Page 1

User’s Guide

Shop online at

e-mail: info@omega.com

For latest product manuals:

omega.com

omegamanual.info

DP63100

Analog Input Panel Meter

LP0884A

Page 2

OMEGAnet

Online Service

omega.com

Internet e-mail

info@omega.com

Servicing North America:

U.S.A.: One Omega Drive, P.O. Box 4047

ISO 9001 Certified Stamford, CT 06907-0047

TEL: (203) 359-1660 FAX: (203) 359-7700 e-mail: info@omega.com

Canada: 976 Bergar

Laval (Quebec) H7L 5A1, Canada TEL: (514) 856-6928 FAX: (514) 856-6886 e-mail: info@omega.ca

For immediate technical or application assistance:

U.S.A. and Canada: Sales Service: 1-800-826-6342/1-800-TC-OMEGA

Customer Service: 1-800-622-2378/1-800-622-BEST Engineering Service: 1-800-872-9436/1-800-USA-WHEN

Mexico: En Español: (001) 203-359-7803 e-mail: espanol@omega.com

FAX: (001) 203-359-7807 info@omega.com.mx

Servicing Europe:

Czech Republic: Frystatska 184, 733 01 Karviná, Czech Republic

TEL: +420 (0)59 6311899 FAX: +420 (0)59 6311114 Toll Free: 0800-1-66342 e-mail: info@omegashop.cz

Germany/Austria: Daimlerstrasse 26, D-75392 Deckenpfronn, Germany

TEL: +49 (0)7056 9398-0 FAX: +49 (0)7056 9398-29 Toll Free in Germany: 0800 639 7678 e-mail: info@omega.de

United Kingdom: One Omega Drive, River Bend Technology Centre ISO 9002 Certified Northbank, Irlam, Manchester

M44 5BD United Kingdom TEL: +44 (0)161 777 6611 FAX: +44 (0)161 777 6622 Toll Free in United Kingdom: 0800-488-488 e-mail: sales@omega.co.uk

It is the policy of OMEGA Engineering, Inc. to comply with all worldwide safety and EMC/EMI regulations that apply. OMEGA is constantly pursuing certification of its products to the European New Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification.

The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.

WARNING : These products are not designed for use in, and should not be used for, human applications.

Page 3

 UNIVERSAL PROCESS, VOLTAGE, CURRENT, RESISTANCE

AND TEMPERATURE INPUTS

 UNIVERSAL AC/DC POWER SUPPLY

 6 / 9 DIGIT DUAL LINE/TRI-COLOR DISPLAY WITH 0.71" & 0.35"

DIGITS

 PROGRAMMABLE UNITS DISPLAY

 VARIABLE CONTRAST AND INTENSITY DISPLAY

 UP TO 160 SAMPLES PER SECOND CONVERSION RATE

 BUILT-IN USB PROGRAMMING PORT ENABLING UNIT

CONFIGURATION WITH DP6-SOFT PROGRAMMING SOFTWARE

 NEMA 4X/IP65 SEALED FRONT BEZEL

DESCRIPTION

The Analog Panel Meter offers many features and performance capabilities to suit a wide range of industrial applications. The DP63100 has a universal input to handle various input signals including DC Voltage/Current, Process, Resistance and Temperature. The optional plug-in output cards allow the opportunity to configure the meter for present applications, while providing easy upgrades for future needs. The DP63100 employs a dual line, tri-color display with a large 0.71", tri-color 6 digit top display line and a 0.35", 9 digit green bottom display line.

The meter provides a MAX and MIN reading memory with programmable capture time. The capture time is used to prevent detection of false max or min readings which may occur during start-up or unusual process events.

The signal totalizer (integrator) can be used to compute a time-input product. This can be used to provide a readout of totalized flow or calculate service intervals of motors, pumps, etc. The meter has up to four setpoint outputs, implemented on plug-in option cards. The plug-in cards provide dual FORM-C relays, quad FORM-A, or either quad sinking or quad sourcing open collector logic outputs. The setpoint alarms can be configured to suit a variety of control and alarm requirements.

Communication and bus capabilities are also available as option cards. These include RS232 and RS485. The DP63100 can be programmed to utilize ModBus protocol. With ModBus, the user has access to most configuration parameters. Readout values and setpoint alarm values can be controlled through the bus. Additionally, the meter has a feature that allows a remote computer to directly control the outputs of the meter.

The DP63100 includes a built-in USB programming port. With a Windows based program, made available by Omega, configuration data can be downloaded to the DP63100 without the need of any additional option cards.

A linear DC output signal is available as an optional plug-in card. The card provides either 20 mA or 10 V signals. The output can be scaled independent of the input range and can track either the input, totalizer, max or min readings.

The meter has been specifically designed for harsh industrial environments. With NEMA 4X/IP65 sealed bezel and extensive testing of noise effects and CE requirements, the meter provides a tough reliable application solution.

SAFETY SUMMARY

All safety related regulations, local codes and instructions that appear in this literature or on equipment must be observed to ensure personal safety and to prevent damage to either the instrument or equipment connected to it. If equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. Do not use this unit to directly command motors, valves, or other actuators not equipped with safeguards. To do so can be potentially harmful to persons or equipment in the event of a fault to the unit.

CAUTION: Risk of Danger.

Read complete instructions prior to

installation and operation of the unit.

CAUTION: Risk of electric shock.

DIMENSIONS In inches (mm)

1.95

(49.53)

3.80 (96.52)

Note: Recommended minimum clearance (behind the panel) for

mounting clip installation is 2.1" (53.4) H x 5.5" (140) W.

0.10

(2.54)

4.14 (105)

1.75

(44.45)

PANEL CUT-OUT

3.60 (91.44)

Page 4

Table Of COnTenTs

General Meter Specifications . . . . . . . . . . . . . 4

Optional Plug-In Cards Installing the Meter Setting the Jumpers Installing the Plug-In Cards Wiring the Meter

. . . . . . . . . . . . . . . . . . . . . . . 7

Reviewing the Front Buttons and Display

. . . . . . . . . . . . . . . . . . 5

. . . . . . . . . . . . . . . . . . . . . 6

. . . . . . . . . . . . . . . . . . . . 6

. . . . . . . . . . . . . . 7

. . . . 9

DP63100 Display Loops . . . . . . . . . . . . . . . . 10

Programming the Meter Modbus Register Table Factory Service Operations Troubleshooting Guide Parameter Value Chart Programming Overview

General MeTer speCifiCaTiOns

1. DISPLAY: Negative image LCD Top Line - 6 digit, 0.71" (18 mm), with tri-color backlight (red, green or

orange), display range: -199999 to 999999;

Bottom Line - 9 digit, 0.35" (8.9 mm), with green backlight, display range:

- 199,999,999 to 999,999,999

2. POWER: AC Power: 50 to 250 VAC, 50/60 Hz, 14 VA DC Power: 21.6 to 250 VDC, 8 W Isolation: 2300 Vrms for 1 min. to all inputs and outputs.

3. ANNUNCIATORS: Backlight color: Red 1 - setpoint alarm 1 2 - setpoint alarm 2 3 - setpoint alarm 3 4 - setpoint alarm 4 Line 1 Units Display – programmable 3 digit units annunciator with tri-color

backlight (red, green or orange)

4. KEYPAD: 2 programmable function keys, 4 keys total

5. A/D CONVERTER: 24 bit resolution

6. UPDATE RATES: A/D conversion rate: programmable 5 to 160 readings/sec. Step response:

Input Type

V/I/Resistance 400 200 100 50 30 20

Thermocouple 600 250 100 - - -

RTD 1000 500 250 - - -

5 10 20 40 80 160

Input Update Rate

Readings/

Sec

msec

response

time *

* - max. to within 99% of final readout value (digital filter disabled) Display update rate: 1 to 20 updates/sec. Setpoint output on/off delay time: 0 to 3275 sec. Analog output update rate: 0 to 10 sec Max./Min. capture delay time: 0 to 3275 sec.

7. DISPLAY MESSAGES: “OLOL” - Appears when measurement exceeds + signal range. “ULUL” - Appears when measurement exceeds - signal range “Short” - Appears when shorted sensor is detected. (RTD range only) “OPEN” - Appears when open sensor is detected. (TC/RTD range only)

“. . . . .” - Appears when display values exceed + display range.

“- . . . . .” - Appears when display values exceed - display range.

8. INPUT CAPABILITIES:

Current Input:

INPUT RANGE

± 250 µADC

± 2.5 mADC

± 25 mADC

ACCURACY *

(18 to 28°C)

0.03% of rdg + 0.03µA

0.03% of rdg

+ 0.3µA

0.03% of rdg

+ 3µA

ACCURACY *

(0 to 50°C)

0.12% of rdg + 0.04µA

0.12% of rdg

+ 0.4µA

0.12% of rdg

+ 4µA

IMPEDANCE

1.11 K

111

11.1

‡

RESOLUTION

10nA

0.1µA

1µA

± 250 mADC

± 2 ADC

‡ Higher resolution can be achieved via input scaling.

Voltage Input:

INPUT RANGE

± 250 mVDC

± 2.0 VDC

± 10 VDC

± 25 VDC

± 100 VDC

± 200 VDC

‡ Higher resolution can be achieved via input scaling.

Temperature Inputs:

READOUT:

Scale: F or C

Offset Range: -199,999 to 999,999 display units.

Thermocouple Inputs:

Input Impedance: 20MW Lead Resisitance Effect: 0.03 µV/W Max Continuous Overvoltage: 30 V

INPUT

TYPE

T -200 to 400°C 1.2°C 2.1°C ITS-90

E -200 to 750°C 1.0°C 2.4°C ITS-90

J -200 to 760°C 1.1°C 2.3°C ITS-90

K -200 to 1250°C 1.3°C 3.4°C ITS-90

R 0 to 1768°C 1.9°C 4.0°C ITS-90

S 0 to 1768°C 1.9°C 4.0°C ITS-90

N -200 to 1300°C 1.3°C 3.1°C ITS-90

(W5/W26)

RANGE

150 to 300°C

300 to 1820°C

0 to 2315°C 1.9°C 6.1°C

0.05% of rdg + 30µA

0.5% of rdg + 0.3mA

ACCURACY *

(18 to 28°C)

0.03% of rdg + 30µV

0.03% of rdg

+ 0.3mV

0.03% of rdg

+ 3mV

0.03% of rdg

+ 3mV

0.3% of rdg + 30mV

ACCURACY*

(18 to 28 °C)

0.12% of rdg

0.7% of rdg

ACCURACY *

0.12% of rdg

3.9°C

2.8°C

. . . . . . . . . . . . . . . . 11

. . . . . . . . . . . . . . . . . 24

. . . . . . . . . . . . . 31

. . . . . . . . . . . . . . . . . 33

. . . . . . . . . . . . . . . . . 35

+ 40µA

+ 0.4mA

(0 to 50°C)

+ 40µV

+ 0.4mV

+ 4mV

+ 40mV

ACCURACY*

(0 to 50 °C)

5.7°C

4.4°C

1.1

0.1

IMPEDANCE

451 K

STANDARD

ITS-90

ASTM

E988-90**

10µA

0.1mA

RESOLUTION

10µV

0.1mV

1mV

10mV

WIRE COLOR

ANSI BS 1843

(+) blue (-) red

(+) purple (-) red

(+) white (-) red

(+) yellow (-) red

no standard

(+) orange (-) red

no standard

‡

(+) white (-) blue

(+) brown (-) blue

(+) yellow (-) blue

(+) brown (-) blue

(+) white (-) blue

no standard

(+) orange (-) blue

no standard

Page 5

RTD Inputs:

Type: 3 or 4 wire, 2 wire can be compensated for lead wire resistance Excitation current: 100 ohm range: 136.5 µA ±10% 10 ohm range: 2.05 mA ±10% Lead resistance: 100 ohm range: 10 ohm/lead max. 10 ohm range: 3 ohms/lead max. Max. continuous overload: 30 V

INPUT TYPE RANGE

100 ohm Pt

alpha = .00385

100 ohm Pt

alpha = .00392

120 ohm Nickel

alpha = .00672

10 ohm Copper

alpha = .00427

-200 to 850°C 0.4°C 1.6°C IEC 751

-200 to 850°C 0.4°C 1.6°C

-80 to 259°C 0.2°C 0.5°C

-110 to 260°C 0.4°C 0.9°C

ACCURACY*

(18 to 28 °C)

ACCURACY*

(0 to 50 °C)

STANDARD

no official

standard

no official

standard

no official

standard

Resistance Inputs:

INPUT

RANGE

100 ohm

1000 ohm

10 Kohm

‡ Higher resolution can be achieved via input scaling.

ACCURACY *

(18 to 28°C)

0.05% of rdg +0.03 ohm

0.05% of rdg

+0.3 ohm

0.05% of rdg

+1 ohm

ACCURACY *

(0 to 50°C)

0.2% of rdg +0.04 ohm

0.2% of rdg

+0.4 ohm

0.2% of rdg

+1.5 ohm

COMPLIANCE

0.175 V 30 V 0.01 ohm

1.75 V 30 V 0.1 ohm

17.5 V 30 V 0.1 ohm

MAX CONT. OVERLOAD‡ RESOLUTION

* After 20 min. warm-up, @ 5 sample per second input rate. Accuracy is

specified in two ways: Accuracy over an 18 to 28ºC and 15 to 75% RH environment; and Accuracy over a 0 to 50ºC and 0 to 85% RH (non condensing) environment. The specification includes the A/D conversion errors, linearization conformity, and thermocouple ice point compensation. Total system accuracy is the sum of meter and probe errors. Accuracy may be improved by field calibrating the meter readout at the temperature of interest.

** These curves have been corrected to ITS-90.

9. EXCITATION POWER: Jumper selectable Transmitter Power: +18 VDC, ± 5% @ 50 mA max. Reference Voltage: + 2 VDC, ± 2%

Compliance: 1KW load min (2 mA max) Temperature Coefficient: 40 ppm/ºC max.

Reference Current: 1.05 mADC, ± 2%

Compliance: 10 KW load max. Temperature Coefficient: 40 ppm/ºC max.

10. USER INPUTS: Two programmable user inputs Max. Continuous Input: 30 VDC Isolation To Sensor Input Common: Not isolated. Response Time: 12 msec. max. Logic State: User programmable (USrACt) for sink/source (Lo/Hi)

INPUT STATE

(

USrACt)

Active V

Inactive V

LO/SINK HI/SOURCE

20KW pull-up to +3.3V 20KW pull-down

< 1.1 VDC VIN > 2.2 VDC

> 2.2 VDC VIN < 1.1 VDC

11. TOTALIZER: Time Base: second, minute, hour, or day Batch: Can accumulate (gate) input display from a user input Time Accuracy: 0.01% typical Decimal Point: 0 to 0.0000 Scale Factor: 0.001 to 65.000 Low Signal Cut-out: -199,999 to 999,999 Total: 6 digits on Line 1; 9 digits on Line 2

12. CUSTOM LINEARIZATION: Data Point Pairs: Selectable from 2 to 16 Display Range: -199,999 to 999,999 Decimal Point: 0 to 0.0000

13. MEMORY: Nonvolatile FRAM memory retains all programmable parameters and display values.

14. ENVIRONMENTAL CONDITIONS: Operating Temperature Range: 0 to 50 °C Storage Temperature Range: -40 to 60 °C Vibration According to IEC 68-2-6: Operational 5 to 150 Hz, in X, Y, Z

direction for 1.5 hours, 2 g.

Shock According to IEC 68-2-27: Operational 25 g (10 g relay), 11 msec in 3

directions. Operating and Storage Humidity: 0 to 85% max. RH non-condensing Altitude: Up to 2000 meters

15. CERTIFICATIONS AND COMPLIANCES:

SAFETY

IEC 61010-1, EN 61010-1: Safety requirements for electrical equipment

for measurement, control, and laboratory use, Part 1. IP65 Enclosure rating (Face only), IEC 529 IP20 Enclosure rating (Rear of unit), IEC 529

Type 4X Indoor Enclosure rating (Face only)

ELECTROMAGNETIC COMPATIBILITY

Emissions and Immunity to EN 61326:2006: Electrical Equipment for

Measurement, Control and Laboratory use.

Immunity to Industrial Locations:

Electrostatic discharge EN 61000-4-2 Criterion A

4 kV contact discharge 8 kV air discharge

Electromagnetic RF fields EN 61000-4-3 Criterion B

10 V/m (80 MHz to 1 GHz) 3 V/m (1.4 GHz to 2 GHz) 1 V/m (2 GHz to 2.7 GHz)

Fast transients (burst) EN 61000-4-4 Criterion B

2 kV power 1 kV I/O signal 2 kV I/O signal connected

Surge EN 61000-4-5 Criterion A

to power

power 1 kV L to L, 2 kV L to G signal 1 kV

RF conducted interference EN 61000-4-6 Criterion B

3 Vrms

Power freq magnetic fields EN 61000-4-8 Criterion A

30 A/m

AC power EN 61000-4-11

Voltage dip Criterion A

0% during 1 cycle 40% during 10/12 cycle 70% during 25/30 cycle

Short interruptions Criterion C

0% during 250/300 cycles

Emissions:

Emissions EN 55011 Class A

Notes:

1. Criterion A: Normal operation within specified limits.

2. Criterion B: Temporary loss of performance from which the unit selfrecovers.

3. Criterion C: Temporary loss of function where system reset occurs.

Refer to EMC Installation Guidelines section of the bulletin for additional

information.

16. CONNECTIONS: High compression cage-clamp terminal block Wire Strip Length: 0.3" (7.5 mm) Wire Gauge Capacity: One 14 AWG (2.55 mm) solid, two 18 AWG (1.02

mm) or four 20 AWG (0.61 mm)

17. CONSTRUCTION: This unit is rated for NEMA 4X/IP65 indoor use. IP20 Touch safe. Installation Category II, Pollution Degree 2. One piece bezel/ case. Flame resistant. Synthetic rubber keypad. Panel gasket and mounting clip included.

18. WEIGHT: 8 oz. (226.8 g)

Page 6

OpTiOnal pluG-in OuTpuT Cards

WARNING: Disconnect all power to the unit before

installing plug-in cards.

Adding Option Cards

The DP series meters can be fitted with up to three optional plug-in cards. The details for each plug-in card can be reviewed in the specification section below. Only one card from each function type can be installed at one time. The function types include Setpoint Alarms (LDP6-CDS), Communications (LDP6-CDC), and Analog Output (LDP6-CDL). The plug-in cards can be installed initially or at a later date.

COMMUNICATION CARDS (LDP6-CDC)

A variety of communication protocols are available for the DP63100 meter. Only one of these card can be installed at a time. Note: For Modbus

communications use RS485 Communications Output Card and configure communication (tYPE) parameter for Modbus.

LDP6-CDC10 - RS485 Serial (Terminal) LDP6-CDC1C - RS485 Serial (Connector) LDP6-CDC20 - RS232 Serial (Terminal) LDP6-CDC2C - RS232 Serial (Connector)

SERIAL COMMUNICATIONS CARD

Type: RS485 or RS232

Communication Type: RLC Protocol (ASCII), Modbus RTU, and Modbus

ASCII

Isolation To Sensor & User Input Commons: 500 Vrms for 1 min.

Working Voltage: 50 V. Not Isolated from all other commons.

Data: 7/8 bits

Baud: 1200 to 38,400

Parity: no, odd or even

Bus Address: Selectable 0 to 99 (RLC Protocol), or 1 to 247 (Modbus

Protocol), Max. 32 meters per line (RS485)

Transmit Delay: Selectable for 0 to 0.250 sec (+2 msec min)

QUAD SINKING OPEN COLLECTOR CARD

Type: Four isolated sinking NPN transistors. Isolation To Sensor & User Input Commons: 500 Vrms for 1 min.

Working Voltage: 50 V. Not Isolated from all other commons.

Rating: 100 mA max @ V

QUAD SOURCING OPEN COLLECTOR CARD

Type: Four isolated sourcing PNP transistors. Isolation To Sensor & User Input Commons: 500 Vrms for 1 min.

Working Voltage: 50 V. Not Isolated from all other commons.

Rating: Internal supply: 18 VDC unregulated, 30 mA max. total

External supply: 30 VDC max., 100 mA max. each output

ALL FOUR SETPOINT CARDS

Response Time: See Update Rates step response specification on page 4; add

6 msec (typical) for relay card

= 0.7 V max. V

SAT

MAX

= 30 V

LINEAR DC OUTPUT (LDP6-CDL)

Either a 0(4)-20 mA or 0-10 V retransmitted linear DC output is available from the analog output plug-in card. The programmable output low and high scaling can be based on various display values. Reverse slope output is possible by reversing the scaling point positions.

LDP6-CDL10 - Retransmitted Analog Output Card

ANALOG OUTPUT CARD

Types: 0 to 20 mA, 4 to 20 mA or 0 to 10 VDC

Isolation To Sensor & User Input Commons: 500 Vrms for 1 min.

Working Voltage: 50 V. Not Isolated from all other commons.

Accuracy: 0.17% of FS (18 to 28 °C); 0.4% of FS (0 to 50 °C)

Resolution: 1/3500

Compliance: 10 VDC: 10 K

Powered: Self-powered

Step Response: See Update Rates step response specification on page 4.

Update time: See ADC Conversion Rate and Update Time parameter

W load min., 20 mA: 500 W load max.

SETPOINT CARDS (LDP6-CDS)

The DP63100 meter has 4 available setpoint alarm output plug-in cards. Only one of these cards can be installed at a time. (Logic state of the outputs can be reversed in the programming.) These plug-in cards include:

LDP6-CDS10 - Dual Relay, FORM-C, Normally open & closed LDP6-CDS20 - Quad Relay, FORM-A, Normally open only LDP6-CDS30 - Isolated quad sinking NPN open collector LDP6-CDS40 - Isolated quad sourcing PNP open collector

DUAL RELAY CARD

Type: Two FORM-C relays

Isolation To Sensor & User Input Commons: 2000 Vrms for 1 min.

Working Voltage: 240 Vrms

Contact Rating:

One Relay Energized: 5 amps @ 120/240 VAC or 28 VDC (resistive load). Total current with both relays energized not to exceed 5 amps

Life Expectancy: 100 K cycles min. at full load rating. External RC snubber

extends relay life for operation with inductive loads

QUAD RELAY CARD

Type: Four FORM-A relays

Isolation To Sensor & User Input Commons: 2300 Vrms for 1 min.

Working Voltage: 250 Vrms

Contact Rating:

One Relay Energized: 3 amps @ 240 VAC or 30 VDC (resistive load). Total current with all four relays energized not to exceed 4 amps

Life Expectancy: 100K cycles min. at full load rating. External RC snubber

extends relay life for operation with inductive loads

PROGRAMMING SOFTWARE

DP6-SOFT is a Windows® based program that allows configuration of the meter from a PC. The software offers standard drop-down menu commands, that make it easy to program the meter. The meter’s program can then be saved in a PC file for future use.

Page 7

1.0 insTallinG The MeTer

PANEL

LATCHING SLOTS

BEZEL

PANEL GASKET

PANEL LATCH

LATCHING

TABS

PANEL MOUNTING SCREWS

Installation

The meter meets NEMA 4X/IP65 requirements when properly installed. The unit is intended to be mounted into an enclosed panel. Prepare the panel cutout to the dimensions shown. Remove the panel latch from the unit. Slide the panel gasket over the rear of the unit to the back of the bezel. The unit should be installed fully assembled. Insert the unit into the panel cutout.

While holding the unit in place, push the panel

latch over the rear of the unit so that the tabs of

the panel latch engage in the slots on the

case. The panel latch should be

engaged in the farthest forward slot

possible. To achieve a proper

seal, tighten the latch

2.0 seTTinG The JuMpers

The DP63100 meter has four jumpers that must be checked and/or changed prior to applying power. The following Jumper Selection Figures show an enlargement of the jumper area.

To access the jumpers, remove the meter base from the case by firmly squeezing and pulling back on the side rear finger tabs. This should lower the latch below the case slot (which is located just in front of the finger tabs). It is recommended to release the latch on one side, then start the other side latch.

Warning: Exposed line voltage exists on the circuit boards. Remove

all power to the meter and load circuits before accessing inside of the meter.

FRONT DISPLAY

Main Circuit Board

JUMPER

LOCATIONS

Finger

Tab

REAR TERMINALS

INPUT RANGE JUMPERS

Voltage Input

Two jumpers are used in configuring the meter for voltage/resistance. The first jumper, T/V, must be in the V (voltage) position. The second jumper is used to select the proper voltage input range. (This jumper is also used to select the current input range.) Select a range that is high enough to accommodate the maximum signal input to avoid overloads. For proper operation, the input range selected in programming must match the jumper setting.

RTD

100

Finger

Tab

screws evenly until the unit is snug in the panel (Torque to approximately 7 in-lbs [79N-cm]). Do not over-tighten the screws.

Installation Environment

The unit should be installed in a location that does not exceed the operating temperature and provides good air circulation. Placing the unit near devices that generate excessive heat should be avoided.

The bezel should only be cleaned with a soft cloth and neutral soap product. Do NOT use solvents. Continuous exposure to direct sunlight may accelerate the aging process of the bezel.

Do not use tools of any kind (screwdrivers, pens, pencils, etc.) to operate the keypad of the unit.

PANEL CUT-OUT

+.03

3.62

-.00

+.8

(92 )

-.0

+.02

1.77

-.00

+.5

(45 )

-.0

Current Input

For current input, only one jumper must be configured to select the current range. This jumper is shared with the voltage input range. To avoid overloads, select the jumper position that is high enough to accommodate the maximum signal input level to be applied.

Note: The position of the T/V jumper does not matter when the meter is in the current input mode.

Temperature Input

For temperature measurement the T/V jumper must be in the T (temperature) position. For RTD sensors the RTD jumper must also be set.

Resistance Input

Three jumpers are used to configure the resistance input. The T/V jumper must be in the V (voltage) position, and the excitation jumper must be in the

1.05 mA REF position. The voltage/resistance jumper position is determined by the input range.

Excitation Output Jumper

This jumper is used to select the excitation range for the application. If excitation is not being used, it is not necessary to check or move this jumper.

EXCITATION OUTPUT JUMPER

18V @ 50mA 2V REF.

1.05 mA REF.

10 ohm RTD 100 ohm RTD

RTD INPUTS

INPUT RANGE JUMPERS

2 A

.25 A

.025 A

.0025 A

250 µA

CURRENT INPUTS

THERMOCOUPLE/

VOLTAGE

SELECTION

TEMPERATURE

VOLTAGE

LV - 250mV/2V/100Ω/1KΩ M - 10V/100V HV - 25V/200V/10KΩ

VOLTAGE/RESISTANCE

INPUTS

REAR TERMINALS

Page 8

3.0 insTallinG pluG-in Cards

The plug-in cards are separately purchased optional cards that perform specific functions. These cards plug into the main circuit board of the meter. The plug-in cards have many unique functions when used with the DP63100.

CAUTION: The plug-in card and main circuit board contain static

sensitive components. Before handling the cards, discharge static charges from your body by touching a grounded bare metal object. Ideally, handle the cards at a static controlled clean workstation. Also, only handle the cards by the edges. Dirt, oil or other contaminants that may contact the cards can adversely affect circuit operation.

Connectors

Finger

Tab

Main Circuit Board

Serial

Communications

Card

Alignment

Slots

TOP VIEW

Analog Output Card

Setpoint Output Card

Finger Tab

To Install:

1. With the meter removed from the case, locate the plug-in card connector for the card type to be installed. The types are keyed by position with different main circuit board connector locations. When installing the card, hold the meter by the rear terminals and not by the front display board. If installing the Quad sourcing Plug-in Card (LDP6-CDS40), set the jumper

for internal or external supply operation before continuing.

2. Install the plug-in card by aligning the card terminals with the slot bay in the rear cover. Be sure the connector is fully engaged and the tab on the plug-in card rests in the alignment slot on the display board.

3. Slide the meter base back into the case. Be sure the rear cover latches fully into the case.

4. Apply the plug-in card label to the bottom side of the meter in the designated area. Do Not Cover the vents on the top surface of the meter. The surface of the case must be clean for the label to adhere properly.

Internal Supply

(18 V unregulated)

External Supply (30 V )

max

4.0 WirinG The MeTer

WIRING OVERVIEW

Electrical connections are made via screw-clamp terminals located on the back of the meter. All conductors should conform to the meter’s voltage and current ratings. All cabling should conform to appropriate standards of good installation, local codes and regulations. It is recommended that the power supplied to the meter (DC or AC) be protected by a fuse or circuit breaker.

When wiring the meter, compare the numbers embossed on the back of the meter case against those shown in wiring drawings for proper wire position. Strip the wire, leaving approximately 0.3" (7.5 mm) bare lead exposed (stranded wires should be tinned with solder). Insert the lead under the correct screwclamp terminal and tighten until the wire is secure (Pull wire to verify tightness). Each terminal can accept up to one #14 AWG (2.55 mm) wire, two #18 AWG (1.02 mm), or four #20 AWG (0.61 mm).

EMC INSTALLATION GUIDELINES

Although this meter is designed with a high degree of immunity to ElectroMagnetic Interference (EMI), proper installation and wiring methods must be followed to ensure compatibility in each application. The type of the electrical noise, source or coupling method into the meter may be different for various installations. The meter becomes more immune to EMI with fewer I/O connections. Cable length, routing, and shield termination are very important and can mean the difference between a successful or troublesome installation. Listed below are some EMC guidelines for successful installation in an industrial environment.

1. The meter should be mounted in a metal enclosure, which is properly

connected to protective earth.

2. Use shielded (screened) cables for all Signal and Control inputs. The shield

(screen) pigtail connection should be made as short as possible. The

connection point for the shield depends somewhat upon the application.

Listed below are the recommended methods of connecting the shield, in order

of their effectiveness.

a. Connect the shield only at the panel where the unit is mounted to earth

ground (protective earth).

b. Connect the shield to earth ground at both ends of the cable, usually when

the noise source frequency is above 1 MHz.

c. Connect the shield to common of the meter and leave the other end of the

shield unconnected and insulated from earth ground.

3. Never run Signal or Control cables in the same conduit or raceway with AC power lines, conductors feeding motors, solenoids, SCR controls, and heaters, etc. The cables should be run in metal conduit that is properly grounded. This is especially useful in applications where cable runs are long and portable two-way radios are used in close proximity or if the installation is near a commercial radio transmitter.

4. Signal or Control cables within an enclosure should be routed as far as possible from contactors, control relays, transformers, and other noisy components.

5. In extremely high EMI environments, the use of external EMI suppression devices, such as ferrite suppression cores, is effective. Install them on Signal and Control cables as close to the unit as possible. Loop the cable through the core several times or use multiple cores on each cable for additional protection. Install line filters on the power input cable to the unit to suppress power line interference. Install them near the power entry point of the enclosure. The following EMI suppression devices (or equivalent) are recommended:

Ferrite Suppression Cores for signal and control cables:

Fair-Rite # 0443167251 TDK # ZCAT3035-1330A Steward # 28B2029-0A0

Line Filters for input power cables:

Schaffner # FN2010-1/07 Schaffner # FN670-1.8/07 Corcom # 1 VR3

Note: Reference manufacturer’s instructions when installing a line filter.

6. Long cable runs are more susceptible to EMI pickup than short cable runs. Therefore, keep cable runs as short as possible.

7. Switching of inductive loads produces high EMI. Use of snubbers across inductive loads suppresses EMI.

Page 9

4.1 POWER WIRING

AC Power

1 2

AC/DC AC/DC

DC Power

AC/DC AC/DC

4.2 VOLTAGE/RESISTANCE/CURRENT INPUT SIGNAL WIRING

IMPORTANT: Before connecting signal wires, the Input Range Jumpers and Excitation Jumper should be verified for proper position.

Voltage Signal Process/Current Signal

V-TC-RTD IN

I INPUT

6 7 8



200VDC MAX.

Process/Current Signal (external powered)

INP COMM

Load

2A DC MAX.

I INPUT

(2 wire requiring 18V excitation)

Excitation Jumper: 18 V

INP COMM

V EXEC

COMM

5 63

2 WIRE

TRANSMITTER

RTD EXC

I INPUT

requiring 18 V excitation)

Terminal 3: +Volt supply Terminal 6: +ADC (signal) Terminal 8: -ADC (common) Excitation Jumper: 18 V

Voltage Signal (3 wire requiring 18 V excitation)

Terminal 3: +Volt supply Terminal 7: +VDC (signal) Terminal 8: -VDC (common) Excitation Jumper: 18 V

V EXC

3 WIRE TRANSMITTER

I INPUT

6 7 83

Current Signal (3 wire

V-TC-RTD-IN

INP COMM

VoutIout

Resistance Signal (2 wire requiring excitation)

Terminal 3: Jumper to terminal 7 Terminal 7: Resistance Terminal 8: Resistance Excitation Jumper:

1.05 mA REF. T/V Jumper: V position Voltage/Resistance Input

Jumper: Set per input signal

CAUTION: Sensor input common is NOT isolated from user input common. In order to preserve the safety of the meter application, the sensor input common must be suitably isolated from hazardous live earth referenced voltages; or input common must be at protective earth ground potential. If not, hazardous live voltage may be present at the User Inputs and User Input Common terminals. Appropriate considerations must then be given to the potential of the user input common with respect to earth common; and the common of the isolated plug-in cards with respect to input common.

V EXC

V-TC-RTD-IN

3 7 8

10K MAX

INP COMM

1.05 mA REF.

Potentiometer Signal as Voltage Input (3 wire requiring excitation)

Terminal 3: High end of pot. Terminal 7: Wiper Terminal 8: Low end of pot. Excitation Jumper: 2 V REF. T/V Jumper: V Voltage/Resistance Input Jumper: 2 Volt Module 1 Input Range: 2 Volt

Note: The Apply signal scaling style

should be used because the signal will be in volts.

4.3 TEMPERATURE INPUT SIGNAL WIRING

IMPORTANT: Before connecting signal wires, verify the T/V Jumper is in the T position.

Thermocouple

V-TC-RTD-IN

INP COMM

7 8



3-Wire RTD

RTD EXC

V-TC-RTD-IN

7 8

RTD (Excitation)

INP COMM

Sense Lead

2-Wire RTD

RTD EXC

V-TC-RTD-IN

7 8

INP COMM

Sense Lead

Jumper

V EXC

V-TC-RTD-IN

INP COMM

3 7 8

2V REF.

CAUTION: Sensor input common is NOT isolated

from user input common. In order to preserve the safety of the meter application, the sensor input

common must be suitably isolated from hazardous live earth referenced voltages; or input common must be at protective earth ground potential. If not, hazardous live voltage may be present at the User Inputs and User Input Common terminals. Appropriate considerations must then be given to the potential of the user input common with respect to earth common; and the common of the isolated plugin cards with respect to input common.

2V INPUT

Rmin=1KΩ

Page 10

4.4 USER INPUT WIRING

Programmable Units Display

If not using User Inputs, then skip this section. Only the appropriate User Input terminal has to be wired.

Sinking Logic (USrACt Lo)

When the USrACt parameter is programmed to Lo, the user inputs of the meter are internally pulled up to +3.3 V with 20 KW resistance. The input is active when it is pulled low (<1.1 V).

USER INPUTS

USER COMM

USER 1

10 119

4.5 SETPOINT (ALARMS) WIRING

4.6 SERIAL COMMUNICATION WIRING

4.7 ANALOG OUTPUT WIRING

USER 2

  

Sourcing Logic (USrACt Hi)

When the USrACt parameter is programmed to Hi, the user inputs of the meter are internally pulled down to 0 V with 20 KW resistance. The input is active when a voltage greater than 2.2 VDC is applied.

See appropriate plug-in card bulletin for wiring details.

SUPPLY

USER INPUTS

USER COMM

109 11

(30V max.)

USER 2

USER 1

5.0 revieWinG The frOnT buTTOns and display

Display Line 1

Display Line 2

Setpoint Annunciators

KEY DISPLAY MODE OPERATION PROGRAMMING MODE OPERATION

D Index Line 2 through enabled, max/min/input/total, readouts Quick exit to display mode

P Access the parameter and hidden display loops Access the programming parameter menus, store selected

Function key 1; hold for 3 seconds for second function 1* Increment selected parameter value

Function key 2; hold for 3 seconds for second function 2* Decrement selected parameter value

*Factory setting for F1 and F2 is no mode

The DP63100 display consists of a large, 6-digit upper display referred to as Line 1 and a smaller 9-digit lower display referred to as Line 2. Line 1 can be configured to show one of several values, including the main input reading, min, max, setpoints or total values. Line 2 can be used to display several selectable values including; input value, min, max, total, list, setpoint values, and other values. For these values the mnemonics is shown in the left most digits of Line 2. To the right of Line 1 is a Programmable Units Display. This display consists of 3 programmable digits that are user defined as mnemonics for Line 1.

parameter and index to next parameter

Page 11

dp63100 display lOOps

MAIN DISPLAY LOOP

Alternate Full Programming

entry path

PARAMETER

DISPLAY

LOOP

COdE

HIDDEN

PARAMETER

DISPLAY

LOOP

Code 1-250

Any Code with

PLOC Enabled

1-250

Pro

PLOC Disabled

Code 0

AND

Pro

End

Exit

Programming

Pro

1-INPUt

* Pressing “D” at any time exits back to the Main Display Loop.

Pro

2-FUNCt

Pro

3-dISPLY

Pro

4-SCNdrY

DP63100 DISPLAY LOOPS

The DP63100 offers three display loops to allow users quick access to needed

information. These display loops are available when the meter is in the normal display mode. By pressing the D key, the user can view parameters such as the Total, Min, Max or the Input in the Main Display Loop. Display selections are fully programmable and are viewed on the 9 digit line of the meter.

Pressing the P key with no security code (COdE 0) will put the meter directly

into the programming mode. When a security code is programmed (Code 1-250), pressing the P key will allow access to the Parameter Display Loop. This loop is where the parameters like setpoint values are normally put for general public access. Parameters in this loop can only be viewed/changed if enabled in the meter programming. After all the parameters in the Parameter Display Loop are viewed, an additional press of the P key will bring up the security code (COdE 0). Access the Hidden Parameter Display Loop by entering the selected security code. In this loop displayed parameters can be changed. Combining the two parameter loops provides an area for parameters that require general access and/or protected or secure access depending on your application needs.

During programming of the meter you will need to select if a value is to be

displayed or not. If the value is not required, select the lock mode (LOC). If you decide to display the value, you will need to assign it to a loop; D for the Main Display Loop, P for the Parameter Display Loop, and HidE for the Hidden Display Loop. In the case of the parameters, such as the setpoint values you will also need to decide if the value can only be read (rEd) or entered (ENt). The ! and @ key will increment or decrement the value when the edit mode is active. After the change, press the P key to save and move to the next value. Any values placed in the Hidden Parameter Loop can be changed as they are protected by the security code. While in the parameter display and hidden parameter loops,

Pro

5-totAL

pressing the D key will return the meter to the main display.

When the P key is pushed on a resettable display, the unit will display the value mnemonic and “NO” (if Line 2 value was set for “d-ENt” in “3-dISPLY”). Pressing the ! and @ keys will toggle between “NO’ and “YES”. Pressing the P key with “YES” displayed will cause the reset action to be performed.

parameter values when at the main display or to step through the parameter loop and hidden parameter loop. It is used as the enter key when the meter is in the programming mode.

Pro

6-SEtPNt

There are selections in the programming that allow for the values to be reset.

The P, Parameter key is used to scroll among the programmed Line 2

F1 F1

Pro

7-SErIAL

Pro

8-AnLOut

Numerical Value Entry

If the parameter is programmed for enter (ENt), the ! and @ keys are used

to change the parameter values in any of the display loops.

The ! and @ keys will increment or decrement the parameter value. When

the arrow key is pressed and held, the value automatically scrolls. The longer the arrow key is held the faster the value scrolls.

For large value changes, press and hold the ! or @ key. While holding that

key, momentarily press the D key and the value scrolls by 1000’s as the arrow key is held. Releasing the arrow key removes the 1000’s scroll feature. The arrow keys can then be used to make small value changes as described above.

Pro

9-FACtrY

Page 12

Main Display Loop

Security Code

321.0

tot98753.2

321.0

rEL NO

321.0

S1 100.0

321.0

S2 100.0

321.0

COdE 0

VALID CODE

321.0

S3 500.0

321.0

54 1000.0

Pro

D D

GAL

Security Code

hidE

1-250

GAL

321.0

Lo 23.1

INVALID

CODE

GAL

Parameters

Display

Loop

Hidden

Parameters

Display

Loop

321.0

Hi 9245.5

GAL

6.0 prOGraMMinG The dp63100

Pro

1-INPUt

Signal

Input

Parameters

F1 F1 F1 F1 F1 F1 F1 F1 F1

Pro

2-FUNCt

User Input/

Function

Key

Parameters

Pro

3-dISPLY

Display/ Program Lock out

Parameters

Pro

4-SCNdrY

Secondary

Function

Parameters

Pro

5-totAL

Totalizer

Parameters

Pro

6-SEtPNt

Setpoint

Parameters

Pro

7-SErIAL

Serial

Comms

Parameters

Pro

8-AnLOut

Analog Output

Parameters

Pro

9-FACtrY

Factory Service

Parameters

Page 13

MOdule 1 - inpuT seTup paraMeTers (1-INPUt)

Pro

1-INPUt

rAN9E

200U

Input Range

Temperature Input Types Only

INP

SCALE

Temperature

INP

°F

Scale

FILtEr

Filter

Setting

ICE

Ice Point

Compensation

INP

bANd

1.0

Filter Band

PARAMETER MENU

INP

rAtE

ADC Rate

INP

0.10

INP

POINtS

Scaling

Points

INPUT RANGE

250uA 2U 1000o tc-r r392

rANgE

200U

INP

0.0025A 10U 10000o tc-S r672

0.025A 25U tc-t tc-b r427

0.25A 100U tc-E tc-n 2A 200U tc-J tc-C

0.25U 100o tc-k r385

Select the desired input range.

TEMPERATURE SCALE

For TC and RTD Input Range Selection only.

SCALE

°F

Select the temperature scale. This selection applies for Input, MAX, MIN, and TOT displays. If changed, those parameters that relate to the temperature scale should be checked.

INP

°F °C

ICE POINT COMPENSATION

ICE

INP

This parameter turns the internal ice point compensation on or off. Normally, the ice point compensation is on. If using external compensation, set this parameter to off. In this case, use copper leads from the external compensation point to the meter.

For TC Input Range Selection only.

ON OFF

INPUT UPDATE RATE (/SEC)

rAtE

Select the ADC conversion rate (conversions per second). Temperature inputs can not be set higher than 20 updates per second. The selection does not affect the display update rate, however it does affect setpoint and analog output response time. The default factory setting of 5 is recommended for most applications. Selecting a fast update rate may cause the display to appear very unstable.

INP

5 10 20 40 80 160

DECIMAL RESOLUTION (Display Units)

dECPNt

Select desired display resolution. The available selections are dependent on the Input Range selected (rANgE).

0.00

INP

0 to 0.0000 (curr/volt) 0 to 0.0 (temp)

Pro

0.01

Display

Rounding

INPUt

Input n

Value

INP

0.00

OFFSEt

Display

Offset Value

INP

0.00

dISPLY

0.00

Display n

Value

ScLISt

Enable

Scale List

INP

dECPNt

0.00

Display

Decimal

Point

Voltage and Current Input Type Only

INP

StYLE

KEY

Scaling

round

INP

Style

ROUNDING INCREMENT

round

Rounding selections other than one, cause the Input Display to ‘round’ to the nearest rounding increment selected (ie. rounding of ‘5’ causes 122 to round to 120 and 123 to round to 125). Rounding starts at the least significant digit of the Input Display. Remaining parameter entries (scaling point values, setpoint values, etc.) are not automatically adjusted to this display rounding selection.

0.01

INP

1 2 5 10 20 50 100

DISPLAY OFFSET

OFFSEt

The display can be corrected with an offset value. This can be used to compensate for probe errors, errors due to variances in probe placement or adjusting the readout to a reference thermometer. This value is automatically updated after a Zero Display to show how far the display is offset. A value of zero will remove the affects of offset.

0.00

INP

-199999 to 999999

DIGITAL FILTERING

FILtEr

The input filter setting is a time constant expressed in tenths of a second. The filter settles to 99% of the final display value within approximately 3 time constants. This is an Adaptive Digital Filter which is designed to steady the Input Display reading. A value of ‘0’ disables filtering.

1.0

INP

0.0 to 25.0 seconds

FILTER BAND

bANd

The digital filter will adapt to variations in the input signal. When the variation exceeds the input filter band value, the digital filter disengages. When the variation becomes less than the band value, the filter engages again. This allows for a stable readout, but permits the display to settle rapidly after a large process change. The value of the band is in display units, independent of the Display Decimal Point position. A band setting of ‘0’ keeps the digital filter permanently engaged.

When the meter is programmed for TC or RTD, the following programming steps are not active.

0.10

INP

0 to 250 display units

SCALING POINTS

POINtS

Linear - Scaling Points (2)

For linear processes, only 2 scaling points are necessary. It is recommended

INP

2 to 16

Page 14

that the 2 scaling points be at opposite ends of the input signal being applied. The points do not have to be the signal limits. Display scaling will be linear between and continue past the entered points up to the limits of the Input Signal Jumper position. Each scaling point has a coordinate-pair of Input Value (INPUt n) and an associated desired Display Value (dISPLY n).

Nonlinear - Scaling Points (Greater than 2)

For non-linear processes, up to 16 scaling points may be used to provide a piece-wise linear approximation. (The greater the number of scaling points used, the greater the conformity accuracy.) The Input Display will be linear between scaling points that are sequential in program order. Each scaling point has a coordinate-pair of Input Value (INPUt n) and an associated desired Display Value (dISPLY n). Data from tables or equations, or empirical data could be used to derive the required number of segments and data values for the coordinate pairs. In the DP6-SOFT software, several linearization equations are available.

This parameter does not apply for thermocouple or RTD input ranges.

StYLE

KEY

If Input Values and corresponding Display Values are known, the Key-in (KEY) scaling style can be used. This allows scaling without the presence of the input signal. If Input Values have to be derived from the actual input signal source or simulator, the Apply (APPLY) scaling style must be used.

INP

INPUT VALUE FOR SCALING POINT 1

INPUt

SCALING STYLE

KEY key-in data APPLY apply signal

-199999 to 999999

0.00

For Key-in (KEY), enter the known first Input Value by using the ! or @ arrow keys. (The Input Range selection sets up the decimal location for the Input Value). For Apply (APPLY), the existing programmed value will appear. If this is acceptable, press the P key to save and continue to the next parameter. To update/program this value, apply the input signal that corresponds to Scaling Point 1, press @ key and the actual signal value will be displayed. Then press the P key to accept this value and continue to the next parameter.

DISPLAY VALUE FOR SCALING POINT 1

dISPLY

-199999 to 999999

0.00

Enter the first coordinating Display Value by using the arrow keys. This is the

same for KEY and APPLY scaling styles. The decimal point follows the dECPNt selection.

INPUT VALUE FOR SCALING POINT 2

INPUt

-199999 to 999999

100.00

For Key-in (KEY), enter the known second Input Value by using the ! or @

arrow keys. For Apply (APPLY), the existing programmed value will appear. If this is acceptable, press the P key to save and continue to the next parameter. To update/program this value, apply the input signal that corresponds to Scaling Point 2, press @ key and the actual signal value will be displayed. Then press the P key to accept this value and continue to the next parameter. (Follow the same procedure if using more than 2 scaling points.)

DISPLAY VALUE FOR SCALING POINT 2

dISPLY

-199999 to 999999

100.00

Enter the second coordinating Display Value by using the ! or @ arrow

keys. This is the same for KEY and APPLY scaling styles. (Follow the same procedure if using more than 2 scaling points.)

ENABLE SCALE LIST

ScLISt

NO YES

When enabled, a second list of scaling points is active in the selected

parameter list for List A and List B.

MOdule 2 - user inpuT/funCTiOn Key paraMeTers (2-FUNCt)

Pro

2-FUNCt

FNC

USEr-1

USrACt

The two user inputs are individually programmable to perform specific meter control functions. While in the Display Mode or Program Mode, the function is executed the instant the user input transitions to the active state. The front panel function keys, ! and @, are also individually programmable to perform specific meter control functions. While in the Display Mode, the primary function is executed the instant the key is pressed. Holding the function key for three seconds executes a secondary function. It is possible to program a secondary function without a primary function.

In most cases, if more than one user input and/or function key is programmed for the same function, the maintained (level trigger) actions will be performed while at least one of those user inputs or function keys are activated. The momentary (edge trigger) actions will be performed every time any of those user inputs or function keys transition to the active state.

Note: In the following explanations, not all selections are available for both user inputs and front panel function keys. Displays are shown with each selection. Those selections showing both displays are available for both. If a display is not shown, it is not available for that selection. USEr-n will represent both user inputs. Fn will represent both function keys and second function keys.

FNC

PARAMETER MENU

FNC

USEr-2

FNC

SEC-F1

Function KeysUser Inputs

USER INPUT ACTIVE STATE

FNC

Lo Hi

USrACt

Select the desired active state for the User Inputs. Select Lo for sink input,

active low. Select Hi for source input, active high.

NO FUNCTION

FNC

USEr-n

No function is performed if activated. This is the factory setting for all user

inputs and function keys.

FNC

Pro

SEC-F2

FNC

Page 15

PROGRAMMING MODE LOCK-OUT

FNC

USEr-n

PLOC

Programming Mode is locked-out, as long as activated (maintained action). A

security code can be configured to allow programming access during lock-out.

ZERO (TARE) DISPLAY

USEr-n

rEL

The Zero (Tare) Display provides a way to zero the Input Display value at various input levels, causing future Display readings to be offset. This function is useful in weighing applications where the container or material on the scale should not be included in the next measurement value. When activated (momentary action), rESEt flashes and the Display is set to zero. At the same time, the Display value (that was on the display before the Zero Display) is subtracted from the Display Offset Value and is automatically stored as the new Display Offset Value. If another Zero (tare) Display is performed, the display will again change to zero and the Display offset value will shift accordingly.

USEr-n

d-rEL

This function will switch the Input Display between Relative and Absolute. The Relative is a net value that includes the Display Offset Value. The Input Display will normally show the Relative unless switched by this function. Regardless of the display selected, all meter functions continue to operate based on relative values. The Absolute is a gross value (based on Module 1 DSP and INP entries) without the Display Offset Value. The Absolute display is selected as long as the user input is activated (maintained action) or at the transition of the function key (momentary action). When the user input is released, or the function key is pressed again, the input display switches back to Relative display. (AbS) or (rEL) is momentarily displayed at transition to indicate which display is active.

USEr-n

d-HLd

USEr-n

A-HLd

USEr-n

SYNC

FNC

rEL

RELATIVE/ABSOLUTE DISPLAY

FNC

d-rEL

HOLD DISPLAY

FNC

The active display is held but all other meter functions

continue as long as activated (maintained action).

HOLD ALL FUNCTIONS

FNC

The meter disables processing the input, holds all display contents, and locks the state of all outputs as long as activated (maintained action). The serial port continues data transfer.

SYNCHRONIZE METER READING

FNC

The meter suspends all functions as long as activated (maintained action). When the user input is released, the meter synchronizes the restart of the A/D with other processes or timing events.

FNC

STORE BATCH READING IN TOTALIZER

USEr-n

bAt

The Input Display value is added (batched) to the Totalizer at transition to

activate (momentary action) and Line 2 flashes bAtCh. The Totalizer retains a running sum of each batch operation until the Totalizer is reset. When this function is selected, the normal operation of the Totalizer is overridden and only batched Input Display values accumulate in the Totalizer.

USEr-n

d-tot

D or P keys override and disable the active user input. The Totalizer continues to function including associated outputs independent of being displayed.

USEr-n

r-tot1

When activated (momentary action), rESEt flashes and the Totalizer resets

to zero. The Totalizer then continues to operate as it is configured. This selection functions independent of the selected display.

USEr-n

r-tot2

input is released, the Totalizer stops and holds its value. This selection functions independent of the selected display.

USEr-n

E-tot

independent of the selected display.

USEr-n

d-HI

keys override and disable the active user input. The Maximum continues to function independent of being displayed.

USEr-n

r-HI

When activated (momentary action), rESEt flashes and the Maximum resets

to the present Input Display value. The Maximum function then continues from that value. This selection functions independent of the selected display.

FNC

bAt

SELECT TOTALIZER DISPLAY

FNC

The Totalizer display appears on Line 2 as long as activated (maintained action). When the user input is released, the previously selected display is returned. The

RESET TOTALIZER

FNC

r-tot

RESET AND ENABLE TOTALIZER

FNC

When activated (momentary action), rESEt flashes and the Totalizer resets to zero. The Totalizer continues to operate while active (maintained action). When the user

ENABLE TOTALIZER

FNC

The Totalizer continues to operate while active (maintained action). When the user input is released, the Totalizer stops and holds its value. This selection functions

SELECT MAXIMUM DISPLAY

FNC

The Maximum display appears on Line 2 as long as activated (maintained). When the user input is released, the previously selected display is returned. The D or P

RESET MAXIMUM DISPLAY

FNC

r-HI

FNC

SELECT MINIMUM DISPLAY

FNC

USEr-n

d-Lo

keys override and disable the active user input. The Minimum continues to function independent of being displayed.

The Minimum display appears on Line 2 as long as activated (maintained). When the user input is released, the previously selected display is returned. The D or P

Page 16

RESET MINIMUM DISPLAY

USEr-n

r-Lo

When activated (momentary action), rESEt flashes and the Minimum resets

to the present Input Display value. The Minimum function then continues from that value. This selection functions independent of the selected display.

USEr-n

r-HL

When activated (momentary action), rESEt flashes and the Maximum and

Minimum readings are set to the present Input Display value. The Maximum and Minimum function then continues from that value. This selection functions independent of the selected display.

USEr-n

dISP

FNC

r-Lo

RESET MAXIMUM AND MINIMUM DISPLAY

FNC

r-HL

DISPLAY SELECT

FNC

When activated (momentary action), Line 2 advances to the next display that is not locked out from the Display Mode.

FNC

SELECT PARAMETER LIST

USEr-n

LISt

Two lists of input scaling points and setpoint values (including band and

deviation) are available. The two lists are named LISt-A and LISt-b. If a user input is used to select the list then LISt-A is selected when the user input is not active and LISt-b is selected when the user input is active (maintained action). If a front panel key is used to select the list then the list will toggle for each key press (momentary action). The display will only indicate which list is active when the list is changed. To program the values for LISt-A and LISt-b, first complete the programming of all the parameters. Exit programming and switch to the other list. Re-enter programming and enter the desired values for the input scaling points, setpoints, band, and deviation if used.

The following selections are functional only with a Setpoint plug-in card

installed.

FNC

LISt

SETPOINT SELECTIONS

r-1

- Reset Setpoint 1 (Alarm 1)

r-2 - Reset Setpoint 2 (Alarm 2) r-3 - Reset Setpoint 3 (Alarm 3) r-4 - Reset Setpoint 4 (Alarm 4) r-34 - Reset Setpoint 3 & 4 (Alarm 3 & 4) r-234 - Reset Setpoint 2, 3 & 4 (Alarm 2, 3 & 4) r-ALL - Reset All Setpoints (Alarms 1-4)

FNC

ADJUST DISPLAY INTENSITY

USEr-n

d-LEU

When activated (momentary action), the display intensity changes to the next

intensity level.

USEr-n

Color

FNC

d-LEU

CHANGE DISPLAY COLOR

FNC

When activated (momentary action), Line 1 will change color.

FNC

PRINT REQUEST

USEr-n

The meter issues a block print through the serial port when activated, and the

serial type is set to rLC. The data transmitted during a print request and the serial type is programmed in Module 7. If the user input is still active after the transmission is complete (about 100 msec), an additional transmission occurs. As long as the user input is held active, continuous transmissions occur.

FNC

Page 17

MOdule 3 - display paraMeTers (3-dISPLY)

Pro

3-dISPLY

GrEEN

Display

Color

Ln1

d-LEV

LOC

Line 2 MIN

Access

Color

Module 3 is the programming of the Main Display Loop, Parameter Display

Loop, Hidden Parameter Loop, and Full Programming lock-out. The large upper display line value is configured by the “LINE1” parameter. The Units mnemonic can be used to assign a custom display mnemonic to the upper display value. When in the Main Display Loop, the available Line 2 displays (items configured for d-rEd or d-ENt) can be consecutively read on lower display by repeatedly pressing the D key. A left justified 3 character mnemonic indicates which parameter value is being shown on the lower display. When in the Main Display Loop the User keys ! and @ function as programmed in Module 2.

The Parameter display loop items can be accessed by pressing the P key. To

edit a main display line item, that is configured as d-ENt, the P key is pushed and the unit enters a parameter edit mode in which the ! and @ key increments or decrements the value.

Full Programming Mode permits all parameters to be viewed and modified.

This Programming Mode can be locked with a security code and/or user input.

Display

Intensity

Ln2

dSP

LISt

LOC

Parameter

List A/B

Access

d-Cont

Display

Contrast

Ln2

dSP

Setpoint

Value

Access

PARAMETER MENU

INPUt

Line 1

Display

Ln2

dSP

UNItS

OFF

Units

Mnemonic

Ln2

bn-dn

LOC

Band and Deviation

Value Access

LINE 1

LOC

LINE 1 DISPLAY COLOR

Color

Ln1

GrEEN rEd OrANGE

GrEEN

Enter the desired Display Line 1 and programmable Units Display color.

DISPLAY INTENSITY LEVEL

d-LEV

dSP

0 to 4

Enter the desired Display Intensity Level (0-4) by using the arrow keys. The display will actively dim or brighten as the levels are changed. This parameter also appears in the Parameter Display Loop when enabled.

Pro

dSP

CoLor

LOC

Color

Access

ACCESS

Access

Line 2

YES

Ln2

d-LEV

LOC

Display

Intensity

Access

INPUt

LOC

Line 2 Input

Access

Ln2

tOtAL

Line 2 Total

d-Cont

LOC

Display

Contrast

Access

LOC

Access

Ln2

FUNCt

Aux User Functions

Access

LOC

Line 2 MAX

Access

Ln2

COdE

Security

Code

dSP

UNITS MNEMONIC

UNItS

dSP

OFF LISt

OFF

This parameter allows programming of the display mnemonics characters. Three individual characters may be selected from a preprogrammed list. The list includes:

_ A b C d E F G H I J K L N O P Q R S t U V Y Z 0 1 2

3 4 5 6 7 8 9 c e g h i n o q r u - ° blank

LINE 2 MAIN, SECONDARY & HIDDEN DISPLAY LOOP

ACCESSIBLE ITEMS

ACCESS

Ln2

NO YES

Select YES to program the display Line 2 accessible values. The default setting of NO bypasses the programming of these values to shorten the module.

All of the individual Line 2 settings are retained.

The following values can be made accessible on Line 2 of the Main (D key), Parameter (P key) and Hidden (P key following code entry) Display Loops.

Each of the following parameters can be configured for one of the following settings. Not all selections are available for each parameter.

SELECTION DESCRIPTION

LOC Not viewed on display line

d-rEd View in Main Display Loop. Cannot change or reset.

d-ENt View and change (reset) in Main Display Loop

P-rEd View in Parameter Display Loop. Cannot change or reset.

P-ENt View and change (reset) in Parameter Display Loop

HidE View and change in Hidden Parameter Display Loop

DISPLAY CONTRAST LEVEL

d-Cont

dSP

0 to 15

Enter the desired Display Contrast Level (0-15) by using the arrow keys. The display contrast / viewing angle will actively move up or down as the levels are changed. This parameter also appears in the Parameter Display Loop when enabled.

LINE 1 DISPLAY

LINE 1

dSP

INPUt

Select the value to be assigned to the primary or top line of the meter display.

INPUt totAL Hi Lo S1 S2 S3 S4 NONE

LINE 2 INPUT ACCESS

INPUt

Ln2

LOC d-rEd d-ENt

LOC

When configured for d-ENt, the Input value can be reset (tare) using a front

keypad sequence. To reset (tare), push the P key while viewing the Input value on Line 2. The display will show rEL NO. Press the ! key to select yYES and then press P key. The display will indicate rESEt and then advance to Parameter Display.

LINE 2 TOTAL ACCESS

totAL

Ln2

LOC d-rEd d-ENt

LOC

When configured for d-ENt, the Total value can be reset using a front keypad

sequence. To reset, push the P key while viewing the Total value on Line 2. The display will show r-tot NO. Press the ! key to select yYES and then press P key. The display will indicate rESEt and then advance to Parameter Display.

Page 18

LINE 2 MAX ACCESS

Ln2

LOC d-rEd d-ENt

LOC

When configured for d-ENt, the Max Display value can be reset using a front

keypad sequence. To reset, push the P key while viewing the Hi value on Line 2. The display will show r-Hi NO. Press the ! key to select yYES and then press

P key. The display will indicate rESEt and then advance to Parameter Display.

LINE 2 MIN ACCESS

Ln2

LOC d-rEd d-ENt

LOC

When configured for d-ENt, the Min Display value can be reset using a front

keypad sequence. To reset, push the P key while viewing the Lo value on Line 2. The display will show r-Lo NO. Press the ! key to select yYES and then press

P key. The display will indicate rESEt and then advance to Parameter Display.

LINE 2 PARAMETER LIST A/B ACCESS

LISt

Ln2

LOC

When configured for d-ENt, the Parameter list can be selected using a front

keypad sequence. To select, push the P key while viewing LISt x”. “x” will begin to flash, press the ! key to select “A” or “B” and then press P key. The selected Parameter List will become active and the display will advance to Parameter Display. See User Functions “Select Parameter List” for a description

of the list function. The Line 2 Parameter List provides a means of setting or viewing the active parameter list.

LOC d-rEd d-ENt P-rEd P-ENt HidE

LINE 2 USER FUNCTIONS ACCESSIBLE ITEMS

FUNCt

Ln2

YES NO

Select YES to display the following list of User functions that can be made

available at the end of the Parameter (P-ENt) or Hidden (HidE) display loops. The more critical and frequently used Functions should be first assigned to the User Inputs and User Function keys. If more functions are needed than what can be obtained with User Inputs, this feature will provide a means to provide that access. Refer to module 2, 2-FUNCt for a description of the function.

rEL bAt r-tot r-HI r-Lo r-HL r-1 r-2 r-3 r-4 r-34 r-234 r-ALL Print

PROGRAMMING SECURITY CODE

COdE

dSP

000 to 250

To activate either the Parameter or Hidden Parameter Display Loops, a

security code (1-250) must be entered. If a “0” security code is programmed, pressing the P key takes you directly to the Full Programming Mode.

The Security Code determines the programming mode and the accessibility

of programming parameters. This code can be used along with the Program Mode Lock-out (PLOC) in the User Input Function parameter (Module 2).

Two programming modes are available. Full Programming Mode allows all parameters to be viewed and modified. Parameter Display Loop mode provides access to those selected parameters, that can be viewed and/or modified without entering the Full programming mode.

The following chart indicates the levels of access based on various CodE and User Input PLOC settings.

LINE 2 SETPOINTS ACCESS

Ln2

LOC

When configured for d-ENt, the P key must be pressed to select the item for

change before the ! and @ keys will increment or decrement the value.

LINE 2 BAND/DEVIATION ACCESS

Ln2

bn-dn

LOC

When configured for d-ENt, the P key must be pressed to select the item for

change before the ! and @ keys will increment or decrement the value.

LINE 1 DISPLAY COLOR ACCESS

Ln2

Color

LOC d-rEd d-ENt P-rEd P-ENt HidE

LOC P-rEd P-ENt HidE

LOC

When configured for P-ENt, Line 1 Color can be selected in the Parameter

Display by using the ! and @ keys while viewing Color.

DISPLAY INTENSITY ACCESS

d-LEV

Ln2

LOC P-rEd P-ENt HidE

LOC

When configured for P-ENt, the display intensity can be selected in the

Parameter Display by using the ! and @

keys while viewing d-LEV.

SECURITY

USER INPUT

CODE

CONFIGURED

0 not PLOC ———— Full Programming Immediate Access

>0 not

PLOC

USER INPUT

STATE

PLOC ————

Active

Not Active Full Programming Immediate Access

Active

Not Active Full Programming Immediate Access

WHEN P KEY IS

PRESSED

Enter Parameter Display Loop

FULL PROGRAMMING

MODE ACCESS

After Parameter Display Loop with correct code # at

COdE prompt.

After Parameter Display Loop with correct code # at

COdE prompt.

No Access

DISPLAY CONTRAST ACCESS

d-Cont

Ln2

LOC P-rEd P-ENt HidE

LOC

When configured for P-ENt, the display contrast can be selected in the

Parameter Display by using the ! and @ keys while viewing d-Cont.

Page 19

MOdule 4 - seCOndary funCTiOn paraMeTers (4-SCNdrY)

PARAMETER MENU

Time

SEC

1.0

LO-AS

rEL

MIN Capture

Assignment

HI-t

MAX Capture

HI-AS

Pro

4-SCNdrY

HI-AS

rEL

MAX Capture

Assignment

MAX CAPTURE ASSIGNMENT

SEC

rEL AbS

SEC

rEL

Select the desired parameter that will be assigned to the Max Capture.

MAX CAPTURE DELAY TIME

HI-t

SEC

0.0 to 3275.0 seconds

1.0

When the Input Display is above the present MAX value for the entered delay time, the meter will capture that display value as the new MAX reading. A delay time helps to avoid false captures of sudden short spikes.

MIN CAPTURE ASSIGNMENT

LO-AS

SEC

rEL AbS

rEL

Select the desired parameter that will be assigned to the Min Capture.

Pro

SEC

LO-t

MIN Capture

LO-t

Time

SEC

1.0

SEC

dSP-t

Display

Update Rate

MIN CAPTURE TIME

0.0 to 3275.0 seconds

SEC

1.0

When the Input Display is below the present MIN value for the entered delay time, the meter will capture that display value as the new MIN reading. A delay time helps to avoid false captures of sudden short spikes.

DISPLAY UPDATE RATE

dSP-t

SEC

1 2 5 10 20

updates/second

This parameter configures the display update rate. It does not affect the response time of the setpoint output or analog output option cards.

Page 20

MOdule 5 - TOTalizer (inTeGraTOr) paraMeTers (5-totAL)

Pro

5-totAL

dECPNt

Decimal

The totalizer accumulates (integrates) the Input Display value using one of two modes. The first is using a time base. This can be used to compute a time temperature product. The second is through a user input or function key programmed for Batch (one time add on demand). This can be used to provide a readout of temperature integration, useful in curing and sterilization applications. If the Totalizer is not needed, its display can be locked-out and this module can be skipped during programming.

tOt

0.000

Point

PARAMETER MENU

MIN

tOt

SCLFAC

t bASE

Time Base Scale Factor Low Cut

TOTALIZER DECIMAL POINT

0.000

tOt

0 0.0 0.00 0.000 0.0000

dECPNt

For most applications, this matches the Input Display Decimal Point (dECPNt). If a different location is desired, refer to Totalizer Scale Factor.

TOTALIZER TIME BASE

t bASE

tOt

MIN

This is the time base used in Totalizer accumulations. If the Totalizer is being accumulated through a user input programmed for Batch, then this parameter does not apply.

SEC-seconds (/1) MIN -minutes (/60) hour-hours (/3600) dAY -days (/86400)

TOTALIZER SCALE FACTOR

SCLFAC

tOt

0.001 to 65.000

1.000

For most applications, the Totalizer reflects the same decimal point location and engineering units as the Input Display. In this case, the Totalizer Scale Factor is 1.000. The Totalizer Scale Factor can be used to scale the Totalizer to a value that is different than the Input Display. Common possibilities are:

1. Changing decimal point location (example tenths to whole)

2. Average over a controlled time frame.

Details on calculating the scale factor are shown later.

If the Totalizer is being accumulated through a user input programmed for Batch, then this parameter does not apply.

TOTALIZER LOW CUT VALUE

Lo Cut

tOt

-199999 to 999999

-1999.99

A low cut value disables Totalizer when the Input Display value falls below the value programmed.

TOTALIZER POWER UP RESET

PWrUP

tOt

NO - do not reset buffer YES - reset buffer

Pro

1.000

tOt

Lo Cut

-19999.9

Value

tOt

PWrUP

Power Up

Reset

tOt

TOTALIZER BATCHING

The Totalizer Time Base and scale factor are overridden when a user input or

function key is programmed for store batch (bAt). In this mode, when the user input or function key is activated, the Input Display reading is one time added to the Totalizer (batch). The Totalizer retains a running sum of each batch operation until the Totalizer is reset. This is useful in weighing operations, when the value to be added is not based on time but after a filling event.

TOTALIZER USING TIME BASE

Totalizer accumulates as defined by:

Input Display x Totalizer Scale Factor

Totalizer Time Base

Where:

Input Display - the present input reading Totalizer Scale Factor - 0.001 to 65.000 Totalizer Time Base - (the division factor of tbASE)

Example: The input reading is at a constant rate of 10.0 gallons per minute. The

Totalizer is used to determine how many gallons in tenths has flowed. Because the Input Display and Totalizer are both in tenths of gallons, the Totalizer Scale Factor is 1. With gallons per minute, the Totalizer Time Base is minutes (60). By placing these values in the equation, the Totalizer will accumulate every second as follows:

10.0 x 1.000 = 0.1667 gallon accumulates each second 60 This results in:

10.0 gallons accumulates each minute

600.0 gallons accumulates each hour

TOTALIZER SCALE FACTOR CALCULATION EXAMPLES

1. When changing the Totalizer Decimal Point (dECPNt) location from the

Input Display Decimal Point (dECPNt), the required Totalizer Scale Factor is multiplied by a power of ten.

Example: Input (dECPNt) = 0 Input (dECPNt) = 0.0 Input (dECPNt) = 0.00

Totalizer

dECPNt

x1000 0.001

2. To obtain an average reading within a controlled time frame, the selected Totalizer Time Base is divided by the given time period expressed in the same timing units.

Example: Average temperature per hour in a 4 hour period, the scale factor

would be 0.250. To achieve a controlled time frame, connect an external timer to a user input programmed for r-tot. The timer will control the start (reset) and the stopping (hold) of the totalizer.

Scale

Factor

0.0 10

0 1

x10 0.1

x100 0.01

Totalizer

Factor

dECPNt

0.00 10

0.0 1

0 0.1

x10 0.01

x100 0.001

Scale

Totalizer

dECPNt

Scale

Factor

100.000

10.00

0.10.0

0.010

0.001x10

The Totalizer can be reset to zero on each meter power-up by setting this

parameter to YES.

Page 21

MOdule 6 - seTpOinT OuTpuT paraMeTers (6-SEtPNt)

Pro

6-SEtPNt

SPt

SELECt

Setpoint

Select

Programming information contained in this manual supercedes all programming information included with the LDP6-CDS card.

ASSIGN

NONE

Setpoint

Assignment

ACtION

Setpoint

Output Action

PARAMETER MENU

LOGIC

nor

Output

Logic

SEtPNt

100

Setpoint

Value

rESEt

Auto

Reset Action

bn-dEV

SETPOINT SELECT

SELECt

SPt

NO S1 S2 S3 S4

Enter the setpoint (alarm output) to be programmed. The “n” in the following

parameters will reflect the chosen setpoint number. After the chosen setpoint is completely programmed, the display will return to NO. Repeat step for each setpoint to be programmed. The NO chosen at SELECt

SPt

, will return to Pro NO. The

number of setpoints available is setpoint output card dependent.

SETPOINT ASSIGNMENT

ASSIGN

NONE rEL AbS totAL

NONE

Selects the meter value to be used to trigger the Setpoint Alarm. The rEL

setting will cause the setpoint to trigger off of the relative (net) input value. The relative input value is the absolute input value that includes the Display Offset Value. The AbS setting will cause the setpoint to trigger off of the absolute (gross) input value. The absolute input value is based on Module 1 dISPLY and INPUt entries.

Setpoint Alarm Figures

With reverse output logic

rEv, the below alarm states are opposite.

Pro

Band/

Deviation

Value

StndbY

Setpoint Standby

Operation

HYStEr

Setpoint

Hysteresis

t-ON

On Time

Annun

nor

Setpoint

Annunciator

Delay

0.0

Color

NO CHG

Change

Color

t-OFF

Off Time

Delay

0.0

brnAct

Probe

Burn-out

Action

OFF

SETPOINT ACTION

ACtION

Enter the action for the selected setpoint (alarm output). See Setpoint Alarm

Figures for a visual detail of each action. The Setpoint Actions that pertains to the total is only active when the Setpoint Assignment is set to totAL.

NO Ab-HI Ab-LO AU-HI AU-LO dE-HI dE-LO bANd bNdIn totLo totHI

= No Setpoint Action

= Absolute high, with balanced hysteresis

= Absolute low, with balanced hysteresis

= Absolute high, with unbalanced hysteresis

= Absolute low, with unbalanced hysteresis

= deviation high, with unbalanced hysteresis

= deviation low, with unbalanced hysteresis

= Outside band, with unbalanced hysteresis

= Inside band, with unbalanced hysteresis

= Lower 6 digits of 9 digit Totalizer, with unbalanced hysteresis

= Upper 6 digits of 9 digit Totalizer, with unbalanced hysteresis

NO Ab-HI Ab-LO AU-HI AU-LO dE-HI dE-LO bANd bNdIn totLo totHI

Temperature

Input Only

SP + ½Hys

SP - ½Hys

ALARM STATE

Absolute High Acting (Balanced Hys) = Ab-HI

SP + ½Hys

SP - ½Hys

ALARM

STATE

Absolute Low Acting (Balanced Hys) = Ab-LO

SP - Hys

ALARM

STATE

Absolute High Acting (Unbalanced Hys) = AU-HI

This is also for Totalizer alarms: totLo, totHI

OFF

TRIGGER POINTS

OFF

Hys

SP + Hys

Hys

ALARM STATE

Absolute Low Acting (Unbalanced Hys) = AU-LO

SP + Dev

ALARM

STATE

Deviation High Acting (Dev > 0) = dE-HI

SP - Dev

ALARM

STATE

Deviation Low Acting (Dev > 0) = dE-LO

OFF

TRIGGER POINTS

OFF

Hys

OFF

Hys

OFF

SP + (-Dev)

ALARM

STATE

Deviation High Acting (Dev < 0) = dE-HI

SP + Bnd

SP - Bnd

ALARM

STATE

SP + Bnd

SP - Bnd

ALARM

STATE

OFF

Band Outside Acting = bANd

Band Inside Acting = bNdIn

OFF

TRIGGER POINTS

OFF

TRIGGER POINTS

OFF

TRIGGER POINTS

OFF

Hys

OFF

Hys

Page 22

SETPOINT VALUE

SEtPNt

-199999 to 999999

100

Enter desired setpoint alarm value. Setpoint values can also be entered in the

Display Mode during Program Lockout when the setpoint is programmed as ENt in Parameter Module 3. The decimal point position is determined by the Setpoint Assignment value.

BAND/DEVIATION VALUE

bn-dEV

-199999 to 999999

This parameter is only available in band and deviation setpoint actions. Enter desired setpoint band or deviation value. When the Setpoint Action is programmed for Band, this value can only be a positive value.

HYSTERESIS VALUE

HYStEr

1 to 65000

Enter desired hysteresis value. See Setpoint Alarm Figures for visual explanation of how setpoint alarm actions (balanced and unbalanced) are affected by the hysteresis. When the setpoint is a control output, usually balanced hysteresis is used. For alarm applications, usually unbalanced hysteresis is used. For unbalanced hysteresis modes, the hysteresis functions on the low side for high acting setpoints and functions on the high side for low acting setpoints. Note: Hysteresis eliminates output chatter at the switch point, while time delay can be used to prevent false triggering during process transient events.

ON TIME DELAY

t-ON

0.0 to 3275.0 seconds

0.0

Enter the time value in seconds that the alarm is delayed from turning on after the trigger point is reached. A value of 0.0 allows the meter to update the alarm status per the response time listed in the Specifications. When the output logic is rEv, this becomes off time delay. Any time accumulated at power-off resets during power-up.

OFF TIME DELAY

t-OFF

0.0 to 3275.0 seconds

0.0

Enter the time value in seconds that the alarm is delayed from turning off after the trigger point is reached. A value of 0.0 allows the meter to update the alarm status per the response time listed in the Specifications. When the output logic is rEv, this becomes on time delay. Any time accumulated at power-off resets during power-up.

OUTPUT LOGIC

LOGIC

nor rEv

nor

Enter the output logic of the alarm output. The nor logic leaves the output operation as normal. The rEv logic reverses the output logic. In rEv, the alarm states in the Setpoint Alarm Figures are reversed.

RESET ACTION

rESEt

Auto LAtCh1s LAtCh2

Auto

Enter the reset action of the alarm output. Auto = Automatic action; This action allows the alarm output to automatically

reset off at the trigger points per the Setpoint Action shown in Setpoint Alarm

Figures. The “on” alarm may be manually reset (off) immediately by a front

panel function key or user input.The alarm remains reset off until the trigger

point is crossed again. LAtCh1 = Latch with immediate reset action; This action latches the alarm

output on at the trigger point per the Setpoint Action shown in Setpoint Alarm

Figures. Latch means that the alarm output can only be turned off by front panel function key or user input manual reset, serial reset command or meter power cycle. When the user input or function key is activated (momentary or maintained), the corresponding “on” alarm output is reset immediately and remains off until the trigger point is crossed again. (Previously latched alarms will be off if power up Display Value is lower than setpoint value.)

LAtCh2 = Latch with delay reset action; This action latches the alarm output on

at the trigger point per the Setpoint Action shown in Setpoint Alarm Figures. Latch means that the alarm output can only be turned off by front panel function key or user input manual reset, serial reset command or meter power cycle. When the user input or function key is activated (momentary or maintained), the meter delays the event until the corresponding “on” alarm output crosses the trigger off point. (Previously latched alarms are off if power up Display Value is lower than setpoint value. During a power cycle, the meter erases a previous Latch 2 reset if it is not activated at power up.)

MANUAL RESET

SP - Hys

ALARM

STATE

StndbY

OFF



OFF



OFF



Setpoint Alarm Reset Actions

SETPOINT STANDBY OPERATION

OFF

NO YES

OFF

Hys

( Auto)

(LAtCh1)

(LAtCh2)

When YES, the alarm is disabled (after a power up) until the trigger point is

crossed. Once the alarm is on, the alarm operates normally per the Setpoint Action and Reset Mode.

SETPOINT ANNUNCIATOR

Annun

nor rEv FLASh OFF

nor

The OFF mode disables display setpoint annunciators. The nor mode

displays the corresponding setpoint annunciators of “on” alarm outputs. The rEv mode displays the corresponding setpoint annunciators of “off” alarms outputs. The FLASh mode flashes the corresponding setpoint annunciators of “on” alarm outputs.

LINE 1 CHANGE COLOR

Color

NO CHG

This parameter allows the Line 1 Display to change color, or alternate between two colors, when the alarm is activated. When multiple alarms are programmed to change color, the highest numbered active alarm (S4-S1) determines the display color.

The NO CHG selection will maintain the color displayed prior to the alarm activation. The LINE 1 selection sets the display to the Line 1 Display Color (Color), programmed in Module 3.

The following programming step is only available when Input Range in Module 1 is set for a temperature input (TC/RTD).

brnAct

NO CHG GrEEN OrANGE rEd GrnOrG rEdOrG rEdGrn LINE 1

PROBE BURN-OUT ACTION

OFF ON

OFF

Enter the probe burn-out action. In the event of a temperature probe failure (TC open; RTD open or short), the output can be programmed to be on or off.

Page 23

MOdule 7 - serial COMMuniCaTiOns paraMeTers (7-SErIAL)

PARAMETER MENU

OPt

Options

Pro

SRL

Pro

7-SErIAL

CONFIG

USB

Setup

SRL

tYPE

USb

Programming information contained in this manual supercedes all programming information included with the LDP6-CDC card.

MbASC

Comms

Type

SRL

bAUd

Baud Rate

38400

SRL

dAtA

Data Bit

SRL

PArItY

Parity Bit Meter

SRL

Addr

247

Address

SRL

dELAY

0.010

Transmit

Delay

SRL

Abrv

Abbreviated

Printing

SRL

USB SETUP

USb

SRL

CONFIG Port

CONFIG

CONFIG – Configures USB with settings required to operate with DP6-SOFT

configuration software. This will automatically internally configure the DP63100 to use ModBus RTU protocol, 38400 baud, 8 bits, and unit address of 247 when a USB cable is attached to DP63100 and PC. The serial port settings shown in 7- SErIAL (this module) will not change, or show this.

Port – Configures USB to utilize serial settings and protocol as configured in

“7- SErIAL” (this module).

COMMUNICATIONS TYPE

tYPE

SRL

MbASC

Select the desired communications protocol. Modbus is preferred as it provides access to all meter values and parameters. Since the Modbus protocol is included within the DP63100, the Modbus option card, LDP6-CDC4, should not be used. The LDP6-CDC1 (RS485), or LDP6-CDC2 (RS232) card should be used instead.

SRL

bAUd

38400

Set the baud rate to match the other serial communications equipment on the serial link. Normally, the baud rate is set to the highest value that all the serial equipment are capable of transmitting and receiving.

SRL

dAtA

MbASC - ModBus ASCII rLC - RLC Protocol (ASCII) Mbrtu - ModBus RTU

BAUD RATE

1200 4800 19200 2400 9600 38400

DATA BIT

7 8

Select either 7 or 8 bit data word lengths. Set the word length to match the other serial communications equipment on the serial link.

PARITY BIT

PArItY

SRL

NO EUEN Odd

Set the parity bit to match that of the other serial communications equipment on the serial link. The meter ignores the parity when receiving data and sets the parity bit for outgoing data. If no parity is selected with 7 bit word length, an additional stop bit is used to force the frame size to 10 bits.

METER UNIT ADDRESS

Addr

SRL

247

Select a Unit Address that does not match an address number of any other

equipment on the serial link.

SRL

dELAY

0 to 99 - RLC Protocol 1 to 247 - ModBus

TRANSMIT DELAY

0.000 to 0.250 seconds

0.010

Following a transmit value (“*” terminator) or Modbus command, the DP63100 will wait this minimum amount of time in seconds before issuing a serial response

The following programming steps are only available when Communications Type (

tYPE) is programmed for rLC.

ABBREVIATED PRINTING

Abrv

SRL

NO YES

Select YES for full print or Command T transmissions (meter address, mnemonics and parameter data) or NO for abbreviated print transmissions (parameter data only). This will affect all the parameters selected in the print options. If the meter address is 00, it will not be sent during a full transmission.

PRINT OPTIONS

OPt

SRL

NO YES

YES - Enters the sub-menu to select the meter parameters to appear during a print

request. For each parameter in the sub-menu, select YES for that parameter

information to be sent during a print request or NO for that parameter

information not to be sent. A print request is sometimes referred to as a block

print because more than one parameter information (meter address, mnemonics

and parameter data) can be sent to a printer or computer as a block.

DISPLAY DESCRIPTION

INPUt totAL HILO SPNt

Signal Input

Total Value

Max & Min

Setpoint Values

FACTORY

SETTING

YES

NO NO NO

MNEMONIC

INP

TOT

MAX, MIN

SP1-SP4

Page 24

serial COMMuniCaTiOns

The DP63100 supports serial communications using the optional serial communication cards or via the USB programming port located on the side of the unit. When USB is being used (connected), the serial communication card is disabled. When using the standard RS232 and RS485 option cards, the DP63100 supports both the RLC protocol and also supports ModBus communications. The ModBus option card should not be used with the DP63100, as the DP63100 internal ModBus protocol supports complete unit configuration, and is much more responsive.

USB

The USB programming port is primarily intended to be used to configure the DP63100 with the DP6-SOFT programming software. It can also, be used as a virtual serial communications port following installation of the DP63100 USB drivers that are supplied with the software. When the USB port is being used, i.e. the USB cable is connected between DP63100 and PC, all serial communications with the serial option card (if used) is disabled.

USB Cable type required: USB A to Mini-B (not supplied)

DP63100 CONFIGURATION USING DP6-SOFT AND USB

1. Install DP6-SOFT software.

2. Supply power to DP63100

3. Insure “USB” parameter in module 7-SERIAL, is set to “CONFIG” (factory

default setting).

4. Attach USB A – MiniB cable between PC and DP63100

5. Create a new (File, New) or open an existing DP63100 database within the

software.

6. Configure DP6-SOFT Link, Options to the serial port the communication

cable is attached (in Step 4).

SERIAL MODBUS COMMUNICATIONS

Modbus Communications requires that the Serial Communication Type Parameter (tYPE) be set to “Mbrtu” or “MbASC”.

DP63100 CONFIGURATION USING DP6-SOFT AND SERIAL COMMUNICATIONS CARD

1. Install DP6-SOFT software.

2. Install RS232 or RS485 card and connect communications cable from

DP63100 to PC.

3. Supply power to DP63100

4. Configure serial parameters in 7-SERIAL to Mbrtu, 38,400 baud, address 247.

5. Create a new (File, New) or open an existing DP63100 database within DP6-

SOFT.

6. Configure DP6-SOFT Link, Options to the serial port the comunication cable

is attached (in step 2).

SUPPORTED FUNCTION CODES

FC03: Read Holding Registers

1. Up to 32 registers can be requested at one time.

2. HEX <8000> is returned for non-used registers.

FC04: Read Input Registers

1. Up to 32 registers can be requested at one time.

2. Block starting point can not exceed register boundaries.

3. HEX <8000> is returned in registers beyond the boundaries.

4. Input registers are a mirror of Holding registers.

FC06: Preset Single Register

1. HEX <8001> is echoed back when attempting to write to a read only register.

2. If the write value exceeds the register limit (see Register Table), then that

response.

FC16: Preset Multiple Registers

1. No response is given with an attempt to write to more than 32 registers at a time.

2. Block starting point cannot exceed the read and write boundaries (40001-

41280).

3. If a multiple write includes read only registers, then only the write registers will change.

4. If the write value exceeds the register limit (see Register Table), then that register value changes to its high or low limit.

FC08: Diagnostics

The following is sent upon FC08 request:

Module Address, 08 (FC code), 04 (byte count), “Total Comms” 2 byte count, “Total Good Comms” 2 byte count, checksum of the string “Total Comms” is the total number of messages received that were addressed

to the DP63100. “Total Good Comms” is the total messages received by the DP63100 with good address, parity and checksum. Both counters are reset to 0 upon response to FC08 and at power-up.

FC17: Report Slave ID

The following is sent upon FC17 request:

RLC-DP63100 ab<0100h><20h><20h><10h> a = SP Card, “0”-No SP, “2” or “4” SP b = Linear Card “0” = None, “1” = Yes <0100> Software Version Number (1.00) <20h>Max Register Reads (32) <20h>Max Register Writes (32) <10h> Number Guid/Scratch Pad Regs (16)

SUPPORTED EXCEPTION CODES

01: Illegal Function

Issued whenever the requested function is not implemented in the meter.

02: Illegal Data Address

Issued whenever an attempt is made to access a single register that does not

exist (outside the implemented space) or to access a block of registers that falls completely outside the implemented space.

03: Illegal Data Value

Issued when an attempt is made to read or write more registers than the meter

can handle in one request.

07: Negative Acknowledge

Issued when a write to a register is attempted with an invalid string length.

Page 25

The below limits are shown as Integers or HEX < > values. Read and write functions can be performed in either Integers or Hex as long as the conversion was done

DP63100 MODBUS REGISTER TABLE

correctly. Negative numbers are represented by two’s complement.

Note 1: The DP63100 should not be powered down while parameters are being changed. Doing so may corrupt the non-volatile memory resulting in checksum

errors.

ADDRESS

FREQUENTLY USED REGISTERS

40001 Input Relative Value (Hi word)

40002 Input Relative Value (Lo word)

40003 Maximum Value (Hi word)

40004 Maximum Value (Lo word)

40005 Minimum Value (Hi word)

40006 Minimum Value (Lo word)

40007 Total Value (Hi word)

40008 Total Value (Lo word)

40009 Setpoint 1 Value (Hi word)

40010 Setpoint 1 Value (Lo word)

40011 Setpoint 2 Value (Hi word)

40012 Setpoint 2 Value (Lo word)

40013 Setpoint 3 Value (Hi word)

40014 Setpoint 3 Value (Lo word)

40015 Setpoint 4 Value (Hi word)

40016 Setpoint 4 Value (Lo word)

40017 Setpoint 1 Band/Dev. Value (Hi word)

40018 Setpoint 1 Band/Dev. Value (Lo word)

40019 Setpoint 2 Band/Dev. Value (Hi word)

40020 Setpoint 2 Band/Dev. Value (Lo word)

40021 Setpoint 3 Band/Dev. Value (Hi word)

40022 Setpoint 3 Band/Dev. Value (Lo word)

40023 Setpoint 4 Band/Dev. Value (Hi word)

40024 Setpoint 4 Band/Dev. Value (Lo word)

40025 Setpoint Output Register (SOR) 0 15 N/A Read/Write

40026 Manual Mode Register (MMR) 0 31 0 Read/Write

40027 Reset Output Register 0 15 0 Read/Write

40028 Analog Output Register (AOR) 0 4095 0 Read/Write

40029 Input Absolute Value (Hi word)

40030 Input Absolute Value (Lo word)

40031 Input Offset Value (Hi word)

40032 Input Offset Value (Lo word)

INPUT PARAMETERS SEE MODULE 1 FOR PARAMETER DESCRIPTIONS

40081 Input Range 0 26 10 Read/Write

40082 Temperature Scale (TC or RTD only) 0 1 1 Read/Write 0 = °C, 1 = °F

40083 Ice Point Compensation (TC only) 0 1 1 Read/Write 0 = Off, 1 = On

40084 ADC Conversion Rate (samples/sec) 0 5 0 Read/Write 0 = 5, 1 = 10, 2 = 20, 3 = 40, 4 = 80, 5 = 160

40085 Decimal Point 0 4 2 Read/Write 0 = 0, 1 = 0.0, 2 = 0.00, 3 = 0.000, 4 = 0.0000

40086 Rounding Factor 0 6 0 Read/Write 0 = 1, 1 = 2, 2 = 5, 3 = 10, 4 = 20, 5 = 50, 6 = 100

40087 Digital Input Filter 0 250 10 Read/Write 1 = 0.1 Second

40088 Filter Band 0 250 10 Read/Write 1 = 1 display unit

40089 Input Scaling Points in List Function 0 1 0 Read/Write 0 = No, 1 = Yes

List A List B Input Scaling Points Parameters

40101 40201 Number of Scaling Points 2 16 2 Read/Write Number of Linearization Scaling Points

40102 40202 Reserved N/A N/A N/A N/A

40103 40203 Scaling Pt.1 Input Value (Hi word)

40104 40204 Scaling Pt.1 Input Value (Lo word)

N/A N/A N/A Read Only

-199999 999999 N/A Read/Write

-199999999 999999999 N/A Read/Write

-199999 999999 100 Read/Write Active List (A or B)

-199999 999999 200 Read/Write Active List (A or B)

-199999 999999 300 Read/Write Active List (A or B)

-199999 999999 400 Read/Write Active List (A or B)

-199999 999999 0 Read/Write

N/A N/A N/A Read Only

-199999 999999 0 Read/Write

-199999 999999 0 Read/Write 1 = 1 in least significant digit (Input Range dependant)

FACTORY

SETTING

ACCESS COMMENTS

Process value of present input level. This value is affected by Input Type, Resolution, Scaling, & Offset Value. (Relative Value = Absolute Input Value + Offset Value)

Active List (A or B). Applicable only for Band or Deviation Setpoint Action.

Status of Setpoint Outputs. Bit State: 0 = Off, 1 = On. Bit 3 = S1, Bit 2 = S2, Bit 1 = S3, Bit 0 = S4. Outputs can only be activated/reset with this register when the respective bits in the Manual Mode Register (MMR) are set.

Bit State: 0 = Auto Mode, 1 = Manual Mode Bit 4 = S1, Bit 3 = S2, Bit 2 = S3, Bit 1 = S4, Bit 0 = Linear Output

Bit State: 1 = Reset Output, bit is returned to zero following reset processing; Bit 3 = S1, Bit 2 = S2, Bit 1 = S3, Bit 0 = S4

Linear Output Card written to only if Linear Output is in Manual Mode.(MMR bit 0 = 1)

Gross value of present Input level. This value is affected by Input Type, Resolution, Scaling, but not affected by Offset Value

Input Offset Value plus the Input Absolute Value equals the Relative Input Value (standard meter value).

0 = 250µA 5 = 250mV 11 = 100Ω 17 = TC-K 23 = RTD 385 1 = 2.5mA 6 = 2V 12 = 1KΩ 18 = TC-R 24 = RTD 392 2 = 25mA 7 = 10V 13 = 10KΩ 19 = TC-S 25 = RTD 672 3 = 250mA 8 = 25V 14 = TC-T 20 = TC-B 26 = RTD 427 4 = 2A 9 = 100V 15 = TC-E 21 = TC-N 10 = 200V 16 = TC-J 22 = TC-C

Page 26

40105 40205 Scaling Pt.1 Display Value (Hi word)

40106 40206 Scaling Pt.1 Display Value (Lo word)

-199999 999999 0 Read/Write 1 = 1 display unit (disregard decimal point)

FACTORY

SETTING

ACCESS COMMENTS

Registers 40107-40162 and 40207-40262 hold values

thru thru Scaling Pts. 2 thru 15 Values … … … …

for Scaling Points 2 thru 15, and follow the same ordering as Scaling Point 1.

40163 40263 Scaling Pt.16 Input Value (Hi word)

40164 40264 Scaling Pt.16 Input Value (Lo word)

40165 40265 Scaling Pt.16 Display Value (Hi word)

40166 40266 Scaling Pt.16 Display Value (Lo word)

-199999 999999 0 Read/Write 1 = 1 in least significant digit (Input Range dependant)

-199999 999999 0 Read/Write 1 = 1 display unit (disregard decimal point)

List A List B Setpoint Values

40167 40267 Setpoint 1 Value (Hi word)

40168 40268 Setpoint 1 Value (Lo word)

40169 40269 Setpoint 2 Value (Hi word)

40170 40270 Setpoint 2 Value (Lo word)

40171 40271 Setpoint 3 Value (Hi word)

40172 40272 Setpoint 3 Value (Lo word)

40173 40273 Setpoint 4 Value (Hi word)

40174 40274 Setpoint 4 Value (Lo word)

40175 40275 Setpoint 1 Band/Dev. Value (Hi word)

40176 40276 Setpoint 1 Band/Dev. Value (Lo word)

40177 40277 Setpoint 2 Band/Dev. Value (Hi word)

40178 40278 Setpoint 2 Band/Dev. Value (Lo word)

40179 40279 Setpoint 3 Band/Dev. Value (Hi word)

40180 40280 Setpoint 3 Band/Dev. Value (Lo word)

40181 40281

Setpoint 4 Band/Dev. Value (Hi word)

40182 40282 Setpoint 4 Band/Dev. Value (Lo word)

-199999 999999 100 Read/Write 1 = 1 display unit (disregard decimal point)

-199999 999999 200 Read/Write 1 = 1 display unit (disregard decimal point)

-199999 999999 300 Read/Write 1 = 1 display unit (disregard decimal point)

-199999 999999 400 Read/Write 1 = 1 display unit (disregard decimal point)

-199999 999999 0 Read/Write Applicable only for Band or Deviation Setpoint Action.

USER INPUT / FUNCTION KEYS SEE MODULE 2 FOR PARAMETER DESCRIPTIONS

40301 User Input Active State 0 1 0 Read/Write 0 = Active Low, 1 = Active High

0 = NO 8 = d-tot 16 = r-HL 24 = r-4 1 = PLOC 9 = r-tot1 17 = dISP 25 = r-34 2 = rEL 10 = r-tot2 18 = d-LEV 26 = r-234

40302 User Input 1 Action 0 28 0 Read/Write

3 = d-rEL 11 = E-tot 19 = Color 27 = r-ALL 4 = d-HLd 12 = d-HI 20 = LISt 28 = Print 5 = A-HLd 13 = r-HI 21 = r-1 6 = SYNC 14 = d-Lo 22 = r-2 7 = bAt 15 = r-Lo 23 = r-3

40303 User Input 2 Action 0 28 0 Read/Write Same as User Input 1 Action

0 = NO 5 = r-HI 10 = r-1 15 = r-234 1 = rEL 6 = r-Lo 11 = r-2 16 = r-ALL

40304 User F1 Key Action 0 17 0 Read/Write

2 = d-rEL 7 = r-HL 12 = r-3 17 = Print 3 = bAt 8 = d-LEV 13 = r-4 4 = r-tot 9 = LISt 14 = r-34

40305 User F2 Key Action 0 17 0 Read/Write Same as User F1 Key Action

40306 User F1 Second Action 0 17 0 Read/Write Same as User F1 Key Action

40307 User F2 Second Action 0 17 0 Read/Write Same as User F1 Key Action

DISPLAY PARAMETERS SEE MODULE 3 FOR PARAMETER DESCRIPTIONS

40331 Line 1 Display Color 0 2 0 Read/Write 0 = Green, 1 = Red, 2 = Orange

40332 Display Intensity Level 0 4 4 Read/Write 0 = Min.(off), 4 = Max.

40333 Display Contrast Level 0 15 7 Read/Write

40334 Line 1 Display 0 8 1 Read/Write

0 = None, 1 = Input, 2 = Total, 3 = Hi, 4 = Lo, 5 = S1, 6 = S2, 7 = S3, 8 = S4

40335 Units Mnemonic 0 1 0 Read/Write 0 = Off, 1 = List

0 = _ 7 = G 14 = O 21 = V 28 = 4 35 = e 42 = r 1 = A

8 = H 15 = P 22 = Y 29 = 5 36 = g 43 = u

2 = b

9 = I 16 = Q 23 = Z 30 = 6 37 = h 44 = -

3 = C

40336 Units Digit 1 (Left) 0 46 0 Read/Write

10 = J 17 = R 24 = 0 31 = 7 38 = i 45 = °

4 = d

11 = K 18 = S 25 = 1 32 = 8 39 = n 46 =

5 = E

12 = L 19 = t 26 = 2 33 = 9 40 = o

6 = F 13 = N 20 = U 27 = 3 34 = c 41 = q

40337 Units Digit 2 (Center) 0 46 0 Read/Write Same selections as Digit 1

40338 Units Digit 3 (Right) 0 46 0 Read/Write Same selections as Digit 1

40339 Line 2 Input Display Access 0 2 0 Read/Write 0=LOC, 1=d-rEd, 2=d-Ent

40340 Line 2 Totalizer Display Access 0 2 0 Read/Write 0=LOC, 1=d-rEd, 2=d-Ent

40341 Line 2 Maximum (Hi) Value Access 0 2 0 Read/Write 0=LOC, 1=d-rEd, 2=d-Ent

40342 Line 2 Minimum (Lo) Value Access 0 2 0 Read/Write 0=LOC, 1=d-rEd, 2=d-Ent

40343 Line 2 List Selection Access 0 5 0 Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE

40344 Line 2 Setpoint 1 Value Access 0 5 0 Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE

40345 Line 2 S1 Band/Dev. Value Access 0 5 0 Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE

40346 Line 2 Setpoint 2 Value Access 0 5 0 Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE

40347 Line 2 S2 Band/Dev.Value Access 0 5 0 Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE

Page 27

ADDRESS

FACTORY

SETTING

ACCESS COMMENTS

40348 Line 2 Setpoint 3 Value Access 0 5 0 Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE

40349 Line 2 S3 Band/Dev.Value Access 0 5 0 Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE

40350 Line 2 Setpoint 4 Value Access 0 5 0 Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE

40351 Line 2 S4 Band/Dev.Value Access 0 5 0 Read/Write 0=LOC, 1=d-rEd, 2=d-ENt, 3=P-rEd, 4=P-ENt, 5=HidE

40352 Reserved N/A N/A N/A N/A

40353 Reserved N/A N/A N/A N/A

40354 Reserved N/A N/A N/A N/A

40355 Reserved N/A N/A N/A N/A

40356 Line 2 Display Color Access 0 3 0 Read/Write 0=LOC, 1=P-rEd, 2=P-ENt, 3=HidE

40357 Line 2 Display Intensity Level Access 0 3 0 Read/Write 0=LOC, 1=P-rEd, 2=P-ENt, 3=HidE

40358 Line 2 Display Contrast Level Access 0 3 0 Read/Write 0=LOC, 1=P-rEd, 2=P-ENt, 3=HidE

40359 Line 2 Zero (Tare) Display Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40360 Line 2 Batch Input to Totalizer Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40361 Line 2 Reset Totalizer Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40362 Line 2 Reset Max (Hi) Display Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40363 Line 2 Reset Min (Lo) Display Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40364 Line 2 Reset Max and Min Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40365 Line 2 Reset Alarm 1 Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40366 Line 2 Reset Alarm 2 Access 0

2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40367 Line 2 Reset Alarm 3 Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40368 Line 2 Reset Alarm 4 Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40369 Line 2 Reset Alarm 3 and 4 Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40370 Line 2 Reset Alarm 2, 3 and 4 Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40371 Line 2 Reset All Alarms (1-4) Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40372 Line 2 Print Request Access 0 2 0 Read/Write 0=LOC, 1=P-ENt, 2=HidE

40373 Line 2 Security Code Value 0 250 0 Read/Write

SECONDARY PARAMETERS SEE MODULE 4 FOR PARAMETER DESCRIPTIONS

40381 Max (Hi) Capture Value Assignment 0 1 0 Read/Write 0 = Relative, 1 = Absolute

40382 Max (Hi) Capture Delay Time 0 32750 10 Read/Write 0 = Max Update Rate, 1 = 0.1Sec

40383 Min (Lo) Capture Value Assignment 0 1 0 Read/Write 0 = Relative, 1 = Absolute

40384 Min (Lo) Capture Delay Time 0 32750 10 Read/Write 0 = Max Update Rate, 1 = 0.1Sec

40385 Display Update (readings per second) 0 4 0 Read/Write 0 = 1, 1 = 2, 2 = 5, 3 = 10, 4 = 20

TOTALIZER PARAMETERS SEE MODULE 5 FOR PARAMETER DESCRIPTIONS

40391 Totalizer Decimal Point 0 4 3 Read/Write 0 = 0, 1 = 0.0, 2 = 0.00, 3 = 0.000, 4 = 0.0000

40392 Totalizer Time Base 0 3 1 Read/Write 0 = Second, 1 = Minute, 2 = Hour, 3 = Day

40393 Totalizer Scale Factor 1 65000 1000 Read/Write 1 = 0.001

40394 Totalizer Reset at Power Up 0 1 0 Read/Write 0 = No, 1 = Yes

40395 Totalizer Low Cut Value (Hi word)

40396 Totalizer Low Cut Value (Lo word)

-199999 999999 -199999 Read/Write

SETPOINT PARAMETERS SEE MODULE 6 FOR PARAMETER DESCRIPTIONS

Setpoint 1

40401 Assignment 0

40402 Action 0 10 0 Read/Write

3 0 Read/Write 0 = None, 1 = Rel, 2 = Abs, 3 = Total

0=No, 1=Ab-HI, 2=Ab-LO, 3=AU-HI, 4=AU-LO, 5=dEHI, 6=dE-LO, 7=bANd, 8=bNdIn, 9=totLo, 10=totHI

40403 Hysteresis Value 1 65000 2 Read/Write 1 = 1 Display Unit

40404 On Time Delay 0 32750 0 Read/Write 1 = 0.1 Second

40405 Off Time Delay 0 32750 0 Read/Write 1 = 0.1 Second

40406 Output Logic 0 1 0 Read/Write 0 = Normal, 1 = Reverse

40407 Reset Action 0 2 0 Read/Write 0 = Auto, 1 = Latch1, 2 = Latch2

40408 Standby Operation 0 1 0 Read/Write 0 = No, 1 = Yes

40409 Annunciator 0 3 1 Read/Write 0 = Off, 1 = Normal, 2 = Reverse, 3 = Flash

0 = No Change, 1 = Green, 2 = Orange, 3 = Red,

40410 Color 0 7 0 Read/Write

4 = Grn/Org, 5 = Red/Org, 6 = Red/Grn, 7 = Line 1 Color

40411 Probe Failure Action (TC or RTD only) 0 1 0 Read/Write 0 = Off, 1 = On (only applies for TC or RTD input)

Setpoint 2

40421 Assignment 0 3 0 Read/Write 0 = None, 1 = Rel, 2 = Abs, 3 = Total

40422 Action 0 10 0 Read/Write

0=No, 1=Ab-HI, 2=Ab-LO, 3=AU-HI, 4=AU-LO, 5=dEHI, 6=dE-LO, 7=bANd, 8=bNdIn, 9=totLo, 10=totHI

40423 Hysteresis Value 1 65000 2 Read/Write 1 = 1 Display Unit

40424 On Time Delay 0 32750 0 Read/Write 1 = 0.1 Second

40425 Off Time Delay 0 32750 0 Read/Write 1 = 0.1 Second

40426 Output Logic 0 1 0 Read/Write 0 = Normal, 1 = Reverse

40427 Reset Action 0 2 0 Read/Write 0 = Auto, 1 = Latch1, 2 = Latch2

Page 28

FACTORY

SETTING

ACCESS COMMENTS

40428 Standby Operation 0 1 0 Read/Write 0 = No, 1 = Yes

40429 Annunciator 0 3 1 Read/Write 0 = Off, 1 = Normal, 2 = Reverse, 3 = Flash

0 = No Change, 1 = Green, 2 = Orange, 3 = Red,

40430 Color 0 7 0 Read/Write

4 = Grn/Org, 5 = Red/Org, 6 = Red/Grn, 7 = Line 1 Color

40431 Probe Failure Action (TC or RTD only) 0 1 0 Read/Write 0 = Off, 1 = On (only applies for TC or RTD input)

Setpoint 3

40441 Assignment 0 3 0 Read/Write 0 = None, 1 = Rel, 2 = Abs, 3 = Total

40442 Action 0 10 0 Read/Write

0=No, 1=Ab-HI, 2=Ab-LO, 3=AU-HI, 4=AU-LO, 5=dEHI, 6=dE-LO, 7=bANd, 8=bNdIn, 9=totLo, 10=totHI

40443 Hysteresis Value 1 65000 2 Read/Write 1 = 1 Display Unit

40444 On Time Delay 0 32750 0 Read/Write 1 = 0.1 Second

40445 Off Time Delay 0 32750 0 Read/Write 1 = 0.1 Second

40446 Output Logic 0 1 0 Read/Write 0 = Normal, 1 = Reverse

40447 Reset Action 0 2 0 Read/Write 0 = Auto, 1 = Latch1, 2 = Latch2

40448 Standby Operation 0 1 0 Read/Write 0 = No, 1 = Yes

40449 Annunciator 0 3 1 Read/Write 0 = Off, 1 = Normal, 2 = Reverse, 3 = Flash

0 = No Change, 1 = Green, 2 = Orange, 3 = Red,

40450 Color 0 7 0 Read/Write

4 = Grn/Org, 5 = Red/Org, 6 = Red/Grn, 7 = Line 1 Color

40451 Probe Failure Action (TC or RTD only) 0 1 0 Read/Write 0 = Off, 1 = On (only applies for TC or RTD input)

Setpoint 4

40461 Assignment 0 3 0 Read/Write 0 = None, 1 = Rel, 2 = Abs, 3 = Total

40462 Action

0 10 0 Read/Write

0=No, 1=Ab-HI, 2=Ab-LO, 3=AU-HI, 4=AU-LO, 5=dEHI, 6=dE-LO, 7=bANd, 8=bNdIn, 9=totLo, 10=totHI

40463 Hysteresis Value 1 65000 2 Read/Write 1 = 1 Display Unit

40464 On Time Delay 0 32750 0 Read/Write 1 = 0.1 Second

40465 Off Time Delay 0 32750 0 Read/Write 1 = 0.1 Second

40466 Output Logic 0 1 0 Read/Write 0 = Normal, 1 = Reverse

40467 Reset Action 0 2 0 Read/Write 0 = Auto, 1 = Latch1, 2 = Latch2

40468 Standby Operation 0 1 0 Read/Write 0 = No, 1 = Yes

40469 Annunciator 0 3 1 Read/Write 0 = Off, 1 = Normal, 2 = Reverse, 3 = Flash

0 = No Change, 1 = Green, 2 = Orange, 3 = Red,

40470 Color 0 7 0 Read/Write

4 = Grn/Org, 5 = Red/Org, 6 = Red/Grn, 7 = Line 1 Color

40471 Probe Failure Action (TC or RTD only) 0 1 0 Read/Write 0 = Off, 1 = On (only applies for TC or RTD input)

SERIAL COMMUNICATIONS PARAMETERS SEE MODULE 7 FOR PARAMETER DESCRIPTIONS

40481 USB Mode 0 1 0 Read/Write 0 = Configuration, 1 = Port

40482 Type 0 2 2 Read/Write

0 = RLC Protocol (ASCII), 1 = Modbus RTU, 2 = Modbus ASCII

40483 Baud Rate 0 5 5 Read/Write 0=1200, 1=2400, 2=4800, 3=9600, 4=19200, 5=38400

40484 Data Bits 0 1 1 Read/Write 0 = 7 Bits, 1 = 8 Bits

40485 Parity 0 2 0 Read/Write 0 = None, 1 = Even, 2 = Odd

40486 Address

0 99

1 247 Modbus: 1-247

247 Read/Write

RLC Protocol: 0-99

40487 Transmit Delay 0 250 10 Read/Write 1 = 0.001 Second

40488 Abbreviated Transmission (RLC only) 0 1 0

Read/Write

0 = No, 1 = Yes (Not used when communications type is Modbus)

0 = No, 1 = Yes (Not used when communications type

40489 Print Options (RLC only) 0 15 1 Read/Write

is Modbus) Bit 0 – Print Input Value, Bit 1 – Print Total Value, Bit 2 – Print Max & Min Values, Bit 3 – Print Setpoint Values

Changing 40481-40487 will not update the DP63100

40490 Load Serial Settings 0 1 0 Read/Write

until this register is written with a 1. After the write, the communicating device must be changed to new DP63100 settings and this register returns to 0.

ANALOG OUTPUT PARAMETERS SEE MODULE 8 FOR PARAMETER DESCRIPTIONS

40491 Type 0 2 1 Read/Write 0 = 0-20 mA, 1 = 4-20 mA, 2 = 0-10 V

40492 Assignment 0 9 0 Read/Write

40493 Analog Low Scale Value (Hi word)

40494 Analog Low Scale Value (Lo word)

40495 Analog High Scale Value (Hi word)

40496 Analog High Scale Value (Lo word)

-199999 999999 0 Read/Write

-199999 999999 10000 Read/Write

0=NONE, 1=rEL, 2=AbS, 3=tOtAL, 4=HI, 5=LO, 6=S1, 7=S2, 8=S3, 9=S4

Display value that corresponds with 0 V, 0 mA or 4 mA output

Display value that corresponds with 10 V or 20 mA output

40497 Update time 0 100 0 Read/Write 0 = Max update rate, 1 = 0.1 Second

40498 Probe Failure Action (TC or RTD only) 0 1 0 Read/Write

0 = Low Scale, 1 = High Scale (only applies for TC or RTD input)

Page 29

ADDRESS

FACTORY SERVICE

40501-40506 Factory Service Registers N/A N/A N/A Read/Write Factory Use Only - Do Not Modify

41001-41010 Slave ID N/A N/A N/A Read Only

41101-41116 GUID/Scratch N/A N/A N/A Read/Write Reserved (may be used in future software)

FACTORY

SETTING

ACCESS COMMENTS

RLC-DP63100 <a><b><0100h><0020h><0020h><001

0h>

<a> = SP Card Status. “0”-No Card, “2”-Dual SP,

“4”-Quad SP

<b> = Linear Card Status. “0”-Not Installled,

“1”-Installed <0100h> = Version Number (1.00 or higher) <0020h><0020h> = 32 Register Writes, 32 Register

Reads (Max.) <0010h> = 16 Register GUID/Scratch

SERIAL RLC PROTOCOL COMMUNICATIONS

RLC Communications requires the Serial Communications Type Parameter

(tYPE) be set to “rLC”.

SENDING SERIAL COMMANDS AND DATA TO THE METER

When sending commands to the meter, a string containing at least one command character must be constructed. A command string consists of a command character, a value identifier, numerical data (if writing data to the meter) followed by a command terminator character * or $.

Command Chart

COMMAND DESCRIPTION NOTES

N Node Address

Specifier

T Transmit Value

(read)

V Value Change

(write )

R Reset Reset a register or output. Must be followed by

P Block Print

Request

Command String Construction

The command string must be constructed in a specific sequence. The meter does not respond with an error message to invalid commands. The following procedure details construction of a command string:

1. The first characters consist of the Node Address Specifier (N) followed by a

1 or 2 character address number. The address number of the meter is

programmable. If the node address is 0, this command and the node address

itself may be omitted. This is the only command that may be used in

conjunction with other commands.

2. After the address specifier, the next character is the command character.

3. The next character is the Register ID. This identifies the register that the

command affects. The P command does not require a Register ID character.

It prints according to the selections made in print options.

4. If constructing a value change command (writing data), the numeric data is

sent next.

5. All command strings must be terminated with the string termination

characters * or $. The meter does not begin processing the command string

until this character is received. See Timing Diagram figure for differences

between terminating characters.

Address a specific meter. Must be followed by a one or two digit node address. Not required when address = 0.

Read a register from the meter. Must be followed by register ID character

Write to register or output. Must be followed by register ID character and numeric data.

Initiates a block print output. Registers are defined in programming.

A Input (relative

B Total TOT T, P, R (Reset command resets total

C Max Input MAX T, P, R (Reset command resets Max

D Min Input MIN T, P, R (Reset command resets Min

E Setpoint 1 SP1 T, P, V, R (Reset command resets

F Setpoint 2 SP2

G Setpoint 3 SP3

H Setpoint 4 SP4

I Band/Deviation 1 BD1 T, V

J Band/Deviation 2 BD2 T, V

K Band/Deviation 3 BD3 T, V

L Band/Deviation 4 BD4 T, V

M Absolute Input

O Offset OFS T, V

U Auto/Manual

W Analog Output

X Setpoint Register SOR T, V

VALUE

DESCRIPTION

value)

value

MNEMONIC APPLICABLE COMMANDS/COMMENTS

INP T, P, R (Reset command resets input

to zero; tares)

to zero)

to current reading)

the setpoint output)

ABS T

MMR T, V

AOR T, V

Command String Examples:

1. Node address = 17, Write 350 to Setpoint 1. String: N17VE350$

2. Node address = 5, Read Input value. String: N5TA*

3. Node address = 0, Reset Setpoint 4 output. String: RH*

Sending Numeric Data

Numeric data sent to the meter must be limited to 6 digits (-199999 to

999999). Leading zeros are ignored. Negative numbers must have a minus sign.

The meter ignores any decimal point and conforms the number to the scaled resolution. (For example: the meter’s scaled decimal point position = 0.0 and 25 is written to a register. The value of the register is now 2.5.

Note: Since the meter does not issue a reply to value change commands, follow

with a transmit value command for readback verification.

Page 30

RECEIVING DATA FROM THE METER

Data is transmitted by the meter in response to either a transmit command (T), a print block command (P) or User Function print request. The response from the meter is either a full field transmission or an abbreviated transmission. The meter response mode is selected in program Module 7 (Abrv).

Full Field Transmission (Address, Mnemonic, Numeric data)

Byte Description

1, 2 2 byte Node Address field [00-99] 3 <SP> (Space) 4-6 3 byte Register Mnemonic field 7-18 2 byte data field, 10 bytes for number, one byte for sign, one byte for decimal point 19 <CR> carriage return 20 <LF> line feed 21 <SP>* (Space) 22 <CR>* carriage return 23 <LF>* line feed

* These characters only appear in the last line of a block print.

The first two characters transmitted are the node address, unless the node address assigned = 0, in which case spaces are substituted. A space follows the node address field. The next three characters are the register mnemonic.

The numeric data is transmitted next. The numeric field is 12 characters long (to accommodate the 10 digit totalizer), with the decimal point position floating within the data field. Negative values have a leading minus sign. The data field is right justified with leading spaces.

The end of the response string is terminated with a carriage return <CR> and <LF>. When block print is finished, an extra <SP><CR> <LF> is used to provide separation between the blocks.

Abbreviated Transmission (Numeric data only)

Byte Description

1-12 12 byte data field, 10 bytes for number, one byte for sign, one byte for decimal point 13 <CR> carriage return 14 <LF> line feed 15 <SP>* (Space) 16 <CR>* carriage return 17 <LF>* line feed

* These characters only appear in the last line of a block print.

Meter Response Examples:

1. Node address = 17, full field response, Input = 875

17 INP 875 <CR><LF>

2. Node address = 0, full field response, Setpoint 2 = -250.5

SP2 -250.5<CR><LF>

3. Node address = 0, abbreviated response, Setpoint 2 = 250, last line of block

250<CR><LF><SP><CR><LF>

Analog Output Register (AOR) ID: W

This register stores the present signal value of the analog output. The range of values of this register is 0 to 4095, which corresponds to the analog output range per the following chart:

Value

0 0.00 4.00 0.000

1 0.005 4.004 0.0025

2047 10.000 12.000 5.000

4094 19.995 19.996 9.9975

4095 20.000 20.000 10.000

Output Signal*

0-20 mA 4-20 mA 0-10 V

*Due to the absolute accuracy rating and resolution of the output card, the

actual output signal may differ 0.15% FS from the table values. The output

signal corresponds to the range selected (0-20 mA, 4-20 mA or 0-10 V).

Writing to this register (VW) while the analog output is in the Manual Mode causes the output signal level to update immediately to the value sent. While in the Automatic Mode, this register may be written to, but it has no effect until the analog output is placed in the manual mode. When in the Automatic Mode, the meter controls the analog output signal level. Reading from this register (TW) will show the present value of the analog output signal.

Example: VW2047 will result in an output of 10.000 mA, 12.000 mA or

5.000V depending on the range selected.

Setpoint Output Register (SOR) ID: X

This register stores the states of the setpoint outputs. Reading from this register (TX) will show the present state of all the setpoint outputs. A “0” in the setpoint location means the output is off and a “1” means the output is on.

X abcd

d = SP4

c = SP3

b = SP2

a = SP1

In Automatic Mode, the meter controls the setpoint output state. In Manual Mode, writing to this register (VX) will change the output state. Sending any character besides 0 or 1 in a field or if the corresponding output was not first in manual mode, the corresponding output value will not change. (It is not necessary to send least significant 0s.)

Example: VX10 will result in output 1 on and output 2 off.

Auto/Manual Mode Register (MMR) ID: U

This register sets the controlling mode for the outputs. In Auto Mode (0) the meter controls the setpoint and analog output. In Manual Mode (1) the outputs are defined by the registers SOR and AOR. When transferring from auto mode to manual mode, the meter holds the last output value (until the register is changed by a write). Each output may be independently changed to auto or manual. In a write command string (VU), any character besides 0 or 1 in a field will not change the corresponding output mode.

U abcde

e = Analog Output

d = SP4

c = SP3

b = SP2

a = SP1

Example: VU00011 places SP4 and Analog in manual.

Page 31

COMMAND RESPONSE TIME

The meter can only receive data or transmit data at any one time (half-duplex operation). When sending commands and data to the meter, a delay must be imposed before sending another command. This allows enough time for the meter to process the command and prepare for the next command.

At the start of the time interval t string to the com port, thus initiating a transmission. During t characters are under transmission and at the end of this period, the command terminating character (*) is received by the meter. The time duration of t dependent on the number of characters and baud rate of the channel.

= (10 * # of characters) / baud rate

At the start of time interval t command and when complete, performs the command function. This time interval t expected, the meter is ready to accept another command.

varies from 2 msec to 15 msec. If no response from the meter is

If the meter is to reply with data, the time interval t of the command terminating character and the (Serial Transmit Delay parameter (dELAY)). The standard command line terminating character is “*”. This terminating character results in a response time window of the Serial Transmit Delay time (dELAY) plus 15 msec. maximum. The dELAY parameter should be programmed to a value that allows sufficient time for the release of the sending driver on the RS485 bus. Terminating the command line with “$” results in a response time window (t response time of this terminating character requires that sending drivers release

) of 2 msec minimum and 15 msec maximum. The

within 2 msec after the terminating character is received.

At the beginning of time interval t character of the reply. As with t number of characters and baud rate of the channel.

= (10 * # of characters) / baud rate.

At the end of t maximum serial throughput of the meter is limited to the sum of the times t and t

, the meter is ready to receive the next command. The

, the computer program prints or writes the

, the meter starts the interpretation of the

, the meter responds with the first

, the time duration of t3 is dependent on the

, the command

is controlled by the use

, t2

Timing Diagrams

NO REPLY FROM METER

RESPONSE FROM METER

COMMUNICATION FORMAT

Data is transferred from the meter through a serial communication channel. In serial communications, the voltage is switched between a high and low level at a predetermined rate (baud rate) using ASCII encoding. The receiving device reads the voltage levels at the same intervals and then translates the switched levels back to a character.

The voltage level conventions depend on the interface standard. The table lists the voltage levels for each standard.

LOGIC RS232* RS485*INTERFACE STATE

1 TXD,RXD; -3 to -15 V a-b < -200 mVmark (idle)

0 TXD,RXD; +3 to +15 V a-b > +200 mVspace (active)

* Voltage levels at the Receiver

Data is transmitted one byte at a time with a variable idle period between characters (0 to ∞). Each ASCII character is “framed” with a beginning start bit, an optional parity bit and one or more ending stop bits. The data format and baud rate must match that of other equipment in order for communication to take place. The figures list the data formats employed by the meter.

Start bit and Data bits

Data transmission always begins with the start bit. The start bit signals the receiving device to prepare for reception of data. One bit period later, the least significant bit of the ASCII encoded character is transmitted, followed by the remaining data bits. The receiving device then reads each bit position as they are transmitted. Since the sending and receiving devices operate at the same transmission speed (baud rate), the data is read without timing errors.

Character Frame Figure

Parity bit

After the data bits, the parity bit is sent. The transmitter sets the parity bit to a zero or a one, so that the total number of ones contained in the transmission (including the parity bit) is either even or odd. This bit is used by the receiver to detect errors that may occur to an odd number of bits in the transmission. However, a single parity bit cannot detect errors that may occur to an even number of bits. Given this limitation, the parity bit is often ignored by the receiving device. The meter ignores the parity bit of incoming data and sets the parity bit to odd, even or none (mark parity) for outgoing data.

Stop bit

The last character transmitted is the stop bit. The stop bit provides a single bit period pause to allow the receiver to prepare to re-synchronize to the start of a new transmission (start bit of next byte). The receiver then continuously looks for the occurrence of the start bit. If 7 data bits and no parity is selected, then 2 stop bits are sent from the meter.

Page 32

MOdule 8 - analOG OuTpuT paraMeTers (8-AnLOut)

PARAMETER MENU

ASSIGN

Assignment

AnL

NONE

This module is only accessible with the optional LDP6-CDL Analog card installed.

Programming information contained in this manual supercedes all programming information included with the LDP6-CDL card.

ANALOG OUTPUT TYPE

tYPE

AnL

4-20 0-10 0-20

Pro

8-AnLOut

tYPE

Analog Type Analog Output

AnL

4-20

Enter the analog output type. For 0-20 mA or 4-20 mA use terminals 18 and

19. For 0-10 V use terminals 16 and 17. Only one range can be used at a time.

ANALOG OUTPUT ASSIGNMENT

ASSIGN

AnL

NONE

Enter the source for the analog output to retransmit:

NONE = Manual Mode operation. (See Module 7, Serial RLC Protocol). rEL = Relative (net) Input Value. The Relative Input Value is the Absolute Input

Value including the Display Offset Value.

AbS = Absolute (gross) Input Value. The Absolute Input Value is the scaled input

value. It does not include the Display Offset Value.

totAL = Totalizer Value Hi = Maximum Display Value Lo = Minimum Display Value S1-S4 = Setpoint Values

ANALOG

NONE rEL AbS totAL Hi Lo S1 S2 S3 S4

ANALOG LOW SCALE VALUE

-199999 to 999999

Enter the Display Value that corresponds to 0 mA (0-20 mA) , 4 mA (4-20

mA) or 0 VDC (0-10 VDC).

Pro

ANALOG

0.000

Analog Low Scale Value

ANALOG

Analog High

Scale Value

100.00

UPdAtE

ANALOG HIGH SCALE VALUE

AnL

brnAct

0.0

Update

Time

Burn-out

-199999 to 999999

AnL

Action

Temperature Input Only

10000

Enter the Display Value that corresponds to 20 mA (0-20 mA) , 20 mA (4-20

mA) or 10 VDC (0-10 VDC).

ANALOG UPDATE TIME

UPdAtE

AnL

0.0 to 10.0

0.0

Enter the analog output update rate in seconds. A value of 0.0 allows the

meter to update the analog output at the ADC Conversion Rate.

The following programming step is only available when Input Range in Module 1 is set for a temperature input (TC/RTD).

PROBE BURN-OUT ACTION

brnAct

AnL

Hi Lo

Enter the probe burn-out action. In the event of a temperature probe failure, the analog output can be programmed for low or high scale.

MOdule 9 - faCTOry serviCe OperaTiOns (9-FACtrY)

Pro

9-FACtrY

COdE

Service Code

COdE

Use the ! and @ keys to display COdE 66 and press P. The meter will flash

rESEt and then return to COdE 50. Press the P key to return to Display Mode.

This will overwrite all user settings with the factory settings.

COdE

The meter will briefly display the model (P2A) on Line 1, and the current

firmware version (UEr x.xx) on Line 2, and then return to COdE 50.

FCS

Factory

RESTORE FACTORY DEFAULTS

FCS

MODEL AND CODE VERSION

FCS

Pro

rESEt

P2A

V Er x.xx

FCS

COdE

PARAMETER MENU

FCS

COdE

The meter has been fully calibrated at the factory. Scaling to convert the input signal to a desired display value is performed in Module 1. If the meter appears to be indicating incorrectly or inaccurately, refer to Troubleshooting before attempting to calibrate the meter. When recalibration is required (generally every 2 years), it should only be performed by qualified technicians using appropriate equipment. Calibration does not change any user programmed parameters. However, it will affect the accuracy of the input signal and the values previously stored using the Apply (APPLY) Scaling Style.

FCS

CAL

CALIBRATION

FCS

NO Curr UoLt OhMS tc ICE rtd AnLOut

Page 33

Preparation for Current, Volt, and Ohm Input Calibration

Warning: Input Calibration of this meter requires a signal source

capable of producing a signal greater than or equal to the range being calibrated with an accuracy of 0.01% or better.

Before starting, verify that the Input Range, T/V, and Excitation Jumper is set for the range to be calibrated. Verify that the precision signal source is connected and ready. Allow a 30 minute warm-up period before calibrating the meter. Selecting NO at any calibration step, will cause the unit to maintain the existing calibration parameters for that step. Selecting YES and pressing the P key will cause the unit to store new calibration settings for the range selected. Pressing D at any time will exit programming mode, but any range that has been calibrated will maintain the new settings.

Current, Volt and Ohm Calibration Procedure

1. After entering CodE 48, in Module 9, select the input signal type (Curr,

UoLt, OhMS) to be calibrated.

2. Press the P key until the desired range along with 2ER is indicated on Line 1

of the meter.

3. Apply the zero input limit of the range indicated on Line 1 of the meter.

4. Press ! to select YES.

5. Press P. Display will indicate ---- on Line 2 as the unit reads and stores the

new calibration parameter.

6. Display will indicate the desired range along with FUL on Line 1 of the meter.

7. Apply the signal level indicated on Line 1 of the meter.

8. Press ! to select YES.

9. Press P. Display will indicate ---- on Line 2 as the unit reads and stores the

new calibration parameter.

10. Repeat Preparation and Calibration Procedure for each Input Range to be

calibrated.

Preparation for TC calibration

TC calibration parameters will affect RTD calibration. If using an RTD, it is recommended that the RTD calibration be performed after completing the TC calibration.

Warning: TC Input Calibration of this meter requires a signal source

capable of producing a 60 mV signal with an accuracy of 0.01% or better.

Before starting, verify the T/V jumper is in the T position. Verify the precision signal source is connected and ready. Allow a 30 minute warm-up period before calibrating the meter. Selecting NO at any calibration step, will cause the unit to maintain the existing calibration parameters for that step. Selecting YES and pressing P key will cause the unit to store new calibration settings for the range selected. Pressing D at any time will exit programming mode, but any range that has been calibrated will maintain the new settings.

TC Calibration Procedure

1. After entering CodE 48, in Module 9, select the tc.

2. Press the P key. Display will indicate 0.060U with 2ER in upper right.

3. Apply 0 mV to input.

4. Press ! to select YES.

5. Press P. Display will indicate ---- on Line 2 as the unit reads and stores the

new calibration parameter.

6. Display will indicate 0.060U with FUL in upper right.

7. Apply 60 mV to input.

8. Press ! to select YES.

9. Press P. Display will indicate ---- on Line 2 as the unit reads and stores the

new calibration parameter.

10. TC Calibration complete.

Preparation for RTD Input Calibration

RTD calibration is dependent on TC calibration parameters. Therefore, the TC calibration should be performed prior to attempting the RTD calibration.

Warning: RTD Input Calibration of this meter requires a signal

source capable of producing a 300 ohm resistance with an accuracy of 0.01% or better.

Before starting, verify that the T/V Jumper is in the T position. Verify the RTD jumper is in the proper range. Verify the precision signal source is connected and ready. Allow a 30 minute warm-up period before calibrating the meter. Selecting NO at any calibration step, will cause the unit to maintain the existing calibration parameters for that step. Selecting YES and pressing P key will cause the unit to store new calibration settings for the range selected. Pressing D at any time will exit programming mode, but any range that has been calibrated will maintain the new settings.

RTD Calibration Procedure

1. After entering Code 48, in Module 9, select rtd.

2. Press the P key until the desired range along with 0 in upper right corner is

indicated on Line 1 of the meter.

3. Apply zero ohms to the input of the meter.

4. Press ! to select YES.

5. Press P. Display will indicate ---- on Line 2 as the unit reads and stores the

new calibration parameter.

6. Display will indicate the desired range along with a value in the upper right corner, in ohms, to be applied in the next step on Line 1 of the meter.

7. Apply the signal level, in ohms, indicated in the upper right corner of Line 1 on the meter.

8. Press ! to select YES.

9. Press P. Display will indicate ---- on Line 2 as the unit reads and stores the new calibration parameter.

10. Repeat Preparation and Calibration Procedure for each Input Range to be calibrated.

Ice Point Calibration Procedure

1. Remove all option cards.

2. Verify ambient temperature of meter environment is between 20°C and 30°C.

3. Set T/V jumper in the T position.

4. Connect a thermocouple with an accuracy of 1°C or better to the meter.

5. In Module 1 of unit programming, verify Input Range (rANgE) is set to the type thermocouple connected in step 4, Temperature Scale (SCALE) is °C, Ice Point Compensation (ICE) is turned ON, Decimal Resolution (dECPNt) is 0.0, Rounding Increment (round) is 0.1 and Display Offset (OFFSEt) is set to 0.

6. Place the thermocouple in close thermal contact to a reference thermometer probe. (Use a reference thermometer with an accuracy of 0.25% °C or better.) The two probes should be shielded from air movement and allowed sufficient time to equalize in temperature. (A calibration bath could be used in place of the thermometer.)

7. If a difference exits between DP63100 display and reference thermometer, continue calibration.

8. Note the DP63100 display reading as the “Display Mode” reading to be used in Step 12.

9. Enter Module 9, select CodE 48 and press P.

10. Select ICE and press P.

11. Display will indicate the Existing ICE Point Value.

12. Calculate a new ICE Point Value using: Existing ICE Point Value + (reference temperature – Display Mode reading). All values are in °C.

13. Using ! and @ change Existing ICE Point Value to indicate the new ICE Point Value calculated in Step 12.

14. Press P and return to Display Mode. Verify the Display Mode reading (with 0 Display Offset) matches the reference temperature. If not, repeat steps 8 thru 14.

Preparation for Analog Output Card Calibration

Warning: Calibration of this meter requires an external meter with

Before starting, verify that the precision voltmeter (voltage output) or current

meter (current output) is connected and ready. Perform the following procedure.

1. After entering CodE 48, in Module 9, select AnLOut.

2. Using the chart below, step through the five selections to be calibrated. At each prompt, use the DP63100 ! and @ keys to adjust the external meter display to match the selection being calibrated. When the external reading matches, or if the particular range is not in need of calibration, press the P key to advance to the next range.

3. Calibration Complete.

an accuracy of 0.005% or better.

DP63100 DISPLAY

0.000A

0.004A

0.020A

0.0v

10.0v

EXTERNAL METER ACTION

0.00 mA

4.00 mA

20.00 mA

0.00 V

10.00 V

! and @ to adjust External Meter ! and @ to adjust External Meter ! and @ to adjust External Meter ! and @ to adjust External Meter ! and @ to adjust External Meter

Page 34

TROUBLESHOOTING

PROBLEM REMEDIES

No Display At Power-Up Check power level and power connections

No Display After Power-Up

Program Locked-Out

No Line 1 Display

No Line 2 Display Check Module 3:

No Programmable Units Display

Incorrect Input Display Value Check Input Jumper Setting, Input Level, and Input Connections.

Display of

Modules or Parameters Not Accessible Check for corresponding plug-in option card.

Error Code:

Error Code: Error Code: EE Pdn

Error Code:

OLOL, ULUL, Short, OPEN, or “ . . . .” See General Meter Specifications, Display Messages.

ErrKEY Keypad is active at power up. Check for depressed or stuck keypad. Press

EE PAr

ErrPro Parameter Data Validation Error. Press any key to clear Error Code, verify all

EE CAL Calibration Data Validation Error. Contact factory.

EE Lin Linear Output Card Data Validation Error. Press any key to clear Error Code

Check Module 3: d-LEU, d-Cont, and LINE 1 program settings.

Check for Active User Input, programmed for

Enter proper access code at

Check Module 3:

LINE 1 program setting.

COdE 0 prompt.

PLOC. Deactivate User Input.

ACCESS program settings.

Check Module 3:

Verify Module 1 program settings.

Contact factory

Verify parameter is valid in regard to previous program settings.

any key to clear Error Code.

Parameter Data Checksum Error. Press any key to clear Error Code, verify all program settings and cycle power. Contact factory if Error Code returns at next power-up.

program settings and cycle power. Contact factory if Error Code returns at next power-up.

and cycle power. If Error Code returns at next power-up, replace Linear Option Card or contact factory.

UNItS Mnemonic program settings.

PARAMETER VALUE CHART Programmer ________________ Date ________ DP63100 Meter# _____________ Security Code ________

1-InPUt INPUT SETUP PARAMETERS

DISPLAY PARAMETER USER SETTING

rANgE SCALE ICE rAtE dECPNt round OFFSEt FILtEr bANd POINtS StYLE INPUt 1 dISPLY 1 INPUt 2 dISPLY 2 INPUt 3 dISPLY 3 INPUt 4 dISPLY 4 INPUt 5 dISPLY 5 INPUt 6 dISPLY 6

INPUT RANGE

TEMPERATURE SCALE

ICE POINT CONPENSATION

ADC CONVERSION RATE

SCALING DECIMAL POINT

DISPLAY ROUNDING

DISPLAY OFFSET

DIGITAL FILTER

DIGITAL FILTER BAND

SCALING POINTS

SCALING STYLE

INPUT 1 SCALING VALUE

DISPLAY 1 VALUE

INPUT 2 SCALING VALUE

DISPLAY 2 VALUE

INPUT 3 SCALING VALUE

DISPLAY 3 VALUE

INPUT 4 SCALING VALUE

DISPLAY 4 VALUE

INPUT 5 SCALING VALUE

DISPLAY 5 VALUE

INPUT 6 SCALING VALUE

DISPLAY 6 VALUE

DISPLAY PARAMETER USER SETTING

INPUt 7 dISPLY 7 INPUt 8 dISPLY 8 INPUt 9 dISPLY 9 INPUt 10 dISPLY 10 INPUt 11 dISPLY 11 INPUt 12 dISPLY 12 INPUt 13 dISPLY 13 INPUt 14 dISPLY 14 INPUt 15 dISPLY 15 INPUt 16 dISPLY 16 ScLISt

INPUT 7 SCALING VALUE

DISPLAY 7 VALUE

INPUT 8 SCALING VALUE

DISPLAY 8 VALUE

INPUT 9 SCALING VALUE

DISPLAY 9 VALUE

INPUT 10 SCALING VALUE

DISPLAY 10 VALUE

INPUT 11 SCALING VALUE

DISPLAY 11 VALUE

INPUT 12 SCALING VALUE

DISPLAY 12 VALUE

INPUT 13 SCALING VALUE

DISPLAY 13 VALUE

INPUT 14 SCALING VALUE

DISPLAY 14 VALUE

INPUT 15 SCALING VALUE

DISPLAY 15 VALUE

INPUT 16 SCALING VALUE

DISPLAY 16 VALUE

ENABLE SCALE LIST

Page 35

2-FUNCt USER INPUT/FUNCTION KEY PARAMETERS

DISPLAY PARAMETER USER SETTING

USrACt USEr-1 USEr-2 F1 F2 SEC-F1 SEC-F2

USER ACTIVE STATE

USER INPUT 1

USER INPUT 2

FUNCTION KEY 1

FUNCTION KEY 2

2nd FUNCTION KEY 1

2nd FUNCTION KEY 2

3-dISPLY DISPLAY PARAMETERS

DISPLAY PARAMETER USER SETTING

Color d-LEV d-Cont LINE 1 UNItS

UNItS1 UNItS2 UNItS3

ACCESS

LINE 1 DISPLAY COLOR

DISPLAY LEVEL

DISPLAY CONTRAST LEVEL

LINE 1 DISPLAY

UNITS MNEMONIC

SEGMENT 1

SEGMENT 2

SEGMENT 3

LINE 2 LOOP ACCESSIBILE ITEMS

OFF LISt

NO YES

INPUt b2-d2 totAL S3

Hi b3-d3 Lo S4

LISt b4-d4

S1 Color

b1-d1 d-LEV

S2 d-Cont

FUNCt

LINE 2 USER FUNC. ACCESS. ITEMS

NO YES

rEL r-2 bAt r-3

r-tot r-4

r-HI r-34 r-Lo r-234 r-HL r-ALL

COdE

r-1

SECURITY CODE

4-SCNdrY SECONDARY FUNCTION PARAMETERS

DISPLAY PARAMETER USER SETTING

HI-AS HI-t LO-AS LO-t dSP-t

MAX ASSIGNMENT

MAX CAPTURE DELAY TIME

MIN ASSIGNMENT

MIN CAPTURE DELAY TIME

DISPLAY UPDATE TIME

5-totAL TOTALIZER PARAMETERS

DISPLAY PARAMETER USER SETTING

dECPNt t bASE SCLFAC Lo Cut PWrUP

TOTALIZER DECIMAL POINT

TOTALIZER TIME BASE

TOTALIZER SCALE FACTOR

TOTALIZER LOW CUT VALUE

TOTALIZER POWER-UP RESET

7-SErIAL SERIAL COMMUNICATIONS PARAMETERS

DISPLAY PARAMETER USER SETTING

USb tYPE bAUd dAtA PArItY Addr dELAY Abrv OPt

USB PORT

TYPE

BAUD RATE

WORD LENGTH

PARITY

ADDRESS

TRANSMIT DELAY

ABBREVIATED

PRINT OPTION

Signal Input

INPUt

Total Value

totAL

Max & Min

HILO

Setpoint Values

SPNt

NO YES

8-AnLOut ANALOG OUTPUT PARAMETERS

DISPLAY PARAMETER USER SETTING

tYPE ASSIGN ANALOG ANALOG UPdAtE brnAct

ANALOG TYPE

ANALOG ASSIGNMENT

ANALOG LOW

ANALOG HIGH

ANALOG UPDATE TIME

PROBE BURN-OUT ACTION

6-SEtPNt SETPOINT OUTPUT PARAMETERS

DISPLAY PARAMETER USER SETTING USER SETTING USER SETTING USER SETTING

SELECt

ASSIGN ACtION SEtPNt bn-dEV HYStEr t-ON t-OFF LOGIC rESEt StndbY Annun Color brnAct

SETPOINT SELECTION

SETPOINT SOURCE

ACTION FOR SETPOINT

SETPOINT VALUE

SETPOINT BAND/DEVIATION VALUE

HYSTERESIS FOR SETPOINT

ON TIME DELAY SETPOINT

OFF TIME DELAY SETPOINT

OUTPUT LOGIC

RESET ACTION

STANDYBY OPERATION

OUTPUT ANNUNCIATOR LIGHT

CHANGE COLOR

PROBE BURN-OUT ACTION

S1 S2 S3 S4

Page 36

Pro

1-INPUt

Pro

2-FUNCt

Pro

3-dISPLY

dp63100 prOGraMMinG QuiCK OvervieW

rANGE

200U

Input Range

USrACt

Color

GrEEN

Display

Color

Temperature Input Types Only

INP

Temperature

SCALE

Scale

INP

°F

FILtEr

Filter

Setting

FNC

Ln1

d-LEV

USEr-1

Display

Intensity

FNC

dSP

ICE

Ice Point

Compensation

INP

bANd

1.0

Filter Band

USEr-2

d-Cont

Display

Contrast

ADC Rate

POINtS

Scaling

Points

INPUt

Line 1

Display

INP

FNC

dSP

INP

rAtE

INP

0.10

FNC

dSP

LINE 1

INP

KEY

Scaling

Style

FNC

Function KeysUser Inputs

dSP

round

INP

SEC-F1

ACCESS

dECPNt

0.00

Display

Decimal

Point

Voltage and Current Input Type Only

StYLE

UNItS

OFF

Units

Mnemonic

0.01

Display

Rounding

INPUt

Access

Line 2

INP

Input n

Value

FNC

Ln2

0.00

YES

OFFSEt

0.00

Display

Offset

Value

dISPLY

Display n

Value

SEC-F2

INPUt

LOC

Line 2 Input

Access

INP

0.00

FNC

Ln2

tOtAL

Line 2 Total

Access

ScLISt

Enable

Scale List

Ln2

LOC

Line 2 MAX

Access

Pro

Ln2

Pro

4-SCNdrY

Pro

5-totAL

Pro

6-SEtPNt

Pro

7-SErIAL

Pro

8-AnLOut

Pro

9-FACtrY

LOC

Line 2 MIN

Access

Decimal

Point

Setpoint

Select

USb

CONFIG

USB

Setup

Factory

SEC

tOt

0.000

SPt

SRL

AnL

4-20

FCS

HI-AS

rEL

MAX Capture

Assignment

dECPNt

SELECt

tYPE

Analog Type Analog Output

COdE

Service Code

Ln2

HI-t

MAX Capture

Time

t bASE

Time Base Scale Factor Low Cut

ASSIGN

NONE

Setpoint

Assignment

tYPE

MbASC

Comms

Type

ASSIGN

NONE

Assignment

LISt

LOC

Parameter

List A/B

Access

SEC

1.0

tOt

MIN

SRL

AnL

Ln2

LO-AS

rEL

MIN Capture

Assignment

SCLFAC

ACtION

Setpoint

Output Action

bAUd

38400

Baud Rate

ANALOG

Analog Low Scale Value

LOC

Setpoint

Value

Access

SEC

tOt

1.000

LOGIC

SRL

0.000

Ln2

LO-t

MIN Capture

Lo Cut

SEtPNt

nor

Output

Logic

dAtA

ANALOG

Analog High Scale Value

bn-dn

LOC

Band and

Deviation

Value Access

SEC

1.0

Time

tOt

-19999.9

Value

100

Setpoint

Value

rESEt

SRL

Data Bit

100.00

Ln2

CoLor

LOC

Color

Access

SEC

dSP-t

Display

Update Rate

tOt

PWrUP

Power Up

Reset

bn-dEV

Band/

Deviation

Value

Auto

Reset

Action

StndbY

Operation

SRL

PArItY

Parity Bit Meter

AnL

UPdAtE

0.0

Update

Time

Ln2

HYStEr

Setpoint Standby

Addr

brnAct

d-LEV

LOC

Display

Intensity

Access

Setpoint

Hysteresis

247

Address

Burn-out

Action

Ln2

t-ON

On Time

Annun

nor

Setpoint

Annunciator

SRL

dELAY

Transmit

AnL

d-Cont

LOC

Display

Contrast

Access

0.0

Delay

0.010

Delay

Ln2

Color

NO CHG

Change

Color

SRL

FUNCt

Aux User

Functions

Access

t-OFF

0.0

Off Time

Delay

brnAct

Abrv

Abbreviated

Printing

Ln2

OFF

Probe

Burn-out

Action

SRL

OPt

COdE

Security

Code

Options

dSP

SRL

Temperature Input Only

Page 37

This page intentionally left blank.

Page 38

This page intentionally left blank.

Page 39

WARRANTY/DISCLAIMER

OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of 25 months from date of purchase. OMEGA’s WARRANTY adds an additional one (1) month grace period to the normal two (2) year product warranty to cover handling and shipping time. This ensures that OMEGA’s customers receive maximum coverage on each product.

If the unit malfunctions, it must be returned to the factory for evaluation. OMEGA’s Customer Service Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification. This WARRANTY is VOID if the unit shows evidence of having been tampered with or shows evidence of having been damaged as a result of excessive corrosion; or current, heat, moisture or vibration; improper specification; misapplication; misuse or other operating conditions outside of OMEGA’s control. Components in which wear is not warranted, include but are not limited to contact points, fuses, and triacs.

OMEGA is pleased to offer suggestions on the use of its various products. However, OMEGA neither assumes responsibility for any omissions or errors nor assumes liability for any damages that result from the use of its products in accordance with information provided by OMEGA, either verbal or written. OMEGA warrants only that the parts manufactured by the company will be as specified and free of defects. OMEGA MAKES NO OTHER WARRANTIES OR REPRESENTATIONS OF ANY KIND WHATSOEVER, EXPRESSED OR IMPLIED, EXCEPT THAT OF TITLE, AND ALL IMPLIED WARRANTIES INCLUDING ANY WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED. LIMITATION OF LIABILITY: The remedies of purchaser set forth herein are exclusive, and the total liability of OMEGA with respect to this order, whether based on contract, warranty, negligence, indemnification, strict liability or otherwise, shall not exceed the purchase price of the component upon which liability is based. In no event shall OMEGA be liable for consequential, incidental or special damages.

CONDITIONS: Equipment sold by OMEGA is not intended to be used, nor shall it be used: (1) as a “Basic Component” under 10 CFR 21 (NRC), used in or with any nuclear installation or activity; or (2) in medical applications or used on humans. Should any Product(s) be used in or with any nuclear installation or activity, medical application, used on humans, or misused in any way, OMEGA assumes no responsibility as set forth in our basic WARRANTY/DISCLAIMER language, and, additionally, purchaser will indemnify OMEGA and hold OMEGA harmless from any liability or damage whatsoever arising out of the use of the Product(s) in such a manner.

RETURN REQUESTS/INQUIRIES

Direct all warranty and repair requests/inquiries to the OMEGA Customer Service Department. BEFORE RETURNING ANY PRODUCT(S) TO OMEGA, PURCHASER MUST OBTAIN AN AUTHORIZED RETURN (AR) NUMBER FROM OMEGA’S CUSTOMER SERVICE DEPARTMENT (IN ORDER TO AVOID PROCESSING DELAYS). The assigned AR number should then be marked on the outside of the return package and on any correspondence. The purchaser is responsible for shipping charges, freight, insurance and proper packaging to prevent breakage in transit.

FOR WARRANTY RETURNS, please have the following information available BEFORE contacting OMEGA:

1. Purchase Order number under which the product was PURCHASED,

2. Model and serial number of the product under warranty, and

3. Repair instructions and/or specific problems relative to the product.

OMEGA’s policy is to make running changes, not model changes, whenever an improvement is possible. This affords our customers the latest in technology and engineering. OMEGA is a registered trademark of OMEGA ENGINEERING, INC. © Copyright 2006 OMEGA ENGINEERING, INC. All rights reserved. This document may not be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form, in whole or in part, without the prior written consent of OMEGA ENGINEERING, INC.

FOR NON-WARRANTY REPAIRS, consult OMEGA for current repair charges. Have the following information available BEFORE contacting OMEGA:

1. Purchase Order number to cover the COST of the repair,

2. Model and serial number of the product, and

3. Repair instructions and/or specific problems relative to the product.

Page 40

Where Do I Find Everything I Need for

Process Measurement and Control?

OMEGA…Of Course!

Shop online at omega.com

TEMPERATURE

] Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies ] Wire: Thermocouple, RTD & Thermistor ] Calibrators & Ice Point References ] Recorders, Controllers & Process Monitors ] Infrared Pyrometers

PRESSURE, STRAIN AND FORCE

] Transducers & Strain Gages ] Load Cells & Pressure Gages ] Displacement Transducers ] Instrumentation & Accessories

FLOW/LEVEL

] Rotameters, Gas Mass Flowmeters & Flow Computers ] Air Velocity Indicators ] Turbine/Paddlewheel Systems ] Totalizers & Batch Controllers

pH/CONDUCTIVITY

] pH Electrodes, Testers & Accessories ] Benchtop/Laboratory Meters ] Controllers, Calibrators, Simulators & Pumps ] Industrial pH & Conductivity Equipment

DATA ACQUISITION

] Data Acquisition & Engineering Software ] Communications-Based Acquisition Systems ] Plug-in Cards for Apple, IBM & Compatibles ] Datalogging Systems ] Recorders, Printers & Plotters

HEATERS

] Heating Cable ] Cartridge & Strip Heaters ] Immersion & Band Heaters ] Flexible Heaters ] Laboratory Heaters

ENVIRONMENTAL MONITORING AND CONTROL

] Metering & Control Instrumentation ] Refractometers ] Pumps & Tubing ] Air, Soil & Water Monitors ] Industrial Water & Wastewater Treatment ] pH, Conductivity & Dissolved Oxygen Instruments

M5056/1111
