Omcan SE-CN-0358 Operators Manual

14” Impulse Sealers

Models SE-CN-0358, 0361

Items 14432, 14433

Instruction Manual

Revised - 09/18/2019

Toll Free: 1-800-465-0234

Fax: 905-607-0234

Email: service@omcan.com

www.omcan.com

Table of Contents

Model SE-CN-0358 / Model SE-CN-0361

Section

General Information

Safety and Warranty

Technical Specications

Operation

Maintenance

Troubleshooting

--------------------------------------------------------------------------------------------- 6

------------------------------------------------------------------------------------ 6 - 7

--------------------------------------------------------------------------- 3 - 4

--------------------------------------------------------------------------- 4 - 5

-------------------------------------------------------------------------------- 7 - 8

Page

-------------------------------------------------------------------------- 5

Parts Breakdown

Electrical Schematics

Notes

Warranty Registration

------------------------------------------------------------------------------------------- 12 - 14

----------------------------------------------------------------------------- 9 - 10

---------------------------------------------------------------------------- 11

---------------------------------------------------------------------------- 15

2

General Information

Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or negligent use of this equipment. The product shall only be operated by someone over the age of 18, of

sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of the machine while in operation.

CHECK PACKAGE UPON ARRIVAL

Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the external packaging, open carton to ensure all ordered items are within the box, and there is no concealed damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be

lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse

for damaged products that were shipped collect or third party.

Before operating any equipment, always read and familiarize yourself with all operation and safety

instructions.

Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save these instructions for future reference. Also save the original box and packaging for shipping the

equipment if servicing or returning of the machine is required.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de

plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication

de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine ou des personnes à proximité de la machine pendant son fonctionnement.

VÉRIFIEZ LE COLIS DÈS RÉCEPTION

Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage

n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés

sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant

d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager

une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine

doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli

par un tiers transporteur.

3

General Information

Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations et les consignes de sécurité.

Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces

instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour

l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona

mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada. Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la

máquina mientras esta en el funcionamiento.

REVISE EL PAQUETE A SU LLEGADA

Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el

empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes

o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro

de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron

a recoger por terceros.

Antes de utilizar cualquier equipo, siempre leer y familiarizarse con todas las instrucciones de operación y seguridad.

Omcan quisiera darles las gracias por la compra de esta máquina. Es de la máxima importancia para guardar estas instrucciones para referencias en el futuro. También guarde la caja original y el embalaje

para envío del equipo si el mantenimiento o la devolución de la máquina es necesaria.

Safety and Warranty

• This machine should only be installed and operated by trained personnel. Do not change the electrical wiring of the machine.

• Read all instructions carefully and do not operate the machine until the operator has fully read this manual.

• Do not use the machine without the personal safety equipment.

• Keep hands, long hair, foreign objects, clothes and jewelry away from any moving parts.

• Do not leave the machine unattended while the unit is on or in operation.

• Always turn off and unplug the unit before performing any maintenance.

4

Safety and Warranty

1 YEAR PARTS AND LABOR WARRANTY

Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized

service technician to repair the equipment locally.

Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not

improper use.

Please see https://omcan.com/disclaimer for complete info.

WARNING:

The packaging components (cardboard, polyethylene, and others) are classied as normal solid urban waste and can therefore be disposed of without difculty.

In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms.

DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

Technical Specications

Model SE-CN-0358 SE-CN-0361 Description 14” seal bar - 2mm seal width 14” seal bar - 5mm seal width Electrical 110V / 60Hz / 1Ph Weight 42 lbs. / 19 kgs.

Packaging Weight 45 lbs. / 20.4 kgs.

Dimensions 20.75” x 16.5” x 33.5” / 527 x 419 x 851mm

Packaging

Dimensions Item Number 14432 14433

21.5” x 31” x 10” / 546 x 787 x 254mm

5

Operation

Fig. 1 - Diagram of the control panel for the impulse sealer

ADJUSTMENT AND USAGE OF IMPULSE SEALER

Connect to 110V power source according to the indication label on the machine. Switch on the power, the red light will turn on. Adjust the sealing time according to the materials and the thickness of the bags to be sealed.

The sealing time should be adjusted to around grade 1 before sealing. Put the opening of the bag between

the heat sealers, step down on the pedal and the yellow lamp lights. Take out the sealed bag after the yellow lamp is off. If the seal is not tight enough, lengthen the sealing time. Try sealing the bag several times until it is sealed well with clearness and no wrinkles. Seal the bag at this measured time and temperature. The cooling time should not be too short, otherwise wrinkles will be the result. The longer the sealing time, the longer the cooling time.

Maintenance

Never try to seal without bags. Don’t set the sealing time to the high grade without trial of the sealing bag. Otherwise, the polymer cloth will be burned. If some plastics adheres to the polymer cloth, never try to scrape it off. Slightly reduce the sealing time and seal the bag again. Release the pedal after the yellow lamp is off. It is very important to remove the bag from one side to the other. The remains of the plastics will be cleared from the polymer cloth with the bag.

REPLACEMENT OF THE HEATER

Turn off sealer and unplug from the wall. Loosen the screws of the plate pressing the polymer cloth, roll back the cloth to expose the heater. Loosen the Bakelite boxes at both sides of the heater and take out the screws on the copper block. The heater can now be removed. Replace it with a new one. The heater should always be in tension with the function of the spring. The copper block should be replaced if it is oxidized, to ensure

it has a good connection with the heater. Pay close attention when xing the heater so that the polymer cloth below is at (no wrinkles are allowed). The heater must have a excellent isolation. Otherwise the heater will be

6

Maintenance

damaged because of the short-circuiting.

REPLACEMENT OF THE POLYMER CLOTH

Turn off sealer and unplug from the wall. Remove the screws and the plates above the polymer cloth, loosen the shaft of the polymer cloth roll, pull out the cloth and cut out the burned part. Reassemble the plates and

screws, tighten the roll shaft. No wrinkles are allowed in the polymer cloth, otherwise the seal quality will be

affected.

REPLACEMENT OF THE MICRO-SWITCH

Turn off sealer and unplug from the wall. There is one micro-switch at the side of the machine head. It must be replaced when it is damaged. The adjustment of the pressing pole for micro-switch are as follows:

• Put 1mm thick carton between the upper and lower and lower pressing arms, check if the micro-switch is

pressed and if there is a “click” from the switch.

• If it is not pressed, adjust down the pressing pole or tighten the nut until the switch is pressed 1-2mm down when it works.

• Always keep the sealing surface clean. Otherwise, the remains in the sealing surface will shorten the life of the heater and the life of the polymer cloth.

• When working, never try to clean the sealing surface with wet cloth.

• After long time usage, the rubber in the upper pressing arm must be checked if it is still at and straight. Otherwise, the seal quality will be affected.

• Often add lubricating oil into the moving parts.

• All parts in the machine should not be disassembled regularly.

Troubleshooting

Problem Causes and Solution

The seal is not good. Lengthen the sealing time if it is not tight enough. Shorten the sealing

time if the seal is melted or if the melted seal is creased by not being pressed tightly.

The seal is wrinkled. 1. The problem may be overheating. In this case, shorten the

sealing time.

2. The problem may be insufcient time for cooling. In this case, lengthen the cooling time.

The temperature rises when working for some time.

The power lamp does not light and the sealer does not work.

It is normal that the temperature of the machine rises because the unit absorbs heat during operation. Shorten the sealing time slightly to balance the heat.

Check if the power switch is on and if the fuse is damaged.

7

Troubleshooting

The power lamp lights but the sealing lamp is off and the sealer does not work.

The sealer is always electried when

the power is switched on.

Step down on the pedal to check if the micro-switch works. Adjust if

necessary (see “REPLACEMENT OF MICRO-SWITCH).

Switch the power off at once. Check the status of the micro-switch.

Adjust if necessary (see “REPLACEMENT OF MICRO-SWITCH).

REFERENCE

Item Number Model Number Description Manufacturer Model Number

Sealer Impulse Foot Operated

14432 SE-CN-0358

14433 SE-CN-0361

14” / 356mm Seal Bar 2mm Seal Width

110V/60/1 cQPSus

Sealer Impulse Foot Operated

14” / 356mm Seal Bar 5mm Seal Width

110V/60/1 cQPSus

F3502

F3505

8

Model SE-CN-0358 14432 Model SE-CN-0361 14433

Parts Breakdown

9

Parts Breakdown

Model SE-CN-0358 14432 Model SE-CN-0361 14433

Item No. Description Position Item No. Description Position Item No. Description Position

75287 Machine Base for F3502 & F3505 KS1 75311 Upper Sealing Shelf for F3502 & F3505 KS25 75341 Touching Board for F3502 & F3505 KS55-56

75288 Bolt for F3502 & F3505 KS2 75312

75289 Pedal Board for F3502 & F3505 KS3 75313 Flexible Mat for F3502 & F3505 KS27 75345 Buttery Nuts for F3502 & F3505 KS59

75290 Flat Washer for F3502 & F3505 KS4 75314

75291 Nut for F3502 & F3505 KS5 75315 Flexible Mat for F3502 & F3505 KS29 75347 Bolt for F3502 & F3505 KS61

75292 Bolt for F3502 & F3505 KS6 75316 Flat Washer for F3502 & F3505 KS30 75348 Insulated Pad for F3502 & F3505 KS62

75293 Adjusting Bolt for F3502 & F3505 KS7 75317

75294 Buttery Nut for F3502 & F3505 KS8 75318 Bolt Groups for F3502 & F3505 KS32 75350

75295 Bolt Groups for F3502 & F3505 KS9 75319

75296 Pedal Board Tie for F3502 & F3505 KS10 17737 Silicon Rubbers for F3502 & F3505 KS34 75352 Insulated Pad for F3502 & F3505 KS66

75297 Connecting Nut for F3502 & F3505 KS11 75321 Spring for F3502 & F3505 KS35 75353

75298 Coupler Tie for F3502 & F3505 KS12 75322

75299 Upright Column Base for F3502 & F3505 KS13 75323

75300 Machine Cover for F3502 & F3505 KS14 75324 Flexible Pin for F3502 & F3505 KS38 75356

75301 Nut for F3502 & F3505 KS15 75325 Tie for F3502 & F3505 KS39 75357 Flat Cushion for F3502 & F3505 KS71

75302

75303 Wire Guider for F3502 & F3505 KS17 75327 Washer for F3502 & F3505 KS41 75359 Flat Mat for F3502 & F3505 KS73

75304

75305

75306 Bolt for F3502 & F3505 KS20 75364 Ceramic Base for F3502 & F3505 KS44-50 75358 Bolt Groups for F3502 & F3505 KS76

75307 Operation Panel for F3502 & F3505 KS21 75337 Polymer for F3502 & F3505 KS51 75360 Bolt Groups for F3502 & F3505 KS77

75308 Countersink Screw for F3502 & F3505 KS22 75338 Axles for Polymer for F3502 & F3505 KS52 75364 Ceramic Base for F3502 & F3505 KS78-84

75309 Bolt Groups for F3502 & F3505 KS23 75339 Buttery Nut for F3502 & F3505 KS53 75329 Plastic Cover for F3502 & F3505 KS85

75310

Screw and Flat Gasket for F3502 & F3505

Cross Recessed Pan Head Screw for F3502 & F3505

Transformers and Back Cover for F3502 & F3505

Tetrauorohydrazine Convention for

F3502 & F3505

KS16 75326 Rubber Cushion for F3502 & F3505 KS40 75358 Bolts Groups for F3502 & F3505 KS72

KS18 75328 Cap Nuts for F3502 & F3505 KS42 75360 Bolts Groups for F3502 & F3505 KS74

KS19 75329 Plastic Cover for F3502 & F3505 KS43 75361 Flat Mat for F3502 & F3505 KS75

KS24 75340 Hold-Down Plate for F3502 & F3505 KS54

Tetrauorohydrazine Convention for

F3502 & F3505

Inner Hex Screw and Nut for F3502 & F3505

Tetrauorohydrazine Convention for

F3502 & F3505

Upper Sealing Silicon Fasten Block for F3502 & F3505

Inner Hex Screw and Nut for F3502 & F3505

Small Connecting Board for F3502 & F3505

KS26 75342 Switch Shelf for F3502 & F3505 KS57-58

KS28 75346 Pressor for F3502 & F3505 KS60

KS31 75349 Bolt for F3502 & F3505 KS63

Countersink Flat Head Screws for F3502 & F3505

KS33 75351 Heater for F3502 & F3505 KS65

Lower Sealing Fasten Base for F3502 & F3505

KS36 75354 Polymer Pressor for F3502 & F3505 KS68

KS37 75355

Cross Recessed Pan Head Screw for F3502 & F3505

Fasten Board of Working Table for F3502 & F3505

KS64

KS67

KS69

KS70

10

Model SE-CN-0358 14432 Model SE-CN-0361 14433

Electrical Schematics

11

Notes

________________________________________________________________________________________

12

Notes

________________________________________________________________________________________

13

Notes

________________________________________________________________________________________

14

Warranty Registration

Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at

the perforation and then send to the address specied below. You can also register online by visiting:

Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:

Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación, cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:

https://omcan.com/warranty-registration/

For mailing in Canada

Pour postale au Canada

Por correo en Canadá

OMCAN

PRODUCT WARRANTY REGISTRATION

3115 Pepper Mill Court,

Mississauga, Ontario

Canada, L5L 4X5

PRODUCT WARRANTY REGISTRATION

4450 Witmer Industrial Estates, Unit 4,

For mailing in the US

Pour diffusion aux États-Unis

Por correo en los EE.UU.

OMCAN

Niagara Falls, New York

USA, 14305

or email to: service@omcan.com



Purchaser’s Information

Name: Company Name:

Address:

Telephone:

City: Province or State: Postal or Zip: Email Address:

Country: Type of Company:

Restaurant Bakery Deli

Dealer from which Purchased: Butcher Supermarket Caterer

Dealer City: Dealer Province or State: Institution (specify):

Invoice: Other (specify):

Model Name: Model Number: Serial Number:

Machine Description:

Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):

Would you like to extend the warranty? Yes No

Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

15

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers. Today with partners in North America, Europe, Asia and South America, we continually work to improve

and grow the company. We strive to offer customers exceptional value through our qualied local sales

and service representatives who provide convenient access to over 5,000 globally sourced products.

Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à

nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 5000

produits provenant du monde entier.

Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan

continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor

excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un fácil acceso a más de 5,000 productos con origen a nivel mundial.

Omcan SE-CN-0358 Operators Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
