm output Blank

1
2

3 Input type KJ

P

T

4 Voltage

specifications

5 Case color Blank

Blank
D

W

Relay: SPST-NO (single-pole,
single-throw, normally open)

Voltage

No alarms
One alarm
Two alarms

Thermocouple (K, J)
Platinum resistance thermometer

(Pt100, JPt100)
Multi-input (thermocouple/

platinum resistance
thermometer) models

100 to 240 VAC
24 VAC/VDC

Black
Light gray

■ Display

Previous model E5CSV

ALALSP

The display digits can be increased up to 1,999.
The ALM2 display has been added.
The display “ON” has changed to “OUT” and “AL” has changed to “ALM.”

■ Functions

The control outputs for relay outputs have been changed from SPDT (single-pole, double-throw) to SPST-NO (single-pole, single-throw, normally
open) contacts.
The control method has been changed to 2-PID control.
An auto-tuning (AT) function has been added.
The deviation display flashes during self-tuning (ST) and auto-tuning (AT).
The control calculation period has been improved from 2 s to 0.5 s.

■ External Dimensions

The depth has been shortened from 100 mm to 76 mm.

Temperature Controllers E5CSV 13

■ Terminal Arrangement

• The terminal arrangement has changed from a horizontal to vertical configuration.

Previous model E5CSV

100 to 240 VAC,
50/60 Hz or 24 VAC/VDC,
50/60 Hz

87

SOURCE

876

321

B

10

9

5

4

ALARM

250 VAC, 1 A

(Resistive load)

12 VDC,

21 mA

2

A

3

B

4

B

5

Platinum resistance

thermometer input

Multi-input (thermocouple/platinum resistance thermometer)

250 VAC, 3 A
(Resistive load)

Thermocouple

input

Platinum resistance

A

thermometer input

12 VDC,

20 mA

B

■ DIP Switch and Rotary Switch Setting Methods

No change from previous models.

Relay outputVoltage output

11

1

2

2

3

4

5

Thermocouple

input

6

7

8

9

10

Alarm output 2

Alarm output 1

100 to 240 VAC,
50/60 Hz
(24 VAC/VDC)

14 Temperature Controllers E5CSV

Dimensions

92A -48 B

Note: All units are in millimeters unless otherwise indicated.

■ Controller

E5CSV

48×48

Note: Terminals cannot be removed.

E5CSV + Adapter for Flush Mounting
(Provided)

58

Hard Protective Cover

The Y92A-48B Protective Cover (hard type) is available for the
following applications.

• To protect the set from dust and dirt.

• To prevent the panel from being accidentally touched causing

displacement of set values.

• To provide effective protection against water droplets.

84

786

Adapter for flush mounting

48

Terminal Cover

E53-COV10

Panel Cutout Dimensions

+0.6

45

44.8×44.8

7.5

+0.6

45

0

60 min.

Y92F-30 Adapter for flush mounting

Panel

Tightening
screws

76.5

0

+0.6

45

0

L = (48 × N−2.5)
Mounting side-by-side
(group mounting of N Controllers)

L

+1
0

Note: 1. The recommended panel thickness is 1 to 4 mm.

2. Group mounting is possible in one direction only.

48

48.8

°C

22

9

2

9

A

2

A

-4

-4

8

B

8

B

9.1

Temperature Controllers E5CSV 15

Precautions

!CAUTION

Do not touch the terminals while power is being supplied.
Doing so may occasionally result in minor injury due to
electric shock.

Do not allow pieces of metal, wire clippings, or fine
metallic shavings or filings from installation to enter the
product. Doing so may occasionally result in electric
shock, fire, or malfunction.

Do not use the product where subject to flammable or
explosive gas. Otherwise, minor injury from explosion
may occasionally occur.

Never disassemble, modify, or repair the product or touch
any of the internal parts. Minor electric shock, fire, or
malfunction may occasionally occur.

CAUTION - Risk of Fire and Electric Shock
a) This product is UL listed as Open Type Process

Control Equipment. It must be mounted in an
enclosure that does not allow fire to escape externally.

b) More than one disconnect switch may be required to

de-energize the equipment before servicing the

product.
c) Signal inputs are SELV, limited energy. (See note 1.)
d) Caution: To reduce the risk of fire or electric shock, do

not interconnect the outputs of different Class
2 circuits. (See note 2.)

If the output relays are used past their life expectancy,
contact fusing or burning may occasionally occur. Always
consider the application conditions and use the output
relays within their rated load and electrical life
expectancy. The life expectancy of output relays varies
considerably with the output load and switching
conditions.

Loose screws may occasionally result in fire.
Tighten terminal screws to the specified torque of 0.74 to

0.90 N·m.

Unexpected operation may result in equipment damage
or accidents if the settings are not appropriate for the
controlled system. Set the Temperature Controller as
follows:

• Set the parameters of the Temperature Controller so

that they are appropriate for the controlled system.

• Turn the power supply to the Temperature Controller

OFF before changing any switch setting. Switch settings
are read only when the power supply is turned ON.

• Make sure that the INIT switch in the control mode

switches is turned OFF before operating the
Temperature Controller.

A malfunction in the Temperature Controller may
occasionally make control operations impossible or
prevent alarm outputs, resulting in property damage.
To maintain safety in the event of malfunction of the
Temperature Controller, take appropriate safety
measures, such as installing a monitoring device on a
separate line.

Faulty terminal contact or decreased waterproofing
capability may result in a fire or equipment malfunction.
When inserting the Temperature Controller into the rear
case after setting the switches, check the watertight
packing and make sure that the top and bottom hooks are
locked securely in place.

Note: 1. A SELV circuit is one separated from the power supply with

double insulation or reinforced insulation, that does not
exceed 30 V r.m.s. and 42.4 V peak or 60 VDC.

2. A class 2 power supply is one tested and certified by UL as
having the current and voltage of the secondary output
restricted to specific levels.

■ Precautions for Safe Use

Be sure to observe the following precautions to prevent operation
failure, malfunction, or adverse affects on the performance and
functions of the product. Not doing so may occasionally result in
unexpected events.

1. The product is designed for indoor use only. Do not use the
product outdoors or in any of the following locations.

• Places directly subject to heat radiated from heating equipment.

• Places subject to splashing liquid or oil atmosphere.

• Places subject to direct sunlight.

• Places subject to dust or corrosive gas (in particular, sulfide gas

and ammonia gas).

• Places subject to intense temperature change.

• Places subject to icing and condensation.

• Places subject to vibration and large shocks.

2. Use and store the product within the rated temperature and

humidity ranges.
Group-mounting two or more Temperature Controllers, or
mounting Temperature Controllers above each other may cause
heat to build up inside the Temperature Controllers, which will
shorten their service life. In such a case, use forced cooling by
fans or other means of air ventilation to cool down the
Temperature Controllers.

3. To allow heat to escape, do not block the area around the product.
Do not block the ventilation holes on the product.

4. Use the specified size (M3.5, width of 7.2 mm or less) crimped
terminals for wiring. To connect bare wires to the terminal block,
use copper braided or solid wires with a gage of AWG24 to
AWG18 (equal to a cross-sectional area of 0.205 to 0.832 mm
(The stripping length is 5 to 6 mm.) Up to two wires of the same
size and type, or two crimp terminals can be inserted into a single
terminal.

5. Be sure to wire properly with correct polarity of terminals. Do not
wire any of the I/O terminals incorrectly.

6. Do not wire the terminals that are not used.

7. The voltage output (control output) is not electrically isolated from

the internal circuits. When using a grounded temperature sensor,
do not connect any of the control output terminals to ground.
Otherwise unwanted current paths will cause measurement
errors.

8. To avoid inductive noise, keep the wiring for the Temperature
Controller's terminal block away from power cables carrying high
voltages or large currents. Also, do not wire power lines together
with or parallel to Temperature Controller wiring. Using shielded
cables and using separate conduits or ducts is recommended.
Attach a surge suppressor or noise filter to peripheral devices that
generate noise (in particular, motors, transformers, solenoids,
magnetic coils or other equipment that have an inductance
component).
When a noise filter is used at the power supply, first check the
voltage or current, and attach the noise filter as close as possible
to the temperature controller.
Allow as much space as possible between the Temperature
Controller and devices that generate powerful high frequencies
(high-frequency welders, high-frequency sewing machines, etc.)
or surge.

2

).

16 Temperature Controllers E5CSV

9. Use the product within the rated load and power supply.

10.Use a switch, relay, or other contact so that the power supply

voltage reaches the rated voltage within 2 seconds. If the applied
voltage is increased gradually, the power supply may not be reset
or malfunctions may occur.

11.When using PID operation (self-tuning), turn ON the power supply
to the load (e.g., heater) at the same time or before turning the
power supply to the Temperature Controller ON. If power is turned
ON for the Temperature Controller before turning ON power
supply to the load, self-tuning will not be performed properly and
optimum control will not be achieved.

12.Design the system (e.g., control panel) to allow for the 2 seconds
of delay required for the Temperature Controller's output to
stabilize after the power is turned ON.

13.A switch or circuit breaker should be provided close to this unit.
The switch or circuit breaker should be within easy reach of the
operator, and must be marked as a disconnecting means for this
unit.

14.Approximately 30 minutes is required for the correct temperature
to be displayed after turning the power supply to the Temperature
Controller ON. Turn the power supply ON at least 30 minutes prior
to starting control operations.

15.Be sure that the platinum resistance thermometer type and the
input type set on the Temperature Controller are the same.

16.When extending the thermocouple lead wires, always use
compensating conductors suitable for the type of thermocouple.
Do not extend the lead wires on a platinum resistance
thermometer. Use only low-resistance wire (5
lead wires and make sure that the resistance is the same for all
three wires.

17.When drawing out the Temperature Controller from the case, do
not apply force that would deform or alter the Temperature
Controller.

18.When drawing out the Temperature Controller from the case to
replace the Temperature Controller, check the status of the
terminals. If corroded terminals are used, contact faults with the
terminals may cause the temperature inside the Temperature
Controller to increase, possibly resulting in fire. If the terminals
are corroded, replace the rear case as well.

19.When drawing out the Temperature Controller from the case, turn
the power supply OFF first, and absolutely do not touch the
terminals or electronic components or apply shock to them. When
inserting the Temperature Controller, do not allow the electronic
components to come into contact with the case.

20.Static electricity may damage internal components. Always touch
grounded metal to discharge any static electricity before handling
the Temperature Controller. When drawing out the Temperature
Controller from the case, do not touch the electronic components
or patterns on the board with your hand. Hold the Temperature
Controller by the edge of the front panel when handling it.

21.Do not use paint thinner or similar chemical to clean with. Use
standard grade alcohol.

22.Use tools when separating parts for disposal. Contact with the
sharp internal parts may cause injury.

Ω max. per line) for

■ Precautions for Correct Use

Service Life

Use the Temperature Controller within the following temperature and
humidity ranges:

Temperature:
Humidity: 25% to 85%

If the Controller is installed inside a control board, the ambient
temperature must be kept to under 55
around the Controller.

The service life of electronic devices like Temperature Controllers is
determined not only by the number of times the relay is switched but
also by the service life of internal electronic components. Component
service life is affected by the ambient temperature: the higher the
temperature, the shorter the service life and, the lower the
temperature, the longer the service life. Therefore, the service life
can be extended by lowering the temperature of the Temperature
Controller.

When two or more Temperature Controllers are mounted horizontally
close to each other or vertically next to one another, the internal
temperature will increase due to heat radiated by the Temperature
Controllers and the service life will decrease. In such a case, use
forced cooling by fans or other means of air ventilation to cool down
the Temperature Controllers. When providing forced cooling,
however, be careful not to cool down the terminals sections alone to
avoid measurement errors.

−10 to 55°C (with no icing or condensation)

°C, including the temperature

Measurement Accuracy

When extending or connecting the thermocouple lead wire, be sure
to use compensating wires that match the thermocouple type. Do not
extend the lead wire of the platinum resistance thermometer. If the
lead wire of the platinum resistance thermometer must be extended,
be sure to use wires that have low resistance and keep the
resistance of the three lead wires the same.

Mount the Temperature Controller so that it is horizontally level.

If the measurement accuracy is low, check whether the input shift
has been set correctly.

Waterproofing

The degree of protection is as shown below. Sections without any
specification on their degree of protection or those with IP@0 are not
waterproof.

Front panel: IP66, rear case: IP20, terminals: IP00

Temperature Controllers E5CSV 17

18 Temperature Controllers E5CSV

Temperature Controllers E5CSV 19

Warranty and Application Considerations

Read and Understand this Catalog

Please read and understand this catalog before purchasing the products. Please consult your OMRON representative if you
have any questions or comments.

Warranty and Limitations of Liability

WARRANTY

OMRON's exclusive warranty is that the products are free from defects in materials and workmanship for a period of one year (or
other period if specified) from date of sale by OMRON.

OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING NON-INFRINGEMENT,
MERCHANTABILITY, OR FITNESS FOR PARTICULAR PURPOSE OF THE PRODUCTS. ANY BUYER OR USER
ACKNOWLEDGES THAT THE BUYER OR USER ALONE HAS DETERMINED THAT THE PRODUCTS WILL SUITABLY MEET
THE REQUIREMENTS OF THEIR INTENDED USE. OMRON DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED.

LIMITATIONS OF LIABILITY

OMRON SHALL NOT BE RESPONSIBLE FOR SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, LOSS OF PROFITS,
OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS BASED ON
CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY.

In no event shall the responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted.
IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS REGARDING THE

PRODUCTS UNLESS OMRON'S ANALYSIS CONFIRMS THAT THE PRODUCTS WERE PROPERLY HANDLED, STORED,
INSTALLED, AND MAINTAINED AND NOT SUBJECT TO CONTAMINATION, ABUSE, MISUSE, OR INAPPROPRIATE
MODIFICATION OR REPAIR.

Application Considerations

SUITABILITY FOR USE

OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to the combination of
products in the customer's application or use of the products.

Take all necessary steps to determine the suitability of the product for the systems, machines, and equipment with which it will
be used.

Know and observe all prohibitions of use applicable to this product.
NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR PROPERTY WITHOUT

ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO ADDRESS THE RISKS, AND THAT THE OMRON
PRODUCTS ARE PROPERLY RATED AND INSTALLED FOR THE INTENDED USE WITHIN THE OVERALL EQUIPMENT OR
SYSTEM.

Disclaimers

PERFORMANCE DATA

Performance data given in this catalog is provided as a guide for the user in determining suitability and does not constitute a
warranty. It may represent the result of OMRON's test conditions, and the users must correlate it to actual application
requirements. Actual performance is subject to the OMRON Warranty and Limitations of Liability.

CHANGE IN SPECIFICATIONS

Product specifications and accessories may be changed at any time based on improvements and other reasons. Consult with
your OMRON representative at any time to confirm actual specifications of purchased product.

DIMENSIONS AND WEIGHTS

Dimensions and weights are nominal and are not to be used for manufacturing purposes, even when tolerances are shown.

ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.

To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.

Cat. No. H138-E1-01

In the interest of product improvement, specifications are subject to change without notice.

OMRON Corporation

Industrial Automation Company

Control Devices Division H.Q.
Analog Controller Division

Shiokoji Horikawa, Shimogyo-ku,
Kyoto, 600-8530 Japan
Tel: [phone]/Fax: [phone]

Printed in Japan
0805-1M (0805) (B)
