Handheld Digital
Thermometers
HH508
Optional
U NEMA 4X Dustproof
U Water/Splash Resistant
U Warning Beeper with
Hi/Lo Setting, Time Setting
U Clock and Elapsed Time
U 0.1° Resolution
U Differential
Thermocouple Input
U Stated Accuracy
@ 23 ± 5°C<75% RH
U Battery Life: 200 Hours
U Dimensions:
192 H x 91 W x 53 mm D
(7.6 x 3.6 x 2.2")
U Weight: Approx 255 g (9 oz)
HH508.
Probes sold
separately.
Please see
omega.com
for details.
Features
U Data Hold
U Max/Min
U Relative
U Hi/Lo Limits with
Beeper Warning
U T1-T2 (HH509 Only)
U Auto Power Off
Specifications
Display Type: Backlit LCD
Number of Digits: 1999
Probe (Type): K/J/E/T/S
Input Channels
HH508: 1
HH509: 2
Temperature Range: -210 to 1767°C
(-346 to 1999°F)
Resolution: 0.1°/1°
Power: One 9V battery (included)
Basic Accuracy: 0.1% +1°C
Free Thermocouple Included!
These models include a free 1 m (40") Type
K insulated beaded wire thermocouple with
subminiature connector and wire spool
caddy (1 per channel). Order a Spare!
Model No. SC-TT-K-30-36
To Order
Model No. Description
HH508 Digital thermometer
HH509 Digital thermometer, dual
HH509R Digital thermometer, dual, with RS232
SC-TT-K-30-36 Spare Type K beaded thermocouple (1 m long)
KTSS-HH 150 mm (6") long, 3 mm (1⁄8") diameter stainless
steel Type K probe with 300 mm (12") retractable
cable [expands to 1.2 m (48")] terminating with
male subminiature connector
HH-NIST NIST-traceable calibration, no points
CAL-3-HH NIST-traceable calibration with points
MN1604 Spare 9V alkaline battery
SC-HH500 Soft carrying case
Ordering Examples: HH508, digital thermometer.
HH509R, dual input digital thermometer with RS232.
L-41
