Olympus Accura View Zoom 90 User Manual

INSTRUCTIONS
Read this manual carefu lly before using your camera.
WARNING
Indicates
circumstances under
which mishandling
resulting from ignoring this symbol could result
KEEP THE BATTERIES AWAY
FROM FIRE. NEVER T R Y TO
DISASSEMBLE, RECHARGE, OR SHORT-CIRCUIT BATTERIES.
KEEP THE BATTERY OUT OF
THE REACH OF CHILDREN. IF A CHILD SWALLOWS A
BATTERY, CONTACT A
2
DOCTOR IMMEDIATELY.
NEVER ATTEMPT TO DISASSEMBLE THE CAMERA; IT CONTAINS A HIGH-VOLTAGE CIRCUIT. IF THE INTERNAL PARTS OF THE CAMERA ARE EXPOSED DUE TO DROPPING OR DAMAGE, REMOVE THE BATTERIES IMMEDIATELY TO
PREVENT FURTHER USAGE.
IN CASE OF MALFUNCTION,
CONSULT YOUR NEAREST
OLYMPUS DEALER OR
OLYMPUS SERVICE CENTER.
3
Names of parts ......................... 6
Viewfinder display/LCD panel .... 8
Diopter adjustment ................. 11
Using the strap ........................ 11
Loading the battery................. 12
Checking the battery .............. 14
Proper shutter release ............ 15
Loading the film ...................... 16
Taking pictures ....................... 19
Using the focus lock ............... 25
After shooting.......................... 27
Unloading the film ................... 28
Using the flash modes ............ 29
Selftimer.................................. 38
4
Printing the date and time* ..... 40
Correcting the data* ...............
Replacing the date unit's
battery* ................................... 44
42
Care and storage .................... 46
Troubleshooting ...................... 51
Specifications ......................... 64
Specifications for date unit*.... 70
* QUARTZDATE model only.
5

NAMES OF PARTS

Shutter release button
Power button Autof oc u s windows*
Flash mode button
Selftimer button
Mid-roll rewind button LCD panel Flash*
Zoom buttons Selftimer indicator
Lens* Viewfinder*
* Keep clean. Otherwise you
may get blurred pictures.
Wipe clean with a soft cloth.
6
Battery compartment cover
Date/time indicator"
Diopter adjustment dial Viewfinder
Film window
Back cover release
Strap eyelet
Tripod socket
Date/time MODE /SELECT/
SET
buttons"
Back cove r
** QUARTZDATE model only.
7
VIEW/FINDER DISPLAY/
LCD PANEL
Viewfinder Display
Flash indicator (orange) Lights: Flash is ready. Blinks: Flash is recharging.
• Lights when the shutter
release button is pr essed
halfway.
Autofocus mark (red)
If this starts blinking after the shutter release button is pressed halfway, it means that
the subject is out of focus.
Close-up correction mark (orange)
The area inside this mark
(which lights) when the shutter release button is pressed halfway is the picture area.
8
Shutter release indicator (green) Lights when the camera starts releasing the shutter. Goes out
when the camera finishes
releasing the shutter.
When the camera is turned on, only the autofocus mark (red) will light. When the camera is turned off, all the indicators will
go
out.
9
LCD Panel
Selftimer
Battery check Exposure counter
Night Sce n e Flash mode Red-Eye Reducing Flash mode Off (Flash Override) mode Fill-In Flash mode
Notes:
• If you don't use the camera, the
LCD goes off after four and half minutes.
• The LCD panel does not
actually display all indications
simultaneously as shown.
10

DIOPTER ADJUSTMENT

Press the power button to
turn on the camera. Then
turn the diopter adjustment dial until the autofocus mark
is clear.
Turn to the right if you are
farsighted. Turn to the left if you are nearsighted.

USING THE STR AP

Attach the strap as shown.
11

LOADING THE BATTERY

1. Press the power button to turn off the camera. Push
OPEN to open the
battery compartment
cover
2. Insert the new battery
correctly. (One 3V lithium battery. CR123A or
DL123A)
Notes:
• Dispose of used batteries in the battery recycling boxes at stores selling batteries.
• If lithium batteries are not fully
discharged, protect against
short-circuit (e.g. by taping the
contacts) before disposing.
12
Notes:
• About 15 rolls of 24-exposure film can be used with one new
battery. (Flash use 50%)
• Keep a spare battery on hand when going on a l ong trip or to
a cold area.
• Sweat, oil, and so on can
prevent a battery's terminals from making electrical contact. To avoid this, wipe both
terminals before loading the battery.
13

CHECKING THE BATTERY

Press the power button to
turn on the camera.
Display: lights Meaning: Battery is OK. You can
shoot. Display: blinks and other
indicators are displayed
normally. Meaning: Battery power is low and battery should be replaced.
Display: blinks and other indicators go out. Meaning: Battery is dead and should be replaced immediately.
14

PROPER SHUTTER RELEASE

Practice before loading the
film.
1. Depress the shutter release
button halfway to lock the focus.
• The shutter won't release when the autofocus and/or flash mark inside the viewfinder is blinking.
2. Depress the shu tt er release button fully to release the shutter and take the picture.
Cautions:
• Press the shutter release button
gently.
• Avoid shaking the camera
when pressing the shutter
release button to prevent blurry pictures.
15

LOADING THE FILM

1. Slide the back cover release button upward to open the back cover.
Do not touch t he inside of
the camera, especially the
lens.
2. Insert the film cartridge
until it clicks.
Note: Use of ISO 400 film is
recommended.
16
A. Correct
Make sure the film is lying flat before closing the back cover.
B. Incorrect
Push the film cartridge gently to
position the film correctly. Then press the left side of the back cover and close it securely. If the
film is not lying flat, the film may
not advance to the first frame.
17
3. Pull the film leader so that it is
positioned about 10 mm (0.4 in.) from the tip of the arrow of
[ FILM TIP], and close the
back cover. The fi lm automatically
advances to the first frame. Make sure that the film is
positioned between the
positioning guides (A) before closing the back cover.
4. Press the power button to turn on the camera.
The exposure counter on the
LCD panel reads .
Note: If blinks in the exposure counter, the film is improperly
18
loaded. Reload the film .

TAKING PICTURES

1. Press the power button to
turn on the camera.
The lens protector opens, the
lens extends slightly, and the
autofocus mark in the viewfinder lights.
19
2. Aim the camera at your subject. Use the zoom
buttons for telephoto or wide-angle photography.
Note: Keep your hair, hands, strap etc. away from the
autofocus windows, lens, light
sensor and flash.
20
How to Use the Zoom Buttons
Telephoto: Push the "T" button to
zoom in.
Wide angle: Pus h th e "W " button to zoom out.
21
3. Position the autofocus
mark on your subject.
WARNING: DO NOT LOOK DIRECTLY AT THE SUN THROUGH THE VIEWFINDER.
4. Depress the shutter
release button halfway to
adjust the focus.
Focus has been correctly
adjusted and the autofocus mark lights. Exposure also will
be adjusted automatically.
22
