Page 1
child restraint
instructions
Page 2
2
Smart
Design
We like design.
And people who like design get us.
We will not embarrass your kids.
We cannot promise they will stay clean.
But we know it will all be okay. We are parents.
We are Nuna.
Page 3
1
EN
Contents
Important Information
Product Information/Registration 2
Safety Warnings 3
Vehicle Compatibility 4–5
Child Restraint Overview
Features Overview 6–7
Features Usage 8–14
Child Usage Requirements 15
Rear Facing Installation
Rear Facing Setup 16
Using Vehicle Lap/Shoulder Belt 17
Using Lower Anchor Belt 17
Using Vehicle Lap Belt 18
Check Installation 18
Forward Facing Installation
Forward Facing Setup 19
Using Vehicle Lap/Shoulder Belt 20
Using Lower Anchor Belt 20
Using Vehicle Lap Belt 21
Check Installation 21
Securing Child in Child Restraint 22–23
Aircraft Installation 24
Cleaning and Maintenance 24–26
Warranty, Product Registration and Contact 27
WARNING: Carefully read and comply with all instructions
and warnings in this manual, and those labeled on your Child
Restraint. Failure to do so can result in the SERIOUS INJURY
or DEATH of your child. Store manual in pocket at rear of
base for future use.
Page 4
2
EN
Product Information/Registration
Model Number: __________________________________________________________________________
Manufactured in: ________________________________________________________________________
Manufactured Date: ___________________________________________________________________
Expiration Date: ___________________________________________
Register Your Child Restraint
Please ll in the above information. The model number and the
manufactured in (date) can be found on a label on the bottom
of your Child Restraint. Fill out the prepaid registration postcard
attached to the seat cover and mail it today.
Child Restraints could be recalled for safety reasons. You must
register this Restraint to be reached in a recall. Send your name,
address, e-mail address if available and the Child Restraint’s
model number and manufacturing date to:
Nuna Baby Essentials Inc.
70 Thousand Oaks Blvd.
Morgantown, PA 19543
or call 1-855-NUNA-USA (1-855-686-2872) or register online at:
http://www.nuna.eu/usa/register-car-seat
Recall Information
For recall information, call the U.S. Government’s Vehicle Safety
Hotline at; 1-888-327-4236 (TTY: 1-800-424-9153) or go to
http://www.NHTSA.gov
Nuna USA: 1-855-NUNA-USA or nuna.eu/USA
If You Need Help
In the USA, please contact our Customer Service Department
with any questions you may have concerning parts, use, or
maintenance. When you contact us, please have your product’s
model and serial numbers ready so we may help you efciently.
These numbers can be found on a sticker on the bottom of your
Child Restraint.
Nuna USA: 1-855-NUNA-USA or nuna.eu/USA.
Page 5
3
EN
Safety Warnings
WARNING
DEATH OR SERIOUS INJURY CAN OCCUR
! Never leave child unattended in this Child Restraint.
! Do not allow anyone who has not read the Instructions to install
or use this Child Restraint.
! Never leave Child Restraint unsecured in your vehicle even when
it is unoccupied. In a crash, it could become a projectile and
injure other vehicle occupants.
! To avoid strangulation, do not allow children to play with vehicle
or Child Restraint belts or straps. If possible, move unused belts
out of reach.
! Cover the Child Restraint when your vehicle is parked in
sunlight. Parts of a Child Restraint can become very hot if left in
the sun, and can burn a child’s skin. Check for hot parts before
putting your child in the Child Restraint.
! Do not use any products or accessories with this Child Restraint
unless they are approved by Nuna USA for use with this Child
Restraint. Doing so may be unsafe and may void the warranty.
! Do not use Child Restraint if it has frayed or cut harness straps,
or is damaged in any way. To nd out if damaged parts are
replaceable, call 1-855-NUNA-USA.
! Never modify any part of the Child Restraint. Only disassemble
Child Restraint if instructed to by Instructions.
! Replace this Child Restraint if it has been involved in a car
accident, even if it was minor and there appears to be no
damage to the Child Restraint.
! Do not use Child Restraint if it is more than 10 years old. Check
the manufacturer´s label or stamped ‘do not use after’ date on
the bottom of the Child Restraint Base.
Page 6
4
EN
Vehicle Compatibility
WARNING: You MUST read and comply with ALL Child
Restraint related instructions and warnings in your vehicle
owner’s manual to correctly and safely use this Child Restraint
in your vehicle.
This Child Restraint can ONLY be
installed on vehicle seats that face
forward. DO NOT install in seats that
face to the sides or rear of the vehicle.
WARNING: SERIOUS INJURY OR DEATH
MAY OCCUR. NEVER install this Child
Restraint rear facing in a vehicle seating
position with a frontal air bag unless it is turned
off. If your vehicle is equipped with front
passenger side air bags, check your vehicle owner's manual
for Child Restraint installation instructions.
WARNING: According to accident statistics, children are
safer when properly restrained in the rear seating positions
than in the front seating positions.
LATCH (Lower Anchors and Tethers for CHildren) is a system for
installing a Child Restraint in a vehicle without using the vehicle
belts. Refer to your vehicle owner’s manual to determine if your
vehicle is equipped with LATCH, and how to correctly use LATCH
to install this Child Restraint in your vehicle.
Vehicle Top Tether
Anchor Points
Vehicle
Lower
Anchor Points
Rear
Shelf
Back
Wall
Back
of Seat
Vehicle
Floor
Page 7
5
EN
This Child Restraint can be installed without vehicle belts, by
connecting the Restraint’s Lower Anchor Belt to the lower
anchorages in your vehicle. Any LATCH seating position or
anchorage spacing permitted in your vehicle owner’s manual can
be used, as long as the installation is secure. The Restraint’s
Tether Strap should be used for ALL Forward Facing
Installations, as it provides a more secure installation.
WARNING: DO NOT USE the LATCH lower anchor belts to
attach this Child Restraint rear facing when restraining a
child weighing over 35 lbs (15.8 kg) or forward facing when
restraining a child weighing over 40 lbs (18.1 kg). Check your
vehicle owner’s manual for Tether Anchor weight limits.
The following types of vehicle belts MUST NOT be used to
install this Child Restraint. They will not provide a secure, safe
installation. Refer to your vehicle owner’s manual for which seating
positions in your vehicle can be used to install this Child Restraint
using vehicle belts or LATCH.
Motorized Belts Dual Retractor Non-Locking (ELR)
(Automatic) Lap/Shoulder Belts Lap Belts
Airbag Belts Door Mounted Lap Belts forward
Belts of Seat Bight
WARNING: NEVER use a Child Restraint in a vehicle seating
position where it cannot be correctly secured. An incorrectly
installed Child Restraint will not protect your child in a crash.
X
X
X
X
X
X
Page 8
6
EN
Features Overview
1 Shoulder Harness Pads
2 Harness Buckle
3 Crotch Pad
4 Harness Release Button
5 Harness Adjuster Strap
6 Calf Support
7 Cup Holder
8 Hip Harness Pads
9 Buckle Holder
10 Chest Clip
11 Infant Insert
12 Head Insert
13 Head Support
1
2
4
3
13
14
15
5
19
7
6
17
10
9
8
16
20
21
22
23
18
11
12
24
Page 9
7
EN
28
30
29
29
25
27
26
31
14 Harness Strap
15 Seat Cover
16 Lower Anchor Belt Storage
(underneath door)
17 Recline Position Indicator
18 Recline Button
19 Rear Facing True Tension
Door
20 Rear Facing True Tension
Button
21 Forward Facing True
Tension Button
22 Forward Facing True
Tension Door
23 Side Impact Protection (SIP)
pods
24 Head Support Button
25 Tether Strap Adjuster
26 Tether Strap
27 Tether Hook
28 Lower Anchor Belt
29 Lower Anchor Connectors
30 Instruction Manual Storage
31 Lower Anchor Adjuster
Page 10
8
EN
Feature Usage
Harness Use
To Loosen Harness
Press on Harness Release Button while
pulling forward on the Harness Straps.
(1)
To Open Chest Clip
Press button on front of Clip and pull
Clip apart. (2)
To Open Harness Buckle
Press red button on front of Buckle and
pull out Buckle Tongues. (3)
To Use Buckle Holders
Loosen and unfasten harness. Place
Buckle Tongues in Holders. (4)
To Fasten Chest Clip
Push Chest Clip halves together until
they click. Pull to check. (5)-1
To Fasten Buckle
Insert Buckle Tongues rmly into Buckle
until they click. Pull up on Tongues to
ensure they are locked. (5)-2
To Tighten Harness
Pull on Harness Adjuster Strap. (6)
2
3
4
5
6
1
1
2
Page 11
9
EN
Head Insert Use
The Head Insert may be used or
removed for improved comfort or t of
any child. (7)
Harness & Crotch Pad Use
The Harness Pads are a comfort feature
that may be used or removed for any
child. Small infants may have better t
to Harness with Shoulder Pads removed.
(8)
Infant Insert Use
The Infant Insert (9) can be used with
infants 5–11 lbs (2.3–5 kg) to improve t
to Child Restraint and increase recline
angle.
To Install Infant Insert
1 Pull Harness Buckle through slot in the bottom of Infant Insert.
(9)-1
2 Route Harness Straps through gaps in sides of Infant Insert.
(9)-2
3 Push Infant Insert rmly into Child Restraint (9)-3 to make
sure insert is properly positioned. (9)-4
4
1
3
2
8
7
9
When properly
installed, the
Infant Insert will
not interfere with
Harness Straps
or Crotch Belt.
Crotch Belt must
be locked in inner
position when
Infant Insert is
used.
Page 12
10
EN
Head Support Adjustment
1 With Harness loose (p8), press Head
Support Button and move Head
Support up or down to desired
position. (10)
2 Release button and slide Head
Support slightly up or down to lock
into appropriate use position. (10)
True Tension Door Use
This Child Restraint has 2 True Tension
Doors that provide a simple and secure
installation of the Child Restraint in your
vehicle. They are located underneath
the Seat Cover. The upper Door is for
forward facing use, and the lower Door is
for rear facing use.
1 Remove Infant Insert, loosen and
unfasten Harness (p8), and retain with
Buckle Holders (p8).
2 Adjust Head Support to highest
position, unsnap Seat Cover and pull
to front of seat. (11)
3 Open appropriate True Tension Door
by squeezing the Door release button
(12)-1 and lifting Door. (12)-2
4 Close True Tension Door by pressing
down rmly on Door until both
latches lock in place. (13)
5 Replace Seat Cover and reinstall
Infant Insert if used (p9).
Crotch Belt Adjustment
The Crotch Belt can be used in a forward
or rearward position. Use the position that
is closest to, but not under your child.
1 Remove Infant Insert (p9) and loosen
and unbuckle Harness (p8).
10
11
13
12
1
2
click
Page 13
11
EN
2 Unsnap Seat Cover and pull forward
while pulling crotch buckle through
slot in Seat Cover. (14)
3 Depress and slide Crotch Belt plate
forward or backward and lock in
desired position. (15)
4 Place buckle back through correct
slot in Seat Cover and replace Seat
Cover and Infant Insert (if using).
Lower Anchor Belt Storage and Use
The Lower Anchor Belt, located in
Storage Pockets under the Rear Facing
True Tension Door, can be used instead
of a vehicle belt to install this Child
Restraint. The Lower Anchor Belt must
not be used rear facing if your child
weighs more than 35 lbs (15.8 kg), or
forward facing if your child weighs
more than 40 lbs (18.1 kg).
1 To use Lower Anchor Belt, open
Rear Facing True Tension Door (p10),
remove Lower Anchor Belt, and
lengthen by pressing adjuster button
while pulling on Belt. (16)
2 To connect Lower Anchor Belt to
lower anchors in vehicle, press
Connector rmly onto lower anchor
and pull to check. (17)
3 To release Lower Anchor Belt, press
red button on end of Connector while
pulling on Belt. (18)
4 To store, fold Lower Anchor Adjuster
and Lower Anchor Belt, and insert
in Storage Pocket (19). Store other
Lower Anchor Belt in adjacent Storage
Pocket. Tuck excess webbing.
When not in use, the Lower Anchor
Belt MUST be properly stored in Lower
Anchor Storage Pockets under Rear
Facing True Tension Door, and MUST
NOT interfere with latching of Door.
push & slide
14
15
16
17
18
19
Page 14
12
EN
Cup Holder Use
1 Pivot Cup Holder up and lock in use position. (20)
2 Push center of Cup Holder down to extend to opened position. (21)
3 While in the opened position, pull up on the Cup Holder to
remove for washing.
4 To store, collapse Cup Holder and pivot down. (22)
Cup Holders must be opened to access Belt Path during
Rear Facing Installation of Child Restraint. Cup Holders may
be collapsed down against vehicle belt after installation.
DO NOT place glass or metal containers or hard or sharp
objects in Cup Holder. In a crash they could cause serious injury.
Calf Support Use
The Calf Support may be used to give
your child more leg room or improve
installation when rear facing and provide
improved comfort when forward facing.
It is designed to change position without
damage if excessive force is applied.
1 Recline Child Restraint to rear facing
position 1 (BLUE).
2 Move Calf Support to use position by
reaching under front of Child Restraint
and rotating Calf Support down and
forward. (23)
3 Move Calf Support to storage position
by pulling down on Calf Support to
unlock, and rotating it to storage position. (24)
When used rear facing for children over 40 lbs, Calf Support
should be in the use position.
1
20 21 22
23
24
1
2
2
Page 15
13
EN
Side Impact Protection (SIP) Use:
SIP Pods should be deployed whenever
the Child Restraint is installed in a
vehicle.
1 To deploy, pull out SIP Pod from
corner of stored position until it locks
into position. (25)
2 To store, press button and push SIP
Pod into stored position. (26)
Tether Use
1 To use, remove Tether by loosening
strap and unclipping from storage
anchor. (27)
2 To extend Tether for use, tilt Tether
Adjuster and pull to lengthen. (28)
3 To store, attach Tether to storage
anchor and remove slack in strap by
pulling on free end of strap. Loose
strap should be stored in provided
sleeve. When not in use, Tether MUST
be properly stored. (29)
WARNING: ALWAYS USE Tether for
forward facing installation if vehicle
is equipped with a Tether Anchor
point and vehicle requirements are
met (see vehicle owner's manual).
25
26
27
28
29
Page 16
14
EN
Recline Use
This Child Restraint has 10
recline positions. Recline can
be changed for child comfort or
to improve installation of Child
Restraint.
1 Positions 1–5 (BLUE) are for
rear facing use with children
5–50 lbs. (30)
2 Positions 1–5 (RED) are
for forward facing use with
children 25–65 lbs. (31)
If infant’s head falls forward, Child Restraint must be reclined
more. Use Infant Insert with infants 5–11 lbs (2.3–5 kg) for
best t and positioning.
To Adjust Recline
3 Press Recline Button
(32)-1 on either side of
the Child Restraint and
move seat to desired
recline position. (32)-2
4 Release Recline Button,
and check that Child
Restraint is locked in
desired recline position.
Recline must be selected before installing Child Restraint.
To change recline position after installation, uninstall Child
Restraint, select new recline position, and reinstall Child
Restraint.
5 4 3
2
1
1
2
3
4
5
543
2
1
1
2
3
4
5
31
30
32
1
2
Page 17
15
EN
Child Usage Requirements
To use this Child Restraint, your child must meet ALL of the
following weight and height requirements below:
Weight: 5-65 lbs (2.3–29.4 kg)
Height: 49 in (124 cm) or less
The Infant Insert (p9) is only for use with infants who weigh
5–11 lbs (2.3–5 kg).
Rear Facing Installation
suggested birth to 2+ years (5–50 lbs)
Forward Facing Installation
suggested 2 years or older (25–65 lbs)
WARNING: Use either vehicle seat belt or Lower Anchors.
Never use both methods to install Child Restraint.
vehicle belt
OR
OR
vehicle belt & tether strap
Tether strap should always be used in Forward Facing Installation.
lower anchor belt
lower anchor belt
infant
insert
5 lbs
(2.3 kg)
50 lbs
(22.6 kg)
25 lbs
(11.3 kg)
35 lbs
(15.8 kg)
40 lbs
(18.1 kg)
11 lbs
(5 kg)
65 lbs
(29.4 kg)
Page 18
Rear Facing Installation
suggested birth to 2+ years (5–50 lbs)
The American Academy of Pediatrics recommends that
children ride in a rear facing Child Restraint until they are at
least 2 years old. An infant’s head, neck and spine are not
supported as well in a forward facing position.
Rear Facing Setup
1 Move Calf Support to desired
installation position (p12).
2 Place Child Restraint rear facing in a
compatible vehicle seat (p4). (33)
3 Select desired rear facing recline
position 1–5 (BLUE) (p14). (34)
If infant’s head falls forward, Child
Restraint must be reclined more.
Use Infant Insert with infants 5–11 lbs
(2.3–5 kg) for best t and positioning.
4 Loosen and unbuckle Harness and
retain with Buckle Holders (p8).
5 Pivot Cup Holders to use position to
access Rear Facing Belt Path (p12).
6 Remove Infant Insert, lift lower Seat
Cover, and open Rear Facing True
Tension Door (p10). (35)
543
2
1
1
2
3
4
5
16
EN
vehicle belt
OR
lower anchor belt
infant
insert
5 lbs
(2.3 kg)
50 lbs
(22.6 kg)
25 lbs
(11.3 kg)
35 lbs
(15.8 kg)
11 lbs
(5 kg)
65 lbs
(29.4 kg)
34
35
33
Page 19
7 Complete installation using your vehicle’s Lap/Shoulder Belt
(p17), the Lower Anchor Belt (p17), or a compatible vehicle Lap
Belt (p18).
Using Vehicle Lap/Shoulder Belt
(preferred method)
8 Route vehicle Lap/Shoulder belt
through BLUE Rear Facing Belt Path
and buckle vehicle Lap/Shoulder Belt.
Vehicle belt must be routed under
True Tension Door. (36)-1
9 Lock vehicle shoulder belt by pulling
it all the way out and letting it go
back in, and remove all slack from
vehicle Lap/Shoulder Belt.(36)-2
10 Close True Tension Door and replace
Seat Cover and Infant Insert (if used).
(37)
11 Test by pulling on shoulder belt to
ensure it is locked.
Using Lower Anchor Belt
WARNING: Do not install by this
method for a child weighing more
than 35 lbs (15.8 kg).
8 Remove Lower Anchor Belt from Storage Compartment (p11)
and route through BLUE Rear Facing Belt Path under Cup
Holder. (38)-1
9 Lengthen Lower Anchor Belt as necessary (p11) and attach to
Lower Anchor points in vehicle. (38)-2
10 Remove all slack from Lower Anchor Belt by pulling loop at
end of Belt. (38)-3
17
EN
36
38
37
1
3
2 2
1
2
Page 20
18
EN
11 Close True Tension Door and replace
Seat Cover and Infant Insert (if used).
Pull crotch belt through slot. (39)
Using Vehicle Lap Belt
8 Route vehicle Lap belt through BLUE
Rear Facing Belt Path and buckle
vehicle Lap Belt. (40)-1
9 Remove all slack from vehicle Lap
Belt. (40)-2
10 Close True Tension Door and replace
Seat Cover and Infant Insert (if used).
(41)
WARNING: Check that Child
Restraint is securely installed
before each use.
Check Installation
Seat is in appropriate rear facing recline position.
Seat is securely installed. Hold seat near rear facing belt path
and move seat side to side, front to back, and up and down.
Seat should move less than 1 inch.
Tether strap is not used for Rear Facing Installation and must
be secured in storage location on back of Child Restraint.
Cup Holders may be placed in any position after installation.
40
41
1
2
39
Page 21
19
EN
Forward Facing Installation
suggested 2 years or older (25–65 lbs)
Forward Facing Setup
1 Remove Tether from storage location
and lengthen for use (p13).
2 Place Child Restraint forward facing
in a compatible vehicle seat (p4).
(42)
3 Select desired forward facing recline
position 1–5 (RED) (p14). (43)
4 Loosen and unbuckle harness and
retain with Buckle Holders (p8).
5 Fully raise Head Support, lift Seat
Cover, and open Forward Facing True
Tension Door (p10). (44)
6 Complete installation using your
vehicle’s Lap/Shoulder Belt (p20),
the Lower Anchor Belt (p20), or a
compatible vehicle Lap Belt (p21).
5 lbs.
(2.3 kg)
50 lbs.
(22.6 kg)
40 lbs.
(18.1 kg)
25 lbs.
(11.3 kg)
11 lbs.
(5 kg)
65 lbs.
(29.4 kg)
vehicle belt & tether strap
lower anchor belt
Tether strap should always be used in Forward Facing Installation.
OR
5 4 3
2
1
1
2
3
4
5
43
44
42
Page 22
20
EN
Using Vehicle Lap/Shoulder Belt
(preferred method)
7 Route vehicle Lap/Shoulder belt
through RED Forward Facing
Belt Path and buckle vehicle Lap/
Shoulder Belt. (45)-1
8 Lock vehicle shoulder belt by pulling
it all the way out and letting it go
back in, and remove all slack from
vehicle Lap/Shoulder Belt. (45)-2
9 Close True Tension Door and replace
Seat Cover. (46)
10 Test by pulling on shoulder belt to
ensure it is locked.
11 Attach Tether Hook to Tether Anchor
on vehicle and tighten. Tuck excess
webbing behind Child Restraint. (47)
Using Lower Anchor Belt
WARNING: Do not install by this
method for a child weighing more
than 40 lbs (18.1 kg).
7 Remove Lower Anchor Belt from Storage Compartment (p11),
move along wire, and route through RED Forward Facing Belt
Path. (48)
8 Lengthen Lower Anchor Belt as necessary (p11) and attach to
Lower Anchor points in vehicle. (49)-1
9 Remove all slack from Lower Anchor Belt by pulling loop at
end of Belt straight back from Latch Connector. (49)-2
47
46
48
45
1
2
Page 23
21
EN
10 Close True Tension Door and replace
Seat Cover.
11 Attach Tether Hook to Tether Anchor
on vehicle and tighten (p13). Tuck
excess webbing behind Child
Restraint. (47)
Using Vehicle Lap Belt
7 Route vehicle Lap Belt through RED
Forward Facing Belt Path and buckle
vehicle Lap belt. (50)-1
8 Remove all slack from vehicle Lap
Belt. (50)-2
9 Close True Tension Door and replace
Seat Cover. (51)
10 Attach Tether Hook to Tether Anchor
on vehicle and tighten (p13). Tuck
excess webbing behind Child
Restraint. (47)
WARNING: Check that Child Restraint is securely installed
before each use.
Check Installation
Seat is in appropriate forward facing recline position.
Seat is securely installed. Hold seat near Forward Facing Belt
Path and move seat side to side, front to back, and up and
down. Seat should move less than 1 inch.
Tether is properly used and attached to vehicle Tether Anchor.
50
51
1
2
49
1
1
2
Page 24
22
EN
Securing Child in
Child Restraint
WARNING: If your child is not properly secured in the
Child Restraint, they may be ejected in a crash, resulting in
serious injury or death.
1 Loosen and unfasten Harness. Retain
with Buckle Holders (p8).
2 Place child in Child Restraint with
child’s back at against Child
Restraint seat back.
3 Adjust Head Support (p10) to
position harness straps correctly on
child. (52) Lock Head Support in
appropriate use position. Bottom of
Head Support should be close to, but
not compressing, child's shoulders.
4 Adjust Crotch Belt to t child (p11).
Crotch Belt should be close to, but
not under child.
5 Position harness over child’s
shoulders and around child’s waist,
and buckle harness.
6 Tighten harness (p8) to t snugly on
child’s shoulders and thighs. It is
snug if you cannot pinch a fold in the
strap. (53)-1
7 Fasten and position Chest Clip (p8)
level with child’s armpits. (53)-2
52
53
Rear Facing:
Harness AT or just
below shoulders
Forward Facing:
Harness AT or
just above
shoulders
1
2
1
2
Page 25
23
EN
Secure Child Checklist
WARNING: Before securing child, always check that Child
Restraint is securely installed.
Harness straps are at correct height.
rear facing: AT or just below child’s shoulders (52)-1
forward facing: AT or just above child’s shoulders (52)-2
Use Infant Insert with infants 5-11 lbs (2.3-5 kg) to
improve t to seat and harness and to increase recline.
Recline angle is appropriate for Child.
If infant’s head falls forward, Child Restraint must be
reclined more. Use Infant Insert with infants 5–11 lbs
(2.3–5 kg) for best t and positioning.
Head Support is locked in a use position.
Harness Buckle is securely fastened. Pull to check!
Harness Straps are snug and at on shoulders and thighs.
WARNING: A snug strap should not allow any slack. It
lies in a relatively straight line without sagging. It does not
press on the child's esh or push the child's body into an
unnatural position.
WARNING: Child cannot be properly secured in Child
Restraint when wearing bulky clothing or wrapped in a
blanket. For warmth, add blanket after properly securing
Child in the Child Restraint.
Chest Clip is fastened and at Child’s armpit level.
Page 26
24
EN
Aircraft Installation
The FAA recommends that children up to 40 lbs (18.1 kg) use
a certied, harnessed Child Restraint while travelling on an
aircraft.
This Child Restraint is certied for use on aircraft. Contact
your airline about their policies prior to travel.
Install Child Restraint rear facing or forward facing in a
forward facing aircraft seat following “Using Vehicle Lap/
Belt” instructions, but install aircraft belt on top of closed
True Tension Door and under Seat Cover.
Cleaning and Maintenance
WARNING: Do not attempt to disassemble the Child
Restraint further than these instructions allow.
Seat Cover Removal
1 Congure Child Restraint for
disassembly. (54)
a Recline Child Restraint to rear
facing position 1 (BLUE).
b Set Head Support in highest
position.
c Loosen and unbuckle Harness
and Chest Clip.
d Fully extend Calf Support.
e Remove Tether from Storage Anchor.
2 Remove Harness/Buckle Pads as well as Infant and Head
Inserts.
Take care when removing Head Support Cover so as not to
damage the energy absorbing foam.
54
e
a
b
c
d
Page 27
25
EN
3 Remove Head Support Cover. (55)
a Grasp Head Support Cover at top
behind Head Support Button.
b Peel Cover off Head Support;
work on one side then the other.
Unsnap Cover and remove.
4 Unsnap Seat Cover. (56)
5 Remove Seat Cover from Calf Support.
6 Remove Seat Cover from beneath
Harness Release Button frame. (57)
a Grasp the Seat Cover at the top of
the Harness Release Button.
b Pull away from Button (toward
seat back) and up.
c Work cover out from under the
Button frame.
7 Remove Cover from Child Restraint.
(58)
a Start at bottom, near Calf Support,
work toward Buckle Holder.
Pull Seat Cover out of seat cover
retaining slot.
b Unhook Cover beneath Buckle
Holder.
c Continue to the Tether.
d Repeat steps A through C for the
other side.
8 Flip cover over the top of the Child
Restraint. Slide Seat Cover off of
the Tether. (59)
58
59
b
a
55
57
a
b
56
Page 28
26
EN
Seat Cover Assembly
1 Reverse steps of Cover Removal.
Recline Child Restraint to rear facing position 1.
Be sure seat cover is tucked into retaining slot.
Pull on Buckle Holder area to ensure cover is tucked
securely.
Ensure both corner pockets to the outside of the Calf
Support are secured under the child restraint.
Cleaning the Seat Cover and Harness Pads
1 When required, Seat Cover and harness pads may be machine
washed with a mild soap and cold water.
2 Allow to air dry.
Do not use bleach or other harsh chemicals to clean your
Child Restraint Cover or Harness. Wash the covers with cold
water and mild detergent, on the delicate cycle. Hang to dry.
Do not attempt to iron your Child Restraint Cover or Harness.
The Child Restraint harness system cannot be removed.
Do not use bleach or other harsh chemicals to clean your
Child Restraint Cover or Harness. Wash the covers with cold
water and mild detergent, on the delicate cycle. Hang to dry.
Do not attempt to iron your Child Restraint Cover or Harness.
The Child Restraint harness system cannot be removed.
Cleaning the Infant Insert
1 When required, the Infant Insert may be machine washed with
a mild soap and cold water. The support wedge located on the
back side of the Infant Insert should be spot cleaned only. Do
not machine wash the support wedge.
2 Allow to air dry.
Cleaning the Harness
1 When required, harness may be hand washed with a sponge
and warm soapy water.
2 Towel dry excess water and allow to air dry.
Cleaning the Shell
1 When required, shell may be hand washed with a sponge and
warm soapy water.
2 Towel dry.
Do not use abrasive cleansers on the Shell.
Page 29
27
EN
Warranty, Product
Registration and Contact
Warranty
We have purposely designed our high-quality product so that it
can grow with both your child and your family. Because we stand
by our product, our gear is covered by a custom warranty per
product, starting from the day it was purchased. Please have the
proof of purchase, model number and serial number available
when you contact us.
For warranty information please visit:
http://www.nuna.eu/warranty
Product Registration
All products include a serial label which lists the product model
number and serial number. This label is located on the bottom of
your Child Restraint. Before contacting customer service, please
have these numbers available for reference.
To register your product:
• Car Seats: Please ll out and mail in the provided registration
card or visit http://www.nuna.eu/usa/register-car-seat
• All other products: Please ll out and mail in the provided
registration card or visit http://www.nuna.eu/usa/register-gear
Contact
For replacement parts, service, or additional warranty questions,
please contact our customer service departments.
infousa@nuna.eu
www.nuna.eu
1-855-NUNA-USA
This product is covered by one or more issued or pending
patents.
Page 30
IM-0190H
nuna.eu
1-855-NUNA-USA
Loading...
