Olympus FE-330, C-550 User Manual

DIGITAL CAMERA

FE-330/X-845/C-550

Advanced Manual

( Thank you for purchasing an Olympus digital camera. Before you start to use your new camera, please

read these instructions carefully to enjoy optimum performance and a longer service life. Keep this manual in a safe place for future reference.

( We recommend that you take test shots to get accustomed to your camera before taking important

photographs.

( In the interest of continually improving products, Olympus reserves the right to update or modify

information contained in this manual.

( The screen and camera illustrations shown in this manual were produced during the development stages

and may differ from the actual product.

Quick Start Guide

Get started using your camera right away.

Button operations

Menu operations

Printing pictures

Using OLYMPUS Master

Getting to know your camera better

Appendix

Contents

Quick Start Guide

Button operations

Menu operations

Printing pictures

Using OLYMPUS Master

Getting to know your camera better

Appendix

P. 3

P. 11

P. 18

P. 30

P. 35

P. 39

P. 47

Test out the functions of the camera buttons by following along with th e illustrations.

Learn about the menus that control the functions and settings for basic operation.

Learn how to print pictures you have taken.

Learn how to transfer and save pictures to a computer.

Find out more about camera operations and how to take better pictures.

Read about convenient functions and safety precautions to use your camera more effectively.

Quick Start Guide

Gather these items (box contents)

Digital Camera Strap Lithium Ion Battery

Battery Charger

(LI-40C)

Items not shown: Advanced Manual (this manual), Basic Manual, and the Warranty Card. Contents may vary depending on purchase location.

USB Cable AV Cable OLYMPUS Master 2

(LI-42B)

CD-ROM

Attach the strap

Quick Start Guide

( Pull the strap tight so that it does not come loose.

Prepare the camera

a. Charge the battery.

Power Cable

Lithium Ion Battery

AC Wall

Outlet

Charging Indicator Red light on: Charging

Light off: Charging complete (Charging time: Approx. 5 hours)

( Battery comes partially charged.

b. Insert the battery and the xD-Picture Card (optional) into the

camera.

Quick Start Guide

Battery Charger

Prepare the camera

(Insert the battery by putting in

the marked side first, with the C marks toward the end of the camera, the B marks toward the center of the camera.

If you insert the battery incorrectly, you may not be able to remove it. Do not use force. Contact authorized distributors/service centers. Damage to the battery exterior (scratches, etc.) may produce heat or an explosion.

Battery lock knob (To remove the battery, press the battery lock knob

in the direction of the arrow.

Notch

Contact area

(Orient the card as shown in the illustration

and insert it straight into the card slot. Insert the card until it clicks into place.

(To remove the card, push the card all the

way in, release slowly, grasp the card and remove it.

( With this camera, you can take pictures without inserting the optional xD-

Picture Card™ (hereinafter referred to as “the card”). If you take pictures without inserting the card, the pictures will be stored in the internal memory. For details on the card, please refer to “The card” (P. 48).

Quick Start Guide

Turn the camera on

This explains how to turn on the camera in shooting mode.

a. Set the mode dial to h.

When shooting still pictures

When shooting movies

Still picture shooting modes

h The camera automatically determines the optimum settings for shooting pictures.

P The camera automatically sets the optimum aperture value and shutter speed.

h This function reduces blur incurred by a moving subject or camera shake when taking

B Suitable for taking pictures of people. E Suitable for taking pictures of a landscape.

f Select from 11 available scene modes, according to the shooting conditions.

R Use the shooting guide displayed on the screen to shoot pictures according to the

Quick Start Guide

b. Press the o button.

pictures.

situation.

o button

D TIME

---- -- -- -- --

YMD

( To turn off the camera, press the o button once again.

Hint

The directions of the arrow pad is indicated with ONXY in the supplied instruction manual.

CANCEL

• This screen is displayed if the date and time are not set.

Set the date and time

The date and time screen

D TIME

---- -- -- -- --

CANCEL

YMD

Y-M-D

Hour

Minute

Date formats (Y-M-D, M-D-Y, D-M-Y)

Cancels the setting

a. Press the OF/< and NY buttons to select [Y].

• The first two digits of the year are fixed.

OF/< button

NY button

2008

CANCEL

-- -- -- --

b. Press the Y# button.

Y# button

Quick Start Guide

D TIME

YMD

c. Press the OF/< and NY buttons to

select [M].

2008 08

CANCEL

D TIME

-- -- --

YMD

Set the date and time

YYMMD

ORM

d. Press the Y# button. e. Press the OF/< and NY buttons to

select [D].

f. Press the Y# button. g. Press the OF/< and NY buttons to

select the hours and minutes.

• The time is displayed in the 24-hour format.

D TIME

2008 08 26

CANCEL

D TIME

2008 08 26 12

-- --

YMD

h. Press the Y# button. i. Press the OF/< and NY buttons to

select [Y/M/D].

Quick Start Guide

j. After all settings have been set, press .

• For a more accurate setting, press  when the time signal hits 00 seconds.

 button

CANCEL SET

TIME

2008 08 26 12 30

CANCEL SET

AUTO

ORM

The number of storable still pictures is displayed.

YMD

Take a picture

ORM

1/1000

F3.5

a. Hold the camera.

Horizontal grip Vertical grip

AUTO

ORM

b. Focus.

Shutter Button

(Press Halfway)

• The AF target mark lights up green when the focus and exposure are locked. The shutter speed and aperture value are also displayed.

• If the AF target mark blinks in red, the focus is not adjusted properly. Try locking the focus again.

c. Shoot.

Shutter Button

(Press

Completely)

AUTO

1/1000

F3.5

AF target mark Place this mark over your subject.

The card access lamp blinks.

Quick Start Guide

Review your pictures

2008.08.26

12:30

100-0001

ORM

ERASE

YES

a. Press the q button.

q button

Arrow pad

Displays the next image

2008.08.26

12:30

Displays the previous image

Erase pictures

a. Press the X& and Y# buttons to display the picture you want

to erase.

Quick Start Guide

b. Press the /S button.

ERASE

/S button

CANCEL

YES

c. Press the OF/< button, select [YES], and press .

OF/< button

 button

ERASE

CANCEL

YES

ORM

100-0001

SET

Button operations

ORM

1/1000

F3.5

Shooting mode

Flash mode

4 6

ORM

o button Turning the camera on and off

Macro mode/ Super macro mode

Self-timer

Number of storable still pictures

Power on: Camera turns on in shooting mode.

• Lens extends

• Monitor turns on

Shutter button Shooting pictures/Recording movies

Shooting still pictures

Set the mode dial to a setting other than n, and lightly press the shutter button (halfway). The AF target mark lights up green when the focus and exposure are locked (focus lock). The shutter speed and aperture value are displayed (only when the mode dial is set to h, P or h). Now press the shutter button all the way (completely) to shoot a picture.

1/1000

F3.5

Locking the focus and then composing the shot (focus lock)

Compose your picture with the focus locked, and then fully press the shutter button to shoot a picture.

• If the AF target mark blinks red, the focus is not adjusted properly. Try locking the focus again.

Button operations

AF target mark

Recording movies

Set the mode dial to n and lightly press the shutter button to lock the focus. Then, press the shutter button completely to start recording. Press the shutter button again to stop recording.

K button (Shooting) Selecting shooting mode/Turning the camera on

2008.08.26

12:30

100-0004

2008.08.26

12:30

100-0004

00:12 /00:34

2008.08.26

12:30

100-0004

00:14 /00:34

Shooting mode is selected. This function is used to set the camera to turn on in shooting mode when K is pressed with the camera off.

g “K/q Turning on the camera with the K or q button” (P. 28)

q button (Playback) Selecting playback mode/Turning the camera on

The last picture taken is displayed.

• Press the arrow pad to view other pictures.

• Use the zoom lever to switch between close-up playback and index display. This function is used to set the camera to turn on in playback mode when q is pressed with the camera off. g “K/q Turning on the camera with the K or q button” (P. 28)

Playing back movies

Select the movie in the playback mode and press  to play.

2008.08.26

12:30

100-0004

MOVIE PLAY

Operations during movie playback

Playing time/Total recording time

2008.08.26

12:30

Button operations

100-0004

00:12 /00:34

O: Increases the volume. N: Reduces the volume.

Y: Fast forwards playback when pressed and held. X: Rewinds playback when pressed and held.

•Press  to pause the playback.

Operations during pause

2008.08.26

12:30

100-0004

00:14 /00:34

O: Displays the first frame. N: Displays the last frame.

Y: Plays when pressed and held. X: Plays the movie in reverse when pressed and held.

• To resume the movie, press .

• To cancel the playback of the movie in the middle of it or during pause, press m.

Mode dial Switching shooting modes

Set the mode dial to the desired shooting mode.

h Shooting pictures with automatic settings

The camera determines the optimum settings for shooting pictures. [CAMERA MENU] settings such as ISO sensitivity cannot be changed.

P Set the optimum aperture value and shutter speed

The camera automatically sets the optimum aperture value and shutter speed for the brightness of the subject. [CAMERA MENU] settings such as ISO sensitivity can be changed.

h Shooting pictures using digital image stabilization

This function reduces the blur incurred by a moving subject or camera shake when taking pictures.

Shooting pictures according to the situation

B E

Use PORTRAIT and LANDSCAPE to shoot pictures with the optimal settings.

f Shooting pictures by selecting a scene mode according to the

situation

Select from 11 available scene modes, according to the shooting conditions. Press  to set.

M NIGHT+PORTRAIT / j SPORT /N INDOOR /W CANDLE / R SELF PORTRAIT /S SUNSET /X FIREWORKS /P BEHIND GLASS / V CUISINE /d DOCUMENTS /i AUCTION

NIGHT+PORTRAIT

EXIT

SET

• The scene selection screen displays sample images and the shooting mode to best suit the situation.

• To switch to a different scene mode after a scene mode has been selected, press m to select [SCENE] from the top menu and display the scene selection screen.

• By switching to another scene, most settings will be changed to the default settings of each scene.

R Follow the shooting guide

SHOOTING GUIDE

Brightening subject.

Shooting into backlight.

Set particular lighting.

Blurring background.

Adjusting area in focus.

SETBACK

Follow the shooting guide displayed on the screen to set the target items.

• Press m to display the shooting guide again.

• To change the setting without using the shooting guide, set the shooting mode to another one.

• The content set using the shooting guide will change to the default setting by pressing m or changing the mode

using the mode dial.

Button operations

n Recording movies

00:34

REC

2008.08.26

12:30

100-0004

ORM

2008.08.26

12:30

100-0004

+2.0

F3.5

1/1000

ISO400

ORM

+2.0

ORM

ISO 400

+2.0

ORM

ISO 400

Audio is recorded with the movie.

• During audio recording, only the digital zoom can be used. To record the movie with the

optical zoom, set [R] (movie) to [OFF].

g “R (movie) Recording movies with or without sound” (P. 22)

REC

This icon lights during movie recording.

The remaining recording time is displayed. When the remaining recording time reaches 0, recording

00:34

stops.

g/E button Changing the information on display/Display the menu guide

g Changing the information displays

Press g to change the display in the following order.

Shooting mode

Playback mode

ISO 400

ORM

+2.0

Normal display

Simple display

Button operations

ISO 400

ORM

+2.0

Frame assist

* This is not displayed when the mode dial is set to n or R.

E Displaying the menu guide

With a menu item highlighted, press and hold down E to display the menu guide which will provide more information on the function or setting.

Sets the language for menus and error messages.

2008.08.26

12:30

1/1000

ISO400

ORM

100-0004

F3.5 +2.0

ORM

100-0004

Normal display

Detailed display

No information display

Arrow pad (ONXY)

3264

2448

PICS LEFT

ISO

AUTO

0.0

+0.3

+0.7

+1.0

Use the arrow pad to select scenes, items on the menus, and to play back pictures.

 button (OK/FUNC)

Displays the Function Menu which contains the functions and settings used during shooting. This button is also used to confirm your selection.

The functions you can set with the Function Menu

g “WB Adjusting the color of a picture” (P. 21)

“ISO Changing the ISO sensitivity” (P. 22) “IMAGE QUALITY Changing the image quality” (P. 20)

Function Menu

AUTO

ISO

AUTO

3264

2448

5M3M2

OF/< button Changing picture brightness (Exposure compensation)/

The current camera settings are displayed. ON: Select the function to be set.

PICS LEFT

XY: Select a setting, and press .

Printing pictures

Shooting mode: Changing picture brightness

0.0

Press OF/< in shooting mode, use the arrow pad to select preferred brightness, and press .

• Adjustable from -2.0 EV to +2.0 EV

+0.3

Button operations

+0.7

+1.0

Use XY to change the display.

Playback mode: Printing pictures

Display a picture to print out in playback mode, connect the camera to the printer, and then press OF/< to print the picture. g “Direct printing (PictBridge)” (P. 30)

X& button Shooting pictures close to the subject (Macro mode)

Press X& in shooting mode to select the macro mode. Press  to set.

OFF Macro off Cancels macro mode.

& Macro mode This mode lets you shoot from as close as 10 cm/3.9 in. (when

% Super macro mode This mode lets you shoot from as close as 3 cm/1.2 in. to your

• Zoom and flash cannot be used in super macro mode.

the zoom is set for the zoom-out angle) and as close as 60 cm/

23.6 in. (when the zoom is set for the zoom-in angle) to your subject.

subject. The zoom position is fixed automatically and cannot be changed.

NY button Self-timer shooting

Press NY in shooting mode to select ON or OFF for the self-timer. Press  to set.

OFF Cancel the self-timer.

ON Set the self-timer.

• After setting the self-timer, press the shutter button completely. Then, the self-timer lamp lights for approximately 10 seconds, blinks for approximately 2 seconds, and the shutter is released.

• To cancel the self-timer, press NY.

• Self-timer shooting is automatically canceled after one shot.

Y# button Flash shooting

Press Y# in shooting mode to select the flash mode. Press  to set.

AUTO Flash auto The flash fires automatically in low light or backlight conditions. ! Red-eye reduction

flash

# Fill-in flash The flash fires regardless of the available light. $ Flash off The flash does not fire.

m button Displaying the top menu

Displays the top menu.

/S button Increasing the brightness of the monitor (Backlight boost)/

Button operations

 Increasing the brightness of the monitor (Backlight boost)

The monitor lights brighter when  is pressed in shooting mode. If there is no operation for 10 seconds, it dims back to the original brightness.

• When [BRIGHT] is selected in [s], the monitor brightness does not change.

This emits pre-flashes for red-eye reduction.

Erasing pictures

S Erasing pictures

In playback mode, select the picture you want to erase, and press S.

• Once erased, pictures cannot be restored. Check each picture before erasing to avoid accidentally erasing pictures you want to keep.

g “0 Protecting pictures” (P. 25)

Zoom lever Zooming while shooting/Close-up playback

ORM

WWT

ORM

2008.08.26

12:30

2008.08.26

12:30

100-0004

ORM

2008.08.26

12:30

2008.08.26

12:30

2008.08.26

12:30

Shooting mode: Zooming in on your subject

Optical zoom: 5× Digital zoom: 4× (optical zoom × digital zoom: Max. 20×)

Zoom out: Turn the zoom lever to the Wside.

ORM

Zoom in: Turn the zoom lever to the Tside.

The zoom bar appears white when the current zoom position is within the optical zoom area. When the digital zoom activates, the zoom bar appears yellow and the image is further enlarged.

Playback mode: Switching the picture display

Single-frame playback

• Use the arrow pad to browse pictures.

Zoom bar

2008.08.26

12:30

2008.08.26

Index display

• Use the arrow pad to select a

picture for playback, and press  to play back the single-frame of the picture

selected.

12:30

ORM

100-0004

Close-up playback

• Turn and hold the zoom lever to the T-side to incrementally zoom in (up to 10 times the original size), and to the W-side to zoom out.

• Press the arrow pad during closeup playback to scroll the picture in the indicated direction.

• When returning to the singleframe playback, press .

Button operations

12:30

2008.08.26

Menu operations


QUALITY CAMERA

CAMERA

SETUPSETUPSETUP

RESET

SCENESCENESCENE

SILENT

MODE

SILENT

MODE

SILENT

MODE


QUALITY CAMERA

CAMERA

SETUPSETUPSETUP

RESET

SCENESCENESCENE

SILENT

MODE

SILENT

MODE

SILENT

MODE

K button (Shooting mode)

q button (Playback mode)



m button

Arrow pad (ONXY)

About the menus

Press m to display the top menu on the monitor.

• The contents displayed on the top menu differ according to the mode.

Top menu

(Still picture shooting mode)


QUALITY CAMERA

RESET

SCENE

EXIT

• Select [CAMERA MENU], [PLAYBACK MENU], [EDIT], [ERASE] or [SETUP] and press

. The screen for selecting the menu item is then displayed.

• When the mode dial is set to R and the settings are made by following the shooting

SETUP

SILENT

MODE

SET

CAMERA MENU items

CAMERA MENU

ISO

PANORAMA FACE DETECT

EXIT

AUTOWB

AUTO OFF

OFF

SET

guide, press m to display the shooting guide screen.

Menu operations

Operation guide

During menu operations, the buttons and their respective functions are displayed at the bottom of the screen. Follow these guides to navigate the menus.


RESET

EXIT

QUALITY CAMERA

SCENE

SETUP

SILENT MODE

SET

BACK EXIT

SET

: Moves back one menu.

: Exits the menu.

: Sets the selected item.

Operation guide

m button



Using the menus


QUALITY CAMERA

CAMERA

SETUPSETUPSETUP

RESET

SCENESCENESCENE

SILENT

MODE

SILENT

MODE

SILENT

MODE

This explains how to use the menus with the [POWER SAVE] setting as an example.

1 Set the mode dial to a setting other than R. 2 Press m to display the top menu. Press Y

to select [SETUP], and press .

• [POWER SAVE] is on a menu in [SETUP].

3 Press ON to select [POWER SAVE], and

press .

• Unavailable settings cannot be selected.

• Press X on this screen to move the cursor to the page

display. Press ON to change the page. To return to the item selection screen, press Y or .

Page display: This mark is displayed when there are more menu items on the next page.

EXIT

SETUP

EXIT

SETUP


QUALITY CAMERA

RESET

SCENE

MEMORY FORMAT

BACKUP

PIXEL MAPPING

K/q

POWER SAVE OFF

SET

ENGLISH

SETUP

SILENT

MODE

SET

4 Press ON to select [OFF] or [ON], and press

.

• The menu item is set and the previous menu is displayed.

Press m repeatedly to exit the menu.

• To cancel any changes and continue operating the menus,

press m without pressing .

EXIT SET

The selected item is displayed in a different color.

SETUP

POWER SAVE

POWER MODE

OFF

SETBACK

Menu operations

Shooting mode menu K


QUALITY CAMERA

CAMERA

SETUPSETUPSETUP

RESET

SCENESCENESCENE

SILENT

MODE

SILENT

MODE

SILENT

MODE


RESET

EXIT

QUALITY CAMERA

SCENE

SETUP

SILENT

MODE

SET

• Some functions are not available according to the selected mode.

g “Functions available in shooting modes and scenes” (P. 46) g “SETUP menus” (P. 27)

• The factory default settings are displayed in gray ( ).

IMAGE QUALITY Changing the image quality

This function allows you to set [IMAGE SIZE] and [COMPRESSION].

Still picture image quality and their applications

Menu operations

IMAGE SIZE Application

G 3264 × 2448 H 2560 × 1920 I 2048 × 1536 J 1600 × 1200 K 1280 × 960 C 0640 × 480

D 1920 × 1080

COMPRESSION

L FINE

M NORMAL

• Suitable for printing pictures over A3 (11 × 17 in.).

• Suitable for printing pictures at A4 (8.5 × 11 in.).

• Suitable for printing pictures up to A4 (8 × 11 in.).

• Suitable for printing pictures at A5 (5 × 7 in.).

• Suitable for printing pictures at postcard size.

• Suitable for viewing pictures on a TV or using pictures on emails and web sites.

• Suitable for playing pictures at Wide screen TV.

• Shooting at high quality.

• Shooting at normal quality.

Movie image quality

IMAGE SIZE

C 640 × 480 E 320 × 240

g “Number of storable still pictures and recording length of movies” (P. 42)

4 CAMERA MENU

WB ISO

R (still picture) R (movie)

PANORAMA FACE DETECT

* An Olympus xD-Picture Card

is required.

RESET Changing the shooting functions back to default settings

NO /YES

Restore shooting functions back to default settings.

Functions restored to the factory default settings

Function Factory default setting Ref. Page

F 0.0 P. 15

& OFF P. 15 Y OFF P. 16 #

IMAGE SIZE (Still picture/ Movie)

COMPRESSION M P. 20

WB AUTO P. 21

ISO AUTO P. 22

R (still picture) OFF P. 22 R (movie) ON P. 22

FACE DETECT OFF P. 23

f (Scene) Shooting pictures by selecting a scene according to the situation

The scene selection screen displays sample images and the shooting mode to best suit the situation. This can be set only when the mode dial is set to f.

• By switching to another scene, most settings will be changed to the default settings of each scene.

g “f Shooting pictures by selecting a scene mode according to the situation” (P. 13)

CAMERA MENU

M NIGHT+PORTRAIT P. 13

Normal display P. 14

AUTO P. 16 G / E P. 20

Menu operations

............................................................................................Adjusting the color of a picture

AUTO The white balance is adjusted automatically for natural color,

5 Sunny day For shooting under a clear sky. 3 Cloudy day For shooting under a cloudy sky. 1 Tungsten light For shooting under tungsten lighting. w Fluorescent

lamp 1

x Fluorescent

lamp 2

y Fluorescent

lamp 3

regardless of the light source.

For shooting under daylight fluorescent lamp. (This type of lamp is mainly used in homes.)

For shooting under a neutral white fluorescent lamp. (This type of lamp is mainly used in desk lamps.)

For shooting under a white fluorescent lamp. (This type of lamp is mainly used in offices.)

ISO.................................................................................................. Changing the ISO sensitivity

AUTO Sensitivity is automatically adjusted according to the conditions of the

64/100/200/400/ 640

subject.

A low value lowers the sensitivity for daylight shooting of clear, sharp pictures. The higher the value, the better the camera’s light sensitivity and ability to shoot with a fast shutter speed and in low light conditions. However, high sensitivity introduces noise into the resulting picture, which may give it a grainy appearance.

R (still picture) ............................................................... Recording sound with still pictures

OFF /ON

When activated [ON], the camera will record about 4 seconds of audio after the picture is taken. When recording, aim the camera microphone at the source of the sound you want to record.

Microphone

R (movie) ................................................................ Recording movies with or without sound

OFF

/ON

When [ON] (sound is recorded) is selected, the optical zoom cannot be used during movie recording. Only the digital zoom can be used.

PANORAMA............................................................................... Creating a panoramic picture

Panorama shooting lets you create a panoramic picture, using the OLYMPUS Master software on the provided CD-ROM. An Olympus xD-Picture Card is required for panorama shooting.

Connects pictures from left to right Connects pictures from bottom to top

Menu operations

Y: The next picture is

connected at the right edge.

X: The next picture is

connected at the left edge.

O: The next picture is

connected at the top.

N: The next picture is

connected at the bottom.

Use the arrow pad to specify at which edge you want to connect the pictures; and then compose your shots so that the edges of the pictures overlap. The part of the previous picture where it will be joined to the next picture does not remain in the frame. You have to remember what the part in the frame looked like and take the next picture so it overlaps.

•Press  to exit.

• Panorama shooting is possible for up to 10 pictures. The warning mark (g) is displayed

after 10 pictures have been taken.

FACE DETECT........................................................................................... Focusing on a face

SLIDE-

SHOW

ORDER

PLAYBACK

PERFECT

FIX

PERFECT

FIX

PERFECT

FIX

SETUPSETUPSETUP

ERASEERASEERASE

EDITEDITEDIT

SILENT

MODE

SILENT

MODE

SILENT

MODE

FAVORITE

OFF /ON

The camera searches for a face within the frame and focuses on it.

• A face may not be detected depending on the subject.

SILENT MODE Muting operational sounds

OFF /ON

This function allows you to mute operational sounds during shooting and playback (e.g. warning beeps, shutter sounds, etc.).

Playback mode menu q

*1, *2

ORDER

SETUP

SILENT

MODE

6 PLAYBACK MENU

y R

*1 A card is required. *2 This is not selected

when the movie is selected.

together.

dark when there is backlighting.

SLIDESHOW

FIX

EDIT

PLAYBACK

ERASE

4 EDIT

Q P

PERFECT

FAVORITE

EXIT SET

g “SETUP menus” (P. 27) g “SILENT MODE Muting operational sounds” (P. 23)

• The factory default settings are displayed in gray ( ).

SLIDESHOW Playing back pictures automatically

Press  to start the slideshow.

• Only the first frame of each movie is displayed.

• To cancel the slideshow, press  or m.

PERFECT FIX Editing images

The recorded image is corrected and saved as a new one.

PERFECT FIX

ALL

LIGHTING FIX REDEYE FIX

EXIT

• Movies, pictures shot by another camera, and previously fixed or edited pictures cannot be corrected.

• When edited pictures are displayed, the picture cannot be re-edited.

• Depending on the picture, the editing may not be effective.

• Editing an image may cause it to suffer a minor loss in quality.

• Use ON to select the effect you want to apply, and press .

• Use XY to display picture you want to edit and press .

ALL Lighting fix and red-eye fix are activated

LIGHTING FIX Edit only the portions that photographed

SET

REDEYE FIX Corrects a subject with red-eye.

Menu operations

MY FAVORITE Viewing and registering pictures in My Favorite

SLIDESHOW

ADD

FAVORITE

ADD

FAVORITE

ADD

FAVORITE

EXITEXITEXIT

My Favorite

Registers and plays back your favorite still pictures as new ones in the internal memory. Up to 9 pictures can be registered.

• Registered pictures will not be erased even if the internal memory is formatted.

g “Erasing pictures registered in MY FAVORITE” (P. 24)

Note

• Registered pictures cannot be edited, printed, copied to a card, transferred to a computer, or viewed on a computer.

VIEW FAVORITE......................................................................... Viewing registered pictures

• Select [VIEW FAVORITE] to display pictures registered in MY FAVORITE. Use the arrow pad to browse pictures.

•Press m to select [ADD FAVORITE] or [SLIDESHOW].

My Favorite

ADD

FAVORITE

EXIT

SLIDESHOW

My Favorite

EXIT

SET

ADD FAVORITE Adds pictures to My Favorite.

SLIDESHOW Plays back registered pictures automatically.

EXIT Reverts to normal playback mode.

• Select a picture with XY, and press .

• Press  to exit the slideshow.

Erasing pictures registered in MY FAVORITE

YES/

• Use the arrow pad to select the picture to be erased, and press

S. Select [YES], and press

• Even if pictures registered in MY FAVORITE are erased, original pictures in the internal memory or the card may not be erased.

.

SET................................................................................................. Registering favorite pictures

SET

• Select a picture with XY, and press .

Menu operations

BACK

EDIT

................................................................................................. Changing the size of pictures

C 640 × 480/ E 320 × 240

This changes the image size of a picture and saves it as a new file.

SET

P.....................................................................................................................Cropping a picture

Crop a picture, and save the cropped picture as a new picture.

• Use XY to select a picture to be cropped and press .

• Use the arrow pad and zoom lever to adjust the position and size of the area-selection box, and press .

PRINT ORDER Making print reservations (DPOF)

This function allows you to save printing data (the number of prints and the date and time information) with the pictures stored on the card.

SET

g “Print settings (DPOF)” (P. 32)

PLAYBACK MENU

.................................................................................................................. Protecting pictures

OFF /ON

OFFOFF

EXIT

Protected pictures cannot be erased using [ERASE], [SEL. IMAGE] or [ALL ERASE], but they are all erased by formatting.

• Select the picture with XY, and protect it by selecting [ON]

with ON. You can protect several frames in succession. When a picture is protected, 9 will be displayed on the monitor.

y........................................................................................................................ Rotating pictures

U +90° /

V 0° / T -90°

Pictures taken with the camera held vertically are displayed horizontally. This function lets you turn such pictures so that they are displayed vertically. New picture orientations are saved even when the power is turned off.

Menu operations

EXIT

+90°

Select a picture with XY, and select [U +90°]/[V 0°]/[T -90°] with ON to rotate pictures. You can rotate several frames in succession.

EXIT

0° -90°

EXIT

R.................................................................................................... Adding sound to still pictures

YES /NO

YESYES

BACK

ERASE Erasing selected pictures/Erasing all pictures

SET

Protected pictures cannot be erased. Cancel protection before erasing protected pictures. Once erased, pictures cannot be restored. Check each picture before erasing to avoid accidentally erasing pictures you want to keep.

• When erasing pictures in the internal memory, do not insert the card into the camera.

• When erasing pictures from the card, insert the card into the camera in advance.

• You can confirm on the monitor whether the internal memory or card is being used. g “Using the internal memory or card” (P. 48)

Sound is recorded for about 4 seconds.

• Use the arrow pad XY to select a picture, select [YES] with

ON to begin recording, then press .

• The [BUSY] bar will be temporarily displayed.

SEL. IMAGE................................................................. Erasing by selecting the single-frame

SEL. IMAGE

42536

BACK GO

• Use the arrow pad to select the picture, and press  to mark

R on your selection.

• To cancel the selection, press  again.

• When the selection is completed, press /S.

• Select [YES], and press .

ALL ERASE .........................Erasing all the pictures in the internal memory or on the card

• Select [YES], and press

.

Menu operations

SETUP menus


QUALITY CAMERA

CAMERA

SETUPSETUPSETUP

RESET

SCENESCENESCENE

SILENT

MODE

SILENT

MODE

SILENT

MODE

PLAYBACK

SETUPSETUPSETUP

ERASEERASEERASE

EDITEDITEDIT

SILENT

MODE

SILENT

MODE

SILENT

MODE

ORDER

FAVORITE

SLIDESHOW

PERFECT

FIX

PERFECT

FIX

PERFECT

FIX

Shooting mode


QUALITY CAMERA

SCENE

SETUP

SILENT

MODE

SET

RESET

EXIT

Playback mode

EDIT

PLAYBACK

ERASE

ORDER

SETUP

SILENT

MODE

SET

*1 A card is required. *2 You cannot select this item

SLIDE-

SHOW

PERFECT

FIX

FAVORITE

EXIT

• The factory default settings are displayed in gray ( ).

MEMORY FORMAT (FORMAT) ........................Formatting the internal memory or card

All existing data, including protected pictures, are erased when the internal memory or card is formatted (images registered to “My Favorite” are not erased). Make sure that you save or transfer important data to a computer before formatting.

• Make sure there is no card inserted in the camera when formatting the internal memory.

• Be sure that the card is inserted in the camera when formatting the card.

• Before using non-Olympus cards or cards which have been formatted on a computer, you must format them with this camera.

BACKUP................................................Copying pictures in the internal memory to the card

Insert the optional card into the camera. Copying data does not erase the picture in the internal memory.

• It takes some time to back up data. Check that the battery is not empty before starting the copy.

SETUP

MEMORY FORMAT (FORMAT*1)

BACKUP

PIXEL MAPPING K/q MENU COLOR SOUND SETTINGS

VIDEO OUT POWER SAVE

in playback mode.

Menu operations

W ..............................................................................................Selecting a display language

You can select a language for on-screen display. Available languages vary depending on the area where you purchased this camera.

PIXEL MAPPING.................................................. Adjusting the image processing function

The pixel mapping feature allows the camera to check and adjust the CCD and image processing functions. It is not necessary to operate this function frequently. Approximately once a year is recommended. Wait at least one minute after taking or viewing pictures to allow the pixel mapping function to perform properly. If you turn the camera off during pixel mapping, start again. Select [PIXEL MAPPING]. When [START] is displayed, press .

K/q......................................................... Turning on the camera with the K or q button

YES Pressing K turns on the camera and starts the camera in the shooting mode.

NO The power is not turned on. To turn on the camera, press o.

Pressing q turns on the camera and starts the camera in the playback mode.

MENU COLOR ......................................... Setting the menu screen color and background

NORMAL / COLOR1 / COLOR2 / COLOR3 / MY FAVORITE

• Select [MY FAVORITE] and press Y to set a still picture registered in “My Favorite” as the

background.

g “SET Registering favorite pictures” (P. 24)

SOUND SETTINGS ......................................... Setting the sound output from the camera

You can set the following with [SOUND SETTINGS].

• Setting the volume of the button operation sound. (BEEP)

• Selecting the volume of the shutter button. (SHUTTER SOUND)

• Adjusting the volume of the camera warning sound. (8)

• Adjusting the volume during playback. (q VOLUME)

BEEP OFF (No sound) /

SHUTTER SOUND OFF (No sound) / 8 OFF (No sound) /

Menu operations

q VOLUME OFF (No sound) /

• You can set all the sounds muted at once by setting [SILENT MODE].

g “SILENT MODE Muting operational sounds” (P. 23)

LOW / HIGH

1 / 2 / 3 / 4 / 5

s .......................................................................................... Adjusting the monitor brightness

BRIGHT/

NORMAL

X......................................................................................................... Setting the date and time

The date and time is saved with each image and is used in the file name. If the date and time are not set, the [X] screen is displayed each time the camera is turned on.

DTIME

2008 08 26 12 30

CANCEL

Y-M-D Hour Minute

Date formats

YMD

(Y-M-D, M-D-Y, D-M-Y)

• The first two digits of [Y] are fixed.

• The time is displayed in the 24hour format.

• To set the time precisely, with the cursor on either “Minute” or “Y/M/ D”, press  as the time signal strikes 00 seconds.

Cancels the setting

VIDEO OUT ...............................................................................Playing back pictures on a TV

NTSC /PAL

To play back camera images on a TV, set the video output according to your TV’s video signal type.

• TV video signal types differ by country/region. Check the video signal type before connecting the camera to the TV.

NTSC: North America, Taiwan, Korea, Japan PAL: European countries, China

The factory default settings differ according to the region where the camera is sold.

Playing back pictures on a TV

Turn off the camera and the TV before connecting.

Connector cover

Multi-connector

Connect to the TV’s video input (yellow) and audio input (white) terminals.

Menu operations

AV cable (provided)

Settings on the camera

Turn the camera on and press q to select the playback mode.

• The last picture taken is displayed on the TV. Use the arrow pad to select the picture you want to display.

Settings on the TV

Turn the TV on and set it to video input mode.

• For details of switching to video input, refer to your TV’s instruction manual.

• Images and the information displayed on the screen may be cropped depending on the TV’s settings.

POWER SAVE...................................................Setting the camera to the power save mode

OFF /ON

When no operation has been performed for approximately 10 seconds while in shooting mode, the monitor automatically shuts off. Pressing the zoom lever or other buttons restores the camera from power save mode.

Printing pictures

Direct printing (PictBridge)

By connecting the camera to a PictBridge-compatible printer, you can print out pictures directly.

EASY PRINT................ Prints the picture displayed in the monitor by using

the standard settings of your printer.

CUSTOM PRINT.......... Prints with the various print settings available on

your printer.

• PictBridge is a standard for connecting digital cameras and printers of different makers and printing out pictures directly. To find out if your printer is compatible with PictBridge, refer to the printer’s instruction manual.

• For printer’s standard settings, available printing modes, the setting items such as paper sizes, and printer’s specifications such as available types of paper, how to install the papers and ink cassettes, etc., refer to the printer’s instruction manual.

EASY PRINT

1 In playback mode, display the picture you want to print out on the

monitor.

2 Turn the printer on and plug the USB cable provided with the camera

into the multi-connector of the camera and the printer’s USB port.

Connector cover

• The [EASY PRINT START] screen is displayed.

Printing pictures

USB cable

Multi-connector

3 Press OF/<.

• Printing starts.

• When printing is finished, the picture selection screen is displayed.

To print another picture, press XY to select a picture, and press OF/<.

4 Disconnect the USB cable.

EASY PRINT START PC / CUSTOM PRINT

Other print modes and print settings (CUSTOM PRINT)

100-0004

1 Follow Steps 1 and 2 on P. 30 to display the screen for Step 3 above,

and then press .

2 Select [CUSTOM PRINT], and press .

3 Follow the operation guide to adjust print settings.

Selecting a print mode

PRINT MODE SELECT

ALL PRINT

MULTI PRINT ALL INDEX PRINT ORDER

EXIT

SET

Operation guide

Setting the print paper

PRINT Prints the selected picture.

ALL PRINT Prints all the pictures stored in the internal

memory or the card.

MULTI PRINT Prints one picture in multiple layout format.

ALL INDEX Prints an index of all the pictures stored in the

PRINT ORDER Prints the pictures according to the print

internal memory or the card.

reservation data on the card. g “Print settings (DPOF)” (P. 32)

USB

PC EASY PRINT

CUSTOM PRINT

EXIT

SET

PRINTPAPER

SIZE BORDERLESS

STANDARDSTANDARD

BACK

• If the [PRINTPAPER] screen is not displayed, [SIZE], [BORDERLESS] and [PICS/SHEET]

SET

are set to the default.

SIZE Choose from the available paper sizes on your

BORDERLESS Select with or without borders. In [MULTI PRINT]

PICS/SHEET Select the number of pictures to be laid out on a

printer.

mode, you cannot print with a border.

sheet of paper. Available in [MULTI PRINT] mode only.

Selecting the picture to print

Press XY to select the picture you want to print. You can also use the zoom button and select a picture from the index display.

SINGLEPRINT MORE

100-0004

PRINT Prints one copy of the selected picture. When

SINGLE PRINT Makes a print reservation for the displayed

MORE Sets the number of prints and data to be printed

[SINGLE PRINT] or [MORE] has been selected, a single copy or more copies are printed.

picture.

for the displayed picture.

Printing pictures

Setting the number of prints and data to be printed

PRINT INFO

DATE FILE NAME

EXIT

WITHOUT WITHOUT

SET

<× Sets the number of prints. You can select up

DATE ( ) If you select [WITH], pictures are printed with

FILE NAME ( ) If you select [WITH], pictures are printed with

P Use the arrow pad and zoom lever, adjust the

to 10 prints.

the date.

the file name.

location and size of the trimming frame, then press  to print the cropped picture.

4 Select [PRINT], and press .

• Printing starts.

• When [OPTION SET] is selected in [ALL PRINT] mode, [PRINT INFO] screen is displayed.

• When printing is finished, the [PRINT MODE SELECT] screen is displayed.

To cancel printing

CONTINUE

TRANSFERRING

CANCEL

Screen during data transfer

Press .

CANCEL

SET

5 In the [PRINT MODE SELECT] screen, press m.

• A message is displayed.

6 Disconnect the USB cable.

CANCEL

BACK

Select [CANCEL], and press .

PRINT MODE SELECT

ALL PRINT MULTI PRINT ALL INDEX PRINT ORDER

EXIT

SET

Print settings (DPOF)

Printing pictures

Print reservation allows you to save printing data (the number of prints and the date and time information) with the pictures stored on the card. With print reservations, you can print out pictures easily either at home using a personal DPOF-compatible printer or at a photo store that supports DPOF. DPOF is a standard format used to record automatic print information from digital cameras.

• Only the images stored on the card can be reserved to print. Insert a card with recorded pictures into the camera before making print reservations.

• DPOF reservations set by another device cannot be changed by this camera. Make changes using the original device. If a card contains DPOF reservations set by another device, entering reservations using this camera may overwrite the previous reservations.

• You can make DPOF print reservations for up to 999 images per card.

• Not all functions may be available on all printers, or at all photo stores.

Making a print reservation

2008.08.26

12:30

100-0004

ORM

1 Press m in the playback mode and select [PRINT ORDER]. 2 Select [<] or [U], and press .

< Makes a print reservation for the selected picture. U Makes print reservations for all the pictures stored on the

card.

• When [U] is selected, go to step 5.

When [<] is selected

3 Press XY to select the frames for print

reservations, and then press ON to set the number of prints.

• You cannot make print reservations for pictures with A.

• Repeat Step 3 to make print reservations for other pictures.

Cropping a picture

• Use zoom lever to display the trimming frame.

• Use the arrow pad and zoom lever to adjust the position and the size of area-selection box

then press .

PRINT ORDER

EXIT

Operation guide

4 When you finish making print reservations, press .

2008.08.26

SET

ORM

100-0004

SET

12:30

5 Select the date and time setting, and press .

NO The pictures are printed without the date and time. DATE The selected pictures are printed with the shooting date. TIME The selected pictures are printed with the shooting time.

6 Select [SET], and press .

Resetting print reservation data

You can reset all the print reservation data or just for selected pictures.

1 Select top menu [PRINT ORDER], and press .

To reset the print reservation data for all the pictures

2 Select [<] or [U], and press . 3 Select [RESET], and press .

DATE TIME

BACK

PRINT ORDER

)

1 ( 1

SET

CANCEL

PRINT ORDER SETTING

PRINT ORDERED

RESET

KEEP

SET

Printing pictures

SETBACK

To reset the print reservation data for a selected picture

2 Select [<], and press . 3 Select [KEEP], and press . 4 Press XY to select the picture with the print reservations you want to

cancel, and press N to decrease the number of prints to 0.

• Repeat Step 4 to cancel print reservations for other pictures.

5 When you are finished canceling print reservations, press . 6 Select the date and time setting, and press .

• The setting is applied to the remaining pictures with print reservations.

7 Select [SET], and press .

Printing pictures

Using OLYMPUS Master

Using the USB cable provided with your camera, you can connect the camera and computer and download (transfer) the images to your computer using the OLYMPUS Master software, also provided with the camera.

Prepare the following items before starting.

OLYMPUS Master 2

CD-ROM

USB cable A computer that satisfies the operating

environment (P. 35) requirements

What is OLYMPUS Master?

OLYMPUS Master is a software application for managing your digital images on your computer.

Install the OLYMPUS Master software

Before installing the OLYMPUS Master software, please confirm that your computer is compatible with the following system requirements. For newer operating systems, please refer to the Olympus web site as shown on the back cover of this manual.

Operating environment

Windows Macintosh

OS Windows 2000 Professional/XP Home

CPU Pentium III 500 MHz or later Power PC G3 500 MHz or later

RAM 256 MB or more 256 MB or more

Hard disk capacity 500 MB or more 500 MB or more

Monitor 1,024 × 768 pixels or more 65,536

Other USB port or IEEE 1394 port

Edition/XP Professional/Vista

colors or more (16.77 million colors or more recommended)

Internet Explorer 6 or later QuickTime 7 or later recommended DirectX 9 or later recommended

Mac OS X v10.3 or later

Intel Core Solo/Duo 1.5 GHz or later

1,024 × 768 pixels or more 32,000 colors or more (16.77 million colors or more recommended)

USB port or IEEE 1394 port (FireWire) Safari 1.0 or later (1.3 or later recommended) QuickTime 6 or later

Using OLYMPUS Master

Note

• Use a computer with a pre-installed operating system. Operations are not guaranteed on home-built computers or computers with an updated operating system.

• Operations are not guaranteed when using an added USB or IEEE 1394 (FireWire) port.

• To install the software, you must log on as a user with administrators’ privileges.

• If you are using Macintosh, be sure to remove the media (drag & drop onto the trash icon) before performing the following operations. Failure to do so could result in unstable computer operation and the need to reboot.

• Disconnect the cable connecting the camera to the computer

• Turn off the camera

• Open the camera’s battery/card compartment cover

For how to install the OLYMPUS Master software, refer to the installation guide included in the CD-ROM.

Connecting the camera to a computer

1 Make sure the camera is turned off.

• The monitor is off.

• The lens is retracted.

Monitor

2 Connect the multi-connector on the camera to

the USB port on the computer using the provided USB cable.

• Refer to your computer’s instruction manual to locate the position of the USB port.

• The camera turns on automatically.

• The monitor turns on and the selection screen for the USB connection is displayed.

Connector cover

Multi-connector

3 Select [PC], and press .

Using OLYMPUS Master

USB

EASY PRINT CUSTOM PRINT EXIT

SET

4 The camera is recognized by the computer.

• Windows When you connect the camera to your computer for the first time, the computer attempts to recognize the camera. Click “OK” to exit the message that is displayed. The camera is recognized as a “Removable Disk”.

• Macintosh The iPhoto program is the default application for managing digital images. When you connect your digital camera for the first time, the iPhoto application starts automatically, so close this application and start OLYMPUS Master.

Note

• The camera functions are disabled while the camera is connected to a computer.

• Connecting the camera to a computer via a USB hub may cause unstable operation. In this case, do not use a hub, but connect the camera directly to the computer.

• Images cannot be transferred to your computer with OLYMPUS Master if [PC] is selected in Step 3, Y is pressed and [MTP] is selected.

Start up the OLYMPUS Master software

Windows

1 Double-click the “OLYMPUS Master 2” icon on the desktop.

Macintosh

1 Double-click the “OLYMPUS Master 2” icon in the “OLYMPUS

Master 2” folder.

• The browse window is displayed.

• When OLYMPUS Master is started up for the first time after installation, the OLYMPUS Master initial setting screen and user registration screen are displayed before the browse window. Follow the on-screen instructions.

Displaying camera images on a computer

Downloading and saving images

1 Click “Transfer Images” on the browse

window, and then click “From Camera” .

• The window for selecting the pictures you want to transfer from the camera is displayed. All the images in the camera are displayed.

2 Select “New Album” and enter an album name.

3 Select the image files and click “Transfer

Images”.

• A window indicating that the download is complete is displayed.

4 Click “Browse images now”.

• The downloaded images are displayed in the browse window.

Using OLYMPUS Master

To disconnect the camera

1 Make sure that the card access lamp has

Card access lamp

stopped blinking.

2 Make the following preparations for

disconnecting the USB cable.

Windows

1 Click the “Unplug or Eject Hardware” icon in the

system tray.

2 Click the message that is displayed. 3 When a message is displayed saying that the hardware

can be ejected safely, click “OK”.

Macintosh

1 The trash icon changes to the eject icon when the

“Untitled” or “NO_NAME” icon on the desktop is dragged. Drag and drop it on the eject icon.

3 Disconnect the USB cable from the camera.

Note

• Windows: When you click “Unplug or Eject Hardware”, a warning message may be displayed. Make sure that image data is not being downloaded from the camera and that all applications are closed. Click the “Unplug or Eject Hardware” icon again and disconnect the cable.

For detailed operations of OLYMPUS Master, refer to the quick start guide displayed upon startup or the help of the OLYMPUS Master.

To download and save images to a computer without using OLYMPUS Master

This camera is compatible with USB mass storage. You can connect the camera to your computer using the USB cable provided with the camera to download and save images without using OLYMPUS Master. The following environment is required to use the USB cable to connect the camera to your computer.

Windows: Windows 2000 Professional/XP Home Edition/XP Professional/Vista Macintosh: Mac OS X v10.3 or later

Note

• If your computer is running Windows Vista, you can select [PC] in Step 3 on P. 36, press Y,

Using OLYMPUS Master

and select [MTP] to use Windows Photo Gallery.

• Data transfer is not guaranteed in the following environments, even if your computer is equipped with a USB port.

• Computers with a USB port added by means of an extension card, etc.

• Computers without a factory-installed OS and home-built computers

Getting to know your camera better

Shooting tips and information

Tips before you start taking pictures

The camera does not turn on even when a battery is loaded

The battery is not charged

• Charge the battery with the charger.

The battery is temporarily unable to function because of the cold

• Battery performance declines in low temperatures, and the charge may not be sufficient to turn on the camera. Remove the battery and warm it by putting it in your pocket for a while.

The card cannot be used

Sometimes when the contact area of the card is dirty, the camera cannot recognize the card, and the [CARD SETUP] screen will be displayed. In this case, select [CLEAN CARD] and after pressing , take out the card, and wipe the contact area with a soft, dry cloth.

No picture is taken when the shutter button is pressed

The camera is in sleep mode

• To save battery power, the camera automatically goes into sleep mode and the monitor turns off if there is no operation for 3 minutes when the camera is turned on. No picture is taken even if the shutter button is fully pressed in this mode. Operate the zoom lever or other buttons to restore the camera from sleep mode before taking a picture. If the camera is left for another 12 minutes, it automatically turns off. Press o to turn the camera on.

The mode dial is in the position of R

• No pictures can be taken when the shooting guide is being displayed. Take pictures after selecting the settings by following the shooting guide, or turn the mode dial and set it to a shooting mode other than R.

The flash is charging

• Wait until the # (flash charge) mark stops blinking before taking the picture.

Getting to know your camera better

The date and time have not been set

The camera has been used in the same condition from the time of purchase

• No date and time have been set in the camera at the time of purchase. Set the date and time before using the camera.

g “Set the date and time” (P. 7), “X Setting the date and time” (P. 29)

The battery has been removed from the camera

• The date and time settings will be returned to the factory default settings if the camera is left without the battery for approximately 1 day. If the battery is in the camera for a short period of time, the date and time setting will be reset earlier than this. Before taking important pictures, check that the date and time settings are correct.

Shooting tips

Focusing on the subject

There are several ways to focus, depending on the subject.

When the subject is not in the center of the frame

• Place the subject in the center of the frame, lock the focus on the subject, and then

recompose your picture.

g “Shutter button Shooting pictures/Recording movies” (P. 11)

The subject is moving quickly

• Focus the camera on a point roughly the same distance away as the subject you want to

shoot (by pressing the shutter button halfway); and then recompose your picture and wait for the subject to enter the frame.

Subjects that are difficult to focus on

• Under certain types of conditions, it is difficult to focus using auto focus.

Subject with low contrast Subject wit h an extremely

Subjects at different distances

In these cases, focus (focus lock) on an object with high contrast at the same distance as the intended subject, recompose your shot and then take the picture. If the subject has no vertical lines, hold the camera vertically and focus the camera using the focus lock function by pressing the shutter button halfway, and then return the camera to the horizontal position while keeping the button pressed halfway and take the picture.

Getting to know your camera better

Taking pictures without blurring

Hold the camera correctly and press the shutter button gently to shoot the picture. In addition, blurring is reduced when taking pictures in the h mode.

g “h Shooting pictures using digital image stabilization” (P. 13)

The factors that can cause the picture to blur are as follows:

• When you zoom at a high magnification to shoot the picture

• When the shutter speed is set low to shoot a dark subject

• When the flash cannot be used or a low shutter speed set f mode is selected.

bright area in the center of the frame

Fast-moving subject The subject is not in the

Subject without vertical lines

center of the frame

Taking blur-free pictures without the flash

The flash fires automatically when insufficient light is available and may cause your image to be blurry. When taking pictures in low lights without the flash, set the flash mode to [$] (flash off), then increase the ISO sensitivity.

g “Y# button Flash shooting” (P. 16)

Increase the [ISO] setting

g “ISO Changing the ISO sensitivity” (P. 22)

The picture is too grainy

There are several factors that can cause the picture to appear grainy.

Using the digital zoom to take close-up pictures

• With the digital zoom, part of the image is cropped and enlarged. The greater the magnification, the grainier the picture appears.

g “Zoom lever Zooming while shooting/Close-up playback” (P. 17)

Increasing the ISO sensitivity

• When you increase the [ISO] setting, “noise”, which appears as spots of unwanted color or unevenness in the color, can be introduced and give the picture a grainy appearance. This camera is equipped with a function to allow shooting at high sensitivity while suppressing noise; however, increasing the ISO sensitivity can result in some noise, depending on the shooting conditions.

g “ISO Changing the ISO sensitivity” (P. 22)

Taking pictures with the f mode set to M, W, S or X

• When taking pictures of dark subjects using the above scene modes, the picture may appear grainy.

g “f Shooting pictures by selecting a scene mode according to the situation” (P. 13)

Taking pictures with the correct color

• The reason why there are sometimes differences between the actual colors and the colors recorded in a picture is related to the light source illuminating the subject. [WB] is the function that helps the camera determine the true colors. Normally, the [AUTO] setting provides the optimal white balance, but depending on the subject, results may be better if you manually adjust the [WB] setting.

• When the subject is in the shade on a sunny day

• When the subject is illuminated by both natural light and indoor lighting, such as when near a window

• When there is no white in the center of the frame

g “WB Adjusting the color of a picture” (P. 21)

Taking pictures of a white beach or snow scene

• Often, bright subjects (such as snow) turn out darker than their natural colors. Adjusting

OF toward [+] makes the subject closer to their real shades. Conversely, when you are shooting dark subjects, it can be effective to adjust toward [–]. Sometimes, using the flash may not produce the brightness (exposure) that was intended.

g “OF/< button Changing picture brightness (Exposure compensation)/

Printing pictures” (P. 15)

Getting to know your camera better

Taking pictures of a subject against backlight

• Set the flash to [#] (fill-in) to activate fill-in-flash. You can shoot a subject against backlight without the face of the subject appearing dark. [#] is effective not only for shooting against backlight, but also for shooting under fluorescent and other artificial lighting.

g “Y# button Flash shooting” (P. 16)

• Setting OF to [+] is effective when shooting against backlight.

g “OF/< button Changing picture brightness (Exposure compensation)/

Printing pictures” (P. 15)

• When [FACE DETECT] is set to [ON], faces in pictures appears bright, since adequate exposure for the detected face can be obtained even under backlight conditions.

g “FACE DETECT Focusing on a face” (P. 23)

Additional shooting tips and information

Increasing the number of pictures that can be taken

There are two ways to record the pictures you take with this camera.

Recording pictures to the internal memory

• Pictures are recorded to the internal memory, and when the number of storable still

pictures reaches 0, you connect the camera to a computer to download the pictures; and then erase the pictures from the internal memory.

Using a card (xD-Picture Card) (optional)

• Pictures are recorded to the card when inserted in the camera. When the card is full, you

download the pictures to a computer and then either erase the pictures from the card or use a new card.

• Pictures are not recorded to the internal memory when a card is inserted in the camera.

Pictures in the internal memory can be copied to the card using the [BACKUP] function.

g “BACKUP Copying pictures in the internal memory to the card” (P. 27)

“The card” (P. 48)

Number of storable still pictures and recording length of movies

Still pictures

Number of storable still pictures

IMAGE SIZE

G 3264 × 2448

H 2560 × 1920

I 2048 × 1536

J 1600 × 1200

K 1280 × 960

Getting to know your camera better

C 640 × 480

D 1920 × 1080

COMPRESSION

Movies

IMAGE SIZE

C 640 × 480 21 sec. 22 sec. E 320 × 240 58 sec. 1 min. 1 sec. 29 min. 29 min.

Internal memory

With sound

4 4 221 223

7 8 429 438

6 6 353 359

12 12 673 695

10 10 566 576

20 21 1,102 1,142

16 17 913 940

32 34 1,728 1,881

25 26 1,390 1,453

47 53 2,558 2,907

84 107 4,568 5,814

148 197 7,995 10,660

15 16 841 876

30 32 1,640 1,728

Internal memory Using a 1 GB card

With sound

Without

sound

Continuous recording length

Without

sound

Using a 1GB card

With sound

17 min. 48 sec. 18 min. 11 sec.

Without

sound

Without

sound

Using a new card

• If you use a non-Olympus card or a card used for another application, such as a computer, use the [FORMAT] function to format the card.

g “MEMORY FORMAT (FORMAT) Formatting the internal memory or card” (P. 27)

The card access lamp is blinking

• An image or movie is being recorded or downloaded (when connected to a computer).

• Do not do any of the following while the card access lamp is blinking. Doing so may prevent the image data from being saved and render the internal memory or card unusable.

• Open the battery/card compartment cover

• Remove the battery and card

Extending the useful life of the battery

• Performing any of the following operations when not actually taking pictures can deplete the battery power.

• Repeatedly pressing the shutter button halfway

• Repeatedly using the zoom

• To save battery power, set [POWER SAVE] to [ON], or turn off the camera whenever it is not in use.

g “POWER SAVE Setting the camera to the power save mode” (P. 29)

Functions that cannot be selected from menus/Functions that cannot be selected even by pressing the function buttons

• Some items may not be selectable from the menus when using the arrow pad. (The menu items displayed in gray cannot be selected.)

• Items that cannot be set with the current shooting mode

• Items that cannot be set because of an item that has already been set: [%] and [#],

etc.

• Some functions cannot be used when there is no card in the camera.

[PANORAMA], [PRINT ORDER], [FORMAT], [BACKUP]

• When the mode dial is set to R, functions cannot be changed.

To return the settings of functions to default settings

• To return the changed shooting settings to default settings while shooting, set [RESET] to [YES].

g “RESET Changing the shooting functions back to default settings” (P. 21)

• All shooting settings except for P mode, [IMAGE QUALITY] and the selected scene mode return to default settings when the camera is turned off.

Getting to know your camera better

Playback help and troubleshooting tips

The red-eye cannot be fixed

• Depending on the picture, the red-eye may not be fixed. Also, parts except the eye may be fixed.

Bright specks appear in the picture

• Light reflecting from dust and other particles in the air at night may appear as bright specks in pictures taken using the flash.

Playback tips

Playing back pictures in the internal memory

• When a card has been inserted in the camera, the pictures in the internal memory cannot

be played back. Pull out the card before operating the camera.

Viewing picture information

• Play back a picture, and press g/E. Press g/E repeatedly to change the amount

of information displayed.

g “g/E button Changing the information on display/Display the menu guide” (P. 14)

Quickly displaying a desired picture

• Turn the zoom lever to the W-side to display the pictures as thumbnails (index display).

g “Zoom lever Zooming while shooting/Close-up playback” (P. 17)

Erasing sound recorded to still pictures

• Once sound is added to a picture, it is not possible to erase the sound. In this case, make

a re-recording with silence.

g “R Adding sound to still pictures” (P. 26)

Viewing pictures on a computer

Viewing the entire picture on a computer screen

The size of the picture displayed on a computer screen changes depending on the computer settings. When the monitor setting is 1,024 × 768 and you are using Internet Explorer to view a picture with an image size of 2,048 × 1,536 at 100%; the entire picture cannot be viewed without scrolling. There are several ways you can view the entire picture on the computer screen.

View the picture using image browsing software

• Install the OLYMPUS Master 2 software from the provided CD-ROM.

Change the monitor setting

• The icons on the computer desktop may be rearranged. For details of changing the

settings on your computer, refer to the computer’s instruction manual.

Getting to know your camera better

When you get an error message on the camera...

Monitor indication Possible cause Corrective action

CARD ERROR

WRITE PROTECT

MEMORY FULL

There is a problem with the card.

Writing to the card is prohibited.

The internal memory has no available memory and cannot store any new data.

This card cannot be used. Insert a new card.

The recorded image has been protected (read-only) on a computer. Download the image to a computer and cancel the readonly setting.

Insert a card or erase unwanted data. Before erasing, backup the data of important pictures using the card or download such pictures to a computer.

Monitor indication Possible cause Corrective action

CARD FULL

NO PICTURE

PICTURE ERROR

THE IMAGE

CANNOT BE

EDITED

CARD-COVER

OPEN

BATTERY EMPTY

CARD SETUP

CLEAN CARD

FORMAT

MEMORY SETUP

POWER OFF

MEMORY FORMAT

NO CONNECTION

NO PAPER

SET

The card has no available memory and cannot store any new data.

There are no pictures in the internal memory or on the card.

There is a problem with the selected picture and it cannot be played back on this camera.

Pictures taken by other cameras, or previously edited or corrected pictures cannot be edited or fixed.

The battery/card compartment cover is open.

The battery is empty. Charge the battery.

The card is not being recognized by the camera. Or, the card is not formatted.

There is an error in the internal memory.

The camera is not connected to the computer or the printer correctly.

There is no paper in the printer.

The printer has run out of ink.

Replace the card or erase unwanted data. Before erasing, download important pictures to a computer.

The internal memory or the card contains no pictures. Record pictures.

Use image processing software to view the picture on a computer. If that cannot be done, the image file is damaged.

Use image processing software to edit the pictures.

Close the battery/card compartment cover.

• Select [CLEAN CARD], and press . Remove the card and wipe the contact area with a soft, dry cloth.

• Select [FORMAT] [YES] and press

. All data on the card is erased.



Select [MEMORY FORMAT] [YES] and press . All data in the internal memory is erased.

Disconnect the camera and connect it again correctly.

Load some paper into the printer.

Replace the ink cartridge in the printer.

NO INK

The paper is jammed. Remove the jammed paper.

JAMMED

SETTINGS CHANGED

PRINT ERROR

CANNOT PRINT

The printer’s paper tray has been removed or the printer has been operated while changing settings on the camera.

There is a problem with the printer and/or camera.

Pictures recorded on other cameras may not be printed on this camera.

Do not operate the printer while changing settings on the camera.

Turn off the camera and printer. Check the printer and remedy any problems before turning the power on again.

Use a computer to print.

Getting to know your camera better

Functions available in shooting modes and scenes

Some functions cannot be set in certain shooting modes. For more details, refer to the table below.

Functions available in shooting modes

Shooting mode

h P

Function F 999999999999P. 15

& 999– 9 – 99–––– % 999– 9 – 99––––P.15 Y 999999999999P. 16 # 9999–

Zoom 9 9999999 – 999P. 17

IMAGE QUALITY 9 9999999999–

WB – 99999999999P. 21

ISO – 9 ––––––––––P.22

R (still picture) – 999 – 999999–P.22 R (movie) – – – – 9 –––––––P.22

PANORAMA – 999 – 999999–P.22

FACE DETECT – 999 – 99999 – 9 P. 23

*1 Shooting mode is fixed at [&]. *2 [#] is fixed at [$]. *3 [IMAGE QUALITY] is fixed at [C].

l A

MCN

99–*29 –*2–*2–*2P. 16

W PdRSXi

Ref.

Page

P. 15

P. 20

Getting to know your camera better

Appendix

Camera care

Cleaning the camera

Exterior:

• Wipe gently with a soft cloth. If the camera is very dirty, soak the cloth in mild soapy water and wring well. Wipe the camera with the damp cloth and then dry it with a dry cloth. If you have used the camera at the beach, use a cloth soaked in clean water and wrung well.

Monitor:

• Wipe gently with a soft cloth.

Lens:

• Blow dust off the lens with a commercial blower, then wipe gently with a lens cleaner.

Battery/Charger:

• Wipe gently with a soft, dry cloth.

Note

• Do not use strong solvents such as benzene or alcohol, or chemically treated cloth.

• Mold may form on the lens surface if the lens is left dirty.

Storage

• When storing the camera for extended periods, remove the battery and card, and keep in a cool, dry place that is well ventilated.

• Periodically, insert the battery and test the camera functions.

Note

• Avoid leaving the camera in places where chemical products are handled since this may result in corrosion.

Battery and charger

( This camera uses one Olympus lithium ion battery (LI-42B/LI-40B). No other type of batteries

can be used.

( Power consumption by the camera varies depending on which functions are used. ( During the conditions described below, power is consumed continuously and the battery

becomes exhausted quickly.

• The zoom is used repeatedly.

• The shutter button is pressed halfway repeatedly in shooting mode, activating the auto focus.

• A picture is displayed on the monitor for an extended period of time.

• The camera is connected to a computer or printer.

( Using an exhausted battery may cause the camera to turn off without displaying the battery

level warning.

( The rechargeable battery is not fully charged at the time of purchase. Charge the battery fully

with the LI-40C charger before use.

( The provided rechargeable battery usually takes approximately 5 hours to charge. ( This camera uses a charger specified by Olympus. Do not use any other type of charger.

Appendix

Using your charger abroad

( The charger can be used in most home electrical sources within the range of 100 V to 240 V

AC (50/60Hz) around the world. However, depending on the country or area you are in, the AC wall outlet may be shaped differently and the charger may require a plug adapter to match the wall outlet. For details, ask at your local electrical shop or travel agent.

( Do not use travel voltage converters as they could damage your charger.

Useful use of the accessories

2008.08.26

12:30

100-0004

ORM

The card

Pictures can be recorded on the optional card.

The internal memory and card are the camera’s media for recording pictures, similar to film in a film camera. Pictures recorded to the internal memory or card can be easily erased on the camera or processed using a computer. Unlike portable storage media, the internal memory cannot be removed or exchanged. The number of recordable pictures can be increased by using a card with a larger capacity.

1 Index area

You can use this space to write the contents of the card.

2 Contact area

The part where the data transferred from the camera enters the card. Do not touch this area directly.

Compatible cards

xD-Picture Card (16MB – 2GB) (Type H/M, Standard)

Using the internal memory or card

You can confirm on the monitor whether the internal memory or card is being used during shooting and playback operations.

Shooting mode Playback mode

Memory indicator B: When using the internal memory

ORM

No icon: When using a card

2008.08.26

12:30

Note

• Do not open the battery/card compartment cover while the card access lamp is blinking, as the lamp is indicating that it is reading or writing data. Doing so may damage the data in the internal memory or the card and render the internal memory or card unusable.

ORM

100-0004

Appendix

SAFETY PRECAUTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED OLYMPUS SERVICE PERSONNEL.

An exclamation mark enclosed in a triangle alerts you to important operating and maintenance instr uctions in the documentation provided with the product.

DANGER

WARNING

CAUTION

WARNING! TO AVOID THE RISK OF FIRE OR ELECTRICAL SHOCK, NEVER DISASSEMBLE, EXPOSE THIS PRODUCT TO WATER OR OPERATE IN A HIGH HUMIDITY ENVIRONMENT.

General Precautions

Read All Instructions — Before you use the product, read all operating instructions. Save all

manuals and documentation for future reference. Cleaning — Always unplug this product from the wall outlet before cleaning. Use only a damp cloth for cleaning. Never use any type of liquid or aerosol cleaner, or any type of organic solvent to clean this product. Attachments — For your safety, and to avoid damaging the product, use only accessories recommended by Olympus. Water and Moisture — For precautions on products with weatherproof designs, read the weatherproofing sections. Location — To avoid damage to the product, mount the product securely on a stable tripod, stand, or bracket.

Power Source — Connect this product only to the power source described on the product label. Foreign Objects — To avoid personal injury, never insert a metal object into the product. Heat — Never use or store this product near any heat source such as a radiator, heat register,

stove, or any type of equipment or appliance that generates heat, including stereo amplifiers.

If the product is used without observing the information given under this symbol, serious injury or death may result.

If the product is used without observing the information given under this symbol, injury or death may result.

If the product is used without observing the information given under this symbol, minor personal injury, damage to the equipment, or loss of valuable data may result.

Appendix

Handling the Camera

WARNING

( Do not use the camera near flammable or explosive gases. ( Do not use the flash and LED on people (infants, small children, etc.) at

close range.

• You must be at least 1 m (3 ft.) away from the faces of your subjects. Firing the flash too close to the subject’s eyes could cause a momentary loss of vision.

( Keep young children and infants away from the camera.

• Always use and store the camera out of the reach of young children and infants to prevent the following dangerous situations which could cause serious injury:

• Becoming entangled in the camera strap, causing strangulation.

• Accidentally swallowing the battery, cards or other small parts.

• Accidentally firing the flash into their own eyes or those of another child.

• Accidentally being injured by the moving parts of the camera.

( Do not look at the sun or strong lights with the camera. ( Do not use or store the camera in dusty or humid places. ( Do not cover the flash with a hand while firing.

CAUTION

( Stop using the camera immediately if you notice any unusual odors,

noise, or smoke around it.

• Never remove the batteries with bare hands, which may cause a fire or burn your hands.

( Never hold or operate the camera with wet hands. ( Do not leave the camera in places where it may be subject to extremely

high temperatures.

• Doing so may cause parts to deteriorate and, in some circumstances, cause the camera to catch fire. Do not use the charger if it is covered (such as a blanket). This could cause overheating, resulting in fire.

( Handle the camera with care to avoid getting a low-temperature burn.

• When the camera contains metal parts, overheating can result in a low-temperature burn. Pay attention to the following:

• When used for a long period, the camera will get hot. If you hold on to the camera in this

state, a low-temperature burn may be caused.

• In places subject to extremely cold temperatures, the temperature of the camera’s body

may be lower than the environmental temperature. If possible, wear gloves when handling the camera in cold temperatures.

( Be careful with the strap.

• Be careful with the strap when you carry the camera. It could easily catch on stray objects and cause serious damage.

Appendix

Battery Handling Precautions

Follow these important guidelines to prevent batteries from leaking, overheating, burning, exploding, or causing electrical shocks or burns.

DANGER

• The camera uses a lithium ion battery specified by Olympus. Charge the battery with the specified charger. Do not use any other chargers.

• Never heat or incinerate batteries.

• Take precautions when carrying or storing batteries to prevent them from coming into contact with any metal objects such as jewelry, pins, fasteners, etc.

• Never store batteries where they will be exposed to direct sunlight, or subjected to high

temperatures in a hot vehicle, near a heat source, etc.

• To prevent causing battery leaks or damaging their terminals, carefully follow all instructions

regarding the use of batteries. Never attempt to disassemble a battery or modify it in any way, by soldering, etc.

• If battery fluid gets into your eyes, flush your eyes immediately with clear, cold running water and

seek medical attention immediately.

• Always store batteries out of the reach of small children. If a child accidentally swallows a battery,

seek medical attention immediately.

WARNING

• Keep batteries dry at all times.

• To prevent batteries from leaking, overheating, or causing a fire or explosion, use only batteries

recommended for use with this product.

• Insert the battery carefully as described in the operating instructions.

• If rechargeable batteries have not been recharged within the specified time, stop charging them

and do not use them.

• Do not use a battery if it is cracked or broken.

• If a battery leaks, becomes discolored or deformed, or becomes abnormal in any other way during

operation, stop using the camera.

• If a battery leaks fluid onto your clothing or skin, remove the clothing and flush the affected area

with clean, running cold water immediately. If the fluid burns your skin, seek medical attention immediately.

• Never subject batteries to strong shocks or continuous vibration.

CAUTION

• Before loading, always inspect the battery carefully for leaks, discoloration, warping, or any other

abnormality.

• The battery may become hot during prolonged use. To avoid minor burns, do not remove it

immediately after using the camera.

• Always unload the battery from the camera before storing the camera for a long period.

Caution for Usage Environment

• To protect the high-precision technology contained in this product, never leave the camera in the

places listed below, no matter if in use or storage:

• Places where temperatures and/or humidity are high or go through extreme changes. Direct sunlight, beaches, locked cars, or near other heat sources (stove, radiator, etc.) or humidifiers.

• In sandy or dusty environments.

• Near flammable items or explosives.

• In wet places, such as bathrooms or in the rain. When using products with weatherproof designs, read their manuals as well.

• In places prone to strong vibrations.

• Never drop the camera or subject it to severe shocks or vibrations.

• When mounted on a tripod, adjust the position of the camera with the tripod head. Do not twist the camera.

• Do not touch electric contacts on cameras.

• Do not leave the camera pointed directly at the sun. This may cause lens or shutter curtain damage, color failure, ghosting on the CCD, or may possibly cause fires.

• Do not push or pull severely on the lens.

• Before storing the camera for a long period, remove the battery. Select a cool, dry location for storage to prevent condensation or mold from forming inside the camera. After storage, test the camera by turning it on and pressing the shutter release button to make sure that it is operating normally.

• Always observe the operating environment restrictions described in the camera’s manual.

Appendix

Battery Handling Precautions

• This camera uses a lithium ion battery specified by Olympus. Do not use any other type of battery.

For safe and proper use, read the battery’s instruction manual carefully before using it.

• If the battery’s terminals get wet or greasy, camera contact failure may result. Wipe the battery

well with a dry cloth before use.

• Always charge a battery when using it for the first time, or if it has not been used for a long period.

• When operating the camera with battery power at low temperatures, try to keep the camera and

spare battery as warm as possible. A battery that has run down at low temperatures may be restored after it is warmed at room temperature.

• The number of pictures you can take may vary depending on the shooting conditions or battery.

• Before going on a long trip, and especially before traveling abroad, purchase extra batteries. A

recommended battery may be difficult to obtain while traveling.

• Please recycle batteries to help save our planet’s resources. When you throw away dead

batteries, be sure to cover their terminals and always observe local laws and regulations.

LCD Monitor

• Do not push the monitor forcibly; otherwise the image may become vague, resulting in a playback

mode failure or damage to the LCD monitor.

• A strip of light may appear on the top/bottom of the monitor, but this is not a malfunction.

• When a subject is viewed diagonally in the camera, the edges may appear zigzagged on the

monitor. This is not a malfunction; it will be less noticeable in playback mode.

• In places subject to low temperatures, the LCD monitor may take a long time to turn on or its color

may change temporarily. When using the camera in extremely cold places, it is a good idea to occasionally place it in a warm place. An LCD monitor exhibiting poor performance due to low temperatures will recover in normal temperatures.

• The LCD used for the monitor is made with high-precision technology. However, black spots or

bright spots of light may appear constantly on the LCD monitor. Due to its characteristics or the angle at which you are viewing the monitor, the spot may not be uniform in color and brightness. This is not a malfunction.

Legal and Other Notices

• Olympus makes no representations or warranties regarding any damages, or benefit expected by

using this unit lawfully, or any request from a third person, which are caused by the inappropriate use of this product.

• Olympus makes no representations or warranties regarding any damages or any benefit

expected by using this unit lawfully which are caused by erasing picture data.

Disclaimer of Warranty

• Olympus makes no representations or warranties, either expressed or implied, by or concerning

any content of these written materials or software, and in no event shall be liable for any implied warranty of merchantability or fitness for any particular purpose or for any consequential,

Appendix

incidental or indirect damages (including but not limited to damages for loss of business profits, business interruption and loss of business information) arising from the use or inability to use these written materials or software or equipment. Some countries do not allow the exclusion or limitation of liability for consequential or incidental damages, so the above limitations may not apply to you.

• Olympus reserves all rights to this manual.

Warning

Unauthorized photographing or use of copyrighted material may violate applicable copyright laws. Olympus assumes no responsibility for unauthorized photographing, use or other acts that infringe upon the rights of copyright owners.

All rights reserved. No part of these written materials or this software may be reproduced or used in any form or by any means, electronic or mechanical, including photocopying and recording or the use of any type of information storage and retrieval system, without the prior written permission of Olympus. No liability is assumed with respect to the use of the information contained in these written materials or software, or for damages resulting from the use of the information contained therein. Olympus reserves the right to alter the features and contents of this publication or software without obligation or advance notice.

Appendix

For customers in Europe

“CE” mark indicates that this product complies with the European requirements for safety, health, environment and customer protection. “CE” mark cameras are intended for sales in Europe.

This symbol [crossed-out wheeled bin WEEE Annex IV] indicates separate collection of waste electrical and electronic equipment in the EU countries. Please do not throw the equipment into the domestic refuse. Please use the return and collection systems available in your country for the disposal of this product.

Use Only Dedicated Rechargeable Battery and Battery Charger

We strongly recommend that you use only the genuine Olympus dedicated rechargeable battery and battery charger with this camera. Using a non-genuine rechargeable battery and/or battery charger may result in fire or personal injury due to leakage, heating, ignition or damage to the battery. Olympus does not assume any liability for accidents or damage that may result from the use of a battery and/ or battery charger that are not genuine Olympus accessories.

Provisions of warranty

1. If this product proves to be defective, although it has been used properly (in accordance with the

written Handling Care and Operating instructions supplied with it), during a period of two years from the date of purchase from an authorized Olympus distributor within the business area of Olympus Imaging Europa GmbH as stipulated on the web site: http://www.olympus.com this product will be repaired, or at Olympus’s option replaced, free of charge. To claim under this warranty the customer must take the product and this Warranty Certificate before the end of the two year warranty period to the dealer where the product was purchased or any other Olympus service station within the business area of Olympus Imaging Europa GmbH as stipulated on the web site: http://www.olympus.com. During the one year period of the World Wide Warranty the customer may turn the product in at any Olympus service station. Please notice that not in all countries such Olympus service station exists.

2. The customer shall transport the product to the dealer or Olympus authorized service station at

his own risk and shall be responsible for any costs incurred in transporting the product.

3. This warranty does not cover the following and the customer will be required to pay repair

charge, even for defects occurring within the warranty period referred to above. (a) Any defect that occurs due to mishandling (such as an operation performed that is not

mentioned in the Handling Care or other sections of the instructions, etc.)

(b) Any defect that occurs due to repair, modification, cleaning, etc. performed by anyone other

than Olympus or an Olympus authorized service station.

product.

(d) Any defect or damage that occurs due to fire, earthquake, flood damage, thunderbolt, other

natural disasters, environmental pollution and irregular voltage sources.

(e) Any defect that occurs due to careless or improper storage (such as keeping the product

Appendix

under conditions of high temperature and humidity, near insect repellents such as

naphthalene or harmful drugs, etc.), improper maintenance, etc. (f) Any defect that occurs due to exhausted batteries, etc. (g) Any defect that occurs due to sand, mud, etc. entering the inside of the product casing. (h) When this Warranty Certificate is not returned with the product. (i) When any alterations whatsoever are made to the Warranty Certificate regarding the year,

month and date of purchase, the customer’s name, the dealer’s name, and the serial

number. (j) When proof of purchase is not presented with this Warranty Certificate.

4. This Warranty applies to the product only; the Warranty does not apply to any other accessory equipment, such as the case, strap, lens cap and batteries.

5. Olympus’s sole liability under this warranty shall be limited to repairing or replacing the product. Any liability for indirect or consequential loss or damage of any kind incurred or suffered by the customer due to a defect of the product, and in particular any loss or damage caused to any lenses, films, other equipment or accessories used with the product or for any loss resulting from a delay in repair or loss of data, is excluded. Compelling regulations by law remain unaffected by this.

Notes regarding warranty maintenance

1. This warranty will only be valid if the Warranty Certificate is duly completed by Olympus or an authorized dealer or other documents contain sufficient proof. Therefore, please make sure that your name, the name of the dealer, the serial number and the year, month and date of purchase are all completed or the original invoice or the sales receipt (indicating the dealer’s name, the date of purchase and product type) is attached to this Warranty Certificate. Olympus reserves the right to refuse free-of-charge service if neither Warranty Certificate is completed nor the above document is attached or if the information contained in it is incomplete or illegible.

2. Since this Warranty Certificate will not be re-issued, keep it in a safe place.

* Please refer to the list on the web site: http://www.olympus.com for the authorized international

Olympus service network.

Trademarks

• IBM is a registered trademark of International Business Machines Corporation.

• Microsoft and Windows are registered trademarks of Microsoft Corporation.

• Macintosh is a trademark of Apple Inc.

• xD-Picture Card™ is a trademark.

• All other company and product names are registered trademarks and/or trademarks of their

respective owners.

• The standards for camera file systems referred to in this manual are the “Design Rule for Camera

File System/DCF” standards stipulated by the Japan Electronics and Information Technology Industries Association (JEITA).

Appendix

SPECIFICATIONS

(Camera

Product type : Digital camera (for shooting and displaying) Recording system

Still pictures : Digital recording, JPEG (in accordance with Design rule for

Applicable standards : Exif 2.2, Digital Print Order Format (DPOF), PRINT Image

Sound with still pictures : Wave format Movies : AVI Motion JPEG

Memory : Internal memory

Number of effective pixels : 8,000,000 pixels Image pickup device : 1/2.35" CCD (primary color filter),

Lens : Olympus lens 6.3 to 31.5 mm, f3.5 to 5.6

Photometric system : Center-weighted metering Shutter speed : 4 to 1/2000 sec. Shooting range : 0.6 m (2.0 ft.) to ) (W), 1 m (3.3 ft.) to ) (T) (normal)

Monitor : 2.7" TFT color LCD display, 154,000 dots Outer connector : USB connector, A/V OUT jack (multi-connector) Automatic calendar system : 2000 up to 2099 Operating environment

Temperature : 0°C to 40°C (32°F to 104°F) (operation)/

Humidity : 30% to 90% (operation)/10% to 90% (storage) Power supply : One Olympus lithium ion battery (LI-42B/LI-40B) Dimensions : 97.7 mm (W) × 57.7 mm (H) × 23.3 mm (D)

Weight : 123 g (4.3 oz) without battery and card

Camera File system (DCF))

Matching III, PictBridge

xD-Picture Card (16 MB – 2 GB) (Type H/M, Standard)

8,500,000 pixels (gross)

(equivalent to 36 to 180 mm on a 35 mm camera)

0.1 m (0.3 ft.) to ) (W), 0.6 m (2.0 ft.) to ) (T) (macro mode)

0.03 m (0.1 ft.) to ) (super macro mode)

-20°C to 60°C (-4°F to 140°F) (storage)

(3.8 × 2.3 × 0.9 in.) (excluding protrusions)

Appendix

(Lithium ion battery (LI-42B)

Product type : Lithium ion rechargeable battery Standard voltage : DC 3.7 V Standard capacity : 740 mAh Battery life : Approx. 300 full charges (varies on usage) Operating environment

Temperature : 0°C to 40°C (32°F to 104°F) (charging)/

Dimensions : 31.5 × 39.5 × 6 mm (1.2 × 1.5 × 0.2 in.) Weight : Approx. 15 g (0.5 oz)

-10°C to 60°C (14°F to 140°F) (operation)/

-20°C to 35°C (-4°F to 95°F) (storage)

(Battery charger (LI-40C)

Power requirements : AC 100 to 240 V (50 to 60 Hz)

Output : DC 4.2 V, 200 mA Charging time : Approx. 5 hours Operating environment

Temperature : 0°C to 40°C (32°F to 104°F) (operation)/

Dimensions : 62 × 23 × 90 mm (2.4 × 0.9 × 3.5 in.) Weight : Approx. 65 g (2.3 oz)

Design and specifications subject to change without notice.

3.2 VA (100 V) to 5.0 VA (240 V)

-20°C to 60°C (-4°F to 140°F) (storage)

Appendix

Names of Parts

Camera

Multi connector gP. 29, 30, 36

Strap eyelet gP. 3

Self-timer lamp gP. 16

Zoom lever gP. 17

o button gP. 11

Flash gP. 16

Microphone gP. 22

Connector cover gP. 29, 30, 36

Card access lamp gP. 38, 43, 48

K button (Shooting) gP. 12

Monitor gP. 28

q button (Playback) gP. 12

 button gP. 14

Appendix

X& button (Macro mode) gP. 15

Tripod socket

Speaker

Battery/card compartment cover gP. 4

Lens

Shutter button gP. 11

Mode dial gP. 13

OF/< button (Exposure Compensation/Print) gP. 15

Arrow pad (ONXY) gP. 15

Y# button (Flash mode) gP. 16

 button (OK/FUNC)

gP. 15

NY button (Self-timer) gP. 16

/S button (Backlight boost/ Erase) gP. 16

m button gP. 16

Monitor Symbols & Icons

+2.0

00:34

VGA

+2.0

1/1000

F3.5

ISO 400

ORM

(Shooting Mode

2 4 53

ISO

400

ORM

+2.0

1/1000

F3.5

2 4 53

6 7

101113 12

VGA

+2.0

101113

00:34

8 9

MoviesStill pictures

Item Indications Ref. Page

1 Shooting mode A, c

B, F, U, C, A etc. P. 13

2 Flash mode !, #, $ P. 16 3 Silent mode U P. 23

4 Macro mode

Super macro mode

5 Battery check

6 Flash standby

Camera movement warning/flash charge

7 AF target mark

& %

= full power, [ = charge the battery P. 45

# (Lit)

(Blinks)

8 Sound record R P. 22

9 Number of storable still

pictures Remaining recording time400:34

10 Current memory B (Recording pictures to the internal memory),

No icon (Recording pictures to the card)

11 Self-timer Y P. 16

12 Shutter speed/Aperture

value

1/1000 F3.5, etc. P. 9

13 Exposure compensation -2.0 – +2.0 P. 15 14 Compression M (NORMAL), L (FINE) P. 20 15 Image size G, H, D, C, etc. P. 20

16 ISO ISO100, ISO400, etc. P. 22 17 White balance 5, 3, 1, w – y P. 21

P. 15

P. 39

P. 9

P. 11

P. 14

P. 48

Appendix

(Playback Mode

2008.08.26

12:30

100-0004

00:14 /00:34

VGA

2008.08.26

12:30

100-0004

+2.0

F3.5

1/1000

ISO400

ORM

4 51

2008.08.26

00:14 /00:34

VGA

12:30

100-0004

2008.08.26

12:30

4 51

F3.5

1/1000

ISO400

100-0004

ORM

+2.0

7 8

9 10 11

121314

MoviesStill pictures

Item Indications Ref. Page

1 Silent mode U P. 23

2 Print reservation/Number

of prints

<×10 P. 32

3 Sound record H P. 22 4Protect 9 P. 25

5 Battery check

6 Shutter speed/Aperture

value

= full power, [ = charge the battery P. 45

1/1000 F3.5, etc. P. 9

7 Exposure compensation -2.0 – +2.0 P. 15 8 White balance WB AUTO, 5, 3, 1, w – y P. 21 9 Image size G, H, D, C, etc. P. 20

10 File number M 100

11 Number of frames

Playing time/Total recording time

12 Current memory B (Playing back the picture in the internal memory),

-0004 –

4 00:14/00:34

No icon (Playing back the picture in the card)

P. 12

P. 48

13 Compression M (NORMAL), L (FINE) P. 20

14 ISO ISO100, ISO400, etc. P. 22

15 Date and time 2008.08.26 12:30 P. 29

8 9 15 10 11

–

Appendix

Index

Names of Parts......................................... 58

ALL ERASE ............................................... 26

ALL INDEX ................................................ 31

ALL PRINT................................................. 31

All-frame reservation U............................ 33

Aperture value ....................................... 9, 11

AUCTION i............................................. 13

h (AUTO) .............................................. 6

AUTO (ISO) ............................................... 22

AUTO (WB)................................................ 21

Auto flash AUTO........................................ 16

Auto focus.................................................. 40

AV cable ................................................ 3, 29

BACKUP .................................................... 27

Battery ................................................... 4, 47

Battery charger ...................................... 4, 47

Battery check ............................................. 59

BEEP ......................................................... 28

BEHIND GLASS P................................... 13

CAMERA MENU........................................ 21

CANDLE W .............................................. 13

Card ............................................... 32, 42, 48

Close-up playback U ................................ 17

Cloudy day 3 .......................................... 21

COMPRESSION........................................ 20

Continuous recording length...................... 42

Cropping pictures P..................... 25, 32, 33

CUISINE V................................................ 13

CUSTOM PRINT ....................................... 31

Date and time X............................ 7, 29, 39

Digital zoom ......................................... 14, 17

Direct printing............................................. 30

DOCUMENTS d ...................................... 13

DPOF......................................................... 32

EASY PRINT ............................................. 30

EDIT........................................................... 24

ERASE................................................. 10, 26

Error messages ......................................... 44

Exposure compensation F ....................... 41

FACE DETECT.......................................... 23

FILE NAME................................................ 32

File name ................................................... 29

Fill-in flash #............................................. 16

FIREWORKS X ....................................... 13

Flash .......................................................... 16

Flash charge .............................................. 39

Flash mode # ........................................... 16

Flash off $................................................ 16

Fluorescent lamp wxy....................... 21

Focus .............................................. 9, 11, 40

Focus lock ................................................. 11

FORMAT ................................................... 27

Function menu .......................................... 15

R (Shooting guide) ......................... 6, 13

IMAGE QUALITY ...................................... 20

IMAGE SIZE.............................................. 20

Index display G ....................................... 17

INDOOR N .............................................. 13

Information displays .................................. 14

Internal memory ...................... 27, 42, 44, 48

ISO ............................................................ 22

LIGHTING FIX........................................... 23

Lithium ion battery................................... 3, 4

Macro mode & ......................................... 15

MEMORY FORMAT.................................. 27

Menu ......................................................... 18

MENU COLOR.......................................... 28

Menu guide ............................................... 14

Monitor .......................................... 11, 28, 59

Monitor brightness adjustment s

.............................................................. 28

MULTI PRINT............................................ 31

MY FAVORITE.......................................... 24

NIGHT+PORTRAIT M............................. 13

NTSC ........................................................ 29

Number of storable still pictures ................ 42

OLYMPUS Master..................................... 35

Operation guide......................................... 18

Optical zoom ....................................... 14, 17

PAL ........................................................... 29

PANORAMA.............................................. 22

PC ............................................................. 36

PERFECT FIX........................................... 23

PictBridge.................................................. 30

Picture rotation y ..................................... 25

PIXEL MAPPING ...................................... 28

Playback mode q............ 10, 12, 14, 17, 60

Playback mode menu q.......................... 23

Playback on a TV ...................................... 29

Playing time/Total recording time .............. 12

POWER SAVE .......................................... 29

Press completely................................... 9, 11

Press halfway........................................ 9, 11

PRINT ORDER < .............................. 25, 31

Print settings <......................................... 32

Printing pictures......................................... 30

P (Program auto)......................................... 6

Protect 0................................................ 25

Recording movies with or without

sound R ................................................ 22

Recording R .............................................. 26

Recording sound with still pictures R ........ 22

REDEYE FIX ............................................. 23

Red-eye reduction flash ! ..................... 16

RESET................................................. 21, 43

Resizing Q.............................................. 24

f (Scene) ................................. 6, 13, 21

SEL. IMAGE .............................................. 26

Selecting a language W....................... 27

SELF PORTRAIT R................................. 13

Self-timer Y .............................................. 16

SETUP menu............................................. 27

Shooting mode ............ 11, 12, 14, 17, 46, 59

Shooting movies n............................. 11, 14

Shooting still pictures................................. 11

SHUTTER SOUND.................................... 28

Shutter speed ........................................ 9, 11

SILENT MODE U ..................................... 23

Single-frame playback ............................... 17

Single-frame reservation < ...................... 33

Sleep mode ............................................... 39

SLIDESHOW ....................................... 23, 24

SOUND SETTINGS................................... 28

SPORT j ................................................ 13

Strap ............................................................ 3

Sunny day 5............................................ 21

SUNSET S .............................................. 13

Super macro mode % .............................. 15

Top menu .................................................. 18

Tungsten light 1....................................... 21

USB cable............................ 3, 30, 35, 36, 38

VIDEO OUT............................................... 29

q VOLUME ............................................. 28

VOLUME ................................................... 12

Warning sound 8..................................... 28

White balance WB ..................................... 21

xD-Picture Card ............................. 22, 42, 48

Zoom ......................................................... 17

VS545201

Olympus FE-330, C-550 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Button operations

o button Turning the camera on and off

Shutter button Shooting pictures/Recording movies

K button (Shooting) Selecting shooting mode/Turning the camera on

q button (Playback) Selecting playback mode/Turning the camera on

Mode dial Switching shooting modes

h Shooting pictures with automatic settings

P Set the optimum aperture value and shutter speed

h Shooting pictures using digital image stabilization

Shooting pictures according to the situation

R Follow the shooting guide

n Recording movies

g/E button Changing the information on display/Display the menu guide

g Changing the information displays

E Displaying the menu guide

X& button Shooting pictures close to the subject (Macro mode)

NY button Self-timer shooting

Y# button Flash shooting

m button Displaying the top menu

 Increasing the brightness of the monitor (Backlight boost)

Erasing pictures

Zoom lever Zooming while shooting/Close-up playback

Menu operations

About the menus

Operation guide

Using the menus

Shooting mode menu K

IMAGE QUALITY Changing the image quality

RESET Changing the shooting functions back to default settings

f (Scene) Shooting pictures by selecting a scene according to the situation

CAMERA MENU

SILENT MODE Muting operational sounds

Playback mode menu q

SLIDESHOW Playing back pictures automatically

PERFECT FIX Editing images

MY FAVORITE Viewing and registering pictures in My Favorite

EDIT

PRINT ORDER Making print reservations (DPOF)

PLAYBACK MENU

ERASE Erasing selected pictures/Erasing all pictures

SETUP menus

Playing back pictures on a TV

Printing pictures

Direct printing (PictBridge)

EASY PRINT

Other print modes and print settings (CUSTOM PRINT)

Print settings (DPOF)

Making a print reservation

Resetting print reservation data

Using OLYMPUS Master

Install the OLYMPUS Master software

Connecting the camera to a computer

Start up the OLYMPUS Master software

Displaying camera images on a computer

Downloading and saving images

To download and save images to a computer without using OLYMPUS Master

Getting to know your camera better

Shooting tips and information

Tips before you start taking pictures

The camera does not turn on even when a battery is loaded

The card cannot be used

No picture is taken when the shutter button is pressed

The date and time have not been set

Shooting tips

Focusing on the subject

Subjects that are difficult to focus on

Taking pictures without blurring

Taking blur-free pictures without the flash

The picture is too grainy

Taking pictures with the correct color

Taking pictures of a white beach or snow scene

Taking pictures of a subject against backlight

Additional shooting tips and information

Increasing the number of pictures that can be taken

Using a new card

The card access lamp is blinking
