1 DATA ACQUISITION IN WINDOWS VERSION
1.1 The CyberComm DAS Package
The CyberComm Data Acquisition Software (DAS) package is a user-friendly data acquisition package that
provides a convenient way to capture data for future analysis. This CyberComm Pro is only able to run on
Windows
meter and PC is bi-directional as the meter functions can be remotely controlled by the DAS. Data type
stored is in the ASCII format.
Windows is the registered trademark of Microsoft Corporation
1.2 System Requirements
To run the CyberComm Pro DAS software, the following items are required:
1.2.1 Setting the Communication Parameters
The meter is capable of different communication configurations for baud rate, parity and stop bits. The
values chosen for these parameters of the meter must match those chosen for the computer, same goes for
the serial printer if it is connected.
Operating System (refer to 1.2 System Requirements for details). Communication between your
1 IBM Compatible PC Pentium and above
2 Windows Operating Systems 95 and above
3 VGA/SVGA Monitor
4 RS232C Serial Communication Cable
5
Instruction Manual CyberComm pH 1100/ 2100
2 INSTALLATION OF CYBERCOMM DATA ACQUISITION SOFTWARE (DAS)
2.1 Loading of CD-ROM
See Figure 1.
Before running the program, check that the pH 1100/ pH 2100 meter is properly connected to the computer.
It is preferable to connect to either one of the COM (serial) ports available on a computer. Note the number
of the COM port that you have connected to the meter as this will be required in setting up the CyberComm
DAS later.
a) Turn on the computer (PC).
b) Insert the CD-ROM provided into a CD-ROM drive of your PC.
c) To install the DAS, use the My Computer to view the file contents in your CD_ROM drive. Locate and
click onto the SETUP file under the CyberComm directory. Double-click again on this file and the
program automatically starts installation. Alternatively you can use the Add/Remove Programs feature in
Control Panel to install the CyberComm and follow the instruction accordingly. If in doubt, please refer to
your Microsoft Operating Manual for further details.
Figure 1: CyberComm Pro Installation/ Welcome Screen
6
Instruction Manual CyberComm pH 1100/ 2100
2.2 User Name and Organisation Entry
The CyberComm program (as below) prompts you to enter the name of the user and organization.
Figure 2: CyberComm Pro Installation/ User Information
See Figure 2.
Follow the instruction in the subsequent menu for your desired location of this file to be saved. Make relevant
changes until the setup is completed (shown below). Click on the Finish button.
Figure 3: CyberComm Pro Installation/ Setup Complete
See Figure 3.
“Launch the program file” if you wish to use it instantaneously. Note: The file is now stored in your
designated hard-disk location. Create a shortcut of this file later if you wish.
7
Instruction Manual CyberComm pH 1100/ 2100
2.3 Splash Screen
See Figure 4.
Upon clicking the Finish button, a splash screen pops up (shown below). The meter’s communication
protocol setting i.e. baud rate, parity and stop bits must be properly set before you power the meter on. DO
NOT press any key on the meter while the program is running.
Go to the URL stated to download the latest FREE version of the CyberComm Pro software.
Figure 4: Start up Menu
Click OK to go to the following CyberComm Pro Main Menu.
8
Instruction Manual CyberComm pH 1100/ 2100
3 CYBERCOMM PRO MAIN MENU
Figure 5: CyberComm Main Menu
See Figure 5. Select Communications Settings and set the appropriate requirements before connecting the
meter.
3.1 Communication Settings (File)
See Figure 6.
To make changes, use the drop-down menu of each parameter to set to desired values to match the meter’s
settings. After selecting proper communication parameters, select OK button to proceed. Otherwise click
CANCEL if no change is made. To restore to factory default settings, click onto the Restore Defaults.
a) Connect Using
Select preferred connection port from the drop down menu; 1 or 2.
b) Baud Rate
Select preferred baud rate from the drop down menu. 4800, 9600, 19200 and 38400.
c) Parity
Select preferred parity from the drop down menu: None (0), Odd (1) or Even (2).
d) Stop Bits
Select preferred Stop Bits from the drop down menu; 1 or 2.
Figure 6: Communications Settings
9
