Eight Channel Thermocouple/Voltage Input USB Data Acquisition
Modules
OM-USB-TC,
shown smaller
than actual
size.
⻬ OM-USB-TC
and OM-USB-5201
Have 8 Thermocouples
Inputs
⻬ OM-USB-TC-AI Has
4 Thermocouple Inputs
and 4 Analog Voltage Inputs
⻬ OM-USB-5201 Has Data
Logging Capability
(Compact Flash)
⻬ 24-Bit Resolution
⻬ Software Programmable
for Thermocouple Types
J, K, T, E, R, S, B, N
⻬ Built-In Cold junction
Compensation and Open
Thermocouple Detection
⻬ Eight Digital I/O
⻬ No External Power Supply
Required (Except for
OM-USB-5201)
The OM-USB-TC, OM-USB-TC-AI
and OM-USB-5201 are USB 2.0
full-speed thermocouple input
data acquisition modules (fully
compatible with both USB 1.1
and USB 2.0 ports).
These are stand-alone plug-andplay modules which draw power
from the USB cable (included). No
external power supply is required
(except for OM-USB-5201 which
requires an ac adaptor). All
configurable options are software
programmable, and the modules
are fully software calibrated.
The OM-USB-TC and
OM-USB-5201 provide eight
differential thermocouple input
1
To Order, Call or Shop Online at omega.com
channels and have two integrated
cold junction compensation (CJC)
sensors for thermocouple
measurements.
The OM-USB-TC-AI provides
eight analog input channels that
are configured as four differential
temperature inputs and four
differential or single-ended voltage
inputs. The module has one cold
junction compensation (CJC)
sensors for the thermocouple
measurements. Thermocouples
inputs are software programmable
for types J, K, T, E, R, S, B and N.
An open thermocouple detection
feature lets you detect a broken
thermocouple. An on-board
microprocessor automatically
linearizes the thermocouple
measurement data.
Voltage inputs (OM-USB-TC-AI
only) are software programmable
for ±10V, ±5V, ±2.5V and ±1.25V
ranges. Eight independent, TTLcompatible digital I/O channels are
provided to monitor TTL-level
inputs, communicate with external
devices and to generate alarms.
The digital I/O channels are
software programmable for input or
output.
The OM-USB-5201 features eight
independent temperature alarms.
Each alarm controls an associated
digital I/O channel as an alarm
output.
OM-USB-TC,
OM-USB-TC-AI
and OM-USB-5201
The input to each alarm is any
one of the temperature input
channels. The output of each
alarm is software configurable as
active high or low. The
temperature threshold condition
to activate each alarm is user
programmable. When an alarm is
activated, the associated digital
I/O channel is driven to the output
state. The OM-USB-5201 also
has data logging capability.
Measurements can be logged to
a standard CompactFlash
memory card (a 512 MB
CompactFlash memory card is
included with the OM-USB-5201).
Data logging can only be done
when the OM-USB-5201 is
disconnected from the computer.
External power is required for
data logging via the included ac
adaptor. User programmable
settings in data logging mode
include sampling interval and
logging start mode (on power up,
on button press or at a specified
data and time).
SM
The OM-USB-TC, OM-USB-TC-AI
and OM-USB-5201 modules ship
with an impressive array of
software, including the new
TracerDAQ®, a full-featured,
out-of-the-box data logging, viewing,
and analysis application; Universal
LibraryTM; ULx for NI LabVIEW
(comprehensive library
of VIs and example programs
compatible with LabVIEW v.8.2.1
and later); and InstaCal
TM
collection of four virtual instrument
applications used to graphically
display and store input data and
generate output signals:
• Strip Chart—Log and graph
values acquire from analog
inputs, digital inputs,
temperature inputs and
counter inputs
• Oscilloscope—Display values
acquired from analog inputs
• Function Generator—Generate
waveforms for analog outputs
• Rate Generator—Generate
waveforms for counter outputs
TracerDAQ PRO is an enhanced
version of TracerDAQ.
A comparison
features included in TracerDAQ vs
TracerDAQ PRO is shown below.
of some of the
installation, calibration, and test
utility-powerful software solutions for
programmers and nonprogrammers
alike. These modules operate under
Microsoft Windows 2000/XP/Vista
(32-bit or 64-bit/7 (32-bit or 64-bit)
operating systems.
The OM-USB-TC, OM-USB-TC-AI
and OM-USB-5201 data acquisition
modules are supplied with
TracerDAQ software which is a
Features Comparison
TracerDAQ Strip Chart.
TracerDAQ Pro Strip Chart
with Measurements.
Strip Chart
Feature TracerDAQ TracerDAQ Pro
Channel Types Analog input, temperature input, Analog input, temperature input,
Number of Channels 8 48
Number of Lanes 28
Maximum Samples per Channel 32,000 1 million
Alarm Conditions No Yes
Measurements Window No Yes
Enter Annotations No Yes
Software Triggering No Yes
Hardware Triggering No Yes
Time-of-Day Triggering No Yes
Linear Scaling No Yes
Oscilloscope
Feature TracerDAQ TracerDAQ Pro
Channel Type Analog input Analog input
Number of Channels 24
Measurements Window No Yes
Reference Channel No Yes
Math Channel No Yes
digital input, event counter digital input, event counter
Rate Generator
Feature TracerDAQ TracerDAQ Pro
Channel Type Counter output Counter output
Number of Channels 1 20
Function Generator
Feature TracerDAQ TracerDAQ Pro
Channel Type Analog output Analog output
Number of Channels 1 16
Waveform Types Sine Sine, square, triangle, flat, pulse, ramp, random, arbitrary
Duty Cycle No Yes
Phase No Yes
Gate Ratio No Yes
Rate Multiplier No Yes
Sweep (Linear and Exponential) No Yes
To Order, Call or Shop Online at omega.com
SM
2
SPECIFICATIONS
A/D CONVERTER
OM-USB-TC and OM-USB-5201:
Four dual 24-bit sigma delta
A/D converters
OM-USB-TC-AI: Dual 24-bit
sigma-delta A/D converters
Input Isolation: 500 Vdc min
between field wiring and USB
interface
Number of Channels:
OM-USB-TC and OM-USB-5201:
8 differential thermocouple inputs
OM-USB-TC-AI; 4 differential
thermocouple inputs and
4 differential or single-ended
voltage inputs
Maximum Input Voltage:
Thermocouple inputs; ±25V
(power on), ±40V (power off):
voltage inputs; ±25V (power on),
±15V (power off)
Throughput Rate: 2 samples/sec
max for all active channels
Input Impedance:
Thermocouple inputs; 5 GΩ
(power on), 1 MΩ (power off):
voltage inputs; 10 GΩ
(power on), 2.49 kΩ (power off)
Input Leakage Current:
Thermocouples inputs;
105 nA max (with open
thermocouple detection
enabled), 30 nA max (with
open thermocouple detection
disabled): voltage inputs;
±1.5 nA typ, ±25 nA max
Maximum Working
Voltage
(OM-USB-TC-AI
Voltage Inputs): ±10.25V max
(input signal + common mode)
Common Mode Rejection:
Thermocouple inputs,
110 dB min; voltage mode,
83 dB min
Warm-Up Time: 30 minutes max
Open Thermocouple Detection:
Automatically enabled when a
channel is configured for a
thermocouple sensor
CJC Sensor Accuracy:
±0.25°C typical, ±0.5°C max
(15 to 35°C); -1.0 to 0.75°C max
(0 to 70°C)
DIGITAL I/O
Number of Digital I/O
Channels: 8
Type: CMOS
Configuration: Each DIO bit can
be independently configured for
input or output; power on reset is
3
input mode
To Order, Call or Shop Online at omega.com
Pull-Up/Pull-Down Configuration:
All pins pulled up to 5V via 47 kΩ
resistors (default). Pull-down to
ground (GND) also available
Digital I/O Transfer Rate
(Software Paced):
Digital Input: 50 port reads or
single bit reads per second (typical)
Digital Output: 100 port writes or
single bit writes per second (typical)
Input High Voltage: 2.0V min,
DC Voltage Input Ranges
(OM-USB-TC-AI only)
5.5V absolute max
Input Low Voltage: 0.8V min,
-0.5V absolute min
Output High Voltage: 0.7V max
(IOL = 2.5 mA)
Output Low Voltage: 3.8V min
(IOH = -2.5 mA)
Range (Absolute, mV)
± 10V ± 2.78
± 5V ± 1.40
± 2.5V ± 0.71
± 1.25V ± 0.36
Compatible Thermocouple Input Types
Type Temperature
Range OM-USB-TC
OM-USB-TC-AI OM-USB-5201
-210 to 1200°C (-346 to 2192°F) ±0.28 @ 0°C ±0.31 (0 to 1200°C)
-210 to 1372°C (-346 to 2502°F) ±0.28 @ 0°C ±0.35 (0 to 1372°C)
-200 to 400°C (-328 to 752°F) ±0.29 @ 0°C ±0.26 (0 to 400°C)
-200 to 1000°C (-328 to 1832°F) ±0.32 @ 0°C ±0.25 (0 to 1000°C)
-50 to 1768°C (-58 to 3214°F) ±0.19 @ 250°C ±0.36 (250 to 1768°C)
-50 to 1768°C (-58 to 3214°F) ±0.20 @ 250°C ±0.40 (250 to 1768°C)
250 to 1820°C (482 to 3308°F) ±0.82 @ 700°C ±0.37 (700 to 1820°C)
-200 to 1300°C (-328 to 2372°F) ±0.28 @ 0°C ±0.27 (0 to 1000°C)
Includes cold junction compensation measurement error. Dependent on A/D data rate.
*
±0.29 @ 1200°C
±0.39 @ 1372°C
±0.24 @ 1000°C
±0.13 @ 1768°C
±0.16 @ 1768°C
±0.47 @ 1820°C
±0.25 @ 1300°C
Accuracy* (Typical, °C)
±0.71 @ -210°C ±0.51 (-210 to 0°C)
±0.76 @ -210°C ±0.54 (-210 to 0°C)
±0.74 @ -200°C ±0.51 (-200 to 0°C)
±0.21 @ 400°C
±0.68 @ -200°C ±0.46 (-200 to 0°C)
±0.46 @ -50°C ±0.65 (-50 to 250°C)
±0.44 @ -50°C ±0.65 (-50 to 250°C)
±2.19 @ 250°C ±0.58 (250 to 700°C)
±0.76 @ -200°C ±0.50 (-200 to 0°C)
OM-USB-TC-AI, shown
smaller than actual size.
Accuracy
SM
COUNTER
Extended Warranty
Program
SM
(OM-USB-TC-AI ONLY)
Number of Channels: 1
Resolution: 32-bit
Counter Type: Event counter
Input Type: TTL, rising edge
triggered
Counter Read/Write Rates
(Software Paced, System
Dependent): 33 to 1000
read/writes per second
Schmitt Trigger Hysteresis:
20 to 100 mV
Input Leakage Current:
±1.0 uA typical
Input Frequency: 1 MHz max
High Pulse Width: 500 ns min
Low Pulse Width: 500 ns min
Input High Voltage: 4.0V min,
5.5V absolute max
Input Low Voltage: 1.0V max,
-0.5V absolute min
DATA LOGGING
(OM-USB-5201 ONLY)
Memory Card Type: Compact
Flash 512 MB card included:
stores data for approx. 60 days
when logging all 8-channels
at 2 samples/sec or 150 days
when logging only 1-channel
at 2 samples/sec
Logging Rate: 1 sec up to 2
32
seconds (1 sec intervals)
Logging Start Method: On power
up, on button press or at specified
date/time (user programmable)
Logging Stop Method:
Button press
OM-USB-5201, shown
smaller than actual
size.
GENERAL
Power Supply Voltage
(Supplied by USB Port):
4.75V min to 5.25V max
Power Supply Current (Supplied
by USB Port): <100 mA typical
(USB enumeration); 270 mA typical
for continuous input with all inputs
configured for disabled mode
(500 mA for OM-USB-5201)
User 5V Output Voltage Range
(connected to self-powered hub):
OM-USB-TC/OM-USB-5201;
4.75V min to 5.25V max
OM-USB-TC-AI; 4.9 V min
to 5.1 V max
User 5V Output Current
(bus powered and connected
to self-powered hub):
OM-USB-TC/OM-USB-5201;
10 mA max
OM-USB-TC-AI; 5 mA max
Available Isolation: 500 Vdc min
measurement system to PC
USB Device Type: USB 2.0
(full-speed)
Device Compatibility:
USB 1.1, USB 2.0
USB Cable Length: 3 m (10') max
Dimensions:
127 L x 89 W x 36 mm H
(5.0 x 3.5 x 1.4")
Input Connections: Screw
terminal blocks (accept 16
to 30 AWG wire)
Operating Temperature:
0 to 50°C (32 to 122°F),
0 to 90% RH non-condensing
Storage Temperature:
-40 to 85°C (-40 to 185°F)
Weight:
OM-USB-TC and
OM-USB-TC-AI: 182 g (6.4 oz)
OM-USB-5201: 227 g (8.0 oz)
OMEGACARE
warranty program is
available for models
shown on this page. Ask
your sales representative
for full details when placing
an order. OMEGACARE
covers parts, labor and
equivalent loaners.
SM
extended
SM
All models include a 2 m (6') USB cable, software and user manual on CD.
OM-USB-5201 also includes 100/240 Vac 50/60 Hz ac adaptor (USA plug) and 512 MB Compact Flash card.
Ordering Example: OM-USB-TC, 8-channel thermocouple input USB data acquisition module and OMEGACARESMOCW-1, 1-year
extended warranty adds 1 year to standard 1-year warranty,
AVAILABLE FOR FAST DELIVERY!
To Order
Model No. Description
OM-USB-TC 8-channel thermocouple input USB data acquisition module
OM-USB-TC-AI 4-channel thermocouple and 4-channel voltage input USB data acquisition module
OM-USB-5201 8-channel thermocouple input USB data acquisition module
SWD-TRACERDAQ-PRO TracerDAQ Pro software
OM-USB-5200-ADAPTOR Spare 100/240 Vac 50/60 Hz ac adaptor for OM-USB-5201 (USA plug)
(Visit omega.com/om-usb-tc for Pricing and Details)
with data logging capability
To Order, Call or Shop Online at omega.com
SM
4
Loading...
