NVIDIA P1988W User Manual

Tegra NOTE™ 7
User Guide
1
Contents
What’s in the Box ............................................................................................................................................... 5
Buttons and Connectors ..................................................................................................................................... 6
Charging the Battery .......................................................................................................................................... 7
Inserting an SD/SIM Card .................................................................................................................................... 8
Micro SD Card ................................................................................................................................................. 8
SIM Card ......................................................................................................................................................... 8
Power On ........................................................................................................................................................... 9
Do I Need a Google Account? .......................................................................................................................... 9
Let Your Fingers (or Stylus) do the Work .......................................................................................................... 10
About the NVIDIA® DirectStylus™ .................................................................................................................... 11
Favorites Icon Tray ............................................................................................................................................ 13
Navigation Icons ................................................................................................................................................ 13
Quick-Access Tray ............................................................................................................................................ 14
Notification Icons ............................................................................................................................................. 14
Status Icons ....................................................................................................................................................... 15
Organize Home Screens ................................................................................................................................... 16
Add Widget/App Icon to Home Screen .......................................................................................................... 16
Move Widget/App Icon .................................................................................................................................. 16
Making Folders .............................................................................................................................................. 17
Changing Font Size ........................................................................................................................................ 17
Select a Background Wallpaper ...................................................................................................................... 17
Customizing Sounds and Notifications ........................................................................................................... 17
Keyboard Layout .............................................................................................................................................. 18
Basic Keyboard Usage ................................................................................................................................... 19
Write by Stylus labs .......................................................................................................................................... 21
Camera Awesome ............................................................................................................................................ 22
Focus and Exposer ........................................................................................................................................ 22
Camera Icons ................................................................................................................................................ 23
Focus, Exposure, Zoom, and Tap to Track Gestures ...................................................................................... 24
Video Capture and Slow Motion .................................................................................................................... 25
NVIDIA DirectStylus™ Launcher ...................................................................................................................... 25
Tegra NOTE 7 Draw .......................................................................................................................................... 26
NVIDIA Lasso Capture Tool .............................................................................................................................. 26
NVIDIA TegraZone™ ........................................................................................................................................ 26
Wireless & Networks ........................................................................................................................................ 29
Wi-Fi ............................................................................................................................................................. 29
Miracast ........................................................................................................................................................ 29
Bluetooth ...................................................................................................................................................... 30
Data Usage ................................................................................................................................................... 30
Airplane Mode ............................................................................................................................................... 31
Default SMS App ............................................................................................................................................ 31
Tethering & Portable Hotspot ........................................................................................................................ 31
2
Portable Wi-Fi Hotspot .................................................................................................................................. 31
Set-Up Wi-Fi Hotspot ..................................................................................................................................... 31
Bluetooth Tethering ....................................................................................................................................... 31
VPN .............................................................................................................................................................. 32
Mobile Networks ........................................................................................................................................... 32
Mobile Network Settings ............................................................................................................................... 33
Device .............................................................................................................................................................. 34
Controller ...................................................................................................................................................... 34
Sound ............................................................................................................................................................35
Display ...........................................................................................................................................................35
NVIDIA DirectStylus™................................................................................................................................... 36
HDMI ............................................................................................................................................................ 36
Storage .......................................................................................................................................................... 37
Battery ........................................................................................................................................................... 37
Power Saving ................................................................................................................................................ 38
Apps ............................................................................................................................................................. 38
Users ............................................................................................................................................................. 39
Personal ........................................................................................................................................................... 40
Location Access ............................................................................................................................................ 40
Security ......................................................................................................................................................... 40
Language and Input ...................................................................................................................................... 41
Backup and Reset .......................................................................................................................................... 42
Accounts .......................................................................................................................................................... 43
Add an Account ............................................................................................................................................. 43
Remove an Account ...................................................................................................................................... 43
System ............................................................................................................................................................. 43
Bookmarks ....................................................................................................................................................... 44
Sync Bookmarks ........................................................................................................................................... 44
How to Create an All-in-One Calendar .............................................................................................................. 45
How to Email .................................................................................................................................................... 45
Reading Incoming Messages ......................................................................................................................... 45
Sending Email ............................................................................................................................................... 45
Setting General Options ................................................................................................................................ 45
Setting Personal Options .............................................................................................................................. 46
How to Use the Clock ....................................................................................................................................... 46
Important Safety Information........................................................................................................................... 49
Symbols on Equipment .................................................................................................................................... 50
General Precautions ......................................................................................................................................... 50
3
About Tegra NOTE 7 LTE
Congratulations on your new Tegra NOTE™ 7 tablet, powered with the leading-edge NVIDIA® Tegra® 4 quad­core applications processor. The Tegra NOTE 7 LTE also has a built-in modem with ultra-fast connectivity anywhere with download speeds up to 100 Mbps and upload speeds up to 50 Mbps. Your tablet is loaded with the Google® Android™ operating system and functions as any standard Android device. You can use your Tegra NOTE 7 to surf the web, video chat with friends, take pictures, play games, make phone calls through any third­party app, and much more. The new Tegra NOTE 7 LTE provides a slot for your SIM card, which allows you to take your connected experience anywhere.
Your Tegra NOTE 7 LTE comes with the standard Android apps and with the following preloaded software:
AdobeCamera Awesome
Tegra NOTE Draw Write by Stylus Labs
NVIDIA DirectStylus™ Launcher NVIDIA Lasso Capture tool NVIDIA TegraZone™ NVIDIA Game Mapper
®
Reader®
®
by SmugMug®
®
4
What’s in the Box
About Tegra NOTE 7 LTE
1 Tegra NOTE 7 with Stylus 4 Power Adapter – Hong Kong, UK
2 Quick Start Guide 5 Power Adapter – China, Japan, US
3 USB-to-Micro USB cable 6 Power Adapter – Europe
5
Buttons and Connectors
About Tegra NOTE 7 LTE
1 Stylus in Housing 8 Micro USB
2 Volume Up/Down 9 Base Reflux Port
3 Micro SD Card Slot 10 Cover Spine (slide out to install cover)
4 Rear Camera 11 Dual Speakers
5 Power/Sleep Button 12 Front Camera (behind glass)
6 3.5 MM Audio Port Microphone (behind speaker grill)
7 Micro HDMI
6
About Tegra NOTE 7 LTE
Charging the Battery
The battery in your new Tegra NOTE™ 7 is partially charged. It is recommended that you fully charge your device as soon as possible.
To charge your Tegra NOTE 7, use the included AC adapter and the USB cable. Plug the micro USB end of the cable into the Tegra NOTE 7 and the other standard USB end into the power adapter. Plug the power adapter into a wall power outlet.
Note:
Use the AC Adapter and the USB cable that came with your Tegra NOTE 7. Other chargers and USB cables may be different and could charge more slowly or not at all. Using other USB adapters may add noise that can interfere with the touch function.
You can also charge your Tegra NOTE 7 by plugging the standard end of the USB cable into any USB connection on your computer system. However, using the AC adapter plugged into a wall outlet will charge your Tegra NOTE 7 faster. When connected to a PC, if the tablet is on, it may consume more power than it is getting from the charge.
Note:
It is recommended that when charging your Tegra NOTE 7, make sure the tablet is turned off specifically when the power is low or you are charging it from a PC. Charging should take approximately two hours. However, if the tablet is on while charging, it continues to consume power and will extend the charging time. When the Tegra NOTE 7 is plugged into a PC, it may continue to drain faster than it charges.
7
About Tegra NOTE 7 LTE
Inserting an SD/SIM Card
Micro SD Card
There are various types of SD cards available; Standard, Mini, and Micro. Your Tegra NOTE 7 uses a Micro SD card. The SD card is used as extra storage space for games, photos, music, or anything else you would like to keep on your Tegra NOTE 7. Note that most apps will not load to an SD card.
Remove the cover off of the Micro SD-card/SIM card slot.
When installing the SD card into the SD slot, make sure the fingers are facing the back of the tablet.
When selecting an SD card for your tablet, note that they come in different sizes (capacity) and different classes. The size is the amount of space on the card; for example, 16 GB or 32 GB. The class of an SD card reflects the speed. A Class 2 SD card has a write speed of about 2MB/s, a class 4 SD card is about 4 Mb/s, and so on. For your tablet, a class 6 or higher is recommended.
SIM Card
To use your tablet with mobile network data, you must first insert and activate a SIM card. If no card is installed, the message No SIM card displays on the tablet’s lock screen.
Tegra Note 7 LTE SIM card slot requires the Micro SIM card size. If you have regular size SIM you should exchange it for the Micro SIM size card.
Insert SIM card
1. Hold your tablet with the screen facing down and the card slot facing you.
2. Open the cover over the slot for the SD/SIM Card.
3. Gently insert the SIM Card into the slot on the right, notch first and the metal contacts facing up.
4. You will be prompted to reset your tablet to enable the SIM.
Back of Tablet
Front of Tablet
Activate SIM card
5. Be sure that the SIM you are using is valid. SIMs that are expired will not work
6. Follow the activation instructions provided by your carrier
n most cases the tablet will get on the network right away and display signal strength on the notification bar
I
.
Important: It may take time for some carriers to activate your SIM card. If you feel it is taking too long,
try restarting your tablet. Call your carrier if you cannot get the SIM card to activate. Some carriers may require special functions or require you to enter data.
8
Get Started
Power On
Your new Tegra NOTE 7 tablet is loaded with the Google Android operating system.
hen you power on your tablet, you are going to be guided through the standard
W Android setup.
To turn on your Tegra NOTE 7, press the Power button on the right side of the tablet for a few seconds and then release.
The first time you power on your Tegra NOTE 7, a Welcome screen displays. Select your language and press Start.
The automated set-up takes you through a series of screens to customize your tablet. You will be asked to set-up a Google account and configure your Wi-Fi connections.
Important: During set-up, you must have a Wi-Fi connection to complete the
process.
When you are prompted to sign-in or create a Google account, you can use an email account for any one of the following Google accounts you may have:
Gmail YouTube Google Apps Any other Google product
hen you sign in with a Google account, all the email, contacts, calendar events, and
W other data associated with that account are automatically synced with your tablet. If you have multiple Google accounts, you can add the others later after you have completed the set-up
When set-up is done, press Finish to begin enjoying your new Tegra NOTE 7.
Do I Need a Google Account?
No, you are not required to have a Google account associated with your Tegra NOTE
7. However, you do need an account if you want to use Google mobile services (like Google Play, Google Music, Google Books, etc.) to download and manage Google apps between devices.
9
Get Started
A Google Account does provide the ability to organize and access personal information from any computer or mobile device that is also using your Google account. A Google Account lets you organize and access your personal information from any computer or mobile device:
Use Google Play. Google Play brings together all your favorite content in one place: movies, TV shows, books,
music, magazines, apps, and more.
Synchronize and back up everything. Whether you draft an email, add an event to your calendar, or add a
friend’s address, your work gets backed up continuously by Google and synchronized with any computer where you use the same Google Account.
Access from anywhere. Check your latest calendar, email, text messages, or social stream, no matter what
omputer or mobile device you’re using.
c
Keep everything secure and available. Google works round the clock to protect your personal data from
unauthorized access and to ensure that you get it when you need it, wherever you need it.
Simplify shopping. You can connect your Google account with Google Wallet, which makes it easy to purchase
music, books, apps, and more on Google Play and other online stores.
Let Your Fingers (or Stylus) do the Work
With Android, your fingers do all the work. Swipe, pinch, press, or tap—they all have a resulting action.
Touch or Tap Most apps require just a touch to open and run. A simple tap on the app icon opens the application. A touch in a field requiring input displays a keyboard.
Double-Tap Tap twice quickly on a webpage, map, or other screen to zoom. An example would be to double­tap a picture in Browser to zoom in, and double-tap again to zoom out
Touch and Hold Pressing and holding an item on-screen can trigger different actions. An example is the keyboard: If you touch an alphabet key, a letter is typed. If you touch and hold the key, a number or a mark (displayed in upper right corner of key) is typed. Use touch and hold with drag to move icons between screens
Drag To drag, touch and hold an icon and without lifting your finger, move it to any location on a screen. To drag it to another screen, move to the edge of the current screen in either direction to go to the adjacent screen
Swipe or Slide Swipe your finger across the surface of the screen, without pausing, up/down or across to move through lists, screens, or pictures. When swiping, do not pause or hesitate or you may end up dragging something you touched. For example, you can slide a screen left or right to view another screen
Pinch There are some apps such as Browser, Gallery, and Maps, that you can zoom in and out by placing two fingers on the screen at once and pinching them together to zoom in (make it smaller) or spreading them apart to zoom out (making it bigger).
10
Get Started
About the NVIDIA® DirectStylus™
Your Tegra NOTE 7 has a built-in stylus that launches specified apps when pulled from its Tegra NOTE 7 housing.
Wherever you can control the tablet with your finger, you can also use the stylus to tap, swipe, or draw. The DirectStylus gives you fine point control that makes it much easier to write, draw, and activate small buttons or browser hot spots.
The optional DirectStylus Pro accessory kit has two different tips; the chisel pen tip and the 2 mm fine point tip. The chisel pen tip is shaped like a highlighter pen tip and can be used to easily create thin and thick lines, allowing you to switch from writing fine lines to bold strokes all with a twist of the stylus1.
Stylus Housing
1
The application must have pressure sensitivity support in order to experience dynamically changing stroke
widths.
11
Home Screens
Your Tegra NOTE 7 supports multiple screens that can be configured with various apps and widgets. The center screen is the default home screen that is displayed every time you press the Home icon. To move between screens, swipe left or right.
A suggestion would be to place your most used app/widget icons on the Home page. You can then configure the other screens for games, one for music, and so on.
The difference between an App and a Widget is that a Widget runs continuously (such as a clock, weather,
tasks, etc.) and does not take up the entire screen. An App is an application that you start and close and while it is running, takes up the entire screen (such as games, music, photo gallery, etc.).
Swipe left or right to see other pages
Note that the Favorites tray and the Navigation Icons are displayed on each page.
The thickness in the white line indicates the home page you are currently on. This will move as you swipe through the pages. After a second the highlight will fade away.
12
Home Screens
Favorites Icon Tray
At the bottom of every Home screen is an area called Favorites Tray. This area is for you to place your favorite and most used apps or short-cut icons for faster access. To replace an icon, simply press and hold your finger on the desired icon and move it to the Favorites Tray over an icon you wish to replace. Lift your finger and the icon is in place.
Favorites Tray
Navigation Bar
Navigation Icons
Always displayed at the bottom of every screen are three navigational buttons:
Back: Takes you back to the previous screen you were in. With each tap of the Back icon you are taken back through the previous screens/apps until you are at the Home screen.
Home: A tap of the Home icon takes you to the central Home screen.
Recent Apps: A tap of this icon opens a thumbnail list of recently used apps. To open one of the apps listed, touch the thumbnail.
If you do not use these buttons for an extended length of time, they may shrink to dots or fade away. To bring them back, touch their location.
13
Home Screens
Quick-Access Tray
Swipe down from the top of the screen to display a quick-access tray with commonly used controls and settings. This saves you from having to navigate through the settings menus.
Swipe down from the top of the tablet screen to display the Quick Access Tray. The tray contains commonly-used controls and settings.
Notification Icons
Along the top of every screen icons are displayed to notify you that new text or email messages, calendar events,
larms, and any ongoing downloads such as app updates or video downloads have occurred.
a
Notification Icons Status Icons
To view the notification shade, swipe down from the top. A shade is an informational area that swipes down and up just like a window shade.
Some notifications can be expanded to show more information, such as email
reviews or calendar events. The notification at the top is always expanded
p when possible. When finished with a notification, just swipe it away horizontally.
New Email message
New text message
Upcoming calendar event
Tegra NOTE 7 is connected to a computer via a USB cable.
Warning message
Error message
Software updates available
Upload/download data
More undisplayed notifications
14
Home Screens
Dismiss all notifications
Status Icons
Along the top right of each screen is the status area. Here is where you will see battery status, Wi-Fi connection status, and Bluetooth status. The time is also displayed.
Tablet is connected to a computer
Airplane mode. Device can be used but Wi-Fi and Bluetooth are turned off.
Error occurred or caution required
Batter power status. The level of fill in the battery icon represents the percentage of battery power.
Battery is charging
Alarm: Alarm clock is set and activated
Mute. Sound is turned off
The microphone is muted
Wi-Fi: Number of bars shown on the icon represents the strength of the Wi-Fi signal.
Bluetooth: Bluetooth is on.
Cellular bars indicate signal strength
SIM card is not installed
3G is available
Synchronization is ongoing
Problem with sign-in or synchronization
15
Organize Home Screens
Add Widget/App Icon to Home Screen
To add an app or widget icon to a Home screen:
1. Go to the Home screen where you want to place the widget/app.
2. Touch the All Apps
3. Swipe through the widget/app to find the widget you are looking for.
4. Touch and hold the widget/app until the Home screen displays, slide
it into place, and lift your finger.
icon.
Home Screens
Touch APPS for a list of
App icons
Touch WIDGETS for a list of
Wi
dget icons
0.
Move Widget/App Icon
Use the following steps to move an app or widget icon to a different location on a Home screen or to a different screen:
1. Touch and hold the icon.
2. Slide your finger to the new position dragging the icon.
• To move between Home screens, slide toward the edge of the
screen.
• To bump another icon out of the way, slide slowly into it.
3. Lift your finger and the icon drops into its new position.
0.
Touch and hold the icon and drag it from one home screen to another. An outline of the home screen shows as you drag the icon.
16
Loading...
+ 36 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
