NVIDIA Quadro FX 4500 SDI User’s Guide

Version 1.0

NVIDIA Corporation January 27, 2006

NVIDIA ForceWare Graphics Drivers NVIDIA Quadro FX 4500 SDI User’s Guide v1.0

Published by NVIDIA Corporation 2701 San Tomas Expressway Santa Clara, CA 95050

Notice

ALL NVIDIA DESIGN SPECIFICATIONS, REFERENCE BOARDS, FILES, DRAWINGS, DIAGNOSTICS, LISTS, AND OTHER DOCUMENTS (TOGETHER AND SEPARATELY, “MATERIALS”) ARE BEING PROVIDED “AS IS.” NVIDIA MAKES NO WARRANTIES, EXPRESSED, IMPLIED, STATUTORY, OR OTHERWISE WITH RESPECT TO THE MATERIALS, AND EXPRESSLY DISCLAIMS ALL IMPLIED WARRANTIES OF NONINFRINGEMENT, MERCHANTABILITY, AND FITNESS FOR A PARTICULAR PURPOSE.

Information furnished is believed to be accurate and reliable. However, NVIDIA Corporation assumes no responsibility for the consequences of use of such information or for any infringement of patents or other rights of third parties that may result from its use. No license is granted by implication or otherwise under any patent or patent rights of NVIDIA Corporation. Specifications mentioned in this publication are subject to change without notice. This publication supersedes and replaces all information previously supplied. NVIDIA Corporation products are not authorized for use as critical components in life support devices or systems without express written approval of NVIDIA Corporation.

Tradem arks

NVIDIA, the NVIDIA logo, 3DFX, 3DFX INTERACTIVE, the 3dfx Logo, STB, STB Systems and Design, the STB Logo, the StarBox Logo, NVIDIA nForce, GeForce, NVIDIA Quadro, NVDVD, NVIDIA Personal Cinema, NVIDIA Soundstorm, Vanta, TNT2, TNT, RIVA, RIVA TNT, VOODOO, VOODOO GRAPHICS, WAVEBAY, Accuview Antialiasing, the Audio & Nth Superscript Design Logo, CineFX, the Communications & Nth Superscript Design Logo, Detonator, Digital Vibrance Control, DualNet, FlowFX, ForceWare, GIGADUDE, Glide, GOFORCE, the Graphics & Nth Superscript Design Logo, Intellisample, M-BUFFER, nfiniteFX, NV, NVChess, nView, NVKeystone, NVOptimizer, NVPinball, NVRotate, NVSensor, NVSync, the Platform & Nth Superscript Design Logo, PowerMizer, Quincunx Antialiasing, Sceneshare, See What You've Been Missing, StreamThru, SuperStability, T-BUFFER, The Way It's Meant to be Played Logo, TwinBank, TwinView and the Video & Nth Superscript Design Logo are registered trademarks or trademarks of NVIDIA Corporation in the United States and/or other countries. Other company and product names may be trademarks or registered trademarks of the respective owners with which they are associated.

Intel, Indeo, and Pentium are registered trademarks of Intel Corporation. Microsoft, Windows, Windows NT, Direct3D, DirectDraw, and DirectX are trademarks or registered trademarks of Microsoft Corporation. OpenGL is a registered trademark of Silicon Graphics Inc.

Other company and product names may be trademarks or registered trademarks of the respective owners with which they are associated.

NVIDIA Corporation

Driver Utilities Quadro FX 4500 SDI User’s Guide Version

Table of Contents

1.About NVIDIA Graphics to SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

2.NVIDIA Graphics-to-SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Feature Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Installing and Preparing the NVIDIA Quadro FX 4500 SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

About Your NVIDIA Quadro FX 4500 SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Installing the NVIDIA Quadro FX 4500 SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Operating NVIDIA SDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Understanding the Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

About the Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Recommended Operating Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

3.Windows–Using the Graphics to SDI Control Panel . . . . . . . . . . . . . . . . . . . . . 15

How to Set Up the SDI Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Basic SDI Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Advanced Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Synchronizing the SDI Output to an External Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Genlock Versus Frame Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Supported Synchronization Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Synchronization Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Viewing System Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Using SDI Under Dualview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

About Dualview Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

How to Enable Dualview Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Changing SDI Settings Under Dualview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

4.Linux—Using the Graphics to Video Out Control Panel . . . . . . . . . . . . . . . . . . 31

How to Set Up the SDI Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Basic SDI Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Advanced Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Synchronizing the SDI Output to an External Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Genlock Versus Frame Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Supported Synchronization Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Synchronization Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

5.API Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

SDI Application Programming Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Windows XP NvGvo API Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Viewing the SDI Hardware Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

NvGvo Function Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

NvGvo Structures, Enumerations, and Defines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

Linux CONTROL X Extension API . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

Using the NV-CTRL X APIs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

NV_CTRL_GVO Attributes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

NV-Control X Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

Appendix A:OnBoard DIP Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

NVIDIA Corporation i

NVIDIA Drivers Quadro FX 4500 SDI User’s Guide Version 1.0

NVIDIA Corporation

HAPTER 1

About NVIDIA Graphics to SDI

C HAPTER

BOUT

Serial Digital Interface (SDI) is a digital, uncompressed high quality video format used for film and video post production and broadcast applications. The NVIDIA Quadro uncompressed 8-bit, 10-bit, or 12-bit SDI output.

FX 4500 SDI graphics card converts composited video and graphics to

NVIDIA G

RAPHICS TO

SDI

About This Document

This manual explains the graphics-to-SDI functionality of the NVIDIA Quadro FX 4500 SDI graphics card and software, described in the following sections:

• “NVIDIA Graphics-to-SDI” on page 3 lists the supported SDI features and explains the basic operation in a broadcast environment.

• “Windows–Using the Graphics to SDI Control Panel” on page 15 describes how to use the Display Properties control panel to set up and start the SDI output under Windows.

• “Linux—Using the Graphics to Video Out Control Panel” on page 31 describes how to use the Display Properties control panel to set up and start the SDI output under Linux.

• “API Control” on page 43 gives an overview of API control of the SDI functions.

For instructions on installing the graphics card and drivers, refer to the documentation that accompanies your NVIDIA Quadro FX 4500 SDI graphics card.

NVIDIA Graphics-to-SDI

C HAPTER

NVIDIA G

This chapter provides an overview of the NVIDIA graphics-to-SDI functionality, described in the following sections:

• “Feature Overview” on page 4 lists the hardware connections, supported SDI formats, and additional SDI support features of the NVIDIA Quadro FX 4500 SDI graphics card.

• “Installing and Preparing the NVIDIA Quadro FX 4500 SDI” on page 6 describes how to install the NVIDIA Quadro FX 4500 SDI card and prepare it for use.

• “Operating NVIDIA SDI” on page 10 provides an overview of SDI operation.

RAPHICS-TO

-SDI

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 3

HAPTER 2

C NVIDIA Graphics-to-SDI

Feature Overview

Output Connections

• Two BNC connections that can be configured for fill + key dual-link SDI outputs, or for single-link SDI outputs

• One DVI video monitoring output

• BNC connections for external sync signals

Supported SDI Signal Formats

• Standard Definition (SD) Modes

• 487i @ 59.95 Hz (SMPTE259) NTSC

• 576i @ 50.00 Hz (SMPTE259) PAL

• High Definition (HD) Modes

• 720p @ 23.97 Hz, 24.00 Hz, 25.00 Hz, 29.97 Hz, 30.00 Hz, and 50.00 Hz

• 720p @ 59.94Hz, 60.00 Hz (SMPTE296)

• 1035i @ 59.94 Hz, 60.00 Hz (SMPTE260)

• 1080i @ 50.00 Hz (SMPTE295)

• 1080i @ 50.00 Hz, 59.94 Hz, 60.00 Hz (SMPTE274)

• 1080PsF @ 24.00 Hz, 23.976 Hz

• 1080PsF @ 25.00 Hz, 29.97 Hz, 30 Hz (SMPTE274)

• 1080p @ 23.976 Hz, 24.00 Hz, 25.00 Hz, 29.97 Hz, 30.00 Hz (SMPTE274)

• 2048x1080p @ 23.976 Hz, 24.00 Hz, 25.00 Hz, 29.97 Hz, 30.00 Hz, 47.96Hz, 48Hz,

60Hz (SMPTE272)

Supported SDI Color Formats

• RGB 4:4:4

• YCrCb 4:2:2 or 4:4:4

• RGBA 4:4:4:4

• YCrCbA 4:2:2:4

1. The 720p modes in this bullet entry are available with firmware revision 6 or later.

2. The 1080PsF modes in this bullet entry are available with firmware revision 6 or later.

4 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Supported Output Modes

• Transparent Clone Mode

See “Windows–Using the Graphics to SDI Control Panel” on page 15.

• Transparent Dualview Mode

See “Dualview Mode” on page 53.

• Extended Mode using NVIDIA SDI APIs

See “API Control” on page 43.

Desktop Region Adjustment Capability

Lets you define a portion of the desktop to convert to SDI output.

Genlock and Frame Lock Capability

Lets you synchronize the SDI output to an external digital or analog sync source.

HAPTER 2

NVIDIA Graphics-to-SDI

Note: The NVIDIA Quadro FX 4500 SDI card does not support SLI mode at this time.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 5

HAPTER 2

C NVIDIA Graphics-to-SDI

Installing and Preparing the NVIDIA Quadro FX 4500 SDI

About Your NVIDIA Quadro FX 4500 SDI

The following describes the components included in your NVIDIA Quadro FX 4500 SDI product package:

Cards

The NVIDIA Quadro FX 4500 SDI consists of the following two cards:

• NVIDIA Quadro FX 4500 Graphics Card

• NVIDIA SDI Output Card

Cables

In addition, you need the following cables, which should be provided with your NVIDIA Quadro FX 4500 SDI package:

• (Qty 1 ea.) 14-Pin Ribbon Cable

This cable connects the NVIDIA Quadro FX 4500 card to the SDI Output card for genlock and frame-lock functionality.

• (Qty 1 ea.) DVI-to-DVI Cable

This cable connects the video output from the graphics card to the SDI output card.

• (Qty 4 ea.) SMA-to-BNC Cable

These cables convert the SMA connectors on the SDI card to standard BNC connectors.

Cable Bands Kit

A package of cable bands of various colors is provided to distinguish the individual SMA-

-to-BNC cables after installation.

6 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Installing the NVIDIA Quadro FX 4500 SDI

Step 1: Install the NVIDIA Quadro FX 4500 SDI

1 Power down the system and open the chassis cover.

2 Install the NVIDIA Quadro FX 4500 card

a Insert the graphics card into the x16 PCI-express slot and use a screw to secure the

card’s bracket to the system chassis.

b Connect the auxiliary power connector.

3 Install the NVIDIA SDI Output card.

Insert the NVIDIA SDI Output card into any available expansion slot within six inches of the NVIDIA Quadro FX 4500 G-Sync connector, and use a screw to secure the card’s bracket to the system chassis.

Power to the auxiliary power connection is not needed at this time. NVIDIA recommends not connecting power to this connection.

HAPTER 2

NVIDIA Graphics-to-SDI

4 Connect one end of the 14-pin ribbon cable to the G-Sync connector on the NVIDIA

Quadro FX 4500 card, and the other end to the NVIDIA SDI Output card.

14-pin ribbon cable connecting the NVIDIA Quadro FX 4500 to the NVIDIA SDI Output card.

5 Close the chassis cover.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 7

HAPTER 2

C NVIDIA Graphics-to-SDI

Step 2: Connect the Auxiliary Cabling and Monitor

1 (Optional) Install the identification color bands.

Use the provided color bands to assist in properly identifying the function associated with each SMA-to-BNC cable.

a Using a different color for each SMA-to-BNC cable, place the band over the SMA-

connector end (the smaller end) and push up to the BNC-connector end.

b Position the band snugly over the wide portion of the insulation next to the BNC

connector.

2 Connect the SMA-to-BNC Cables.

Screw the male SMA connector onto the female SMA connector on the SDI output card.

Note: Use care when connecting, disconnecting, or handling the cables that you do not

3 Record which color corresponds to the individual connector:

break the center conductor on the SMA connector.

C Sync

V1 OutV2 OutS Sync

4 Connect the DVI Connectors.

Connect one end of the DVI cable to the DVI connector on the SDI Output card, and the other end to the “north” DVI connector on the NVIDIA Quadro FX 4500 card.

The cable must be connected to the “north” DVI connector. The NVIDIA Quadro FX 4500 SDI will not work properly if the cable is connected to the “south” DVI connector.

North DVI Connector

SDI-Output Card DVI Connector

8 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

5 Connect your display to the “south” DVI connector on the graphics card.

South DVI Connector

Step 3: Install the NVIDIA ForceWare Graphics Drivers

If you will be installing new graphics drivers for the NVIDIA Quadro FX 4500 SDI card, it is highly recommended that you uninstall any previous version of the NVIDIA ForceWare graphics driver software before installing updated graphics drivers.

1 Follow the instructions on the NVIDIA.com Web site driver download page to locate

the appropriate driver to download, based on your hardware and operating system.

2 Click the driver download link.

The license agreement dialog box appears.

HAPTER 2

NVIDIA Graphics-to-SDI

3 Click Accept if you accept the terms of the agreement, then either open the file or save

the file to your PC and open it later.

Opening the EXE file launches the NVIDIA InstallShield Wizard.

4 Follow the instructions in the NVIDIA InstallShield Wizard to complete the

installation.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 9

HAPTER 2

C NVIDIA Graphics-to-SDI

Operating NVIDIA SDI

The following sections provide an overview of SDI operation:

• “Understanding the Connections” on page 10

• “About the Software” on page 12

• “Recommended Operating Practices” on page 13

Understanding the Connections

Figure 2.1 shows the available SDI and external sync connectors on the NVIDIA Quadro

FX 4500 SDI.

Composite Genlock Sync Signal

SDI Genlock Sync Signal

Key portion of a dual link SDI output

Single link SDI output

Fill portion of a dual link SDI output

- or -

Single link SDI output

V1 OUTV2 OUTS SYNCC SYNC

Figure 2.1

10 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Quadro FX 4500 SDI Connectors

NVIDIA Corporation

Connecting the SDI Video Output

Refer to Figure 2.1.

• 4:4:4/4:2:2:4/4:4:4:4 dual-link signals are sent to the V1 Out and V2 Out connectors (corresponding to the fill + key signals respectively).

• 4:2:2 single-link signals are sent to the V1 Out connector only.

In application control mode, using the APIs, an additional 4:2:2 signal can be sent to the V2 Out connector.

Connecting to an External Sync Source

• You can genlock the output to an external digital or analog sync source.

NVIDIA Genlock supports the following two external synchronization signal types:

• SDI

• Composite, which can be one of the following:

Composite Bi-level (NTSC or PAL sources use bi-level composite signals.)

HAPTER 2

NVIDIA Graphics-to-SDI

Composite Tri-level (HDTV sources commonly use tri-level composite signals.)

• To use an external sync source, connect the sync signal to the appropriate BNC connector as indicated in Figure 2.1.

You can connect to both types of sync sources at the same time. The software gives precedence to the SDI signal, but you can use the control panel to choose which signal to use (see “Synchronizing the SDI Output to an External Source” on page 22.)

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 11

HAPTER 2

C NVIDIA Graphics-to-SDI

About the Software

The NVIDIA SDI software lets you specify the

•SDI signal format

• Color formats

• Synchronization method

• Gamma correction

Graphics-to-SDI functionality can be set up and controlled in two basic ways—using the NVIDIA control panel or using the NVIDIA SDI API.

Using the SDI APIs

The SDI application programming interface allows OpenGL applications to have full and exclusive control of the SDI output. This is also known as extended mode.

When the SDI output is under application control, you can use the NVIDIA Graphics to SDI property page to view the SDI hardware status.

• See the chapter “API Control” on page 43 for a description of the graphics-to-video-out API calls.

• Also, refer to the document instructions on using the APIs.

Using the Control Panel

When the SDI output is not being controlled by an application, you can use the NVIDIA graphical user interface to

• Specify the SDI signal format, output format, and then enable the SDI output.

• Configure the external synchronization signal if needed.

This is also known as transparent mode. In this mode, the SDI software works on top of existing applications, and the active workstation desktop or full screen application display is automatically forwarded to the SDI video outputs.

• For detailed intructions under Windows, see the chapter “Windows–Using the

Graphics to SDI Control Panel” on page 15.

• For detailed instruction under Linux, see the chapter “Linux—Using the Graphics to

Video Out Control Panel” on page 31.

Programming the NVIDIA Quadro FX 4000/4500 SDI for

12 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Recommended Operating Practices

This section provides some basic operating practices to follow in order to obtain the best SDI performance for your application.

Initial On-Air Broadcast

When starting a live broadcast of SDI video, follow the sequence below to ensure proper allocation of system resources and to prevent visual disturbances in the on air broadcast.

1 Set up the SDI format settings and start the SDI output

2 Start the application to be broadcast

3 Verify the video quality

4 Close the Graphics to SDI control panel

5 Go on air

To avoid visual disturbances while broadcasting live, DO NOT

• Start or stop the graphics or video application

HAPTER 2

NVIDIA Graphics-to-SDI

• Turn on or off the SDI output

• Make changes to the SDI signal format

Changing Applications

To avoid visual disturbances while switching applications, observe the following sequence:

1 Stop the live broadcast (go off air)

2 Stop the application

3 Start the new application

4 Verify video quality

5 Resume the live broadcast

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 13

HAPTER 2

C NVIDIA Graphics-to-SDI

Changing Video Formats

When changing any of the SDI settings, visual disturbances might occur as the video resets to the new settings. To prevent such disturbances from being visible to the public or from being recorded, observe the following sequence when making changes to any SDI setting:

1 Stop the live broadcast (go off air)

2 Change video format or SDI settings

3 Verify video quality

4 Resume the live broadcast

When Using the Control Panel

NVIDIA recommends the following

• Set the desktop to the same or higher resolution than the SDI output for better image quality.

• Close all background applications—such as virus scan, backup, and archiving applications—before starting the SDI output and going on air.

• Close the Display Properties panel before going on air.

• When running multiple OpenGL applications, tearing may occur if the applications are not synchronized.

In general, NVIDIA does not recommend running multiple OpenGL applications when starting the SDI output or when going live.

Running Multiple OpenGL Applications

To maximize the system resources and bandwidth available for converting graphics to SDI output, NVIDIA recommends broadcasting only one OpenGL application at a time.

14 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

HAPTER 3

Windows–Using the Graphics to SDI Control Panel

C HAPTER

INDOWS

This chapter explains how to set up the NVIDIA Quadro FX 4500 SDI graphics card under Windows using the NVIDIA Graphics to SDI properties page—also known as transparent mode. It contains the following sections:

–U

SING THE

RAPHICS TO

ONTROL

SDI

ANEL

• “How to Set Up the SDI Output” on page 16 provides step-by-step instructions for using the control panel to set up the SDI output.

• “Synchronizing the SDI Output to an External Source” on page 22 explains in more detail the genlock and frame lock features.

• “Viewing System Information” on page 26

• “Using SDI Under Dualview” on page 27

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 15

HAPTER 3

C Windows–Using the Graphics to SDI Control Panel

How to Set Up the SDI Output

Basic SDI Setup

To ensure proper operation, NVIDIA recommends the following -

• Set the desktop resolution to be the same or larger than the SDI output for better image quality

• Stop background applications—such as virus scan, backup and archiving applications—prior to starting SDI output and going on air.

• Close the control panel before going on air.

• When running multiple OpenGL applications, synchronize them, otherwise tearing may occur.

Step 1: Enable the Graphics to SDI Property Page

1 Open the NVIDIA Graphics to SDI property page.

a Right click the desktop, then from the pop-up menu, click NVIDIA Display->[your

monitor].

b Click the Graphics to SDI tree item from the slide-out tray.

Figure 3.1

2 In the Output Options group box, click On for Send Output to SDI.

If you have enabled Dualview mode, this option is grayed out and the panel says “Send SDI output to: NVIDIA SDIʺ. See “Dualview Mode” on page 53 for instructions on enabling Dualview mode.

Graphics to SDI Page

16 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Windows–Using the Graphics to SDI Control Panel

Step 2: Choose a Synchronization Method

Click the Sync Option arrow and then click the method you want to use to synchronize the SDI output:

• Internal: The SDI output will be synchronized with the timing chosen from the SDI

signal format list.

• Genlock: The SDI output will be synchronized with the external sync signal.

• Frame Lock: The SDI output will be synchronized with the timing chosen from the SDI

signal format list.

This list is limited to timings that can be synchronized with the detected external sync signal.

For more information regarding genlock and frame lock, see the section “Synchronizing

the SDI Output to an External Source” on page 22.

Step 3: Specify the SDI Signal Format

HAPTER 3

The SDI signal format controls the video resolution, field rate, and SMPTE signalling standard for the outgoing video stream.

Click the SDI signal format arrow and then click the signal format you want to use.

Note: Your options for this setting depend on which Sync option you chose in the

previous step.

• If you chose

The list box will be grayed out, preventing you from choosing another format.

• If you chose

the detected sync signal will appear in the SDI signal format list.

genlock synchronization, the sync source controls the SDI signal format.

frame lock synchronization, only those modes that are compatible with

Step 4: Specify the SDI Output Format

The SDI output format controls the color model, data packing, and alpha or z components in the outgoing video stream.

Click the SDI output format arrow and then click the color format you want to use.

Step 5: Apply and Verify the Changes

Click OK or Apply to put the new settings into effect.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 17

HAPTER 3

C Windows–Using the Graphics to SDI Control Panel

The Graphics to SDI property page banner indicates the status of the SDI output as well as the external synchronization signals. Figure 3.2 shows the correlation between the indicators on the banner and the actual connectors..

Graphics to SDI Property Page Banner

Quadro FX 4500 SDI Connectors

Figure 3.2

Connection Status Indicators

The activity of the LED graphics indicates the signal status as follows:

• Vid. 1 Out or Vid. 2 Out

Status Meaning

Off (gray)

Blinking Green

Blinking Yellow

SDI output is not in use

SDI output is active and is in HD mode.

SDI output is active and is in SD mode.

• SDI Sync

Status Meaning

Off (gray)

Blinking Green

Blinking Yellow

Steady Yellow

SDI synchronization signal is not present or not detected.

SDI synchronization signal is detected in HD mode.

SDI synchronization signal is detected in SD mode.

SDI synchronization error has occurred.

• COMP Sync

Status Meaning

Off (gray)

Blinking Green

Composite synchronization signal is not present or not detected.

Composite synchronization signal is detected.

18 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Advanced Adjustments

This section describes the following additional settings that you can control using the Graphics to SDI page:

• “Adjusting the Desktop Area” on page 19

• “Applying Gamma Correction” on page 21

Adjusting the Desktop Area

Instead of using the entire desktop, you can specify a region of the desktop to convert to SDI output as follows:

1 In the Desktop group box, click Change Desktop region.

The display property page minimizes and the SDI Output dialog box appears. Superimposed over the desktop is a rectangular outline that shows the region that will be used for SDI output.

HAPTER 3

Windows–Using the Graphics to SDI Control Panel

Figure 3.3

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 19

Desktop Region Adjustment

HAPTER 3

C Windows–Using the Graphics to SDI Control Panel

2 Click the Select Region to use option.

3 Adjust the region size.

• Click and drag within the rectangular outline to adjust the position on the desktop.

• Click and drag the appropriate corner or side grab handles to resize.

• You can also adjust the region by specifying the X, Y, Width, and Height values in

the SDI Output dialog box. Either enter pixel values directly into the corresponding text boxes or click the up and down arrows by the appropriate box.

Note: The X and Y values indicate the pixel distance of the upper left corner of the

output box from the upper left corner of the desktop.

4 Click OK when finished.

The desktop graphic image shows a thumbnail preview of the desktop region that you have set up for SDI output.

5 Click OK or Apply to put the settings into effect.

20 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Applying Gamma Correction

To specify the gamma correction to use for the source stream:

1 In the Desktop group box, click Adjust Gamma Correction.

The SDI Color Settings dialog box appears.

HAPTER 3

Windows–Using the Graphics to SDI Control Panel

2 Specify the RGB Gamma values using one or more of the following methods:.

• Click and drag the slider for the appropriate R, G, or B setting

• Specify the R, G, or B gamma value by entering a value in the text box or using the

up and down arrows.

• Click and drag the handle in the graphic.

• To keep all gamma channels at the same value while you adjust them

simultaneously, click the Lock all channels option.

3 Click OK when finished.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 21

HAPTER 3

C Windows–Using the Graphics to SDI Control Panel

Synchronizing the SDI Output to an External Source

You can synchronize the SDI output with other equipment in a broadcast or post production environment.

Genlock Versus Frame Lock

The Graphics to SDI page provides two methods for synchronizing the SDI output to a common sync source—Genlock and Frame lock.

Using Genlock

Genlock synchronizes the pixel scanning of the SDI output to an external synchronization source.

When using genlock, the SDI refresh rate is determined by the sync source, so any refresh rates that you may have chosen in the SDI signal format list do not apply.

Using Frame Lock

Frame lock synchronizes the frame rate of the SDI output to an external synchronization source.

When using frame lock, only modes that are valid for the frame rate of the sync source can be used for the SDI output. The valid modes will appear in the SDI signal format list.

Supported Synchronization Signals

NVIDIA Genlock supports the following external synchronization signal types:

•SDI

• Composite Bi-level (NTSC or PAL sources use bi-level composite signals.)

• Composite Tri-level (HDTV sources commonly use tri-level composite signals.)

22 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Synchronization Instructions

Basic Setup Summary

The following are the basic steps to synchronize the SDI output.

1 Connect the external sync source to the appropriate BNC connector on the graphics

card.

See “Understanding the Connections” on page 10 for instructions on connecting the external sync signal to the graphics card.

2 Configure the sync source.

Use the NVIDIA Graphics to SDI property page to configure the SDI output synchronization.

HAPTER 3

Windows–Using the Graphics to SDI Control Panel

Figure 3.4

a Click the Sync Options list arrow and then click either External genlock or External

framelock synchronizing modes.

b If you chose external frame lock synchronization, click the SDI signal format arrow

and then click the signal format you want to use.

Only those modes that are compatible with the detected sync signal will appear in the SDI signal format list.

c Click Apply.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 23

Graphics to SDI Page—Configuring an External Sync Source

HAPTER 3

C Windows–Using the Graphics to SDI Control Panel

Detecting the External Sync Signal Source

The software should automatically detect the external sync signal. When it does, the sync format information appears in the Genlock/Framelock format text box.

If you have both SDI and Composite signals connected -

• The software automatically chooses the SDI signal.

• If you want to switch to the composite signal, click the arrow in the Genlock/

Framelock format group box and then click COMP Sync.

If the software fails to automatically detect the signal -

• If the software loses the external sync signal or does not detect it

automatically, click the signal detect button to force detection of the sync signal.

• For composite signals, if the software is unable to automatically detect the correct

signal type–either bi-level or tri-level– click the Genlock/Framelock format list box arrow and then click the COMP option corresponding to your sync source.

24 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Adding a Delay to the Signal

You can introduce a slight delay in the genlocked or frame locked SDI output. For example, if delivery of video from other equipment is delayed because of greater cable length, you can introduce a delay in the SDI output from this card so that both deliveries are in sync. To introduce a synchronization delay:

1 Click Advanced Options from the Graphics to SDI page.

The SDI Advanced Options window appears.

HAPTER 3

Windows–Using the Graphics to SDI Control Panel

Figure 3.5

SDI Advanced Options Window

2 Click the Synchronization Delay tab.

Figure 3.6

Synchronization Delay Page

3 Introduce delays in the HSYNC and VSYNC signals as needed by clicking the

appropriate up and down arrows.

You can also enter values directly into the text boxes.

4 Click OK or Apply when finished.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 25

HAPTER 3

C Windows–Using the Graphics to SDI Control Panel

Viewing System Information

To view information about the graphics card and the installed driver software, click Advanced Options from the Graphics to SDI page.

The General tab shows the graphics card model, firmware version, driver version and current SDI resolution.‘

Figure 3.7

SDI Advanced Options—General tab

26 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Using SDI Under Dualview

In the default configuration, the SDI output is a clone of the display output. The NVIDIA Quadro FX 4500 SDI graphics card also supports Dualview mode, where the desktop extends across two monitors.

About Dualview Mode

Under Dualview mode, you can define one large desktop that extends from the display to the SDI output. This lets you move windows between the SDI output and the graphics (DVI) display part of the extended desktop.

With applications that use video overlay or Microsoft VMR, you can also display the video full-screen on the SDI output.

Area displayed on primary display Area displayed on the SDI output

HAPTER 3

Windows–Using the Graphics to SDI Control Panel

Use Full-Screen Video Mirror to present a video overlay or Microsoft VMR video full screen on the SDI output.

Windows can be dragged from one display to the other.

Figure 3.8

The display and the SDI output do not need to be the same resolution and refresh rate.

Refer to the document Dualview mode and the NVIDIA graphics drivers.

Extended Desktop with Dualview Mode

Quadro Workstation User’s Guide for more information regarding

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 27

HAPTER 3

C Windows–Using the Graphics to SDI Control Panel

How to Enable Dualview Mode

To enable Dualview mode:

1 Right-click the desktop, then from the pop-up menu, click Properties.

The Display Properties page appears.

2 From the Display Properties page, click the Settings tab.

The Settings page appears.

3 Click the monitor icon that is grayed (not attached) and then check the Extend my

Windows desktop onto this monitor check box.

4 Click OK or Apply.

The SDI settings last set in the Graphics to SDI control panel are preserved under Dualview mode.

28 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Windows–Using the Graphics to SDI Control Panel

Changing SDI Settings Under Dualview

To change the SDI settings once Dualview is enabled,

1 Open the Microsoft Display Properties Settings page as described in steps 1 and 2

above

2 Right-click Display #2, then from the pop-up menu click Properties.

3 Click the Quadro FX 4000/4500 SDI tab and then click the Graphics to SDI tree item

from the side menu.

You can now change the SDI settings for the 2nd display, or SDI output. Because Dualview is enabled, the Enable/Disable controls are not available and the panel says ʺSend SDI output to: NVIDIA SDIʺ.

HAPTER 3

Figure 3.9

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 29

Graphics to SDI Page with Dualview Enabled

HAPTER 3

C Windows–Using the Graphics to SDI Control Panel

30 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

INUX

—U

SING THE

HAPTER 4

Linux—Using the Graphics to Video Out Control Panel

C HAPTER

RAPHICS TO

IDEO

ONTROL

ANEL

This chapter explains how to set up the NVIDIA Quadro FX 4500 SDI graphics card under Linux using the NVIDIA Graphics to Video Out properties page

It contains the following sections:

• “How to Set Up the SDI Output” on page 32 provides step-by-step instructions for using the control panel to set up the SDI output.

• “Synchronizing the SDI Output to an External Source” on page 38 explains in more detail the genlock and frame lock features.

1. This method of controlling the SDI output is also known as ‘transparent mode’.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 31

HAPTER 4

C Linux—Using the Graphics to Video Out Control Panel

How to Set Up the SDI Output

Basic SDI Setup

To ensure proper operation, NVIDIA recommends the following -

• Set the desktop resolution to be the same or larger than the SDI output for better image quality

• Stop background applications—such as virus scan, backup and archiving applications—prior to starting SDI output and going on air.

• Close the control panel before going on air.

• When running multiple OpenGL applications, synchronize them, otherwise tearing may occur.

Step 1: Open the NVIDIA Graphics to Video Out Property Page

1 From the command line, enter “

The NVIDIA X Server Settings page appears.

Figure 4.1

2 Click the Graphics to Video Out tree item from the side menu.

NVIDIA X Server Settings Page

nvidia-settings

”

32 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Linux—Using the Graphics to Video Out Control Panel

The Graphics to Video Out page appears.

HAPTER 4

Figure 4.2

Graphics to Video Out Page

Step 2: Choose a Synchronization Method

From the Sync Options group box, click the Sync Mode list arrow and then click the method you want to use to synchronize the SDI output:

• Free Running: The SDI output will be synchronized with the timing chosen from the

SDI signal format list.

• Genlock: The SDI output will be synchronized with the external sync signal.

• Frame Lock: The SDI output will be synchronized with the timing chosen from the SDI

signal format list.

This list is limited to timings that can be synchronized with the detected external sync signal.

For more information regarding genlock and frame lock, see the section “Synchronizing

the SDI Output to an External Source” on page 38.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 33

HAPTER 4

C Linux—Using the Graphics to Video Out Control Panel

Step 3: Choose the Output Options

• Output Video Format controls the video resolution, field rate, and SMPTE signalling

standard for the outgoing video stream.

• Output Data Format controls the color model, data packing, and alpha or z

components in the outgoing video stream.

1 Specify the Output Video Format

From the Output Options group box, click the Output Video Format arrow and then click the signal format you want to use.

Note: Only those resolutions that your monitor supports appear in the Output Video

Format list. Your options for this setting also depend on which Sync option you chose in the previous step.

• If you chose

format. The list box will be grayed out, preventing you from choosing another format.

• If you chose

the detected sync signal will appear in the Output Video Format list.

genlock synchronization, the sync source controls the output video

frame lock synchronization, only those modes that are compatible with

2 Specify the Output Data Format

From the Output Options group box, click the Output Data Format arrow and then click the color format you want to use.

Step 4: Verify the Changes

The settings go into effect immediately.

The Graphics to SDI property page banner indicates the status of the SDI output as well as the external synchronization signals. Figure 4.3 shows the correlation between the indicators on the banner and the actual connectors.

Graphics to Video Out Banner

Quadro FX 4500 SDI Connectors

Figure 4.3

34 Quadro FX 4500 SDI User’s Guide– Version 1.0

Connection Status Indicators

NVIDIA Corporation

Linux—Using the Graphics to Video Out Control Panel

The activity of the LED graphics indicates the signal status as follows:

• Vid. 1 Out or Vid. 2 Out

Status Meaning

Off (gray)

Blinking Green

Blinking Yellow

SDI output is not in use

SDI output is active and is in HD mode.

SDI output is active and is in SD mode.

• SDI Sync

Status Meaning

Off (gray)

Blinking Green

Blinking Yellow

Steady Yellow

SDI synchronization signal is not present or not detected.

SDI synchronization signal is detected in HD mode.

SDI synchronization signal is detected in SD mode.

SDI synchronization error has occurred.

• COMP Sync

HAPTER 4

Status Meaning

Off (gray)

Blinking Green

Composite synchronization signal is not present or not detected.

Composite synchronization signal is detected.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 35

HAPTER 4

C Linux—Using the Graphics to Video Out Control Panel

Advanced Adjustments

This section describes the following additional settings that you can control using the Graphics to SDI page:

• “Adjusting the Desktop Area” on page 36

• “Customizing the Color Space Conversion” on page 37

Adjusting the Desktop Area

By default, the entire desktop is converted to SDI output. If the desktop is smaller than the size of the SDI output, it will be scaled to fit. If the desktop is larger than the SDI output, it will be cropped to fit. Instead of using the entire desktop, you can specify a region of the desktop to convert to SDI output as follows:

In the Region of Interest group box, adjust the region size by specifying the X Offset and Y Offset values. Either enter pixel values directly into the corresponding text boxes or click the up and down arrows by the appropriate box.

Note: The X and Y values indicate the pixel distance of the upper left corner of the output

box from the upper left corner of the desktop.

36 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Linux—Using the Graphics to Video Out Control Panel

Customizing the Color Space Conversion

To set your own RGB color space conversion:

1 Click the Color Space Conversion tree item from the side menu.

The Color Space Conversion page appears.

HAPTER 4

2 Check Override default Color Space Conversion.

3 Click the Initialize Color Space Conversion with list arrow and then click one of the

standards to use as a starting point: ITU-601, 709, 177, or Identity.

4 Either enter values directly in the text boxes or use the corresponding up and down

arrows to change any of the settings.

5 Click Apply to apply the settings.

To apply the settings as you change them, check Apply Changes Immediately.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 37

HAPTER 4

C Linux—Using the Graphics to Video Out Control Panel

Synchronizing the SDI Output to an External Source

You can synchronize the SDI output with other equipment in a broadcast or post production environment.

Genlock Versus Frame Lock

The Graphics to SDI page provides two methods for synchronizing the SDI output to a common sync source—Genlock and Frame lock.

Using Genlock

Genlock synchronizes the pixel scanning of the SDI output to an external synchronization source.

When using genlock, the SDI refresh rate is determined by the sync source, so any refresh rates that you may have chosen in the Output Video Format list do not apply.

Using Frame Lock

Frame lock synchronizes the frame rate of the SDI output to an external synchronization source.

When using frame lock, only modes that are valid for the frame rate of the sync source can be used for the SDI output. The valid modes will appear in the Output Video Format list.

Supported Synchronization Signals

NVIDIA Genlock supports the following external synchronization signal types:

•SDI

• Composite Bi-level (NTSC or PAL sources use bi-level composite signals.)

• Composite Tri-level (HDTV sources commonly use tri-level composite signals.)

38 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Synchronization Instructions

Basic Setup Summary

The following are the basic steps to synchronize the SDI output.

1 Connect the external sync source to the appropriate BNC connector on the graphics

card.

See “Understanding the Connections” on page 10 for instructions on connecting the external sync signal to the graphics card.

2 Configure the sync source.

a Open the Graphics to Video Out page and click Enable SDI Output.

HAPTER 4

Linux—Using the Graphics to Video Out Control Panel

Figure 4.4

a Click the Sync Mode list arrow and then click either Genlock or Framelock

synchronizing modes.

b If you chose frame lock synchronization, click the Output Video Format list arrow

and then click the signal format you want to use.

Only those modes that are compatible with the detected sync signal will appear in the SDI signal format list.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 39

Graphics to Video Out Page

HAPTER 4

C Linux—Using the Graphics to Video Out Control Panel

Detecting the External Sync Signal Source

The software should automatically detect the external sync signal. When it does, the sync format information appears in the Input Video Format text box.

If you have both SDI and Composite signals connected -

• The software automatically chooses the SDI signal.

• If you want to switch to the composite signal, click the Sync Format list arrow and

then click COMP Sync.

If the software fails to automatically detect the signal -

• If the software loses the external sync signal or does not detect it

automatically, click Detect to force detection of the sync signal.

• For composite signals, if the software is unable to automatically detect the correct

signal type–either bi-level or tri-level– click the Sync Format list arrow and then click the COMP option corresponding to your sync source.

40 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Adding a Delay to the Signal

1 Open the Graphics to Video Out page and click Enable SDI Output.

HAPTER 4

Linux—Using the Graphics to Video Out Control Panel

2 In the Synchronization Delay group box, introduce delays in the HSYNC and VSYNC

signals as needed by clicking the appropriate up and down arrows.

You can also enter values directly into the text boxes.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 41

HAPTER 4

C Linux—Using the Graphics to Video Out Control Panel

42 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

HAPTER 5

API Control

C HAPTER

API C

The SDI application programming interface allows OpenGL or Direct3D applications to have full and exclusive control of the SDI output. This method of controlling the SDI output is also known as extended mode.

This chapter gives a brief introduction to this method of implementing graphics to SDI, and includes the following sections:

• “SDI Application Programming Overview” on page 44

• “Windows XP NvGvo API Description” on page 45

• “Linux CONTROL X Extension API” on page 66

Refer to the following documents for additional information on using the APIs:

•

Programming the NVIDA Quadro FX 4000/4500 SDI

• The

NVGVOSDK , which can be obtained from NVIDIA.

ONTROL

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 43

HAPTER 5

C API Control

SDI Application Programming Overview

Application programming of the NVIDIA Quadro FX 4000/FX4500 SDI consists of two principle parts–device control and data transfer.

• Device control handles the hardware configuration as well as the starting and stopping

of data transfers.

This chapter covers the APIs related to data control.

• Data transfer is the sequence of operations that send graphics data to the video device

for output.

Under WindowsXP

• Device control is handled by the NvGvo API, described in this chapter.

• Data transfer operations are performed by the OpenGL extension

WGL_NV_video_out.

Under Linux

• Device control is handled by the NV-CONTROL X extension, described in this

chapter.

• Data transfer operations are performed by the OpenGL extension

GLX_NV_video_output.

44 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Windows XP NvGvo API Description

This section describes the NvGvo APIs inthe following sections:

• “NvGvo Function Description” on page 46

• “NvGvo Structures, Enumerations, and Defines” on page 53

Viewing the SDI Hardware Status

When the SDI output is under application control, you can use the NVIDIA Graphics to SDI property page to view the SDI hardware status.

To view the SDI status using the NVIDIA Graphics to SDI property page

1 Open the Windows Display Properties control panel, click Settings>Advanced, and

then click the Quadro FX 4500 tab to open the NVIDIA graphics card display properties page.

HAPTER 5

API Control

2 Click the Graphics to SDI tree item from the slide-out tray.

Figure 5.1

Graphics to SDI Page—Application Control

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 45

HAPTER 5

C API Control

NvGvo Function Description

Table 5.1

NvGvo Function Index

Call Description

NvGvoCaps()

NvGvoOpen()

NvGvoClose()

NvGvoDesktopOpen()

NvGvoDesktopClose()

NvGvoStatus()

NvGvoSyncFormatDetect()

NvGvoConfigGet()

NvGvoConfigSet()

NvGvoIsRunning()

NvGvoStart()

NvGvoStop()

NvGvoEnumSignalFormats()

NvGvoIsFrameLockModeCompatible()

NvGvoEnumDataFormats()

Determine the graphics-to-video capabilities of the graphics card.

Open the graphics card for graphics-to-video operations using the OpenGL application interface.

Close the graphics card for graphics-to-video operations using the OpenGL application interface.

Open the graphics cards for graphics-to-vVideo operations using the Desktop transparent mode interface.

Close the graphics cards for graphics-to-video operations using the Desktop transparent mode interface.

Get the graphics-to-video status.

Detect the video format of the iincoming sync signal.

Get the current graphics-to-video configuration.

Set the graphics-to-video configuration.

Determine if there is an SDI out video stream.

Start the SDI out video stream.

Stop the SDI out video stream.

Enumerate the supported SDI signal formats.

Verify whether a mode is compatible with frame lock mode.

Enumerate the supported SDI data formats.

NvGvoCaps()

//---------------------------------------------------------------------

// Function: NvGvoCaps

// Description: Determine graphics adapter Graphics to Video capabilities.

// Parameters: nAdapterNumber - Graphics adapter number

// nReserved - Reserved (must be set to zero)

// pAdapterCaps - Pointer to receive capabilities

// Returns: NV_OK - Success

// NV_NOTSUPPORTED - Graphics to Video not supported

//---------------------------------------------------------------------

46 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

NVRESULT NVAPIENTRY NvGvoCaps(UINT nAdapterNumber IN,

UINT nReserved IN,

NVGVOCAPS* pAdapterCaps OUT);

NvGvoOpen()

//---------------------------------------------------------------------

// Function: NvGvoOpen

// Description: Open graphics adapter for Graphics to Video operations

// using the OpenGL application interface. Read operations

// are permitted in this mode by multiple clients, but Write

// operations are application exclusive.

// Parameters: nAdapterNumber - Graphics adapter number

// nReserved - Reserved (must be set to zero)

// dwClass - Class interface (NVGVOCLASS_* value)

// dwAccessRights - Access rights (NVGVO_O_* mask)

// phGvoHandle - Pointer to receive handle

// Returns: NV_OK - Success

// NV_ACCESSDENIED - Access denied for requested access

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoOpen(UINT nAdapterNumber IN,

UINT nReserved IN,

DWORD dwClass IN,

DWORD dwAccessRights IN,

NVGVOHANDLE* phGvoHandle OUT);

HAPTER 5

API Control

NvGvoClose()

//---------------------------------------------------------------------

// Function: NvGvoClose

// Description: Closes graphics adapter for Graphics to Video operations

// using the OpenGL application interface. Closing an

// OpenGL handle releases the device.

// Parameters: hGvoHandle - Handle to graphics adapter

// Returns: NV_OK - Success

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoClose(NVGVOHANDLE hGvoHandle IN);

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 47

HAPTER 5

C API Control

NvGvoDesktopOpen()

//---------------------------------------------------------------------

// Function: NvGvoDesktopOpen

// Description: Open graphics adapter for Graphics to Video operations

// using the Desktop transparent mode interface. Read

// operations are permitted in this mode by multiple clients,

// but write operations are application exclusive.

// Parameters: nAdapterNumber - Graphics adapter number

// nReserved - Reserved (must be set to zero)

// dwClass - Class interface (NVGVOCLASS_* value)

// dwAccessRights - Access rights (NVGVO_O_* mask)

// phGvoHandle - Pointer to receive handle

// Returns: NV_OK - Success

// NV_ACCESSDENIED - Access denied for requested access

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoDesktopOpen(UINT nAdapterNumber IN,

UINT nReserved IN,

DWORD dwClass IN,

DWORD dwAccessRights IN,

NVGVOHANDLE* phGvoHandle OUT);

NvGvoDesktopClose()

//---------------------------------------------------------------------

// Function: NvGvoDesktopClose

// Description: Closes graphics adapter for Graphics to Video operations

// using the Desktop transparent mode interface.

// Parameters: hGvoHandle - Handle to graphics adapter

// bGvoRelease - TRUE to release device when handle closes

// FALSE to remain in desktop mode when handle

// closes (other clients can open using

// NvGvoDesktopOpen and release using

// NvGvoDesktopClose)

// Returns: NV_OK - Success

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoDesktopClose(NVGVOHANDLE hGvoHandle IN,

BOOL bRelease IN);

48 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

NvGvoStatus()

//---------------------------------------------------------------------

// Function: NvGvoStatus

// Description: Get Graphics to Video status.

// Parameters: hGvoHandle - Handle to graphics adapter

// Returns: NV_OK - Success

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoStatus(NVGVOHANDLE hGvoHandle IN,

NVGVOSTATUS* pStatus OUT);

NvGvoSyncFormatDetect()

//---------------------------------------------------------------------

// Function: NvGvoSyncFormatDetect

// Description: Detects Graphics to Video incoming sync video format.

// Parameters: hGvoHandle - Handle to graphics adapter

// pdwWait - Pointer to receive milliseconds to wait

// before NvGvoStatus will return detected

// syncFormat.

// Returns: NV_OK - Success

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoSyncFormatDetect(NVGVOHANDLE hGvoHandle IN,

DWORD* pdwWait OUT);

HAPTER 5

API Control

NvGvoConfigGet()

//---------------------------------------------------------------------

// Function: NvGvoConfigGet

// Description: Get Graphics to Video configuration.

// Parameters: hGvoHandle - Handle to graphics adapter

// pConfig - Pointer to Graphics to Video configuration

// Returns: NV_OK - Success

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoConfigGet(NVGVOHANDLE hGvoHandle IN,

NVGVOCONFIG* pConfig OUT);

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 49

HAPTER 5

C API Control

NvGvoConfigSet()

NvGvoIsRunning()

//---------------------------------------------------------------------

// Function: NvGvoConfigSet

// Description: Set Graphics to Video configuration.

// Parameters: hGvoHandle - Handle to graphics adapter

// pConfig - Pointer to Graphics to Video config

// Returns: NV_OK - Success

// NV_ACCESSDENIED - Access denied (no write access)

// NV_RUNNING - Requested settings require NvGvoStop

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoConfigSet(NVGVOHANDLE hGvoHandle IN,

const NVGVOCONFIG* pConfig IN);

//---------------------------------------------------------------------

// Function: NvGvoIsRunning

// Description: Determine if Graphics to Video output is running.

// Parameters: hGvoHandle - Handle to graphics adapter

// Returns: NV_RUNNING - Graphics-to-Video is running

// NV_NOTRUNNING - Graphics-to-Video is not running

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoIsRunning(NVGVOHANDLE hGvoHandle IN);

NvGvoStart()

//---------------------------------------------------------------------

// Function: NvGvoStart

// Description: Start Graphics to Video output.

// Parameters: hGvoHandle - Handle to graphics adapter

// Returns: NV_OK - Success

// NV_ACCESSDENIED - Access denied (no write access)

// NV_RUNNING - Graphics to Video already running

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoStart(NVGVOHANDLE hGvoHandle IN);

50 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

NvGvoStop()

//---------------------------------------------------------------------

// Function: NvGvoStop

// Description: Stop Graphics to Video output.

// Parameters: hGvoHandle - Handle to graphics adapter

// Returns: NV_OK - Success

// NV_ACCESSDENIED - Access denied (no write access)

// NV_NOTRUNNING - Graphics to Video not running

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoStop(NVGVOHANDLE hGvoHandle IN);

NvGvoEnumSignalFormats()

//---------------------------------------------------------------------

// Function: NvGvoEnumSignalFormats

// Description: Enumerate signal formats supported by Graphics to Video.

// Parameters: hGvoHandle - Handle to graphics adapter

// nEnumIndex - Enumeration index

// bByEnum - TRUE nEnumIndex is NVSIGNALFORMAT_*

// FALSE nEnumIndex is 0..n-1

// pSignalFormatDetail - Pointer to receive detail or NULL

// Returns: NV_OK - Success

// NV_NOMORE - No more signal formats to enumerate

// NV_NOTSUPPORTED - Unsupported NVSIGNALFORMAT_ enumeration

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoEnumSignalFormats(NVGVOHANDLE hGvoHandle IN,

int nEnumIndex IN,

BOOL bByEnum IN,

NVGVOSIGNALFORMATDETAIL* pSignalFormatDetail OUT);

HAPTER 5

API Control

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 51

HAPTER 5

C API Control

NvGvoIsFrameLockModeCompatible()

//---------------------------------------------------------------------

// Function: NvGvoIsFrameLockModeCompatible

// Description: Checks whether modes are compatible in framelock mode

// Parameters: hGvoHandle - Handle to graphics adapter

// nSrcEnumIndex - Source Enumeration index

// nDestEnumIndex - Destination Enumeration index

// pbCompatible - Pointer to receive compatability

// Returns: NV_OK - Success

// NV_NOTSUPPORTED - Unsupported NVSIGNALFORMAT_ enumeration

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoIsFrameLockModeCompatible(NVGVOHANDLE hGvoHandle IN,

int nSrcEnumIndex IN,

int nDestEnumIndex IN,

BOOL* pbCompatible OUT);

NvGvoEnumDataFormats()

//---------------------------------------------------------------------

// Function: NvGvoEnumDataFormats

// Description: Enumerate data formats supported by Graphics to Video.

// Parameters: hGvoHandle - Handle to graphics adapter

// nEnumIndex - Enumeration index

// bByEnum - TRUE nEnumIndex is NVDATAFORMAT_*

// FALSE nEnumIndex is 0..n-1

// pDataFormatDetail - Pointer to receive detail or NULL

// Returns: NV_OK - Success

// NV_NOMORE - No more data formats to enumerate

// NV_NOTSUPPORTED - Unsupported NVDATAFORMAT_ enumeration

//---------------------------------------------------------------------

NVRESULT NVAPIENTRY NvGvoEnumDataFormats(NVGVOHANDLE hGvoHandle IN,

int nEnumIndex IN,

BOOL bByEnum IN,

NVGVODATAFORMATDETAIL* pDataFormatDetail OUT);

52 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

NvGvo Structures, Enumerations, and Defines

Miscellaneous Defines

typedef UINT NVGVOHANDLE; // Handle from NvGvoOpen() or NvGvoDesktopOpen()

#define INVALID_NVGVOHANDLE 0 // Invalid NVGVOHANDLE

typedef DWORD NVGVOOWNERID; // Unique identifier for owner of Graphics to

Video output (process identifier or

NVGVOOWNERID_NONE)

#define NVGVOOWNERID_NONE 0 // Unregistered ownerId

enum NVGVOOWNERTYPE // Owner type for device

{

NVGVOOWNERTYPE_NONE , // No owner for device

NVGVOOWNERTYPE_OPENGL , // OpenGL application owns device

NVGVOOWNERTYPE_DESKTOP , // Desktop transparent mode owns device

HAPTER 5

API Control

// Access rights for NvGvoOpen() or NvGvoDesktopOpen()

#define NVGVO_O_READ 0x00000000 // Read access

#define NVGVO_O_WRITE_EXCLUSIVE 0x00010001 // Write exclusive access

Video Signal Format and Resolution Enumeration

enum NVGVOSIGNALFORMAT

{

NVGVOSIGNALFORMAT_ERROR = -1 , // Invalid signal format

NVGVOSIGNALFORMAT_487I_5994_SMPTE259_NTSC , // 01 487i 59.94Hz (SMPTE259)

NTSC

NVGVOSIGNALFORMAT_576I_5000_SMPTE259_PAL , // 02 576i 50.00Hz (SMPTE259)

PAL

NVGVOSIGNALFORMAT_720P_5994_SMPTE296 , // 03 720p 59.94Hz (SMPTE296)

NVGVOSIGNALFORMAT_720P_6000_SMPTE296 , // 04 720p 60.00Hz (SMPTE296)

NVGVOSIGNALFORMAT_1035I_5994_SMPTE260 , // 05 1035i 59.94Hz (SMPTE260)

NVGVOSIGNALFORMAT_1035I_6000_SMPTE260 , // 06 1035i 60.00Hz (SMPTE260)

NVGVOSIGNALFORMAT_1080I_5000_SMPTE295 , // 07 1080i 50.00Hz (SMPTE295)

NVGVOSIGNALFORMAT_1080I_5000_SMPTE274 , // 08 1080i 50.00Hz (SMPTE274)

NVGVOSIGNALFORMAT_1080I_5994_SMPTE274 , // 09 1080 59.94Hz (SMPTE274)

NVGVOSIGNALFORMAT_1080I_6000_SMPTE274 , // 10 1080i 60.00Hz (SMPTE274)

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 53

HAPTER 5

C API Control

NVGVOSIGNALFORMAT_1080PSF_23976_SMPTE274 , // 11 1080PsF 23.976Hz (SMPTE274)

NVGVOSIGNALFORMAT_1080PSF_2400_SMPTE274 , // 12 1080PsF 24.00Hz (SMPTE274)

NVGVOSIGNALFORMAT_1080PSF_2500_SMPTE274 , // 13 1080PsF 25.00Hz (SMPTE274)

NVGVOSIGNALFORMAT_1080PSF_3000_SMPTE274 , // 14 1080PsF 30.00Hz (SMPTE274)

NVGVOSIGNALFORMAT_1080P_23976_SMPTE274 , // 15 1080p 23.976Hz (SMPTE274)

NVGVOSIGNALFORMAT_1080P_2400_SMPTE274 , // 16 1080p 24.00Hz (SMPTE274)

NVGVOSIGNALFORMAT_1080P_2500_SMPTE274 , // 17 1080p 25.00Hz (SMPTE274)

NVGVOSIGNALFORMAT_1080P_2997_SMPTE274 , // 18 1080p 29.97Hz (SMPTE274)

NVGVOSIGNALFORMAT_1080P_3000_SMPTE274 , // 19 1080p 30.00Hz (SMPTE274)

NVGVOSIGNALFORMAT_1080PSF_2997_SMPTE274 , // 20 1080PsF 29.97Hz (SMPTE274)

NVGVOSIGNALFORMAT_720P_5000_SMPTE296 , // 21 720p 50.00Hz (SMPTE296)

NVGVOSIGNALFORMAT_720P_3000_SMPTE296 , // 22 720p 30.00Hz (SMPTE296)

NVGVOSIGNALFORMAT_720P_2997_SMPTE296 , // 23 720p 29.97Hz (SMPTE296)

NVGVOSIGNALFORMAT_720P_2500_SMPTE296 , // 24 720p 25.00Hz (SMPTE296)

NVGVOSIGNALFORMAT_720P_2400_SMPTE296 , // 25 720p 24.00Hz (SMPTE296)

NVGVOSIGNALFORMAT_720P_2398_SMPTE296 , // 26 720p 23.98Hz (SMPTE296)

NVGVOSIGNALFORMAT_1080I_4800_SMPTE274 , // 27 1080i 48.00Hz (SMPTE296)

NVGVOSIGNALFORMAT_1080I_4796_SMPTE274 , // 28 1080i 47.96Hz (SMPTE296)

NVGVOSIGNALFORMAT_1080PSF_2398_SMPTE274 , // 29 1080PsF 23.98Hz (SMPTE296)

NVGVOSIGNALFORMAT_2048P_3000_SMPTE372 , // 30 2048P 30.00Hz (SMPTE372)

NVGVOSIGNALFORMAT_2048P_2997_SMPTE372 , // 31 2048P 29.97Hz (SMPTE372)

NVGVOSIGNALFORMAT_2048I_6000_SMPTE372 , // 32 2048I 60.00Hz (SMPTE372)

NVGVOSIGNALFORMAT_2048I_5994_SMPTE372 , // 33 2048I 59.94Hz (SMPTE372)

NVGVOSIGNALFORMAT_2048P_2500_SMPTE372 , // 34 2048P 25.00Hz (SMPTE372)

NVGVOSIGNALFORMAT_2048I_5000_SMPTE372 , // 35 2048I 50.00Hz (SMPTE372)

NVGVOSIGNALFORMAT_2048P_2400_SMPTE372 , // 36 2048P 24.00Hz (SMPTE372)

NVGVOSIGNALFORMAT_2048I_4800_SMPTE372 , // 37 2048I 48.00Hz (SMPTE372)

NVGVOSIGNALFORMAT_2048P_2398_SMPTE372 , // 38 2048P 23.98Hz (SMPTE372)

NVGVOSIGNALFORMAT_2048I_4796_SMPTE372 , // 39 2048I 23.98Hz (SMPTE372)

NVGVOSIGNALFORMAT_END // 40 To indicate end of signal

format list

};

54 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

SMPTE Standards Format Enumeration

enum NVVIDEOSTANDARD

{

NVVIDEOSTANDARD_SMPTE259 , // SMPTE259

NVVIDEOSTANDARD_SMPTE260 , // SMPTE260

NVVIDEOSTANDARD_SMPTE274 , // SMPTE274

NVVIDEOSTANDARD_SMPTE295 , // SMPTE295

NVVIDEOSTANDARD_SMPTE296 , // SMPTE296

NVVIDEOSTANDARD_SMPTE372 , // SMPTE372

};

HD or SD Video Type Enumeration

enum NVVIDEOTYPE

{

NVVIDEOTYPE_SD , // Standard-definition (SD)

NVVIDEOTYPE_HD , // High-definition (HD)

};

HAPTER 5

API Control

Interlace Mode Enumeration

enum NVINTERLACEMODE

{

NVINTERLACEMODE_PROGRESSIVE , // Progressive (p)

NVINTERLACEMODE_INTERLACE , // Interlace (i)

NVINTERLACEMODE_PSF , // Progressive Segment Frame (psf)

};

Video Data Format Enumeration

enum NVGVODATAFORMAT

{

NVGVODATAFORMAT_R8G8B8_TO_YCRCB444 , // R8:G8:B8 => YCrCb (4:4:4)

NVGVODATAFORMAT_R8G8B8A8_TO_YCRCBA4444 , // R8:G8:B8:A8 => YCrCbA (4:4:4:4)

NVGVODATAFORMAT_R8G8B8Z10_TO_YCRCBZ4444 , // R8:G8:B8:Z10 => YCrCbZ (4:4:4:4)

NVGVODATAFORMAT_R8G8B8_TO_YCRCB422 , // R8:G8:B8 => YCrCb (4:2:2)

NVGVODATAFORMAT_R8G8B8A8_TO_YCRCBA4224 , // R8:G8:B8:A8 => YCrCbA (4:2:2:4)

NVGVODATAFORMAT_R8G8B8Z10_TO_YCRCBZ4224 , // R8:G8:B8:Z10 => YCrCbZ (4:2:2:4)

NVGVODATAFORMAT_R8G8B8_TO_RGB444 , // R8:G8:B8 => RGB (4:4:4)

NVGVODATAFORMAT_R8G8B8A8_TO_RGBA4444 , // R8:G8:B8:A8 => RGBA (4:4:4:4)

NVGVODATAFORMAT_R8G8B8Z10_TO_RGBZ4444 , // R8:G8:B8:Z10 => RGBZ (4:4:4:4)

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 55

HAPTER 5

C API Control

Video Output Area Enumeration

NVGVODATAFORMAT_Y10CR10CB10_TO_YCRCB444 , // Y10:CR10:CB10 => YCrCb (4:4:4)

NVGVODATAFORMAT_Y10CR8CB8_TO_YCRCB444 , // Y10:CR8:CB8 => YCrCb (4:4:4)

NVGVODATAFORMAT_Y10CR8CB8A10_TO_YCRCBA4444 , // Y10:CR8:CB8:A10

=> YCrCbA (4:4:4:4)

NVGVODATAFORMAT_Y10CR8CB8Z10_TO_YCRCBZ4444 , // Y10:CR8:CB8:Z10

=> YCrCbZ (4:4:4:4)

NVGVODATAFORMAT_DUAL_R8G8B8_TO_DUAL_YCRCB422 , // R8:G8:B8 + R8:G8:B8

=> YCrCb (4:2:2 + 4:2:2)

NVGVODATAFORMAT_DUAL_Y8CR8CB8_TO_DUAL_YCRCB422 , // Y8:CR8:CB8 + Y8:CR8:CB8

=> YCrCb (4:2:2 + 4:2:2)

NVGVODATAFORMAT_R10G10B10_TO_YCRCB422 , // R10:G10:B10 => YCrCb (4:2:2)

NVGVODATAFORMAT_R10G10B10_TO_YCRCB444 , // R10:G10:B10 => YCrCb (4:4:4)

NVGVODATAFORMAT_Y12CR12CB12_TO_YCRCB444 , // Y12:CR12:CB12 => YCrCb (4:4:4)

NVGVODATAFORMAT_Y12CR12CB12_TO_YCRCB422 , // Y12:CR12:CB12 => YCrCb (4:2:2)

};

enum NVGVOOUTPUTAREA

{

NVGVOOUTPUTAREA_FULLSIZE , // Output to entire video resolution

(full size)

NVGVOOUTPUTAREA_SAFEACTION , // Output to centered 90% of video resolution

(safe action)

NVGVOOUTPUTAREA_SAFETITLE , // Output to centered 80% of video resolution

(safe title)

};

Synchronization Source Enumeration

enum NVGVOSYNCSOURCE

{

NVGVOSYNCSOURCE_SDISYNC , // SDI Sync (Digital input)

NVGVOSYNCSOURCE_COMPSYNC , // COMP Sync (Composite input)

};

Composite Synchronization Type Enumeration

enum NVGVOCOMPSYNCTYPE

{

NVGVOCOMPSYNCTYPE_AUTO , // Auto-detect

NVGVOCOMPSYNCTYPE_BILEVEL , // Bi-level signal

56 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

NVGVOCOMPSYNCTYPE_TRILEVEL , // Tri-level signal

};

Video Output Status Enumeration

enum NVGVOOUTPUTSTATUS

{

NVGVOOUTPUTSTATUS_OFF , // Output not in use

NVGVOOUTPUTSTATUS_ERROR , // Error detected

NVGVOOUTPUTSTATUS_SDI_SD , // SDI output (standard-definition)

NVGVOOUTPUTSTATUS_SDI_HD , // SDI output (high-definition)

};

Synchronization Input Status Enumeration

enum NVGVOSYNCSTATUS

{

NVGVOSYNCSTATUS_OFF , // Sync not detected

NVGVOSYNCSTATUS_ERROR , // Error detected

NVGVOSYNCSTATUS_SYNCLOSS , // Genlock in use, format mismatch with output

NVGVOSYNCSTATUS_COMPOSITE , // Composite sync

NVGVOSYNCSTATUS_SDI_SD , // SDI sync (standard-definition)

NVGVOSYNCSTATUS_SDI_HD , // SDI sync (high-definition)

};

HAPTER 5

API Control

Device Capabilities Defines

#define NVGVOCAPS_VIDOUT_SDI 0x00000001 // Supports Serial Digital Interface

(SDI) output

#define NVGVOCAPS_SYNC_INTERNAL 0x00000100 // Supports Internal timing source

#define NVGVOCAPS_SYNC_GENLOCK 0x00000200 // Supports Genlock timing source

#define NVGVOCAPS_SYNCSRC_SDI 0x00001000 // Supports Serial Digital Interface

(SDI) synchronization input

#define NVGVOCAPS_SYNCSRC_COMP 0x00002000 // Supports Composite

synchronization input

#define NVGVOCAPS_OUTPUTMODE_DESKTOP 0x00010000 // Supports Desktop

transparent mode

#define NVGVOCAPS_OUTPUTMODE_OPENGL 0x00020000 // Supports OpenGL

application mode

#define NVGVOCLASS_SDI 0x00000001 // SDI-class interface:

SDI output with two genlock inputs

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 57

HAPTER 5

C API Control

Device Capabilities Structure

typedef struct tagNVGVOCAPS

{

WORD cbSize; // Caller sets to sizeof(NVGVOCAPS)

char szAdapterName[NVADAPTERNAME_MAXLEN]; // Graphics adapter name

DWORD dwClass; // Graphics adapter classes (NGVOCLASS_* mask)

DWORD dwCaps; // Graphics adapter capabilities (NVGVOCAPS_* mask)

DWORD dwDipSwitch; // On-board DIP switch settings bits

DWORD dwDipSwitchReserved; // On-board DIP switch settings reserved bits

struct //

{ // Driver version

WORD wMajorVersion; // Major version

WORD wMinorVersion; // Minor version

WORD wRevision; // Revision

WORD wBuild; // Build

} Driver; //

struct //

{ // Firmware version

WORD wMajorVersion; // Major version

WORD wMinorVersion; // Minor version

} Firmware; //

NVGVOOWNERID ownerId; // Unique identifier for owner of video

output (NVGVOOWNERID_NONE if free running)

NVGVOOWNERTYPE ownerType; // Owner type for video output

(OpenGL application or Desktop mode)

} NVGVOCAPS;

Device Status Structure

typedef struct tagNVGVOSTATUS

{

WORD cbSize; // Caller sets to sizeof(NVGVOSTATUS)

NVGVOOUTPUTSTATUS vid1Out; // Video 1 output status

NVGVOOUTPUTSTATUS vid2Out; // Video 2 output status

NVGVOSYNCSTATUS sdiSyncIn; // SDI sync input status

NVGVOSYNCSTATUS compSyncIn; // Composite sync input status

BOOL syncEnable; // Sync enable (TRUE if using syncSource)

NVGVOSYNCSOURCE syncSource; // Sync source

NVGVOSIGNALFORMAT syncFormat; // Sync format

NVGVOOWNERID ownerId; // Unique identifier for owner of video output

58 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

NVGVOOWNERTYPE ownerType; // Owner type for video output

(OpenGL application or Desktop mode)

BOOL bframeLockEnable; // Framelock enable flag

BOOL bOutputVideoLocked; // Output locked status

int nDataIntegrityCheckErrorCount; // Data integrity check error count

BOOL bDataIntegrityCheckEnabled; // Data integrity check status enabled

BOOL bDataIntegrityCheckFailed; // Data integrity check status failed

} NVGVOSTATUS;

Output Region Structure

typedef struct tagNVGVOOUTPUTREGION

{

WORD x; // Horizontal origin in pixels

WORD y; // Vertical origin in pixels

WORD width; // Width of region in pixels

WORD height; // Height of region in pixels

} NVGVOOUTPUTREGION;

HAPTER 5

API Control

Gamma Ramp (8-bit Index) Structure

typedef struct tagNVGAMMARAMP8

{

WORD cbSize; // Caller sets to sizeof(NVGAMMARAMP8)

WORD wRed[256]; // Red channel gamma ramp

(8-bit index, 16-bit values)

WORD wGreen[256]; // Green channel gamma ramp

(8-bit index, 16-bit values)

WORD wBlue[256]; // Blue channel gamma ramp

(8-bit index, 16-bit values)

} NVGAMMARAMP8;

Gamma Ramp (10-bit Index) Structure

typedef struct tagNVGAMMARAMP10

{

WORD cbSize; // Caller sets to sizeof(NVGAMMARAMP10)

WORD wRed[1024]; // Red channel gamma ramp

(10-bit index, 16-bit values)

WORD wGreen[1024]; // Green channel gamma ramp

(10-bit index, 16-bit values)

WORD wBlue[1024]; // Blue channel gamma ramp

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 59

HAPTER 5

C API Control

Sync Delay Structure

Video Mode Information Structure

(10-bit index, 16-bit values)

} NVGAMMARAMP10;

typedef struct tagNVGVOSYNCDELAY

{

WORD wHorizontalDelay; // Horizontal delay in pixels

WORD wVerticalDelay; // Vertical delay in lines

} NVGVOSYNCDELAY;

typedef struct tagNVVIDEOMODE

{

DWORD dwHorizontalPixels; // Horizontal resolution (in pixels)

DWORD dwVerticalLines; // Vertical resolution for frame (in lines)

NVFLOAT fFrameRate; // Frame rate

NVINTERLACEMODE interlaceMode; // Interlace mode

NVVIDEOSTANDARD videoStandard; // SMPTE standards format

NVVIDEOTYPE videoType; // HD or SD signal classification

} NVVIDEOMODE;

Signal Format Details Structure

typedef struct tagNVGVOSIGNALFORMATDETAIL

{

WORD cbSize; // Caller sets to

sizeof(NVGVOSIGNALFORMATDETAIL)

NVGVOSIGNALFORMAT signalFormat; // Signal format enumerated value

char szValueName[NVVALUENAME_MAXLEN];

// Signal format name, in the form:

// <name>\t<rate>\tHz\t(<standard>)[\t<description>]

// "480i\t59.94\tHz\t(SMPTE259)\tNTSC"

// "1080i\t50.00\tHz\t(SMPTE274)"

char szAlternateName[NVVALUENAME_MAXLEN];

// Signal format alternate name (or empty string):

// "1080PsF\t25.00\tHz\t(SMPTE274)"

NVVIDEOMODE videoMode; // Video mode for signal format

} NVGVOSIGNALFORMATDETAIL;

60 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

P-Buffer Format Defines

#define NVGVOPBUFFERFORMAT_R8G8B8 0x00000001 // R8:G8:B8

#define NVGVOPBUFFERFORMAT_R8G8B8Z24 0x00000002 // R8:G8:B8:Z24

#define NVGVOPBUFFERFORMAT_R8G8B8A8 0x00000004 // R8:G8:B8:A8

#define NVGVOPBUFFERFORMAT_R8G8B8A8Z24 0x00000008 // R8:G8:B8:A8:Z24

#define NVGVOPBUFFERFORMAT_R16FPG16FPB16FP 0x00000010 // R16FP:G16FP:B16FP

#define NVGVOPBUFFERFORMAT_R16FPG16FPB16FPZ24 0x00000020

// R16FP:G16FP:B16FP:Z24

#define NVGVOPBUFFERFORMAT_R16FPG16FPB16FPA16FP 0x00000040

// R16FP:G16FP:B16FP:A16FP

#define NVGVOPBUFFERFORMAT_R16FPG16FPB16FPA16FPZ24 0x00000080

// R16FP:G16FP:B16FP:A16FP:Z24

Data Format Details Structure

typedef struct tagNVGVODATAFORMATDETAIL

{

WORD cbSize; // Caller sets to

sizeof(NVGVODATAFORMATDETAIL)

NVGVODATAFORMAT dataFormat; // Data format enumerated value

DWORD dwCaps; // Data format capabilities

(NVGVOCAPS_* mask)

struct

{

DWORD dwPbufferFormats; // Supported p-buffer formats

(NVGVOPBUFFERFORMAT_* mask)

DWORD dwPbufferCount; // Number of p-buffers

char szValueName[NVVALUENAME_MAXLEN];

// Data format input name, in the form:

// <name>

// "R8:G8:B8:A8"

} in;

struct

{

char szValueName[NVVALUENAME_MAXLEN];

// Data format output name, in the form:

// <name>\t<format>

// "YCrCbA\t(4:2:2:4)"

} out;

} NVGVODATAFORMATDETAIL;

HAPTER 5

API Control

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 61

HAPTER 5

C API Control

Device Configuration Defines

These are

Test/CreateDefaultConfig()

#define NVGVOCONFIG_SIGNALFORMAT 0x00000001 // dwFields: signalFormat

#define NVGVOCONFIG_DATAFORMAT 0x00000002 // dwFields: dataFormat

#define NVGVOCONFIG_OUTPUTREGION 0x00000004 // dwFields: outputRegion

#define NVGVOCONFIG_OUTPUTAREA 0x00000008 // dwFields: outputArea

#define NVGVOCONFIG_COLORCONVERSION 0x00000010 // dwFields: colorConversion

#define NVGVOCONFIG_GAMMACORRECTION 0x00000020 // dwFields: gammaCorrection

#define NVGVOCONFIG_SYNCSOURCEENABLE 0x00000040 // dwFields: syncSource and syncEnable

#define NVGVOCONFIG_SYNCDELAY 0x00000080 // dwFields: syncDelay

#define NVGVOCONFIG_COMPOSITESYNCTYPE 0x00000100 // dwFields:

compositeSyncType

#define NVGVOCONFIG_FRAMELOCKENABLE 0x00000200 // dwFields: EnableFramelock

#define NVGVOCONFIG_422FILTER 0x00000400 // dwFields: bEnable422Filter

#define NVGVOCONFIG_COMPOSITETERMINATE 0x00000800 // dwFields:

bCompositeTerminate

#define NVGVOCONFIG_DATAINTEGRITYCHECK 0x00001000 // dwFields:

bEnableDataIntegrityCheck

#define NVGVOCONFIG_CSCOVERRIDE 0x00002000 // dwFields:

colorConversion override

#define NVGVOCONFIG_ALLFIELDS ( NVGVOCONFIG_SIGNALFORMAT | \

NVGVOCONFIG_DATAFORMAT | \

NVGVOCONFIG_OUTPUTREGION | \

NVGVOCONFIG_OUTPUTAREA | \

NVGVOCONFIG_COLORCONVERSION | \

NVGVOCONFIG_GAMMACORRECTION | \

NVGVOCONFIG_SYNCSOURCEENABLE | \

NVGVOCONFIG_SYNCDELAY | \

NVGVOCONFIG_COMPOSITESYNCTYPE | \

NVGVOCONFIG_FRAMELOCKENABLE | \

NVGVOCONFIG_422FILTER | \

NVGVOCONFIG_COMPOSITETERMINATE | \

NVGVOCONFIG_DATAINTEGRITYCHECK | \

NVGVOCONFIG_CSCOVERRIDE)

dwFields

masks indicating NVGVOCONFIG fields to use for

NvGvoGet/Set/

62 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

Device Configuration Structure

typedef struct tagNVGVOCONFIG

{

WORD cbSize; // Caller sets to sizeof(NVGVOCONFIG)

DWORD dwFields; // Caller sets to NVGVOCONFIG_* mask for fields to use

NVGVOSIGNALFORMAT signalFormat; // Signal format for video output

NVGVODATAFORMAT dataFormat; // Data format for video output

NVGVOOUTPUTREGION outputRegion; // Region for video output (Desktop mode)

NVGVOOUTPUTAREA outputArea; // Usable resolution for video output (safe area)

struct // Color conversion:

// Output[n] = Input[0] * colorMatrix[n][0] +

// Input[1] * colorMatrix[n][1] + Input[2] *

// colorMatrix[n][2] + OutputRange * colorOffset[n]

// Where OutputRange is the standard magnitude of

// Output[n][n] and colorMatrix and colorOffset values are

// within the range -1.0 to +1.0

HAPTER 5

API Control

{ //

NVFLOAT colorMatrix[3][3];

NVFLOAT colorOffset[3]; //

NVFLOAT colorScale[3]; //

BOOL bCompositeSafe; // bCompositeSafe constrains luminance

range when using composite output

} colorConversion; //

union // Gamma correction:

{ // cbSize field in gammaRamp describes type

NVGAMMARAMP8 gammaRamp8; // Gamma ramp (8-bit index, 16-bit values)

NVGAMMARAMP10 gammaRamp10; // Gamma ramp (10-bit index, 16-bit values)

} gammaCorrection;

BOOL syncEnable; // Sync enable (TRUE to use syncSource)

NVGVOSYNCSOURCE syncSource; // Sync source

NVGVOSYNCDELAY syncDelay; // Sync delay

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 63

HAPTER 5

C API Control

NVGVOCOMPSYNCTYPE compositeSyncType; // Composite sync type

BOOL frameLockEnable; // Flag indicating whether framelock

was on/off

double fGammaValueR; // Red Gamma value within gamma

ranges. 0.5 - 6.0

double fGammaValueG; // Green Gamma value within gamma

ranges. 0.5 - 6.0

double fGammaValueB; // Blue Gamma value within gamma

ranges. 0.5 - 6.0

BOOL bPSFSignalFormat; // Indicates whether contained format

is PSF Signal format

BOOL bEnable422Filter; // Enables/Disables 4:2:2 filter

BOOL bCompositeTerminate; // Composite termination

BOOL bEnableDataIntegrityCheck; // Enable data integrity check:

// true - enable, false - disable

BOOL bCSCOverride; // Use provided CSC color matrix to

overwrite

BYTE reservedData[256]; // Indicates last stored SDI output

state TRUE-ON / FALSE-OFF

} NVGVOCONFIG;

Device Configuration–Revision 0 Structure

typedef struct tagNVGVOCONFIG_REV_0

{

WORD cbSize; // Caller sets to sizeof(NVGVOCONFIG)

DWORD dwFields; // Caller sets to NVGVOCONFIG_* mask for fields to use

NVGVOSIGNALFORMAT signalFormat; // Signal format for video output

NVGVODATAFORMAT dataFormat; // Data format for video output

NVGVOOUTPUTREGION outputRegion; // Region for video output (Desktop mode)

NVGVOOUTPUTAREA outputArea; // Usable resolution for video output (safe area)

struct // Color conversion:

// Output[n] = Input[0] * colorMatrix[n][0] + Input[1] *

// colorMatrix[n][1] + Input[2] * colorMatrix[n][2] +

// OutputRange * colorOffset[n]

// Where OutputRange is the standard magnitude of

// Output[n][n] and colorMatrix and colorOffset

// values are within the range -1.0 to +1.0

64 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

HAPTER 5

API Control

{ //

NVFLOAT colorMatrix[3][3]; //

NVFLOAT colorOffset[3]; //

BOOL bCompositeSafe; // bCompositeSafe constrains luminance

range when using composite output

} colorConversion; //

union // Gamma correction:

{ // cbSize field in gammaRamp describes type

NVGAMMARAMP8 gammaRamp8; // Gamma ramp (8-bit index, 16-bit values)

NVGAMMARAMP10 gammaRamp10; // Gamma ramp (10-bit index, 16-bit values)

} gammaCorrection;

BOOL syncEnable; // Sync enable

(TRUE to use syncSource)

NVGVOSYNCSOURCE syncSource; // Sync source

NVGVOSYNCDELAY syncDelay; // Sync delay

NVGVOCOMPSYNCTYPE compositeSyncType; // Composite sync type

BOOL frameLockEnable; // Flag indicating whether framelock

was on/off

double fGammaValueR; // Red Gamma value within gamma

ranges. 0.5 - 6.0

double fGammaValueG; // Green Gamma value within gamma

ranges. 0.5 - 6.0

double fGammaValueB; // Blue Gamma value within gamma

ranges. 0.5 - 6.0

BOOL bPSFSignalFormat; // Indicates whether contained format

is PSF Signal format

BYTE reservedData[256]; // Indicates last stored SDI output

state TRUE-ON / FALSE-OFF

} NVGVOCONFIG_REV_0;

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 65

HAPTER 5

C API Control

Linux CONTROL X Extension API

This section describes the NvGvo APIs inthe following sections:

• “Using the NV-CTRL X APIs” on page 66

• “NV_CTRL_GVO Attributes” on page 67

• “NV-Control X Functions” on page 76

Using the NV-CTRL X APIs

The NV_CTRL_GVO* integer attributes are used to configure GVO (graphics to video out) functionality on the Quadro FX 4500 SDI graphics board.

The following is a typical usage pattern for the GVO attributes:

• Query NV_CTRL_GVO_SUPPORTED to determine if the X screen supports GV0.

• Specify NV_CTRL_GVO_SYNC_MODE (either FREE_RUNNING, GENLOCK, or

FRAMELOCK).

If you specify GENLOCK or FRAMELOCK, you should also specify

NV_CTRL_GVO_SYNC_SOURCE.

• Use NV_CTRL_GVO_SYNC_INPUT_DETECTED and

NV_CTRL_GVO_SDI_SYNC_INPUT_DETECTED to detect what input syncs are present.

If no analog sync is detected but it is known that a valid bi-level or tri-level sync is connected, set NV_CTRL_GVO_COMPOSITE_SYNC_INPUT_DETECT_MODE appropriately and retest with

NV_CTRL_GVO_COMPOSITE_SYNC_INPUT_DETECTED.

• If syncing to input sync, query theNV_CTRL_GVO_INPUT_VIDEO_FORMAT

attribute.

The input video format can only be queried after SYNC_SOURCE is specified.

• Specify the NV_CTRL_GVO_OUTPUT_VIDEO_FORMAT.

• Specify the NV_CTRL_GVO_DATA_FORMAT.

• Specify any custom Color Space Conversion (CSC) matrix, offset, and scale with

XNVCTRLSetGvoColorConversion().

• If using the GLX_NV_video_out extension to display one or more pbuffers, call

glXGetVideoDeviceNV() to lock the GVO output for use by the GLX client, then bind the pbuffer(s) to the GVO output with glXBindVideoImageNV() and send pbuffers to the GVO output with glXSendPbufferToVideoNV().

See the GLX_NV_video_out spec for more details.

66 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

• If, rather than using the GLX_NV_video_out extension to display GLX pbuffers on

the GVO output, you wish display the X screen on the GVO output, set

NV_CTRL_GVO_DISPLAY_X_SCREEN to

NV_CTRL_GVO_DISPLAY_X_SCREEN_ENABLE.

• Setting most GVO attributes only causes the value to be cached in the X server.

The values will be flushed to the hardware either when

NV_CTRL_GVO_DISPLAY_X_SCREEN is enabled, or when a GLX pbuffer is bound to

the GVO output (with glXBindVideoImageNV()).

• GLX_NV_video_out and NV_CTRL_GVO_DISPLAY_X_SCREEN are mutually exclusive.

If NV_CTRL_GVO_DISPLAY_X_SCREEN is enabled, then glXGetVideoDeviceNV will fail. Similarly, if a GLX client has locked the GVO output (via glXGetVideoDeviceNV), then NV_CTRL_GVO_DISPLAY_X_SCREEN will fail. The NV_CTRL_GVO_LOCKED event will be sent when a GLX client locks the GVO output.

NV_CTRL_GVO Attributes

HAPTER 5

API Control

NV_CTRL_GVO_SUPPORTED

* NV_CTRL_GVO_SUPPORTED - returns whether this X screen supports GVO;

* if this screen does not support GVO output, then all other GVO

* attributes are unavailable.

#define NV_CTRL_GVO_SUPPORTED 67 /* R-- */

#define NV_CTRL_GVO_SUPPORTED_FALSE 0

#define NV_CTRL_GVO_SUPPORTED_TRUE 1

NV_CTRL_GVO_SYNC_MODE

* NV_CTRL_GVO_SYNC_MODE - selects the GVO sync mode; possible values

* are:

* FREE_RUNNING - GVO does not sync to any external signal

* GENLOCK - the GVO output is genlocked to an incoming sync signal;

* genlocking locks at hsync. This requires that the output video

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 67

HAPTER 5

C API Control

NV_CTRL_GVO_SYNC_SOURCE

* format exactly match the incoming sync video format.

* FRAMELOCK - the GVO output is framelocked to an incoming sync

* signal; framelocking locks at vsync. This requires that the output

* video format have the same refresh rate as the incoming sync video

* format.

#define NV_CTRL_GVO_SYNC_MODE 68 /* RW- */

#define NV_CTRL_GVO_SYNC_MODE_FREE_RUNNING 0

#define NV_CTRL_GVO_SYNC_MODE_GENLOCK 1

#define NV_CTRL_GVO_SYNC_MODE_FRAMELOCK 2

* NV_CTRL_GVO_SYNC_SOURCE - if NV_CTRL_GVO_SYNC_MODE is set to either

* GENLOCK or FRAMELOCK, this controls which sync source is used as

* the incoming sync signal (either Composite or SDI). If

* NV_CTRL_GVO_SYNC_MODE is FREE_RUNNING, this attribute has no

* effect.

#define NV_CTRL_GVO_SYNC_SOURCE 69 /* RW- */

#define NV_CTRL_GVO_SYNC_SOURCE_COMPOSITE 0

#define NV_CTRL_GVO_SYNC_SOURCE_SDI 1

NV_CTRL_GVO_OUTPUT_VIDEO_FORMAT

* NV_CTRL_GVO_OUTPUT_VIDEO_FORMAT - specifies the output video

* format. Note that the valid video formats will vary depending on

* the NV_CTRL_GVO_SYNC_MODE and the incoming sync video format. See

* the definition of NV_CTRL_GVO_SYNC_MODE.

* Note that when querying the ValidValues for this data type, the

* values are reported as bits within a bitmask

* (ATTRIBUTE_TYPE_INT_BITS); unfortunately, there are more valid

* value bits than will fit in a single 32-bit value. To solve this,

* query the ValidValues for NV_CTRL_GVO_OUTPUT_VIDEO_FORMAT to check

68 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

HAPTER 5

API Control

* which of the first 31 VIDEO_FORMATS are valid, then query the

* ValidValues for NV_CTRL_GVO_OUTPUT_VIDEO_FORMAT2 to check which of

* the VIDEO_FORMATS with value 32 and higher are valid.

#define NV_CTRL_GVO_OUTPUT_VIDEO_FORMAT 70 /* RW- */

#define NV_CTRL_GVO_VIDEO_FORMAT_NONE 0

#define NV_CTRL_GVO_VIDEO_FORMAT_480I_59_94_SMPTE259_NTSC 1

#define NV_CTRL_GVO_VIDEO_FORMAT_576I_50_00_SMPTE259_PAL 2

#define NV_CTRL_GVO_VIDEO_FORMAT_720P_59_94_SMPTE296 3

#define NV_CTRL_GVO_VIDEO_FORMAT_720P_60_00_SMPTE296 4

#define NV_CTRL_GVO_VIDEO_FORMAT_1035I_59_94_SMPTE260 5

#define NV_CTRL_GVO_VIDEO_FORMAT_1035I_60_00_SMPTE260 6

#define NV_CTRL_GVO_VIDEO_FORMAT_1080I_50_00_SMPTE295 7

#define NV_CTRL_GVO_VIDEO_FORMAT_1080I_50_00_SMPTE274 8

#define NV_CTRL_GVO_VIDEO_FORMAT_1080I_59_94_SMPTE274 9

#define NV_CTRL_GVO_VIDEO_FORMAT_1080I_60_00_SMPTE274 10

#define NV_CTRL_GVO_VIDEO_FORMAT_1080P_23_976_SMPTE274 11

#define NV_CTRL_GVO_VIDEO_FORMAT_1080P_24_00_SMPTE274 12

#define NV_CTRL_GVO_VIDEO_FORMAT_1080P_25_00_SMPTE274 13

#define NV_CTRL_GVO_VIDEO_FORMAT_1080P_29_97_SMPTE274 14

#define NV_CTRL_GVO_VIDEO_FORMAT_1080P_30_00_SMPTE274 15

#define NV_CTRL_GVO_VIDEO_FORMAT_720P_50_00_SMPTE296 16

#define NV_CTRL_GVO_VIDEO_FORMAT_1080I_24_00_SMPTE274 17 //deprecated

#define NV_CTRL_GVO_VIDEO_FORMAT_1080I_48_00_SMPTE274 17

#define NV_CTRL_GVO_VIDEO_FORMAT_1080I_23_98_SMPTE274 18 //deprecated

#define NV_CTRL_GVO_VIDEO_FORMAT_1080I_47_96_SMPTE274 18

#define NV_CTRL_GVO_VIDEO_FORMAT_720P_30_00_SMPTE296 19

#define NV_CTRL_GVO_VIDEO_FORMAT_720P_29_97_SMPTE296 20

#define NV_CTRL_GVO_VIDEO_FORMAT_720P_25_00_SMPTE296 21

#define NV_CTRL_GVO_VIDEO_FORMAT_720P_24_00_SMPTE296 22

#define NV_CTRL_GVO_VIDEO_FORMAT_720P_23_98_SMPTE296 23

#define NV_CTRL_GVO_VIDEO_FORMAT_1080PSF_25_00_SMPTE274 24

#define NV_CTRL_GVO_VIDEO_FORMAT_1080PSF_29_97_SMPTE274 25

#define NV_CTRL_GVO_VIDEO_FORMAT_1080PSF_30_00_SMPTE274 26

#define NV_CTRL_GVO_VIDEO_FORMAT_1080PSF_24_00_SMPTE274 27

#define NV_CTRL_GVO_VIDEO_FORMAT_1080PSF_23_98_SMPTE274 28

#define NV_CTRL_GVO_VIDEO_FORMAT_1080P_30_00_SMPTE372 29

#define NV_CTRL_GVO_VIDEO_FORMAT_1080P_29_97_SMPTE372 30

#define NV_CTRL_GVO_VIDEO_FORMAT_1080I_30_00_SMPTE372 31

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 69

HAPTER 5

C API Control

NV_CTRL_GVO_INPUT_VIDEO_FORMAT

#define NV_CTRL_GVO_VIDEO_FORMAT_1080I_29_97_SMPTE372 32

#define NV_CTRL_GVO_VIDEO_FORMAT_1080P_25_00_SMPTE372 33

#define NV_CTRL_GVO_VIDEO_FORMAT_1080I_25_00_SMPTE372 34

#define NV_CTRL_GVO_VIDEO_FORMAT_1080P_24_00_SMPTE372 35

#define NV_CTRL_GVO_VIDEO_FORMAT_1080P_23_98_SMPTE372 36

#define NV_CTRL_GVO_VIDEO_FORMAT_1080I_24_00_SMPTE372 37

#define NV_CTRL_GVO_VIDEO_FORMAT_1080I_23_98_SMPTE372 38

* NV_CTRL_GVO_INPUT_VIDEO_FORMAT - indicates the input video format

* detected; the possible values are the NV_CTRL_GVO_VIDEO_FORMAT

* constants.

#define NV_CTRL_GVO_INPUT_VIDEO_FORMAT 71 /* R-- */

NV_CTRL_GVO_DATA_FORMAT

* NV_CTRL_GVO_DATA_FORMAT - This controls how the data in the source

* (either the X screen or the GLX pbuffer) is interpretted and

* displayed.

#define NV_CTRL_GVO_DATA_FORMAT 72 /* RW- */

#define NV_CTRL_GVO_DATA_FORMAT_R8G8B8_TO_YCRCB444 0

#define NV_CTRL_GVO_DATA_FORMAT_R8G8B8A8_TO_YCRCBA4444 1

#define NV_CTRL_GVO_DATA_FORMAT_R8G8B8Z10_TO_YCRCBZ4444 2

#define NV_CTRL_GVO_DATA_FORMAT_R8G8B8_TO_YCRCB422 3

#define NV_CTRL_GVO_DATA_FORMAT_R8G8B8A8_TO_YCRCBA4224 4

#define NV_CTRL_GVO_DATA_FORMAT_R8G8B8Z10_TO_YCRCBZ4224 5

#define NV_CTRL_GVO_DATA_FORMAT_R8G8B8_TO_RGB444 6

#define NV_CTRL_GVO_DATA_FORMAT_R8G8B8A8_TO_RGBA4444 7

#define NV_CTRL_GVO_DATA_FORMAT_R8G8B8Z10_TO_RGBZ4444 8

#define NV_CTRL_GVO_DATA_FORMAT_Y10CR10CB10_TO_YCRCB444 9

#define NV_CTRL_GVO_DATA_FORMAT_Y10CR8CB8_TO_YCRCB444 10

#define NV_CTRL_GVO_DATA_FORMAT_Y10CR8CB8A10_TO_YCRCBA4444 11

#define NV_CTRL_GVO_DATA_FORMAT_Y10CR8CB8Z10_TO_YCRCBZ4444 12

#define NV_CTRL_GVO_DATA_FORMAT_DUAL_R8G8B8_TO_DUAL_YCRCB422 13

70 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

#define NV_CTRL_GVO_DATA_FORMAT_DUAL_Y8CR8CB8_TO_DUAL_YCRCB422 14

#define NV_CTRL_GVO_DATA_FORMAT_R10G10B10_TO_YCRCB422 15

#define NV_CTRL_GVO_DATA_FORMAT_R10G10B10_TO_YCRCB444 16

#define NV_CTRL_GVO_DATA_FORMAT_Y12CR12CB12_TO_YCRCB444 17

#define NV_CTRL_GVO_DATA_FORMAT_R12G12B12_TO_YCRCB444 18

NV_CTRL_GVO_DISPLAY_X_SCREEN

* NV_CTRL_GVO_DISPLAY_X_SCREEN - enable/disable GVO output of the X

* screen. At this point, all the GVO attributes that have been

* cached in the X server are flushed to the hardware and GVO is

* enabled. Note that this attribute can fail to be set if a GLX

* client has locked the GVO output (via glXGetVideoDeviceNV). Note

* that due to the inherit race conditions in this locking strategy,

* NV_CTRL_GVO_DISPLAY_X_SCREEN can fail unexpectantly. In the

* failing situation, X will not return an X error. Instead, you

* should query the value of NV_CTRL_GVO_DISPLAY_X_SCREEN after

* setting it to confirm that the setting was applied.

HAPTER 5

API Control

#define NV_CTRL_GVO_DISPLAY_X_SCREEN 73 /* RW- */

#define NV_CTRL_GVO_DISPLAY_X_SCREEN_ENABLE 1

#define NV_CTRL_GVO_DISPLAY_X_SCREEN_DISABLE 0

NV_CTRL_GVO_COMPOSITE_SYNC_INPUT_DETECTED

* NV_CTRL_GVO_COMPOSITE_SYNC_INPUT_DETECTED - indicates whether

* Composite Sync input is detected.

#define NV_CTRL_GVO_COMPOSITE_SYNC_INPUT_DETECTED 74 /* R-- */

#define NV_CTRL_GVO_COMPOSITE_SYNC_INPUT_DETECTED_FALSE 0

#define NV_CTRL_GVO_COMPOSITE_SYNC_INPUT_DETECTED_TRUE 1

NV_CTRL_GVO_COMPOSITE_SYNC_INPUT_DETECT_MODE

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 71

HAPTER 5

C API Control

NV_CTRL_GVO_SYNC_INPUT_DETECTED

* NV_CTRL_GVO_COMPOSITE_SYNC_INPUT_DETECT_MODE - get/set the

* Composite Sync input detect mode.

#define NV_CTRL_GVO_COMPOSITE_SYNC_INPUT_DETECT_MODE 75 /* RW- */

#define NV_CTRL_GVO_COMPOSITE_SYNC_INPUT_DETECT_MODE_AUTO 0

#define NV_CTRL_GVO_COMPOSITE_SYNC_INPUT_DETECT_MODE_BI_LEVEL 1

#define NV_CTRL_GVO_COMPOSITE_SYNC_INPUT_DETECT_MODE_TRI_LEVEL 2

* NV_CTRL_GVO_SYNC_INPUT_DETECTED - indicates whether SDI Sync input

* is detected, and what type.

#define NV_CTRL_GVO_SDI_SYNC_INPUT_DETECTED 76 /* R-- */

#define NV_CTRL_GVO_SDI_SYNC_INPUT_DETECTED_NONE 0

#define NV_CTRL_GVO_SDI_SYNC_INPUT_DETECTED_HD 1

#define NV_CTRL_GVO_SDI_SYNC_INPUT_DETECTED_SD 2

NV_CTRL_GVO_VIDEO_OUTPUTS

* NV_CTRL_GVO_VIDEO_OUTPUTS - indicates which GVO video output

* connectors are currently outputing data.

#define NV_CTRL_GVO_VIDEO_OUTPUTS 77 /* R-- */

#define NV_CTRL_GVO_VIDEO_OUTPUTS_NONE 0

#define NV_CTRL_GVO_VIDEO_OUTPUTS_VIDEO1 1

#define NV_CTRL_GVO_VIDEO_OUTPUTS_VIDEO2 2

#define NV_CTRL_GVO_VIDEO_OUTPUTS_VIDEO_BOTH 3

NV_CTRL_GVO_FPGA_VERSION

* NV_CTRL_GVO_FPGA_VERSION - indicates the version of the Firmware on

* the GVO device. XXX would this be better as a string attribute?

72 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

#define NV_CTRL_GVO_FIRMWARE_VERSION 78 /* R-- */

NV_CTRL_GVO_SYNC_DELAY_PIXELS

* NV_CTRL_GVO_SYNC_DELAY_PIXELS - controls the delay between the

* input sync and the output sync in numbers of pixels from hsync;

* this is a 12 bit value.

#define NV_CTRL_GVO_SYNC_DELAY_PIXELS 79 /* RW- */

NV_CTRL_GVO_SYNC_DELAY_LINES

HAPTER 5

API Control

* NV_CTRL_GVO_SYNC_DELAY_LINES - controls the delay between the input

* sync and the output sync in numbers of lines from vsync; this is a

* 12 bit value.

#define NV_CTRL_GVO_SYNC_DELAY_LINES 80 /* RW- */

NV_CTRL_GVO_INPUT_VIDEO_FORMAT_REACQUIRE

* NV_CTRL_GVO_INPUT_VIDEO_FORMAT_REACQUIRE - must be set for a period

* of about 2 seconds for the new InputVideoFormat to be properly

* locked to. In nvidia-settings, we do a reacquire whenever genlock

* or framelock mode is entered into, when the user clicks the

* "detect" button. This value can be written, but always reads back

* _FALSE.

#define NV_CTRL_GVO_INPUT_VIDEO_FORMAT_REACQUIRE 81 /* -W- */

#define NV_CTRL_GVO_INPUT_VIDEO_FORMAT_REACQUIRE_FALSE 0

#define NV_CTRL_GVO_INPUT_VIDEO_FORMAT_REACQUIRE_TRUE 1

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 73

HAPTER 5

C API Control

NV_CTRL_GVO_LOCKED

* NV_CTRL_GVO_LOCKED - indicates that GVO configurability is locked;

* this occurs when the GLX_NV_video_out function calls

* glXGetVideoDeviceNV(). All GVO output resources are locked until

* either glXReleaseVideoDeviceNV() is called or the X Display used

* when calling glXGetVideoDeviceNV() is closed.

* When GVO is locked; all GVO NV-CONTROL attributes are read only.

#define NV_CTRL_GVO_GLX_LOCKED 82 /* R-- */

#define NV_CTRL_GVO_GLX_LOCKED_FALSE 0

#define NV_CTRL_GVO_GLX_LOCKED_TRUE 1

NV_CTRL_GVO_VIDEO_FORMAT_{WIDTH,HEIGHT,REFRESH_RATE}

* NV_CTRL_GVO_VIDEO_FORMAT_{WIDTH,HEIGHT,REFRESH_RATE} - query the

* width, height, and refresh rate for the specified

* NV_CTRL_GVO_VIDEO_FORMAT_*. So that this can be queried with

* existing interfaces, XNVCTRLQueryAttribute() should be used, and

* the video format specified in the display_mask field; eg:

* XNVCTRLQueryAttribute (dpy,

* screen,

* NV_CTRL_GVO_VIDEO_FORMAT_480I_59_94_SMPTE259_NTSC

* NV_CTRL_GVO_VIDEO_FORMAT_WIDTH,

* &value);

* Note that Refresh Rate is in 1/1000 Hertz values

#define NV_CTRL_GVO_VIDEO_FORMAT_WIDTH 83 /* R-- */

#define NV_CTRL_GVO_VIDEO_FORMAT_HEIGHT 84 /* R-- */

#define NV_CTRL_GVO_VIDEO_FORMAT_REFRESH_RATE 85 /* R-- */

74 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

NV_CTRL_GVO_X_SCREEN_PAN_[XY]

* NV_CTRL_GVO_X_SCREEN_PAN_[XY] - when GVO output of the X screen is

* enabled, the pan x/y attributes control which portion of the X

* screen is displayed by GVO. These attributes can be updated while

* GVO output is enabled, or before enabling GVO output. The pan

* values will be clamped so that GVO output is not panned beyond the

* end of the X screen.

#define NV_CTRL_GVO_X_SCREEN_PAN_X 86 /* RW- */

#define NV_CTRL_GVO_X_SCREEN_PAN_Y 87 /* RW- */

HAPTER 5

API Control

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 75

HAPTER 5

C API Control

NV-Control X Functions

Table 5.2

NV-Control X Function Index

Call Description

XNVCTRLQueryExtension()

XNVCTRLQueryVersion()

XNVCTRLIsNvScreen()

XNVCTRLSetAttribute()

XNVCTRLSetAttributeAndGetStatus( )

XNVCTRLQueryAttribute()

XNVCTRLQueryStringAttribute()

XNVCTRLSetStringAttribute()

XNVCTRLQueryValidAttributeValues ()

XNVCTRLSetGvoColorConversion()

XNVCTRLQueryGvoColorConversion()

XNVCTRLQueryExtension()

Queries for the existence of the Nv_Gvo extensions

Queries the extension version

Queries whether the specified screen is controlled by the NVIDIA driver.

Sets the specified attribute to the specified value.

Same as XNVCTRLSetAttribute().

Queries the value of the specified attribute

Queries the value of the specified string attribute

Set the specified string attribute with the specified string.

Queries the valid values for the specified attribute

Sets the color conversion matrix

Queries the color conversion matrix

Bool XNVCTRLQueryExtension (

Display *dpy,

int *event_basep,

int *error_basep

);

This function returns True if the extension exists, False otherwise.

error_basep

are the extension event and error bases. Currently, no extension specific

event_basep

and

errors or events are defined.

XNVCTRLQueryVersion()

Bool XNVCTRLQueryVersion (

Display *dpy,

int *major,

int *minor

76 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

);

This function returns True if the extension exists, False otherwise. the extensionʹs major and minor version numbers.

XNVCTRLIsNvScreen()

Bool XNVCTRLIsNvScreen (

Display *dpy,

int screen

);

This function returns True is the specified screen is controlled by the NVIDIA driver, otherwise False.

XNVCTRLSetAttribute()

void XNVCTRLSetAttribute (

Display *dpy,

major

API Control

and

minor

HAPTER 5

are

int screen,

unsigned int display_mask,

unsigned int attribute,

int value

);

This function sets the attribute to the given value. Not all attributes require the display_mask parameter. See “NV_CTRL_GVO Attributes” on page 67 for details.

Possible errors:

• BadValue - The screen or attribute doesnʹt exist.

• BadMatch - The NVIDIA driver is not present on that screen.

XNVCTRLSetAttributeAndGetStatus()

Bool XNVCTRLSetAttributeAndGetStatus (

Display *dpy,

int screen,

unsigned int display_mask,

unsigned int attribute,

int value

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 77

HAPTER 5

C API Control

XNVCTRLQueryAttribute()

);

This function is the same as XNVCTRLSetAttribute(), and returns True if the operation succeeds, otherwise False.

Bool XNVCTRLQueryAttribute (

Display *dpy,

int screen,

unsigned int display_mask,

unsigned int attribute,

int *value

);

This function returns True if the attribute exists, otherwise False.

If XNVCTRLQueryAttribute returns True, value will contain the value of the specified attribute. Not all attributes require the display_mask parameter. See “NV_CTRL_GVO

Attributes” on page 67 for details.

Possible errors:

• BadValue - The screen doesnʹt exist.

• BadMatch - The NVIDIA driver is not present on that screen.

XNVCTRLQueryStringAttribute()

Bool XNVCTRLQueryStringAttribute (

Display *dpy,

int screen,

unsigned int display_mask,

unsigned int attribute,

char **ptr

);

This function returns True if the attribute exists, otherwise False.

If XNVCTRLQueryStringAttribute returns True, *ptr will point to an allocated string containing the string attribute requested. It is the callerʹs responsibility to free the string when done.

Possible errors:

78 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

• BadValue - The screen doesnʹt exist.

• BadMatch - The NVIDIA driver is not present on that screen.

• BadAlloc - Insufficient resources to fulfill the request.

XNVCTRLSetStringAttribute()

Bool XNVCTRLSetStringAttribute (

Display *dpy,

int screen,

unsigned int display_mask,

unsigned int attribute,

char *ptr

);

Returns True if the operation succeeded, otherwise False.

HAPTER 5

API Control

Possible X errors:

• BadValue - The screen doesnʹt exist.

• BadMatch - The NVIDIA driver is not present on that screen.

• BadAlloc - Insufficient resources to fulfill the request.

XNVCTRLQueryValidAttributeValues()

Bool XNVCTRLQueryValidAttributeValues (

Display *dpy,

int screen,

unsigned int display_mask,

unsigned int attribute,

NVCTRLAttributeValidValuesRec *values

);

This function returns True if the attribute exists. otherwise False. If XNVCTRLQueryValidAttributeValues returns True, values will indicate the valid values for the specified attribute.

See the description of NVCTRLAttributeValidValues in NVCtrl.h.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 79

HAPTER 5

C API Control

XNVCTRLSetGvoColorConversion()

void XNVCTRLSetGvoColorConversion (

Display *dpy,

int screen,

float colorMatrix[3][3],

float colorOffset[3],

float colorScale[3]

);

This function sets the color conversion matrix, offset, and scale that should be used for GVO (Graphic to Video Out).

The Color Space Conversion data is ordered as follows:

• colorMatrix[0][0] // r.Y

• colorMatrix[0][1] // g.Y

• colorMatrix[0][2] // b.Y

• colorMatrix[1][0] // r.Cr

• colorMatrix[1][1] // g.Cr

• colorMatrix[1][2] // b.Cr

• colorMatrix[2][0] // r.Cb

• colorMatrix[2][1] // g.Cb

• colorMatrix[2][2] // b.Cb

• colorOffset[0] // Y

• colorOffset[1] // Cr

• colorOffset[2] // Cb

• colorScale[0] // Y

• colorScale[1] // Cr

• colorScale[2] // Cb

where the data is used according to the following formulae:

• Y = colorOffset[0] + colorScale[0] *

(R * colorMatrix[0][0] + G * colorMatrix[0][1] + B * colorMatrix[0][2]);

80 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

• Cr = colorOffset[1] + colorScale[1] *

(R * colorMatrix[1][0] + G * colorMatrix[1][1] + B * colorMatrix[1][2]);

• Cb = colorOffset[2] + colorScale[2] *

(R * colorMatrix[2][0] + G * colorMatrix[2][1] + B * colorMatrix[2][2]);

Possible errors:

• BadMatch - The NVIDIA driver is not present on that screen.

• BadImplementation - GVO is not available on that screen.

XNVCTRLQueryGvoColorConversion()

Bool XNVCTRLQueryGvoColorConversion (

Display *dpy,

int screen,

float colorMatrix[3][3],

float colorOffset[3],

float colorScale[3]

);

HAPTER 5

API Control

This function retrieves the color conversion matrix and color offset that are currently being used for GVO (Graphic to Video Out). The values are ordered within the arrays according to the comments for XNVCTRLSetGvoColorConversion().

Possible errors:

• BadMatch - The NVIDIA driver is not present on that screen.

• BadImplementation - GVO is not available on that screen.

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 81

HAPTER 5

C API Control

82 Quadro FX 4500 SDI User’s Guide– Version 1.0

NVIDIA Corporation

PPENDIX A

OnBoard DIP Switch

A PPENDIX

ONB

The Quadro FX 4500 SDI graphics card has an onboard dip switch, located on the SDI output card, that determines the default SDI operating mode. Subsequent software changes override these settings.

SDI Output Card

(7) Auto Switch (See Table A.3)

(5-6) Sync Source (See Table A.2)

OARD

DIP S

WITCH

(1-4) Output Video Format (See Table A.1)

Figure 1.1

NVIDIA Corporation Quadro FX 4500 SDI User’s Guide – Version 1.0 83

Onboard DIP Switch Positions

PPENDIX A

A OnBoard DIP Switch

In the following tables, a “0” value corresponds to the “ON” switch position, and a “1” value corresponds to the “OFF” switch position.

Table A.1

Switch Position

1234

0000 1000 0100 1100 0010 1010 0110 1110 0001 1001 0101 1101 0011 1011 0111 1111

Output Video Format Switch Settings

Video Format

Reserved SMPTE 259 NTSC, 1440x487, 30/1.001 Hz, Interlace SMPTE 259 PAL, 1440x576, 25 Hz, Interlace SMPTE 260, 1920x1035, 30 Hz, Interlace SMPTE 260, 1920x1035, 30/1.001 Hz, Interlace SMPTE 295, 1920x1080, 25 Hz, Interlace SMPTE 274, 1920x1080, 30 Hz, Interlace SMPTE 274, 1920x1080, 30/1.001 Hz, Interlace SMPTE 274, 1920x1080, 25 Hz, Interlace SMPTE 274, 1920x1080, 30 Hz, Progressive SMPTE 274, 1920x1080, 30/1.001 Hz, Progressive SMPTE 274, 1920x1080, 25 Hz, Progressive SMPTE 274, 1920x1080, 24 Hz, Progressive SMPTE 274, 1920x1080, 24/1.001 Hz, Progressive SMPTE 296, 1280x720, 60 Hz, Progressive SMPTE 296, 1280x720, 60/1.001 Hz, Progressive

Table A.2

Sync Source Switch Settings

Switch Position

00 10 01 11

Table A.3

Sync Source

Internal (free running) Synchronize to SDI sync source Synchronize to Composite sync source Reserved

Auto Switch Settings

Switch Position

0 1

84 Quadro FX 4500 SDI User’s Guide– Version 1.0

Auto Switch Setting

Do not auto switch Automatically switch to the new video format based on the

source sync.

NVIDIA Corporation

Nvidia Quadro FX 4500 SDI User's Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
