Olympus AU 400 - 600 - 640 instructions
rev 422.0.2 - 2010-08-01
Chema Diagnostica
Via Campania 2/4
I-60030 Monsano | An Italy
T +39 0731 605064 | F +39 0731 605672
www.chema.com | mail@chema.com
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Olympus AU 400 - 600 - 640 instructions
rev 422.0.2 - 2010-08-01
Warning!
These programs should be used only as guideline.
To check the reagent correct setting on the
instrument, use only good quality control sera
and work accordingly to with good laboratory
practice. Instrumental factor must be checked.
Chema Diagnostica will not be responsible for
instrumental bad programming.
IUS.422.0.2 Directions for use Edition 2010-08-01 page 3 of 41
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: ACID PHOSPHATASE - Codes AC 0120 TC
Preparation: POWDER SINGLE REAGENT. FOLLOW PREPARATION PROGRAM INDICATED IN INSERT
SHEET. INSTALL AS R1
Storage: REFRIGERATE AT 2-8°C
TEST NAME: ACP
Sample: Volume 20 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 410 Sec. 800 Min OD Max OD
Method: RATE L - 0.1 H 2.5
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.3
Last L - 0.1 First H 0.3
Measuring point 1: First 12 Last 27
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: NO L 1 H 60
Correlation factor:
A 1 B 0
On-board stability period: 30
Unit: U/L
Factor: 853
IUS.422.0.2 Directions for use Edition 2010-08-01 page 4 of 41
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: ALBUMIN - Codes BC 0100 / 0500 / 1000 / 1500 CH
Preparation: R1 - LIQUID READY TO USE SINGLE REAGENT
Storage: REFRIGERATE (2-8°C)
Stability: AS INDICATED IN THE LABEL
TEST NAME: ALB
Sample: Volume 2 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 295 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 600 Sec. 800 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First 0 Last 4
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: YES L 0.1 H 6.0
Correlation factor:
A 1 B 0
On-board stability period: 90
Unit: g/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 5 of 41
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: ALKALINE PHOSPHATASE FL (IFCC) - Codes AF F080 / F245 / F400 / F600 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: ALP
Sample: Volume 5 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 410 Sec. 480 Min OD Max OD
Method: RATE L -0.1 H 2.5
Reaction slope: + Reagent OD limit:
First L -0.1 First H 1.5
Last L -0.1 First H 1.5
Measuring point 1: First 13 Last 19
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: NO L 5 H 3000
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: U/L
Factor: 2757
IUS.422.0.2 Directions for use Edition 2010-08-01 page 6 of 41
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: ALKALINE PHOSPHATASE (DGKC) FL - Codes AL F080 / F245 / F400 / F600 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: ALP
Sample: Volume 5 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 410 Sec. 480 Min OD Max OD
Method: RATE L - 0.1 H 2.0
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 1.2
Last L - 0.1 First H 1.2
Measuring point 1: First 20 Last 24
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: NO L 7 H 3000
Correlation factor:
A 1 B 0
On-board stability period: 30
Unit: U/L
Factor: 2757
IUS.422.0.2 Directions for use Edition 2010-08-01 page 7 of 41
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: AMYLASE FL - Codes AM F060 / F120 / F245 CH
Preparation: R1 - LIQUID READY TO USE SINGLE REAGENT
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: AMY
Sample: Volume 6 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 240 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 410 Sec. 480 Min OD Max OD
Method: RATE L - 0.1 H 2.0
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.3
Last L - 0.1 First H 0.3
Measuring point 1: First 5 Last 10
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: NO L 10 H 3000
Correlation factor:
A 1 B 0
On-board stability period: 30
Unit: U/L
Factor: 3178
IUS.422.0.2 Directions for use Edition 2010-08-01 page 8 of 41
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: AMYLASE EPS FL - Codes EA F080 / F245 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: AMY
Sample: Volume 8 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 192 ml Dilution 0 ml
R2 volume 48 ml Dilution 0 ml
Wavelenght: Pri. 410 Sec. 480 Min OD Max OD
Method: RATE L - 0.1 H 2.0
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.3
Last L - 0.1 First H 0.3
Measuring point 1: First 20 Last 27
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: NO L 6 H 1500
Correlation factor:
A 1 B 0
On-board stability period: 30
Unit: U/L
Factor: 3480
IUS.422.0.2 Directions for use Edition 2010-08-01 page 9 of 41
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: PANCREATIC ISOAMYLASE FL - Code PA F080 / F245 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: AMYP
Sample: Volume 5 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 410 Sec. 480 Min OD Max OD
Method: RATE L - 0.1 H 2.0
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.3
Last L - 0.1 First H 0.3
Measuring point 1: First 20 Last 27
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: NO L 2 H 2500
Correlation factor:
A 1 B 0
On-board stability period: 30
Unit: U/L
Factor: 3480
IUS.422.0.2 Directions for use Edition 2010-08-01 page 10 of 4110 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: BICARBONATE FL - Code BR F060 / F245 / F400 CH
Preparation: R1 - LIQUID READY TO USE SINGLE REAGENT
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: CO2
Sample: Volume 2.5 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 250 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 410 Sec. 480 Min OD Max OD
Method: FIXED L 0.1 H 2.5
Reaction slope: - Reagent OD limit:
First L - 2.0 First H 2.5
Last L - 2.0 First H 2.5
Measuring point 1: First 1 Last 9
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: L 1 H 50
Correlation factor:
A 1 B 0
On-board stability period: 30
Unit: mmol/L
IUS.422.0.2 Directions for use Edition 2010-08-01 page 11 of 4111 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: BILIRUBIN TOTAL FL - Code DT F125 / F500 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: BILT
Sample: Volume 10 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 520 Sec. 800 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First Last 27
Measuring point 2: First Last 10
Linearity: Dynamic range:
No Lag Time: L 0.05 H 20
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 12 of 4112 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: BILIRUBIN DIRECT FL - Code DD F125 / F500 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: BILD
Sample: Volume 10 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 540 Sec. 660 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First Last 27
Measuring point 2: First Last 10
Linearity: Dynamic range:
No Lag Time: L 0.05 H 20
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 13 of 4113 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: CALCIUM - Code CA 0305 / 0505 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT B
R2 - INSTALL LIQUID READY TO USE REAGENT A
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: CA
Sample: Volume 5 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 145 ml Dilution 0 ml
R2 volume 145 ml Dilution 0 ml
Wavelenght: Pri. 570 Sec. 660 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 1.2
Measuring point 1: First Last 27
Measuring point 2: First Last 10
Linearity: Dynamic range:
No Lag Time: L 0.1 H 20
Correlation factor:
A 1 B 0
On-board stability period: 30
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 14 of 4114 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: CALCIUM ASX - Code CA 0100 / 0500 CH
Preparation: R1 - LIQUID READY TO USE SINGLE REAGENT
Storage: ROOM TEMPERATURE OR REFRIGERATE (2-30°C)
Stability: AS INDICATED IN THE LABEL
TEST NAME: CA
Sample: Volume 3 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 295 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 660 Sec. 700 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 2.0
Last L - 0.1 First H 2.0
Measuring point 1: First Last 10
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: L 0.2 H 20
Correlation factor:
A 1 B 0
On-board stability period: 90
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 15 of 4115 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: CHOLESTEROL FL - Codes CT F100 / F400 / 100F / 150F CH
Preparation: R1 - LIQUID READY TO USE SINGLE REAGENT
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: CHOL
Sample: Volume 3 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 295 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 520 Sec. 700 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First Last 27
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: L 1 H 700
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 16 of 4116 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: HDL direct FL- Code HD F080 / F245 / F400 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: 60 DAYS OPEN BOTTLES
TEST NAME: HDLC
Sample: Volume 2 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 180 ml Dilution 0 ml
R2 volume 60 ml Dilution 0 ml
Wavelenght: Pri. 600 Sec. 700 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.3
Last L - 0.1 First H 0.3
Measuring point 1: First 0 Last 27
Measuring point 2: First 0 Last 10
Linearity: Dynamic range:
No Lag Time: L 1 H 220
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 17 of 4117 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: LDL direct FL- Code DL F080 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: 60 DAYS OPEN BOTTLES
TEST NAME: LDLC
Sample: Volume 2 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 180 ml Dilution 0 ml
R2 volume 60 ml Dilution 0 ml
Wavelenght: Pri. 600 Sec. 700 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.3
Last L - 0.1 First H 0.3
Measuring point 1: First 0 Last 27
Measuring point 2: First 0 Last 10
Linearity: Dynamic range:
No Lag Time: L 1 H 400
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 18 of 4118 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: CHOLINESTERASE FL (DGKC) - Codes CH F080 / F245 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: CHE
Sample: Volume 4 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 40 ml Dilution 0 ml
Wavelenght: Pri. 410 Sec. 480 Min OD Max OD
Method: RATE L 0.4 H 2.5
Reaction slope: - Reagent OD limit:
First L 1.1 First H 2.2
Last L 1.1 First H 2.2
Measuring point 1: First 16 Last 20
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: NO L 0.4 H 25*
Correlation factor:
A 1 B 0
On-board stability period: 30
Unit: U/L
Factor: 66*
* NOTE: results in kU/L
IUS.422.0.2 Directions for use Edition 2010-08-01 page 19 of 4119 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: CK-NAC FL - Codes CK F060 / F120 / F245 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: CK
Sample: Volume 10 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 340 Sec. 660 Min OD Max OD
Method: RATE L -0.1 H 2.0
Reaction slope: + Reagent OD limit:
First L -0.1 First H 0.5
Last L -0.1 First H 0.5
Measuring point 1: First 21 Last 27
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: NO L 1 H 1000
Correlation factor:
A 1 B 0
On-board stability period: 30
Unit: U/L
Factor: 4127
IUS.422.0.2 Directions for use Edition 2010-08-01 page 20 of 4120 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: CK-MB FL - Codes MB F060 / F120 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: CKMB
Sample: Volume 10 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 340 Sec. 660 Min OD Max OD
Method: RATE L -0.1 H 2.0
Reaction slope: + Reagent OD limit:
First L -0.1 First H 0.5
Last L -0.1 First H 0.5
Measuring point 1: First 21 Last 27
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: NO L 2 H 1000
Correlation factor:
A 1 B 0
On-board stability period: 30
Unit: U/L
Factor: 8254
IUS.422.0.2 Directions for use Edition 2010-08-01 page 21 of 4121 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: COPPER - Code CU 0100 CH
Preparation: R1 - MIX REAGENT A + REAGENT B AS INDICATED IN INSERT SHEET
Storage: ROOM TEMPERATURE - DO NOT REFRIGERATE IF POSSIBLE
Stability: 2 WEEKS
TEST NAME: CU
Sample: Volume 20 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 295 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 600 Sec. 700 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First Last 27
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: L 4 H 500
Correlation factor:
A 1 B 0
On-board stability period: 10
Unit: microg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 22 of 4122 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: CREATININE - Code CR 0500 / 1000 / 1500 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT B
R2 - INSTALL LIQUID READY TO USE REAGENT A
Storage: ROOM TEMPERATURE OR REFRIGERATE (2-30°C)
Stability: AS INDICATED IN THE LABEL
TEST NAME: CREA
Sample: Volume 20 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 145 ml Dilution 0 ml
R2 volume 145 ml Dilution 0 ml
Wavelenght: Pri. 520 Sec. 800 Min OD Max OD
Method: FIXED L - 0.1 H 2.5
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First 20 Last 24
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: L 0.2 H 20
Correlation factor:
A 1 B 0
On-board stability period: 14
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 23 of 4123 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: GAMMA-GT FL - Codes GT F080 / F245 / F400 / F600 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: GGT
Sample: Volume 25 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 410 Sec. 480 Min OD Max OD
Method: RATE L -0.1 H 2.0
Reaction slope: + Reagent OD limit:
First L -0.1 First H 1.5
Last L -0.1 First H 1.5
Measuring point 1: First 14 Last 23
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: NO L 2 H 800
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: U/L
Factor: 1571
IUS.422.0.2 Directions for use Edition 2010-08-01 page 24 of 4124 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: GLUCOSE FL - Codes GL F400 / 100F / 150F CH
Preparation: R1 - LIQUID READY TO USE SINGLE REAGENT
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: GLUC
Sample: Volume 3 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 295 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 520 Sec. 700 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First Last 27
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: L 1 H 500
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 25 of 4125 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: GLUCOSE UV FL - Code GL F601 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: GLUC
Sample: Volume 2.5 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 340 Sec. 380 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First Last 27
Measuring point 2: First Last 10
Linearity: Dynamic range:
No Lag Time: L 1 H 700
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 26 of 4126 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: GOT/AST FL - Codes GO F080 / F245 / F400 / F600 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: GOT
Sample: Volume 25 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 340 Sec. 660 Min OD Max OD
Method: RATE L 0.7 H 2.5
Reaction slope: - Reagent OD limit:
First L 1.0 First H 2.5
Last L 1.0 First H 2.5
Measuring point 1: First 14 Last 27
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: YES L 2 H 440
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: U/L
Factor: 1746
IUS.422.0.2 Directions for use Edition 2010-08-01 page 27 of 4127 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: GPT/ALT FL - Codes GP F060 / F245 / F400 / F600 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: GPT
Sample: Volume 25 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 340 Sec. 660 Min OD Max OD
Method: RATE L 0.7 H 2.5
Reaction slope: - Reagent OD limit:
First L 1.0 First H 2.5
Last L 1.0 First H 2.5
Measuring point 1: First 14 Last 27
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: YES L 2 H 440
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: U/L
Factor: 1746
IUS.422.0.2 Directions for use Edition 2010-08-01 page 28 of 4128 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: IRON FZ - Codes FE F245 / F400 CH
Preparation: R1 - INSTALL REAGENT A AFTER PREPARATION
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: FE
Sample: Volume 50 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 570 Sec. 800 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.3
Last L - 0.1 First H 0.3
Measuring point 1: First 0 Last 12
Measuring point 2: First 0 Last 10
Linearity: Dynamic range:
No Lag Time: L 25 H 1000
Correlation factor:
A 1 B 0
On-board stability period: 30
Unit: microg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 29 of 4129 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: LDH FL - Codes LD F060 / F120 / F245 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: LDH
Sample: Volume 4 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 340 Sec. 380 Min OD Max OD
Method: RATE L 0.7 H 2.5
Reaction slope: - Reagent OD limit:
First L 1.0 First H 2.5
Last L 1.0 First H 2.5
Measuring point 1: First 12 Last 27
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: YES L 30 H 2000
Correlation factor:
A 1 B 0
On-board stability period: 30
Unit: U/L
Factor: 8015
IUS.422.0.2 Directions for use Edition 2010-08-01 page 30 of 4130 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: LIPASE FL - Code LP F080 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: ALP
Sample: Volume 4 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 570 Sec. 800 Min OD Max OD
Method: RATE L -0.1 H 2.5
Reaction slope: + Reagent OD limit:
First L -0.1 First H 0.8
Last L -0.1 First H 0.8
Measuring point 1: First 13 Last 19
Measuring point 2: First Last
Linearity: 20% Dynamic range:
No Lag Time: NO L 3 H 300
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: U/L
IUS.422.0.2 Directions for use Edition 2010-08-01 page 31 of 4131 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: MAGNESIUM - Codes MG 0200 / 0500 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT B
R2 - INSTALL LIQUID READY TO USE REAGENT A
Storage: ROOM TEMPERATURE OR REFRIGERATE (2-30°C)
Stability: AS INDICATED IN THE LABEL
TEST NAME: MG
Sample: Volume 3 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 145 ml Dilution 0 ml
R2 volume 145 ml Dilution 0 ml
Wavelenght: Pri. 520 Sec. 800 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L 0.3 First H 2.0
Last L 0.3 First H 2.0
Measuring point 1: First Last 27
Measuring point 2: First Last 10
Linearity: Dynamic range:
No Lag Time: L 0.1 H 8
Correlation factor:
A 1 B 0
On-board stability period: 14
Unit: mEq/l
IUS.422.0.2 Directions for use Edition 2010-08-01 page 32 of 4132 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: MAGNESIUM XL - Codes MX 0300 / 0500 CH
Preparation: R1 - LIQUID READY TO USE SINGLE REAGENT
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: MG
Sample: Volume 3 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 295 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 520 Sec. 800 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L 0.3 First H 2.0
Last L 0.3 First H 2.0
Measuring point 1: First Last 27
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: L 0.3 H 6
Correlation factor:
A 1 B 0
On-board stability period: 14
Unit: mEq/l
IUS.422.0.2 Directions for use Edition 2010-08-01 page 33 of 4133 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: PHOSPHORUS - Code PH 0100 / 0500 CH
Preparation: R1 - LIQUID READY TO USE SINGLE REAGENT
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN INSERT SHEET
TEST NAME: PHOS
Sample: Volume 3 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 295 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 340 Sec. 380 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First Last 27
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: L 0.4 H 20
Correlation factor:
A 1 B 0
On-board stability period: 90
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 34 of 4134 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: PROTEINS HS - Code HS 0100 / 0500 CH
Preparation: R1 - LIQUID READY TO USE SINGLE REAGENT
Storage: ROOM TEMPERATURE OR REFRIGERATE (2-30°C)
Stability: AS INDICATED IN THE LABEL
TEST NAME: HS
Sample: Volume 2 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 295 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 600 Sec. 800 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First Last 27
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: L 0.3 H 500
Correlation factor:
A 1 B 0
On-board stability period: 90
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 35 of 4135 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: TOTAL PROTEINS - Codes TP 0500 / 1000 / 1500 CH
Preparation: R1 - LIQUID READY TO USE SINGLE REAGENT
Storage: ROOM TEMPERATURE OR REFRIGERATE (2-30°C)
Stability: AS INDICATED IN THE LABEL
TEST NAME: TP
Sample: Volume 3 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 295 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 540 Sec. 700 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First Last 27
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: L 0.1 H 12
Correlation factor:
A 1 B 0
On-board stability period: 30
Unit: g/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 36 of 4136 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: TRIGLYCERIDES FL - Code TR F100 / F400 / 100F / 150F CH
Preparation: R1 - LIQUID READY TO USE SINGLE RAGENT
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: TRIG
Sample: Volume 3 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 295 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 520 Sec. 700 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First Last 27
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: L 1 H 1000
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 37 of 4137 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: UREA UV FL - Codes AZ F080 / F245 / F400 / F600 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: UREA
Sample: Volume 3 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 340 Sec. 660 Min OD Max OD
Method: RATE L 1.0 H 2.5
Reaction slope: - Reagent OD limit:
First L 1.2 First H 2.5
Last L 1.2 First H 2.5
Measuring point 1: First 12 Last 18
Measuring point 2: First Last
Linearity: 25% Dynamic range:
No Lag Time: YES L 1 H 300
Correlation factor:
A 1 B 0
On-board stability period: 60
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 38 of 4138 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: URIC ACID T FL - Code AU F402 CH
Preparation: R1 - MIX REAGENT A + REAGENT B AS INDICATED IN INSERT SHEET
Storage: REFRIGERATE AT 2-8°C
Stability: 90 DAYS
TEST NAME: UA
Sample: Volume 10 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 295 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 540 Sec. 700 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First Last 27
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: L 0.2 H 25
Correlation factor:
A 1 B 0
On-board stability period: 90
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 39 of 4139 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: URIC ACID AOX FL - Codes AX F100 / F250 / F600 CH
Preparation: R1 - INSTALL LIQUID READY TO USE REAGENT A
R2 - INSTALL LIQUID READY TO USE REAGENT B
Storage: REFRIGERATE AT 2-8°C
Stability: AS INDICATED IN THE LABEL
TEST NAME: UA
Sample: Volume 10 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 200 ml Dilution 0 ml
R2 volume 50 ml Dilution 0 ml
Wavelenght: Pri. 540 Sec. 700 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.5
Last L - 0.1 First H 0.5
Measuring point 1: First Last 27
Measuring point 2: First Last 10
Linearity: Dynamic range:
No Lag Time: L 0.1 H 35
Correlation factor:
A 1 B 0
On-board stability period: 90
Unit: mg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 40 of 4140 of 4141
Chema Diagnostica - Guidelines for automatic analyzers - Olympus AU 400 - 600 - 640
Analyzer: Olympus AU 400 - 600 - 640
Application: ZINC - Code ZN 0125 CH
Preparation: R1 - MIX REAGENT A + REAGENT B AS INDICATED IN INSERT SHEET
Storage: REFRIGERATE AT 2-8°C
Stability: 2 WEEKS
TEST NAME: ZN
Sample: Volume 15 ml Dilution 0 ml Pre-dilution Rate: 1
Reagents: R1 volume 295 ml Dilution 0 ml
R2 volume 0 ml Dilution 0 ml
Wavelenght: Pri. 570 Sec. 800 Min OD Max OD
Method: END L H
Reaction slope: + Reagent OD limit:
First L - 0.1 First H 0.8
Last L - 0.1 First H 0.8
Measuring point 1: First Last 27
Measuring point 2: First Last
Linearity: Dynamic range:
No Lag Time: L 5 H 1000
Correlation factor:
A 1 B 0
On-board stability period: 10
Unit: microg/dl
IUS.422.0.2 Directions for use Edition 2010-08-01 page 41 of 4141 of 4141
Loading...
