Omcan MG-BR-0022 Operators Manual

Meat Grinder

Model MG-BR-0022

Item 11067

Instruction Manual

Revised - 04/25/2019

Toll Free: 1-800-465-0234

Fax: 905-607-0234

Email: service@omcan.com

www.omcan.com

Table of Contents

Model MG-BR-0022

Section

General Information

Safety and Warranty

Technical Specications

Installation

Operation

Maintenance

--------------------------------------------------------------------------------------- 6 - 7

----------------------------------------------------------------------------------------- 7 - 8

----------------------------------------------------------------------------------------- 8

--------------------------------------------------------------------------- 3 - 4

--------------------------------------------------------------------------- 4 - 6

Page

-------------------------------------------------------------------------- 6

Parts Breakdown

Electrical Schematics

Notes

Warranty Registration

------------------------------------------------------------------------------------------- 12 - 14

----------------------------------------------------------------------------- 9 - 10

---------------------------------------------------------------------------- 11

---------------------------------------------------------------------------- 15

2

General Information

Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or negligent use of this equipment. The product shall only be operated by someone over the age of 18, of

sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of the machine while in operation.

CHECK PACKAGE UPON ARRIVAL

Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the external packaging, open carton to ensure all ordered items are within the box, and there is no concealed damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be

lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse

for damaged products that were shipped collect or third party.

Before operating any equipment, always read and familiarize yourself with all operation and safety

instructions.

Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save these instructions for future reference. Also save the original box and packaging for shipping the

equipment if servicing or returning of the machine is required.

--------------------------------------------------------------------------------------------------------------------------------------------------Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de

plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication

de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine ou des personnes à proximité de la machine pendant son fonctionnement.

VÉRIFIEZ LE COLIS DÈS RÉCEPTION

Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage

n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés

sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant

d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager

une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine

doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli

par un tiers transporteur.

3

General Information

Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations et les consignes de sécurité.

Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces

instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour

l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.

--------------------------------------------------------------------------------------------------------------------------------------------------Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona

mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada. Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la

máquina mientras esta en el funcionamiento.

REVISE EL PAQUETE A SU LLEGADA

Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el

empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes

o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro

de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron

a recoger por terceros.

Antes de utilizar cualquier equipo, siempre leer y familiarizarse con todas las instrucciones de operación y seguridad.

Omcan quisiera darles las gracias por la compra de esta máquina. Es de la máxima importancia para guardar estas instrucciones para referencias en el futuro. También guarde la caja original y el embalaje

para envío del equipo si el mantenimiento o la devolución de la máquina es necesaria.

Safety and Warranty

GENERAL SAFETY REGULATIONS

This meat grinder is designed to grind meat products safely and efciently. Unless the operator is properly

trained and supervised, however, there is the possibility of a serious injury. It is the responsibility of the owner to ensure that this machine is used properly and safely, strictly following the instructions contained in this

manual and any requirements of local law.

4

Safety and Warranty

This machine can be potentially dangerous when used incorrectly. Therefore, read all the following instructions carefully to avoid damage:

• Before cleaning, disconnect machine from power source.

• Always turn machine off in case of power supply lack.

• Provide enough space around machine to avoid breakings.

• Never use tools not belonging to machine to help operation.

• Never feed by hand; always use stomper.

• Never put your ngers or any other object but the stomper inside the feed throat.

• Never connect power source with wet hands or wet clothes.

• Never spray water or other liquid substances directly at motor, power switch, or any other electrical

components.

• Keep your working area clean and dry to prevent it from becoming slippery.

• Always install equipment in working area with adequate light and space away from children and visitors.

• Never operate without all warning labels attached and owner/operator manual available to operator.

• Never leave unattended while operating.

• Stop the machine immediately if you hear abnormal noises to prevent injuries.

• Never let dust or water get into electrical and mechanical comp machine.

• Always ground machine properly.

• Do not modify original features of the machine.

• Do not take out nor tear off any safety or identication label.

• Contact your distributor if you have any problems with the installation and operation of this machine.

1 YEAR PARTS AND LABOR BENCH WARRANTY

Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the

equipment.

Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not

improper use.

Please see https://omcan.com/disclaimer for complete info.

WARNING:

The packaging components are classied as normal solid urban waste and can therefore be disposed of without difculty.

In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms.

5

Safety and Warranty

DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

Technical Specications

Model MG-BR-0022 Power 2 HP / 1.47 kW

Throat 1 5/8” / 41mm RPM on Motor 1750 RPM on Worm 150 Electrical 110V / 60Hz / 1Ph Weight 89.8 lbs. / 40.7 kg.

Dimensions (DWH) 28” x 13” x 24.8” / 711 x 330 x 629mm

Item Number 11067

Installation

MAIN COMPONENTS

The machine consists of an electrical motor that, through a gear box, operates a worm. The worm feeds the meat to the knife and hole plate. Several types of hole plates are available. The holes on these plates have different diameter. The type of plate is chosen depending on the desired ground meat characteristics.

The feed throat (No. 02; Figure 1) and worm (No. 03; Figure

2) receive an special treatment to isolate and facilitate the cleaning.

The knife (No. 05; Figure 2) and disc (No. 06; Figure 2) are made of hard material to provide a long life cutting quality.

INSTALLATION OF THE GRINDER

• The meat grinder must be installed on a level, non-skid surface with a maximum recommended height of 850 mm by qualied or experienced people.

• There should have a suitable space for the tray to collect

processed meat in front of the grinding device.

01. Stomper

02. Feed Throat

03. Locking Ring

04. Tray

05. Motor Housing

06. ON/OFF Switch

Figure 1

6

Installation

• Check the voltage of the machine. The unit voltage must be the same as the power source.

• Grounding wire must always be connected.

Operation

PRE-OPERATION

• Check if the machine is rm; no movement shall be allowed on the supporting surface.

• It is recommended that the machine be carefully cleaned before rst operation.

• Clean the grinder as explained in the maintenance section.

• After cleaning, reassemble the components in the following order: barrel, ber washer, worm, worm pin, knife, plates, and locking ring (See Figure 2).

• Then check if all removable components are reassembled properly.

• Turn locking ring (No. 07) counterclockwise until it applies a slight pressure on the hole plate and on the

knife.

NOTE: Do not tighten the locking ring too much, as an excessive pressure on the hole plate and knife may lead to their abnormal wear.

01. Barrel

02. Fiber Washer

03. Worm

04. Worm Pin

05. Knife

06. Plates: 3 mm, 5 mm or 8 mm (optional)

07. Locking Ring

NOTE: Assemble the components following the order shown above (Figure 2). It is recommended that you

follow the order carefully. Assembling the components in a different order could cause serious damages to

the grinding device. When re-installing the knife in the worm stud, make sure that the cutting edge is facing

outwards.

After following the pre-operation instructions, your meat grinder is now ready to operate.

Figure 2

7

Operation

OPERATING THE MEAT GRINDER

1. Start the machine. This meat grinder is very high speed and, therefore, needs a fast feeding too.

2. Put the meat lumps on the tray.

3. Using the stomper (No. 01; Figure 1), push the meat into the feed throat where they will be sucked in by

the worm.

4. Feed meat at a constant rate for better grinding.

IMPORTANT: Only use the stomper to push the meat into the feed throat; never use your hands or any other kind of instrument. It is strongly recommended that the meat chopper is not being operated without meat in feed. Therefore, never let the machine to work without loading. If it happens, the temperature may rise as high

as 180°F in approximately 3 minutes, causing serious damages to the grinding components. Never leave any

kind of knives, metal hooks, or other instruments on the tray.

Maintenance

Clean the machine before rst use and after use. To do the cleaning, proceed as follows:

• Turn off the machine and disconnect it from power source.

• Remove pusher (No. 01; Figure 1) and tray (No. 04; Figure 1).

• Remove Locking Ring (No. 03; Figure 1), turning it clockwise, and the internal components of the barrel,

pulling them out.

NOTE: Do not try to pull the plate, knife, and worm out off the barrel as this may result in serious injury to the hands.

• To remove the barrel, loosen the locking knob located on the left side of the barrel with both hands, and move it to the left and right pulling it at the same time.

• Proceed washing the components with warm water and neutral soap.

• Wipe the body of the machine with a damp clean cloth.

REFERENCE

Item Number Model Number Description Manufacturer Model Number

11067

MG-BR-0022

Meat Grinder #22 Stainless Steel

2 HP/1491 W 110V/60/1

PSEE22

8

Model MG-BR-0022 11067

Parts Breakdown

9

Parts Breakdown

Model MG-BR-0022 11067

Item No. Description Position Item No. Description Position Item No. Description Position

38388 PFS SEX UNC1/4x1 RTZB for PSEE22 00035.3 38530

38531 PCA SEX UNC 3/8 ZB for PSEE22 00108.2 69361 Nylon Cape CN-4478 for PSEE22 03678.1 38521 Cover. Compl. Low. for PSEE22 17400.9

30258 Washer L 5/16 ZB for PSEE22 00119.8 69362

69355

69356 Wireless Steel Mixer 092231 for PSEE22 00218.6 69363 PFS M8x20 DIN 933 ZB for PSEE22 04474.1 38544 CS Cover Back Cover for PSEE22 17403.3

38525 Screw B.6 3x19 for PSEE22 00291.7 21578 Knob with Bar M10x30mm for PSEE22 04511.0 30050 Terminal Cover for PSEE22 17582.0

24022 Fiber Washer #22/98 for PSEE22 00477.4 38523 Rubber Cover for PSEE22 05065.2 38528 Term.Positiv Lock 2 A 4 for PSEE22 17628.1

21843 Ball Bearing 6001 for PSEE22 00738.2 17511 Worm Pin for PSEE22 08854.4 21580 Complete Tray for PSEE22 17634.6

69357 Term. Pre-Isol.EF-4228 for PSEE22 01213.0 21577 Oil Cap PSN/EE-CMSE for PSEE22 08900.1 17515 Pusher for PSEE22 18081.5

38520 Screw M5x6 DIN for PSEE22 01648.9 21845 Lubrication Tube for PSEE22 08948.6 21846 Complete Head Low #22 for PSEE22 18224.9

21581 Wheel for PSEE22 01656.0 38533 Foot Prolongation for PSEE22 09519.2 20203 Head Cylinder for PSEE22 18225.7

11078

11220

11221

69358

21844 Worm Gear for PSEE22 02720.0 38526 Exhauster Ring for PSEE22 13888.6 69364

38534 PFS M8x25 DIN 933 ZB for PSEE22 02728.6 21842 Fiber Gear for PSEE22 14791.5 27720 Omcan Logo (Machines) for PSEE22 27154.3

69359 PFS M6x8 DIN 916 INOX for PSEE22 03188.7 38536 Gear Box with Pin for PSEE22 14891.1 45648

69360 PFS M8x10 DIN 933 ZB for PSEE22 03196.8 21841 Voltage Selector for PSEE22 15843.7 78551 Cleaning Maintenance Label for PSEE22 50665.6

Helmet K22 (T-50R) (Half) (Comp) for PSEE22

#22 European Style Hard Steel Machine Knife for PSEE22

#22 European Style Hard Steel, Hubless Machine Plate 3.2mm for PSEE22

#22 European Style Hard Steel, Hubless Machine Plate 4.8mm for PSEE22

Retainer 00784BR1 (F.0122) DI.19xDE.35 for PSEE22

00210.0 30038 Screw M3x6 DIN 84 ZB for PSEE22 04208.0 38532 CS Base Low (Grey) for PSEE22 17402.5

01657.8 38527 Cord 3x2.5mm2 for PSEE22 09551.6 38542 Copper Tube for PSEE22 19566.9

01658.6 38093 Rubber Foot M8x15mm for PSEE22 09627.0 38541 Meat Mincer Staple for PSEE22 19568.5

01659.4 17513 Worm without Pin for PSEE22 10843.0 38539 Gear Box Lid (C.Martel.) for PSEE22 19647.9

01741.8 38581 Motor Gear for PSEE22 13831.2 38050 Caution Label for PSEE22 22814.1

PFS SEX UNC3/8x2.3/4 RPZB for PSEE22

T-18R-Small Holder (Compr.100m) for PSEE22

03214.0 38529 Wire Connection Key L/D for PSEE22 15844.5

04203.0 38543 CS Coverage for PSEE22 17401.7

Thread 1.5x200mm Green / Yellow for PSEE22

On/Off Switch Black C/Prot.30223 M2FT2FE3V for PSEE22

26476.8

30565.0

10

Model MG-BR-0022 11067

ON/OFF Switch

Electrical Schematics

11

Notes

________________________________________________________________________________________

12

Notes

________________________________________________________________________________________

13

Notes

________________________________________________________________________________________

14

Warranty Registration

Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at

the perforation and then send to the address specied below. You can also register online by visiting:

Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:

Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación, cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:

https://omcan.com/warranty-registration/

For mailing in Canada

Pour postale au Canada

Por correo en Canadá

OMCAN

PRODUCT WARRANTY REGISTRATION

3115 Pepper Mill Court,

Mississauga, Ontario

Canada, L5L 4X5

PRODUCT WARRANTY REGISTRATION

4450 Witmer Industrial Estates, Unit 4,

For mailing in the US

Pour diffusion aux États-Unis

Por correo en los EE.UU.

OMCAN

Niagara Falls, New York

USA, 14305

or Email to: service@omcan.com



Purchaser’s Information

Name: Company Name:

Address:

Telephone:

City: Province or State: Postal or Zip: Email Address:

Country: Type of Company:

Restaurant Bakery Deli

Dealer from which Purchased: Butcher Supermarket Caterer

Dealer City: Dealer Province or State: Institution (specify):

Invoice: Other (specify):

Model Name: Model Number: Serial Number:

Machine Description:

Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):

Would you like to extend the warranty? Yes No

Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

15

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers. Today with partners in North America, Europe, Asia and South America, we continually work to improve

and grow the company. We strive to offer customers exceptional value through our qualied local sales

and service representatives who provide convenient access to over 5,000 globally sourced products.

Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à

nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 5000

produits provenant du monde entier.

Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un fácil acceso a más de 5,000 productos con origen a nivel mundial.

Omcan MG-BR-0022 Operators Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
