CONTROL & TRAY CABLES
DIRECT BURIAL, SHIELDED
-25°C + 90°C DRY 75°C WET-600 VOLTS, UL TYPE TC-ER
UL SUBJECT 1277
OSHA ACCEPTABLE
IEEE-383
DESCRIPTION:
Stranded bare copper conductors,
color coded PVC insulation with overall nylon jacket,
sizes 18 and 16 AWG are rated TFFN,
sizes 14, 12 and 10 AWG are rated VW-1 THHN/THWN,
conductors are twisted with fillers as needed,
polyester binder tape,
stranded tinned copper drain wire,
alum-mylar shield (100% coverage),
black PVC jacket
OLYMPIC
NO.
NUMBER
OF COND.
JACKET
THICKNESS
18 AWG, STRANDED 7 x .0152
†
8200S
8202S
†
8203S
†
8205S
8210S
12
2
3
4
6
.045”
.045”
.045”
.045”
.045”
NOM.
O.D.
.270”
.280”
.298”
.360”
.460”
†
Quad Rated: TC-ER, PLTC, NPLF, FPL
APPLICATIONS:
For use in Class 1, Division 2 hazardous locations;
for installation in trays, wireways, ducts, conduit and
aerially when properly supported by a messenger;
approved for direct burial, wet or dry locations and outdoors
in cable trays where a sunlight and oil resistant rating is required
COLOR CODE:
See Chart 10
OLYMPIC
NO.
NUMBER
OF COND.
JACKET
THICKNESS
NOM.
O.D.
14 AWG, STRANDED 7 x .0242
8400S
†
8402S
†
8403S
8404S
8406S
8410S
12
2
3
4
5
7
.045”
.045”
.045”
.045”
.045”
.060”
.318”
.337”
.364”
.397”
.431”
.610”
16 AWG, STRANDED 7 x .0192
†
8300S
8302S
8303S
8304S
8305S
8306S
8308S
8310S
8321S
8345S
2
3
4
5
6
7
9
12
19
25
.045”
.045”
.045”
.045”
.045”
.045”
.045”
.045”
.060”
.060”
.290”
.306”
.330”
.359”
.370”
.389”
.460”
.510”
.630”
.720”
12 AWG, STRANDED 7 x .0305
8500S
8502S
8503S
8504S
8506S
8508S
8510S
8513S
8521S
2
3
4
5
7
9
12
15
19
10 AWG, STRANDED 7 x .0385
8600S
8602S
8603S
8604S
8606S
8608S
2
3
4
5
7
9
.045”
.045”
.045”
.060”
.060”
.060”
.060”
.060”
.080”
.045”
.045”
.045”
.060”
.060”
.060”
.356”
.377”
.410”
.448”
.488”
.600”
.708”
.750”
.790”
.430”
.450”
.500”
.580”
.640”
.740”
*10AWG Insulation thickness .020”
Passes the VW-1 vertical flame test
