CP-series CP1E CPU Units

CP1E-E20SDR-A

CP1E-N40S1DR-A

CP1E-E@@SD@-@ CP1E-N@@S@D-@-@ CP1E-E@@D@-@ CP1E-N@@D@-@/NA20D@-@

The CP1E Programmable Controller: Economical, Easy to use, and Efficient

■ The E@@(S)-type Basic CPU Units provide cost

performance and easy application with only basic functionality.

■ The N@@(S@) and NA-types Application CPU Units

support Programmable Terminal connection, position control, and inverter connection

Features

• New CP1E CPU Units now available.

- Lineup including CPU Units with built-in three ports: USB, RS-232C, RS-485.

- The depth of CPU Units with RS-232C connectors is reduced by 20 mm. (N30/40/60S(1))

• Easy connection with computers using commercially available USB cables.

• With E30/40/60(S), N30/40/60(S@) or NA20 CPU Units, Add I/O, Analog I/O or Temperature Inputs by Connecting

Expansion Units or Expansion I/O Units.

• Input interrupts

• Complete High-speed Counter Functionality.

• Versatile pulse control for Transistor Output for N14/20/30/40/60(S@) or NA20 CPU Units.

• PWM Outputs for Transistor Output for N14/20/30/40/60(S@) or NA20 CPU Units.

• Mounting Serial Option Boards, Ethernet Option Board and Analog Option Board to N30/40/60 or NA20 CPU Units.

• Built-in analog I/O, two inputs and one output, for NA-type CPU Units.

Windows is a registered trademark of Microsoft Corporation in the United States and other countries. Other company names and product names in this document are the trademarks or registered trademarks of their respective companies. The product photographs and figures that are used in this catalog may vary somewhat from the actual products.

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Expansion I/O Units Expansion Units

20 or 40 I/O Points

8 inputs

8 outputs

16 outputs

32 outputs

Up to 3 Units can be connected

CP1W-CN811

CP1E CPU Unit

Expansion Units and Expansion I/O Units

I/O Connecting Cable

When a two level layout is created by expansion and distance is required

DIN Track

Analog I/O

Analog inputs

Analog outputs

Temperature sensors

CompoBus/S I/O Link Unit

Personal computer

Support Software CX-Programmer

IBM PC/AT or equivalent

CP1E-E14SDR- CP1E-E20SDR-

CP1E-E30SDR- CP1E-E40SDR- CP1E-E60SDR-

Personal computer

CP1E-E30DR-A CP1E-E40DR-A

CP1E-E10D@-@ CP1E-E14DR-A CP1E-E20DR-A

Support Software CX-Programmer

IBM PC/AT or equivalent

CP1E CPU Unit Expansion I/O Units Expansion Units

20 or 40 I/O Points

8 inputs

8 outputs

16 outputs

32 outputs

Up to 3 Units can be connected

CP1W-CN811

CP1E CPU Unit

Expansion Units and Expansion I/O Units

I/O Connecting Cable

When a two level layout is created by expansion and distance is required

DIN Track

Analog I/O

Analog inputs

Analog outputs

Temperature sensors

CompoBus/S I/O Link Unit

System Configuration

■Basic Model Basic System Configuration Using an E@@S-type CPU Unit

Basic System Configuration Using an E@@-type CPU Unit

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Expansion I/O Units Expansion Units

8 inputs

8 outputs

16 outputs

32 outputs

Analog I/O

Analog inputs

Analog outputs

Temperature sensors

CompoBus/S I/O Link Unit

Up to 3 Units can be connected

DIN Track

CP1W-CN811

CP1E CPU Unit

Expansion Units and Expansion I/O Units

I/O Connecting Cable

When a two level layout is created by expansion and distance is required

20 or 40 I/O Points

(NT Link/Host Link)

General component

(No-protocol mode)

(Modbus-RTU)

CP-series PLC or CJ1M PLC

(Serial PLC Link)

Host computer

(Host Link)

Programmable Terminal (PT)

Inverter

Personal computer

Support Software CX-Programmer

IBM PC/AT or equivalent

Battery

CP1W-BAT01

CP1E-N30S(1)D- CP1E-N40S(1)D- CP1E-N60S(1)D-

CP1E-N30D- CP1E-N40D- CP1E-N60D- CP1E-NA20D-

CP1E-N14D- CP1E-N20D-

CP1E CPU Unit

Expansion I/O Units Expansion Units

20 or 40 I/O Points

8 inputs

8 outputs

16 outputs

32 outputs

Analog I/O

Analog inputs

Analog outputs

Temperature sensors

CompoBus/S I/O Link Unit

Up to 3 Units can be connected

DIN Track

CP1W-CN811

CP1E CPU Unit

Expansion Units and Expansion I/O Units

I/O Connecting Cable

Personal computer

IBM PC/AT or equivalent

Built in RS-232C

Battery

CP1W-BAT01

When a two level layout is created by expansion and distance is required

(NT Link/HOST Link)

General component

(No-protocol mode)

(Modbus-RTU)

CP-series PLC or CJ1M PLC

(Serial PLC Link)

Host computer

(Host Link)

Programmable Terminal (PT)

Inverter

Support Software CX-Programmer

COMM

RS-232C

Option Board

CP1W-CIF01

COMM

RS-422A/485 Option Board

CP1W-CIF11 CP1W-CIF12-V1

IP ADDRESS:

SUBNET MASK:

COMMERR

10BASE-T 100BASE-TX

Ethernet

Option Board

CP1W-CIF41

(version 2.0 or higher)

rOrO

Analog

Option Board

CP1W-ADB21 CP1W-DAB21V CP1W-MAB221

Note Neither the CP1W-DAM01 LCD Option Board nor the CP1W-CIF41

Ethernet Option Board version 1.0 can be used.

* Analog Option Board can be mounted only to N30/40/60 or NA20 CPU

Units version 1.2 or higher.

■Application Model Basic System Configuration Using an N/NA@@S(1)-type CPU Unit

Basic System Configuration Using an N/NA-type CPU Unit

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

CP1E-@@@@@D@-@

(1) (2) (3) (4) (5) (6) (7)

Peripheral USB Port

Model Number Structure

■ Model Number Legend (Not all models that can be represented with the model number legend can necessarily be produced.)

1. Class E : Basic model N : Application model NA :Application model with built-in analog

2. I/O capacity 10 : 10 I/O points (6 inputs, 4 outputs) 14 : 14 I/O points (8 inputs, 6 outputs) 20 : 20 I/O points (12 inputs, 8 outputs) 30 : 30 I/O points (18 inputs, 12 outputs) 40 : 40 I/O points (24 inputs, 16 outputs) 60 : 60 I/O points (36 inputs, 24 outputs)

3. Unit type S : Renewal None : Normal

4. Built-in RS-485 port 1 : RS-485 None : -

5. Input type D : DC inputs

6. Output type R : Relays outputs T : Transistor outputs, sinking T1 : Transistor outputs, sourcing

7. Power supply A : AC power supply D : DC power supply

Difference between E/N/NA@@-type and E/N@@S(1)-type

■Basic Model E@@(S)-type CPU Units

Normal-type

E@@-type

Peripheral USB Port

Renewal-type

E@@S-type

Difference in Characteristics and Functions

Function E@@-type (Normal) E@@S-type (Renewal)

Analog adjusters

2 adjusters (Setting range: 0 to 255)

None The analog adjuster PV in A642/A643 is fixed on 0000.

Product Lineup

E@@ CPU Unit (Normal) E@@S CPU Unit (Renewal)

Power

supply

Relay outputs

AC DC AC DC AC DC AC DC

Transistor outputs (sinking/sourcing)

Relay outputs

Transistor outputs (sinking/sourcing)

10 I/O points ❍❍❍❍-- -- -- -- 14 I/O points ❍ -- -- -- ❍ -- -- -- 20 I/O points ❍ -- -- -- ❍ -- -- -- 30 I/O points ❍ -- -- -- ❍ -- -- -- 40 I/O points ❍ -- -- -- ❍ -- -- -- 60 I/O points -- -- -- -- ❍ -- -- --

■Application Model

Peripheral USB Port

Built-in RS-232C port

Option Board slot

Analog input terminal (NA-type only)

Analog output terminals (NA-type only)

Built-in RS-232C port

Built-in RS-485 port

Peripheral USB Port

NC0001 02

NC COM COM COM 03

CIO 100.00 and CIO 100.01 are different COM.

N/NA@@(S)-type CPU Units

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Normal-type

N@@-/NA-type

Renewal-type

N@@S1-type

Built-in RS-232C port

Difference in Characteristics and Functions

Function N/NA@@-type (Normal) N@@S(1)-type (Renewal)

Analog adjusters

Built-in RS-232C port 6 signals are supported: SD, RD, RS, CS, DR and ER.

Option board 1 port (N30/40/60, NA20 CPU Unit only)

Built-in RS-485 port None

2 adjusters (Setting range: 0 to 255)

CIO 100.00 and CIO 100.01 correspond with different common terminals.

None The analog adjuster PV in A642/A643 is fixed on 0000.

4 signals are supported: SD, RD, RS and CS. DR (pin 7) and ER (pin 8) are not supported.

Cannot be mounted There is no slot for an option board.

1 port (N30/40/60S1 CPU Unit only) With 2-wire connections, it can only communicate in half duplex. Terminating resistance ON/OFF can be set by DIP switch.

CIO 100.00 and CIO 100.01 correspond with the same common terminal.

Renewal-type

N@@S-type

Peripheral USB Port

V+00 0102

Terminal Arrangements (Transistor outputs only)

allocation

Power supply for transistor outputs

Not needed Do not connect an external power supply.

V- COM(V-) COM 03

CIO 100.00 and CIO 100.01 are the same COM.

Needed It is necessary to connect a DC24V external power supply when using terminals 00 and 01 on terminal block CIO 100. Do not connect the external power supply to the terminals except 00 and 01 on terminal block CIO 100.

COM

Product Lineup

Normal-type Renewal-type

Power

supply

N@@ CPU Unit

RS-232C+1 option slot (*)

Relay outputs

AC DC AC DC AC DC AC DC AC DC AC DC

Transistor outputs

(sinking/sourcing)

Relay outputs

N@@S CPU Unit

Built-in RS-232C

Transistor outputs (sinking/sourcing)

N@@S1 CPU Unit

Built-in RS-232C+RS-485

Relay outputs

Transistor outputs (sinking/sourcing)

10 I/O points -- -- -- -- -- -- -- -- -- -- -- -- 14 I/O points ❍❍❍❍ -- -- -- -- -- -- -- -- 20 I/O points ❍❍❍❍ -- -- -- -- -- -- -- -- 30 I/O points ❍❍❍❍❍ -- -- ❍❍ -- -- ❍ 40 I/O points ❍❍❍❍❍ -- -- ❍❍ -- -- ❍ 60 I/O points ❍❍❍❍❍ -- -- ❍❍ -- -- ❍

20 I/O points (Built-in analog)

* 30, 40 and 60 I/O points only.

❍ -- -- ❍ -- -- -- -- -- -- -- --

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Ordering Information

Applicable standards

Refer to the OMRON website (www.ia.omron.com) or ask your OMRON representative for the most recent applicable standards for each model.

Basic Model

●Renewal-type

■E@@S-type CP1E CPU Units (Built-in USB port)

Current

consumption (A)

5 V 24 V

Product name

E@@S-type CPU Units with 14 I/O Points

E@@S-type CPU Units with 20 I/O Points

E@@S-type CPU Units with 30 I/O Points

Power

Supply

100 to 240 VAC

Specifications

Inputs Outputs

8 6 Relay 2K steps 2K words -- 0.16 0.07 CP1E-E14SDR-A

12 8 Relay 2K steps 2K words -- 0.17 0.08 CP1E-E20SDR-A

18 12 Relay 2K steps 2K words 0.30 0.17 0.07 CP1E-E30SDR-A

Output

type

Program

capacity

Data

memory

capacity

External

power

supply

(24 VDC)

(A)

Model

E@@S-type CPU Units with 40 I/O Points

E@@S-type CPU Units with 60 I/O Points

100 to 240 VAC

24 16 Relay 2K steps 2K words 0.30 0.17 0.09 CP1E-E40SDR-A

36 24 Relay 2K steps 2K words 0.30 0.17 0.13 CP1E-E60SDR-A

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

●Normal-type

■E@@-type CP1E CPU Units (Built-in USB port)

Specifications

Product name

E@@-type CPU Units with 10 I/O Points

Power

Supply

100 to 240 VAC

Inputs Outputs

Output

type

Relay

Transistor (sinking)

Transistor (sourcing)

Relay -- 0.08 0.04 CP1E-E10DR-D

Program capacity

2K steps

Data memory capacity

2K words

External

power

supply

(24 VDC)

(A)

-- 0.08 0.04 CP1E-E10DR-A

-- 0.11 -- CP1E-E10DT-A

-- 0.11 -- CP1E-E10DT1-A

Current

consumption (A)

5 V 24 V

Model

E@@-type CPU Units with 14 I/O Points

E@@-type CPU Units with 20 I/O Points

E@@-type CPU Units with 30 I/O Points

E@@-type CPU Units with 40 I/O Points

24 VDC

100 to 240 VAC

Transistor (sinking)

Transistor (sourcing)

8 6 Relay 2K steps 2K words -- 0.16 0.07 CP1E-E14DR-A

12 8 Relay 2K steps 2K words -- 0.17 0.08 CP1E-E20DR-A

18 12 Relay 2K steps 2K words 0.30 0.17 0.07 CP1E-E30DR-A

24 16 Relay 2K steps 2K words 0.30 0.17 0.09 CP1E-E40DR-A

-- 0.11 -- CP1E-E10DT-D

-- 0.11 -- CP1E-E10DT1-D

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Application Model

●Renewal-type

■N@@S1-type CP1E CPU Units (Built-in RS-232C, RS-485, USB ports)

Current

consumption (A)

5 V 24 V

Product name

N@@S1-type CPU Units with 30 I/O Points

Power

Supply

100 to 240 VAC

Specifications

Inputs Outputs

Output

type

Relay

Program

capacity

Data

memory

capacity

External

power

supply

(24 VDC)

(A)

0.30 0.21 0.07 CP1E-N30S1DR-A

Model

Transistor (sinking)

Transistor (sourcing)

Relay

Transistor (sinking)

Transistor (sourcing)

Relay

Transistor (sinking)

Transistor (sourcing)

8K steps 8K words

-- 0.27 0.02 CP1E-N30S1DT-D

-- 0.27 0.02 CP1E-N30S1DT1-D

0.30 0.21 0.09 CP1E-N40S1DR-A

-- 0.31 0.02 CP1E-N40S1DT-D

-- 0.31 0.02 CP1E-N40S1DT1-D

0.30 0.21 0.13 CP1E-N60S1DR-A

-- 0.31 0.02 CP1E-N60S1DT-D

-- 0.31 0.02 CP1E-N60S1DT1-D

N@@S1-type CPU Units with 40 I/O Points

N@@S1-type CPU Units with 60 I/O Points

DC24V

100 to 240 VAC

DC24V

100 to 240 VAC

DC24V

18 12

24 16

36 24

■N@@S-type CP1E CPU Units (Built-in RS-232C, USB ports)

External

power

supply

(24 VDC)

(A)

0.30 0.21 0.07 CP1E-N30SDR-A

Product name

N@@S-type CPU Units with 30 I/O Points

Power

Supply

100 to 240 VAC

Specifications

Inputs Outputs

Output

type

Relay

Program

capacity

Data

memory

capacity

Current

consumption (A)

5 V 24 V

Model

N@@S-type CPU Units with 40 I/O Points

N@@S-type CPU Units with 60 I/O Points

DC24V

100 to 240 VAC

DC24V

100 to 240 VAC

DC24V

18 12

24 16

36 24

Transistor (sinking)

Transistor (sourcing)

Relay

Transistor (sinking)

Transistor (sourcing)

Relay

Transistor (sinking)

Transistor (sourcing)

8K steps 8K words

-- 0.27 0.02 CP1E-N30SDT-D

-- 0.27 0.02 CP1E-N30SDT1-D

0.30 0.21 0.09 CP1E-N40SDR-A

-- 0.31 0.02 CP1E-N40SDT-D

-- 0.31 0.02 CP1E-N40SDT1-D

0.30 0.21 0.13 CP1E-N60SDR-A

-- 0.31 0.02 CP1E-N60SDT-D

-- 0.31 0.02 CP1E-N60SDT1-D

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

●Normal-type

■N/NA@@-type CP1E CPU Units (Built-in RS-232C, USB ports)

External

power

supply

(24 VDC)

(A)

-- 0.17 0.07 CP1E-N14DR-A

-- 0.22 0.02 CP1E-N14DT-A

-- 0.22 0.02 CP1E-N14DT1-A

-- 0.22 0.02 CP1E-N14DT-D

-- 0.22 0.02 CP1E-N14DT1-D

-- 0.18 0.08 CP1E-N20DR-A

Product name

N@@-type CPU Units with 14 I/O Points

N@@-type CPU Units with 20 I/O Points

Power

Supply

100 to 240 VAC

24 VDC

Specifications

Inputs Outputs

Output

type

Relay

Transistor (sinking)

Transistor (sourcing)

Relay -- 0.17 0.07 CP1E-N14DR-D

Transistor (sinking)

Transistor (sourcing)

Relay

Program capacity

8K steps

Data memory capacity

8K words

Current

consumption (A)

5 V 24 V

Model

N@@-type CPU Units with 30 I/O Points

N@@-type CPU Units with 40 I/O Points

100 to 240 VAC

24 VDC

100 to 240 VAC

24 VDC

100 to 240 VAC

24 VDC

12 8

18 12

24 16

Transistor (sinking)

Transistor (sourcing)

Relay -- 0.18 0.08 CP1E-N20DR-D

Transistor (sinking)

Transistor (sourcing)

Relay

Transistor (sinking)

Transistor (sourcing)

Relay -- 0.21 0.07 CP1E-N30DR-D

Transistor (sinking)

Transistor (sourcing)

Relay

Transistor (sinking)

Transistor (sourcing)

Relay -- 0.21 0.09 CP1E-N40DR-D

Transistor (sinking)

Transistor (sourcing)

8K steps 8K words

-- 0.23 0.02 CP1E-N20DT-A

-- 0.23 0.02 CP1E-N20DT1-A

-- 0.23 0.02 CP1E-N20DT-D

-- 0.23 0.02 CP1E-N20DT1-D

0.30 0.21 0.07 CP1E-N30DR-A

0.30 0.27 0.02 CP1E-N30DT-A

0.30 0.27 0.02 CP1E-N30DT1-A

-- 0.27 0.02 CP1E-N30DT-D

-- 0.27 0.02 CP1E-N30DT1-D

0.30 0.21 0.09 CP1E-N40DR-A

0.30 0.31 0.02 CP1E-N40DT-A

0.30 0.31 0.02 CP1E-N40DT1-A

-- 0.31 0.02 CP1E-N40DT-D

-- 0.31 0.02 CP1E-N40DT1-D

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Product name

N@@-type CPU Units with 60 I/O Points

NA-type CPU Units with 20 I/O Points (Built-in analog)

Power

Supply

100 to 240 VAC

24 VDC

100 to 240 VAC

24 VDC

Inputs Outputs

36 24

(Built-in analog inputs: 2)

(Built-in analog outputs: 1)

Optional Products

Specifications

Output

type

Relay

Transistor (sinking)

Transistor (sourcing)

Relay -- 0.21 0.13 CP1E-N60DR-D

Transistor (sinking)

Transistor (sourcing)

Relay

Transistor (sinking)

Transistor (sourcing)

Program

capacity

8K steps

Data

memory

capacity

8K words

External

power

supply

(24 VDC)

(A)

0.30 0.21 0.13 CP1E-N60DR-A

0.30 0.31 0.02 CP1E-N60DT-A

0.30 0.31 0.02 CP1E-N60DT1-A

-- 0.31 0.02 CP1E-N60DT-D

-- 0.31 0.02 CP1E-N60DT1-D

0.30 0.18 0.11 CP1E-NA20DR-A

-- 0.23 0.09 CP1E-NA20DT-D

-- 0.23 0.09 CP1E-NA20DT1-D

Current

consumption (A)

5 V 24 V

Model

■Battery Set

Product name Specifications Model Battery Set For N/NA@@(S@)-type CP1E CPU Units

Note: Mount a Battery to an N/NA@@(S@)-type CPU Unit if the data in the following areas must

be backed up for power interruptions.

• DM Area (D) (except backed up words in the DM Area), Holding Area (H), Counter Completion Flags (C), Counter Present Values (C), Auxiliary Area (A), and Clock Function (Use batteries within two years of manufacture.)

CP1W-BAT01

■Option Board (for CP1E N30/40/60 or NA20 CPU Units)

The Options cannot be used for CP1E N14/20, N30/40/60S(1), E10/14/20/30/40/60(S) CPU Units.

Product name Specifications Model

RS-232C Option Board

One RS-232C Option Board can be mounted to the Option Board slot. CP1W-CIF01

RS-422A/485 Option Board

CP1W-CIF11

RS-422A/485 Isolated-type Option Board

Ethernet Option Board

Analog Input Option Board

One RS-422A/485 Option Board can be mounted to the Option Board slot.

One Ethernet Option Board can be mounted to the Option Board slot. CP1E CPU Units are supported by CP1W-CIF41 version 2.0 or higher. When using CP1W-CIF41, CX-Programmer version 9.12 or higher is required.

Can be mounted in CPU Unit Option Board slot. 2 analog inputs. 0-10V(Resolution:1/4000), 0-20mA (Resolution:1/2000).

CP1W-CIF12-V1

CP1W-CIF41

CP1W-ADB21 *

Analog Output Option Board

Analog I/O Option Board

Can be mounted in CPU Unit Option Board slot. 2 analog outputs. 0-10V (Resolution:1/4000).

Can be mounted in CPU Unit Option Board slot. 2 analog inputs. 0-10V(Resolution:1/4000), 0-20mA(Resolution:1/2000). 2 analog outputs. 0-10V (Resolution:1/4000).

CP1W-DAB21V *

CP1W-MAB221 *

Note: It is not possible to use a CP-series Ethernet Option Board version 1.0 (CP1W-CIF41), LCD Option Board (CP1W-DAM01), or Memory Card

(CP1W-ME05M) with a CP1E CPU Unit.

* Support is provided with CP1E CPU Unit version 1.2 and later.

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

■

Expansion I/O Units and Expansion Units (for CP1E E30/40/60(S), N30/40/60(S@), or NA20 CPU Units)

CP1E E10/14/20(S) or N14/20 CPU Units do not support Expansion I/O Units and Expansion Units.

Unit type Product name

Input Unit

Specifications

Inputs Outputs Output type 5 V 24 V

8 -- 24 VDC Input 0.018 -- CP1W-8ED

Current

consumption (A)

Model

CP1W Expansion I/O Units

CP1W Expansion Units

Output Units

I/O Units

Analog Input Unit

Analog Output Unit

Analog I/O Unit

Temperature Sensor Unit

CompoBus/S I/O Link Unit

Relay 0.026 0.044 CP1W-8ER

-- 8

-- 16

-- 32

12 8

24 16

4CH --

-- 2CH

-- 4CH

4CH 4CH

4CH 2CH

2CH 1CH

2CH -- Sensor type: Thermocouple (J or K) 0.040 0.059 CP1W-TS001

4CH -- Sensor type: Thermocouple (J or K) 0.040 0.059 CP1W-TS002

2CH --

4CH --

12CH -- Sensor type: Thermocouple (J or K) 0.080 0.050 CP1W-TS004

8 8 CompoBus/S slave 0.029 -- CP1W-SRT21

Transistor (sinking)

Transistor (sourcing)

Relay 0.042 0.090 CP1W-16ER

Transistor (sinking)

Transistor (sourcing)

Relay 0.049 0.131 CP1W-32ER

Transistor (sinking)

Transistor (sourcing)

Relay 0.103 0.044 CP1W-20EDR1

Transistor (sinking)

Transistor (sourcing)

Relay 0.080 0.090 CP1W-40EDR

Transistor (sinking)

Transistor (sourcing)

Resolution:

Input range: 0 to 5 V, 1 to 5 V, 0 to 10 V, ±10 V, 0 to 20 mA, or 4 to 20 mA.

Output range: 1 to 5 V, 0 to 10 V, ±10 V, 0 to 20 mA, or 4 to 20 mA.

Input range: 0 to 5 V, 1 to 5 V, 0 to 10 V, ±10 V, 0 to 20 mA, or 4 to 20 mA. Output range: 1 to 5 V, 0 to 10 V, ±10 V, 0 to 20 mA, or 4 to 20 mA.

Sensor type: Platinum resistance

Sensor type: Thermocouple (J or K) 2channels can be used as analog input. Input range: 1 to 5 V, 0 to 10 V, 4-20 mA

thermometer (Pt100 or JPt100)

1/6000

Resolution: 1/12000

Resolution: 1/6000

Resolution: 1/12000

Resolution: 1/6000

Resolution: 1/12000

0.075 -- CP1W-8ET

0.075 -- CP1W-8ET1

0.076 -- CP1W-16ET

0.076 -- CP1W-16ET1

0.113 -- CP1W-32ET

0.113 -- CP1W-32ET1

0.130 -- CP1W-20EDT

0.130 -- CP1W-20EDT1

0.160 -- CP1W-40EDT

0.160 -- CP1W-40EDT1

0.100 0.090 CP1W-AD041

0.100 0.050 CP1W-AD042

0.040 0.095 CP1W-DA021

0.080 0.124 CP1W-DA041

0.070 0.160 CP1W-DA042

0.120 0.170 CP1W-MAD44

0.120 0.120 CP1W-MAD42

0.083 0.110 CP1W-MAD11

0.054 0.073 CP1W-TS101

0.054 0.073 CP1W-TS102

0.070 0.030 CP1W-TS003

■I/O Connecting Cable

Product name Specifications Model

I/O Connecting Cable

Note: An I/O Connecting Cable (approx. 6 cm) for horizontal connection is provided with CP1W Expansion I/O Units and Expansion Units.

80 cm (for CP1W Expansion I/O Units and Expansion Units) Only one I/O Connecting Cable can be used in each PLC.

CP1W-CN811

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

■DIN Track Accessories

Name Specifications Model

Length: 0.5 m; Height: 7.3 mm PFP-50N

DIN Track

End Plate A stopper to secure the Units on the DIN Track. PFP-M

Length: 1 m; Height: 7.3 mm PFP-100N

Length: 1 m; Height: 16 mm PFP-100N2

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Programming Devices

■Software

Product name

FA Integrated Tool Package CX-One Lite Ver.4.@

FA Integrated Tool Package CX-One Package Ver. 4.@

CX-One Lite is a subset of the complete CX-One package that provides only the Support Software required for micro PLC applications. CX-One Lite runs on the following OS. OS: Windows 7 (32-bit/64-bit version) / Windows 8 (32-bit/64-bit version) / Windows 8.1 (32-

bit/64-bit version) / Windows 10 (32-bit/64-bit version)

CX-One Lite Ver. 4.@ includes Micro PLC Edition CX-Programmer Ver.9.@.

CX-One is a comprehensive software package that integrates Support Software for OMRON PLCs and components. CX-One runs on the following OS. OS: Windows 7 (32-bit/64-bit version) / Windows 8 (32-bit/64-bit version) / Windows 8.1 (32-

bit/64-bit version) / Windows 10 (32-bit/64-bit version)

CX-One Ver. 4.@ includes CX-Programmer Ver. 9.@.

Note: 1. The E20/30/40(S), N20/N30/N40(S) CPU Units are supported by CX-Programmer version 8.2 or higher.

The E10, E14, N14, N60, and NA20 CPU Units are supported by CX-Programmer version 9.03 or higher. When Micro PLC Edition CXProgrammer is used, you need version 9.03 or higher. The E60S CPU Units are supported by CX-Programmer version 9.42 or higher. When Micro PLC Edition CX-Programmer is used, you need version 9.42 or higher.

2. The CX-One and CX-One Lite cannot be simultaneously installed on the same computer.

* Multi licenses (3, 10, 30, or 50 licenses) and DVD media without licenses are also available for the CX-One.

The following tables lists the Support Software that can be installed from CX-One

Support Software in CX-One

Micro PLC Edition CX-Programmer Ver.9.@ Yes No CX-Drive Ver.1.@ Yes Yes CX-Programmer Ver.9.@ No Yes CX-Process Tool Ver.5.@ No Yes CX-Integrator Ver.2.@ Yes Yes Faceplate Auto-Builder for NS Ver.3.@ No Yes Switch Box Utility Ver.1.@ Yes Yes CX-Designer Ver.3.@ Yes Yes CX-Protocol Ver.1.@ No Yes NV-Designer Ver.1.@ Yes Yes CX-Simulator Ver.1.@ Yes Yes CX-Thermo Ver.4.@ Yes Yes CX-Position Ver.2.@ No Yes CX-ConfiguratorFDT Ver.1.@ Yes Yes CX-Motion-NCF Ver.1.@ No Yes CX-FLnet Ver.1.@ No Yes CX-Motion-MCH Ver.2.@ No Yes Network Configurator Ver.3.@ Yes Yes CX-Motion Ver.2.@ No Yes CX-Server Ver.4.@ Yes Yes

CX-One Lite

Ver.4.@

Note: For details, refer to the CX-One Catalog (Cat. No. R134).

Specifications

CX-One Ver.4.@

Number of

licenses

1 license DVD CXONE-LT01D-V4

1 license * DVD CXONE-AL01D-V4

Support Software in CX-One

Media

CX-One Lite

Ver.4.@

Model

CX-One Ver.4.@

Unit Versions

Units Model numbers Unit version

CP1E-E@@SDR-A

CP1E CPU Units

CP1E-N@@S@D@-@ CP1E-E@@D@-@ CP1E-N@@D@-@ CP1E-NA@@D@-@

Unit version 1.@

Unit Versions and Programming Devices

The following tables show the relationship between unit versions and CX-Programmer versions.

Required Programming Device *1

CPU Unit Functions

Ver.8.2 or

higher

CP1E-E20/30/40(S)D@-A CP1E-N20/30/40(S@)D@-@

CP1E-E10D@-@ CP1E-@14(S)D@-@ CP1E-N60(S@)D@-@ CP1E-NA20D@-@

CP1E-E60SDR-A

Unit version 1.@ functions

Note: 1. To update the CX-Programmer, the CX-One version 3/version 4 auto-update must be installed.

2. Use the CX-Programmer version 9.12 or higher, when the CP1W-CIF41 is applied.

* 1 A Programming Console cannot be used. * 2 Supports Smart Input function. * 3 Does not support Smart Input function.

CX-Programmer Micro PLC Edition CX-Programmer

Ver.9.03

or higher

Yes

No No

Yes

Ver.9.42

or higher

Yes

Ver.8.2 or

higher

Yes

No No

Ver.9.03

or higher

Yes

Ver.9.42

or higher

Yes

CX-

Programmer

for CP1E

Ver.1.0

Yes

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

General Specifications

Type AC power supply models DC power supply models

Model

Enclosure Mounted in a panel

E/N/NA@@-type CPU Unit with 10 I/O points (CP1E-E10D@-@): 90mm *1 × 85mm *2 × 66 mm CPU Unit with 14 or 20 I/O points (CP1E-@14D@-@/@20D@-@): 90mm *1 × 85mm *2 × 86 mm CPU Unit with 30 I/O points (CP1E-@30D@-@): 90mm *1 × 85mm *2 × 130 mm CPU Unit with 40 I/O points (CP1E-@40D@-@): 90mm *1 × 85mm *2 × 150 mm

Dimensions (H × D × W)

Weight

Supply voltage 100 to 240 VAC 50/60 Hz 24 VDC

Operating voltage range

Power consumption

Electrical specifications

Application environment

Terminal block Fixed (not removable)

Terminal screw size M3

Applicable standards Conforms to EC Directive

Grounding method Ground to 100 Ω or less.

Inrush current

External power supply *3

Insulation resistance

Dielectric strength

Power OFF detection time

Ambient operating temperature

Ambient humidity 10% to 90%

Atmosphere No corrosive gas.

Ambient storage temperature

Altitude 2,000 m max.

Pollution degree 2 or less: Meets IEC 61010-2-201.

Noise resistance 2 kV on power supply line (Conforms to IEC61000-4-4.)

Overvoltage category Category II: Meets IEC 61010-2-201.

EMC Immunity Level Zone B

Vibration resistance

Shock resistance

CPU Unit with 60 I/O points (CP1E-N60D@-@): 90mm *1 × 85mm *2 × 195 mm CPU Unit with 20 I/O points and built-in analog (CP1E-NA20D@-@): 90mm *1 × 85mm *2 × 130 mm

E/N/@@S(1)-type CPU Unit with 14 or 20 I/O points (CP1E-@14SD@-@/@20SD@-@): 90mm *1 × 79mm *2 × 86 mm CPU Unit with 30 I/O points (CP1E-@30S(1)D@-@): 90mm *1 × CPU Unit with 40 I/O points (CP1E-@40S(1)D@-@): 90mm *1 × 79mm *2 × 150 mm CPU Unit with 60 I/O points (CP1E-@60S(1)D@-@): 90mm *1 × 79mm *2 × 195 mm

CPU Unit with 10 I/O points (CP1E-E10D@-@): 300g max. CPU Unit with 14 I/O points (CP1E-@14(S)D@-@): 360g max. CPU Unit with 20 I/O points (CP1E-@20(S)D@-@): 370g max. CPU Unit with 30 I/O points (CP1E-@30(S@)D@-@): 600g max. CPU Unit with 40 I/O points (CP1E-@40(S@)D@-@): 660g max. CPU Unit with 60 I/O points (CP1E-@60(S@)D@-@): 850g max. CPU Unit with 20 I/O points and built-in analog (CP1E-NA20D@-@): 680g max.

85 to 264 VAC 20.4 to 26.4 VDC

15 VA/100 VAC max. 25 VA/240 VAC max. (CP1E-E10D@-A/@14(S)D@-A/@20(S)D@-A)

50 VA/100 VAC max. 70 VA/240 VAC max. (CP1E-NA20D@-A/@30(S@)D@-A/@40(S@)D@-A/ N60(S@)D@-A)

120 VAC, 20 A for 8 ms max. for cold start at room temperature 240 VAC, 40 A for 8 ms max. for cold start at room temperature

Not provided. (CP1E-E10D@-A/@14(S)D@-A/@20(S)D@-A) 24 VDC, 300 mA (CP1E-NA20D@-A/@30D@-A/@40D@-A/@60D@-A/ @30SDR-A/@40SDR-A/@60SDR-A)

20 MΩ min. (at 500 VDC) between the external AC terminals and GR terminals

2,300 VAC 50/60Hz for 1 min between AC external and GR terminals Leakage current: 5 mA max.

10 ms min. 2 ms min.

0 to 55 °C

-20 to 75 °C (excluding battery)

Conforms to JIS 60068-2-6. 5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz Acceleration of 9.8 m/s

Conforms to JIS 60068-2-27. 147 m/s

CP1E-@@@S@D@-A

CP1E-@@@D@-A

for 100 min in X, Y, and Z directions (10 sweeps of 10 min each = 100 min total)

, 3 times in X, Y, and Z directions

9 W max. (CP1E-E10D@-D) 13 W max. (CP1E-N14D@-D/N20D@-D)

20 W max. (CP1E-NA20D@-D/N30 N60

(S@)D@

24 VDC, 30 A for 20 ms max. for cold start at room temperature

Not provided

Except between DC primary current and DC secondary current

* 1 Total of 110 mm with mounting brackets. * 2 Excluding cables. * 3 Use the external power supply to power input devices. Do not use it to drive output devices.

This is the rated value for the maximum system configuration. Use the following formula to calculate power consumption for CPU Units with DC power.

* 4

Formula: DC power consumption = (5V current consumption ✕ 5 V/70% (internal power efficiency) + 24V current consumption) ✕ 1.1(current fluctuation factor) The above calculation results show that a DC power supply with a greater capacity is required.

CP1E-@@@S@D@-D

CP1E-@@@D@-D

79mm *2 ×

-D) *4

130 mm

(S@)D@

-D/N40

(S@)D@

-D/

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Performance Specifications

Item

Program capacity

Control method Stored program method

I/O control method Cyclic scan with immediate refreshing

Program language Ladder diagram

Instructions Approximately 200

Processing speed

Number of CP1W-series Expansion Units connected

Maximum number of I/O points

Built-in I/O

Built-in input functions

Built-in output functions

Built-in analog

Analog adjusters

Overhead processing time 0.4 ms

Instruction execution times

High-speed counter mode/ maximum frequency

High-speed counters

Input interrupts

Quick-response Inputs

Normal input

Pulse outputs (Models with transistor outputs only)

Counting mode

Count value 32 bits

Counter reset modes

Control method

Input constants

Pulse output method and output frequency

Output mode

Number of output pulses

Acceleration/ deceleration curves

Changing SVs during instruction execution

Origin searches

Frequency

Duty factor

Output mode Continuous Mode

Analog input

Analog output Setting range: 0 to 6,000 (1 channels only for NA-type)

2 K steps (8 Kbytes) including the symbol table, comments, and program indices of the CX-Programmer

Basic instructions (LD): 1.19 µs min. Special instructions (MOV): 7.9 µs min.

CP1E-E10D@-@/@14(S)D@-@/@20(S)D@-@: None CP1E-@30(S@)D@-@/@40(S@)D@-@/@60(S@)D@-@/NA20(S@)D@-@: 3 units

CP1E-E10D@-@ : 10 CP1E-@14(S)D@-@: 14 CP1E-@20(S)D@-@: 20 CP1E-@30(S@)D@-@: 150 (30 built in, 40 × 3 expansion) CP1E-@40(S@)D@-@: 160 (40 built in, 40 × 3 expansion) CP1E-@60(S@)D@-@: 180 (60 built in, 40 × 3 expansion) CP1E-NA20D@-@: 140 (20 built in, 40 × 3 expansion)

CP1E-E10D@-@ : 10 (6 inputs, 4 outputs) CP1E-@14(S)D@-@: 14 (8 inputs, 6 outputs) CP1E-@20(S)D@-@: 20 (12 inputs, 8 outputs) CP1E-@30(S@)D@-@: 30 (18 inputs, 12 outputs) CP1E-@40(S@)D@-@: 40 (24 inputs, 16 outputs) CP1E-@60(S@)D@-@: 60 (36 inputs, 24 outputs) CP1E-NA20D@-@: 20 (12 inputs, 8 outputs)

Incremental Pulse Inputs

10 kHz: 6 counters

Up/Down Inputs

10 kHz: 2 counters

Pulse + Direction Inputs

10 kHz: 2 counters

Differential Phase Inputs (4x)

5 kHz: 2 counters

Linear mode Ring mode

Phase Z and software reset (excluding increment pulse input) Software reset

Target Matching Range Comparison

6 inputs (4 inputs only for 10 I/O points) Interrupt input pulse width: 50 µs min.

6 inputs (4 inputs only for 10 I/O points) Input pulse width: 50 µs min.

Delays can be set in the PLC Setup (0 to 32 ms, default: 8 ms). Set values: 0, 1, 2, 4, 8, 16, or 32 ms

Pulse output function not included

PWM output function not included

Analog function not included

E/N/NA@@-type: 2 adjusters (Setting range: 0 to 255) E/N@@S(1)-type: None

CP1E-E@@SD@-@

CP1E-@@D@-@

5 counters (only for 10 I/O points)

CP1E-N@@S@D@-@

CP1E-N@@D@-@

CP1E-NA@@D@-@

8 K steps (32 Kbytes) including the symbol table, comments, and program indices of the CX-Programmer

Incremental Pulse Inputs

100 kHz: 2 counters,10 kHz: 4 counters

Up/Down Inputs

100 kHz: 1 counters,10 kHz: 1 counters

Pulse + Direction Inputs

100 kHz: 2 counters

Differential Phase Inputs (4x)

50 kHz: 1 counter, 5 kHz: 1 counter

Pulse + Direction Mode 1 Hz to 100 kHz: 2 outputs

Continuous mode (for speed control) Independent mode (for position control)

Relative coordinates: 0000 0000 to 7FFF FFFF hex (0 to 2147483647) Absolute coordinates: 8000 0000 to 7FFF FFFF hex (-2147483647 to 2147483647)

Trapezoidal acceleration and deceleration (Cannot perform S-curve acceleration and deceleration.)

Only target position can be changed.

Included

2.0 to 6,553.5 Hz (in increments of 0.1 Hz) with 1 output or 2 Hz to 32,000 Hz (in increments of 1 Hz) with 1 output

0.0% to 100.0% (in increments of 0.1%) Accuracy: +1%/-0% at 2 Hz to 10,000 Hz and

Setting range: 0 to 6,000 (2 channels only for NA-type)

+5%/-0% at 10,000 Hz to 32,000 kHz

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Item

B-type Peripheral USB Port Conforming to USB 2.0 B type connector

Built-in RS-232C port

Built-in RS-485 port

Communications

Serial Option port

Number of tasks

Maximum subroutine number 128 Maximum jump number 128 Scheduled interrupt tasks 1 interrupt task

Clock

Built-in EEPROM

Memory backup

CIO Area

Work Area (W) 1,600 bits (100 words): W0.00 to W99.15 (W0 to W99)

Holding Area (H)

Auxiliary Area (A)

Temporary Relay Area (TR) (TR Area) 16 bits: TR0 to TR15 Timer Area (T) 256 timer numbers (T0 to T255 (separate from counters)) Counter Area (C) 256 counter numbers (C0 to C255 (separate from timers))

Battery backup With CP1W-BAT01 Battery (Sold separately)

Input Bits 1,600 bits (100 words): CIO 0.00 to CIO 99.15 (CIO 00 to CIO 99) Output Bits 1,600 bits (100 words): CIO 100.00 to CIO 199.15 (CIO 100 to CIO 199) Serial PLC Link Words 1,440 bits (90 words): CIO 200.00 to CIO 289.15 (words CIO 200 to CIO 289)

Transmission distance

Communications method

synchronization Baud rate 1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6, or 115.2 kbps Transmission

distance

Supported protocol

Communications method

synchronization Baud rate 1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6, or 115.2 kbps Transmission

distance

Supported protocol

Mountable Option Boards

Communications method

synchronization Baud rate 1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6, or 115.2 kbps

Compatible protocols

5 m max.

No built-in RS-232C port

No built-in RS-485 port

Option Board cannot be mounted.

• One cyclic execution task

• One scheduled interrupt task (always interrupt task 1)

• Six input interrupt tasks (interrupt tasks 2 to 7)

• Sixteen high-speed counter interrupt tasks (interrupt tasks 1 to 16)

Clock function not included. The time of error occurrence displays 01-01-01 01:01:01 Sunday

Ladder programs and parameters are automatically saved to built-in EEPROM A section of the Data Memory Area can be saved to the built-in EEPROM.

Battery cannot be mounted.

800 bits (50 words): H0.00 to H49.15 (H0 to H49) Bits in this area maintain their ON/OFF status when operating mode is changed.

Read-only: 7,168 bits (448 words) A0 to A447 Read/write: 4,896 bits (306 words) in words A448 to A753

CP1E-E@@SD@-@

CP1E-E@@D@-@

Interface: Conforms to EIA RS-232C.

Half duplex

Start-stop

15 m max.

N30/40/60S1-type only Interface: Conforms to EIA RS-485. 2-wire sensors No isolation

Half duplex

Start-stop

50 m max.

N30/40/60 and NA20-type only 1 port

Depends on Option Board.

Included. Accuracy (monthly deviation):

-4.5 min to -0.5 min at ambient temperature of 55

-2.0 min to +2.0 min at ambient temperature of 25

-2.5 min to +1.5 min at ambient temperature of 0

CP1W-BAT01 can be used. Maximum battery service life: 5 years Backup Time Guaranteed value (ambient temperature: 55 13,000 hours (approx. 1.5 years) Effective value (ambient temperature: 25 43,000 hours (approx. 5 years)

CP1E-N@@S@D@-@

CP1E-N@@D@-@

CP1E-NA@@D@-@

• Host Link

• 1:N NT Link

• No-protocol mode

• Serial PLC Links (master, slave)

• Modbus-RTU Easy Master

• Host Link

• 1:N NT Link

• No-protocol mode

• Serial PLC Links (master, slave)

• Modbus-RTU Easy Master

• One RS-232C port: CP1W-CIF01

•

One RS-422A/485 port (not isolated): CP1W-CIF11

• One RS-422A/485 port (isolated): CP1W-CIF12-V1

• One Ethernet port: CP1W-CIF41

• Host Link

• 1:N NT Link

• No-protocol mode

• Serial PLC Links (master, slave)

• Modbus-RTU Easy Master

C):

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Item

Data Memory Area (D)

Operating modes

CP1E-E@@SD@-@

CP1E-E@@D@-@

2 Kwords: D0 to D2047 Of these, 1,500 words can be saved to the backup memory (built-in EEPROM) using settings in the Auxiliary Area.

PROGRAM mode: Program execution is stopped.

MONITOR mode: Programs are executed.

RUN mode: Programs are executed.

Preparations can be executed prior to program execution in this mode.

Some operations, such as online editing, and changes to present values in I/O memory, are enabled in this mode.

This is the normal operating mode.

CP1E-N@@S@D@-@

CP1E-N@@D@-@

8 Kwords: D0 to D8191 Of these, 7,000 words can be saved to the backup memory (built-in EEP-ROM) using settings in the Auxiliary Area

CP1E-NA@@D@-@

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

CPU Unit

Built-in EEPROM Built-in RAM

Backup memory

User Program Area (Backup)

PLC Setup PLC Setup

DM Area DM Area

User Program Area

I/O Memory Areas

Data is retained even if the power supply is interrupted for longer than the backup time of the built-in capacitor.

Execution Memory

Automatic backup

Read at startup

Automatic backup

Read at startup

Backup using bit in Auxiliary Area

DM Area data read at startup

If a CP1W-BAT01 Battery (sold separately) is mounted to an N/NA@@(S@)-type CPU Unit, which is normally backed up by a built-in capacitor, data will be backed up by the battery.

Area where data is backed up even if the power supply is interrupted for longer than the back-up time of the built-in capacitor.

Area where data is cleared if the power supply is interrupted for longer than the back-up time of the built-in capacitor.

Backup time of built-in capacitor

50 hours

40 hours

25 hours 20 hours

9 hours 7 hours

CP1E E@@(S)-type CPU Unit

CP1E N/NA@@(S@)-type CPU Unit

Ambient temperature

25 40 60

Internal Memory in the CPU Units

CPU Unit Memory Backup Structure

The internal memory in the CPU Unit consists of built-in RAM and built-in EEPROM. The built-in RAM is used as execution memory and the builtin EEPROM is used as backup memory.

●Precautions for Correct Use

Create a system and write the ladder programs so that problems will not occur in the system if the data in these area may be unstable.

• Data in areas such as the DM area (D), Holding Area (H), the Counter Present Values (C) and the status of Counter Completion Flags (C), which is retained by the battery, may be unstable when the power supply is turned off (Except for the DM area that are retained by the built-in EEPROM using the Auxilliary Area bit.)

• The error log, and clock data (N/NA@@(S@)-type CPU Unit only) in the Auxiliary Area will become unstable. Other words and bits in the Auxiliary Area will be cleared to their default values.

The built-in capacitor’s backup time varies with the ambient temperature as shown in the following graph.

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Input bits (starting from CIO 0)

User Areas

Holding Area (H)

DM Area (D)

Timer Area (T)

Counter Area (C)

Output bits (starting from CIO 100)

Work Area (W)

System Areas

Auxiliary Area

(A)

Condition Flags

Clock Pulses

I/O Memory Areas

Data can be read and written to I/O memory from the ladder programs. I/O memory consists of an area for I/O with external devices, user areas, and system areas.

I/O Memory Areas

Name No. of bits Word addresses Remarks

Input Bits 1,600 bits (100 words) CIO 0 to CIO 99 For NA-type, CIO90, CIO91 is occupied by analog input 0, 1.

CIO Area

Work Area (W) 1,600 bits (100 words) W0 to W99 --

Holding Area (H) 800 bits (50 words) H0 to H49

Data Memory Area (D)

Timer Area (T)

Counter Area (C)

Auxiliary Area (A)

Output Bits 1,600 bits (100 words) CIO 100 to CIO 199 For NA-type, CIO190 is occupied by analog output 0.

Serial PLC Link Words 1,440 bits (90 words) CIO 200 to CIO 289 --

Data in this area is retained during power interruptions if a Battery Set (sold separately) is mounted to an N/NA@@(S@)- type CPU Unit.

Data in specified words of the DM Area can be retained in the

E@@(S)-type CPU Unit 2K words D0 to D2047

N/NA@@(S@)-type CPU Unit

Present values 256

Timer Completion Flags 256 --

Present values 256

Counter Completion Flags 256 --

Read only 7168 bits (448 words) A0 to A447 Data in this area is retained during power interruptions if a

Read-write 4,896 bits (306 words) A448 to A753

8K words D0 to D8191

T0 to T255

C0 to C255

built-in EEPROM in the backup memory by using a bit in the Auxiliary Area. Applicable words: D0 to D1499

Data in specified words of the DM Area can be retained in the built-in EEPROM in the backup memory by using a bit in the Auxiliary Area. Applicable words: D0 to D6999

Data in this area is retained during power interruptions if a Battery Set (sold separately) is mounted to an N/NA@@(S@)- type CPU Unit.

Battery Set (sold separately) is mounted to an N/NA@@(S@)- type CPU Unit.

(One word can be specified at a time.)

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

D(n-1)

Built-in RAM

CP1E CPU Unit

A751.15 (DM Backup Save Start Bit) turned ON

DM Area (D)

Data backed up

Built-in EEPROM Backup Memory

DM backup data

Specified number of words

Specify the number of words starting from D0 in the Number of CH of DM

for backup Box in the Startup Data Read Area in PLC Setup.

DM backup data is restored to the RAM when power supply is turned ON again if the Restore D0- from backup memory Check Box is selected in the Startup Data Read Area in the PLC Setup.

Data restored

Backing Up and Restoring DM Area Data

The contents of the DM Area (D) will become unstable if the power supply is interrupted for longer than the backup time of the built-in capacitor (50 hours for an E The contents of the specified words in the DM Area data can be backed up from RAM to the built-in EEPROM backup memory during operation by turning ON a bit in the Auxiliary Area. The number of DM Area words to back up is specified in the Number of CH of DM for backup Box in the PLC Setup. If the Restore D0- from backup memory Check Box is selected in the PLC Setup, the backup data will automatically be restored to RAM when the power is turned back ON so that data is not lost even if power is interrupted.

@@(S)-type CPU Unit, 40 hours for an N/NA@@(S@)-type CPU Unit without a Battery).

Conditions for Executing Backup

Specified words starting from D0 in the RAM can be saved to the built-in EEPROM backup memory by turning ON A751.15. (These words are called the DM backup words and the data is called the DM backup data.) A751.15 (DM Backup Save Start Bit) can be used in any operating mode (RUN, MONITOR, or PROGRAM mode).

Words That Can Be Backed Up

• E@@(S)-type CP1E CPU Units: D0 to D1499

@@(S@)-type CP1E CPU Units: D0 to D6999

• N/NA

Number of Words To Back Up

The number of words to back up starting from D0 is set in the Number of CH of DM for backup Box in the Startup Data Read Area in the PLC Setup.

Restoring DM Backup Data to RAM When Power Is Turned ON

The DM backup data can be restored to RAM when power is turned ON by selecting the Restore D0- from backup memory Check Box in the Startup Data Read Area in the PLC Setup.

The DM backup data will be read from the backup memory even if the Clear retained memory area (HR/DM/CNT) Check Box is selected in the PLC Setup.

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

CIO 0

L1 L2/N

COM 01 03 05

00 02 04NC

−

COM 01 03 05 07 NC NC

00 02 04 06 NC NCNC

CIO 0

L1 L2/N

COMNC01 03 05 07 09 11

00 02 04 06 08 10

01 03 05

00 02 04

CIO 0 CIO 1

+−

COM

01 03 05 07 09 11

00 02 04 06 08 10

01 03 05

00 02 04

CIO 0 CIO 1

Built-in Inputs

Terminal Arrangements

●Input Terminal Arrangement for CPU Unit with 10 I/O Points

AC power supply models

DC power supply models

CIO 0

−

COM 01 03 05

00 02 04NC

●Input Terminal Arrangement for CPU Unit with 14 I/O Points

AC power supply models

CIO 0

L1 L2/N

COM 01 03 05 07 NC NC

00 02 04 06 NC NCNC

DC power supply models

●Input Terminal Arrangement for CPU Unit with 20 I/O Points

AC power supply models

CIO 0

L1 L2/N

DC power supply models

+−

COM 01 03 05 07 09 11

00 02 04 06 08 10NC

CIO 0

COM 01 03 05 07 09 11

00 02 04 06 08 10NC

●Input Terminal Arrangement for CPU Unit with 30 I/O Points

AC power supply models

DC power supply models

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

L1 L2/N

COM 01 03 05

00 02 04

07 09 11

06 08 10

01 03 05

00 02 04

07 09

06 08 10

CIO 0 CIO 1

+−

COMNC01 03 05

00 02 04

07 09 11

06 08 10

01 03 05

00 02 04

07 09

06 08 10

CIO 0 CIO 1

L1 L2/N

COM 01 03 05

00 02 04

07 09 11

06 08 10

01 03 05

00 02 04

07 09

06 08 10

01 03 05

00 02 04

07 09

06 08 10

CIO 0 CIO 1 CIO 2

01 03 05 07 09 11

04 08

01 03 05 07 09 11

00 0000 02

01 03 05 07 09 11

10NC

−

COM

06 10

L1 L2/N

COM

COM1

01 03 05 07 09 11

00 02 04 06 08 10

I IN0 AG I IN1

VIN0

COM0

VIN1

CIO 0 CIO 90 CIO 91

COM

COM1

01 03 05 07 09 11

00NC 02 04 06 08 10

I IN0 AG I IN1

VIN0

COM0

VIN1

●Input Terminal Arrangement for CPU Unit with 40 I/O Points

AC power supply models

DC power supply models

●Input Terminal Arrangement for CPU Unit with 60 I/O Points

AC power supply models

DC power supply models

●Input Terminal Arrangement for CPU Unit with 20 I/O Points and Built-in Analog

AC power supply models

DC power supply models

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

These functions are supported only by N/NA

@@(S@

)-type CPU Units with

transistor outputs.

Allocating Built-in Inputs to Functions

Input terminals are allocated functions by setting parameters in the PLC Setup. Set the PLC Setup so that each terminal is used for only one function.

Settings in PLC Setup

High-speed counter 0 to 3 setting on

Built-in Input Tab Page

(increment

pulse input)

Two-phase

(differential

phase x4 or

up/down)

Counter 0, phase A or up input

Two-phase

direction)

Counter 0, pulse input

(pulse/

Origin search settings on Pulse

Output 0/1 Tab Page

CPU Unit with

20 to 60 points

-- --

CPU Unit with

14 I/O points

CPU Unit with

I/O Points

Input terminal block

Terminal

block

label

Terminal

number

Interrupt input setting on

Built-in Input Tab Page

Normal Interrupt Quick

Normal

input

Normal input 0

Input

interrupt

-- --

Quick-

response

input

Single-phase

Counter 0, increment input

CIO 0

CIO 1

40 06 to 11

60 CIO 2 00 to 11

00 to 05

Normal input 1

Normal input 2

Normal input 3

Normal input 4

Normal input 5

Normal input 6

Normal input 7

Normal input 8

Normal input 9

Normal input 10

Normal input 11

Normal input 12 to17

Normal input 18 to 23

Normal input 24 to 35

-- --

Interrupt input 2

Interrupt input 3

Interrupt input 4

Interrupt input 5

Interrupt input 6

Interrupt input 7

Quick-response input 2

Quick-response input 3

Quick-response input 4

Quick-response input 5

Quick-response input 6

Quick-response input 7

-- -- -- -- -- -- --

-- -- -- -- --

-- -- -- -- -- -- --

Counter 1, increment input

Counter 2, increment input

Counter 3, increment input

Counter 4, increment input

Counter 5, increment input

-- -- --

Counter 0, phase B or down input

Counter 1, phase A or up input

Counter 1, phase B or down input

Counter 0, phase Z or reset input

Counter 1, phase Z or reset input

-- --

Counter 1, pulse input

Counter 0, direction

Counter 1, direction

Counter 0, reset input

Counter 1, reset input

-- --

Pulse 0: Origin input signal

Pulse 1: Origin input signal

Pulse 0: Origin proximity input signal

Pulse 1: Origin proximity input signal

Pulse 0, Origin proximity input signal

Pulse 1, Origin proximity input signal

Pulse 0, Origin input signal

Pulse 1, Origin input signal

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

00 01 02 03

COM COM NC COM NC

CIO 100

00 01 02 03

COM COM NC COM

04 05 07

COMNC

CIO 100

100 CH 101 CH

00 01 02 04 05 07 00

03 06

01 03

V+

V- COM(V-) COM COM COM

100 CH 101 CH

00 01 02 04 05 07 00

03 06

01 03

V+

V- COM(V+) COM COM COM

Built-in Outputs

Terminal Arrangements

●Output Terminal Arrangement for CPU Unit with 10 I/O Points

AC power supply model DC power supply model

●Output Terminal Arrangement for CPU Unit with 14 I/O Points

AC power supply model DC power supply model

00 01 02 03

COM COM NC COM

CIO 100

●Output Terminal Arrangement for CPU Unit with 20 I/O Points

AC power supply model DC power supply model

●Output Terminal Arrangement for CPU Unit with 30 I/O Points

AC power supply model E/N30(S@)D@-A

00 01 02 04 05 07 00

- COM COMCOM COM COM

DC power supply model N30D@-D

CIO 100 CIO 101

00 01 02 04 05 07 00

03 06

01 03

04 05 NC

COMNC

NC COM COMCOM COM COM

CIO 100 CIO 101

N30S(1)DT-D

Note: V- and COM(V-) are internally connected.

N30S(1)DT1-D

Note: V+ and COM(V+) are internally connected.

03 06

01 03

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

+0001

02 03 04 06 00 01

COM COM 05 07 COM

03 04 06

02 05COMCOMCOM-

CIO 100 CIO 101

NC 00 010702 03 04 06 00 01

COM COM 05 07 COM

03 04 06

02 05

COMCOMCOMNC

100 CH 101 CH

V+ 00 01

02 03 04 06 00 01

COM 05 07 COM

03 04 06

02 05

COM COM COM(V-)V-

100 CH 101 CH

V+ 00 01

02 03 04 06 00 01

COM 05 07 COM

03 04 06

02 05

COM COM COM(V+)V-

CIO 101

CIO 100

CIO 102

+ 0001020405070002040507

COMCOM- COM 03 COM 06 COM 01 03 COM 0600COM0201040305COM0706

CIO 101

CIO 100

CIO 102

NC 00 01 02 04 05 07 00 02 04 05 07

COMCOMNC COM 03 COM 06 COM 01 03 COM 0600COM0201040305COM0706

100 CH 101 CH

00 010602 04 05 07 00 02

COM COM 06 COM

04 05 07

01 COM

102 CH

00 02

COM

04 05 07

01 COM0303

V+

COM(V-)V-

V+

100 CH 101 CH

00 010602 04 05 07 00 02

COM COM 06 COM

04 05 07

01 COM

102 CH

00 02

COM

04 05 07

01 COM0303COM(V+)V-

●Output Terminal Arrangement for CPU Unit with 40 I/O Points

AC power supply model E/N40(S@)D@-A

DC power supply model N40D@-D

N40S(1)DT-D

Note: V- and COM(V-) are internally connected.

N40S(1)DT1-D

Note: V+ and COM(V+) are internally connected.

●Output Terminal Arrangement for CPU Unit with 60 I/O Points

AC power supply model E/N60(S@)D@-A

DC power supply model N60D@-D

N60S(1)DT-D

Note: V- and COM(V-) are internally connected.

N60S(1)DT1-D

Note: V+ and COM(V+) are internally connected.

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

CIO 100 CIO 190

00 01 02 04 05 07 NC

03 06

IOUT0

VOUT0

COM0

−

COM COMCOM COM NC

CIO 100 CIO 190

020104 05 07 NC

IOUT0

COM COM COM COM NC

03 06

VOUT0

COM0

These functions are supported only by N/NA@@(S@)-type CPU Units with transistor outputs.

●Output Terminal Arrangement for CPU Unit with 20 I/O Points and Built-in Analog

AC power supply model DC power supply model

Allocating Built-in Output Terminals to Functions

Output terminals are allocated functions by setting parameters in the PLC Setup. Set the PLC Setup so that each terminal is used for only one function.

Setting in PLC Setup

Origin search setting on

Pulse Output 0/1 Tab Page

When the PWM

instruction is executed

Variable duty ratio

pulse output

CPU Unit with

I/O points

Output terminal

block

Terminal

block label

Other than those

shown right

Terminal

number

00 Normal output 0 Pulse output 0 (pulse) -- --

Normal output

When a pulse output instruction

(SPED, ACC, PLS2, or ORG) is

executed

Fixed duty ratio pulse output

Pulse + direction Use PWM output

CIO 100

CIO 101

40 04 to 07 Normal output 12 to 15 -- -- --

60 CIO 102 00 to 07 Normal output 16 to 23 -- -- --

01 Normal output 1 Pulse output 1 (pulse) -- PWM output 0

02 Normal output 2 Pulse output 0 (direction) -- --

03 Normal output 3 Pulse output 1 (direction) -- --

04 Normal output 4 --

05 Normal output 5 --

06 Normal output 6 -- -- --

07 Normal output 7 -- -- --

00 to 03 Normal output 8 to 11 -- -- --

Pulse 0: Error counter reset

output

Pulse 1: Error counter reset

output

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Input indicator

COM

3.3kΩ

910Ω

1000pF

Internal circuits

COM

4.8kΩ

750Ω

Input indicator

COM

3.3kΩ

4.3kΩ

1000pF

Input indicator

Internal circuits

COM

910Ω

1000pF

3.3kΩ

Input indicator

Internal circuits

COM

750Ω

4.8kΩ

Internal circuits

Input indicator

I/O Specifications for CPU Units

Input Specifications

Item Specification

Input type

High-speed counter inputs or Normal Inputs

Input bits CIO 0.00 to CIO 0.01 CIO 0.02 to CIO 0.07 *1

Input voltage 24 VDC, +10%, -15%

Applicable sensors 2-wire and 3-wire sensors

Input Impedance 3.3 kΩ 3.3 kΩ 4.8 kΩ

Input current 7.5 mA typical 7.5 mA typical 5 mA typical

ON voltage/current 3 mA min. at 17.0 VDC min. 3 mA min. at 17.0 VDC min. 3 mA min. at 14.4 VDC min.

OFF voltage/current 1 mA max. at 5.0 VDC max. 1 mA max. at 5.0 VDC max. 1 mA max. at 5.0 VDC max.

ON response time *2

OFF response time *2

E@@(S)-type CPU Unit: 50 µs min. N/NA@@(S@)-type CPU Unit: 2.5 µs min.

E@@(S)-type CPU Unit N/NA@@(S@)-type CPU Unit

Input 0.00 to 0.07

High-speed counter inputs, interrupt input, quick-response inputs, or Normal Inputs

Normal inputs

CIO 0.08 to CIO 0.11, CIO 1.00 to CIO 1.11 and CIO 2.00 to CIO 2.11 *1

50 µs max. 1 ms max.

Input 0.00 to 0.01

Input 0.08 to 0.11, 1.00 to 1.11

Input 0.02 to 0.07

Circuit configuration

Inputs CIO 0.08 to CIO 0.11, CIO 1.00 to CIO 1.11 and CIO 2.00 to CIO 2.11

* 1 The bits that can be used depend on the model of CPU Unit. * 2 The response time is the delay caused by hardware. The delay set in the PLC Setup (0 to 32 ms, default: 8 ms) for a normal input must be

added to this value.

Pulse plus direction input mode, Increment mode Up/down input mode

Differential phase mode

N/NA@@(S@)-type: 0.00/0.01 N/NA@@(S@)-type: 0.00/0.01

OFF

10.0 μs min.

2.5 μs min.

90% 50% 10%

OFF

20.0 μs min.

T1 T2 T3 T4

90% 50% 10%

90% 50%

T1, T2, T3, T4: 2.5 μs min.

10%

E@@(S)-type: 0.00 to 0.07 N/NA@@(S@)-type: 0.02 to 0.07

100 μs min.

OFF

50 μs min.

90% 50% 10%

E@@(S)-type: 0.00 to 0.03 N/NA@@(S@)-type: 0.02/0.03

200 μs min.

OFF

T1 T2 T3 T4

90% 50% 10%

90% 50%

T1, T2, T3, T4: 50 μs min.

10%

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Output indicator

Internal circuits

COM

OUT

250 VAC, 2A, 24 VDC, 2 A max.

30-VDC/250-VAC resistive load

125-VAC resistive load

125 VAC cosφ= 0.4

250 VAC cosφ= 0.4/ 30 VDC, τ = 7ms

Contact current (A)

Life (x 10

)

300

500

700

1000

200

100

30 20

3 2

0.1 0.2 0.3 0.5 0.7 1 2 3 5 7 10

50%

100%

˚C

Power voltage

21.6 VDC

Power voltage

20.4 VDC

Ambient temperature

50%

100

35 45 55˚C

Power voltage

21.6 VDC

Power voltage

20.4 VDC

Ambient temperature

30 45

50%

100%

˚C

Power voltage

21.6 VDC

Power voltage

20.4 VDC

Ambient temperature

50%

100%

˚C

Ambient temperature

80%

100%

°C

Ambient temperature

50%

100%

˚C

Power voltage

21.6 VDC

Power voltage

20.4 VDC

Ambient temperature

Output Specifications

●Output Specifications for Relay Outputs

Item Specification

Maximum switching capacity

Minimum switching capacity 5 VDC, 10 mA

Service life of relay

ON delay 15 ms max.

OFF response time 15 ms max.

Circuit configuration

Electrical

Mechanical 20,000,000 operations

Resistive load 200,000 operations (24 VDC)

Inductive load 70,000 operations (250 VAC, cosφ = 0.4)

Estimating the Service Life of Relays

Under normal conditions, the service life of output contacts is as shown above. The service life of relays is as shown in the following diagram as a guideline

CP1E-@@DR-@

250 VAC/2 A (cosφ = 1) 2 A, 24 VDC (4 A/common)

Relationship between Continuous Simultaneous ON Rate and Ambient Temperature

There are restrictions on the power supply voltage and output load current imposed by the ambient temperature. Make sure that the power supply voltage and output load current are within the following ranges.

CP1E-N20DR-D CP1E-N30DR-D CP1E-N40DR-D

Note: The above restrictions apply to the relay output load current from the CPU Unit even if Expansion I/O Units are not connected.

CP1E-@20@DR-A/N20DT@-@ CP1E-NA20DR-A CP1E-N60DR-D

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

OUT

COM (V-)

V+

V-

4.5 to 30 VDC

20.4 to 26.4 VDC

Internal circuits

24 VDC,

4.5 to 30 VDC

OUT

COM(+)

4µs min.

2µs min.

OFF

●Output Specifications for Transistor Outputs (Sinking or Sourcing)

Normal Outputs

Specification

Item

N@@S(1)-type N@@-type

0.3 A/output, 0.9 A/common *1

4.5 to 30 VDC

Maximum switching capacity

CP1E-E10D@-@: 0.9 A/Unit CP1E-N40(S@)D@-@: 3.6 A/Unit CP1E-N14D@-@: 1.5 A/Unit CP1E-N60(S@)D@-@: 5.4 A/Unit CP1E-N20D@-@: 1.8 A/Unit CP1E-NA20D@-@: 1.8 A/Unit CP1E-N30(S@)D@-@: 2.7 A/Unit

Minimum switching capacity 1 mA 4.5 to 30 VDC Leakage current 0.1mA max. Residual voltage 0.6 V max. 1.5V max. ON response time 0.1 ms max. 0.1 ms max. OFF response time 0.1 ms max. 1 ms max. Fuse Not provided.

External Power Supply

20.4 to 26.4V VDC 30mA max.

N@@S (1)-type sinking

sourcing

Internal circuits

Circuit configuration

N/NA@@-type sinking

N@@(S@)-type

100.00, 100.01

None None

Internal circuits

V+

V-

COM (V+)

OUT

20.4 to 26.4 VDC

4.5 to 30

VDC

sinking

sourcing

Internal circuits

N@@(S@)-type

100.02 to 102.07 *2

E10-type

100.00 to 100.03

OUT

COM(–)

COM(+)

OUT

24 VDC,

4.5 to 30 VDC

24 VDC,

4.5 to 30 VDC

OUT

COM(–)

24 VDC,

4.5 to 30 VDC

Internal circuits

sourcing

Note: Do not connect a load to an output terminal or apply a voltage in excess of the maximum switching capacity.

* 1 Also do not exceed 0.9 A for the total for CIO 100.00 to CIO 100.03. (CIO 100.00 to CIO 100.03 is different common.) * 2 The bits that can be used depend on the model of CPU Unit.

Pulse Outputs (CIO 100.00 and CIO 100.01)

Item Specification Maximum switching capacity 100 mA/4.5 to 26.4 VDC Minimum switching capacity 7 mA/4.5 to 26.4 VDC Maximum output frequency 100 kHz

Output waveform

Note: 1. The load for the above values is assumed to be the resistance load, and does not take into account the impedance for the connecting

cable to the load.

2. Due to distortions in pulse waveforms resulting from connecting cable impedance, the pulse widths in actual operation may be smaller than the values shown above.

3. The OFF and ON refer to the output transistor. The output transistor is ON at level “L”.

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

ON duty=

100

OFF

PWM Output (CIO 100.01)

Item Specification Maximum switching capacity 30 mA/4.5 to 26.4 VDC Maximum output frequency 32 kHz

PWM output accuracy

Output waveform

Note: The OFF and ON refer to the output transistor. The output transistor is ON at level “L”.

Built-in Analog I/O (NA-type CPU Units)

●Analog Input Specifications

Item Voltage input Current input

Number of inputs 2 inputs (Allocated 2 words: CIO 90 to CIO 91.)

Input signal range 0 to 5 V, 1 to 5 V, 0 to 10 V, or -10 to 10 V 0 to 20 mA or 4 to 20 mA

Max. rated input ±15 V ±30 mA

External input impedance 1 MΩ min. Approx. 250Ω

Resolution 1/6000

Overall accuracy

A/D conversion data

Averaging function Supported (Set for individual inputs in the PLC Setup.)

Open-circuit detection function Supported (Value when disconnected: 8000 hex)

●Analog Output Specifications

Number of outputs 1 output (Allocated 1 word: CIO 190.)

Output signal range 0 to 5 V, 1 to 5 V, 0 to 10 V, or -10 to 10 V 0 to 20 mA or 4 to 20 mA

Allowable external output load resistance 1 kΩ min. 600Ω max.

External input impedance 0.5Ωmax. ---

Resolution 1/6000

Overall accuracy

D/A conversion data

* In 0 to 20 mA mode, accuracy cannot be ensured at 0.2 mA or less.

At 25°C ±0.3% full scale ±0.4% full scale

0 to 55°C ±0.6% full scale ±0.8% full scale

-10 to +10 V F448 to 0BB8 hex Full Scale

Other ranges 0000 to 1770 hex Full Scale

Item Voltage output Current output

At 25°C ±0.4% full scale * 0 to 55°C ±0.8% full scale *

-10 to +10 V F448 to 0BB8 hex Full Scale

Other ranges 0000 to 1770 hex Full Scale

For ON duty +1%, .0%:10 kHz output For ON duty +5%, .0%: 0 to 32 kHz output

●Shared I/O Specifications

Item Specification

Conversion time 2 ms/point (6 ms total for 2 analog inputs and 1 analog output.)

Isolation method

Photocoupler isolation between analog I/O terminals and internal circuits. No isolation between analog I/O signals.

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

CP-series Expansion Units and Expansion I/O Units cannot be connected.

A total of up to three CP-series Expansion I/O Units and Expansion Units can be connected.

NCNCNC

COM

COM COM COM COM COM COM03 06 01 03 06

00 02 04 06 08 10

00 01 02 04 05 07 00 02 04 05 07

00 02 04 06 08 10

01 03 05 07 09 11 01 03 05 07 09 11

40EDR

OUT

CH CH

EXP

111009080706050403020100

0706050403020100

NCNCNC

COM

COM COM COM COM COM COM03 06 01 03 06

00 02 04 06 08 10

00 01 02 04 05 07 00 02 04 05 07

00 02 04 06 08 10

01 03 05 07 09 11 01 03 05 07 09 11

40EDR

OUT

CH CH

EXP

111009080706050403020100

0706050403020100

NCNCNC

COM

COM COM COM COM COM COM03 06 01 03 06

00 02 04 06 08 10

00 01 02 04 05 07 00 02 04 05 07

00 02 04 06 08 10

01 03 05 07 09 11 01 03 05 07 09 11

40EDR

OUT

CH CH

EXP

111009080706050403020100

0706050403020100

Specifications of Expansion I/O Units and Expansion Units

Expandable CPU Units

• Expansion I/O Units and Expansion Units cannot be connected to E10/14/20(S) or N14/20 CPU Units.

• A total of up to three Expansion I/O Units and Expansion Units can be connected to an E30/40/60(S), N30/40/60(S@), NA20 CPU Unit.

●CP1E E10/14/20(S) or N14/20CPU Unit

●CP1E E30/40(S), N30/40/60(S@) or NA20 CPU Unit

Connection Methods

Connection cables for the Expansion I/O Units and Expansion Units are used to connect the Units. The length can be extended by using a CP1WCN811 I/O Connection Cable (length: 800 m).

Maximum Number of I/O Points for an Expanded System

Number of inputs: 24

CPU Unit

Built-in I/O on CPU Unit Built-in Analog

Total

Number of

inputs

Number of

outputs

AD DA Total

CP1E-E10D@-@ 10 6 4 CP1E-@14@D@-@ 14 8 6 14 8 6 CP1E-@20@D@-@ 20 12 8 20 12 8 CP1E-@30@D@-@ 30 18 12

None None

CP1E-@40@D@-@ 40 24 16 160 96 64 CP1E-@60@D@-@ 60 36 24 180 108 72

Total number of

Expansion I/O Units and

Expansion Units that

can be connected

Not possible.

3 Units maximum

Total number of I/O points when three CP1W-40ED@

10 6 4

150 90 60

Number of outputs: 16

Expansion I/O Units are connected

Number of

inputs

Number of

outputs

CP1E-NA20D@-@ 20 12 8 2 1 140 84 56

Restrictions on External Power Supply Capacity

The following restrictions apply when using the CPU Unit’s external power supply.

●AC-power-supply E30/40(S), N30/40/60(S@) or NA20 CPU Unit

The power supply capacity is restricted for AC-power-supplyE30/40/60(S), N30/40/60(S@), NA20 CPU Units. It may not be possible to use the full 300 mA of the external power supply, though a CPU Unit can connect any CP-series Expansion I/O Unit or Expansion Unit. The entire 300 mA from the external power supply can be used if Expansion Units and Expansion I/O Units are not connected. Refer to the CP1E CPU Unit Hardware Manual (Cat. No. W479) for details.

●AC-power-supply or DC-power-supply E10/14/20(S), N14/20(S) CPU Unit

There is no external power supply on AC-power-supply or DC-power-supply E10/14/20, N14/20 CPU Units.

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

COM

OUT

Output LED

Internal circuits

Maximum 250 VAC: 2 A 24 VDC: 2 A

300

200

100

3 2

0.1

0.2 0.3 0.5 0.7 1 235

Life (× 10

)

Contact current (A)

120 VAC resistive load 24 VDC τ = 7 ms

120 VAC cosφ = 0.4 240 VAC cosφ = 0.4 24 VDC/240 VAC resistive load

Switching rate: 1,800 operations/hour

Specifications of Expansion I/O Units

●Input Specifications (CP1W-40EDR/40EDT/40EDT1/20EDR1/20EDT/20EDT1/8ED)

Item Specification

Input voltage 24 VDC +10%/-15%

Input impedance 4.7 kΩ

Input current 5 mA typical

ON voltage 14.4 VDC min.

OFF voltage 5.0 VDC max. ON delay 1 ms max. * OFF delay 1 ms max. *

Input LED

Circuit configuration

COM

4.7 kΩ

750 Ω

Internal circuits

Note: Do not apply voltage in excess of the rated voltage to the input terminal. * The response time is the hardware delay value. The delay set in the PLC Setup (0 to 32 ms, default: 8 ms) must be added to this value. For the

CP1W-40EDR/EDT/EDT1, a fixed value of 16 ms must be added.

●Output Specifications Relay Outputs (CP1W-40EDR/32ER/20EDR1/16ER/8ER)

Item Specification

Max. switching capacity

Min. switching capacity 5 VDC, 10 mA

Service life of relay (See note.)

ON delay 15 ms max.

OFF delay 15 ms max.

Electrical

Mechanical 20,000,000 operations

Resistive load 150,000 operations (24 VDC)

Inductive load 100,000 operations (240 VAC, cosφ = 0.4)

2 A, 250 VAC (cosφ = 1), 2 A, 24 VDC (4 A/common)

Circuit configuration

Note: 1. Estimating the Service Life of Relays

The service life of output contacts is as shown in the following diagram.

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

100

Ambient temperature(˚C)

Output load current(%)

Ambient temperature (˚C)

Number of inputs

ON simultaneously (%)

50%

100%

°C4535

Power voltage:

21.6 VDC

Power voltage:

20.4 VDC

Ambient temperature

50%

100%

°C45

Power voltage:

21.6 VDC

Power voltage:

20.4 VDC

Ambient temperature

50%

100%

°C4535

Power voltage:

21.6 VDC

Power voltage:

20.4 VDC

Ambient temperature

2. Restrictions of CP1W-16ER/32ER Limit the output load current to satisfy the following derating curve.

3. CP1W-32ER’s maximum number of simultaneously ON output points is 24 (75%). Relation between Number of ON Outputs and Ambient Temperature (CP1W-32ER)

4. According to the ambient temperature, there are restrictions on power supply voltage and output load current for the CPU Units connected with the Expansion I/O Units (CP1W-8ER/16ER/20EDR1/32ER/40EDR). Use the PLC in the range of the power supply voltage and output load current as show below. The ambient temperature is restricted for the power-supply CPU Units (CP1E-N/NA@@@@-@). Derating curve of the output load current for Expansion I/O Units (CP1W-8ER/16ER/20EDR1/32ER/40EDR).

Connected to CP1E-N30DR-D

Connected to CP1E-N60DR-D/ CP1E-N60(S@)DT@-D

100%

Power voltage:

21.6 VDC

50%

Power voltage:

20.4 VDC

Ambient temperature

Connected to CP1E-N40DR-D

Connected to CP1E-NA20DT@-D Connected to CP1E-NA20DR-A

100%

Power voltage:

21.6 VDC

50%

Power voltage:

20.4 VDC

°C45

Ambient temperature

Connected to CP1E-N30(S@)DT@-D Connected to CP1E-N40(S@)DT@-D

100%

Power voltage:

21.6 VDC

50%

Power voltage:

20.4 VDC

Ambient tem

100%

80%

°C45

Ambient temperature

erature

°C4535

°C

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

0.9

0.8

(A)

(°C)

50 55

Ambient temperature

Total current for common

●Transistor Outputs (Sinking or Sourcing)

Item

Max. switching capacity *1

CP1W-40EDT

CP1W-40EDT1

4.5 to 30 VDC

0.3 A/output

0.9 A/common

3.6 A/Unit

CP1W-32ET

CP1W-32ET1

4.5 to 30 VDC

0.3 A/output

0.9 A/common

7.2 A/Unit

Leakage current 0.1 mA max. 0.1 mA max. 0.1 mA max. 0.1 mA max. 0.1 mA max.

Residual voltage 1.5 V max. 1.5 V max. 1.5 V max. 1.5 V max. 1.5 V max.

ON delay 0.1 ms max. 0.1 ms max. 0.1 ms. 0.1 ms max. 0.1 ms max.

OFF delay

Max. number of Simultaneously ON Points of Output

1 ms max. 24 VDC +10%/-5% 5 to 300 mA

16 pts (100%) 24 pts (75%) 8 pts (100%) 16 pts (100%) 8 pts (100%)

1 ms max. 24 VDC +10%/-5% 5 to 300 mA

Fuse *2 1 fuse/common

Sinking Outputs Sourcing Outputs

Circuit configuration

Output LED

Internal circuits

OUT

COM (−)

Specification

CP1W-20EDT

CP1W-20EDT1

24 VDC +10%/-5%

0.3 A/output

0.9 A/common

1.8 A/Unit

1 ms max. 24 VDC +10%/-5% 5 to 300 mA

24 VDC/4.5 to 30 VDC

Output LED

Internal circuits

CP1W-16ET

CP1W-16ET1

4.5 to 30 VDC

0.3 A/output

0.9 A/common

3.6 A/Unit

1 ms max. 24 VDC +10%/-5% 5 to 300 mA

OUT

COM (+)

24 VDC/4.5 to 30 VDC

CP1W-8ET

CP1W-8ET1

4.5 to 30 VDC

0.3 A/output

0.9 A/common

1.8 A/Unit

1 ms max. 24 VDC +10%/-5% 5 to 300 mA

*1 If the ambient temperature is maintained below 50°C, up to 0.9 A/common can be used.

*2 The fuse cannot be replaced by the user. Replace the Unit if the fuse breaks due to an short-circuit or overcurrent. *3 Do not connect a load to an output terminal or apply a voltage in excess of the maximum switching capacity.

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Specifications of Expansion Units

●Analog Input Units

Model CP1W-AD041 CP1W-AD042

Item Voltage Input Current Input Voltage Input Current Input

Number of inputs 4 inputs (4 words allocated)

Input signal range

Max. rated input ±15 V ±30 mA ±15 V ±30 mA

External input impedance 1 MΩ min. Approx. 250 Ω 1 MΩ min. Approx. 250 Ω

Resolution 1/6000 (full scale) 1/12000 (full scale)

Overall accuracy

A/D conversion data

Averaging function Supported (Set in output words n+1 and n+2.)

Open-circuit detection function Supported

Conversion time 2 ms/point (8 ms/all points) 1 ms/point (4 ms/all points)

Isolation method Photocoupler isolation between analog I/O terminals and internal circuits. No isolation between analog I/O signals.

Current consumption 5 VDC: 100 mA max.; 24 VDC: 90 mA max. 5 VDC: 100 mA max.; 24 VDC: 50 mA max.

25°C 0.3% full scale 0.4% full scale 0.2% full scale 0.3% full scale

0 to 55°C 0.6% full scale 0.8% full scale 0.5% full scale 0.7% full scale

0 to 5 VDC, 1 to 5 VDC, 0 to 10 VDC, or –10 to 10 VDC

16-bit binary (4-digit hexadecimal) Full scale for –10 to 10 V: F448 to 0BB8 Hex Full scale for other ranges: 0000 to 1770 Hex

0 to 20 mA or 4 to 20 mA

●Analog Output Units

Model CP1W-DA021/CP1W-DA041 CP1W-DA042

Item Voltage Output Current Output Voltage Input Current Input

Number of outputs

Output signal range

External output allowable

Analog output section

Conversion time

Isolation method Photocoupler isolation between analog I/O terminals and internal circuits. No isolation between analog I/O signals.

Current consumption

load resistance

External output impedance 0.5 Ω max. --- 0.5 Ω max. ---

Resolution 1/6000 (full scale) 1/12000 (full scale)

Overall accuracy

D/A conversion data

25°C 0.4% full scale 0.3% full scale

0 to 55°C 0.8% full scale 0.7% full scale

CP1W-DA021: 2 outputs (2 words allocated) CP1W-DA041: 4 outputs (4 words allocated)

1 to 5 VDC, 0 to 10 VDC, or –10 to 10 VDC

2 kΩ min. 350 Ω max. 2 kΩ min. 350 Ω max.

16-bit binary (4-digit hexadecimal) Full scale for –10 to 10 V: F448 to 0BB8 Hex Full scale for other ranges: 0000 to 1770 Hex

CP1W-DA021: 2 ms/point (4 ms/all points) CP1W-DA041: 2 ms/point (8 ms/all points)

CP1W-DA021: 5 VDC: 40 mA max.; 24 VDC: 95 mA max. CP1W-DA041: 5 VDC: 80 mA max.; 24 VDC: 124 mA max.

0 to 20 mA or 4 to 20 mA

0 to 5 VDC, 1 to 5 VDC, 0 to 10 VDC, or -10 to 10 VDC

16-bit binary (4-digit hexadecimal) Full scale for –10 to 10 V: E890 to 1770 Hex Full scale for other ranges: 0000 to 2EE0 Hex

4 outputs (4 words allocated)

1 to 5 VDC, 0 to 10 VDC, or –10 to 10 VDC

16-bit binary (4-digit hexadecimal) Full scale for –10 to 10 V: E890 to 1770 Hex Full scale for other ranges: 0000 to 2EE0 Hex

1 ms/point (4 ms/all points)

5 VDC: 70 mA max.; 24 VDC: 160 mA max.

0 to 20 mA or 4 to 20 mA

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

●Analog I/O Units

Model CP1W-MAD42/CP1W-MAD44 CP1W-MAD11

Item Voltage I/O Current I/O Voltage I/O Current I/O

Number of inputs 4 inputs (4 words allocated) 2 inputs (2 words allocated)

Analog Input Section

Analog Output Section

Conversion time

Isolation method

Current consumption

Input signal range

Max. rated input ±15 V ±30 mA ±15 V ±30 mA

External input impedance 1 MΩ min. Approx. 250 Ω 1 MΩ min. Approx. 250 Ω

Resolution 1/12000 (full scale) 1/6000 (full scale)

Overall accuracy

A/D conversion data

Averaging function Supported

Open-circuit detection function Supported

Number of outputs

Output signal range

Allowable external output load resistance 2 kΩ min. 350 Ω max. 1 kΩ min. 600 Ω max.

External output impedance 0.5 Ω max. --- 0.5 Ω max. ---

Resolution 1/12000 (full scale) 1/6000 (full scale)

Overall accuracy

Set data (D/A conversion)

25°C 0.2% full scale 0.3% full scale 0.3% full scale 0.4% full scale

0 to 55°C 0.5% full scale 0.7% full scale 0.6% full scale 0.8% full scale

25°C 0.3% full scale 0.4% full scale

0 to 55°C 0.7% full scale 0.8% full scale

0 to 5 VDC, 1 to 5 VDC, 0 to 10 VDC, or –10 to 10 VDC

16-bit binary (4-digit hexadecimal) Full scale for –10 to 10 V: E890 to 1770 hex Full scale for other ranges: 0000 to 2EE0 hex

CP1W-MAD42: 2 outputs (2 words allocated) CP1W-MAD44: 4 outputs (4 words allocated)

1 to 5 VDC, 0 to 10 VDC, or

−10 to 10 VDC

16-bit binary (4-digit hexadecimal) Full scale for −10 to 10 V: E890 to 1770 hex Full scale for other ranges: 0000 to 2EE0 hex

CP1W-MAD42: 1 ms/point (6 ms/all points) CP1W-MAD44: 1 ms/point (8 ms/all points)

Photocoupler isolation between analog I/O terminals and internal circuits. No isolation between analog I/O signals.

CP1W-MAD42: 5 VDC: 120 mA max., 24 VDC: 120 mA max. CP1W-MAD44: 5 VDC: 120 mA max., 24 VDC: 170 mA max.

0 to 20 mA or 4 to 20 mA

0 to 5 VDC, 1 to 5 VDC, 0 to 10 VDC, or −10 to 10 VDC

16-bit binary (4-digit hexadecimal) Full scale for −10 to 10 V: F448 to 0BB8 hex Full scale for other ranges: 0000 to 1770 hex

Supported (Settable for individual inputs via DIP switch)

1 output (1 word allocated)

1 to 5 VDC, 0 to 10 VDC, or

−10 to 10 VDC,

16-bit binary (4-digit hexadecimal) Full scale for −10 to 10 V: F448 to 0BB8 hex Full scale for other ranges: 0000 to 1770 hex

2 ms/point (6 ms/all points)

5 VDC: 83 mA max., 24 VDC: 110 mA max.

0 to 20 mA or 4 to 20 mA

●Temperature Sensors Units

Item CP1W-TS001 CP1W-TS002 CP1W-TS101 CP1W-TS102

Temperature sensors

Number of inputs 2424

Allocated input words 2424

Accuracy

Conversion time 250 ms for 2 or 4 input points

Converted temperature data 16-bit binary data (4-digit hexadecimal)

Isolation Photocouplers between all temperature input signals

Current consumption 5 VDC: 40 mA max., 24 VDC: 59 mA max. 5 VDC: 54 mA max., 24 VDC: 73 mA max.

* Accuracy for a K-type sensor at -100°C or less is ±4°C ±1 digit max.

The rotary switch is used to set the temperature range.

Setting

1 0.0 to 500.0 0.0 to 900.0 JPt100 −200.0 to 650.0 −300.0 to 1,200.0

4 to F --- Cannot be set. ---

Thermocouples Platinum resistance thermometer

Switchable between K and J, but same type must be used for all inputs.

(The larger of ±0.5% of converted value or ±2°C) ±1 digit max. *

CP1W-TS001/TS002 CP1W-TS101/TS102

Input type Range (°C) Range (°F) Input type Range (°C) Range (°F)

−200 to 1,300 −300 to 2,300 Pt100 −200.0 to 650.0 −300.0 to 1,200.0

−100 to 850 −100 to 1,500 ---

Switchable between Pt100 and JPt100, but same type must be used for all inputs.

(The larger of ±0.5% of converted value or ±1°C) ±1 digit max.

Cannot be set.3 0.0 to 400.0 0.0 to 750.0 ---

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

1 2 3 4 5 6

OFF

●Main Specifications

Item CP1W-TS003

Temperature sensors

Number of inputs

Thermocouple inputs

Accuracy at 25°C

Accuracy at 0 to 55°C

Input signal range

Resolution

Max. rated input

External input impedance

Open-circuit detection function Supported

Averaging function Unsupported

Conversion time 250 ms for 4 input points

Converted temperature data 16-bit binary data (4-digit hexadecimal)

Converted AD data 16-bit binary data (4-digit hexadecimal)

Isolation Photocouplers between any two input signals

Current consumption 5 VDC: 70 mA max., 24 VDC: 30 mA max.

Analog voltage inputs

Analog inputs

Thermocouple inputs

Analog voltage inputs

Analog inputs

Thermocouple inputs

Analog voltage inputs

Analog inputs

Thermocouple inputs

Analog inputs

Analog voltage inputs

Analog inputs

Analog voltage inputs

Analog inputs

* 1 Accuracy for a K-type sensor at -100°C or less is ±4°C ±1 digit max. * 2 Accuracy for a K-type sensor at -100°C or less is ±10°C ±1 digit max.

Thermocouples or analog input

Switchable between K and J, but same type must be used for all inputs.

Thermocouples inputs :4 , Analog inputs :2 Two analog inputs can be shared with thermocouples inputs.

(The larger of ±0.5% of converted value or ±2°C) ±1 digit max. *1

0.5% full scale

0.6% full scale (The larger of ±1% of converted value or ±4°C) ±1 digit max. *2

1.0 % full scale

1.2 % full scale

K: -200.0 to 1300.0°C or .300.0 to 2300.0°F J: -100.0 to 850.0°C or .100.0 to 1500.0°F

0 to 10V/1 to 5V

4 to 20mA

0.1°C or 0.1°F

1/12000 (full scale)

±15V

±30mA

1MΩ min.

Approx. 250Ω

DIP Switch Settings

The DIP switch is used to set the input type (temperature or analog input), the input thermocouple type (K or J) and the temperature unit (°C or °F). Note: Set the temperature range according to the type of temperature sensor connected to the Unit. Temperature data will not be converted

correctly if the temperature range does not match the sensor.

SW Setting

2 Temperature unit

3NC

6 Analog input signal range

Temperature input

Input type Range (°C) Range (°F)

K -200.0 to 1300.0 -300 to 2300

J -100.0 to 850.0 -100.0 to 1500

Thermocouple type of temperature sensor

Input type selection for the third input (Input 2)

Input type selection for the fourth input (Input 3)

ON J

OFF K

ON °F

OFF °C

ON Analog input

OFF Thermocouple

ON Analog input

OFF Thermocouple

ON 1 to 5V/4 to 20mA

OFF 0 to 10V

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

1 2

OFF

●Main Specifications

Item CP1W-TS004

Temperature sensors

Number of inputs 12 (2 input words and 1 output word allocated)

Accuracy

Conversion time 500 ms for 12 input points

Converted temperature data

Isolation Photocouplers between any two input signals

Current consumption 5 VDC: 80 mA max., 24 VDC: 50 mA max.

25°C (The larger of ±0.5% of converted value or ±2°C) ±1 digit max. *1 0 to 55°C (The larger of ±1% of converted value or ±4°C) ±1 digit max. *2

* 1 Accuracy for a K-type sensor at -100°C or less is ±4°C ±1 digit max. * 2 Accuracy for a K-type sensor at -100°C or less is ±10°C ±1 digit max.

DIP Switch Settings

The DIP switch is used to set the temperature unit and to set the temperature input range. Note: Set the temperature range according to the type of temperature sensor connected to the Unit. Temperature data will not be converted

correctly if the temperature range does not match the sensor.

SW Setting

1 Input type

2 Temperature unit

Temperature input

Input type Range (°C) Range (°F)

K -200.0 to 1300.0 -300 to 2300

J -100.0 to 850.0 -100.0 to 1500

Thermocouples

Switchable between K and J, but same type must be used for all inputs.

16-bit binary data (4-digit hexadecimal) 2-decimal-place mode is not supported

ON J

OFF K

ON °F

OFF °C

●CompoBus/S I/O Link Unit

Model number CP1W-SRT21

Master/slave CompoBus/S Slave

Number of I/O points 8 input points, 8 output points

Number of words allocated in CPU Unit I/O memory

Node number setting

1 input word, 1 output word

Set using the DIP switch (Set before turning on the CPU Unit’s power supply.)

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Analog Option Board

An analog option board can be added to the CP1E-N/NA@@.

Note: 1. Can be used for the CP1E-N/NA@@ version 1.2 or later.

2. Analog boards can not be used for E@@-type and N@@S(1)-type.

Built-in RS-232C port

CP1E N30/40/60 or NA20 CPU Unit

CP1W-ADB21 Analog Input Option Board

CP1W-DAB21V Analog Output Option Board

CP1W-MAB221 Analog Input/Output Option Board

Specifications of Analog Option Board

●CP1W-ADB21 ●CP1W-DAB21V

Item

Input signal range 0 to 10 VDC 0 to 20 mA

Max. rated input 0 to 15 VDC 0 to 30 mA

External input impedance

Resolution 1/4000 (full scale) 1/2000 (full scale)

Overall accuracy

A/D conversion data 0000 to 0FA0 Hex 0000 to 07D0 Hex

Averaging function None

Isolation method

Current consumption 5 VDC: 20 mA max.

25°C 0.5% full scale 0.6% full scale

0 to 55°C 1.0% full scale 1.2% full scale

Voltage Input Current Input

200 kΩ min. Approx. 250 Ω

No isolation between analog I/O terminals and internal circuits.

●CP1W-MAB221

Item

Input signal range 0 to 10 VDC 0 to 20 mA

Max. rated input 0 to 15 VDC 0 to 30 mA

External input impedance

Analog Input Section

Analog Output Section

Isolation method No isolation between analog I/O terminals and internal circuits.

Current consumption 5 VDC: 80 mA max.

Resolution 1/4000 (full scale) 1/2000 (full scale)

Overall accuracy

A/D conversion data 0000 to 0FA0 Hex 0000 to 07D0 Hex

Averaging function None

Output signal range 0 to 10 VDC ---

External output allowable load resistance

External output impedance

Resolution 1/4000 (full scale) ---

Overall accuracy

Set data (D/A conversion)

Specifications

Output signal range 0 to 10 VDC ---

External output allowable load resistance

External output impedance

Resolution 1/4000 (full scale) ---

Overall accuracy

Set data (D/A conversion)

Isolation method

Current consumption 5 VDC: 60 mA max.

Voltage I/O Current I/O

200 kΩ min. Approx. 250 Ω

25°C 0.5% full scale 0.6% full scale

0 to 55°C 1.0% full scale 1.2% full scale

2 kΩ min. ---

0.5 Ω max. ---

25°C 0.5% full scale ---

0 to 55°C 1.0% full scale ---

0000 to 0FA0 Hex ---

Item

2 kΩ min. ---

0.5 Ω max. ---

25°C 0.5% full scale ---

0 to 55°C 1.0% full scale ---

0000 to 0FA0 Hex ---

No isolation between analog I/O terminals and internal circuits.

Specifications

Voltage Output Current Output

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Analog Option Board Refresh Time

Analog Opiton Board

CP1W-ADB21 40 ms ±30% 50 ms ±30% 80 ms ±30%

CP1W-DAB21V 30 ms ±40% 40 ms ±50% 70 ms ±40%

CP1W-MAB221(AD) 60 ms ±40% 80 ms ±60% 100 ms ±50%

CP1W-MAB221(DA) 40 ms ±80% 60 ms ±60% 90 ms ±50%

1 ms 10 ms 20 ms

Cycle time

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Output terminal

block

Input terminals

Ground terminal

Output indicators

Power supply input terminals

Output terminals

Input indicators

Peripheral

USB port

Operation indicators

Input terminal block

Output

terminal block

Ground

terminal

Output

indicators

Expansion

I/O Unit connector

Output terminals

External power supply

Input terminal

block

Input

indicators

Peripheral

USB port

Operation

indicators

Power supply input terminals

Input terminals

Input terminal block

Output terminal block

Power supply input terminals

Input terminals

Output terminals

Ground terminal

Input indicators

Output indicators

Peripheral USB port

Analog adjusters

Operation indicators Battery cover

Built-in RS-232C port

Built-in RS-232C communications status indicator

Input terminal block

Output terminal block

Power supply input terminals

Input terminals

Output terminals

External power supply

Ground terminal

Input indicators

Output indicators

Peripheral USB port

Analog adjusters

Operation indicators

Expansion I/O Unit connector

Serial Option Board slot

Built-in RS-232C communications status indicator

Battery cover

Built-in RS-232C port

Analog input terminal (NA-type only)

Analog output terminals (NA-type only)

External Interfaces

The CP1E CPU Units provide the following external interfaces.

E14/20S CPU Units

E30/40/60S CPU Units N30/40/60S(1) CPU Units

E@@S-type N@@S(1)-type

Battery

cover

Built-in RS-232C

communications status indicator

Built-in RS-232C

port

Built-in RS-485

communications status indicator *

Built-in RS-485 port

E10/14/20 CPU Units N14/20 CPU Units

E@@-type N@@-type

Note: Terminal Block (Fixed)

E30/40 CPU Units N30/40/60 or NA20 CPU Units

E@@-type N@@-type/NA-type

* N@@S1-type only.

Note: Terminal Block (Fixed)

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Built-in RS-232C

Built-in RS-2485

CP1W-CIF11/CIF12-V1 RS-422A/485 Option Board

CP1W-CIF01 RS-232C Option Board

Built-in RS-232C port

CP1W-CIF41 Ethernet Option Board version 2.0 or higher

IP ADDRESS:

SUBNET MASK:

COMMERR

10BASE-T

100BASE-TX

Optional Serial Communication Board

Note: The Optional Serial Communication Board cannot be used for CP1E

N/NA@@S(1)-type CPU Units and E@@-type CPU Units.

Model number Port

Maximum

transmission

distance

Connection method

CP1W-CIF01 One RS-232C port 15 m

Connector (D-sub, 9 pin female)

CP1W-CIF11

One RS-422A/485 port (not isolated)

50 m

Terminal block (using ferrules)

CP1W-CIF12-V1

One RS-422A/485 port (isolated)

500 m

Terminal block (using ferrules)

CP1W-CIF41 One Ethernet port 100 m

Connector (RJ45, 8 pin modular)

Built-in RS-232C port

Serial Communications Port for N/NA@@(S@)-type CPU Units

The Serial Communication Port can be used for a CP1E N/NA@@(S@)-type CPU Unit.

N30/40/60S1 CPU Units N30/40/60S CPU Units

Built-in RS-232C, RS-485 ports. Built-in RS-232C port.

Built-in RS-232C

N30/40/60 or NA20 CPU Units

One built-in RS-232C port and one Option Board can be used.

N14/20 CPU Units

Built-in RS-232C ports.

Note: Option Boards cannot be used for CP1E N14/20 CPU Units.

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Abbreviation for signal name

Signal name Signal direction

N@@-type

built-in

RS-232C port /

CP1W-CIF01

N@@S(1)-type

Buit-in

RS-232C port

1 FG Frame ground --

2 SD (TXD) Send data Output

3 RD (RXD) Receive data Input

4RS (RTS) Request to send Output

5 CS (CTS) Clear to send Input

6 5 V Power supply -7 DR (DSR) NC * Data set ready Input 8 ER (DTR) NC * Data terminal ready Output

9 SG (0 V) Signal ground --

Connector hood

FG Frame Ground --

* Built-in RS-232C port of N@@S(1)-type does not support DR/ER.

CJ1W-CIF11 cannot be used for the built-in RS-232C port of N@@S(1)-type.

●RS-232C Connector

●DIP Switch for Terminating Resistance Settings

Settings

ON ON (both ends)

Terminating resistance selection Resistance: Approx. 220Ω

OFF OFF

●RS-485 Terminal Block

DIP Switch

COMM

Front Back

Communications Status Indicator

DIP Switch for Operation Settings

RS-422A/485 Connector

RDA- RDB+ SDA- SDB+ FG

CPU Unit Connector

●RS-422A/485 Terminal Block

RDB+

RDA-

SDA- SDB+

Tighten the terminal block screws to a torque of 0.28 N·m.

Built-in RS-232C Port and CP1W-CIF01 RS-232C Option Board

Front Back

Communications Status Indicator

COMM

RS-232 Connector CPU Unit Connector

Built-in RS-232C Port (2-wire sensors) (N@@S1-type only)

CP1W-CIF11/CIF12-V1 RS-422A/485 Option Board

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

IP ADDRESS:

SUBNET MASK:

COMMERR

10BASE-T

100BASE-TX

Front Rear

Label

Attach the label here to show IP address and subnet mask.

Ethernet Connector

Used to connect the Ethernet twisted-pair cable.

LED Indicators

Display the operating status of the Option Board.

CPU Unit connector

USB port

A connector

Commercially available USB cable

Peripheral USB port (Conforming to USB 2.0, B connector)

B connector

CP1E CPU Unit

CX-Programmer

CP1W-CIF41 Ethernet Option Board version 2.0 or higher

●Specifications ●FINS Communications Service Specifications

Type 100/10Base-TX (Auto-MDIX)

Support Software CX-Programmer version 9.12 or higher

Transfer

Media access method

Modulation method Baseband

Transmission paths

Baud rate

Transmission media

Transmission Distance

Number of cascade connections

CSMA/CD

Star form

100 Mbit/s (100Base-TX)

• Half/full auto-negotiation for each port

• Link speed auto-sensing for each port

• Unshielded

twisted-pair (UDP) cable Categories: 5, 5e

• Shielded twistedpair (STP) cable Categories: 100Ω at 5, 5e

100 m (distance between hub and node)

No restrictions if switching hubs are used.

10 Mbit/s (10Base-TX)

• Unshielded twisted-pair (UDP) cable Categories: 3, 4, 5, 5e

•

Shielded twistedpair (STP) cable Categories:

at 3, 4, 5, 5e

100

Number of nodes 254

Message Length 552 bytes max.

Date Length

Number of buffer 8k byte

Protocol name FINS/UDP method FINS/TCP method

Protocol used

Server/Client Only server (Cannot be used as a client)

Number of connections --- 2

Port number

Protection No

540 bytes max. (except for FINS header 10 byte and Comm and header 2 byte.)

UDP/IP TCP/IP

The selection of UDP/IP or TCP/IP is made from the FINS/TCP Tab by the Web browser function.

9600 (default) Can be changed.

Yes (Specification of client IP addresses when unit is used as a server)

Connecting to Support Software

Connecting Methods

Using commercially available USB cable, connect the CX-Programmer to the peripheral USB port on the CPU Unit. Host link connection can be made with RS-232C port to connect the Programming Device (CX-Programmer).

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Connecting Cable

Use the following cable to connect the CP1E CPU Unit to the computer running the Support Software.

USB port

Port at Unit Port at computer

Peripheral USB port (Conforming to USB 2.0, B connector)

USB port USB 2.0 (or 1.1)

RS-232C Port for N/NA@@(S@)-type CPU Units

Port at Unit Port at computer Communications mode

RS-232C Port or CP1W-CIF01 (Add this to the option board slot.)

Note: Connectable with CX-Programmer Ver.9.1 or higher only. * Use the USB-Serial Conversion Cable CS1W-CIF31 together to connect a PLC to a personal computer's USB port.

RS-232C port *

Network type

(communications mode)

Host Link (SYSWAY)

Model numbers Length

Commercially available USB cable (A connector - B connector)

Connecting Cable

Model Length Remarks

XW2Z-200S-CV 2m

XW2Z-500S-CV 5m

XW2Z-200S-V 2m ---

XW2Z-500S-V 5m ---

Less than 5 m

With anti-static connectors

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Programming Instructions

Sequence Input Instructions

Instruction Mnemonic

LOAD LD

LOAD NOT LD NOT

AND AND

AND NOT AND NOT

OR OR

OR NOT OR NOT

AND LOAD AND LD

OR LOAD OR LD

NOT NOT

CONDITION ON UP

CONDITION OFF DOWN

Sequence Output Instructions

Instruction Mnemonic

OUTPUT OUT

OUTPUT NOT OUT NOT

KEEP KEEP

DIFFERENTIATE UP DIFU

DIFFERENTIATE DOWN DIFD

SET SET

RESET RSET

MULTIPLE BIT SET SETA

MULTIPLE BIT RESET RSTA

SINGLE BIT SET SETB

SINGLE BIT RESET RSTB

Sequence Output Instructions

Instruction Mnemonic

END END

NO OPERATION NOP

INTERLOCK IL

INTERLOCK CLEAR ILC

MULTI-INTERLOCK DIFFERENTIATION HOLD

MULTI-INTERLOCK DIFFERENTIATION RELEASE

MULTI-INTERLOCK CLEAR MILC

JUMP JMP

JUMP END JME

CONDITIONAL JUMP CJP

FOR LOOP FOR

BREAK LOOP BREAK

NEXT LOOP NEXT

MILH

MILR

Timer and Counter Instructions

Instruction Mnemonic

TIMER

COUNTER

HIGH-SPEED TIMER

ONE-MS TIMER

ACCUMULATIVE TIMER

LONG TIMER

REVERSIBLE COUNTER

RESET TIMER/COUNTER

TIM

TIMX

CNT

CNTX

TIMH

TIMHX

TMHH

TMHHX

TTIM

TTIMX

TIML

TIMLX

CNTR

CNTRX

CNR

CNRX

Comparison Instructions

Instruction Mnemonic

LD,AND,OR+=

LD,AND,OR+<>

Input Comparison Instructions (unsigned)

Input Comparison Instructions (double, unsigned)

Input Comparison Instructions (signed)

Input Comparison Instructions (double, signed)

Time Comparison Instructions

COMPARE CMP

DOUBLE COMPARE CMPL

SIGNED BINARY COMPARE CPS

DOUBLE SIGNED BINARY COMPARE

TABLE COMPARE TCMP

UNSIGNED BLOCK COMPARE BCMP

AREA RANGE COMPARE ZCP

DOUBLE AREA RANGE COMPARE ZCPL

LD,AND,OR+<

LD,AND,OR+<=

LD,AND,OR+>

LD,AND,OR+>=

LD,AND,OR+=+L

LD,AND,OR+<>+L

LD,AND,OR+<+L

LD,AND,OR+<=+L

LD,AND,OR+>+L

LD,AND,OR+>=+L

LD,AND,OR+=+S

LD,AND,OR+<>+S

LD,AND,OR+<+S

LD,AND,OR+<=+S

LD,AND,OR+>+S

LD,AND,OR+>=+S

LD,AND,OR+=+SL

LD,AND,OR+<>+SL

LD,AND,OR+<+SL

LD,AND,OR+<=+SL

LD,AND,OR+>+SL

LD,AND,OR+>=+SL

=DT

<>DT

<DT

<=DT

>DT

>=DT

CPSL

Data Movement Instructions

Instruction Mnemonic

MOVE MOV

DOUBLE MOVE MOVL

MOVE NOT MVN

MOVE BIT MOVB

MOVE DIGIT MOVD

MULTIPLE BIT TRANSFER XFRB

BLOCK TRANSFER XFER

BLOCK SET BSET

DATA EXCHANGE XCHG

SINGLE WORD DISTRIBUTE DIST

DATA COLLECT COLL

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Data Shift Instructions

Instruction Mnemonic

SHIFT REGISTER SFT

REVERSIBLE SHIFT REGISTER SFTR

WORD SHIFT WSFT

ARITHMETIC SHIFT LEFT ASL

ARITHMETIC SHIFT RIGHT ASR

ROTATE LEFT ROL

ROTATE RIGHT ROR

ONE DIGIT SHIFT LEFT SLD

ONE DIGIT SHIFT RIGHT SRD

SHIFT N-BITS LEFT NASL

DOUBLE SHIFT N-BITS LEFT NSLL

SHIFT N-BITS RIGHT NASR

DOUBLE SHIFT N-BITS RIGHT NSRL

Increment/Decrement Instructions

Instruction Mnemonic

INCREMENT BINARY ++

DOUBLE INCREMENT BINARY ++L

DECREMENT BINARY --

DOUBLE DECREMENT BINARY --L

INCREMENT BCD ++B

DOUBLE INCREMENT BCD ++BL

DECREMENT BCD --B

DOUBLE DECREMENT BCD --BL

Symbol Math Instructions

Instruction Mnemonic

SIGNED BINARY ADD WITHOUT CARRY

DOUBLE SIGNED BINARY ADD WITHOUT CARRY

SIGNED BINARY ADD WITH CARRY

DOUBLE SIGNED BINARY ADD WITH CARRY

BCD ADD WITHOUT CARRY +B

DOUBLE BCD ADD WITHOUT CARRY

BCD ADD WITH CARRY +BC

DOUBLE BCD ADD WITH CARRY +BCL

SIGNED BINARY SUBTRACT WITHOUT CARRY

DOUBLE SIGNED BINARY SUBTRACT WITHOUT CARRY

SIGNED BINARY SUBTRACT WITH CARRY

DOUBLE SIGNED BINARY SUBTRACT WITH CARRY

BCD SUBTRACT WITHOUT CARRY -B

DOUBLE BCD SUBTRACT WITHOUT CARRY

BCD SUBTRACT WITH CARRY -BC

DOUBLE BCD SUBTRACT WITH CARRY

SIGNED BINARY MULTIPLY *

DOUBLE SIGNED BINARY MULTIPLY BCD MULTIPLY *B DOUBLE BCD MULTIPLY *BL

SIGNED BINARY DIVIDE /

DOUBLE SIGNED BINARY DIVIDE /L

BCD DIVIDE /B

DOUBLE BCD DIVIDE /BL

+CL

+BL

-L

-C

-CL

-BL

-BCL

Conversion Instructions

Instruction Mnemonic

BCD-TO-BINARY BIN

DOUBLE BCD-TO-DOUBLE BINARY

BINARY-TO-BCD BCD

DOUBLE BINARY-TO-DOUBLE BCD

2’S COMPLEMENT NEG

DATA DECODER MLPX

DATA ENCODER DMPX

ASCII CONVERT ASC

ASCII TO HEX HEX

BINL

BCDL

Logic Instructions

Instruction Mnemonic

LOGICAL AND ANDW

DOUBLE LOGICAL AND ANDL

LOGICAL OR ORW

DOUBLE LOGICAL OR ORWL

EXCLUSIVE OR XORW

DOUBLE EXCLUSIVE OR XORL

COMPLEMENT COM

DOUBLE COMPLEMENT COML

Special Math Instructions

Instruction Mnemonic

ARITHMETIC PROCESS APR

BIT COUNTER BCNT

Floating-point Math Instructions

Instruction Mnemonic

FLOATING TO 16-BIT FIX

FLOATING TO 32-BIT FIXL

16-BIT TO FLOATING FLT

32-BIT TO FLOATING FLTL

FLOATING-POINT ADD +F

FLOATING-POINT SUBTRACT -F

FLOATING-POINT DIVIDE /F FLOATING-POINT MULTIPLY *F

LD, AND, OR+=F

LD, AND, OR+<>F

Floating Symbol Comparison

FLOATING- POINT TO ASCII FSTR

ASCII TO FLOATING-POINT FVAL

LD, AND, OR+<F

LD, AND, OR+<=F

LD, AND, OR+>F

LD, AND, OR+>=F

Table Data Processing Instructions

Instruction Mnemonic

SWAP BYTES SWAP

FRAME CHECKSUM FCS

Data Control Instructions

Instruction Mnemonic

PID CONTROL WITH AUTOTUNING PIDAT

TIME-PROPORTIONAL OUTPUT TPO

SCALING SCL

SCALING 2 SCL2

SCALING 3 SCL3

AVERAGE AVG

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Subroutine Instructions

Instruction Mnemonic

SUBROUTINE CALL SBS

SUBROUTINE ENTRY SBN

SUBROUTINE RETURN RET

Interrupt Control Instructions

Instruction Mnemonic

SET INTERRUPT MASK MSKS

CLEAR INTERRUPT CLI

DISABLE INTERRUPTS DI

ENABLE INTERRUPTS EI

High-speed Counter and Pulse Output Instructions

Instruction Mnemonic

MODE CONTROL INI

HIGH-SPEED COUNTER PV READ PRV

COMPARISON TABLE LOAD CTBL

SPEED OUTPUT SPED

SET PULSES PULS

PULSE OUTPUT PLS2

ACCELERATION CONTROL ACC

ORIGIN SEARCH ORG

PULSE WITH VARIABLE DUTY FACTOR

PWM

Step Instructions

Instruction Mnemonic

STEP DEFINE STEP

STEP START SNXT

I/O Unit Instructions

Instruction Mnemonic

I/O REFRESH IORF

7-SEGMENT DECODER SDEC

DIGITAL SWITCH INPUT DSW

MATRIX INPUT MTR

7-SEGMENT DISPLAY OUTPUT 7SEG

Serial Communications Instructions

Instruction Mnemonic

TRANSMIT TXD

RECEIVE RXD

Clock Instructions

Instruction Mnemonic

CALENDAR ADD CADD

CALENDAR SUBTRACT CSUB

CLOCK ADJUSTMENT DATE

Failure Diagnosis Instructions

Instruction Mnemonic

FAILURE ALARM FAL

SEVERE FAILURE ALARM FALS

Other Instructions

Instruction Mnemonic

SET CARRY STC

CLEAR CARRY CLC

EXTEND MAXIMUM CYCLE TIME WDT

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

110 100 90

Two, 4.5 dia.

90100

110

Two, 4.5 dia.

90100

110

78.6

Two, 4.5 dia.

90100

130

120

110

Four, 4.5 dia.

Dimensions (Unit: mm)

CP1E CPU Unit

●CPU Units with 10 I/O Points

●CPU Units with 14 or 20 I/O Points

CP1E-@14/20D@@-@

CP1E-@14/20SD@@-@

●CPU Units with 30 I/O Points CPU Units with 20 I/O Points and Built-in Analog

CP1E-@30D@@-@, CP1E-NA20D@-@

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

90100

Four, 4.5 dia.

150

140

110

78.6

90100

150

140

110

Four, 4.5 dia.

CP1E-@30S(1)D@@-@

130

120

90100

110

●CPU Units with 40 I/O Points

CP1E-@40D@@-@

Four, 4.5 dia.

78.6

CP1E-@40S(1)D@@-@

●CPU Units with 60 I/O Points

CP1E-N60D@-@

110 100 90

195

185

Four, 4.5 dia.

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

78.6

90100

195

185

110

Four, 4.5 dia.

56±0.2

100±0.2

Two, 4.5 dia.

76±0.2

100±0.2

Two, 4.5 dia.

Four, 4.5 dia.

90100110

140

150

CP1E-@60S(1)D@@-@

Expansion I/O Units and Expansion Units

●CP1W-8E@@/CP1W-SRT21

●CP1W-20ED@/CP1W-16E@@/CP1W-AD04@/CP1W-DA021/CP1W-DA04@/CP1W-MAD@@/

CP1W-TS@@1/@@2/@@3

●CP1W-40ED@/CP1W-32E@@/CP1W-TS004

CP1E-E@@(S)D@-@ CP1E-N@@(S@)D@-@/NA20D@-@

Related Manuals

Manual name Cat. No. Model numbers Application Contents

Describes the following information for CP1E PLCs.

• Overview and features

• Basic system configuration

• Part names and functions

• Installation and settings

• Troubleshooting

Describes the following information for CP1E PLCs.

• CPU Unit operation

• Internal memory

• Programming

• Settings

• CPU Unit built-in functions

terrupts

• In

• High-speed counter inputs

• Pulse o

• Serial communications

• Analog I/O function

• Other functions

Describes each programming instruction in detail. When programming, use this manual together with the CP1E CPU Unit Hardware Manual (Cat. No. W479) and CP1E CPU Unit Software Manual (Cat. No. W480).

Describes 1) C-mode commands and 2) FINS commands in detail. Read this manual for details on C-mode

nd FINS commands addressed to CPU

a Units.

Describes the following information for CP1L/CP1E PLCs.

• Basic configuration and component names

• Mounting and wiring

• Programming, data transfer, and

debugging using the CX-Programmer

• Application program examples

SYSMAC CP Series CP1E CPU Unit Hardware Manual

SYSMAC CP Series CP1E CPU Unit Software Manual

SYSMAC CP Series CP1E CPU Unit Instructions Reference Manual

CS/CJ/CP/NSJ Series Communications Commands Reference Manual

SYSMAC CP Series CP1L/CP1E CPU Unit Introduction Manual

W479

W480

W483

W342

W461

CP1E-E@@SD@-@ CP1E-N@@S@D@-@ CP1E-E@@D@-@ CP1E-N@@D@-@ CP1E-NA@@D@-@

CS1G/H-CPU@@H CS1G/H-CPU@@-V1 CS1D-CPU@@HA CS1D-CPU@@SA CS1D-CPU@@H CS1D-CPU@@S CS1W-SCU@@-V1 CS1W-SCB@@-V1 CJ1G/H-CPU@@H CJ1G-CPU@@P CJ1M-CPU@@ CJ1G-CPU@@ CJ1W-SCU@@-V1

CP1L-L10D@-@ CP1L-L14D@-@ CP1L-L20D@-@ CP1L-M30D@-@ CP1L-M40D@-@ CP1L-M60D@-@ CP1E-E@@D@-@ CP1E-N@@D@-@ CP1E-NA@@D@-@

To learn the hardware specifications of the CP1E PLCs

Use this manual together with the CP1E CPU Unit Software Manual (Cat. No. W480) and CP1E CPU Unit Instructions Reference Manual (Cat. No. W483).

To learn the software specifications of the CP1E

Use this manual together with the CP1E CPU Unit Hardware Manual (Cat. No. W479) and CP1E CPU Unit Instructions Reference Manual (Cat. No. W483).

To learn programming instructions in detail

To learn communications commands for CS/CJ/CP/NSJ-series Controllers in detail

Note: This m

To learn the basic setup methods of the CP1L/CP1E PLCs

anual describes commands addressed to CPU Units. It does not cover commands addressed to other Units or ports (e.g., serial communications ports on CPU Units, communications ports on Serial Communications Units/Boards, and other Communications Units).

]

utputs

Printed on recycled paper.

OMRON AUTOMATION AMERICAS HEADQUARTERS • Chicago, IL USA • 847.843.7900 • 800.556.6766 • automation.omron.com

OMRON CANADA, INC. • HEAD OFFICE

Toronto, ON, Canada • 416.286.6465 • 866.986.6766 • automation.omron.com

OMRON ELECTRONICS DE MEXICO • HEAD OFFICE

Ciudad de México • 52.55.5901.4300

OMRON ELECTRONICS DE MEXICO • SALES OFFICE

San Pedro Garza García, N.L. • 81.12.53.7392 • 01.800.386.6766 • mela@omron. com

OMRON ELECTRONICS DE MEXICO • SALES OFFICE

Eugenio Garza Sada,León, Gto • 01.800.386.6766 • mela@omron.com

• 01.800.386.6766 • mela@omron.com

Authorized Distributor:

OMRON ELETRÔNICA DO BRASIL LTDA • HEAD OFFICE

São Paulo, SP, Brasil • 55 11 5171-8920 • automation.omron.com

OMRON ARGENTINA • SALES OFFICE

Buenos Aires, Argentina

mela@omron.com

OTHER OMRON LATIN AMERICA SALES

+54.11.4521.8630 • +54.11.4523.8483 • mela@omron.com

• +54.11.4521.8630 • +54.11.4523.8483

Controllers & I/O

• Machine Automation Controllers (MAC) • Motion Controllers

• Programmable Logic Controllers (PLC) • Temperature Controllers • Remote I/O

Robotics

• Industrial Robots • Mobile Robots

Operator Interfaces

• Human Machine Interface (HMI)

Motion & Drives

• Machine Automation Controllers (MAC) • Motion Controllers • Servo Systems

• Frequency Inverters

Vision, Measurement & Identification

• Vision Sensors & Systems • Measurement Sensors • Auto Identification Systems

Sensing

• Photoelectric Sensors • Fiber-Optic Sensors • Proximity Sensors

• Rotary Encoders • Ultrasonic Sensors

Safety

• Safety Light Curtains • Safety Laser Scanners • Programmable Safety Systems

• Safety Mats and Edges • Safety Door Switches • Emergency Stop Devices

• Safety Switches & Operator Controls • Safety Monitoring/Force-guided Relays

Control Components

• Power Supplies • Timers • Counters • Programmable Relays

• Digital Panel Meters • Monitoring Products

Switches & Relays

• Limit Switches • Pushbutton Switches • Electromechanical Relays

• Solid State Relays

Software

• Programming & Configuration • Runtime

P061I-E3-11

Omron CP1E-E20SDR-A, CP1E-N40S1DR-A Datasheet

Specifications and Main Features

Frequently Asked Questions

User Manual
