English
Safety Information
•Before use, be sure to carefully read this manual for safety issues and to ensure that you use this product correctly.
WARNING
In order to avoid any electrical shock, short-circuit, burns, or possibly cause a fire:
•Do not disassemble. This product may only be disassembled by qualified repair technicians. To request repair, see Warranty Page at the back of this manual.
•Do not use if the power cord or plug is damaged, or if the plug is not fully inserted into the outlet.
•Do not scratch, damage, modify, forcibly bend, pull, twist, bind/clamp, or place heavy objects on the power cord.
•Do not insert metal objects, such as pins, wires, or other foreign materials into any gaps of the product.
•Do not allow children to use this product by themselves, and keep product and power cords out of the reach of small children.
•Use only with the designated power supply 110 – 120 V.
CAUTION
When cleaning the product, be sure to unplug the power cord from the outlet.
Do not use in area with high humidity (85% or higher).
Do not use in area where the mist directly contacts furniture, bedding, walls, curtains, ceiling, or other objects.
Do not place on slanted surfaces, high locations such as bookshelves, or on unstable surfaces.
2
English
Do not place the humidifier directly onto a carpet or other object with soft fibers or a thick pile. These could block the vent hole from performing properly and can cause the unit to malfunction or leak.
Do not block the mist outlet.
Fill the reservoir tank using only clean cool tap water.
Do not use hot water. Use of hot water that is 104°F or higher can cause the product to deform and malfunction.
Never put aroma oil or other fragrances into the water reservoir tank as this can damage the humidifier.
Do not wipe product with turpentine/benzene, thinner or other chemicals, since this can ruin the sheen.
When unplugging the power cord, always unplug by grasping the power plug, not by pulling on the power cord. If the supply cord is damaged, it must be replaced by the manufacturer, or its service agent.
Spill out the water when not using the humidifier or when moving the appliance.
Replace the water in the reservoir tank with fresh water every day. Regularly maintaining the inside will ensure that the product is always clean and ready for use.
Be sure that the water passage cover is always reattached before use. Use without attaching the cover could result in water spillage. Do not remove the cover unless cleaning the hybrid humidifier
Do not place cell phones, computers, or other electronic devices near the humidifier. The area around the humidifier can become very humid while the humidifier is operating and these items are sensitive to humidity. Product should be placed at least 6 feet away from these objects.
Take care that the product does not freeze. If the product is placed in a area subject to freezing temperatures, spill out all the water inside.
3
English
Parts and Their Functions
Mist outlet
Mist cone
Mist hole
Water tank
Water tank handle
Use when carrying the water tank as well as inserting a finger into the mist hole, and hold from the inside.
Water passage cover
Humidifier
Power cord
Vent Hole
Power plug
Water passage cover
Heater
* If the water passage cover is not attached correctly, hot water
can overflow from the hybrid humidifier body. Insert the legs at the bottom of the water passage cover (dotted line section) all the way into the grooves of the water passage in the hybrid humidifier body (location shown by the arrows).
4
English
Inside body
*Overflow sensor |
Overflow pool |
**Fan outlet |
Water tub |
Water level sensor
Ultrasonic vibration plate
Water drain direction arrow indicator
Bottom of Water Tank
Water tank cap
Mist hole
Accessories
Remote control
(Works the same as the buttons on the humidifier)
Power button
Mist Setting button
Timer Setting button
5
English
Aroma base
Replacement felt × 2
Lithium button battery for the remote control
Remote control stand
Ceramic disc set
IMM-DISC001
Ceramic disc
Replacement ceramic disc set
Special tool
CAUTION
*Overflow sensor
An overflow occurs when the water level is excessively high. The overflow sensor will be activated and the heater operation will stop. This is to prevent water from overflowing into the electrical part of the unit. If water has collected in the overflow pool, drain it. When the water level in the water passage returns to normal, restart operation.
**Fan outlet
Take care not to get water into the fan outlet or overflow drain when filling with water, draining out water or cleaning.
6
