Instruction Manual
Please read the instructions carefully
before using.
Please keep the user’s guide where
it is easily accessible.
Design and product development may be
upgraded without a public notice.
www.omegajuicers.com
VRT330
OMEGA PRODUCTS, INC
IMPORTANT SAFEGAURDS
1. When using electrical appliances, basic safety precautions should always
be followed including the following.
Read all instructions.
2. To protect against risk of electrical shock, do not put the main body
(motor) in water or any other liquid.
3. Close supervision is necessary when any appliance is used by or near
children.
4. Unplug from outlet when not in use, before assembling or taking of
parts and before cleaning.
5. Avoid contact moving parts.
6. Do not operate any appliance with a damaged cord or plug of after
the appliance malfunctions, or is dropped or damaged in any manner.
Return appliance to the nearest authorized service facility for examination,
repair or electrical or mechanical adjustment.
7. The use of attachments not recommended or sold by the manufacturer
may cause fire, electric shock or injury.
8. Do not let cord hang over edge of table or counter.
9. Always make sure juicer locking clip is locked while juicer is in operation.
10. Be sure to turn switch to off position after each use of your juicer.
Make sure the motor stops completely before disassembling.
11. Do not put your fingers or other objects into the juicer while it is in
operation. If food becomes lodged in opening, use food plunger or
another piece of fruit or vegetable to push it down. When this method
is not possible, turn the motor off and disassemble juicer to remove
the remaining food.
12. Do not use outdoors.
13. Do not place on or near a hot gas or electric burner or in a heated oven.
14. Do not use appliance for other than intended use.
SAVE THESE INSTRUCTIONS
Omega Vert juicer USERS
The Omega Vert Juicer is a completely different mechanism where fresh juice comes
from squeezing rather than grinding. Omega Vert Juicer is a newly developed patent
product which is capable of making soy milk, vegetable extracting, fresh squeezed
fruit juice, etc.
LSJS (Low Speed Juicing System) squeezes instead of grinding which allows the
juice to maintain it’s pure color, natural taste, nutrients and vitamins.
For better use and maintenance of the product please follow the instructions carefully.
Please refer to the user’s guide when you are having technical difficulties or unsure of
the usage of this product. Omega Products, Inc is not liable for any damages or
injuries that may occur due to the lack of understanding of the user’s guide.
Omega Vert juicer TABLE OF CONTENTS
Introduction ------------------------------------------------------------- 01
Attachment Listing ----------------------------------------------------- 02
Assembly Instruction -------------------------------------------------- 03
How to use Vert juicer ------------------------------------------------ 05
Warning while operating ---------------------------------------------- 07
How to disassemble and clean ---------------------------------------- 08
Before requesting for repair service ---------------------------------- 09
Product Specification --------------------------------------------------- 10
01
Hopper
Attachment Listing
Top Set
Auger
Strainer(white)
- less pulp
Auto Cleaning
Brush
Bowl
Crushing
Rib
Strainer(yellow)
- more pulp
Base
Pusher
IMPT
As shown below, the hopper edge must
point to “close” sign on the base in order
for the machine to operate properly.
Container(2)
Cleaning
brush
pulp ejection
Notice
Do not pre-operate before inputting
materials or do not operate with an
empty bowl.
02
Juice Spout
Assembly instruction
Place the strainer into the auto cleaning brush
Strainer
auto cleaning
brush
Auger
Bowl
Strainer
Red dot
on the
auto cleaning brush
Red dot
on the bowl
Crushing Rib
Place the strainer + auto cleaning brush
into the bowl
make sure the red dot on the strainer
and the red dot on the bowl is aligned
Push in the Auger into the strainer
Bowl
03
Hopper
Bowl
Assembly instruction
Assemble the hopper onto the bowl.
①Make sure the arrow on the hopper and the red
dot on the bowl is aligned.
②Make sure the arrow on the hopper is pointing
The arrow
on the hopper
Red dot
on the bowl
to close sign on the base.
Juice
spout
04
Base
Assemble the entire top set onto the base.
As shown below, assemble the bowl onto the
base and twist the bowl so that the hopper edge
is pointing to “close” sign
OPEN
CLOSE
Assembly instruction
Must connect the power cord.
Place containers under both ejections.
(Juice & pulp ejection)
Underneath the bowl, there is a yellow rubber gasket which allows all the juice to only
discharge from the fresh juice spout.
The rubber gasket is removable, simply grab onto one side of the rubber pad and pull out.
rubber pad
05
Pusher
How to use Omega vert juicer
The machine has three(3) settings.
ON
“On” starts motor, Start making juice.
“ON”
REV
“REV”
“Rev” is reverse. Only use when something is
stuck and you need to unclog.
“Off” is at center position. This allow the
machine to turn off.
Please rinse everything thoroughly
before putting into the machine.
After rinsing, put material into the machine
using the pusher.
“ON”
ON
REV
Please remove any hard seeds before using.
Warning
Any unused juice should be refrigerated.
Do not operate with wet hands.
“REV”
Do not pre-operate before inputting materials
or do not operate with an empty bowl.
06
Warning while operating
Do not use longer than
30minutes at a time.
Do not use anything as a
pusher (fork , chopsticks,
spoons, etc) other than
the pusher itself.
Remove any hard seeds.
Do not operate with wet
hands.
Violating the warning may cause serious
damage to the product.
Violating the warning may cause serious
damage to the product.
Violating the warning may cause serious
damage to the product especially the screw.
Violating the warning may cause serious
injuries or electrocution.
Do not place the attachment
parts in the dishwasher
When the machine is stuck and not operable, Please…
ON
OFF
Violating the warning may cause serious
damage to the product.
Turn off the machine and put it reverse for few
seconds then try operating again.
When reverse switch does not work, turn off the
machine and reassemble following the instructions
given. After reassemble, please try turning on the
machine.
07
How to disassemble and clean
Turn machine “Off”.
Twist the hopper to unlock by
grabbing the two ejections.
Make sure the arrow is aligned
with the open sign before pulling
off the bowl.
Use the brush to clean
thoroughly after operating.
Do not use metal sponge to clean,
it will damage the machine.
Do not use dishwasher to clean.
Do not rinse the base with
direct water, use dry towel or
wet towel to clean.
Order to disassemble.
08
rev
on
1.Hopper
2.Auger
3.Strainer
4.Auto cleaning
brush
5.Bowl
Please dry the attachments
after cleaning.
Before requesting for repair service
Please check when
Machine does not
operate.
a. Check if the power cord has been plugged in correctly.
b. Check if the assembly has been done correctly.
c. Call customer service.
The juice does not disch
-arge suffciently or there
is juice discharging from
the pulp ejector.
Machine is stopped.
Making “squeaking”
noise when making
juice.
a. Check if the rubber pad has been installed correctly.
b. Check if the fruits, vegetables, etc is fresh material.
a. Check if there are too much materials put in at once.
b. Check if the hard seeds are removed.
- Turn off the machine and try the reverse button for 2-3
seconds then try operating again.
This sound is perfectly normal when making juice. It is the
sound of juice being squeezed by the squeezing screw.
The machine shakes.
This shaking is perfectly normal.
It is the sign of the motor is working properly.
09
Product Specification
10
Specification
Product Name
Model Name
Voltage
Frequency
Power Consumption
RPM
Electrical cord length
Motor
Weight
Width
Dimensions
Standard usage time
Length
Height
Omega Vert Juicer
VRT330
120 V
60Hz
150w
+
70 rpm
-
4.592 ft +
Single –Phase induction
11 lbs
7.08 in
9.84 in
10.74 in
Less than 30 minutes continuously
