BARRIER-FREE VERSACOOLER® II
P8ACSLEE
Suggested Specification
Model P8ACSLEE shall deliver 8.0 gph of 50° F degree water
at 90° F ambient and 80° F inlet water. Shall include an
infrared sensor to activate the flow of water. Basin shall be
designed to eliminate splashing and standing water. Bubbler shall
have a flexible guard and operate between 20 and 120 PSI.
Cabinet finish shall be Sandstone powder coated paint on galvanized steel or brushed stainless steel. Cooling system shall use
R-134a refrigerant. Shall comply with ANSI A117.1 and ADA. Shall
be listed by Underwriters’ Laboratories to U.S. and Canadian
standards. Shall comply with ANSI/NSF 61.
Model
P8ACSLEE delivers 8.0 gallons of chilled drinking water per hour.
The infrared sensor produces a light beam that is refelected off the
user to automatically start water flowing. Not even a touch is
needed. If user does not move away within 30 seconds, water
shuts off automatically. Apron is used on the upper unit when
properly installed. Apron is not requried when installed in an alcove
or is a wing wall is installed on the right side for a right high unit or
left side for a left high unit.
Standard Features
> Built-in 100 micron strainer stops particles
before they enter the waterway
> Waterways are Lead-Free In Materials & Construction
> Stainless Steel Top
> Flexible Bubbler Guard
> Heavy Duty Galvanized Steel Frame
> High Efficiency Cooling Tank and Coil
> Refrigerant R-134a
> Infrared Sensor activation
Finishes
> Standard Cabinet Finish: Sandstone powder coated
paint on galvanized steel
> Optional finishes at additional cost: Stainless Steel, Regency
Bronze, and optional powder coated finishes
Options (at additional cost)
□
Stainless Steel, Regency Bronze, and powder coated
finishes
□ Glass Fillers (Factory Installed)
□ Push Handle (029603-004)
□ Push Back (029603-005)
□ Push Down (029603-006)
□ One Piece Chrome Plated Brass Bubbler (036700-001)
Powder Coated Finish Warranty (Continental limits of the
United States and Canada): 3 years on the powder coat
finish provided that the water cooler has not been subjected
to abuse, misuse, or alteration.
Limited 5-Year Warranty (Continental limits of the United
States and Canada): Five years on the sealed refrigeration
system and most component parts. Detailed warranty
certificate enclosed with each water cooler; sample available
upon request.
Export Warranty: One year on component parts. Detailed
warranty certificate enclosed with each drinking fountain;
sample copy available upon request.
Models covered by this specification comply with all known
Plumbing Codes. Listed by Underwriters’ Laboratories to
U.S.and Canadian standards.
ADA Compliant when properly installed
Components in this fountain are lead free as defined by the
Safe Drinking Water Act Amendments of 1986, and the Lead
Contamination Control Act of 1988.
Installation
> Prior to roughing consult with local, state, and federal
codes for proper mounting height.
> Shipped with complete instructions and wall mounting
bracket.
> Universal side access panel and universal drain pipe for right
high or left high installation included
> Removable side and front panels provide easy
access for installation
50° F Drinking Water
90° F Ambient Air Temp*
Model
CAP Fountain Only Yes Yes 25 Lbs.
**Industry Standard Rating Condition 80° F inlet water temperature.
**Special export models available, operable on 220-240 volts, 50/60 Hz.
Rated Capacity
GPH
**CA8P 8.0 8.0 No No 1/4 4.4 500 Yes Yes 69 Lbs.
Base Rate
GPH
Pre-Cooler Hot’N Cold™
Model
Compr.
HP
115 Volts, 60 HZ
Full Load
Amps
Rated
Watts
**Specifications subject to change without notice
Glass Filler
Acc. Option
Cabinet
Color Finish
Oasis International Product
Certified by NSF to
NSF/ANSI Standard 61, G
Net Wt.
Approx.
OASIS® BARRIER-FREE SPLIT-LEVEL Versacooler® II MODELS
PACSL, P8ACSL, PGACSL, PG8ACSL, P8ACSLEE
Form 3973 | Rev. 06/11
