PSW2000
Operating Instructions Dual Pressure Switch
Shop online at
User
s Guide
PSW2000.qxp 6/12/2008 10:37 AM Page cov-3
2
Servicing North America:
U.S.A.: One Omega Drive, P.O. Box 4047
ISO 9001 Certified Stamford, CT 06907-0047
TEL: (203) 359-1660 FAX: (203) 359-7700 e-mail: info@omega.com
Canada: 976 Bergar
Laval (Quebec) H7L 5A1, Canada TEL: (514) 856-6928 FAX: (514) 856-6886 e-mail: info@omega.ca
For immediate technical or application assistance:
U.S.A. and Canada: Sales Service: 1-800-826-6342/1-800-TC-OMEGA
®
Customer Service: 1-800-622-2378/1-800-622-BEST
®
Engineering Service: 1-800-872-9436/1-800-USA-WHEN
®
Mexico: En Espan˜ ol: (001) 203-359-7803
e-mail: espanol@omega.com FAX: (001) 203-359-7807 info@omega.com.mx
Servicing Europe:
Czech Republic: Frystatska 184, 733 01 Karviná, Czech Republic
TEL: +420 (0)59 6311899 FAX: +420 (0)59 6311114
Toll Free: 0800-1-66342 e-mail: info@omegashop.cz
Germany/Austria: Daimlerstrasse 26, D-75392 Deckenpfronn, Germany
TEL: +49 (0)7056 9398-0 FAX: +49 (0)7056 9398-29 Toll Free in Germany: 0800 639 7678 e-mail: info@omega.de
United Kingdom: One Omega Drive, River Bend Technology Centre
ISO 9002 Certified Northbank, Irlam, Manchester
M44 5BD United Kingdom TEL: +44 (0)161 777 6611 FAX: +44 (0)161 777 6622 Toll Free in United Kingdom: 0800-488-488 e-mail: sales@omega.co.uk
OMEGAnet®Online Service Internet e-mail
omega.com info@omega.com
It is the policy of OMEGA Engineering, Inc. to comply with all worldwide safety and EMC/EMI regulations that apply. OMEGA is constantly pursuing certification of its products to the European New Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification.
The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves the right to alter specifications without notice. WARNING: These products are not designed for use in, and should not be used for, human applications.
PSW2000.qxp 6/12/2008 10:37 AM Page cov-4
3
1. Product Description
2. Starting operations
Intended Applications
- The dual pressure switch monitors system pressures and has up to two switching outputs and one analog output.
- According to DESINAstandard
- The instruments must only be installed in systems where the maximum pressure Pmax is not exceeded (according to the values on the type label).
- Attention: This device is not designed to be used as the only safety relevant element in pressurized systems according PED 97/23/RC
Only install or uninstall the device when depressurized!
- Mount the pressure switch from bottom to the fitting with a wrench hex 36 (1/4 ) resp. 19 with 45 Nm torque.
- Electrical connection depends on the type of pressure switch (see type label) according to the chart below.
Electrical connections
PSW3000
Dimensions (in mm)
Plug M 12 x 1, 4-pin
Model with 1 switching output
Model with 2 switching outputs (DESINA
)
Model with 1 switching output and 1 analog output
Pin 1 (15...32 V DC) (15...32 V DC) (15...32 V DC) Pin 2 - SP2 (0,5 A max.) analog Pin 3 0V 0 V 0 V Pin 4 SP1 (0,5 A max.) SP1 (0,5 A max.) SP1 (0,5 A max.)
PSW2000.qxp 6/12/2008 10:37 AM Page cov-5
Dialog item Value Description
0 ... 400 Display of the actually measured value
.... Select the display unit
Activation of the unit display
....
0 ... xxx Switch-on point for SP1; if the ON value is smaller than the OFF value the
switching point evaluation is falling
0 ... xxx Switch-off point for SP1
0.0 s ... 9.9 s Switch-on delay for SP1 in seconds
0.0 s ... 9.9 s Switch-off delay for SP1 in seconds
.... Inversion of switching output SP1
Only models with 2nd switching contact:
0 ... xxx Switch-on point for SP2; if the ON value is smaller than the OFF value the
switching point evaluation is falling
0 ... xxx Switch-off point for SP2
0.0 s ... 9.9 s Switch-on delay for SP2 in seconds
0.0 s ... 9.9 s Switch-off delay for SP2 in seconds
.... Inversion of switching output SP2
List of functions:
4
= mbar
= bar
= unit display on (every 30 sec)
= no unit display
= psi x 10
= Window technology
= standard evaluation
= high-level-fail-save (normally open function)
= low-level-fail-save (normally closed function)
= high-level-fail-save (normally open function)
= low-level-fail-save (normally closed function)
= error output
= Window technology
= standard evaluation
= error output
= psi
= hPa
= mPa
PSW2000.qxp 6/12/2008 10:38 AM Page cov-6
List of functions: (continued)
5
Dialog item Value Description
Only models with analog output:
0 ... xxx Scale the analog output - start value (e. g. 0 bar = 4 mA)
0 ... xxx Scale the analog output - end value (e. g. 400 bar = 20 mA)
(output signal start value always corresponds to the display initial value, e. g. 0 bar = 4mA) Maximum turn-down 4 : 1, i.e. at values below 25 % of the measuring range the analog output is switched off
0 ... xxx Display of peak value "Max" (xxxx: = max. 125 % f. s.)
.... Delete the maximum value memory
Error display:
Note:
When changing units from psi to bar or bar to psi, the switching point values must be changed accordingly.
= exceeding neg. measuring range
= sensor error
= no error
= exceeding pos. measuring range
= data error (EEProm)
= program error
= error switching output 1
= error switching output 2
= calibration error
= error analog out
= no deletion
= delete value
PSW2000.qxp 6/12/2008 10:38 AM Page cov-7
6
Operation
The pressure switch should be installed and operated only by authorized persons. After being switched on, the PSW2000 runs through a self-text. The device is menu operated and configured with three keys on the front. With the Mkey (= mode) you change between the dialog values and the adjusted / actual values. With the keys ““= up and ““= down you change between the dialog values in the menu or change the values / functions in the menus (see below List of functions“).
If the dialog is not continued within two minutes the device automatically returns to the measuring mode. When the software lock is entered, LOCKappears in the display when an attempt is made to change values.
Electrical connections (scheme)
*SP2 = Diagnosis output (DESINA-version)
Programming:
The setting menu is activated with the mode key. The dialog items are selected with the ““and ““keys. If the mode key is pressed again the corresponding value for the dialog item is shown and can be altered with the ““and ““keys. If the dialog with the unit is not continued within two minutes the device automatically returns to the measuring mode without accepting the new values. To terminate programming more quickly, you can switch back to the measuring mode (primary menu) from any item in the menu by holding the M-key pressed for five seconds.
If the key lock has been activated, the values can be shown, but no changes made. ( ““appears in the display when an attempt is made to change values). The key lock is activated by pressing the ““and ““ keys simultaneously for at least five seconds. Press again to deactivate the key lock again.
DESINA conformity:
When the switch operates in systems according to DESINA standard, switching point SP2 has to be programmed as monitoring function: Enter the value (error output) in programming step and the value (normally closed function) in programming step . In case of error identification (see menu) a diagnosis signal is automatically actuated on the alarm dis­play on the front panel and on switching point SP2 (pin 2).
PSW2000.qxp 6/12/2008 10:38 AM Page cov-8
