Omcan BE-IT-0406 User Manual

Pizza Dough Molder

Model BE-IT-0406

Item 13177

Instruction Manual

Revised - 07/25/2016

Toll Free: 1-800-465-0234

Fax: 905-607-0234

Email: service@omcan.com

www.omcan.com

Table of Contents

Model BE-IT-0406

Section

General Information

Safety and Warranty

Technical Specications

Installation

Operation

Maintenance

---------------------------------------------------------------------------------------- 6 - 7

----------------------------------------------------------------------------------------- 8 - 9

--------------------------------------------------------------------------------- 10 - 11

--------------------------------------------------------------------------- 3 - 4

--------------------------------------------------------------------------- 4 - 5

Page

-------------------------------------------------------------------------- 5

Troubleshooting

Illustrated Drawings

Parts Breakdown

Electrical Schematics

Notes

Warranty Registration

-------------------------------------------------------------------------------------------16 - 18

----------------------------------------------------------------------------------- 11

---------------------------------------------------------------------------- 13 - 14

------------------------------------------------------------------------------ 12

---------------------------------------------------------------------------- 15

---------------------------------------------------------------------------- 19

General Information

Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or negligent use of this equipment. The product shall only be operated by someone over the age of 18, of

sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of the machine while in operation.

CHECK PACKAGE UPON ARRIVAL

Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the external packaging, open carton to ensure all ordered items are within the box, and there is no concealed damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be

lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse

for damaged products that were shipped collect or third party.

Before operating any equipment, always read and familiarize yourself with all operation and safety

instructions.

Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save these instructions for future reference. Also save the original box and packaging for shipping the

equipment if servicing or returning of the machine is required.

--------------------------------------------------------------------------------------------------------------------------------------------------Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de

plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication

de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine ou des personnes à proximité de la machine pendant son fonctionnement.

VÉRIFIEZ LE COLIS DÈS RÉCEPTION

Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage

n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés

sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant

d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager

une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine

doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli

par un tiers transporteur.

General Information

Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations et les consignes de sécurité.

Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces

instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour

l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.

--------------------------------------------------------------------------------------------------------------------------------------------------Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona

mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada. Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la

máquina mientras esta en el funcionamiento.

REVISE EL PAQUETE A SU LLEGADA

Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el

empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes

o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro

de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron

a recoger por terceros.

Antes de utilizar cualquier equipo, siempre leer y familiarizarse con todas las instrucciones de operación y seguridad.

Omcan quisiera darles las gracias por la compra de esta máquina. Es de la máxima importancia para guardar estas instrucciones para referencias en el futuro. También guarde la caja original y el embalaje

para envío del equipo si el mantenimiento o la devolución de la máquina es necesaria.

Safety and Warranty

The following safety instructions must be followed in order to prevent hazardous conditions and/or possible

injuries caused by electricity, mechanical parts, re or of a hygienic nature. Failure to follow these instructions

can be an element of danger for the user.

• Keep the workplace tidy at all times. Untidiness leads to the danger of accidents.

• Assess the environmental conditions. Do not use the machine on damp, wet or poorly lit premises, or

near ammable liquids or gas. Keep a clearance of at least 50 cm from the machine.

• Keep children and unauthorised people away. Do not let them come near the machine or the workplace.

Safety and Warranty

• Use the machine within the rating plate power and only for the use allowed. Without overloading

it, it will work better and be safer. When the machine is working the surfaces inside the chambers, those adjacent and the glass fronted doors get extremely hot and can be a burning hazard.

• Dress appropriately. Do not wear clothes or accessories that hang that could get caught in moving parts.

Wear slip-proof shoes. For hygiene reasons, as well as safety, wear a hairnet for long hair and gloves to

protect hands.

• Protect the power cable. Do not pull on the cable to take it out of the socket. Do not expose the cable to

high temperatures. Do not let the cable touch sharp edges, water or solvents.

• Avoid insecure positions. Find the most suitable position to guarantee your balance at all times.

• Always be very careful. Pay attention to your work. Do not use the machine when you are distracted.

• Take the plug out of the socket. After each use of the machine and before cleaning, servicing or moving

it. The specications of the power outlet must be compatible with the plug tted on the cable.

• Extension leads in the open. It must not be used.

• Check that the machine is not damaged. Before using the appliance, check carefully that the safety

devices are working efciently. Check that the movable parts are not jammed, that there are no damaged components, that all the parts have been mounted correctly, and that all the conditions that could inuence

the proper working order of the appliance are ideal.

• Always have qualied personnel repair the machine. Repairs must be done by qualied personnel only

and with original spare parts.

1 YEAR PARTS AND BENCH WARRANTY

Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the

equipment.

Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not

improper use.

Please see www.omcan.com/warranty.html for complete info.

WARNING:

The packaging components are classied as normal solid urban waste and can therefore be disposed of without difculty.

In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms.

DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

RESPONSIBILITIES OF THE USER

Technical Specications

Model BE-IT-0406 Power 0.5 HP

Dough Weight 7.5 oz.-24.5 oz. / 212.6 - 694.5 g.

Pizza Diameter 11” - 15.75” / 279.4 - 400 mm

Electrical 110 V / 60Hz / 1Ph

Dimensions (DWH) 17” x 22” x 28” / 431.8 x 558.8 x 711.2 mm Packaging Dimensions 31” x 24” x 23” / 787.4 x 609.6 x 584.2 mm Packaging Weight 79 lbs. / 35.8 kg.

Item Number 13177

Installation

This machine is designed and made exclusively for use with food for cold rolling dough for bread and cakes with the aim of facilitating the forming of discs (without altering the dough’s fundamental characteristics) in the preparation of:

• pizzas;

• bread;

• at bread,

• buns, etc.

Each Dough Molder consists of:

• a metallic structure;

• two sets of rollers with relative protections.

The rollers are operated by means of belts, a card controlled electric motor electronic, powered by means of a cable at mains voltage, to which the following are connected at low voltage (12 V.) the front switching on (green) and switching off (red) controls integrated by a pedal connected to an outlet that controls startingstopping.

Read these instructions through carefully before using the machine.

The place, where the machine is to be installed, must have the following environmental characteristics:

• it must be dry;

• the water sources must be at a safe distance;

• ventilation and lighting must be suitable and comply with the hygiene and safety standards foreseen by the

existing laws.
