Oasis PG8ACEE User Manual

BARRIER-FREE VERSACOOLER® II

Energy and Water Conservation Technology

PG8AC, PGAC

Mechanical Activation

Suggested Specification

Model PG8AC shall be for Green Specified construction,
deliver 8.0 gph of 50° F water at 90° F ambient and 80° F inlet water.
Model PGAC is a non-refrigerated drinking fountain and delivers
ambient water. Models PG8AC and PGAC shall include front and
side push pads to shall be Mechanically Activated. Basin shall be
designed to eliminate splashing and standing water. Water Saver
Bubbler reduce waste water by 50% and shall have a flexible
guard and operate between 20 and 120 psi. Cabinet finish shall
be Sandstone powder coated paint on galvanized steel or brushed
stainless steel. New High Efficient positive start compressor and
cooling system shall use R-134a refrigerant, fully insulated and
controlled by positive sensing thermostat. Shall comply with
ANSI A117.1 and ADA. Shall be listed by Underwriters’
Laboratories to U.S. and Canadian standards. Shall comply with
ANSI/NSF 61.

Finishes

> Standard cabinet finish: Sandstone powder coated
paint on steel
> Optional finishes (at additional cost): Stainless Steel,
Regency Bronze, and optional powder coated finishes

Options (at additional cost)

> Glass Fillers (factory installed)
> Push Handle (029603-004)
> Push Back (029603-005)
> Push Down (029603-006)
> Filtration System 100% Biodegradable
> Stainless Steel Bubbler

Installation

> Prior to roughing, consult with local, state and federal
codes for proper mounting height
> Shipped with complete instructions and wall mounting bracket
> Removable side and front panels provide easy access
for installation

ADA Compliant for both adult or child when
properly installed.

Models

PG8AC delivers 8.0 gallons of chilled drinking water per hour.
PGAC is a non-refrigerated fountain. These models satisfy

CABO/ANSI A117.1. This cooler will comply with ADA
guidelines when properly installed. Models also meet
guidelines for children’s accessibility providing the floor to
orifice height is 30 inches and proper clear floor space is
provided for frontal approach.

Components in this fountain are lead free as defined
by the Safe Drinking Water Act Amendments of 1986,
and the LeadContamination Control Act of 1988.

Limited 5-Year Warranty (Continental limits of the United
States and Canada): Five years on the sealed refrigeration
system and most component parts. Detailed warranty certificate
enclosed with each water cooler; sample available upon request.

Export Warranty: One year on the sealed refrigeration

Standard Features

> Built-in 100 micron strainer stops particles before they enter
the waterway
> Waterways are lead-free in materials & construction
> Stainless Steel top
> Flexible, one-piece Water Saver Bubbler guard
> Heavy Duty galvanized steel frame
> New High Efficiency cooling system
> Refrigerant R-134a

> Product Certified to NSF/ANSI Standard 61,
Annex G (AB1953)

> Four push pad Mechanical activation electricity not required
> External stream height adjustment

50°F Drinking Water

90° F Ambient Air Temperature*

Model

PG8AC** 8.0 8.0 No No 1/4 3.1 286 Yes Yes 59 lbs.

Rated Capacity

GPH

Base Rate

GPH

Pre-Cooler

Hot 'N Cold™

Model

system and most component parts. Four-year replacement
contract on sealed refrigeration system. Detailed warranty
certificate enclosed with each drinking fountain; sample copy
available upon request.

Product Certified to NSF/ANSI Standard 61, Annex G
(weighted average lead content of <=0.25%) and is in
compliance with California's Health & Safety Code Section
116875 (commonly known as AB1953).

Models covered by this specification complies with all known
Plumbing Codes. Listed by
Underwriters’ Laboratories
to U.S. and Canadian
standards.

115 Volts, 60 Hz

Compr.

HP

Full Load

Amps

Rated
Watts

Glass Filler

Acces. Option

Cabinet

Color Finish

Net Wt.
Approx.

PGAC Yes Yes 25 lbs.

* Industry Standard Rating Condition 80°F inlet water temperature
** Special export models available, operable on 220-240 volts, 50/60 Hz

Specifications subject to change without notice

OASIS™ BARRIER-FREE Versacooler® II MODELS

PG8AC, PGAC, PG8ACEE, PGF8AC, PGFAC, PGF8ACEE, PGV8AC

Form 4087 | Rev. 06/09
Oasis International | 222 East Campus View Blvd. | Columbus, OH 43235
For Customer Service and Technical Helpline assistance call: 800.950.3226

www.oasiscoolers.com

OASIS is a trademark of Oasis International

2009 Oasis International
