Nvidia RIVA TNT2 User Manual

Graphics Blaster RIVA TNT2 Value
Installation Guide
Contents
Introduction
Introduction .................................................................................................................1
Preliminary step for Windows 95 users.......................................................................3
Installing Your Graphics Card.....................................................................................4
Installing Software.......................................................................................................6
Changing Settings......................................................................................................10
About Sonnetech Colorific/3Deep.............................................................................12
Getting More Information .........................................................................................14
Technical Specifications............................................................................................16
Troubleshooting.........................................................................................................20
The Graphics Blaster™ RIVA TNT2™ Value is a high quality 2D/3D/video graphics accelerator card that is well suited for a wide variety of applications ranging from everyday desktop use to gaming and entertainment.
Leveraging NVIDIA Value delivers high quality and performance. Its dual texture architecture can process 2 pixels or textures per clock cycle; this enables developers to create special effects such as multi­layered textures, bump mapping to simulate rough surfaces, and environmental mapping that gives objects reflective properties. Developers can take advantage of advanced filtering modes (including trilinear mipmapping and anisotropic filtering) with full scene anti-aliasing to create realistic images that rival more expensive graphics workstations.
’s RIVA TNT2 graphics controller, the Graphics Blaster RIVA TNT2
The Graphics Blaster RIVA TNT2 Value provides outstanding 2D and video acceleration as well and also supports software DVD decoders through hardware color and pixel format conversion.
Serial and Model Numbers
Before You Begin
Minimum System Requirements
Your card’s serial and model numbers can be found at the back of the card. We recommend that you record the serial and model number below. This information will be useful in the event that you need to contact our Technical Support staff for troubleshooting or your dealer for warranty service.
Table 1: Serial numbers and model numbers.
Hardware Product Codes Numbers
Graphics Blaster RIVA TNT2 Value
The README file on the CD-ROM contains information not a vailable at the time of printing. Read the file before you continue. In addition, read the following:
Minimum System RequirementsUpdating Drivers
IBMGenuine Intel Pentium II, Pentium III, AMD-K6 or AMD-K6-2 processor running at
32 MB RAM15 MB free hard disk spaceVacant 32-bit AGP 1.0 expansion slot for Graphics Blaster RIVA TNT2 ValueVGA monitor
®
PC 100% compatible
90 MHz or higher
Serial Number
Model Number
2 Graphics Blaster RIVA TNT2 Value Installation Guide
CD-ROM drive installedWindows 95, Windows 98, Windows NT 4.0 (with Service Pack 3),
or Windows 2000 (when available)
Updating Drivers
Preliminary step for Windows 95 users
Check the appropriate box so that you can refer to the Windows’ version number quickly during the software installation process.
To download the latest drivers for Graphics Blaster RIVA TNT2 Value, visit Creative’s Web site (refer to the
Since Windows automatically detects new hardware and starts the software installation procedure upon startup, you should verify your Windows version number before installing the graphics card.
To verify your Windows 95 version number
1. Click Start -> Settings -> Control Panel.
2. In the Control Panel window, double-click the System icon. Your Windows 95 version number is displayed in the General tabbed page of the Systems Properties dialog box.
3. Note the version number. The following are the possible Windows 95 version numbers:
4.00.950 (Retail version)4.00.950A (Retail version)4.00.950B (OSR version 2 and 2.1)4.00.950C (OSR version 2.5)
Technical Support
leaflet for details).
Graphics Blaster RIVA TNT2 Value Installation Guide 3
Installing Your Graphics Card
Figure 1 shows you the connectors on the Graphics Blaster RIVA TNT2 Value card.
Video Expansion connector
Connect to a video expansion board.
VGA Out connector
Connects to your monitor via a monitor cable.
AGP bus connector
Figure 1: The Graphics Blaster RIVA TNT2 Value card.
To install the graphics card
1. Switch off your computer and all peripheral devices.
2. Disconnect the power cord from the wall outlet.
3. Touch any metallic surface on your computer to discharge any static electricity.
4. Remove the computer cover.
5. Locate a free AGP expansion slot. Figure 2 shows the various types of ex pansion slots.
If you are replacing an existing VGA card with Graphics Blaster RIVA TNT2 Value, please remember to remove the existing VGA card.
4 Graphics Blaster RIVA TNT2 Value Installation Guide
6. Remove the metal plate from the AGP slot. Keep the screw and metal plate for future use.
7. Align the bus connector of the graphics card with the expansion slot.
An AGP slot
A PCI slot
An ISA slot
Figure 2: Types of expansion slots.
If you are using a multi­frequency monitor, you may need a special 15-pin PS/2-compatible adapter cable. If your multi­frequency monitor allows you to switch between ‘TTL’ and ‘analog’ operation modes, set the switch to ‘analog’. For details, refer to your monitor’s manual.
8. Press the card’s bus connector gently and evenly into the slot, making sure that the bus connector comes into full contact with the slot. Then, secure the card to the computer casing with a screw. See Figure 3 below.
ii.Secure the card to the slot with a screw.
Warning: Do not force the graphics card into place. If it does not fit properly, gently remove it and try again.
i. Gently and evenly press the card’s bus connector into the slot.
Figure 3: Securing the graphics card to the slot.
9. Connect the monitor cable to the VGA Out connector of Graphics Blaster RIVA TNT2 Value, as shown in Figure 4.
VGA Monitor cable
VGA Out connector
VGA monitor
Graphics Blaster RIVA TNT2 Value
Figure 4: Connecting your VGA monitor to Graphics Blaster RIVA TNT2 Value.
10.Replace the computer cover and plug the power cord back into the wall outlet.
Graphics Blaster RIVA TNT2 Value Installation Guide 5
Installing Software
After installing the graphics card, you can install the software. The Graphics Blaster RIVA TNT2 Value CD contains the following:
Drivers for Windows 95/98 (common to both)Drivers for Windows NT 4.0Creative Enhanced BlasterControlCreative SoftMPEG for Windows 95/98Sonnetech Colorific®/3Deep™ for Windows 95/98 and Windows NT 4.0
This section is organized as follows:
To install in Windows 95 (Retail version)To install in Windows 95 (OSR version 2.0 and later)To install in Windows 98To install in Windows NT 4.0 (Service Pack 3)
for Windows 95/98 and Windows NT 4.0
To install in Windows 95 (Retail version)
6 Graphics Blaster RIVA TNT2 Value Installation Guide
1. Switch on your system. Windows 95 automatically detects the graphics card. A New Hardware Found message box appears, informing you that a display adapter has been detected.
2. When a dialog box similar to Figure 5 appears, ensure that the Driver from disk provided by hardware manufacturer option is selected.
3. Click the OK button.
4. Insert the Graphics Blaster RIVA TNT2 Value CD into your CD-ROM drive.
Figure 5: Selecting the Driver from disk provided by
hardware manufacturer option.
5. In the Install From Disk dialog box, type D:\WINDOWS (where D: represents your CD-ROM drive) and click the OK button.
6. If prompted to select drivers, click the Graphics Blaster RIVA TNT2 Value drivers. The drivers are copied to your system.
7. When prompted to restart your system, click the Yes button.
8. After the system has restarted, proceed to install the applications. Click Start -> Run.
9. In the Run dialog box, type D:\WINDOWS\SETUP and click the OK button.
10.Follow the instructions on the screen to complete the setup. If you do not install all the applications now, you can install them later.
To install in Windows 95 (OSR version 2.0 and later)
1. Switch on your system. Windows 95 automatically detects the graphics card. A New Hardware Found message box appears, informing you that a display adapter has been detected.
2. When a dialog box similar to Figure 6 appears, click the Next button.
3. Click the Other Locations button when it appears in the Update Device Driver Wizard dialog box.
4. Insert the Graphics Blaster RIVA TNT2 Value CD into your CD-ROM drive.
5. In the Select Other Location dialog box, type D:\WINDOWS (where D: represents your CD-ROM drive) and click the OK button.
6. In the Update Device Driver Wizard dialog box, click the Finish button.
7. In the Insert Disk message box, click the OK button.
Figure 6: The Update Device Driver Wizard dialog box.
Graphics Blaster RIVA TNT2 Value Installation Guide 7
8. In the Copying Files dialog box, type D:\WINDOWS and click the OK button.
The drivers are copied to your system.
9. In the Update Device Driver Wizard dialog box, click the OK button.
10.When prompted to restart your system, click the Yes button.
11.After the system has restarted, proceed to install the applications. Click Start -> Run.
12.In the Run dialog box, type D:\WINDOWS\SETUP and click the OK button.
13.Follow the instructions on the screen to complete the setup. If you do not install all the applications now, you can install them later.
To install in Windows 98
1. Switch on your system. Windows 98 automatically detects the graphics card. An Add New Hardware Wizard message box appears, informing you that a display adapter has been detected.
2. When a dialog box similar to Figure 7 appears, select the option Display a list of
all the drivers in a specific location, so you can select the driver you want.
3. Click the Next button.
4. Insert the Graphics Blaster RIVA TNT2 Value CD into your CD-ROM drive.
5. In the Models list box, click the Have Disk button.
8 Graphics Blaster RIVA TNT2 Value Installation Guide
Figure 7: Selecting the option Display a list of all the
drivers in a specific location, so you can select the driver you want.
6. In the Install From Disk dialog box, type D:\WINDOWS (where D: represents your CD-ROM drive) and click the OK button. If you are installing Graphics Blaster RIVA TNT2 Value as a second or subsequent card to make use of Windows 98’s multi-monitor capability, you will see an Update Driver Warning message telling you that the driver you have selected may not work correctly . You
must
click the Yes button to confirm that you want to use the selected driver . Otherwise, the
system will install the wrong driver and will not recognize the card as a Graphics Blaster RIVA TNT2 Value card (for details, see “Windows 98 Multi-Monitor Display Problems” on page 20).
7. In the Models list box of the Select Device dialog box, make sure the Graphics Blaster RIVA TNT2 Value entry is selected and click the OK button.
8. Click the Next button.
9. Click the Finish button. The drivers are copied to your system.
10.When prompted to restart your system, click the Yes button.
11.After the system has restarted, proceed to install the applications. Click Start -> Run.
12.In the Run dialog box, type D:\WINDOWS\SETUP and click the OK button.
13.Follow the instructions on the screen to complete the setup. If you do not install all the applications now, you can install them later.
To install in Windows NT 4.0 (Service Pack 3)
1. Switch on your system.
2. Click Start -> Run.
3. In the Run dialog box, type D:\WINNT40\SETUP and click the OK button.
4. Follow the instructions on the screen to complete the setup. If you do not install all the applications now, you can install them later.
5. If the Invalid Display Settings message box appears after your system has restarted, click the OK button and change the display settings. For details, see “To change the display settings in Windows NT 4.0” on page 10.
Graphics Blaster RIVA TNT2 Value Installation Guide 9
Changing Settings
To change the display settings in Windows NT 4.0
1. Right-click your desktop, and then click Properties on the shortcut menu.
2. In the Display Properties dialog box, click the Settings tab .
3. In the Desktop Area group box, move the slider to set the desired resolution.
4. In the Color Palette group box, select the desired color . Certain colors may not be av ailable
for some display resolutions.
5. In the Refresh Frequency group box, select the desired refresh rate.
6. To test the settings, click the Test button, and then click the OK button. When the Testing Mode dialog box re-appears:
If the test bitmap is properly displayed, click the Yes button.
If not, click the No button. A warning message will be displayed. Click the OK button
and repeat steps 3 through 6, changing one or more of the settings.
7. Click the OK button to close the Display Properties dialog box.
10 Graphics Blaster RIVA TNT2 Value Installation Guide
To change the performance settings in Windows 95/98 and Windows NT 4.0
Y ou can customize the settings of your graphics card for optimal performance with applications. However , if your monitor display exhibits pixel drop (that is, pixels, usually white in color, appear on the screen) or any other abnormal behavior, revert to the factory default settings (see “Troubleshooting” on page 12.).
To do so in Windows 95 and Windows NT 4.0
1. Right-click your desktop, and then click Properties on the shortcut menu.
2. In the Display Properties dialog box, click the BlasterControl tab.
3. On the BlasterControl tabbed page, click the Tweak icon.
4. In the Tweak module, select the desired settings.
5. To specify additional settings for Graphics Blaster RIVA TNT2 Value, click the Advanced Settings button.
6. Select the desired settings and click the OK button. To see a brief description of an option or check box in the BlasterControl Tweak module, right-click the item, and then click What’s This.
To do so in Windows 98
1. Right-click your desktop, and then click Properties on the menu that appears.
2. In the Display Properties dialog box, click the Settings tab.
3. On the Settings tabbed page, click the Advanced button.
4. In the Advanced Properties dialog box, click the BlasterControl tab.
5. Select the desired settings and click the OK button. To see a brief description of an option or check box in the BlasterControl Advanced module, right-click the item, and then click What’s This.
Graphics Blaster RIVA TNT2 Value Installation Guide 11
About Sonnetech Colorific/3Deep
About Colorific
Running Colorific
• If your monitor has a color temperature control, adjust it to 6500 K to get the best results.
• When printing to an inkjet printer, it is best to use special coated paper.
About 3Deep
Colorific® color management software is the industry-standard process for monitor-to­monitor and monitor-to-printer color management. It gives you accurate, predictable color­matching between your screen and printer or over the Internet by calibrating the colors on your monitor. The softw are leads you through a series of simple choices about what you see on your screen. From this information, Colorific builds a precise description of how your monitor displays color, taking into account variable viewing conditions, monitor control settings, and video card adjustments.
You should calibrate with Colorific before doing critical color work and whenever you change monitor color settings.
To run Colorific in Windows 95, Windows 98 and Windows NT 4.0
1. Click the Colorific Control Panel icon in the taskbar. The Display Properties dialog box appears.
2. Click the Colorific tab.
3. Click the Recalibrate button. The Colorific calibration utility is opened.
4. Follow the instructions on the screen to complete the process.
3Deep™ is an exciting new tool (supporting Windows 95 and Windows 98) that allows gamers to experience 3D games as the game developers intended. Only 3Deep can provide accurate 3D lighting and shading for 3D games because it adjusts the user’s monitor to match the game developer’s monitor — not too dark and not washed out.
12 Graphics Blaster RIVA TNT2 Value Installation Guide
3Deep uses Colorific’s technology (the industry standard for monitor calibration) to measure the unique characteristics of each gamer’s display. No more dark games, and no more washed out games when you increase the contrast of your monitor. The results are awesome 3D lighting and shading effects. 3Deep is a consistent and high-quality solution for improving the 3D effect of your games!
Using 3Deep
To uninstall Colorific in Windows 95/98 and Windows NT 4.0, and 3Deep in Windows 95/98
To use 3Deep to calibrate your monitor’s gamma value
1. Click Start -> Settings -> Control Panel.
2. In the Control Panel window, double-click the 3Deep icon.
3. On the 3Deep Control Panel, move the Tweak slider or click the Calibrate Display button.
4. Before playing a game, click Default System Gamma. You can also display the 3Deep Control Panel by doing the following:
1. Right-click your desktop, and then click Properties on the shortcut menu.
2. In the Display Properties dialog box, click the 3Deep tab.
1. Right-click the Colorific Control Panel icon in the taskbar.
2. On the menu that appears, click Exit.
3. Click Start -> Settings -> Control Panel.
4. In the Control Panel window, double-click the Add/Remove Programs icon. The Add/Remove Programs Properties dialog box appears with the Install/Uninstall tabbed page displayed.
5. Select the entry Colorific For Windows from the list, and then click the Add/Remove button.
6. After Colorific For Windows is removed, select the entry 3Deep from the list, and then click the Add/Remove button.
Graphics Blaster RIVA TNT2 Value Installation Guide 13
Getting More Information
For Graphics Blaster RIVA TNT2 Value
For Creative BlasterControl
For Creative SoftMPEG
The Help file for Graphics Blaster RIVA TNT2 Value gives a brief introduction to the features supported by this graphics card.
To open the Help file for Graphics Blaster RIVA TNT2 Value
Click Start -> Programs -> Creative -> Graphics Blaster RIVA TNT2 Value -> Graphics Blaster RIVA TNT2 Value Help.
The Help file for Creative BlasterControl shows you how to use the BlasterControl utility to customize your screen resolution, color depth, and refresh rate in Windows.
To open the Help file for BlasterControl
Click Start -> Programs -> Creative -> BlasterControl Help.
For Help topics specific to a BlasterControl module
In the BlasterControl module you want, click the Help button.
The Help file for Creative SoftMPEG teaches you how to use SoftMPEG to play Video CDs and MPEG files.
To open the Help file for SoftMPEG
In Creative SoftMPEG, right-click the Video window, and then click Help on the menu that appears.
14 Graphics Blaster RIVA TNT2 Value Installation Guide
For Colorific and 3Deep
The Help file for Colorific contains the User’s Manual.
To open the Help file for Colorific
1. Click Start -> Programs -> Colorific. The Colorific calibration utility is opened.
2. On the right-hand corner of the menu bar, click Help.
3. On the Help menu, click Help Contents.
To open the Help file for 3Deep
1. Click Start -> Settings -> Control Panel.
2. In the Control Panel window, double-click the 3Deep icon.
3. On the 3Deep Control Panel, click the Help button.
Technical Support for Colorific and 3Deep
Updated information about using Colorific and 3Deep can be obtained from Sonnetech’s Web site at www.sonnetech.com/tech_support. If you cannot find the information you need from the W eb site or in the program’s Help screens, send an e-mail message to info@sonnetech.com.
Graphics Blaster RIVA TNT2 Value Installation Guide 15
Technical Specifications
Architecture Highlights
3D Features
64-bit wide graphics engine and frame buffer16 MB SDRAM250 million pixels/sec, bilinear filtered
Optimized for Microsoft’s Direct3D APIComplete DirectX 6.x support100% hardware triangle setupTwin texel (TNT) 32-bit graphics pipeline
2 texture-mapped, lit pixels per clock
Single pass multi-texturing support (DirectX 6.x and OpenGL ICD)
Square and non-square texture support
TextureBlend support examples:
Multi-texture
•Bump map
Texture modulation
Light maps
Reflection maps
Detail textures
Environmental maps
Procedural textures
Sub-pixel accurate
16 Graphics Blaster RIVA TNT2 Value Installation Guide
Backend blend
32-bit ARGB rendering with destination alpha
Point sampled, bilinear, trilinear and 8-tap
Anisotropic filtering
Per pixel perspective correct texture mapping
•Fog
•Light
Mipmapping
24-bit or 16-bit hardware Z-buffer (fixed or floating)8-bit stencil bufferFull scene anti-aliasing
2D Features
Video Support
High performance 128-bit 2D/GUI/DirectDraw acceleration
Accelerated primitives include BLT, indexed DIB color translation, transparent BLT,
stretch BLT, points, lines, polylines, polygons, fills, patterns, arbitrary rectangular clipping and fast text rendering hardware font cache
Pipeline optimized for multiple color depths including 32, 24, 16, 15, and 8 bits per
pixel
Fast 32-bit VGA/SVGA supportMulti-buffering (Double, Triple, Quad buff ering) for smooth animation and video playback
Video acceleration for DirectShow, MPEG-1, MPEG-2 and IndeoX and Y smooth up and down scaling with filteringPer-pixel color keyingMultiple video windows with hardware color space conversion and filtering (YUV 4:2:2
and 4:2:0)
Video port supports ITU-CCIR 565
Graphics Blaster RIVA TNT2 Value Installation Guide 17
Specifications
AGP 2X data transferVESA DDC 2B + DPMSSingle slot 2D, 3D graphics, and video acceleratorNVIDIA RIVA TNT2 Model 64 graphics engineIntegrated 300 MHz RAMDAC supporting up to 1920x1200 true colorMPEG-1, MPEG-2, and full-motion video acceleration/assistanceFull Plug and Play compliant
Drivers
Utilities
Applications Supported
18 Graphics Blaster RIVA TNT2 Value Installation Guide
Windows NT 4.0 and Windows 2000 (when available) display driversWindows 95 and Windows 98 display driver, DirectDraw, Direct3D, DirectVideo, ActiveXOpenGL ICD for Windows 95 and Windows NT 4.0VBE 3.0 compliant
Creative Enhanced BlasterControlCreative Enhanced SoftMPEGSonnetech Colorific/3Deep
All Windows 95 applications, including DirectDraw and Direct3D games and applicationsOpenGL applications under Windows 95 and Windows 98
Table 2: Refresh rates supported by different video modes
The refresh rates shown in the table are the highest obtainable and are monitor-dependent. Resolutions, pixel depths, and refresh rates are also driver­dependent and may not be available for some applications or operating systems.
Refresh
Rates
Number of Colors
Resolution 256 (8-bit) 64k (16-bit) 16.7 million (32-bit)
640x480
800x600
1024x768
1152x864
1280x1024
60, 70, 72, 75, 85, 100,
120, 140, 144, 150,
170, 200, 240
60, 70, 72, 75, 85, 100,
120, 140, 144, 150,
170, 200, 240
60, 70, 72, 75, 85, 100, 120, 140, 144, 150, 170
60, 70, 72, 75, 85, 100,
120, 140, 144, 150
60, 70, 72, 75, 85, 100,
120
60, 70, 72, 75, 85, 100,
120, 140, 144, 150,
170, 200, 240
60, 70, 72, 75, 85, 100,
120, 140, 144, 150,
170, 200, 240
60, 70, 72, 75, 85, 100, 120, 140, 144, 150, 170
60, 70, 72, 75, 85, 100,
120, 140, 144, 150
60, 70, 72, 75, 85, 100,
120
60, 70, 72, 75, 85, 100,
120, 140, 144, 150,
170, 200, 240
60, 70, 72, 75, 85, 100,
120, 140, 144, 150,
170, 200, 240
60, 70, 72, 75, 85, 100, 120, 140, 144, 150, 170
60, 70, 72, 75, 85, 100,
120, 140
60, 70, 72, 75, 85, 100
1600x1200 60, 70, 72, 75, 85 60, 70, 72, 75, 85 60, 70, 72, 75 1920x1080 60, 70, 72, 75, 85 60, 70, 72, 75, 85 60, 70, 72 1920x1200 60, 70, 72, 75 60, 70, 72, 75
Graphics Blaster RIVA TNT2 Value Installation Guide 19
Troubleshooting
System Hangs, Blank Screen or Corrupted Display
Windows 98 Multi-Monitor Display Problems
20 Graphics Blaster RIVA TNT2 Value Installation Guide
$IWHULQVWDOOLQJ*UDSKLFV%ODVWHU5,9$7179DOXHDQGVWDUWLQJ\RXUV\VWHPWKH
PRQLWRUGLVSOD\VDEODQNVFUHHQ
Solutions Try the following:
7KHPRQLWRUFRQQHFWHGWRWKHVHFRQGRUVXFFHVVLYH*UDSKLFV%ODVWHU5,9$717
9DOXHFDUGUHPDLQVEODQNHYHQWKRXJKWKHFDUGDQGLWVGULYHUVKDYHEHHQLQVWDOOHG
Cause If Graphics Blaster RIVA TNT2 Value’s drivers are not specified during the
Solution Update the device drivers to Graphics Blaster RIVA TNT2 Value’s drivers:
Switch off your system and wait a while before switching it on again.Verify that any built-in VGA on your motherboard is disabled and that you
have removed any other video display card from your system.
Ensure that your Graphics Blaster RIV A TNT2 Value card’s bus connector is
fully inserted into the expansion slot. Ensure this by pressing it gently and evenly into the slot.
Verify that the pins of your monitor’s VGA Input connector are not bent and
that the connector is properly connected to the VGA Out connector of Graphics Blaster RIVA TNT2 Value.
software installation (see “To install in Windows 98” on page 8), the system installs the second or successive Graphics Blaster RIVA TNT2 Value card as a VGA card which does not support Windows 98’s multi-monitor feature.
1. Right-click your desktop, and then click Properties on the shortcut menu.
2. In the Display Properties dialog box, click the Settings tab.
3. On the Settings tabbed page, click the Advanced Properties button.
4. In the Advanced Display Properties dialog box, click the Change button.
5. In the Select Device dialog box, click the Have Disk button.
6. Insert the Graphics Blaster RIVA TNT2 Value CD into your CD-ROM drive.
7. Follow steps 6 through 13 of the procedure in “To install in Windows 98” on page 8 to complete the update.
Other Display Problems
For the resolutions supported by your monitor, refer to its manual.
0RQLWRUGLVSOD\IOLFNHUVRUWKHVFUHHQJRHVEODQNDIWHU:LQGRZVVWDUWV
Cause Your monitor may not support the resolution or refresh rate that you have set. Solution Use display settings supported by the monitor.
To change the display settings:
1. Restart your system in Windows 98 Safe mode. To do so: i. Restart your system and when the message “Starting Windows 98...”
appears, press <F8>. A list of options such as Safe Mode and Command Prompt Only Mode appears.
ii. Select Safe Mode and press <Enter>.
2. After your system has restarted, right-click the desktop and click Properties.
3. In the Display Properties dialog box, click the Settings tab.
4. Try the following: Make sure that the correct monitor is selected.
To verify, click the Change Display Type button or the Advanced Properties button on the Settings tabbed page.
Use a lower refresh rate or the adapter’s default.
For details on this, refer to the topic “Using BlasterControl Monitor Settings” in the BlasterControl Help file.
Lower your monitor’s resolution.
To do so, adjust the color depth and desktop area on the Settings tabbed page.
Graphics Blaster RIVA TNT2 Value Installation Guide 21
0RQLWRUGLVSOD\H[KLELWVSL[HOGURSWKDWLVSL[HOVXVXDOO\ZKLWHLQFRORUDSSHDURQ
WKHVFUHHQRURWKHUDEQRUPDOEHKDYLRU
Cause The settings that you have selected for your graphics card may be incompatible
with one or more games or applications that you are running.
Solution Use the factory default settings:
1. Right-click your desktop, and then click Properties on the shortcut menu.
2. In the Display Properties dialog box, click the BlasterControl tab.
3. On the BlasterControl tabbed page, click the Tweak icon.
4. Click the Restore Defaults button.
Beeping Sounds During System Startup
Problems Installing Software
22 Graphics Blaster RIVA TNT2 Value Installation Guide
:KHQWKHV\VWHPLVVWDUWLQJXSWKHUHLVDVHULHVRISURORQJHGEHHSV
Cause Y our Graphics Blaster RIVA TNT2 Value card may not be f irmly inserted into the
Solution Ensure that the bus connector of the graphics card is fully inserted into the
,Q:LQGRZVRU:LQGRZVWKHLQVWDOODWLRQSURJUDPIRU%ODVWHU&RQWUROGRHVQRW
UXQDXWRPDWLFDOO\DIWHU\RXKDYHLQVHUWHGWKHLQVWDOODWLRQ&'LQWR\RXUGULYH
Cause The AutoPlay feature in your Windows 95 or Windows 98 system is not enabled. Solution To install the software from the CD:
expansion slot.
expansion slot. Ensure this by pressing the card gently and evenly into the slot. You can also try removing the card and re-inserting it.
1. Double-click the My Computer icon on your Windows desktop.
2. In the My Computer window, double-click the Creative Graphics Blaster RIVA TNT2 Value icon. If the installation program does not run, double-click the Windows folder icon followed by the Setup icon.
3. Follow the instructions on the screen to complete the installation.
Problems Using Software
:KHQ\RXUHVWDUW:LQGRZVRQHRIWKHIROORZLQJHUURUPHVVDJHVDSSHDUV
“BlasterControl will only work on Creative graphics product drivers.
Do you want BlasterControl to be loaded the next time you start Windows?”
“BlasterControl will only work on Creative graphics product drivers.” Cause Graphics Blaster RIVA TNT2 Value drivers, required by BlasterControl, may
have been replaced by other drivers when you installed DirectX applications.
Solution Re-install or revert to the Graphics Blaster RIVA TNT2 Value drivers.
To revert to the drivers:
1. Right-click your desktop, and then click Properties on the shortcut menu.
2. In the Display Properties dialog box, click the Settings tab, and then click the Change Display Type button or the Advanced Properties button.
3. In the Adapter Type group box or on the Adapter tabbed page, click the Change button.
4. In the Select Device dialog box, click Graphics Blaster RIVA TNT2 V alue, and then click the OK button.
5. In the Insert Disk message box, click the OK button without inserting any CD.
6. If Graphics Blaster RIVA TNT2 Value drivers and later versions of DirectX drivers are already installed, click the Skip File button until the Adapter T ype group box or the Adapter tabbed page appears.
7. Click the two Close buttons to close the Display Properties dialog box.
8. When prompted to restart your system, click the Yes button. After you have restarted your system, the newer DirectX drivers will work with the latest Graphics Blaster RIVA TNT2 Value drivers.
Graphics Blaster RIVA TNT2 Value Installation Guide 23
Problem with OpenGL Applications
:KHQVWDUWLQJ2SHQ*/6FUHHQ6DYHURUDSSOLFDWLRQVLQ:LQGRZVWKHPHVVDJH
´1RORFDOEXIIHUPHPRU\DYDLODEOHµDSSHDUV
Solution Set a lower resolution and color depth:
1. Right-click your desktop, and then click Properties on the shortcut menu.
2. In the Display Properties dialog box, click the Settings tab.
3. In the Desktop Area group box, move the slider to set a lower resolution.
4. In the Color Palette group box, set to 640x480 and 16-bit color (high color)
for OpenGL applications to work properly.
2SHQ*/DSSOLFDWLRQVUXQXQFKDUDFWHULVWLFDOO\VORZO\LQ:LQGRZV
Cause OpenGL applications do not support Windows 98’s multi-monitor feature.
Consequently, Windows 98 disables all hardware acceleration when the multi­monitor option is enabled.
Solution Disable the multi-monitor option:
1. Right-click your desktop, and then click Properties on the shortcut menu.
2. In the Display Properties dialog box, click the Settings tab.
3. Clear the Extend my Windows desktop onto this monitor check box.
Problem with PCI Bridge (in Windows 95)
24 Graphics Blaster RIVA TNT2 Value Installation Guide
$IWHULQVWDOOLQJ*UDSKLFV%ODVWHU5,9$7179DOXHRQWRD3HQWLXP,,/;V\VWHPRUDQ\
RWKHU$*3V\VWHPWKH5HVRXUFHVWDEEHGSDJHRIWKH5,9$7179DOXH3URSHUWLHV
GLDORJER[LQ:LQGRZVVKRZVUHVRXUFHFRQIOLFWVVLPLODUWRWKHIROORZLQJ
0HPRU\5DQJHXVHG)('&)(''))))XVHGE\3&,VWDQGDUG3&,WR3&,EULGJH
0HPRU\5DQJHXVHG)')'))))))XVHGE\3&,VWDQGDUG3&,WR3&,EULGJH
0HPRU\5DQJHXVHG)()()))))XVHGE\3&,VWDQGDUG3&,WR3&,EULGJH
Cause The “PCI standard PCI-to-PCI bridge” is the CPU chipset to AGP controller,
which Windows 95 cannot identify properly.
Solution No action required.
A conflict between the AGP video controller and the “PCI standard PCI-to-PCI bridge” in the Windows 95 Device Manager does not affect the functionality of the AGP card within W indo ws 95. This problem is common to all A GP graphics cards and does not affect Graphics Blaster RIVA TNT2 Value’s functionality. It has been resolved in Windows 98.
Problem with AGP Aperture Size
Changing settings in CMOS incorrectly can cause the system to stop functioning.
Some of the steps from step 3 onwards may not apply to your system’s CMOS. Refer to your system’s CMOS documentation for more details.
'LUHFW'UDZ'LUHFW'IDLOVWRXVHKDUGZDUHDFFHOHUDWLRQ+$/
Cause The CMOS setting for the AGP Aperture size is less than 8 MB. Solution Set the AGP Aperture size to 8 MB or more.
Do the following in CMOS:
1. Restart your system.
2. During the memory check, press <Delete>. The CMOS setup menu appears.
3. Select Chipset Features Setup and press <Enter>.
4. Set your AGP Aperture Size (MB) to 8 MB or more.
5. Press <Esc> to return to the CMOS setup menu.
6. Select Save & Exit Setup, and then press <Enter>.
7. Press <Y> and then press <Enter>.
Graphics Blaster RIVA TNT2 Value Installation Guide 25
Creative End-User Software License Agreement
Version 2.0, June 1998
PLEASE READ THIS DOCUMENT CAREFULLY BEFORE USING THE SOFTWARE. BY USING THE SOFTWARE, YOU AGREE TO BE BOUND BY THE TERMS OF THIS AGREEMENT. IF YOU DO NOT AGREE TO THE TERMS OF THE AGREEMENT, DO NOT OPEN THE SEALED DISK PACKAGE, INSTALL OR USE THE SOFTWARE. PROMPTLY RETURN, WITHIN 15 DA YS, THE SOFTWARE, ALL RELATED DOCUMENTATION AND ACCOMPANYING ITEMS TO THE PLACE OF ACQUISITION FOR A FULL REFUND.
This is a legal agreement between you and subsidiaries (“Creative”). This Agreement states the terms and conditions upon which Creative offers to license the software sealed in the disk package together with all related documentation and accompanying items including, but not limited to, the executable programs, drivers, libraries and data files associated with such programs (collectively, the “Software”).
LICENSE
1.
Grant of License
The Software is licensed, not sold, to you for use only under the terms of this Agreement. You own the disk or other media on which the Software is originally or subsequently recorded or fixed; but, as between you and Creativ e (and, to the extent applicable, its licensors), Creative retains all title to and ownership of the Software and reserves all rights not expressly granted to you.
2.
For Use on a Single Computer
The Software may be used only on a single computer by a single user at any time. You may transfer the machine-readable portion of the Software from one computer to another computer, provided that (a) the Software (including any portion or copy thereof) is erased from the first computer and (b) there is no possibility that the Software will be used on more than one computer at a time.
3.
Stand-Alone Basis
You may use the Software only on a stand-alone basis, such that the Software and the functions it provides are accessible only to persons who are physically present at the location of the computer on which the Software is loaded. You may not allow the Software or its functions to be accessed remotely, or transmit all or any portion of the Software through any network or communication line.
4.
Copyright
The Software is owned by Creative and is protected by United States copyright laws and international treaty provisions. You may not remove the copyright notice from any copy of the Software or any copy of the written materials, if any, accompanying the Software.
5.
One Archival Copy
You may make one (1) archival copy of the machine-readable portion of the Software for backup purposes only in support of your use of the Software on a single computer, provided that you reproduce on the copy all copyright and other proprietary rights notices included on the originals of the Software.
6.
No Merger or Integration
You may not merge any portion of the Software into, or integrate any portion of the Software with, any other program, except to the extent expressly permitted by the laws of the jurisdiction where you are located. Any portion of the Software merged into or integrated with another program, if any, will continue to be subject to the terms and conditions of this Agreement, and you must reproduce on the merged or integrated portion all copyright and other proprietary rights notices included in the originals of the Software.
7.
Network Version
If you have purchased a “network” version of the Software, this Agreement applies to the installation of the Software on a single “file server”. It may not be copied onto multiple systems. Each “node” connected to the “file server”
Creative Technology Ltd
. and its
must also have its own license of a “node copy” of the Software, which becomes a license only for that specific “node”.
8.
Transfer of License
You may transfer your license of the Software, provided that (a) you transfer all portions of the Software or copies thereof, (b) you do not retain any portion of the Software or any copy thereof, and (c) the transferee reads and agrees to be bound by the terms and conditions of this Agreement.
9.
Limitations on Using, Copying, and Modifying the Software
Except to the extent expressly permitted by this Agreement or by the laws of the jurisdiction where you acquired the Software, you may not use, copy or modify the Software. Nor may you sub-license any of your rights under this Agreement.
10.
Decompiling, Disassembling, or Reverse Engineering
You acknowledge that the Software contains trade secrets and other proprietary information of Creative and its licensors. Except to the extent expressly permitted by this Agreement or by the laws of the jurisdiction where you are located, you may not decompile, disassemble or otherwise reverse engineer the Software, or engage in any other activities to obtain underlying information that is not visible to the user in connection with normal use of the Software.
In particular, you agree not for any purpose to transmit the Software or display the Software’s object code on any computer screen or to make any hardcopy memory dumps of the Software’s object code. If you believe you require information related to the interoperability of the Software with other programs, you shall not decompile or disassemble the Software to obtain such information, and you agree to request such information from Creative at the address listed below. Upon recei ving such a request, Creative shall determine whether you require such information for a legitimate purpose and, if so, Creative will provide such information to you within a reasonable time and on reasonable conditions.
In any event, you will notify Creative of any information derived from re v erse engineering or such other activities, and the results thereof will constitute the confidential information of Creative that may be used only in connection with the Software.
TERMINATION
The license granted to you is effective until terminated. You may terminate it at any time by returning the Software (including any portions or copies thereof) to Creative. The license will also terminate automatically without any notice from Creative if you fail to comply with any term or condition of this Agreement. You agree upon such termination to return the Software (including any portions or copies thereof) to Creative. Upon termination, Creative may also enforce any rights provided by law. The provisions of this Agreement that protect the proprietary rights of Creative will continue in force after termination.
LIMITED WARRANTY
Creative warrants, as the sole warranty, that the disks on which the Software is furnished will be free of defects, as set forth in the Warranty Card or printed manual included with the Software. No distributor, dealer or any other entity or person is authorized to expand or alter this warranty or any other provisions of this
Agreement. Any representation, other than the warranties set forth in this Agreement, will not bind Creative.
Creative does not warrant that the functions contained in the Software will meet your requirements or that the operation of the Software will be uninterrupted, error­free or free from malicious code. For purposes of this paragraph, “malicious code” means any program code designed to contaminate other computer programs or computer data, consume computer resources, modify, destroy, record, or transmit data, or in some other fashion usurp the normal operation of the computer, computer system, or computer network, including viruses, Trojan horses, droppers, worms, logic bombs, and the like.
AGREEMENT, THE SOFTWARE IS PROVIDED AS-IS WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED W ARRANTIES OF MERCHANTABILITY, AND FITNESS FOR A PARTICULAR PURPOSE. CREATIVE IS NOT OBLIGATED TO PROVIDE ANY UPDATES, UPGRADES OR TECHNICAL SUPPORT FOR THE SOFTWARE.
Further, Creative shall not be liable for the accuracy of any information provided by Creative or third-party technical support personnel, or any damages caused, either directly or indirectly, by acts taken or omiss ions made by you as a result of such technical support.
You assume full responsibility for the selection of the Software to achieve your intended results, and for the installation, use and results obtained from the Software. You also assume the entire risk as it applies to the quality and performance of the Software. Should the Software prove defective, you (and not Creative, or its distributors or dealers) assume the entire cost of all necessary servicing, repair or correction.
This warranty gives you specific legal rights, and you may also have other rights which vary from country/state to country/state. Some countries/states do n ot allow the exclusion of implied warranties, so the above exclusion may not apply to you. Creative disclaims all warranties of any kind if the Software was customized, repackaged or altered in any way by any third party other than Creative.
LIMITATION OF REMEDIES AND DAMAGES THE ONLY REMEDY FOR BREACH OF WARRANTY WILL BE THAT SET FORTH IN THE WARRANTY CARD OR PRINTED MANUAL INCLUDED WITH THE SOFTWARE. IN NO EVENT WILL CREATIVE OR ITS LICENSORS BE LIABLE FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OR FOR ANY LOST PROFITS, LOST SAVINGS, LOST REVENUES OR LOST DATA ARISING FROM OR RELATING TO THE SOFTWARE OR THIS AGREEMENT, EVEN IF CREATIVE OR ITS LICENSORS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT WILL CREATIVE’S LIABILITY OR DAMAGES TO YOU OR ANY OTHER PERSON EVER EXCEED THE AMOUNT PAID BY YOU TO USE THE SOFTWARE, REGARDLESS OF THE FORM OF THE CLAIM.
countries/states do not allow the limitation or exclusion of liability for inciden tal or consequential damages, so the above limitation or exclus ion may no t apply to y ou.
EXCEPT AS STATED ABOVE IN THIS
Some
26 Graphics Blaster RIVA TNT2 Value Installation Guide
PRODUCT RETURNS
If you must ship the software to Creative or an authorized Creative distributor or dealer, you must prepay shipping and either insure the software or assume all risk of loss or damage in transit.
U.S. GOVERNMENT RESTRICTED RIGHTS
All Software and related documentation are provided with restricted rights. Use, duplication or disclosure by the U.S. Government is subject to restrictions as set forth in subdivision (b)(3)(ii) of the Rights in Technical Data and Computer Software Clause at 252.227-7013. If you are sub-licensing or using the Software outside of the United States, you will comply with th e applicable local la ws of your country, U.S. export control law, and the English version of this Agreement.
CONTRACTOR/MANUFACTURER
The Contractor/Manufacturer for the Software is:
GENERAL
This Agreement is binding on you as well as your employees, employers, contractors and agents, and on any successors and assignees. Neither the Software nor any information derived therefrom may be exported except in accordance with the laws of the U.S. or other applicable provisions. This Agreement is governed by the laws of the State of California (except to the extent federal law governs copyrights and federally registered trademarks). This Agreement is the entire agreement between us and supersedes any other understandings or agreements, including, but not limited to, advertising, with respect to the Software. If any provision of this Agreement is deemed invalid or unenforceable by any country or government agency having jurisdiction, that particular provision will be deemed modified to the extent necessary to make the provision valid and enforceable, and the remaining provisions will remain in full force and effect. For questions concerning this Agreement, please contact Creative at the address stated above. For questions on product or technical matters, contact the Creative technical support center nearest you.
SPECIAL PROVISIONS APPLICABLE TO THE EUROPEAN UNION
IF YOU ACQUIRED THE SOFTWARE IN THE EUROPEAN UNION (EU), THE FOLLOWING PROVISIONS ALSO APPLY TO YOU. IF THERE IS AN Y INCONSISTENCY BETWEEN THE TERMS OF THE SOFTWARE LICENSE AGREEMENT SET OUT EARLIER AND IN THE FOLLOWING PROVISIONS, THE FOLLOWING PROVISIONS SHALL TAKE PRECEDENCE.
DECOMPILATION
You agree not for any purpose to transmit the Software or display the Software’s object code on any computer screen or to make any hard copy memory dumps of the Software’s object code. If you believe you require information related to the interoperability of the Software with other programs, you shall not decompile or disassemble the Software to obtain such information, and you agree to request such information from Creative at the address listed earlier. Upon receiving such a request, Creative shall determine whether you require such information for a legitimate purpose and, if so, Creative will provide such information to you within a reasonable time and on reasonable conditions.
LIMITED WARRANTY EXCEPT AS STATED EARLIER IN THIS AGREEMENT, AND AS PROVIDED UNDER THE HEADING “STATUTORY RIGHTS”, THE SOFTWARE IS PROVIDED AS-IS WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OR CONDITIONS OF
Creative Technology Ltd
31, International Business Park Creative Resource Singapore 609921
MERCHANTABILITY, QUALITY AND FITNESS FOR A PARTICULAR PURPOSE.
LIMITATION OF REMEDY AND DAMAGES THE LIMITATIONS OF REMEDIES AND DAMAGES IN THE SOFTWARE LICENSE AGREEMENT SHALL NOT APPLY TO PERSONAL INJURY (INCLUDING DEATH) TO ANY PERSON CAUSED BY CREATIVE’S NEGLIGENCE AND ARE SUBJECT TO THE PROVISION SET OUT UNDER THE HEADING “STATUTORY RIGHTS”.
STATUTORY RIGHTS
Irish law provides that certain conditions and warranties may be implied in contracts for the sale of goods and in contracts for the supply of services. Such conditions and warranties are hereby excluded, to the extent such exclusion, in the context of this transaction, is lawful under Irish law. Conversely, such conditions and warranties, insofar as they may not be lawfully excluded, shall apply. Accordingly nothing in this Agreement shall prejudice any rights that you may enjoy by virtue of Sections 12, 13, 14 or 15 of the Irish Sale of Goods Act 1893 (as amended).
GENERAL
This Agreement is governed by the laws of the Republic of Ireland. The local language version of this agreement shall apply to Software acquired in the EU. This Agreement is the entire agreement between us, and you agree that Creative will not have any liability for any untrue statement or representation made by it, its agents or anyone else (whether innocently or negligently) upon whi ch you relied upon entering this Agreement, unless such untrue statement or representation was mad e fraudulently.
Safety & Regulatory Information
The following sections contain notices for various countries:
CAUTION: This device is intended to be installed by the user in a CSA/TUV/UL certified/listed IBM AT or compatible personal computers in the manufacturer’s defined operator access area. Check the equipment operating/installation manual and/or with the equipment manufacturer to verify/confirm if your equipment is suitable for user-installed application cards.
ATTENTION: Ce carte est destiné à être installé par l’utilisateur, dans un ordinateur compatible certifié CSA/TUV/UL ou listé IBM AT , à l’intérieur de la zone définie par le fabricant. Consulter le mode d’emploi ou le fabricant de l’appareil pour vérifier ou confirmer si l’utilisateur peut y installer lui-même des cartes périphériques.
Notice for the USA
FCC Part 15: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, this notice is not a guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the distance between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician.
Caution
To comply with the limits for the Class B digital device, pursuant to Part 15 of the FCC Rules, this device must be installed in computer equipment certified to comply with the Class B limits.
All cables used to connect the computer and peripherals must be shielded and grounded. Operation with non-certified computers or non-shielded cables may result in interference to radio or television reception.
Modifications
Any changes or modifications not expressly ap prov ed by the grantee of this device could void the user’s authority to operate the device.
Notice for Canada
This apparatus complies with the Class “B” limits for radio interference as specified in the Canadian Department of Communications Radio Interference Regulations.
Cet appareil est conforme aux normes de CLASSE “B” d’interference radio tel que spe’cifie’ par le Ministère Canadien des Communications dans les règlements d’interfe’rence radio.
Compliance
This product conforms to the following Council Directive:
Directive 89/336/EEC, 92/31/EEC (EMC)
Graphics Blaster RIVA TNT2 Value Installation Guide 27
Declaration of Conformity
According to the FCC96 208 and ET95-19 documents, Name: Creative Labs Inc. Address: 1901 McCarthy Boulevard
declares under its sole responsibility that the product Trade Name: Creative Labs Model Number: CT6890
has been tested according to the FCC / CISPR22/85 requirements for Class B devic es and found compliant with the following standards:
EMI/EMC: ANSI C63.4 1992, FCC Part 15 Subpart B This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
Ce matériel est conforme à la section 15 des régles FCC. Son Fonctionnement est soumis aux deux conditions suivantes:
1. Le matériel ne peut étre source D’interférences et
2. Doit accepter toutes les interférences reques, Y compris
Milpitas, CA. 95035 United States Tel: (408) 428-6600
interference that may cause undesirable operation.
celles pouvant provoquer un fonctionnement indésirable.
Compliance Manager
Creative Labs, Inc.
25 February, 1999
No part of this publication may be reproduced or transmitted in any form or by any means without the prior written consent of Creative Technology Ltd. Copyright © 1999 Creative Technology Ltd. All rights reserved. Version 1.0
June 1999 Graphics Blaster is a trademark of Creative Technology Ltd.
NVIDIA, RIVA, RIVA TNT, and RIVA TNT2 are trademarks of NVIDIA Corporation. Colorific is a registered trademark of Sonnetech, Ltd. 3Deep is a trademark of Sonnetech, Ltd. All other products are trademarks or registered trademarks of their respective owners.
28 Graphics Blaster RIVA TNT2 Value Installation Guide
Loading...
