Page 1
Extension Grade
CHROMEGA®/ALOMEGA®
Duplex
ANSI Color Code: Positive Wire, Yellow;
Negative Wire, Red; Overall, Yellow
ANSI Type KX
To Order Visit omega.com/exgg_rsx_wire for Pricing and Details
AWG Model Type
Insulation No. Number Wire Conductor Overall °C °F Size mm (inch) (lb /1000')
Glass 16 EXGG-K-16 Solid Glass Braid Glass Braid 200 392 2.2 x 3.3 (0.085 x 0.130) 9 (17)
Neoflon 16 EXTT-K-16 Solid PFA PFA 200 392 2.2 x 3.9 (0.086 x 0.152) 8 (16)
PFA 20 EXTT-K-20 Solid PFA PFA 200 392 1.7 x 3.0 (0.068 x 0.116) 4 (9)
24 EXTT-K-24 Solid PFA PFA 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (6)
14 EXPP-K-14 Solid Polyvinyl Polyvinyl 105 221 3.4 x 7.3 (0.134 x 0.288) 13 (28)
16 EXPP-K-16 Solid Polyvinyl Polyvinyl 105 221 3.1 x 5.3 (0.123 x 0.207) 10 (22)
16 EXPP-K-16S 7 x 24 Polyvinyl Polyvinyl 105 221 5.5 x 5.7 (0.139 x 0.226) 10 (22)
Polyvinyl 18 EXPP-K-18S 7 x 26 Polyvinyl Polyvinyl 105 221 3.5 x 5.2 (0.138 x 0.205) 8 (16)
20 EXPP-K-20 Solid Polyvinyl Polyvinyl 105 221 2.4 x 3.8 (0.095 x 0.151) 6 (12)
20 EXPP-K-20S 7 x 28 Polyvinyl Polyvinyl 105 221 3.1 x 4.4 (0.123 x 0.175) 6 (12)
24 EXPP-K-24 Solid Polyvinyl Polyvinyl 105 221 1.9 x 3.0 (0.075 x 0.120) 2 (4)
24 EXPP-K-24S 7 x 32 Polyvinyl Polyvinyl 105 221 2.1 x 3.4 (0.082 x 0.134) 4 (9)
Neoflon 16 EXFF-K-16 Solid FEP FEP 200 392 2.2 x 3.9 (0.086 x 0.152) 8 (16)
FEP 20 EXFF-K-20 Solid FEP FEP 200 392 1.7 x 2.9 (0.068 x 0.116) 4 (9)
24 EXFF-K-24 Solid FEP FEP 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (6)
*
Maximum temperature is for extension grade wire or insulation, whichever is lower.
†
Weight of spool and wire, rounded to next highest kg/lb. (does not include packing material).
††
To order special limits of error wire, add “-SLE” to model number before spool length
Ordering Example: EXTT-K-20-25, 25' spool of extension grade thermocouple wire, Type KX,
20 gage, stranded,
ANSI Color Code: Positive Wire, Purple;
Negative Wire, Red; Overall, Purple
Neoflon PFA insulation
.
AWG Model Type
Insulation
Neoflon 16 EXTT-E-16 Solid PFA PFA 200 392 2.2 x 3.9 (0.086 x 0.152) 8 (16)
PFA 20 EXTT-E-20 Solid PFA PFA 200 392 1.7 x 2.9 (0.068 x 0.116) 4 (9)
24 EXTT-E-24 Solid PFA PFA 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (6)
16 EXPP-E-16 Solid Polyvinyl Polyvinyl 105 221 3.1 x 5.3 (0.123 x 0.207) 10 (22)
Polyvinyl
20 EXPP-E-20 Solid Polyvinyl Polyvinyl 105 221 2.4 x 3.8 (0.095 x 0.151) 6 (14)
24 EXPP-E-24S 7 x 32 Polyvinyl Polyvinyl 105 221 2.1 x 3.4 (0.82 x 0.134) 4 (9)
Neoflon 16 EXFF-E-16 Solid FEP FEP 200 392 2.2 x 3.9 (0.086 x 0.152) 8 (16)
FEP 20 EXFF-E-20 Solid FEP FEP 200 392 1.7 x 2.9 (0.068 x 0.116) 4 (9)
24 EXFF-E-24 Solid FEP FEP 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (6)
* Maximum temperature is for extension grade wire or insulation, whichever is lower.
† Weight of spool and wire, rounded to next highest kg/lb. (does not include packing material).
††
To order special limits of error wire, add “-SLE” to model number before spool length
Ordering Example: EXPP-E-20-50, 50' spool of extension grade thermocouple wire,
Type EX, 20 gage, Polyvinyl over Polyvinyl insulation.
Compensating Extension Wires for Platinum
( - )/Platinum-Rhodium (+) Thermocouples.
ANSI Color Code: Positive Wire, Black; Negative Wire, Red; Overall, Green
No. Number Wire Conductor Overall °C °F Size mm (inch)
18 EXPP-E-18S 7 x 26 Polyvinyl Polyvinyl 105 221 3.5 x 5.2 (0.138 x 0.205) 8 (16)
AWG Model Type
Insulation
Glass 20 EXGG-RS-20 Solid Glass Braid Glass Braid
24 EXGG-RS-24 Solid Glass Braid Glass Braid
Neoflon
PFA
24 EXTT-RS-24 Solid PFA PFA 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (6)
No. Number Wire Conductor Overall °C °F Size mm (inch)
20 EXTT-RS-20 Solid PFA PFA 200 392 1.7 x 2.9 (0.068 x 0.116) 4 (9)
Insulation Max. Temp
Insulation
Max. Temp*
Extension Grade
Copper/Alloy#11
ANSI Type RX and SX
Insulation Max. Temp*
200 392
200 392
* Nominal
Wt.kg/300m
Extension Grade
CHROMEGA®/
ConstantanDuplex
ANSI Type EX
Nominal Wt.kg/300m
(lb/1000')
Duplex
Nominal Wt.kg /300m
(lb/1000')
1.5 x 2.4 (0.060 x 0.095) 3 (6)
1.3 x 2.0 (0.050 x 0.080) 1.8 (1.4)
†
H
†
†
Polyvinyl 16 EXPP-RS-16 Solid Polyvinyl Polyvinyl 105 221 3.0 x 5.0 (0.118 x 0.195) 10 (22)
Neoflon
FEP
*
Maximum temperature is for extension grade wire or insulation, whichever is lower.
†
Weight of spool and wire, rounded to next highest kg/lb. (does not include packing material).
Ordering Example: EXTT-RS-20-500, 500' spool of extension grade thermocouple wire, Type RX, 24 gage,
Neoflon PFA
20 EXFF-RS-20 Solid FEP FEP 200 392 1.7 x 2.9 (0.068 x 0.116) 4 (9)
24 EXFF-RS-24 Solid FEP FEP 200 392 1.4 x 2.3 (0.056 x 0.092) 3 (6)
ANSI
color
insulation.
code
shown
To order
IEC color
code see
omega.com
H-32
