INTRODUCTION
This instrument is a portable 3½ digit, compact-sized digital thermometer
designed to use external K-type thermocouple as temperature sensor. Temperature indication follows Reference Temperature/Voltage Tables (N.I.S.T.
Monograph 175 Revised to ITS-90) for K-type thermocouples.
SAFETY INFORMATION
It is recommended that you read the safety and operation instructions before
using the thermometer.
WARNING
To avoid electrical shock, do not use this instrument when voltages at the
measurement surface exceed 24V AC or DC.
WARNING
To avoid damage or burns, do not make temperature measurement in
microwave ovens.
CAUTION
Repeated sharp flexing can break the thermocouple leads. To prolong
lead life, avoid sharp bends in the leads, especially near the connector.
The
symbol on the instrument indicates that the operator must refer to an
explanation in this manual.
1
Page 4
SPECIFICATIONS
ELECTRICAL
Temperature Scale: Celsius or Fahrenheit user-selectable
Measurement Range: -40°C to 1350°C, (-40°F to 2000°F)
Calibration Range: -200°C to 1372°C, (-328°F to 2502°F)
Resolution: 1°C or 1°F, 0.1°C or 0.1°F
Accuracy: Accuracy is specified for operating temperatures over the range of
18°C to 28°C (64°F to 82°F), for 1 year, not including thermocouple error.
±(0.1% rdg + 1°C) on -40°C to 1350°C
±(0.1% rdg + 2°F) on -40°F to 2000°F
Temperature Coefficient: 0.1 times the applicable accuracy specification
per °C from 0°C to 18°C and 28°C to 50°C (32°F to 64°F and 82°F to 122°F).
Input Protection: 24V dc or 24V ac rms maximum input voltage on any
combination of input pins.
Reading Rate: 2.5 times per second.
Input Connector: Accepts standard miniature thermocouple connectors (flat
blades spaced 7.9mm, center to center).
2
Page 5
ENVIRONMENTAL
Ambient Operating Ranges: 0°C to 50°C (32°F to 122°F) <80% R.H.
Storage Temperature: -20°C to 60°C (-4°F to 140°F) <70% R.H.
GENERAL
Display: 3½ digit liquid crystal display (LCD) with maximum reading of 1999
Battery: Standard 9V battery.
Battery Life: 200 hours typical.
Dimensions: 190.7mm(H) x 90mm(W) x 53.4mm(D).
Weight: 440g.
Supplied Probe: 4 foot type "K" thermocouple bead probe (teflon tape
insulated). Maximum insulation temperature 260°C (500°F). Probe accu-
racy ±2.2°C or ±0.75% of reading (whichever is greater) from 0°C to 800°C.
3
Page 6
OPERATING INSTRUCTIONS
Function Switch
The function switch limited to rotate in 180º range, the overlay OUTPUT ºF
refer to scale of the OUTPUT ºC only.
Selecting the Temperature Scale
Readings are displayed in either degrees Celsius(°C) or degrees
Fahrenheit(°F). When the thermometer is turned on, it is set to the temperature
scale that was in use when the thermometer was last turned off. To change the
temperature scale, press the "°C/°F"key.
Selecting the Display Resolution
The thermometer allows two choices of resolution:
High resolution: 0.1°C or 0.1°F
Low resolution: 1.0°C or 1.0°F
To select the alternate display resolution, press the corresponding "0.1°/1°"
key.
Back-Light and Data-Hold Switch ( >2sec),( H ):
Press this button briefly to activate DATA-HOLD mode. The " H " annunciator
is displayed.
Press this button for 2 seconds to turn the Back-Light on. As this also
activates the DATA-HOLD mode, briefly press the button to return to normal
display. To turn the Back-Light off press again for 2 seconds.
4
Page 7
MAX Mode
Pressing the Max key to enter the MAX mode. The thermometer then
records and updates the maximum absolute values and the MAX annunciator
appears on the display. Pressing the MAX key again to exit the MAX recording
mode.
T1 , T2 Temperature Measurement
1. The function switch indicates which input is selected for display; T1
thermocouple, T2 thermocouple.
2. Connect a type K thermocouple to the jack on the instrument. Place the
probe or thermocouple tip on or in the material to be measured and take the
temperature reading directly from the display.
Thermocouple Calibration
1.Connect the proper K-type thermocouple wire and miniature male SMP
connector to the CL3512 output.
2. Connect the other end of the thermocouple wire to the instrument to be
calibrated.
3. Using the range switch and the COARSE / FINE adjust knobs set the
CL3512 to the output required as read on the LCD.
4.If output over -40°C to 1350°C ( -40°F to 2000°F ) range, Please refer to
Other Type Thermocouple Calibration.
5
Page 8
Other Type Thermocouple Calibration
1. Connect the two proper thermocouple wires and miniature male SMP
connector to the CL3512 output.
2. Connect the other end of one thermocouple wire to the instrument to be
calibrated and other end of one thermocouple wire to the monitoring
reference thermometer.
3. Using the range switch and the COARSE / FINE adjust knobs set the
CL3512 to the output required as read on the indicating thermometer.
6
Page 9
OPERATOR MAINTENANCE
WARNING
To avoid possible electrical shock, disconnect the thermocouple
connectors from the thermometer before removing the cover.
Battery Replacement
Power is supplied by a 9 volt "transistor" battery. The " " appears on the
LCD display when replacement is needed. To replace the battery, remove the
two screws from the back of the meter and lift off the battery cover. Remove
the battery from battery contacts.
7
Page 10
