ODL Add-on DIY Blinds User Manual [en, es, fr]

Reduced Travel Unit

Easy to add on. No drilling into door.

Las instrucciones en

español comienzan en

la página 6

La traduction française

est sur la page 10

INSTALLATION/MAINTENANCE INSTRUCTIONS

For full view and half view sizes.

ENCLOSED TREATMENT INSTALLATION INSTRUCTIONS

Thank you for your purchase of ODL enclosed treatment. Unpack your

lind/shade assembly and check for damage. Be sure to remove the

b
protective cardboard located on both sides of the treatment. Be sure
you have the right unit size for your window by holding the assembly
up to the door window. It is important to operate the treatment only
while it is upright. Be sure to read the instructions prior to beginning
actual installation.

For assistance with enclosed treatment installation or for additional
product information, call ODL customer service toll free at

1.866.ODL.4YOU (635-4968), or visit our website at www.odl.com.

Top Brackets

Soportes superiores
Supports supérieurs

Lengüeta paraelevary bajar

Tab-Open/Close (blind only)

Lengüeta paraabrir y cerrar

Languettepour ouvrir/fermer

Tab-Raise/Lower

Languettepour

soulever/abaisser

Spacer

Separador

Espaceur

LockClip

Sujetador

Patte verrouillable

Spacer

Separador
Espaceur

Spacer

Separador

Espaceur

LockClip

Sujetador
Patte verrouillable

LockClip

Sujetador

Patte verrouillable

HALFVIEW

VISTA PARCIAL

DEMIVUE

Top Brackets

Soportes superiores
Supports supérieurs

Tab-Raise/Lower

Lengüeta paraelevary bajar
Languettepour
soulever/abaisser

Tab-Open/Close (blind only)

Lengüeta paraabrir y cerrar
Languettepour ouvrir/fermer

Spacer

Separador
Espaceur

LockClip

Sujetador
Patte verrouillable

FULLVIEW

VISTA COMPLETA

FENÊTRE COMPLÈTE

1

DOES IT FIT?

Carefullyliftthetreatmentassembly andplace overthe window.
The frame shouldfit snugly overthe entire windowframe against the
door. Lookfor anythingthatwill preventa flushfitor keepthe treatment
fromfunctioning.Set theassembly down, standingitupright.

DOOR HARDWARE INTERFERENCE

If your door hardware is located close to your door glass frame,
you could encounter interference with the fit of your Enclosed
Treatment Unit. To avoid this interference simply remove the filler
strip located on that side of the Enclosed Treatment frame. This
will allow the escutcheon plate on your door hardware to slip
underneath the Enclosed Treatment frame. If the tabs on the
frame (used to hold the filler strip on the frame) are in the way,
you can simply clip them off with pliers.

If you have a lever door handle and the handle extends over your door glass / door glass frame, the Enclosed
Treatment unit may not fit. This interference issue is common with lever arm handles and window treatments.
In order to make the Enclosed Treatment unit fit you will either have to change your door knob so that it does
not extend over the door glass frame, or purchase a lever door handle extender.

1

ENCLOSED TREATMENT INSTALLATION INSTRUCTIONS

2

LOOSEN SCREWS AND INSERT SPACERS

Loosen frame screws at the top and bottom corners (some snap
frame windows do not have screws). If the screws on your window
have plugs over them and do not easily come out, use a wood screw
and turn it into the plug. Turn the wood screw into the plug until it
comes out. Push spacers in behind the lower corners of the frame,
(approximately 14" up from the bottom for the 36" unit, 11 1/2" up
from the bottom for the 64" unit) until tab is flush with the frame.
Tighten bottom screws.

3

TOP BRACKETS

Slideleft and right top brackets behind the door frame on
each top corner until the wings at the top and outside end
are flush againstthe frame. Tightenthe top screws.

4

CLEAN

Standtreatment upright. Fully raise the treatment.
Cleanthe inside glass of the treatment assemblyand
the window on thedoor.

2

ENCLOSED TREATMENT INSTALLATION INSTRUCTIONS

5

HANG

Carefully lift and securelyhang the top of the treatment assembly
over the top brackets. Angle the lower unit towards you while you
slideit on. Be certain the brackets are in the slots at thetop, inside
edge of the treatment frame. Move side to side to verify the unit is
square and secure.

PUSH
EMPUJAR
POUSSER

6

LOCK CLIPS

Press thebottom corners of the treatment assembly
against the door andswing the lock clips in behind the
window frame. They should snap ineasily and stay in
place.

7

3

SECURE

Checktop, bottom and sides of
treatment frame to be sure it is
flushto door. Be certain alllock
clipsare snug and pushed in fully.

NCLOSED TREATMENT INSTALLATION INSTRUCTIONS

E

OPERATION

OPEN/CLOSE
(blind only)

Slideleft hand tab
up or down to tilt
the treatment.

RAISE/LOWER

Slideright hand tab up
and down to raiseand
lowerthe blind/shade.

MAINTAIN

■

Framecan be washed with soap and water. Glass can be cleaned with a quality window cleaner.

■

Framecan be painted with acrylic latex enamel paint.

■

To remove treatment from door, reverse
installation steps inthis guide.

■

For best performance, shades should not beleft
in raised positionfor extendedperiods of time
and should be excercised - raised and lowered
on a regular basis toprolong fabric life.

PREVENTING CONDENSATION

Interior condensation is caused by excess humidity in your
home. Enclosed Treatments do not cause condensation, but
are a good indicator of humidity levels that are too high.
Keep in mind thatnewhomes release moisture fromconstruction
materials through several heating and cooling sessions.
To the right is a quick guide to appropriate humidity levels:

If your door glass has interior condensation, you should be
able to control it by reducing the humidity level in your home
(for example you could reduce or eliminate humidifiers).
You can also help limit the potential for condensation by removing the filler strips located on the sides of your Enclosed
Treatment frame (see step 1 for removal instructions). By removing these filler strips you will increase the airflow between the
enclosed treatment unit and your door glass.

Condensation does not indicate a defect in an Enclosed Treatment unit and will not damage your Enclosed Treatment unit.

For assistance with enclosed treatment installation or for additional product information, call ODLcustomer service toll free at

1.866.ODL.4YOU (635-4968), or visitour website at www.odl.com

Maximum Recommended Humidity Levels
(based on inside home temperature of 70 F)

Outside Temperature F Inside Humidity
20 F to 40 F Not over 40 %
10 F to 20 F Not over 30 %
0 F to 10 F Not over 25 %

-20 F to 0 F Not over 20 %
Below -20 F Not over 15 %

4
