Parts Breakdown
Model G326 41219 General Assembly
1
Parts Breakdown
Model G326 41219 Evaporator Assembly
2
Parts Breakdown
Model G326 41219 Condenser Assembly
3
Parts Breakdown
Model G326 41219 Door Assembly
4
Parts Breakdown
Model G326 41219 General Assembly
Item No. Description Position Item No. Description Position Item No. Description Position
66529 Pilaster, 1268 6B Diam 6.35 for G326 1 66532 Shelf, G322x26 for G326 4 66534
66530
66531 Grill, Wire Rear for G326 3 66533 Baseboard, PE Rail ARG G3 for G326 6
Controller. ELE BEV 115V N/SEN for
G326
2 66399 Clip, F/Pilaster 16G Polished for G326 5
Evaporator Assembly
Item No. Description Position Item No. Description Position Item No. Description Position
66535
66469 Temp Sensor, ETC1H 1.0M for G326 2 66475
Evaporator 20T 3/8 CU 6FPI FIL491 PAH
for G326
1 66409 Nylon Motor Ring for G326 3 66477
Motor, E ELC 16W 115V 50/60HZ
1850RPM for G326
4 66510 Evaporator Housing ABS for G326 6
Front Grill, Ther BK VL300 L/R Hinge
for G326
Fan Blade ELC PLA 8” Diam. 28 Deg.
for G326
7
5
Condenser Assembly
Item No. Description Position Item No. Description Position Item No. Description Position
66536 LED Driver, VDM#3017356 for G326 1 66475
66537
66518 ABS Condenser Pan EV46x72 for G326 3 66446 ABS Motor Evaporator Support for G326 6
Condenser, NFI 72T 5/16 CU V225 Diam.
for G326
2 66477
Motor, E ELC 16W 115V 50/60HZ
1850RPM for G326
Fan Blade ELC PLA 8” Diam. 28 Deg.
for G326
4 66538
5 66425 Power Cord 115V 15A 14AWG for G326 8
Compressor SEC NF 11FX 115V 60HZ
for G326
7
Door Assembly
Item No. Description Position Item No. Description Position
66539 Hinge, Met Top UNI Slope for G326 1 66541 Door G J LEF LED SCS BDH for G326 3
66540 HINGE, Met Bot UNI SCS TR31 for G326 2 66542 Door G J RIG LED SCS BDH for G326 4
5
