USER MANUAL
English
Safety Information
•Before use, be sure to carefully read this manual for safety issues and to ensure that you use this product correctly. Be sure to follow information printed in this manual when using this product.
WARNING
In order to avoid any electrical shock, short-circuit, burns, or possibly cause a fire:
•Do not disassemble. This product may only be disassembled by qualified repair technicians. To request repair, see Warranty Page at the back of this manual.
•Do not use if the power cord or plug is damaged, or if the plug is not fully inserted into the outlet.
•Do not scratch, damage, modify, forcibly bend, pull, twist, bind/clamp, or place heavy objects on the power cord.
•Do not insert metal objects, such as pins, wires, or other foreign materials into any gaps of the product.
•Do not allow children to use this product by themselves, and keep product and power cords out of the reach of small children.
•Use only with the designated power supply 110 – 120 V.
CAUTION
When cleaning the product, be sure to unplug the power cord from the outlet.
Do not use in area with high humidity (85% or higher).
Do not use in area where the mist directly contacts furniture, bedding, walls, curtains, ceiling, or other objects.
Do not place on slanted surfaces, high locations such as bookshelves, or on unstable surfaces.
2
English
Do not place the ultrasonic humidifier directly onto a carpet or other object with soft fibers or a thick pile. These could block the vent hole from performing properly and can cause the unit to malfunction or leak.
Do not block the mist outlet.
Fill the reservoir tank using only clean cool tap water.
Do not use hot water. Use of hot water that is 104°F or higher can cause the product to deform and malfunction.
Never put aroma oil or other fragrances into the water reservoir tank as this can damage the ultrasonic humidifier.
Do not wipe product with turpentine/benzene, thinner or other chemicals, since this can ruin the sheen.
When unplugging the power cord, always unplug by grasping the power plug, not by pulling on the power cord. If the supply cord is damaged, it must be replaced by the manufacturer, or its service agent.
Spill out the water when not using the ultrasonic humidifier or when moving the appliance.
Replace the water in the reservoir tank with fresh water every day. Regularly maintaining the inside will ensure that the product is always clean and ready for use.
Use without attaching the cover could result in water spillage. Do not remove the cover unless cleaning the Ultrasonic humidifier.
Do not place cell phones, computers, or other electronic devices near the ultrasonic humidifier. The area around the humidifier can become very humid while the ultrasonic humidifier is operating and these items are sensitive to humidity. Product should be placed at least 6 feet away from these objects.
Take care that the product does not freeze. If the product is placed in a area subject to freezing temperatures, spill out all the water inside.
3
English
Parts and Their Functions
Mist outlet
Mist cone
Mist hole
Water tank handle
Use when carrying the water tank
Water tank
Fan outlet
Power cord
Power plug
Humidifier
Air inlet
4
English
Inside body
Drain water in the direction of arrow indicator
Water tub
*Fan outlet
Overflow drain
Water level sensor
Ultrasonic vibration plate
Bottom of water tank
Water tank cap
Mist hole
*Take care not to get water into the fan outlet or overflow drain when filling with water, draining out water or cleaning.
