Nuu Wave User Manual
User Manual
Contents:
Getting Started .................................................................. 2
Waterproof & Dustproof Performance ................................. 8
Speci cations ..................................................................... 9
Troubleshooting ................................................................. 10
Contact Support ................................................................. 11
Warnings ............................................................................ 12
FCC Statements .................................................................... 14
Warranty Information ........................................................ 15
3
GETTING STARTED
Bluetooth Status LED
On/O Button
Action Button
Volume Up
Volume Down
Battery Status LED
USB Charge Port
DC Input
3.5mm AUX-IN
Micro USB Input
(NUU Service Technician use only)
a
b
c
d
e
f
g
h
i
j
b
c
d
e
f
a
h
i
j
g
In the Box
• NUU Wave
• AC Adaptor
• 3.5mm to 3.5mm audio cable
4
Bluetooth Status LED
This is a small LED next to the On/O switch that illuminates to show the current status of the Wave’s Bluetooth connection.
• Flashing Slowly and Intermittently: The Wave is on and is not in pairing mode. This is also the indicator for
“auto-reconnect”, where the Wave attempts to connect with the last paired Bluetooth device immediately after it
is powered on.
• Flashing Quickly and Steadily: Pairing mode.
• Solidly Lit: Paired and connected.
On/O Button
On: Press and hold the
button for ~3 seconds to turn the NUU Wave on. You will hear a two-tone (low-high) sound,
indicating that the speaker is on.
O : Press and hold the
button for ~3 seconds to turn the NUU Wave o . You will hear a two-tone (high-low) sound,
indicating that the speaker has been switched o .
Auto-o : After 30 minutes of inactivity, the NUU Wave will shut o automatically. To turn the Wave on again, Press and
hold the
button for ~3 seconds. The NUU Wave will not automatically shut o if you are playing audio through
Bluetooth, 3.5mm connection, or are charging a device with the USB port.
NOTE: The Bluetooth Status LED
will light when the Wave is on, and go dark when it is o .
a
b
5
Action Button
The Action button has the Bluetooth symbol embossed into it as well as a Play/Pause icon silkscreened above it .
This button controls:
• Pairing of Bluetooth device• Play/Pause • Re-connect
TO PAIR THE WAVE WITH YOUR BLUETOOTH DEVICE:
1. Switch on the NUU Wave. The Bluetooth Status LED will ash slowly.
2.
Press and hold the Action Button for about ~3 seconds. You will hear a double-beep (low-low) and the
Bluetooth Status Light
will ash quickly. The NUU Wave is now in pairing mode.
3. Enable Bluetooth on your phone or other device.* Then select “NUU Wave”
from the list of discoverable devices.
4.
If prompted for a PIN code, enter “0000” (4 zeros).
5. It will take between 10-15 seconds for the NUU Wave to pair with your device. When pairing is successful, you will
hear a two-tone (low-high) sound and the Bluetooth Status LED
will remain steadily lit.
*NOTE: Procedures for activating Bluetooth will vary across devices. Consult the documentation that came with your
phone or other device for further information.
c
6
PLAYBACK:
The Action Button doubles as a “Play/Pause” button. While music is playing, press and release the Action Button
to
pause the music. Press and release
button again to resume playback.
RE-CONNECTION:
If you press the Action Button while no Bluetooth device is connected, the NUU Wave will attempt to re-connect with the
last paired device and resume playback.
Volume Up
Volume Down
CONTROLLING VOLUME
Press or hold the volume keys
/ to adjust the volume. The NUU Wave will beep with each change in volume.
When you reach maximum volume, you will hear a high-pitched beep. When you reach minimum volume, you will hear a
faint low-pitched beep.
NOTE: Volume may only be adjusted while the NUU Wave is either connected to a Bluetooth device or is connected via the
AUX-IN port.
d
e
