Numark Industries EM460 User Manual

Professional Disc Jockey Products

EM460

EM460EM460

PROFESSIONAL DJ EFFECTS MIXER

PROFESSIONAL DJ EFFECTS MIXERPROFESSIONAL DJ EFFECTS MIXER

With

With KAOSS* Pad Multi-effects Processor

With With

Pad Multi-effects Processor

Pad Multi-effects Processor Pad Multi-effects Processor

Owner’s Manual

*KAOSS technology under license from KORG

EM 460

Safety Information

SAFETY INSTRUCTIONS

a) Read Instructions - All the safety and operating

instructions should be read before this product is connected and used.

b) Retain Instructions - The safety and operating instructions

should be kept for future reference.

c) Heed Warnings - All warnings on this product and in

these operating instructions should be followed.

d) Follow Instructions - All operating and other instructions

should be followed.

e) Water and Moisture -

This product should be kept away from direct contact with liquids.

f) Heat - Avoid placing this

product to close to any high heat sources such as radiators.

g) Ventilation - The appliance should be situated so that it’s

location or position does not interfere with it’s proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation opening; or, placed in a builtinstallation, such as bookcase or cabinet that may impede the flow of air through the ventilation openings.

h) Power Sources - This product should be connected to a

power supply only of the type described in these operating instructions, or as marked on the unit.

i) Power Cord Protection - Power supply cords should be

routed so that they are not likely to be walked upon or pinched by items placed on or against them. When removing the cord from a power outlet be sure to remove it by holding the plug attachment and not by pulling on the cord.

j) Object and Liquid Entry - Take care that objects do not

fall into and that liquids are not spilled into the inside of the mixer.

k) Cleaning – The appliance should be cleaned only as

recommended by the manufacturer.

Non-use Periods – The power cord of the appliance should be unplugged from the outlet when left unused for long periods of time.

m) Damage Requiring Service - Never attempt to make any

adjustments or repairs other than those described in this manual. personnel should service this product. If you have any questions about service please contact Numark at the number(s) shown on the back cover of this manual.

n) Grounding or Polarization - Precautions should be taken

so that the grounding or polarization means built into the CD player is not defeated.

o) Internal/External Voltage Selectors - Internal or external

voltage selector switches, if any, should only be reset and re-equipped with a proper plug for alternative voltage by a qualified service technician. Do not attempt to alter this yourself.

WARNING: To reduce the risk of fire or electrical shock, do not expose this appliance to rain or moisture. Electrical equipment should NEVER be kept or stored in damp environments.

Only qualified

- The Leader in DJ Technology

EM460

EM460EM460

With

With KAOSS PAD Multi-effects Processor

With With

CONGRATULATIONS!

You have purchased the EM460 Stereo Effects Mixer by . The first series of DJ mixers with a completely interactive, real-time effects processor. This one of a kind DJ product boasts all of the qualities that you have come to expect from a equipment literally puts effects processing at the DJ’s fingertips. The EM460 is easily suited for mobile or installation use. Special features found on this product are eight line inputs, rotary cut control, balanced outputs, and fader start. The fader start feature is designed to work with ’s Fader Start CD players as well as its other popular CD players. The KAOSS Pad* effects processing unit lets the DJ control his choice of up to sixty effects programs in real-time. The effects unit allows for sampling functions, parameter controls, and MIDI compatibility.

Thank you for purchasing NUMARK products!

PAD Multi-effects Processor

PAD Multi-effects Processor PAD Multi-effects Processor

mixer plus, it features a built in KAOSS PAD*. This piece of

PROFESSIONAL DJ EFFECTS MIXER

Mixer Features:

• Eight line, three phono, two mic inputs

• Front panel Neutrik

• Master with Balanced outputs with EQ and Panning

• 3-band EQ, Pan, and gain control on all channels

• Completely assignable and replaceable cross-fader

• Fader start

• 2 Zone outputs

• Split/blend headphone cueing

mic input

Safety Measures 2

Introduction 3

Registration 3

Description of the Features 4

Quick Setup Diagram 7

KAOSS PAD* Features:

• Real-time effects processing

• X-Y touch sensitive pad

• Separate parameter controls

• Sixty “effects programs”

• Hold switch to lock in settings

• Sampler (5 seconds at 48 kHz)

• MIDI compatibility

• 100% digital processing

*KAOSS technology under license from KORG

KAOSS Effects 8

MIDI Implementation 9

Specifications 10

Bock Diagram 11

Warranty 12

Product Registration

Please record the serial number of your unit as shown on the back of the chassis as well as the name of the dealer from whom you purchased the unit. Retain this information and your original purchase receipt for your records. Please return the enclosed warranty card to register your unit with us.

MODEL: __________________________ PURCHASED FROM:_________________________ SERIAL NUMBER:__________________ DATE OF PURCHASE:________________________

- The Leader in DJ Technology

EM460

MIXER FEATURES

20 21

INPUTS

1. Input faders - control individual source levels in the mix.

Note: Never use spray cleaners on the slide controls. Residues cause excessive dirt build-up and this will void your warranty. In normal use slide controls can last for many years. If they malfunction (usually because of a dirty or dusty environment) consult a professional technician.

2. Input Toggle Switches - select which source will be live to that

channel based on what you have connected to the rear panel input section.

3. Panning – adjusts the balance of right to left audio

4. 3-Band Stereo Equalizer (EQ) - compensates for differences in

source material sound quality. You can create interesting effects by removing frequencies if you turn the knob to –30dB.

5. PFL Gain – allows you to adjust the input level of the music to

match other channels. The idea is to set all input levels to approx. 0dB so channels match. Do not try to match to the master output meter.

6. PFL Meter – to allow for precise matching of channel input

levels.

7. Neutrik™ “Combo” connector - allows connection of either a

1/4” jack or an XLR jack. This is ideal for connecting an XLR gooseneck directly into the mixer.

HEADPHONE CUEING

8. Channel Cue Assign - are used to route Pre Fader Level (PFL)

channel audio to the Monitor Section. The channel faders do not control the Cue volume.

9. Headphone Mix - controls the mix of PFL and PGM signals to

your headphones. When the slider is moved to the left, all you will hear is the cue source. When the slider is all the way to the right, you will hear what is playing through the master output. By blending, beats can be matched exactly and segues can be smooth when a song is cued.

10. Headphone Level – adjusts cue volume.

11. Split/Blend Cue – controls how PFL and Program audio are

sent to your headphones. In split mode, the PFL audio can be heard in your left ear and PGM audio can be heard in your right ear. In blend mode, both PFL and PGM can be heard in both ears.

12. Headphone output – for your 1/4” headphones.

13. Master Fader – controls the overall output level.

14. Stereo/Mono toggle - adjusts the Master output for stereo or

mono operation.

15. Panning – adjusts the output balance of right to left audio.

16. 3-Band Stereo Equalizer (EQ) - compensates for differences in

source material sound quality. In ultra-compact mobile systems this EQ can be used to tailor the sound to the acoustical requirements of the room.

17. Booth/Zone Fader - controls speaker volume for a remote zone

or booth monitors.

NOTE: This can also be used to supply line level audio to a lighting controller or to lights that are sound activated.

18. Stereo Auto Peak Hold Level Indicator- quickly and

accurately tracks level of audio output. The red LEDs for +3dB, +5dB and +8dB hold program peaks for a second or two. With peak metering, it's OK to be "in the red" as long as +5dB or +8dB aren't constantly lit. When using as a master output meter, set the crossover, equalizer and power amp inputs to avoid distortion at each step in the audio chain. Proper attention to the peak meter results in the punchiest possible sound without audible distortion.

91011 12

OUTPUTS

- The Leader in DJ Technology
