Omcan BE-CN-2083-FSS User Manual

Dough Sheeter

Model BE-CN-2083-FSS

Item 44135

Instruction Manual

Revised - 11/14/2017

Toll Free: 1-800-465-0234

Fax: 905-607-0234

Email: service@omcan.com

www.omcan.com

QPS

approved

Table of Contents

Model BE-CN-2083-FSS

Section

General Information

Safety and Warranty

Technical Specications

Installation

Operation

Maintenance

-------------------------------------------------------------------------------------------- 6

--------------------------------------------------------------------------------------------- 6

----------------------------------------------------------------------------------------- 7

--------------------------------------------------------------------------- 3 - 4

--------------------------------------------------------------------------- 4 - 5

Page

---------------------------------------------------------------------- 5 - 6

Troubleshooting

Parts Breakdown

Electrical Schematics

Notes

Warranty Registration

------------------------------------------------------------------------------------------------- 14

-------------------------------------------------------------------------------- 7 - 8

----------------------------------------------------------------------------- 9 - 12

---------------------------------------------------------------------------- 13

---------------------------------------------------------------------------- 15

2

General Information

Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or negligent use of this equipment. The product shall only be operated by someone over the age of 18, of

sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of the machine while in operation.

CHECK PACKAGE UPON ARRIVAL

Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the external packaging, open carton to ensure all ordered items are within the box, and there is no concealed damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be

lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse

for damaged products that were shipped collect or third party.

Before operating any equipment, always read and familiarize yourself with all operation and safety

instructions.

Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save these instructions for future reference. Also save the original box and packaging for shipping the

equipment if servicing or returning of the machine is required.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de

plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication

de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine ou des personnes à proximité de la machine pendant son fonctionnement.

VÉRIFIEZ LE COLIS DÈS RÉCEPTION

Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage

n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés

sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant

d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager

une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine

doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli

par un tiers transporteur.

3

General Information

Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations et les consignes de sécurité.

Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces

instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour

l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona

mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada. Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la

máquina mientras esta en el funcionamiento.

REVISE EL PAQUETE A SU LLEGADA

Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el

empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes

o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro

de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron

a recoger por terceros.

Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de

funcionamiento y seguridad.

Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el

envío del equipo si servicio técnico o devolución de la máquina que se requiere.

Safety and Warranty

Thanks for using this high performance, reversible sheeter. It will assist in making bread, cheese, cake and many other products. Before using this machine, please carefully read this manual and follow the procedures to operate the machine.

All the safety devices must be checked before operation. Maintenance should be done immediately when defects or malfunction are found.

4

Safety and Warranty

1. Check the warning signs on the machine.

2. Clean up any water, oil and liquids on the machine immediately when found. This will prevent injury.

3. Keep your body away from any moving part of the machine.

4. Do not let foreign objects enter the machine while operating.

5. Do not climb onto the machine while it is running.

6. If any problems occur in the process of operation, press the Emergency Stop button.

1 YEAR PART AND LABOUR WARRANTY

Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized

service technician to repair the equipment locally.

Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not

improper use.

Please see www.omcan.com/warranty.html for complete info.

WARNING:

The packaging components (cardboard, polyethylene, and others) are classied as normal solid urban waste and can therefore be disposed of without difculty.

In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms.

DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

Technical Specications

Model BE-CN-2083-FSS Description Floor model dough sheeter, stainless steel Electrical 220 V / 60 Hz / 1 Ph

Power 0.5 HP/ 0.37 kW Roller Size 3.5”/ 88mm (Dia.), 20.5”/ 520mm (W)

Roller Adjustable Gap 1-1.4”/ 1 - 35 mm Conveyor Belt Width 19.75”/ 501.7 mm Conveyor Width 22.5”/ 571.5 mm Conveyor Belt Speed 18m/min - 32m/min Roller Speed 124r/min

5

Technical Specications

Maximum Dough Capacity 5 kg/ 11 lbs.

Working Position

Dimensions Resting Position

Dimensions Weight 419lbs. / 190 kgs. Item Number 44135

33.25” x 82” x 41.5” / 749 x 2080 x 1054mm

26” x 63” / 660 x 1600mm

Installation

1. Installation must be performed on a at, dry surface with a stable temperature environment. Press down pedals of active wheels to lock the machine.

2. Follow the instructions on the plaque of electrical cabinet to connect power supply. The breaker for power

supply should be installed on the wall with 1.7 m height from the oor.

3. Pull conveyor straight, put down the table and then put down both safety guards.

4. Then check the movement of the conveyors. Press the left-hand side pedal and the conveyors move left.

Press the right-hand side pedal and the conveyors move right. If the movement is in the wrong direction,

change the two wires of the power supply and re-test the machine.

5. The power cord must be grounded.

Operation

1. When using machine, set up the thickness handle to the farthest left position.

2. Note: do not put hands in or near the safety guard.

3. Switch off the power when cleaning and disconnect the power mains.

4. Turn off power switch and then lift up the safety guards after operation.

The machine needs to be placed in a dry, stable temperature environment. Make sure the safety guards are

always used during operation. To start, use the pedal switch. Press the left-hand side switch and the conveyors move left. Press right-hand side switch, the conveyors will move right. If the movement is opposite from the

desired direction, change the two wires of the power supply and re-test the machine. Make sure the electrical

requirements of the machine correspond with the power supply before operating this machine.

6

Maintenance

REPLACING THE GEARS:

First switch off the power and lift up the safety guards. Then use a screw driver to dismantle the side plate of lower machine body and disconnect the three electrical wires on the connecting box. Then set the thickness handle to scale “O”. Use the alan-key on M5 to open the cover take out the gear housing. Next replace the gears. After replacement, reverse the listed procedures and set the thickness handle to scale “O”.

REPLACING THE DRIVING ROLLER AND BEARING:

Switch off the power and lift up the safety guards. Then use the alan-key to open the cover. Loosen the nuts of bearing using a cross type screw driver to move the bearing through the joint or roller and bearing. Replace the roller and assembly by reversing the listed procedures.

CHANGING THE CONVEYORS:

• Remove the roller by following the procedures mentioned above.

• Apply spanner M8 to take the belts on roller and remove product tray.

• Apply spanner M24 to loosen the nuts of roller.

• Use spanner M16 to loosen the belts of support and separate the table.

• Use spanner M10 to take away the belts from the table holder and separate them.

• Dismantle the table and belts for replacement.

• Complete assembly by reversing the listed procedures.

• The tightness of belts should be correct. When the machine is running press the belts slightly and check if

a slip happened between belts and roller.

CLEANING:

Wash the conveyor belt with clean water after every operation. Do not use the machine until the conveyor belt is completely dry. DO NOT USE EXCESSIVE WATER OR JET SPRAY.

Troubleshooting

Problem Possible Causes

The machine does not work. Is the power supply on?

Is the power switch on?

Has the safety guard been put down?

Lift safety guard, start level and check if you hear a click from the limit switch.

7

Troubleshooting

Electrical cabinet continuously vibrates. Is the belt loose?

Are the wires improperly connected? Is there something inside the electrical cabinet?

The machine only works on one side. Has the breaker failed?

The wiring of the Level or limit switch failed? Is the wiring of the motor incorrect? Is the electricity not three phase?

One conveyor side works while the other side has stopped.

Thickness handle cannot stay xed and falls

downward.

Conveyor moves toward one side during production. Adjusting the nuts to let the belt move straight. For

Noise from roller. Bearing wore out.

Conveyor is too tight. Machine is located in a humid area and this may

The gear is worn out. Conveyor belt is not tight enough. If machine runs smoothly when toward the right-hand

side but does not when toward left-hand side, this means the chain inside the rear of the machine body is too loose. Set the handle at a scale of 15-20, and use a screw driver to open the cover. Apply spanner to adjust motor plate to tighten chain. Check if handle can be operated smoothly.

example, if belt moves toward the rear side, loosen

the front nut. When adjusting the nuts, make sure

that the speed of belt is the same as roller and there are no gaps between the roller and belt.

If noise comes from the pressing roller & scraper and conveyor, something is stuck on the active roller. To clean the active roller simply lift the table. Refer to assembly drawing for active roller and passive roller position.

cause the conveyor to become shorter. If conveyors arc is too tight, loose nuts during regular inspection. If conveyors are too tight, it may:

Not have sufcient horse power.

Damaged bearing & shaft of active roller and passive roller.

Over load and damage to the driving gear.

NOTE: FOR ELECTRICAL AND MECHANICAL REPAIRS, PLEASE CONTACT AN AUTHORIZED AND QUALIFIED TECHNICIAN.

8

Model BE-CN-2083-FSS 44135

Parts Breakdown

9

Parts Breakdown

Model BE-CN-2083-FSS 44135

10

Parts Breakdown

Model BE-CN-2083-FSS 44135

Item No. Description Position Item No. Description Position Item No. Description Position

75900 Thickness Handle for JDR520 1 75943 Cam for JDR520 44 75988 Pin for JDR520 87

75901 Shaft (Handle) for JDR520 2 75944 Cam Housing for JDR520 45 75989 Lower Press Roller for JDR520 88

75902 Bearing for JDR520 3 75945 Washer for JDR520 46 75990 Pin for JDR520 89

75903 Scale for JDR520 4 75946 Bearing for JDR520 47 75991 Holder for JDR520 90

75904 Washer for JDR520 5 75947 Screw for JDR520 48 75992 Bearing Holder for JDR520 91

75905 Screw for JDR520 6 75948 Screw for JDR520 49 75993 Bearing for JDR520 92

75906 Shaft Level for JDR520 7 75949 Washer for JDR520 50 75994 Active Roller for JDR520 93

75907 Screw for JDR520 8 75950 Gear for JDR520 51 75995 Bearing for JDR520 94

75908 Holder for JDR520 9 75951 Shaft for JDR520 52 75996 Holder for JDR520 95

75909 Screw for JDR520 10 75952 Gear Housing for JDR520 53 75997 Shaft for JDR520 96

75910 Hold Plate for JDR520 11 75953 Lockwasher for JDR520 54 75998 Table Holder for JDR520 97

75911 Screw for JDR520 12 75954 Nut for JDR520 55 75999 Bearing for JDR520 98

75912 Screw for JDR520 13 75955 Bearing for JDR520 56 76000 Ring for JDR520 99

75913 Shaft for JDR520 14 75956 Washer for JDR520 57 76001 Pin for JDR520 100

75914 Holder for JDR520 15 75957 Washer for JDR520 58 76002 Fixed Wheel for JDR520 101

75915 Screw for JDR520 16 75958 Screw for JDR520 59 76003 Washer for JDR520 102

75916 Washer for JDR520 17 75959 Holder for JDR520 60 76004 Screw for JDR520 103

75917 O Ring for JDR520 18 75960 Bearing for JDR520 61 76005 Screw for JDR520 104

75918 Screw for JDR520 19 75961 Gear for JDR520 62 76006 Lockwasher for JDR520 105

75919 Housing for JDR520 20 75962 Gear for JDR520 63 76007 3/4 HP 220V Motor for JDR520 106

75920 Nut for JDR520 21 75963 Washer for JDR520 64 76008 Motor Plate for JDR520 107

75921 Screw for JDR520 22 75964 Screw for JDR520 65 76009 Screw for JDR520 108

75922 Shaft (Handle) for JDR520 23 75965 Gear for JDR520 66 76010 Nut for JDR520 109

75923 Handle Ball for JDR520 24 75966 Gear for JDR520 67 76011 Table Support for JDR520 110

75924 Gear for JDR520 25 75967 Shaft for JDR520 68 76012 Plate for JDR520 111

75925 Pin for JDR520 26 75968 Base for JDR520 69 76013 Screw for JDR520 112

75926 Pin for JDR520 27 75969 Cover for JDR520 70 76014 Screw for JDR520 113

75927 Casing for JDR520 28 75970 Washer for JDR520 71 76015 Table Support for JDR520 114

75928 Screw for JDR520 29 75971 Shaft for JDR520 72 76016 Nut for JDR520 115

64131 Spring for JDR-520 30 75972 Holder for JDR520 73 76017 Support for JDR520 116

75930 Pin for JDR520 31 75973 Lockwasher for JDR520 74 76018 Support for JDR520 117

75931 Gear for JDR520 32 75974 Nut for JDR520 75 76019 Screw for JDR520 118

75932 Lockwasher for JDR520 33 75975 Pin for JDR520 76 76020 Nut for JDR520 11 9

75933 Shaft for JDR520 34 75976 Shaft for JDR520 77 76021 Screw for JDR520 120

75934 Lockwasher for JDR520 35 75977 Pin for JDR520 78 64133 O Ring for Shaft for JDR-520 121

75935 Gear for JDR520 36 75978 Upper Press Holder for JDR520 79 76025 Gear for JDR520 122

75936 Ring for JDR520 37 75979 Gear for JDR520 80 76026 Gear Set for JDR520 123

75937 Gear Rack for JDR520 38 75980 Ring for JDR520 81 64134 Cover for JDR-520 124

64132 Spring for JDR-520 39 75982 Washer for JDR520 82 64135 Nut for JDR-520 125

75939 Gear Rod for JDR520 40 75983 Casing for JDR520 83 76028 Lockwasher for JDR520 126

75940 Screw for JDR520 41 75984 Screw for JDR520 84 76029 Washer for JDR520 127

75941 Cam for JDR520 42 75986 Roller for JDR520 85 76030 Flour Tray for JDR520 128

75942 Ring for JDR520 43 75987 Bearing for JDR520 86 76031 Safety Guard for JDR520 129

11

Parts Breakdown

Model BE-CN-2083-FSS 44135

Item No. Description Position Item No. Description Position Item No. Description Position

76032 Bush for JDR520 130 76039 Shaft for JDR520 139 64138 Washer for JDR520 148

41428 Ring for JDR520 131 76040 Table for JDR520 140 64139 Nut for JDR520 149

41427 Short Spring for JDR520 132 76041 Table Support for JDR520 141 64140 Washer for JDR520 150

76033 Screw for JDR520 133 76042 Roller Complete for JDR520 142 64141 Screw for JDR520 151

76034 Top Scraper Holder for JDR520 134 76043 Shaft for JDR520 143 64142 Block Gine for JDR520 152

76035 Screw for JDR520 135 76044 Product Tray for JDR520 144 64143 Gear (24T) for JDR520 153

76036 Top Scraper for JDR520 136 76045 Flour Receiving Dish for JDR520 145 64144 Switch for JDR520 154

76037 Bottom Scraper Holder for JDR520 137 64136 Battery Switch for JDR520 146 64124 Emergency Stop Button for JDR520 155

76038 Bottom Scraper for JDR520 138 64137 Spring for JDR520 147 64162 Dough Sheet Roll for JDR520

12

Model BE-CN-2083-FSS 44135

Electrical Schematics

E Ground Wire M Motor SB3

KM1 AC Contactor N Power Input SB4

KM2 AC Contactor SB1

L Power Input SB2

Safety Guard Microswitch

SB5 Foot Pedal

SB6 Foot Pedal

13

Left/Right Direction

ST On/Off Switch

SQ

Emergency Stop Button

Notes

________________________________________________________________________________________

14

Warranty Registration

Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at

the perforation and then send to the address specied below. You can also register online by visiting:

Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:

Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación, cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:

www.omcan.com/warrantyregistration.html

For mailing in Canada

Pour postale au Canada

Por correo en Canadá

OMCAN

PRODUCT WARRANTY REGISTRATION

3115 Pepper Mill Court,

Mississauga, Ontario

Canada, L5L 4X5

PRODUCT WARRANTY REGISTRATION

4450 Witmer Industrial Estates, Unit 4,

For mailing in the US

Pour diffusion aux États-Unis

Por correo en los EE.UU.

OMCAN

Niagara Falls, New York

USA, 14305

or email to: service@omcan.com



Purchaser’s Information

Name: Company Name:

Address:

Telephone:

City: Province or State: Postal or Zip: Email Address:

Country: Type of Company:

Restaurant Bakery Deli

Dealer from which Purchased: Butcher Supermarket Caterer

Dealer City: Dealer Province or State: Institution (specify):

Invoice: Other (specify):

Model Name: Model Number: Serial Number:

Machine Description:

Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):

Would you like to extend the warranty? Yes No

Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

15

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers. Today with partners in North America, Europe, Asia and South America, we continually work to improve

and grow the company. We strive to offer customers exceptional value through our qualied local sales

and service representatives who provide convenient access to over 3,500 globally sourced products.

Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à

nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 3500

produits provenant du monde entier.

Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un fácil acceso a más de 3,500 productos con origen a nivel mundial.

Omcan BE-CN-2083-FSS User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
