RoHS Compliant
PLENUM CABLE SHIELDED PAIRS
UL CMP, CL2P
NEC 800, 725
COMPUTER AND
P.O.S. CABLE
OVERALL FOIL SHIELDED PAIRS
DESCRIPTION:
Stranded tinned copper conductors,
insulated, twisted pairs, with overall
aluminum mylar shield, stranded
tinned copper drain wire, jacket
COLOR CODE:
Chart 3
OLYMPIC
NO.
3170T
NUMBER
OF PAIRS
3171T
3172T
3173T
†
@
3180T
†
Color code: black & white,
red & green
Bare copper
@
3181T
@
3182T
INDIVIDUALLY FOIL SHIELDED PAIRS
DESCRIPTION:
Stranded tinned copper conductors,
insulated, twisted pairs, individually
aluminum mylar shielded, jacket
†
COLOR CODE: 0+9, 0+2, 0+5, 0+6
**
COLOR CODE: Red/Grn, Blk/Ylw
‡
COLOR CODE: Red/Blk, Grn/Wht
§
COLOR CODE: Chart 3
OLYMPIC
NO.
†
2998T*
†
6400T*
†
6409T*
2976TA
**
‡
2976T
§
2980T
§
2981T
†
3197TL
NUMBER
OF PAIRS
UL CMP
CL3P
CONDUCTOR
AWG
2
3
4
6
2
3
4
22
22
22
22
18
18
18
STRAND
7
7
7
7
7
7
7
NOM.
O.D.
.183”
.175”
.195”
.235”
.260”
.270”
.280”
NOM. CAPACITANCE
pF/ft
28.6
28.6
28.6
28.6
36.0
36.0
36.0
UL CMP*, CL3P
CONDUCTOR
AWG
2
3
4
2
2
3
6
2
24
24
24
22
22
22
22
18
STRAND
7
7
7
1
7
7
7
7
NOM.
O.D.
.243”
.259”
.288”
.172”
.147”
.178”
.250”
.268”
NOM. CAPACITANCE
pF/ft
12.5
12.5
12.5
35.0
30.0
39.7
30.0
38.0
OVERALL FOIL & BRAID SHIELDED PAIRS
DESCRIPTION:
Solid tinned copper conductors,
insulated, twisted pairs,
overall alum. mylar and
T.C. braid shield, jacket
173010_olympic_catalog_2017_v9.indd 51 6/26/17 10:31 AM
OLYMPIC
NO.
6173T
NCR P.O.S. CABLE, COLOR CODE: Red & Blue, Black & Yellow
6196T
IBM P.O.S. CABLE, COLOR CODE: Blue, White with Blue stripe and
Orange, White with Orange stripe
NUMBER
OF PAIRS
21.211” 15.0
21.264” 15.022
CONDUCTOR
AWG
STRAND
22
NOM.
O.D.
NOM. CAPACITANCE
UL CL2P
pF/ft
51
