VB100T product information sheet
Product Specifications
Fits most: 23” - 42” flat panels
Supports up to: 100 lbs (45.4 kg)
Tilt: up to +7°
Mounting profile: 1.77” (45mm)
Universal & VESA compliant: 100x100 to 300x400
Mounting: Double-stud
Warranty: 5 years
Color: Black
Product Benefits
• Low 1.77” (45mm) mounting profile allows for
easy connectivity and sufficient panel cooling
• Tilt up to +7° to reduce glare
• Ideal for ultra thin panels with bottom-
or side-loading connectors
• Includes universal rails and spacers
for greater panel compatibility
• Single wall plate allows for quick installation
• Small footprint provides ample room for
power and A/V cutouts behind panel
• Lift n’ Lock
your flat panel to the mount
• Sliding lateral on-wall adjustment
• Locking bar secures panel to mount
• Includes complete hardware kit
™
allows you to easily attach
Series
LED Wire
Full Motion Mounts
Tilt Mounts
1.77”
With a 1.77” (45mm) mounting profile,
the VB100T sets flat panels just far enough
from the wall for easy connectivity while
still allowing for sufficient cooling.
OmniMount, an innovator of A/V mounts and furniture for more than a
quarter century, is the choice of professional installers and the brand
most recommended by flat panel manufacturers. The VideoBasics
Series is a basic line of fixed, tilt and full motion mounts brought
to you by OmniMount – the leader in flat panel mounting solutions.
The VB100T is a low-cost, low-profile mounting
solution for medium thin profile flat panels.
08092010
800.MOUNT.IT (800.668.6848)
Fixed Mounts
VB100T technical data sheet
OmniMount, an innovator of A/V mounts and furniture for more than a
quarter century, is the choice of professional installers and the brand
most recommended by flat panel manufacturers. The VideoBasics Series
is a basic line of fixed, tilt and full motion mounts brought to you by
OmniMount – the leader in flat panel mounting solutions. The VB100T is a
low-cost, low-profile mounting solution for medium thin profile flat panels.
Product Specifications
Fits most: 23” - 42” flat panels
Supports up to: 100 lbs (45.4 kg)
Tilt: up to +7°
Mounting profile: 1.77” (45mm)
Universal & VESA compliant: 100x100 to 300x400
Mounting: Double-stud
Warranty: 5 years
Color: Black
Product Benefits
• Low 1.77” (45mm) mounting profile allows for
easy connectivity and sufficient panel cooling
• Tilt up to +7° to reduce glare
• Ideal for ultra thin panels with bottom-
or side-loading connectors
• Includes universal rails and spacers
for greater panel compatibility
• Single wall plate allows for quick installation
• Small footprint provides ample room for
power and A/V cutouts behind panel
• Lift n’ Lock
your flat panel to the mount
• Sliding lateral on-wall adjustment
• Locking bar secures panel to mount
• Includes complete hardware kit
™
allows you to easily attach
Stock Code Packaging UPC MC UPC
Americas
International
Box Contents Qty
Wall plate 1
Vertical rail 2
Rubber vertical rail stop 2
Locking bar 1
08092010
1004812-1 728901026553 728901720000
1004812INT-1 728901026553 728901720000
Dimensions WxDxH inches (mm) Wt lbs (kg)
Product Box
Master Carton
Box Contents Qty
Bubble level 1
Complete monitor hardware kit 1
Complete wall hardware kit 1
Instruction manual 1
2.6 x 22.1 x 3.5 (65x560x90) 3.8 (1.7)
10.2 x 22.6 x 5.3 (260x575x135) 24.3 (11)
800.MOUNT.IT (800.668.6848)
12.6
(320)
13.78
(350)
1.46
(37)
1.22
(31)
1.77
(45)
2.76
(70)
+7°
1.42-19.53 (36-496)
20.87 (530)
VB100T line drawing
08092010
inches (mm)
800.MOUNT.IT (800.668.6848)
