BRAID - BUS BAR
TINNED COPPER FLAT BRAID, SPECIFICATIONS AA59569F*
OLYMPIC
DESCRIPTION:
A woven braid, composed of
tinned copper strands, which is
rolled flat at time of manufacture
to a specific width depending
upon construction.
APPLICATION:
Flat braid is usually employed
for its current carrying capacity
and its extreme flexibility. It is
generally used as a high current
conductor at low voltages.
Battery grounding is typical of
this application. It is also used
as a bonding strap in vehicles
and aircraft to help eliminate
ignition interference. Because
of its extreme flexibility it can
be used in confined areas or
as electrical connections on
moving parts.
OLYMPIC
DESCRIPTION:
A woven tinned copper braid
which is manufactured
completely round as outlined
in AA59569R. Each
strand of the braid is soft drawn
tinned copper wire. The braid
is self-supporting and maintains
its round configuration. The
percentage of shielding coverage
is 95% or more when placed
over a mandrel of an equivalent
diameter to the inside braid
diameter.
APPLICATIONS:
Maximum shielding against
electrostatic interference for
wires,cables and other
components. Also as a protective
covering against mechanical
abrasion and stresses.
SPECIFICATIONS AA59551S – QQ-W-343
TYPE S – ASTM-B-33
NO.
700
701
* 702
703
* 704
* 705
* 706
707
708
* 709
* 710
711
* 712
* 713
714
715
716
NOM.
FLAT
WIDTH
.025”
1/32”
3/64”
3/32”
1/8”
3/16”
1/4”
3/8”
1/2”
5/8”
3/4”
1”
1-3/8”
1-1/2”
1-3/4”
2”
3”
NOM.
THICK.
.015”
.020”
.020”
.020”
.020”
.020”
.030”
.030”
.030”
.030”
.040”
.045”
.050”
.060”
.080”
.120”
.200”
BRAID CONSTRUCTION
AWG OF
IND.
ENDS
36
36
36
36
36
36
36
36
36
36
36
36
30
30
30
30
30
CAR-
RIERS
8
16
24
16
24
24
24
48
48
48
48
48
48
48
48
48
48
TOTAL
NO. OF
IND. ENDS
8
16
24
48
72
120
168
288
384
384
864
864
336
528
1248
1536
2256
APPROX.
AWG
EQUIV.
27
24
22
19
18
15
14
12
10
10
7
7
5
3
00
000
0000
NOM.
CIRCULAR
MILLS
200
400
600
1200
1800
3000
4200
7200
9600
9600
20800
20800
33700
53064
125424
154368
225000
CURRENT
CARRYING
CAP (Amps)
4.0
6.0
7.0
11.0
16.0
25.0
32.0
46.0
53.0
53.0
85.0
85.0
100.0
150.0
280.0
310.0
390.0
TINNED COPPER TUBULAR BRAID, SPECIFICATIONS AA59569R
NO.
720
721
722
723
724
725
726
727
728
729
730
731
732
733
734
735
NOM. I.D.
WHEN
ROUNDED
1/32
1/16
5/64
7/64
1/8
”
5/32
11/64
13/64
1/4
”
9/32
3/8
”
7/16
1/2
”
9/16
21/32
25/32
BRAID CONSTRUCTION
STRAND
WIRE
SIZE
”
”
”
”
36
36
36
36
36
”
”
”
36
36
34
36
”
30
36
”
30
36
”
”
”
30
30
36
CAR-
RIERS
24
24
24
24
24
24
24
24
24
24
48
24
48
48
48
48
TOTAL
NO. OF
IND. ENDS
24
48
72
96
120
240
168
192
384
120
384
240
528
480
768
864
APPROX.
AWG
EQUIV.
22
19
18
16
15
12
14
11
10
9
10
6
9
3
1
7
NOM.
CIRCULAR
MILLS
600
1200
1800
2400
3000
6000
4200
7630
9600
12060
9600
24120
13200
48240
77180
21600
CURRENT
CARRYING
CAP (Amps)
7.0
11.0
16.0
19.0
25.0
40.0
32.0
46.0
53.0
60.0
53.0
90.0
62.0
145.0
190.0
88.0
TINNED COPPER BUS WIRE
DESCRIPTION:
Pure electrolytic soft drawn, solid,
copper properly annealed and tinned
for quick soldering.
APPLICATIONS:
Winding of coils. Antennas. Point to point
wiring. Bus-bar. Component leads. Ground wire.
OLYMPIC
NO.
749
750
751
752
753
754
COND.
SIZE
32 AWG
30 AWG
28 AWG
26 AWG
24 AWG
22 AWG
NOM. CIRCULAR
MIL AREA
63.21
100.5
159.8
254.1
404.0
642.4
NOM.
O.D.
.008”
.010”
.013”
.016”
.020”
.025”
OLYMPIC
NO.
755
756
757
758
759
COND.
SIZE
20 AWG
18 AWG
16 AWG
14 AWG
12 AWG
NOM. CIRCULAR
MIL AREA
1022.0
1642.0
2583.0
4107.0
6530.0
NOM.
O.D.
.033”
.040”
.051”
.065”
.082”
