Olympus 227575 User Manual

DIGITAL CAMERA

STYLUS-7030 /

Instruction Manual

● Thank you for purchasing an Olympus digital camera. Before you start to
use your new camera, please read these instructions carefully to enjoy
optimum performance and a longer service life. Keep this manual in a
safe place for future reference.

● The application software and instruction manual PDF fi le are stored on
the internal memory of the camera.

● We recommend that you take test shots to get accustomed to your
camera before taking important photographs.

● In the interest of continually improving products, Olympus reserves the
right to update or modify information contained in this manual.

● The screen and camera illustrations shown in this manual were produced
during the development stages and may differ from the actual product.

μ

-7030

Contents

1

Step

Checking the contents of the box

Strap

Digital camera

USB cable

Other accessories not shown: Warranty card
Contents may vary depending on purchase location.

2

Step

Preparing the Camera

“Preparing the Camera” (p. 10)

4

Step

How to Use the Camera

“Camera Settings” (p. 3)

Contents

Names of Parts .............................. 6

¾

Preparing the Camera .................10

¾

Shooting, Playback, and

¾

Erasing ......................................... 15

Using Shooting Modes ................22

¾

Using Shooting Functions .......... 27

¾

Menus for Shooting Functions ...31

¾

Lithium Ion Battery

(LI-42B)

AV cable

3

Step

Shooting and Playing Back Images

“Shooting, Playback, and Erasing” (p. 15)

5

Step

Printing

“Direct printing (PictBridge)” (p. 47)
“Print Reservations (DPOF)” (p. 50)

Menus for Playback, Editing, and

¾

Printing Functions ....................... 35

Menus for Other Camera

¾

Settings ........................................ 41

Printing ......................................... 47

¾

Usage Tips ................................... 52

¾

Appendix ...................................... 57

¾

or

USB-AC adapter

(F-2AC)

2

EN

Camera Settings

Using the Direct Buttons

Using the Direct Buttons

Frequently used functions can be accessed using the direct buttons.

Operation guide

The symbols FGHI displayed for image selections
and settings indicate that the wheel controller is to
be used by pressing, not turning, the wheel controller
sections shown below.

YMDTIME

Wheel controller

Shutter button (p. 15, 52)

X

02 26 12 30:..2010

Y/M/DY/M/D

MENU

SETCANCEL

F (up) /

INFO button (changing
information display) (p. 17, 20)

4/304/30

14

M

ORM

ORM

N

N

FILE

100 0004100 0004

’10/02/26 12:30’10/02/26 12:30

OK

SINGLE PRINT

OK

PRINT
MORE

Zoom buttons (p. 17, 19)

q button (switching
between shooting and
playback) (p. 16, 18, 42)

m button (p. 4)

E button (camera guide/
menu guide) (p. 21)

H (left)

I (right)

A button

G (down) /

D button (erase) (p. 19)

Operation guides displayed at the bottom of the screen
indicate that the m button, A button, or zoom
buttons can be used.

1

IMAGE SIZEIMAGE SIZE

2

COMPRESSION

SHADOW ADJUST

AF MODE FACE/iESP

1

ESP/

2

FINE ZOOM OFF

3

DIGITAL ZOOM OFF

MENU

14M14M

NORMAL

AUTO

ESP

SETEXIT

SEL. IMAGE

OK

OK

SET

OK

ERASE/CANCEL

MENU

Operation guide

EN

3

Using the Menu

Using the Menu

Use the menu to change camera settings such as the shooting mode.

Press the m button to display the function menu. The function menu can be used to set frequently
used shooting and playback functions such as shooting mode.

Shooting Playback

PROGRAM AUTOPROGRAM AUTO

Selected option

PP

Shooting

mode

SLIDESHOWSLIDESHOW

PHOTO SURFING

EVENT

0.00.0

WB

AUTOWBAUTO

ISO

ISO

AUTO

AUTO

14

M

44

To select the shooting mode

Use HI to select the shooting mode and
press the A button.

To select the function menu

Use FG to select a menu and use HI to
select a menu option. Press the A button to
set the function menu.

Function

menu

o [SETUP]

menu

In the [SETUP] menu, various camera functions can be set,
including shooting and playback functions not displayed in the
function menu, and other settings such as date, time and screen
display.

Use FG to select a menu and press
the A button.

BEAUTY FIX

EDIT

ERASE

SETUP

1 Select [SETUP] and then press the A

button.

The [SETUP] menu is displayed.

●

1

IMAGE SIZEIMAGE SIZE

2

COMPRESSION

SHADOW ADJUST

AF MODE FACE/iESP

1

ESP/

2

FINE ZOOM OFF

3

DIGITAL ZOOM OFF

2 Press H to select the page tabs. Use FG

to select the desired page tab and press I.

Page tab

1

2

1

2

3

3 Use FG to select the desired submenu 1

1

2

1

2

3

4

EN

--.--.-- --:--X

WORLD TIME

VIDEO OUT

MENU

NTSC

OFFPOWER SAVE

x

SETEXIT

and then press the A button.

--.--.-- --:--X

WORLD TIME x

VIDEO OUT

MENU

NTSC

OFFPOWER SAVEPOWER SAVE OFF

SETEXIT

1

2

WORLD TIME

VIDEO OUT

1

2

3

OK

1

2

WORLD TIME

1

2

3

OK

MENU

MENU

MENU

Submenu 1

--.--.-- --:----.--.-- --:--XX --.--.-- --:----.--.-- --:--XX

Submenu 2

--.--.-- --:--X

POWER SAVE

VIDEO OUTVIDEO OUT
OFFOFF

ON

NORMAL

4 Use FG to select the desired submenu 2

and then press the A button.

Once a setting is selected, the display returns

●

14M14M

AUTO

ESP

x

NTSC

OFFPOWER SAVE

HOME

OFFPOWER SAVEPOWER SAVE OFF

OK

SETEXIT

OK

SETEXIT

OK

SETEXIT

to the previous screen.

There may be additional operations.

“Menu Settings” (p. 31 to 46)

5 Press the m button to complete the

setting.

Some functions cannot be used in some

shooting modes. In such cases, the
following message is displayed after
setting.

1

2

WORLD TIME x

VIDEO OUT

1

2

3

MENU

1

IMAGE SIZEIMAGE SIZE

2

COMPRESSION

SHADOW ADJUST

CONFLICTING SETTINGS

AF MODE iESP

1

ESP/*1 ESP

2

FINE ZOOM OFF

3

DIGITAL ZOOM OFF

MENU

--.--.-- --:--X

NTSC

ON

ONPOWER SAVEPOWER SAVE

14M14M

NORMAL

AUTO

OK

SETEXIT

OK

SETEXIT

Menu Index

Menus for Shooting Functions

PROGRAM AUTOPROGRAM AUTO

14

M

44

1 Shooting mode

P (PROGRAM AUTO) .......p. 15

M

(iAUTO) ....................p. 22

s (SCENE MODE) ......p. 22

P (MAGIC FILTER) .....p. 23

p (PANORAMA) ...............p. 24

Q(BEAUTY) ................p. 26

A (MOVIE) ....................... p. 16

2 Flash ..................................p. 27

3 Macro ................................p. 27

4 Self-timer ........................... p. 28

5 Exposure compensation ....p. 28

1

PP

0.00.0

WB
AUTOWBAUTO

ISO

ISO
AUTO

AUTO

6 White balance .................... p. 28

7 ISO .................................... p. 29

8 Drive .................................. p. 30

9 o (SETUP)

9

2
3
4
5
6
7
8

IMAGE SIZE (Still images)

.......................................p. 31

IMAGE SIZE (Movies) ....... p. 31

COMPRESSION (Still images)

.......................................p. 31

FRAME RATE (Movies) .....p. 31

SHADOW ADJUST ........... p. 32

AF MODE .......................... p. 32

1

IMAGE SIZEIMAGE SIZE

2

COMPRESSION

SHADOW ADJUST

AF MODE FACE/iESP

1

ESP/

2

FINE ZOOM OFF

3

DIGITAL ZOOM OFF

MENU

Menus for Playback, Editing, and Printing Functions

SLIDESHOWSLIDESHOW

PHOTO SURFING

EVENT

COLLECTION

BEAUTY FIX

EDIT

ERASE

SETUP

1 SLIDESHOW .....................p. 35

2 PHOTO SURFING.............p. 35

3 EVENT q ........................p. 36

4 COLLECTION q .............p. 36

5 BEAUTY FIX......................p. 37

1

8

1

2
3
4
5
6
7

6 EDIT .................................. p. 37

7 ERASE .............................. p. 39

8 o (SETUP)

PRINT ORDER ..................p. 39

0 (Protect) .....................p. 39

PRINT ORDER

2

0

y
R

1

2

3

MENU

14M14M

NORMAL

1

R OFF

AUTO

IMAGE STABILIZER

2

REC VIEW ON

ESP

ICON GUIDE

1

2

OK

SETEXIT

3

MENU

OK

SETEXIT

ON

1

IMAGE SIZE VGA

2

FRAME RATE

ON

IS MOVIE MODE

R

1

2

SETEXIT

3

MENU

ESP/n ............................p. 32

FINE ZOOM ......................p. 33

DIGITAL ZOOM .................p. 33

R (Still images) ..................p. 33

R (Movies) .........................p. 33

IMAGE STABILIZER
(Still images)/
IS MOVIE MODE

(Movies) .............................p. 34

REC VIEW .........................p. 34

ICON GUIDE ..................... p. 34

y (Rotate).........................p. 40

R (Add sound to still images)

.......................................p. 40

30fps

OFF

ON

OK

OK

SETEXIT

Menus for Other Camera Settings

SETEXIT

1 r (Settings 1)

OK

2 s (Settings 2)

1
2
3

1

INTERNAL/SD

2

MEMORY FORMAT

DATA REPAIR

COPY

1

RESET

2

3

USB CONNECTION

MENU

AUTO

ENGLISH

PC

INTERNAL/SD ...................p. 41

MEMORY FORMAT/

FORMAT ............................ p. 41

DATA REPAIR ...................p. 41

u COPY .....................p. 41

l (Language) ................p. 41

RESET...............................p. 42

USB CONNECTION ..........p. 42

q POWER ON ................p. 42

SAVE SETTINGS ..............p. 42

PW ON SETUP .................p. 42

SOUND SETTINGS ..........p. 43

FILE NAME .......................p. 43

PIXEL MAPPING ...............p. 44

s (Monitor) ..................... p. 44

3 t (Settings 3)

X (Date/time) ..................p. 44

WORLD TIME....................p. 45

VIDEO OUT .......................p. 45

POWER SAVE...................p. 46

EN

5

Names of Parts

Camera unit

1

2

3

4

5

1 Connector cover ..................... p. 11, 12

2 Multi-connector ...........p. 11, 12, 45, 47

3 Strap eyelet .................................... p. 7

4 Flash ............................................p. 27

5 Battery/card compartment cover

.................................................... p. 10

6

7

8

9

10

6 Self-timer lamp ............................. p. 28

7 Microphone ............................p. 33, 40

8 Lens .............................................p. 57

9 Tripod socket
10 Speaker

6

EN

1

62

3

4

5

1 Shutter button ......................... p. 15, 52

2 n button ........................p. 13, 15

3 Zoom buttons .........................p. 17, 19

4 Monitor ......................... p. 8, 15, 44, 52

5 m button ..............................p. 3, 4

6 Indicator lamp ......................... p. 11, 12

7 q button (switching between shooting

and playback) ...................p. 16, 18, 42

Attaching the camera strap

7

8

9

10

8 A button (OK) ............................... p. 3

9 Wheel controller ............................. p. 3

INFO button (changing information

display) ............................. p. 17, 20

D button (erase) ....................p. 19

10 E button

(camera guide/menu guide) .........p. 21

Pull the strap tight so that it does not come loose.

EN

7

Monitor

Shooting mode display

1 2

22

21

20

14

M

44

19

ORM

N

15161718 14 13 12

1/100 F3.01/100 F3.0

Still image

1 2

PP

AUTOWBAUTO

4
5

0.00.0

6

WB

7

10
11

3
4

AUTOWBAUTO

AUTO

AUTO

5

0.00.0

6

PP

WB

7

ISO

ISO

8
9
11

21

19

00:3400:34

VGA

ONON

14151718 121316

Movie

2324

1 Battery check ......................... p. 12, 53

2 Shooting mode .......................p. 15, 22

3 Flash ............................................p. 27

Flash standby/fl ash charge ..........p. 52

4 Macro/super macro ......................p. 27

5 Self-timer ......................................p. 28

6 Exposure compensation ............... p. 28

7 White balance .............................. p. 28

8 ISO ...............................................p. 29

9 Drive .............................................p. 30

10 Recording with sound (movies)

........... ......................................... p. 33

11 [SETUP] menu ........................... p. 4, 5

12 World time ....................................p. 45

13 Image stabilization (still images)/

Digital image stabilization (movies)

.................................................... p. 34

8

EN

14 Metering .......................................p. 32

15 Shadow Adjustment Technology

.................................................... p. 32

16 Compression (still images) .....p. 31, 60

Frame rate (movies) ...............p. 31, 60

17 Image size ..............................p. 31, 60

18 Number of storable still pictures

(still images) ........................... p. 15, 60

Remaining recording time (movies)

..............................................p. 16, 60

19 Current memory ........................... p. 59

20 Histogram .....................................p. 17

21 AF target mark .............................p. 15

22 Camera shake warning

23 Aperture value ..............................p. 15

24 Shutter speed ...............................p. 15

Playback mode display

6

Standard display

●

1 65432

1010

4/30

4/30

1

Advanced display

●

’10/02/26 12:30’10/02/26 12:30

Still image Movie

17

1 6 8 9 11105432

1010

1/1000 F3.0 2.0

P

4/304/30

ISO

ORM

N

FILE

100 0004

’10/02/26 12:30

7

22
21

20
19

AUTOWBAUTO

18

14

M

1 Battery check ......................... p. 12, 53

2 Print reservation/

number of prints ..................p. 50/p. 49

3 Protect ..........................................p. 39

4 Adding sound ......................... p. 33, 40

5 Current memory ........................... p. 59

6 Frame number/total number of images

(still images) ................................. p. 18

Elapsed time/total recording time

(movies) .......................................p. 18

7 Histogram .....................................p. 17

8 Shutter speed ...............................p. 15

9 Aperture value ..............................p. 15

10 ISO ...............................................p. 29

00:12/00:3400:12/00:34

1/1000 F3.0 2.0

WB

FILE

100 0004

ISO

AUTO

ORM

N

P

’10/02/26 12:30

AUTO

14

12
13
14

M

15
16

17

11 Exposure compensation ............... p. 28

12 White balance ..............................p. 28

13 Compression (still images) ..... p. 31, 60

Frame rate (movies) ............... p. 31, 60

14 Image size .............................. p. 31, 60

15 Drive .............................................p. 30

16 File number

17 Date and time ......................... p. 13, 44

18 Metering .......................................p. 32

19 Shadow Adjustment Technology

................................................... p. 32

20 Flash ............................................p. 27

21 Shooting mode ....................... p. 15, 22

22 Macro ...........................................p. 27

9

EN

Preparing the Camera

Inserting the battery

1

Battery/card compartment coverBattery/card compartment cover

2

Battery lock knobBattery lock knob

3

Insert the battery by putting in the ▼ marked

side fi rst, with the C marks toward the
battery lock knob.
Damage to the battery exterior (scratches,
etc.) may produce heat or an explosion.

Insert the battery while sliding the battery

lock knob in the direction of the arrow.

Slide the battery lock knob in the direction

of the arrow to unlock, and then remove the
battery.

Turn off the camera before opening the

battery/card compartment cover.

When using the camera, be sure to close

the battery/card compartment cover.

Battery charge and camera
setup

Connect the camera to the computer to charge
the battery and setup the camera.

System requirements

Windows XP (SP2 or later)/Windows Vista/
Windows 7

When using another system other
than the above or no computer,
see “Charging the battery with the
included USB-AC adapter” (p. 12).

10

EN

1

Connect the camera to the

computer.

Indicator lamp

Connector
cover

Computer (on
and running)

Multi-connector

USB cable (supplied)

Charging the battery

When the camera is connected to the
computer, the battery in the camera will be
charged.

When charging, the indicator lamp light. When

●

charging is complete, the indicator lamp will turn
off.

If the indicator lamp does not light, the

camera may be incorrectly connected, or
the battery, camera, computer or USB cable
may not be functioning correctly.

Camera setup

Set the camera date and time, time zone
and display language automatically; install
the camera instruction manual and PC
software (ib).

Do not insert SD/SDHC memory cards

before the camera setup.

Do not format the internal memory until the

camera setup is complete. Doing so will
erase the camera instruction manual and
the PC software (ib) data that are stored on
the internal memory.

Check that your computer meets the

following system requirements:
Windows XP (SP2 or later)/
Windows Vista/Windows 7

Refer to the PC software (ib) help guide for

details on how to use the PC software (ib).

2

Select and execute “OLYMPUS

Camera Initialization”, which is
displayed on the computer screen
when the camera is recognized by
the computer.

If nothing is displayed on the camera screen

even after connecting the camera to the
computer, the battery may be exhausted.
Leave the camera connected to the
computer until the battery has charged, then
disconnect and reconnect the camera.

Even if a computer has USB ports, proper

operation is not guaranteed in the following
cases:

Computers with USB ports installed using an

●

expansion card, etc.

●

Computers without a factory-installed OS and
home-built computers

Double-click the icon for the camera drive

(Removable Disk), and then execute
Setup. exe to start the camera setup.

3

Follow the instructions on the

computer screen and setup the
camera.

EN

11

Charging the battery with the
included USB-AC adapter

The included USB-AC adapter (F-2AC)

(hereafter referred as AC adapter) has
been designed to be used for charging
and playback. Make sure that shooting
is not being used while the AC adapter is
connected to the camera.

1

Connector

Connector

AC outlet

AC outlet

2

cover

cover

USB cable (supplied)

USB cable (supplied)

3

3

Multi-connector

Multi-connector

Indicator lamp

Indicator lamp
On: Charging

On: Charging
Off: Charged

Off: Charged

The battery is not fully charged at shipment.

Before use, be sure to charge the battery
until the indicator lamp turns off (up to
3 hours).

If the indicator lamp does not light, the AC

adapter is not connected to the camera
correctly, or the battery, camera, or AC
adapter may be broken.

For details on the battery and the AC

adapter, see “Battery, USB-AC adapter
(included), Charger (sold separately)”
(p. 57).

Battery can be charged by connecting

the camera to the computer. However,
when charging with the system other than
Windows XP (SP2 or later)/Windows Vista/
Windows 7, charging takes much time.

When to charge the batteries

Charge the battery when the error message
shown below appears.

Flashes in red

14

M

44

Monitor top left Error message

When not using a computer

See the next section under “Setting the date,

1

1

time and time zone.”

When using a computer with system
other than Windows XP (SP2 or later)/
Windows Vista/Windows 7

The Instruction Manual PDF fi le can be
saved on a computer with the following
procedure.
Connect the camera to the computer and
copy the instruction manual PDF fi le for
your language in the “Manual” folder in the
internal memory of the camera.

BATTERY EMPTY

12

EN

Setting the date, time and
time zone

The date and time set here are saved to image
fi le names, date prints, and other data.

1

Press the n button to turn on

the camera.

The date and time setting screen is displayed

●

when the date and time are not set.

X

Y M D TIME

-- -- -- --:..

--------

MENU

CANCEL

Date and time setting screen

2

Use FG to select the year for [Y].

Y/M/D

4

As in Steps 2 and 3, use FGHI

and the A button to set [M]
(month), [D] (day), [TIME] (hours
and minutes), and [Y/M/D] (date
order).

For precise setting, press the A button as

the time signal strikes 00 seconds.

To change the date and time, adjust the

setting from the menu. [X] (Date/time)
(p. 44)

5

Use HI to select the [x] time

zone and then press the A button.

Use FG to turn daylight saving time ([SUMMER])

●

on or off.

’10.02.26 12:30

Seoul

Seoul
Tokyo

Tokyo

X

Y M D TIME

-- -- -- --:.

.

20102010

MENU

CANCEL

3

Press I to save the setting for [Y].

X

Y M D TIME

-- -- --:..2010

0000

MENU

CANCEL

Y/M/D

Y/M/D

SUMMER

The menus can be used to change the

selected time zone. [WORLD TIME] (p. 45)

SET

OK

13

EN

Changing the display language

The language for the menu and error messages
displayed on the monitor is adjustable.

1

Display the [SETUP] menu.

“Using the Menu” (p. 4)

2

Use FG to select the r (Settings

1) tab and then press I.

1

INTERNAL/SDINTERNAL/SD AUTOAUTO

2

MEMORY FORMAT
DATA REPAIR

COPY

1

RESET

2

USB CONNECTION

3

MENU

3

Use FG to select [l] and press

ENGLISH

PC

SETEXIT

the A button.

4

Use FGHI to select your

language and press the A button.

5

Press the m button.

Inserting the SD/SDHC
memory card (sold separately)

Always use SD/SDHC memory cards with

this camera. Do not insert other types of
memory card. “Using a SD/SDHC memory
card” (p. 58)

Although the camera can store images in

internal memory, SD/SDHC memory cards
(sold separately) can be also used to store
pictures.

1

Insert the card straight until it clicks into

place.

Do not touch the contact area directly.

Write-protect switchWrite-protect switch

2

OK

“Number of storable pictures (still images)/

Continuous recording length (movies) in the
internal memory and SD/SDHC memory
cards” (p. 60)

To remove the SD/SDHC memory card

12

Press the card in until it clicks and comes

out slightly, then remove the card.

14

EN

Shooting, Playback, and Erasing

Shooting with the optimum
aperture value and shutter
speed (P mode)

In this mode, automatic shooting settings are
activated while also allowing changes to a wide
range of other shooting menu functions, such
as exposure compensation, white balance, etc.
as needed.

1

Press the n button to turn on

the camera.

P mode indicator

AUTOWBAUTO

AUTO

AUTO

14

M

44

Number of storable still pictures (p. 60)

Monitor

(standby mode screen)

If P mode is not displayed, press the m

button to display the function menu screen
and then set the shooting mode to P. “Using
the Menu” (p. 4)

Current shooting mode display

PROGRAM AUTOPROGRAM AUTO

PP

2

Hold the camera and compose the

shot.

Monitor

Horizontal grip

PP

Vertical grip

0.00.0

WB

ISO

ISO

When holding the camera, take care not to

cover the fl ash with your fi ngers, etc.

3

Press the shutter button halfway

down to focus on the subject.

When the camera focuses on the subject, the

●

exposure is locked (shutter speed and aperture
value are displayed), and the AF target mark
changes to green.

●

The camera was unable to focus if the AF target
mark fl ashes red. Try focusing again.

AF target mark

PP

14

M

44

Press the n button again to turn off

the camera.

Press halfway

0.00.0

WB

AUTOWBAUTO

ISO

ISO

AUTO

AUTO

“Focusing” (p. 54)

1/4001/400 F3.0F3.0

Shutter speed Aperture value

EN

15

4

To take the picture, gently press

the shutter button all the way down
while being careful not to shake the
camera.

Press fully

1/4001/400 F3.0F3.0

Image review screen

To view images during shooting

Pressing the q button enables playback of
images. To return to shooting, either press
the q button or press the shutter button
halfway down.

Shooting movies (n mode)

1

Press the m button to display

the function menu screen.

PROGRAM AUTOPROGRAM AUTO

14

M

44

2

Use the HI buttons to set the

shooting mode to A and then
press the A button.

A mode indicator

PP

0.00.0

WB

AUTOWBAUTO

ISO

ISO

AUTO

AUTO

VGA

00:3400:34

3

Press the shutter button halfway

down to focus on the subject, and
gently press the button all the way
down to start recording.

Continuous recording length
(p. 60)

Press halfway

PP

Press fully

0.00.0

WB

AUTOWBAUTO

ISO

ISO

AUTO

AUTO

4

Gently press the shutter button all

the way down to stop recording.

Sound will also be recorded.

During sound recording, only the digital
zoom can be used. To record a movie with
optical zoom, set [R] (movies) (p. 33) to
[OFF].

00:3400:34

RECREC

00:1200:12

Recording time

Lights up red when recording

16

EN

Using the zoom

Pressing the zoom buttons adjusts the shooting
range.

Pressing the wide

(W) button

Zoom bar

14

M

4444

Optical zoom: 7x

Digital zoom: 5x

To take larger images without reducing
image quality

[FINE ZOOM] (p. 33)

To take larger images

[DIGITAL ZOOM] (p. 33)

The zoom bar appearance identifi es the

status of the fi ne zoom/digital zoom.

When using
optical zoom

When using
fi ne zoom

When using
digital zoom

Pressing the telephoto
(T) button

PP

0.00.0

WB

AUTOWBAUTO

ISO

ISO

AUTO

AUTO

14

M

Optical zoom range

Fine zoom

range

Digital zoom

range

Changing the shooting
information display

The display of the screen information can
be changed to best match the situation, for
example, the need for a clear view of the screen
or for making a precise composition by using the
grid display.

1

Press F (INFO).

The displayed shooting information changes in

●

PP

0.00.0

WB

AUTOWBAUTO

ISO

ISO

AUTO

AUTO

the order shown below each time the button is
pressed. “Shooting mode display” (p. 8)

Normal

PP

0.00.0

WB

AUTOWBAUTO

No information

ISO

ISO

AUTO

14M

44

AUTO

Detailed

PP

0.00.0

WB

AUTOWBAUTO

ISO

ISO

AUTO

14M

44

N

ORM

AUTO

Reading a histogram

If the peak fi lls too much of the frame,
the image will appear mostly white.

If the peak fi lls too
much of the frame,
the image will
appear mostly black.

The green section shows
luminance distribution
within the screen’s center.

EN

17

Viewing images

1

Press the q button.

Number of frames/

Total number of images

4/30

4/30

To play back movies

Select a movie, and press the A button.

4/30

4/30

’10/02/26 12:30’10/02/26 12:30

Playback image

2

Turn the wheel controller to select

an image.

It can be performed by pressing HI.

●

Displays
previous


Keep turning the wheel controller to fast

forward or reverse. It can be performed by
holding HI.

The display size of the images can be

changed. “Index view, close-up view, and
event index” (p. 19)

Displays
next image

To play sound recordings

To play sound recorded with an image,
select the image and press the A button. A
! icon appears on images with which sound
has been recorded.

[R] (still images) (p. 33, 40)

MOVIE PLAYMOVIE PLAY

OK

Movie

’10/02/26 12:30’10/02/26 12:30

Operations during movie playback

Elapsed time/

Total recording

time

Pausing and

restarting

playback

Fast forward

Rewind

Adjusting the

volume

Press the A button to pause
playback. During pause, fast
forward or reverse, press the
A button to restart playback.

Press I to fast forward. Press
I again to increase the fast
forward speed.

Press H to rewind. The speed
at which the recording rewinds
increases each time H is
pressed.

Turn the wheel controller
or use FG to adjust the
volume.

00:12/00:3400:12/00:34

During playback

During audio playback

18

EN

Operations while playback is paused

00:14/00:3400:14/00:34

During pause

Cueing

Advancing
and rewinding
one frame at a

time

Resuming

playback

Use F to display the fi rst
frame and press G to display
the last frame.

Turn the wheel controller to
advance or rewind by one
frame at a time. Keep turning
the wheel controller for

*1

continuous advance or rewind.
Press the A button to resume

playback.

To operate with HI

*1

Press I or H to advance or rewind one frame

at a time. Hold I or H pressed for continuous
advance or rewind.

To stop movie playback

Press the m button.

Erasing images during
playback (Single image erase)

1

Display the image you want to erase

and press G (D).

Index view, close-up view, and
event index

Index view enables quick selection of a desired
image. Close-up view (up to 10x magnifi cation)
allows checking of image details. In event

*1

, images are grouped by the shooting

index
dates and representative images for an event
can be displayed.

*1

Pictures with different dates can be grouped into the

same event using the PC software (ib).

1

Press the zoom buttons.

Single-image view Close-up view

4/30

4/30

W

’10/02/26 12:30’10/02/26 12:30

T

WT

Index view

’10/02/26

2

2

44

WT

’10/02/26

24

42

’10/02/26

12:30’10/02/26 12:30

4/304/30

ERASE

ALL ERASE

SEL. IMAGE

ERASE

CANCEL

CANCEL

MENU

2

Press FG to select [ERASE], and

press the A button.

[ALL ERASE] (p. 39) and [SEL. IMAGE]

(p. 39) can be used to erase multiple images
at the same time.

WT

Event index

OK

SETBACK

’10/02/26

EN

19

To select an image in index view

Use FGHI to select an image, and press
the A button to display the selected image
in single-image view.

To scroll an image in close-up view

Use FGHI to move the viewing area.

To select an image in event index

Use HI to select the representative image
and press the A button. The images in the
selected event are played back.

Changing the image
information display

Shooting information settings displayed on the
screen can be changed.

1

Press F (INFO).

The displayed image information changes in

●

the order shown below each time the button is
pressed.

Normal

1010

4/30

4/30

No information

’10/02/26 12:30’10/02/26 12:30

Detailed

1010

4/304/30

1/1000 F3.0 2.0

ISO

P

AUTOWBAUTO

14

M

ORM

N

FILE

100 0004

’10/02/26 12:30

“Reading a histogram” (p. 17)

Playing back panorama
images

Panorama images that were combined together
using [AUTO] or [MANUAL] can be scrolled for
viewing.

“Creating panoramic images (p mode)”

(p. 24)

1

Select a panorama image during

playback.

“Viewing images” (p. 18)

4/30

4/30

OK

REPLAY

2

Press the A button.

To control panorama image playback

Zoom in/Zoom out: Press the A button to

pause playback. Then press the zoom button
to enlarge/shrink the image.
Playback direction: Press FGHI to
pause playback and scroll the image in the
direction of the pressed button.

Pause: Press the A button.
Restart scrolling: Press the A button.
Stop playback: Press the m button.

’10/02/26 12:30’10/02/26 12:30

Current viewing area

20

EN

Using the menu guide

If the E button is pressed while settings are
being adjusted in the playback function or
[SETUP] menus, a description of the selected
option is displayed.

“Using the Menu” (p. 4)

Using the camera guide

Use the camera guide to look up camera
operations.

1

Press the E button in the standby

mode screen or the playback
screen.

IN-CAMERA MANUAL

SearchSearch

Learn about the camera

History

Message

EXIT

Submenu 2 Application

Search

Learn about the
camera

History

Message

2

Use FG to select the desired item.

Follow the on-screen instructions to search the

●

desired contents.

Functions or operating methods
can be searched from a term or
shooting objective.

Information is shown about
recommended functions and basic
operating methods for the camera.

Searches can be performed from
the search history.

Messages from the camera can
be viewed.

IN-CAMERA MANUAL

Search

Learn about the cameraLearn about the camera

History

Message

EXIT

SET

SET

OK

OK

21

EN

Using Shooting Modes

To change the shooting mode

The shooting mode (P, M, s, P,

p, Q, n) can be changed with using
the function menu.
“Using the Menu” (p. 4)

Shooting with automatic
settings (M mode)

The camera will automatically select the optimal
shooting mode for the scene. This is a fully
automatic mode that allows you to take a picture
suited to the scene by simply pressing the
shutter button. In M mode, settings in the
shooting menu can be selected, but the changed
setting is not refl ected in the actual shot.

1

Set the shooting mode to M.

The icon changes depending on the scene
that the camera automatically selects.

14

M

44

ORM

N

In some cases, the camera may not select

the desired shooting mode.

When the camera cannot identify the

optimal mode, P mode will be selected.

Using the best mode for the
shooting scene (s mode)

1

Set the shooting mode to s.

SCENE MODESCENE MODE

14

M

44

2

Press G to go to the submenu.

PORTRAITPORTRAIT

14

M

44

3

Use HI to select the mode and

then press the A button to set.

14

M

44

Icon indicating the scene mode
that is set

0.00.0

WB

AUTOWBAUTO

0.00.0

WB

AUTOWBAUTO

0.00.0

WB

AUTOWBAUTO

22

EN
