UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

Rev. 1.0 — 2 March 2016 User manual

Document information

Info Content Keywords JN5179, ZigBee, module Abstract JN5179-001-M06 module user manual

NXP Semiconductors

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

Revision history

Rev Date Description

1.0 20160212 Initial version

Contact information

For more information, please visit: http://www.nxp.com For sales office addresses, please send an email to: salesaddresses@nxp.com

User manual Rev. 1.0 — 2 March 2016 2 of 21

NXP Semiconductors

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

UM10984

1. General description

The JN5179-001-M06 module provides designers with a ready-made component that provides a fully integrated solution for applications, using the IEEE802.15.4 standard in the 2.4 GHz - 2.5 GHz ISM frequency band, including ZigBee Smart Energy and Home Automation and can be quickly and easily included in product designs. The module integrates all of the RF components required, removing the n eed to perform expensive RF design and test. Products can be designed by simply connecting sensors and switches to the module IO pins. The module uses NXP’s single chip IEEE802.15.4 wireless microcontroller, allowing designers to make use of the extensive chip development support material. Hence, this module allows designers to bring wireless applications to market in the minimum time with significantly reduce d de ve lopm en t effort and co st.

JN5179-001-M06 module includes a 21 dBm power amplifier and a LNA for extended range. It also includes 2 Fl connectors that allow to take benefit of the antenna diversity technique supported by the JN5179.

1.1 FCC and Industry Canada identification

Table 1. FCC and Industry Canada identification

Module name Description FCCID Industry Canada

JN5179-001-M06 21 dBm power, 2 Fl connectors for external antenna XXMJN5179M6 8764A-JN5179M6

1.2 Regulatory approvals

The module has received FCC “Modular Approval”, in compliance with CFR 47 FCC part 15 regulations and in accordance to FCC public notice DA00-1407. The modular approval notice and test report are available on requ est .

The module is compliant to Industry Canada RSS210 (Issue8 Annex8) and has Industry Canada modular approval.

2. Features and benefits

2.1 Benefits

•

Microminiature module solutions

• Ready to use in products

• Minimises product development time

• No RF test required for systems

• Compliant with:

– FCC 47CFR Part 15C – Temperature range: 40 C to +85 C – Lead-free and RoHS compliant

2.2 Features: module

• 2.4 GHz IEEE 802.15.4, ZigBee Smart Energy and Home Automation compatible

User manual Rev. 1.0 — 2 March 2016 3 of 21

NXP Semiconductors

• Integral antenna

• 16 mm  30 mm PCB size

• TX power 21 dBm

• Receiver sensitivity –100 dBm

• TX current 159 mA

• RX current 22 mA

• 2.0 V to 3.6 V battery operation

2.3 Features: microcontroller

•

• JN5179: 512 kB/32 kB/4 kB (Flash/RAM/EEPROM)

• OTA firmware upgrade capability

• 32 MHz clock selectable down to 1 MHz for low-power operation

• Dual PAN ID support

• Fail-safe I

• 8  Timers (6  PWM and 2 timer/counters)

• 2 low-power sleep counters

• 2  UART supporting DALI and DMX512, one with flow control

• SPI-bus master and slave port, 2 simultaneous selects

• Variable instruction width for high coding efficiency

• Multi-stage instruction pipeline

• Data EEPROM with guaranteed 100 k write operations

• ZigBee PRO stack with Smart Home, Smart Lighting and Smart Energy profiles

• Supply voltage monitor with 8 programmable thresholds

• Battery voltage and temperature sensors

• 4-input 10-bit ADC (ADC3 and ADC4 are not available on this module)

• Analog comparator

• Digital monitor for ADC

• Watchdog timer and POR

• Standby power controller

• Up to 16 Digital IO (DIO) and 2 digital outputs pins

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

ARM Cortex-M3 CPU with debug support

C-bus interface. operates as either master or slave

UM10984

3. Applications

• Robust and secure low-power wireless applications

• Thread

• ZigBee 3.0

• Commercial Building and Home Automation

• ZigBee Smart Energy networks

• Smart Lighting and ZigBee Light Link networks

User manual Rev. 1.0 — 2 March 2016 4 of 21

NXP Semiconductors

• Toys and gaming peripherals

• Energy harvesting, for example self-powered light switch

• Remote control

4. Overview

The JN5179-001-M06 is an ultra-low power, high performance surface mount module targeted at IEEE 802.15.4, ZigBee Smart Energy , ZigBee LightLink and Home Automation networking applications, enabling us er s to re aliz e pr od uc ts with minim u m tim e to mark e t and at the lowest cost. It removes the need for expensive and lengthy development of custom RF board designs and test suites. The module uses NXP’s JN5179 wireless microcontroller to provide a comprehensive solution with large memory, high CPU and radio performance and all RF components included. All that is required to develop and manufacture wireless control or sensing products is to connect a power supply and peripherals such as switches, actuators and sensors, considerably simplifying product development.

The module includes a 21 dBm power amplifier, a LNA and 2 Fl connectors for external antenna.

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

5. Marking

JN5179-001-M06

FCC ID:XXMJN5179M6 IC: 8764A-JN5179M6

Fig 1. JN5179-001-M06 package marking (top view)

Table 2. Marking code

Line number Marking code

Line 1 NXP Logo: B&W outline logo Line 2 part ID: JN5179-001-M06 Line 3 FCC ID: XXMJN5179M6 Line 4 IC ID: 8764A-JN5179M6

The JN5179-001-M06 module meets the re quirements of the Chinese RoHS requirements SJ/T11363-2006 which came into force on 1st March 2007.

User manual Rev. 1.0 — 2 March 2016 5 of 21

NXP Semiconductors

6. Block diagram

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

µFl

EXTERNAL

ANTENNA

EXTERNAL

ANTENNA

CONNECTOR

µFl

CONNECTOR

Fig 2. Block diagram

PA/ LNA

MATCHING

XTAL

10 V to 3.6 V

SWITCHED MODE

POWER SUPPLY

2.4 GHz RADIO

INCLUDING DIVERSITY

POWER

MANAGEMENT

WATCHDOG

TIMER

VOLTAGE

BROWNOUT

O-QPSK MODEM

IEEE802.15.4

MAC

ACCELERATOR

128-BIT AES

ENCRYPTION

ACCELERATOR

RAM

ARM Cortex-M3

EEPROM

FLASH

SPI-BUS MASTER

AND SLAVE

C-BUS MASTER

AND SLAVE

6 x PWM

PLUS TIMER

2 x UART

DIO

SLEEP COUNTER

6 CHAN

10 BIT ADC

SUPPLY AND

TEMP SENSORS

User manual Rev. 1.0 — 2 March 2016 6 of 21

NXP Semiconductors

7. Pinning information

7.1 Pinning

DIO2

ADC0

DIO0

DIO1

DIO3

DIO4

DIO10

DIO9

DIO8

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

(2)

(3)

(1)

SPIMISO

SPIMOSI

SPI_CS

Transparent top view

DIO17

SPICLK

DIO11

DD(SMPS)

ADC1

DIO18

DIO15

RESET_N

DIO14

DIO13

DIO12

n.c.

DIO5

(1) SPI_CS = SPISEL0 on the JN5179. (2) DIO0 pin of the module is not connected to DIO0 pin of the JN5179. The DIO0 of the module is

LNA_BYPASS.

(3) DIO1 pin of the module is not connected to DIO1 pin of the JN5179. The DIO1 of the module is

ANT_SEL.

Fig 3. Pin configuration

7.2 Pin description

Table 3. Pin description

Symbol Pin Type

DIO2 1 IO DIO2 (I) pull-up DIO2 — digital input/output 2

ADC0 2 I DIO0 3 I pull-up LNA_BYPASS — receiver byp ass

User manual Rev. 1.0 — 2 March 2016 7 of 21

[1]

Default at reset/ during boot

Default internal pull-up/pull-down

Description

ADC5 — ADC input 5

SDA — I

C-bus master/slave SDA

input/output (push-pull output)

RXD1 — UART 1 receive data input TIM0CAP — Timer0 capture input RFRX — radios receiver control output VAUX_SENSE — auxiliary voltage sense

input

[2]

ADC0 — ADC input 0

NXP Semiconductors

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

Table 3. Pin description

Symbol Pin Type

…continued

[1]

Default at reset/ during boot

Default internal pull-up/pull-down

Description

DIO1 4 I pull-up ANT_SEL — antenna selection DIO3 5 IO DIO3 (I) pull-down DIO3 — digital input/output 3

ADC2 — ADC input 2 PWM4 — PWM4 output

SCL — I

C-bus master/slave SCL

input/output (push-pull output)

TXD1 — UART 1 transmit data output TIM0OUT — Timer0 output RFTX — radio transmit control input FLICK_CTRL — flicker control output

DIO4 6 IO (open-drain) DIO4 (I) pull-up DIO4 — digital input/output 4

SCL — I

C-bus master/slave SCL

input/output (open-drain)

RXD0 — UART 0 receive data input TIM0CK_GT — Timer0 clock/gate input ADO — antenna diversity odd output

DIO10 7 IO JTAG_TDI (I)/

RXD0 (I)

pull-up DIO10 — digital input/output 10

JTAG_TDI — JTAG TDI data input RXD0 — UART 0 receive data input

DIO9 8 IO JTAG_TDO (O)/

TXD0 (O)

pull-up DIO9 — digital input/output 9

JTAG_TDO — JTAG TDO data output TXD0 — UART 0 transmit data output TRACESWV — ARM trace serial wire

viewer output

DIO8 9 IO DIO8 (I) pull-down DIO8 — digital input/output 8

PWM5 — PWM5 output TIM0OUT — Timer0 output TRACECLK — trace clock output 32KXTALIN — 32 kHz clock input

[5]

SPIMOSI

10 IO SPIMOSI (O) pull-down DIO7 — digital input/output 7

SPIMOSI — SPI-bus master data output JTAG_TDI — JTAG TDI data input SPISEL2 — SPI-bus master select output

SPISSEL — SPI-bus slave select input CMP_OUT — comparator output 32KIN — 32 kHz External clock input 32KXTALOUT — 32 kHz clock output

User manual Rev. 1.0 — 2 March 2016 8 of 21

NXP Semiconductors

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

Table 3. Pin description

Symbol Pin Type

SPI_CS

[4]

11 IO SPISEL0 (O) pull-up DIO6 — digital input/output 6

…continued

[1]

Default at reset/ during boot

Default internal pull-up/pull-down

Description

SPISEL0 — SPI-bus master select output

CTS0 — UART 0 clear to send input RXD1 — UART 1 receive data input JTAG_TCK — JTAG TCK input SWCK — Serial Wire Debugger Clock

input

SPISCLK — SPI-bus slave clock input TIM1CAP — Timer1 capture input

[3]

SPIMISO

12 IO SPIMISO (I) pull-up DO1 — digital output 1

SPIMISO — SPI-bus master data input SPISMISO — SPI-bus slave data output ADO — antenna diversity odd output

[2]

SPICLK

13 O SPICLK (O) pull-up DO0 — digital output 0

SPICLK — SPI-bus master clock output ADE — antenna diversity even output

DIO17 14 IO at reset: DIO17 (I);

during boot: SWCK (I)

pull-up DIO17 — digital input/output 17

JTAG_TCK — JTAG TCK input SWCK — Serial Wire Debugger Clock

input SPISEL0 — SPI-bus master select output

TIM1CAP — Timer1 capture input COMP1P — comparator plus input SPISMISO — SPI-bus slave data output

DIO11 15 IO SWD (I) pull-up DIO11 — digital input/output 11

JTAG_TMS — JTAG TMS input SWD — serial wire debugger input RTS0 — UART 0 request to send output TXD1 — UART 1 transmit data output SPICLK — SPI-bus master clock output SPISMOSI — SPI-bus slave data input TIM1OUT — Timer1 output TRACED0 — ARM trace data0 output

DD(SMPS)

16 P; 3.6 V to 10 V V

DD(SMPS)

17 G VSS — ground 18 P VDD — supply voltage

— SMPS input supply voltage

User manual Rev. 1.0 — 2 March 2016 9 of 21

NXP Semiconductors

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

Table 3. Pin description

Symbol Pin Type

DIO5 19 IO (open-drain) DIO5 (I) pull-up DIO5 — digital input/output 5

n.c. 20 - - - not connected DIO12 21 IO DIO12 (I) pull-down DIO12 — digital input/output 12

DIO13 22 IO DIO13 (I) pull-down DIO13 — digital input/output 13

DIO14 23 IO DIO14 (I) pull-down DIO14 — digital input/output 14

RESET_N 24 I pull-up RESET_N — reset input DIO15 25 IO DIO15 (I) pull-down DIO15 — digital input/output 15

…continued

[1]

Default at reset/ during boot

Default internal pull-up/pull-down

Description

SDA — I input/output (open-drain)

TXD0 — UART 0 transmit data output PC1 — pulse counter 1 input TIM0CAP — Timer0 capture input ADE — antenna diversity even output

PWM1 — PWM1 output TXD0 — UART 0 transmit data output TRACED3 — ARM trace data3 output VAUX_OUT — auxiliary voltage control

output

PWM2 — PWM2 output RXD0 — UART 0 receive data input PC0 — pulse counter 0 input TRACED2 — ARM trace data2 output

PWM3 — PWM3 output PC1 — pulse counter 1 input CMP_OUT — comparator output TRACED1 — ARM trace data1 output SPISMOSI — SPI-bus slave data input

PWM6 — PWM6 output JTAG_TDO — JTAG TDO data output SPIMOSI — SPI-bus master data output SPISEL1 — SPI-bus master select output

TIM0CK_GT — Timer0 - clock gate input TRACESWV — ARM trace Serial Wire

Viewer output

SPISSEL — SPI-bus slave select input VAUX_SENSE — auxiliary voltage sense

C-bus master/slave SDA

User manual Rev. 1.0 — 2 March 2016 10 of 21

NXP Semiconductors

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

[2]

…continued

[1]

Default at reset/ during boot

Default internal pull-up/pull-down

Description

JTAG_TMS — JTAG TMS input SWD — Serial Wire Debugger input SPIMISO — SPI-bus master data input TIM1OUT — Timer1 output COMP1M — comparator minus input SPISCLK — SPI-bus slave clock input VREF — analog peripheral reference

voltage ADC1 — ADC input 1

Table 3. Pin description

Symbol Pin Type

DIO18 26 IO DIO18 (I) pull-up DIO18 — digital input/output 18

ADC1 27 I

[1] P = power supply; G = ground; I = input, O = output; IO = input/output. [2] JTAG programming mode: must be left floating high during reset to avoid entering JTAG programming mode. [3] UART programming mode: leave pin floating high during reset to avoid entering UART programming mode or hold it low to program. [4] Specific precautions have to be followed for UART flow control: CTS0 is not usable in the same time with SPISEL0. [5] Specific precautions have to be followed if external 32 kHz crystal is used. See Ref. 3

8. Functional description

8.1 JN5179 single chip wireless microcontroller

The JN5179-001-M06 is constructed around the JN5179-001 single chip wireless microcontroller, which includes the radio system, a ARM Cortex-M3 CPU, Flash, RAM and EEPROM memory and a range of analogue and digital peripherals.

The chip is described fully in JN5179 Wireless Microcontroller Datasheet (see Ref. 2

8.2 Peripherals

Table 4. Peripherals

Peripherals JN5179-001-M06 Notes

Master SPI-bus port 1 250 kHz - 16 MHz Slave SPI-bus port 1 250 kHz - 8 MHz UART 2 16550 compatible Two-wire serial I/F (compatible with SMbus and I PWM 16 MHz clock

timer 6

timer/counter 2 Programmable Sleep Timers 2 32 kHz clock Digital IO lines (multiplexed with UARTs, timers and SPI-bus

selects) Analog-to-Digital converter 4 10-bit

C-bus) 1 Up to 400kHz

16 DIO0 and DIO1 are not available

on JN5179-001-M06 modules

User manual Rev. 1.0 — 2 March 2016 11 of 21

NXP Semiconductors

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

Table 4. Peripherals

…continued

Peripherals JN5179-001-M06 Notes

Programmable analogue comparator 1 ultra low power mode for sleep Internal temperature sensor 1 Internal battery sensor 1

The performance of all peripherals is defined in the JN5179 Wireless Microcontroller Datasheet (see Ref. 2

NXP supplies all the development tools and networking stacks needed to enable end-product development to occur quickly and efficiently. These are all freely available from the NXP Wireless Connectivity (see Ref. 3

). A range of evaluation/developer kits is also available, allowing products to be quickly bread boarded . Efficient deve lop m ent of software applications is enabled by the provision of a complete, unlimited, software developer kit. Together with the available libraries for the IEEE802.15.4 MAC and ZigBee PRO network stacks, this package provides everything required to develop application code and to trial it with hardware representative of the final module.

The module can be user programmed both in development and in production using software supplied by NXP. Access to the on-chip peripherals, MAC and network stack software is provided through specific APIs. This information is available on the NXP support website, together with many example applications, user guides, reference manuals and application notes.

9. Limiting values

Table 5. Limiting values

Symbol Parameter Conditions Min Max Unit

ADCX

IO(dig)

stg

ESD

[1] With x = 0, 1. [2] With x = 2, 3, 4, 5, 8, 9, 10, 11, 12, 13, 14, 15, 17 or 18. [3] Testing for HBM discharge is performed as specified in JEDEC Standard JS-001. [4] Testing for CDM discharge is performed as specified in JEDEC Standard JESD22-C101.

supply voltage 0.3 +3.6 V voltage on pin ADCX digital input/output voltage on pins DIOx storage temperature 40 +150 C electrostatic discharge voltage HBM

[1]

0.3 VDD+ 0.3 V

[2]

0.3 VDD+ 0.3 V

[3]

- 2000 V

[4]

CDM

- 1000 V

10. Recommended operating conditions

Table 6. Operating conditions

Symbol Parameter Conditions Min Max Unit

amb

[1] To reach the maximum TX power, 2.8 V is the minimum. [2] Supplied with DC-to-DC at 2.8 V if the SMPS is used.

User manual Rev. 1.0 — 2 March 2016 12 of 21

supply voltage ambient temperature standard range 40 +85 C

[1][2]

23.6V

NXP Semiconductors

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

11. Characteristics

11.1 DC current

Table 7. Active processing

VDD=3.3V; T

amb

Symbol Parameter Conditions Min Typ Max Unit

supply current with radio in receive mode - 22 - mA

=25C; unless otherwise specified.

with radio in transmit mode - 159 - mA

Table 8. Sleep mode

=3.3V; T

amb

=25C; unless otherwise specified.

Symbol Parameter Conditions Min Typ Max Unit

DD(IO)

input/output supply current

Table 9. Deep sleep mode

VDD=3.3V; T

amb

=25C; unless otherwise specified.

in sleep mode; with I/O and RC oscillator timer wake-up; T

amb

=25C

-0.60-A

Symbol Parameter Conditions Min Typ Max Unit

[1] Waiting on chip RESET or I/O event.

supply current deep sleep mode; measured at 25 C

[1]

-100-nA

11.2 AC characteristics

11.2.1 Radio transceiver

This module meets all the requirements of the IEEE802.15.4 standard over 2.0 V to 3.6 V and offers the improved RF characteristics shown in Table 10 measured single ended.

Table 10. Antenna port characteristics

Single-ended; Impedance = 50

Symbol Parameter Conditions Min Typ Max Unit

range

ESD

frequency range 2.4 - 2.485 GHz electrostatic discharge

voltage

[1]



; VDD= 2 V to 3.6 V; T

=40C to +125C; unless otherwise specified.

amb

HBM - 2 - kV CDM - 500 - V

. All RF characteristics are

---

[1] With external matching inductors and assuming PCB layout.

Table 11. Radio transceiver characteristics: +25 C

VDD= 3.3 V; unless otherwise specified.

Symbol Parameter Conditions Min Typ Max Unit

Receiver

i(RX)(max)

User manual Rev. 1.0 — 2 March 2016 13 of 21

receiver sensitivity nominal for 1 % PER, as per 802.15.4 - 100 - dBm maximum receiver input

power

1 % PER, measured as sensitivity; supply current at 14.8 mA; high-performance mode

- 1- dBm

NXP Semiconductors

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

Table 11. Radio transceiver characteristics: +25 C

VDD= 3.3 V; unless otherwise specified.

Symbol Parameter Conditions Min Typ Max Unit



RSSI

Transmitter

EVM error vector magnitude at maximum output power - 8 - % EVM

offset

RSSI variation 93 d B m to 21 dBm; available through

UM10984 Integrated Peripherals API

output power PAP = 4 and Att. 2.5 dB ON - 21 - dBm

error vector magnitude offset

at maximum output power - 3 4.5 %

…continued

4- +4dB

12. Federal Communication Commission Statement

• This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules see Ref. 4 designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:

– Reorient or relocate the receiving antenna – Increase the separation between the equipment and receiver – Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected

– Consult the dealer or an experienced radio/TV technician for help

• OEM integrators instructions

– The OEM integrators are responsible for ensuring that the e nd-user has no manual

instructions to remove or install module

– The module is limited to installation in mobile or fixed applications, according to

CFR 47 Part 2.1091(b)

– Separate approval is required for all other operating configurations, including

portable configurations with respect to CFR 47 Part 2.1093 and different antenna configurations

• User guide mandatory statements

– User's instructions of the host device must contain the following statements in

addition to operation instructions: * “This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that

may cause undesired operation” * “Changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment”

User manual Rev. 1.0 — 2 March 2016 14 of 21

. These limits are

NXP Semiconductors

• FCC RF Exposure requirements

– User's instructions of the host device must contain the following instructions in

addition to operation instructions: Avoid direct contact to the antenna, or keep it to a 20 cm minimum distance while

using this equipment. This device must not be collocated or operating in conjunction with another antenna or transmitter.

12.1 FCC end product labelling

The final ‘end product’ should be labelled in a visible area with the following: “Contains TX FCC ID: XXMJN5179M6”.

13. Industry Canada statement

Table 12.

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

This device complies with Industry Canada RF radiation exposure limits set forth for general population (uncontrolled exposure). This device must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter.

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) il ne doit pas produire de brouillage, et (2) l’utilisateur du dispositif doit être prêt a accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.

Le présent appareil est conforme aux niveaux limites d’exigences d’exposition RF aux personnes définies par Industrie Canada. Cet appareil doit être installé afin d’offrir une distance de séparation d’au moins 20 cm avec l’utilisateur, et ne doit pas être installé à proximité ou être utilisé en conjonction avec une autre antenne ou un autre émetteur.

To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropic radiated power (e.i.r.p.) is not more than that permitted for successful communication.

These modules have been designed to operate with an te nna s ha ving a maxim um gain of

2.0 dBi. Antennas having a gain greater than 2.0 dBi are strictly prohibited for use with this device. The required antenna impedance is 50 ohms.

As long as the above condition is met, further transmitter testing will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc).

13.1 Industry Canada end product labelling

For Industry Canada purposes the following should be used: “Contains Industry Canada ID IC: 8764A-JN5179M6”

User manual Rev. 1.0 — 2 March 2016 15 of 21

NXP Semiconductors

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

14. Module integration special warnings for US and Canada

UM10984

•

N5179-001-M06 module is considered as component that will be operated

The J in combination with the final equipment. Then, the final equipment (including power supply system) still needs to re-confirm that the whole system complies with intentional and unintentional emission requirements.

• The statement warning of 20cm separation distance and warning of collocation should

appear in the user manuals of end products.

• The end product’s regulatory label should mention:

"Contains FCC ID: XXMJN5179M6 and IC: 8764A-JN5179M6".

15. Footprint information for reflow soldering

16.0

2.54

1.27

Ø 1

1.5

2.54

Dimensions in mm

Fig 4. Module PCB footprint

3.30

aaa-019074

User manual Rev. 1.0 — 2 March 2016 16 of 21

NXP Semiconductors

16. Package outline

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

16 mm

4.0 mm

2.0 mm

30 mm

2.54

hickness: 3.5mm

Fig 5. Package outline JN5179-001-M06

3.30

1.27

2.54

User manual Rev. 1.0 — 2 March 2016 17 of 21

NXP Semiconductors

17. Abbreviations

Table 13. Abbreviations

Acronym Description

API Application Program Interface ADC Analog to Digital Converter ARM Advanced RISC Machine FCC Federal Communication Commission IO Input Output OEM Original Equipment Manufacturer PAP PCB Printed Circui t Boa r d PER Packet Error Rate PWM Pulse Width Modulation R&TTE Radio and Telecommunications Terminal Equipment RF Radio Frequency RISC Reduce Instruction Set Computing RSSI Receive Signal Stren gth Indicator RTS Request-To-Send SPI Serial Peripheral Interface SVM Supply Voltage Monitor SYNTH SYNTHesizer UART Universal Asynchronous Receiver/Transmitter

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

ower Adjustment Programming

UM10984

18. References

[1] IEEE Std 802.15.4-2011 — IEEE Std 802.15.4-2011 IEEE Standard for Information

Technology.

[2] JN517x — JN517x wireless microcontroller datasheet. [3] Wireless Connectivity —

http://www.nxp.com/products/interface-and-connectivity/wireless-connectivity:WIRE LESS-CONNECTIVITY

[4] Part 15 of the FCC Rules —

http://www.ecfr.gov/cgi-bin/text-idx?SID=d01e00935bfcb0d53b914e7c8e63f383&no de=47:1.0.1.1.16&rgn=div5

User manual Rev. 1.0 — 2 March 2016 18 of 21

NXP Semiconductors

19. Legal information

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

19.1 Definitions

Draft — The document is a draft version only. The content is still under

internal review and subject to formal approval, which may result in modifications or additions. NXP Semiconductors does not give any representations or warranties as to the accuracy or completeness of information included herein and shall have no liability for the consequences of use of such information.

19.2 Disclaimers

Limited warranty and liability — Information in this document is believed to

be accurate and reliable. However, NXP Semiconductors does not give any representations or warranties, expressed or implied, as to the accuracy or completeness of such information and shall have no liability for the consequences of use of such information. NXP Semiconductors takes no responsibility for the content in this document if provided by an information source outside of NXP Semiconductors.

In no event shall NXP Semiconductors be lia ble for any indirect, incidental, punitive, special or consequential damages (including - without limitation - lost profits, lost savings, business interruption, costs related to the removal or replacement of any products or rework charges) whether or not such damages are based on tort (including negligence), warranty, breach of contract or any other legal theory.

Notwithstanding any damages that customer might incur for any reason whatsoever, NXP Semi conductors’ aggregat e and cumulative liabil ity towards customer for the products described herein shall be limited in accordance with the Terms and conditions of commercial sale of NXP Semiconductors.

Right to make changes — NXP Semiconductors reserves the right to make changes to information published in this document, including without limitation specifications and product descriptions, at any time and without notice. This document supersedes and replaces all information supplied prior to the publication hereof.

Suitability for use — NXP Semiconductors products are not designed, authorized or warranted to be suitable for use in life support, life-critical or safety-critical systems or equipment, nor in applications where failure or malfunction of an NXP Semiconductors product can reasonably be expected to result in personal injury, death or severe property or environmental damage. NXP Semiconductors and its suppliers accept no liability for inclusion and/or use of NXP Semiconductors products in such equipment or applications and therefore such inclusion and/or use is at the cu stome r’s own risk.

Applications — Applications that are described herein for any of these products are for illustrative purposes only. NXP Semiconductors makes no representation or warranty that such applications will be suitable for the specified use without further testing or modification.

Customers are responsible for the design and operation of their appli cations and products using NXP Semiconductors product s, and NXP Semiconductors accepts no liability for any assistance with applications or customer product

design. It is customer’s sole responsibility to determine whether the NXP Semiconductors product is suitable and fit for the customer’s applications and products planned, as well as for the planned application and use of customer’s third party customer(s). Customers should provide appropriate design and operating safeguards to minimize the risks associated with their applications and products.

NXP Semiconductors does not accept any liability related to any default , damage, costs or problem which is based on any weakness or default in the customer’s applications or products, or the application or use by customer’s third party customer(s). Customer is responsible for doing all necessary testing for the customer’s applications and products using NXP Semiconductors products in order to avoid a default of the applications and the products or of the application or use by customer’s third part y customer(s). NXP does not accept any liability in this respect.

Export control — This document as well as the item(s) described herein may be subject to export control regulations. Export might require a prior authorization from competent authorities.

Evaluation products — This product is provided on an “as is” and “with all faults” basis for evaluation purposes only. NXP Semiconductors, its affiliates and their suppliers expressly disclaim all warranties, whet her express, implied or statutory, including but not limited to the implied warranties of non-infringement, merchantability and fitness for a particular purpose. The entire risk as to the quality, or arising out of the use or performance, of this product remains with customer.

In no event shall NXP Semiconductors, its affiliates or their supplie rs be liable to customer for any special, indirect, consequential, punitive or incidental damages (including without limitation damages for l oss of busi ness, busi ness interruption, loss of use, loss of data or information, and the like) arising out the use of or inability to use the product, whether or not based on tort (including negligence), strict liability, breach of contract, breach of warranty or any other theory , even if advised of the possibility of such damages.

Notwithstanding any damages that customer might incur for any reason whatsoever (including without limitation, all damages referenced above and all direct or general damages), the entire liability of NXP Semiconductors, its affiliates and their suppliers and customer’s exclusive remedy for all of the foregoing shall be limited to actual damages incurred by customer based on reasonable reliance up to the greater of the amount actually paid by customer for the product or five dollars (US$5.00). The foregoin g limitatio ns, exclusions and disclaimers shall apply to the maximum extent permitted by applicable law, even if any remedy fails of its essent ial purpose.

Translations — A non-English (t ranslated) version of a document is for reference only. The English version shall prevail in case of any discrepancy between the translated and English versions.

19.3 Trademarks

Notice: All referenced brands, product names, service names and trademarks are the property of their respective owners.

C-bus — logo is a trademark of NXP Semiconductors N.V.

User manual Rev. 1.0 — 2 March 2016 19 of 21

NXP Semiconductors

20. Tables

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

Tab le 1. FCC and Industry Canada identification. . . . . . .3

Table 2. Marking code . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Table 3. Pin description . . . . . . . . . . . . . . . . . . . . . . . . . .7

Tab le 4. Peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Table 5. Limiting values . . . . . . . . . . . . . . . . . . . . . . . . .12

Table 6. Operating conditions . . . . . . . . . . . . . . . . . . . .12

Table 7. Active processing . . . . . . . . . . . . . . . . . . . . . .13

21. Figures

Fig 1. JN5179-001-M06 package marking (top view) . . .5

Fig 2. Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Fig 3. Pin configuration . . . . . . . . . . . . . . . . . . . . . . . . . .7

Fig 4. Module PCB footprint. . . . . . . . . . . . . . . . . . . . . .16

Fig 5. Package outline JN5179-001-M06 . . . . . . . . . . . 17

Tab le 8. Sleep mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Table 9. Deep sleep mode . . . . . . . . . . . . . . . . . . . . . . 13

Table 10. Antenna port characteristics . . . . . . . . . . . . . . 13

Tab le 11. Radio transceiver characteristics: +25 °C . . . . 14

Table 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Table 13. Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . 18

User manual Rev. 1.0 — 2 March 2016 20 of 21

NXP Semiconductors

22. Contents

1 General description. . . . . . . . . . . . . . . . . . . . . . 3

1.1 FCC and Industry Canada identification. . . . . . 3

1.2 Regulatory approvals . . . . . . . . . . . . . . . . . . . . 3

2 Features and benefits . . . . . . . . . . . . . . . . . . . . 3

2.1 Benefits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2.2 Features: module . . . . . . . . . . . . . . . . . . . . . . . 3

2.3 Features: microcontroller . . . . . . . . . . . . . . . . . 4

3 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

5 Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

6 Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . 6

7 Pinning information. . . . . . . . . . . . . . . . . . . . . . 7

7.1 Pinning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

7.2 Pin description . . . . . . . . . . . . . . . . . . . . . . . . . 7

8 Functional description . . . . . . . . . . . . . . . . . . 11

8.1 JN5179 single chip wireless microcontroller. . 11

8.2 Peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

9 Limiting values. . . . . . . . . . . . . . . . . . . . . . . . . 12

10 Recommended operating conditions. . . . . . . 12

11 Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . 13

11.1 DC current . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

11.2 AC characteristics. . . . . . . . . . . . . . . . . . . . . . 13

11.2.1 Radio transceiver . . . . . . . . . . . . . . . . . . . . . . 13

12 Federal Communication Commission Statement

12.1 FCC end product labelling . . . . . . . . . . . . . . . 15

13 Industry Canada statement. . . . . . . . . . . . . . . 15

13.1 Industry Canada end product labelling. . . . . . 16

14 Module integration special warnings for US and

Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

15 Footprint information for reflow soldering . . 16

16 Package outline . . . . . . . . . . . . . . . . . . . . . . . . 17

17 Abbreviations. . . . . . . . . . . . . . . . . . . . . . . . . . 18

18 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

19 Legal information. . . . . . . . . . . . . . . . . . . . . . . 19

19.1 Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

19.2 Disclaimers . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

19.3 Trademarks. . . . . . . . . . . . . . . . . . . . . . . . . . . 19

20 Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

21 Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

22 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

UM10984

ZigBee PRO and IEEE802.15.4 JN5179-001-M06 module

Please be aware that important notices concerning this document and the product(s) described herein, have been included in section ‘Legal information’.

For more information, please visit: http://www.nxp.com For sales office addresses, please send an email to: salesaddresses@nxp.com

Date of release: 2 March 2016

Document identifier: UM10984

NXP Semiconductors JN5179M6 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1. General description

1.1 FCC and Industry Canada identification

1.2 Regulatory approvals

2. Features and benefits

2.1 Benefits

2.2 Features: module

2.3 Features: microcontroller

3. Applications

4. Overview

5. Marking

6. Block diagram

7. Pinning information

7.1 Pinning

7.2 Pin description

8. Functional description

8.1 JN5179 single chip wireless microcontroller

8.2 Peripherals

9. Limiting values

10. Recommended operating conditions

11. Characteristics

11.1 DC current

11.2 AC characteristics

11.2.1 Radio transceiver

12. Federal Communication Commission Statement

12.1 FCC end product labelling

13. Industry Canada statement

13.1 Industry Canada end product labelling

14. Module integration special warnings for US and Canada

15. Footprint information for reflow soldering

16. Package outline

17. Abbreviations

18. References

19. Legal information

19.1 Definitions

19.2 Disclaimers

19.3 Trademarks

20. Tables

21. Figures

22. Contents
