NXP Semiconductors FRDMKW24D512 Users manual

QUICK START GUIDE FOR NXP FREEDOM DEVELOPMENT PLATFORM
FRDM-KW24D512
EXTERNAL USE
Contents
Quick Start Package Overview
Getting Started Out of the Box
Introduction to OpenSDA
Explore Further
1
EXTERNAL USE
Quick Start Package Overview
Additional reference documents are available on nxp.com/FRDM-KW24D512
2
EXTERNAL USE
Get to Know the FRDM-KW24D512 1 of 3
3
EXTERNAL USE
Get to Know the FRDM-KW24D512 2 of 3
4
EXTERNAL USE
Get to Know the FRDM-KW24D512 3 of 3
The NXP Freedom development platform is a set of software and hardware tools for evaluation and development. It is ideal for rapid prototyping of microcontroller-based applications. The NXP Freedom KW24 hardware, FRDM­KW24D512, is a simple, yet sophisticated design featuring a Kinetis W series MCU, the industry’s first MCU built on the ARM® Cortex® M4 core.
This equipment is to be used by developers for evaluation purposes only, and must be incorporated into any other device or system. Integrators are responsible for re-evaluating the end product (including the transmitter) and obtaining a separate authorization.
Features:
MKW24D512VHA5 MCU – 50MHz, 512KB Flash, 64KB SRAM, 63LGA Small RF reference design area marked in silkscreen, combo sensor
FXOS8700CQ, Tri-color LED, Flexible power supply options – USB, external source
Two (4) user push-button switches (SW1-SW4) Easy access to MCU I/O Power-measurement access points UART, SPI, I2C, optional USB 2.0 FS/LS H/D/OTG Form factor compatible with Arduino ™ R3 pin layout New, OpenSDA debug interface
o Mass storage device flash programming interface (default) – no tool
installation required to evaluate demo apps
o CMSIS-DAP interface: new ARM standard for embedded debug interface
Refer to the FRDM-KW24D512 User’s Manual and OpenSDA User’s Guide for more information.
5
EXTERNAL USE
FRDM-KW24D512 Operation Description
The KW24 operating frequency range is 2405 MHz to 2480 MHz, the data rate is 250 Kbps, and the modulation type is O-QPSK – all of these parameters are defined by the 802.15.4 standard.
The antenna is a fixed printed inverted “F”, or PIFA antenna on the PCB. The operating voltage for the KW24 is 5V and the current for TX/RX is < 20 mA. The KW24 crystal oscillator is 32 MHz and the radio uses an internal PLL to generate the RF frequency.
6
EXTERNAL USE
Getting Started Out of the Box
Installing Drivers and Running the Out of Box Demo
7
EXTERNAL USE
Introduction to OpenSDA 1 of 2
OpenSDA is an open-standard serial and debug adapter. It bridges serial and debug communications between a USB host and an embedded target processor. OpenSDA software includes a flash-resident USB mass-storage device (MSD) bootloader and a collection of OpenSDA Applications. FRDM-KW24D512 comes with the following applications preloaded:
- MSD Flash Programmer
- Debug Application
- Virtual mbed serial port Follow these instructions to run the OpenSDA Bootloader and change the installed OpenSDA application:
8
EXTERNAL USE
Introduction to OpenSDA 2 of 2
The MSD Flash Programmer is a composite USB application that provides a virtual serial port and an easy and convenient way to program applications into the KW24 MCU. It emulates a FAT16 file system, appearing as a removable drive in the host file system with a volume label of ‘DAPLink’. Raw binary files that are copied to the drive are programmed directly into the flash of the KW24 and executed automatically. The virtual serial port can be opened with standard serial terminal applications.
9
EXTERNAL USE
Explore Further
The MSD Flash Programmer is a composite USB application that provides a virtual serial port and an easy and convenient way to program applications into the KW24 MCU. It emulates a FAT16 file system, appearing as a removable drive in the host file system with a volume label of ‘DAPLink’. Raw binary files that are copied to the drive are programmed directly into the flash of the KW24 and executed automatically. The virtual serial port can be opened with standard serial terminal applications.
Now that you are familiar with the FRDM­KW24D512 and OpenSDA, it’s time to explore the additional software and lab guides available on
www.nxp.com/FRDM-KW24D512.
Select your next path from the links in the
Jump Start Your Design section.
10
EXTERNAL USE
FCC NOTE:
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth
environment .This equipment should be installed and operated with minimum distance
20cm between the radiator& your body.
for an uncontrolled
ISED W arning
This device complies with Innovation, Science and Economic Development Canada licence-exempt RSS standard(s). Operation is subject to the fol this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'ISED applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
1) l'appareil ne doit pas produire de brouillage, et
( (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
ISED RF exposure statement:
This equipment
uncontrolled environment. This equipment should be installed and operated with minimum
complies with ISED radiation exposure limits set forth for an
lowing two conditions: (1)
distance 20cm between the radiator& your body.This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
Le rayonnement de la classe b repecte ISED fixaient un environnement non
contrôlés.Installation et mise en œuvre de ce matériel devrait avec échangeur distance
minimale entre 20 cm ton corps.Lanceurs ou ne peuvent pas coexister cette antenne ou
capteurs avec d’autres.
FCC/ISED Label Instructions
The outside of final products that contains this module device must display a label referring to the
enclosed module. This exterior label can use wording such as: “Contains Transmitter Module
FCC ID:XXMFRDMKW24D512,IC:8764A-FRDMKW24D" or “Contains
FCC ID:XXMFRDMKW24D512,IC:8764A-FRDMKW24D” Any similar wording that expresses the
same meaning may be used.
