1-1 Package Contents
Introduction
Section 1
INTRODUCTION
Contents
A. Mainboard
B. User’s manual
C. Floppy drive cable
D. HDD drive cable
E. CD (drivers and utilities)
F. I/O Shield
G .S-ATA data and power cable
A
USER’S
MANUAL
B
Optional Items
H. Extra USB2.0 port cable
If you need the optional item, please contact your dealer for assistance.
C
D
E
F
H
G
Page 1-1
Introduction
1-2 Mainboard Features
Brief Introduction
AthlonTM 64 Processor
The AMD AthlonTM 64 processor family is designed to support performance
desktop. It provides a high performance HyperTransportTM link to I/O, as well
as a single 64-bit high-performance DDR memory controller.
For more information about all the new features AthlonTM 64 Processor deliver, check out
the AMD website at
Chipset
http://www.amd.com
The board is designed with NVIDIA nForce4 4X chipset, featuring performance
and stability with the most innovative technology and features, including the
world’s first and only native Gigabit Ethernet interface and hardware-optimized
Firewall security solution.
For more details about the NVIDIA nForce4, please visit the NVIDIA Web site at
http://www.nvidia.com.
PCI-Express (PCI-E)
Next generation peripheral interface to succeed to current PCI bus for the next
decade. With smaller slot size and 250MB/sec (PCI-E*1) or 4GB/sec(PCI-E*16)
maximum transfer, PCI-Express overcomes PCI bus bottleneck.
Hardware Monitoring
Hardware monitoring enables you to monitor various aspects of the system
operation and status. This includes CPU temperature, voltage and fan speed in
RPMs.
10/100 LAN
This mainboard is mounted with a ethernet LAN PHY. It allows the mainboard to
connect to a local area network by means of a network hub.
Serial ATA
Support Serial ATA, an evolutionary replacement for Parallel ATA IDE storage
interface. Increases the peak data transfer speed up to 150MB/sec and allows
future enhancements to the computing platform.
Page 1-2
Introduction
S-ATA RAID
RAID function available on chipset S-ATA ports.
USB2.0
A popular USB standard for plugging in peripherals with up to 480Mbps transfer
speed while maintaining backward compatibility with older USB1.1 device.
6ch
Mainboard is equipped with 6 channel of audio to support Dolby Digital 5.1
audio for DVD-playback. The onboard audio jacks can be configured for normal
2 channel mode or 6 channel mode.
AMD Cool'n'QuietTM Technology
AMD's Cool'n'QuietTM Technology lowers CPU operating voltage when the
system is in idle mode. This helps to reduce heat dissipation and in effect lowers
the fan speed to noise from your PC.
Page 1-3
Introduction
Special Features
BIOS Features:
Magic Health
&
Reports your system hardware status for every boot-up to help detect faults
early. Monitor hardware status including CPU temperature, CPU/Memory/
Chipset voltage, fan RPM speed for chassis fan, CPU fan & Power supply fan.
EZ-Boot
&
Simply press “ESC” to select your bootable device. No more hassle to search
the BIOS menu, change and re-start.
PowerBIOS
&
Supporting a full range of overclocking setting via BIOS. Various adjustable
feature include FSB/Chipset/Memory voltage tweaking.
H/W Features:
QuickSPDIF
&
On board SPDIF-out connector for quick connection to multi-channel
speakers. Not only removes cable cluttering but also delivers loss-free digital
audio to let you enjoy DVD movies and games with crystal clear sound.
Page 1-4
1-3 System Block Diagram
Introduction
Page 1-5
Introduction
Page 1-6
Mainboard Specification
Processor
Support Socket-754 based AMD Athlon-64/Sempron processor up to
3700+ with 1.6GTs Hyper Transport
Chipset
nVidia nForce4 4X Chipset
Main Memory
Two 184-pin DDR SDRAM DIMM sockets
Support single-sided or double-sided 2.5v DDR-266/333/400 DIMMs in
128/256/512Mb technologies
Supports up to 2GB memory size
Expansion Slots
Three PCI connectors compliant with PCI v2.3
Two PCI-E x1 connectors compliant with PCI Express 1.0a
One PCI-E x16 connectors compliant with PCI Express 1.0a
Specification
Section 2
SPECIFICATION
USB
Te n USB connectors compliant with USB2.0 from embedded USB controller
(4 connectors at rear panel)
P-ATA IDE
Two IDE interface (up to 4 IDE devices) with UDMA-33, ATA-66/100/133
support from embedded IDE controller
S-ATA RAID
Four S-ATA ports with up to 150MB/s bandwidth support RAID 0, 1, 0+1,
JBOD
Page 2-1
Specification
LAN
10/100Mbps Ethernet from Realtek RTL8201 LAN PHY
Audio
6 channel audio from onboard ALC655 AC’97 v2.3 compliant CODEC
- Support Aux-In, CD-In
- Coaxial S/PDIF-out available on rear panel
- Support Jack detection for fool-proof audio device installation
- Rear panel audio jacks configuration
roloCkcaJoiduA
eulBthgiLni-eniLtuo-oeretsraeR
emiLtuo-eniLtuo-oeretstnorF
kniPni-ciMrefoowbuS&retneC
lennahc2 lennahc6
I/O
Onboard Fintek LPC bus I/O controller
Legacy peripheral interface for PS/2 keyboard & mouse, FDD, Parallel,
Serial, and IrDA (v1.0 compliant)
Support Hardware Monitoring for fan speed monitoring, CPU/System
temperature
Intelligent fan speed control for quiet operation
BIOS
Flash EEPROM with Award Plug&Play BIOS
Support EZ Boot for fast bootable device selection
Support Magic Health for system hardware status report during system
boot-up
Peripheral Interfaces
))
) At Rear Panel
))
PS/2 keyboard and mouse ports
One Parallel (printer) port
One S/PDIF-Out Coaxial jack
Page 2-2
One Serial port
One RJ45 LAN connector
Four USB2.0 ports
Three Audio jacks
))
) Onboard connector and pin-header
))
One floppy drive connector
Two ATA-100/133 IDE connector
Six extra USB2.0 ports
One CD-IN and AUX-IN connector
One IR connector
Four S-ATA connectors
Three Fan connectors
Front Panel Controller
Supports Reset & Soft-Off switches
Supports HDD & Power LEDs
Supports PC speaker
Supports Front Panel Audio connector
Specification
Special Features
Support KBPO function – Keyboard power on, turn on the computer from
keyboard
Support Wake-On-LAN by PME
PowerBIOS for excellent overclocking capabilities through
- Programmable FSB and PCI-E Clock output frequency with 1MHz fine
tuning
- Support BIOS adjustable CPU Core voltage, Chipset voltage, DIMM
frequency and voltage settings
Form Factor
305mm x 210 mm ATX size
Page 2-3
Specification
Page 2-4
Mainboard Layout
Installation
Section 3
INSTALLATION
Page 3-1
Installation
Easy Installation Procedure
The following must be completed before powering on your new system:
3-1. CPU Installation
3-2. Jumper Settings
3-3. System Memory
3-4. Expansion Slots
3-5. Device Connectors
3-1 CPU Installation
<Figure 1>
Step 1
Open the socket by raising the actuation lever.
Note:
Thermal compound and qualified heatsink recommended by AMD are a must to avoid CPU overheat damage
Page 3-2
<Figure 2>
Step 2
Align pin 1 on the CPU with pin 1 on
the CPU socket and gently insert the
CPU. The CPU is keyed to prevent
incorrect insertion. Do not force the
processor into the socket. If it does not
go in easily, check for mis-orientation
and reinsert the CPU.
Make sure the processor is fully
inserted into the socket.
.
Installation
<Figure 3>
Step 3
Close the socket by lowering and locking the actuation lever. Apply thermal compound to the top of
the CPU.
<Figure 5>
Step 5
Plug the CPU fan power into the mainboard’s CPU fan connector.
The installation is complete.
<Figure 4>
Step 4
Insert the heatsink as shown above. Press the clips in the direction of the arrows shown in Figure 4 to secure the assembly to the CPU socket.
Page 3-3
Installation
3-2 Jumper Settings
JCMOS:
Clear CMOS data Jumper
If the CMOS data becomes corrupted or
you forgot the supervisor or user
password, clear the CMOS data to
reconfigure the system back to the
default values stored in the ROM BIOS.
1
To CMOS Clear data, please follow the steps below.
1. Turn off the system.
2. Change the jumper from “1-2” to “2-3” position for a few seconds.
3. Replace the jumper back to the “1-2” position.
4. Turn on the system and hold down the <Del> key to enter BIOS setup.
Settings: 1-2: Normal (Default) 2-3: Clear CMOS
Page 3-4
Installation
3-3 System Memory Configuration
Memory Layout
The mainboard accommodates two PC2100/PC2700/PC3200 184-pin DIMMs (Dual In-
line Memory Modules):
Supports up to 2.0GB of 266/333/400MHz DDR SDRAM.
Supports unbuffered DIMM configurations defined in JEDEC DDR DIMM
specification.
DDR DIMM 1
DDR DIMM 2
<Figure 6>
Memory configurations supported:
oNtolSMMID1sMMID2
1#MMIDSS/SDSS/SD
2#MMIDSS/SDSS/SD
* DS - Double-sided DIMM, * SS - Single-sided DIMM
NOTES:
Using non-compliant memory with higher bus speeds (overclocking)
may severely compromise the integrity of the system.
Memory Installation :
To install, align the notch on the DIMM module with the connector.
Press straight down as shown in the figure below until the white clips
close and the module fits tightly into the DIMM socket.
Notch
Page 3-5
Installation
3-4 Expansion Slots
PCI-E Slots
PCI-E VGA Slot
PCI Slots
VGA Card Installation Caution
1. Remove the bracket (on the PC case) for the slot you intend to use.
2. Firmly press down the card into the slot until it is completely
seated. Ensure the VGA slot clicker is locked as shown in the
picture below.
PCI-E Slots
The mainboard is equipped with two
PCI-E*1 compliant with PCI Express 1.0a.
PCI-E VGA Slots
The elongated PCI-E*16 is intended for
PCI-E VGA card installation.
PCI Slots
The mainboard is equipped with three
PCI slots.
Page 3-6
3. Secure the card's bracket to the PC case with a screw.
Installation
3-5 Device Connectors
The I/O back panel for this mainboard is shown below. When installing the mainboard
into the computer case, use the bundled I/O shield to protect this back panel.
PS/2
Mouse
PS/2
Keyboard
JPWR_FAN
Parallel Port
S/PDIF-out Coaxial Jack
JCPU_FAN
JSYS_FAN
RJ45
COM1
LAN
USB2.0 x 4 ports
Line-in/Rear out (Light Blue)
Line-out/Front out (Lime)
Mic-in/Center&Subwoofer (Pink)
Figure 7 - I/O Ports
JCPU_FAN / JPWR_FAN / JSYS_FAN:
CPU/Power/Chassis Fan Power Connectors
JCPU_FAN: The CPU must be kept cool by using a
heatsink with fan assembly.
JPWR_FAN: If you are installing an additional fan
in the unit, connect to this fan
connector.
JSYS_FAN: The chassis fan will provide adequate
airflow throughout the chassis to
prevent overheating the CPU.
JCPU_FAN
Control
Sense
+12V
Ground
This mainboard is equipped with intelligent fan
JPWR_FAN
Sense
+12V
Ground
JSYS_FAN
Sense
+12V
Ground
speed control. Refer to the PC Health Status submenu of the BIOS.
Page 3-7
Loading...
+ 49 hidden pages
