USB2.0 to ATA/ATAPI Bridge
Designer Reference Manual
HCS12
Microcontrollers
DRM062
Rev. 0
1/2005
freescale.com
USB2.0 to ATA/ATATPI Bridge
Designer Reference Manual
by: Dennis Lui and Derek Lau
Applications Engineering
Microcontroller Division
Hong Kong
To provide the most up-to-date information, the revision of our documents on the World Wide Web will be
the most current. Your printed copy may be an earlier revision. To verify you have the latest information
available, refer to:
http://www.freescale.com
Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc.
This product incorporates SuperFlash® technology licensed from SST.
© Freescale Semiconductor, Inc., 2005. All rights reserved.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 3
Revision History
The following revision history table summarizes changes contained in this document. For your
convenience, the page number designators have been linked to the appropriate location.
Revision History
Date
Jan 2005 0 Initial release N/A
Revision
Level
Description
Page
Number(s)
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
4 Freescale Semiconductor
Table of Contents
Chapter 1
System Overview
1.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2 System Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3 MC9S12UF32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.4 System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 2
Hardware Overview
2.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Hardware Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.3 Voltage Regulation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.4 Background Debug Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.5 USB Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.6 ATA Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Chapter 3
Software Overview
3.1 System Software Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1.1 Main Program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1.2 Timer Interrupt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1.3 USB Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Chapter 4
USB Module
4.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.2 Endpoints Configurations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Chapter 5
IQUEUE Module
5.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2 IQUEUE Request Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Chapter 6
ATA Module
6.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.2 ATA Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.2.1 Write to ATA Device Registers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.2.2 Read from ATA Device Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 5
Table of Contents
Chapter 7
USB Mass Storage Interface Driver
7.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.2 USB Mass Storage Class Bulk-Only Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.2.1 USB Command Block Wrapper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7.2.2 USB Command Status Wrapper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7.2.3 SCSI Command Descriptor Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7.2.4 Example of Command Block Wrapper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.3 Driver Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.3.1 Handling of USB Command Block Wrapper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.3.1.1 Commands Without Data Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.3.1.2 Host Sends out Data to Storage Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.3.1.3 Host Receives Data from Storage Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.3.2 Class Specific Request . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Chapter 8
ATA/ATAPI Driver
8.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8.2 ATA and ATAPI Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8.3 Software Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8.3.1 Commands Without Data Transfer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.3.2 Host Sends out Data to ATA/ATAPI Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.3.3 Host Receives Data from ATA/ATAPI Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.3.4 Individual Software Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Chapter 9
Test and Customization
9.1 Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
9.2 Customization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
9.2.1 Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
9.2.1.1 Self-powered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
9.2.1.2 Bus-powered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
9.2.1.3 Amadeus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
9.2.2 Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
6 Freescale Semiconductor
Chapter 1
System Overview
1.1 Introduction
This manual describes a reference design of a Universal Serial Bus (USB) 2.0 to ATA/ATAPI Bridge
solution by using the MC9S12UF32 microcontroller.
Since the MC9S12UF32 is a highly integrated USB 2.0 high speed device for mass storage applications,
the system consists of the MC9S12UF32 and passive components only. All hardware schematic
diagrams and most firmware source codes are available as reference materials.
1.2 System Features
• USB 2.0 High Speed and Full Speed compliance
• Windows 98 SE, Windows 2000, and Windows XP Compatible
• Supports ATA/ATAPI devices higher than 137G bytes capacity
• Supports PIO mode 0 to 4
• Supports UMDA mode 0 to 4
• Maximum 60M bytes per second burst transfer rate
• In-circuit evaluation and programming
1.3 MC9S12UF32
The MC9S12UF32 microcontroller (hereafter referred as UF32) features an integrated Universal Serial
Bus (USB) 2.0 controller and physical layer transceivers to provide comprehensive USB specification
implementation for both high-speed (480 Mbps) and full-speed (12 Mbps) operations. The high-speed
operation, running at bus speeds of 30 MHz, implements fast large data transfers for applications such
as real-time movies that were impractical at the previous lower-speed operation.
Besides standard USB functionality, the UF32 enables control of external harddisk drives, CD-ROM and
DVD-ROM drives. The UF32 also enables controls of different common Flash memory devices such as
CompactFlash, Secure Digital, MultiMediaCards, SmartMedia, and Memory Stick memory cards.
The availability of up to 75 programmable I/O lines helps to minimize the system costs and enhance
flexibility.
The UF32 is designed to reduce overall system components count and improves performance by
off-loading peripheral overhead functions from the CPU. The on-board Flash enables the peripheral
system to accommodate future software changes. The UF32 can be used in card readers for popular
Flash memory cards, ATA/ATAPI bridges for external hard disks and DVD ROM, USB Flash disks and
digital wallets.
There are 100 pins and 64 pins options for the UF32. The 100 pin device is designed for card reader and
digital wallet applications while the 64 pin device is designed for ATA/ATAPI bridge with SD or USB Flash
disk with SD and MS, and other USB applications that do not require so many I/O pins.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 7
System Overview
MC9S12UF32 features:
• HCS12 CPU core
• 32K bytes Flash, 3.5K bytes RAM, 1.5K bytes Queue-RAM
• Universal Serial Bus 2.0 controller and transceivers
• Integrated Queue controller
• ATA/ATAPI controller
• CompactFlash controller
• Secure Digit and MultiMediaCards controller
• SmartMedia and NAND Flash controller
• Memory Stick controller
• 8-channel, 16-bit timer
• Serial communications interface
1.4 System Overview
To PC System
USB SIE
Standard ATA (IDE) Interface
(Harddisk, CDR, CDRW, DVDR, DVDRW...)
9S12UF32
ATA/ATAPI Device
Figure 1-1. Block Diagram of USB2.0 to ATA/ATAPI Bridge
Since UF32 is a highly integrated USB 2.0 high speed device with embedded ATA controller, the system
consists of the UF32 and passive components only.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
8 Freescale Semiconductor
Chapter 2
Hardware Overview
2.1 Introduction
The system consists of the 64 pin package UF32 and passive components only. The major external
component is an MOSFET used for 5V to 3.3V voltage regulation. There are two reference demo boards
available: one is USB bus powered for 2.5" hard disk use, another is self-powered for 3.5" hard disk and
ATAPI devices use.
Figure 2-1. USB Bus Powered Demo Board
Figure 2-2. Self-Powered Demo Board
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 9
Hardware Overview
2.2 Hardware Functions
3V
5V
VDDR
REF3V
VDD3X
VDD Core
VDDX
3V
VDDA
3V
5V
2.5V
REG
2.5V
CORE
USB
5V / 3.3V
5V
3V
MC9S12UF32
PORTE
PORTM
PORTJ
PORTQ
PORTT
PORTU
PORTS
PORTB
PORTA
Figure 2-3. Hardware Functions
The hardware functions can be divided into the following parts:
• Voltage regulation
• Background debug interface
• USB interface
• ATA interface
BKGD
USB Power
CS0–1, IOWR
DA0–2, IORD, DMACK
RESET
IORDY
DMARQ, INTRQ
D0–D7
D8–D15
BDM
USB
ATA
2.3 Voltage Regulation
The UF32 is designed for a single 5V voltage input. There are three kinds of I/Os:
• Port E of 5V I/Os
• Port J, M, and Q of 5V or 3.3V I/O powered by V
• Port A, B, S, T, and U of 5V or 3.3V I/O powered by VDDX
However, for UF32 to be used in ATA applications VDD3X and VDDX must be with 3.3V, hence, only the
port E is with 5V I/Os while the others are with 3.3V I/Os.
The UF32 has four built-in voltage regulators:
• 3.3V regulator for USB transceiver and PLL use
• 3.3V regulator (with a required external MOSFET) for I/O use
• 2.5V regulator for S12 CPU core use
• 2.5V regulator for USB transceiver use
The UF32 needs 5V power supplied to V
3.3V supply to V
DD3X and VDDX. The USB transceivers and PLL are powered by the internal 3.3V
DDR. The external MOSFET is regulated by the UF32 to provide
regulator and the S12 CPU core is powered by the internal 2.5V regulator.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
DD3X
10 Freescale Semiconductor
Background Debug Interface
2.4 Background Debug Interface
The single-wired background debug pin BKGD is used for software development and programming.
2.5 USB Interface
The UF32 features an integrated Universal Serial Bus (USB) 2.0 controller and physical layer
transceivers. An external 1.5kΩ pullup resistor, 510Ω reference resistor, and four serial resistors are
required for USB connection. The USB power detection is used for self-powered system only.
2.6 ATA Interface
A standard 40 pin ATA connector is used. Only pullup, pulldown and serial termination resistors are
needed to connect the UF32 to the ATA device. The ATA CSEL pin is shorted to ground and the firmware
has fixed the device to be master, therefore the ATA/ATAPI device must be set for the option of either
master or cable select.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 11
Hardware Overview
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
12 Freescale Semiconductor
Chapter 3
Software Overview
3.1 System Software Architecture
Mini-Kernel
for UF32
MCU Resources (Timer, IRQ...)
Memory Device
Interface Module
Application Task
(Protocol Adapter)
USB Mass Storage
SCSI Command Module
USB Protocol Layer
Mass
Storage
Device
Figure 3-1. System Software Architecture
Figure 3-1 shows the system software architecture for the UF32 ATA/ATAPI Bridge. The mini-kernel is
designed for multi-tasks operation. In this application, it mainly handles the USB event tasks and the timer
hook function tasks after system initialization. The initialization subroutines initializes the modules of
timer, voltage regulator, ATA controller, IQUEUE RAM, IQUEUE, and USB controller. The main program
continually checks and serves different event tasks.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 13
Software Overview
MAIN PROGRAM
INITIALIZATION
USB EVENTS
HANDLER
USBMS EVENTS
HANDLER
OTHER APPLICATOIN
EVENTS HANDLERS
TIMER INTERRUPT
CHECK AND SERVE
ANY HOOK FUNCTION
INCREASE GLOBAL TIMER
COUNTER FOR EVERY 1ms
RETURN
USB INTERRUPTS
USB ENDPOINT 0
HANDLER
USBMS BULK IN
HANDLER
USBMS BULK OUT
HANDLER
RETURN
Figure 3-2. Main Software Flow
3.1.1 Main Program
The USB events handler puts the UF32 into suspend when USB bus suspend is detected. The USB Mass
Storage (USBMS) handler calls corresponding routines for different USBMS commands. Other
application events handlers can be added to the main program.
3.1.2 Timer Interrupt
A 1ms timer interrupt is set. It will check if there is any timer hook functions and serve them. There are
two timer hook functions: one is a 10ms hook function to check the USB bus power, another is a 1s hook
function to check the ATA process time out. The 10ms hook function means it will be served for every
10ms which is registered in the initialization routine.
3.1.3 USB Interrupts
There are three kinds of USB interrupts:
• Interrupts for the control Endpoint 0
• Interrupts for the Bulk IN Endpoint
• Interrupts for the Bulk OUT Endpoint
All of the interrupt events are fully handled in the interrupt routines excepts the following interrupts:
• USB suspend
• USB Mass Storage reset
• USB Mass Storage Command Block Wrapper received
The above 3 interrupt routines set some flags to indicate their presence and will then be served in the
main routine.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
14 Freescale Semiconductor
Chapter 4
USB Module
4.1 Introduction
The USB module consists of an integrated Universal Serial Bus (USB) 2.0 controller and physical layer
transceivers to provide comprehensive USB specification implementation for both high-speed (480 Mbps)
and full-speed (12 Mbps) operations.
4.2 Endpoints Configurations
Table 4-1. Endpoints Configurations
Physical
Endpoint
0 0 SETUP CONTROL 64
1
2 1 – 3 IN / OUT BULK / INT 64
3 1 – 3 IN / OUT BULK / INT 64
4 1 – 3 OUT ISO / BULK / INT 64 / 512
5 1 – 3 IN BULK / INT 64 / 512
Logical
Endpoint
0 IN CONTROL 64
0 OUT CONTROL 64
Transfer
Mode
Transfer
Type
Maximum Buffer
Size
Table 4-1 shows the endpoints configurations. The physical Endpoint 0 and Endpoint 1 are mapped to
logical control Endpoint 0. The physical Endpoints 2 to 5 can be mapped to logical Endpoints 1 to 3.
However, only one logical endpoint can be mapped to the logical endpoint 3. The USB host only sees the
logical Endpoints.
The maximum buffer sizes of the Endpoints 4 and 5 are 64 bytes (full-speed) or 512 bytes (high-speed).
IQUEUE RAM is used as the buffers for these two endpoints. The other endpoints are associated with
dedicated 64 bytes of buffers.
In this application, only the control Endpoints and the physical Endpoints 4 and 5 are used.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 15
USB Module
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
16 Freescale Semiconductor
Chapter 5
IQUEUE Module
5.1 Introduction
The Intelligent Queue (IQUEUE) module allows automatic data transfer between the USB module and
IQUEUE RAM, and between IQUEUE RAM and mass storage devices without CPU intervention. The
IQUEUE RAM is configured to address $2000 to $25FF by writing 0x21 to the INITEE register.
S12 CPU
USB IQRAM
USB
ATA/ATAPI
DEVICE
IQUEUE
MODULE
IQRAM ATA
Figure 5-1. IQUEUE Module
IQUEUE RAM
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 17
IQUEUE Module
5.2 IQUEUE Request Mapping
Table 5-1. IQUEUE Request Mapping
Data Flow QCnREQ
PC → USB → QRAM QC1REQ = 0 USB Rx
PC ← USB ← QRAM QC3REQ = 1 USB Tx
QRAM ← ATA QC4REQ = 2 ATA Rx
QRAM → ATA QC2REQ = 3 ATA Tx
Peripheral
Functions
4 CF Rx
5 CF Tx
6 MS Rx
7 MS Tx
8 SD Rx
9 SD Tx
10 SM Rx
11 SM Tx
Direction
There are four IQUEUE channels of QC1 to QC4 which can be configured to transfer data to and from
different peripherals. QC1 has the highest priority while QC4 has the lowest priority. QC1 and QC2, QC3
and QC4 can be configured as two double buffer channels. For the IQUEUE module to transfer data from
one peripheral to another automatically, a single or double buffers channel with passing through mode
must be used. For proper operation, the USB peripheral must use the channel with higher priority.
When writing data to an ATA/ATAPI device, QC1REQ is set to USB receive and QC2REQ is set to ATA
transmit. When reading data from the device, QC3REQ is set to USB transmit and QC4REQ is set to ATA
receive.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
18 Freescale Semiconductor
Chapter 6
ATA Module
6.1 Introduction
The ATA host controller is designed according to the AT Attachment with Packet Interface–5
(ATA/ATAPI–5) specification. It can support PIO mode 0 to 4 and UDMA mode 0 to 4 with maximum burst
transfer rate of 60M bytes per second.
The firmware is written according to the ATA/ATAPI–6 specification, therefore it can support higher than
137G byte capacity.
6.2 ATA Registers
Table 6-1. ATA Registers
Registers Description
Host Configuration Register Configure ATA host controller
Host Status Register Host controller operating status
PIO Timing Registers 1–4
Multi-Word DMA Timing Registers 1–4
UDMA Timing Registers 1–9
ATA Drive Control Register (write)
ATA Drive Alternate Status Register (read)
ATA Drive Data Register
ATA Drive Feature Register
ATA Drive Error Register
ATA Drive Sector Count Register
ATA Drive Sector Number Register
ATA Drive Cylinder Low Register
ATA Drive Cylinder High Register
ATA Drive Device/Head Register
ATA Drive Cylinder High Register
ATA Drive Command and
DMA Mode Register (write)
ATA Drive Status Register (read)
Timing registers for PIO, DMA and UDMA modes.
One Timing unit is 1/60MHz.
(i.e.: 1 in the register represents 16.67ns)
These registers are mapped to external ATA device
registers with the same names based on the ATA5
specifications except the DMA Mode Register which
is for the ATA host controller to operate in DMA
mode or not.
Table 6-1 summarizes the ATA registers. There are two types of registers: (1) controls the ATA controller
and (2) registers mapped to external ATA/ATAPI device. There are special procedures to read and write
to the ATA device registers.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 19
ATA Module
6.2.1 Write to ATA Device Registers
1. Wait if TIP of the Host Status Register = 1
2. ATA device register = data
3. Wait if DRAB = 1
6.2.2 Read from ATA Device Registers
1. Wait if TIP of the Host Status Register = 1
2. Data = ATA device register (dummy read)
3. Wait if DRAB = 1
4. Data = ATA device register
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
20 Freescale Semiconductor
Chapter 7
USB Mass Storage Interface Driver
7.1 Introduction
The driver is implemented according to the specification of the USB Mass Storage Class Bulk-Only
Transport and the specification of the Small Computer Computer Interface 2.
We have chosen the Bulk-Only Transport rather than the Command Bulk Interrupt because the drivers
for the Bulk-Only Transport are embedded in the Windows 2000 and the Windows XP operating systems.
Regarding the endpoints usage, one bulk IN and one bulk OUT endpoints together with the control
endpoints are needed. The subclass of the SCSI Transparent command 0x06 is used since the SCSI
command can support most storage and multimedia devices.
7.2 USB Mass Storage Class Bulk-Only Transport
In Bulk-Only Transport, transport of command, data, and status occurs solely via Bulk endpoints. There
are two class specific requests through the SETUP command:
• Bulk-Only Mass Storage Reset
• Get Max LUN
The Bulk-Only Mass Storage Reset is to reset the mass storage device and its associated interface. The
Get Max LUN is used to get the number of logical units the device supports.
The host shall send out a Command Block Wrapper through an OUT endpoint before sending out data or
requesting the device to return data. The device then responds with the Command Status Wrapper.
Figure 7-1 shows the command data status flow.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 21
USB Mass Storage Interface Driver
READY
HOST SENDS OUT CBW
OUT
DATAx
31 BYTE CBW
HOST SENDS OUT DATA
OUT
DATAx
YES
MORE DATA
TO SEND?
DATA
NO
DEVICE RETURNS DATA
IN
DATAx
DATA
MORE DATA
TO RECEIVE?
NO
YES
DEVICE RETURNS CSW
IN
DATAx 13 BYTE CSW
Figure 7-1. Command Data Status Flow
7.2.1 USB Command Block Wrapper
The host sends each Command Block Wrapper containing a command block to the device via the
Bulk-OUT endpoint. The Command Block is represented by the bits 15 to 30 of the CBW. Our device
supports the sub-class code of 0x06 of the SCSI Transparent Command Set.
bit
byte
0–3
4–7 dCBWTag
8–11 dCBWDataTransferLength (number of bytes of data transfer expected)
12 bmCBWFlags
13 Reserved (0) bCBWLUN (logical device number)
14 Reserved (0) bCBWCBLength (Command Block length)
15–30 bCBWCB (Command Block)
22 Freescale Semiconductor
76543210
LSB (Byte 0)
MSB (Byte 3)
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Table 7-1. Command Block Wrapper
dCBWSignature
(0x55 0x53 0x42 0x43)
USB Mass Storage Class Bulk-Only Transport
7.2.2 USB Command Status Wrapper
The USB Command Status Wrapper (CSW) starts on a packet boundary and ends as a short packet with
exactly 13 bytes transferred. The bCSWStatus indicates the success or failure of the command. The
device shall set this byte to zero if the command is completed successfully, to 1 if failed, and to 2 for phase
error. The host shall perform a Reset Recovery when phase error status is returned in the CSW.
Table 7-2. Command Status Wrapper
76543210
0–3 dCSWSignature (0x55 0x53 0x42 0x53)
4–7 dCSWTag (get from the CBW)
8–11
12 bmCSWStatus
(number of bytes different between expected transfer length and actual handled)
dCSWDataResidule
7.2.3 SCSI Command Descriptor Block
The SCSI Command Descriptor Block (CDB) always has an operation code as the first byte and the
control byte as its last byte. For any command, if there is an invalid parameter in the CDB, the target
should terminate the command without altering the medium.
Table 7-3. CDB of 6-Byte Command
76543210
0 Operation Code
dCBWTag (MSB)
1–3
4
5 Control
Logical Block Address (if required)
(LSB)
Transfer Length (if required)
Parameter List Length (if required)
Allocation Length
Table 7-4. CDB of 10-Byte Command
765432210
0 Operation Code
1 Reserved (0) Service Action (if required)
2–5 (MSB byte 2) Logical Block Address (if required) (LSB byte 5)
6 Reserved (0)
(MSB byte 7) Transfer Length (if required)
7–8
9 Control
Parameter List Length (if required)
Allocation length (if required) (LSB byte 8)
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 23
USB Mass Storage Interface Driver
0 Operation Code
1 Reserved (0) Service Action (if required)
2–5 (MSB byte 2) Logical Block Address (if required) (LSB byte 5)
(MSB byte 6) Transfer Length (if required)
6–9
10 Reserved
11 Control
Table 7-5. CDB of 12-Byte Command
765432210
Parameter List Length (if required)
Allocation length (if required) (LSB byte 9)
Table 7-6. CDB of 16-Byte Command
76543221
0 Operation Code
1 Reserved (0) Service Action (if required)
2–5 (MSB byte 2) Logical Block Address (if required) (LSB byte 5)
6–9 (MSB byte 6) Additional CDB Data (if required) (LSB byte 9)
(MSB byte 10) Transfer Length (if required)
10–13
14 Reserved
15 Control
Parameter List Length (if required)
Allocation length (if required) (LSB byte 13)
0
Table 7-7. CDB of Long LBA 16-Byte Command
765432210
0 Operation Code
1 Reserved (0) Service Action (if required)
2–9 (MSB byte 2) Logical Block Address (if required) (LSB byte 9)
(MSB byte 10) Transfer Length (if required)
10–13
14 Reserved
15 Control
Parameter List Length (if required)
Allocation length (if required) (LSB byte 13)
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
24 Freescale Semiconductor
Driver Structure
7.2.4 Example of Command Block Wrapper
Table 7-8. Example of a CBW containing SCSI Write_10 Command
USB CBW SCSI Command
Bytes Data (HEX) Bytes Data (HEX) Meaning
0–3 55 53 42 43 (Signature) 0 2A Write_10
4–7 A8 1A A4 FF (Tag) 1 00 Not used
8–11 00 10 00 00 (Length)
12 00 (Device Number)
13 00 (Reserved)
14 0A (Command Length)
15–30
2A 00 00 9C 46 37 00 00
00 08 00 00 00 00 00 00
2–5 00 9C 46 37
6–9 00 00 00 08
10–15
00 00 00
00 00 00
Table 7-8 shows a USB CBW issued to the device number 0 (byte 12 of the CBW) with effective SCSI
command length of 10 (byte 14). The expected transfer length is 0x1000, i.e. Byte 11 (MSB) to Byte 8
(LSB).
The “2A” in byte 15 of the CBW means it is a SCSI Write_10 command. The command requests the
device to write 8 blocks of data to the LBA 0x9C4637. In this example one block of data equals 512 bytes.
Therefore, 8 blocks of data equal 4K bytes which matches the expected transfer length of 0x1000 bytes
of data length requested in the CBW.
Logical Block
Address
Number of
blocks to transfer
Not used
7.3 Driver Structure
The driver handles and responds to the commands included in the USB Command Block Wrapper and
the Class Specific Requests.
7.3.1 Handling of USB Command Block Wrapper
Figure 7-2 shows the handling of the USB Command Block Wrapper, which is a detail implementation
including errors handling. There are only three kinds of commands to handles:
• Commands without data transfer
• Host sends out data to storage device
• Host receives data from storage device
After decoding the SCSI command from the CBW, the driver will either:
• handle the command without interfering with the individual storage device driver, or
• translate the command and call individual routines of the storage device driver.
After receiving a 31 byte CBW and all data has been transferred, the UF32 will return a 13 byte CSW to
the host with either a result of pass or fail which depends on the global variable gUSBMSResult. Pass
result only happens if the command is supported and the storage device has successfully executed the
command.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 25
USB Mass Storage Interface Driver
HOST SENDS OUT CBW
OUT
DATAx 31 BYTE CBW
SCSI COMMAND
HANDLING
HOST TO SEND DATA
TO DEVICE
COMMAND
SUPPORTED?
HOST SENDS OUT DATA
OUT
DATAx
ERROR
FOUND?
NO
DEVICE RECEIVES
ALL DATA?
COMMAND
SUCCESS?
YES
DATA
NO
YES
YES
NO
YES
NO
gUSBCSWResult
DEVICE RECEIVES
ALL DATA?
NO
STALL
IN
OUT
STALL
ENDPOINT
= Failed
NO DATA TRANSFER
IS EXPECTED
COMMAND
SUPPORTED?
YES
COMMAND
SUCCESS?
YES
YES
DEVICE RETURNS CSW
IN
DATAx
gUSBCSWResult
13 BYTE CSW
NO
NO
= Failed
gUSBCSWResult
= Failed
HOST TO RECEIVE
DATA FROM DEVICE
COMMAND
SUPPORTED?
ERROR FOUND?
DEVICE RETURNS DATA
IN
IN
DATAx DATA
NO
HOST RECEIVES
ALL DATA?
NO
COMMAND
SUCCESS?
YES
NO
YES
YES
NO
YES
YES
gUSBCSWResult
= Failed
HOST RECEIVES
ALL DATA?
NO
RETURNS ZERO
LENGTH DATA
IN
DATAx DATA
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
26 Freescale Semiconductor
Figure 7-2. CSW Command Handling
Driver Structure
7.3.1.1 Commands Without Data Transfer
Since no data transfer is required. After processing the CBW, the UF32 will return the 13 bytes of CBW.
7.3.1.2 Host Sends out Data to Storage Device
After sending out a 31 byte CBW, the host continues to send data to the UF32. If error happens and the
UF32 has not acknowledge (ACK) all the data from the host, the OUT endpoint is STALLED to inform the
host that the UF32 is not able to accept further data. After the UF32 receives all the data from host and
sends all the data to the storage, it will check whether the device has successfully received the data
without any error.
7.3.1.3 Host Receives Data from Storage Device
After sending out a 31 byte CBW, the host expects the storage device to send out data. If error happens
and the host has not acknowledge (ACK) all the data from the device, a zero length data will be sent out
for next IN token to inform the host that there is no more data to transfer.
7.3.2 Class Specific Request
There are two class specific requests through the SETUP command, the Bulk-Only Mass Storage Reset
and the Get Max LUN.
The driver responds to the Get Max LUN command by returning one byte of maximum LUN with value
from 0 to 15 representing logical unit number 1 to 16.
After receiving the Bulk-Only Mass Storage Reset, the driver calls the reset routines of the registered
storage devices one by one.
The driver returns STALL to other reserved class specific requests.
HOST SENDS OUT
CLASS SPECIFIC REQUESTS
SETUP
GET MAX LUN
(bRequest = 0xFE)
DEVICE RETURNS LUN
IN
DATAx
1 BYTE LUN
DATA0
8 BYTE CBW
BULK-ONLY MASS
STORAGE RESET
(bRequest = 0xFF)
RESET DEVICES
OTHERS
(bRequest = 0x00 to 0xFD)
STALL
IN
STALL
Figure 7-3. Software Flow of Class Specific Request
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 27
RETURN
USB Mass Storage Interface Driver
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
28 Freescale Semiconductor
Chapter 8
ATA/ATAPI Driver
8.1 Introduction
The driver is implemented according to the specification of the AT Attachment with Packet Interface-6
(ATA/ATAPI-6).
8.2 ATA and ATAPI Devices
ATA devices are those that do not implement the Packet command feature set, while ATAPI devices are
those that implement it. ATA devices include hard disks and CompactFlash running at IDE mode. ATAPI
devices include CD-ROMs and DVD-ROMs, etc. The ATAPI device is identified by checking the Cylinder
Mid register equals 0x14 and Cylinder High register equals 0x1b after reset.
Commands may be delivered in two forms. For ATA devices, command and command parameters are
delivered by writing the device Command Block registers. Such commands are referred as ATA
commands in this document. ATA Packet command is one of the ATA commands. SCSI commands are
passed to ATAPI device using the ATA Packet command. ATA devices use only the ATA commands.
ATAPI devices use both the ATA Packet command and some of the ATA commands.
8.3 Software Functions
The software functions can be divided into the following categories:
• SCSI equivalent functions — starting with ATA_SCSI
• Function for ATAPI devices only — ATA_PacketCommand
• Functions for ATA devices only
• Functions for both ATA and ATAPI devices
Table 8-1. USB Mass Storage Driver and ATA Driver Interface
Command ATAMS Drivers ATA Drivers
Test Unit Ready (6) ATAMS_SCSIList00 —
Request Sense (6)(10) ATAMS_SCSIList03 gATAErrorCode
Inquiry (6) ATAMS_SCSIList12 ATA_SCSIInquiry
Read Capacity (10) ATAMS_SCSIList25 ATA_SCSIReadCapacity
Read (10)(12) ATAMS_SCSIList28 ATA_LBAATACommand
Write (10)(12) ATAMS_SCSIList2A ATA_LBAATACommand
Verify (10)(12) ATAMS_SCSIList2F —
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 29
ATA/ATAPI Driver
SCSI commands are passed to ATAPI devices by calling the ATA Packet command. Therefore, for ATAPI
devices, the USBMS driver will directly call the ATA_PacketCommad() and passes the SCSI CDB
parameters to the devices.
For ATA devices, the USBMS driver will either:
• handle the command without calling the ATA Driver, or
• call the ATA_SCSI commands, or
• call the ATA_LBAATACommand for read and write commands.
Recall from the last section that there are only three kinds of USB CBW commands.
8.3.1 Commands Without Data Transfer
For ATAPI device, the USBMS Driver will call the ATAMS_ATAPI routine.
For ATA device, there are two commands supported:
• Test Unit Ready
•Verify
For Test Unit Ready Command, the USBMS Driver always returns pass that means the device is always
ready.
The Verify Command is used in Full-Format, the USBMS Driver always returns pass.
8.3.2 Host Sends out Data to ATA/ATAPI Device
For ATAPI device, the USBMS Driver calls the ATAMS_ATAPIWrite routine.
For ATA device, only write command is supported in which host writes data into device. The command is
handled by the ATAMS_SCSIList2A routine setting up the IQUEUE channels and calling the
ATA_LBAATACommand routine.
8.3.3 Host Receives Data from ATA/ATAPI Device
For ATAPI device, the USBMS Driver calls the ATAMS_ATAPIRead routine.
For ATA device, the commands supported are:
• Request Sense (device returns error code of the global variable gATAErrorCode to host)
• Inquiry (device returns ATA information to host by the ATA_SCSIInquiry routine)
• Read Capacity (device returns total capacity to host by the ATA_SCSIReadCapacity routine)
• Read (device returns data to host by the ATA_SCSIList28 routine setting up the IQUEUE channels
and calling the ATA_LBAATACommand routines
8.3.4 Individual Software Function
All functions can be used by both ATA and ATAPI devices except those specified. All functions return the
ATA error code which is defined according to Table 8-2.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
30 Freescale Semiconductor
Table 8-2. ATA Error Code Definitions
Error Code Description
0x00 Command Passed
0x01 Command Failed
0x02 Unrecoverable Error (e.g. timeout)
The following tables show the summary of all the ATA/ATAPI drivers.
ATA_PacketCommand
Description ATA Packet Command for ATAPI devices only
Input
Output nil
Return ATAErrorCode
Description Software reset to ATA/ATAPI devices
Input nil
Output nil
Return ATAErrorCode
muint16 *pCommand
6 or 8 words of ATAPI command
ATA_SoftwareReset
Software Functions
ATA_PIOReadCommand
Description Read ATA or ATAPI device using PIO mode
muint16 *pBuffer
Input
Output data put into buffer
Return ATAErrorCode
Description Write to ATA or ATAPI device using PIO mode
Input
Output data put into device
Return ATAErrorCode
buffer pointer for data to put into
muint16 XferLen
number of words to be read from the device
ATA_PIOWriteCommand
muint16 *pBuffer
buffer pointer for data to put into
muint16 XferLen
number of words to be written to the device
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 31
ATA/ATAPI Driver
ATA_SCSIInquiry
Description
Handle SCSI Inquiry Command by getting the ATA/ATAPI devices
information and put corresponding data into buffer
muint16 *pBuffer
Input
buffer pointer of 24 words for storing temporary data and result
muint16 XferLen
transfer length in byte specified in the SCSI command
Output 32 bytes of SCSI Inquiry result into the buffer
Return ATAErrorCode
ATA_SCSIReadCapacity
Description Handle SCSI Read Capacity Command by returning data into buffer
Input
muint16 *pBuffer
buffer pointer of 4 byte length for data to put into
Output data put into buffer
Return ATAErrorCode
ATA_WaitRegBusy
Description Wait until ATA hardware module is ready
Input nil
Output nil
Return ATAErrorCode
ATA_WaitATABusy
Description Wait until ATA/ATAPI device is ready
Input nil
Output nil
Return ATAErrorCode
ATA_SetPIOTiming
Description Set ATA hardware module timing in PIO mode
Input
muint8 PIOMode
PIO mode 0–4
Output nil
Return ATAErrorCode
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
32 Freescale Semiconductor
ATA_SetUDMATiming
Description Set ATA hardware module Timing in UDMA mode
Input
muint8 UDMAMode
UDMA mode 0–4
Output nil
Return ATAErrorCode
ATA_Init
Description Initialize ATA hardware module and reset the ATA/ATAPI device
Input nil
Output nil
Return ATAErrorCode
ATA_Command
Description Send ATA Command to ATA/ATAPI device
sATACommand *ATACommand
Input
structure point of 7 byte command plus
1 byte indicating read/write with udma mod or not
Output ATA command set to ATA/ATAPI device
Return ATAErrorCode
Software Functions
ATA_LBAATACommand
Description ATA command designed for SCSI parameter passing for ATA device only
muint8 Block
Input
number of Block in 512 bytes
muint8 ATACmd
ATA Command
Output ATA command written to ATA device
Return ATAErrorCode
ATA_Identify Device
Description
Input
Get ATA device information by using the identify device command or
ATAPI device information by using the Identify Packet Device command
muint16 *pBuffer
buffer point with 128 words
Output nil
Return ATAErrorCode
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 33
ATA/ATAPI Driver
ATA_GetSetDeviceInfo
Description Get device information and set global variables
Input
muint16 *pBuffer
buffer pointer with 128 words to store temporary data
gATADevice Info
indicate it’s ATA or ATAPI device
gATAPacketLen
Output
ATAPI packet length is 12 or 16 bytes
gATAUDMAMode
Maximum UDMA mode that device supports
Set ATA/ATAPI device with maximum PIO and UDMA mode
Return ATAErrorCode
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
34 Freescale Semiconductor
Chapter 9
Test and Customization
9.1 Testing
This reference design was tested with different ATA/ATAPI devices and under different Windows
Operating Systems on several different PCs.
• USB compliance test using Command Verifier version 1.21
• Compatibility tests under Windows 98 SE, 2000 and XP
• Compatibility tests under AMD 750, Intel 810 and 865 chip set Desktops, and IBM Thinkpad T23.
9.2 Customization
9.2.1 Hardware
There are some circuits present in the schematic but absent in the printed circuit board. You have to
modify the PCB according to your applications. There are three kinds of supported applications:
• Self-powered
• Bus-powered
• Amadeus
9.2.1.1 Self-powered
Add the USB bus power detection circuitry as shown in the schematic.
9.2.1.2 Bus-powered
Please note that for ATA USB bus-powered application a special USB cable is needed to draw current
from another USB port or from a PS2 port. Since this kind of application violates the USB specification,
operation stability depends on the PC systems and the ATA devices.
9.2.1.3 Amadeus
Add the PE7 pin circuitry as shown in the schematic. Amadeus is a 32-bit Coldfire chip designed for
multimedia applications. The UF32, together with the Amadeus form a USB2.0 multimedia platform. For
a multimedia platform using harddisk, the UF32 operation is controlled by the PE7 pin. A logic high on the
pin puts the UF32 into normal ATA/ATAPI bridge application. A logic low on the pin puts the UF32 into
STOP and the UF32 then releases the ATA bus for Amadeus to access the ATA device. A logic high on
PE7, followed by an external reset or interrupt (negative pulse) is required to wake up the UF32 to enable
it to work again as a normal ATA/ATAPI bridge.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
Freescale Semiconductor 35
Test and Customization
9.2.2 Firmware
There are six targets created in the Codewarrior version 3.1 project:
• Development (100-pin)
• Development (64-pin)
• Self-powered (64-pin)
• Bus-powered (64-pin)
• Amadeus (64-pin)
• Amadeus (100-pin)
The project file is under the “Application” directory. The project supports the self-powered demo board
(64-pin), the USB bus-powered demo board (64-pin), and the M68KIT912UF32 board (100-pin).
A proper project must be chosen according to the application. When using the development project, if you
unplug and replug the USB connector, the system may not work.
You must choose the self-powered, bus-powered or Amadeus target as a reference for your end product.
It works normally when you unplug and re-plug the USB connector.
USB2.0 to ATA/ATAPI Bridge Designer Reference Manual, Rev. 0
36 Freescale Semiconductor
How to Reach Us:
Home Page:
www.freescale.com
E-mail:
support@freescale.com
USA/Europe or Locations Not Listed:
Freescale Semiconductor
Technical Information Center, CH370
1300 N. Alma School Road
Chandler, Arizona 85224
+1-800-521-6274 or +1-480-768-2130
support@freescale.com
Europe, Middle East, and Africa:
Freescale Halbleiter Deutschland GmbH
Technical Information Center
Schatzbogen 7
81829 Muenchen, Germany
+44 1296 380 456 (English)
+46 8 52200080 (English)
+49 89 92103 559 (German)
+33 1 69 35 48 48 (French)
support@freescale.com
Japan:
Freescale Semiconductor Japan Ltd.
Headquarters
ARCO Tower 15F
1-8-1, Shimo-Meguro, Meguro-ku,
Tokyo 153-0064
Japan
0120 191014 or +81 3 5437 9125
support.japan@freescale.com
Asia/Pacific:
Freescale Semiconductor Hong Kong Ltd.
Technical Information Center
2 Dai King Street
Tai Po Industrial Estate
Tai Po, N.T., Hong Kong
+800 2666 8080
support.asia@freescale.com
For Literature Requests Only:
Freescale Semiconductor Literature Distribution Center
P.O. Box 5405
Denver, Colorado 80217
1-800-441-2447 or 303-675-2140
Fax: 303-675-2150
LDCForFreescaleSemiconductor@hibbertgroup.com
Information in this document is provided solely to enable system and software
implementers to use Freescale Semiconductor products. There are no express or
implied copyright licenses granted hereunder to design or fabricate any integrated
circuits or integrated circuits based on the information in this document.
Freescale Semiconductor reserves the right to make changes without further notice to
any products herein. Freescale Semiconductor makes no warranty, representation or
guarantee regarding the suitability of its products for any particular purpose, nor does
Freescale Semiconductor assume any liability arising out of the application or use of any
product or circuit, and specifically disclaims any and all liability, including without
limitation consequential or incidental damages. “Typical” parameters that may be
provided in Freescale Semiconductor data sheets and/or specifications can and do vary
in different applications and actual performance may vary over time. All operating
parameters, including “Typicals”, must be validated for each customer application by
customer’s technical experts. Freescale Semiconductor does not convey any license
under its patent rights nor the rights of others. Freescale Semiconductor products are
not designed, intended, or authorized for use as components in systems intended for
surgical implant into the body, or other applications intended to support or sustain life,
or for any other application in which the failure of the Freescale Semiconductor product
could create a situation where personal injury or death may occur. Should Buyer
purchase or use Freescale Semiconductor products for any such unintended or
unauthorized application, Buyer shall indemnify and hold Freescale Semiconductor and
its officers, employees, subsidiaries, affiliates, and distributors harmless against all
claims, costs, damages, and expenses, and reasonable attorney fees arising out of,
directly or indirectly, any claim of personal injury or death associated with such
unintended or unauthorized use, even if such claim alleges that Freescale
Semiconductor was negligent regarding the design or manufacture of the part.
Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc.
All other product or service names are the property of their respective owners.
© Freescale Semiconductor, Inc. 2005. All rights reserved.
DRM062
Rev. 0, 1/2005
Loading...
