Omega Products MDSwi822-ZT User Manual

Wireless Benchtop Meter,
Scanner and Controller
With Embedded Ethernet Connectivity
MDSwi8, $545.
All models shown
smaller than actual size.
UWTC-NB9-CASS-18-U-12
MDSwi8 Series
W
Works with
wireless thermocouple/
transmitter assembly,
$195, see page W-16.
$
545
Read 8 Wireless Sensors
Simultaneously
Portable, Rugged Metal Benchtop
Enclosure with Tilt Handle
Built Around OMEGA’s New
Series Meters
User-Friendly, Simple to ConfigureWireless Inputs: Thermocouple
RTD Temperature
Embedded Ethernet Standard
wiSeries Wireless Monitoring and Control System
The OMEGA®wiSeries wireless monitoring and control system features meters and scanners compatible with a large and growing number of OMEGA®wireless sensors:
UWTC “Universal Wireless Thermocouple”
Type J, K, T, E, R, S, B, N, and C.
UWRTD “Universal Wireless RTD” zSeries Wireless End Devices with sensors
for temperature.
W-46
The Smart Connector
PATENT
PENDING
Works with UWTC wireless thermocouple connector, $125, see page W-7.
Works with zED-T, $95, s
ee pages W-55 to W-58.
TM
Temperature Readings of up to 8 Sensors
The wiSeries 1⁄8 DIN panel meter and controller can monitor up to 8 wireless sensors.
The compact instrument connects directly to an Ethernet network and the Internet and features OMEGA’s award­winning embedded Web Server. It is easily configured and monitored with a Web browser over the Ethernet network or the Internet.
Alternatively, the wi8 meter-controller can instead be connected to the USB port of a single computer with a “USB Ethernet Adaptor” that are inexpensive and widely available.
Monitor and Alarm
The wi-8 meter-controller comes standard with a choice of either two Form C relays, or two SSRs (solid state relays) that can be used for control functions or alarms. The wi8 meter can monitor alarm conditions for any or all of the wireless sensors. For example, the wi-8 meter can be set up to trip an alarm if any one of the sensors indicated it was above or below a pre-set alarm point.
Monitor and Control Locally and Over the Internet
The OMEGA®wiSeries wireless monitoring and control system provides local monitoring and control, along with remote Web-based monitoring of temperature from thermocouples, RTDs, and semiconductor sensors.
The wireless sensors transmit up to 1000 m (3280') (without obstructions or interference) to a wiSeries monitor-controller connected directly to an Ethernet network and the Internet. The wireless system complies with IEEE 802.15.4 operating at 2.4 GHz.
Note: Distances for UWTC-1, UWRTD-1: up to 60 m (200'), UWTC-2, UWRTD-2: up to 120 m (400'), zED-x-P: up to 1000 m (3280'), zED-x: up to 90 m (300') all distances without obstructions or interference.
The OMEGA wiSeries system let’s you monitor and record temperature over an Ethernet network or the Internet without any special software—just your Web Browser.
Wireless Sensors
OMEGA offers a wide and growing selection of wireless sensors for a variety of applications. Depending on application, the wireless sensors are powered by 2 “AA”
See page W-58 for ordering information.
External
temperature lug
mount probe, included with
zED-T-TP2.
External temperature
stick probe,
included with
zED-T-TP1.
batteries, a single lithium battery (approx “AA” size), 2 “D” cell batteries, or an external AC adaptor that operates on any voltage worldwide from 100 to 240 Vac.
Wireless sensors are available with external probes appropriate for an almost unlimited variety of industrial and commercial applications.
Ethernet
The wiSeries meter-controller-scanner is an independent node on the network sending and receiving data in standard TCP/IP packets. It is easily configured from a Web Browser and can be password protected. From within an Ethernet LAN or over the Internet, the user simply types the IP address (such as 192.168.1.200) or an easy to remember name (such as “Oven 5” or “Chicago Test Fixture”) and the wiSeries meter serves a Web Page with the current readings.
Alarm and Email
The wiSeries meter can trigger an alarm if variables go above or below a set point that you determine. Your alarm can be sent by email to a single user or to a group distribution list, including text messages to cell phones and PDAs. The OMEGA “Mail Notifier” software is a free and easy program for this application.
The wiSeries meter-controllers operate on any AC voltage worldwide from 90 to 240 Vac and 50 to 60 Hz. The meter­controller connects directly to an Ethernet Network or the Internet. Unlike an RS232 or USB device, it does not require a host computer.
Embedded Webserver
The OMEGA wiSeries wireless sensor system is easy to install, simple to operate, and features OMEGA’s award­winning iServer technology with an Embedded Web Server that requires no special software.
Charts and Graphs
The OMEGA wiSeries system serves Active Web Pages to display real time readings and charts of temperature. You can also log data in standard data formats for use in a spreadsheet or data acquisition program such as Excel or Visual Basic. OMEGA offers a free and easy to use program for logging data to Excel.
The virtual chart viewed on the web page is a JAVA™ Applet that records a chart over the LAN or Internet in real time. With the OMEGA wiSeries system there is no need to invest time and money learning a proprietary software program to log or chart the data.
Chart scales are fully adjustable on the fly. For example, the chart can display one minute, one hour, one day, one week, one month or one year. Temperature can be charted across the full span (-40 to 125°C), or within any narrow range such as (20 to 30°C).
W-47
A complete wireless system requires at least 1 benchtop receiver
(wi8XX) and 1 end device (UWTC, UWRTD or zED).
OMEGA offers an OPC Server software ($295) that makes it easy to integrate the wiSeries wireless sensor system with many popular Data Acquisition and Automation programs offered by OMEGA, Wonderware, iConics, Intellution, Rockwell Automation, and National Instruments, among others.
to change back when the value drops back below the alarm point or to "latch" on until being reset by the operator.
The wiSeries can also be programmed to display only one unchanging color: GREEN, AMBER, or RED. This is a useful way to let an operator identify, at a glance, process values in three separate locations, or to display three different measurements such as Temperature, Pressure, and Flow.
Quality and Technology
The innovative OMEGA wiSeries of meters and controllers features an extended 1 year warranty at no extra charge.
at any set point
Specifications
Network and Communications
PATENTED
Programmable Color Display
The OMEGA wiSeries feature OMEGA’s patented programmable color displays. The display can be programmed to change color at any set point or alarm point
For example, the wiSeries can be programmed to display the process value in GREEN during warm-up, switching to
AMBER to signal the normal operating range, and in RED to
signal an alarm condition. The changes in color are quickly seen from a distance, and machine operators can intuitively react to changing conditions. The colors can be programmed
Ethernet: Standards Compliance IEEE 802.3 10 Base-T Supported Protocols: TCP/IP, ARP, HTTPGET Connection: Screw terminals
General
Display: 4-digit, 9-segment LED, 10.2 mm (0.40") and
21 mm (0.83"), red, green and amber programmable colors
Operating Temp: 0 to 55°C (32 to 131°F), 90% RH non-condensing
Line Voltage/Power: 90 to 240 Vac ±10%, 50 to 400 Hz*, 110 to 375 Vdc, equivalent voltage
No CE compliance above 60 Hz
*
MOST POPULAR MODEL HIGHLIGHTED!
To Order
Model No. Price Description MDSwi833-U $545 Wireless benchtop meter for UWTC/UWRTD models with 2 relays
MDSwi853-U 545 Wireless benchtop meter for UWTC/UWRTD models with analog output
MDSwi822-U 545 Wireless benchtop Meter For UWTC/UWRTD models with two solid state relays
MDSwi833-ZT 545 Wireless benchtop meter for zSeries models with 2 relays:
MDSwi853-ZT 545 Wireless benchtop meter for zSeries models with analog output
MDSwi822-ZT 545 Wireless benchtop meter with for zSeries models with two solid state relays (SSRs)
Accessories
Model No. Price Description POWER CORD-DM $20 Power cord with connector for Denmark POWER CORD-E-10A 20 Power cord with connector for Continental Europe POWER CORD-IT 20 Power cord with connector for Italy or Ireland POWER CORD-SE 7 Power cord with stripped ends (no connection), all countries 250 Vac max POWER CORD-UK 35 Power cord with connector for United Kingdom POWER CORD-MOLDED
Comes complete with operator’s manual. Order Example: MDSwi833-U wireless benchtop meter for UWTC/UWRTD sensors, $545, with POWER CORD-MOLDED, power cord, $7,
$545 + 7 = $552.
(Specify Model Number)
(form “C” SPDT 3 A @ 120 Vac, 3 A @ 240 Vac)
(0 to 10 Vdc or 0 to 20 mA @ 500 max) and form “C” relay
(SSRs) (0.5 A @ 120/240 Vac continuous)
(form “C” SPDT 3 A @ 120 Vac, 3 A @ 240 Vac)
(0 to 10 Vdc or 0 to 20 mA @ 500 max) and form “C” relay
(0.5 A @ 120/240 Vac continuous)
7
Power cord with connector for North America (USA, Mexico, Canada), standard 120 Vac
W-48
