Omega Products OM-SL-L110 Installation Manual

RMS Current Loggers
Model OM-SL-L100
Model OM-SL-L110

USER MANUAL

M-3437/0899

WARRANTY/DISCLAIMER

OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for
a period of 13 months from date of purchase. OMEGA Warranty adds an additional one (1) month
grace period to the normal one (1) year product warranty to cover handling and shipping time. This
ensures that OMEGA's customers receive maximum coverage on each product.

If the unit should malfunction, it must be returned to the factory for evaluation. OMEGA's Customer
Service Department will issue an Authorized Return (AR) number immediately upon phone or written
request. Upon examination by OMEGA, if the unit is found to be defective it will be repaired or replaced
at no charge. OMEGA's WARRANTY does not apply to defects resulting from any action of the
purchaser, including but not limited to mishandling, improper interfacing, operation outside of design
limits, improper repair, or unauthorized modification. This WARRANTY is VOID if the unit shows
evidence of having been tampered with or shows evidence of being damaged as a result of excessive
corrosion; or current, heat, moisture or vibration; improper specification; misapplication; misuse or other
operating conditions outside of OMEGA's control. Components which wear are not warranted, including
but not limited to contact points, fuses, and triacs.

OMEGA is pleased to offer suggestions on the use of its various products. However, OMEGA
neither assumes responsibility for any omissions or errors nor assumes liability for any
damages that result from the use of its products in accordance with information provided by
OMEGA, either verbal or written. OMEGA warrants only that the parts manufactured by it will be
as specified and free of defects. OMEGA MAKES NO OTHER WARRANTIES OR
REPRESENTATIONS OF ANY KIND WHATSOEVER, EXPRESSED OR IMPLIED, EXCEPT THAT OF
TITLE, AND ALL IMPLIED WARRANTIES INCLUDING ANY WARRANTY OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED. LIMITATION OF
LIABILITY: The remedies of purchaser set forth herein are exclusive and the total liability of
OMEGA with respect to this order, whether based on contract, warranty, negligence,
indemnification, strict liability or otherwise, shall not exceed the purchase price of the
component upon which liability is based. In no event shall OMEGA be liable for consequential,
incidental or special damages.

CONDITIONS: Equipment sold by OMEGA is not intended to be used, nor shall it be used: (1) as a
"Basic Component" under 10 CFR 21 (NRC), used in or with any nuclear installation or activity; or (2) in
medical applications or used on humans. Should any Product(s) be used in or with any nuclear
installation or activity, medical application, used on humans, or misused in any way, OMEGA assumes
no responsibility as set forth in our basic WARRANTY/ DISCLAIMER language, and additionally,
purchaser will indemnify OMEGA and hold OMEGA harmless from any liability or damage whatsoever
arising out of the use of the Product(s) in such a manner.

RETURN REQUESTS/ INQUIRIES

Direct all warranty and repair requests/inquiries to the OMEGA Customer Service Department. BEFORE
RETURNING ANY PRODUCT(S) TO OMEGA, PURCHASER MUST OBTAIN AN AUTHORIZED
RETURN (AR) NUMBER FROM OMEGA'S CUSTOMER SERVICE DEPARTMENT (IN ORDER TO
AVOID PROCESSING DELAYS). The assigned AR number should then be marked on the outside of
the return package and on any correspondence.

The purchaser is responsible for shipping charges, freight, insurance and proper packaging to prevent
breakage in transit.

FOR WARRANTY RETURNS, please have the following
information available BEFORE contacting OMEGA:

1. P.O. number under which the product was
PURCHASED,

2. Model and serial number of the product under
warranty, and

3. Repair instructions and/or specific problems
relative to the product.

OMEGA's policy is to make running changes, not model changes, whenever an improvement is
possible. This affords our customers the latest in technology and engineering.

OMEGA is a registered trademark of OMEGA ENGINEERING, INC.
© Copyright 1996 OMEGA ENGINEERING, INC. All rights reserved. This document may not be copied,

photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form, in
whole or in part, without prior written consent of OMEGA ENGINEERING, INC.

FOR NON-WARRANTY REPAIRS, consult
OMEGA for current repair charges. Have the
following information available BEFORE
contacting OMEGA:

1. P.O. number to cover the COST of the repair,

2. Model and serial number of product, and

3. Repair instructions and/or specific problems
relative to the product.

Table of Contents

Warning................................................................................................ 4

International Electrical Symbols............................................................. 4

Receiving Your Shipment...................................................................... 5

Packaging............................................................................................. 5

Specifications........................................................................................ 6

Features ............................................................................................... 8

Indicators And Buttons....................................................................... 8

Inputs And Outputs ............................................................................ 8

Mounting........................................................................................... 8

Battery Installation............................................................................. 9

Operation.............................................................................................. 9

Software ..............................................................................................10

Minimum Computer Requirements....................................................10

Installation........................................................................................10

Using The Software..........................................................................11

Cleaning ..............................................................................................11

3

Warning

These safety warnings are provided to ensure the safety of personnel
and proper operation of the instrument.

• Read the instruction manual completely and follow all the safety
information before attempting to use or service this instrument.

• Use caution on any circuit: Potentially high voltages and currents may
be present and may pose a shock hazard.

• Read the Safety Specifications section prior to using the current probe.
Never exceed the maximum voltage ratings given.

• Safety is the responsibility of the operator.

• For maintenance, use only original replacement parts.

• NEVER open the back of the instrument while connected to any circuit

or input.

• ALWAYS connect the recorder to the probe before clamping the probe
onto the sample being tested.

• ALWAYS inspect the instrument and lead prior to use. Replace any
defective parts immediately.

• NEVER use the Models OM-SL-L100 and L110 on electrical
conductors rated above 600 V in overvoltage category III (CAT III).

• ALWAYS use probes rated for 600 V working voltage.

International Electrical Symbols

This symbol signifies that the Loggers are protected by double or
reinforced insulation. Use only specified replacement parts when
servicing the instrument.

This symbol signifies CAUTION! and requests that the user refer
to the user manual before using the instrument.

For more information about the Logger, refer to disk 2: MAIN MANUAL

4

Receiving Your Shipment

Upon receiving your shipment, make sure that the contents are
consistent with the packing list. Notify OMEGA of any missing items. If
the equipment appears to be damaged, file a claim immediately with the
carrier and notify OMEGA at once, giving a detailed description of any
damage.

Packaging

The Loggers OM-SL-L100 and OM-SL-L110 include the following:

• User manual

• One 9 V battery

• Two 3½” disks containing the window-based download and graphic

software and a generic user manual

• Six ft. long RS232 cable

• Set of velcro mounting pads

5

Specifications

ELECTRICAL
Number of Channels: 1
Measurement Range: 0 to 10,000 Arms

(Requires optional current probe)
Input: 0 -1 Vrms (L100)

0 - 1 Arms (L110)

Input Connection: Recessed Safety Banana Jacks
*Accuracy: 1% Readings + Resolution + Probe accuracy
Resolution : 8 Bits

Scale Range Maximum Input Resolution

100% 1 A or 1 V 0.004 A or V

50% 0.5 A or 0.5 V 0.002 A or V
25% 0.25 A or 0.25 V 0.001 A or V

12.5% 0.125 A or 0.125 V 0.0005 A or V

Sample Rate: 4096/hr max. decreases by 50% each time memory is full
Data Storage: 8192 readings
Data Storage Technique: (TXR™) Time Extension Recording™
Power: 9V Alkaline NEDA 1604, 6LF22, 6LR61
Battery Life Recording: 1 year continuous recording @ 25°C
Output: RS-232 via 9 pin “D” shell

INDICATORS
Operation Mode Indicator: One Red LED

• Single Blink in stand-by mode

• Double Blink in RECORD mode

• Continuously on: Overload condition

• No Blinks in OFF mode

*Reference condition: 23°C ± 3K, 20 to 70% RH, Frequency 50/60Hz, No AC
external magnetic Field, DC magnetic field ≤ 40A/m, centered conductor, battery
voltage 9 Volts ± 10%.

6

CONTROLS:

One button used to start and stop recording sessions and to turn the
data logger on and OFF.

ENVIRONMENTAL
Operating Temperature: -4 to + 158°F (-20 to +70°C)
Storage Temperature: -4 to + 174°F (-20 to +80°C)
Relative Humidity: 5 to 95% non-condensing

MECHANICAL
Size: 2-7/8” W x 2-5/16” H x 1-5/8” D (73mm x 59mm x 41mm)
Weight (with battery): 5 oz (140 g)
Mounting: Base plate mounting holes or Velcro® pads

SAFETY

Working Voltage: IEC1010-1, 600V, Cat III

ORDERING INFORMATION

RMS Current Logger, 0 - 1 V AC .............................Model OM-SL-L100

RMS Current Logger, 0 - 1 A AC.............................. Model OM-SL-L110

Accessories:

Flexible Current Probe 24” 1-500 A AC ..........................Model HHM806

Flexible Current Probe 24” 1-1000 A AC ........................Model HHM808

Flexible Current Probe 24” 10-6000 A AC ...................... Model HHM812

Flexible Current Probe 36” 10-6000 A AC ................. Model HHM812-36

Flexible Current Probe 24” 10-10000 A AC..................... Model HHM814

Flexible Current Probe 36” 10-10000 A AC................ Model HHM814-36

Flexible Current Probe 48” 1-10000 A AC ................. Model HHM814-48

Replacement 6ft RS232 cable with DB9F ............... OM-SL-RS232-DB9

7

Features

Indicators and Buttons

The data logger has only one button and one indicator. Both are located
on the front panel.

The button is used to start and stop recordings and to turn the data
logger on and off. The red LED indicates the status of the data logger;
OFF, STANDBY or RECORDING. When the LED is lit continuously it
indicates an Overload condition.

Inputs and Outputs

The left side of the data logger incorporates 2mm safety banana jacks
input connectors compatible with the current probes for which your data
logger was designed.

The right side of the data logger has a female 9 pin “D” shell serial
connector used for data transmission from the data logger to your
computer.

Mounting

Your data logger is equipped with clearance holes in the base plate tabs
for mounting. For less permanent mounting, the Velcro pads (supplied
loose) can be attached to the data logger and the surface to which the
data logger will be mounted.

8

Battery Installation

Under normal conditions, the battery will last up to a year of continuous
recording unless the logger is re-started very frequently.

In the OFF mode, the logger puts almost no load on the battery. Use the
OFF mode when the logger is not in use. Replace the battery once a
year in normal use.

If the logger will be used at temperatures below 32°F (0°C) or is
frequently turned on and off, replace the battery every six to nine
months.

1. Make sure your logger is turned off (no light blinking) and all
inputs are disconnected.

2. Turn the data logger upside down. Remove the four Phillips head
screws from the base plate of the data logger and take off the
base plate.

3. Locate the two wire (red/black) battery connector and attach the
9 V battery to it. Make sure that you observe polarity by lining up
the battery posts to the proper terminals on the connector.

4. Once the connector is plugged onto the battery, insert the battery
into the holding clip on the circuit board

5. Re-attach the base plate using the four screws removed in step
two.

Your data logger is now recording (LED blinking). Press the test button
for 5 seconds to stop the instrument

Note: For long term storage, remove the battery to prevent discharge
effects.

Operation

Connect the current probe to the Logger and position the probe around
the conductor to be measured. Make sure that the jaws are firmly closed
before beginning the recording session. (Probe output can not be more
than 1V AC for Model OM-SL-L100 and 1A AC for the Model OM-SL-

110).
Next, press the start/stop button on the front of the unit to begin the

recording session. The indicator light will double blink to indicate that the
recording session has started.

When the recording session has been completed, press the start/stop
button to end the recording. The indicator light will single blink to indicate
that the recording session has ended and the unit is in stand-by.

Unclamp the probe from the conductor and connect the Logger to the
computer for data downloading. See Section 2 page 19 of the main
manual for downloading.

9

SOFTWARE

MINIMUM COMPUTER REQUIREMENTS
Processor: 386 or higher
RAM Storage: 4 MB minimum
Hard Drive Space:

100K for application, approximately 200K for each stored file

Environment: Windows 3.1 or Windows 95
Port Access: 1 available 9 pin serial port

1 parallel port for printer support

INSTALLATION

Your data logger software is supplied on a single 3½” floppy disk. To
install the program on your Windows based computer, proceed as
follows: The software is Multilanguage. A prompt will ask you to select
the language at the end of the installation process.

Windows 3.1 Systems

1. Insert the floppy disk containing the data logger software in your
computer’s floppy drive (usually Drive A).

2. From the Program Manager select “File” on the command line.

3. Select “Run” from the pull-down menu and type a:setup in the
dialog box then click on “OK”.

4. The set up program will temporarily load onto your computer.

5. Next the setup program will offer C:\DATALOG as location where
the software will be installed. Click on “Next” to use this directory or
type in a new name, then click on “Next”.

6. A bar graph will appear showing the progress of installation. When
installation is complete a message screen will appear stating that
the program has been installed. Click on “OK”. You are now ready
to use the data logger software.

Windows 95 Systems

1. Insert the floppy disk containing the data logger software in your
computer’s floppy drive (usually Drive A).

2. Click on the “Start” button on the bottom left side of the screen.

3. Select “Run” from the menu and type a:setup in the dialog box then
click on “OK”.

4. The setup program will temporarily load onto your computer.

10

5. Next the setup program will offer C:\DATALOG as location where
the software will be installed. Click on “Next” to use this directory or
type in a new name, then click on “Next”.

6. A bar graph will appear showing the progress of installation. When
installation is complete a message screen will appear stating that
the program has been installed. Click on “OK”. You are now ready
to use the data logger software.

USING THE SOFTWARE

Launch the software and connect the RS232 cable from your computer
from the logger.

Select “FILE”, “Baud rate” and “1200”, then select “PORT”, Com1, Com2,
Com3 or Com4 (see your computer manual). The logger must now
communicate with your computer (ID number of the logger and number
of points recorded displayed).

Select “FUNCTION”, then Logger L100 or L110 to choose your probe
ratio. Select download to display the graph. (Download takes about 90
seconds)

Function

The FUNCTION command allows you to select the correct engineering
units for the recorded data.

When you click on Function, a pull-down window will appear with all the
choices supported by the version of software you have installed. This
menu will only appear if a data logger is connected to the COM port.

Simply click on the desired group and then select the proper units from
the window that opens. Depending on which type of logger is connected,
the pull-down menu under Function may be empty. You will be returned
to the main screen and the graph Y axis scale will be recalculated using
the choice you made here.

Future downloads will use the units selected here for graphing as well.
The data logger communicates to the software its basic configuration.
Therefore, you will only be offered choices that are compatible to the
data logger.

Cleaning

The body of the clamp should be cleaned with a cloth moistened with
soapy water. Rinse with a cloth moistened with clean water. Do not use
solvent.

11

OMEGAnetSM On-Line Service: http://www.omega.com

Internet e-mail: [e-mail]

Servicing North America:

USA: One Omega Drive, Box 4047

ISO 9001 Certified Stamford, CT 06907-0047

Tel: [phone] FAX: [phone]
e-mail: [e-mail]

Canada: 976 Bergar

Laval (Quebec) H7L 5A1
Tel: [phone] FAX: [phone]
e-mail: [e-mail]

For Immediate Technical or Application Assistance:

USA and Canada: Sales Service: 1-800-826-6342 1-800-TC-OMEGA

Customer Service: 1-800-622-2378 / 1-800-622-BEST
Engineering Service: 1-800-872-9436 / 1-800-USA-WHEN
TELEX: 996404 EASYLINK 62968934 CABLE: OMEGA

Mexico and Tel: (95) 800-TC-OMEGA

SM

FAX: [phone]

Latin America: En Espanol: [phone] ext: 2203 e-mail: [e-mail]

SM

SM

SM

Servicing Europe:

Benelux: Postbus 8034,1180 LA Amstelveen, The Netherlands

Czech Republic: Ostravska 767, 733 01 Karvina

France: 9, rue Denis Papin, 78190 Trappes

Germany/Austria: Daimlerstrasse 26, D-75392 Deckenpfronn, Germany

United Kingdom: 25 Swannington Road, P.O. Box 7, Omega Drive,

150 9002 Certified Broughton Astley, Leicestershire, Irlam, Manchester,

It is the policy of OMEGA to comply with all worldwide safety and EMC/EMI regulations that apply.
OMEGA is constantly pursuing certification of its products to the European New Approach Directives.
OMEGA will add the CE mark to every appropriate device upon certification.

The information contained in this document is believed to be correct but OMEGA Engineering, Inc.
accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.

WARNING: These products are not designed for use in, and should not be used for, patient connected
applications.

Tel: [phone] FAX: [phone]
Toll Free in Benelux: 06 0993344
e-mail: [e-mail]

Tel: [phone] FAX: [phone]
e-mail: [e-mail]

Tel: [phone] FAX: [phone]
Toll Free/France: 0800-4-06342 e-mail: [e-mail]

Tel: [phone] FAX: [phone]
Toll Free in Germany: 0130 11 21 66
e-mail: [e-mail]

LE9 6TU, England M44 5EX, England
Tel: [phone] Tel: [phone]
FAX: [phone] FAX: [phone]
Toll Free in England: 0800-488-488 e-mail: [e-mail]

Where Do I Find Everything I Need for

Process Measurement and Control?

OMEGA ... Of Course!

TEMPERATURE

ο Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies
ο Wire: Thermocouple, RTD & Thermistor
ο Calibrators & Ice Point References
ο Recorders, Controllers & Process Monitors
ο Infrared Pyrometers

PRESSURE / STRAIN FORCE

ο Transducers & Strain Gauges
ο Load Cells & Pressure Gauges
ο Displacement Transducers
ο Instrumentation & Accessories

FLOW / LEVEL

ο Rotameters, Gas Mass Flowmeters & Flow Computers
ο Air Velocity Indicators
ο Turbine / Paddlewheel Systems
ο Totalizers & Batch Controllers

pH/CONDUCTIVITY

ο pH Electrodes, Testers & Accessories
ο Benchtop / Laboratory Meters
ο Controllers, Calibrators, Simulators & Pumps
ο Industrial pH & Conductivity Equipment

DATA ACQUISITION

ο Data Acquisition & Engineering Software
ο Communications-Based Acquisition Systems
ο Plug-in Cards for Apple, IBM & Compatibles
ο Datalogging Systems
ο Recorders, Printers & Plotters

HEATERS

ο Heating Cable
ο Cartridge & Strip Heaters
ο Immersion & Band Heaters
ο Flexible Heaters
ο Laboratory Heaters

ENVIRONMENTAL MONITORING AND CONTROL

ο Metering & Control Instrumentation
ο Refractometers
ο Pumps & Tubing
ο Air, Soil & Water Monitors
ο Industrial Water & Wastewater Treatment

ο pH, Conductivity & Dissolved Oxygen Instruments

14
